access cONtrOL

Hi-tech.

Advanced.

Multifaceted.

These are some of the terms that best describe our diverse range of access control offerings.

SOLO

Standalone Proximity Access Control System

Product Code: SOLO0001V1

SOLO is designed for small standalone access control applications where security, cost and simplicity are important. This reader allows for easy programming of up to 50 user tags as well as selective, easy adding and deleting of users thanks to the reader’s exceptionally user-friendly LED-based interface.

Main Features

Mechanical features

• Optional secure link (SmartSwitch II) – additional security measure to prevent unauthorised access even if the unit is tampered with

• Weatherproof reader

• Optional anti-knock shield for reader

electronic features

• 50 user tag memory – ideal for basic proximity access applications

• Tags are encrypted and cannot be cloned

• Excellent read range

• 13.56MHz operating frequency

• Output is configurable as follows:

• Pulsed output configurable from 1 - 254 seconds

• Latched output

• Free-exit input

• Door Sense input

• Output for external alarm – alarm is generated under the following conditions:

• Door Held Open for an extended period of time

• Door Forced Open

Technical Specifications

Technical Data

Input voltage

Current draw

Quiescent

Maximum

Tag frequency

Read range

Reader dimensions (mm)

Surface-mount

Flush-mount

Weight

Temperature range

Humidity

Degree of protection

Number of tags (including Masters)

Number of Master tags

Voltage-free relay output

Relay time configurable (off/1 - 254s/latching)

Door Open Timer (0 - 254s/continuous)

Door Open Pre-warn Timer (0 - 254s/continuous)

Door Open Alarm (Off/1 - 254s/continuous)

Door Forced Alarm (Off/1 - 254s/continuous)

User interface

Door Sense Input

Free-exit input

Onboard buzzer

Output for optional external alarm

SmartSwitch II compatible

Anti-tamper switch facility

Networkable

Anti Passback

Firmware upgrade facility

SOLO

10V – 12V AC or 11V – 15V DC

110mA

150mA

13.56MHz

80 – 100mm

Width: 90mm x Depth: 30mm x Height:129mm

Width: 86mm x Depth: 15mm x Height:124mm

0.1kg

-20°C to 50°C

0 – 90% (non-condensing)

IP55

51

2

√

√

√

√

√

√

5 LEDs

√

√

-

-

√

√

√

√

√

TM

www.CentSys.com

10mm

85mm 29mm 25mm staNdaLONe

PrOxiMitY access cONtrOL sYsteM

page 131

Lattice

Networked Proximity Access Control System

Product Code: Lattice Controller: LATC0003V1, Lattice Slave Head: LATS0001V1

Start as a standalone proximity unit and expand into a powerful networked system with up to 32 readers. A handy three-digit LED display allows for easy programming of user tags and Lattice’s user-friendly interface makes selective adding and deleting of tags veritable child’s play. For added functionality and even simpler administration, the system can be interfaced with the LatticeWARE computer software package. Lattice allows for the addition of up to 1000 user tags.

Main Features

Mechanical features

• Weatherproof reader

• Optional anti-knock shield for reader

• Optional secure link (SmartSwitch II)

• Choose from either surface-mount or flush-mount fascias

(included in kit)

electronic features

• 1000 user tag memory – perfect for larger applications with many users

• Tags are encrypted and cannot be cloned

• 13.56MHz operating frequency

• Start with a standalone controller and add up to 31

Slave Heads – great versatility

• Excellent read range

• Dual outputs on the controller and a single output on the

Slave Heads – configurable as follows:

• Pulsed output configurable from 1 - 254 seconds

• Latched output

• Free-exit input

• Door Sense input

• Output for external alarm – alarm is generated under the following conditions:

• Door Held Open for an extended period of time

• Door Forced Open

• Anti-passback for improved security

• Limited Uses support – useful in pay-per-use and security applications

• Backup Memory Module available

TM

www.CentSys.com

Technical Specifications

Lattice

Input voltage

Current draw:

Standby

Operating

Tag frequency

Read range

Reader dimensions

Surface-mount

Flush-mount

Weight

Temperature range

Humidity

Standalone capability

Dipswitch configurable network address

Relay time configuration (Off/1 -254s/Latch)

Open collector output time configuration (Off/1 - 254s/latch)

Door Open Timer (0 - 255s)

Door Open Pre-warn Timer (0 - 254s/infinite)

Door Open Alarm (Off/1 - 254s/infinite)

Door Forced Alarm (Off/1 - 254s/infinite)

Reduced power consumption

Functional tags in off-line situation

Output channels

Voltage-free relay output (Potential-free)

Open collector output (SmartSwitch II enabled)

Free-exit input (Potential free normally open contact - FRX)

Door Sense input (Potential free normally closed contact - DOOR SEN)

Output for optional external alarm (Potential free normally closed contact -

Optional extra)

Anti-tamper Indication

User interface - 3 digit display + 3 LEDs

User interface - 5 LEDs

Hardware link to TUH (Lattice Take-up Head)

Alarm output time(s) increments

1. Jumper on Slave Head selects between relay or open collector output.

L1000 LSH

9V - 12V AC or 12V - 15V DC

110mA

170mA

110mA

150mA

13.56MHz

80 - 100mm

Width: 85mm x Depth: 29mm x Height:125mm

Width: 85mm x Depth: 10mm (visible) x Height:125mm

0.1kg

-10 to +50°C

0- 90% (non-condensing)

√ -

-

√

√

√

√

√

√

1000

2

√

√

√

√

√

√

√

√

√

√

√

√

√

40

1

√

√

√

√

1

√ √

-

√

√

√

√

-

√

-

0 - 254 sec; adjustable in 1 sec increments

10mm

85mm 29mm 25mm

NetwOrked

PrOxiMitY access cONtrOL sYsteM

page 133

LatticeWARE

Networked Proximity Access Control System

Product Code: Take-up head: LATTUH01V2

The LatticeWARE software is intuitive, easy to use and greatly enhances the functionality of the Lattice system.

The Lattice system, whether a standalone reader or networked system, can be further scaled by adding a PC. The PC or laptop becomes the Lattice server, which will now behave as the brains of the operation. The PC links to the controller via the Lattice

Take-up Head (TUH). The TUH provides the system with a convenient tag reader for initial tag take-up and administration

The LatticeWARE software makes the task of modifying and managing the system far simpler.

Main Features

electronic features

• Interface with the Lattice system at any stage

• Complete and easy setup

• Full management of the system

• Integrated time-barring support

• Multiple operating reports with export capability

• LatticeWARE accessible from any PC in a networked system

SmartSwitch II

Product Code: SMARTSW2V1

SOLO and Lattice

Accessories

SOLO and Lattice Anti-knock Shield

Product Code: SOLOAKS0V1

The SmartSwitch II serves as an interface board that provides for an additional security measure, effectively guarding your system against any unwarranted triggers.

It relies upon the receipt of a coded signal from the controller, which will then respond to the trigger.

Switch

Product Code:

SOLOTAMP01

A Grade 304 stainless steel enclosure with a stylish and durable brushed finish for protecting your SOLO and

Lattice reader from getting knocked and damaged.

Controller

Product Code: PCA11667V1

A useful ancillary micro-switch that can be connected to the reader’s onboard buzzer or a third party alarm system and provides an output whenever the reader is removed from its enclosure.

Effortlessly create a backup of all tags and settings saved to a Lattice controller’s memory for superior data security.

TM

www.CentSys.com

NetwOrked

PrOxiMitY access cONtrOL sYsteM

page 135

SAFLEC

Comprehensive Access Control System

Various kit combinations available - refer to Price List

An excellent access control system for small, medium and large networked installations. Besides the proximity access control readers, the system can cater for many different components such as biometric readers, Time and Attendance-compliant readers, and keypad access control.

The network integrates with various protocols such as Wiegand; RS-485 and RS-232 allowing for network flexibility.

Main Features

• Networked, scalable access control system

• Easy user-friendly installation and administration

• Anti-passback, timed Anti-passback and Zone Control

• Flexible Time & Attendance exporting

• Site-based configuration and hardware filtering

• Graphical event and alert monitoring and control

• PC-based actions for controlling third party devices such as

CCTV, intrusion and fire systems

Example of a Typical System Configuration www.CentSys.com

cOMPreheNsive access cONtrOL sYsteM

page 137

SAFLEC Door Controllers

Comprehensive Proximity Access Control System

Various kit combinations available - refer to Price List

The Multiple Door Controllers can cater for, as a standard, five doors with a reader on both sides of each door for access control in both directions, and up to 3200 tag-holders. The tag holder capacity is expandable up to 30 000, depending on the expansion boards utilised. Using remote I/O boards the system can be expanded for a further three doors, totalling eight off the same controller. A total of 16 controllers can be networked together to handle up to 256 readers or 128 doors.

However, multiple 16-controller networks can be linked together via a PC to create an ever-expanding access control meganetwork.

Maximum door capacity

1

Tag holder capacity

2

Robust RS-485 reader connection

Relay outputs - can be potential-free or powered

Digital inputs

4

Wiegand interface connections

Events and actions on controller

Controller offline transaction buffer capacity

Robust isolated RS-485 bus between controllers with high stability and surge protection

5

Onboard communication port

Weatherproof enclosure with lockable hinged access door

Integrated power supply

6

Battery backup

Mains monitoring with a battery charging circuit and a low-voltage cut off

Rotary coded address switch for easy addressing

Diagnostic LEDs for easy testing

1. Additional expansion modules required

2. Expandable to 30,000 via SEB-700 TCP/IP module

3. Either isolated or networked topology

Multiple door controller SDC-550

8

3200

16

3

-

√

5

8

6000

√

Optional TCP/IP

√

4.5A

7Ah

√

√

√

Multiple door controller SDC-520

8

30 000

16

3

2

√

2

4

40 000

√

TCP/IP

√

2.6A

7Ah

√

√

√

4. 2 inputs may be configured to Automatic Fire and Tamper Control

5. Maximum 16 controllers per device network (unlimited device networks)

6. Maximum controller output 3A

SDC-220 Two-door controller

2

1000

4 (isolated)

3

2

-

2

4

100 000

-

TCP/IP

√

2.6A

7Ah

√

-

√

Proximity Readers

Comprehensive Proximity Access Control System

Various kit combinations available - refer to Price List

SAFLEC readers cover the majority of proximity access control needs, with the Wiegand Reader SSR-202 connecting to

Wiegand-compatible controllers

High-bright, tri-colour LED

Audible buzzer with different sounds for allowing and denying access

Industry standard 125khz operational frequency

Reads Hitag1, Hitag 2, EM4102 card technologies

Rotary-coded address switch for easy addressing

Configurable bitmasking for limiting card number length from 16 to 40 bits

Wiegand standard connection

USB Connectivity

Wiegand Reader

SSR-202

√

√

√

√

√

√

√

-

Proximity Reader

SSR-201

√

USB Take-on Reader

SSR-221

√

√

√

√

√

√

-

-

-

√

√

-

√

-

√

www.CentSys.com

cOMPreheNsive access cONtrOL sYsteM

page 139

SMARTGUARD

High-Security Keyless Access Control

Product Code: SK/1BLK (SMARTGUARD), SK/AIRBLK (SMARTGUARDair)

The CENTURION SMARTGUARD range provides efficient, secure keyless access control by enabling users to store up to 1000 unique codes comprising one to ten digits in its non-volatile memory. A variety of electrical devices can be activated (including gate operators, alarm panels, water pumps, etc.) by making use of one or more of the outputs provided.

Models Available

sMartGUard:

Multi-function, high-security, wired, keypad access-control.

sMartGUardair: High-security, wireless, keypad access control.

Main Features

sMartGUard

• SMARTGUARD for hard-wired installations – compatible with almost any access control device

• 1000 unique codes using one to ten digits – for greater security and versatility in a multi-user application

• Three channel output – activate up to three devices

• Selectively add and delete user codes – convenient and secure management of the system

• Backup Memory Module – guarantees data security

• Limited Uses Counter – grant access to armed response, garden services, etc. - codes are automatically rendered invalid after pre-set number of uses

sMartGUardair

• Wireless for quick and easy installations

• 1000 unique codes using one to ten digits – for greater security and versatility in a multi-user application

• 15 channel output – activate up to 15 compatible devices

• Selectively add and delete user codes – convenient and secure management of the system

• Backup Memory Module – guarantees data security

• Limited-uses counter – grant access to armed response, garden services, etc. - codes are automatically rendered invalid after use

• Operates on two AA Alkaline batteries (included), or a separate 12V power supply

• Up to two years of battery life with up to 300 uses per day

• Wireless operating range of up to 30 metres (line of sight)

• Compatible with CENTURION’s code-hopping receivers

TM

TM

Technical Specifications

Technical Data

Input voltage

Current

Operating temperature

Operating range

Operating frequency

Outputs

Output pulse time range

Memory

Dimensions

Housing material

Degree of protection

SMARTGUARD SMARTGUARDair

12V - 24V AC/DC

32mA (standby) – 180mA (max)

-20 o

C – +60 o

C

NA

NA

3 (1 Relay output, 2 open collector outputs)

1 – 255 sec (adjustable) or latched

2 x AA Alkaline batteries (included)

NA

-18 o

C – +55 o

C

Up to 30m

433MHz

Up to 15 individual channels

NA

1000 user codes 1000 user codes

Width:80mm x Depth: 38mm x Height: 132mm

Polycarbonate

IP55

www.CentSys.com

SMARTGUARD SMARTGUARDair

80mm 38mm

NetwOrked

PrOxiMitY access cONtrOL sYsteM

page 141

SMARTGUARD and SMARTGUARDair

Accessories

Memory Module

Product Code:

CP108

Anti-tamper Switch

Product Code:

CP19

Create a backup of all users and settings stored in your keypad’s memory using this compact and useful memory module.

Anti-knock Shield

Product Code:

SK/AKS

An optional independent tamper switch can be fitted to provide a contact indicating if the unit has been forced open, or removed from its mountings.

SmartSwitch II

Product Code: SMARTSW2V1

An anti-knock shield constructed from brushed Grade 304 stainless steel. Also available in mild steel.

Relay Switch

Product Code:

CP106

An interface board that provides additional security. It will only respond to a coded signal from the SMARTGUARD keypad. This ensures that - unauthorised person can operate the device by simply opening the keypad and shorting wires to trigger the device.

NOVA Single- and Multichannel Receivers

Various products available - refer to Price List

This optional controller interfaces with the open collector output of the SMARTGUARD hard-wired keypad to provide a potential-free contact (normally-open/normally-closed).

It can be used to operate a door lock, gate operator, roller-shutter operator, traffic barrier, etc.

SMARTGUARDair interfaces with high-security NOVA codehopping receivers.

Access Control Kits

SOLO Standalone System Kit

Product code: SOLO0001V1

• 1 x SOLO reader – Surface or Flush-Mount

1

• Order tags as needed

Lattice Controller Kit

Product code: LATC0003V1

• 1 x Lattice controller – Surface or Flush-Mount

2

• Order tags as needed

Lattice Slave Kit

Product code: LATS0001V1

• 1 x Lattice Slave Head – Surface or Flush-Mount

2

Lattice Take-up Head Kit

Product code: LATTUH01V2

• 1 x Lattice Take-up Head, USB-type

3

• 1 x Software package

SAFLEC SDC-220 Door Controller Kit

Product code: SFSDC22000

• 1 x Controller

5

• 1 x Lockable enclosure

5

• 1 x Power supply

5

• 1 x Battery

5

SAFLEC SDC-550 Door Controller Kit

Product code: SFSDC55000

• 1 x Controller

5

• 1 x Lockable enclosure

5

• 1 x Power supply

5

• 1 x Battery

5

SAFLEC SDC-520 Door Controller Kit

Product code: SFSDC52000

• 1 x Controller

5

• 1 x Lockable enclosure

5

• 1 x Power supply

5

• 1 x Battery

5

SMARTGUARDair kit

Product code: SK/AIR_R1B

• 1 x SMARTGUARDair keypad

4

• 2 x AA Alkaline batteries

B

• 1 x Single-channel CENTURION receiver

C

www.CentSys.com

1

SOLO

Reader

2

Lattice

Reader

3

Lattice

Take-up Head

4

SMARTGUARDair

Keypad

5

SAFLEC SDC-220

SAFLEC SDC-520

SAFLEC SDC-550 a access tag b aa alkaline batteries c single-channel ceNtUriON receiver

NetwOrked

PrOxiMitY access cONtrOL sYsteM

page 143

SAFLEC Software

Comprehensive Access Control System

Various kit combinations available - refer to Price List

SAFLEC software is available in three different levels to suit the needs of any installation, - matter how large and sophisticated, or small and simple.

The Corporate Edition is the most comprehensive package, followed closely by the Professional Edition.

The Standard Edition, included free with the purchase of a SDC-550 Multiple Door Controller, is a good solution for smaller installations where the full functionality of the SAFLEC system is not required.

Main Features

• Easy user-friendly installation and administration

• Anti-passback, Timed Anti-passback and Zone Control for greater security

• Flexible Time & Accumulation exporting

• Site-based configuration and hardware filtering

• Graphical event and alert monitoring and control

• PC-based actions for controlling third party devices such as

CCTV, intrusion and fire systems

• Tag-holder sequencing tasks (enforcing Time & Attendance clockings)

• Quick search filters, low bandwidth setting and on-the-fly configuration

• Random search and tag-holder counters for scripting

• Software plug-in for PC-based overrides or custom extensions

Flexible Time & Accumulation exporting

Extremely flexible event-based action mode on controllers

Multiple companies and departments

Mantrap (Booth) and turnstile operation supported

16 powerful schedules per controller

32 public holidays integrated into schedules

Maximum number of doors supported

Timed Anti-passback, Anti-passback and Zone Control

Card capture/drop-box function available

Biometric reader integration

Supports Personal Assistant Software SSS-120

Supports Remote Client Software SSS-101

64 event controlled Counters or Timers per Controller

Configurable extra data fields with automatic lists, dropdown lists, photographs or notes fields

Tag-holder sequencing tasks (enforcing Time &

Attendance clockings)

Site-based configuration and hardware filtering

Site-based configuration and hardware filtering

Graphical event and alert monitoring and control

PC-based actions for controlling third party devices

Quick search filters, low bandwidth setting and on-thefly configuration

Random search and tag holder counters for scripting

1. Personal Assistant Software SSS-120 is a visitor management, data capture solution which is ideal for picture capturing, card design and biometric reader take-on. Includes card printer capability - supports Windows drivers

2. Remote Client Software SSS-101 provides additional administrators full use of the master software from remote computer terminals

Corporate Edition

SSS-110

Product code: SFSSS11000

√

Across all

√

√

√

√

√

√

√

√

√

√

√

√

√

√

√

√

√

√

√

Professional Edition

SSS-130

Product code: SFSSS13000

√

Local only

√

√

√

√

√

√

√

√

√

√

-

-

-

-

-

-

-

-

-

Standard Edition

SSS-100

Product code: SFSSS10000

√

Local only

√

√

√

√

√

√

√

√

√

-

-

-

-

-

-

-

-

-

-

www.CentSys.com

SAFLEC Expansion Boards

Comprehensive Access Control System

Various kit combinations available - refer to Price List

Expansion boards offer a seemingly never-ending list of additional functionality to the SAFLEC system. From adding additional inputs and outputs and increasing memory to converting the interface protocol, virtually all potential user requirements are catered for.

SEB 720 Remote I/O Expansion Board

Product Code: SFSSEB72000

• 2 x Outputs (potential-free/powered)

• 4 x Digital inputs

• Support for 1 x Wiegand device or 4 x RS-485 readers

• Connects to SDC-550 and SDC-520 on reader network

SEB-722 Remote I/O Expansion Board

Product Code: SFSSEB72200

• 2 x Outputs (potential-free/powered)

• 4 x Digital/analogue inputs

• Support for 2 x Wiegand device or 4 x RS-485 readers

• Connects to SDC-550 and SDC-520 on reader network

• Lockable enclosure

• Power supply

• Battery

with Onboard Receiver

Product Code: SFSSEB72100

• 4 x receiver channels; each receiver can control up to four buttons

• Each transmitter will have a unique number that will be linked as a card holder

• Connects to SDC-550 and SDC-520 on reader network

Expansion Board for SDC-550

Product Code: SFSEB70000

• Increase tag holder capacity to 30 000

• Provides native TCP/IP connectivity

• Connects to Expansion Head on SDC-550.

Converter Board

Product Code: SFSSI300WO

• Converts Wiegand data into the RS-485 used by the

SDC-550 Multiple Door Controller, the SDC-520

Ethernet Controller and the SEB-720 remote I/O board

• Small, space-saving board for unobtrusive installation behind a device, or within the controller cabinet

• In-circuit programming for easy product updates

• Rotary-coded address switch for easy addressing

• Requires 12V DC power source

Expansion Board

Product Code: SFSEB71000

• Extends the I/O capabilities of the SDC-550 Multiple

Door Controller

• 8 x Relay outputs (configure as either powered or potential-free contacts)

• 8 x Programmable digital inputs

• 8 x Multi-purpose I/O points

(set as either inputs or outputs)

cOMPreheNsive access cONtrOL sYsteM

page 145

Biometric Components

Biometric Fingerprint Readers

Various kit combinations available - refer to Price List

Adding a biometric reader significantly increases the security of any access control installation by providing a formidable biometric identification system that is very difficult to circumvent.

Centurion Systems is a proud stockist of the award-winning Virdi range of biometric and general access control devices.

Virdi AC2100 Reader

Biometric Reader

Product Code: VIRDA2100

The Virdi AC2100 is a practical and affordable fingerprint reader with Fake Fingerprint Detection technology.

Virdi AC2100H RF Reader

Biometric Reader

Product Code: VIRDAC2500

Virdi’s patented fingerprint authentication technology taken to the next level with network compatibility and an even larger user template capacity.

Virdi AC4000 RF

Biometric Reader

Product Code: VIRDAC4000

The Virdi AC4000 RF system offers an award-winning

Fingerprint, PIN and RF/SC cards authentication.

New-generation technology, convenience and design with

LCD, LED and motion sensor technology.

Virdi AC5000 RF

Biometric Reader

Product Code: VIRDAC5000

The Virdi AC5000 RF Fingerprint Reader incorporates state-of-the-art design, elegant looks and a robust

IP65-rated housing, designed to withstand any weather conditions.

It has a customisable colour LCD screen, with an LED touch keypad (i.e. - plastic/rubber buttons which can wear out).

Main Features

• 100 user and 200 fingerprint template capacity

• Patented Virdi Fake Fingerprint Detection – can detect fingerprints made from paper, silicone, wax, etc.

• IPX3 rating – IPX is an international waterproofing standard; it can be installed in virtually any location

• Built-in Smartcard/RF card module for added security or to facilitate 1:1 searches

• Auto-sensing – saving energy and reducing battery usage during power failures

• Voice prompting – easy operation for first time users

• High-performance processor

Main Features

• 1500 user and 1500 fingerprint template capacity

• Patented Virdi Fake Fingerprint Detection – can detect fingerprints made from paper, silicone, wax, etc

• IPX3 rating – IPX is an international waterproofing standard; it can be installed in virtually any location

• High-performance processor – fast operating and processing speeds

• Can operate in Standalone Mode or on a TCP/IP network,

RS485, Wiegand

• Built-in Smartcard/RF card module for added security or to facilitate 1:1 searches

• Auto-sensing – saving energy and reducing battery usage during power failures

Main Features

• 22 000-user and 22 000 fingerprint template capacity

• Patented Virdi Fake Fingerprint Detection – can detect fingerprints made from paper, silicone, wax, etc.

• Fast authentication speed (1:1 < 0.5 seconds; 1:N

[1000] <1 seconds)

• Can operate in a standalone mode or on a TCP/IP network, RS-232, RS-485, Wiegand

• Interphone integration for Visitor Control with enhanced security

• Access Control, Time & Attendance and Meal Control

Main Features

• IP65-rated Outdoor Fingerprint Reader – use in any environment

• 20 000 user and 20 000 fingerprint template storage capacity

• Patented Virdi Fake Fingerprint Detection – can detect fingerprints made from silicone, wax, etc.

• High-performance processor/CPU – fast operating and processing speeds

• Can operate in Standalone Mode or on a TCP/IP network, RS-232, RS-485, Wiegand

• Built-in Smartcard/RF card module for added security and to facilitate 1:1 searches

• Auto-sensing – saving energy and reducing battery usage during power failures

www.CentSys.com

biOMetric fiNGerPriNt readers

page 147

Virdi AC6000 High-End

Biometric Reader

Product Code: VIRDAC6000

This state-of-the-art terminal embraces the latest technology with a large, colour, touch-screen LCD, embedded digital camera and extremely fast processor.

Virdi USB Enrolment

Device

Biometric Reader

Product Code: VIRDFOHO2

Award-winning USB Fingerprint Reader with Live and Fake

Fingerprint Detection Technology incorporating an RFID

Reader.

Virdi ACF100

Biometric Reader

Product Code: VIRDACF100

The ACF100 is a robust access control terminal which is aesthetically pleasing and simple to install, configure and operate.

It is not only designed for access control applications, but for time and attendance monitoring as well. The ACF100 supports DDNS, which creates a secure link for each device to a central communication server. Simply put, this means that an ACF100 installed at a site on an ADSL network in New York can be controlled by a Smartphone in London on a 3G connection provided both devices are connected to the internet, without the need for a VPN (Virtual Private Network).

Main Features

• 100 000 user and 60 000 fingerprint template storage capacity

• Patented Virdi Fake Fingerprint Detection – can detect fingerprints made from silicone, wax, etc.

• 4.8” colour TFT LCD touch screen – intuitive user interface simplifies operation

• Embedded 1.3 megapixel camera – takes a photo at the time of each transaction for added security

• High quality sound

• Ultra-fast authentication speed (1:1 < 0.5 seconds, 1:N

[7000] < 1 seconds)

• USB memory slot for convenient configuration, firmware upgrades, Database backups, user info, etc

• Optional face detection

Main Features

• 125KHz Proximity Card and Fingerprint Enrolment Support

• Detecting fake fingerprint materials such as paper, file, silicon, rubber, etc.

• It is convenient to use as it does not require users to carry special tools for verification

• It is a high-tech fingerprint recognition system that uses fingerprints which carry - risk of replication or unauthorised use

• Uses 500DPI high-capacity fingerprint recognition sensors for fast and accurate verification

• Insert into PC’s USB terminal for easy recognition and installation

Virdi Template

Management Software

Biometric Software

Product Code: VIRDUNISTD

Sophisticated device and template management application with powerful access control functionality and optional Time &

Attendance and Meal Management modules.

Main Features

• Multiple terminal management

• Client/Server environment

• TCP/IP communication

• ERP and Groupware System Interface

• Firmware upgrade functionality

• Database backup

• Multi-language support

www.CentSys.com

Main Features

Mechanical Features

• IP65 degree of protection

• Die-cast aluminium housing

• Sapphire crystal (hardened) fingerprint sensor

• Battery backup

Electronic Features

• Fingerprint sensor with live and fake finger detection technology

• Integrated card reader (either 125KHz RFID or 13.65MHz

Mifare)

• 1000 user, fingerprint template and card capacity

• 1 000 000 transaction memory

• Embedded 1.3 megapixel camera

• Lock control (relay) via RS485 – built into the power supply

• Supports magnetic lock (EM), dead bolt and striker

• Standalone option – device managed by Smartphone

• Network option – connects to UNIS via LAN (wireless); device is managed by Server/PC

• Remote option – connects to DDNS server via internetenabled LAN (wireless); device is controlled by

Smartphone

• Can be used for both access control and Time &

Attendance

• Wi-fi Direct-enabled – does not require a separate wireless access point to connect to Smartphone

biOMetric fiNGerPriNt readers

page 149
