in1110a
Lighten Up
The perfect mobile projector
for your portable devices.
in1110a
So small, light and bright,
it’s the perfect mobile projector
The InFocus in1110a Series of projectors deliver bright, clear
images from your notebook, tablet, smartphone, USB drive, or
the projector's internal memory no matter where you are. In fact,
weighing in at only 2.7 lbs (1.2 kg) and shining up to 2200
lumens, they’re our brightest projectors pound-for-pound.
The combination of high brightness, light weight and compact size
is ideal for the travelling professional that faces unpredictable
environments every day. Whether you’re in a brightly lit room or
cramped for time and space, the in1110a Series is the mobile
projector you can count on to perform every time.
models
in1110a
in1112a
XGA 1024 × 768
2100 lumens
2.7 lbs (1.2 kg)
WXGA 1280 × 800
2200 lumens
2.7 lbs (1.2 kg)
Easy Display from Any Device
Built-in apps and optional wireless
adapter quickly displays files from your
Apple or Android notebook, tablet or
smartphone without messy cables.
Why Choose the in1110a Series?
¡ Compact and light weight (only 2.7 lbs / 1.2 kg) for easy travel
¡ Up to 2200 lumens of brightness to combat any lighting situation
¡ Wireless connectivity with optional adapter and mobile
¡
¡
¡
¡
¡
app compatibility
PC-less display from USB drive or 2GB of internal memory
Present Office docs, video, audio, photos and more wirelessly
from your mobile device
Annotate on documents you're presenting and save the changes
with mobile app
Connect via HDMI and USB with ease
Durable, road-tested design that’s built to last
Display from No Device at All
Project images, audio and video directly
from the projector's on-board 2GB of
memory. Just load it and go.
in1110a
Optional Wireless
Connect and present wirelessly
with all your favorite devices
with the optional wireless
network adapter (SP-WIFIUSB-2)
and free presentation app. Leave
the cables at home!
Present photos, Office documents,
PDFs, audio, video, a live camera
feed, and more!
Connectivity
Document Annotation
Free wireless presentation app lets you annotate on documents you're presenting
with a wide variety of colored pens and shapes and then save the changes.
VGA (D-Sub HD15)
HDMI
USB-A (for thumb drive or wireless adapter)
Composite video
3.5 mm audio out
3.5 mm audio in
USB Mini-B (for display over USB, internal memory
file loading, presentation control and firmware updates)
Built for the Road
No Computer Needed
Present photos, PPT presentations, spreadsheets, PDFs, audio, video, and more
directly from a USB thumb drive.
The projector has a recessed lens and tethered lens
cap to keep it safe from impact. Plus, its smooth
exterior leaves nothing to snag or break off when
taking it in and out of its case.
Compact and Light
At only 2.7 lbs (1.2 kg), the in1110a/
in1112a is easy to pack, easy to carry
and won’t weigh you down.
Connect Fast
Connect your notebook or tablet via HDMI or USB to
present full HD quality video (and audio too) in just
seconds. VGA and Composite Video ports are also
included for when the need arises. You can even connect
it to an external audio system with the audio out port.
3D Capable
Display Blu-ray 3D content via HDMI and other PC-based
3D content created in the top emerging 3D standards.
Brightness Adds Confidence
Padded carrying
case is included
Room lighting can be a wildcard for the business traveler. You never know what
you’ll get. Pound-for-pound these powerful little projectors pump out the most
lumens of most any other projector. So you know your content will be brightly
displayed regardless of ambient light.
No Projector Screen? No Problem.
Because a projector screen won’t always be available,
the Presets button on top of the projector lets you
choose a mode to get the best image quality on a beige
wall, whiteboard, blackboard, or other surface.
Plus, you can point the projector at the wall and its
automatic vertical keystone correction will instantly
fix the image to be square-cornered and true.
Specifications*
Optional Accessories
in1110a
Native Resolution
Maximum Input Resolution
Display Technology
Brightness
Lamp Life**
Contrast Ratio
Audio
Input Connections
Output Connections
Control
Internal Memory
File Formats Supported
(via any source)
Documents Supported
- via USB drive or internal memory
- via EZ Display for Android
- via EZ Display for iOS
Aspect Ratio
Lamp Power
Power Consumption
Power Supply
Video Compatibility
Synch - Scan Freq
Throw Ratio (distance/image width)
Zoom Ratio
Projection Distance
Image Size (width)
Image Offset
Projection Methods
Keystone Correction
3D
Audible Noise
Operating Temperature
Maximum Altitude
Product Weight
Product Dimensions - W×D×H
Shipping Weight
Shipping Dimensions - W×D×H
Ships with - Accessories
Menu Languages
Approvals
in1112a
XGA 1024 × 768
WXGA 1280 × 800
WUXGA^ 1920 × 1200
DLP®
2100 ANSI lm (1550 lm Eco Mode)
2200 ANSI lm (1650 lm Eco Mode)
4000 hours Eco Mode (3000 hours Normal)
2600:1
1W
VGA, HDMI, USB-A (for USB thumb drive or wireless network adapter), USB mini-B (for
display over USB and internal memory file management) Composite, Audio in 3.5 mm
Audio out 3.5 mm
USB mini-B (for presentation control and firmware updates)
2 GB
Photo (JPG, JPEG, BMP); Video (at 1080: XVID, MPEG4, H.264, H.263, M-JPEG, WMV3, MPEG-1)
(at 720: RV3, RV4); Audio (MP1, MP2, MP3, WMA, OGG, ADPCM-WAV, AAC)
PDF, docs from Office 95, 97, 2000, 2003, 2007, 2010
Adobe PDF 1.6 or later, docs from Office 2003, 2007 or 2010
Adobe PDF 1.6 or later, docs from Office 2003, 2007 or 2010, docs from iWork ’09 or later
Native 4:3 (Supports 5:4, 16:9, 16:10)
Native 16:10 (Supports 4:3, 5:4, 16:9)
165 W
Bright: 220 W, Eco: 180 W, Standby: <0.5 W
90 - 264 Vac, 50/60 Hz
NTSC/NTSC4.43/PAL/PAL-M/PAL-N/SECAM, 480i/p, 576i/p, 720p, 1080i/p
Horizontal: 31.4 - 91.1 KHz / Vertical: 23.5 - 85 Hz , 120 Hz (3D)
1.95 - 2.15
1.55 - 1.7
1.1:1
3.9 - 39 ft / 1.2 - 12 m
22 - 242 in / 56 - 615 cm
28 - 304 in / 71 - 772 cm
15%
12%
Front, Rear, Ceiling
Automatic, vertical ± 30°
Supports Blu-ray 3D content (over HDMI only) and PC-based 3D content configured
at 720p running at 120Hz signal. DLP Link 3D glasses required.
29 dBA Eco Mode (33 dBA High Power)
41° - 95° F / 5°- 35° C
7,500 ft / 2,286 m
2.7 lbs / 1.2 kg
8.4 × 7.1 × 2.5 in / 213 × 181 × 65 mm
7.5 lbs / 3.4 kg
7.28 × 15.55 × 11.42 in / 185 × 395 × 290 mm
Power Cord, VGA Cable, Remote, USB Cable, Lens Cap with tether, Carry Case
English, French, German, Dutch, Italian, Korean, Norwegian, Portuguese, Russian, Spanish, Simplified Chinese,
Traditional Chinese, Swedish, Polish, Turkish, Danish, Finnish, Bahasa Indonesia, Persian, Vietnamese, Arabic
Warranty
The in1110a and in1112a projectors come standard with a 2-year
factory warranty, a 6-month lamp replacement warranty, and
90-day limited accessories warranty. Warranty terms may vary by
region. Extended product warranty programs are also available.
Wireless Software System Requirements
EZ WiFi (download from projector)
Operating System: Windows XP SP3, Vista SP2, Win 7 SP1 and Win 8
(Starter versions not supported; Mac OS X 10.7 and above
CPU: Windows: Dual Core Intel Core i 1.6 GHz or higher (ATOM not
supported); Mac: Dual Core Intel Core i 1.4 GHz or higher (PowerPC not
supported)
Graphic card: Intel, nVIDIA or ATI graphic card with 64MB VRAM or above
EZ Display (Free download from iTunes)
Compatible with iPhone 3GS, iPhone 4, iPhone 4S, iPhone 5, iPod touch
(4th generation), iPod touch (5th generation), iPad 2 Wi-Fi, iPad 2 Wi-Fi +
3G, iPad (3rd generation), iPad Wi-Fi + 4G, iPad (4th generation), iPad Wi-Fi
+ Cellular (4th generation), iPad mini and iPad mini Wi-Fi + Cellular.
Requires iOS 5.1 or later. This app is optimized for iPhone 5.
EZ Display (Free download from Google Play store)
Requires Android 4.0 and up
www.infocus.com
InFocus Corporate Headquarters
13190 SW 68th Parkway
Portland, Oregon 97223-8368, USA
Phone: (1) 503-207-4700
Toll Free: (1) 877-388-8385
Fax: (1) 503-207-4707
FCC (USA), cULus (USA and Canada), WEEE (European Union), C-Tick mark (Australia), S-Mark (Argentina), NOM (Mexico), CE (Europe),
Gost (Russian), CECP/CCC (China), CE/TUV-GS (Germany), KC Mark (Korea), SASO (Saudi Arabia), PSB (Singapore), SABS (South Africa)
Security
Replacement Lamp (SP-LAMP-043)
Wireless Network Adapter (SP-WIFIUSB-2)
DLP Link 3D Glasses by XPAND (X103-EDUX3-R1)
Presenter RF Remote with USB Receiver (HW-PRESENTER-2)
Extended warranties (PROJ-EW1YR-MC, PROJ-EW2YR-MC)
ATA Shipping Case (CA-ATA-MOB)
Security Lock (SEC-LOCK-01)
Projector Screens
Kensington Lock, User PIN
* Product specifications, terms, and offerings are subject to change at any time without notice. ** Actual lamp life may vary based on the ambient environment and projector usage. Conditions that may affect
lamp life include temperature, altitude, and rapidly switching the projector on and off. ^ Reduced blanking.
©2013 InFocus Corporation. All rights reserved. Specifications are subject to change without further notice. InFocus
and InFocus The New Way to Collaborate are either trademarks or registered trademarks of InFocus Corporation in the
United States and other countries. DLP, the DLP logo, and the DLP medallion are trademarks of Texas Instruments. All
trademarks are used with permission or are for identification purposes only and are the property of their respective
companies. InFocus_in1110a_Datasheet_31OCT13.
