Automotive

Infotainment Guide

Audio

Data Converters

Embedded Processors

Interface

Microcontrollers

Power Management

Wireless Connectivity

www.ti.com/automotive 2014

Automotive Infotainment Guide

Table of Contents

Texas Instruments Commitment to Transportation

Texas Instruments (TI) is committed to providing innovative automotive technologies that make safer, greener and more enjoyable driving experiences. With deep understanding and expertise in analog and embedded processing, Texas Instruments provides a rich portfolio for the automotive/ transportation space. TI is committed to providing superior cost-effective solutions to the transportation market along with benchmark service in terms of excellent product documentation, on-time delivery and conformance to specifications.

TI makes it possible to achieve the quality, reliability and cost goals needed to succeed in today’s marketplace. TI enables customers to innovate and be safer, greener, more fun.

Automotive Qualified Products (Q1)

TI’s automotive qualified products are indicated by the Q1 suffix. The Q1 indicates that a product has met TI’s stringent automotive standards and includes:

• 180-day product change notification from final notice

• Extended temperature qualification

• Automotive documentation service

• Target zero defects

Table of Contents

3 Introduction

4 Design Considerations

6

6

7

7

7

7

7

Data Converters/Audio

5 Automotive Data Converters/Audio Solutions

6 Audio ADCs

Class-D Audio Amplifiers

Audio CODECs

Audio DACs

Sample Rate Converters

Digital Audio Receivers

Digital Audio Processors

Touch Screen Controllers

Interface

8 Automotive Interface Solutions

9 FPD Link II & III Ser/Des

9

9

9

9

10

10

10

10

LVDS

CAN Transceivers

LIN Transceivers

Analog Switches

ESD Protection

Voltage Level Translators

Thermal Management

Clocks

Microcontrollers/Embedded Processors

11 Automotive Microcontrollers/Embedded Processor Solutions

12 Automotive Infotainment Processors

Power Management

13 Automotive Power Solutions

14 LDOs

15

17

17

17

18

18

18

DC/DC Conrollers & Converters

Integrated Power Management ICs

LCD/LED Display

Motor Drivers for Flip-Up Display

High Side Switches (Load Switches)

PWM Power Supply Controllers

Sequencer

Wireless Connectivity

19 Automotive Wireless Connectivity Solutions

WW Technical Support

2

|

Automotive Infotainment Guide 2014

Texas Instruments

Automotive Infotainment Guide

Introduction

With the race to deliver the best features in new cars escalating, the infotainment system is now a key focus in the automotive design process. To support the growing importance of infotainment,

Texas Instruments offers a strong portfolio and design support. TI’s broad analog and digital embedded and applications processing portfolio provides improved audio quality and system speed, efficient power management and low power consumption for applications such as car audio, navigation systems, power supply, as well as in-car and personal entertainment.

Infotainment systems combine entertainment, multi-media and driver information functions in one module.

They offer AM/FM or satellite radio,

DC/DVD player for music and video, navigation system, data and multi- media ports (USB,

Bluetooth, line in, line out, video in) as well as general and vehicle status information.

Power management: The power supply is connected to the 12V or 24V board net and regulates down/up to voltages for DSP, uC, memory and ICs and functions in the infotainment system.

In some cases there may be 10 or more different power rails, making the design of the power supply a critical task when trying to design for size, cost and efficiency.

Linear regulators with low quiescent current help reduce battery leakage current during standby operating modes (ignition off), are load dump voltage tolerant for direct battery devices, and need low drop-out and tracking for low battery crank operation.

Beyond providing increased conversion efficiencies, switching power supplies provide EMI improvement with slew rate control of the switching FET, frequency hopping, spread spectrum or triangulation method for attenuation of peak spectral energy, low Iq, soft start for power sequencing and in rush current limitation, phased switching for multiple SMPS’s regulators to minimize input ripple current and lower input capacitance, higher switching frequency for smaller components

(L and C’s), and SVS functions for brown out indications

WiLink™

Wi-Fi, GPS, BT

PCMxxxx

Audio DAC

Amp

AM/FM/DAB

AFE

TPV51xx

Video

Decoder

TMP/LM

Thermal Mgmt media

Ethernet

TPD4E05U06

ESD

Protection

TPD4E001-Q1

ESD

Protection

USB, HDMI, dock, line in

DP83848Q

10/100 PHY

CAN

HVDA54x

CAN XCVR power supply

– +

HV DC/DC up to 100V

Jacinto

SoC

Clock

Generator

DS90UH9xx

Serializer

LV DC/DC

<28V eCall subsystem

HDD/

SDD

LDO

SOS backup battery bQ240xxx

Charger

TPS65xxx

PMU/PMIC

Controller &

Multi-Rail

Power

Signal Chain

Connectivity

Processor to other subsystem

TPS/LM

DC/DC

DS90UH9xx

FPD-Link III

Deserializer white balancing dithering

PCMxxxx

Audio DAC

Timing

Controller

Amp

HVDA54x

CAN XCVR

TMS470/570

MCU

TMP/LM

Thermal Mgmt

TSC20xx

Touch Ctrl

LCD

Touchscreen

DRVxxxx

Haptic Driver

OPT30xx

ALS ambient light

LM34/LP8xx

Backlight

TPS651xx

Bias Supply

DLP

®

Technology

Free Shape

Interactive Display (ID)

Automotive infotainment block diagram.

Texas Instruments

Automotive Infotainment Guide 2014

|

3

Automotive Infotainment Guide

Design Considerations

Bi-directional FPD-Link III embedded clock Ser/Des with ultra-low EMI signaling integrate data, clock, and real-time control over a single twisted wire pair.

Communication interfaces allow data exchange between independent electronic modules in the car, the remote sub modules of the infotainment system as well as external devices like USB memory or video sources.

High Speed CAN (up to 1Mbps, ISO

119898) is a two wire, fault tolerant differential bus. With a wide input common mode range and differential signal technology it serves as the main vehicle bus type for connecting the various electronic modules in the car with each other. LIN supports low speed (up to 20 kbps) single bus wire networks, primarily used to communicate with remote sub functions of the infotainment system. LVDS interfaces are used to transfer large amounts of data (e.g. HD video data) via a high speed serial connection to an external location like a video screen.

The Audio input front end and audio output is often combined into a single

Codec. The Audio line level input from the source is converted into digital samples by the ADC and feed to the system’s DSP. On the output side.

ADCs convert the digital output an analog signal, which is amplified to the levels needed by the speakers or headphones used with the system.

By using Class-D amplifiers the system’s power efficiency can exceed

90% while maintaining low THD. This improved efficiency leads to significant size, weight and heat reductions. TI’s class-D car audio solutions exhibit extremely low EMI levels and are being used in OEM systems with stringent

EMC requirements.

The audio DSP performs I/Q demodulation and outputs digital audio and data. This includes functions like volume, treble, bass and sound effects, as well as more sophisticated features like mixing input channels and digitally process multiple channels, performing sound effects processing such as Dolby

®

Pro Logic

®

II, SRS

®

Circle Surround™ II, TruSound and other audio algorithms. The uC +

DSP controls the user interface, bus interface, and network interface as well as GPS navigation and touch screen control. It is also used to process and output video data from multiple sources.

Wireless connectivity: For multimedia streaming, hands-free calling and

A2DP stereo with easy pairing, a highly integrated combination chip that enables Wi-Fi®, Bluetooth®, and GPS/

GLONASS is connected to the host processor.

4

|

Automotive Infotainment Guide 2014

Texas Instruments

Data Converters/Audio

Automotive Data Converters/Audio Solutions

Very Low-Power Stereo Audio CODEC with miniDSP and PowerTune™ Technology

TLV320AIC3254-Q1

The TLV320AIC3254-Q1 (also called the AIC3254- Q1) is a flexible, low-power, low-voltage stereo audio codec with programmable inputs and outputs, PowerTune capabilities, fully-programmable miniDSP, fixed predefined and customizable signal processing blocks, integrated PLL, integrated LDOs and flexible digital interfaces making it ideal for Automotive Applications such as Car Radio and Infotainment.

The TLV320AIC3254-Q1 features two fully-programmable miniDSP cores that support application-specific algorithms in the record and/or the playback path of the device. The miniDSP cores are fully software controlled. Target algorithms, like active noise cancellation, acoustic echo cancellation or advanced DSP filtering are loaded into the device after power-up. It also includes a digitally-controlled stereo microphone preamplifier and integrated microphone bias.

To ease system-level design, LDOs are integrated to generate the appropriate analog or digital supply from input voltages ranging from 1.8V to 3.6V. Digital IO voltages are supported in the range of 1.1V–3.6V.

The device is available in the 5-mm × 5-mm, 32-pin QFN package that is qualified per AEC-Q100 guidelines and supports Grade 3: –40°C to 85°C ambient operating temperature range.

Key Features

• Stereo audio DAC with 100 dB SNR

• 4.1 mW stereo 48 ksps DAC playback

• Stereo audio ADC with 93 dB SNR

• Extensive signal processing options

• Embedded miniDSP

• Six single-ended or three fullydifferential analog Inputs

• Stereo analog and digital microphone inputs

• Stereo headphone outputs

• Stereo line outputs

• Very low-noise PGA

• Low power analog bypass mode

• Programmable microphone bias

• Programmable PLL

• Integrated LDO

I2S

OMAP35xx

DM3xx

I2C

Application Processor

TLV320AIC3254

Speaker Amplifier

TPA201xD1

TPS201xD2

Earbud/Microphone

Combo

Audio CODEC block diagram.

Learn more at:

www.ti.com/

tlv320aic3254-q1

Texas Instruments

Automotive Infotainment Guide 2014

|

5

Data Converters/Audio

Component Recommendations

Audio ADCs

Device

ADS5204-Q1

Product Description

Dual, 10-Bit, 40 MSPS Low-Power ADC with PGA

PCM5100A-Q1

2VRMS DirectPath™, 112/106/100dB Audio Stereo DAC with 32-bit, 384kHz

PCM Interface

TLC2543-Q1

TLV1548-Q1

TLV5535-Q1

12-Bit ADC with Serial Control and 11 Analog Inputs

Low-Voltage, 10-Bit ADC with Serial Control and

8 Analog Inputs

8-Bit, 35-MSPS ADC, Single-Channel and Low Power

Key Specifications

10-Bit, 40 MSPS,Pipeline, 275mW, 60.5-dB SNR, ENOB = 9.7, 2 Input Channels

Audio DAC + Support Circuitry in One Monolithic IC; Market-Leading Low Out-of-

Band Noise; No DC Blocking Capacitors Required; Intelligent Muting System; Soft

Up or Down Ramp and Analog Mute (AMUTE) for 120-dB Mute; Signal-To-Noise

Ratio (SNR) with Popless Operation; Integrated High-Performance Audio Phased-

Locked Loop (PLL); Supports 1.8-V Digital Input Interface

12-Bit, 66 kSPS, SAR, 5mW, 10-μs Conversion Time Over Operating Temperature,

±1 LSB (max)

2.7-V to 5.5-V Supply, 10-Bit, 85 kSPS, SAR,

Conversion Time ≤ 10 μs

Meets AEC-Q100-011 C3A CDM Classification,

3.3-V Single Supply, 8-Bit, 35 MSPS

Class-D Audio Amplifiers

Device Product Description

TAS5414B-Q1

TAS5424B-Q1

TAS5414C-Q1

TAS5514B-Q1

TPA3112D1-Q1

4-Channel Automotive Audio Amplifier with Single-Ended Inputs

4-Channel Automotive Audio Amplifier with Differential Inputs

4-Channel Automotive Audio Amplifier with Single-Ended Inputs

4-Channel Automotive Digital Amplifier, Stand Alone Version

Automotive Catalog, 25-W Filter-Free Mono Class-D Audio Amplifier with SpeakerGuard

Key Specifications

8Four-Channel Digital Power Amplifier; Four Analog Inputs, Four BTL Power

Outputs; Typical Output Power at 10% THD+N; 28 W/Ch Into 4 Ω at 14.4 V; 50 W/

Ch Into 2 Ω at 14.4 V; THD+N < 0.02%, 1 kHz, 1 W Into 4 Ω; Patented Pop- and

Click-Reduction Technology; Load Diagnostic Functions

Four-Channel Digital Power Amplifier; Four Analog Inputs, Four BTL Power

Outputs; Typical Output Power at 10% THD+N

28 W/Ch Into 4 Ω at 14.4 V; 50 W/Ch Into 2 Ω at 14.4 V; THD+N < 0.02%, 1 kHz,

1 W Into 4 Ω; Patented Pop- and Click-Reduction Technology; Load Diagnostic

Functions

Four-Channel Digital Power Amplifier; Four Analog Inputs, Four BTL Power

Outputs; Typical Output Power at 10% THD+N

28 W/Ch Into 4 Ω at 14.4 V; 50 W/Ch Into 2 Ω at 14.4 V; THD+N < 0.02%, 1 kHz,

1 W Into 4 Ω; Patented Pop- and Click-Reduction Technology; Load Diagnostic

Functions

Four Channels at 23 W Continuously into 4 Ω at Less than 1% THD+N from a

14.4-V Supply; Channels Deliver 38 W into 2 Ω at 1% THD+N Each

20-W into an 4-Ω Load at 10% THD+N From a 12-V Supply; 94% Efficient

Class-D Operation into 8-Ω Load eliminates Need for Heat Sinks; Wide Supply

Voltage Range Allows Operation from 8 to 26 V; Differential Inputs

Audio Codecs

Device

TWL1103T-Q1

Product Description

Voice-Band Audio Processor (VBAP)

TLV320AIC3104-Q1

TLV320AIC3254-Q1

PCM3168-Q1

Automotive Catalog Low-Power Stereo CODEC with 6 Inputs, 6 Outputs,

HP Amp and Enhanced Digital Effects

Automotive Catalog, Very Low-Power Stereo Audio CODEC with miniDSP and

Power Tune

TM

Technology

24-Bit Multi-Channel Audio CODEC 6ch-in/8ch-out with 96/192kHz

Sampling Rate

Key Specifications

2.7-V Operation, On-Chip I2C Bus, ESD Protection Exceeds 2 kV, Transmit and

Receive Filtering for Voice-Band Communications Systems

2-ADC (92dB SNR), 2-DAC (102dB SNR), 6in, 6out, 96Khz Sampling, Low Power,

Analog Bypass, Programmable PLL, I2C Digital Interface, Supports L, R, I2S, DSP,

TDM Audio Formats

Stereo Audio DAC with 100dB SNR; Stereo Audio ADC with 93dB SNR; Embedded miniDSP; Programmable PLL; Integrated LDO

24-Bit, 6-ADC (107dB SNR), 8-DAC (112dB SNR), SPI or I2C Digital Interface,

Supports R, L, I2S, TDM, DSP Audio Formats

6

|

Automotive Infotainment Guide 2014

Texas Instruments

Data Converters/Audio

Component Recommendations

Audio DACs

Device

PCM1681-Q1

PCM1690-Q1

PCM5102-Q1

PCM1753-Q1

PCM1754-Q1

105-dB, 8-Channel, TDM DAC

Product Description

Automotive Catalog 113dB SNR 8-Channel Audio DAC with Differential Outputs

Automotive Catalog 112dB Stereo DAC with 2VRMS Output and

Integrated Audio PLL

Automotive Catalog 106dB SNR Stereo DAC (S/W Control)

Automotive Catalog 106dB SNR Stereo DAC (H/W Control)

TLV320DAC3100-Q1

Low-Power Stereo Audio DAC With Audio Processing

Key Specifications

24-Bit, 192-kHz, 8-Channel Audio DAC, D-Range/SNR: 105 dB, 3-Way Control

Interface (SPI/I2C/HW)

24-Bit, 192-kHz, 8-Channel Audio DAC, D-Range/SNR: 113 dB, L,R,I2S,TDM,DSP

Audio Interfaces, Analog Mute

32-Bit, 384-kHz, 2-Channel Audio Delta Sigma DAC, 112 dB SNR, HW Control

Interface, Integrated PLL, Under Voltage Protection, Intelligent Muting

24-Bit, 192-kHz, 2-Channel Audio Delta Sigma DAC, D-Range/SNR: 106 dB,

Control Interface (SPI)

24-Bit, 192-kHz, 2-Channel Audio Delta Sigma DAC, D-Range/SNR: 106 dB,

Control Interface (H/W)

Stereo Audio DAC with 95-dB SNR; Supports 8-kHz to 192-kHz Sample Rates;

Mono Class-D BTL Speaker Driver

(2.5 W Into 4-Ω or 1.6 W Into 8-Ω); Stereo Headphone/Lineout and Mono Class-D;

Microphone Bias

Sample Rate Converters

Device

SRC4190-Q1

Product Description

Automotive Catalog 192kHz Stereo Asynchronous Sample Rate Converters

Digital Audio Receivers

Device

DIR9001-Q1

Product Description

96-kHz Digital Audio Interface Receiver

Key Specifications

28-kHz to 108-kHz Sample Frequency, Low Clock Jitter: 50ps (typ), 100ps (max),

3.3-V, Single Supply, 5-V, Tolerant Digital Input

Digital Audio Processors

Device

DA710

DA70x

DA830

DA828

DA810

DA808

DA807

DA805

DA804/2

Product Description Key Specifications

DSPs for Multi-Channel, Multi-Zone Decode Applications

DSPs for Multi-Channel, Multi-Zone Decode Applications

DSPs for Multi-Channel, Multi-Zone Decode Applications with

Integrated ARM and Additional Connectivity

DSPs for Multi-Channel/Zone Decode Applications with Integrated ARM

Fixed and Floating Point,, 256 BGA, up to 300MHz, SDRAM

Floating Point, 144 QFP, up to 250MHz, SDRAM

Fixed and Floating Point,, 250 BGA, up to 300MHz DSP + ARM, SDRAM

Fixed and Floating Point,, 176 QFP, up to 400MHz DSP + ARM, SDRAM

DSPs for Multi-Channel/Zone Decode Applications with Additional Connectivity Fixed and Floating Point,, 256 BGA, up to 400MHz, SDRAM

SPs for Multi-Channel, Multi-Zone Decode Applications with

Additional Connectivity

Fixed and Floating Point,, 176 QFP, up to 400MHz, SDRAM

DSPs for Multi-Channel, Multi-Zone Decode Applications with

Additional Connectivity

DSPs for Multi-Channel, Multi-Zone Decode Applications with

Additional Connectivity

DSPs for Multi-Channel, Multi-Zone Decode Applications with

Additional Connectivity

Fixed and Floating Point,, 176 QFP, up to 266MHz, SDRAM

Fixed and Floating Point,, 176 QFP, up to 266MHz

Fixed and Floating Point,, 80 QFP, up to 250 MHz

Touch Screen Controllers

Device

TSC2008-Q1

TSC2007-Q1

Product Description

Automotive Catalog Nano-Power Touch Screen Controller with SPI

Automotive Catalog Nano-Power Touch Screen Controller with I2C

Key Specifications

2-Channel, 212 kHz Sampling, 128 dB Dynamic Range, 3.3V Supply, Normal, I2S,

TDM Audio Interface

Key Specifications

Single 1.2V to 3.6V Supply, Low Power: (12 bit), Enhanced IEC ESD Protection

25kV Air - 15kV Contact, On-Chip Temperature Measurement, Auxiliary Input,

Touch Pressure Measurement

Single 1.2V to 3.6V Supply (No Separate I/O Supply), 22k/11kSPS

Throughput in High-Speed Mode (3.4MHz), High-Speed I2C Serial Interface,

12- or 8-Bit Resolution Mode, On-Chip Temperature Measurement, Touch

Pressure Measurement, Enhanced IEC ESD Protection 25kV Air - 15kV Contact

Texas Instruments

Automotive Infotainment Guide 2014

|

7

Interface

Automotive Interface Solutions

FPD-Link III Ser/Des

DS90UH925/6Q

The DS90UH925Q serializer, in conjunction with the DS90UH926Q deserializer, provides a solution for secure distribution of content-protected digital video within automotive entertainment systems. This chipset translates a parallel RGB Video

Interface into a single pair high-speed serialized interface. The digital video data is protected using the industry standard high bandwidth digital content protection

(HDCP) copy protection scheme, enabling playback of content-protected media.

The serial bus scheme, FPD-Link III, supports video and audio data transmission and full duplex control including I2C communication over a single differential link.

Consolidation of video data and control over a single differential pair reduces the interconnect size and weight, while also eliminating skew issues and simplifying system design.

Automotive Head Unit

24 Bit Video

I 2 S Audio

Graphics

Processor

I 2 C Control

Pixel Clock

DS90UH925

Serializer

HDCP

Encryption

HD Content

Video, Audio,

Bidirectional Control, and Key Exchange

DS90UH926

Deserializer

HDCP

Decryption

24 Bit Video

Pixel Clock

I 2 C Control

LCD Display

WQVGA to 720p

I 2 S Audio

Audio

DAC

Audio

Amp

Automotive infotainment block diagram.

Automotive Display

Key Features

• Integrated HDCP cipher engine with on-chip key storage

• Bidirectional control interface channel interface with I2C compatible serial control bus

• Supports high definition 720 pixels digital video format

• RGB888 + VS, HS, DE and synchronized I2S audio supported

• 5 to 85-MHz PCLK supports high definition resolutions, dual-view displays and 24-bit color depth

• Single 3.3-V operation with 1.8-V or 3.3-V compatible LVCMOS I/O interface

• AC-coupled STP interconnect up to

10 meters

• Parallel LVCMOS video inputs

• I2C compatible serial control bus for configuration (DS90UH926Q)

• DC-balanced & scrambled data with embedded clock simplifies interconnects and reduces the number of cables and connectors

• Adaptive cable equalization

(DS90UH926Q)

• HDCP content protected

• Supports HDCP repeater application

• @ SPEED link BIST mode and LOCK status pin (DS90UH926Q)

• EMI minimization (SSCG and EPTO)

(DS90UH926Q)

• Image Enhancement (white balance and dithering) and internal pattern generation

• Low power modes minimize power dissipation

• Automotive grade product:

AEC-Q100 grade two qualified

• >8-kV HBM and ISO 10605 ESD rating

• Backward compatible modes

Learn more at:

www.ti.com/

ds90uh925-6q

8

|

Automotive Infotainment Guide 2014

Texas Instruments

Interface

Component Recommendations

FPD-Link II & III Ser/Des

Device Application(s) Parallel Data

FPD-Link III with Embedded Bidirectional Control Bus

DS90UH925/6

Display 24 (27) CMOS

Pixel Clock

5 to 85 MHz

DS90UB925/6

Display

DS90UB913/4

DS90UB903/4

DS90UB901/2

FPD-Link II

Camera

Display

Camera

DS90UR910

DS90UR907/8

DS90UR905/6/16

DS90UR903/4

DS99R421/124

Display, Camera

Display

Display

Display

Display

DS90UR241/124

Display, Camera

DS90C241/124

Display, Camera

LVDS

Device

SN65LVDS051-Q1

SN65LVDM050-Q1

SN65LVDM051-Q1

25 (27) CMOS 6 to 85 MHz

10 or 12 CMOS 10 to 100 MHz

18 (21) CMOS

14 (16) CMOS

10 to 43 MHz

10 to 43 MHz

CSI-2

4 LVDS

24 (27) CMOS

18 (21) CMOS

3 LVDS

24 CMOS

24 CMOS

10 to 65 MHz

5 to 65 MHz

6 to 65 MHz

10 to 43 MHz

5 to 43 MHz

5 to 43 MHz

5 to 35 MHz

Product Description

Dual, High-Speed LVDS Transmitter/Receiver

Dual, High-Speed LVDS Transmitter/Receiver

Dual, High-Speed LVDS Transmitter/Receiver

Equalization

Adaptive

Adaptive

Adaptive

Y

Y

Y

Y

Y

Y

Y

SN65LVDS84A-Q1

SN65LVDS86A-Q1

FlatLink

TM

Transmitter

FlatLink

TM

Receiver

Spread

Spectrum

Y

Y

Y

Y

Y

Y

Y

Y

Y

Other Features

HDCP, Repeater, I2S Audio,

White Balance, Dithering

Repeater, I2S Audio,

White Balance, Dithering

2:1 Input Mux

White Balance, Dithering

ESD

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

8 kV HBM, ISO 10605

Key Specifications

Single 3.3-V Supply, Meets ANSI TIA/EIA-644-1995 Standard,

Signaling Rates up to 400 Mbps

Single 3.3-V Supply, Signaling Rates up to 500 Mbps

Single 3.3-V Supply, Signaling Rates up to 500 Mbps, TIA/EIA-644

Standard Compliant Devices

3.3-V Supply Voltage, 197-Mbps Data Rate, Very Low EMI, 21 Data Channels

Plus Clock-In Low-Voltage TTL Inputs and 3 Data Channels Plus Clock-Out

Low-Voltage Differential Signaling (LVDS) Outputs

21 inputs, 163 MBs

CAN Transceivers

Device Product Description

SN65HVDA1040A-Q1

5 V High Speed CAN Transceiver

SN65HVDA1050A-Q1

5 V High Speed CAN Transceiver

SN65HVDA54x-Q1

Family

5 V High Speed CAN Transceivers (HVDA540, HVDA541, HVDA542)

SN65HVDA54x5-Q1

Family

5 V High Speed CAN Transceivers (HVDA540-5, HVDA541-5, HVDA542-5)

SN65HVDA55x Family

5 V High Speed CAN Transceivers (HVDA551, HVDA553)

Key Specifications

Low-Power Standby Mode with Wake, Common Mode Bus Stabilization Output

Silent Mode, Common Mode Bus Stabilization Output

I/O Level Shifting (All), Low-Power Standby Mode (540), Low-Power Standby

Mode with Wake (541), and Silent Mode (542)

Low-Power Standby Mode (540-5), Low-Power Standby Mode with

Wake (541-5), and Silent Mode (542-5)

Enhanced ESD and Transient Protection, Low-Power Standby Mode with

Wake, I/O Level Shifting (551), Common Mode Bus Stabilization Output (553)

LIN Transceivers

Device

TPIC1021A-Q1

SN65HVDA100-Q1

LIN Transceiver

LIN Transceiver

Product Description Key Specifications

LIN Specifiation 2.0 Compliant, 5V or 3.3V I/O Support, up to 20kbps,

Low Current Consumption

LIN Specifiation 2.0 Compliant, Extended Operation with Supply from

5V to 27V DC, External Wakeup Pin

Analog Switches

Device

CD74HC4051-Q1

CD74HCT4067-Q1

SN74HC4851-Q1

SN74HC4852-Q1

Product Description Key Specifications

High-Speed, CMOS Logic, Analog Multiplexers/Demultiplexers

2-V to 6-V Supply Voltage, High-Noise Immunity NIL = 30%,

NIH = 30% of VCC, VCC = 5V

High Speed CMOS 16-Channel Analog Multiplexer/Demultiplexer with TTL Inputs 4.5-5.5V Supply, Low Power Consumption, Low 70Ω On Resistance

8-Channel, Analog Multiplexer/Demultiplexer with Injection-Current Effect Control 2-V to 6-V VCC Supply, 2 to 6 Node Voltage, Low Crosstalk Between Switches

Dual, 4-to-1 Channel, Analog Multiplexer/Demultiplexer with Injection-Current

Effect Control

2-V to 6-V VCC Supply, Injection-Current Cross Coupling<1 mV/mA, ICC 10 μA

Texas Instruments

Automotive Infotainment Guide 2014

|

9

Interface

Component Recommendations

ESD Protection

Device

TPD4E001-Q1

TPD2E001-Q1

Product Description

Ideal for Automotive Infotainment: Dual

USB2.0, Ethernet, and LVDS

Ideal for Automotive Infotainment: Single USB2.0

TPD4E05U06-Q1

TPD2E2U18-Q1

TPD3S714-Q1

Key Specifications

4-Channel, 1.5pF, ESD Protection, 15kV IEC Air Gap, 8kV IEC Contact

2-Channel, 1.5pF, ESD Protection, 15kV IEC Air Gap, 8kV IEC Contact

Ideal for Automotive Infotainment: USB3.0 and HDMI 4-Channel, 0.5pF, ESD Protection, 15kV IEC Air Gap, 12kV IEC Contact

Ideal for Automotive Infotainment: High Voltage ESD Protection for Single

USB2.0, Ethernet, and LVDS

Ideal for Automotive Infotainment: USB Interface Protection with Short-to-Battery and Short-to-Ground Protection

2-Channel, 2pF, 18VRWM, ESD Protection, 15kV IEC Air Gap, 8kV IEC Contact

3-Channel, 18VRWM, Short-to-Battery and Short-to-Ground Protection,

ESD Protection, 15kV IEC Air Gap, 8kV IEC Contact

Preview products ar elisted in bold blue.

Voltage Level Translators

Device

SN74AVC4T245-Q1

SN74AVC8T245-Q1

Product Description

4-Bit Dual-Supply Bus Transceiver With Configurable Voltage Translation

8-Bit Dual-Supply Bus Transceiver With Configurable Voltage Translation

SN74AVC16T245-Q1

16-Bit Dual-Supply Bus Transceiver With Configurable Voltage Translation

TXB0104-Q1

TXB0106-Q1

4-Bit Bidirectional Voltage-Level Translator with Auto Direction Sensing

6-Bit Bidirectional Voltage-Level Translator with Auto Direction Sensing

Key Specifications

4-Bit, 1.2-3.6V, 380Mbps, ICC 16 μA, Output Enable Pin

8-Bit, 1.2-3.6V, 320Mbps, ICC 25 μA, Output Enable Pin

16-Bit, 1.2-3.6V, 380Mbps, ICC 60 μA, Output Enable Pin

4-Bit, 1.2-3.6V on Port A, 1.65-5.5V on Port B, 100Mbps

6-Bit, 1.2-3.6V on Port A, 1.65-5.5V on Port B, 100Mbps

Thermal Management

Device

TMP101-Q1

TMP102-Q1

TMP411-Q1

TMP451-Q1

LM60-Q1

LM26LV-Q1

TMP300-Q1

TMP302-Q1

INA210-214-Q1

INA220B-Q1

Product Description Key Specifications

Digital Temperature Sensor with I2C Serial Interface, Prog. Thermostat/Alarm

Func

±3°C MAX Accuracy, Alert Function, IQ=75µA MAX, I2C Interface to MCU, SOT-23

Package

Low Power Digital Temperature Sensor with SMBus/Two-Wire Serial Interface in

SOT563

±3°C MAX Accuracy, Alert Function, IQ=10µA MAX, I2C Interface to MCU, 1.6mm x 1.6mm SOT-563 Package

+/-1degC Remote and Local Digital Temperature Sensor with N-Factor and Series

Resistance Correction

Local=±1°C MAX Accuracy, Remote=±1°C MAX Accuracy, Dual Alert Functions,

IQ=475µA MAX, I2C Interface to MCU

1.8V Supply Remote and Local Digital Temperature Sensor with N-Factor and

Series Resistance Correction

Local=±1°C MAX Accuracy, Remote=±1°C MAX Accuracy, Dual Alert Functions,

IQ=250µA MAX, I2C Interface to MCU

Analog Temperature Sensor with 2.7V Supply ±3°C MAX Accuracy, Gain=6.25mV/°C, IQ=130µA MAX

1.6 V, LLP-6 Factory Preset Temperature Switch and Temperature Sensor

1.8V, Resistor-Programmable Temperature Switch and Analog Out

Temperature Sensor

Low Power, 1.4V Temperature Switch in SOT563

Analog Voltage Output, High/Low-Side Measurement, Bi-Directional Zero-Drift

Series Current Shunt Monitor

Bi-Directional Current/Power Monitor With I2C Interface

Local Sensor=±2.3°C MAX Accuracy

Switch: Factory Preset Trip Point, ±2.3°C MAX Accuracy

Local Sensor=±5°C MAX Accuracy

Switch: Resitor Programmed Trip Point, ±6°C MAX Accuracy

16 Pin-Selectable Trip Points, Trip Point Accuracy=±2°C MAX from +40°C to

+125°C, IQ=15µA MAX, SOT563 PACKAGE: 1.6mmx1.6mm SOT563 Package

Gain Options of 50, 100, 200, 500, & 1000 V/V, VOS=35µV (Gain of 200-1000)

MAX, IQ=115µA MAX, -0.3V to +26V Cpmmon Mode Voltage Range

Current, Volatge, or Power Output, VOS=50µV MAX, 0V to +26V Common Mode

Voltage Range, I2C Interface to MCU

Preview products ar elisted in bold blue.

Clocks

Device

CDCE937-Q1

CDCE949-Q1

CDCS503-Q1

CDCVF2505-Q1

Product Description

3-PLL, Integrated VCXO, Spread Spectrum Clocking, 2.5V or 3.3V LVCMOS

Outputs

4-PLL, Integrated VCXO, Spread Spectrum Clocking, 2.5V or 3.3V LVCMOS

Outputs

Spread Spectrum Clock Generator

3.3V PLL Clock Driver for General Purpose & SDRAM Apps, w/Spread Spectrum

Clock Compatibility

Key Specifications

Low Jitter of 60ps Peak to Peak Period, EEPROM/I2C/Pin Programming, XTAL or

LVCMOS Input, Integrated on-chip VCXO with External XTAP, 7 LVCMOS Outputs

Low Jitter of 60ps Peak to Peak Period, EEPROM/I2C/Pin Programming, XTAL or

LVCMOS Input, Integrated On-Chip VCXO with External XTAP, 9 LVCMOS Outputs

Up to +/-2% Spread Spectrum Clocking to Reduce EMI, Pin Programmable, 1

LVCMOS Input and Output, Single 3.3V supply

24M to 200MHz Operating Frequency, <150ps Cycle-to-Cycle Jitter, <150ps

Propagation Delay, on-Chip Series Damping Resistor, Automatic Input Clock

Detector

10

|

Automotive Infotainment Guide 2014

Texas Instruments

Microcontrollers/Embedded Processors

Automotive Microcontroller/Embedded Processor Solutions

Automotive Infotainment Processors

Texas Instruments provides full system solutions for connected automotive infotainment. Our unparalleled solutions combine industry-leading hardware and solutions with a comprehensive software ecosystem. Automotive infotainment processors enable cost-effective, scalable, and feature-rich automotive applications such as automotive infotainment head units and rear-seat entertainment systems with solutions that smartly integrate industry-leading

ARM

®

cores, graphics accelerators, software-defined radio, speech recognition, high-definition video, and both wired and wireless connectivity, as well as the right mix of peripherals for automotive use cases.

TI provides processor technology leadership, complete bills of materials that are optimized for innovative automotive capabilities, and full solution interoperability. TI further demonstrates its commitment to quality by pursuing applicable automotive qualifications for its parts and has a zero-DPPM strategy.

ARM A15

ARM A15

ARM M4

ARM M4

Shared L2

*

<<

-

+

C66x DSP

DSP L2

High-Speed Interconnect

1080p60 Video

Acceleration

On Chip Memory Controller

Graphics Acceleration

3D GPU

SGX544MP2

2D GPU

GC320

L3 RAM w/ECC

Radio Acceleration

DDR2/3 32b DDR2/3 32b

EDMA

MMU Mailbox RTC

System Services

PWM WDT

2 Video Input

Ports

Keyboard

Controller

Display Subsystem

LCD

HDMI 1.4a

1080p

Blend/Scale/Convert

GPIO Spinlock Timer

Vehicle Connectivity

PCIe eAVB

USB2

MLB DCAN USB3

Serial Connectivity

McSPI

HDQ

McASP

UART QSPI I2C

Functional block diagram.

Storage Connectivity

SATA

MMC/

SD

NAND/

NOR

DMM

Key Features

• 45–nanometer CMOS process for maximum system performance and low power

• ARM

®

Cortex™-A8 Core

Up to 800 MHz

VFPv3 floating point

• DSP Core: C674x™

Up to 570 MHz

Floating point extension

• 3D Graphics accelerator

Up to 250 MHz

~23M polygons/sec

• IVA-HD Video co-processor – 1080-p video encode/decode support

• Two ARM

®

Cortex™-M3 cores

200 MHz

• Highly flexible display subsystem

Multiple video/graphics pipelines

Flexible video processing

Multiple simultaneous display outputs

• Other peripheral highlights

(1.8/ 3.3-V IOs)

Multiple configurable video input ports

Multiple USB 2.0 ports with PHY,

MMC/SD, and NAND/Async interface support

Vehicle peripherals: MOST MLB

150, PCIe, 10/100/1000 Ethernet

AVB w/ optional 2 port switch,

PATA, SATA, multiple CAN, Audio serial ports, SPI, UART, and I2C ports

EMIF: two 32-bit wide DDR2/3

@333MHz

Optional security features

• Power (1.1-V/1.2-V Core, 1.8-V/3.3-V

IOs): Support for dynamic voltage scaling and SmartReflex™ technology for power/performance management

Learn more at:

www.ti.com/solution/

automotive_infotainment

Texas Instruments

Automotive Infotainment Guide 2014

|

11

Microcontrollers/Embedded Processors

Component Recommendations

Embedded Proceccors – Automotive Infotainment Processors

Device

DRA64x

Jacinto 4 Family

Product Description Key Specifications

5High performance ARM® Cortex™-A8 (CA8) + Neon Infotainment

Processor targeted at mid to high-tier automotive applications like fully featured head units requiring High Definition video support. Rich automotive peripheral integration. Includes programmable DSP to support software customizations like digital radio.

CA8 + Neon, 2x Cortex M3, SGX530 3D graphics, 2D composition, C674x DSP with radio accelerators, IVA-HD multi-standard codecs (up to 1080p30fps), hardware accelerated display subsystem, 2x 32 bit EMIFs supporting DDR2-800 and DDR3-800 (400 MHz), multiple video input & display output ports (including HDMI v1.3), support of key automotive interfaces such as CAN, MOST, gigabit Ethernet AVB , SATA, PCIe, MLB

DRA60x / DRA61x

Jacinto 5 Entry Family

DRA62x

Jacinto 5 Eco Family

DRA65x

Jacinto 5 Family

DRA74x

Jacinto 6 Family

High performance ARM® Cortex™-A8 (CA8) + Neon Infotainment Processor targeted at entry-level automotive applications like telematics / e-call boxes & entry head units. Key automotive peripheral integration. Optional display and graphics support.

CA8+ Neon, optional SGX530 3D graphics engine and optional 24 bit WXGA LCD Controller, 1x 16 bit EMIF supporting DDR2-400 (200 MHz) or DDR3-600 (300 MHz), support of key automotive interfaces such as CAN, MOST, gigabit Ethernet AVB

Cost-optimized version of J5, high performance ARM® Cortex™-A8 (CA8)

+ Neon Infotainment Processor targeted at mid to high-tier automotive applications like fully featured head units (without need of video support). Rich automotive peripheral integration. Includes programmable DSP to support software customizations like digital radio.

CA8 + Neon, 2x Cortex M3, SGX530 3D graphics, 2D composition, C674x DSP with radio accelerators, hardware accelerated display subsystem, single 32 bit EMIFs supporting DDR2-800 and DDR3-800 (400 MHz), multiple video input & display output ports

(including HDMI v1.3), support of key automotive interfaces such as CAN, MOST, gigabit

Ethernet AVB , SATA, PCIe, MLB

High performance ARM® Cortex™-A8 (CA8) + Neon Infotainment Processor targeted at mid to high-tier automotive applications like fully featured head units (without need of video support). Rich automotive peripheral integration. Includes programmable DSP to support software customizations like digital radio.

CA8 + Neon, 2x Cortex M3, SGX530 3D graphics, 2D composition, C674x DSP with radio accelerators, hardware accelerated display subsystem, 2x 32 bit EMIFs supporting

DDR3-1066, multiple video input & display output ports (including HDMI v1.3), support of key automotive interfaces such as CAN, MOST, gigabit Ethernet AVB , SATA, PCIe, MLB

High performance dual ARM® Cortex™-A15 (CA15) + Neon + HW virtualization extensions Infotainment Processor targeted at mid to hightier automotive applications like fully featured head units requiring High

Definition video support. Rich automotive peripheral integration. Includes programmable DSP to support software customizations like digital radio.

Dual CA15 + Neon, 2x Cortex M4, dual SGX530 3D graphics, 2D composition, upgraded

C66x DSP with radio accelerators, upgraded IVA-HD multi-standard codecs (up to

1080p60fps), hardware accelerated display subsystem, 2x 32 bit EMIFs supporting

DDR2-800 and DDR3-800 (400 MHz), multiple video input & display output ports (including HDMI v1.4a), support of key automotive interfaces such as CAN, MOST, gigabit

Ethernet AVB , SATA, PCIe gen2, MLB

12

|

Automotive Infotainment Guide 2014

Texas Instruments

Power Management

Automotive Power Solutions

SWIFT

6-V, 6-A Synchronous Step-Down Converter

TPS54618RTE-Q1

The TPS54618RTE-Q1 SWIFT™ integrated circuit is a full-featured 6-V, 6-A, synchronous step-down current-mode converter with two integrated MOSFETs.

The input voltage range of 2.95 V to 6 V is well suited for regulating off the 5 V and

3.3 V bus voltage in an automotive subsystem.

The TPS54618RTE-Q1 enables small designs by integrating the MOSFETs, implementing current-mode control to reduce external component count, reducing inductor size by enabling up to 2-MHz switching frequency, and minimizing the IC footprint with a small 3-mm × 3-mm thermally enhanced QFN package.

The SwitcherPro™ software tool, available at

www.ti.com/switcherpro

, supports the TPS54618RTE-Q1.

12V

Key Features

• Device temperature Grade 1:

• –40°C to 125°C ambient operating temperature range

• Device HBM ESD classification Level

H2

• Device CDM ESD classification Level

C4B

• Two 12-mΩ (Typical) MOSFETs for high efficiency at 6-A loads

• 300-kHz to 2-MHz switching frequency

• 0.8-V ±1% voltage reference overtemperature (–40°C to 150°C)

• Synchronizes to external clock

• Adjustable slow start and sequencing

• UV and OV power-good output

• Thermally enhanced 3-mm × 3-mm

16-pin QFN

TI

TPS43336Q1

TI

TPS54618Q1

DDR3

TI

TPS51200Q1

TI

TPS54618Q1

DDR3 Termination

Core

Learn more at:

www.ti.com/ tps54618rte-q1

Texas Instruments

Automotive Infotainment Guide 2014

|

13

Power Management

Component Recommendations

Low-Dropout Regulators (LDOs)

Device

TPS79850-Q1

Product Description

50 V High-Voltage Micropower Low-Dropout Linear

Regulators

Key Specifications

50mA, 50V Vin, 40 µA Operating and 1 µA in Shutdown

TPS7B4250-Q1

TPS7A1650-Q1

TPS7A6601-Q1

TPS7A6633-Q1

TPS7A6550-Q1

TPS7A6933-Q1

TPS7A6950-Q1

TPS76501-Q1

TPS7A6050-Q1

TPS7A6150-Q1

TPS7A6650-Q1

TPS7B6701-Q1

TPS76950-Q1

TLE4275-Q1

LM2936Q-Q1

40 V, 50 mA Low-Dropout Tracking Regulator

60V, 5uA IQ, 100mA, Low-Dropout Voltage Regulator with

Enable and Power Good

40 V, 20 uA IQ, Low-Dropout 150 mA Linear Regulator

40 V, 20 uA IQ Low-Dropout 150mA Linear Regulator

300-mA 40-V Low-Dropout Regulator With Ultra-Low

Quies- cent Current

40 V, 20 uA IQ Low-Dropout 150mA Linear Regulator

150 mA, 5 V Low Quiescent Current Low-Dropout Voltage

Regulator

5-V, Low-Dropout Voltage Regulator

300-mA 40-V Low-Dropout Regulator With Ultra-Low

Quies- cent Current

300-mA 40-V Low-Dropout Regulator With Ultra-Low

Quies- cent Current and enable

150 mA, 5 V Low Quiescent Current Low-Dropout Voltage

Regulator

40 V, 25 uA IQ, Low-Dropout 450 mA Linear Regulator

4 to 40 V Vin, 5 mV Ultra-Low Tracking Accuracy, Short to GND, Reverse Polarity and Short to

Battery Protection

Wide Input Voltage Range: 3 V to 60 V; Ultra-low Quiescent Current: 5 µa;

QuiescentCurrent at Shutdown: 1 µA

4 to 40V Vin, 1.5 to 5 V Adjustable Output 2% Accuracy, Very Low Quiescent Current, 12 uA Typical at Light Load with Enable and PG and Programmable Delay

4-40V Vin, 3.3V Fixed Output 2% Accuracy, Very Low Quiescent Current, 12uA

Typical at Light Load, with Enable and PG and Programmable Delay

Low Dropout Voltage; 4-V to 40-V Wide Input Voltage Range With up to 45-V Transients; 300-mA

MaximumOutput Current

4-40V Vin, 3.3V Fixed Output 2% Accuracy, Very Low Quiescent Current, 12uA

Typical at Light Load with Voltage Supervision and RESET, PG and Programmable Delay

4-40V Vin, 5V Fixed Output, 2% Accuracy, Very low Quiescent Current, 12uA Typical at Light Load, with

Enable and PG and Programmable Delay

150 mA, 3% Tolerance, Open-Drain Power Good Output with Thermal

Shutdown Protection

4-V to 40-V Wide Input Voltage Range With up to 45-V Transients; 300-mA Maximum Output Current;

Ultra-Low Quiescent Current

4-V to 40-V Wide Input Voltage Range With up to 45-V Transients; Low Dropout Voltage; 300-mA Maximum

Output Current; Ultra-Low Quiescent Current

4-40V Vin, 5V Fixed Output, 2% Accuracy, Very low Quiescent Current, 12uA Typical at Light Load, with

Enable and PG and Programmable Delay

4 to 40V Vin, 1.5 to 18 V Adjustable Output 2% Accuracy, Very Low Quiescent Current, 15 uA Typical at Light

Load with Enable and Reset and Programmable Delay

Ultra-Low Power, 100 mA, Low-Dropout Linear Regulator Adjustable Voltage, 1-μA Quiescent Current in Standby Mode, Over-Current Limitation

5-V, Low-Dropout Voltage Regulator , 450mA

Ultra-Low Quiescent Current LDO Voltage Regulator

5.5-V to 42-V Supply, 2% Accuracy, Very Low Current Consumption and

ESD Protection > 6kV

5.5-60V Vin; Vout: 3V,3.3V,5V; Iq<= 15uA; 2% Tolerance; Vdo = 200mV; Reverse Battery Protection; Internal

Thermal Shutdown Protection

LM9036Q-Q1

LM9076Q-Q1

LP2951-33-Q1

LP2951-50-Q1

LP38691-Q1

LP38693-Q1

LP3988-Q1

LP3996-Q1

Ultra-Low Quiescent Current Voltage Regulator -45-40V Vin; Vout: 3.3V,5V; Reverse Transient Protection (-45V); Ultra Low Ground Pin Current

150mA Ultra-Low Quiescent Current LDO Regulator with

Delayed Reset Output

Automotive Single Output LDO, 100mA, Fixed(3.3V), Wide

Vin Range, RESET Flag

Automotive Catalog Single Output, 100mA, Fixed, Wide Vin

Range

500mA Low Dropout CMOS Linear Regulators Stable with

Ceramic Output Capacitors

3.65-40V Vin; Vout: 3.3V,5V; Ultra Low Ground Pin Current; 1.5% Vout Accurancy; Low Dropout Voltage;

Delayed RESET Output Pin for Low Vout Detection

Rated Output Current of 100 Ma; Low Dropout: 380 mV (Typ) at 100 mA; Low Quiescent Current: 75 μA (Typ);

1.4% Vout Accuracy

Rated Output Current of 100 Ma; Low Dropout: 380 mV (Typ) at 100 mA; Low Quiescent Current: 75 μA (Typ);

1.4% Vout Accuracy

Precision (Trimmed) Bandgap Reference; All WSON Packages Available in AECQ; Thermal Overload Protection;

2.7-10V Vin; Vdo: 250mV; 2% Vout Accuracy;

Precision (Trimmed) Bandgap Reference; All WSON Packages Available in AECQ; Thermal Overload Protection;

2.7-10V Vin; 1uA Off-State Quiescent Current; 55uA Iq

Precision (Trimmed) Bandgap Reference; All WSON Packages Available in AECQ; Thermal Overload Protection;

1µA Off-State Quiescent Current; 55uA Iq

500mA Low Dropout CMOS Linear Regulators Stable with

Ceramic Output Capacitors

Micropower, 150mA Ultra Low-Dropout CMOS Voltage

Regulator With Power Good

Precision (Trimmed) Bandgap Reference; All WSON Packages Available in AECQ; Thermal Overload Protection;

2.7-10V Vin; 55uA Iq; Vdo 250mV,330mV,430mV

2.7- 6V Vin, 85 uA Iq, Power Good Flag Output, Short Circuit Current Limit and Thermal Shutdown

Dual Linear Regulator with 300mA and 150mA Outputs and

Power-On-Reset for Automotive Applications

Power-On-Reset Function with Adjustable Delay; 1.5% Accuracy; Independent Enable Pin; 300mA Iout2;

36uVrms; Compatible with Ceramic Caps

New Products in bold red.

14

|

Automotive Infotainment Guide 2014

Texas Instruments

Power Management

Component Recommendations

DC/DC Controllers and Converters

Device

LM26001/3-Q1

TPIC74100-Q1

TPS40200-Q1

TPS5430-Q1

TPS5420-Q1

TPS54x62-Q1

TPS57160-Q1

TPS57114-Q1

TPS4333x-Q1

TPS4334x-Q1

TPS4335x-Q1

TPS40200-Q1

TPS54061-Q1

TPS54240-Q1

TPS54340-Q1

TPS54360-Q1

TPS54540-Q1

TPS54560-Q1

TPS54618-Q1

TPS62231-Q1

TPS62290-Q1

TPS62090-Q1

TPS61240-Q1

LM3481-Q1

LM22670-Q1

LM22671-Q1

LM22672-Q1

LM22673-Q1

LM22674-Q1

Product Description

Switching Regulators with High Efficiency Sleep Mode

Buck/Boost Switch-Mode Regulator

Wide-Input Range, Nonsynchronous Voltage-Mode Controller

3 A, Wide-Input Range, Step-Down SWIFT

TM

2 A, Wide-Input Range, Step-Down SWIFT

TM

Converter

Converter

48 V low-Iq, 65uA, Step-Down DC/DC Converter

3.5V to 60V, 1.5A Step Down SWIFT

TM

Converter with Eco-Mode

2.95V to 6V Input, 4A, 2MHz Synchronous Step Down SWIFT

Converter

TM

DCDC

40-V Low Iq, 30uA, Single Boost, Dual Synchronous Buck Controller

40-V Low Iq, 30uA, Quad Output Power Supply

40-V Low Iq, 30uA, Dual Synchronous Buck Controller

Key Specifications

Wide Vin Range: 3 V to 38 V, High Efficiency Sleep Mode, 40 uA Typical Iq in Sleep Mode

Wide-Input-Voltage-Range 1.5-V to 40-V, Fixed 5V Output, Programmable Slew Rate and

Frequency Modulation for EMI Consideration

4.5-V to 52-V Supply, 35 kHz to 500 kHz , Integrated 200-mA PMOS-FET Driver

5.5-V to 36-V Supply, Switching Frequency 500KHz Fixed, High Efficiency Due to Low rDSON

5.5 V to 36 V, 95% Efficiency, Adjustable-Output Voltage

3.6V - 48V Input-Voltage Range, 200kHz - 2.2MHz Switching Frequency, 1 - 3A Output

Current, 0.9 - 18V Output

3.5-V to 60-V Input Voltage Range, 100-kHz to 2.5-MHz Switching Frequency,

Synchronizes to External Clock, 1.5A Output current (0.5A & 2.5A version also available)

2.95V to 6V Input Voltage Range, 200 kHz to 2 MHz Switching Frequency,

Synchronizes to External Clock, 4A Output Current (2A & 3A version also available)

4 - 40 V Input-Voltage Range, 150 - 600 kHz Switching Frequency, 0.9 - 11V Output Voltage,

0.7 - 1.5A Peak Gate Drive Current, Boost Frontend, Frequency Spread Spectrum

4 - 40 V Input-Voltage Range, 150 - 600 kHz Switching Frequency, 0.6A Peak Gate Drive

Current, 2A Buck Converter Output current, 300mA LDO output current

4 - 40 V Input-Voltage Range, 150 - 600 kHz Switching Frequency, 0.9 - 11V Output

Voltage, 0.7 - 1.5A Peak Gate Drive Current, Frequency Spread Spectrum

4.5-V to 52-V, 200-mA Internal P-FET Driver, UVLO, External Synchronization

24.7 V to 60 V, 200 mA, 90 uA low Iq, 50 KHz to 1.1 MHz Switching Frequency, Frequency

Synchronization, Light Load Efficiency, Fixed Soft Start,  3x3 SON

3.5 V to 42 V, 2.5A, 138 A low Iq, 100 KHz to 2.5 MHz Switching Frequency, Frequency

Synchronization, Light Load Efficiency, Power Good, Adjustable Soft Start, MSOP and 3x3 SON

Wide-Input Range, Nonsynchronous Voltage-Mode Controller

SWIFT™ 4.7 V to 60 V, 200 mA Synchronous Step-Down

DC/DC Converter

4.7 V to 60 V, 200 mA, 90 uA low Iq, 50 KHz to 1.1 MHz Switching

Frequency, Frequency Synchronization, Light Load Efficiency,

Fixed Soft Start,  3x3 SON

SWIFT™ 4.5 V to 42 V, 3.5 A Step-Down DC/DC Converter

SWIFT™ 4.5 V to 60 V, 3.5 A Step-Down DC/DC Converter

SWIFT™ 4.5 V to 42 V, 5 A Step-Down DC/DC Converter

SWIFT™ 4.5 V to 60 V, 5 A Step-Down DC/DC Converter

4.5 V to 42 V, 3.5 A, 146 uA low Iq, 100 KHz to 2.5 MHz Switching Frequency, Frequency

Synchronization, Light Load Efficiency, Fixed Soft Start, 8 pin HSOIC

4.5 V to 60 V, 3.5 A, 146 uA low Iq, 10 0KHz to 2.5 MHz Switching Frequency, Frequency

Synchronization, Light Load Efficiency, Fixed Soft Start, 8 pin HSOIC

4.5 V to 42 V, 5 A, 146 uA low Iq, 100 KHz to 2.5 MHz Switching Frequency, Frequency

Synchronization, Light Load Efficiency, Fixed Soft Start, 8 pin HSOIC

4.5 V to 60 V, 5 A, 146 uA low Iq, 100 KHz to 2.5 MHz Switching Frequency, Frequency

Synchronization, Light Load Efficiency, Fixed Soft Start, 8 pin HSOIC

SWIFT™ 2.95 V to 6 V, 6 A Synchronous Step-Down DC/DC Converter

Step Down Buck Converter

Step Down Buck Converter

Step Down Buck Converter

Step Down Buck Converter

2.95 V to 6 V, 6A, 200 KHz to 2 MHz Switching Frequency, Frequency Synchronization,

Power Good and Tracking, Adjustable Soft Start, 3x3 SON

0.5A, 3MHz Ultra-Small Buck, DCS-Control, 1x1.5 SON

1A, 2.25MHz Buck, 2x2mm SON

3A, 2.8MHz/ 1.4MHz Buck, DSC-Control, 3x3 QFN

400mA, 4MHz Boost, 2×2 SON

48V Wide Vin Low-Side N-Channel Controller for Switching Regulators

3A SIMPLE SWITCHER®, Step-Down Voltage Regulator with

Synchronization or Adjustable Switching Freq

500mA SIMPLE SWITCHER®

Adjustable Frequency

Soft-Start and Current Limit

®,

Step-Down Voltage Regulator with

1A SIMPLE SWITCHER®, Step-Down Voltage Regulator with Adjustable

Frequency

3A SIMPLE SWITCHER®, Step-Down Voltage Reg. with Adjustable

2.97V to 48V Supply, 100 kHz to 1 MHz Adjustable and Synchronizable Frequency,

10 µA Shutdown Current

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Adjustable Switching

Frequency and Synchronization

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Adjustable Switching

Frequency and Synchronization

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Adjustable Switching

Frequency and Synchronization

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Adjustable Soft-Start and Current Limit

500 mA SIMPLE SWITCHER®, Step-Down Voltage Regulator with Precision

Enable

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Precision Enable Pin

Texas Instruments

Automotive Infotainment Guide 2014

|

15

Power Management

Component Recommendations

DC/DC Controllers and Converters

Device

LM22675-Q1

LM22676-Q1

LM22677-Q1

LM22678-Q1

Product Description

1A SIMPLE SWITCHER®, Step-Down Voltage Regulator with Precision

Enable

3A SIMPLE SWITCHER®, Step-Down Voltage Regulator with Precision

Enable

5A SIMPLE SWITCHER®, Step-Down Voltage Reg. with Synchronization or Adjustable Switching Frequency

5A SIMPLE SWITCHER®, Step-Down Voltage Regulator with Precision

Enable

5A SIMPLE SWITCHER®, Step-Down Voltage Regulator with Adjustable

Soft-Start & Current Limit

2A SIMPLE SWITCHER®, Step-Down Voltage Regulator with

Precision Enable

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Adjustable Switching

Frequency and Synchronization

Key Specifications

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Precision Enable Pin

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Precision Enable Pin

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Precision Enable Pin

LM22679-Q1

LM22680-Q1

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Adjustable Soft-Start and Current Limit

Wide Input Voltage Range: 4.5V to 42V, Internally Compensated, Adjustable Switching

Frequency and Synchronization

6V to 75V Input Range, Frequency Synchronization

LM5574/5/6-Q1

SIMPLE SWITCHER® 75V, Step-Down Switching Regulator

LM25574/5/6-Q1

SIMPLE SWITCHER® 42V, Step-Down Switching Regulator

LM2700Q-Q1

600kHz/1.25MHz, 2.5A, Step-up PWM DC/DC Converter

LM3671-Q1

LM25085-Q1

6V to 42V Input Range, Frequency Synchronization

3.6A, 0.08Ω, Internal Switch; Operating Input Voltage Range of 2.2V to 12V

1.2 V, 5 Vin, 2 MHz, 600 mA, Synchronous Step-Up PWM DC/DC Converter 5 V Input Range, AEC-Q100 Grade 0 and 1 Qualified

4.5-42V Wide Vin Constant On-Time PFET Buck Switching Controller 100% Duty Cycle for Low Dropout, Ultra-Fast Transient Response

LM5085-Q1

LM25088-Q1

4.5-75V Wide Vin Constant On-Time PFET Buck Switching Controller

4.5-42V Wide Vin Non-Synchronous Buck Controller

100% Duty Cycle for Low Dropout, Ultra-Fast Transient Response

Frequency Dithering for EMI Reduction, Low Iq Standby and Shutdown

LM5088-Q1

LM34919B-Q1

LM34919C-Q1

LM25010-Q1

LM25011-Q1

LM5121-Q1

LM5122-Q1

4.5-75V Wide Vin Non-Synchronous Buck Controller

6-40V Ultra-Small Wide Vin 600mA Buck Converter

4.5-40V Ultra-Small Wide Vin 600mA Buck Converter

6-42V, 1A Step-Down Switching Regulator

6-42V, 2A Wide Vin Constant On-Time Switching Regulator

3-65V Wide Vin Synchronous Boost Controller

Frequency Dithering for EMI Reduction, Low Iq Standby and Shutdown

2.6MHz Switching, Tiny 2x2mm µSMD Package

2.6MHz Switching, Tiny 2x2mm µSMD Package

Constant On-Time Control, Operation up to 1MHz

Emulated Ripple Mode, Adjustable Current Limit

Disconnection Switch Control for Input Current Limiting

LM5118-Q1

LM25118-Q1

LM5119-Q1

LM25119-Q1

LM25117-Q1

LM5117-Q1

3-65V Wide Vin Stackable Synchronous Boost Controller

3-42V Wide Vin Buck-Boost Controller

3-75V Wide Vin Buck-Boost Controller

6-65V Wide Vin Dual Synchronous Buck Controller

4.5-42V Wide Vin Dual Synchronous Buck Controller

6-42V Wide Vin Synchronous Buck Controller

4.5-42V Wide Vin Synchronous Buck Controller

Current Sharing and Phase Interleaving for High Current Applications

Emulated Current Mode Control, Frequency Synchronization to 500kHz

Emulated Current Mode Control, Frequency Synchronization to 500kHz

2-Channel or 2-Phase Operation with Current Sharing

2-Channel or 2-Phase Operation with Current Sharing

Emulated Current Mode Control, Analog Current Monitor

Emulated Current Mode Control, Analog Current Monitor

16

|

Automotive Infotainment Guide 2014

Texas Instruments

Power Management

Component Recommendations

Integrated Power Management IC (PMIC)

Device

LP3907-Q1

Product Description

Dual High-Current Step-Down DC/DC and Dual Linear Regulator with I2C-

Compatible Interface 5V Input

LP8728Q-Q1

Quad High-Current Step-Down Synchronous DC/DC 5 V Input

TPS65300-Q1

TPS65301-Q1

TPS65320-Q1

TPS659119-Q1

TPS658629-Q1

3-MHz Step-Down Regulator, 1x Linear Regulator and 2x Linear Regulator

Controller

3-MHz Step-Down Regulator, 2x Linear Regulator and 2x Linear Regulator

Controller

40-V Low-Iq, 140uA, Step-Down Buck Converter and low-Iq, 40uA,

LDO Regulator

5-V PMIC, 3 Step-Down Converter, 8 Linear Regulators /w I2C and RTC

5-V PMIC, 3 Step-Down Converter, 11 Linear Regulators /w I2C and RTC

TPS65000-Q1

TPS65023-Q1

TPS659038-Q1

Step Down Converter

6-Channel Power Mgmt IC with 3DC/DCs, 3 LDOs, I2C Interface and DVS

Power Management IC with 7 DC/DCs and 11 LDOs

TPS659039-Q1

Power Management IC with 7 DC/DCs and 6 LDOs

Key Specifications

1A/600 mA Step-down DC/DC Converters with Dynamic Voltage Management (DVM),

2-300 mA Linear Regulators, 2.1 MHz PWM Switching Frequency

1 A Synchronous Step-Down, 600 mA Synchronous Step-Down, 3.3 MHz Switching

Frequency, Spread Spectrum for EMI Reduction

5.6 V - 40 V Input-Voltage Range, 2-3MHz Switching Frequency, Integrated 1.2A Peak

Current Switch. 5V LDO 200mA, 3.3V LDO Controller, 1.2V LDO Controller

5.6 V - 40 V Input-Voltage Range, 2-3MHz Switching Frequency, Integrated 1.2A Peak

Current Switch, 5V LDO 200mA, 5V LDO 100mA, .3V LDO Controller, 1.2V LDO Controller

3.6-V to 40V - Input-Voltag Range, adj. 100kHz - 2.5 MHz Switching Frequency, 3.2A

Peak Current, 200mA LDO Output Current

5V, 1.5A Peak Current, 2.7MHz - 3.3MHz Swichting Frequency

5V, 1.5A Peak Current, 2.25MHz Swichting Frequency, LED Drivers, PWM Outputs,

11-ch ADC

0.6mA Buck and 2x 300mA LDOs, 3×3 QFN

2.5V – 6V Input Voltage Range, 2.25MHz Switching Frequency, 1.5A Peak Current

3.1V – 5.5V Input Voltage Range, 1.7MHz – 2.7MHz Switching Frequency with External

Clock Synchronization, 9A Peak Current

3.1V – 5.5V Input Voltage Range, 1.7MHz – 2.7MHz Switching Frequency with External

Clock Synchronization, 9A Peak Current

LCD/LED Display Solutions

Device

LP8860-Q1

TPS65150-Q1

TPS65131-Q1

TPS65100-Q1

TPS61085-Q1

TPS65140-Q1

TPS65145-Q1

TPS61040-Q1

TPS61041-Q1

TLC6C598-Q1

TLC6C5912-Q1

TLC5916-Q1

TLC5917-Q1

TLC5926-Q1

TLC5927-Q1

Product Description Key Specifications

Low EMI, High Performance, 4-Channel LED Driver for Automotive Lighting 3.0 V to 40 V Input Voltage Range, 1:13000 Dimming

Low Input Voltage, Compact LCD Bias IC With VCOM Buffer 1.8-V to 6-V Input Voltage Range, Gate Voltage Shaping, Integrated Vcom Buffer

Positive and Negative Output DC/DC Converter

2.7-V to 5.5-V Input Voltage Range, Dual Adjustable Output Voltages Up to 15 V and Down to –15 V

Triple Output LCD Supply w/Linear Regulator and Vcom Buffer

650 kHz/1.2 MHz, 18.5 V STEP-UP DC-DC CONVERTER

4-Channel Power Supply for LCD Monitor (5V)

Triple-Output LCD Supply with Linear Regulator and Power-Good Output

2.7-V to 5.8-V Input-Voltage-Range, 1.6-MHz Fixed Switching Frequency, Internal

Power-On Sequencing, Vcom Buffer, 3.3V LDO

2.3 V to 6 V Input Voltage Range, 18.5 V Boost Converter With 2.0 A Switch Current

2.7-V to 5.8-V Input-Voltage-Range, 1.6-MHz Fixed Switching Frequency,

Internal Power-On Sequencing

2.7-V to 5.8-V, 1.6-MHz Fixed Frequency, Internal Power-On Sequencing,

Thermal Shutdown

Low-Power DC/DC Boost Converter

Low-Power DC/DC Boost Converter

8-Bit Power Shift Register LED Driver

12-Bit Power Shift RegisterLED Driver

8-Bit Constant Current Sink LED Driver

8-Bit Constant Current Sink LED Driver

16-Bit Constant Current Sink LED Driver

16-Bit Constant Current Sink LED Driver

1.8-V to 6-V, Adjustable Output Voltage up to 28 V, Lower Output Voltage

Ripple, Low Quiescent Current

1.8-V to 6-V, SOT-23 Package, Small Overall Solution Size, Lower

Output Voltage Ripple

8-Bit Power Shift Registers, 50mA Sink Current Per Channel, 40V Transient Protection on

Drain Output, Controlled Switching Time for EMI with Thermal Shutdown Protection

12-Bit Power Shift Registers, 50mA Sink Current Per Channel, 40V Transient Protection on

Drain Output, Controlled Switching Time for EMI with Thermal Shutdown Protection

8-Bit Constant Current From 5mA to 120mA with 256-Step Programmable Current Gain with Open Load, Short Load and Overtemperature Protection

8-Bit Constant Current From 5mA to 120mA with 256-Step Programmable Current Gain with Open Load, Short Load and Overtemperature Protection

16-Bit Constant Current From 5mA to 120mA with 256-Step Programmable Current Gain with Open Load, Short Load and Overtemperature Protection

16-Bit Constant Current From 5mA to 120mA with 256-Step Programmable Current Gain with Open Load, Short Load and Overtemperature Protection

Motor Drivers for Flip-Up Display

Device Product Description

DRV8801-Q1

2.8 A Brushed DC Motor Driver

DRV8832-Q1

1 A Brushed DC Motor Driver

Key Specifications

Up to 38 V Operation; Phase Enable Control I/F, Current Sense Pin iIdicates Coil Current,

Fully Protected

2.7 to 6.8 V Operation;  IN/IN Control Interface, Fully Protected, 3 x 4.9mm HTSSOP

Package

Texas Instruments

Automotive Infotainment Guide 2014

|

17

Power Management

Component Recommendations

High Side Switches (Load Switches)

Device

TPS22965-Q1

TPS22966-Q1

Product Description

Ultra-Low RON, 5.5V/4A Load Switch with Configurable Controlled Turn On

(Trise)

On Ultra-Low RON, 5.5V/4A Dual-Channel Load Switch with Configurable

Controlled Turn On (Trise)

Key Specifications

EIntegrated Solution Providing: 16mΩ On-Resistance, Output Discharge Resistance, 2μA

(Max) Shutdown Current, and Configurable Rise Time for Optimized Timing and Power

Sequencing

Integrated Solution Providing: 16mΩ On-Resistance, Output Discharge Resistance, 2μA

(Max) Shutdown Current, and Configurable Rise Time for Optimized Timing and Power

Sequencing

Preview Products in bold blue.

PWM Power Supply Controllers

Device Product Description

UCC2813-1-Q1

Low-Power BICMOS Current-Mode PWM

TPS2022-Q1

TPS2024-Q1

TPS2030-Q1

TPS2042B-Q1

TPS2051B-Q1

TPS2561-Q1

TPS2065-Q1

TPS2066-Q1

TPS2068-Q1

TS3USB221A-Q1

TPS2543-Q1

TPS2511-Q1

TPS2546-Q1

TP2513A-Q1

USB Power Distribution Switch

USB Power Distribution Switch

USB Power Distribution Switch

USB Dual, Current-Limited Power-Distribution Switches

USB Dual, Current-Limited Power-Distribution Switches

Automotive Catalog Dual Channel Precision Adjustable Current-Limited

Power Switches

Automotive Catalog Single 1A Current-Limited, Power-Distribution Switches for USB Applications

Automotive Catalog Dual 1A Current-Limited, Power-Distribution Switches

Automotive Catalog Current-Limited, Power-Distribution Switch

Automotive Catalog ESD Protected,High-Speed USB 2.0 (480-Mbps)

1:2 Multiplexer/Demultiplexer Switch

Automotive Catalog Programmable 2.5 A Current Limited USB-CPC Power

Switch

Automotive Catalog Programmable 2.2 A Current Limited USB-CPC Power

Switch

Automotive Catalog Programmable 2.5 A Current Limited USB-CPC Power

Switch

Automotive Catalog Switchless Dual USB-CPC ( Charge Port Controller)

Key Specifications

500-μA Operating Supply Current, Operation to 1 MHz, Ideal for Battery Operated Systems

2.7-V to 5.5-V Supply, 50-mΩ N-Channel MOSFET, High-Side Power Switches,

Short-Circuit and Thermal Protection

2.7-V to 5.5-V Supply, 50-mΩ N-Channel MOSFET, High-Side Power Switches,

Short-Circuit and Thermal Protection

2.7-V to 5.5-V Supply, 50-mΩ N-Channel MOSFET, High-Side Power Switches,

Short-Circuit and Thermal Protection

2.7-V to 5.5-V Supply, 70-mΩ N-Channel MOSFET, High-Side Power Switches,

Short-Circuit and Thermal Protection

2.7-V to 5.5-V Supply, 70-mΩ N-Channel MOSFET, High-Side Power Switches,

Short-Circuit and Thermal Protection

0.25 to 2.5A Adj Current Limit, 2.7V to 6.5V, 45mΩ Rdson, 15KV/8KV ESD Protection, Soft

Start, Thermal, SC Protection

Single, 1.5A, Fixed Current Limit, 2.7V to 5.5V, 70mΩ Rdson, Active High

Enable, Thermal, SC Protection

Dual, 1.5A, Fixed Current Limit, 2.7V to 5.5V, 70mΩ Rdson, Active High Enable, Thermal,

SC Protection

Single, 2.1A Fixed Current Limit, 2.7V to 5.5V, 79mΩ Rdson, Active Low enable, Thermal,

SC Protection

USB 2.0 High-Speed 1:2 Mux/Demux, with 7kV ESD & IEC61000–4–2 Immunity

Two Programmable ILIMITS, USB1.2 Compliant, Charge Port Control for Many Popular

Phones, Tablets, with Data Switch

USB1.2 Compliant, Charge Port Control for BC1.2 and  All Popular Phones, Tablets, for

Charge Only Ports. Load Detect Output for Droop Compensation

Two Programmable ILIMITS, USB1.2 Compliant, Charge Port Control for All Popular Phones,

Tablets, with Data Switch, Load Detect Output

Manages Data Lines of Two USB Ports to Provide Charge Port Control (CPC) l for All

Popular Phones, Tablets

New Products in bold red.

Sequencer

Device

LM3880-Q1

Power Sequencer

Product Description Key Specifications

Easiest Method to Sequence Rails Power Up and Power Down Control Input Voltage Range of 2.7V to 5.5V

18

|

Automotive Infotainment Guide 2014

Texas Instruments

Wireless Connectivity

Automotive Wireless Connectivity Solutions

WiLink™ 8Q – Scalable WiFi, Bluetooth

®

and GNSS

The Texas Instruments WiLink™ 8Q product family brings high performing Wi-Fi,

Bluetooth

® and GNSS positioning solutions to Infotainment systems enabling close integration with mobile handsets and high-speed data traffic to multiple devices in parallel. The WiLink 8Q family has a scalable and flexible combo chip architecture where the pin-to-pin compatible devices enable hardware and software reuse across platforms. It offers the lowest power and best-in-class RF performance and co-existence.

Learn more at:

Functional block diagram.

www.ti.com/

wilink8q

Key Features

• Integrated solution for Wi-Fi,

Bluetooth

®

and GNSS

• Qualified following AEC-Q100 guidelines for automotive

• Bluetooth

Bluetooth 4.0, including Bluetooth low energy

Best-in-class sensitivity

On-chip mSBC codec

Shared UART for Bluetooth, GNSS control

PCM for audio

• Wi-Fi

IEEE 802.11a/b/g/n

Station / Access Point / Wi-Fi

Direct

Wi-Fi Protected Access 2 (WPA2) and Setup (WPS)

100Mbps throughput

Wi-Fi Miracast™ ready

SDIO interface

• Location

Autonomous and Assisted GNSS

Supporting four satellite systems in parallel: GPS, Glonass, QZSS and

SBAS

Short TTFF, fast cold start

High tracking sensitivity

Sensors blending

Integrated LNA, support for external LNA / Active antenna

On-chip Position Engine

• Leading co-ex performance through advanced techniques

• Operating temp. -40 to +85 deg.

WiLink™ 8Q Solutions

Available technology options

Dual-band 2x2 MIMO mobile

Wi-Fi 802.11 a/b/g/n

Wi-Fi 802.11 b/g/n

Wi-Fi SS 40MHz (HT40)

GNSS

Bluetooth

®

4.0 (including BLE)

WL187xQ

WL1877

WL1873

WL1871

WL183xQ

WL1837

WL1833

WL1831

Texas Instruments

Automotive Infotainment Guide 2014

|

19

TI Worldwide Technical Support

Internet

TI Semiconductor Product Information Center

Home Page

support.ti.com

TI E2E™ Community Home Page

e2e.ti.com

Product Information Centers

Americas

Phone +1(512) 434-1560

Brazil

Phone 0800-891-2616

Mexico

Phone 0800-670-7544

Fax +1(972) 927-6377

Internet/Email support.ti.com/sc/pic/americas.htm

Europe, Middle East, and Africa

Phone

European Free Call 00800-ASK-TEXAS

(00800 275 83927)

International

Russian Support

+49 (0) 8161 80 2121

+7 (4) 95 98 10 701

Note: The European Free Call (Toll Free) number is not active in all countries. If you have technical difficulty calling the free call number, please use the international number above.

Fax +(49) (0) 8161 80 2045

Internet www.ti.com/asktexas

Direct Email [email protected]

Japan

Phone Domestic 0120-92-3326

Fax International +81-3-3344-5317

Domestic 0120-81-0036

Internet/Email International support.ti.com/sc/pic/japan.htm

Domestic www.tij.co.jp/pic

Asia

Phone

International +91-80-41381665

Domestic Toll-Free Number

Note: Toll-free numbers do not support mobile and IP phones.

Australia

China

1-800-999-084

800-820-8682

India

Indonesia

Korea

Malaysia

800-96-5941

1-800-425-7888

001-803-8861-1006

080-551-2804

1-800-80-3973

New 0800-446-934

Philippines

Singapore

Taiwan

Thailand

1-800-765-7404

800-886-1028

0800-006800

001-800-886-0010

Fax +8621-23073686

Email [email protected] or [email protected]

Internet support.ti.com/sc/pic/asia.htm

Important Notice: The products and services of Texas Instruments

Incorporated and its subsidiaries described herein are sold subject to TI’s standard terms and conditions of sale. Customers are advised to obtain the most current and complete information about TI products and services before placing orders. TI assumes no liability for applications assistance, customer’s applications or product designs, software performance, or infringement of patents. The publication of information regarding any other company’s products or services does not constitute TI’s approval, warranty or endorsement thereof.

A090712

The platform bar, TI E2E Community, C674x, DirectPath, FlatLink, PowerTune, SmartReflex, SwitcherPro, SWIFT, and

WiLink are trademarks of and SIMPLESWITCHER is a registered mark of Texas Instruments. ARM and Cortex are registered trademarks of ARM Limited. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc., and any use of such marks by Texas Instruments is under license. All other trademarks are the property of their respective owners.

SSAY002

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily performed.

TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional restrictions.

Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.

TI is not responsible or liable for any such statements.

Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use of any TI components in safety-critical applications.

In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and requirements. Nonetheless, such components are subject to these terms.

No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties have executed a special agreement specifically governing such use.

Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and regulatory requirements in connection with such use.

TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.

Products Applications

Audio

Amplifiers

Data Converters

DLP® Products

DSP

Clocks and Timers

Interface

Logic

Power Mgmt

Microcontrollers

RFID

OMAP Applications Processors

Wireless Connectivity www.ti.com/audio amplifier.ti.com

dataconverter.ti.com

www.dlp.com

dsp.ti.com

www.ti.com/clocks interface.ti.com

logic.ti.com

power.ti.com

microcontroller.ti.com

www.ti-rfid.com

www.ti.com/omap

Automotive and Transportation www.ti.com/automotive

Communications and Telecom www.ti.com/communications

Computers and Peripherals

Consumer Electronics

Energy and Lighting

Industrial

Medical

Security www.ti.com/computers www.ti.com/consumer-apps www.ti.com/energy www.ti.com/industrial www.ti.com/medical www.ti.com/security

Space, Avionics and Defense www.ti.com/space-avionics-defense

Video and Imaging

TI E2E Community

www.ti.com/wirelessconnectivity www.ti.com/video e2e.ti.com

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Copyright © 2013, Texas Instruments Incorporated

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
