TruSight Enrichment Sample Prep Guide Translated into Spanish (15040457 B)

TruSight Enrichment Sample Prep Guide Translated into Spanish (15040457 B)

This document and its contents are proprietary to Illumina, Inc. and its affiliates ("Illumina"), and are intended solely for the contractual use of its customer in connection with the use of the product(s) described herein and for no other purpose. This document and its contents shall not be used or distributed for any other purpose and/or otherwise communicated, disclosed, or reproduced in any way whatsoever without the prior written consent of Illumina. Illumina does not convey any license under its patent, trademark, copyright, or common-law rights nor similar rights of any third parties by this document.

The instructions in this document must be strictly and explicitly followed by qualified and properly trained personnel in order to ensure the proper and safe use of the product(s) described herein. All of the contents of this document must be fully read and understood prior to using such product(s).

FAILURE TO COMPLETELY READ AND EXPLICITLY FOLLOW ALL OF THE INSTRUCTIONS CONTAINED HEREIN MAY RESULT IN

DAMAGE TO THE PRODUCT(S), INJURY TO PERSONS, INCLUDING TO USERS OR OTHERS, AND DAMAGE TO OTHER PROPERTY.

ILLUMINA DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE IMPROPER USE OF THE PRODUCT(S) DESCRIBED HEREIN

(INCLUDING PARTS THEREOF OR SOFTWARE) OR ANY USE OF SUCH PRODUCT(S) OUTSIDE THE SCOPE OF THE EXPRESS

WRITTEN LICENSES OR PERMISSIONS GRANTED BY ILLUMINA IN CONNECTION WITH CUSTOMER'S ACQUISITION OF SUCH

PRODUCT(S).

FOR RESEARCH USE ONLY

© 2013 Illumina, Inc. All rights reserved.

Illumina, IlluminaDx, BaseSpace, BeadArray, BeadXpress, cBot, CSPro, DASL, DesignStudio, Eco, GAIIx, Genetic Energy, Genome

Analyzer, GenomeStudio, GoldenGate, HiScan, HiSeq, Infinium, iSelect, MiSeq, Nextera, NuPCR, SeqMonitor, Solexa, TruSeq,

TruSight, VeraCode, the pumpkin orange color, and the Genetic Energy streaming bases design are trademarks or registered trademarks of

Illumina, Inc. All other brands and names contained herein are the property of their respective owners.

Note regarding biomarker patents and other patents unique to specific uses of products.

Some genomic variants, including some nucleic acid sequences, and their use in specific applications may be protected by patents. Customers are advised to determine whether they are required to obtain licenses from the party that owns or controls such patents in order to use the product in customer's specific application.

ii

Part # 15040457 Rev. B

Revision History

Part #

15040457

15040457

Revision

B

A

Date

March 2013

January 2013

Description of Change

Edited statement regarding biomarker patents to copyright page.

Initial release

TruSight Enrichment DNA Sample Preparation Guide iii

iv

Part # 15040457 Rev. B

Table of Contents

Revision History

Table of Contents

Chapter 1 Overview

Introduction

Tracking Tools

Documentation

Chapter 2 Getting Started

TruSight Enrichment DNA Sample Preparation Kit

Consumables and Equipment

Best Practices

Prevent PCR Product Contamination

Acronyms

DNA Input Recommendations

Chapter 3 TruSight Enrichment Protocol

TruSight Enrichment Workflow

Tagmentation of Genomic DNA

Clean-Up of Tagmented DNA

PCR Amplification

PCR Clean-Up

First Hybridization

First Wash

Second Hybridization

Second Wash

PCR Amplification

Enriched Library Validation

Appendix A References

Library Pooling Guidelines

Technical Assistance

TruSight Enrichment DNA Sample Preparation Guide

27

35

37

41

47

28

29

31

33

49

55

59

61

62

65

iii

v

1

2

3

4

5

6

15

18

20

23

25

v

vi

Part # 15040457 Rev. B

  Chapter 1  Overview

Overview

Introduction

Tracking Tools

Documentation

2

3

4

TruSight Enrichment DNA Sample Preparation Guide

1

Introduction

This protocol explains how to prepare up to 96 indexed paired-end libraries, followed by enrichment using the TruSight ™ Content Set CSO (custom selected oligos), and subsequent cluster generation and DNA sequencing using the reagents provided in the Illumina

TruSight Enrichment DNA Sample Preparation Kit. The goal of this protocol is to fragment and add adapter sequences onto template DNA with a single tube TruSight Enrichment tagmentation reaction to generate multiplexed sequencing libraries that can be carried through enrichment for targeted resequencing applications.

The TruSight Enrichment DNA Sample Preparation kits are based on the Nextera

Enrichment DNA Sample Prep kits and use the same reagents, but are designed to be used in conjunction with the TruSight Content Sets as the Custom Selected Oligos (CSO). The

TruSight Enrichment DNA Sample Preparation protocol is the same as the Nextera

Enrichment DNA Sample Prep protocol except for an increased number of cycles in the final PCR Amplification steps. To analyze the TruSight Content Sets via MiSeq Reporter

Enrichment analysis flow, an Illumina provided manifest file is required. There is a unique manifest file for each TruSight Content Set. The manifest files can be downloaded from the

TruSight Enrichment DNA Sample Preparation Kit Support page.

The TruSight Enrichment DNA Sample Preparation protocol offers:

Sequencing's fastest and easiest preparation

}

Prep up to 12 samples in a single enrichment reaction in less than 3 hours; prep and enrichment time reduced to 2.5 days

}

High manual throughput or simple automation friendly with no fragmentation bottlenecks

Lowest DNA input and excellent data quality

}

Excellent data quality with low input of 50 ng

} Access precious samples with no impact to performance

}

Ability to archive samples for additional analysis

Highest enrichment rates and exceptional coverage uniformity

} Efficient use of sequencing and reliable variant calling

}

Reduce FTE time with the most cost-effective, high-throughput workflow

2

Part # 15040457 Rev. B

Tracking Tools

Illumina provides the following tools for sample tracking and guidance in the lab:

}

Experienced User Card (EUC) to guide you through the protocol, but with less detail than provided in this user guide. New or less experienced users are strongly advised

to follow this user guide and not the EUC.

}

Lab Tracking Form (LTF) to record information about library preparation such as operator name, sample and index information, start and stop times, reagent lot numbers, and barcodes.

• Create a copy of the lab tracking form for each time you perform this protocol to prepare a library for sequencing.

• Use it online and save it electronically or print it and fill it out manually.

NOTE

You can download the above TruSight Enrichment DNA Sample Preparation documents from the Illumina website at http://www.illumina.com. Go to the

TruSight Enrichment DNA Sample Preparation support page and click the

Documentation & Literature tab.

}

The Illumina Experiment Manager (IEM) can be used to create your sample sheet using a wizard-based application. The sample sheet is used to record information about your samples for later use in data analysis. The IEM guides you through the steps to create your sample sheet based on the analysis workflow for your run. The

IEM provides a feature for recording parameters for your sample plate, such as sample

ID, single indexing, and other parameters applicable to your 96-well plate. When using

IEM for sample sheet generation, make sure you select Adapter Trimming when you create your sample sheet for all Illumina Sequencing Platforms. Shorter inserts can lead to sequencing into the adapter, and this feature helps filter out adapter sequence from the final sequence data. The IEM can be run on any Windows platform. You can download IEM from the Illumina website at http://www.illumina.com. Go to the

TruSight Enrichment DNA Sample Preparation support page and click Downloads. A

MyIllumina account is required.

• When prompted to select a Sample Prep Kit Type in IEM, choose Nextera

Enrichment.

• When creating a MiSeq compatible sample sheet in IEM, choose the Targeted

Resequencing category and then the Enrichment application.

TruSight Enrichment DNA Sample Preparation Guide

3

Documentation

Additional documentation is available for download from the Illumina website. Refer to the inside back cover of this guide for more information.

4

Part # 15040457 Rev. B

  Chapter 2  Getting Started

Getting Started

TruSight Enrichment DNA Sample Preparation Kit

Consumables and Equipment

Best Practices

Prevent PCR Product Contamination

Acronyms

DNA Input Recommendations

6

15

18

20

23

25

TruSight Enrichment DNA Sample Preparation Guide

5

TruSight Enrichment DNA Sample Preparation Kit

The TruSight Enrichment DNA Sample Preparation Kit is packaged in 288, 96, 48, 16, or 8 sample boxes and shipped on dry ice unless specified otherwise below.

NOTE

Certain components of the kit should be stored at a different temperature than the temperature at which they are shipped. As soon as you receive your kit, store the kit components at the specified temperature.

CAUTION

If sequencing TruSight Enrichment libraries with HiSeq2000/1000, HiScanSQ, or

GAIIx, you must be sure to use the TruSeq Dual Index Sequencing Primer Boxes

(Single Read or Paired End, as appropriate) for all sequencing run types: nonindexed, single-indexed, and dual-indexed. These add-on kits are not required

if sequencing a TruSight Enrichment library with the MiSeq System.

TruSight

 Enrichment Kits

Consumable

TruSight Enrichment Kit (1 Index, 8 Samples)

TruSight Enrichment Kit (2 Indices, 8 Samples)

TruSight Enrichment Kit (4 Indices, 16 Samples)

TruSight Enrichment Kit (24 Indices, 48 Samples)

TruSight Enrichment Kit (24 Indices, 96 Samples)

TruSight Enrichment Kit (96 Indices, 288 Samples)

Catalog #

FC-123-1200

FC-123-1201

FC-123-1202

FC-123-1203

FC-123-1205

FC-123-1206

*TG Catalog #

TG-140-1004

TG-140-1001

TG-140-1002

TG-140-1003

TG-140-1005

TG-140-1006

NOTE

*TG-labeled consumables include features intended to help reduce the frequency of revalidation. They are available only under supply agreement and require you to provide a binding forecast. Please contact your account manager for more information.

NOTE

In order to support the number of samples as noted on the kit box, samples will need to be pooled appropriately prior to the enrichment step, as indicated in the user guide. For additional pooling instructions see

Library Pooling Guidelines on page 62

.

6

Part # 15040457 Rev. B

Note regarding biomarker patents and other patents unique to specific uses of products.

Some genomic variants, including some nucleic acid sequences, and their use in specific applications may be protected by patents. Customers are advised to determine whether they are required to obtain licenses from the party that owns or controls such patents in order to use the product in customer's specific application.

TruSight Content Sets - Oligos Only

Consumable

TruSight Exome Content Set

TruSight Cancer Content Set

TruSight Autism Content Set

TruSight Cardiomyopathy Content Set

TruSight Inherited Disease Content Set

*TG Catalog #

TG-141-1001

TG-141-1002

TG-141-1003

TG-141-1004

TG-141-1005

NOTE

*TG-labeled consumables include features intended to help reduce the frequency of revalidation. They are available only under supply agreement and require you to provide a binding forecast. Please contact your account manager for more information.

NOTE

Illumina does not support 1-plex enrichments for the TruSight Cancer,

Cardiomyopathy, or Autism Content Sets.

TruSeq Index Plate Fixture Kit

It is recommended to use the index plate fixture to assist in correctly arranging the index primers during the PCR Amplification steps. Each kit contains two fixtures and can be used for all TruSight Enrichment DNA Sample Preparation kits.

Consumable

TruSeq Index Plate Fixture Kit

Catalog #

FC-130-1005

TG Catalog #

TG-130-1005

TruSight Enrichment DNA Sample Preparation Guide

7

TruSight Enrichment Kit Contents

(1 Index, 8 Samples) (FC-123-1200, TG-140-1004)

Box 1

Quantity

2

1

2

2

1

Acronym

SMB

WS1

WS3

ET2

ST

Reagent Name

Streptavidin Magnetic Beads

Wash Solution 1

Wash Solution 3

Elute Target Buffer 2

Stop Tagment Buffer

Box 2

Quantity

1

1

1

1

1

1

2

1

2

2

Storage Temperature

2° to 8°C

2° to 8°C

2° to 8°C

2° to 8°C

Room temperature

Acronym Reagent Name

WS2

NCT1

ET1

HP3

Wash Solution 2

Nextera Capture Target Buffer 1

Elute Target Buffer 1

2N NaOH

PPC PCR Primer Cocktail

LP#-PMM PCR Master Mix, Polymerase

TD

TDE1

Tagment DNA Buffer

Tagment DNA Enzyme

RSB Resuspension Buffer

TC#-PMM PCR Master Mix, Polymerase

Storage Temperature

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

NOTE

LP#-PMM and TC#-PMM contain the same reagent, but have different volumes. They are used at different steps of the protocol, as described in this guide.

Box 3

Quantity

1 tube

1 tube

Reagent Name

Index Primer, E501

Index Primer, N701

Storage Temperature

-15° to -25°C

-15° to -25°C

8

Part # 15040457 Rev. B

TruSight Enrichment Kit Contents

(2 Indices, 8 Samples) (FC-123-1201, TG-140-1001)

Box 1

1

1

1

1

Quantity

1

Acronym

SMB

WS1

WS3

ET2

ST

Reagent Name

Streptavidin Magnetic Beads

Wash Solution 1

Wash Solution 3

Elute Target Buffer 2

Stop Tagment Buffer

Box 2

1

1

1

1

1

1

1

1

1

Quantity

1

Storage Temperature

2° to 8°C

2° to 8°C

2° to 8°C

2° to 8°C

Room temperature

Acronym

WS2

NCT1

ET1

Reagent Name

Wash Solution 2

Nextera Capture Target Buffer 1

Elute Target Buffer 1

HP3

PPC

2N NaOH

PCR Primer Cocktail

LP#-PMM PCR Master Mix, Polymerase

TD Tagment DNA Buffer

TDE1

RSB

Tagment DNA Enzyme

Resuspension Buffer

TC#-PMM PCR Master Mix, Polymerase

Storage Temperature

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

NOTE

LP#-PMM and TC#-PMM contain the same reagent, but have different volumes. They are used at different steps of the protocol, as described in this guide.

Box 3

Quantity

1 tube

2 tubes

Reagent Name

Index Primer, E501

Index Primers, N701 to N702

Storage Temperature

-15° to -25°C

-15° to -25°C

TruSight Enrichment DNA Sample Preparation Guide

9

TruSight Enrichment Kit Contents

(4 Indices, 16 Samples) (FC-123-1202, TG-140-1002)

Box 1

Quantity

1

1

1

1

1

Acronym

SMB

WS1

WS3

ET2

ST

Reagent Name

Streptavidin Magnetic Beads

Wash Solution 1

Wash Solution 3

Elute Target Buffer 2

Stop Tagment Buffer

Box 2

Quantity

1

1

1

1

1

1

1

1

1

1

Storage Temperature

2° to 8°C

2° to 8°C

2° to 8°C

2° to 8°C

Room temperature

Acronym Reagent Name

WS2

NCT1

ET1

HP3

Wash Solution 2

Nextera Capture Target Buffer 1

Elute Target Buffer 1

2N NaOH

LP#-PMM PCR Master Mix, Polymerase

PPC PCR Primer Cocktail

TD

TDE1

Tagment DNA Buffer

Tagment DNA Enzyme

RSB Resuspension Buffer

TC#-PMM PCR Master Mix, Polymerase

Storage Temperature

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

NOTE

LP#-PMM and TC#-PMM contain the same reagent, but have different volumes. They are used at different steps of the protocol, as described in this guide.

Box 3

Quantity

1 tube

4 tubes

Reagent Name

Index Primer, E501

Index Primers, N701 to N704

Storage Temperature

-15° to -25°C

-15° to -25°C

10

Part # 15040457 Rev. B

TruSight Enrichment Kit Contents

(24 Indices, 48 Samples) (FC-123-1203, TG-140-1003)

Box 1

1

1

1

1

Quantity

1

Acronym

SMB

WS1

WS3

ET2

ST

Reagent Name

Streptavidin Magnetic Beads

Wash Solution 1

Wash Solution 3

Elute Target Buffer 2

Stop Tagment Buffer

Box 2

2

1

1

1

1

1

1

1

1

Quantity

1

Storage Temperature

2° to 8°C

2° to 8°C

2° to 8°C

2° to 8°C

Room temperature

Acronym

WS2

NCT1

ET1

Reagent Name

Wash Solution 2

Nextera Capture Target Buffer 1

Elute Target Buffer 1

HP3

PPC

2N NaOH

PCR Primer Cocktail

LP#-PMM PCR Master Mix, Polymerase

TD Tagment DNA Buffer

TDE1

RSB

Tagment DNA Enzyme

Resuspension Buffer

TC#-PMM PCR Master Mix, Polymerase

Storage Temperature

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

NOTE

LP#-PMM and TC#-PMM contain the same reagent, but have different volumes. They are used at different steps of the protocol, as described in this guide.

Box 3

Quantity

2 tubes

12 tubes

Reagent Name

Index Primers, E501 to E502

Index Primers, N701 to N712

Storage Temperature

-15° to -25°C

-15° to -25°C

TruSight Enrichment DNA Sample Preparation Guide

11

TruSight Enrichment Kit Contents

(24 Indices, 96 Samples) (FC-123-1205, TG-140-1005)

Box 1

Quantity

2

2

2

2

1

Acronym

SMB

WS1

WS3

ET2

ST

Reagent Name

Streptavidin Magnetic Beads

Wash Solution 1

Wash Solution 3

Elute Target Buffer 2

Stop Tagment Buffer

Box 2

Quantity

2

3

1

2

1

1

2

2

2

2

Storage Temperature

2° to 8°C

2° to 8°C

2° to 8°C

2° to 8°C

Room temperature

Acronym Reagent Name

WS2

NCT1

ET1

HP3

Wash Solution 2

Nextera Capture Target Buffer 1

Elute Target Buffer 1

2N NaOH

PPC PCR Primer Cocktail

LP#-PMM PCR Master Mix, Polymerase

TD

TDE1

Tagment DNA Buffer

Tagment DNA Enzyme

RSB Resuspension Buffer

TC#-PMM PCR Master Mix, Polymerase

Storage Temperature

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

NOTE

LP#-PMM and TC#-PMM contain the same reagent, but have different volumes. They are used at different steps of the protocol, as described in this guide.

Box 3

Quantity

4 tubes

12 tubes

Reagent Name

Index Primers, E501 to E502

Index Primers, N701 to N712

Storage Temperature

-15° to -25°C

-15° to -25°C

12

Part # 15040457 Rev. B

TruSight Enrichment Kit Contents

(96 Indices, 288 Samples) (FC-123-1206, TG-140-1006)

Box 1

6

3

6

6

Quantity

6

Acronym

SMB

WS1

WS3

ET2

ST

Reagent Name

Streptavidin Magnetic Beads

Wash Solution 1

Wash Solution 3

Elute Target Buffer 2

Stop Tagment Buffer

Box 2

8

1

3

6

6

6

3

6

6

Quantity

6

Storage Temperature

2° to 8°C

2° to 8°C

2° to 8°C

2° to 8°C

Room temperature

Acronym

WS2

NCT1

ET1

Reagent Name

Wash Solution 2

Nextera Capture Target Buffer 1

Elute Target Buffer 1

HP3

PPC

2N NaOH

PCR Primer Cocktail

LP#-PMM PCR Master Mix, Polymerase

TD Tagment DNA Buffer

TDE1

RSB

Tagment DNA Enzyme

Resuspension Buffer

TC#-PMM PCR Master Mix, Polymerase

Storage Temperature

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

-15° to -25°C

NOTE

LP#-PMM and TC#-PMM contain the same reagent, but have different volumes. They are used at different steps of the protocol, as described in this guide.

Box 3

Quantity

16 tubes

24 tubes

Reagent Name

Index Primers, E501 to E508

Index Primers, N701 to N712

Storage Temperature

-15° to -25°C

-15° to -25°C

TruSight Enrichment DNA Sample Preparation Guide

13

TruSight Content Sets - Oligos Only

NOTE

Illumina does not support 1-plex enrichments for the TruSight Cancer,

Cardiomyopathy, or Autism Content Sets.

TruSight Exome Content Set

Quantity

1

Reagent Name

Exome TruSight Content Set CSO

Storage Temperature

-15° to -25°C

TruSight Cancer Content Set

Quantity

1

Reagent Name

Cancer TruSight Content Set CSO

TruSight Autism Content Set

Quantity

1

Reagent Name

Autism TruSight Content Set CSO

TruSight Cardiomyopathy Content Set

Quantity

1

Reagent Name

Cardiomyopathy TruSight Content Set CSO

TruSight Inherited Disease Content Set

Quantity

1

Reagent Name

Inherited Disease TruSight Content Set CSO

Storage Temperature

-15° to -25°C

Storage Temperature

-15° to -25°C

Storage Temperature

-15° to -25°C

Storage Temperature

-15° to -25°C

14

Part # 15040457 Rev. B

Consumables and Equipment

Check to ensure that you have all of the necessary user-supplied consumables and equipment before proceeding to sample preparation. These consumables and equipment are

Illumina recommended for the TruSight Enrichment DNA Sample Preparation protocols.

Table 1 User-Supplied Consumables

Consumable

10 µl barrier pipette tips

10 µl multichannel pipettes

10 µl single channel pipettes

1000 µl barrier pipette tips

1000 µl multichannel pipettes

1000 µl single channel pipettes

200 µl barrier pipette tips

200 µl multichannel pipettes

200 µl single channel pipettes

96-well storage plates, round well,

0.8 ml (“MIDI” plate)

300 µl 96-well skirtless PCR plates or

Twin.Tec 96-well PCR plates

Adhesive seal roller

Agencourt AMPure XP 60 ml kit

Distilled water

Supplier

General lab supplier

General lab supplier

General lab supplier

General lab supplier

General lab supplier

General lab supplier

General lab supplier

General lab supplier

General lab supplier

Fisher Scientific, part # AB-0859

E&K Scientific, part # 480096 or

Eppendorf, part # 951020303

General lab supplier

Beckman Coulter Genomics, part # A63881

General lab supplier

TruSight Enrichment DNA Sample Preparation Guide

15

16

Consumable

Ethanol 200 proof (absolute) for molecular biology (500 ml)

Microseal ‘A’ film

Microseal ‘B’ adhesive seals

PCR grade water (for gel-free method)

PCR tubes

RNase/DNase-free multichannel reagent reservoirs, disposable

Qubit dsDNA BR Assay Kit

Qubit assay tubes or

Axygen PCR-05-C tubes

Ultra pure water

Microseal 96-well PCR plates

(“TCY” plate)

Table 2 User-Supplied Equipment

Equipment

96-well thermal cycler

(with heated lid)

[Optional] 2100 Bioanalyzer Desktop

System

Supplier

See table in Thermal Cycler section.

Agilent, part # G2940CA

Supplier

Sigma Aldrich, part #  E7023

BioRad, part # MSA-5001

BioRad, part # MSB-1001

General lab supplier

General lab supplier

VWR, part # 89094-658

Life Technologies,

100 assays - catalog # Q32850

500 assays - catalog # Q32853

Life Technologies, catalog # Q32856 or

VWR, part #  10011-830

General lab supplier

Bio-Rad, part # HSP-9601

Part # 15040457 Rev. B

Equipment

[Optional] High Sensitivity Agilent DNA

Chip

DNA Engine Multi-Bay Thermal Cycler

High Speed Micro Plate Shaker

Magnetic stand-96

Microcentrifuge

Microplate centrifuge

Qubit 2.0 Fluorometer

Vacuum concentrator

Vortexer

Supplier

Agilent, part # 4067-4626

Bio-Rad, part #  PTC-0240G or PTC-0220G, with Alpha Unit, part #  ALS-1296GC

VWR, catalog # 13500-890 (110V/120V)

VWR, catalog # 14216-214 (230V)

Ambion, part # AM10027

General lab supplier

General lab supplier

Life Technologies, catalog # Q32866 http://products.invitrogen.com/ivgn/product/Q32866

General lab supplier

General lab supplier

Thermal Cycler

The following table lists the recommended settings for selected thermal cycler models.

Illumina recommends that you validate any thermal cyclers not listed below if your lab has not yet performed the TruSight Enrichment DNA Sample Preparation protocol.

Thermal Cycler

Bio-Rad DNA Engine

Tetrad 2

MJ Research DNA

Engine Tetrad

Eppendorf Mastercycler

Pro S

Temp Mode

Calculated

Calculated

Gradient S,

Simulated Tube

Lid Temp

Heated, Constant at 100°C

Heated

Heated

Vessel Type

Polypropylene plates and tubes

Plate

Plate

TruSight Enrichment DNA Sample Preparation Guide

17

Best Practices

Adhere to the following best practices when preparing libraries for sequencing using this protocol. Several components of this kit are shipped at one temperature and stored at a warmer temperature. The components are stable at either temperature, but should be used at the warmer temperature. To avoid delay during sample preparation, each component should be stored according to the recommendations in the Getting Started section.

Ensuring Consistency

} Use multichannel pipettes—To make sure there is consistency across samples, use a multichannel pipette where possible. Calibrate pipettes periodically.

}

Pre-aliquot reagents—To avoid unnecessary freeze-thaw cycles when performing experiments of fewer than 96 samples, Illumina recommends that you aliquot smaller volumes of reagents normally stored frozen after they are thawed for the first time.

Handling Magnetic Beads

}

Use at room temperature—Prior to use, allow the beads to reach room temperature.

Use a 25°C water bath as necessary.

} Vortex until well-suspended—Immediately prior to use, vortex the beads until they are well-suspended and the color appears homogeneous.

}

Allow maximum binding—For best results, incubate your bead/sample mixtures at room temperature for the entire duration indicated in the protocol.

}

Slowly aspirate cleared solution—After placing the plate on the magnetic stand, wait for the solution to clear before proceeding. Keep the plate on the magnetic stand when slowly aspirating cleared solution, taking care not to disturb the separated beads.

Avoiding Cross-Contamination

} Change tips between samples—Always use fresh pipette tips between samples and between dispensing index primers.

}

Mix plates as directed—Mix samples with a multichannel pipette and centrifuge the plate when indicated. Do not vortex the plates.

}

Use aerosol-resistant tips—Using aerosol-resistant pipette tips reduces the risk of amplicon carry-over and sample-to-sample cross-contamination.

NOTE

If aerosol-resistant tips are not available, ensure careful pipetting to avoid contamination.

18

Part # 15040457 Rev. B

Washing with 80% Ethanol During PCR Clean-Up

}

Prepare fresh 80% ethanol—Always prepare fresh 80% ethanol for wash steps.

Ethanol can absorb water from the air impacting your results.

}

Remove all ethanol from wells—Make sure that you remove all ethanol from the bottom of the wells as it might contain residual contaminants. Use a P20 multichannel pipette to remove residual ethanol and accelerate drying.

}

Allow complete evaporation—Allow at least ten minutes of drying time on the magnetic stand at room temperature for complete evaporation. Residual ethanol can impact the performance of subsequent reactions.

Freeze/thawing for Small Number of Samples

}

Each reagent tube supplied with your assay kit contains sufficient volume to process

96 samples at once, using an 8-channel pipette and a reservoir. When processing smaller sample batches (fewer than 96 samples) using a reagent reservoir, dead volume and pipetting error losses can increase. To make sure there is an accurate reagent volume for all samples, single-pipette the reagent into each well.

} To store remaining reagent, Illumina recommends freezing aliquots, rather than repeatedly freezing and thawing the supplied reagent tubes.

TruSight Enrichment DNA Sample Preparation Guide

19

Prevent PCR Product Contamination

The PCR process is commonly used in the laboratory to amplify specific DNA sequences.

Unless proper laboratory hygiene is used, PCR products can contaminate reagents, instrumentation, and genomic DNA samples, causing inaccurate and unreliable results.

PCR product contamination can shut down lab processes and significantly delay normal operations.

Make sure that the lab is set up appropriately to reduce the risk of PCR product contamination:

}

Physically Separate Pre-PCR and Post-PCR Areas

• Physically separate laboratory space where pre-PCR processes are performed (DNA extraction, quantification, and normalization) from the laboratory space where PCR products are made and processed (post-PCR processes).

• Never use the same sink to wash pre-PCR and post-PCR troughs.

• Never share the same water purification system for pre-PCR and post-PCR processes.

• Store all supplies used in the protocols in the pre-PCR area, and transfer to the post-PCR area as needed.

}

Use Dedicated Equipment and Supplies

• Dedicate separate full sets of equipment and supplies (pipettes, centrifuges, oven, heat block, etc.) to pre-PCR and post-PCR lab processes, and never share between processes.

• Dedicate separate storage areas (freezers and refrigerators) to pre-PCR and post-

PCR consumables.

Because the pre- and post-amplification reagents are shipped together, it is important to unpack the reagents in the pre-PCR lab area, and then move the post-amplification reagents to the proper post-PCR storage area.

Pre-PCR and Post-PCR Lab Procedures

To prevent PCR product contamination, it is important to establish lab procedures and follow best practices. Illumina recommends daily and weekly cleaning of lab areas using

0.5% Sodium Hypochlorite (10% Bleach).

CAUTION

To prevent sample or reagent degradation, make sure that all vapors from the cleaning solution have fully dissipated before beginning any processes.

20

Part # 15040457 Rev. B

Daily Cleaning of Pre-PCR Area

A daily cleaning of the pre-PCR area using a 0.5% Sodium Hypochlorite (10% Bleach) solution helps to eliminate PCR product that has entered the pre-PCR area.

Identify pre-PCR areas that pose the highest risk of contamination, and clean these areas with a 0.5% Sodium Hypochlorite (10% Bleach) solution before beginning any pre-PCR processes. High-risk areas might include, but are not limited to, the following items:

}

Bench tops

} Door handles

} Refrigerator/freezer door handles

}

Computer mouse

}

Keyboards

Daily Cleaning of Post-PCR Area

Reducing the amount of PCR product in the post-PCR area helps reduce the risk of contamination in the pre-PCR area. Daily cleaning of the post-PCR area using a 0.5%

Sodium Hypochlorite (10% Bleach) solution helps achieve this.

Identify post-PCR areas that pose the highest risk of contamination, and clean these areas with a 0.5% Sodium Hypochlorite (10% Bleach) solution daily. High-risk areas might include, but are not limited to, the following items:

}

Thermal cyclers

} Bench space used to process amplified DNA

}

Door handles

}

Refrigerator/freezer door handles

}

Computer mouse

} Keyboards

Weekly Cleaning of All Lab Areas

Once a week, perform a thorough cleaning of the pre-PCR and post-PCR areas using 0.5%

Sodium Hypochlorite (10% Bleach).

}

Clean all bench tops and laboratory surfaces.

}

Clean all instruments that are not cleaned daily.

} Thoroughly mop lab floors.

}

Make sure that personnel responsible for weekly cleaning are properly trained on prevention of PCR product contamination.

TruSight Enrichment DNA Sample Preparation Guide

21

Items Fallen to the Floor

The floor is contaminated with PCR product transferred on the shoes of individuals coming from the post-PCR area; therefore, anything falling to the floor must be treated as contaminated.

}

Disposable items that have fallen to the floor, such as empty tubes, pipette tips, gloves, lab coat hangers, must be discarded.

}

Non-disposable items that have fallen to the floor, such as a pipette or an important sample container, must be immediately and thoroughly cleaned with a 0.5% Sodium

Hypochlorite (10% Bleach) solution to remove PCR product contamination.

} Clean any lab surface that has come in contact with the contaminated item.

Individuals handling anything that has fallen to the floor, disposable or nondisposable, must discard their lab gloves and put on a new pair.

22

Part # 15040457 Rev. B

Acronyms

Table 3 TruSight Enrichment DNA Sample Preparation

Acronyms

NEA1

NEA2

NEL

NET1

NET2

PCR

PMM

Acronym

CAP

CSO

CTP1

CTP2 dsDNA

ET1

ET2

HP3

IWP1

IWP2

NCT1

Definition

Cleaned Amplification Plate

Custom Selected Oligos

Capture Target Plate 1

Capture Target Plate 2

Double-stranded DNA

Elute Target Buffer 1

Elute Target Buffer 2

2N NaOH

Intermediate Wash Plate 1

Intermediate Wash Plate 2

Nextera Capture Target Buffer 1

Nextera Enrichment Amplification Plate 1

Nextera Enrichment Amplification Plate 2

Nextera Enrichment Library Plate

Nextera Enrichment Tagmentation Plate 1

Nextera Enrichment Tagmentation Plate 2

Polymerase Chain Reaction

PCR Master Mix, Polymerase

TruSight Enrichment DNA Sample Preparation Guide

23

24

Acronym

PPC

RSB

ST

SMB

TAP1

TD

TDE1

TTP

WS1

WS2

WS3

WTP1

WTP2

Definition

PCR Primer Cocktail

Resuspension Buffer

Stop Tagment Buffer

Streptavidin Magnetic Beads

Target Amplification Plate 1

Tagment DNA Buffer

Tagment DNA Enzyme

Temporary Target Plate

Wash Solution 1

Wash Solution 2

Wash Solution 3

Wash Target Plate 1

Wash Target Plate 2

Part # 15040457 Rev. B

DNA Input Recommendations

The TruSight Enrichment DNA Sample Preparation Kit protocol is optimized for 50 ng of genomic DNA total. Illumina strongly recommends quantifying the starting genomic material.

Input DNA Quantitation

TruSight Enrichment DNA Sample Preparation library preps use an enzymatic DNA fragmentation step and thus can be more sensitive to DNA input compared to mechanical fragmentation methods. The ultimate success of enrichment strongly depends on using an accurately quantified amount of input DNA library. Therefore, the correct quantitation of the DNA library is essential.

Assessing DNA Quality

Absorbance measurements at 260 nm are commonly used to quantify DNA. The ratio of absorbance at 260 nm to absorbance at 280 nm is used as an indication of sample purity.

This protocol is optimized for DNA with absorbance ratio values of 1.8–2.0.

TruSight Enrichment DNA Sample Preparation Guide

25

26

Part # 15040457 Rev. B

  Chapter 3  TruSight Enrichment Protocol

TruSight Enrichment Protocol

TruSight Enrichment Workflow

Tagmentation of Genomic DNA

Clean-Up of Tagmented DNA

PCR Amplification

PCR Clean-Up

First Hybridization

First Wash

Second Hybridization

Second Wash

PCR Amplification

Enriched Library Validation

28

29

31

47

49

55

59

33

35

37

41

TruSight Enrichment DNA Sample Preparation Guide

27

TruSight Enrichment Workflow

The following diagram illustrates the workflow using the TruSight Enrichment DNA

Sample Preparation Kit. Safe stopping points are marked between steps.

Figure 1 TruSight Enrichment DNA Sample Preparation Workflow (For 8 samples)

28

Part # 15040457 Rev. B

Tagmentation of Genomic DNA

During this step genomic DNA is tagmented (tagged and fragmented) by the Nextera transposome. The Nextera transposome simultaneously fragments the genomic DNA and adds adapter sequences to the ends, allowing amplification by PCR in subsequent steps.

Consumables

Item

TD (Tagment DNA Buffer)

TDE1 (Tagment DNA Enzyme)

96-well hard shell TCY plate

Genomic DNA (2.5 ng/µl)

Microseal 'B' adhesive seal

Quantity

1 tube

1 tube

1 plate

50 ng

Storage

-15° to -25°C

-15° to -25°C

Room temperature

-15° to -25°C

Room temperature

Supplied By

Illumina

Illumina

User

User

User

Preparation

1 Remove the TD, TDE1, and genomic DNA from -15° to -25°C storage and thaw on ice.

NOTE

In preparation for the next step of the protocol, ensure ST buffer is at room temperature, and there are no particles or precipitate visible in the solution.

2 After thawing, ensure all reagents are adequately mixed by gently inverting the tubes

3–5 times, followed by a brief spin in a microcentrifuge.

Procedure

NOTE

Ensure the reaction is assembled in the order described for optimal kit performance.

The reaction does not need to be assembled on ice.

1 Label a new 96-well TCY plate "NET1" (Nextera Enrichment Tagmentation Plate 1) with a smudge resistant pen.

TruSight Enrichment DNA Sample Preparation Guide

29

30

2 Add 20 µl of genomic DNA at 2.5 ng/µl (50 ng total) to each sample well of the NET1 plate.

3 Add 25 µl of TD Buffer to the wells containing genomic DNA. Change tips between samples.

NOTE

Calculate the total volume of TD for all reactions, and divide among an appropriate number of tubes in an 8-well PCR strip tube. Use a multichannel pipette to dispense into the NET1 plate.

4 Add 5 µl of TDE1 to the wells containing genomic DNA and TD Buffer. Change tips between samples.

NOTE

Calculate the total volume of TDE1 for all reactions, and divide among an appropriate number of tubes in an 8-well PCR strip tube. Use a multichannel pipette to dispense into the NET1 plate.

5 Using a multichannel pipette, gently pipette up and down 10 times to mix. Change tips between samples.

6 Cover the NET1 plate with Microseal 'B'.

7 Centrifuge at 280 xg at 20°C for 1 minute.

8 Place the NET1 plate in a thermocycler and run the following program:

NOTE

Ensure that the thermocycler lid is heated during the incubation.

• 55°C for 5 minutes

• Hold at 10°C

9 Proceed to Clean-Up of Tagmented DNA.

Part # 15040457 Rev. B

Clean-Up of Tagmented DNA

The tagmented DNA is purified from the Nextera transposome. This step is critical because the Nextera transposome can bind tightly to DNA ends and will interfere with downstream processes if not removed.

Consumables

Item

RSB (Resuspension Buffer)

ST Buffer

AMPure XP Beads

Freshly Prepared 80% Ethanol

(EtOH)

96-well hard shell TCY plate

96-well MIDI plate

Quantity

1 tube

1 tube

1 tube

1 plate

1 plate

Storage

-15° to -25°C

Room temperature

2° to 8°C

Supplied By

Illumina

Illumina

User

User

User

User

Preparation

1 Remove the AMPure XP beads from storage and let stand for at least 30 minutes to bring them to room temperature.

2 Remove the NET1 plate from the Thermocycler and remove the seal.

3 Visually inspect the ST buffer to ensure there is no precipitate. If there is precipitate, vortex until all particulates are resuspended.

Procedure

1 Add 15 µl ST buffer to each well of the NET1 plate with sample.

2 Gently pipette up and down 10 times to mix.

3 Incubate at room temperature (20° to 25°C) for 5 minutes.

TruSight Enrichment DNA Sample Preparation Guide

31

32

4 Centrifuge the NET1 plate at 280 xg at 20°C for 1 minute.

5 Using a multichannel P200 transfer the entire solution in each well of the NET1 plate to a clean 96-well midi plate labeled "NET2" (Nextera Enrichment Tagmentation Plate

2) with a smudge resistant pen.

6 Add 52 µl of well-resuspended AMPure XP beads to each well of the NET2 plate with sample and gently pipette up and down 10 times.

7 Incubate at room temperature for 10 minutes.

8 Cover the NET2 plate with a seal and centrifuge at 280 xg at 20°C for 1 minute.

9 Remove the seal and place the plate on a magnetic stand for 2 minutes or until the supernatant has cleared.

10 Remove and discard supernatant.

11 While the NET2 plate is still on the magnet slowly add 200 µl of freshly made 80% ethanol to each sample. Wait 30 seconds.

12 Remove and discard the ethanol.

13 Repeat steps

11

and

12

. Make sure there is no residual ethanol left in the plate.

14 While the NET2 plate is still on the magnet stand dry beads at room temperature for 10 minutes.

15 Remove the NET2 plate from the magnet and add 22.5 µl of RSB buffer.

16 Pipette mix up and down 10 times to resuspend beads.

17 Place the NET2 plate on the magnet for 2 minutes until the solution becomes clear.

18 Label a new 96-well TCY plate "NEA1" (Nextera Enrichment Amplification Plate 1) with a smudge resistant pen.

19 Transfer 20 µl of supernatant to the new NEA1 plate.

NOTE

(Optional) Check the products of the tagmentation reaction by loading 1 µl of supernatant on a HS Bioanalyzer chip. This should produce a broad distribution of

DNA fragments with a size range from ~150 bp – <1 Kb.

Part # 15040457 Rev. B

PCR Amplification

In this step, the purified tagmented DNA is amplified via a limited-cycle PCR program.

The PCR step also adds index 1 (i7) and index 2 (i5) and sequencing, as well as common adapters (P5 and P7) required for cluster generation and sequencing. It is critical to use the full amount of recommended input DNA, as well as to not add extra cycles of PCR cycles to ensure high quality libraries that produce high-quality sequencing results.

Consumables

Item

PMM (PCR Master Mix)

Index 1 primers (N7XX)

Index 2 primers (E5XX)

TruSeq Index Plate Fixture

Microseal 'A' adhesive film

96-well hard shell TCY plate

Quantity

1 tube

1 tube each index

1 tube each index

1 plate

Storage

-15° to -25°C

-15° to -25°C

-15° to -25°C

Supplied By

Illumina

Illumina

Illumina

Illumina

User

User

NOTE

The TruSight Enrichment DNA Sample Preparation kit is designed to work only with

Index 2 primers with the "E" prefix. Index 2 primers from other Nextera sample prep kits should not be used.

Procedure

NOTE

For pooling libraries prior to enrichment, it is recommended to pool libraries so all

Index 1 (i7) indexes are unique. Choose Index 1 and index 2 primers for PCR accordingly. For further details refer to Appendix A of the TruSight Enrichment DNA

Sample Preparation Guide.

NOTE

PCR Set up should be done in the NEA1 plate, same plate that your final elution is.

1 To each well of the NEA1 plate containing sample add:

TruSight Enrichment DNA Sample Preparation Guide

33

34

• 20 µl of PMM

• 5 µl of the Index 1 (i7, N7xx) primer

• 5 µl of the Index 2 (i5, E5xx) primer

• Total volume = 50 µl

2 Gently pipette mix up and down.

3 Cover the NEA1 plate with Microseal 'A' and seal with a rubber roller.

4 Centrifuge at 280 xg at 20°C for 1 minute.

5 Perform PCR using the following program on a thermal cycler:

NOTE

Ensure that the thermocycler lid is heated during the incubation. Pre-heat lid to

100˚C.

• 72°C for 3 minutes

• 98°C for 30 seconds

• 10 cycles of:

— 98°C for 10 seconds

— 60°C for 30 seconds

— 72°C for 30 seconds

• 72°C for 5 minutes

• Hold at 10°C

SAFE STOPPING POINT

If you do not plan to immediately proceed to PCR Clean-Up following the completion of PCR, the NEA1 plate can remain on the thermalcycler overnight, or you can store it at 2° to 8°C up to two days.

Part # 15040457 Rev. B

PCR Clean-Up

This step uses AMPure XP beads to purify the library DNA, and provides a size selection step that removes very short library fragments from the population.

Consumables

Item

RSB (Resuspension Buffer)

AMPure XP beads

80% Ethanol, freshlyprepared

96-well MIDI plates

96-well TCY plates

Quantity

1 tube

1 plate

1 plate

Storage

-15° to -25°C

2° to 8°C

Supplied By

Illumina

User

User

User

User

Preparation

1 Remove the AMPure XP beads from storage and let stand for at least 30 minutes to bring them to room temperature.

Procedure

1 Remove the NEA1 plate from the thermocycler and centrifuge at 280 xg at 20°C for 1 minute.

2 Carefully remove the cover so the solution does not splash (if this happens centrifuge again).

3 Label a new 96-well TCY plate "NEA2" (Nextera Enrichment Amplification Plate 2) with a smudge resistant pen.

4 Transfer the entire PCR reaction to the NEA2 plate.

5 Add 45 µl of well-resuspended AMPure XP beads to each well of the NEA2 plate with sample.

6 Gently pipette up and down 10 times to mix.

TruSight Enrichment DNA Sample Preparation Guide

35

36

7 Incubate at room temperature for 10 minutes.

8 Place the NEA2 plate on a magnetic stand for 2 minutes or until the supernatant has cleared.

9 Carefully remove and discard the supernatant.

10 While the NEA2 plate is still on the magnet slowly add 200 µl of freshly made 80% ethanol to each sample and wait 30 seconds.

11 Remove and discard the entire ethanol wash.

12 Repeat steps

10

and

11

.

13 While the NEA2 plate is still on the magnet stand dry beads at room temperature for

15 minutes.

14 Remove the NEA2 plate from the magnet and add 40 µl of RSB buffer.

15 Pipette mix up and down 10 times to resuspend beads.

16 Place the NEA2 plate on the magnet for 2 minutes until the solution becomes clear.

17 Label a new 96-well TCY plate "NEL" (Nextera Enrichment Library Plate) with a smudge resistant pen.

18 Transfer 38 µl of supernatant to the NEL plate.

19 Quantify the library by either Picogreen or Qubit.

Part # 15040457 Rev. B

First Hybridization

This process mixes the DNA library with capture probes of targeted regions. The recommended hybridization time makes sure that targeted regions bind to the capture probes thoroughly. It also describes how to combine multiple libraries with different indices into a single pool prior to enrichment.

Consumables

Item

TruSight Content Set CSO

(Custom Selected Oligos)

NCT1 (Nextera Capture Target

Buffer 1)

300 µl 96-well skirtless PCR

Plate or twin.tech 96-well PCR

Plate

Microseal 'B' adhesive seal

PCR grade water

500 ng DNA library from NEL

Plate

Quantity

1 tube

1 tube

1 plate

Storage

-15° to -25°C

-15° to -25°C

Supplied By

Illumina

Illumina

User

User

User

User

Preparation

}

Remove the CSO tube from -15° to -25°C storage and thaw at room temperature.

}

Remove the NCT1 tube from -15° to -25°C storage and thaw at room temperature.

} Pre-program the thermal cycler as follows:

• 95°C for 10 minutes

• 18 cycles of 93°C for 1 minute, decreasing 2°C per cycle

• 58°C for forever

} Pre-heat the thermal cycler lid to 100°C.

} Label a new 300 µl 96-well skirtless PCR plate or twin.tech 96-well PCR plate "CTP1"

(Capture Target Plate 1) with a smudge resistant pen.

TruSight Enrichment DNA Sample Preparation Guide

37

Pool Libraries

NOTE

In order to support the number of samples as noted on the kit box, samples will need to be pooled appropriately prior to the enrichment step, as indicated in the user guide. For additional pooling instructions see

Library Pooling Guidelines on page 62

.

1 Reference

Table 4

for the amount of DNA libraries to use for enrichment. Illumina recommends using 500 ng of each DNA library, quantified by picogreen or the Qubit

Fluorometric Quantitation system. See

DNA Input Recommendations on page 25 . If

pooling libraries, combine 500 ng of each DNA library. If the total volume is greater than 40 µl, use a vacuum concentrator without heat to reduce the pooled sample volume to 40 µl.

2 The recommended pre-enrichment pooling strategy is to pool up to 12 libraries each with a unique Index 1/i7 index. With this pooling approach samples can be sequenced using a single index read workflow, as described in the HiSeq and GAIIx user guides. If

Index1/i7 indexes are not unique, ensure that libraries with different Index 2/i5 indexes are included (e.g. N703/E501 and N703/E502). With this approach, samples can be sequenced using a dual index read workflow, as described in the HiSeq and GAIIx user guides. Please see

Library Pooling Guidelines on page 62

for further details.

38

Part # 15040457 Rev. B

NOTE

Adding >500 ng library DNA into the enrichment assay (up to 1 ug per sample) may produce greater mean coverage/sample.

Table 4 DNA Libraries for Enrichment

Library Pool

Complexity

1-plex

2-plex

3-plex

4-plex

5-plex

6-plex

7-plex

8-plex

9-plex

10-plex

11-plex

12-plex

Total

DNA Library Mass (ng)

500

1000

1500

2000

2500

3000

3500

4000

4500

5000

5500

6000

TruSight Enrichment DNA Sample Preparation Guide

39

Make CTP1

1 Thoroughly vortex the NCT1 tube until the solution is completely resuspended.

Visually make sure that no crystal structures are present.

NOTE

If crystals and cloudiness are observed, vortex the NCT1 tube until it appears clear.

2 In the order listed below, prepare the reaction mix in each well of the new 300 µl

96-well PCR plate or twin.tech 96-well PCR plate labeled CTP1. Gently pipette the entire volume up and down 5–10 times to mix thoroughly. Multiply each volume by the number of pooled samples being prepared.

Reagent

DNA library from NEL plate

NCT1

TruSight Content Set CSO

Total Volume per Sample

Volume (µl)

40

50

10

100

3 Seal the CTP1 plate with a Microseal ‘B’ adhesive seal. Make sure that the plate is tightly sealed to prevent potential evaporation. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

Incubate CTP1

1 Centrifuge the CTP1 plate at 280 xg at 20°C for 1 minute.

2 Place the sealed CTP1 plate on the pre-programmed thermal cycler. Close the lid and incubate as follows: a Choose the pre-heat lid option and set to 100°C.

b 95°C for 10 minutes.

c 18 cycles of 93°C for 1 minute, decreasing 2°C per cycle.

d 58°C for 16–20 hours.

40

Part # 15040457 Rev. B

First Wash

This process uses streptavidin beads to capture probes containing the targeted regions of interest. Three wash steps remove non-specific binding from the beads. The enriched library is then eluted from the beads and prepared for a second hybridization.

Consumables

Item

HP3 (2N NaOH)

ET1 (Elute Target Buffer 1)

ET2 (Elute Target Buffer 2)

SMB (Streptavidin Magnetic

Beads)

WS1 (Wash Solution 1)

WS2 (Wash Solution 2)

WS3 (Wash Solution 3)

96-well MIDI Plate

300 µl 96-well skirtless PCR

Plate or twin.tech 96-well PCR

Plate

Microseal 'B' adhesive seal

PCR grade water

PCR tubes

Quantity

1 tube

1 tube

1 tube

1 tube

1 tube

1 tube

1 tube

2 plates

5

Storage

-15° to -25°C

-15° to -25°C

2° to 8°C

2° to 8°C

2° to 8°C

-15° to -25°C

2° to 8°C

Supplied By

Illumina

Illumina

Illumina

Illumina

Illumina

Illumina

Illumina

User

User

User

User

User

Preparation

}

Remove the SMB, ET2, WS1, and WS3 tubes from 2° to 8°C storage and let stand at room temperature.

TruSight Enrichment DNA Sample Preparation Guide

41

} Remove the ET1, HP3, and WS2 tubes from -15° to -25°C storage and thaw at room temperature.

}

Label a new 300 µl 96-well skirtless PCR plate or twin.tech 96-well PCR plate "IWP1"

(Intermediate Wash Plate 1) with a smudge resistant pen.

}

Label a new 300 µl 96-well skirtless PCR plate or twin.tech 96-well PCR plate "CTP2"

(Capture Target Plate 2) with a smudge resistant pen.

} Label a new 96-well MIDI plate "WTP1" (Wash Target Plate 1) with a smudge resistant pen.

Make WTP1

1 Remove the CTP1 plate from the thermal cycler.

2 Centrifuge the CTP1 plate at 280 xg at 20°C for 1 minute.

3 Place the CTP1 plate on a 96-well rack and remove the adhesive seal from the plate.

Take care when removing the seal to avoid spilling the contents of the wells.

4 Transfer the entire contents of each well from the CTP1 plate to the corresponding well of the new 96-well MIDI plate labeled WTP1.

NOTE

It is normal to see a small degree of sample loss after overnight hybridization. However, if the sample loss is greater than 15%, Illumina does not recommended proceeding with the sample preparation. This amount of loss can be caused by poor sealing or not heating the lid.

5 Vortex the SMB tube until the beads are well dispersed, then add 250 µl of well-mixed

SMB to the wells of the WTP1 plate. Gently pipette the entire volume up and down 10–

20 times until mixed.

6 Seal the WTP1 plate with a Microseal ‘B’ adhesive seal.

7 Let the WTP1 plate stand at room temperature for 30 minutes.

8 Centrifuge the WTP1 plate at 280 xg at 20°C for 1 minute.

9 Remove the adhesive seal from the WTP1 plate.

10 Place the WTP1 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

11 Remove and discard all of the supernatant from each well.

12 Remove the WTP1 plate from the magnetic stand.

42

Part # 15040457 Rev. B

Wash 1 WTP1 and Wash 2 WTP1

Perform WS1 Clean Up and WS2 Clean Up on the WTP1 plate as follows:

WS1 Clean Up

1 Thoroughly vortex the WS1 tube. Visually make sure that no crystal structures are present.

NOTE

If crystals are observed, vortex the WS1 tube until no crystal structures are visible.

2 Add 200 µl WS1 to each well of the WTP1 plate. Gently pipette the entire volume up and down 10–20 times to make sure the beads are fully resuspended.

3 Place the WTP1 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

4 Remove and discard all of the supernatant from each well.

5 Remove the WTP1 plate from the magnetic stand.

WS2 Clean Up

1 Thoroughly vortex the WS2 tube. Visually make sure that the WS2 is mixed thoroughly.

2 Add 200 µl WS2 to each well of the WTP1 plate. Gently pipette the entire volume up and down 10–20 times. Mix thoroughly and avoid excessive bubbling or foaming.

Make sure that the beads are fully resuspended.

3 Place the WTP1 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

4 Remove and discard all of the supernatant from each well.

5 Remove the WTP1 plate from the magnetic stand.

6 Add 200 µl WS2 to each well of the WTP1 plate. Gently pipette the entire volume up and down 10–20 times. Mix thoroughly and avoid excessive bubbling or foaming.

Make sure that the beads are fully resuspended.

TruSight Enrichment DNA Sample Preparation Guide

43

7 Transfer the entire contents of each well of the WTP1 plate to the corresponding well of the new 96-well PCR plate labeled IWP1.

8 Seal the IWP1 plate with a Microseal ‘B’ adhesive seal. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

9 Incubate the IWP1 plate on the thermal cycler at 42°C for 30 minutes with a heated lid set to 100°C.

NOTE

For optimal results, it is important that the thermal cycler lid be heated to 100°C.

10 Place the magnetic stand next to the thermal cycler for immediate access.

11 Remove the IWP1 plate from the thermal cycler and immediately place it on the magnetic stand for 2 minutes until the liquid appears clear.

12 Remove the adhesive seal from the IWP1 plate.

13 Immediately remove and discard all of the supernatant from each well.

14 Remove the IWP1 plate from the magnetic stand.

15 Add 200 µl WS2 to each sample well of the IWP1 plate. Gently pipette the entire volume up and down 10–20 times. Mix thoroughly and avoid excessive bubbling or foaming. Make sure that the beads are fully resuspended.

16 Repeat steps

8 – 13

once.

Wash 3 WTP1

Perform WS3 Clean Up and Elute Target on the WTP1 plate as follows:

WS3 Clean Up

1 Remove the IWP1 plate from the magnetic stand.

2 Add 200 µl WS3 to each well of the IWP1 plate. Gently pipette the entire volume up and down 10–20 times to mix thoroughly.

3 Place the IWP1 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

4 Remove and discard all of the supernatant from each well.

5 Repeat steps

1 – 4

once.

44

Part # 15040457 Rev. B

6 To remove any residual WS3, seal the IWP1 plate with a Microseal ‘B’ adhesive seal.

Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

7 Briefly centrifuge the IWP1 plate to collect any residual WS3.

8 Place the IWP1 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

9 Carefully remove the adhesive seal from the IWP1 plate to avoid spilling the contents of the wells.

10 Remove and discard any residual supernatant from each well.

Elute Target

1 Mix the following reagents in the order listed in a separate PCR tube to create the elution pre-mix. Multiply each volume by the number of pooled samples being prepared.

Reagent

ET1

HP3

Total Volume per Sample

Volume (µl)

28.5

1.5

30

2 Remove the IWP1 plate from the magnetic stand.

3 Add 23 µl of the elution pre-mix to each well of the IWP1 plate. Gently pipette the entire volume of each well up and down 10–20 times to mix thoroughly. Make sure that the beads are fully resuspended.

4 Seal the IWP1 plate with a Microseal ‘B’ adhesive seal. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

5 Let the IWP1 plate stand at room temperature for 5 minutes.

6 Centrifuge the IWP1 plate at 280 xg at room temperature for 1 minute.

7 Place the IWP1 plate on the magnetic stand for 2 minutes until the liquid appears clear.

8 Carefully remove the adhesive seal from the IWP1 plate to avoid spilling the contents of the wells.

9 Transfer 21 µl of supernatant from each well of the IWP1 plate to the corresponding well of the new 96-well PCR plate labeled CTP2.

TruSight Enrichment DNA Sample Preparation Guide

45

46

10 Add 4 µl ET2 to each well of the CTP2 plate containing samples to neutralize the elution. Gently pipette the entire volume up and down 5–10 times to mix thoroughly.

11 Seal the CTP2 plate with Microseal 'B' adhesive seal. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

12 Store the remaining reagents as follows: a Place the SMB, ET2, WS1, and WS3 tubes in 2° to 8°C storage.

b Place the ET1, HP3, and WS2 tubes in -15° to -25°C storage.

c Discard any remaining elution pre-mix.

SAFE STOPPING POINT

If you do not plan to proceed to

Second Hybridization on page 47

immediately, the protocol can be safely stopped here. If you are stopping, seal the CTP2 plate with a Microseal ‘B’ adhesive seal and store it at -15° to -25°C for up to seven days. When proceeding, thaw the CTP2 plate on ice.

Part # 15040457 Rev. B

Second Hybridization

This process mixes the first elution of the DNA library with the capture probes of target regions. The second hybridization make sure that the targeted regions are further enriched.

Consumables

Item

TruSight Content Set CSO

(Custom Selected Oligos)

NCT1 (Nextera Capture Target

Buffer 1)

300 µl 96-well skirtless PCR

Plate or twin.tech 96-well PCR

Plate

Microseal 'B' adhesive seal

PCR grade water

Quantity

1 tube

1 tube

1 plate

Storage

-15° to -25°C

-15° to -25°C

Supplied By

Illumina

Illumina

User

User

User

Preparation

}

Remove the CSO tube from -15° to -25°C storage and thaw at room temperature.

}

Remove the NCT1 tube from -15° to -25°C storage and thaw at room temperature.

} Remove the CTP2 plate from -15° to -25°C storage, if it was stored at the conclusion of

First Wash on page 41

and let stand to thaw at room temperature.

• Briefly centrifuge the thawed CTP2 plate to 280 xg for 1 minute

• Remove the adhesive seal from the thawed CTP2 plate.

}

Pre-program the thermal cycler as follows: a 95°C for 10 minutes.

b 18 cycles of 93°C for 1 minute, decreasing 2°C per cycle.

c 58°C for forever.

}

Pre-heat the thermal cycler lid to 100°C.

} Ensure CTP2 plate is completely thawed. Centrifuge at 280 xg for 1 minute.

TruSight Enrichment DNA Sample Preparation Guide

47

Add CTO/CSO

NOTE

The second hybridization should be set up in the same plate that the elution of the first wash is in, CTP2.

1 Thoroughly vortex the NCT1 tube until the solution is completely resuspended.

Visually make sure that no crystal structures are present.

NOTE

If crystals and cloudiness are observed, vortex the NCT1 tube until it appears clear.

2 In the order listed below, add the following to each well of the CTP2 plate. Gently pipette the entire volume up and down 5-10 times to mix thoroughly. Multiply each volume by the number of samples being prepared.

Reagent

NCT1

TruSight Content Set CSO

PCR Grade Water

First elution

Total Volume per Sample

Volume (µl)

50

10

15

25

100

3 Seal the CTP2 plate with a Microseal ‘B’ adhesive seal. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

Incubate CTP2

1 Centrifuge the CTP2 plate at 280 xg at 20°C for 1 minute.

2 Place the sealed CTP2 plate on the pre-programmed thermal cycler. Close the lid and incubate as follows: a Choose the pre-heat lid option and set to 100°C.

b 95°C for 10 minutes.

c 18 cycles of 93°C for 1 minute, decreasing 2°C per cycle.

d 58°C for 16–20 hours.

48

Part # 15040457 Rev. B

Second Wash

This process uses streptavidin beads to capture probes containing the targeted regions of interest. Three wash steps remove non-specific binding from the beads. The enriched library is then eluted from the beads and prepared for sequencing.

NOTE

These procedures are similar to the

First Wash on page 41

.

Consumables

Item

HP3 (2N NaOH)

ET1 (Elute Target Buffer 1)

ET2 (Elute Target Buffer 2)

SMB (Streptavidin Magnetic

Beads)

WS1 (Wash Solution 1)

WS2 (Wash Solution 2)

WS3 (Wash Solution 3)

96-well MIDI Plate

300 µl 96-well skirtless PCR

Plate or twin.tech 96-well PCR

Plate

Microseal 'B' adhesive seal

PCR grade water

PCR tubes

Quantity

1 tube

1 tube

1 tube

1 tube

1 tube

1 tube

1 tube

2 plates

5

Storage

-15° to -25°C

-15° to -25°C

2° to 8°C

2° to 8°C

2° to 8°C

-15° to -25°C

2° to 8°C

Supplied By

Illumina

Illumina

Illumina

Illumina

Illumina

Illumina

Illumina

User

User

User

User

User

TruSight Enrichment DNA Sample Preparation Guide

49

Preparation

}

Remove the SMB, ET2, WS1, and WS 3 tubes from 2° to 8°C storage and let stand at room temperature.

} Remove the ET1, HP3, and WS2 tubes from -15° to -25°C storage and thaw at room temperature.

}

Label a new 300 µl 96-well skirtless PCR plate or twin.tech 96-well PCR plate "IWP2"

(Intermediate Wash Plate 2) with a smudge resistant pen.

}

Label a new 300 µl 96-well skirtless PCR plate or twin.tech 96-well PCR plate "TTP"

(Temporary Target Plate) with a smudge resistant pen.

} Label a new 96-well MIDI plate "WTP2" (Wash Target Plate 2) with a smudge resistant pen.

}

[Optional] Label one new PCR tube per sample “Second Elution for qPCR”.

Make WTP2

1 Remove the CTP2 plate from the thermal cycler.

2 Centrifuge the room temperature CTP2 plate at 280 xg at room temperature for 1 minute.

3 Place the CTP2 plate on a 96-well rack and remove the adhesive seal from the plate.

Take care when removing the seal to avoid spilling the contents of the wells.

4 Transfer the entire contents from each well of the CTP2 plate to the corresponding well of the new 96-well MIDI plate labeled WTP2.

NOTE

It is normal to see a small degree of sample loss after overnight hybridization. However, if the sample loss is greater than 15%, Illumina does not recommended proceeding with the sample preparation. This amount of loss can be caused by poor sealing or not heating the lid.

5 Vortex the SMB tube until the beads are well dispersed, then add 250 µl of well-mixed

SMB to the wells of the WTP2 plate. Gently pipette the entire volume up and down 10 times to mix thoroughly.

6 Seal the WTP2 plate with a Microseal ‘B’ adhesive seal.

7 Let the WTP2 plate stand at room temperature for 30 minutes.

8 Centrifuge the WTP2 plate at 280 xg at 20°C for 1 minute.

50

Part # 15040457 Rev. B

9 Remove the adhesive seal from the WTP2 plate.

10 Place the WTP2 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

11 Remove and discard all of the supernatant from each well.

12 Remove the WTP2 plate from the magnetic stand.

Wash 1 WTP2 and Wash 2 WTP2

Perform WS1 Clean Up and WS2 Clean Up on the WTP2 plate as follows:

WS1 Clean Up

1 Thoroughly vortex the WS1 tube. Visually make sure that no crystal structures are present.

NOTE

If crystals are observed, vortex the WS1 tube until no crystal structures are visible.

2 Add 200 µl WS1 to each well of the WTP2 plate. Gently pipette the entire volume up and down 10–20 times to make sure the beads are fully resuspended.

3 Place the WTP2 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

4 Remove and discard all of the supernatant from each well.

5 Remove the WTP2 plate from the magnetic stand.

WS2 Clean Up

1 Thoroughly vortex the WS2 tube. Visually make sure that the WS2 is mixed thoroughly.

2 Add 200 µl WS2 to each well of the WTP2 plate. Gently pipette the entire volume up and down 10–20 times. Mix thoroughly and avoid excessive bubbling or foaming.

Make sure that the beads are fully resuspended.

3 Place the WTP2 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

4 Remove and discard all of the supernatant from each well.

TruSight Enrichment DNA Sample Preparation Guide

51

5 Remove the WTP2 plate from the magnetic stand.

6 Add 200 µl WS2 to each well of the WTP2 plate. Gently pipette the entire volume up and down 10–20 times. Mix thoroughly and avoid excessive bubbling or foaming.

Make sure that the beads are fully resuspended.

7 Transfer the entire contents of each well of the WTP2 plate to the corresponding well of the new 96-well PCR plate labeled IWP2.

8 Seal the IWP2 plate with a Microseal ‘B’ adhesive seal. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

9 Incubate the IWP2 plate on the thermal cycler at 42°C for 30 minutes with a heated lid set to 100°C.

NOTE

For optimal results, it is important that the thermal cycler lid be heated to 100°C.

10 Place the magnetic stand next to the thermal cycler for immediate access.

11 Remove the IWP2 plate from the thermal cycler and immediately place it on the magnetic stand for 2 minutes until the liquid appears clear.

12 Remove the adhesive seal from the IWP2 plate.

13 Immediately remove and discard all of the supernatant from each well.

14 Remove the IWP2 plate from the magnetic stand.

15 Add 200 µl WS2 to each sample well of the IWP2 plate. Gently pipette the entire volume up and down 10–20 times. Mix thoroughly and avoid excessive bubbling or foaming. Make sure that the beads are fully resuspended.

16 Repeat steps

8 – 13

once.

Wash 3 WTP2

Perform WS3 Clean Up and Elute Target on the WTP2 plate as follows:

WS3 Clean Up

1 Remove the IWP2 plate from the magnetic stand.

2 Add 200 µl WS3 to each well of the IWP2 plate. Gently pipette the entire volume up and down 10–20 times to mix thoroughly.

52

Part # 15040457 Rev. B

3 Place the IWP2 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

4 Remove and discard all of the supernatant from each well.

5 Repeat steps

1 –

4

once.

6 To remove any residual WS3, seal the IWP2 plate with a Microseal ‘B’ adhesive seal.

Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

7 Briefly centrifuge the IWP2 plate to collect any residual WS3.

8 Place the IWP2 plate on the magnetic stand for 2 minutes at room temperature until the liquid appears clear.

9 Carefully remove the adhesive seal from the IWP2 plate to avoid spilling the contents of the wells.

10 Remove and discard any residual supernatant from each well.

Elute Target

1 Mix the following reagents in the order listed in a separate PCR tube to create the elution pre-mix. Multiply each volume by the number of pooled samples being prepared.

Reagent

ET1

HP3

Total Volume per Sample

Volume (µl)

28.5

1.5

30

2

Remove the IWP2 plate from the magnetic stand.

3 Add 23 µl of the elution pre-mix to each well of the IWP2 plate. Gently pipette the entire volume of each well up and down 10–20 times to mix thoroughly. Make sure that the beads are fully resuspended.

4 Seal the IWP2 plate with a Microseal ‘B’ adhesive seal. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

5 Let the IWP2 plate stand at room temperature for 5 minutes.

6 Centrifuge the IWP2 plate at 280 xg at 20°C for 1 minute.

7 Place the IWP2 plate on the magnetic stand for 2 minutes until the liquid appears clear.

TruSight Enrichment DNA Sample Preparation Guide

53

54

8 Carefully remove the adhesive seal from the IWP2 plate to avoid spilling the contents of the wells.

9 Transfer 21 µl of supernatant from each well of the IWP2 plate to the corresponding well of the new 96-well PCR plate labeled TTP.

10 Add 4 µl ET2 to each well of the TTP plate containing samples to neutralize the elution. Gently pipette the entire volume of each well up and down 10-20 times to mix thoroughly.

11 [Optional] The Second Elution for qPCR tube can be used for yield quantification. To do so, dilute 2 µl of supernatant from each well of the TTP plate in 98 µl PCR grade water

(1:50 dilution) in a new PCR tube labeled “Second Elution for qPCR”. Cap each tube and store at -15° to -25°C.

12 Store the remaining reagents as follows: a Place the SMB, ET2, WS1, and WS3 tubes in 2° to 8°C storage.

b Place the ET1, HP3, and WS2 tubes in -15° to -25°C storage.

c Discard any remaining elution pre-mix.

Part # 15040457 Rev. B

PCR Amplification

This process uses PCR to amplify the enriched DNA library for sequencing.

Consumables

Item

PMM (PCR Master Mix)

PPC (PCR Primer Cocktail)

RSB (Resuspension Buffer)

300 µl 96-well skirtless PCR

Plate or twin.tech 96-well PCR

Plate

AMPure XP beads

80% Ethanol, freshly-prepared

Microseal 'B' adhesive seal

Quantity

1 tube

1 tube

1 tube

2 plates

3

Storage

-15° to -25°C

-15° to -25°C

-15° to -25°C

2° to 8°C

Supplied By

Illumina

Illumina

Illumina

User

User

User

User

Preparation

}

Remove one tube each of PMM and PPC from -15° to -25°C storage and thaw on ice.

NOTE

If you do not intend to consume the PMM and PPC reagents in one use, dispense the reagents into single use aliquots and freeze in order to avoid repeated freeze thaw cycles.

}

Briefly centrifuge the thawed PPC and PMM tubes for 5 seconds.

}

Remove the AMPure XP beads from storage and let stand for at least 30 minutes to bring them to room temperature.

} Pre-program the thermal cycler as follows:

• Choose the pre-heat lid option and set to 100°C

• 98°C for 30 seconds

• 12 cycles of:

— 98°C for 10 seconds

TruSight Enrichment DNA Sample Preparation Guide

55

— 60°C for 30 seconds

— 72°C for 30 seconds

• 72°C for 5 minutes

• Hold at 10°C

} Label a 300 µl 96-well skirtless PCR plate or twin.tech 96-well PCR plate "CAP"

(Cleaned Amplification Plate).

}

Label a 300 µl 96-well skirtless PCR plate or twin.tech 96-well PCR plate "TAP1"

(Target Amplification Plate 1).

Add PPC

1 Add the following to each well of the new TAP1 300 µl 96-well PCR plate. Gently pipette the entire volume up and down 10 times to mix thoroughly.

Reagent

Second Elution from TTP plate

PMM

PPC

Total Volume per Sample

Volume (µl)

20

25

5

50

2 Seal the TAP1 plate with a Microseal ‘B’ adhesive seal. Use an adhesive seal roller to apply force to the seal and make sure the seal is secured.

3 Centrifuge the TAP1 plate at 280 xg at 20°C for 1 minute.

Amp PCR

1 Place the sealed TAP1 plate on the pre-programmed thermal cycler. Close the lid and incubate using the pre-programmed settings: a Choose the pre-heat lid option and set to 100°C.

b 98°C for 30 seconds.

c 12 cycles of:

— 98°C for 10 seconds

— 60°C for 30 seconds

— 72°C for 30 seconds d 72°C for 5 minutes.

e Hold at 10°C.

56

Part # 15040457 Rev. B

Make CAP

1 Remove the adhesive seal from the TAP1 plate.

2 Vortex the AMPure XP Beads until the beads are well dispersed, then add 90 µl of the mixed AMPure XP Beads to each well of the TAP1 plate containing 50 µl of the PCR amplified library. Gently pipette the entire volume up and down 10 times to mix thoroughly.

3 Incubate the TAP1 plate at room temperature for 15 minutes.

4 Place the TAP1 plate on the magnetic stand at room temperature for 5 minutes or until the liquid appears clear.

5 Using a 200 µl single or multichannel pipette, remove and discard 140 µl of the supernatant from each well of the TAP1 plate.

NOTE

Leave the TAP1 plate on the magnetic stand while performing the following

80% EtOH wash steps ( 6

8 ).

6 With the TAP1 plate remaining on the magnetic stand, add 200 µl of freshly prepared

80% EtOH to each well without disturbing the beads.

7 Incubate the TAP1 plate for at least 30 seconds at room temperature, then remove and discard the supernatant from each well.

8 Repeat steps

6 – 7

once for a total of two 80% EtOH washes.

9 Keep the TAP1 plate on the magnetic stand and allow plate to stand at room temperature for 15 minutes to dry, then remove the plate from the magnetic stand.

10 Resuspend the dried pellet in each well with 30 µl RSB. Gently pipette the entire volume up and down 10 times to mix thoroughly.

11 Incubate the TAP1 plate at room temperature for 2 minutes.

12 Place the TAP1 plate on the magnetic stand at room temperature for 5 minutes or until the liquid appears clear.

13 Transfer 28 µl of the clear supernatant from each well of the TAP1 plate to the corresponding well of the new 96-well PCR plate labeled CAP.

TruSight Enrichment DNA Sample Preparation Guide

57

SAFE STOPPING POINT

If you do not plan to proceed to

Enriched Library Validation on page 59

immediately, the protocol can be safely stopped here. If you are stopping, seal the CAP plate with a Microseal ‘B’ adhesive seal and store it at -15° to -25°C for up to seven days.

58

Part # 15040457 Rev. B

Enriched Library Validation

Illumina recommends performing the following procedure for quality control analysis on your enriched DNA library and quantification of the DNA library templates.

In order to achieve the highest quality of data on Illumina sequencing platforms, it is important to create optimum cluster densities across every lane of every flow cell. This requires accurate quantitation of enriched DNA library templates. Quantitate libraries using qPCR as described in the Illumina Sequencing Library qPCR Quantification Guide.

TruSight Enrichment DNA Sample Preparation Guide

59

60

Part # 15040457 Rev. B

Appendix A  References

References

Library Pooling Guidelines 62

TruSight Enrichment DNA Sample Preparation Guide

61

Library Pooling Guidelines

Illumina uses a green laser to sequence G/T and a red laser to sequence A/C. At each cycle at least one of two nucleotides for each color channel need to be read to ensure proper registration. It is important to maintain color balance for each base of the index read being sequenced, otherwise index read sequencing could fail due to registration failure. Follow the instructions described here to determine which libraries are pooled pre-enrichment.

The TruSight Enrichment DNA Sample Preparation kit supports pre-enrichment pooling of up to 12 different indexed samples. For pooling of 12 samples pre-enrichment, the recommended strategy is to pool samples with Index1/i7 701-712 (any Index2/i5), followed by a single-index sequencing run. For pooling <12 samples the recommended strategy is to set up a single index workflow sequencing run using different Index1/i7 indexes (any

Index2/i5). Reference

Table 5

to ensure proper index combinations. See

Table 6

for pooling details when using both Index1/i7 and Index2/i5, followed by a dual indexed sequencing run.

NOTE

In order to support the number of samples as noted on the kit box, samples will need to be pooled appropriately prior to the enrichment step, as indicated in the user guide.

Table 5 Libraries Pooled: 6 or Fewer; Sequencing Workflow: Single Index

Plex Index 1 (i7) Selection Index 2 (i5) Selection

Any Index 1 adapter Any Index 2 adapter 1-plex

(no pooling)

2-plex

3-plex

4- or 5-plex

6-plex

• [option 1] N702 and N701

• [option 2] N702 and N704

• [option 1] N701, N702, and N704

• [option 2] N703, N705, and N706

• [option 1] N701, N702, N704, and any other Index 1 adapter

• [option 2] N703, N705, N706, and any other Index 1 adapter

N701, N702, N703, N704, N705, and N706

62

Part # 15040457 Rev. B

Table 6 Sequencing Workflow: Single or Dual Index

Plex Index 1 (i7) Selection

7–12 plex, Dual

Index

7–12 plex,

Single Index

• [option 1] N701, N702, N704, and any other Index 1 adapter

(as needed)

• [option 2] N703, N705, N706, and any other Index 1 adapter

(as needed)

• N701–N706 and any other Index

1 adapter (as needed)

Index 2 (i5) Selection

• [option 1] E501 and E502

• [option 2] E503 and E504

• [option 3] E505 and E506

• Any Index 2 (i5) adapter

The table below represents only some of the acceptable combinations. Alternatively, please check the real sequences of each index in

Table 6

to make sure each base position will have signal in both color channels for the index read:

Index 1

705 GG AC T CC T

706 T A GG CA TG

701 T AA GG C G A

702 C GT AC T A G

√ √ √ √ √ √ √ √

Good

Index 2

503 T A T CC T C T

503 T A T CC T C T

504 A G A GT A G A

504 A G A GT A G A

√ √ √ √ √ √ √ √

Index 1

705 GG AC T CC T

706 T A GG CA TG

701 T AA GG C G A

702 C GT AC T A G

√ √ √ √ √ √ √ √

Bad

Index 2

502 C T C T C T A T

502 C T C T C T A T

503 T A T CC T C T

503 T A T CC T C T

√ √ √ √ xxxx

√=signal in both color x=signal missing in one color channel

TruSight Enrichment DNA Sample Preparation Guide

63

64

Part # 15040457 Rev. B

Technical Assistance

For technical assistance, contact Illumina Technical Support.

Table 7 Illumina General Contact Information

Illumina Website

www.illumina.com

Email

[email protected]

Table 8 Illumina Customer Support Telephone Numbers

Region

North America

Austria

Belgium

Denmark

Finland

France

Germany

Ireland

Contact Number

1.800.809.4566

0800.296575

0800.81102

80882346

0800.918363

0800.911850

0800.180.8994

1.800.812949

Region

Italy

Netherlands

Norway

Spain

Sweden

Switzerland

United Kingdom

Other countries

Contact Number

800.874909

0800.0223859

800.16836

900.812168

020790181

0800.563118

0800.917.0041

+44.1799.534000

MSDSs

Material safety data sheets (MSDSs) are available on the Illumina website at www.illumina.com/msds.

Product Documentation

Additional product documentation in PDF is available for download from the Illumina website. Go to www.illumina.com/support, select a product, then click Documentation &

Literature.

TruSight Enrichment DNA Sample Preparation Guide

65

Illumina

San Diego, California, U.S.A.

+1.800.809.ILMN (4566)

+1.858.202.4566 (outside North America) [email protected]

www.illumina.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
