mikroProg for Tiva User Manual

mikroProg for Tiva User Manual
mikroProg
mikroProg™ is a fast USB programmer with hardware
Debugger support. Smart engineering allows mikroProg™
to support all Tiva™ and Stellaris® ARM® Cortex™-M3 and
Cortex™-M4 microcontrollers in a single programmer.
™
for Tiva™
TO OUR VALUED CUSTOMERS
I want to express my thanks to you for being interested in our products and for having
confidence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic products
and to constantly improve the performance thereof in order to better suit your needs.
Nebojsa Matic
General Manager
The Tiva™, ARM® and Windows® logos and product names are trademarks of Texas Instruments®, ARM® Holdings and Microsoft® in the USA. and other countries.
Table of Contents
Introduction to mikroProg™ 4
Key features
5
6. Connection schematic examples
Connecting with LM3SX00 series
14
15
1. Driver installation
6
Connecting with LM3S1000 series
16
step 1 – Start installation
7
Connecting with LM3S2000 series
17
step 2 – Accept EULA
7
Connecting with LM3S3000 series
18
step 3 – Installing the drivers
8
Connecting with LM3S5000 series
19
step 4 – Finish installation 8
Connecting with LM3S6000 series
20
9
Connecting with LM3S8000 series
21
3. mikroProg Suite™ for ARM® software
10
Connecting with LM3S9000 series
22
4. Connecting with a target device
12
Connecting with TM4C123 series
23
5. Connector Pinout
13
Connecting with TM4C129 series
24
2. Connecting to a PC
Page 3
Introduction to mikroProg™
mikroProg™ for Tiva™ is a fast programmer and hardware debugger. Smart engineering allows mikroProg™ to support all Tiva™ and
Stellaris® ARM® Cortex™-M3 and Cortex™ -M4 devices in a single programmer! Outstanding performance, easy operation, elegant design
and low price are it’s top features. It is supported in MikroElektronika ARM® compilers, as well as in other ARM® compilers.
Page 4
Key features
- Hardware Debugging
- No need for firmware update
- New microcontrollers supported via
latest version of mikroProg Suite™
for ARM® software
01
02
03
04
05
What you see
06
01 Flat cable
02 USB MINIB connector
03 DATA transfer indication LED
04 ACTIVE indication LED
05 LINK indication LED
06 POWER indication LED
Page 5
1. Driver installation
On-board mikroProg™ requires drivers in order to work. Drivers can be found on the link bellow:
http://www.mikroe.com/downloads/get/1810/mikroprog_tiva_drivers_v100.zip
When you download the drivers, please extract files from the ZIP archive. Folder with extracted files contains folders with drivers for
different operating systems. Depending on which operating system you use, choose adequate folder and open it.
In the opened folder you should be able
to locate the driver setup file. Double click
the setup file to begin installation of the
programmer drivers.
NOTE: Make sure to disconnect
mikroProg™ before installing drivers.
Page 6
step 1 – Start installation
step 2 – Accept EULA
02
01
01
03
In welcome screen click the Next> button
02 In order to proceed select I accept the this EULA
(End User License Agreement)
03 Click the Next> button
Page 7
step 3 – Installing the drivers
step 4 – Finish installation
04
05
05 Click the Finish button to end installation process
04 Drivers are installed automatically
Page 8
2. Connecting to a PC
After driver installation is complete, you can now connect the programmer with your PC using
USB cable provided with the package. Green POWER LED should turn ON, indicating the presence
of power supply. Amber-colored LINK LED will turn ON when link between mikroProg™ and PC is
established. Link can be established only when correct drivers are installed on your PC.
Page 9
3. mikroProg Suite™ for ARM® software
mikroProg™ for Tiva™ programmer requires special programming software called mikroProg
Suite™ for ARM®. This software is used for programming all Tiva™ and Stellaris® ARM® Cortex-M3™
and Cortex-M4™ microcontroller families. It features intuitive interface and SingleClick™
programming technology. Software installation is available on following link:
http://www.mikroe.com/downloads/get/1809/mikroprog_suite_for_arm.zip
After downloading, extract the package and double click the executable setup file to start installation.
Quick Guide
01
Click the Detect MCU button in order to recognize the device ID.
02
Click the Read button to read the entire microcontroller memory. You can click the Save button
to save it to the target HEX file.
03
If you want to write the HEX file into the microcontroller, first make sure to load the target HEX
file using the Load button. Then click the Write button to begin programming.
04
Click the Erase button to clear the microcontroller memory.
Page 10
Software installation wizard
01 Start Installation
02 Accept EULA and continue
03 Install for all users
04 Choose destination folder
05 Installation in progress
06 Finish installation
Page 11
4. Connecting with a target device
Figure 4-1:
IDC10 JTAG
connector
For connection with a target device mikroProg™ uses IDC10 JTAG connector, as shown on Figure 4-1. In order to make
proper connection with the target board it is necessary to pay attention to IDC10 connector pinout. Every pin has a
different purpose and for easy orientation IDC10 connector is marked with a little knob and incision between pins
number 9 and 7, Figure 5-1.
Page 12
5. Connector Pinout
01 VCC-3.3V - MCU power supply
03 GND - Ground
05 GND - Ground
09
10
07
08
05
06
03
04
01
02
07 N/C - Not Connected
09 GND - Ground
02 TMS - Mode Select
04 TCK - Clock
06 TDO - Data output
08 TDI - Data input
JTAG programming/
debugging lines
10 SRSTn - System Reset
Figure 5-1: Female connector pinout
Page 13
6. Connection schematic examples
Following examples demonstrate connections with some of the most popular supported microcontrollers. Each
one is carefully selected as a representative of the entire family. All MCUs use TMS, TCK, TDO, TDI and SRSTn lines
for programming. These lines are located on same microcontroller pins within a family.
