Supplemental Guide
Valves
Directional Control Valve Products
Interflow and Non-Interflow in Barksdale Valves
Interflow in a Barksdale Shear-Seal® valve is a small amount of fluid flow from the Pressure A and B ports to the return port through
the clearance between the rotor and the body. This interflow occurs whenever the valve is shifted from one position to another or
when the valve is being used for throttling. This is due to the Shear-Seal® in the valve being only partially covered by the rotor.
Interflow is not leakage and does not occur when the valve is fully engaged.
The interflow in a Shear-Seal® valve is beneficial in that it reduces the hydraulic shock or “water hammer” that can occur when a
valve is closed rapidly. The small amount of interflow between ports acts as a cushion as the fluid flow is stopped in the system.
Non-interflow valves are constructed with Shear-Seal®s using a much smaller flow passage than a comparably sized interflow valve.
By doing this, the orifice in the pressure seal and rotor are completely covered during transition thus preventing interflow. Noninterflow valves may be required when precise control of a cylinder is needed and the small settling associated with interflow valves
can not be tolerated. Non-interflow valves have a much lower flow rate than interflow valves with the same port size. Mandatory
higher force is required to actuate them.
Barksdale Shear-Seal® Valves are available with many standard options as well as special order features. Many of the options
available are listed below. Consult Factory for additional details and availability for a particular valve model. Don’t see what you need
here? Call us - we’re only a phone call away.
Seal Material
Std. P/N Suffix
Modification
Std. P/N Suffix
Butyl
-Z10
2-Position 45° CW detent
-Z30
Neoprene
-Z12
2-Position 45° CCW detent
-Z31
Viton®
-Z13
2-Position 90° detent
-Z32
EPR
-Z15
No valve detent
-Z33
Silicone
-Z16
No valve handle
-Z34
Valve with actuator mounting
Hardware only (no actuator)
-Z35
FSR
-Z17
Thiokol
-Z18
Teflon (PTFE)
-Z19
Disogrin
-Z21
Maintenance
1. Disassemble and inspect. Replace or repair damaged or worn parts and “O” rings; clean all parts including solenoid and
plunger. Grease valve parts before assembly. The solenoid should be cleaned at least every 1,000,000 cycles or every six months.
The valve should be checked every 2,000,000 or once a year.
2. All Barksdale manual selector valves for water service are equipped with a grease fitting in the housing. On untreated water, valve
should be lubricated through this fitting. Frequency of lubrication depends entirely on duty cycle of valve. An increase in handle
load will indicate exactly what lubrication schedule should be followed. Use water resistant lubricant such as Socony-Vacuum
“Sovarex 2W”, Shell “Alvania” or equivalent. Preceding operation may be disregarded if valve is used on water treated with
soluble oil.
3. At the first sign of excessive internal leakage the valve should be disassembled and the source of leakage repaired. Allowing valve
to continue in operation may cause damage to other components, as the escaping fluid is generally in the form of a jet stream.
WARNING: Reverse assembly of any valve parts may result in high case pressure and possible injury. Assembly drawings, sales
drawings and parts lists MUST be consulted.
1
Supplemental Guide
Directional Control Valve Products
Pressure Drop Curves
(Theoretical)
150
3/16
7/32
9/32
1/4
140
5/16
3/8
7/16
1/2
PRESSURE DROP (PSI)
130
17/32
9/16
5/8
120
110
23/32
100
90
3/4
80
70
60
50
7/8
40
30
1
20
1-1/8
1-1/4
10
0
5
10
15
20 25 30 35 40 45 50 55 60 65 70 75 80
RATE OF FLOW (G.P.M.) - HYD. OIL OR WATER
85
90 95 100
Pressure Drop
Barksdale’s Shear-Seal® Valves have a much lower pressure drop than other valve technologies. This is possibly due to smooth
internal passages and transitions within the valves which keep turbulent fluid flow to a minimum. This translates to less heat build-up
and higher pressures available to perform the required work.
Determine Pressure Drop for Barksdale Shear-Seal Valves
1. Determine the Rate of Flow in G.P.M. or L.P.M. for fluid being controlled.
2. Determine minimum flow passage for valve from vale data sheet or sales drawing.
3. Locate the Pressure Drop Curve from the chart above for the appropriate minimum flow passage
(indicated by the small circles at each curve).
4. Read the Pressure Drop from the vertical axis at the point where the flow rate (horizontal axis) intersects
the appropriate pressure drop curve.
Note: The Pressure Drop is about the same in all flow directions.
2
Valves
Supplemental Guide
Directional Control Valve Products
Velocity Curves
(Theoretical)
70
3/16
65
VELOCITY (FT. PER SEC.)
9/32 5/16
7/32
3/8
7/16
1/2
17/32
9/16
23/32
5/8
3/4
1/4
60
55
7/8
50
45
1
40
35
30
1-1/8
25
1-1/4
20
15
10
5
0
5
10
15
20 25 30
35 40 45 50 55 60 65
RATE OF FLOW (G.P.M.)
70 75 80
85
90 95 100
Fluid Velocity
Barksdale’s Shear-Seal® Valves control fluid at a much higher velocity than other types of valve technologies. This means that a
smaller valve can be used to do the same types of job, saving you space and component costs. The recommended velocity for
Barksdale valves is about 30 ft/sec (9.1 m.sec) for continuous operation. However, the valve can easily handle higher velocities up to
60 ft/sec (19.3 m/sec) for intermittent duty.
Determining Fluid Velocity in a Shear-Seal Valve for a known Rate of Flow
1. Determine the Rate of Flow in G.P.M. or L.P.M. for fluid being controlled.
2. Determine minimum flow passage for valve from valve data sheet or sales drawing.
3. Locate the Velocity curve from the chart above for the appropriate minimum flow passage (indicated
by the small circles at each curve).
4. Read the Velocity from the vertical axis at the point where the flow rate (horizontal axis) intersects the
appropriate Velocity curve.
3
Supplemental Guide
Directional Control Valve Products
Trouble-Shooting Pointers
Barksdale Manual Directional Control Valves
SUSPECTED TROUBLE
High force required to shift valve
Possible Cause
1 Restriction or blockage in “return” port
causing back pressure in excess of
maximum allowable for valve style
SOLUTION
1 Remove restriction
1 Worn Shear-Seal O-ring
2 Valve installed in system incorrectly
allowing pressure to be applied to
return port
2 Install valve correctly
SUSPECTED TROUBLE
Internal Leakage
Across Face of Shear-Seal®
1 Scratch or other damage to face of
Shear-Seal®
3 Bent detent disk rubbing valve housing
3 Repair or replace detent disk
4 Dirt or debris under trust washer causing tipping of rotor
4 Disassemble and clean valve
5 Worn or missing pin rotor pin on shaft
which allows rotor to rub on housing
5 Disassemble and replace shaft pin
6 Worn or scored thrust washers causing bearings to bind
6 Replace thrust washers and bearings.
If balls run on top of rotor inspect this
area for damage as well.
7 Pressure in excess of valve rating
7 Reduce working pressure of valve in
system with regulator, relief valve or other
means.
8 Lip worn off of Shear-Seal®
8 Replace Shear-Seals®
9 Galling between Shear-Seal® and rotor
9 This is typically an affect of rotor tipping. Replace Shear-Seal®. If possible
grind and lap rotor and use shim on top
of rotor to make up difference that is
ground off. Otherwise replace rotor.
SUSPECTED TROUBLE
Symptom: Leakage around shaft
1 Replace shaft O-ring
2 Enlarged shaft hole in housing caused
by side load on shaft. Typically only
found when valve is actuated by some
mechanical means which is misaligned
2 Replace housing. Inspect shaft for
wear and replace if necessary.
Correct side loading condition.
1 Replace O-ring
SOLUTION
1 Replace Shear-Seal®. Field dressing
can be performed on the face of
Shear-Seal® by lapping with 600 grit
paper. Paper should be held securely on a surface plate for best results.
2 Scratch or other damage to rotor
2 Lap rotor with 600 grit paper as
described above. Replace rotor if
leakage continues
3 Incorrect position of rotor in relation to
Shear-Seals®. This can be caused by
worn rotor shaft pins or worn detent
disk
3 Replace detent disk or shaft pins
4 Wear on surface of Shear-Seal® after
millions of cycles. This can reduce
spring tension on Shear-Seal® due to
material loss on seal face.
4 Replace Shear-Seal®s
5 Shear-Seal® spring fails due to breakage or taking permanent set.
5 Replace springs
SOLUTION
SUSPECTED TROUBLE
External Leakage Between
Body and Housing
1 Improperly installed body O-ring
1 Replace body O-ring and install
completely in O-ring groove
2 Excessive back pressure in housing
caused by restriction or blockage in
return port. Back pressure can cause
body bolts to stretch and allow leakage at body O-ring
2 Check pressure at return port with
pressure gauge and insure it is
below maximum rating for valve.
Replace body O-ring
3 Body bolts not tightened to specification on assembly drawing.
3 Replace body O-ring and tighten
bolts as per assembly drawing
SOLUTION
1 Worn shaft O-ring
SOLUTION
SUSPECTED TROUBLE
Internal Leakage around Shear-Seal
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
4
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0050-D • 03/08 • ©2008 • Printed in the U.S.A.
Valves
Shear-Seal® Directional Control Valve
Series 9000, 9020
Features
Original Shear-Seal® technology
Interflow/non interflow
Easy panel mounting
Tolerates contaminates
Spring return option
Applications
Pilot valve for pneumatic valve actuators
Gas manifold controls
Manual control of 2-position cylinder
Shown with option “D” red ball type handle
General Specifications*
Working Pressure:
Pneumatic or hydraulic from 150
psi to 350 psi (10.3 to 24.1 bar); see
table
Wetted Material:
Body:
Anodized aluminum
Standard O-Rings:
Buna N
Pressure Seals:
Brass
1-1/2 times working pressure except
at return port (without damage to
valve)
Rotor:
Hard anodized aluminum
Handle Rotation:
90°; 45° each side of center
2-1/2 times working pressure except
at return port (300 psi, 20.7 bar)
Detent:
3-position detent (except -MC,
-MR options)
Cv, Minimum Orifice:
See table
Back Pressure:
Must not exceed 250 psi (17.2
bar) at return port for satisfactory
operation
Proof Pressure:
Burst Pressure:
Media Temperature Range: -40° to +250°F (-40° to +121°C)
* See product configurator for additional options.
CLOSED CENTER
CLOSED CENTER (Float Center)
T
9000 Series
Non Interflow
9020 Series
Interflow
1
T
OPEN CENTER
T
T
T
Port
Size
NPT
Min.
Flow
Passage
Dia.
Cv
Factor
Air and Oil
Rated
Pressure
psi (bar)
Manipulator
Rated
Pressure
psi (bar)
Approx.
Shipping
Weight
lbs. (kg)
1/4”
3/16”
0.52
150 (10.3)
150 (10.3)
2 (0.9)
3/8”
3/16”
0.52
150 (10.3)
150 (10.3)
2 (0.9)
1/4”
3/8”
2.3
350 (24.1)
250 (17.2)
2 (0.9)
3/8”
3/8”
2.3
350 (24.1)
250 (17.2)
2 (0.9)
1/2”
3/8”
2.3
350 (24.1)
250 (17.2)
2 (0.9)
T
Shear-Seal® Directional Control Valve
Series 9000, 9020
Technical Drawings
REGULAR
#10-24NC-2 THD.
.375 MIN. FULL THD.
FOR PANEL MTG.
(TYP) 4 PLACES
A
A
G1 DIA.
PANEL MOUNTING
SURFACE .250 MAX.
PANEL THICKNESS
“-D” option
PORT*
PANEL MOUNTING
SURFACE
G2 DIA.
H
PORT*
PORT*
E
C
1.250
(31.8 )
MOUNTING BRACKET
and 4 SCREWS
RED BALL
TYPE HANDLE
SPRING CENTER/REVERSE
B
“-C” option
F1
2.125
(54.0)
2.375
(60.3)
PORT*
2.781
(70.6)
C
E
H
5.437
(138.1)
F2
D1
1.0 (25.4)
1.0 (25.4)
.562 (14.3)
“-E” option
BLACK KNOB
(not available with spring return)
.281 DIA.
3 PLACES
1.0 (25.4)
2.781
(70.6)
3.125
(79.4)
D2
2.0
(50.8)
.625
2.375
Dimensions in inches (mm)
PORT
SIZE
Black
Knob
Regular
NPT
1/4 & 3/8
1/2
Spring
Center/
Rever
Black
Knob
Regular
Spring
Center/
Rever
Black
Knob
Regular
Spring
Center/
Rever
A
B
C
D
D-1
D-2
E
F
F-1
F-2
G
G-1
G-2
H
J
1.000
2.625
4.125
3.656
4.781
5.188
1.688
2.062
2.000
2.406
0.437
0.437
1.906
0.531
0.656
(25.4)
(66.7)
(104.8)
(92.9)
(121.4)
(133.8)
(42.9)
(52.4)
(50.8)
(61.1)
(11.1)
(11.1)
(48.4)
(13.5)
(16.7)
1.000
3.125
4.125
3.718
4.843
5.250
1.750
2.125
2.062
2.468
0.437
0.437
1.906
0.625
0.937
(25.4
(79.4)
(104.8)
(94.4)
(123.0)
(133.4)
(44.5)
(54.0)
(52.4)
(62.7)
(11.1)
(11.1)
(48.4)
(15.9)
(23.8)
Product Configurator
Example:
902
2
-M
Series
Optional O-ring Material
900
Non interflow
902
Interflow
Port Size
1
1/4” pressure port
2
3/8” pressure port
3
1/2” pressure port (interflow only)
-Zxx
See supplemental guide
Options
-B
2-position 90° rotation (no center position)
-C
Mounting bracket w/ 4 screws
-D
Red ball type handle
-CD
-E
Mounting bracket & red ball type handle
Black knob (not available for spring return)
Operation
-M
Manual operation
-MC
Manual (spring return to center)
-MR
Manual (spring return to reverse)
Flow Pattern
Blank if closed center selector
-A
Closed center manipulator
-G
Open center manipulator
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0040-H • 12/08 • ©2008 • Printed in the U.S.A.
2
Low Pressure OEM Valves
Valves
Series 9040, 9080
Patent # 3,014,499
Features
Original Shear-Seal® technology
Low pressure drop
Tolerates contaminates
Spring return option
Flexible design
Applications
Paper mill controls
Air pilot valves
Halon fill systems
Heating oil control
Compressed gas manifold control
General Specifications*
Working Pressure:
Gasses or hydraulic fluids up to 500
psi (34 bar)
Media Temperature
Range:
Flow Capacity, Cv:
See table
Back Pressure:
Must not exceed 250 psi (17.2 bar) at
return port for satisfactory operation
Wetted Material:
Rotor:
Hard anodized aluminum
Pressure Seals:
Brass
Pressure Drop:
14 psi (0.96 bar) at 20 ft/sec
See Supplemental Guide for more
detailed information
Shaft:
Stainless steel
Body, Housing:
Anodized aluminum
Bearings:
Teflon/stainless steel
Standard O-rings:
Buna N, others available
Proof Pressure:
1-1/2 times working pressure except
at return port
Burst Pressure:
2-1/2 times working pressure except
at return port (500 psi [34 bar])
-40° to +250°F (-40° to +121°C)
* See product configurator for additional options.
Main Valve
Port Size
1/2" & 3/4"
1"
1-1/2"
1
Flow Capacity (Approx.)
Service: Oil
20 ft/sec 40 ft/sec
Min. Flow
gpm
gpm
60 ft/sec
Passage
(l/min)
(l/min)
gpm (l/min)
Dia.
17/32"
14 (53)
28 (106)
Use
25 (95)
51(190)
23/32"
Heavy
62 (235) 124 (471) Duty Valve
1-1/8"
Cv
Factor
4.80
9.20
24.0
Approx.
Shipping
Weight
lbs (kgs)
3 (1.4)
10-1/2 (4.8)
20 (9.1)
Low Pressure OEM Valves
Series 9040, 9080
Technical Drawings
9040 SERIES
9080 SERIES
9040 Series Regular (side) Porting
Port Size
A
B
C
C1
D
E
F
G
Dia.
NPT
1/2" & 3/4"
3.5 (88.9)
1"
4.5 (114)
1-1/2"
6.38 (162)
7.37 (187.3) 7.94 (201.6) 2.56 (65.0) 3/8 - 16 NC 3.03 (77.0) 0.56 (14.2) 2.56 (65.0) 0.88 (22.4)
9.03 (229.4) 3.31 (84.1) 1/2 - 13 NC 3.59 (91.2) 0.75 (19.1) 3.375 (85.7) 1.06 (26.9)
10.35 (263) 9.66 (245) 10.53 (267.5) 4.75 (121) 3/4 - 10 NC 4.656 (118.3) 0.88 (22.4) 3.375 (85.7) 1.37 (34.9)
8.16 (207)
C1
D
E
5.44 (138)
7.34 (186)
7.9 (200.8) 2.56 (65.0) 3/8 - 16 NC
J1
3.38 (85.9)
3.94 (100)
3.94 (100)
4.81 (122.2)
5.906 (150)
5.03 (128)
F
G
Dia.
G1
Dia.
H
J
3.88 (98.6)
0.56 (14.2)
2.56 (65.0)
2.50 (65.5)
4.22 (107)
NPT
4.19 (106)
J
H
5.44 (138)
8.44 (214)
9080 Series Straight (bottom) Porting
Port Size
A
C
B
1/2" & 3/4"
G1
Dia.
J1
4.78 (121)
Dimensions in inches (mm)
Product Configurator
Example:
904
5
R
0
A
C
3
Series
904
Regular (side) porting
908
Straight (bottom) porting
Options
Port Size
3
1/2” NPT ports
4
3/4” NPT ports
5
7
S
0
500 psi max. Air or hydraulic fluid
See Supplemental Guide
-
for complete list
1” NPT ports
(Series 904 only)
1-1/2” NPT ports
(Series 904 only)
Style
R
Pressure Range
Service
A
Air (pneumatic) or hydraulic fluid
Options
-A
-MC
Flow Pattern
SAE porting
Spring centering
Regular (side) porting,
(Series 904)
C
Closed center
Straight (bottom) porting,
O
Open center (tandem center)
Position
(Series 908)
3
Three position
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0055-B • 12/07 • ©2007 • Printed in the U.S.A.
2
Valves
High Pressure OEM Valves
Series 6140, 6180
Patent# 3,014,499
Features
Original Shear-Seal® technology
Low pressure drop
Tolerates contaminates
Spring return option
Flexible design for OEM requirements
Applications
Hydraulic presses
Military equipment
Paper mill controls
Hydraulic pilot valves
Railroad maintenance equipment
Halon fill systems
General Specifications*
Working Pressure:
Hydraulic fluid up to 3000 psi (206
bar)
Media Temperature
Range:
Flow Capacity, Cv:
See table
Back Pressure:
Must not exceed 250 psi (17.2
Bar) at return port for satisfactory
operation
Wetted Material:
Rotor:
Hard anodized aluminum
Pressure Seals:
Brass
Shaft:
Stainless steel
Body Housing:
Anodized aluminum
Pressure Drop:
14 psi (0.96 bar) at 20 ft/sec
See Supplemental Guide for more
detailed information
Proof Pressure:
1-1/2 times working pressure except
at return port
Bearings:
Carbon steel
Burst Pressure:
2-1/2 times working pressure
except at return port (see flow chart)
Standard O-rings:
Buna N, others available
Back-up Rings:
Teflon®
* See product configurator for additional options.
Main Valve
Port Size
1/4" & 3/8"
1/2" & 3/4"
**
1"
**
1-1/2"
Flow Capacity (Approx.)
Service: Oil
20 ft/sec 40 ft/sec 60 ft/sec
gpm
gpm
gpm
(l/min)
(l/min)
(l/min)
5 (19)
10 (38)
Use
14 (53)
28 (106)
Heavy
25 (95)
51(190)
Duty
Valve
62 (235) 124 (471)
** 6140 Series Only
1
-40° to +250°F (-40° to +121°C)
Approx.
Min. Flow
Shipping
Return Port
Passage
Cv
Weight
Dia.
Factor lbs (kgs)
Burst Rating
5/16"
1.56 1 1/2 (0.7)
3,000 psi (207 bar)
17/32"
4.80
3 (1.4)
23/32"
9.20 10 1/2 (4.6) 2,000 psi (138 bar)
1-1/8"
24.0
20 (9.1)
1,500 psi (103 bar)
High Pressure OEM Valves
Series 6140, 6180
Technical Drawings
6140 Series
6180 Series
6140 Series In-Line (side) Porting
Port Size
A
B
C
C1
D
E
F
G
Dia.
NPT
G1
Dia.
H
J
J1
3.03 (77.0)
1/4" & 3/8"
2.63 (66.8)
5.44 (138) 6.38 (161.9) 6.718 (170.6) 1.81(46.0) 5/16 - 18 NC 2.31(58.7)
0.44 (11.2)
1.91(48.5)
0.56 (14.2
2.66 (67.6)
1/2" & 3/4"
3.5 (88.9)
5.44 (138)
7.37 (187)
7.93 (201)
2.56 (65.0) 3/8 - 16 NC
3.03 (77.0)
0.56 (14.2)
2.56 (65.0)
0.88 (22.4)
3.38 (85.9)
3.94 (100)
1"
4.5 (114)
8.44 (214)
8.16 (207)
9.03 (229.3) 3.31 (84.1) 1/2 - 13 NC
3.59 (91.2)
0.75 (19.1)
3.38 (86)
1.06 (26.9)
3.94 (100)
1-1/2"
6.38 (162)
10.35 (263)
9.66 (245)
10.53 (268)
4.75 (121)
3/4 - 10 NC
4.6 (118)
0.88 (22.4)
3.38 (86)
1.34 (34.0)
5.03 (128)
4.81 (122)
5.91 (150)
C1
D
E
F
G
Dia.
G1
Dia.
H
J
J1
6180 Series Straight (bottom) Porting
Port Size
A
B
C
NPT
1/4" & 3/8"
2.63 (66.8)
5.44 (138)
6.13 (156)
6.50 (165)
1.81(46.0) 5/16 - 18 NC 2.66 (67.6)
0.44 (11.2)
1.91(48.5)
1.50 (38.1)
3.00 (76.2)
3.38 (85.9)
1/2" & 3/4"
4.19 (106)
5.44 (138)
7.34 (186)
7.91 (201)
2.56 (65.0) 3/8 - 16 NC
0.56 (14.2)
2.56 (65.0)
2.50 (65.5)
4.22 (107)
4.78 (121)
3.88 (98.6)
Dimensions in inches (mm)
Product Configurator
Example:
614
2
R
3
H
C
3
Series
614
Regular (side) porting
618
Straight (bottom) porting
Options
Pressure
3
See Supplemental
Guide for complete list
3,000 psi
Port Size
1/4” NPT ports
Working Media
2
3/8” NPT ports
Hydraulic oil
3
1/2” NPT ports
4
3/4” NPT ports
5
1” NPT ports (614 only)
7
1-1/2” NPT ports (614 only)
1
Style
H
Options
-A
-MC
Flow Pattern
C
O
-NF
Closed center
Open center (tandem center)
SAE Porting
Spring centering *
Non-interflow (port size 1/4”
and 3/8” NPT only)
* For 1” ported pressure rating 2,500 psi
Not available on 1-1/2” ported valves.
Position
R
Regular (side) porting (series 614)
S
Straight (bottom) porting (series 618)
3
3-position
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0054-B • 11/08 • ©2008 • Printed in the U.S.A.
2
Valves
High Pressure OEM Manipulator Valves
Series 6900, 6940
Patent# 3,014,499
Features
Original Shear-Seal® technology
Low pressure drop
Tolerates contaminates
Spring return option
Special flow pattern for OEM designs
Applications
Hydraulic presses
Military equipment
Paper mill controls
Pipe forming
Railroad maintenance equipment
General Specifications*
Working Pressure:
Hydraulic fluid up to 3000 psi (206
bar)
Media Temperature
Range:
Flow Capacity, Cv:
See table
Back Pressure:
Must not exceed 250 psi (17.2
Bar) at return port for satisfactory
operation
Wetted Material:
Rotor:
Hard anodized aluminum
Pressure Seals:
Brass
Shaft:
Stainless steel
Body Housing:
Anodized aluminum
Bearings:
Carbon steel
Standard O-rings:
Buna N, others available
Back-up Rings:
Teflon®
Pressure Drop:
14 psi (0.96 bar) at 20 ft/sec
See Supplemental Guide for more
detailed information
Proof Pressure:
1-1/2 times working pressure except
at return port
Burst Pressure:
2-1/2 times working pressure
except at return port (3000 psi [206
bar])
-40° to +250°F (-40° to +121°C)
* See product configurator for additional options.
Main Valve
Port Size
1/4" & 3/8"
1/2" & 3/4"
1
Flow Capacity (Approx.)
Service: Oil
20 ft/sec 40 ft/sec 60 ft/sec
gpm
gpm
gpm
(l/min)
(l/min)
(l/min)
Use
5 (19)
10 (38)
Heavy
Duty
14 (53)
28 (106)
Valve
Min. Flow
Cv
Passage
Factor
Dia.
Approx.
Shipping
Weight
lbs (kgs)
5/16"
1.56
1 1/2 (0.7)
17/32"
4.80
3 (1.4)
High Pressure OEM Manipulator Valves
Series 6900, 6940
Technical Drawings
6900 Series
6940 Series
6900 Series In-Line (side) Porting
Port Size
A
B
C
C1
D
E
F
G
Dia.
NPT
G1
Dia.
H
J
J1
1/4" & 3/8"
2.63 (66.8)
5.44 (138) 6.38 (161.9) 6.718 (170.6) 1.81(46.0) 5/16 - 18 NC 2.31(58.7)
0.44 (11.2)
1.91(48.5)
0.56 (14.2
2.66 (67.6)
3.03 (77.0)
1/2" & 3/4"
3.5 (88.9)
5.44 (138)
3.03 (77.0)
0.56 (14.2)
2.56 (65.0)
0.88 (22.4)
3.38 (85.9)
3.94 (100)
F
G
Dia.
G1
Dia.
H
J
J1
7.37 (187)
6940 Series Straight (bottom) Porting
Port Size
A
B
C
7.93 (201)
2.56 (65.0) 3/8 - 16 NC
D
C1
E
NPT
1/4" & 3/8"
2.63 (66.8)
5.44 (138)
6.13 (156)
6.50 (165)
1.81(46.0) 5/16 - 18 NC 2.66 (67.6)
0.44 (11.2)
1.91(48.5)
1.50 (38.1)
3.00 (76.2)
3.38 (85.9)
1/2" & 3/4"
4.19 (106)
5.44 (138)
7.34 (186)
7.91 (201)
2.56 (65.0) 3/8 - 16 NC
0.56 (14.2)
2.56 (65.0)
2.50 (65.5)
4.22 (107)
4.78 (121)
3.88 (98.6)
Dimensions in inches (mm)
Product Configurator
Example:
690
2
R
3
H
C
3
Series
690
694
Regular (side) porting, manipulator
Options
flow pattern
Straight (bottom) porting,
manipulator flow pattern
Port Size
Pressure
3
See Supplemental
Guide for complete list
3,000 psi
Working Media
Options
1
1/4” NPT ports
2
3/8” NPT ports
-A
3
1/2” NPT ports
-MC
4
3/4” NPT ports
Style
R
Regular (side) porting (series 690)
S
Straight (bottom) porting (series 694)
H
Hydraulic oil
Flow Pattern
C
Closed center manipulator (float center)
O
Open center (tandem center)
-NF
SAE Porting
Spring centering
Non-interflow (port size 1/4”
and 3/8” NPT only)
Position
3
3-position
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0057-A • 11/08 • ©2008 • Printed in the U.S.A.
2
Valves
Heavy Duty Valves
Series 140, 200, 920, 5620
Patent# 2.696.219
Features
Shear-Seal®
Original
technology
High velocity flow
Tolerates contaminates
Low handle load at high pressures
Spring return option
Low pressure drop
Applications
Land-based and offshore drilling equipment
Steel mills
Nitrogen charging panels
Refineries and chemical processing plants
Power generation facilities
General Specifications*
Working Pressure:
Air (pneumatic) up to 4,000 psi (276 bar)
hydraulic oil or lubricated water up to
6,000 psi (413 bar)
Media Temperature
Range:
-40° to +250°F (-40° to +121°C)
Rotor:
400 series stainless steel
Flow Capacity, Cv:
See table
Pressure Seals:
Stainless steel
Back Pressure:
Must not exceed 250 psi (17.2 bar) at
return port for satisfactory operation
Shaft:
Stainless steel
14 psi (0.96 bar) at 20 ft/sec
See Supplemental Guide for more
detailed information
Body:
Bronze
Housing:
Ductile iron
Standard O-ring:
Buna N, others available
Back-up Rings:
Teflon®
Pressure Drop:
Proof Pressure:
1-1/2 times working pressure except at
return port
Burst Pressure:
2-1/2 times working pressure except at
return port (3,000 psi [206 bar])
* See product configurator for additional options.
Flow Capacity (Approx.)
Service: Oil and Lubricated Water
140/920
Series
Valve
200/562
Series
Valve
1
Main Valve
Port Size
20 ft/sec
gpm (l/min)
40 ft/sec
gpm (l/min)
1/4”
3 (11)
6 (23)
3/8” & 1/2”
9 (34)
19 (72)
60 ft/sec
gpm (l/min)
Min. Flow
Passage Dia.
Cv
Factor
Approx. Shipping
Weight lbs (kgs)
9 (34)
1/4”
0.95
4.5 (2)
28 (106)
7/16”
3.20
8.5 (3.9)
3/4” & 1”
25 (95)
50 (189)
75 (284)
23/32”
9.20
21.5 (9.8)
1-1/2”
57 (217)
114 (433)
171 (650)
1-3/32”
21.00
48.5 (22)
1/4”
3 (11)
6 (23)
9 (34)
1/4”
0.95
4.5 (2)
1/2”
5 (19)
10 (38)
15 (57)
5/16”
1.60
8.5 (3.9)
1”
9 (34)
19 (72)
28 (106)
7/16”
3.20
21.5 (9.8)
Heavy Duty Valves
Series 140, 200, 920, 5620
Technical Drawings
E (4 TAPPED HOLES)
PANEL MOUNTING STUDS
CYL. 2
PRESSURE
H
J-1
PANEL
MOUNTING
STUDS
OPTIONAL
H
J
F
PANEL
MOUNTING
STUDS
OPTIONAL
PRESSURE
F
CYL. 1
A D
G
DIA.
B
CL PORTS
D
A
G-1
DIA.
RETURN
CL PORTS
C
RETURN
C-1
PANEL MOUNTING
DIMENSIONS
SPRING CENTERED
DIMENSIONS in inches (mm)
Port
Size
NPT
A
B
C
C-1
D
E
G
Dia.
F
G-1
Dia.
H
J
J-1
1/4”
2.6 (66.0)
5 (127.0)
4.7 (119.4)
4.87 (124)
1.8 (48.3)
3/8 - 16 NC
2.6 (66.0)
0.7 (17.8)
1.9 (48.3)
0.6 (15.2)
2.9 (73.7)
3/8” & 1/2”
3.3 (83.8)
7.0 (177.8)
6.8 (173)
6.8 (173)
2.4 (61.0)
3/8 - 16 NC
3.5 (88.9)
1.1 (27.9)
2.6 (66.0)
0.7 (17.8)
4.0 (101)
3.1 (79.3)
3.9 (99.1)
3/4” & 1”
4.6 (116.8)
10.0 (254.0)
8.7 (221.0)
9.9 (251.5)
3.6 (91.4)
1/2 - 13 NC
4.8 (121.9)
1.3 (33.0)
3.6 (91.4)
1.0 (25.4)
5.2 (132.1)
6.4 (162.6)
1-1/2” *
6.8 (172.7)
12.0 (304.8)
10.5 (266.7)
11.8 (299.7)
5.3 (134.6)
3/4 - 10 NC
6.2 (157.5)
1.3 (33.0)
3.6 (91.4)
1.5 (38.1)
6.5 (165.1)
7.8 (198.1)
* 1 1/2” available in 140 and 920 Series only
Product Configurator
Example:
20
3
P
6
W
C
3
Series
14
Basic 140 series valve (3,000 psi)
20
Basic 200 series valve (6,000 psi)
92
Basic 920 series valve (3,000 psi
manipulator)
562
Basic 5620 series valve (6,000 psi
manipulator)
Options
Working Media
A
Air (pneumatic)
W
Lubricated water
or hydraulic oil
Port Size
1
1/4” NPT ports
2
3/8” NPT ports (Series 140 & 920 only)
3
1/2” NPT ports
4
3/4” NPT ports (Series 140 & 920 only)
5
1” NPT ports
7
1-1/2” NPT ports (Series 140 & 920 only)
-
See Supplemental
Guide for complete
list
Flow Pattern
C
Closed center (Series 140, 200)
O
Open center (tandem center)
(Series 140, 200)
Q
Manipulator (float center)
(Series 920, 5620)
Port Location
R
Regular (side) porting
P
Panel mount with side porting
Position
3
Pressure Range
3
6
3,000 psi lubricated water or hydraulic,
2,000 psi air (14 & 92 Series)
6,000 psi lubricated water or hydraulic,
4,000 psi air (20 & 562 Series)
Three position
Options
-MC
Spring centering *
-MS
SAE Porting
* For 1” ported valve pressure rating 1,500 psi
Not available on 1-1/2” ported valves
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0035-F • 11/08 • ©2008 • Printed in the U.S.A.
2
Valves
Subplate Mounted Heavy Duty Valve
Series 3760
Patent # 2.696.219
Features
Original Shear-Seal® technology
Convenient sub-plate manifold mounting
Low pressure drop
High velocity flow
Tolerates contaminates
Low handle load at high pressures
Applications
Steel mills
Shipboard hydraulic control systems
Refineries and chemical processing plants
Power generation facilities
General Specifications*
Working Pressure:
Hydraulic oil or lubricated
water up to 4,500 psi (310 bar)
Flow Capacity, Cv:
See table
Back Pressure:
Must not exceed 250 psi (17.2
Bar) at return port for satisfactory
operation
Pressure Drop:
14 psi (0.96 bar) at 20 ft/sec
* See Supplemental Guide for more
detailed information
Wetted Material:
Rotor:
400 series stainless steel
Pressure Seals:
Stainless steel
Shaft:
Stainless steel
Body:
Bronze
Housing:
Ductile iron
Proof Pressure:
1-1/2 times working pressure except
at return port
Standard O-rings:
Buna N, others available
Burst Pressure:
2-1/2 times working pressure except
at return port (3,000 psi [206 bar])
Back-up Rings:
Teflon®
Subplates: (Optional)
Carbon steel
Media Temperature
Range:
-40° to +250°F (-40° to +121°C)
* See product configurator for additional options.
Flow Capacity (Approx.)
1
Approx.
Service: Oil and Lubricated Water
Min. Flow
Main Valve
20 ft/sec
40 ft/sec
60 ft/sec
Passage
Cv
Weight
Port Size
gpm (l/min)
gpm (l/min)
gpm (l/min)
Dia.
Factor
lbs (kgs)
Shipping
3760
1/2"
9 (34)
19 (72)
28 (106)
7/16"
3.20
8.5 (4.5)
Series
1"
25 (95)
50 (189)
75 (284)
23/32"
9.20
24 (10.9)
Valve
1-1/2"
57 (217)
114 (433)
171 (650)
1-3/32"
21.00
53 (24)
Subplate Mounted Heavy Duty Valve
Series 3760
Technical Drawings
H
Q
DIA.
4 PLACES
J
L
K
K
L
J
N
4 PLACES
0 DIA.
4 PLACES
H
J
R
M
S1
S
F
M
J
T-1 DIA.
B1
T DIA.
B
P DIA.
M 4 PLACES
K
K
G
A-1
A
G
CYL. 1
CYL. 1
SPRING
CENTERED
D
M
PRESSURE
CYL. 1
Optional
Sub Plate
E
C DIA.
(4 PLACES)
RETURN
CYL. 2
Valve Dimensions - inches (mm)
Size
1/2"
1"
1-1/2"
A
7.00 (178)
10.0 (254)
12.00 (305)
B-1
A-1
B
C
D
E
F
S
S-1
9.00 (229) 5.81 (148) 6.06 (154) 0.47 (12) 3.44 (87) 5.44 (138) 3.56 (90) 3.94 (100) 4.06 (103)
14.0 (356) 7.63 (194) 8.81 (224) 0.75 (19) 4.75 (121) 6.88 (175) 4.81(122) 5.13 (130) 6.19 (157)
14.0 (356) 8.75 (222) 10.0 (254) 1.25 (32) 6.81 (173) 9.38 (238) 5.94 (151) 6.25 (159) 7.5 (191)
T
1.06 (27)
1.25 (32)
1.25 (32)
T-1
2.63 (67)
3.56 (90)
3.56 (90)
SubPlate Dimensions - inches (mm) Options:
Port Type
Size
NPT
1/2"
Socket Weld
NPT
1"
Socket Weld
NPT
1-1/2"
Socket Weld
NPT
2"
Socket Weld
Sub Plate
p/n
34013
34011
34015
34012
34016
34014
34018
34017
G
H
J
K
L
M
N
O
P
Q
6.0 (152)
6.0 (152)
8.0 (203)
8.0 (203)
10.0 (254)
10.0 (254)
10.0 (254)
10.0 (254)
3.0 (76)
3.0 (76)
4.0 (102)
4.0 (102)
5.0 (127)
5.0 (127)
5.0 (127)
5.0 (127)
2.19 (56)
2.19 (56)
2.88 (73)
2.88 (73)
4.0 (102)
4.0 (102)
4.0 (102)
4.0 (102)
0.78 (20)
0.78 (20)
1.25 (32)
1.25 (32)
1.94 (49)
1.94 (49)
1.94 (49)
1.94 (49)
1.19 (30)
1.19 (30)
1.81 (46)
1.81 (46)
2.69 (68)
2.69 (68)
2.69 (68)
2.69 (68)
1.41 (36)
1.41 (36)
1.97 (50)
1.97 (50)
2.69 (68)
2.69 (68)
2.69 (68)
2.69 (68)
3/8 N.C.
3/8 N.C.
1/2 N.C
1/2 N.C
5/8 N.C.
5/8 N.C.
5/8 N.C.
5/8 N.C.
0.41 (10)
0.41 (10)
0.53 (13)
0.53 (13)
0.53 (13)
0.53 (13)
0.53 (13)
0.53 (13)
1/2 NPT
.855 C'Bore
1" NPT
1.330 C'bore
1 1/2 NPT
1.915 C'bore
2" NPT
2.406 C'bore
1.25 (32)
1.25 (32)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
Product Configurator
Example:
376
5
M
3
W
C
R
WT.
0.44 (11)
11 3/4
0.44 (11)
0.72 (19)
32 1/2
0.72 (19)
1.22 (31)
49
1.22 (31)
1.22 (31)
49
1.22 (31)
3
Series
Options
Basic 376 series
376
See Supplemental Guide
for complete list
valve
Port Size
3
1/2” NPT ports
5
1” NPT ports
7
1-1/2” NPT ports
Working Media
W
Lubricated water or
hydraulic
-MC
Flow Pattern
Style
M
Manifold porting
Options
C
Closed center
O
Open center (tandem center)
Q
Closed center manipulator
-H
Spring centering *
4,500 psi rated
* For 1” ported valve pressure rating 1,500 psi
Not available on 1-1/2” ported valves
Pressure Range
3
3,000 psi lubricated water
Position
or hydraulic oil
3
3-position
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0037-D • 11/08 • ©2008 • Printed in the U.S.A.
2
Valves
Series II Valve
Models A14 and H14
Patent# US D521.599 S
Patent# US D521.598 S
Features
Original Shear-Seal® technology
Integrated actuator
2- and 3-position
Superior shifting performance
High velocity flow
Compact design
Corrosion resistant materials
Applications
Land-based & offshore oil drilling controls
BOP control units
Steel mills
Shipboard hydraulic control systems
Industrial hydraulic power units
Refineries and chemical processing plants
General Specifications*
- Pilot Actuator
- Main Valve
Working Pressure:
Working Pressure:
Air:
Hydraulic up to 3,000 or 6,000 psi
(206 bar or 413 bar)
Air up to 4,000 psi (276 bar)
80 psi (5.2 bar) minimum
250 psi (17.2 bar) maximum
500 psi (34 bar) minimum
1,500 psi (103 bar) maximum
Hydraulic (2-position only):
Flow Capacity, Cv:
See table
Back Pressure:
Must not exceed 250 psi (17.2 bar) at
return port for satisfactory operation
Proof Pressure:
1-1/2 times working pressure except
at return port
Burst Pressure:
2-1/2 times working pressure except
at return port (3,000 psi [206 bar])
Porting:
1/4” NPT
Media Temperature Range: -40° to +250°F (-40° to +121°C)
Speed of Operation:
Shift time for 90° must be 1/2
second minimum to avoid damage
Body, Housing, End Plate:
Al-Ni Bronze
20 ft/s –14 psi; 6.1 m/s – 1 bar
40 ft/s – 58 psi; 12.2 m/s – 4.0 bar
60 ft/s – 130 psi; 18.3 m/s – 9.0 bar
Cylinder:
Amalga tubing (air)
Stainless steel (hydraulic)
Shaft:
Stainless steel
Media Temperature
Range:
-40° to +250°F (-40° to +121°C)
Hardware:
Stainless steel
Handle:
Zinc plated alloy steel
Wetted Materials:
Standard O-Rings:
Back-up Rings:
400 Series Stainless Steel
Buna N
Teflon®
Rotor, Seals:
400 series stainless steel
Handle Detent:
All valves have 3-position detents for
manual shift to Center position
Pressure Drop
(all Valves):
2-POSITION FLOW PATTERN SELECTOR
Standard for 1/4”- 1/2” valves
Consult Factory for 3/4” & 1” valves
HANDLE ORENTATION (AS SHOWN CCW)
(ACTUATOR PORT 'A' PRESSURIZED)
A
MAIN VALVE
1 2
AB C
2
P R
PILOT VALVE 4-WAY
Service: Oil and Lubricated Water
14, 92
Series
Valves
20, 562
Series
Valves
Main Valve
20 ft/sec 40 ft/sec 60 ft/sec
Min. Flow
Port Size NPT gpm (l/min) gpm (l/min) gpm (l/min) Passage Dia.
1/4"
3 (11)
6 (23)
9 (34)
1/4"
3/8" & 1/2"
9 (34)
19 (72)
28 (106)
7/16"
3/4" & 1"
25 (95)
50 (189)
75 (284)
23/32"
1/4"
3 (11)
6 (23)
9 (34)
1/4"
1/2"
5 (19)
10 (38)
15 (57)
5/16"
1"
9 (34)
19 (72)
28 (106)
7/16"
Cv
Factor
0.95
3.20
9.20
0.95
1.60
3.20
Approx.
Shipping
Weight
30
35
50
30
35
50
R P
P R
PILOT VALVE 4-WAY
C
R
P
PILOT VALVE 3-WAY
CLOSED CENTER MANIPULATOR FLOW PATTERN
(VIEWED FROM SHAFT END)
CYL1
CYL1
RET
PRESS
CYL1
RET
PRESS
RET
PRESS
CYL2
CYL2
HANDLE ORENTATION (AS SHOWN CW)
(ACTUATOR PORT 'B' PRESSURIZED)
HANDLE CENTERED
(MANUALLY OVERRIDE ONLY)
HANDLE ORENTATION (AS SHOWN CW)
(ACTUATOR PORT 'A' PRESSURIZED)
MAIN VALVE
1 2 1 2 1 2
A
R P R P
1
2
P R
PILOT VALVE 4-WAY
1
CYL2
HANDLE ORENTATION (AS SHOWN CW)
HANDLE CENTERED
HANDLE ORENTATION (AS SHOWN CCW)
(ACTUATOR PORT 'B' & ‘C’ PRESSURIZED) (ACTUATOR PORT 'A' & ‘C’ PRESSURIZED) (ACTUATOR PORT 'A' PRESSURIZED)
(PORTS ‘A’ VENTED)
( PORT ‘B’ VENTED)
(PORTS ‘B’ & ‘C’ VENTED)
C1 C2
Flow Capacity (Approx.)
RET
PRESS
CYL2
B
R P
1
CYL1
RET
PRESS
CYL2
MAIN VALVE
1 2
* See product configurator for additional options.
RET
PRESS
CYL2
HANDLE ORENTATION (AS SHOWN CW)
(ACTUATOR PORT 'B' PRESSURIZED)
CYL1
CYL1
RET
PRESS
RET
PRESS
(VIEWED FROM SHAFT END)
CYL1
CYL2
Panel Mounting:
3-POSITION FLOW PATTERN SELECTOR
(VIEWED FROM SHAFT END)
CYL1
B
Series II Valve
Models A14 and H14
Technical Drawings
2-Position Valve
A
E
P
P
PANEL MOUNT
N
(4 PLACES)
3-Position Valve
3.40
PANEL CUTOUT
D
D
L
L
C
A
D
C
B
H
D
B
R
Q
J
C
PANEL
MOUNT
N
(3)
C
B
H
T
M
S
B
U
9
A
2X 1/2-13 UNC-2B 1.00
PANEL MOUNTING HOLES
A
K
K
G
F
K
G
F
1/4”, 3/8”, 1/2”
9.509
3/4”, 1"
Porting
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
T
U
1/4” NPT
2.75
(60.3)
10.38
(254.0)
2.0
(50.8)
1.0
(25.4)
5.0
(127.0)
5.72
(146.1)
4.25
(108)
.50
(12.7)
3.34
(85)
3.25
(82.6)
1.94
(49.2)
9.43
(231.7)
3/8-16UNC
4.88
(124.0)
7.44
(189.0)
2.44
(62)
3.75
(95.3)
8.44
(214.4)
10.468
(265.9)
3/8” & 1/2”
NPT
3.406
(86.5)
10.937
(277.8)
2.625
(66.7)
1.312
(33.3)
5.0
(127.0)
6.25
(158.8)
4.75
(120.65)
.688
(17.46)
3.531
(89.7)
3.25
(82.6)
1.94
(49.2)
9.531
(242.1)
3/8-16UNC
5.50
(139.7)
7.85
(199.3)
2.56
(65.1)
3.88
(98.4)
8.688
(220.7)
10.25
(260.4)
3/4” & 1”
NPT
4.781
(121.4)
14.375
(365.1)
3.625
(92)
1.812
(46)
9.0
(228.6)
8.75
(222.3)
6.562
(166.6)
1.0
(25.4)
4.25
(108)
3.50
(88.9)
3.0
(76.2)
12.0
(482.0)
1/2-13UNC
7.562
(192.0)
10.125
(257.0)
NA
NA
NA
NA
Example:
A
20
3
Product Configurator
R
6
W
C
3
Actuator Media
A
Air cylinder
H
Hydraulic cylinder
Optional O-ring Material
-Zxx
See supplemental guide
Series
14
3,000 psi (206 bar), 4-way selector or diverter
20
6,000 psi (412 bar), 4-way selector or diverter
92
3,000 psi (206 bar), 4-way closed center
manipulator
562
6,000 psi (412 bar), 4-way closed center
manipulator
376
3,000 psi (206 bar), 4-way sub-plate mount
Port Size
1
1/4” NPT
2
3/8” NPT (14 and 92 series only)
3
1/2” NPT
4
3/4” NPT (14 and 92 series only)
5
1” NPT
Pressure Range
3
3,000 psi lubricated water
or hydraulic oil, 2,000 psi air
(14, 92 & 376 Series)
6
6,000 psi lubricated water
or hydraulic oil, 4,000 psi air
(20 & 562 series)
Regular side porting
M
Manifold porting (376 series only)
-B
W
Lubricated water or hydraulic oil
A
Air or other gasses
Flow Pattern
Position Indicator
-C
3 x 2 converter
-H
4,500 psi working pressure
-M
5,000 psi working pressure
-D
Working Media
Diverter flow pattern
-MS
SAE Porting
-Zxx
Optional O-ring material1
Position
C
Closed center
2
2-position actuator, 90º rotation
O
Open center (tandem center)
3
3-position actuator
Q
Closed center manipulator
Standard on 92 and 562 series
Optional on 376 Series in closed center only
Not available on 14 and 20 Series
Port Location
R
Options
1
See Supplemental Guide for the appropriate
“Z number”
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0022-I • 02/09 • ©2009 • Printed in the U.S.A.
2
Valve
Explosion Proof Position Indicator
Model 371MT7
Reliable valve position feedback for Series II Valve
Features
Fits all Series II valves
2 position and 3 position
30 VDC max, 500 mA (PLC compatible)
Designed for Division I and I.S. use
UL & ATEX approved
NEMA 4X, IP67
Applications
Valve status output
BOP closing unit ‘OPEN-CLOSE’ signal
Hydraulic power units
UL &
ATEX
appr
oved
General Specifications*
Housing Material:
Stainless steel
Enclosure:
NEMA 4X, IP67
Electrical Rating:
30 VDC max, 500 mA (carry current)
Electrical Connection: ½” NPT rotating female conduit
connection with 3 ft (36 in) cable
Electrical Cable:
UL listing, 4 conductors, 22
AWG TPE flame resistant jacket.
Resistance to oils, fuels, and solvents
Maximum Contact
Resistance:
100 milliohms
Dielectric:
100 megaohms minimum
(@ 250 VDC)
Switch Type:
Approvals:
Division 1, Class 1, Groups A, B, C & D
Ex d ia IIc T6
Intrinsically safe to 24 VDC, 50 mA,
10 W
Valve Position
Feedback:
2-Way
3-Way
Operating Temperature:
-40 to +185°F (-40 to 85°C)
Installation Instructions:
- Connect electrical wires
- Lightly lubricate the position
indicator O-rings (2)
- Fully insert switch into stop screw
- Rotate position indicator for
optimum cable exit
- Secure set screws (2)
Weight:
2 lbs.
SPST
* See Product Configurator for additional options.
Wiring Code
CYLINDER 2/ORANGE
CENTER/RED
CYLINDER 1/BROWN
COMMON/BLACK
CASE GROUND - DRAIN
1
Explosion Proof Position Indicator
Model 371MT7
Reliable valve position feedback for Series II Valve
Technical Drawings
57.2
1.45
36.8
2X
1.26
32
FLATS
1 9/16-12 UN-2A
2.95
75
371MT75
.50
12.7
O-RING
BUNA-N
.24
6
1.22
31
1.54
39
FLATS
2X .87
22
3.6
91.4
GROUND SCREW
8-32 UNC-2A
JAM NUT
UL/ATEX NAMEPLATE NOT SHOWN
CONDUIT
NAMEPLATE
1.06
26.9
FLATS
1.375
34.9
4X 10-24 UNC-2A X .31
SOCKETHEAD SETSCREW, CUP POINT
1.65
42
UL/ATEX NAMEPLATE
2.09
53
CABLE 5
1/2 NPT THREAD
2.09
53
1.65
42
1.65
42
1.13
28.6
1.45±.010
36.8±0.25
1.73
44.0
1.417
36
8
1.417
36
.83
21.0
1.65
42
2.83
72.0
371MT73
1.54
39.0
1.42
36.0
CABLE 5
.24
6.0
3/4-16 UNF 2A
JAM NUT
6X #10-24 UNC X .31 LG
SET SCREW
2.81
71.4
.50
12.7
GROUND
SCREW
8-32 UNC-2A
(2) O-RINGS
(BUNA-N)
2.28
58.0
3.60
91.4
1/2 NPT MALE THREADS
8
1.38
34.9
1.26
32.0
1.65
42.0
.91
23.0
2.28
58.0
1.06
26.9
Product Configurator
When ordering together
with Series II Valves
Example:
When ordering separately
as replacement or spare part
CABLE 5
1.85
47.0
.91
23.0
FITTING - JAM NUT
8
STOP SCREW TO REMAIN IN VALVE
DO NOT REMOVE
1.38
34.9
Series II Valve part number
-B
Base Model
Optional Cable Length
-B
Position indicator for ¼” and ½” Series II valves
-B
Position indicator for 1” and 1½” Series II valve
Example:
371MT7
Additional cable length
(in inches)
3
Base Model
371MT7
XXX
Optional Cable Length
Position indicator
-Wxxx
Additional cable length
(in inches)
Size
3
Fits ¼” and ½” Series II valves
5
Fits 1” and 1-1/2” Series II valves
Example:
When ordering to retrofit
existing valves without -B option Size
371MT73-KIT
Optional Cable Length
371MT73-KIT
Fits ¼” and ½” Series II valves
371MT75-KIT
Fits 1” Series II valves
-Wxxx
Additional cable length
(in inches)
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0053-C • 02/11 • ©2011 • Printed in the U.S.A.
2
Valves
High Pressure Valve
Series 4140
Features
Original Shear-Seal® technology
Stainless steel construction
Low pressure drop
High velocity flow
Pressures to 15,000 psi
Low handle load
Applications
Offshore drilling equipment
Refineries and chemical processing plants
Gas compression systems
Marine umbilical reels
General Specifications*
Working Pressure:
Standard to 10,000 psi (690 bar)
Optional to 15,000 psi (1,034 bar) (on 1/4”
model only)
Media Temperature
Range:
-40° to +250°F (-40° to +121°C)
Rotor:
400 series stainless steel
Flow Capacity, Cv:
See table
Pressure Seals:
Stainless steel
Back Pressure:
Must not exceed 250 psi (17.2 bar) at return
port for satisfactory operation
Shaft:
Stainless steel
Pressure Drop:
14 psi (0.96 bar) at 20 ft/s
Body, Housing:
300 series stainless steel
Proof Pressure:
1-1/2 times working pressure except at
return port
Standard O-ring:
Buna N
Back-up Rings:
Teflon®
Burst Pressure:
2-1/2 times working pressure except at
return port (3,000 psi [206 bar]) maximum
* See product configurator for additional options and Supplemental Guide for more detailed information.
Flow Capacity (Approx.)
Service: Oil and Lubricated Water
Main Valve
Port Size
1
20 ft/sec
gpm (l/min)
40 ft/sec
gpm (l/min)
60 ft/sec
gpm (l/min)
Min. Flow
Passage Dia.
Cv
Factor
Approx. Shipping
Weight lbs (kgs)
1/4”
4 (15)
8 (30)
12 (45)
9/32”
0.95
13.5 (6.2)
1/2”
4 (15)
8 (30)
12 (45)
9/32”
0.95
13.5 (6.2)
1”
9 (34)
19 (72)
28 (106)
7/16”
3.20
29.5 (13.5)
High Pressure Valve
Series 4140
Technical Drawings
B
2.50
DIA.
E DIA.
(4 HOLES)
CYL. 2
1.06
DIA.
.31
C
.25
MOUNTIN
PLATE
J
D
G
F
PRESSURE
D
CL PORTS
CYL. 1
G
H
K
(TYP.)
RETURN
A
DIA.
Port
Size
A
Dia.
B
C
D
E
Dia.
F
G
H
J
K
1/4”
3.50 (89)
7.00 (178)
7.69 (195)
3.25 (83)
0.28 (7)
4.22 (107)
4.00 (102)
0.63 (16)
5.81(148)
1.63 (41)
1/2”
3.50 (89)
7.00 (178)
7.69 (195)
3.25 (83)
0.28 (7)
4.22 (107)
4.00 (102)
0.63 (16)
5.81(148)
1.63 (41)
1”
4.50 (114)
9.00 (229)
10.69 (272) 4.00 (102)
0.34 (9)
5.84 (148)
5.00 (127)
1.00 (25)
8.81(224)
2.03 (52)
Product Configurator
Example:
414
1
R
9
A
C
3
Series
414
Basic 3 position 4 way
Port Size
1
1/4” NPT ports
3
1/2” NPT ports
5
Operating Pressure
10,000 psi
9
Options
-MC
Spring centering *
-MS
SAE Porting
* Not available on 1” ported valves
1” NPT ports
Service
A
Style
R
Air, lubricated water or hydraulic oil
Regular (side) porting
Position
Flow Pattern
C
Closed center
O
Open center (tandem center)
3
Three position
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0038-E • 11/08 • ©2008 • Printed in the U.S.A.
2
Valves
MicrotorqueTM Valve
518, 526 Series
Features
Original Shear-Seal® technology
Compact design
Non-interflow option
Spring return option
Multiple handle types
2 or 3 position detent
Applications
Work holding clamps and systems
Hydraulic presses and lifting systems
Hydraulic test equipment
Grease injection equipment
Hydraulic power units
General Specifications*
Media:
Hydraulic oil
Working Pressure:
6,000 psi (415 bar) **
Detent:
2-position:
Flow Capacity, Cv:
See table
3-position:
Back Pressure:
Must not exceed 250 psi (17.2
bar)*** at return port for satisfactory
operation
Detents at center and 2 extreme
positions
Optional Spring Return:
Available to center or either
shifted position
5,000 psi (345 bar) max working
pressure on spring return option
Body & Housing:
Anodized aluminum
Shaft, Rotor, Pressure
Seals:
400 series stainless steel
Standard O-Rings:
Buna N, others available
Proof Pressure:
1-1/2 times working pressure except
at return port
Burst Pressure:
2-1/2 times working pressure except
at return port
Detent at 90° positions
Media Temperature
Range:
-40° to +250°F (-40° to +121°C)
Porting:
1/4” NPT, SAE for 1/4” tubing, or DO3
pattern for manifold mounting
Back-up Rings:
Teflon
Bearings:
Hardened steel
Mounting:
Panel mountable with p/n 22357
mounting nut (-P option)
DO3 Manifold mounting shipped with
(4) #10-24 screws and O-Rings
Shipping Weight:
.95 lbs
Handle Rotation:
90°; 45° each side of center position
OPEN (TANDEM) CENTER
PRESS
PRESS
CYL 1 CYL 2
CYL 2
RET
518 Series
Interflow
526 Series
Non-Interflow
1
2
Min. Flow
Passage Dia.
Cv
Factor
1.4 (5.6)
2.8 (11)
0.17"
0.40
0.36 (1.4)
0.72 (2.7)
0.086"
0.09
1
P
R
CYL 1
RET
CLOSED CENTER
1
R
PRESS
PRESS
PRESS
RET
RET
CYL 1
CYL 1 CYL 2
CYL 1 CYL 2
CYL 2
P
2
PRESS
CYL 1 CYL 2
RET
Flow Capacity (Approx.)
20 ft/sec
40 ft/sec
(6.1 m/s)
(12.2 m/s)
gpm (l/min)
gpm (l/min)
RET
RET
RET
CLOSED CENTER MANIPULATOR
CYL 1
CYL 1 CYL 2
CYL 1 CYL 2
CYL 2
PRESS
PRESS
PRESS
* See product configurator for additional options.
** Consult factory for pressure up to 10,000 psi (690 bar)
*** For requirements in excess of 250 psi (17.2 bar) at return port consult factory
2
1
P
R
RET
MicrotorqueTM Valve
518, 526 Series
Technical Drawings
M
PANEL
E
"PRESSURE"
PORT
1.062
(27)
"CYL.1" PORT
1.125
(29)
"PRESSURE"
PORT
F
J
(4 PLACES)
N
"CYL.2" PORT
"CYL.2" PORT
.562 (14)
1.0
(25)
D
1.437
(37)
P
Q
.562 (14)
REGULAR (SIDE) PORTING
PANEL CUTOUT
H
"RETURN" PORT
"CYL.1" PORT
"RETURN" PORT
G
C
1.125
(29)
.250
(7)
MAX. PANEL
THICKNESS
ø 1.250
(31.8)
STRAIGHT (BOTTOM) PORTING
L
K
Ø.16 X .16 DEEP
1.594
(40.5)
"PRESSURE"
PORT
Regular and Straight Porting
.850
(21.6)
"CYL.2" PORT
.450
(11.4)
1.220
(31.0)
.410
(10.4)
.610
(15.9)
"CYL.1" PORT
"RETURN" PORT
.345
(8.8)
.640
(16.3)
J
(4 PLACES)
B
.820 (20.8)
1.260
(32.5)
2.375 (60.3)
P
A
.206 THRU (5.2)
4 PLACES
Q
M
.690
(17.5)
MANIFOLD PORTING
(Mounting per DO3 Spec)
1.312
(33.3)
L
ø 1.250
(31.8)
Series Porting
518
or
526
21R , 61S Porting
41M Manifold Porting
A
1.968
(50.0)
1.968
(50.0)
B
2.031
(51.6)
2.031
(51.6)
C
D
1.281 .640
(32.5) (16.3)
E
F
G
1.594 .850 1.219
(40.5) (21.6) (31.1)
Spring Return Option
Product Configurator
Example:
518
Optional Knob (-E)
K
41M
6
H
J
K
.610 1/4-28 3.812
(15.5) UNF (96.8)
10-24 3.875
UNC (98.4)
5.562
(141.3)
H
C
L
M
1.437 1.781
(36.5) (45.2)
1.437 1.406
(36.5) (29.0)
2.500
(63.3)
N
.437
(11.1)
P
1.375
(34.9)
1.375
(34.9)
Q
3.125
(79.4)
3.125
(79.4)
5.437
(138.1)
3
Series
518
Interflow
526
Non-interflow
Position
-Zxx
Optional O-ring material 2
Working Media
Porting
H
Hydraulic oil
Options
-MC
21R
Regular (side) porting
41M
Manifold porting (D03)
61S
Straight (bottom)
Porting
Flow Pattern
-MR
C
4-way closed center
O
4-way open center
M
1
2
6,000 psi
5,000psi max working pressure for spring return option
See supplemental guide for the appropriate “Z number”
Spring return to right
(Pressure port to C1) 1
Spring return to left
(Pressure port to C2) 1
4-way manipulator
Closed center
Pressure Range
6
-ML
Spring return to center 1
-MS
-E
Detent Position
2
2-position 90° rotation
3
3-position
-P
SAE porting for 1/4” tubing
Black knob (not available
with spring return)
Panel mounting nut p/n
22357
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0020-E • 09/07 • ©2007 • Printed in the U.S.A.
2
Valves
Shear-Seal® Directional Control
Series 422 Solenoid Valve
Features
Original Shear-Seal® technology
Explosion-Proof option
Zero-leakage*
Spring close with no power
Flexible flow patterns
Tolerates contaminates
Applications
Mining operations
Offshore oil platforms
Refineries and chemical processing plants
Power generation facilities
Air or hydraulic test equipment
General Specifications**
Working Pressure:
Pressure Drop:
Air (pneumatic) up to 1,500 psi (103
bar)
Hydraulic oil or lubricated water, up to
3,000 psi (206 bar)
9 psi at 2.5 gpm
32 psi at 4 gpm
(For more detailed pressure drop and
flow capacity information, see valve
supplemental guide)
Electrical Data:
Solenoid Voltage:
115V AC at 60 Hz
(Alternative AC & DC voltages are
available).
Current - Inrush:
16.8 amps
Current - Holding:
1.52 amps
Voltage Tolerance:
±10% of rated voltage
Max. Fluid Velocity:
20ft/sec (6.1 m/sec)
Solenoid Rating:
Continuous duty
Cv Factor:
0.7
Min. Flow Diameter:
7/32 in. (5.6mm)
Material of Construction:
Slide:
400 series stainless steel
Back Pressure:
Must not exceed 250 psi (17.2 bar) at
return port for satisfactory operation
Body & Pressure Fittings:
Bronze
Proof Pressure:
1-1/2 times working pressure except
at return port
Pressure Seals:
Stainless Steel
Burst Pressure:
2-1/2 times working pressure except
at return port (3000 psi [206 bar])
Standard O-Ring:
Buna N
Back-up Rings:
Teflon®
Media Temperature
Range:
-40° to +250°F (-40° to +121°C)
Shipping Weight:
11.5 Lbs. / Explosion-Proof 20 Lbs.
* Less than four cc per minute
** See product configurator for additional options.
Flow Pattern
4-Way
*Plug Port
Marked “X”
None
3-Way
Shut-Off
Norm. Open
Norm. Closed
Norm. Open
Norm. Closed
Cyl. 2
Cyl. 1
Ret. & Cyl. 2
Ret. & Cyl. 1
Normal
Position
Spring Loaded
Energized
Position
ASA Symbol
These Flow Patterns are obtainable from a single Standard Valve. Every valve is shipped with the necessary plugs
*To acheive the desired flow pattern, plug ports as shown.
1
Diverter
Ret.
Shear-Seal® Directional Control
Series 422 Solenoid Valve
Technical Drawings
Porting: 3/8” NPT except return port 1/2” NPT
Solenoid
A
B
C
D
E
F
G
H
J
K
L
M
N
P
422
11.562
(293.7
1.312
(32.5)
3.875
(98.4)
1.625
(41.3)
.75
(19.1)
.75
(19.1)
1.50
(38.1)
1.156
(29.4)
2.875
(73.0)
1.281
(32.5)
4.125
(104.8)
1.187
(30.2)
.593
(15.1)
5.5
(138.7)
X422
14.437
(366.7)
3.593
(91.3)
3.875
(98.4)
1.625
(41.3)
.75
(19.1)
.75
(19.1)
1.50
(38.1)
1.156
(29.4)
2.875
(73.0)
1.281
(32.5)
5.00
(127)
1.187
(30.2)
.593
(15.1)
8.375
(212.7)
Product Configurator
Example:
422S3WS2A1
Prefix
X
Explosion-proof solenoid cover (optional)
Part Number
422S3WS2A1
Oil or lubricated water, 3,000 psi max, 115V AC
422S3AS2A1
Air , 1,500 psi, 115V AC
Alternative voltage and DC Solenoids are available. Consult factory for more detail
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0039-E • 11/08 • ©2008 • Printed in the U.S.A.
2
Valves
1/2” Heavy Duty Hydraulic Regulator
Series 20313
Features
Original Shear-Seal® technology
Self adjusting
High flow capacity
Tolerates contaminated media
Fail-safe motor control options
Applications
BOP Control Units
Coiled tube reels
Oil and gas systems
Pressure sensitive applications
General Specifications*
Pressure:
Supply/Inlet Pressure:
5,000 psi (345 bar)
Regulated Pressure Range:
High Sensitivity
Full Range
300 - 1600 psi (21 -110 bar)
300 - 3000 psi (21 - 207 bar)
Regulated Pressure Range
“F” Prefix Pneumatic
failsafe motor:
High Sensitivity
Full Range
Materials of Construction:
Body:
Flanges:
Spring Tower Housing:
Manual:
Pneumatic Motor model:
Hydraulic Motor model:
300 - 1600 psi (21 -110 bar)
300 - 3000 psi (21 - 207 bar)
Stainless Steel (standard)
Carbon Steel (standard)
Option: Stainless steel
Phosphate coated alloy steel (std.)
Phosphate coated alloy steel (std.)
Phosphate coated alloy steel (std.)
Option: Stainless Steel
Standard O’ring Material:
Buna N
Socket Head Screws:
Zinc plated alloy steel (standard)
Option: Stainless steel
Regulated Pressure Range
“G” Prefix Hydraulic
failsafe motor:
High Sensitivity
Full Range
300 - 1600 psi (21 -110 bar)
300 - 3000 psi (21 - 207 bar)
Wetted Parts:
Stainless steel & bronze
Fluid Temperature Range:
-40° to +250°F (-40° to +121° C)
Pneumatic Pilot Motor
(“F” prefix):
Pilot Motor Working Pressure:
80 - 120 psi (5.5 - 8.3 bar)
Proof Pressure:
7,500 psi (517 bar)
Porting:
1/4” NPT
Flow:
Flow Rate:
45 GPM (@ 50/ft/s)
Operating Temperature Range:
32° to +250°F (0° to +120°C)
Cv Inlet:
6.7
Cv Vent:
6.7
Hydraulic Pilot Motor
(“G” prefix):
Pilot Motor Working Pressure:
400 - 1600 PSI (6.9 - 110 bar)
Porting:
Inlet:
Porting:
SAE for 3/8” Tube (Size -6)
1/2” NPT Standard, SAE Option
Operating Temperature Range:
-40° to +250°F (-40° to +121°C)
Outlet:
1/2” NPT Standard, SAE Option
Approximate Shipping Weight:
Manual:
Vent:
21 lbs. (9.5 kg)
1/2” NPT Standard, SAE Option
Bleed Port:
1/4” Dia. hole
Pneumatic or Hydraulic
Motor:
44 lbs. (20.0 kg)
* See product configurator for additional options.
1
1/2” Heavy Duty Hydraulic Regulator
Series 20313
Technical Drawings
7.968
(202.2)
7.125
15.188
3.500
2.250
18.938
(481)
1/8” NPT
BLEED PORT
19.125
MAX(485.8)
1.750
9.281
(235.7)
4.500
1.500
1.75
(44.5)
2.375
4.750
2.500
(63.5)
2.500
.250
.250
2.500
(63.5)
1.562
2.250
Dimensions in inches (mm)
Product Configurator
Example:
20313S6WQ2
Option
Blank
NPT porting
-MS
SAE porting
-SS
Stainless Steel Flanges & Trim
Adjustment Method
Blank
Manual
Regulated Pressure Range (Manual)
F
Pneumatic motor
G
Hydraulic motor
Blank
-1
300 - 1600 psi (21 -110 bar)
Full range
300 - 3000 psi (21 - 207 bar)
Regulated Pressure Range (Failsafe)
(F or G models)
Series
Blank
20313S6WQ2
High sensitivity
1/2” Shear-Seal Regulator
3211 Fruitland Avenue • Los Angeles, CA 90058 •
-1
High sensitivity
300 - 1600 psi (21 -110 bar)
Full range
300 - 3000 psi (21 - 207 bar)
800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0026-F • 03/11 • ©2011 • Printed in the U.S.A.
2
3/4” Hydraulic Regulator
Valves
Series 20415
Features
Original Shear-Seal® technology
Self adjusting
High flow capacity
Tolerates contaminated media
Fail-safe motor control options
Self venting
Applications
Coiled tube reels
Land-based oil drilling controls
BOP control units
General Specifications*
Pressure:
Supply/Inlet Pressure:
3,000 psi (207bar)
Regulated Pressure Range:
High Sensitivity
Full Range
500 - 1600 PSI (34 -110 bar)
500 - 2800 PSI (34 - 193 bar)
Regulated Pressure Range
“F” Prefix Pneumatic
failsafe motor:
High Sensitivity
Full Range
500 - 1600 PSI (34 -110 bar)
500 - 2800 PSI (34 - 193 bar)
Regulated Pressure Range
“G” Prefix Hydraulic
failsafe motor:
High Sensitivity
Full Range
500 - 1600 PSI (34- 110 bar)
500 - 2800 PSI (34 - 193 bar)
Fluid Temperature Range:
-40° to +250°F (-40° to +121°C)
Proof Pressure:
Flanges:
Spring Tower:
Manual
Pneumatic Motor model
Hydraulic Motor model
Phosphate coated alloy steel (std.)
Option: Stainless steel
Phosphate coated alloy steel (std.)
Option: Stainless steel
Phosphate coated alloy steel (std.)
Painted alloy steel (std.)
Painted alloy steel (std.)
Option: Stainless steel
Standard O’ring Material:
Buna N
Socket Head Screws:
Zinc plated alloy steel (std.)
Option: Stainless steel
Wetted Parts:
Stainless steel & bronze
4,500 PSI (310 bar)
Flow:
Flow Rate:
Pneumatic Pilot Motor
(“F” prefix):
Pilot Motor Working Pressure:
80 - 120 PSI (5.5 - 8.3 bar)
70 GPM (@ 50 ft/s)
Porting:
1/4” NPT
Cv Inlet:
9.8
Operating Temperature Range:
32° to +250°F (0° to +120°C)
Cv Vent:
0.6
Porting:
Inlet 1:
1” NPT Standard, SAE Optional
Hydraulic Pilot Motor
(“G” prefix):
Pilot Motor Working Pressure:
400 - 1600 PSI (6.9 - 110 bar)
1” NPT Standard, SAE Optional
Porting:
SAE for 3/8” Tube (Size -6)
Outlet (regulated):
1/2” NPT Standard, SAE Optional
Operating Temperature Rating:
-40° to +250°F (-40° to +121°C)
Vent:
Gauge Port:
3/8” NPT Standard, SAE Optional
* See product configurator for additional options.
1
Materials of Construction:
Body:
Approximate Shipping Weight:
Manual:
47 lbs. (21.3 kg)
Pneumatic or Hydraulic
Motor:
70 lbs. (31.8 kg)
3/4” Hydraulic Regulator
Series 20415
Technical Drawings
7.125
3.500
25.625
(652)
25.625
(652)
.500
16.625
(423)
4.500
3.312
21.500
1.375
6.063
4.562
2.875
2.125
5.188
6.875
1.562
Dimensions in inches (mm)
Product Configurator
Example:
20415S3WQ2
Option
Adjustment Method
Blank
Blank
NPT porting
-MS
SAE porting
-SS
Stainless steel flanges & trim
Manual
F
Pneumatic failsafe motor
G
Hydraulic failsafe motor
Regulated Pressure Range (Manual)
Blank
Series
20415S3WQ2
-1
High sensitivity
500 - 1600 psi (34 - 110 bar)
Full range
500 - 2800 psi (34 - 193 bar)
1” Pressure regulator
Regulated Pressure Range (Failsafe)
F & G Models
Blank
-1
High sensitivity
500 - 1600 psi (34 - 110 bar)
Full range
500 - 2800 psi (34 - 193 bar)
3211 Fruitland Avenue • Los Angeles, CA 90058 •  800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0025-G • 02/11 • ©2011 • Printed in the U.S.A.
2
Valves
3/4” Heavy Duty Hydraulic Regulator
Series 20495
Features
Original Shear-Seal® technology
Ultra flow regulator
API compliant for sensitivity
Fail-safe motor control options
Tolerates contaminated media
Self venting
Surge dampening
Applications
Coiled tube reels
Land-based and offshore oil drilling controls
Wireline service tractors
Pressure sensitive applications
General Specifications*
Pressure:
Supply/Inlet Pressure:
5,000 psi (345 bar)
Regulated Pressure Range:
High Sensitivity
Full Range
500 - 1800 PSI 34 - 124 bar)
500 - 3300 PSI (34 - 228 bar)
Regulated Pressure Range
“F” Prefix Pneumatic
failsafe motor:
High Sensitivity
Full Range
Materials of Construction:
Body:
Flanges:
Spring Tower:
Manual
Pneumatic Motor model
Hydraulic Motor model
500 - 1800 PSI (34 - 124 bar)
500 - 3000 PSI (34 -207 bar)
Stainless steel (standard)
Phosphate coated alloy steel (std.)
Option: Stainless steel
Phosphate coated alloy steel (std.)
Painted alloy steel (std.)
Painted alloy steel (std.)
Option: Stainless steel
Standard O’ring Material:
Buna N
Socket Head Screws:
Wetted Parts:
Zinc plated alloy steel (std.)
Option: Stainless steel
Stainless steel & bronze
-40° to +250°F (-40° to +121°C)
Pneumatic Pilot Motor
(“F” prefix):
Pilot Motor Working Pressure:
80 - 120 PSI (5.5 - 8.3 bar)
Proof Pressure:
7,500 psi (517 bar)
Porting:
1/4” NPT
Flow:
Flow Rate:
Operating Temperature Range:
32° to +250°F (0° to +120°C)
90 GPM (@ 50 ft/s)
Cv Inlet:
9.8
Hydraulic Pilot Motor
(“G” prefix):
Pilot Motor Working Pressure:
400 - 1600 PSI (6.9 - 110 bar)
Cv Vent:
0.7
Porting:
SAE for 3/8” Tube (Size -6)
Porting:
Inlet 1:
1” NPT Standard, SAE Optional
Operating Temperature Rating:
-40° to +250°F (-40° to +121°C)
Outlet (regulated):
1” NPT Standard, SAE Optional
Approximate Shipping Weight:
Manual:
47 lbs. (21.3 kg)
Vent:
1/2” NPT Standard, SAE Optional
Gauge Port:
3/8” NPT Standard, SAE Optional
Regulated Pressure Range
“G” Prefix Hydraulic
failsafe motor:
High Sensitivity
Full Range
500 - 1800 PSI (34 - 124 bar)
500 - 3000 PSI (34 - 207 bar)
Fluid Temperature Range:
* See product configurator for additional options.
1
Pneumatic or Hydraulic
Motor:
70 lbs. (31.8 kg)
3/4” Heavy Duty Hydraulic Regulator
Series 20495
Technical Drawings
7.125
3.500
26.382
(670.1)
26.382
(670.1)
.500
4.500
3.312
22.670
(575.8)
1.375
6.063
2.875
4.562
2.177
5.187
6.875
1.562
Dimensions in inches (mm)
Product Configurator
Example:
20495S6WQ2
Option
Adjustment Method
Blank
Blank
NPT porting
-MS
SAE porting
-SS
Stainless steel flanges & trim
Manual
F
Pneumatic failsafe motor
G
Hydraulic failsafe motor
Regulated Pressure Range (Manual)
Blank
-1
High sensitivity
500 - 1800 psi (34 - 124 bar)
Full range
500 - 3300 psi (34 - 228 bar)
Series
20495S6WQ2
1” Pressure regulator
Regulated Pressure Range (Failsafe)
F & G Models
Blank
-1
High sensitivity
500 - 1800 psi (34 - 124 bar)
Full range
500 - 3000 psi (34 - 207 bar)
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0056-I • 02/11 • ©2011 • Printed in the U.S.A.
2
1-½” Hydraulic Regulator
Valves
Series 20517
Features
Original Shear-Seal® technology
High flow capacity
Large pressure range
Tolerates contaminated media
Fail-safe motor control options
Self venting
Applications
Land-based hydraulic drilling controls
BOP control units
Hydraulic powered tube reels
General Specifications*
Pressure:
Supply/Inlet Pressure:
3,000 psi (207 bar)
Materials of Construction:
Body:
Regulated Pressure Range:
200 - 1600 PSI (14 -110 bar)
High Sensitivity
350 - 2800 PSI (24 - 193 bar)
Full Range
Flanges:
Regulated Pressure Range
“F” Prefix Pneumatic
failsafe motor:
High Sensitivity
Full Range
Spring Tower:
Manual:
Pneumatic Motor model:
Hydraulic Motor model:
Regulated Pressure Range
“G” Prefix Hydraulic
failsafe motor:
High Sensitivity
Full Range
200 - 1600 PSI (14 - 110 bar)
350 - 2800 PSI (24 - 193 bar)
200 - 1600 PSI (14 -110 bar)
350 - 2800 PSI (24 - 193 bar)
Fluid Temperature Range:
-40° to +250°F (-40° to +121°C)
Proof Pressure:
4,500 psi (310 bar)
Flow:
Flow Rate:
120 GPM (@ 50 ft/s)
Cv Inlet:
17.5
Cv Vent:
Phosphate coated alloy steel (std.)
Option: Stainless steel
Phosphate coated alloy steel (std.)
Option: Stainless steel
Stainless steel (std.)
Painted alloy steel (std.)
Painted alloy steel (std.)
Option: Stainless steel
Standard O’ring Material:
Buna N
Socket Head Screws:
Stainless steel (std.)
Wetted Parts:
Stainless steel & bronze
Pneumatic Pilot Motor
(“F” prefix):
Pilot Motor Working Pressure:
80 - 120 PSI (5.5 - 8.3 bar)
Porting:
1/4” NPT
Operating Temperature Range: 32° to +250°F (0° to +120°C)
1.6
400 - 1600 PSI (6.9 - 110 bar)
Porting:
Inlet 1:
Hydraulic Pilot Motor
(“G” prefix):
Pilot Motor Working Pressure:
1” NPT Standard, SAE Optional
Porting:
SAE for 3/8” Tube (Size -6)
Inlet 2:
1” NPT Standard, SAE Optional
Operating Temperature Rating: -40° to +250°F (-40° to +121°C)
Outlet:
1-1/2” NPT Standard, SAE Optional
Vent:
1” NPT Standard, SAE Optional
Approximate Shipping
Weight:
Manual:
* See product configurator for additional options.
1
Pneumatic or Hydraulic
Motor:
67 lbs. (30.4 kg)
90 lbs. (40.8 kg)
1-½” Hydraulic Regulator
Series 20517
Technical Drawings
7.125
3.500
26.382
(670.1)
26.382
(670.1)
4.500
2.177
1.562
Dimensions in inches (mm)
Product Configurator
Example:
20517S3WQ2
Option
Blank
Adjustment Method
Blank
NPT porting
-MS
SAE porting
-SS
Stainless steel flanges & trim
Manual
F
Pneumatic failsafe motor
G
Hydraulic failsafe motor
Regulated Pressure Range (Manual)
Blank
-1
High sensitivity
200 - 1600 psi (14 - 110 bar)
Full range
350 - 2800 psi (24 - 193 bar)
Series
20517S3WQ2
1-1/2” Pressure regulator
Regulated Pressure Range (Failsafe)
F & G Models
Blank
-1
High sensitivity
200 - 1600 psi (14 - 110 bar)
Full range
350 - 2800 psi (24 - 193 bar)
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0061-C • 02/11 • ©2011 • Printed in the U.S.A.
2
Valves
1-½” Heavy Duty Hydraulic Regulator
Series 20597
Features
Original Shear-Seal® technology
API compliant for sensitivity
High flow capacity
Large pressure range
Tolerates contaminated media
Fail-safe motor control options
Self venting
Surge dampening
Applications
Land-based and offshore oil drilling controls
l
BOP control units
Pressure sensitive equipment
General Specifications*
Pressure:
Supply/Inlet Pressure:
5,000 psi (345 bar)
Regulated Pressure Range:
High Sensitivity
Full Range
300 - 1600 psi (21 -110 bar)
500 - 3300 psi (34 - 228 bar)
Regulated Pressure Range
“F” Prefix Pneumatic
failsafe motor:
High Sensitivity
Full Range
Flanges:
Spring Tower:
Manual:
Pneumatic Motor model:
Hydraulic Motor model:
300 - 1600 psi (21 - 110 bar)
500 - 3000 psi (34 - 207 bar)
Stainless steel (std.)
Phosphate coated alloy steel (std.)
Option: Stainless steel
Stainless steel (std.)
Painted alloy steel (std.)
Painted alloy steel (std.)
Option: Stainless steel
Standard O’ring Material:
Buna N
Socket Head Screws:
Stainless steel (std.)
Wetted Parts:
Stainless steel
Pneumatic Pilot Motor
(“F” prefix):
Pilot Motor Working Pressure:
80 - 120 psi (5.5 - 8.3 bar)
Porting:
1/4” NPT
120 GPM (@ 50 ft/s)
Operating Temperature Range:
32° to +250°F (0° to +120°C)
Cv Inlet:
17.5
Cv Vent:
2.6
Hydraulic Pilot Motor
(“G” prefix):
Pilot Motor Working Pressure:
400 - 1600 psi (6.9 - 110 bar)
Porting:
Inlet 1:
Porting:
SAE for 3/8” Tube (Size -6)
1” NPT Standard, SAE Optional
Operating Temperature Rating:
-40° to +250°F (-40° to +121°C)
Inlet 2:
1” NPT Standard, SAE Optional
Outlet:
1-1/2” NPT Standard, SAE Optional
Vent:
1” NPT Standard, SAE Optional
Regulated Pressure Range
“G” Prefix Hydraulic
failsafe motor:
High Sensitivity
Full Range
300 - 1600 psi (21 -110 bar)
500 - 3000 psi (34 - 207 bar)
Fluid Temperature Range:
-40° to +250°F (-40° to +121°C)
Proof Pressure:
7,500 psi (517 bar)
Flow:
Flow Rate:
* See product configurator for additional options.
1
Materials of Construction:
Body:
Approximate Shipping Weight:
Manual:
67 lbs. (30.4 kg)
Pneumatic or Hydraulic
Motor:
90 lbs. (40.8 kg)
1-½” Heavy Duty Hydraulic Regulator
Series 20597
Technical Drawings
7.125
3.500
26.382
(670.1)
26.382
(670.1)
4.500
2.177
1.562
Dimensions in inches (mm)
Product Configurator
Example:
20597S6WQ2
Option
Adjustment Method
Blank
Manual
Blank
NPT porting
-MS
SAE porting
-SS
Stainless steel flanges & trim
Regulated Pressure Range (Manual)
F
Pneumatic motor
Blank
G
Hydraulic motor
-1
High sensitivity
300 - 1600 psi (21 - 110 bar)
Full range
500 - 3300 psi (34 - 228 bar)
Regulated Pressure Range (Failsafe)
F & G Models
Series
20597S6WQ2
Blank
1-1/2” Pressure regulator
-1
High sensitivity
300 - 1600 psi (21 - 110 bar)
Full range
500 - 3000 psi (34 - 207 bar)
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0060-C • 02/11 • ©2011 • Printed in the U.S.A.
2
Valve
Pressure Relief Valve
Series 8010
Features
High flow with Zero Leak
Extended seat life
Factory pre-set or field adjustable
Optional tamper-proof cap
Stainless steel internals
Metal-to-metal seal
Applications
Pump system safety
Compressor over pressure protection
Hydraulic power units
Tank protection
Accumulator systems
General Specifications*
Hydraulic oil up to 5500 psi (380 bar)
Proof Pressure:
10,000 psi (690 bar)
Pressure Ranges:
500 - 1500 psi (35 - 105 bar)
1500 - 3500 psi (105 - 240 bar)
3500 - 5500 psi (240 - 380 bar)
Flow Rate:
15 GPM (NOMINAL)
Wetted Material:
Process Fitting:
Heat-treated 410 stainless steel
Internals:
416 stainless steel
Spring:
Powder-coated high strength steel
Ball:
Tungsten Carbide
Housing:
Powder-coated ductile iron
Weight:
2.5 lbs.
Pressure Connection:
3/4” NPTM x 3/4” NPTF
Temperature Range:
-40° to +200°F (-40° to +93°C)
Pressure Settings:
It is recommended that cracking
pressure be set 10% above working
pressure.
Flow Rate at 10% above Cracking Pressure
6000
5000 psi C.P. (-4)
5000
Pressure Drop (PSI)
Working Pressure:
4000
3000 psi C.P. (-3)
3000
2000
1500 psi C.P. (-2)
1000
0
0
Pressure Setpoint
Adjustment:
Loosen hex nut with open-end wrench.
Using allen key turn adjustment screw
clockwise to increase, counterclockwise to decrease set point.
* See product configurator for additional options.
2
4
6
8
10
14
16
Flow (GPM)
Typical 8014 Lift Characteristics
120
Full Open %
100
80
Full Open
60
Significant
Vent
40
First Weep
20
0
90
95
100
105
Set Pressure %
1
12
110
115
120
Pressure Relief Valve
Series 8010
Technical Drawings
2.1
[ 52.39 ]
MAX
(OPTIONAL)
TAMPER-PROOF CAP
OVERALL
7.0
[ 178 ]
6.0
[ 152 ]
3/4 NPT FEMALE
OUTLET
OUTLET PORT
CL 2.59
[ 65.67 ]
INLET PORT
1.63
[ 41.3 ]
WRENCH
FLATS
3/4 NPT MALE INLET
Product Configurator
Example:
801
4
-3
-33
Prefix
T
Tamper-proof cap (optional)
Base Model
801
Housing Option
Inlet male - outlet Female Porting
Blank
SS
Corrosion Resistant Ductile
Iron (standard)
Stainless Steel
Port Size
4
3/4” NPT ports
Pressure Range
-2
Adjustable Range
Approx.
Proof
psi (bar)
Blowdown
Pressure
Min.
Max.
psi (bar)
psi (bar)
500 (35)
1500 (105)
200 (15)
10,000 (690)
-3
1500 (105)
3500 (240)
400 (28)
10,000 (690)
-4
3500 (240)
5500 (380)
600 (42)
10,000 (690)
Factory Set Point
Blank
Field Adjustable
Insert desired set point
-XX
in 00’s (ex. 3300 psi = -33
700 psi = -07)
3211 Fruitland Avenue • Los Angeles, CA 90058 • 800-835-1060 • Fax: 323-589-3463 • www.barksdale.com
See Barksdale’s Standard Conditions of Sale • Specifications are subject to modification at any time • Bulletin #B0051-D • 08/08 • ©2008 • Printed in the U.S.A.
2
Hydraulic Relief Valve
Model 8014
Installation and Operating Instructions
Description:
This is a hydraulic pressure relief valve having a
factory set or field-adjustable set point. The valve is
designed to work with hydraulic oil-based media.
This valve is not intended for water or steam-based
applications. Standard wetted materials include
stainless steel, ductile iron, steel and Buna-N.
Caution:
The recommendations below are general and it is
the responsibility of the user to assure that
installation and maintenance are in accordance with
local requirements and ASME practices. This valve
should be installed by a trained service person. A
media filter should be in the system to protect the
valve. Neither Barksdale nor its agents assume any
liability for valves improperly used in the
application or improperly installed and maintained.
Installation:
Mounting: Valve shall be mounted in a vertical
position and connected in the flow
direction shown by the arrow. Use
wrench flat 1 5/8 inch to secure valve to
pipe line.
Piping:
Support with adequate piping in order to
avoid excessive shock and vibration.
Valve inlet is 3/4” NPT male and the
outlet is 3/4” NPT female. It is
recommended that a minimum of 1/2”
pipe size to be used for the inlet and the
outlet connection.
Ambient Temperature: -40°F to 200°F
Field Adjustment of Relief Pressure Set Point:
1. Tools Required:
x Allen key 5/16 inch
x Torque wrench
x Open end wrench 15/16 inch
2. Adjustment Procedures:
x Use 15/16 inch open end wrench to loosen
locking nut by turning it counter clockwise
(CCW).
x Insert Allen key to top of adjustment stud
and rotate it counter clockwise (CCW) to
decrease set pressure. Turn it clockwise
(CW) to increase set pressure.
x Re-tighten anti-vibration locking nut firmly
against flat valve body and torque with a
torque wrench to 300 in-lb.
Caution: Failure to torque locking nut to
specified value can cause malfunction,
failure of relief pressure, or injury.
Adjustment
Stud
Allen Key
Locking
Nut
~ 6 inch
(Torque to
300 in-lb.)
Flow
Direction
Operating Pressure Range (PSIG):
Adjustable
Range
Code
-1
-2
-3
-4
Pressure
Range (psi)
200 - 500
500 - 1500
1500 - 3500
3500 - 5500
Tolerance
± ( psi)
50
150
350
550
2.1 inch
For service or ordering information:
Consult factory or authorized factory representative.
Specify full catalog number (with any optional
modification) and factory set point.
_________________________________________________________________________________________
Barksdale, Inc. 3211 Fruitland Avenue, Los Angeles CA 90058
(800)835-1060 www.barksdale.com
Bulletin No. 272233-A 12-7-06
20
Global Presence
Global Presence
Barksdale Inc.
3211 Fruitland Ave.
Los Angeles, CA 90058-0843
U.S.A.
Phone: (800) 835-1060
Fax: (323) 589-3463
Email: [email protected]
www.barksdale.com
Barksdale GmbH
Dorn-Assenheimer Strasse 27
61203 Reichelsheim, Germany
Phone: (49) 6035-949-0 (main office)
(49) 6035-949-204 (sales)
Fax:
(49) 6035-949-111/-113
Email: [email protected]
www.barksdale.de
Barksdale GmbH
Dorn-Assenheimer Strasse 27
61203 Reichelsheim, Germany
Phone: (49) 6035-949-0 (main office)
(49) 6035-949-204 (sales)
Fax:
(49) 6035-949-111/-113
Email: [email protected]
www.barksdale.de
Barksdale India
SF- 43, Ansal Fortune Arcade
Sector – 18
India-201301 Noida
Phone: +91-120 25 10 522
Fax: +91-120 25 10 520
[email protected]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
