2013 October MEAN WELL PRODUCT
2013 October
Introduction
Green Enterprises,
Green Products
EXCELLENCE
TAIWAN
SUPERIOR BRANDS
E
stablished in 1982, MEAN WELL is a leading standard switching power supply manufacturer
in the world. During the past 31 years, our slogan “your reliable power partner” has been
curved into the minds of all MEAN WELL employees and put into effect thoroughly between MEAN
WELL and our valuable customers. Sure-footedly nurtured the core competency of P, Q, C, D, S,
R (Product, Quality, Cost, Delivery, Service, and Reliable Relationship), we made every effort to
accomplish the one stop shopping environment with the most complete standard power product lines.
In recent years, we acquired “Taiwan Superior Brand” and “Taiwan Excellence Product Award” from the
Taiwan government. The awards not only represent the identification of our previous efforts on brandbuilding and product design, but also prove that MEAN WELL proceeds toward the right direction
to continuously develop “green power products” with energy-saving concept. We are sure that this
strategy will be kept in the coming years.
We a r e a l s o p roud of tak i ng soci al respo n sibility an d devo te o u rselves to th e balan c e of
“ Te c h n o l o gy, H umani ty, and E nvi ronmen tal Co n scio u sn ess” . T h is visio n will be co n tinue d
a n d i m pl e m e nte d i nto our corp orate s trategy an d daily o peratio n . Rely o n th e co o peratio n of
o u r di s tr i bu to rs, sup p l i e rs, and e mp l o yees, as well as th e su ppo rt o f wo rldwide cu sto m e r s ,
w e be l ie v e that ME A N WE LL wi l l b e co m e stro n ger an d ach ieve an o th er level o f en terpris e in
th e n e x t 3 0 y e ars. ME A N WE LL i s re ady to wo rk with yo u an d always be yo u r best relia b le
po w e r pa r tn er!!
Green Adaptor
LED Power Supply
G re e n C h a rg e r
In ve rter
INDEX
ʄ Enclosed Switching Power Supply
ʄ External Switching Power Supply
RS-15 / 25 / 35 / 50 / 75 / 100 / 150
2~3
RD-35 / 50 / 65 / 85 / 125
G3 Series
RID-50 / 65 / 85 / 125, RT-50 / 65 / 85 / 125
RQ-50 / 65 / 85 / 125
NES-15 / 25 / 35 / 50 / 75 / 100 / 150
4~5
NE Series NED-35 / 50 / 75 / 100, NET-35 / 50 / 75
NES-200, NES-350
SE-100, SE-200, SE-350, SE-450
6
SE Series
MSP-600 7
SE-600, SE-1000, SE-1500
8
LED Sign
ERP-350, NEL-200, NEL-300, NEL-400
Panel
HSP-150, HSP-250, HSP-300, HDP-190/240 9
SP-75, SP-100, SP-150, SP-200, SP-240 10
SP-320, SP-480, PSP-600, SP-750
11
RSP-75, RSP-100, RSP-150, RSP-200
12
RSP-320, RSP-500, RSP-750
13
RSP-1000 / 1500 / 2000 / 2400 / 3000
14
PFC Series RST-5000, SPV-150, SPV-300, SPV-1500
15
TP-75, TP-100, QP-100, TP-150,
16~17
QP-150, QP-200, QP-320, QP-375
HRP-75, HRP-100, HRP G -150, HRP G -200 18
HRP G -300, HRP G -450, HRP G -600
19
20
MSP-100, MSP-200, MSP-300, MSP-450
U-bracket USP-150, USP-225, USP-350, USP-500
21
MP450, MP650, MP1K0
22~23
Modular
Series
MS-75 / 150 / 210 / 300 / 360, MD-100
HLG-40H, HLG-60H
24
HLG-80H,
HLG-100H,
HLG-120H
25
Harsh
Environment HLG-150H, HLG-185H, HLG-240H
26
HLG-320H
27
MDR-10 / 20 / 40 / 60 / 100
28
DR-15, DR-30, DR-60, DR-100
29
DR-45, DR-75, DR-120,
30
DRP-240, DRP-480, DRP-480S
DIN Series
DRH-120, DRT-240/480/960
31
SDR-75 / 120 / 240 / 480 P / 960
32
WDR-120, WDR-240, WDR-480
33
TDR-960, DR-RDN20, DR-UPS40
34
Industrial
Adaptor
Medical
Adaptor
Medical
Type
General
Type
40
41
42
43
44
45
46
47
48
49
50
PA-120, PB-120
ESC/P-120, ESC/P-240, PB-230, PB-300 P
PB-360 P / 600 / 1000 2/3/8 Stage Charging
GC30B/U/E, GC120 / 160 / 220 / 330
51
52
53
54
ATX Power
Security
Series
IPC-200, IPC-250, IPC-300A, IPC-300B
SCP-35, SCP-50, SCP-75,
PSC-60- C , PSC-100- C
ADS-55, ADS-155, AD-55, AD-155,
ADD-55, ADD-155
63
64
57
58
59
60
61
62
63
65
ʄ DC/DC Converter
SRS, SUS01
SBT01, SFT01, DET01
SPR01, SMU01, SMA01
SPU02, SPU03, SPA02, SPB03
SCW03, DCW03, SCW05, DCW05
SLW05, DLW05, SCW08, DCW08
Module Type SKE10, DKE10, SCW12, DCW12
SKM15, SKA15, DKA15
SKE15, DKE15, SKA20, SKM30
SDM30, DKA30, TKA30
SKM50, SKA40, SKA60
MHB75, MHB100 Heat Sink for MHB Series
MHB150
NSD05
On Board
NSD10-S, NSD10-D, NSD15-S, NSD15-D
Type
NID30, NID60
PSD-05, PSD-15
PCB Type
PSD-30, PSD-45
SD-15, SD-25
Enclosed
SD-50, SD-100, SD-150, SD-200
HEP-600
Type
SD-350, SD-500, SD-1000
RSD-100, RSD-150, RSD-200, RSD-300
35
36
37
38
39
66
67
68
69
70
71
72
73
74
75
76
77
78
78
79
80
80
81
81
82
83
84
19" Rack
Power
RCP-1000, RCP-1U , RCP-MU, RCP-2000, 85
RKP-1U , RKP-CMU1, RKP-1U -CMU1
LED Series
Introduction of LED Power Family
86
Inverter
Series
Introduction of Inverter Family
87
ʄ Accessories / Case Drawing
Case 901 / 902 / 903 / 905 / 906 / 907
88
Case 910A / 912 / 915A / 916(A/B) / 919A / 920A 89
Case 926A / 927A / 928A / 929A / 931A / 932A 90
Case 935A / 939A / 940A / 941B / 943A / 946A 91
Case
Drawing
Case 952B / 963A / 971A / 977A / 978A / 980A 92
Case 986A / 987A / 988 / 995A / 996A / 998A 93
Case 999A / 203A / 205A / 206A / 207A / 208A 94
Case 956 / 962A / 973A / 992A / 979A / 984A 95
DRL-01 / 02 / 03A, DRP-01 / 01A / 02 / 03 / 04 96
Accessories MHS012 / 013 / 014 / 025 / 026 / 027
TBC-05 / 07 / 08 / 09
ʄ External Switching Power Supply
Charger
55
56
ʄ Specific Purpose Power Supply
ʄ Open Frame Switching Power Supply
PM-05, PM-10, PM-15, PM-20
NFM-05, NFM-10, NFM-15, NFM-20
MPS-30, MPS / D / T-45
GSM90
RPS-60, RPD-60, RPT-60
MPS-65, MPD-65, MPT-65
RPS-75, RPD-75, RPT-75,
RPS G -160, RPD G -160, RPT G -160
MPS / D / T / Q-200, RPS-300
PS-05, PS-15, PS-25, PD-25
GSM120
PS-35, PS-45, PD-45, PT-45
PT-4503 / 6503, PS / PD / PT-65
RPD-65- C , RPT-65- C , PD-110, PQ-100
PPQ-100, PPS-125, PPT-125
ASP-150, PPS-200, PID-250
LPS-50 / 75 / 100, LPP-100 / 150
IRM-05, IRM-10, IRM-15, IRM-20
EPS-15, EPS-25/35, EPS-45- C , EPS-65- C
ELP-75- C , EPP-100, EPP-150, EPP-300
GE12, GE18, GE24 Interchangeable AC Inlet Plug
GS05E-USB, GS05U-USB
GS06E/U , GS12E/U, GS15A/B/E/U
GS18A, GS18B, GS18E, GS18U, GS25A,
GS25B, GS25E, GS25U, GS36E, GS36U
GS40, GS60, GS90, GS120
GS160, GS220, GS280
P25A, P25B, P50A Optional DC Plug List
MES30A, MES30B, MES30C, MES50A
GSM06E/U, GSM18B/U/E, GSM25B/U/E
GSM36B/U/E
GSM40, GSM60
: New Announced
: New Product within 1 Year
1
: Under Development
: Supplementary Information
Enclosed-G3 Series
High Reliability Miniature
Features
RS- 150
RD / I D / T/Q-125
R S-100
R D /ID /T/Q-85
RS-75
RD/ ID/ T/Q-65
RS-50
RD/ ID/ T/Q-50
RS-35
RD-35
RS-25
• No load power consumption <0.5W (RS-15~75)
• All using 105OC long life electrolytic capacitors
• Protections: Short circuit / Overload /
Over voltage / Over Temp.(RS-15)
• Meet EMS EN50082-2/EN61000-6-2
heavy industry level (35~150W)
• Withstand 300VAC surge input for 5 sec.
• High operating temperature up to 70°C
• Withstand 5G vibration test
• Miniature size, high power density
• High efficiency, long life and high reliability
• LED indicator for power on
• 100% full load burn-in test
• Suitable for critical applications
• 3 years warranty
RS-15
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No.
RS-15
RS-25
RS-35
RD-35
RS-50
RD / ID / T / Q-50
RS-75
RD / ID / T / Q-65
RS-100
RD / ID / T / Q-85
85~264VAC, 120~370VDC 88~264VAC, 125~373VDC
AC input voltage range
40A at 230VAC
AC inrush current (max.) Cold start, 65A at 230VAC 30A at 230VAC 36A at 230VAC 33A at 230VAC
±10%
by
potentiometer
for
single
output;
CH1
-5%~+10%
by
potentiometer
for
multiple output
DC adjustment range
115 / 230VAC by switch
Overload protection
>105%, hiccup mode
110%~180%
Over voltage protection
115%~135%, shut off
115%~135% rated output voltage, hiccup mode, auto-recovery
Withstand voltage
I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, O/P - FG: 0.5kVAC, 1 minute
Working temperature
-20~+70° C
Vibration
10~500Hz, 5G 10min. /1 cycle, period for 60 min. each along X, Y, Z axes
Safety standards
UL60950-1, TUV EN60950-1 approved
EMC standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2) (35~150W)
Connection
Terminal block for input and output
110%~150% hiccup mode, auto-recovery (150% ~190% for RID-125-1205/2405)
-25~+70° C (refer to the derating curve for different models)
Dimension (LxWxH)(mm) 62.5x 51x 28
971A
Case No.
Packing
108pcs /15.0kg
78x 51x 28
99x 82x 36
99x 97x 36
129x 97x 38
159x 97x 38
931A
932A
905B
903
901C
902A
45pcs /19.5kg
30pcs /13.3kg
24pcs /15.4kg
20pcs /15kg
60pcs /13.0kg 45pcs /14.0kg
15WŇSingle Output
Model No.
RS-15-3.3
RS-15-5
RS-15-12
RS-15-15
RS-15-24
RS-15-48
Output
3.3V, 0~3.0A
5V, 0~3.0A
12V, 0~1.3A
15V, 0~1.0A
24V, 0~0.625A
48V, 0~0.313A
Tol.
±3%
±2%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
120mV
200mV
200mV
Effi.
72%
77%
81%
81%
82%
82%
Tol.
±3%
±2%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
120mV
120mV
200mV
Effi.
73.5%
78.5%
81.5%
83.5%
86.0%
85.0%
Tol.
±3%
±2%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
120mV
120mV
200mV
Effi.
76.5%
80.5%
84.5%
86.0%
88.0%
88.5%
Tol.
±3%
±2%
±1%
R&N
80mV
80mV
120mV
Effi.
78.0%
83.0%
84.5%
RS-50-15
RS-50-24
RS-50-48
Output
3.3V, 0~6.0A
5V, 0~5.0A
12V, 0~2.1A
15V, 0~1.7A
24V, 0~1.1A
48V, 0~0.57A
Model No.
RS-75-3.3
RS-75-5
RS-75-12
RS-75-15
RS-75-24
RS-75-48
Output
3.3V, 0~7.0A
5V, 0~7.0A
12V, 0~3.0A
15V, 0~2.4A
24V, 0~1.5A
48V, 0~0.8A
Model No.
RS-100-3.3
RS-100-5
RS-100-12
RS-100-15
RS-100-24
RS-100-48
Output
3.3V, 0~10A
5V, 0~10A
12V, 0~4.2A
120mV
120mV
200mV
86.0%
88.0%
89.0%
Output
3.3V, 0~15A
5V, 0~12A
12V, 0~6.0A
15V, 0~5.0A
24V, 0~3.2A
48V, 0~1.6A
Tol.
±3%
±2%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
120mV
120mV
200mV
Effi.
75.0%
79.0%
84.5%
86.0%
88.5%
89.5%
Output
3.3V, 0~20A
5V, 0~16A
12V, 0~8.5A
15V, 0~7.0A
24V, 0~4.5A
48V, 0~2.3A
Tol.
±3%
±2%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
120mV
120mV
200mV
Effi.
74%
77%
81%
82%
84%
84%
Tol.
±3%
±2%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
120mV
120mV
200mV
Effi.
74%
78%
83%
84%
86%
87%
150WŇSingle Output
Model No.
RS-150-3.3
RS-150-5
RS-150-12
RS-150-15
RS-150-24
RS-150-48
50WŇSingle Output
Model No.
RS-50-3.3
RS-50-5
RS-50-12
±1%
±1%
±1%
100WŇSingle Output
35WŇSingle Output
Model No.
RS-35-3.3
RS-35-5
RS-35-12
RS-35-15
RS-35-24
RS-35-48
15V, 0~3.4A
24V, 0~2.2A
48V, 0~1.1A
199x 98x 38
75WŇSingle Output
25WŇSingle Output
Model No.
RS-25-3.3
RS-25-5
RS-25-12
RS-25-15
RS-25-24
RS-25-48
RS-150
RD / ID / T / Q-125
2
Output
3.3V, 0~30A
5V, 0~26A
12V, 0~12.5A
15V, 0~10A
24V, 0~6.5A
48V, 0~3.3A
Enclosed-G3 Series
35WŇDual Output
Model No.
RD-35A
RD-35B
RD-3513
Tol.
R&N
Effi.
Max.
Model No.
5V, 0.3~4.0A
±2%
80mV
79%
32W
RQ-50B
12V, 0.2~1.0A
±6%
Output
RD-50A
RD-50B
RD-65A
Model No.
RD-85B
Effi.
Max.
74%
46W
120mV
12V, 0.2~1.5A
±6%
120mV
80mV
-5V, 0.0~1.0A
±2%
100mV
-12V, 0.0~1.0A
±2%
80mV
5V, 0.5~6.0A
±2%
80mV
75%
50W
15V, 0.2~1.5A
±6%
120mV
100mV
79%
53W
±4%
120mV
-13.5V, 0.2~0.57A
±4%
120mV
82%
35W
120mV
80%
RQ-50C
35W
(Output isolated for RID-50A/B)
Tol.
R&N
Effi.
Max.
79%
54W
5V, 0.3~6.0A
±2%
80mV
12V, 0.3~3.0A
±7%
120mV
5V, 0.3~6.0A
±2%
80mV
24V, 0.2~2.0A
+8%, -4%
120mV
80%
RQ-50D
54W
5V, 0.3~8.0A
Model No.
Tol.
±2%
R&N
Effi.
Max.
80mV
79%
66W
±6%
120mV
5V, 0.3~8.0A
±2%
80mV
24V, 0.2~3.0A
+4%, -6%
150mV
78%
RQ-65B
68W
RQ-65C
(Output isolated for RID-85A/B)
Output
Tol.
R&N
Effi.
Max.
5V, 2.0~10A
±2%
80mV
78%
88W
12V, 0.3~5.0A
±5%
120mV
5V, 2.0~10A
±2%
80mV
80%
88W
24V, 0.3~2.5A
±5%
120mV
RQ-65D
RD-125A
RD-125B
Output
Tol.
R&N
Effi.
82%
5V, 2.0~15A
±5%
80mV
12V, 0.5~10A
±7%
120mV
5V, 2.0~10A
±5%
80mV
24V, 0.4~5.0A
±7%
120mV
125WŇDual Output
85%
Model No.
Max.
131W
RQ-85C
(Output isolated for RID-125)
Model No.
Output
Tol.
R&N
Effi.
Max.
12V, 1.0~7.0A
±2%
120mV
85%
133W
24V, 0.4~5.0A
+8%, -5%
200mV
24V, 0.5~5.0A
±2%
200mV
12V, 1.0~7.0A
±10%
120mV
12V, 1.0~7.0A
±2%
120mV
48V, 0.2~2.5A
+8%, -5%
240mV
48V, 0.3~2.5A
±2%
240mV
RD-125-1248
*RD-125-4812
RD-125-2448
*RD-125-4824
RID-125-1205
RID-125-2405
RQ-85B
133W
RD-125-1224
*RD-125-2412
12V, 1.0~7.0A
±10%
120mV
24V, 0.5~4.0A
±1%
200mV
48V, 0.2~2.5A
±4%
240mV
48V, 0.3~2.5A
±1%
240mV
24V, 0.5~4.0A
±8%
240mV
12V, 2.0~10.5A
±2%
120mV
5V, 0.0~3.0A
±3%
80mV
24V, 2.0~5.3A
±2%
120mV
5V, 0.0~3.0A
±3%
80mV
-5V, 0.0~1.0A
±2%
-15V, 0.0~1.0A
±2%
80mV
5V, 0.5~6.0A
±6%
80mV
12V, 0.2~1.5A
±6%
120mV
24V, 0.1~1.0A
+7%, -5%
180mV
-12V, 0.0~1.0A
±2%
80mV
85%
RQ-85D
133W
86%
138W
86%
138W
86%
Model No.
144W
144W
80%
125W
83%
125W
Tol.
RQ-125C
RQ-125D
*Modified
3
R&N
Effi.
Max.
76%
63W
76%
65W
78%
68W
5V, 0.5~8.0A
±2%
80mV
12V, 0.2~3.0A
+7%, -5%
120mV
-5V, 0.0~1.0A
±5%
80mV
-12V, 0.0~1.0A
±5%
80mV
5V, 0.5~8.0A
±2%
80mV
15V, 0.2~3.0A
+8%, -4%
120mV
-5V, 0.0~1.0A
±5%
80mV
-15V, 0.0~1.0A
±5%
80mV
5V, 0.5~8.0A
±2%
80mV
12V, 0.2~3.0A
±6%
120mV
24V, 0.1~1.5A
±8%
180mV
-12V, 0.0~1.0A
±5%
80mV
(RT-85 without -5V or -12V output)
Output
5V, 2.0~10A
Tol.
R&N
Effi.
Max.
±2%
80mV
76%
81W
12V, 0.3~4.0A
+7%, -3%
120mV
-5V, 0.0~1.0A
±8%
100mV
-12V, 0.0~1.0A
5V, 2.0~10A
±5%
80mV
±2%
80mV
77%
83W
15V, 0.3~4.0A
+3%, -7%
120mV
-5V, 0.0~1.0A
±8%
100mV
-15V, 0.0~1.0A
±5%
80mV
5V, 2.0~10A
±2%
80mV
78%
84W
12V, 0.3~4.0A
+7%, -3%
120mV
24V, 0.1~1.5A
±8%
150mV
-12V, 0.0~1.0A
±5%
80mV
125WŇQuad Output
RQ-125B
86%
(RT-65 without -5V or -12V output)
Output
85WŇQuad Output
125WŇDual Output
Model No.
Output
65WŇQuad Output
(Output isolated for RID-65A/B)
Output
85WŇDual Output
RD-85A
R&N
80mV
13.5V, 0.3~2.0A
12V, 0.2~4.0A
RD-65B
Tol.
±2%
±5%
Output
(RT-50 without -5V or -12V output)
5V, 0.5~6.0A
24V, 0.2~1.3A
65WŇDual Output
Model No.
±2%
5V, 0.3~4.0A
50WŇDual Output
Model No.
50WŇQuad Output
Output
5V, 2.0~12A
(RT-125 without -5V or -12V output)
±2%
Tol.
R&N
80mV
12V, 0.5~4.5A
+8%, -3%
120mV
-5V, 0.1~1.0A
+6%, -10%
80mV
-12V, 0.0~1.0A
5V, 2.0~12A
±5%
80mV
±2%
80mV
15V, 0.5~4.0A
+8%, -3%
120mV
-5V, 0.1~1.0A
+6%, -10%
80mV
-15V, 0.0~1.0A
±5%
80mV
5V, 2.0~12A
±2%
80mV
12V, 0.5~4.0A
+8%, -3%
120mV
24V, 0.1~2.5A
±8%
150mV
-12V, 0.0~1.0A
±5%
80mV
Effi.
Max.
79%
120W
80%
123W
82%
124W
Enclosed-NE Series
15~350W Miniature
Features
NED - 100
NES- 150
N ES-75/100
NED/T-75
NES-50
NED/T-50
NES-35
NED/T-35
NE S -25
NE S -15
• Universal AC input / Full range ( NES/D-100,
NES-150 AC input selectable by switch )
• Protections: Short circuit / Overload / Over voltage
• Built-in over temperature protection for NES-15
• Cooling by free air convection
• Small size, high power density
• Low cost, high reliability
• 100% full load burn-in test
• Most economical low wattage solution with safety
certificates
• 2 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
(NES-150 only) (NES only)
NES-35
NES-50
NES-75
NED/T-35
NED/T-50
NED/T-75
NES-150
Model No .
NES-15
AC in p u t v o l t a g e ra n g e
8 5 ~2 6 4 VAC; 1 2 0 ~3 7 0 VDC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 4 5 A a t 2 3 0 VAC
DC adjus t me n t ra n g e
±10% by potentiometer for single output;
CH1 -5%~+10% by potentiometer for multiple output
Over load p ro t e c t i o n
>105%
Over vo l t a g e p ro t e c t i o n
115%~135% rated output voltage, shut off
W ithstan d v o l t a g e
I / P - O/ P: 3 k VA C, I / P - F G: 2 k VA C , O / P - FG : 0 . 5 kVA C , 1 m in u t e
W o r kin g t e mp e ra t u re
-20~+60°C (refer to the derating curve for different models)
V ib r ation
10~500Hz, 2G 10min. /1 cycle, period for 60 min. each along X, Y, Z axes
S afety st a n d a rd s
UL 6 0 9 5 0 -1 , EN6 0 9 5 0 -1 (NES-1 5 0 o n ly) , G B 4 9 4 3 ( N E S o n ly) a p p r o ve d , a lso d e sig n r e f e r t o TU V E N 6 0 9 50 - 1
E MC stan d a rd s
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 -2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, G B 9 2 5 4 ( N E S o n ly)
Co n n ect i o n
Terminal block for input and output
Dim en sio n ( L x W x H ) ( mm)
78x 51x 28
99x 82x 35
Case N o .
931A
932B
P ackin g
60pcs/11.8kg 45pcs/14.5kg
NES-25
Output
5V, 0~3.0A
12V, 0~1.3A
15V, 0~1.0A
24V, 0~0.7A
48V, 0~0.35A
Output
5V, 0~5.0A
12V, 0~2.1A
15V, 0~1.7A
24V, 0~1.1A
48V, 0~0.57A
115%~135% hiccup mode, auto-recovery
99x 97x 36
129x 98x 38
Output
5V, 0~7.0A
12V, 0~3.0A
15V, 0~2.4A
24V, 0~1.5A
48V, 0~0.8A
Output
5V, 0~10A
12V, 0~4.2A
15V, 0~3.4A
24V, 0~2.2A
48V, 0~1.1A
159x 97x 38
199x 98x 38
905
903
901
901
902
45pcs/21kg
30pcs/16.6kg
30pcs/17.5kg
20pcs/15kg
75WŇSingle Output
Tol.
±2%
±1%
±1%
±1%
±1%
R&N
150mV
150mV
150mV
200mV
240mV
Effi.
79%
81%
81%
85%
82%
Tol.
±2%
±1%
±1%
±1%
±1%
R&N
80mV
120mV
150mV
200mV
240mV
Effi.
78%
83%
84%
86%
86%
Tol.
±2%
±1%
±1%
±1%
±1%
R&N
80mV
120mV
150mV
200mV
240mV
Effi.
78%
81%
83%
85%
86%
Tol.
±2%
±1%
±1%
±1%
±1%
R&N
80mV
120mV
150mV
200mV
240mV
Effi.
79%
82%
83%
86%
87%
Model No.
NES-75-5
NES-75-12
NES-75-15
NES-75-24
NES-75-48
Output
5V, 0~14A
12V, 0~6.2A
15V, 0~5.0A
24V, 0~3.2A
48V, 0~1.6A
Tol.
±2%
±1%
±1%
±1%
±1%
R&N
80mV
120mV
150mV
200mV
240mV
Effi.
77%
82%
83%
86%
87%
Tol.
±2%
±1%
±1%
±1%
±1%
±1%
±1%
R&N
80mV
120mV
120mV
120mV
120mV
120mV
150mV
Effi.
80%
81%
81%
83%
84%
86%
86%
100WŇSingle Output
Model No.
NES-100-5
NES-100-7.5
NES-100-9
NES-100-12
NES-100-15
NES-100-24
NES-100-48
Output
5V, 0~20A
7.5V, 0~13.6A
9V, 0~11.2A
12V, 0~8.5A
15V, 0~7.0A
24V, 0~4.5A
48V, 0~2.3A
150WŇSingle Output
50WŇSingle Output
Model No.
NES-50-5
NES-50-12
NES-50-15
NES-50-24
NES-50-48
159x 97x 38
45pcs/17.2kg
35WŇSingle Output
Model No.
NES-35-5
NES-35-12
NES-35-15
NES-35-24
NES-35-48
-5%~+10% (NES-100/150)
CH1 -5%~+10% (NED-100)
110%~150% hiccup mode, auto-recovery
25WŇSingle Output
Model No.
NES-25-5
NES-25-12
NES-25-15
NES-25-24
NES-25-48
NED-100
115/230VAC by switch
15WŇSingle Output
Model No.
NES-15-5
NES-15-12
NES-15-15
NES-15-24
NES-15-48
NES-100
4
Model No.
NES-150-3.3
NES-150-5
NES-150-7.5
NES-150-9
NES-150-12
NES-150-15
NES-150-24
Output
3.3V, 0~30A
5V, 0~26A
7.5V, 0~20A
9V, 0~16.7A
12V, 0~12.5A
15V, 0~10A
24V, 0~6.5A
Tol.
±3%
±2%
±1%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
120mV
120mV
120mV
120mV
Effi.
73%
78%
80%
83%
83%
83%
86%
NES-150-48
48V, 0~3.3A
±1%
200mV
86%
Enclosed-NE Series
35WŇDual Output
Model No.
NED-35A
NED-35B
Output
5V, 0.5~5.0A
12V, 0.1~1.5A
5V, 0.5~4.0A
24V, 0.2~1.3A
210W Single Output Switching Power Supply
Tol.
±2%
±6%
±2%
±6%
R&N
80mV
120mV
80mV
200mV
Effi.
78%
Max.
32W
81%
35W
Tol.
±2%
±6%
±2%
±6%
R&N
80mV
120mV
80mV
200mV
Effi.
79%
Max.
54W
82%
54W
Tol.
±2%
±6%
±2%
±6%
R&N
80mV
120mV
80mV
200mV
Effi.
78%
Max.
71W
81%
73W
50WŇDual Output
Model No.
NED-50A
NED-50B
Output
5V, 1.0~6.0A
12V, 0.3~3.0A
5V, 1.0~6.0A
24V, 0.2~2.0A
CASE: 912E
75WŇDual Output
Model No.
NED-75A
NED-75B
Output
5V, 1.0~8.0A
12V, 0.3~4.0A
5V, 1.0~6.0A
24V, 0.2~3.0A
AC input voltage range ....... 90~132VAC / 180~264VAC selectable by switch
DC adjustment range .......... ±10% rated output range
Overload protection ............ 105%~150% constant current limiting, auto-recovery
Over voltage protection ....... 115%~145% rated output voltage
Setup, rise, hold up time ...... 1000ms, 50ms, 20ms at full load and 230VAC
Withstand voltage ............... I/P - O/P: 3kVAC, I/P-FG: 1.5kVAC, O/P-FG: 0.5kVAC
Working temperature .......... -20~+50°C (refer to output derating curve)
Safety standards ................ UL60950-1 approved
Packing .............................. 0.93kg ; 12pcs / 12kg / 0.92CUFT
100WŇDual Output (Output isolated for NED-100 GD)
Model No.
NED-100A
NED-100B
NED-100C
NED-100D
Output
5V, 2~10A
12V, 0.7~7.0A
5V, 1~10A
24V, 0.3~3.5A
12V, 0~8.0A
5V, 0~3.0A
24V, 0~4.0A
5V, 0~3.0A
Tol.
±2%
±10%
±2%
±8%
±2%
±3%
±2%
±3%
R&N
80mV
120mV
80mV
200mV
120mV
80mV
120mV
80mV
Effi.
80%
Max.
100W
82%
100W
80%
99W
82%
99W
Model No.
NES-200-3.3
NES-200-5
NES-200-7.5
NES-200-12
NES-200-15
NES-200-24
NES-200-27
NES-200-36
NES-200-48
35WŇTriple Output
Model No.
NET-35A
NET-35B
NET-35C
NET-35D
Output
5V, 0.5~4.0A
12V, 0.1~1.5A
-5V, 0.1~0.5A
5V, 0.5~4.0A
12V, 0.1~1.5A
-12V, 0.1~0.5A
5V, 0.5~3.5A
15V, 0.1~1.5A
-15V, 0.1~0.5A
5V, 0.5~3.5A
24V, 0.1~1.0A
12V, 0.1~1.0A
Tol.
±2%
±6%
±6%
±2%
±6%
±6%
±2%
±8%
±8%
±2%
±8%
±8%
R&N
80mV
120mV
120mV
80mV
120mV
120mV
80mV
150mV
150mV
80mV
200mV
120mV
Effi.
78%
Max.
30W
79%
33W
Tol.
±2%
±6%
±5%
±2%
±6%
±5%
±2%
±8%
±5%
±2%
±8%
±6%
R&N
80mV
120mV
120mV
80mV
120mV
120mV
80mV
150mV
150mV
80mV
200mV
120mV
Tol.
±2%
±6%
±5%
±2%
±6%
±5%
±2%
±8%
±5%
±2%
±8%
±6%
R&N
80mV
120mV
120mV
80mV
120mV
120mV
80mV
150mV
150mV
80mV
200mV
120mV
215x 115x 50 mm
Output
3.3V, 0~40A
5V, 0~40A
7.5V, 0~27A
12V, 0~17A
15V, 0~14A
24V, 0~8.8A
27V, 0~7.8A
36V, 0~5.9A
48V, 0~4.4A
NET-50B
NET-50C
NET-50D
Output
5V, 0.6~5.0A
12V, 0.2~2.5A
-5V, 0.1~0.7A
5V, 0.6~5.0A
12V, 0.2~2.5A
-12V, 0.1~0.7A
5V, 0.6~5.0A
15V, 0.1~2.0A
-15V, 0.1~0.7A
5V, 0.6~5.0A
24V, 0.1~1.5A
12V, 0.1~1.5A
79%
35W
79%
37W
Effi.
76%
Max.
47W
78%
50W
78%
50W
80%
51W
Effi.
77%
Max.
69W
78%
65W
78%
72W
80%
73W
CASE: 912C
NET-75B
NET-75C
NET-75D
Output
5V, 0.6~7.0A
12V, 0.2~3.5A
-5V, 0.1~0.7A
5V, 0.6~7.0A
12V, 0.2~3.5A
-12V, 0.1~0.7A
5V, 0.6~7.0A
15V, 0.1~3.5A
-15V, 0.1~0.7A
5V, 0.6~6.0A
24V, 0.1~2.0A
12V, 0.1~1.5A
R&N
150mV
150mV
150mV
150mV
150mV
150mV
200mV
240mV
240mV
Effi.
75%
79%
82%
85%
85%
87%
88%
89%
89%
215x 115x 50 mm
• AC input selectable by switch
• Withstand 300VAC surge input for
5 seconds
• Protections: Short circuit / Overload
Over voltage / Over temp.
• Forced air cooling by built-in DC fan
• Built-in fan ON/OFF control
• Built-in constant current limiting circuit
• 100% full load burn-in test
• LED indicator for power on
• Low cost, high reliability
• 2 years warranty
AC input voltage range ....... 90~132VAC / 180~264VAC selectable by switch
DC adjustment range .......... ±10% rated output range
Overload protection ............ 105%~135% constant current limiting, auto-recovery
Over voltage protection ....... 115%~145% rated output voltage
Setup, rise, hold up time ...... 1000ms, 50ms, 20ms at full load and 230VAC
Withstand voltage ............... I/P - O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature .......... -20~+60°C (refer to output derating curve)
Safety standards ................ UL60950-1 approved
Packing .............................. 1.07kg ; 12pcs / 13.5kg / 0.92CUFT
75WŇTriple Output
Model No.
NET-75A
Tol.
±2%
±2%
±2%
±1%
±1%
±1%
±1%
±1%
±1%
350W Single Output Switching Power Supply
50WŇTriple Output
Model No.
NET-50A
• AC input selectable by switch
• Withstand 300VAC surge input for
5 seconds
• Protections: Short circuit / Overload
Over voltage / Over temp.
• Cooling by free air convection
• Built-in constant current limiting circuit
• 100% full load burn-in test
• LED indicator for power on
• Low cost, high reliability
• 2 years warranty
Model No.
NES-350-3.3
NES-350-5
NES-350-7.5
NES-350-12
NES-350-15
NES-350-24
NES-350-27
NES-350-36
NES-350-48
5
Output
3.3V, 0~60A
5V, 0~60A
7.5V, 0~46A
12V, 0~29A
15V, 0~23.2A
24V, 0~14.6A
27V, 0~13A
36V, 0~9.7A
48V, 0~7.3A
Tol.
+3%, -4.5%
±3.0%
±2.0%
±1.5%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
R&N
150mV
150mV
150mV
150mV
150mV
150mV
200mV
240mV
240mV
Effi.
74.0%
78.0%
80.0%
83.0%
84.0%
87.0%
88.0%
87.5%
87.5%
Enclosed-SE Series
100~450W Single Output
Features
SE-450
SE-2 0 0
S E-3 5 0
• AC input selectable by switch
• Withstand 300VAC surge input for 5 seconds
(SE-200/350)
• Protections: Short circuit / Overload / Over voltage /
Over temperature (except for SE-100)
• Forced air cooling by built-in DC fan (SE-350/450)
• Built-in fan ON/OFF control (SE-350)
• Built-in constant current limiting circuit (SE-200/350)
• Withstand 5G vibration test (SE-200/350)
• Built-in remote sense function (SE-450)
• 100% full load burn-in test
• LED indicator for power on
• 2 years warranty
SE-100
General Specification (Please refer to www.meanwell.com for detail spec.)
Mo d el N o .
SE-1 0 0
A C in p u t v o l t a g e ra n g e
115/230VAC by switch
A C in r us h c u rre n t ( ma x . )
Cold start,
36A at 230VAC
SE-350
SE-450
Cold start,
55A at 230VAC
Cold start,
60A at 230VAC
Cold start,
55A at 230VAC
-5%~+10% rated output voltage ± 10% r at ed out put volt age
D C adjus t me n t ra n g e
Over lo ad
pr o tectio n
SE-200
Ra n g e
110%~150%
105%~150%
Type
105%~135%
105%~150%
Hiccup mode, auto-recovery
Constant current limiting, auto-recovery
Over vol t a g e p ro t e c t i o n
115%~135%
115%~145%
W ith stand v o l t a g e
I / P - O/ P: 3 k VA C, I / P - FG: 1 . 5 k VA C , O / P - FG : 0 . 5 kVA C
W or king t e mp e ra t u re
-20~+60° C
S afety s t a n d a rd s
UL60950-1, GB4943(SE-100 only) approved
E MC sta n d a rd s
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, GB9254 for SE-100 only
C o n n ect i o n
7P/9.5mm pitch terminal block
9P/9.5mm pitch terminal block with cover
9P/11mm pitch terminal block with cover
D im en sio n ( L x W x H ) ( mm)
159x 97x 38
215x 115x 50
225x 124x 50
C ase N o .
901
912E
912C
986A
P ackin g
30pcs / 17.5kg
12pcs / 12kg
12pcs / 13.5kg
12pcs / 16kg
-20~+50° C
-20~+60° C
SE-100-5
SE-100-7.5
SE-100-9
-10~+60° C (refer to output derating curve)
SE-350 Series
SE-100 Series
Model No.
Shut down o/p voltage, re-power on to recover
Output
Tol.
R&N
Effi.
Model No.
Output
Tol.
R&N
Effi.
5V, 0~20A
±2%
80mV
80%
SE-350-3.3
3.3V, 0~60A
+3%, -4.5%
150mV
74.0%
7.5V, 0~13.6A
±1%
120mV
81%
SE-350-5
9V, 0~11.2A
±1%
120mV
81%
SE-350-7.5
5V, 0~60A
±3.0%
150mV
78.0%
7.5V, 0~46A
±2.0%
150mV
80.0%
SE-100-12
12V, 0~8.5A
±1%
120mV
83%
SE-350-12
12V, 0~29A
±1.5%
150mV
83.0%
SE-100-15
15V, 0~7.0A
±1%
120mV
84%
SE-350-15
15V, 0~23.2A
±1.0%
150mV
84.0%
SE-100-24
24V, 0~4.5A
±1%
120mV
86%
SE-350-24
24V, 0~14.6A
±1.0%
150mV
87.0%
SE-100-48
48V, 0~2.3A
±1%
150mV
86%
SE-350-27
27V, 0~13A
±1.0%
200mV
88.0%
SE-350-36
36V, 0~9.7A
±1.0%
240mV
87.5%
SE-350-48
48V, 0~7.3A
±1.0%
240mV
87.5%
SE-200 Series
Model No.
Tol.
R&N
Effi.
3.3V, 0~40A
±2%
150mV
75%
5V, 0~40A
±2%
150mV
79%
SE-200-7.5
7.5V, 0~27A
±2%
150mV
82%
SE-200-12
12V, 0~17A
±1%
150mV
85%
SE-200-15
15V, 0~14A
±1%
150mV
SE-200-24
24V, 0~8.8A
±1%
SE-200-27
27V, 0~7.8A
SE-200-36
SE-200-48
SE-200-3.3
SE-200-5
Output
SE-450 Series
Model No.
Output
Tol.
R&N
Effi.
SE-450-3.3
3.3V, 0~75A
±3%
200mV
74%
SE-450-5
5V, 0~75A
±3%
200mV
78%
85%
SE-450-12
12V, 0~37.5A
±1%
200mV
83%
150mV
87%
SE-450-15
15V, 0~30A
±1%
200mV
84%
±1%
200mV
88%
SE-450-24
24V, 0~18.8A
±1.5%
200mV
86%
36V, 0~5.9A
±1%
240mV
89%
SE-450-36
36V, 0~12.5A
±1%
200mV
86%
48V, 0~4.4A
±1%
240mV
89%
SE-450-48
48V, 0~9.4A
±1%
200mV
88%
6
Enclosed-SE Series
600~1500W Single Output
Features
• AC input selectable by switch (600~1000W)
• A C i n p u t 1 8 0 ~ 2 6 4 VA C o n l y ( S E - 1 5 0 0 )
• Protections: Short circuit / Overload /
Over voltage / Over temperature
• Forced air cooling by built-in DC fan
• Built-in remote sense function
• D C OK , r e m o t e ON / OF F c o n t r o l ( S E -1 0 0 0 /1 5 0 0 )
• 100% full load burn-in test
• LED indicator for power on
SE-1500
S E-1 0 0 0
• 2 years warranty
SE-6 0 0
General Specification (Please refer to www.meanwell.com for detail spec.)
Mo d el N o .
SE-6 0 0
A C in p u t v o l t a g e ra n g e
90~132VAC / 180~264VAC selected by switch
180~264VAC
A C in r us h c u rre n t ( ma x . )
Cold start, 60A at 230VAC
Cold start, 60A at 230VAC
D C adjus t me n t ra n g e
SE-1000
SE-1500
Cold start, 55A at 230VAC
±10% rated output voltage
Over lo ad
Ra n g e
105%~125%
pr o tectio n
Type
Shut down o/p voltage, re-power on to recover
Over vol t a g e p ro t e c t i o n
115%~140%
W ith stand v o l t a g e
I / P - O/ P: 3 k VA C, I / P - F G: 1 . 5 k VA C , 1 m in u t e
W or king t e mp e ra t u re
-20~+60° C (refer to output derating curve)
S afety s t a n d a rd s
UL60950-1 approved
E MC sta n d a rd s
Design refer to EN55022 class B
C o n n ect i o n
Terminal block with cover f or input and output (SE-1000/1500: copper pillars for output)
D im en sion ( L x W x H ) ( mm)
247x 127x 63.5
278x 127x 63.5
C ase N o .
926A
935B
982A
P ackin g
6pcs / 13.4kg
6pcs / 16kg
4pcs / 14.2kg
600W
Model No.
SE-600-5
SE-600-12
SE-600-15
SE-600-24
SE-600-27
SE-600-36
SE-600-48
-20~+70° C (refer to output derating curve)
278x 177.8x 63.5
SE-600
Output
5V, 0~100A
12V, 0~50A
15V, 0~40A
24V, 0~25A
27V, 0~22.2A
36V, 0~16.6A
48V, 0~12.5A
Tol.
±2%
±1%
±1%
±1%
±1%
±1%
±1%
R&N
150mV
150mV
150mV
150mV
150mV
200mV
200mV
1000W
Effi.
78%
83%
84%
87%
87%
87%
88%
• Universal AC input / Full range
• Withstand 300VAC surge input for
5 seconds
• Built-in active PFC function
• High efficiency up to 89%
• Protections:
Short circuit / Overload / Over voltage / Over temperature
• /HDNDJHFXUUHQW”ȝ$ • Built-in constant current limiting circuit
• Built-in remote sense function
• Built-in remote ON/OFF control & 5V/0.3A standby output
• Built-in DC OK signal
• Current sharing up to 2400W (3+1) for 24V, 36V, 48V
• No load power consumption <0.75W
• Built-in cooling fan ON/OFF control
• Design refer to IEC60601-1, ANSI/AAMI ES60601-1 (MOOP Level)
• Output models: 3.3V / 5V / 7.5V / 12V / 15V / 24V / 36V / 48V
• Dimension(LxWxH): 218x 105x 63.5mm
• 5 years warranty
SE-1000
Model No.
Output
Tol.
R&N
Effi.
SE-1000-5
5V, 0~150A
±1%
150mV
81%
SE-1000-9
9V, 0~100A
±1%
150mV
84%
SE-1000-12
12V, 0~83.3A
±1%
150mV
85%
SE-1000-15
15V, 0~66.7A
±1%
150mV
86%
SE-1000-24
24V, 0~41.7A
±1%
200mV
88%
SE-1000-48
48V, 0~20.8A
±1%
200mV
89%
1500W
SE-1500
Model No.
Output
Tol.
R&N
SE-1500-5
5V, 0~300A
±2%
150mV
Effi.
81%
SE-1500-12
12V, 0~125A
±1%
150mV
85%
SE-1500-15
15V, 0~100A
±1%
150mV
85%
SE-1500-24
24V, 0~62.5A
±1%
150mV
87%
SE-1500-27
27V, 0~55.6A
±1%
150mV
88%
SE-1500-48
48V, 0~31.3A
±1%
150mV
89%
7
Enclosed
200 ~ 400W Economical Low Profile for LED Sign Panel
350W S i ng l e O utp ut
U L p ending
200x 130x 40 mm
300W Sin g le Ou tpu t
U L pe ndi ng
• AC input 180~264VAC only
• Withstand 300VAC surge input for 5
seconds
• Semi-potted and design against rain
splash
• High efficiency up to 90%
• Protections:
Short circuit / Overload / Over voltage /
Over temperature
• Cooling by free air convection
• 1U low profile: 40mm
• LED indicator for power on
• Low cost
• Suitable for channel letter applications
• 3 years warranty
215x 115x 30 mm
AC input voltage range ......... 180~264VAC; 254~370VDC
AC inrush current ................. Cold start, 60A at 230VAC
DC adjustment range ............ ±10% rated output voltage
Overload protection .............. 105%~135% hiccup mode, auto-recovery
Over voltage protection ......... 24V: 27.6~32.4V; 36V: 41.4~46.8V;
• AC input 180~264VAC only
• Withstand 300VAC surge input for 5
seconds
• Conformal coating
• High efficiency up to 86%
• Protections:
Short circuit / Overload / Over voltage /
Over temperature
• Forced air cooling by built-in DC fan
• 1U low profile: 30mm
• LED indicator for power on
• Low cost
• Suitable for moving sign applications
• 2 years warranty
AC input voltage range ...... 180~264VAC; 254~370VDC
AC inrush current ............... Cold start, 70A at 230VAC
DC adjustment range .......... 2.8V:2.5~3V; 4V:3.6~4.4V; 5V:4.5~5.5V
Overload protection ........... 105%~140% hiccup mode, auto-recovery
48V: 57.6~67.2V hiccup mode, auto-recovery
Setup, rise, hold up time ........1000ms, 50ms, 20ms at full load and 230VAC
Withstand voltage ................. I/P-O/P: 3kVAC, I/P-FG: 2kVAC,
O/P-FG: 0.5kVAC
Over voltage protection ...... 2.8V: 3.22~3.78V; 4V: 4.6~5.4V; 5V: 5.6~7V
Working temperature ............ -30~+60°C (refer to output derating curve)
Safety standards .................. Design refer to UL60950-1
Working temperature .......... -20~+60° C (refer to output derating curve)
Tol.
R&N
Effi.
ERP-350-24
Model No.
24V, 0~14.6A
Output
±1%
150mV
89%
ERP-350-36
36V, 0~9.7A
±1%
240mV
89%
ERP-350-48
48V, 0~7.3A
±1%
240mV
90%
hiccup mode, auto-recovery
Setup, rise, hold up time ..... 2500ms, 50ms, 20ms at full load and 230VAC
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Safety standards ................ Design refer to UL60950-1
Model No.
Output
Tol.
R&N
Effi.
2.8V, 0~60A
+3%, -4.5%
150mV
82.5%
NEL-300-4
4V, 0~60A
+3%, -4.5%
150mV
85.0%
NEL-300-5
5V, 0~60A
±3%
150mV
86.0%
NEL-300-2.8
200W S i ng l e O utp ut
UL p endi n g
215x 115x 30 mm
400W Sin g le Ou tpu t
U L pe ndi ng
• AC input 180~264VAC only
• Withstand 300VAC surge input for 5
seconds
• Conformal coating
• High efficiency up to 87%
• Protections:
Short circuit / Overload / Over voltage /
Over temperature
• Cooling by free air convection
• 1U low profile: 30mm
• LED indicator for power on
• Low cost
• Suitable for moving sign applications
• 2 years warranty
215x 115x 30 mm
AC input voltage range ...... 180~264VAC; 254~370VDC
AC input voltage range ...... 180~264VAC; 254~370VDC
AC inrush current ............... Cold start, 70A at 230VAC
DC adjustment range .......... 2.8V:2.5~3V; 4V:3.6~4.4V; 5V:4.5~5.5V
Overload protection ........... 105%~140% hiccup mode, auto-recovery
Over voltage protection ...... 2.8V: 3.22~3.78V; 4V: 4.6~5.4V; 5V: 5.6~7V
AC inrush current ............... Cold start, 70A at 230VAC
DC adjustment range .......... 2.8V:2.5~3V; 4V:3.6~4.4V; 5V:4.5~5.5V
Overload protection ........... 105%~140% hiccup mode, auto-recovery
Over voltage protection ...... 2.8V: 3.22~3.78V; 4V: 4.6~5.4V; 5V: 5.6~7V
hiccup mode, auto-recovery
hiccup mode, auto-recovery
Setup, rise, hold up time ..... 2500ms, 50ms, 20ms at full load and 230VAC
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature .......... -20~+60° C (refer to output derating curve)
Safety standards ................ Design refer to UL60950-1
Setup, rise, hold up time ..... 2500ms, 50ms, 20ms at full load and 230VAC
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature .......... -20~+60°C (refer to output derating curve)
Safety standards ................ Design refer to UL60950-1
Model No.
NEL-200-2.8
Output
Tol.
R&N
Effi.
• AC input 180~264VAC only
• Withstand 300VAC surge input for 5
seconds
• Conformal coating
• High efficiency up to 84%
• Protections:
Short circuit / Overload / Over voltage /
Over temperature
• Forced air cooling by built-in DC fan
• 1U low profile: 30mm
• LED indicator for power on
• Low cost
• Suitable for moving sign applications
• 2 years warranty
Model No.
Output
Tol.
R&N
Effi.
2.8V, 0~40A
+3%, -4.5%
150mV
85.5%
NEL-400-2.8
2.8V, 0~80A
+3%, -4.5%
150mV
80.0%
NEL-200-4
4V, 0~40A
+3%, -4.5%
150mV
87.0%
NEL-400-4
4V, 0~80A
+3%, -4.5%
150mV
83.0%
NEL-200-5
5V, 0~40A
±3%
150mV
87.0%
NEL-400-5
5V, 0~80A
±3%
150mV
84.0%
8
Enclosed-PFC
150~300W High Reliability Low Profile for LED Sign Panel
150W Single Output with PFC Function
250W Single
for High
Efficiency
Moving
Sign
300W
Output
with PFC
Function
• Universal AC input / Full range
• Withstand 300VAC surge input for 5
seconds
• Built-in active PFC function
• Conformal coating
• High efficiency up to 90%
• Protections:
Short circuit / Overload /
Over voltage / Over temperature
• Cooling by free air convection for
220x 62x 32 mm
150W and 200W with 30CFM forced air
• 1U low profile: 32mm
• Built-in remote sense function
• LED indicator for power on
• Suitable for moving sign applications
• 3 years warranty
AC input voltage range ........ 90~264VAC; 127~370VDC
AC inrush current ................ Cold start, 70A at 230VAC
DC adjustment range ........... 2.5V: 2.35~2.75V; 3.8V: 3.4~4.2V; 5V: 4.5~5V
Overload protection ............. 140%~180% hiccup mode, auto-recovery
Over voltage protection ....... 2.5V: 3.2~3.7V; 3.8V: 4.7~5.7V; 5V: 5.7~7V
hiccup mode, auto-recovery
Setup, rise, hold up time ...... 2000ms, 100ms, 16ms at full load and 230VAC
Withstand voltage ............... I/P - O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature ........... -30~+70°C (refer to output derating curve)
Safety standards ................. UL60950-1, EN60950-1 approved
EMC standards ................... EN55022 class B, EN61000-3-2,3
EN61000-4-2,3,4,5,6,8,11
Packing ............................... 0.61kg ; 24pcs / 15.6kg / 1.63CUFT
Model No.
HSP-150-2.5
HSP-150-3.8
HSP-150-5
Output(Rated/Peak)
2.5V, 0~30A / 40A
3.8V, 0~30A / 40A
5V, 0~30A / 40A
Tol.
±2%
±2%
±2%
R&N
80mV
100mV
100mV
De U
ve nd
lop er
me
nt
250x 78x 28 mm
AC input voltage range ........
DC adjustment range ...........
AC inrush current ................
Overload protection .............
Over voltage protection .......
Setup, rise, hold up time ......
Withstand voltage ...............
Working temperature ...........
Safety standards .................
EMC standards ...................
Model No.
HSP-300-2.8
HSP-300-4
HSP-300-5
Effi.
86%
88%
90%
•
•
•
•
•
•
199x 105x 41 mm
Output
2.5V, 0~50A
3.6V, 0~50A
5V, 0~50A
Tol.
±2%
±2%
±2%
R&N
100mV
100mV
100mV
Output
2.8V, 0~60A
4V, 0~60A
5V, 0~60A
Tol.
±2%
±2%
±2%
R&N
80mV
100mV
100mV
Effi.
86%
88%
90%
•
•
•
•
•
Universal AC input / Full range
Built-in active PFC function
Conformal coating
High efficiency up to 86%
Protections:
Short circuit / Overload /
Over voltage / Over temperature
• Fanless design (HDP-190);
HDP-240
Forced air cooling by built-in DC fan (HDP-240)
215x 115x 36 mm
• 1U low profile: 36mm
HDP-190
• Suitable for moving sign applications
215x 115x 36 mm
• 3 years warranty
AC input voltage range ........ 90~264VAC; 127~370VDC
DC adjustment range ........... V1: 3.6~4V; V2: 2.5~3V
AC inrush current ................ Cold start, 45A at 230VAC
Overload protection ............. V1+V2: 105%~150%, V2: 125%~170%
hiccup mode, auto-recovery
Over voltage protection ....... V1: 4.37~5.13V, V2: 3.22~3.78V
shut down O/P voltage, re-power on to recover
Setup, rise, hold up time ...... 1000ms, 50ms, 16ms at full load and 230VAC
Withstand voltage ............... I/P - O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature ........... -30~+70°C (refer to output derating curve)
Safety standards ................. UL60950-1, TUV EN60950-1 approved
EMC standards ................... EN55022 class B, EN61000-3-2,3, EN55024,
EN61000-4-2,3,4,5,6,8,11, EN61000-6-2
Packing ............................... 0.95kg ; 15pcs / 15.3kg / 0.7CUFT (HDP-190)
1kg ; 15pcs / 16kg / 0.7CUFT (HDP-240)
HDP-190 Series
Universal AC input / Full range
Built-in active PFC function
Conformal coating
High efficiency up to 87%
Protections:
Short circuit / Overload /
Over voltage / Over temperature
Forced air cooling by built-in DC fan
1U low profile: 41mm
Built-in remote sense function
LED indicator for power on
Suitable for moving sign applications
3 years warranty
AC input voltage range ........ 85~264VAC; 120~370VDC
DC adjustment range ........... 2.5V: 2.3~2.8V; 3.6V: 3.24~3.96V; 5V: 4.5~5.5V
AC inrush current ................ Cold start, 70A at 230VAC
Overload protection ............. 105%~135% hiccup mode, auto-recovery
Over voltage protection ....... 2.5V: 2.88~3.38V; 3.6V:4.14~4.86V; 5V: 5.75~6.75V
shut down O/P voltage, re-power on to recover
Setup, rise, hold up time ...... 3000ms, 50ms, 16ms at full load and 230VAC
Withstand voltage ............... I/P - O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature ........... -40~+70°C (refer to output derating curve)
Safety standards ................. UL60950-1, TUV EN60950-1 approved
EMC standards ................... EN55022 class B, EN61000-3-2,3, EN55024,
EN61000-4-2,3,4,5,6,8,11, EN61000-6-2
Packing .............................. 0.97kg ; 16pcs / 16.5kg / 0.87CUFT
Model No.
HSP-250-2.5
HSP-250-3.6
HSP-250-5
90~264VAC; 127~370VDC
2.8V: 2.5~3V; 4V: 3.6~4.4V; 5V: 4.5~5.5V
Cold start, 50A at 230VAC
120%~140% hiccup mode, auto-recovery
2.8V: 3.22~3.78V; 4V: 4.6~5.4V; 5V: 5.7~7.0V
shut down O/P voltage, re-power on to recover
2000ms, 100ms, 16ms at full load and 230VAC
I/P - O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
-30~+70°C (refer to output derating curve)
Design refer to UL60950-1, TUV EN60950-1,
CCC GB4943
Design refer to EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11, GB9254
190W & 240W Dual Output with PFC Function
for High
Efficiency
Moving
Sign
250W Single
Output
with PFC
Function
•
•
•
•
•
• Universal AC input / Full range
• Withstand 300VAC surge input for 5
seconds
• Built-in active PFC function
• Conformal coating
• High efficiency up to 90%
• Protections: Short circuit / Overload
/ Over voltage / Over temperature
• Cooling by free air convection
• 1U low profile: 28mm
• Built-in remote sense function
• LED indicator for power on
• Suitable for moving sign applications
• 3 years warranty
UL/CUL/TUV/CCC/CB/CE pending
Model No.
HDP-190
Output
3.8V, 0~40A
2.8V, 0~22A
HDP-240 Series
Model No.
Output
HDP-240
3.8V, 0~50A
2.8V, 0~27.5A
Effi.
79%
83%
87%
9
Tol.
±2%
±2%
R&N
100mV
100mV
Effi.
86%
Max.
192W
Tol.
±2%
±2%
R&N
100mV
100mV
Effi.
84%
Max.
241W
Enclosed-PFC
75~240W Single Output
Features
SP-200
S P -24 0
SP-1 5 0
SP-1 0 0
• Universal AC input / Full range
• Built-in active PFC function
• Protections: Short circuit / Overload / Over voltage /
Over temperature (SP-150 / 200 / 240)
• Cooling by free air convection (SP-75 / 100 / 150)
• Forced air cooling by built-in DC fan (SP-200 / 240)
• Optional remote ON/OFF control (SP-75~200)
• Built-in fan speed control (SP-200)
• Built-in fan ON/OFF control (SP-240)
• 100% full load burn-in test
• 3 years warranty
SP-75
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
SP-7 5
AC in p u t v o l t a g e ra n g e
8 5 ~2 6 4 VAC; 1 2 0 ~3 7 0 VDC
8 8 ~ 2 6 4 VA C ; 1 2 4 ~ 3 7 0 V D C
Co l d s t a rt ,
Co l d s t ar t ,
C o ld st a r t ,
C o ld st a r t ,
C o ld st a r t ,
4 5 A a t 2 3 0 VAC
3 5 A a t 23 0 VA C
4 5 A a t 2 3 0 VA C
5 0 A a t 2 3 0 VA C
4 0 A a t 2 3 0 VA C
-5%~+10% rated output voltage
±15% rated output voltage
105%~150%
105%~135%
Constant current limiting, auto-recovery
Hiccup mode, auto-recovery
115%~135%
110%~135%
120%~150%
Sh u t o ff , AC re c y c l e t o re -s t a rt
I / P-O/ P: 3 k VA C, I / P-FG: 1 . 5 k VA C , O / P - FG : 0 . 5 kVA C , 1 m in u t e
-1 0 ~+6 0 °C
- 1 0 ~ + 5 5 °C
- 1 0 ~ + 6 0 °C
- 2 0 ~ + 7 0 °C
UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 -1 , GB4 9 4 3 ( S P - 2 0 0 o n ly) a p p r o ve d
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -4 -2 ,3 , 4 , 5 , 6 , 8 , 11, E N 6 1 0 0 0 - 3 - 2 , 3 , G B 9 2 5 4 ( S P - 2 0 0 o n ly)
5P / 9.5mm pitch
7P / 9.5mm pitch terminal block with cover
179x 97x 33
179x 99x 45
199x 99x 50
199x 99x 50
190x 93x 50
920A
915A
916A
916B
987A
20pcs/12.0kg
20pcs/14.3kg
20pcs/16.4kg
20pcs/17.9kg
18pcs/15.4kg
AC in r us h c u rre n t ( ma x . )
DC adjus t me n t ra n g e
Ra n g e
Over load
p r otection
Type
Over vo l t a g e Ra n g e
p r otection
Type
W ithstan d v o l t a g e
W o r kin g t e mp e ra t u re
S afety s t a n d a rd s
E MC stand a rd s
C o n n ect i o n
D im en sion ( L x W x H ) ( mm)
C ase N o .
P ackin g
SP-1 0 0
75W
SP-150
(SP-200 only)
150W
SP-75
Model No.
Output
Tol.
R&N
Effi.
SP-75-3.3
3.3V, 0~15A
±2%
80mV
70.0%
5V, 0~15A
±2%
80mV
76.0%
7.5V, 0~10A
±2%
80mV
79.0%
SP-75-5
SP-75-7.5
SP-75-12
12V, 0~6.3A
±2%
80mV
81.0%
13.5V, 0~5.6A
±2%
80mV
82.0%
SP-75-15
15V, 0~5.0A
±2%
80mV
82.0%
SP-75-24
24V, 0~3.2A
±1%
100mV
83.0%
SP-75-27
27V, 0~2.8A
±1%
100mV
83.0%
SP-75-48
48V, 0~1.6A
±1%
100mV
83.0%
SP-75-13.5
100W
Model No.
SP-150-3.3
SP-150-5
SP-150-7.5
SP-150-12
SP-150-13.5
SP-150-15
SP-150-24
SP-150-27
SP-150-48
Output
Tol.
R&N
Effi.
SP-100-3.3
3.3V, 0~20.0A
±2%
100mV
75.0%
5V, 0~20.0A
±2%
100mV
79.0%
SP-100-7.5
7.5V, 0~13.5A
±2%
100mV
82.0%
SP-100-12
12V, 0~8.50A
±2%
100mV
82.5%
13.5V, 0~7.50A
±2%
100mV
83.0%
15V, 0~6.70A
±2%
100mV
84.0%
SP-100-5
SP-100-13.5
SP-100-15
SP-100-24
24V, 0~4.20A
±1%
150mV
87.0%
SP-100-27
27V, 0~3.80A
±1%
150mV
86.0%
SP-100-48
48V, 0~2.10A
±1%
250mV
84.0%
SP-150
Output
3. 3 V, 0 ~ 3 0 . 0 A
5V, 0 ~ 3 0 . 0 A
7. 5 V, 0 ~ 2 0 . 0 A
12V, 0~12.5A
13.5V, 0~11.2A
15V, 0~10.0A
24V, 0~6.30A
27V, 0~5.60A
48V, 0~3.20A
Tol.
±2%
±2%
±2%
±2%
± 2%
±2%
±1%
±1%
±1%
R&N
1 0 0 mV
100mV
1 0 0 mV
100mV
100mV
100mV
150mV
150mV
250mV
200W
Model No.
SP-200-3.3
SP-200-5
SP-200-7.5
SP-200-12
SP-200-13.5
SP-200-15
SP-200-24
SP-200-27
SP-200-48
SP-100
Model No.
SP-200
SP-240
SP-200
Output
3.3V, 0~40.0A
5V, 0~40.0A
7.5V, 0~26.7A
12V, 0~16.7A
13.5V, 0~14.9A
15V, 0~13.4A
24V, 0~8.40A
27V, 0~7.50A
48V, 0~4.20A
Tol.
±2%
±2%
±2%
±2%
±2%
±2%
±1%
±1%
±1%
R&N
1 0 0 mV
1 0 0 mV
1 0 0 mV
100mV
100mV
100mV
150mV
150mV
250mV
Output
5V, 0~45A
7.5V, 0~32A
12V, 0~20A
15V, 0~16A
24V, 0~10A
30V, 0~8.0A
48V, 0~5.0A
Tol.
±2%
±2%
±1%
±1%
±1%
±1%
±1%
R&N
150mV
150mV
150mV
150mV
150mV
150mV
150mV
240W
Model No.
SP-240-5
SP-240-7.5
SP-240-12
SP-240-15
SP-240-24
SP-240-30
SP-240-48
48hrs delivery—
We keep enough stock for 95% of standard models at our
2400m 2 warehouse. We can arrange prompt delivery within
48hrs.
10
Effi.
73.0%
77.5%
81.0%
84.0%
84.0%
85.0%
85.0%
85.0%
85.0%
Effi.
71.0%
76.0%
78.5%
84.0%
84.0%
84.0%
85.0%
85.0%
85.0%
SP-240
Effi.
79.0%
83.0%
86.0%
86.0%
87.0%
88.0%
89.0%
Enclosed-PFC
320~750W Single Output
Features
SP-750
P S P-6 0 0
SP-4 8 0
• Universal AC input / Full range
• Built-in active PFC function
• Protections: Short circuit / Overload / Over voltage /
Over temperature
• Forced air cooling by built-in DC fan
• Built-in fan speed control (SP-320)
• Built-in remote sense function and ON/OFF control
(SP-480/750 & PSP-600)
• C u r r e n t s h a r i n g u p t o 2 4 0 0 W ( 3 + 1 ) ( P S P -6 0 0 )
• W i t h D C OK s i g n a l o u t p u t ( P S P - 6 0 0 )
• W i t h P G/ P F s i g n a l o u t p u t ( S P - 7 5 0 )
• 100% full load burn-in test
• 3 years warranty
SP-32 0
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
SP-3 2 0
SP- 4 8 0
PSP-600
8 5 ~ 2 6 4 VA C
8 8 ~ 2 6 4 VA C
AC in p u t v o l t a g e ra n g e
8 8 ~2 6 4 VAC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 4 0 A a t 2 3 0 VAC
DC adjus t me n t ra n g e
±10% rated output voltage
SP-750
9 0 ~ 2 6 4 VA C
C o ld S t a r t , 4 5A a t 2 3 0 VA C
Ra n g e
105%~135%
105%~145%
105%~135%
105%~125%
Type
Hiccup mode,
auto-recovery
Constant current limiting,
auto-recovery
Constant current limiting,
auto-recovery
Constant current limiting,
hiccup after 3sec.
Over vo l t a g e p ro t e c t i o n
115%~145%
115%~140%
W ithstan d v o l t a g e
I / P - O/ P: 3 k VA C, I / P - FG: 1 . 5 k VA C , O / P - FG : 0 . 5 kVA C ( sh o r t f o r S P - 4 8 0 ) , 1 m in u t e
W o r kin g t e mp e ra t u re
-2 0 ~+6 5 °C
S afety st a n d a rd s
UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 -1 a p p r o ve d ; G B 4 9 4 3 a p p r o ve d a lso f o r S P - 3 2 0 ( e xp e ct f o r 3 . 3 V / 5 P N C / 3 6 V)
E MC stan d a rd s
EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EN61000-6-2(SP-480/750), GB9254 (SP-320 only)
Co n n ect i o n
9P / 9.5mm pitch terminal
block with cover
Over load
p r otectio n
-2 0 ~ + 6 0 °C
9P / 11mm pitch terminal
block with cover
7+8P / 9.5mm pitch
terminal block with cover
5P / 10mm pitch terminal
block with cover for input;
copper pillars for output
278x127x63.5
Dim en sion ( L x W x H ) ( mm)
215x115x50
278x127x43
170x120x93
C ase N o .
912G
929A
910A
919A
P ackin g
12pcs / 14.0kg
6pcs / 11.3kg
8pcs / 15.5kg
6pcs / 18.4kg
SP-320 Series
PSP-600 Series
Model No.
Output
*SP-320-3.3
SP-320-5
*SP-320-5PNC
Tol.
R&N
Effi.
3.3V, 0~60.0A
±1%
150mV
74%
5V, 0~55.0A
±2%
150mV
79%
Model No.
Output
Tol.
R&N
Effi.
PSP-600-5
5V, 0~80A
±2%
180mV
79%
PSP-600-12
12V, 0~50A
±1%
240mV
84%
13.5V, 0~44.5A
±1%
240mV
85%
15V, 0~40A
±1%
240mV
85%
5V, 0~55.0A
±2%
150mV
80%
SP-320-7.5
7.5V, 0~40.0A
±2%
150mV
83%
SP-320-12
12V, 0~25.0A
±1%
150mV
86%
PSP-600-15
13.5V, 0~22.0A
±1%
150mV
86%
PSP-600-24
24V, 0~25A
±1%
240mV
86%
27V, 0~22.2A
±1%
240mV
86%
48V, 0~12.5A
±1%
300mV
87%
Output
Tol.
R&N
Effi.
SP-750-5
5V, 0~120A
±2%
120mV
80%
SP-750-12
12V, 0~62.5A
±1%
120mV
85%
SP-750-15
15V, 0~50.0A
±1%
120mV
87%
SP-750-24
24V, 0~31.3A
±1%
120mV
89%
SP-750-27
27V, 0~27.8A
±1%
120mV
89%
SP-750-48
48V, 0~15.7A
±1%
120mV
90%
SP-320-13.5
PSP-600-13.5
SP-320-15
15V, 0~20.0A
±1%
150mV
86%
PSP-600-27
SP-320-24
24V, 0~13.0A
±1%
150mV
87%
PSP-600-48
SP-320-27
27V, 0~11.7A
±1%
200mV
88%
*SP-320-36
36V, 0~8.80A
±1%
220mV
87%
SP-320-48
48V, 0~6.70A
±1%
240mV
89%
* Without
SP-750 Series
Model No.
models
SP-320-5PNC with conformal coating and high ambient temperature operation
ability is suitable for LED moving sign applications, MOQ required.
SP-480 Series
Model No.
SP-480-3.3
SP-480-5
SP-480-12
SP-480-15
SP-480-24
SP-480-48
Output
3.3V, 0~85A
5V, 0~85A
12V, 0~43A
15V, 0~35A
24V, 0~22A
48V, 0~11A
Tol.
±2.0%
±2.0%
±1.5%
±1.5%
±1.0%
± 1.0%
R&N
80mV
80mV
120mV
150mV
150mV
240mV
Effi.
73%
79%
85%
85%
87%
89%
Q.A.
11
Who can provide you better services and be a trustworthy
partner in the power industry?
— "MEAN WELL" tries to be —
Enclosed-PFC
75~200W Low Profile
Features
• Ultra low profile: 30mm
• Universal AC input / Full range
• Built-in active PFC function
• Protections: Short circuit / Overload / Over voltage /
Over temperature (RSP-100/150/200)
• Cooling by free air convection
• Built-in constant current limiting circuit
(RSP-75/100/150)
• Remote ON/OFF control (RSP-75/100/150)
• LED indicator for power on
RS P - 2 0 0
R SP-1 5 0
RSP-1 0 0
• 3 years warranty
RSP-75
General Specification (Please refer to www.meanwell.com for detail spec.)
RSP-100
(RSP-75/100 pending)
Model No.
RSP-75
RSP-150
RSP-200
AC input voltage range
85~264VAC; 120~370VDC
AC inrush current (max.)
Cold start, 35A at 230VAC
40A at 230VAC
DC adjustment range
-5%~+10% rated output voltage
±10% rated output voltage
88~264VAC; 124~370VDC
Over load
p r otection
Range
105%~135%
105%~150%
Type
Constant current limiting, auto-recovery
Hiccup mode, auto-recovery
Over voltage
protection
Range
110%~135%
115%~145%
Type
Shut down O/P voltage, re-power on to recover
Withstand voltage
I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature
-25~+70° C
Safety standards
Design refer to UL60950-1, TUV EN60950-1,
EN61558-1, EN61558-2-16, CCC GB4943
EMC standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, GB9254
Connection
5P / 9.5mm pitch terminal block
7P / 9.5mm pitch terminal block
9P / 9.5mm pitch terminal block
Dimension (LxWxH) (mm)
159x97x30
179x99x30
215x115x30
-30~+70° C (refer to output derating curve)
75W
Mo d e l N o .
R S P -7 5 - 3 . 3
R S P -7 5 - 5
RS P -7 5 - 7 . 5
RS P -7 5 - 1 2
R S P -7 5 - 1 3 . 5
R S P -7 5 - 1 5
RSP-75
Ou tput
T ol .
R&N
UL60950-1, UL62368-1,
TUV EN60950-1, EN61558-1,
EN61558-2-16, CCC GB4943
approved
199x99x30
UL60950-1, TUV EN60950-1,
CCC GB4943 approved
150W
NEW
RSP-150
Effi.
Model No.
Output
Tol.
R&N
Effi.
RSP-150-3.3
3.3V, 0~30A
±2%
100mV
81.5%
3. 3V, 0 ~1 5 A
±2%
80mV
79.0%
5V, 0 ~1 5 A
±2%
80mV
82.0%
RSP-150-5
7. 5 V, 0 ~1 0 A
±2%
80mV
84.0%
RSP-150-7.5
5V, 0~30A
±2%
100mV
87.0%
7.5V, 0~20A
±2%
100mV
88.5%
1 2 V, 0 ~6 . 3 A
±2%
120mV
86.0%
RSP-150-12
1 3 . 5V, 0 ~5 . 6 A
±2%
120mV
86.0%
RSP-150-13.5
12V, 0~12.5A
±2%
100mV
90.0%
13.5V, 0~11.2A
±2%
100mV
87.5%
1 5 V, 0 ~5 A
±2%
120mV
86.0%
RSP-150-15
15V, 0~10A
±2%
100mV
88.5%
RSP-150-24
24V, 0~6.3A
±1%
150mV
89.0%
R S P -7 5 - 2 4
2 4 V, 0 ~3 . 2 A
±1%
120mV
88.0%
RS P -7 5 - 2 7
2 7 V, 0 ~2 . 8 A
±1%
120mV
88.0%
RSP-150-27
27V, 0~5.6A
±1%
150mV
89.5%
RS P -7 5 - 4 8
4 8 V, 0 ~1 . 6 A
±1%
200mV
88.5%
RSP-150-48
48V, 0~3.2A
±1%
250mV
90.0%
100W
RSP-100
Mode l No .
Output
Tol .
R&N
Effi.
R S P -1 0 0 - 3 . 3
3. 3V, 0 ~2 0 A
±2%
100mV
83.0%
R S P -1 0 0 - 5
R S P -1 0 0 - 7 . 5
RS P -1 0 0 - 1 2
5V, 0 ~2 0 A
±2%
100mV
86.0%
7. 5V, 0 ~1 3 . 5 A
±2%
100mV
87.0%
1 2 V, 0 ~8 . 5 A
±1%
100mV
86.0%
1 3 . 5 V, 0 ~7 . 5 A
±1%
100mV
86.5%
RS P -1 0 0 - 1 5
1 5 V, 0 ~6 . 7 A
±1%
100mV
87.0%
R S P -1 0 0 - 2 4
2 4 V, 0 ~4 . 2 A
±1%
150mV
87.0%
RS P -1 0 0 - 2 7
2 7 V, 0 ~3 . 8 A
±1%
150mV
87.0%
R S P -1 0 0 - 4 8
4 8 V, 0 ~2 . 1 A
±1%
250mV
88.0%
RS P -1 0 0 - 1 3 . 5
200W
Model No.
RSP-200-2.5
RSP-200-3.3
RSP-200-4
RSP-200-5
RSP-200-7.5
RSP-200-12
RSP-200-13.5
RSP-200-15
RSP-200-24
RSP-200-27
RSP-200-36
RSP-200-48
12
RSP-200
Output
2.5V, 0~40A
3.3V, 0~40A
4V, 0~40A
5V, 0~40A
7.5V, 0~26.7A
12V, 0~16.7A
13.5V, 0~14.9A
15V, 0~13.4A
24V, 0~8.4A
27V, 0~7.5A
36V, 0~5.56A
48V, 0~4.2A
Tol.
±2%
±2%
±2%
±2%
±2%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
R&N
100mV
100mV
100mV
150mV
150mV
150mV
150mV
150mV
150mV
200mV
220mV
240mV
Effi.
81.5%
84.0%
85.5%
87.0%
89.0%
89.0%
89.0%
89.5%
89.5%
89.0%
90.0%
90.0%
Enclosed-PFC
320~750W Low Profile
Features
•
•
•
•
•
•
•
•
RS P - 7 5 0
RSP-5 0 0
•
•
•
•
RSP-3 2 0
1U low profile
Universal AC input / Full range
Built-in active PFC function
Protections: Short circuit / Overload / Over voltage /
Over temp. / Fan alarm (RSP-750)
Forced air cooling by built-in DC fan
Vo can be trimmed 40~110% by 2~5.5VDC external
control signal (RSP-750)
Io can be trimmed 40~110% by 2~5.5VDC external
control signal (RSP-750)
Built-in remote sense and ON/OFF control
(RSP-500/750)
Built-in auxiliary power (RSP-750)
DC OK signal (RSP-750)
LED indicator for power on
3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
( R S P - 5 0 0 p e n d i n g ) (RSP-320 only)
Model No.
RSP-320
RSP-500
RSP-750
AC input voltage range
88~264VAC; 124~370VDC
85~264VAC; 120~370VDC
90~264VAC; 127~370VDC
AC inrush current(max.)
Cold start, 40A at 230VAC
DC adjustment range
±10% rated output voltage
105%~125%
Overload
protection
Over voltage
protection
Range
105%~135%
105%~130%
Type
Hiccup mode, auto-recovery
Constant current limiting, auto-recovery
Range
115%~145%
Type
Shut down O/P voltage, re-power on to recover
Withstand voltage
I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature
-30~+70° C (refer to output derating curve)
Safety standards
UL60950-1, TUV EN60950-1, CCC GB4943(RSP-320 only) approved (TUV / UL pending for RSP-500)
EMC standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(RSP-500/750), GB9254(RSP-320 only)
3P / 9.5mm pitch terminal block
3P / 10mm pitch terminal block with cover
6P / 11mm pitch terminal block
Copper pillars
Dimension (LxWxH) (mm)
215x115x30
230x127x40.5
250x127x41
Case No.
207A
226A
212A
Connection
Input
9P / 9.5mm pitch terminal block
Output
320W
RSP-320
500W
Model No.
RSP-500
Tol.
R&N
Effi.
3.3V, 0~90A
±2%
120mV
81.0%
4V, 0~90A
±2%
120mV
83.5%
RSP-500-5
5V, 0~90A
±2%
150mV
83.5%
RSP-500-12
12V, 0~41.7A
±1%
150mV
88.0%
Model No.
Output
Tol.
R&N
Effi.
RSP-320-2.5
2.5V, 0~60A
±2%
100mV
79.5%
RSP-500-4
RSP-320-3.3
3.3V, 0~60A
±2%
100mV
82.0%
RSP-500-3.3
Output
RSP-320-4
4V, 0~60A
±2%
100mV
84.5%
RSP-500-15
15V, 0~33.4A
±1%
150mV
88.0%
RSP-320-5
5V, 0~60A
±2%
150mV
85.0%
RSP-500-24
24V, 0~21A
±1%
150mV
88.0%
7.5V, 0~40A
±2%
150mV
88.0%
RSP-500-27
27V, 0~18.6A
±1%
200mV
88.5%
RSP-500-48
48V, 0~10.5A
±1%
240mV
90.0%
RSP-320-7.5
RSP-320-12
12V, 0~26.7A
±1%
150mV
88.0%
13.5V, 0~23.8A
±1%
150mV
88.0%
RSP-320-15
15V, 0~21.4A
±1%
150mV
88.5%
RSP-320-24
24V, 0~13.4A
±1%
150mV
89.0%
RSP-320-27
27V, 0~11.9A
±1%
200mV
89.0%
RSP-320-36
36V, 0~8.9A
±1%
220mV
89.5%
RSP-320-13.5
RSP-320-48
48V, 0~6.7A
±1%
240mV
750W
Model No.
90.0%
13
RSP-750
Output
Tol.
R&N
Effi.
RSP-750-5
5V, 0~100A
±2%
150mV
82.0%
RSP-750-12
12V, 0~62.5A
±1%
150mV
87.0%
RSP-750-15
15V, 0~50A
±1%
150mV
89.0%
RSP-750-24
24V, 0~31.3A
±1%
150mV
90.5%
RSP-750-27
27V, 0~27.8A
±1%
150mV
90.5%
RSP-750-48
48V, 0~15.7A
±1%
150mV
92.0%
Enclosed-PFC
1000~3000W Single Output
Features
RS P -24 0 0 / 3 0 0 0
RS P -2 0 0 0
RSP-1 5 0 0
• Universal AC input / Full range (RSP-1000/1500/2000)
AC input 180~264VAC only (RSP-2400/3000)
• Built-in active PFC function
• Protections:
Short circuit / Overload / Over voltage /
Over temperature / Fan alarm (RSP-2400/3000)
• Forced air cooling by built-in DC fan
• High power density up to 21.4W/in³ (RSP-2000)
• Vo can be trimmed by external resistor or external
control signal
• Built-in current sharing
• Built-in remote sense and ON/OFF control
• Built-in auxiliary power
• DC OK signal (RSP-1000/2000)
• Alarm signal output (RSP-1500/2000/2400/3000)
• 5 years warranty
RSP-1 0 0 0
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No.
RSP-1000
RSP-1500
RSP-2000
RSP-2400
RSP-3000
Cold start,
60A at 230VAC
AC input voltage range
90~264VAC; 127~370VDC
AC inrush current (max.)
Cold start,
40A at 230VAC
Cold start,
60A at 230VAC
Cold start,
50A at 230VAC
DC adjustment range
±10%
rated output voltage
-30%~+10%
rated output voltage
±10%
rated output voltage
Range
105%~125%
105%~135%
105%~125%
Type
Constant current limiting,
auto-recovery
Constant current limiting, shut off after 5 sec.,
re-power on to recover
Constant current limiting, shut off after 5
sec., re-power on to recover (can adjust
to continuous constant current limiting)
Range
115%~135%
115%~140%
120%~145%
115%~140%
Type
Shut down O/P voltage, re-power on to recover
-35~+70° C
-20~+70° C
Overload
protection
Over voltage
protection
180~264VAC; 254~370VDC
100%~112%
Withstand voltage
I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature
-20~+60° C
Safety standards
UL60950-1, TUV EN60950-1 approved
EMC standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(RSP-1000/2000)
-20~+70° C
3P/10mm pitch terminal
block with cover
3P/13mm pitch terminal
block with cover
3P/10mm pitch terminal
block with cover
3P/13mm pitch terminal block with cover
Output
Dimension (LxWxH) (mm)
Case No.
Copper pillars
295x127x41
952B
278x127x83.5
943A
295x127x41
952D
278x177.8x63.5
982B
Packing
1.95kg;
3.0kg;
6pcs / 12.7kg / 1.15CUFT 4pcs / 13kg / 1.19CUFT
1.95kg;
6pcs / 12.7kg / 1.15CUFT
3.3kg;
4kg;
4pcs / 14.2kg / 1.89CUFT 4pcs / 16kg / 1.89CUFT
Connection
Input
1000W
2000W
RSP-1000
RSP-2000
Model No.
Output
Tol.
R&N
Effi.
Model No.
Output
RSP-1000-12
12V, 0~60A
±1%
150mV
83%
RSP-1000-15
15V, 0~50A
±1%
150mV
85%
RSP-1000-24
24V, 0~40A
±1%
150mV
88%
RSP-2000-12
RSP-2000-24
RSP-2000-48
12V, 0~100A
24V, 0~80A
48V, 0~42A
RSP-1000-27
27V, 0~37A
±1%
150mV
88%
RSP-1000-48
48V, 0~21A
±1%
150mV
90%
1500W
Model No.
Tol.
R&N
±2%
±1%
±1%
R&N
Effi.
150mV
200mV
300mV
87.0%
90.5%
92.0%
2400W
RSP-2400
Model No.
Output
Tol.
R&N
Effi.
RSP-2400-12
12V, 0~166.7A
±1%
150mV
87.0%
RSP-2400-24
24V, 0~100A
±1%
150mV
90.0%
Effi.
RSP-2400-48
48V, 0~50A
±1%
200mV
91.0%
3000W
RSP-1500
Output
Tol.
RSP-1500-5
5V, 0~240A
±2%
150mV
80%
RSP-1500-12
12V, 0~125A
±1%
150mV
87%
RSP-1500-15
15V, 0~100A
±1%
150mV
87%
Model No.
Output
Tol.
R&N
Effi.
RSP-1500-24
24V, 0~63A
±1%
150mV
90%
RSP-3000-12
12V, 0~200A
±1%
150mV
86.0%
RSP-1500-27
27V, 0~56A
±1%
150mV
90%
RSP-3000-24
24V, 0~125A
±1%
150mV
89.5%
RSP-1500-48
48V, 0~32A
±1%
200mV
91%
RSP-3000-48
48V, 0~62.5A
±1%
200mV
90.5%
14
RSP-3000
Enclosed-PFC
150~5000W Single Output
5 0 0 0 W S i ng l e O utp ut
150~1500W Output Voltage Programmable
• Vo can be trimmed 20~110% by
1~5.5VDC external control signal
• Io can be trimmed 20~100% by
1~5VDC external control signal
• Current sharing up to 4 units
• Built-in remote sense and
ON/OFF control
• Built-in 12V/0.1A auxiliary power
• Alarm signal output
• 5 years warranty
• 3 3-wire/ 196~305VAC or
3 4-wire/ Y 340~530VAC
wide input range
• Built-in active PFC function
• High efficiency up to 91%
• Protections:
Short circuit / Overload /
Over voltage / Over temp. /
Fan alarm
• Built-in fan speed control
• Universal AC input / Full range
• Built-in active PFC function
• Protections:
Short circuit / Overload /
Over voltage / Over temperature
• Vo can be trimmed 20~110% by
1~5.5VDC external control signal
• Forced air cooling by built-in DC
fan (except for SPV-150)
• Cooling by free air convection
(SPV-150)
• Built-in remote sense and
ON/OFF control (SPV-1500)
• Built-in 12V/0.1A auxiliary
power and current sharing up
to 4500W (SPV-1500)
• 3 years warranty
(SPV-1500)
UL / CUL / TUV / CB / CE pending
De U
ve nd
lop er
me
nt
RS T -50 0 0
480x 210x 83.5 mm
AC input voltage range .............. 3
3
3-wire /
196~305VAC or
DC adjustment range ................ -2%~+20% rated output voltage
AC inrush current ..................... Cold start, 50A at 230VAC/ or 400VAC/Y
Overload protection .................. 100%~110% constant current limiting,
constant current limiting, auto-recovery
Over voltage protection ....... 115%~140%(SPV-150/300); 120%~140%(SPV-1500)
shut down O/P voltage, re-power on to recover
Withstand voltage ............... I/P - O/P: 3kVAC, I/P-FG: 1.5kVAC, O/P-FG: 0.5kVAC
Working temperature ........... -20~+65°C (SPV-150/300); -20~+70° C (SPV-1500)
Safety standards ................. UL60950-1, TUV EN60950-1 approved
EMC standards ................... EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Packing ............................... 12pcs / 14kg(SPV-150/300); 4pcs / 13kg(SPV-1500)
re-power on to recover
Setup, rise, hold up time ........... 3000ms, 80ms, 16ms at full load
Withstand voltage ..................... I/P-O/P: 3kVAC, I/P-FG: 2kVAC,
O/P-FG: 0.5kVAC
Working temperature ................. -30~+70°C (refer to output derating curve)
Safety standards ....................... Design refer to UL60950-1, TUV EN60950-1
EMC standards ......................... Design refer to EN55022 class A,
EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11,
SPV-150 Series
EN61000-6-2
Tol.
R&N
Effi.
RST-5000-24
24V, 0~200A
±1%
150mV
89%
RST-5000-48
48V, 0~105A
±1%
200mV
91%
S PV - 1 5 0
215x 115x 50 mm
AC inrush current ................ Cold start, 40A (SPV-150/300);
60A (SPV-1500) at 230VAC
Overload protection ............. 105%~150% (SPV-150); 105%~135% (SPV-300/1500)
auto-recovery (can adjust to delay shut down)
Over voltage protection ............. 125%~140% shut down O/P voltage,
Output
SPV-300
215x 115x 50 mm
AC input voltage range ........ 88~264VAC (SPV-150/300); 90~264VAC (SPV-1500)
DC adjustment range ........... -15%~+10% (SPV-150/300); ±5% (SPV-1500)
rated output voltage
4-wire/ Y 340~530VAC
Model No.
SPV-1500
278x 127x 83.5 mm
Model No.
Output
Tol.
R&N
Effi.
SPV-150-12
12V, 0~12.5A
±1%
150mV
82%
SPV-150-24
24V, 0~6.25A
±1%
150mV
83%
SPV-150-48
48V, 0~3.125A
±1%
240mV
83%
SPV-300 Series
Customer Satisfaction —
Today's effort, tomorrow's reward. Continuously improve
CQTS to satisfy customer is our goal.
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at [email protected] for information of your local
distributors.
15
Model No.
Output
Tol.
R&N
Effi.
SPV-300-12
12V, 0~25A
±1%
150mV
83.5%
SPV-300-24
24V, 0~12.5A
±1%
150mV
85.0%
SPV-300-48
48V, 0~6.25A
±1%
240mV
86.5%
SPV-1500 Series
Model No.
Output
Tol.
R&N
Effi.
SPV-1500-12
12V, 0~125A
±1%
150mV
86.5%
SPV-1500-24
24V, 0~63A
±1%
150mV
90.0%
SPV-1500-48
48V, 0~32A
±1%
200mV
90.0%
Enclosed-PFC
75~375W 3~4 Output
Features
QP-375
QP-320
QP-200
TP-150
QP-150
TP-100
QP-100
• Universal AC input / Full range
• Protections: Short circuit / Overload /
Over voltage / Over temperature
• Over temperature protection (200~375W built-in,
option for 100W and 150W)
• Built-in active PFC function
• Cooling by free air convection (75W / 100W)
• Forced air cooling by built-in DC fan
(150W / 200W / 320W / 375W)
• 100% full load burn-in test
• 3 years warranty
TP -75
General Specification (Please refer to www.meanwell.com for detail spec.)
Mo d el N o .
TP-1 0 0
QP-100
TP-7 5
TP - 1 5 0
QP-150
(except for QP-320)
QP-200
QP-320
C o ld st a r t ,
4 5 A a t 2 3 0 VA C
A C in p u t v o l t a g e ra n g e
9 0 ~2 6 4 VAC; 1 2 7 ~3 7 0 VDC
A C in r us h c u rre n t ( ma x . )
Co l d s t a rt ,
2 0 A a t 2 3 0 VAC
Co l d s t a rt ,
4 0 A a t 2 3 0 VA C
C o ld st a r t ,
3 0 A a t 2 3 0 VA C
DC adjus t me n t ra n g e
CH1:
-5%~+10% rated
output voltage
CH1: -5%~+10% rated output voltage
(CH1&2 for QP-100/150-3x,
QP-100/150-D/F)
CH1&2:
-5%~+10% rated output voltage
Range
Over lo ad
pr o tectio n
Type
QP-375
85~264VAC; 120~370VDC
105%~150%
All outputs:
-5%~+10% for QP-375-5,
±10% for QP-375-24
105%~135%
Constant current
limiting,
auto-recovery
Hiccup mode, auto-recovery
Over vol t a g e p ro t e c t i o n
CH1 : 11 5 % ~1 3 5 %
W ith stand v o l t a g e
W or king t e mp e ra t u re
I / P - O/ P: 3 k VA C, I / P - F G: 1 . 5 k VA C , 1 m in u t e
-1 0 ~+6 0 °C (re f e r t o o u t p u t d e ra t in g cu r ve )
Fold back
current limiting,
auto-recovery
Hiccup mode,
auto-recovery
C H 1 : 11 5 % ~ 1 3 5 % r a t e d
output voltage
115%~135% for CH1 or CH1&2
800ms, 60ms, 24ms at full load
a n d 2 3 0 VAC( TP - 1 0 0 / 1 5 0 ) ;
800ms, 50ms, 24ms at full load
and 230VAC (QP-100/150)
- 1 0 ~ + 7 0 °C
- 1 0 ~ + 6 0 °C
800ms, 50ms,
16ms at full load
and 230VAC
800ms, 50ms, 36ms at
full load and 230VAC
Setup, rise, hold up time
800ms, 60ms,
36ms at full load
and 230VAC
S afety st a n d a rd s
E MC sta n d a rd s
UL 6 0 9 5 0 -1 , T UV EN6 0 9 5 0 -1 a p p r o ve d
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 -2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11
Co n n ect i o n
8P/7.62mm pitch
terminal block
9P/7.62mm pitch terminal block
with cover
9P/9.5mm pitch terminal block with
cover
3P / 9.5mm pitch terminal
block for input;
10P / 9.5mm pitch
terminal block for output
Dim en sion ( L x W x H ) ( mm)
C ase N o .
179x 99x 33
920A
199x 99x 50
916A
215x 115x 50
912B
280x 127x 63.5
927A
916B
75WŇTriple Output
Model No.
TP-75A
TP-75B
TP-75C
TP-75D
TP-7503
Output
5V, 1.5~10A
12V, 0.2~4.0A
-5V, 0.0~0.6A
5V, 1.5~10A
12V, 0.2~4.0A
-12V, 0.0~0.6A
5V, 1.5~10A
15V, 0.2~3.0A
-15V, 0.0~0.6A
5V, 1.5~10A
24V, 0.2~2.5A
12V, 0.0~0.6A
5V, 1.5~10A
3.3V, 0.2~8.0A
12V, 0.0~0.6A
Model No.
TP-100B
Tol.
±3%
±4%
±8%
±3%
±4%
±8%
±3%
±4%
±8%
±3%
±4%
±8%
±3%
±4%
±8%
R&N
100mV
120mV
100mV
100mV
120mV
120mV
100mV
120mV
120mV
100mV
120mV
120mV
100mV
50mV
120mV
Effi.
70%
Max.
74W
TP-100C
70%
76W
TP-100D
70%
75W
70%
76W
70%
75W
Output
5V, 3.0~15A
12V, 0.4~5.0A
-5V, 0.0~1.0A
Model No.
TP-150A
TP-150B
TP-150C
Tol.
±3%
±7%
±6%
R&N
100mV
120mV
100mV
912 I
Output
5V, 3.0~15A
12V, 0.4~5.0A
-12V, 0.0~1.0A
5V, 3.0~15A
15V, 0.4~4.0A
-15V, 0.0~1.0A
5V, 3.0~15A
24V, 0.4~3.0A
12V, 0.0~1.0A
Tol.
±3%
±6%
±6%
±3%
+10%,-6%
±6%
±3%
±8%
±6%
R&N
100mV
120mV
100mV
100mV
150mV
100mV
100mV
150mV
100mV
Effi.
78%
Max.
105W
77%
104W
78%
105W
Tol.
±3%
±8%
±6%
±3%
±8%
±6%
±3%
+10%,-6%
±6%
±3%
±8%
±6%
R&N
100mV
120mV
100mV
100mV
120mV
100mV
100mV
150mV
100mV
100mV
150mV
100mV
Effi.
75%
Max.
150W
77%
148W
77%
152W
78%
154W
150WŇTriple Output
100WŇTriple Output
Model No.
TP-100A
800ms, 50ms,
24ms at full load
and 230VAC
Effi.
75%
Max.
101W
TP-150D
16
Output
5V, 2.0~20A
12V, 0.4~7.0A
-5V, 0.0~1.0A
5V, 2.0~20A
12V, 0.4~7.0A
-12V, 0.0~1.0A
5V, 2.0~20A
15V, 0.4~6.0A
-15V, 0.0~1.0A
5V, 2.0~20A
24V, 0.4~4.0A
12V, 0.0~1.0A
Enclosed-PFC
100WŇQuad Output
Model No.
QP-100B
QP-100C
QP-100D
QP-100F
QP-100-3A
QP-100-3B
QP-100-3C
QP-100-3D
Output
5V, 2.0~10A
12V, 0.3~4.0A
-12V, 0.15~1.0A
-5V, 0.0~1.0A
5V, 2.0~10A
15V, 0.3~3.0A
-15V, 0.15~1.0A
-5V, 0.0~1.0A
5V, 2.0~10A
12V, 0.0~3.0A
24V, 0.3~2.0A
-12V, 0.0~1.0A
5V, 2.0~10A
15V, 0.0~3.0A
24V, 0.3~2.0A
-15V, 0.0~1.0A
5V, 2.0~10A
3.3V, 0.0~10A
12V, 0.3~3.0A
-5V, 0.0~1.0A
5V, 2.0~10A
3.3V, 0.0~10A
12V, 0.3~3.0A
-12V, 0.0~1.0A
5V, 2.0~10A
3.3V, 0.0~10A
15V, 0.3~2.0A
-15V, 0.0~1.0A
5V, 2.0~10A
3.3V, 0.0~10A
24V, 0.3~2.0A
-12V, 0.0~1.0A
200WŇQuad Output
Tol.
±3%
±6%
+10%,-6%
±5%
±3%
+6%,-10%
±8%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
+8%,-6%
±5%
±3%
±3%
±6%
±5%
R&N
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
120mV
150mV
200mV
150mV
120mV
180mV
200mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
Effi.
76%
Max.
101W
77%
101W
78%
100W
78%
103W
Tol.
±3%
±6%
+10%,-6%
±5%
±3%
+6%,-10%
±8%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
±6%
±5%
±3%
±3%
+8%,-6%
±5%
±3%
±3%
±6%
±5%
R&N
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
120mV
150mV
200mV
150mV
120mV
150mV
200mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
Model No.
QP-200D
QP-200F
QP-200-3A
QP-200-3B
QP-200-3C
74%
99W
QP-200-3D
74%
100W
QP-200-3E
75%
101W
75%
105W
QP-150C
QP-150D
QP-150F
QP-150-3A
QP-150-3B
QP-150-3C
QP-150-3D
Output
5V, 3.0~15A
12V, 0.4~5.0A
-12V, 0.3~2.0A
-5V, 0.0~1.0A
5V, 3.0~15A
15V, 0.4~4.0A
-15V, 0.3~2.0A
-5V, 0.0~1.0A
5V, 3.0~15A
12V, 0.0~5.0A
24V, 0.4~3.0A
-12V, 0.0~1.0A
5V, 3.0~15A
15V, 0.0~5.0A
24V, 0.4~3.0A
-15V, 0.0~1.0A
5V, 3.0~15A
3.3V, 0.0~15A
12V, 0.4~5.0A
-5V, 0.0~1.0A
5V, 3.0~15A
3.3V, 0.0~15A
12V, 0.4~5.0A
-12V, 0.0~1.0A
5V, 3.0~15A
3.3V, 0.0~15A
15V, 0.4~5.0A
-15V, 0.0~1.0A
5V, 3.0~15A
3.3V, 0.0~15A
24V, 0.3~3.0A
-12V, 0.0~1.0A
Effi.
76%
Max.
150W
77%
153W
78%
150W
Tol.
±3%
±3%
+10%,-6%
±6%
±3%
±3%
+10%,-6%
±6%
±3%
±3%
+8%,-10%
±6%
±3%
±3%
+8%,-10%
±6%
±3%
±3%
+10%,-6%
±6%
±3%
±3%
+10%,-6%
±6%
±3%
±3%
+10%,-6%
±6%
R&N
100mV
150mV
150mV
150mV
100mV
150mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
100mV
100mV
150mV
150mV
Effi.
75%
Max.
203W
75%
203W
72%
200W
72%
205W
72%
210W
74%
204W
74%
206W
Tol.
±3%
±3%
+10%,-6%
±10%
±3%
±3%
+10%,-6%
±10%
R&N
100mV
150mV
150mV
150mV
100mV
150mV
150mV
150mV
Effi.
83%
Max.
316W
83%
316W
R&N
100mV
150mV
150mV
50mV
100mV
120mV
120mV
50mV
100mV
150mV
150mV
240mV
100mV
120mV
120mV
240mV
100mV
120mV
120mV
240mV
240mV
50mV
120mV
120mV
240mV
50mV
150mV
150mV
Effi.
77%
Max.
378W
77%
357W
77%
378W
78%
378W
78%
378W
78%
386W
80%
410W
320WŇQuad Output
Model No.
QP-320D
150WŇQuad Output
Model No.
QP-150B
Output
5V, 3.0~20A
12V, 0.0~7.0A
24V, 0.4~6.0A
-12V, 0.0~1.0A
5V, 3.0~20A
15V, 0.0~6.0A
24V, 0.4~6.0A
-15V, 0.0~1.0A
5V, 3.0~20A
3.3V, 0.0~20A
12V, 0.5~8.0A
-5V, 0.0~1.0A
5V, 3.0~20A
3.3V, 0.0~20A
12V, 0.5~8.0A
-12V, 0.0~1.0A
5V, 3.0~20A
3.3V, 0.0~20A
15V, 0.5~7.0A
-15V, 0.0~1.0A
5V, 3.0~20A
3.3V, 0.0~20A
24V, 0.4~6.0A
-12V, 0.0~1.0A
5V, 3.0~20A
3.3V, 0.0~20A
24V, 0.4~6.0A
-15V, 0.0~1.0A
QP-320F
Output
5V, 2.5~20A
12V, 0.0~10A
24V, 0.2~5.0A
-12V, 0.2~2.0A
5V, 2.5~20A
15V, 0.0~10A
24V, 0.2~5.0A
-15V, 0.2~1.6A
375WŇQuad Output
Model No.
QP-375-5A
QP-375-5B
78%
152W
QP-375-5C
73%
146W
75%
150W
74%
152W
76%
150W
QP-375-5D
QP-375-5E
QP-375-24B
QP-375-24C
17
Output
5V, 3.5~40A
12V, 0.0~16A
±12V, 0.0~6.0A
±12V, 0.0~3.0A
5V, 3.5~40A
12V, 0.0~16A
±12V, 0.0~6.0A
±5V, 0.0~3.0A
5V, 3.5~40A
12V, 0.0~16A
±15V, 0.0~4.0A
±15V, 0.0~4.0A
5V, 3.5~40A
12V, 0.0~16A
±12V, 0.0~6.0A
±24V, 0.0~3.0A
5V, 3.5~40A
12V, 0.0~16A
±24V, 0.0~4.0A
±24V, 0.0~3.0A
24V, 1.0~10A
5V, 0.0~16A
±12V, 0.0~4.0A
±12V, 0.0~4.0A
24V, 1.0~10A
5V, 0.0~10A
±15V, 0.0~4.0A
±15V, 0.0~4.0A
Tol.
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
Enclosed-PFC
75~200W High Reliability
Features
•
•
•
•
HRP-1 0 0
HRP-1 5 0
HRPG-1 5 0
HRP-200
H RP G - 2 0 0
•
•
•
•
•
•
•
•
•
•
HRP-75
Universal AC input / Full range
Withstand 300VAC surge input for 5 seconds
Built-in active PFC function
Protections:
Short circuit / Overload / Over voltage /
Over temperature (optional for HRP-75 / HRP-100)
Built-in constant current limiting circuit
Built-in remote sense function (HRP ƒ -150 / 200)
No load power consumption<0.5W (except for HRP-150/200)
Built-in remote ON/OFF control (except for HRP-150 / 200)
Built-in 5V / 0.3A standby output (HRPG-150 / 200)
Cooling by free air convection
1U low profile
LED indicator for power on
100% full load burn-in test
5 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
HRP-7 5
AC in p u t v o l t a g e ra n g e
8 5 ~2 6 4 VAC; 1 2 0 ~3 7 0 VDC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 6 5 A a t 2 3 0 VAC
C o ld st a r t ; 7 0 A a t 2 3 0 VA C
DC adjus t me n t ra n g e
-5%~+10% rated output voltage
±15% rated output voltage
Over load
p r otection
HRP-100
ƒ-150
Model No .
Ra n g e
105%~135%
Type
Constant current limiting, auto-recovery
HRP
HRP
ƒ-200
Over vo l t a g e p ro t e c t i o n
115%~145%
W ithstan d v o l t a g e
I / P-O/ P: 3 k VA C, I / P-F G: 1 . 5 k VA C , O / P - FG : 0 . 5 kVA C , 1 m in u t e
W o r kin g t e mp e ra t u re
-4 0 ~+7 0 °C (re f e r t o o u t p u t d e ra t i n g cu r ve )
S afety st a n d a rd s
UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 -1 a p p r o ve d
E MC stand a rd s
EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EN61000-6-2 heavy industry level
Co n n ect i o n
5P/9.5mm pitch terminal block with cover
7P/9.5mm pitch terminal block with cover
Dim en sion ( L x W x H ) ( mm)
129x98x38
159x97x38
199x 98x 38
Case N o .
903D
901 I
902E
75W
Model No.
HRP-75-3.3
HRP-75-5
HRP-75-7.5
Output
Tol.
R&N
±2.5%
80mV
77.0%
5V, 0~15A
±2.5%
80mV
82.5%
7.5V, 0~10A
±2.5%
100mV
84.0%
HRP-75-12
12V, 0~6.3A
±1.5%
120mV
87.0%
15V, 0~5A
±1.5%
150mV
88.0%
HRP-75-24
24V, 0~3.2A
±1.5%
150mV
88.5%
HRP-75-36
36V, 0~2.1A
±1.5%
200mV
89.0%
HRP-75-48
48V, 0~1.6A
±1.5%
240mV
89.0%
100W
HRP-100-3.3
HRP-100-5
Model No.
Effi.
3.3V, 0~15A
Tol.
R&N
Effi.
3.3V, 0~20A
+2.5%, -3.5%
80mV
78.0%
5V, 0~17A
±2.5%
80mV
83.0%
HRP-100-7.5
7.5V, 0~13.5A
±2.5%
100mV
84.0%
HRP-100-12
12V, 0~8.5A
±1.5%
120mV
87.5%
HRP-100-15
15V, 0~7A
±1.5%
150mV
88.0%
HRP-100-24
24V, 0~4.5A
±1.5%
150mV
88.5%
HRP-100-36
36V, 0~2.9A
±1.5%
200mV
89.0%
HRP-100-48
48V, 0~2.2A
±1.5%
240mV
90.0%
HRP ƒ-150
Output
Tol.
R&N
Output
Tol.
R&N
Effi.
3.3V, 0~30A
±2.5%
80mV
78.5%
ƒ-150-3.3
5V, 0~26A
±2.5%
80mV
85.0%
HRP ƒ-150-5
7.5V,
0~20A
±2.5%
100mV
87.0%
HRP ƒ-150-7.5
12V, 0~13A
±1.5%
120mV
88.0%
HRP ƒ-150-12
15V, 0~10A
±1.5%
150mV
88.0%
HRP ƒ-150-15
24V, 0~6.5A
±1.5%
150mV
88.0%
HRP ƒ-150-24
36V, 0~4.3A
±1.5%
200mV
89.0%
HRP ƒ-150-36
48V, 0~3.3A
±1.5%
240mV
89.0%
HRP ƒ-150-48
ƒ =blank, G; blank: basic function, G: with 5Vsb & no load <0.5W
HRP
HRP ƒ-200
200W
HRP-100
Output
- 4 0 ~ + 7 0 °C
150W
HRP-75
HRP-75-15
Model No.
- 4 0 ~ + 6 0 °C
Model No.
Effi.
3.3V, 0~40A
±2%
80mV
80.0%
ƒ-200-3.3
5V, 0~35A
±2%
90mV
84.0%
ƒ-200-5
7.5V,
0~26.7A
±2%
100mV
86.0%
HRP ƒ-200-7.5
12V, 0~16.7A
±1%
120mV
88.0%
HRP ƒ-200-12
15V,
0~13.4A
±1%
150mV
88.0%
HRP ƒ-200-15
24V, 0~8.4A
±1%
150mV
88.0%
HRP ƒ-200-24
36V, 0~5.7A
±1%
250mV
89.0%
HRP ƒ-200-36
48V, 0~4.3A
±1%
250mV
89.0%
HRP ƒ-200-48
ƒ =blank, G; blank: basic function, G: with 5Vsb & no load <0.5W
HRP
HRP
18
Enclosed-PFC
300~600W High Reliability
Features
•
•
•
•
HRP-600
HRP G - 6 0 0
HRP-4 5 0
HRPG-4 5 0
•
•
•
•
•
•
HR P - 3 0 0
HRP G - 3 0 0
•
•
•
•
•
Universal AC input / Full range
Withstand 300VAC surge input for 5 seconds
Built-in active PFC function
Protections: Short circuit / Overload / Over voltage /
Over temperature
Built-in constant current limiting circuit
Built-in remote sense function
Built-in DC OK signal
No load power consumption<0.5W (HRPG-300 / 450)
No load power consumption<0.75W (HRPG-600)
Built-in remote ON/OFF control & 5V / 0.3A standby
output (HRPG series)
Built-in current sharing (HRPG-600-24 / 36 / 48)
Forced air cooling by built-in DC fan
1U low profile (HRP ƒ -300 / 450)
100% full load burn-in test
5 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
ƒ-3 0 0
Mo d el N o .
HRP
AC in p u t v o l t a g e ra n g e
8 5 ~2 6 4 VAC; 1 2 0 ~3 7 0 VDC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 7 0 A a t 2 3 0 VAC
DC adjus t me n t ra n g e
±15% rated output voltage
Over load
P r otection
HRP
Ra n g e
105%~135%
Type
Constant current limiting, auto-recovery
ƒ- 4 5 0
HRP
ƒ-600
Over vo l t a g e p ro t e c t i o n
115%~145%
W ithstan d v o l t a g e
I / P - O/ P: 3 k VA C, I / P - FG: 1 . 5 k VA C , O / P - FG : 0 . 5 kVA C , 1 m in u t e
W o r kin g t e mp e ra t u re
-4 0 ~+7 0 °C (re f e r t o o u t p u t d e rat in g cu r ve )
S afety st a n d a rd s
UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 -1 a p p r o ve d
E MC stand a rd s
EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EN61000-6-2 heavy industry level
Co n n ect i o n
7P/11mm pitch terminal block with cover
3+6P/10&11mm pitch terminal block with cover
Dim en sion ( L x W x H ) ( mm)
199x105x41
218x105x41
218x105x63.5
Case N o .
980A
995A
977A
HRP ƒ-300
300W
Model No.
Output
Tol.
R&N
Model No.
Effi.
HRP
HRP ƒ-450
Output
Tol.
R&N
Tol.
R&N
Effi.
± 2%
100mV
78.5%
HRP
HRP
Model No.
Output
3.3V, 0~120A
ƒ-600-3.3
± 2%
100mV
82.0%
5V, 0~120A
ƒ-600-5
± 2%
100mV
87.0%
7.5V, 0~80A
HRP ƒ-600-7.5
± 1%
120mV
88.0%
12V, 0~53A
HRP ƒ-600-12
± 1%
150mV
88.0%
15V, 0~43A
HRP ƒ-600-15
±
1%
150mV
88.0%
24V,
0~27A
HRP ƒ-600-24
±1%
200mV
89.0%
36V, 0~17.5A
HRP ƒ-600-36
±1%
240mV
89.0%
48V, 0~13A
HRP ƒ-600-48
ƒ =blank, G; blank: basic function, G: with 5Vsb & no load <0.75W
3.3V, 0~60A
± 2. 5%
80mV
80.0%
ƒ-300-3.3
5V, 0~60A
± 2. 0%
90mV
82.0%
ƒ-300-5
7.5V, 0~40A
± 2. 0%
100mV
86.0%
HRP ƒ-300-7.5
12V, 0~27A
± 1. 0%
120mV
88.0%
HRP ƒ-300-12
15V, 0~22A
± 1. 0%
150mV
88.0%
HRP ƒ-300-15
24V, 0~14A
± 1. 0%
150mV
87.0%
HRP ƒ-300-24
36V, 0~9A
±1.0%
250mV
88.0%
HRP ƒ-300-36
48V,
0~7A
±1.0%
250mV
89.0%
HRP ƒ-300-48
ƒ =blank, G; blank: basic function, G: with 5Vsb & no load <0.5W
HRP
450W
HRP ƒ-600
600W
We are a TQM (Total Quality Management) company
and ISO-9001 certified since 1994.
Effi.
± 2%
80mV
80.0%
3.3V, 0~90A
ƒ-450-3.3
± 2%
80mV
83.0%
5V, 0~90A
HRP ƒ-450-5
± 2%
100mV
86.5%
7.5V, 0~60A
HRP ƒ-450-7.5
± 1%
120mV
88.0%
12V, 0~37.5A
HRP ƒ-450-12
± 1%
150mV
89.0%
15V, 0~30A
HRP ƒ-450-15
± 1%
150mV
88.0%
24V, 0~18.8A
HRP ƒ-450-24
±1%
240mV
89.0%
36V, 0~12.5A
HRP ƒ-450-36
±1%
240mV
89.5%
48V, 0~9.5A
HRP ƒ-450-48
ƒ =blank, G; blank: basic function, G: with 5Vsb & no load <0.5W
HRP
Q.A.
Who can provide you better services and be a trustworthy
partner in the power industry?
— "MEAN WELL" tries to be —
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at [email protected] for information of your local
distributors.
19
Enclosed-PFC
100~450W High Reliability Medical Type
Features
•
•
•
•
•
•
MS P- 4 5 0
M S P -3 0 0
M SP-2 0 0
•
•
•
•
•
•
•
•
•
MSP-100
Universal AC input / Full range
Medical safety approved (MOOP level)
/ RZOHDNDJHFXUUHQW”ȝ$”ȝ$IRU063
Withstand 300VAC surge input for 5 seconds
Built-in active PFC function
Protections: Short circuit / Overload / Over voltage /
Over temperature
1U low profile
Built-in constant current limiting circuit
Built-in remote sense function (MSP-200/300/450)
No load power consumption<0.5W (<0.6W for MSP-450)
Built-in remote ON/OFF control
Built-in 5V/0.3A standby output (MSP-200/300/450)
Built-in DC OK signal (MSP-300/450)
LED indicator for power on
5 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
M SP-1 0 0
AC in p u t v o l t a g e ra n g e
8 5 ~2 6 4 VAC; 1 2 0 ~3 7 0 VDC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 6 5 A a t 2 3 0 VAC
DC adjus t me n t ra n g e
±15% rated output voltage
Over load
p r otectio n
MSP-200
MSP-300
MSP-450
Co l d st a r t , 7 0 A a t 2 3 0 VA C
Ra n g e
105%~135%
Type
Constant current limiting, auto-recovery
Over vo l t a g e p ro t e c t i o n
115%~145%
W ithstan d v o l t a g e
I / P-O/ P: 4 k VA C, I / P-FG: 2 k VA C, O / P - FG : 0 . 5 kVA C , 1 m in u t e
W o r kin g t e mp e ra t u re
-40~+60° C
S afety st a n d a rd s
ANSI / AAM I ES6 0 6 0 1 -1 , I EC6 0 6 0 1 - 1 a p p r o ve d
E MC stan d a rd s
EN5 5 0 11 c l a s s B, EN6 1 0 0 0 -4 -2 , 3, 4 , 5 , 6 , 8 , 11, E N 6 1 0 0 0 - 3 - 2 , 3 , E N 6 0 6 0 1 - 1 - 2
Co n n ect i o n
7P / 9.5mm pitch terminal block with cover
7P / 11mm pitch
terminal block with cover
3+6P / 10 &11mm pitch
terminal block with cover
Dim en sion ( L x W x H ) ( mm)
159x 97x 38
199x 98x 38
199x 105x 41
218x 105x 41
C ase N o .
901 I
902E
980A
995A
-40~+70° C (refer to output derating curve)
100W
MSP-100
300W
Model No.
Output
Tol.
R&N
Effi.
Model No.
MSP-100-3.3
3.3V, 0~20A
+2. 5% , - 3. 5%
80mV
78.0%
MSP-300-3.3
MSP-100-5
MSP-300
Output
3.3V, 0~60A
Tol.
R&N
Effi.
± 2.5%
80mV
80.0%
5V, 0~17A
+2. 5% , - 3. 5%
80mV
83.0%
MSP-300-5
5V, 0~60A
± 2%
90mV
82.0%
MSP-100-7.5
7.5V, 0~13.5A
± 2. 5%
100mV
84.0%
MSP-300-7.5
7.5V, 0~40A
± 2%
100mV
86.0%
MSP-100-12
12V, 0~8.5A
± 1. 5%
120mV
87.5%
MSP-300-12
12V, 0~27A
± 1%
120mV
88.0%
MSP-100-15
15V, 0~7A
± 1. 5%
150mV
88.0%
MSP-300-15
15V, 0~22A
± 1%
150mV
88.0%
MSP-100-24
24V, 0~4.5A
± 1. 5%
150mV
88.5%
MSP-300-24
24V, 0~14A
± 1%
150mV
87.0%
MSP-100-36
36V, 0~2.9A
± 1. 5%
200mV
89.0%
MSP-300-36
36V, 0~9A
±1%
250mV
88.0%
MSP-100-48
48V, 0~2.2A
± 1. 5%
240mV
90.0%
MSP-300-48
48V, 0~7A
±1%
250mV
89.0%
200W
Model No.
MSP-200-3.3
MSP-200-5
MSP-200
Output
450W
Tol.
R&N
Effi.
Model No.
3.3V, 0~40A
± 2%
80mV
80.0%
MSP-450-3.3
5V, 0~35A
± 2%
90mV
84.0%
MSP-450-5
MSP-450-7.5
NEW
Output
MSP-450
Tol.
R&N
Effi.
3.3V, 0~90A
± 2%
80mV
80.0%
5V, 0~90A
± 2%
80mV
83.0%
7.5V, 0~60A
± 2%
100mV
86.5%
120mV
88.0%
MSP-200-7.5
7.5V, 0~26.7A
± 2%
100mV
86.0%
MSP-200-12
12V, 0~16.7A
± 1%
120mV
88.0%
MSP-450-12
12V, 0~37.5A
± 1%
MSP-200-15
15V, 0~13.4A
± 1%
150mV
88.0%
MSP-450-15
15V, 0~30A
± 1%
150mV
89.0%
MSP-200-24
24V, 0~8.4A
± 1%
150mV
88.0%
MSP-450-24
24V, 0~18.8A
± 1%
150mV
88.0%
MSP-200-36
36V, 0~5.7A
±1%
250mV
89.0%
MSP-450-36
36V, 0~12.5A
±1%
240mV
89.0%
48V, 0~4.3A
±1%
250mV
89.0%
MSP-450-48
48V, 0~9.5A
±1%
240mV
89.5%
MSP-200-48
20
U-bracket-PFC
150~500W Single Output
Features
USP-500
USP-3 5 0
USP-2 2 5
USP-150
• Universal AC input / Full range
• Built-in active PFC
• Protections: Short circuit / Overload /
Over voltage / Over temperature
• Output wattage:
USP-150: 150W convection
U S P - 2 2 5 : 1 5 0 W c o n v e c t i o n , 2 2 5 W w ith 1 8 CFM
forced air
U S P - 3 5 0 : 3 0 0 W c o n v e c t i o n , 3 5 0 W w ith 2 3 .5 CFM
forced air
U S P - 5 0 0 : 4 0 0 W c o n v e c t i o n , 5 0 0 W w ith 2 3 .5 CFM
forced air
• H i g h p o w e r d e n s i t y : 5 . 5 W / i n 3 ( U S P - 1 5 0 );
4 . 7 W / i n 3 ( U S P - 2 2 5 ) ; 6 . 3 2 W / i n 3 ( U S P - 35 0 );
6.2W/in3 (USP-500)
• U - b r a c k e t l o w p r o f i l e : 3 3 m m ( U S P - 1 5 0);
3 8 m m ( U S P - 2 2 5 / 3 0 0 ) ; 4 1 m m ( U S P - 5 0 0)
• Built-in remote ON/OFF control, remote sense,
D C OK s i g n a l ( U S P - 5 0 0 )
• Optional current sharing(1+1) for USP-500-24/48
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No.
USP-150
USP-225
USP-350
USP-500
AC input voltage range
9 0 ~2 9 5 VAC; 1 2 7 ~4 1 7 VDC
9 0 ~ 2 6 4 VA C ; 1 2 7 ~ 3 7 0 V D C
1 5 A a t 11 5 VA C ,
3 0 A a t 2 3 0 VA C
2 2 A a t 11 5 VA C ,
4 4 A a t 2 3 0 VA C
3 0 A a t 11 5 VA C ,
5 0 A a t 2 3 0 VA C
±10% rated output voltage
110%~160%
105%~150%
105%~130%
Hiccup mode, auto-recovery
Constant current limiting, auto-recovery
Constant current,
shut off after 3 sec.
110%~135%
110%~135%
110%~140%
115%~135%
Hiccup mode,
auto-recovery
S h u t o ff ,
A C r e cycle t o r e - s t a r t
AC inrush current (max.) Co l d s t a rt , 6 5 A a t 2 3 0 VAC
DC adjustment range
Ra n g e
Overload
protection
Type
Over voltage
protection
Ra n g e
Type
Sh u t o ff , AC re c y c l e t o re -s t a rt
Withstand voltage
Working temperature
Vibration
Safety standards
EMC standards
I / P - O/ P: 3 k VAC, I / P - F G: 1 . 5 k VAC , O / P - FG : 0 . 5 kV A C , 1 m in u t e
-3 0 ~+6 5 °C
- 2 0 ~ + 6 5 °C
- 1 0 ~ + 6 5 °C
10~500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 -1 (e x c e p t f o r U S P - 1 5 0 ) a p p r o ve d
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 -2 , 3 , EN 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11
Connection
J ST: SVH-2 1 T-P1 . 1 ,
4P/7.62mm pitch terminal block
Dimension (LxWxH)(mm) 215x 67.4x 33
20P/2.54mm pitch,
Molex 39-29-9206
5+9Px2/3.96mm pitch,
JS T: B 5 P / B 9 P x2 - V H
3+8P/8.5mm pitch
terminal block with cover
202x 101.5x 38
235.2x 101.5x 38
254x 127x 41
USP-150 Series
Model No.
USP-150-12
USP-150-15
USP-150-24
USP-150-36
USP-150-48
USP-350 Series
Output
12V, 0~12.5A
15V, 0~10.0A
24V, 0~6.30A
36V, 0~4.20A
48V, 0~3.20A
Tol.
±2%
±2%
±2%
±2%
±2%
R&N
100mV
150mV
150mV
250mV
250mV
Effi.
91.5%
91.5%
93.0%
93.0%
93.0%
Output
3.3V, 0~40.0A
5V, 0~40.0A
12V, 0~18.7A
15V, 0~15.0A
24V, 0~9.40A
48V, 0~4.70A
Tol.
±2%
±2%
±2%
±2%
±2%
±2%
R&N
100mV
100mV
100mV
100mV
150mV
250mV
Effi.
72%
77%
83%
84%
85%
86%
Model No.
USP-350-3.3
USP-350-5
USP-350-12
USP-350-15
USP-350-24
USP-350-48
USP-225 Series
Model No.
USP-225-3.3
USP-225-5
USP-225-12
USP-225-15
USP-225-24
USP-225-48
- 2 0 ~ + 7 0 °C
Output
3.3V, 0~70.0A
5V, 0~70.0A
12V, 0~29.2A
15V, 0~23.4A
24V, 0~14.6A
48V, 0~7.30A
Tol.
±2%
±2%
±2%
±2%
±2%
±2%
R&N
80mV
80mV
100mV
100mV
150mV
150mV
Effi.
78%
84%
88%
88%
88%
89%
Tol.
R&N
Effi.
USP-500 Series
Model No.
USP-500-5
21
Output
5V, 0~80.0A
±2%
80mV
85%
USP-500-12
12V, 0~42.0A
±2%
100mV
90%
USP-500-15
15V, 0~33.5A
±2%
100mV
90%
USP-500-24
24V, 0~21.0A
±2%
150mV
89%
USP-500-48
48V, 0~10.5A
±2%
150mV
90%
Modular Series
450W/650W/1000W Configurable Power
MP450 (450W, 5 SLOT)
MS-75
MP650 (650W, 5 SLOT)
MS-150
MS-210
MS-300
MP1K0 (1000W, 7 SLOT)
MS-360
MD-100
Description
Modular series are switching power supplies with modular design that consist of two stages: front-end PFC and output modules.
Using ZVS (Zero Voltage Switching) technology to realize the power factor correction, the line input is rectified into high DC voltage
(around 390VDC) by the front-end PFC stage, and then the DC output modules will transfer the operating voltage into all kinds o f
DC output voltages from 1.6V~53V. Right now we offer 75W, 150W, 210W, 300W, 360W single output modules and 100W dual output
modules to fulfill all kinds of applications up to 14 isolated outputs.
There are millions of combinations available for the Modular series. Users can configure the DC outputs they need and get the
fastest solution for their own power requirement with safety and EMC certificates. No more NRE / safety application charges and
long period of waiting for certificates! Providing standard products as usual, MEAN WELL offer you a revolutionary standard pow er
solution that fulfills your custom-made request!
Output Configuration Guide
MP
Features
-
-
SLOT 1 SLOT 2 SLOT 3 SLOT 4 SLOT 5 SLOT 6 SLOT 7
Par allel or
opti on code
For MP1K0 only
M ax. output wattage (450 / 650 / 1K0)
M odul ar Power wi th PFC
Example:
MP650-A 2 E H U
SLOT5-O/P:[email protected] 2.5A, 5V @8A
SLOT4-O/P:[email protected] 6.5A
SLOT2, 3-O/P:[email protected] 25A
•
•
•
•
•
•
•
•
•
•
•
•
•
Millions of output configuration is available
ZVS technology to reduce power dissipation and improve efficiency
Universal AC input / Full range
Built-in active PFC compliance to EN61000-3-2
Built-in constant current limiting circuit for single output modules
Remote control on each output module
Remote sense on each output module (MS-75 / 150 / 210 / 300 / 360)
Short circuit / Overload / Over voltage protections for all modules
Parallel function for MS-210 (up to 5 units), MS-300/360 (up to 3 units)
Margining control function (MS-210 / 360)
Cooling by built-in DC fan with fan alarm function
Additional 12V/0.1A auxiliary output for remote control
3 years warranty
SLOT-O/P:[email protected] 25A
General Specification (Please refer to www.meanwell.com for detail spec.)
Model N o .
AC in p u t v o l t a g e ra n g e
P o wer F a c t o r
AC in r us h c u rre n t ( ma x . )
Max outp u t v o l t a g e
E fficien c y ( t y p i c a l )
Over tem p e ra t u re p ro t e c t i on
F an alar m
W ithstan d v o l t a g e
W o r kin g t e mp e ra t u re
S afety st a n d a rd s
E MC stand a rd s
C o n n ect i o n
D im en sio n ( L x W x H ) ( mm)
MP450
MP650
MP1K0
85~264VAC or 120~370VDC
PF >0 . 9 5 / 2 3 0 VAC, PF > 0 . 9 8 / 11 5 VA C a t f u ll lo a d
Co l d s t a rt , 4 0 A a t 2 3 0 VAC
C o ld st a r t , 5 0 A a t 2 3 0 VA C
C o ld st a r t , 4 0 A a t 2 30 VA C
450W
650W
1000W
83%
84%
84%
Output shutdown, auto-recovery
Output shutdown when fan malfunction
I / P-O/ P: 3 k VA C, I / P-F G: 1 . 5 k VA C , O / P - FG : 0 . 5 kVA C , 1 m in u t e
-2 0 ~+5 0 O [email protected] 1 0 0 % , +7 0 O C @ 5 0 % lo a d
UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 -1 a p p r o ve d (MS-210/360 pending)
Compliance to EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN55024 light industry level, criteria A
Input side: 3P/10mm pitch terminal block & JST B3B-XH
254x 127x 63.5
278x 127x 63.5
278x 177.8x 63.5
22
Modular Series
MS-75: 1-SLOT single output (75W max.)
MS-360: 2-SLOT parallelable single output (360W max.)
Item Code
Output
Peak I
Vdc adj.
Tol.
R&N.
Item Code
Output
Peak I
Vdc adj.
Tol.
R&N.
L
3.3V, 0~15A
17.3A
2.6~4.0V
±2%
80mV
2a
2V, 0~60A
69.0A
1.6~2.6V
±3%
80mV
M
5V, 0~15A
17.3A
4.0~6.0V
±2%
80mV
2b
3.3V, 0~60A
69.0A
2.6~4.0V
±2%
80mV
5V, 0~60A
69.0A
4.0~6.0V
±2%
80mV
N
12V, 0~6.3A
7.30A
9.0~13.2V
±1%
150mV
2c
O
15V, 0~5.0A
5.80A
13.2~16.8V
±1%
150mV
2d
7.5V, 0~48A
55.2A
6.0~9.0V
±2%
100mV
12V, 0~30A
34.5A
9.0~13.2V
±1%
150mV
P
24V, 0~3.2A
3.70A
20.0~26.4V
±1%
150mV
2e
Q
48V, 0~1.6A
1.80A
40.0~53.0V
±1%
250mV
2f
15V, 0~24A
27.6A
13.2~16.8V
±1%
150mV
2g
18V, 0~20A
23.0A
16.8~20.0V
±1%
150mV
2h
24V, 0~15A
17.3A
20.0~26.4V
±1%
150mV
MS-150: 1-SLOT single output (150W max.)
Item Code
Output
Peak I
Vdc adj.
Tol.
R&N.
2i
27V, 0~13.4A
15.5A
25.0~31.0V
±1%
200mV
33V, 0~11A
12.7A
30.0~40.0V
±1%
250mV
48V, 0~7.5A
8.7A
40.0~53.0V
±1%
300mV
A
2V, 0~25A
30.0A
1.6~2.6V
±3%
50mV
2j
B
3.3V, 0~25A
30.0A
2.6~4.0V
±2%
80mV
2k
C
5V, 0~25A
30.0A
4.0~6.0V
±2%
80mV
D
7.5V, 0~18A
20.7A
6.0~9.0V
±2%
100mV
E
12V, 0~13A
15.0A
9.0~13.2V
±1%
150mV
F
15V, 0~10A
11.5A
13.2~16.8V
±1%
150mV
G
18V, 0~8.5A
9.80A
16.8~20.0V
±1%
150mV
H
24V, 0~6.5A
7.50A
20.0~26.4V
±1%
150mV
I
27V, 0~5.8A
6.70A
25.0~31.0V
±1%
150mV
J
33V, 0~4.7A
5.40A
30.0~40.0V
±1%
250mV
K
48V, 0~3.2A
3.68A
40.0~53.0V
±1%
250mV
MD-100: 1-SLOT isolated dual output (100W max.)
Item Code
R
S
T
U
V
MS-210: 1-SLOT parallelable single output (210W max.)
W
Output
Peak I
Vdc adj.
Tol.
R&N.
a
2V, 0~35A
42.0A
1.6~2.6V
±3%
50mV
b
3.3V, 0~35A
42.0A
2.6~4.0V
±2%
80mV
c
5V, 0~35A
42.0A
4.0~6.0V
±2%
80mV
d
7.5V, 0~28A
Item Code
X
Output
5V, 2.0~10A
5V, 0.0~8.0A
5V, 2.0~10A
12V, 0.0~5.8A
5V, 2.0~10A
15V, 0.0~4.7A
24V, 0.5~3.0A
5V, 0.0~10A
24V, 0.6~3.0A
12V, 0.0~4.7A
12V, 1.0~5.0A
12V, 0.0~5.8A
15V, 1.0~4.7A
15V, 0.0~4.7A
Vdc adj.
Tol.
R&N.
Max.
4.75~5.5V
4.75~5.5V
4.75~5.5V
11.4~13.2V
4.75~5.5V
14.2~16.5V
22.8~26.4V
4.75~5.5V
22.8~26.4V
11.4~13.2V
11.4~13.2V
11.4~13.2V
14.2~16.5V
14.2~16.5V
±3%
±3%
±3%
±3%
±3%
±3%
±3%
±3%
±2%
±3%
±2%
±3%
±2%
±3%
100mV
100mV
100mV
150mV
100mV
150mV
200mV
100mV
240mV
120mV
120mV
120mV
150mV
150mV
90.0W
100.4W
101.0W
100.0W
100.8W
100.8W
100.5W
Parallel Connection Accessory
32.2A
6.0~9.0V
±2%
100mV
FAP-001
e
12V, 0~17.5A
20.1A
9.0~13.2V
±1%
150mV
(For MS-300)
f
15V, 0~14A
16.1A
13.2~16.8V
±1%
150mV
g
18V, 0~11.6A
13.4A
16.8~20.0V
±1%
150mV
h
24V, 0~8.75A
10.1A
20.0~26.4V
±1%
150mV
i
27V, 0~7.8A
9.00A
25.0~31.0V
±1%
150mV
j
33V, 0~6.4A
7.40A
30.0~40.0V
±1%
250mV
k
48V, 0~4.4A
5.10A
40.0~53.0V
±1%
250mV
FAP-002
(For MS-210)
FAP-003
(For MS-360)
Series Connection Accessory
FAS-001
(For 1-slot modules:
MS-75/150, MD-100)
MS-300: 2-SLOT parallelable single output (300W max.)
FAS-002
Output
Peak I
Vdc adj.
Tol.
R&N.
2A
2V, 0~50A
57.5A
1.6~2.6V
±3%
80mV
2B
3.3V, 0~50A
57.5A
2.6~4.0V
±2%
80mV
FAS-003
2C
5V, 0~50A
57.5A
4.0~6.0V
±2%
80mV
2D
7.5V, 0~40A
46.0A
6.0~9.0V
±2%
100mV
(For 1-slot modules:
MS-210)
2E
12V, 0~25A
29.0A
9.0~13.2V
±1%
150mV
2F
15V, 0~20A
23.0A
13.2~16.8V
±1%
150mV
2G
18V, 0~16.7A
19.2A
16.8~20.0V
±1%
150mV
Peak I: 35% duty cycle maximum within every 10 seconds. Average output
power should not exceed the rated power.
2H
24V, 0~12.5A
14.4A
20.0~26.4V
±1%
150mV
2I
27V, 0~11.2A
12.9A
25.0~31.0V
±1%
200mV
2J
33V, 0~9.1A
10.5A
30.0~40.0V
±1%
250mV
2K
48V, 0~6.3A
7.2A
40.0~53.0V
±1%
300mV
Please use MP450-CNPOQ, MP650-A2EHU, MP1K0-2C2CEKL-1.....etc. as
the order code. For more detail information about technical issues, please
refer to the user manual.
Please refer to the user manual for more detail information about parallel
connection and the parallel codes. About series connection, please contact
us or your local MEAN WELL distributor for more details.
Item Code
(For 2-slot modules:
MS-300)
FAS-004
(For 2-slot modules:
MS-360)
23
Harsh Environment
INPUT
40~60W Single Output
•
•
•
•
•
•
•
•
•
•
•
OU T P U T
Standard
Optional
(Contact MW
for details)
A
B
Features
IP67 / IP65 design for indoor or outdoor installations
Universal AC input 90~305VAC
Built-in active PFC function
High efficiency up to 90.5%
Fanless design, cooling by free air convection
-40~+70 ° C wide operating range
Withstand 5G vibration test
Meet 4kV surge immunity level (IEC61000-4-5)
Built-in constant current limiting circuit
Aluminum case and filling with heat-conducted glue
Protections: Short circuit / Over current /
Over voltage / Over temperature
• Multiple models for choice:
A-Type: IP65 rated. Vo and Io can be adjusted through
internal potentiometer
B-Type: IP67 rated and built-in 3 in 1 dimming function
(1~10VDC, PWM signal, or resistance)
Blank-Type: IP67 rated. Cable for I/O connection
• Suitable for general industrial applications at high/low
temperature, high dust, high moisture, high vibration, or
outdoor environment
• 5 years warranty
Blank
General Specification (Please refer to www.meanwell.com for detail spec.)
Mo d el N o .
H L G-4 0 H
H LG - 6 0 H
AC input voltage range
9 0 ~3 0 5 VAC; 1 2 7 ~4 3 1 VDC
AC inrush current (max.)
Co l d s t a rt , 5 0 A a t 2 3 0 VAC
DC adjustment range
±10% rated output voltage (A-Type only)
Current adjustment range
60%~100% rated output current adjustable by internal potentiometer (A-Type only)
Over current protection
95%~108% constant current limiting, auto-recovery
Over voltage protection
109%~145% rated output voltage, shut off, re-power on to recover
Setup, rise, hold up time
1000ms, 80ms, 16ms at full load and 230VAC
Withstand voltage
I / P-O/ P: 3 . 7 5 k VA C, I / P-FG: 2 k VA C , O / P - FG : 0 . 5 kVA C
Working temperature
-4 0 ~+7 0 °C (re f e r t o o u t p u t d e ra t in g cu r ve )
Safety standards
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved; Design refer to UL60950-1, EN60950-1
EMC standards
EN5 5 0 1 5 , EN6 1 0 0 0 -3 -2 c l a s s C, E N 6 1 0 0 0 - 3 - 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, E N 6 1 5 4 7
Connection
C o ld st a r t , 5 5 A a t 2 3 0 VA C
Input
UL ra t e d , SJ TW 1 8 AWGx 3 C (3 0 cm )
Output
A/ Bl a n k -Ty p e : SVT 1 8 AWGx 2 C (3 0 cm ) ; B - Typ e : S V T 1 8 AW G x2 C ( 3 0 cm ) + U L 2 5 1 7 1 8 AW G x2 C ( 3 0 cm )
Dimension (LxWxH)(mm)
171x 61.5x 36.8
HLG-40H Series
Model No.
HLG-60H-30 A
HLG-60H-36 A
HLG-60H-42 A
HLG-60H-48 A
HLG-60H-54 A
= A, B or Blank
(for 48V/54V) (for 12~42V)
Model No.
HLG-40H-12 A
Output
12V, 0~3.33A
Tol.
±2.5%
R&N
150mV
Effi.
86.5%
HLG-40H-15 A
15V, 0~2.67A
±2.0%
150mV
86.5%
HLG-40H-20 A
20V, 0~2.00A
±1.0%
150mV
88.0%
HLG-40H-24 A
24V, 0~1.67A
±1.0%
200mV
88.0%
HLG-40H-30 A
30V, 0~1.34A
±1.0%
200mV
88.5%
HLG-40H-36 A
36V, 0~1.12A
±1.0%
200mV
88.5%
HLG-40H-42 A
42V, 0~0.96A
±1.0%
200mV
88.5%
HLG-40H-48 A
48V, 0~0.84A
±1.0%
300mV
89.5%
HLG-40H-54 A
54V, 0~0.75A
±1.0%
300mV
89.5%
źźJuction
Output
30V, 0~2.00A
36V, 0~1.70A
42V, 0~1.45A
48V, 0~1.30A
54V, 0~1.15A
Tol.
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
R&N
200mV
200mV
300mV
300mV
300mV
Effi.
90.0%
90.0%
90.0%
90.5%
90.5%
Box for HLG Series
= A, B or Blank
HLG-60H Series
Model No.
HLG-60H-15 A
HLG-60H-20 A
HLG-60H-24 A
Output
15V, 0~4.00A
20V, 0~3.00A
24V, 0~2.50A
(for 48V/54V) (for 15~42V)
Tol.
±2.0%
±1.0%
±1.0%
R&N
150mV
150mV
150mV
• Optional junction box available for HLG-80H~320H series
( A / B / B la n k- Typ e o n ly) . P le a se co n t a ct M E A N W E L L f o r d e t a i l s .
• " U L 8 7 5 0 list e d " sa f e t y & I P 6 6 a p p r o ve d f o r H L G - 8 0 H - B L
(modified from B-Type only)
Effi.
87.5%
89.0%
89.5%
24
Harsh Environment
INPUT
OU T P U T
80~120W Single Output
•
•
•
•
•
•
•
•
•
•
•
•
Standard
Optional
(Contact MW
for details)
A
B
•
Blank
•
•
Features
IP67 / IP65 design for indoor or outdoor installations
Universal AC input 90~305VAC
Built-in active PFC function
High efficiency up to 93.5%
Fanless design, cooling by free air convection
-40~+70°C wide operating range
Withstand 5G vibration test
Meet 4kV surge immunity level (IEC61000-4-5)
Built-in constant current limiting circuit
Aluminum case and filling with heat-conducted glue
Protections: Short circuit / Over current /
Over voltage / Over temperature
Multiple models for choice:
A-Type: IP65 rated. Vo and Io can be adjusted through
internal potentiometer
B-Type: IP67 rated and built-in 3 in 1 dimming function
(1~10VDC, PWM signal, or resistance)
Blank-Type: IP67 rated. Cable for I/O connection
Optional CQC models available
(HLG-100H/120H-A/Blank type)
Suitable for general industrial applications at high/low
temperature, high dust, high moisture, high vibration, or
outdoor environment
5 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Mo d el N o .
H L G-8 0 H
AC input voltage range
AC inrush current (max.)
DC adjustment range
Current adjustment range
Over current protection
Over voltage protection
Setup, rise, hold up time
Withstand voltage
Working temperature
9 0 ~3 0 5 VAC; 1 2 7 ~4 3 1 VDC
Co l d s t a rt , 7 0 A a t 2 3 0 VAC
C o ld st a r t , 6 0 A a t 2 3 0 VA C
±10% rated output voltage (A-Type only)
60%~100% rated output current adjustable by internal potentiometer (A-Type only)
95%~108% constant current limiting, auto-recovery
110%~140% rated output voltage
1000ms, 80ms, 16ms at full load and 230VAC
2500ms, 50ms, 16ms
2500ms, 50ms, 12ms
I / P-O/ P: 3 . 7 5 k VA C, I / P-F G: 2 k VA C , O / P - FG : 0 . 5 kVA C
-4 0 ~+7 0 °C (re f e r t o o u t p u t d e ra tin g cu r ve )
UL 8 7 5 0 , T UV EN6 1 3 4 7 -1 , EN6 1 34 7 - 2 - 1 3 , P S E J6 1 3 4 7 - 1 , J6 1 3 4 7 - 2 - 1 3 a p p r o ve d ;
UL8750 listed for HLG-80H- BL o n ly ; D e sig n r e f e r t o U L 6 0 9 5 0 - 1 , E N 6 0 9 5 0 - 1
EN5 5 0 1 5 , EN5 5 0 2 2 c l a s s B (e x c e p t f o r H L G - 8 0 H ) , E N 6 1 0 0 0 - 3 - 2 cla ss C , E N 6 1 0 0 0 - 3 - 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11 ,
EN6 1 5 4 7
UL ra t e d , SJ T W 1 8 AWGx 3 C (3 0 cm )
A/Blank-Type: SVT 18AWGx2C (30cm);
A / B la n k- Typ e : S JTW 1 4 AW G x2 C ( 3 0 cm ) ;
B-Type: SVT 18AWGx2C (30cm)+UL2517 18AWGx2C (30cm) B - Typ e : S JTW 1 4 AW G x2 C ( 3 0 cm ) + S JTW 1 8 AWG x 2 C ( 3 0 c m)
195.6x 61.5x 38.8
220x 68x 38.8
Safety standards
EMC standards
Input
Connection
Output
Dimension (LxWxH)(mm)
H LG - 1 0 0 H
HLG-80H Series
(for 48V/54V)
Model No.
Output
HLG-80H-12 A
12V, 0~5.0A
HLG-80H-15 A
15V, 0~5.0A
HLG-80H-20 A
20V, 0~4.0A
HLG-80H-24 A
24V, 0~3.4A
HLG-80H-30 A
30V, 0~2.7A
HLG-80H-36 A
36V, 0~2.3A
HLG-80H-42 A
42V, 0~1.95A
HLG-80H-48 A
48V, 0~1.7A
HLG-80H-54 A
54V, 0~1.5A
= A , B, BL or Blank
(for 12~42V)
Tol.
±2.5%
±2.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
(for 48/54BL)
R&N
150mV
150mV
150mV
150mV
200mV
200mV
200mV
200mV
200mV
Model No.
HLG-100H-42 A
HLG-100H-48 A
HLG-100H-54 A
= A , B or Blank
(for 12~42BL)
Effi.
88.0%
89.0%
90.0%
90.5%
91.0%
91.0%
91.0%
91.0%
91.0%
Output
20V, 0~4.8A
24V, 0~4.0A
30V, 0~3.2A
36V, 0~2.65A
Tol.
±1.0%
±1.0%
±1.0%
±1.0%
R&N
150mV
150mV
200mV
200mV
Output
42V, 0~2.28A
48V, 0~2.0A
54V, 0~1.77A
Tol.
±1.0%
±1.0%
±1.0%
R&N
200mV
200mV
200mV
Effi.
93%
93%
93%
Model No.
HLG-120H-12 A
Output
12V, 0~10A
Tol.
±2.5%
R&N
150mV
Effi.
92.0%
HLG-120H-15 A
15V, 0~8.0A
±2.0%
150mV
92.0%
HLG-120H-20 A
20V, 0~6.0A
±1.0%
150mV
93.0%
HLG-120H-24 A
24V, 0~5.0A
±1.0%
150mV
93.0%
HLG-120H-30 A
30V, 0~4.0A
±1.0%
200mV
93.0%
HLG-120H-36 A
36V, 0~3.4A
±1.0%
200mV
93.0%
HLG-120H-42 A
42V, 0~2.9A
±1.0%
200mV
93.0%
HLG-120H-48 A
48V, 0~2.5A
±1.0%
200mV
93.5%
HLG-120H-54 A
54V, 0~2.3A
±1.0%
200mV
93.5%
HLG-120H Series
HLG-100H Series
Model No.
HLG-100H-20 A
HLG-100H-24 A
HLG-100H-30 A
HLG-100H-36 A
H LG - 1 2 0 H
Effi.
93%
93%
93%
93%
= A , B or Blank
HLG-120H-12A/24A/48A are our popular models. We will keep sufficient
stock for prompt delivery of high quantity orders.
25
Harsh Environment
150~240W Single Output
•
•
•
•
•
•
•
•
•
•
•
A
B
General Specification
Features
IP67 / IP65 design for indoor or outdoor installations
Universal AC input 90~305VAC
Built-in active PFC function
High efficiency up to 94%
Fanless design, cooling by free air convection
-40~+70 OC wide operating range
Withstand 5G vibration test
Meet 4kV surge immunity level (IEC61000-4-5)
Built-in constant current limiting circuit
Aluminum case and filling with heat-conducted glue
INPUT
OU T P U T
Protections: Short circuit / Over current /
Over voltage / Over temperature
Standard
• Multiple models for choice:
A-Type: IP65 rated. Vo and Io can be adjusted through
Optional
internal potentiometer
(Contact MW
B-Type: IP67 rated and built-in 3 in 1 dimming function
for details)
(1~10VDC, PWM signal, or resistance)
C-Type: Terminal block for I/O connection (HLG-240H)
C
Blank
Blank-Type: IP67 rated. Cable for I/O connection
• Suitable for general industrial applications at high/low
temperature, high dust, high moisture, high vibration, or
(HLG-240H only)
outdoor environment
• 5 years warranty
(Please refer to www.meanwell.com for detail spec.)
Model No .
AC input voltage range
AC inrush current (max.)
DC adjustment range
Current adjustment range
Over current protection
Over voltage protection
Setup, rise, hold up time
Withstand voltage
Working temperature
H LG-1 5 0 H
H LG - 1 8 5 H
H LG - 2 4 0 H
9 0 ~3 0 5 VAC; 1 2 7 ~4 3 1 VDC
Co l d s t a rt , 6 5 A a t 2 3 0 VAC
C o ld st a r t , 7 5 A a t 2 3 0 VA C
±10% rated output voltage (A-Type only)
±6% rated output voltage (A-Type only)
60%~100% rated output current adjustable by internal potentiometer (A-Type only)
95%~108% constant current limiting, auto-recovery
110%~140% rated output voltage
2500ms, 80ms, 16ms at full load and 230VAC
2500ms, 80ms, 15ms at full load and 230VAC
I / P-O/ P: 3 . 7 5 k VA C, I / P-FG: 2 k VA C , O / P - FG : 0 . 5 kVA C
-4 0 ~+7 0 °C (re f e r t o o u t p u t d e ra t in g cu r ve )
Safety standards
UL 8 7 5 0 , TUV EN6 1 3 4 7 -1 , EN6 1 34 7 - 2 - 1 3 , P S E J6 1 3 4 7 - 1 , J6 1 3 4 7 - 2 - 1 3 ( e xce p t f o r C - Typ e ) a p p r o ve d ;
UL 1 0 1 2 , UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 - 1 a p p r o ve d f o r H L G - 2 4 0 H o n ly
EMC standards
Input
Connection
Output
EN5 5 0 1 5 , EN5 5 0 2 2 c l a s s B, EN61 0 0 0 - 3 - 2 cla ss C , E N 6 1 0 0 0 - 3 - 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, E N 6 1 5 4 7
UL ra t e d , SJ TW 1 8 AWGx 3 C (3 0 cm ) ; Ter m in a l b lo ck f o r C - Typ e ( H L G - 2 4 0 H o n ly)
Dimension (LxWxH)(mm)
A/B/Blank-Type: 228x68x38.8
A & Bl a n k -Ty p e : SJ T W 1 4 AWGx 2C ( 3 0 cm ) ; B - Typ e : S JTW 1 4 AW G x2 C ( 3 0 cm ) + S JTW 1 8 AW G x2 C ( 3 0 cm) ;
C-Type: Terminal block (HLG-240H only)
A/B/Blank-Type: 244.2x68x38.8
C-Type: 251x68x38.8
HLG-150H Series
Model No.
HLG-150H-12 A
HLG-150H-15 A
HLG-150H-20 A
HLG-150H-24 A
HLG-150H-30 A
HLG-150H-36 A
HLG-150H-42 A
HLG-150H-48 A
HLG-150H-54 A
= A, B or Blank
Output
12V, 0~12.5A
15V, 0~10.0A
20V, 0~7.50A
24V, 0~6.30A
30V, 0~5.00A
36V, 0~4.20A
42V, 0~3.60A
48V, 0~3.20A
54V, 0~2.80A
Tol.
±2.5%
±2.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
R&N
150mV
150mV
150mV
150mV
200mV
200mV
200mV
200mV
200mV
Effi.
91.5%
92.0%
93.0%
93.0%
93.5%
93.5%
94.0%
94.0%
94.0%
Tol.
±2.5%
±2.0%
±1.0%
±1.0%
±1.0%
±1.0%
R&N
150mV
150mV
150mV
150mV
200mV
200mV
Effi.
91.5%
92.0%
93.0%
93.5%
93.5%
93.5%
Model No.
HLG-185H-42 A
HLG-185H-48 A
HLG-185H-54 A
= A, B or Blank
Output
12V, 0~13.0A
15V, 0~11.5A
20V, 0~9.30A
24V, 0~7.80A
30V, 0~6.20A
36V, 0~5.20A
Tol.
±1.0%
±1.0%
±1.0%
R&N
200mV
200mV
200mV
Effi.
94.0%
94.0%
94.0%
Tol.
±2.5%
±2.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
R&N
150mV
150mV
150mV
150mV
200mV
250mV
250mV
250mV
350mV
Effi.
90.0%
90.0%
92.0%
93.0%
93.0%
93.0%
93.0%
93.5%
94.0%
HLG-240H Series
Model No.
HLG-240H-12 A
HLG-240H-15 A
HLG-240H-20 A
HLG-240H-24 A
HLG-240H-30 A
HLG-240H-36 A
HLG-240H-42 A
HLG-240H-48 A
HLG-240H-54 A
HLG-185H Series
Model No.
HLG-185H-12 A
HLG-185H-15 A
HLG-185H-20 A
HLG-185H-24 A
HLG-185H-30 A
HLG-185H-36 A
Output
42V, 0~4.40A
48V, 0~3.90A
54V, 0~3.45A
Output
12V, 0~16.0A
15V, 0~15.0A
20V, 0~12.0A
24V, 0~10.0A
30V, 0~8.00A
36V, 0~6.70A
42V, 0~5.72A
48V, 0~5.00A
54V, 0~4.45A
= A, B, C or Blank
HLG-185H-12A/24A/48A & HLG-240H-12A/24A/48A are our popular
models. We will keep sufficient stock for prompt delivery of high
quantity orders.
26
Harsh Environment
INPUT
320W Single Output
OU T P U T
Standard
OUTPUT
Optional
(Contact MW
for details)
A
B
C
Blank
•
•
•
•
•
•
•
•
•
•
•
Features
IP67 / IP65 design for indoor or outdoor installations
Universal AC input 90~305VAC
Built-in active PFC function
High efficiency up to 95%
Fanless design, cooling by free air convection
-40~+70 OC wide operating range
Withstand 5G vibration test
Meet 4kV surge immunity level (IEC61000-4-5)
Built-in constant current limiting circuit
Aluminum case and filling with heat-conducted glue
Protections: Short circuit / Over current /
Over voltage / Over temperature
• Multiple models for choice:
A-Type: IP65 rated. Vo and Io can be adjusted through
internal potentiometer
B-Type: IP67 rated and built-in 3 in 1 dimming function
(1~10VDC, PWM signal, or resistance)
C-Type: Terminal block for I/O connection
Blank-Type: IP67 rated. Cable for I/O connection
• Suitable for general industrial applications at high/low
temperature, high dust, high moisture, high vibration, or
outdoor environment
• 5 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
H L G-3 2 0 H
AC input voltage range
AC inrush current (max.)
DC adjustment range
Current adjustment range
Over current protection
Over voltage protection
Setup, rise, hold up time
Withstand voltage
Working temperature
Safety standards
EMC standards
Input
Connection
Output
9 0 ~3 0 5 VAC; 1 2 7 ~4 3 1 VDC
Co l d s t a rt , 7 0 A a t 2 3 0 VAC
±6% rated output voltage (A-Type only)
60%~100% rated output current adjustable by internal potentiometer (A-Type only)
95%~108% constant current limiting, auto-recovery
110%~140% rated output voltage
2500ms, 80ms, 15ms at full load and 230VAC
I / P-O/ P: 3 . 7 5 k VA C, I / P-FG: 2 k VA C , O / P - FG : 0 . 5 kVA C
-4 0 ~+7 0 °C (re f e r t o o u t p u t d e ra t in g cu r ve )
UL 8 7 5 0 , T UV EN6 1 3 4 7 -1 , EN6 1 34 7 - 2 - 1 3 , P S E J6 1 3 4 7 - 1 , J6 1 3 4 7 - 2 - 1 3 ( e xce p t f o r C - Typ e ) a p p r o ve d
EN5 5 0 1 5 , EN5 5 0 2 2 c l a s s B, EN61 0 0 0 - 3 - 2 cla ss C , E N 6 1 0 0 0 - 3 - 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, E N 6 1 5 4 7
UL ra t e d , SJ TW 1 8 AWGx 3 C (3 0 cm )
Dimension (LxWxH)(mm)
252x90x43.8
Model No.
HLG-320H-12 A
HLG-320H-15 A
HLG-320H-20 A
HLG-320H-24 A
HLG-320H-30 A
ź
źFeature
12V,
15V,
20V,
24V,
30V,
A & Bl a n k -Ty p e : SJ T W 1 4 AWGx 2C ( 3 0 cm ) ; B - Typ e : S JTW 1 4 AW G x2 C ( 3 0 cm ) + S JTW 1 8 AW G x2 C ( 3 0 cm ) ;
C-Type: Terminal block
Output
0~22.0A
0~19.0A
0~15.0A
0~13.34A
0~10.7A
Tol.
±3.0%
±2.0%
±1.5%
±1.0%
±1.0%
R&N
150mV
150mV
150mV
150mV
200mV
Effi.
91.0%
92.5%
93.5%
94.0%
94.0%
Model No.
Output
HLG-320H-36 A
36V, 0~8.90A
HLG-320H-42 A
42V, 0~7.65A
HLG-320H-48 A
48V, 0~6.70A
HLG-320H-54 A
54V, 0~5.95A
= A, B, C or Blank
Tol.
±1.0%
±1.0%
±1.0%
±1.0%
R&N
250mV
250mV
250mV
350mV
Effi.
94.5%
95.0%
95.0%
95.0%
Description of HLG Family
Built-in active PFC function and constant current output, full range of HLG family feature with high IP level (IP65/67), 5G ant i-vibration,
86.5%~95% of high efficiency, and 4kV anti-surge capability. Along with 5-year warranty as well as fan-less design, the whole f amily can
be cooled by free air convection from -40°C to +70°C ambient temperature, so that they can fit in with all kinds of outdoor/ in door harsh
environments against high dust, high moisture, vibration, high ambient temperature and extremely low temperature, or any machin e/
equipment has no noise requirement. In addition to the indoor/ outdoor LED lighting applications , HLG family is also a good so lution to be
used in harsh environment for industrial related purposes, such as LED electronic display, lawn mower, electric vehicle chargin g, telecom
device, and outdoor electrical equipments…etc..
Lawn Mower
Electric Scooter
Telecom Device
27
LED Electronic Display
DIN Series
10~96W Miniature Single Output
MDR-20
MDR-10
MDR-40
MDR-60
MDR-100
Features
•
•
•
•
•
•
Universal AC input / Full range
I n s t a l l ed on D I N rai l TS 35 / 7. 5 or 15
Protections: Short circuit / Overload / Over voltage
N o l o a d pow er consumpt ion < 0. 75W ( < 1W f or M DR- 10 0 )
L E D i n di cat or for pow e r on
Bu i l t - i n acti ve PFC and ov er t em p. pr ot ec t ion ( M DR- 1 0 0 )
•
•
•
•
•
D C OK s i g n a l o u t p u t ( M D R - 1 0 / 2 0 )
D C OK r e l a y c o n t a c t ( M D R - 4 0 / 6 0 / 1 0 0 )
Cooling by free air convection
100% full load burn-in test
3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
M DR-1 0
Model No .
AC in p u t v o l t a g e ra n g e
M DR - 2 0
MDR-40
8 5 ~2 6 4 VAC; 1 2 0 ~3 7 0 VDC
Co l d s t a rt , 3 5 A a t 11 5 VAC, Co l d st a r t , 2 0 A a t 11 5 VA C ,
AC inrush current
MDR-100
MDR-60
C o ld st a r t , 3 0 A a t 11 5 VA C ,
7 0 A a t 2 3 0 VAC
4 0 A a t 2 3 0 VA C
6 0 A a t 2 3 0 VA C
DC adjus t me n t ra n g e
Fixed
± 10% rated output voltage
0~+20% rated output voltage
Over load p ro t e c t i o n
>105% hiccup mode,
auto-recovery
105%~160% constant current
limiting, auto-recovery
105%~150% constant current limiting, auto-recovery
Over vo l t a g e p ro t e c t i o n
115%~135% rated output voltage
S etu p , r i s e , h o l d u p t i me
500ms, 30ms, 120ms
W ithstan d v o l t a g e
W o r kin g t e mp e ra t u re
I / P-O/ P: 3 k VAC, I / P-FG: 1 . 5 k VAC, 1 m in u t e
DC OK s i g n a l
Open collector
S afety st a n d a rd s
UL 5 0 8 , TUV EN6 0 9 5 0 -1 , UL 6 0 9 5 0 - 1 ( M D R - 4 0 / 6 0 ) a p p r o ve d
E MC stand a rd s
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61204-3, EN61000-6-2 heavy industry level (MDR-40/60/100)
Co n n ect i o n
Dim en sion ( W x Hx D) ( mm)
I / P: 3 p o l e s , O/ P: 3 p o l e s s c re w D I N t e r m in a l
I P : 3 p o le s, O / P : 6 p o le s scr e w D I N t e r m in a l
22.5x90x100
40x90x100
P acking
72pcs / 13.2kg
125%~150% rated output voltage
500ms, 30ms, 50ms
-2 0 ~+7 0 °C (re f e r t o o u t p u t d e ra tin g cu r ve )
72pcs / 14.7kg
Output
5V, 0~2.0A
12V, 0~0.84A
15V, 0~0.67A
24V, 0~0.42A
Tol.
±5%
±3%
±3%
±2%
R&N
80mV
120mV
120mV
150mV
Effi.
77%
81%
81%
84%
55x90x100
42pcs / 13.6kg
Output
5V, 0~3.0A
12V, 0~1.67A
15V, 0~1.34A
24V, 0~1.00A
Tol.
±2%
±1%
±1%
±1%
R&N
80mV
120mV
120mV
150mV
Effi.
76%
80%
81%
84%
Output
5V, 0~6.00A
12V, 0~3.33A
24V, 0~1.70A
48V, 0~0.83A
Tol.
±2%
±1%
±1%
±1%
R&N
80mV
120mV
150mV
200mV
Effi.
78%
86%
88%
88%
Model No.
MD R - 60- 5
MD R - 60- 12
MD R - 60- 24
MD R - 60- 48
42pcs / 14.8kg
30pcs / 13.6kg
Output
5V, 0~10.0A
12V, 0~5.00A
24V, 0~2.50A
48V, 0~1.25A
Tol.
±2%
±1%
±1%
±1%
R&N
80mV
120mV
150mV
200mV
Effi.
78%
86%
88%
87%
MDR-100 Series
Model No.
MDR-40 Series
Model No.
MD R -40-5
MD R -40-12
MD R -40-24
MD R -40-48
R elay contact
MDR-60 Series
MDR-20 Series
Model No.
MD R -20-5
MD R -20-12
MD R -20-15
MD R -20-24
-10~+60°C
Open collector
MDR-10 Series
Model No.
MD R -10-5
MD R -10-12
MD R -10-15
MD R -10-24
3000ms, 50ms, 50ms
Output
Tol.
R&N
Effi.
MDR-100-12
12V, 0~7.5A
±1%
120mV
85%
MDR-100-24
24V, 0~4.0A
±1%
150mV
86%
MDR-100-48
48V, 0~2.0A
±1%
200mV
88%
Energy Saving —
We care about energy saving. This logo represents
that this model has "low no load power consumption"!
To satisfy our customers is our goal —
• High Quality
• Low Cost
• Prompt Delivery
• Best Service
28
DIN Series
1 5 ~ 1 0 0 W C l a s s II S i n g l e O u t p u t
Features
DR-100
DR-60
DR-30
DR-15
• Isolation Class I I
• Universal AC input / Full range
• Protections: Short circuit / Overload /
Over voltage
• Over temperature protection (DR-100)
• N o l o a d p o w e r c o n s u m p t i o n < 1 W ( D R -1 0 0 )
• N o l o a d p o w e r c o n s u m p t i o n < 0 . 5 W ( D R-1 5 )
• Installed on DIN rail TS35 / 7.5 or 15
• Cooling by free air convection
• LED indicator for power on
• 100% full load burn-in test
• 3 years warranty
• Suitable for building automation and control of
household appliance
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
DR-1 5
DR- 3 0
DR-60
DR-100
Co l d st a r t ,
3 0 A a t 2 3 0 VA C
C o ld st a r t ,
3 6 A a t 2 3 0 VA C
AC in p u t v o l t a g e ra n g e
8 5 ~2 6 4 VAC; 1 2 0 ~3 7 0 VDC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt ,
6 5 A a t 2 3 0 VAC
DC adjus t me n t ra n g e
±10% rated output voltage
12V: 12~15V, 15V: 15~18V,
24V: 24~29V
105%~135%
Over load
p r otectio n
Over vo l t a g e
p r otection
8 8 ~ 2 6 4 VA C ; 1 2 4 ~ 3 7 0 V D C
Range
105%~160%
Type
constant current limiting, auto-recovery
Ra n g e
115%~135% rated output voltage
Type
Shut off, clamp by zener diode
C o ld st a r t ,
4 5 A a t 2 3 0 VA C
125%~155% rated output voltage
S hut dow n, r e- pow er on t o r ec over
W ithstan d v o l t a g e
I / P-O/ P: 3 k VA C
W o r kin g t e mp e ra t u re
-20~+60°C (refer to output load derating curve)
V ib r ation
10~500Hz, 2G 10 min./1 cycle, period for 60 min. each along X, Y, Z axes
S afety st a n d a rd s
UL60950-1, TUV60950-1 approved
E MC stan d a rd s
EN55022 class B, EN61000-3-2,3, EN61000-6-2, EN61000-4-2,3,4,5,6,8,11, EN61204-3
Co n n ect i o n
I / P a n d O/ P:
2 p o l e s s c re w DI N t e rm i n a l
I/P: 2 poles,
O/ P : 4 p o le s scr e w D I N t e r m in a l
Dim en sion ( W x Hx D) ( mm)
25x93x56
78x93x56
78x93x56
Case N o .
985A
918B
918B
970A
P acking
140pcs / 15.0kg
48pcs / 14.0kg
48pcs / 15.4kg
36pcs / 13.6kg
15W
60W
DR-15
Model No.
DR-15-5
Output
5V, 0~2.40A
100x93x56
DR-60
Tol.
R&N
Effi.
Model No.
±2%
80mV
77.0%
DR-60-5
DR-60-12
Output
Tol.
R&N
Effi.
5V, 0~6.5A
±2%
80mV
76%
12V, 0~4.5A
±1%
120mV
82%
DR-15-12
12V, 0~1.25A
±1%
120mV
84.0%
DR-15-15
15V, 0~1.00A
±1%
120mV
83.5%
DR-60-15
15V, 0~4.0A
±1%
120mV
83%
85.0%
DR-60-24
24V, 0~2.5A
±1%
150mV
84%
DR-15-24
24V, 0~0.63A
±1%
150mV
30W
DR-30
Model No.
Tol.
R&N
Effi.
5V, 0~3.0A
±2%
80mV
74%
DR-30-12
12V, 0~2.0A
±1%
120mV
81%
DR-30-15
15V, 0~2.0A
±1%
120mV
82%
DR-30-24
24V, 0~1.5A
±1%
150mV
83%
DR-30-5
Output
100W
We provide specification, drawing, test report and more
information, please visit our website —
http://www.meanwell.com
DR-100
Model No.
Output
Tol.
R&N
Effi.
DR-100-12
12V, 0~7.5A
±2%
120mV
87%
DR-100-15
15V, 0~6.5A
±1%
120mV
87%
DR-100-24
24V, 0~4.2A
±1%
150mV
89%
Energy Saving —
We care about energy saving. This logo represents
that this model has "low no load power consumption"!
29
DIN Series
45~480W Single Output
Features
• Universal AC input / Full range (DR-45/75, DRP-240)
AC input selectable by switch (DR-120, DRP-480S)
AC input 180~264VAC only (DRP-480)
• Built-in active PFC function (DRP-240)
• Built-in passive PFC function compliance to
EN61000-3-2 (480W models)
• Protections: Short circuit / Overload /
Over voltage / Over temperature
DR -45
D R -75
DR-120
• Cooling by free air convection
DRP -480
DRP -480S
DRP-240
• Can be installed on DIN rail TS35 / 7.5 or 15
• UL508 (industrial control equipment) listed
• 100% full load burn-in test
• LED indicator for power on
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
DR-4 5
A C in p u t v o l t a g e ra n g e
85~264VAC(DR-45/75, DRP-240); 90~132/180~264VAC selectable by switch (DR-120, DRP-480S); 180~264VAC only (DRP-480)
AC inrush current (230VAC)
56A
40A
DC adjus t me n t ra n g e
±10%
12V: 12~14V, 24V: 24~28V, 48V: 48~53V
Over load p ro t e c t i o n
105%~150% constant current limiting, auto-recovery
Over vo l t a g e
p r otectio n
DR-7 5
DR-120
DRP-240
40A
Ra n g e
115%~142% rated output voltage
Type
Sh u t o ff , AC re c y c l e t o re -s t a r t
DRP-480
45A
DRP-480S
40A
45A
30~36V for 24V model, 54~60V for 48V model
Over tem p . p ro t e c t i o n
Shut down output voltage, recovers automatically after temperature goes down
W ithstan d v o l t a g e
I / P-O/ P: 3 k VA C, I / P-F G: 1 . 5 k VA C , O / P - FG : 0 . 5 kVA C , 1 m in u t e
W o r kin g t e mp e ra t u re
-1 0 ~+5 0 °C
S afety st a n d a rd s
UL 5 0 8 , TUV EN6 0 9 5 0 -1 a p p ro ve d ( U L 6 0 9 5 0 - 1 a lso f o r D R - 1 2 0 , D R P - 2 4 0 , D R P - 4 8 0 , D R P - 4 8 0 S )
E MC stan d a rd s
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 heavy industry level
Co n n ect i o n
I / P: 3 p o l e s , O/ P: 4 p o l e s s c rew D I N t e r m in a l
Dim en sio n ( W x Hx D) ( mm)
78x93x67
-1 0 ~+6 0 °C
- 1 0 ~ + 7 0 °C
55.5x125.2x100
65.5x125.2x100
- 2 0 ~ + 7 0 °C
125.5x125.2x100
227x125.2x100
Case N o .
918A
923
921A
922A
930
P ackin g
48pcs / 17.5kg
20pcs / 13.0kg
20pcs / 16.5kg
12pcs / 15.5kg
6pcs / 15.0kg
DR-45 Series
Model No.
6pcs / 16.6kg
DRP-240 Series
R&N
100mV
Model No.
Output
5V, 0~5.0A
Tol.
±2%
Effi.
D R-45 0 5
Output
72%
DRP-240-24
24V, 0~10A
±1%
80mV
84%
D R-45 1 2
12V, 0~3.5A
±1%
200mV
77%
D R-45 1 5
15V, 0~2.8A
±1%
240mV
77%
DRP-240-48
48V, 0~5.0A
±1%
150mV
85%
D R-45 2 4
24V, 0~2.0A
±1%
480mV
80%
Model No.
Output
Tol.
R&N
Effi.
±1%
120mV
89%
48V, 0~10A
±1%
120mV
89%
Output
Tol.
R&N
Effi.
DRP-480S-24
24V, 0~20A
±1%
120mV
89%
DRP-480S-48
48V, 0~10A
±1%
120mV
89%
Model No.
Output
Tol.
R&N
Effi.
D R -75-12
12V, 0~6.3A
±2%
100mV
76%
DRP-480-48
D R -75-24
24V, 0~3.2A
±1%
150mV
80%
D R -75-48
48V, 0~1.6A
±1%
240mV
81%
DRP-480S Series
Model No.
DR-120 Series
Tol.
R&N
Effi.
DR-120 - 1 2
12V, 0~10A
±2%
80mV
80%
DR-120 - 2 4
24V, 0~5.0A
±1%
80mV
84%
DR-120 - 4 8
48V, 0~2.5A
±1%
100mV
85%
Effi.
24V, 0~20A
DRP-480-24
Output
R&N
DRP-480 Series
DR-75 Series
Model No.
Tol.
30
DIN Series
1 2 0 ~ 9 6 0 W H i g h I n p u t Vo l t a g e
Features
• Input 340~550VAC, 3-phase
(two phase for DRH-120)
• Protections: Short circuit / Overload /
Over voltage / Over temperature
• Built-in constant current limiting circuit
• Cooling by free air convection
• Can be installed on DIN rail TS35 / 7.5 or 15
• UL508 (industrial control equipment) listed
D RH- 1 2 0
DRT - 2 4 0
(240~960W)
D R T- 9 6 0
DRT-4 8 0
• EN61000-6-2 industrial immunity level
• Optional parallel function (1+1) (960W only)
• 100% full load burn-in test
• LED indicator for power on
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
DRH-1 2 0
D R T- 2 4 0
A C in p u t v o l t a g e ra n g e
340~550VAC, two phase
340~550VAC, 3-phase (two phase operation possible)
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 5 0 A a t 4 0 0 VA C
DC adjus t me n t ra n g e
24V: 24~28V, 48V: 48~55V
Over load
p r otection
Over vo l t a g e
p r otection
Ra n g e
105%~160%
Type
Constant current limiting, auto-recovery
Ra n g e
24V: 30~36V, 48V: 59~66V
Type
Sh u t o ff , AC re c y c l e t o re- st a r t
D R T- 4 8 0
105%~150%
D R T- 9 6 0
105%~125%
Constant current limiting,
delay shut off after 3 sec.
Over tem p e ra t u re p ro t e c ti o n
Shut down output voltage, recovers automatically after temperature goes down
W ithstan d v o l t a g e
I / P - O/ P: 3 k VA C, I / P - FG : 1 . 5 kVA C , O / P - FG : 0 . 5 kVA C , 1 m in u t e
W o r kin g t e mp e ra t u re
-2 0 ~+6 0 °C
- 2 0 ~ + 7 0 °C
S afety st a n d a rd s
UL 6 0 9 5 0 -1 a p p ro v e d
U L 5 0 8 , U L 6 0 9 5 0 - 1 , TU V E N 6 0 9 5 0 - 1 a p p r o ve d
- 2 0 ~ + 6 0 °C
E MC stan d a rd s
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61204-3, EN61000-6-2 heavy industry level
Co n n ect i o n ( s c re w DI N t erm i n a l ) I/P: 3 poles, O/P: 4 poles
I/P: 4 poles, O/P: 4 poles
Dim en sion ( W x Hx D) ( mm)
125.5x125.2x100
65.5x125.2x100
I/P: 4 poles, O/P: 6 poles
227x125.2x100
276x125.2x100
C ase N o .
921A
922A
930A
934
P ackin g
20pcs / 16.0kg
12pcs / 16.6kg
6pcs / 16.0kg
4pcs / 14.2kg
DRH-120 (Two Phase)
Model No.
Output
DRT-480 (Three Phase)
Tol.
R&N
Effi.
Model No.
Output
Tol.
R&N
Effi.
DRH-120-24
24V, 0~5.0A
±1%
80mV
85%
DRT-480-24
24V, 0~20A
±1%
80mV
89%
DRH-120-48
48V, 0~2.5A
±1%
80mV
86%
DRT-480-48
48V, 0~10A
±1%
80mV
90%
DRT-240 (Three Phase)
Model No.
Output
DRT-960 (Three Phase)
Tol.
R&N
Effi.
Model No.
Output
Tol.
R&N
Effi.
DRT-240-24
24V, 0~10A
±1%
80mV
89%
DRT-960-24
24V, 0~40A
±1%
80mV
91%
DRT-240-48
48V, 0~5.0A
±1%
80mV
89%
DRT-960-48
48V, 0~20A
±1%
80mV
92%
We prvide specification, drawing, test report and more
information, please visit our website —
http://www.meanwell.com
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also they can offer
you technical support & RMA services. Please contact your
48hrs delivery—
We keep enough stock for 95% of standard models at our
2400m 2 warehouse. We can arrange prompt delivery within
48hrs.
local distributors for more product information. You can also
contact us at [email protected] for information of your local
distributors.
31
DIN Series
75~960W Slim and High Efficiency
Features
SDR-75
SDR-120
SDR-240
SDR-480 P
• High efficiency up to 94%
• Universal AC input / Full range (SDR-75/120/240/480)
A C i n p u t 1 8 0 ~ 2 6 4 VA C o n l y ( S D R - 9 6 0)
• Built-in active PFC function (SDR-120/240/480/960)
• Protections: Short circuit / Overload /
Over voltage / Over temperature
• Cooling by free air convection
• C a n b e i n s t a l l e d o n D I N r a i l T S - 3 5 / 7 .5 o r 1 5
• UL508(industrial control equipment) approved
• EN61000-6-2(EN50082-2) industrial immunity level
• B u i l t - i n D C OK r e l a y c o n t a c t ( e x c e p t fo r S DR-7 5 )
• 150% peak load capability (SDR-75/120/240/480)
130% peak load capability (SDR-960)
• C u r r e n t s h a r i n g u p t o 3 8 4 0 W ( 7 + 1 ) f o r S DR-4 8 0 P
C u r r e n t s h a r i n g u p t o 3 8 4 0 W ( 3 + 1 ) f o r S DR-9 6 0
• C o m p l y w i t h GL ( S D R - 1 2 0 / 2 4 0 / 4 8 0 )
C o m p l y w i t h S E M I F 4 7 ( S D R - 7 5 / 1 2 0 /2 4 0 /4 8 0 )
• 3 years warranty
SDR-960
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
SDR-7 5
AC in p u t v o l t a g e ra n g e
8 8 ~2 6 4 VAC; 1 2 4 ~3 7 0 VDC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt ,
5 0 A a t 2 3 0 VAC
DC adjus t me n t ra n g e
1 2 V: 1 2 ~1 4 V (o n l y f o r SDR-7 5 / 12 0 ) , 2 4 V: 2 4 ~ 2 8 V, 4 8 V: 4 8 ~ 5 5 V
SDR-1 2 0
SDR-240
SDR-480
C o ld st a r t ,
6 5 A a t 2 3 0 VA C
C o ld st a r t ,
8 0 A a t 2 3 0 VA C
90~264VAC; 127~370VDC 1 8 0 ~ 2 6 4 VA C ; 2 5 4 ~ 3 7 0 V D C
Co l d s t a rt ,
7 0 A a t 2 3 0 VAC
Normally works within 110%~150% rated output power for 3 seconds and then
shut down output voltage with auto-recovery (re-power on to recover for SDR-75)
Over load p ro t e c t i o n
>150% rated power or short circuit, constant current limiting with auto-recovery
within 2 seconds and may cause to shut down if over 2 seconds
Over voltage
protection
SDR-960
Ra n g e
1 4 ~1 7 V f o r 1 2 V m o d e l (SDR-7 5 / 1 2 0 ) , 2 9 ~ 3 3 V f o r 2 4 V m o d e l, 5 6 ~ 6 5 V f o r 4 8 V m o d e l
Type
Shut down o/p voltage,
re-power on to recover
C o ld st a r t ,
5 0 A a t 2 3 0 VA C
Normally works within 105%~130%
rated output power for 3 seconds
and then shut down o/p voltage with
auto-recovery after 30 seconds if the
peak load condition is removed
Constant current limiting within
130%~150% rated output power for
more than 3 seconds and then shut
down o/p voltage, re-power on to
recover
Shut down o/p voltage with auto-recovery, or re-power on to recover
Over temperature protection
Re -p o we r o n t o
recover
W ithstan d v o l t a g e
W o r kin g t e mp e ra t u re
S afety st a n d a rd s
I / P-O/ P: 3 k VAC, I / P-F G: 1 . 5 k VAC, O / P - FG : 0 . 5 kVA C , O / P - D C O K : 0 . 5 kVA C ( e xce p t f o r S D R - 7 5 )
-3 0 ~+7 0 °C
-2 5 ~+7 0 °C ( r e f e r t o o u t p u t d e r a t in g cu r ve )
- 3 0 ~ + 7 0 °C
UL 5 0 8 , T UV EN6 0 9 5 0 -1 , GL (SD R - 1 2 0 / 2 4 0 / 4 8 0 ) a p p r o ve d
E MC stan d a rd s
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 -2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, E N 6 1 0 0 0 - 6 - 2 ( E N 5 0 0 8 2 - 2 ) , E N 6 1 2 0 4 - 3 ;
SEM I (SDR-7 5 / 1 2 0 / 2 4 0 / 4 8 0 ), GL ( S D R - 1 2 0 / 2 4 0 / 4 8 0 )
Co n n ect i o n
I/P: 3 poles, O/P: 4 poles
s c re w DI N t e rm i n a l
I/P: 3 poles, O/P: 6 poles
screw DIN terminal
I/P: 3 poles, O/P: 8 poles
screw DIN terminal
I/P:3 poles, O/P: 6 poles
scr e w D I N t e r m in a l
Dim en sio n ( W x Hx D) ( mm)
32x125.2x102
63x 125.2x113.5
85.5x125.2x128.5
110x125.2x150
SDR-75 Series
Recovers automatically after temperature goes down
40x125.2x113.5
NEW
SE
M
SDR-240 Series
PQ
I F4
7
Model No.
Model No.
Output
Tol.
R&N
Effi.
S DR-7 5 - 1 2
1 2 V, 0~6 . 3 A
±1.0%
100mV
88.5%
S DR-7 5 - 2 4
2 4 V, 0~3 . 2 A
±1.0%
100mV
89.0%
S DR-7 5 - 4 8
4 8 V, 0~1 . 6 A
±1.0%
SDR-120 Series
Model No.
120mV
GL
Marine
Output
SE
M
SDR-240-24
SDR-240-48
Model No.
Output
SDR-480 -24
2 4 V, 0 ~ 2 0 A
SDR-480 -48
4 8 V, 0 ~ 1 0 A
=blank, P ; Blank: basic function,
PQ
I F4
7
R&N
Effi.
S D R-12 0 - 1 2
1 2 V, 0 ~1 0 A
±1.0%
100mV
89.0%
S DR-12 0 - 2 4
2 4 V, 0 ~ 5 A
±1.0%
100mV
91.0%
S DR-12 0 - 4 8
4 8 V, 0 ~2 . 5 A
±1.0%
120mV
90.5%
Tol.
±1.0%
±1.0%
SDR-480 Series
90.0%
Tol.
Output
2 4 V, 0 ~ 1 0 A
4 8 V, 0 ~ 5 A
GL
SE
M
Marine
PQ
I F4
7
R&N
100mV
120mV
GL
Marine
SE
M
Effi.
94%
94%
PQ
I F4
7
Tol.
R&N
Effi.
±1.2%
100mV
94%
±1.0%
120mV
94%
P: with parallel function
SDR-960 Series
Model No.
SDR-960-24
SDR-960-48
32
Output
2 4 V, 0 ~ 4 0 A
4 8 V, 0 ~ 2 0 A
Tol.
±1.0%
±1.0%
R&N
180mV
250mV
Effi.
94%
94%
DIN Series
120~480W Slim and Wide Input Range
Features
• Single and two phase wide input range
1 8 0 ~ 5 5 0 VA C
• Built-in active PFC (WDR-240/480)
• Protections: Short circuit / Overload /
Ov e r v o l t a g e / Ov e r t e m p e ra tu re
• Cooling by free air convection
• Built-in constant current limiting circuit
• C a n b e i n s t a l l e d o n D I N r a i l T S - 3 5 / 7 .5 o r 1 5
• UL508(industrial control equipment) approved
• EN61000-6-2(EN50082-2) industrial immunity level
WDR-120
WDR-240
WDR-480
• B u i l t - i n D C OK r e l a y c o n t a c t
• 100% full load burn-in test
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No .
W DR-1 2 0
AC in p u t v o l t a g e ra n g e
180~550VAC(single and two phase); 254~780VDC
AC input current
0 . 5 5 A / 4 0 0 VAC, 1 . 2 A / 2 3 0 VA C
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 5 0 A a t 4 0 0 VAC
DC adjus t me n t ra n g e
12V: 12~15V, 24V: 24~29V, 48V: 48~58V
24V: 24~28V, 48V: 48~55V
Over load p ro t e c t i o n
105%~130% rated output power, constant current
limiting, auto-recovery
105%~130% rated output power, constant current limiting, unit will
shut down after 3 sec.; auto-recovery after 1 minute if the fault
condiction is removed.
Over vo l t a g e
p r otectio n
WDR-240
WDR-480
1 A / 4 0 0 VA C , 2 A / 2 3 0 VA C
1 . 6 A / 4 0 0 VA C , 4 A / 2 3 0 VA C
Ra n g e
1 6 ~1 8 V f o r 1 2 V m o d e l (o n l y f or W D R - 1 2 0 ) , 2 9 ~ 3 3 V f o r 2 4 V m o d e l, 5 6 ~ 6 5 V f o r 4 8 V m o d e l
Type
Shut down o/p voltage, auto-recovery
Shut down o/p voltage, auto-recovery after 1 minute if the
fault condition is removed
2000ms, 70ms, 10ms at full load and 230VAC;
2000ms, 70ms, 50ms at full load and 400VAC
1500ms, 150ms, 18ms at full
load and 230VAC;
800ms, 150ms, 18ms at full
load and 400VAC
S etu p , r i s e , h o l d u p t i me
2000ms, 150ms, 16ms at full
load and 230VAC;
800ms, 150ms, 18ms at full
load and 400VAC
Over tem p . p ro t e c t i o n
W ithstan d v o l t a g e
Shut down output voltage, recovers automatically after temperature goes down
Isolation re s i s t a n c e
0 ȍP L Q # 9'&
W o r kin g t e mp e ra t u re
-2 5 ~+7 0 °C (re f e r t o o u t p u t d er a t in g cu r ve )
DC OK s i g n a l
Re l a y Co n t a c t
L eakag e c u rre n t
<3 . 5 m A a t 5 3 0 VAC
V ib r ation
10~500Hz, 2G 10 minutes / 1 cycle, period of 60 minutes each along X, Y, Z axes
S afety st a n d a rd s
UL508 approved ; IEC60950-1 CB approved by SIQ ; Design refer to GL
E MC stan d a rd s
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 - 2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, E N 6 1 0 0 0 - 6 - 2 ( E N 5 0 0 8 2 - 2 ) , E N 6 1 2 0 4 - 3,
heavy industry level
Co n n ect i o n
I / P: 3 p o l e s , O/ P: 4 p o l e s s c rew D I N t e r m in a l
I / P : 3 p o le s, O / P : 6 p o le s scr e w D I N t e r m in a l
Dim en sio n ( W x Hx D) ( mm)
40x125.2x113.5
63x125.2x113.5
85.5x125.2x128.5
P acking
20pcs / 14kg
12pcs / 13.7kg
8pcs / 14.6kg
I / P-O/ P: 3 k VAC, I / P-FG: 1 . 5 k VAC , O / P - FG : 0 . 5 kVA C , O / P - D C O K : 0 . 5 kVA C , 1 m in u t e
WDR-480 Series
WDR-120 Series
Model No.
Output
- 3 0 ~+ 7 0 °C (refer to output derating curve)
Tol.
R&N
Effi.
Model No.
WDR-120-12
12V, 0~10A
±1.5%
120mV
89.5%
WDR-480-24
WDR-120-24
24V, 0~5A
±1.0%
120mV
91%
WDR-120-48
48V, 0~2.5A
±1.0%
150mV
92%
WDR-480-48
Output
Tol.
R&N
Effi.
WDR-240-24
24V, 0~10A
±1.0%
150mV
91%
WDR-240-48
48V, 0~5A
±1.0%
150mV
91%
Tol.
R&N
Effi.
24V, 0~20A
±1.0%
100mV
92%
48V, 0~10A
±1.0%
150mV
93%
Customer Satisfaction —
Today's effort, tomorrow's reward. Continuously improve
CQTS to satisfy customer is our goal.
WDR-240 Series
Model No.
Output
To satisfy our customers is our goal —
• High Quality
• Low Cost
• Prompt Delivery
• Best Service
33
DIN Series
960W High Input Voltage / Peripheral Module
40A DC UPS Module
960W High Input Voltage
•
•
•
•
•
Input 340~550VAC, 3-phase
Width only 110mm
Built-in active PFC function
High efficiency up to 94.5%
Protections: Short circuit / Overload /
Over voltage / Over temp.
• Cooling by free air convection
• Installed on DIN rail TS-35 / 7.5 or 15
• EN61000-6-2(EN50082-2) industrial
immunity level
• Current sharing up to 3840W (3+1)
• Built-in DC OK relay contact
CASE: 214A
110x 125.2x 150 mm
• 3 years warranty
AC input voltage range ..... 340~550VAC, 3-phase ( two phase operation possible)
AC input current (Typ.)….. 2A / 400VAC, 1.4A / 500VAC
AC inrush current ............. Cold start, 60A at 400VAC
DC adjustment range ....... 24V: 24~28V, 48V: 48~55V
Overload protection .......... 105%~130% rated output power, constant current limiting,
unit will shut down after 3 sec., re-power on to recover
Over voltage protection .... 29~33V (24V model), 56~65V (48V model), shut down
o/p voltage, re-power on to recover
Over temperature…...……. 90ºC±5ºC (24V model), 85ºC±5ºC (48V model)
shut down o/p voltage, recovers automatically after
temperature goes down
Withstand voltage………… I/P-O/P:3kVAC I/P-FG:2kVAC O/P-FG:0.5kVAC
O/P-DC OK: 0.5kVAC
Working temperature ........ -30~+70° C (refer to output derating curve)
Safety standards............... UL508 approved; IEC60950-1 CB approved by SIQ
EMC standards ................ EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2),
EN61204-3, heavy industry level
Connection ...................... I/P: 3 poles, O/P: 6 poles screw DIN terminal
Model No.
TDR-960-24
TDR-960-48
Output
24V, 0~40A
48V, 0~20A
Tol.
±1.0%
±1.0%
R&N
180mV
250mV
CASE: 923D
55.5x 125.2x 100 mm
Effi.
94.0%
94.5%
• Suitable for redundant operation of
24V system
• Installed on DIN rail TS35 / 7.5 or 15
• Relay contact signal output and LED
indicator for input failure alarm
• Cooling by free air convection
• 3 years warranty
DC input voltage range ....... 21~28V, 20A max. x 2 channels
Reverse voltage ................ 30V
DC output current .............. 20A max.
DC output voltage drop ...... 0.5V max.
Input voltage alarm ............ When input is > 20V(±5%) and <30V(±5%), relay contacts
Relay contact rating ........... 30VDC, 1A
Working temperature .......... -40~+70°C
EMC standards .................. EN55022 class B, EN61000-4-2,3,4,5,6,8,11
Connection ........................ I/P: 4 poles, O/P: 2 poles screw DIN terminal,
Single output: 4 poles
Model No.
DR-RDN20
ź
źFeature
Output
24V, 20A
Reverse Voltage
30V max.
55.5x 125.2x 100 mm
DC input / DC bus ............. 24~29V, 40A max.
Battery input voltage ......... 21~29V
Battery input Current ......... 0~40A
Charge current (typ.) ......... 2A
External battery (typ.) ....... 24V, 4AH / 7AH / 12AH
DC bus ok ........................ Relay status : Short when DC voltage between
21~29V(±3%), relay contacts
LED(Green) : DC bus OK : light;
DC bus fail : dark
Battery fail ....................... Relay status : Short when battery failure is
observed through the battery
test function, relay contacts
LED(Red) :
Battery over-discharge warning
or battery broken: light;
Battery OK: dark
Battery discharge ............. Relay status : Short when battery in discharge
condition, relay contacts
LED(Yellow) : Battery discharging: light;
Battery is not discharging or
discharging current <2A: dark
Working temperature ......... -20~+70° C
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,5,6,8,11
Connection ...................... I/P: 2 poles, O/P: 2 poles screw DIN terminal,
Single output: 6 poles
20A Power Supply Redundant Module
CASE: 923C
• Battery controller for DIN rail UPS
system
• Parallel connected to DC BUS
• Suitable for 24V system up to 40A
• Installed on DIN Rail TS35 / 7.5 or 15
• Built-in battery test function
• Battery polarity protection
• Relay contact signal output and LED
indicator for DC BUS OK, Battery Fail,
and Battery Discharge
• Cooling by free air convection
• 3 years warranty
Model No.
DC BUS Voltage
DC BUS Current
DR-UPS40
24~29V
40A max.
Block Diagram
25Ax2
LOAD
+
+
BAT.
TEST
CHARGE
CIRCUIT
LIMIT
INPUT
POWER
SUPPLY
Current
20A max.
24V
BATTERY
DETECTION
CIRCUIT
DR-UPS40
Description
DC
OK
DR-RDN-20 is a 20A redundancy (decoupling) module for the 24VDC
power system. Containing 2 sets of 20A Or-ing diodes with wonderful heat
dissipation deployment, DR-RDN20 offers a safe option of 1+1 redundant
set-up. Not only perfectly decouple power sources from each other as well
as from the load, DR-RDN-20 also provides users monitoring signals for
both input channels through the built-in relays.
DR-UPS40 is a 40A max. DC UPS (battery control) module for the 24VDC
power system. Accompany with external batteries, it can back-up up to
40A of current to critical loads for certain period of time depending on the
capacity of batteries. With complete monitoring signals / LED indicators for
DC BUS OK, Battery Fail, Battery Discharge, and the repeated Battery Test
function to check the situation of external batteries, users can customize
their own DC UPS system to back up critical loads and capture the status
of the whole system easily.
BAT
BAT
FAIL DISCHARGE
Example of Application
Back up connection for
AC interruption
24V
Battery
34
+
DR-UPS40
BAT
+ -
DIN Rail
Power
24V
Load
DC
-
+
+
-
+
-
Open Frame
5 ~ 2 0 W A C / D C E n c a p s u l a t e d Ty p e
Features
5W
10W
62.85x 50x 19.7 mm
70x 50x 22.7 mm
•
•
•
•
•
•
•
•
•
•
•
20W
15W
94x 56x 22.7 mm
75x 53x 22.7 mm
Universal AC input / Full range
Medical safety approved (2xMOPP)
Protections: Short circuit / Overload / Over voltage
/ R Z O H D N D J H F X U U H Q W ȝ$ :
No load power consumption <0.5W
(<0.75W for 20W models)
Fully isolated plastic case
Isolation class II ( 5 ~ 1 5 W )
Cooling by free air convection
Meet industrial, IT safety requirements
100% full load burn-in test
3 years warranty
PM-20 Series
PM-05 / 10 / 15 Series
(A)
3.7"(94mm)
(C)
C 0.306"
(7.8mm)
0.315" (8mm)
0.256"
(6.5mm)
D 1.97"
(50mm)
1.97"
2.09"
(53mm)
(50mm)
E
0.689"
(17.5mm)
0.689" (17.5mm)
0.788"
(20mm)
F
0.295"
(7.5mm)
0.295" (7.5mm)
0.256"
(6.5mm)
I
0.776"
(20.04mm) 0.789" (20.04mm) 0.906"
(23.01mm)
(15mm)
0.59"
(15mm)
0.59"
(15mm)
(19.7mm)
0.89"
(22.7mm)
0.89"
(22.7mm)
2.2"(56mm)
0.312"
(7.92mm)
BOTTOM
VIEW
0.041"(1.05mm)
0.89"(22.7mm)
(62mm)
AC/N AC/L
2.441"
0.696"
(17.68mm)
(54mm)
2.13"
FG
(47mm)
0.408"
(10.375mm)
(75mm)
B 1.85"
+V
2.95"
-V
(70mm)
H 0.59"
(I)
15W
(62.85mm) 2.76"
G 0.789"
0.041"(1.05mm)
10W
A 2.475"
FG
(D)
(E)
(F)
0.138"
(3.5mm)
(H)
AC/L
+V
(G)
AC/N
-V
5W
BOTTOM
VIEW
0.224"
(5.7mm)
3.252"(82.6mm)
0.138"(3.5mm)
(B)
PM-05 Series
General Specification
AC input voltage range ...... 85~264VAC; 120~370VDC
Model No.
PM-05-3.3
PM-05-5
PM-05-12
PM-05-15
PM-05-24
Frequency range ............... 47-440Hz
AC inrush current (max.) ... Cold start, 25A at 115VAC, 45A at 230VAC
(PM-15: 30A at 115VAC, 50A at 230VAC)
(PM-20: 30A at 115VAC, 65A at 230VAC)
Overload protection .......... >105% hiccup mode, auto recovery
Output
3.3V, 0~1.25A
5V, 0~1.00A
12V, 0~0.42A
15V, 0~0.33A
24V, 0~0.23A
Tol.
±3%
±2%
±2%
±2%
±2%
R&N
80mV
80mV
150mV
150mV
240mV
Effi.
67%
71%
73%
74%
76%
Output
3.3V, 0~2.50A
5V, 0~2.00A
12V, 0~0.85A
15V, 0~0.67A
24V, 0~0.42A
Tol.
±3%
±2%
±2%
±2%
±2%
R&N
150mV
150mV
150mV
150mV
240mV
Effi.
66%
74%
78%
79%
79%
Output
3.3V, 0~3.50A
5V, 0~3.00A
12V, 0~1.25A
15V, 0~1.00A
24V, 0~0.63A
Tol.
±3%
±2%
±2%
±2%
±2%
R&N
80mV
80mV
150mV
150mV
240mV
Effi.
73%
76%
78%
79%
81%
Output
3.3V, 0~4.50A
5V, 0~4.40A
12V, 0~1.80A
15V, 0~1.40A
24V, 0~0.92A
Tol.
±3%
±2%
±2%
±2%
±2%
R&N
80mV
80mV
150mV
150mV
240mV
Effi.
71%
75%
81%
83%
84%
PM-10 Series
Over voltage protection ..... 115%~135% rated output voltage, shut off,
Model No.
PM-10-3.3
PM-10-5
PM-10-12
PM-10-15
PM-10-24
AC recycle to re-start
Setup, rise, hold up time ... PM-5/15: 1000ms, 20ms, 100ms @ 230VAC
PM-10: 1800ms, 20ms, 100ms @ 230VAC
PM-20: 500ms, 20ms, 50ms @ 230VAC
Withstand voltage ............. I/P-O/P: 4kVAC, 1 minute
PM-15 Series
Working temperature ......... PM-5/10/15: -20~+70°C
PM-20: -20~+60°C
Model No.
PM-15-3.3
PM-15-5
PM-15-12
PM-15-15
PM-15-24
Safety standards .............. ANSI/AAMI ES60601-1, TUV EN60601-1,
UL60950-1 (PM-15) approved
EMC standards ................. EN55011, EN55022 class B, EN61000-3-2,3
EN61000-4-2,3,4,5,6,8,11, EN55024,
EN60601-1-2, EN61204-3 Medical level, criteria A
PM-20 Series
Connection ...................... 4 industrial pins (20W: 6 industrial pins)
Model No.
PM-20-3.3
PM-20-5
PM-20-12
PM-20-15
PM-20-24
Packing ........................... 0.085kg ; 120pcs / 11.2kg / 0.97CUFT(PM-05)
0.105kg ; 120pcs / 13.6kg / 0.97CUFT(PM-10)
0.14kg ; 120pcs / 17.8kg / 0.97CUFT(PM-15)
0.18kg ; 90pcs / 17.2kg / 0.97CUFT(PM-20)
35
Open Frame
5 ~ 2 0 W A C / D C O n B o a r d Ty p e
Features
10W
58x 45x 19.1 mm
65x 45x 22 mm
15W
20W
70x 48x 22 mm
89x 51x 19.3 mm
NFM-20 Series
(I)
0.76"(19.3mm)
NFM-05 / 10 / 15 Series
DC OUTPUT
-V
(G)
(A)
AC/N
B 0.689"
(17.5mm)
0.689" (17.5mm)
(B)
(H)
AC/L
(C)
(D)
(E)
(F)
T2A/250V
(45mm)
1.89"
(48mm)
0.788"
(20mm)
C 0.21"
(5.33mm)
0.22"
(5.5mm)
0.157"
(4mm)
D 1.85"
(47mm)
2.13"
(54mm)
2.441"
(62mm)
(57.9mm)
2.56"
(65mm)
2.75"
(69.85mm)
E
2.28"
0.491"
(12.47mm) 0.491" (12.47mm) 0.492"
(12.5mm)
(20.04mm) 0.789" (20.04mm) 0.906"
(23.01mm)
H 0.196"
(5mm)
0.196" (5mm)
0.157"
(4mm)
(19.1mm)
0.87"
0.87"
(22mm)
I
0.75"
(22mm)
3.5"(88.9mm)
0.15"
(3.8mm)
3.2"(81.3mm)
T2A/250V
G 0.789"
F
+V
15W
1.77"
0.15"(3.8mm)
AC INPUT
10W
(45mm)
2"(50.8mm)
5W
A 1.77"
CN2
1.7"(43.2mm)
CN1
0.07"(1.8mm)
0.177"(4.5mm)
0.041" (1.05mm) 0.138'(3.5mm)
1
2
3
3
2
1
4
T2A/250V
FG
FG
To Chassis Grounding
5W
General Specification
AC input voltage range .......... 85~264VAC; 120~370VDC
Frequency range ................... 47-440Hz
AC inrush current (max.) ....... Cold start, 25A at 115VAC, 45A at 230VAC
( NFM-15: 30A at 115VAC, 50A at 230VAC )
( NFM-20: 30A at 115VAC, 65A at 230VAC )
DC adjustment range ............ ±10% rated output voltage
Overload protection .............. >105% hiccup mode, auto recovery
Over voltage protection ......... 115%~135% rated output voltage, shut off,
AC recycle to re-start
Over temp. protection ........... U1,Tj: 140~160°C, power shutdown, recovers
automatically after temperature goes down
Setup, rise, hold up time ....... NFM-5/15: 1000ms, 20ms, 100ms @ 230VAC
NFM-10: 1800ms, 20ms, 100ms @ 230VAC
NFM-20: 500ms, 20ms, 50ms @ 230VAC
Withstand voltage ................. I/P-O/P: 4kVAC, 1 minute
Working temperature ............. NFM-5/10/15: -20~+70°C
NFM-20: -20~+60°C
Safety standards .................. ANSI/AAMI ES60601-1, TUV EN60601-1,
UL60950-1 (NFM-15) approved
EMC standards ..................... EN55011, EN55022 class B, EN61000-3-2,3
EN61000-4-2,3,4,5,6,8,11, EN55024,
EN60601-1-2, EN61204-3 Medical level,
criteria A
Connection ........................... 4 industrial pins for 5~15W
3P/4P/3.96mm pitch, Molex 41791-03/04 for 20W
Packing ............................... 0.03kg ; 120pcs / 4.6kg / 0.97CUFT(NFM-05)
0.045kg ; 120pcs / 6.4kg / 0.97CUFT(NFM-10)
0.065kg ; 120pcs / 8.8kg / 0.97CUFT(NFM-15)
0.09kg ; 105pcs / 10.5kg / 0.97CUFT(NFM-20)
Model No.
NFM-05-3.3
NFM-05-5
NFM-05-12
NFM-05-15
NFM-05-24
NFM-05
Output
3.3V, 0~1.25A
5V, 0~1.00A
12V, 0~0.42A
15V, 0~0.33A
24V, 0~0.23A
Tol.
±2%
±2%
±1%
±1%
±1%
R&N
80mV
80mV
150mV
150mV
240mV
Output
3.3V, 0~2.50A
5V, 0~2.00A
12V, 0~0.85A
15V, 0~0.67A
24V, 0~0.42A
Tol.
±2%
±2%
±1%
±1%
±1%
R&N
150mV
150mV
150mV
150mV
240mV
Output
3.3V, 0~3.50A
5V, 0~3.00A
12V, 0~1.25A
15V, 0~1.00A
24V, 0~0.63A
Tol.
±2%
±2%
±1%
±1%
±1%
R&N
80mV
80mV
150mV
150mV
240mV
Output
3.3V, 0~4.50A
5V, 0~4.40A
12V, 0~1.80A
15V, 0~1.40A
24V, 0~0.92A
Tol.
±2%
±2%
±1%
±1%
±1%
R&N
80mV
80mV
150mV
150mV
240mV
10W
Model No.
NFM-10-3.3
NFM-10-5
NFM-10-12
NFM-10-15
NFM-10-24
36
Effi.
66%
74%
78%
79%
79%
NFM-15
20W
Model No.
NFM-20-3.3
NFM-20-5
NFM-20-12
NFM-20-15
NFM-20-24
Effi.
67%
71%
73%
74%
76%
NFM-10
15W
Model No.
NFM-15-3.3
NFM-15-5
NFM-15-12
NFM-15-15
NFM-15-24
4-0.12"(3.0mm)
Dia Mounting Hole s
5W
• Universal AC input / Full range
• Medical safety approved (2xMOPP)
• Protections:
Short circuit / Overload / Over voltage / Over temp.
• / R Z O H D N D J H F X U U H Q W ȝ$ :
• No load power consumption <0.5W
(<0.75W for 20W models)
• Isolation class II ( 5 ~ 1 5 W )
• On-board type version available for 20W (optional)
• Cooling by free air convection
• Meet industrial, IT safety requirements
• 100% full load burn-in test
• 3 years warranty
Effi.
73%
76%
78%
79%
81%
NFM-20
Effi.
71%
75%
81%
83%
84%
Open Frame
3 0 ~ 4 5 W 1 ~ 3 O u t p u t M e d i c a l Ty p e
30W Single Output Medical Type
45W 1~3 Output Medical Type
• Universal AC input / Full range
• Low leakage current”ȝ$
• Universal AC input / Full range
• Approvals: UL / CUL / TUV / CB / CE
• Medical safety approved (2xMOPP)
• Protections: Short circuit / Overload /
• Compact size, low profile
• Medical safety approved (2xMOPP)
• Protections: Short circuit / Overload
• Fixed switching frequency at 45kHz
• 100% full load burn-in test
• 100% full load burn-in test
Over voltage / Over temp. • 3 years warranty
/ Over voltage
• 3 years warranty
76(3.0")
• Low leakage current”ȝ$
101.6x 65.8x 23.5 mm
127x 76x 28 mm
AC input voltage range .... 88~264VAC; 120~370VDC
Overload protection ......... >105% hiccup mode, auto-recovery
Over voltage protection ... 110%~135% rated output voltage
AC input voltage range .... 90~264VAC; 120~370VDC
AC inrush current ............ Cold start, 17A at 115VAC, 35A at 230VAC
DC adjustment range ....... CH1: ±10% rated output voltage
Overload protection ......... 53~75W hiccup mode, auto-recovery
Over voltage protection .... CH1: 115%~135% rated output voltage
Leakage current .............. Less than 250ȝA at 264VAC
Leakage current .............. Less than 200ȝA at 264VAC
Withstand voltage ........... I/P-O/P: 4kVAC, I/P-FG:2kVAC, 1minute
Working temperature ....... -10~+60°C (refer to output derating curve)
Safety standards ............. ANSI/AAMI ES60601-1, TUV EN60601-1,
Setup, rise, hold up time .. 800ms, 30ms, 50ms at full load and 230VAC
Withstand voltage ........... I/P-O/P: 4kVAC, I/P-FG: 2kVAC, 1 minute
Working temperature ....... -10~+60° C (refer to output derating curve)
IEC60601-1 approved
EMC standards ............... EN55011 class B, EN60601-1-2, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ..................... 5+4P/ 3.96mm pitch, Molex P/N: 41791-05,04
Safety standards ............. ANSI/AAMI ES60601-1, TUV EN60601-1,
IEC60601-1 approved
EMC standards ............... EN55011 class B, EN61000-4-2,3,4,5,6,8,11,
Packing .......................... 0.16kg ; 90pcs / 15.8kg / 1.02CUFT
Tol.
R&N
Effi.
MPS-30-5
Model No.
5V, 0~5.0A
Output
±3%
80mV
72%
MPS-30-12
12V, 0~2.5A
±3%
120mV
75%
MPS-30-15
15V, 0~2.0A
±3%
150mV
76%
MPS-30-24
24V, 0~1.2A
±3%
240mV
77%
MPS-30-27
27V, 0~1.1A
±3%
240mV
78%
MPS-30-48
48V, 0~0.6A
±2%
240mV
78%
EN61000-3-2,3, EN60601-1-2
Connection ..................... 2P,6P/ 3.96mm pitch, Molex P/N: 5277-02, 5273-06
Packing .......................... 0.18kg ; 72pcs/ 15.1kg / 1.35CUFT (MPS-45)
S i ngl e O ut put
0.20kg ; 72pcs/ 17.4kg / 1.35CUFT (MPD-45)
0.21kg ; 72pcs/ 18.0kg / 1.35CUFT (MPT-45)
Model No.
Output
Tol.
R&N
Effi.
MPS-45-3.3
3.3V, 0~8.0A
5V, 0~8.0A
±3%
80mV
65%
±3%
100mV
MPS-45-7.5
72%
7.5V, 0~5.4A
±3%
100mV
MPS-45-12
75%
12V, 0~3.7A
±2%
100mV
76%
13.5V, 0~3.3A
±2%
100mV
76%
MPS-45-15
15V, 0~3.0A
±2%
100mV
77%
MPS-45-24
24V, 0~1.9A
±2%
100mV
78%
MPS-45-27
27V, 0~1.7A
±2%
100mV
78%
MPS-45-48
48V, 0~1.0A
±2%
100mV
78%
MPS-45-5
MPS-45-13.5
D ua l O ut put
Model No.
• Universal AC input / Full range
MPD-45A
• Low leakage current <100ȝA
• No load power consumption <0.21W
• High efficiency up to 92%
MPD-45B
• Meet ErP step 2 (Level V) & Meet EISA 2007
Output
Tol.
R&N
Effi.
Max.
±4%
60mV
76%
40W
12V, 0.2~2.5A
±7%
120mV
5V, 0.4~5.0A
±4%
60mV
78%
45W
24V, 0.2~1.8A
±7%
150mV
Output
5V, 0.4~5.0A
12V, 0.2~2.5A
-5V, 0.0~0.5A
5V, 0.4~5.0A
12V, 0.2~2.5A
-12V, 0.0~0.5A
5V, 0.4~5.0A
15V, 0.2~2.3A
-15V, 0.0~0.5A
Tol.
±4%
±7%
±5%
±4%
±7%
±5%
±4%
±7%
±5%
R&N
60mV
120mV
60mV
60mV
120mV
100mV
60mV
120mV
100mV
Effi.
73%
Max.
41W
75%
43W
75%
44W
5V, 0.4~5.0A
Tr i pl e O ut put
• Class I power (with earth pin), 3 pole AC inlet IEC320-C14
Model No.
MPT-45A
• Protections:
Short circuit / Overload / Over voltage / Over temperature
• LED indicator for power on
• Design refer to IEC/EN60601-1, ANSI/AAMI ES60601-1
• Output models: 12V / 15V / 19V / 24V / 48V
MPT-45B
• Dimension(LxWxH): 145x 60x 32mm
MPT-45C
• 3 years warranty
37
Open Frame
6 0 ~ 6 5 W 1 ~ 3 O u t p u t M e d i c a l Ty p e
60W 1~3 Output Medical Type
•
•
•
•
4"x2" compact size
Universal AC input / Full range
Medical safety approved (2xMOPP)
Protections: Short circuit / Overload
/ Over voltage
• No load power consumption <0.75W
(single output models only)
•
•
•
•
•
•
65W 1~3 Output Medical Type
Low leakage current <150ȝ$
110% peak load capability
High power density 6.57W/in 3
Cooling by free air convection
3 years warranty
Suitable for medical & IT applications
• Universal AC input / Full range
• Medical safety approved (2xMOPP)
• Protections: Short circuit / Overload
/ Over voltage
•
•
•
•
Low leakage current”250ȝ$
Fixed switching frequency at 45kHz
100% full load burn-in test
3 years warranty
127x 76x 42 mm
AC input voltage range .... 90~264VAC; 127~370VDC
AC inrush current ............ Cold start, 17A at 115VAC, 35A at 230VAC
101.6x 50.8x 29 mm
AC input voltage range ..... 90~264VAC; 127~370VDC
AC inrush current ............. Cold start, 30A at 115VAC, 60A at 230VAC
DC adjustment range ........-5%~+10% rated output voltage (single output only)
Overload protection .......... 115%~150% hiccup mode, auto-recovery
Over voltage protection .... CH1: 110%~135% rated output voltage
Leakage current ............... Less than 150ȝA at 264VAC
Setup, rise, hold up time .. 500ms, 30ms, 50ms at full load and 230VAC (RPS-60)
200ms, 15ms, 70ms at full load and 230VAC (RPD/T-60)
Withstand voltage ............ I/P-O/P: 4kVAC, I/P-FG: 2kVAC, 1 minute
Working temperature ........ -20~+70° C (RPS-60, refer to output derating curve)
-20~+65°C (RPD/T-60, refer to output derating curve)
Safety standards .............. ANSI/AAMI ES60601-1, UL60950-1,
TUV EN60601-1, EN60950-1 approved
EMC standards ................ EN55011 / EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11, EN60601-1-2,
EN61204-3 medical level
Connection ...................... 3,4P / 3.96mm pitch, JST P/N: B3P / B4P-VH (RPS-60)
3,6P / 3.96mm pitch, JST P/N: B3P / B6P-VH (RPD/T-60)
Packing ........................... 0.15kg ; 96pcs / 15.4kg / 0.89CUFT
S in g le O u t p u t
Model No.
Output
Tol.
R&N
Effi.
RPS-60-3.3
3.3V, 0~11A
±2%
80mV
74%
RPS-60-5
5V, 0~11A
±2%
80mV
79%
RPS-60-12
12V, 0~5.5A
±2%
120mV
83%
RPS-60-15
15V, 0~4.4A
±2%
150mV
84%
RPS-60-24
24V, 0~2.75A
±1%
240mV
85%
RPS-60-48
48V, 0~1.375A
±1%
300mV
86%
Du al Out p u t
Model No.
RPD-60A
Output
5V, 0.5~5.5A
12V, 0.1~2.2A
5V, 0.5~3.85A
24V, 0.1~1.65A
Tol.
+3%,-2%
±6%
+3%,-2%
+8%,-4%
R&N
80mV
80mV
80mV
100mV
Effi.
78%
Max.
54W
82%
59W
Output
5V, 0.5~4.4A
12V, 0.1~2.2A
-5V, 0.1~0.55A
5V, 0.5~4.4A
12V, 0.1~2.2A
-12V, 0.1~0.55A
5V, 0.5~4.4A
15V, 0.1~0.65A
-15V, 0.1~0.55A
5V, 0.5~3.85A
24V, 0.1~1.1A
12V, 0.1~0.55A
3.3V, 0.5~5.5A
5V, 0.3~3.3A
12V, 0.1~0.77A
Tol.
+3%,-2%
±6%
+9%,-8%
+3%,-2%
±6%
+10%,-6%
+3%,-2%
±6%
±8%
+3%,-2%
±6%
±8%
+3%,-2%
±8%
+10%,-6%
R&N
80mV
80mV
80mV
80mV
80mV
100mV
80mV
100mV
150mV
80mV
150mV
80mV
80mV
80mV
80mV
Effi.
77%
RPD-60B
DC adjustment range ....... CH1: ±10% rated output voltage
Overload protection ......... 73%~105% hiccup mode, auto-recovery
Over voltage protection .... CH1: 115%~135% rated output voltage
Leakage current .............. Less than 250ȝ$ at 264VAC
Setup, rise, hold up time .. 800ms, 30ms, 50ms at full load and 230VAC
Withstand voltage ........... I/P-O/P: 4kVAC, I/P-FG: 2kVAC, 1 minute
Working temperature ....... -10~+60° C (refer to output derating curve)
Safety standards ............. ANSI/AAMI ES60601-1, TUV EN60601-1 approved
EMC standards ............... EN55011 class B, EN61000-4-2,3,4,5,6,8,11,
EN61000-3-2,3, EN60601-1-2
Connection ..................... 2P, 6P/ 3.96mm pitch, Molex: 5277-02, 5273-06
Packing .......................... 0.23kg ; 54pcs/ 14.6kg / 1.35CUFT (MPS-65)
0.25kg ; 54pcs/ 16.0kg / 1.35CUFT (MPD-65)
0.27kg ; 54pcs/ 16.8kg / 1.35CUFT (MPT-65)
S i ngl e O ut put
Model No.
Output
Tol.
R&N
Effi.
MPS-65-3.3
MPS-65-5
MPS-65-7.5
MPS-65-12
RPT-60B
RPT-60C
RPT-60D
RPT-6003
±3%
80mV
66%
5V, 0~12A
±3%
100mV
74%
7.5V, 0~8.0A
±3%
100mV
76%
12V, 0~5.2A
±2%
100mV
77%
13.5V, 0~4.7A
±2%
100mV
78%
MPS-65-15
15V, 0~4.2A
±2%
100mV
79%
MPS-65-24
24V, 0~2.7A
±2%
100mV
80%
MPS-65-27
27V, 0~2.4A
±2%
100mV
80%
MPS-65-48
48V, 0~1.35A
±2%
100mV
80%
MPS-65-13.5
D ua l O ut put
Model No.
MPD-65A
T r iple O u t p u t
Model No.
RPT-60A
3.3V, 0~12A
MPD-65B
Max.
51W
Tol.
±4%
R&N
Effi.
Max.
5V, 0.4~7.0A
Output
60mV
75%
61W
12V, 0.2~3.2A
±7%
150mV
5V, 0.4~6.0A
±4%
60mV
78%
66W
24V, 0.2~2.6A
±7%
150mV
Tr i pl e O ut put
78%
Model No.
55W
MPT-65A
79%
75%
Tol.
R&N
Effi.
Max.
±4%
60mV
74%
60W
74%
64W
74%
65W
12V, 0.2~3.2A +10%,-7%
55W
MPT-65B
79%
Output
5V, 0.4~7.0A
52W
±5%
60mV
5V, 0.4~7.0A
±4%
60mV
12V, 0.2~3.2A +10%,-7%
MPT-65C
44W
38
120mV
-5V, 0.0~0.7A
-12V, 0.0~0.7A
±5%
5V, 0.4~7.0A
±4%
160mV
100mV
60mV
15V, 0.2~2.6A +10%,-7%
180mV
-15V, 0.0~0.7A
100mV
±5%
Open Frame
7 5 ~ 1 6 0 W 1 ~ 3 O u t p u t M e d i c a l Ty p e
75W 1~3 Output Medical Type
• Universal AC input / Full range
• Medical safety approved (2xMOPP)
• Protections: Short circuit / Overload
/ Over voltage
• No load power consumption <0.75W
(single output models only)
160W 1~3 Output Medical Type with PFC
•
•
•
•
Universal AC input / Full range
Medical safety approved (2xMOPP)
Built-in active PFC function
Protections: Short circuit / Overload
/ Over voltage / Over temperature
• /RZOHDNDJHFXUUHQWȝ$
• Free air convection for 110W and
160W with 20.5 CFM forced air
(RPS-160); Free air convection for
100W and 150W with 20.5 CFM
forced air (RPD / T-160)
• Low leakage current <150ȝA
• Fixed switching frequency at 65kHz
• Free air convection for 75W and
100W with 23.5CFM forced air
• 3 years warranty
• Suitable for medical & IT applications
• 5"x3" compact size
• With power good and fail signal
output
• Built-in remote sense function for
5~15V (RPS-160)
• Standby [email protected] (G model)
• No load power consumption under
0.75W by PS-ON control (G model)
• 3 years warranty
• Suitable for medical & IT applications
127x 76.2x 31 mm
AC input voltage range ....... 90~264VAC; 127~370VDC
AC inrush current .............. Cold start, 25A at 115VAC, 50A at 230VAC
DC adjustment range ......... CH1: -5%~+10% rated output voltage
Overload protection ........... 140%~180% hiccup mode, auto-recovery
Over voltage protection ...... CH1: 115%~135% rated output voltage
Leakage current ................ /HVVWKDQȝ$DW9$&
Setup, rise, hold up time .... 500ms, 30ms, 80ms at full load and 230VAC
Withstand voltage .............. I/P-O/P: 4kVAC, I/P-FG: 2kVAC, 1 minute
Working temperature .......... -20~+70°C (refer to output derating curve)
Safety standards ............... ANSI/AAMI ES60601-1, TUV EN60601-1 approved
EMC standards .................. EN55011 / EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11, EN61000-6-2,
EN60601-1-2, EN61204-3 medical level
Connection ........................ 3+8P / 3.96mm pitch, JST P/N: B3P / B8P-VH
Packing ............................ 0.26kg ; 63pcs / 16.3kg / 1.35CUFT(RPS-75)
0.25kg ; 63pcs / 16.7kg / 1.35CUFT(RPD-75)
0.26kg ; 63pcs / 17.4kg / 1.35CUFT(RPT-75)
S in g le O u t p u t
Model No.
RPS-75-3.3
RPS-75-5
RPS-75-12
RPS-75-15
RPS-75-24
RPS-75-36
RPS-75-48
Output
3.3V, 0~20A
5V, 0~18.7A
12V, 0~8.3A
15V, 0~6.7A
24V, 0~4.2A
36V, 0~2.8A
48V, 0~2.1A
Tol.
±2%
±2%
±1%
±1%
±1%
±1%
±1%
R&N
80mV
80mV
120mV
150mV
240mV
300mV
300mV
127x 76.2x 34.6mm
AC input voltage range .......... 90~264VAC; 127~370VDC
AC inrush current .................. Cold start, 35A at 115VAC, 70A at 230VAC
DC adjustment range ............. RPS-160: ±10% rated output voltage
RPD/T-160: 0~+10% for CH1
Overload protection ............... 105%~135% hiccup mode, auto-recovery
Over voltage protection .......... CH1: 115%~135% shut off,
re-power on to recovery
Leakage current .................... /HVVWKDQȝ$DW9$&
Setup, rise, hold up time ........ 1800ms, 30ms, 16ms at full load and 230VAC
Withstand voltage .................. I/P-O/P: 4kVAC, I/P-FG: 2kVAC, 1 minute
Working temperature .............. -20~+70° C (refer to output derating curve)
Safety standards ................... ANSI/AAMI ES60601-1, TUV EN60601-1 approved
EMC standards ..................... EN55011/EN55022 class B,
EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3,
EN60601-1-2, EN61000-6-2 (RPS(G)-160)
Connection ........................... 3+8+2(4)P/3.96mm pitch JST B3P / B8P-VH,
B2B (B4B)-XH
S i ngl e O ut put
Model No.
Output
Tol.
Effi.
R&N
5V, 0~30.0A
±4%
100mV
85%
RPS -160-5
Effi.
73%
78%
82%
83%
85%
86%
86%
ƒ
ƒ-160-12
RPS ƒ-160-15
RPS ƒ-160-24
RPS ƒ-160-48
RPS
Du al Out p u t
Model No.
RPD-75A
RPD-75B
T r iple O u t p u t
Model No.
RPT-75A
RPT-75B
RPT-75C
RPT-75D
RPT-7503
12V, 0~12.9A
±3%
100mV
87%
15V, 0~10.3A
±3%
120mV
87%
24V, 0~6.5A
±2%
150mV
87%
48V, 0~3.25A
±2%
250mV
88%
D ua l O ut put
Output
5V, 1.0~9.5A
12V, 0.3~4.0A
5V, 1.0~6.8A
24V, 0.2~2.7A
Tol.
±2%
±6%
±2%
±6%
R&N
80mV
120mV
80mV
200mV
Effi.
77%
Max.
96W
79%
99W
Output
5V, 0.6~8.0A
12V, 0.2~4.0A
-5V, 0.1~1.0A
5V, 0.6~8.0A
12V, 0.2~4.0A
-12V, 0.1~1.0A
5V, 0.6~8.0A
15V, 0.1~3.0A
-15V, 0.1~1.0A
5V, 0.6~7.0A
24V, 0.1~2.0A
12V, 0.1~1.0A
3.3V, 0.7~7.0A
5V, 0.0~8.0A
12V, 0.0~1.5A
Tol.
±2%
±6%
±5%
±2%
±6%
±5%
±2%
±8%
±5%
±2%
±8%
±8%
±4%
±6%
+10%,-6%
R&N
80mV
120mV
120mV
80mV
120mV
120mV
80mV
150mV
150mV
80mV
200mV
120mV
80mV
120mV
120mV
Effi.
76%
Max.
93W
RPT
ƒ-160A
77%
100W
RPT
ƒ-160B
77%
100W
RPT
ƒ-160C
79%
95W
RPT
ƒ-160D
74%
81W
Model No.
RPD -160B
ƒ
Output
5V, 1.0~12A
24V, 0.2~3.6A
Tol.
±2.5%
±6%
R&N
80mV
200mV
Effi.
84%
Max.
150W
Output
5V, 0.6~14A
12V, 0.2~5.5A
-5V, 0.1~1.0A
5V, 0.6~14A
12V, 0.2~5.0A
-12V, 0.1~1.0A
5V, 0.6~14A
15V, 0.1~3.6A
-15V, 0.1~1.0A
5V, 0.3~11A
12V, 0.2~5.0A
24V, 0.15~1.2A
Tol.
±2%
±5%
-5%,+7%
±2%
±5%
-4%,+5%
±2%
±4%
±8%
±2%
±5%
-5%,+7%
R&N
100mV
120mV
120mV
100mV
120mV
120mV
100mV
150mV
150mV
100mV
120mV
200mV
Effi.
84%
Max.
145W
84%
146W
83%
143W
83%
148W
Tr i pl e O ut put
Model No.
ƒ = blank, G;
blank: basic function, G: with 5Vsb/0.8A & no load power
consumption< 0.75W
39
Open Frame
2 0 0 ~ 3 0 0 W 1 ~ 4 O u t p u t M e d i c a l Ty p e
200W 1~4 Output Medical Type with PFC
Universal AC input / Full range
Medical safety approved (2xMOPP)
Built-in active PFC function
Protections: Short circuit / Overload /
Over voltage / Over temp.
• Low leakage current”ȝ$
• With P.G. and P.F. signal output
• Built-in remote sense and remote
ON/OFF control
• 140W free air convection, 200W with
25CFM forced air
• 100% full load burn-in test
• 3 years warranty
• Suitable for medical & IT applications
177.8(7")
165.1(6.5")
Model No.
Output
Tol.
R&N
Effi.
Max.
MPQ-200B
5V, 3.0~18A
±2%
80mV
78%
193W
12V, 0.7~8.4A
±8%
120mV
-5V, 0.0~2.4A
±5%
80mV
78%
190W
79%
195W
81%
200W
MPQ-200C
6.35
(0.25")
107.2(4.22")
95.25(3.75")
6.1
(0.24")
•
•
•
•
Q ua d O ut put
MPQ-200D
35.5(1.4")
(0.156")
177.8x 107.2x 35.5 mm
MPQ-200F
AC input voltage range ....... 90~264VAC; 127~370VDC
AC inrush current ............... Cold start, 35A at 115VAC, 60A at 230VAC
DC adjustment range .......... CH1: -5~+10% rated output voltage
Overload protection ............ 110%~160% hiccup mode, auto-recovery
Over voltage protection ....... CH1: 115%~140% rated output voltage
Leakage current ................. /HVVWKDQȝ$DW9$&
Setup, rise, hold up time ..... 1000ms, 20ms, 16ms at full load and 230VAC
Withstand voltage ............... I/P-O/P: 4kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ........... -20~+70° C (refer to output derating curve)
Safety standards ................ ANSI/AAMI ES60601-1, TUV EN60601-1,
IEC60601-1 approved; Design refer to UL60950-1,
TUV EN60950-1
EMC standards ................... EN55011/EN55022 class B,
EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3,
EN60601-1-2, EN61000-6-2
Connection ......................... 3P, 20P / 3.96mm pitch, JST B3P/VH, Molex 5566-20
3P, 8Px2 / 3.96mm pitch, JSTB3P / B8Px2-VH
Packing ............................. 0.66kg ; 24pcs / 16.8kg / 0.99CUFT
S ingle O u t p u t
Model No.
MPS-200-3.3
MPS-200-5
MPS-200-12
MPS-200-15
MPS-200-24
MPS-200-48
Output
3.3V, 0~40A
5V, 0~40A
12V, 0~16.7A
15V, 0~13.4A
24V, 0~8.4A
48V, 0~4.2A
Tol.
±2%
±2%
±2%
±2%
±1%
±1%
R&N
80mV
80mV
100mV
100mV
150mV
200mV
•
•
•
•
•
Effi.
77%
81%
84%
85%
86%
87%
MPD-200B
Output
5V, 4.0~24A
12V, 0.8~9.6A
5V, 4.0~24A
24V, 0.4~4.8A
Tol.
±2%
+8%,-5%
±2%
±6.5%
R&N
80mV
120mV
80mV
180mV
Effi.
82%
Max.
196W
83%
196W
Output
5V, 4.0~24A
12V, 0.8~9.0A
-5V, 0.0~2.4A
5V, 4.0~24A
12V, 0.6~7.2A
-12V, 0.0~2.4A
5V, 4.0~24A
15V, 0.5~5.6A
-15V, 0.0~2.4A
5V, 4.0~24A
24V, 0.3~3.6A
12V, 0.0~2.4A
Tol.
±2%
±8%
±5%
±2%
±8%
±5%
±2%
±8%
±5%
±2%
±8%
±5%
R&N
80mV
120mV
80mV
80mV
120mV
80mV
80mV
150mV
80mV
80mV
180mV
80mV
Effi.
80%
Max.
200W
MPT-200B
80%
196W
MPT-200C
MPT-200D
81%
80mV
15V, 0.5~6.0A
±6%
150mV
-5V, 0.0~2.4A
±5%
80mV
-15V, 0.0~2.4A
±5%
80mV
5V, 3.0~18A
±2%
80mV
24V, 0.3~3.6A
±8%
180mV
80mV
12V, 0.0~2.4A
±5%
-12V, 0.0~2.4A
±5%
80mV
5V, 3.0~18A
±2%
80mV
24V, 0.3~3.3A
±8%
180mV
15V, 0.0~2.4A
±5%
80mV
-15V, 0.0~2.4A
±5%
5"x 3" compact size
Universal AC input / Full range
Medical safety approved (2xMOPP)
Withstand 300VAC surge input for
5 seconds
Built-in active PFC function
No load power consumption <0.5W
by PS-ON control
High efficiency up to 93%
Built-in 12V/0.5A auxiliary output
Built-in remote sense function
80mV
• Protections:
Short circuit / Overload /
Over voltage / Over temp.
• /RZOHDNDJHFXUUHQWȝ$
• Free air convection for 200W and
300W with 20.5 CFM forced air
• Standby [email protected]
• With P.G and P.F. signal output
• High power density 14.5W/in 3
• 3 years warranty
AC input voltage range ....... 90~264VAC; 127~370VDC
AC inrush current ............... Cold start, 40A at 115VAC, 80A at 230VAC
DC adjustment range .......... ±5% rated output voltage
Overload protection ............ 105%~135% hiccup mode, auto-recovery
Over voltage protection ....... 110%~125% shut off, re-power on to recovery
Leakage current ................. /HVVWKDQȝ$DW9$&
Setup, rise, hold up time ..... 2500ms, 30ms, 13ms at full load and 230VAC
Withstand voltage ............... I/P-O/P: 4kVAC, I/P-FG: 2kVAC, 1 minute
Working temperature ........... -30~+70° C (refer to output derating curve)
Safety standards ................ ANSI/AAMI ES60601-1, TUV EN60601-1
EMC standards ................... EN55011/EN55022 class B,
EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3,
EN60601-1-2
Model No.
80%
80mV
±2%
127x 76.2x 35 mm
Tr ip le O u t p u t
Model No.
MPT-200A
±5%
5V, 3.0~18A
300W Single Output Medical Type with PFC
•
•
•
•
Du al Out p u t
Model No.
MPD-200A
-12V, 0.0~2.4A
201W
196W
40
Output
Tol.
R&N
Effi.
RPS-300-12
12V, 0~25A
±3%
120mV
90.0%
RPS-300-15
15V, 0~20A
±3%
120mV
90.0%
RPS-300-24
24V, 0~12.5A
±2%
150mV
92.5%
RPS-300-27
27V, 0~11.12A
±2%
200mV
93.0%
RPS-300-48
48V, 0~6.25A
±2%
250mV
93.0%
Open Frame
5~25W Single and Dual Output
5W Single Output Switching Power Supply
• Universal AC input / Full range
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• Cooling by free air convection
•
•
•
•
•
25W 1~2 Output Switching Power Supply
• Universal AC input / Full range
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• Cooling by free air convection
Fixed switching frequency at 67kHz
Low leakage current <0.5mA
100% full load burn-in test
Low cost, high reliability
2 years warranty
•
•
•
•
•
Fixed switching frequency at 100kHz
Low leakage current <0.5mA
100% full load burn-in test
Low cost, high reliability
2 years warranty
75
67
1
2
3
32
40
To chassis Grounding
1
2
CN2
CN1
4-
20
3 .5
75x 40x 20 mm
AC input voltage range ....... 85~264VAC; 120~370VDC
AC inrush current ............... Cold start, 30A at 230VAC
Overload protection ............ >105% hiccup mode, auto-recovery
Over voltage protection ...... 115%~135% rated output voltage
Over temp. protection ......... U1, Tj:140 O C, hiccup mode, auto-recovery
Leakage current ................. Less than 0.5mA at 240VAC
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature .......... -10~+60°C (refer to output derating curve)
Safety standards .................UL60950-1 CB approval by TUV
EMC standards .................. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ........................ 3P/ 5mm, 2P/ 3.96mm pitch, Molex 5285-03,5273-02
Packing ............................. 0.05kg ; 120pcs / 6.25kg / 1.0CUFT
Model No.
PS-05-5
PS-05-12
PS-05-15
PS-05-24
PS-05-48
Output
5V, 0~1.0A
12V, 0~0.45A
15V, 0~0.35A
24V, 0~0.22A
48V, 0~0.11A
Tol.
±2%
±2%
±2%
±2%
±1%
R&N
100mV
120mV
120mV
200mV
200mV
107x 61x 28 mm
AC input voltage range ..... 85~264VAC; 120~370VDC
AC inrush current ............. Cold start, 36A at 230VAC
Overload protection .......... >105% hiccup mode, auto-recovery
Over voltage protection ..... 115%~135% rated output voltage
Over temp. protection ....... U1, Tj:135ºC, power shutdown
Leakage current ............... Less than 0.5mA at 240VAC
Withstand voltage ............. I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ........ -10~+60°C (refer to output derating curve)
Safety standards .............. UL60950-1, TUV EN60950-1 approved
EMC standards ................ EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5
Effi.
70%
75%
75%
76%
76%
Connection ...................... 3P, 4P/ 3.96mm pitch, Molex P/N: 41791-03, 04
Packing ........................... 0.14kg ; 96pcs / 15.0kg / 1.30CUFT(PS-25)
0.15kg ; 96pcs / 15.9kg / 1.30CUFT(PD-25)
0.13kg ; 96pcs / 15.4kg / 1.30CUFT(PD-2503)
S i ngl e O ut put
15W Single Output Switching Power Supply
• Universal AC input / Full range
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• Cooling by free air convection
•
•
•
•
•
Model No.
Fixed switching frequency at 67kHz
Low leakage current <0.5mA
100% full load burn-in test
Low cost, high reliability
2 years warranty
87
42
49
1
2
CN2
3.5
25
4-
94x 49x 25 mm
3.3V, 0~5.0A
±3%
80mV
66%
5V, 0~5.0A
±2%
80mV
74%
PS-25-7.5
7.5V, 0~3.3A
±2%
80mV
76%
PS-25-12
12V, 0~2.1A
±2%
100mV
78%
13.5V, 0~1.9A
±2%
100mV
78%
PS-25-15
15V, 0~1.7A
±2%
100mV
78%
PS-25-24
24V, 0~1.0A
±2%
240mV
79%
PS-25-27
27V, 0~0.9A
±2%
240mV
79%
PS-25-48
48V, 0~0.5A
±2%
350mV
79%
D ua l O ut put
AC input voltage range ........... 85~264VAC; 120~370VDC
AC inrush current ................... Cold start, 40A at 230VAC
Overload protection ................ >105% hiccup mode, auto-recovery
Over voltage protection .......... 115%~135% rated output voltage
Over temp. protection ............. U1, Tj:140 O C, hiccup mode, auto-recovery
Leakage current ..................... Less than 0.5mA at 240VAC
Withstand voltage .................. I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature .............. -10~+60°C (refer to output derating curve)
Safety standards .................... EN60950-1 CB approval by TUV
EMC standards ...................... EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ............................ 3P, 2P/ 3.96mm pitch, JST B3P/B2P-VH
Packing ................................. 0.083kg ; 120pcs / 10.96kg
Model No.
PS-15-5
PS-15-12
PS-15-15
PS-15-24
PS-15-48
Effi.
PS-25-13.5
CN1
1
2
3
R&N
PS-25-5
94
To chassis Grounding
Tol.
PS-25-3.3
Output
Output
5V, 0~2.80A
12V, 0~1.25A
15V, 0~1.00A
24V, 0~0.625A
48V, 0~0.313A
Tol.
±2%
±2%
±2%
±2%
±2%
R&N
100mV
120mV
120mV
150mV
200mV
Model No.
PD-25A
PD-25B
PD-2505
PD-2512
Effi.
74%
77%
78%
79%
77%
PD-2515
PD-2503
Output
R&N
Effi.
Max.
71%
25W
77%
25W
73%
25W
74%
24W
75%
24W
72%
25W
5V, 0.2~2.5A
±2%
50mV
12V, 0.1~1.5A
±6%
150mV
5V, 0.2~2.0A
±2%
50mV
24V, 0.1~1.0A
±6%
200mV
5V, 0.1~3.0A
±6%
50mV
-5V, 0.1~2.5A
±6%
50mV
12V, 0.1~1.2A
±4%
50mV
-12V, 0.1~1.2A
±4%
50mV
15V, 0.1~1.0A
±4%
50mV
-15V, 0.1~1.0A
±4%
50mV
3.3V, 0.2~5.0A
±2%
50mV
+5%,-8%
50mV
5V, 0.1~4.0A
41
Tol.
Open Frame
35~45W Single, Dual, and Triple Output
35W Single Output Switching Power Supply
• Universal AC input / Full range
• Cooling by free air convection
45W 1~3 Output Switching Power Supply
• Protections: Short circuit / Overload
/ Over voltage
• Universal AC input / Full range
• Protections: Short circuit / Overload
/ Over voltage
• Cooling by free air convection
• Fixed switching frequency at 65kHz
Low leakage current <0.75mA
100% full load burn-in test
Low cost, high reliability
2 years warranty
76 (3.0")
• 2 years warranty
•
•
•
•
101.6x 50.8x 24 mm
AC input voltage range ............ 90~264VAC; 127~370VDC
DC adjustment range ............... ±10% rated output voltage
Overload protection ................. 105%~160% hiccup mode, auto-recovery
127x 76x 28 mm
AC input voltage range ... 90~264VAC; 127~370VDC
AC inrush current ........... Cold start, 15A at 115VAC, 30A at 230VAC
Over voltage protection ............ 115%~150% rated output voltage
Withstand voltage .................... I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
DC adjustment range ...... CH1: -5%~+10% rated output voltage
Overload protection ........53~75W hiccup mode, auto-recovery
Over voltage protection .. CH1: 115%~135% rated output voltage
Leakage current ............. Less than 0.75mA at 240VAC
Withstand voltage .......... I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ...... -10~+60° C (refer to output derating curve)
Working temperature ................ -20~+65° C (refer to output derating curve)
Safety standards ..................... UL60950-1, TUV EN60950-1 approved
EMC standards ........................ EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ............................. 3+4P / 3.96mm pitch, JST B3P/B4P-VH
Packing .................................. 0.124kg; 96pcs / 12.9kg / 0.8CUFT
Model No.
Output
Tol.
PS-35-3.3
3.3V, 0~6.0A
5V, 0~6.0A
PS-35-7.5
PS-35-12
PS-35-5
PS-35-13.5
Safety standards ........... UL60950-1, TUV EN60950-1 approved
EMC standards .............. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
R&N
Effi.
±2%
80mV
70%
±2%
100mV
78%
7.5V, 0~4.7A
±2%
100mV
80%
12V, 0~3.0A
±1%
120mV
81%
S i ngl e O ut put
Connection ................... 2P, 6P/ 3.96mm pitch, Molex 5277-02 / 5273-06
Packing ........................ 0.19kg ; 72pcs / 15.6kg / 1.35CUFT(PS-45)
0.20kg ; 72pcs / 16.0kg / 1.35CUFT(PD-45)
0.21kg ; 72pcs / 17.0kg / 1.35CUFT(PT-45)
13.5V, 0~2.6A
±1%
120mV
81%
Model No.
Output
Tol.
R&N
Effi.
PS-35-15
15V, 0~2.4A
±1%
150mV
81%
PS-45-3.3
3.3V, 0~8.0A
±3%
80mV
69%
PS-35-24
24V, 0~1.5A
±1%
200mV
85%
PS-45-5
PS-35-48
48V, 0~0.75A
±1%
240mV
84%
PS-45-7.5
PS-45-12
5V, 0~8.0A
±3%
100mV
74%
7.5V, 0~5.4A
±3%
100mV
75%
12V, 0~3.7A
±2%
100mV
76%
13.5V, 0~3.3A
±2%
100mV
77%
PS-45-15
15V, 0~3.0A
±2%
100mV
77%
PS-45-24
24V, 0~1.9A
±2%
100mV
78%
PS-45-27
27V, 0~1.7A
±2%
100mV
78%
PS-45-48
48V, 0~1.0A
±2%
100mV
78%
PS-45-13.5
D ua l O ut put
Model No.
PD-45A
• Universal AC input / Full range
• Low leakage current <100ȝA
• No load power consumption <0.21W
PD-45B
• High efficency up to 92%
Output
Tol.
R&N
Effi.
Max.
±4%
50mV
77%
40W
12V, 0.2~2.5A
±7%
120mV
5V, 0.4~5.0A
±4%
50mV
78%
45W
24V, 0.2~1.8A
±7%
120mV
Output
5V, 0.4~5.0A
12V, 0.2~2.5A
-5V, 0.0~0.5A
5V, 0.4~5.0A
12V, 0.2~2.5A
-12V, 0.0~0.5A
5V, 0.4~5.0A
15V, 0.2~2.3A
-15V, 0.0~0.5A
Tol.
±4%
±7%
±5%
±4%
±7%
±5%
±4%
±7%
±5%
R&N
50mV
120mV
50mV
50mV
120mV
100mV
50mV
120mV
100mV
Effi.
75%
Max.
41W
75%
43W
75%
44W
5V, 0.4~5.0A
Tr i pl e O ut put
• Meet ErP step 2 (Level V) & EISA 2007
• Class I power (with earth pin), 3 pole AC inlet IEC320-C14
Model No.
PT-45A
• Protections:
Short circuit / Overload / Over voltage / Over temperature
• LED indicator for power on
• Design refer to IEC/EN60601-1, ANSI/AAMI ES60601-1
PT-45B
• Output models: 12V / 15V / 20V / 24V / 48V
• Dimension(LxWxH): 167x 67x 35mm
PT-45C
• 3 years warranty
42
Open Frame
45~65W Single, Dual, and Triple Output
45 & 65W Triple Output with 3.3V Channel
Universal AC input / Full range
Total power for CH1+2: 35W (PT-45)
Total power for CH1+2: 54W (PT-65)
Protections: Short circuit / Overload
/ Over voltage
•
•
•
•
Fixed switching frequency at 65kHz
Cooling by free air convection
100% full load burn-in test
2 years warranty
• Universal AC input / Full range
• Protections: Short circuit / Overload
/ Over voltage
• Cooling by free air convection
•
•
•
•
•
Fixed switching frequency at 65kHz
Low leakage current <0.75mA
100% full load burn-in test
Low cost, high reliability
2 years warranty
76 (3.0")
•
•
•
•
65W 1~3 Output Switching Power Supply
PT-4503
127x 76x 28 mm
127x 76x 42 mm
AC input voltage range ....... 90~264VAC; 127~370VDC
AC inrush current ............... Cold start, 20A at 115VAC, 40A at 230VAC
DC adjustment range .......... CH1: -5%~+10% rated output voltage
Overload protection ............ 73~105W hiccup mode, auto-recovery
Over voltage protection .......CH1: 115%~135% rated output voltage
Leakage current ................. Less than 0.75mA at 240VAC
Setup, rise, hold up time ..... 800ms, 20ms, 60ms at full load and 230VAC
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature .......... -10~+60° C (refer to output derating curve)
Safety standards ................ UL60950-1, TUV EN60950-1 approved
EMC standards .................. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ....................... 2P, 6P/ 3.96mm pitch, Molex P/N: 5277-02,
5273-06
Packing ............................ 0.21kg ; 54pcs / 14.2kg / 1.35CUFT(PS-65)
0.24kg ; 54pcs / 15.0kg / 1.35CUFT(PD-65)
0.25kg ; 54pcs / 15.9kg / 1.35CUFT(PT-65)
S i ngl e O ut put
PT-6503
127x 76x 42 mm
AC input voltage range ........ 90~264VAC; 127~370VDC
AC inrush current ................ Cold start, 20A at 115VAC, 40A at 230VAC
DC adjustment range ........... 3.3V: ±10% rated output voltage
Overload protection ............. 120%~160% hiccup mode, auto-recovery
Over voltage protection ........ 5V: 115%~135% rated output voltage
Model No.
Leakage current .................. Less than 1.0mA at 240VAC
Output
3.3V, 0~12A
Tol.
R&N
Effi.
±3%
80mV
69%
5V, 0~12A
±3%
100mV
76%
PS-65-7.5
7.5V, 0~8.0A
±3%
100mV
79%
PS-65-12
12V, 0~5.2A
±2%
100mV
79%
Setup, rise, hold up time ...... 800ms, 50ms, 60ms at full load and 230VAC
PS-65-3.3
Withstand voltage ................ I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
PS-65-5
Working temperature ........... -10~+60° C (refer to output derating curve)
Safety standards ................. UL60950-1, TUV EN60950-1 approved
PS-65-13.5
EMC standards .................... EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,11
Connection ......................... 2P, 8P/ 3.96mm pitch, Molex: 5277-02, 5273-08
Packing .............................. 0.23kg ; 72pcs / 17.6kg / 1.35CUFT(PT-4503)
0.28kg ; 54pcs / 16.2kg / 1.35CUFT(PT-6503)
13.5V, 0~4.7A
±2%
100mV
79%
PS-65-15
15V, 0~4.2A
±2%
100mV
79%
PS-65-24
24V, 0~2.7A
±2%
100mV
80%
PS-65-27
27V, 0~2.4A
±2%
100mV
80%
PS-65-48
48V, 0~1.35A
±2%
100mV
80%
D ua l O ut put
Model No.
Tr ip le O u t p u t ( 4 5 W )
Model No.
Output
Tol.
R&N
Effi.
Max.
PT-4503
3.3V, 0.0~5.0A
±2%
50mV
72%
45W
5V, 0.2~7.0A
+4%,-2%
50mV
12V, 0.0~1.2A
±8%
100mV
PD-65A
PD-65B
Output
Tol.
5V, 0.4~7.0A
±4%
R&N
50mV
12V, 0.2~3.2A
±7%
120mV
5V, 0.4~6.0A
±4%
50mV
24V, 0.2~2.6A
±7%
150mV
Output
5V, 0.4~7.0A
12V, 0.2~3.2A
-5V, 0.0~0.7A
5V, 0.4~7.0A
12V, 0.2~3.2A
-12V, 0.0~0.7A
5V, 0.4~7.0A
15V, 0.2~2.6A
-15V, 0.0~0.7A
5V, 0.5~5.0A
12V, 0.2~4.0A
24V, 0.2~1.3A
Tol.
±4%
±7%
±5%
±4%
±7%
±5%
±4%
±7%
±5%
±4%
±6%
±6%
R&N
50mV
120mV
50mV
50mV
120mV
100mV
50mV
120mV
100mV
50mV
100mV
200mV
Effi.
Max.
78%
61W
81%
66W
Effi.
76%
Max.
60W
77%
64W
77%
65W
79%
68W
Tr i pl e O ut put
Model No.
PT-65A
Tr ip le O u t p u t ( 6 5 W )
Model No.
Output
Tol.
R&N
Effi.
Max.
PT-6503
3.3V, 0.0~7.0A
±3%
50mV
72%
62W
5V, 0.2~10A
+4%,-2%
50mV
12V, 0.0~1.2A
±8%
100mV
PT-65B
PT-65C
48hrs delivery—
We keep enough stock for 95% of standard models at our
2400m 2 warehouse. We can arrange prompt delivery within
48hrs.
PT-65D
43
Open Frame
65~110W Dual, Triple, and Quad Output
65W 2, 3 Output Switching Power Supply
• Low leakage current < 1mA
• 100% full load burn-in test
• Optional case available
(RPD/RPT-65x-C)
• 2 years warranty
• Universal AC input / Full range
• Power good signal output (option)
• Protections: Short circuit / Overload
/ Over voltage
• Cooling by free air convection
•
•
•
•
Fixed switching frequency at 45kHz
100% full load burn-in test
Low leakage current <[email protected] 240VAC
2 years warranty
6.35
177.8
6.35
107.95
• Universal AC input / Full range
• Protections: Short circuit / Overload
/ Over voltage
• Cooling by free air convection
• 12V or 24V high peak current capability
• 60~65W free air convection,
77~80W with 18 CFM forced air
100~110W 2, 4 Output Switching Power Supply
PD-110
177.8x 107.95x 46.5 mm
127x 76x 29 mm
6.35
177.8
6.35
107.95
źWith Optional Case
PQ-100
177.8x 107.95x 46.5 mm
130x 85x 37 mm
AC input voltage range .. 100~264VAC; 141~370VDC
AC inrush current .......... Cold start, 45A at 230VAC
DC adjustment range ..... CH1: -5%~+10% rated output voltage
Overload protection ....... 105%~135% hiccup mode, auto-recovery
Over voltage protection ..CH1: 115%~135% rated output voltage
Withstand voltage ......... I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ..... -10~+60° C (refer to output derating curve)
Safety standards .......... UL60950-1, TUV EN60950-1 approved
EMC standards ............. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,11
Connection ................... 5+12P/ 3.96mm pitch, Molex: 5273-05,12(PD-110)
5+6+7P/ 3.96mm pitch, Molex: 5273-05,06,07(PQ-100)
Packing ....................... 0.51kg ; 24pcs / 13.1kg / 1.19CUFT (PD-110)
0.56kg ; 24pcs / 14.5kg / 1.19CUFT (PQ-100)
D ua l O ut put
AC input voltage range .......... 90~264VAC; 127~370VDC
AC inrush current .................. Cold start, 25A at 115VAC, 50A at 230VAC
DC adjustment range ............. CH1 12V: 11.4~12.8V, 24V: 22.8~26.4V
Overload protection ............... 90~125W hiccup mode, auto-recovery
Over voltage protection ......... CH1: 115%~135% rated output voltage
Leakage current .................... Less than 1mA at 240VAC
Setup, rise, hold up time ........ 800ms, 20ms, 20ms at full load and 230VAC
Withstand voltage ................. I/P-O/P: 3kVAC, I/P-FG: 2kVAC, 1minute
Working temperature ............. -20~+60°C (refer to output derating curve)
Safety standards ................... UL60950-1, TUV EN60950-1 approved
EMC standards ..................... EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ........................... 3P, 6P/ 3.96mm pitch, Molex P/N: 5273-03,
5273-06
Packing ................................ 0.24kg ; 63pcs / 16kg / 1.35CUFT (PCB type)
0.47kg ; 32pcs / 16kg / 0.64CUFT (Enclosed type)
Du al Out p u t
Model No.
RPD-65C
RPD-65D
ƒ
ƒ
Model No.
PD-110A
PD-110B
Output
12V, 0~5.8A
Tol.
R&N
Effi.
Max.
±2%
120mV
79%
60W
5V, 0~1.5A
±5%
50mV
24V, 0~2.9A
±2%
150mV
81%
60W
5V, 0~1.5A
±5%
50mV
Model No.
PQ-100B
Model No.
ƒ
Output
12V, 0.18~5.8A
Tol.
R&N
Effi.
Max.
PQ-100C
±2%
120mV
77%
63W
RPT-65F
ƒ
77%
66W
RPT-65G
ƒ
81%
66W
5V, 0.0~1.5A
±5%
100mV
-5V, 0.0~0.7A
±5%
120mV
12V, 0.18~5.8A
±2%
150mV
5V, 0.0~1.5A
±5%
100mV
-12V, 0.0~0.7A
±5%
150mV
24V, 0.09~2.9A
±2%
150mV
5V, 0.0~1.5A
±5%
50mV
12V, 0.0~0.7A
±5%
100mV
Tol.
R&N
Effi.
Max.
±2%
100mV
75%
103W
78%
109W
Effi.
72%
Max.
101W
74%
103W
77%
103W
74%
99W
12V, 0.5~6.5A
±6%
150mV
5V, 0.5~5.0A
±2%
100mV
24V, 0.5~3.5A
±6%
200mV
Output
5V, 2.0~10A
12V, 0.5~4.5A
-5V, 0.0~1.0A
-12V, 0.0~1.0A
5V, 2.0~8.0A
15V, 0.5~4.0A
-5V, 0.0~1.0A
-15V, 0.0~1.0A
5V, 2.0~5.0A
12V, 0.5~4.5A
24V, 0.4~2.0A
-12V, 0.0~1.0A
5V, 2.0~8.0A
12V, 0.5~3.0A
15V, 0.0~1.0A
24V, 0.0~1.0A
Tol.
±3%
±12%
±6%
±6%
±2%
±6%
±6%
±6%
±2%
±6%
±10%
±6%
±2%
±6%
±6%
±6%
R&N
80mV
250mV
80mV
120mV
80mV
150mV
80mV
150mV
80mV
120mV
180mV
120mV
80mV
120mV
150mV
120mV
Q ua d O ut put
T r iple O u t p u t
RPT-65E
Output
5V, 0.5~5.0A
PQ-100D
PQ-100E
ƒ = bl a n k , - C ; b la n k : P CB Typ e , -C: En c l o s e d Typ e
44
Open Frame
100~125W Single, Triple, and Quad Output
100W Quad Output with PFC Function
• Universal AC input / Full range
125W 1,3 Output with PFC Function
• Cooling by free air convection
• Universal AC input / Full range
• 100% full load burn-in test
• Built-in active PFC function
• Protections: Short circuit / Overload • 3 years warranty
• Built-in active PFC function
• High power density 6.117W/in 3
6.35
177.8
125W with 18 CFM forced air
• Protections: Short circuit / Overload • 100% full load burn-in test
• 3 years warranty
/ Over voltage
/ Over voltage
• Built-in remote sense for PPS-125
107.95
6.35
• LED indicator for power on
• Free air convection for 100W and
177.8x 108x 40 mm
AC input voltage range .. 90~264VAC; 127~370VDC
AC inrush current .......... Cold start, 50A at 230VAC (PPQ-1003)
127x 76.2x 34.6 mm
Cold start, 30A at 230VAC (PPQ-100)
DC adjustment range ..... CH1: -5%~+10% (PPQ-1003: CH1&2 -5%~+10%)
AC input voltage range ....... 90~264VAC; 127~370VDC
Overload protection ....... 105%~135% constant current, auto-recovery (PPQ-1003)
AC inrush current ............... Cold start, 24A at 230VAC
105%~135% hiccup mode, auto-recovery (PPQ-100)
DC adjustment range .......... CH1: ±5% rated output voltage
Over voltage protection .. 3.6V~4.3V for 3.3V ; 5.75V~6.75V for 5.0V
Overload protection ............ 130%~160% fold back current limiting, auto-recovery
Leakage current ............ Less than 3.5mA at 240VAC (PPQ-1003: <1mA)
Over voltage protection ...... CH1:110%~135% rated output voltage
Setup, rise, hold up time .. 800ms, 50ms, 18ms at full load and 230VAC
Leakage current ................ Less than 2.0mA at 240VAC
Withstand voltage ......... I/P-O/P: 3kVAC, I/P-FG:2kVAC, 1minute
Setup, rise, hold up time .... 1000ms, 30ms, 24ms at full load and 230VAC
Working temperature ..... -10~+60°C (refer to output derating curve)
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Safety standards ........... UL60950-1, TUV EN60950-1 approved
Working temperature .......... -20~+70° C (refer to output derating curve)
EMC standards ............. EN55022 class B, EN61000-3-2,3,
Safety standards ............... UL60950-1, TUV EN60950-1 approved
EN61000-4-2,3,4,5,6,8,11
EMC standards .................. EN55022 class B, EN61000-3-2,3,
Connection .................. 3P+5P+8P/ 3.96mm pitch, P/N:JST B3/5/8P-VH (PPQ-1003)
EN61000-4-2,3,4,5,6,8,11
5P+5P+8P/ 3.96mm pitch, P/N:JST B5/5/8P-VH (PPQ-100)
Connection ........................ 3+8P /3.96mm pitch, JST: B3P/B8P-VH (PPS-125)
Packing ........................ 0.62kg ; 24pcs / 15.5kg / 1.34CUFT (PPQ-1003)
3+5Px2 /3.96mm pitch, JST: B3P/B5Px2-VH (PPT-125)
0.62kg ; 24pcs / 15.9kg / 1.34CUFT (PPQ-100)
Model No.
PPQ-1003A
PPQ-1003B
PPQ-1003C
PPQ-1003D
PPQ-100B
PPQ-100C
PPQ-100D
Output
3.3V, 0.0~15A
5V, 2.0~15A
12V, 0.2~3.0A
-5V, 0.0~1.0A
3.3V, 0.0~15A
5V, 2.0~15A
12V, 0.2~3.0A
-12V, 0.0~1.0A
3.3V, 0.0~15A
5V, 2.0~15A
15V, 0.2~3.0A
-15V, 0.0~1.0A
3.3V, 0.0~15A
5V, 2.0~15A
12V, 0.2~3.0A
24V, 0.0~1.0A
5V, 2.0~15A
12V, 0.3~4.0A
-12V, 0.0~1.0A
-5V, 0.0~1.0A
5V, 2.0~15A
15V, 0.3~4.0A
-15V, 0.0~1.0A
-5V, 0.0~1.0A
5V, 2.0~10A
24V, 0.3~4.0A
12V, 0.0~1.0A
-12V, 0.0~1.0A
Tol.
±3%
±3%
±6%
±6%
±3%
±3%
±6%
±6%
±3%
±3%
+10%,-5%
±6%
±3%
±3%
+7%,-2%
±6%
±3%
±8%
±5%
±5%
±3%
-6%,+10%
±5%
±5%
±3%
±8%
±5%
±5%
R&N
100mV
100mV
150mV
100mV
100mV
100mV
150mV
120mV
100mV
100mV
180mV
150mV
100mV
100mV
150mV
150mV
100mV
150mV
100mV
100mV
100mV
150mV
100mV
100mV
100mV
200mV
100mV
100mV
Effi.
75%
75%
76%
Packing ............................. 0.37kg; 36pcs / 14.3kg / 0.79CUFT
S i ngl e O ut put
Max.
109W
111W
Model No.
Output
Tol.
R&N
Effi.
PPS-125-3.3
3.3V, 0~25A
±2%
100mV
70%
PPS-125-5
5V, 0~25A
±2%
100mV
79%
PPS-125-12
12V, 0~10.5A
±2%
100mV
80%
PPS-125-13.5
110W
13.5V, 0~9.3A
±2%
100mV
80%
PPS-125-15
15V, 0~8.4A
±2%
100mV
80%
PPS-125-24
24V, 0~5.2A
±1%
150mV
83%
PPS-125-27
27V, 0~4.6A
±1%
150mV
83%
PPS-125-48
48V, 0~2.6A
±1%
250mV
84%
Tr i pl e O ut put
76.5%
75%
114W
Model No.
Output
Tol.
R&N
PPT-125A
3.3V, 1.0~12.5A
±3%
100mV
5V, 0.8~10.0A
±5%
100mV
101W
PPT-125B
76%
78%
101W
PPT-125C
102W
PPT-125D
45
12V, 0.05~0.63A
±6%
120mV
5V, 1.0~14.38A
±3%
100mV
12V, 0.3~3.75A
±5%
120mV
-12V, 0.05~0.63A
±6%
120mV
5V, 1.0~13.75A
±3%
100mV
15V, 0.25~3.13A
±5%
150mV
-15V, 0.05~0.63A
±6%
150mV
5V, 1.0~8.75A
±3%
100mV
24V, 0.25~3.13A
±5%
240mV
12V, 0.05~0.63A
±6%
120mV
Max
Effi.
75%
99W
78%
124W
78%
125W
78%
126W
Open Frame
150~250W Single and Dual Output
150W Single Output with PFC Function
• Universal AC input / Full range
• Built-in active PFC function
• Protections: Short circuit / Overload /
Over voltage / Over temp.
•
•
•
•
•
250W Isolated Dual Output with PFC Function
Cooling by free air convection
High power density 8.4W/in 3
No load power consumption<1W
100% full load burn-in test
3 years warranty
• Universal AC input / Full range
• Optional case available
• Isolated output & GND for CH1,CH2
• Built-in active PFC function
• Cooling by free air convection
• Remote control function for CH1
• Protections: Short circuit / Overload / • Peak load 170% for 10 sec. (CH1)
Over voltage / Over temp. • 100% full load burn-in test
• 3 years warranty
3.5
169x 60.7x 28.5 mm
AC input voltage range ....... 90~264VAC ; 127~370VDC
DC adjustment range ......... Can be modified between ±10% rated output
voltage by factory
Overload protection ........... 105%~135% hiccup mode, auto-recovery
Over voltage protection ...... 110%~135% rated output voltage
Withstand voltage ............. I/P-O/P: 4.25kVDC, I/P-FG:1.5kVAC, 1minute
Working temperature ......... -20~+60°C (refer to output derating curve)
Safety standards ............... UL60950-1 approved
EMC standards ................. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ....................... 5+6P/3.96mm pitch, JST P/N :B5P/B6P-VH
Packing ............................ 0.32kg ; 48pcs / 15.8kg / 0.79CUFT
Model No.
ASP-150-12
ASP-150-15
ASP-150-20
ASP-150-24
ASP-150-48
Output
12V, 0~11A
15V, 0~9.5A
20V, 0~7.5A
24V, 0~6.3A
48V, 0~3.2A
Tol.
±2%
±2%
±1%
±1%
±1%
R&N
150mV
180mV
200mV
240mV
240mV
222x 95x 40 mm
Effi.
88%
88%
90%
90%
89%
250x 105.4x 53 mm
AC input voltage range ......... 90~264VAC; 127~370VDC
AC inrush current ................ Cold start, 58A at 230VAC
Leakage current .................. Less than 3.5mA at 240VAC
DC adjustment range ........... ±10% for CH1; ±5% for CH2
Overload protection(CH1) ..... 105%~170% normally operation, shut off
after 10 sec.; >180%, constant current, shut
off after 10 sec.
(CH2) ..... 101%~150% hiccup mode, auto-recovery
Over voltage protection ........ CH1: 115%~140%, CH2: 110%~135%
Setup, rise, hold up time ....... 1200ms, 60ms, 30ms at full load and 230VAC
Withstand voltage ................ I/P-O/P:3.0kVAC, I/P-FG:2kVAC, 1minute
Working temperature ............ -20~+70° C (refer to output derating curve)
Safety standards ................. UL60950-1, TUV EN60950-1 approved
EMC standards ................... EN55022 class B, EN61000-3-2,-3
EN61000-4-2,3,4,5,6,8,11, EN61000-6-2
Connection ......................... 5+10+2P/3.96mm pitch JST B5P/B10P-VH,
B2B-XH
Packing .............................. 0.74kg ; 18pcs / 14.3kg / 0.88CUFT (PCB type);
1.6kg ; 9pcs / 15.4kg / 0.61CUFT (Enclosed type)
200W Single Output with PFC Function
Universal AC input / Full range
High efficiency up to 90%
PF>[email protected]; >[email protected]
Protections: Short circuit / Overload /
Over voltage / Over temp.
• High power density 9.78W/in 3
• 5"x3" compact size
• ZVS technology to reduce power
dissipation
• Built-in remote sense function
• Free air convection for 150W and
200W with 20.5 CFM forced air
• 3 years warranty
127
6.4
•
•
•
•
115.6
5
12
CN3
1
2
3
4
5
6
7
8
64.8
76.2
SVR1
1
2
3
CN1
CN5
LED1
43.
50mm
5
Air flow
direction
FAN
34.6
20.5CFM
Model No.
Output
Tol.
R&N
Effi.
PID-250A
12V, 0~15A
±3%
120mV
83%
5V, 0~5.0A
±2%
50mV
24V, 0~9.4A
±2%
150mV
5V, 0~5.0A
±2%
50mV
36V, 0~6.3A
±2%
200mV
5V, 0~5.0A
±2%
50mV
48V, 0~4.7A
±2%
200mV
5V, 0~5.0A
±2%
50mV
127x 76.2x 34.6 mm
AC input voltage range .......... 90~264VAC; 127~370VDC
DC adjustment range ............ ±10% rated output voltage
Overload protection .............. 105%~135% hiccup mode, auto-recovery
Over voltage protection ......... 115%~135% rated output voltage
Withstand voltage ................. I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ............. -20~+70°C (refer to output derating curve)
Safety standards ................... UL60950-1, TUV EN60950-1 approved
EMC standards ..................... EN55022 class B, EN61000-3-2,3
EN61000-4-2,3,4,5,6,8,11
Connection ........................... 3+8P/3.96mm pitch, JST B3P/B8P-VH
Packing ................................ 0.37kg ; 36pcs / 14.3kg / 0.79CUFT
Model No.
PPS-200-5
PPS-200-12
PPS-200-15
PPS-200-24
PPS-200-27
PPS-200-48
Output
5V, 0~36.0A
12V, 0~16.6A
15V, 0~13.3A
24V, 0~8.30A
27V, 0~7.40A
48V, 0~4.167A
Tol.
±4%
±3%
±3%
±2%
±2%
±2%
R&N
100mV
100mV
100mV
150mV
150mV
250mV
PID-250B
PID-250C
PID-250D
86%
86%
86%
ź
źFeature Description
PID-250 series is suitable for motor-based equipment with logic control
circuit. CH1 with high peak power capability can provide the required
surge loading while starting up the motor. The isolated 5V/5A CH2 is
good for logic control usage and can still work properly even CH1 is
malfunction or at any protection modes. The isolated design between
CH1 and CH2 can significantly prevent noise of the motor action from
entering control circuits and hence secure the accurate operation of the
end equipment.
Effi.
86%
89%
89%
89%
89%
90%
46
Open Frame
50~150W Single Output
Features
• Universal AC input / Full range
• Built-in active PFC function (LPP-100/150)
• Protections: Short circuit / Overload / Over voltage
• Optional over temperature protection for LPP-150
• Built-in remote ON/OFF control (LPS-50/75)
• Cooling by free air convection
• 100% full load burn-in test
L P S -50
LPS-75
L PS/ LPP-1 0 0
3 years warranty for LPP series
L P S - 75
LPS/LPP-100
LPP-150
3 max.
2.5 max.
2.5 max.
(33.6)
LPS-50
• 2 years warranty for LPS series
LP P - 1 5 0
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No.
LPS-75
AC input voltage range
LPS-50
90~264VAC
LPS-100
115/230 auto switch
AC inrush current (230VAC)
35A
36A
60A
DC adjustment range
±10% rated output voltage
LPP-100
85~264VAC
LPP-150
30A
55A
-5%~+10% rated output voltage
Overload
protection
Ra n g e
122%~160%
Type
Hiccup mode, auto recovery
115%~150%
Over voltage
protection
Ra n g e
110%~135% of rated output voltage
Type
Hiccup mode, auto recovery
105%~140%
105%~150% rated output power
Constant current limiting, auto recovery
Shut off, AC recycle to re-start
Withstand voltage
I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, O/P-FG: 0.5kVAC, 1 minute
Working temperature
-20~+70° C (refer to output derating curve)
Safety standards
UL60950-1, TUV EN60950-1 approved
EMC standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 (EN61000-6-2 heavy industry level for LPS-50/75 only)
Connection
JST B5P / B4P-VH
JST B5P / B6P-VH
5P+8P/3.96mm pitch, JST B5P / B8P-VH
JST B5P / B6Px2-VH
Dimension (LxWxH)(mm)
195x55x23
222x55x30
222x62x32
222x62x33.6
222x75x41
Packing
48pcs / 12.5kg
48pcs / 15.6kg
24pcs / 12.5kg
24pcs / 13.9kg
24pcs / 16.6kg
50W
Model No.
LPS-50-3.3
LPS-50-5
LPS-50-12
LPS-50-15
LPS-50-24
LPS-50-48
LPS-50
Output
3.3V, 0~10A
5V, 0~10A
12V, 0~4.2A
15V, 0~3.4A
24V, 0~2.1A
48V, 0~1.1A
Tol.
±3%
±3%
±2%
±2%
±1%
±1%
R&N
50mV
50mV
80mV
80mV
80mV
100mV
75W
Model No.
LPS-75-3.3
LPS-75-5
LPS-75-12
LPS-75-15
LPS-75-24
LPS-75-48
LPS-100-24
LPS-100-27
LPS-100-48
Effi.
75%
81%
82%
84%
85%
86%
Output
3.3V, 0~15A
5V, 0~15A
12V, 0~6.2A
15V, 0~5.0A
24V, 0~3.2A
48V, 0~1.56A
Tol.
±3%
±3%
±2%
±2%
±2%
±2%
Output
3.3V, 0~20A
5V, 0~20A
7.5V, 0~13.3A
12V, 0~8.4A
13.5V, 0~7.5A
15V, 0~6.7A
Tol.
±3%
±3%
±2%
±2%
±2%
±2%
R&N
80mV
80mV
100mV
100mV
120mV
120mV
Model No.
LPP-100-3.3
LPP-100-5
LPP-100-7.5
LPP-100-12
LPP-100-13.5
LPP-100-15
LPP-100-24
LPP-100-27
LPP-100-48
Effi.
69%
77%
80%
81%
83%
83%
±1%
±1%
±1%
150mV
150mV
200mV
Output
3.3V, 0~20A
5V, 0~20A
7.5V, 0~13.5A
12V, 0~8.5A
13.5V, 0~7.5A
15V, 0~6.7A
24V, 0~4.2A
27V, 0~3.8A
48V, 0~2.1A
Tol.
±2%
±2%
±2%
±2%
±2%
±2%
±1%
±1%
±1%
R&N
100mV
100mV
100mV
100mV
100mV
100mV
150mV
150mV
250mV
Model No.
LPP-150-3.3
LPP-150-5
LPP-150-7.5
LPP-150-12
LPP-150-13.5
LPP-150-15
LPP-150-24
LPP-150-27
LPP-150-48
Effi.
69%
77%
77%
79%
79%
80%
47
Output
3.3V, 0~30A
5V, 0~30A
7.5V, 0~20A
12V, 0~12.5A
13.5V, 0~11.2A
15V, 0~10A
24V, 0~6.3A
27V, 0~5.6A
48V, 0~3.2A
80%
81%
81%
LPP-100
150W.(with.PFC.Function)
LPS-100
R&N
150mV
100mV
100mV
100mV
100mV
100mV
24V, 0~4.2A
27V, 0~3.8A
48V, 0~2.1A
100W.(with.PFC.Function)
LPS-75
100W
Model No.
LPS-100-3.3
LPS-100-5
LPS-100-7.5
LPS-100-12
LPS-100-13.5
LPS-100-15
-10~+60° C (refer to output derating curve)
Effi.
69%
75%
76%
79%
79%
80%
83%
83%
83%
LPP-150
Tol.
±2%
±2%
±2%
±2%
±2%
±2%
±1%
±1%
±1%
R&N
100mV
100mV
100mV
100mV
100mV
100mV
150mV
150mV
250mV
Effi.
70%
76%
80%
82%
83%
83%
85%
85%
85%
Green Open Frame
5~20W AC/DC Miniature Encapsulated Type
Features
IRM - 0 5
I R M-1 0
I RM -1 5
•
•
•
•
•
•
•
•
•
•
•
IRM-20
Universal AC input / Full range
No load power consumption < 0.1W
Miniature size, high power density
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Isolation class II
Fully isolated plastic case
Withstand 5G vibration test
Low cost, high reliability
100% full load burn-in test
3 years warranty
I RM - 05 / 10
IRM-15 / 20
52. 4
45.7
3.4
3.2
45
24
3.2
3.6
-V
AC/L
3.5 ±1mm
+V
1.04
20. 8
27.2
10.75
8
BOTT OM
VIEW
AC/N
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No.
IRM-05
IRM-10
IRM-15
IRM-20
AC input voltage range
85~264VAC; 120~370VDC
AC inrush current (max.)
Cold start, 20A at 115VAC, 40A at 230VAC
Overload protection
115%~260%
Over voltage protection
115%~135% rated output voltage
Setup, rise, hold up time
600ms, 30ms, 80ms
Leakage current
Less than 0.75mA at 240VAC
Withstand voltage
I/P-O/P: 3kVAC
Working temperature
-30~+70°C (refer to output derating curve)
Vibration
10~500Hz, 5G 10min./1 cycle, period for 60 min. each along X, Y, Z axes
Safety standards
UL60950-1, TUV EN60950-1 approved
EMC standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection
4 industrial pins
Dimension (LxWxH)(mm)
45.7x 25.4x 21.5
115%~190%
115%~160%
600ms, 30ms, 30ms
1000ms, 20ms, 40ms at full load and 230VAC
52.4x 27.2x 24
5W
15W
IRM-05
IRM-15
Model No.
Output
Tol.
R&N
Effi.
Model No.
Output
Tol.
R&N
Effi.
IRM-05-3.3
3.3V, 0~1.25A
±2.5%
200mV
68%
IRM-15-3.3
3.3V, 0~3.5A
±2.5%
200mV
74%
±2.5%
200mV
71%
IRM-15-5
IRM-05-5
5V, 0~1A
±2.5%
200mV
78%
IRM-05-12
12V, 0~0.42A
±2.5%
200mV
75%
IRM-15-12
12V, 0~1.25A
±2.5%
200mV
82%
IRM-05-15
15V, 0~0.33A
±2.5%
200mV
75%
IRM-15-15
15V, 0~1A
±2.5%
200mV
82%
IRM-05-24
24V, 0~0.23A
±2.5%
200mV
77%
IRM-15-24
24V, 0~0.63A
±2.5%
200mV
83%
10W
Model No.
IRM-10-3.3
IRM-10-5
20W
IRM-10
Output
5V, 0~3A
IRM-20
Tol.
R&N
Effi.
Model No.
Output
Tol.
R&N
Effi.
3.3V, 0~2.5A
±2.5%
200mV
74%
IRM-20-3.3
3.3V, 0~4.5A
±2.5%
200mV
76%
5V, 0~2A
±2.5%
200mV
77%
IRM-20-5
5V, 0~4A
±2.5%
200mV
79%
IRM-10-12
12V, 0~0.85A
±2.5%
200mV
82%
IRM-20-12
12V, 0~1.8A
±2.5%
200mV
84%
IRM-10-15
15V, 0~0.67A
±2.5%
200mV
82%
IRM-20-15
15V, 0~1.4A
±2.5%
200mV
84%
IRM-10-24
24V, 0~0.42A
±2.5%
200mV
82%
IRM-20-24
24V, 0~0.9A
±2.5%
200mV
85%
48
Green Open Frame
15~65W Single Output
Features
EPS-15
EPS-2 5 / 3 5
EPS-45-C/65-C
E P S - 25/ 35
Universal AC input / Full range
No load power consumption < 0.3W
High efficiency up to 90%
Compact size
Cooling by free air convection
Protections: Short circuit / Overload / Over voltage
Case available (EPS-45-x-C & EPS-65-x-C)
LED indicator for power on (except for EPS-15)
3 years warranty
EPS-45/65
E P S - 4 5 - C / 6 5 -C
29
EPS-15
EPS-4 5 / 6 5
•
•
•
•
•
•
•
•
•
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No.
EPS-15
85~264VAC; 120~370VDC
EPS-25
AC inrush current (max.)
Cold start, 45A at 230VAC
Cold start, 35A at 230VAC Cold start, 40A at 230VAC Cold start, 60A at 230VAC
DC adjustment range
±10% rated output voltage
AC input voltage range
Overload
protection
Ra n g e
115%~150% rated output power
Type
Hiccup mode, auto recovery
EPS-35
EPS-45-(C)
EPS-65-(C)
90~264VAC; 127~370VDC
115%~170% rated output power
115%~160% rated output power
110%~140%
110%~135%
Over voltage protection
110%~135%
Withstand voltage
I/P-O/P: 3kVAC, I/P-FG:2kVAC, O/P-FG: 0.5kVAC, 1 minute
Working temperature
-30~+70° C (refer to output derating curve)
Safety standards
UL60950-1, TUV EN60950-1 approved
EMC standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection
3+2P/3.96mm pitch, JST B3P/B2P-VH
3+4P/3.96mm pitch, JST B3P/B4P-VH
Dimension (LxWxH)(mm)
63.5x45.7x24
PCB: 101.6x50.8x29 ; Case: 103.4x62x37
76.2x50.8x24
15W
Model No.
EPS-15-3.3
EPS-15-5
EPS-15-7.5
EPS-15-12
EPS-15-15
EPS-15-24
EPS-15-27
EPS-15-36
EPS-15-48
EPS-15
Output(Rated / Peak 10 sec.)
3.3V, 0~3A / 3.3A
5V, 0~3A / 3.3A
7.5V, 0~2A / 2.2A
12V, 0~1.25A / 1.38A
15V, 0~1A / 1.1A
24V, 0~0.625A / 0.69A
27V, 0~0.56A / 0.615A
36V, 0~0.42A / 0.46A
48V, 0~0.313A / 0.344A
Tol.
±2%
±2%
±2%
±1%
±1%
±1%
±1%
±1%
±1%
25W
Model No.
EPS-25-3.3
EPS-25-5
EPS-25-7.5
EPS-25-12
EPS-25-15
EPS-25-24
EPS-25-27
EPS-25-36
EPS-25-48
Effi.
75%
78%
81%
82%
83%
83%
84%
85%
85%
Output(Rated / Peak 10 sec.)
3.3V, 0~5A / 5.5A
5V, 0~5A / 5.5A
7.5V, 0~3.4A / 3.74A
12V, 0~2.1A / 2.34A
15V, 0~1.7A / 1.87A
24V, 0~1.05A / 1.17A
27V, 0~0.95A / 1.05A
36V, 0~0.7A / 0.78A
48V, 0~0.53A / 0.59A
Tol.
±2%
±2%
±2%
±1%
±1%
±1%
±1%
±1%
±1%
R&N
60mV
60mV
80mV
100mV
100mV
180mV
180mV
200mV
240mV
Model No.
EPS-45-3.3
EPS-45-5
EPS-45-7.5
EPS-45-12
EPS-45-15
EPS-45-24
EPS-45-36
EPS-45-48
Effi.
79%
81%
83%
86%
87%
88%
89%
89%
90%
ƒ= blank, -C
Tol.
±2.5%
±2.0%
±2.0%
±1.0%
±1.0%
R&N
60mV
70mV
80mV
100mV
100mV
Tol.
±1%
±1%
±1%
±1%
Model No.
EPS-65-3.3
EPS-65-5
EPS-65-7.5
EPS-65-12
EPS-65-15
EPS-65-24
EPS-65-36
EPS-65-48
Effi.
80%
82%
84%
87%
88%
ƒ= blank, -C
49
R&N
180mV
180mV
200mV
240mV
Effi.
89%
89%
89%
90%
EPS-45
Output(Rated / Peak 10 sec.)
3.3V, 0~8A / 9A
5V, 0~8A / 9A
7.5V, 0~5.4A / 6A
12V, 0~3.75A / 4.2A
15V, 0~3A / 3.3A
24V, 0~1.9A / 2.1A
36V, 0~1.25A / 1.4A
48V, 0~1A / 1.1A
Tol.
±3%
±2%
±2%
±2%
±2%
±1%
±1%
±1%
R&N
80mV
80mV
100mV
120mV
150mV
240mV
280mV
300mV
Effi.
80%
82%
84%
87%
88%
89%
89%
90%
; blank: PCB type, -C: Enclosed type
65W
EPS-35
Output(Rated / Peak 10 sec.)
3.3V, 0~6A / 6.6A
5V, 0~6A / 6.6A
7.5V, 0~4.7A / 5.2A
12V, 0~3A / 3.3A
15V, 0~2.4A / 2.65A
Output(Rated / Peak 10 sec.)
24V, 0~1.5A / 1.65A
27V, 0~1.3A / 1.45A
36V, 0~1A / 1.1A
48V, 0~0.75A / 0.82A
45W
EPS-25
35W
Model No.
EPS-35-3.3
EPS-35-5
EPS-35-7.5
EPS-35-12
EPS-35-15
R&N
50mV
50mV
80mV
80mV
100mV
150mV
180mV
200mV
200mV
Model No.
EPS-35-24
EPS-35-27
EPS-35-36
EPS-35-48
EPS-65
Output(Rated / Peak 10 sec.)
3.3V, 0~11A / 12A
5V, 0~11A / 12A
7.5V, 0~8A / 8.8A
12V, 0~5.42A / 6A
15V, 0~4.34A / 4.8A
24V, 0~2.71A / 3A
36V, 0~1.81A / 2A
48V, 0~1.36A / 1.5A
Tol.
±3%
±2%
±2%
±2%
±2%
±1%
±1%
±1%
; blank: PCB type, -C: Enclosed type
R&N
80mV
80mV
100mV
120mV
150mV
240mV
280mV
300mV
Effi.
80%
82%
84%
86%
87%
88%
89%
90%
Green Open Frame
75~300W Single Output
75W Single Output with PFC Function
•
•
•
•
•
Universal AC input / Full range
Built-in active PFC function
No load power consumption <0.5W
High efficiency up to 90%
Cooling by free air convection
150W Single Output with PFC Function
• Protections:
Short circuit / Overload /
Over voltage
• Case available (ELP-75-x-C)
• LED indicator for power on
• 1U low profile
• 3 years warranty
•
•
•
•
•
•
4"x 2" compact size
Universal AC input / Full range
Built-in active PFC function
No load power consumption <0.5W
High efficiency up to 93%
Free air convection for 100W and
150W with 20 CFM forced air
• Protections:
Short circuit / Overload /
Over voltage / Over temperature
• 12V/0.3A auxiliary output
• High power density 16.42W/in 3
• LED indicator for power on
• 3 years warranty
101. 6
95.25
175x 60x 27 mm
195x 68.5x 33 mm
101.6x 50.8x 29 mm
AC input voltage range ....... 90~264VAC; 127~370VDC
AC inrush current .............. Cold start, 60A at 230VAC
DC adjustment range ......... ±10% rated output voltage
Overload protection ........... 105%~150% hiccup mode, auto-recovery
Over voltage protection ...... 115%~135% rated output voltage
Leakage current ................ Less than 1mA at 240VAC
Setup, rise, hold up time .... 2500ms, 50ms, 20ms at full load and 230VAC
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, O/P-FG: 0.5kVAC
Working temperature .......... -30~+70° C (refer to output derating curve)
Safety standards ............... UL60905-1, TUV EN60950-1 approved
EMC standards .................. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Model No.
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
Output
Tol.
3.3V, 0~15A
±3%
ELP-75-3.3
5V, 0~15A
±2%
ELP-75-5
12V, 0~6.25A
±2%
ELP-75-12
15V, 0~5A
±2%
ELP-75-15
24V, 0~3.15A
±1%
ELP-75-24
36V, 0~2.1A
±1%
ELP-75-36
48V,
0~1.6A
±1%
ELP-75-48
= blank, -C ; blank: PCB type, -C: Enclosed type
ƒ
R&N
Effi.
80mV
80mV
120mV
150mV
240mV
280mV
300mV
80%
82%
89%
90%
90%
90%
90%
AC input voltage range ... 90~264VAC; 127~370VDC
DC adjustment range ...... -2%~+5% rated output voltage
Overload protection ........ 105%~145% hiccup mode, auto-recovery
Over voltage protection ... 115%~135% rated output voltage
Withstand voltage ........... I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature ...... -30~+70°C (refer to output derating curve)
Safety standards ............ UL60950-1, TUV EN60950-1 approved
EMC standards ............... EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection .................... 3+4P / 3.96mm pitch, JST B3P / B4P-VH
Model No.
Output
Tol.
R&N
Effi.
EPP-150-12
12V, 0~12.5A
±2%
130mV
91.5%
EPP-150-15
15V, 0~10.0A
±2%
150mV
92.0%
EPP-150-24
24V, 0~6.25A
±1%
240mV
93.0%
EPP-150-27
27V, 0~5.56A
±1%
240mV
92.0%
EPP-150-48
48V, 0~3.125A
±1%
300mV
92.0%
300W Single Output with PFC Function
•
•
•
•
5"x 3" compact size
Universal AC input / Full range
Built-in active PFC function
No load power consumption <0.5W
by PS-ON control
• High efficiency up to 93%
• Free air convection for 200W and
300W with 20.5 CFM forced air
• Protections:
Short circuit / Overload /
Over voltage / Over temperature
100W Single Output with PFC Function
•
•
•
•
•
•
4"x 2" compact size
Universal AC input / Full range
Built-in active PFC function
No load power consumption <0.5W
High efficiency up to 92.5%
Free air convection for 75W and 100W
with 20 CFM forced air
• Protections:
Short circuit / Overload /
Over voltage / Over temperature
• 12V/0.3A auxiliary output
• LED indicator for power on
• 3 years warranty
101. 6
95.25
AC input voltage range ............ 90~264VAC; 127~370VDC
DC adjustment range ............... ±5% rated output voltage
Overload protection ................. 105%~135% hiccup mode, auto-recovery
Over voltage protection ............ 115%~135% rated output voltage
Withstand voltage .................... I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature ................ -30~+70°C (refer to output derating curve)
Safety standards ..................... UL60950-1, TUV EN60950-1 approved
EMC standards ........................ EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
AC input voltage range ............ 90~264VAC; 127~370VDC
DC adjustment range ............... -2%~+5% rated output voltage
Overload protection ................. 105%~145% hiccup mode, auto-recovery
Over voltage protection ............ 115%~135% rated output voltage
Withstand voltage .................... I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature ................ -30~+70°C (refer to output derating curve)
Safety standards ..................... UL60950-1, TUV EN60950-1 approved
EMC standards ........................ EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Output
12V, 0~8.5A
15V, 0~6.67A
24V, 0~4.2A
27V, 0~3.71A
48V, 0~2.1A
127
117
127x 76.2x 35 mm
101.6x 50.8x 29 mm
Model No.
EPP-100-12
EPP-100-15
EPP-100-24
EPP-100-27
EPP-100-48
• Withstand 300VAC surge input for
5 seconds
• 12V/0.5A auxiliary output
• Standby [email protected]
• Built-in remote sense function
• High power density 14.5W/in 3
• LED indicator for power on
• 3 years warranty
Tol.
±2%
±2%
±1%
±1%
±1%
R&N
120mV
150mV
240mV
240mV
300mV
Effi.
91.0%
91.0%
92.0%
92.5%
92.5%
Model No.
EPP-300-12
EPP-300-15
EPP-300-24
EPP-300-27
EPP-300-48
50
Output
12V, 0~25.0A
15V, 0~20.0A
24V, 0~12.5A
27V, 0~11.12A
48V, 0~6.25A
Tol.
±3%
±3%
±2%
±2%
±2%
R&N
120mV
120mV
150mV
200mV
250mV
Effi.
90.0%
90.0%
92.5%
93.0%
93.0%
Charger
120W Bat t ery C harger
Output Diode of
Charger
Power Factor
Correction Choke
2 Color LED
Indication
Fan Connector
P CB Typ e : 1 4 4 x 9 0 x 3 5 mm
External Case Type: 180x 96x 49 mm
Fast Charging
Circuit (A/B
Selectable)
115 / 230
Selectable
P.C.B. Dimension
Case Drawing
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
AC input range selectable by switch
Passive PFC, PF> 0.65(option)
Protection for deeply discharged battery
Protections: Short circuit / Overload / Over voltage / Over temperature
Charger for lead-acid batteries
Built-in ON/OFF power switch
3 poles AC inlet with fuse holder
Charging type can be selected (option)
2 color LED loading indicator
EN60335 approved
Low cost, high reliability
Open frame models available (without safety approval)
2 years warranty
Charging Curve
General Specification
AC input voltage range ...... 88~132VAC/ 176~264VAC selectable by switch
AC inrush current (max.) .... Cold start, 25A at 115VAC, 50A at 230VAC
Overload protection ........... 90%~110% constant current limiting ,autorecovery
Over voltage protection ..... 108%~127% rated output voltage
Setup, rise, hold up time .... 1000ms, 50ms, 16ms at full load and 230VAC
Withstand voltage ............. I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC,
O/P-FG: 0.5kVAC, 1 minute
Working temperature ......... -10~+45°C, derating curve may vary for
different models
Safety standards ............... UL60950-1, TUV EN60950-1, EN60335-1,
EN60335-2-29(except for 55.2V) approved
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,5,6,8,11,
EN61000-3-2,3
DC output cable ............... 6 ft. of SPT-2, 18AWGx2C
Standard output connector ... MIC 3P, male type(standard type)
Packing ............................ 1.1kg ; 16pcs / 17.9kg / 1.47CUFT (without PFC)
1.24kg ; 16pcs / 20.1kg / 1.47CUFT (with PFC)
Model No.
P Ƒ -120 Ƒ -13 Ƒ
P Ƒ -120 Ƒ -27 Ƒ
P Ƒ -120 Ƒ -54 Ƒ
Output
13.8V, 0~7.2A
27.6V, 0~4.3A
55.2V, 0~2.2A
Tol.
±3~±8.5%
±1~±8.0%
±1~±7.5%
R&N
150mV
200mV
250mV
Order Information
Effi.
73%
79%
79%
51
Charger
108~300W Power Supply or B at t ery C harger
108W Desktop Power Supply or Charger
CASE: 909
150x 140x 75 mm
230W Single Output Battery Charger
• 3 stage charging
• AC input range selectable by switch
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• 3 color LED loading indicator
• Battery under / over voltage and
polarity protection (ESC only)
• Cooling by free air convection
• Fixed switching frequency at 25kHz
• 2 years warranty
• Protections:
Short circuit / Over voltage /
Over temperature
• 2 color LED loading indicator
190x 96x 49 mm
Model No.
Output
Tol.
R&N
13.5V, 0~8A
±2%
120mV
81%
ESC-120-27
27V, 0~4A
±1%
150mV
83%
ESC-120-54
54V, 0~2A
±1%
400mV
84%
Model No.
Output
ESP-120-13.5
Tol.
R&N
• 2 years warranty
AC input voltage range ..... 90~264VAC; 127~370VDC
AC inrush current (max.) .. Cold start, 50A at 230VAC
Over voltage protection .... 102%~125% shut off, re-power on to recover
Withstand voltage ............ I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, O/P-FG:0.5kVAC
Working temperature ........ -20~+50° C (refer to output derating curve)
Safety standards ............. UL1012(PB-230xx-AD1 only), EN60950-1 approved
EMC standards ................ EN55022 class B, EN61000-4-2,3,4,5,6,8,11,
EN61000-3-2,3
Packing .......................... 1.21Kg ; 12pcs / 15.5kg / 1.29CUFT
Effi.
Model No.
13.5V, 0~8A
±2%
120mV
81%
27V, 0~4A
±1%
150mV
83%
ESP-120-54
54V, 0~2A
±1%
400mV
84%
PB-230-24 Ƒ
PB-230-48 Ƒ
150x 140x 75 mm
Tol.
±2%
±1%
±1%
R&N
120mV
150mV
400mV
Effi.
81%
84%
85%
Model No.
ESP-240-13.5
ESP-240-27
ESP-240-54
Output
13.5V, 0~16A
27V, 0~8A
54V, 0~4A
Tol.
±2%
±1%
±1%
R&N
120mV
150mV
400mV
Effi.
81%
84%
85%
28.8V, 0~8A
85.5%
57.6V, 0~4A
86.0%
(except for 48V) (P type only)
• Optimal 3 stage charging characteristic
• AC input range selectable by switch
• Passive PFC compliance to
EN61000-3-2 class A (option)
• Protections:
CASE: 801B
AC input voltage range ..... 88~132VAC / 176~264VAC selectable by switch
AC inrush current ............. Cold start, 40A at 230VAC
DC adjustment range ........ 13.5V: 12~15V, 27V: 24~30V, 54V: 48~56V
Overload protection .......... 105%~135% fold back current limiting, autorecovery
Over voltage protection .... 115%~135% rated output voltage
Setup, rise, hold up time ... 200ms, 100ms, 30ms at full load and 230VAC
Withstand voltage ............ I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ........ -10~+60°C (refer to output derating curve)
Safety standards .............. CSA 61010-1 approved
EMC standards ................ EN55022 class B, EN61000-3-2,3
EN61000-4-2,3,4
Packing ........................... 1.5kg ; 8pcs / 13.0kg / 1.1CUFT
Output
13.5V, 0~16A
27V, 0~8A
54V, 0~4A
81.5%
300W Single Output Battery Charger
• AC input range selectable by switch
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• 3 color LED loading indicator
• Battery under / over voltage and
polarity protection (ESC only)
• Built-in DC fan with fan ON/OFF auto
control at 50 OC
• Fixed switching frequency at 25kHz
• 2 years warranty
Model No.
ESC-240-13.5
ESC-240-27
ESC-240-54
Effi.
14.4V, 0~16A
Ƒ = Blank, AD1; Blank= 4 pin power din, AD1= Anderson connector
216W Desktop Power Supply or Charger
CASE: 909
Output
PB-230-12 Ƒ
Effi.
ESP-120-27
• Built-in remote ON-OFF control
• Fan ON/OFF control
• Low cost, high realiability
AC input voltage range ..... 88~132VAC / 176~264VAC selectable by switch
AC inrush current ............. Cold start, 40A at 230VAC
DC adjustment range ........ 13.5V: 12~15V, 27V: 24~30V, 54V: 48~56V
Overload protection .......... 105%~135% fold back current limiting, auto-recovery
Over voltage protection ..... 115%~135% rated output voltage
Setup, rise, hold up time ... 200ms, 100ms, 36ms at full load and 230VAC
Withstand voltage ............ I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ........ -10~+60°C (refer to output derating curve)
Safety standards .............. CSA 61010-1 approved
EMC standards ................. EN55022 class B, EN61000-3-2,3
EN61000-4-2,3,4
Packing ........................... 1.38kg ; 8pcs / 12.0kg / 1.1CUFT
ESC-120-13.5
• Universal AC input / Full range
• Built-in active PFC function
(PB-230-xxAD1)
253x 135x 48.5 mm
•
•
•
•
•
•
•
Reverse polarity / Short circuit /
Over voltage / Over temperature
Charger for lead-acid batteries
Built-in ON/OFF power switch
3 poles AC inlet (IEC 320-C14)
2 color LED loading indicator
Built-in remote ON/OFF control
Cooling by free air convection
3 years warranty
AC input voltage range ..... 90~132VAC / 180~264VAC selectable by switch
AC inrush current (max.) .. Cold start, 60A at 230VAC
Over voltage protection ..... 108%~125% rated output voltage
Withstand voltage ............ I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ........ -10~+50°C (refer to output derating curve)
Safety standards ............. IEC60335-2-29 CB approval by TUV
(except for 48V), UL60950-1 approved
EMC standards ................ EN55022 class B, EN61000-4-2,3,4,5,6,8,11,
EN61000-3-2,3 (P type)
Packing ........................... 1.45kg ; 6pcs / 9.7kg / 0.95CUFT
Model No.
PB-300 Ƒ -12
Output (20 min.) / (Continuous at 25 oC)
12.5A
85%
PB-300 Ƒ -24
28.8V, 10.50A /
6.25A
86%
PB-300 Ƒ -48
57.6V, 5.3A
3.20A
88%
Ƒ = P: with PFC; N: non PFC
52
Effi.
14.4V, 20.85A /
/
Charger
3 60~1 000W Bat t ery C harger
360W Single Output Battery Charger
(P type only)
(except for 48V) (P type only)
CASE: 801A
253x 135x 48.5 mm
1000W Single Output Battery Charger
• Optimal 3 stage charging characteristic
• AC input range selectable by switch
• Passive PFC compliance to
EN61000-3-2 class A (option)
• Protections:
Reverse polarity / Short circuit /
Over voltage / Over temperature
• Charger for lead-acid batteries
• Built-in ON/OFF power switch
• 3 poles AC inlet (IEC 320-C14)
• 2 color LED loading indicator
• Built-in remote ON/OFF control
• Cooling by built-in DC fan
• 3 years warranty
• 2/3/8 stage smart charger for lead-acid
batteries
• Microprocessor controlled power
management
• Universal AC input / Full range
• Built-in active PFC function
• Protections:
Reverse polarity / Short circuit /
Over voltage / Over temperature
• Built-in temp. compensation function
• Can be connected to 2 battery banks
• Status signal sent by relay contacts
• 3 color LED loading indicator
• Built-in remote ON/OFF control
• Fan speed control
• Charging curve can be modified for
different battery applications (optional)
• 3 years warranty
300x 184x 70 mm
CASE: 804B
AC input voltage range ..... 90~132VAC / 180~264VAC selectable by switch
AC inrush current (max.) .. Cold start, 60A at 230VAC
Over voltage protection .... 108%~125% rated output voltage
AC input voltage range ....... 90~264VAC ; 127~370VDC
AC inrush current (max.) .... Cold start, 50A at 230VAC
Over voltage protection ...... 110%~125% shut off, re-power on to recover
Withstand voltage .............. I/P-O/P: 3kVAC, I/P-FG: 2kVAC, 1 minute
Working temperature .......... -20~+60° C (refer to output derating curve)
Safety standards ............... UL60950-1, TUV EN60950-1 approved
EMC standards .................. EN55022 class B conducted,
EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3
Connection ........................ IEC inlet for input; copper pillars for output
Packing ............................. 3.5kg ; 4pcs / 15kg / 1.83CUFT
Withstand voltage ............ I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ........ -20~+60°C (refer to output derating curve)
Safety standards ............. IEC60335-2-29 CB approval by TUV
(except for 48V), UL60950-1 approved
EMC standards ................ EN55022 class B, EN61000-4-2,3,4,5,6,8,11,
EN61000-3-2,3 (P type)
Packing .......................... 1.5kg ; 6pcs / 10kg / 0.95CUFT
Model No.
Output
14.4V, 24.3A
PB-360 Ƒ -12
28.8V, 12.5A
PB-360 Ƒ -24
57.6V, 6.25A
PB-360 Ƒ -48
Ƒ = P: with PFC; N: non PFC
Effi.
85%
86%
87%
Model No.
PB-1000-12
PB-1000-24
PB-1000-48
230x 158x 67 mm
2-Stage Charging Curve
• 2/3/8 stage smart charger for
lead-acid batteries
• Microprocessor controlled power
management
• Universal AC input / Full range
• Built-in active PFC function
• Protections:
Reverse polarity / Short circuit /
Over voltage / Over temperature
• Built-in temp. compensation function
• Status signal sent by relay contacts
• 3 color LED loading indicator
• Built-in remote ON-OFF control
• Fan speed control (depend on
charging current)
• Charging curve can be modified for
different battery applications (optional)
• 3 years warranty
Star t
Output
14.4V, 0~40.0A
28.8V, 0~21.0A
57.6V, 0~10.5A
V boos t
Charge Voltage
100%
10%
Charge Current
Color of LED
Stage 1
Stagel 2
Constant Current
Constant Voltage
Orange
Battery Full
Green
3-Stage Charging Curve
AC input voltage range ..... 90~264VAC; 127~370VDC
AC inrush current (max.) .. Cold start, 50A at 230VAC
Over voltage protection .... 112%~125% shut off, re-power on to recover
Withstand voltage ............ I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature ........ -20~+60° C (refer to output derating curve)
Safety standards ............. TUV EN60335-1, EN60335-2-29(except for 48V),
EN60950-1(48V only), UL1012 approved
EMC standards ................. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection ...................... IEC inlet for input; copper pillars for output
Model No.
PB-600-12
PB-600-24
PB-600-48
Effi.
85%
88%
89%
Built-in Charging Curves for PB-600 and PB-1000
600W Single Output Battery Charger
CASE: 805C
Output
14.4V, 60.0A
28.8V, 34.7A
57.6V, 17.4A
8-Stage Charging Curve
Effi.
86%
87%
89%
53
Green Charger
30~326W Portable Battery Charger
30W Green Adaptor with Charging Function
•
•
•
•
Universal AC input / Full range
Class II power (without earth pin)
No load power consumption < 1W
Constant current and voltage
(CC, CV mode)
• High reliability
160W Green Adaptor with Charging Function
• Suitable for high surge current
equipment
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• 2 color LED indicator for charging status
• Fully enclosed plastic case
• 2 years warranty
•
•
•
•
•
•
•
•
•
(GC160Axx-AD1)
175x 72x 35 mm
GC30U
GC30B
108x 67x 36 mm
AC input voltage range .... 85~264VAC; 120~370VDC
Overload protection ......... 90%~110% constant current, auto-recovery
Over voltage protection .... 105%~135% rated output voltage, re-power on to recover
Withstand voltage ............ I/P-O/P: 3kVAC
Working temperature ........ -30~+70° C (refer to derating curve)
Safety standards ............. UL1012(GC160Axx-AD1 only), EN60950-1 approved
EMC standards ................ EN55022 class B, FCC part 15 class B,
EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Length of output cable ..... 120cm of UL2464, 18AWGx 4C
Standard DC plug ............ Power DIN 4P with lock type (R7B)
GC30E
108x 67x 36 mm
108x 67x 36 mm
AC input voltage range ......... 90~264VAC; 127~370VDC
Overload protection .............. 90%~110% constant current mode and over
300% pulsing mode
Over voltage protection ........ 110%~135% rated output voltage
Withstand voltage ................ I/P-O/P: 3kVAC, 1minute
Working temperature ............ 0~+50°C (refer to output derating curve)
Safety standards .................. UL60950-1, CSA 22.2, TUV EN60950-1 approved
EMC standards .................... EN55014-1, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,11
Length of output cable .......... 120cm of UL1185, 16AWG for 4.2~8.4V
180cm of UL1185, 18AWG for 14.3~28.6V
Standard DC plug ................ P1J: 2.1øx5.5øx11mm / C+, tuning fork type
Output
4.2V, 0~4.00A
5.6V, 0~3.99A
7.2V, 0~3.00A
8.4V, 0~3.00A
14.3V, 0~2.09A
16.8V, 0~1.60A
28.6V, 0~1.04A
Order No.
ƒ-0P1J
ƒ-1P1J
ƒ-11P1J
ƒ-2P1J
ƒ-4P1J
ƒ-5P1J
ƒ-6P1J
GC30
GC30
GC30
GC30
GC30
GC30
GC30
= B,
ƒ
R&N
50mV
50mV
80mV
80mV
100mV
100mV
150mV
Model No.
Output
Effi.
13.6V, 10.0A
89.0%
GC160A1227.2V, 5.89A
92.5%
GC160A2454.4V,
2.95A
94.0%
GC160A48= R7B, AD1 ; R7B= 4 pin power din, AD1= Anderson connector
ƒ
ƒ
ƒ
ƒ
Effi.
55%
70%
74%
76%
78%
78%
80%
218W & 326W Green Adaptor with Charging Function
(GC330) (GC220Axx-AD1)
U, E; B: IEC320-C8, U: US type plug, E: European type plug
120W Green Adaptor with Charging Function
•
•
•
•
•
•
•
•
•
(GC120Axx-AD1)
167x 67x 35 mm
Universal AC input / Full range
Built-in active PFC function
No load power consumption < 0.5W
High efficiency up to 91%
2 stage charging characteristic
Cooling by free air convection
3 pole AC inlet IEC320-C14
Class I power (with earth pin)
Protections: Short circuit / Overload /
Over voltage / Over temp.
• Fully enclosed plastic case
• 2 color LED indicator for charging status
• 2 years warranty
Case (mm)
ƒ
GC120A24- ƒ
GC120A48- ƒ
ƒ = R7B, AD1 ;
GC120A12-
Output
13.6V, 7.5A
Effi.
86.5%
27.2V, 4.42A
90.0%
54.4V, 2.21A
91.0%
GC220
GC330
210x85x46
220x95x46
Connector
•
•
•
•
•
•
•
•
•
Universal AC input / Full range
Built-in active PFC function
No load power consumption < 1W
High efficiency up to 93.5%
2 stage charging characteristic
Cooling by free air convection
3 pole AC inlet IEC320-C14
Class I power (with earth pin)
Protections:
Short circuit / Overload / Over voltage /
Over temperature
• Fully enclosed plastic case
• 2 color LED indicator for charging status
• 2 years warranty
AC input voltage range ....... 90~264VAC; 127~370VDC
Overload protection ............ 90%~110% constant current, auto-recovery
Over voltage protection ...... 105%~135% rated output voltage, re-power on to recover
Withstand voltage .............. I/P-O/P: 3kVAC
Working temperature .......... -30~+60° C (refer to output derating curve)
Safety standards .... GC220: TUV EN60950-1, UL1012 (GC220Axx-AD1 only) approved
GC330: TUV EN60950-1, UL60950-1 approved
EMC standards .................. EN55022 class B, FCC part 15 class B,
EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Length of output cable ........ 100cm of UL2464, 16AWGx 4C
Standard DC plug ... GC220: Power DIN 4P with lock type (R7B)
GC330: 4P/6.35mm pitch, AMP 1-480702-0 (power supply side);
AMP 1-480703-0 (customer side)
GC220 Series
AC input voltage range ......... 85~264VAC; 120~370VDC
Overload protection .............. 90~110% constant current, auto-recovery
Over voltage protection ........ 105%~135% shut down O/P voltage, re-power
on to recover
Withstand voltage ................ I/P-O/P: 3kVAC
Working temperature ............ -30~+70°C (refer to derating curve)
Safety standards .................. UL1012 (GC120Axx-AD1 only), EN60950-1
approved
EMC standards .................... EN55022 class B, FCC part 15 class B,
EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Length of output cable .......... 120cm of UL2464, 18AWGx 4C
Standard DC plug ................ Power DIN 4P with lock type (R7B)
Model No.
Universal AC input / Full range
Built-in active PFC function
No load power consumption < 1W
High efficiency up to 94%
2 stage charging characteristic
Cooling by free air convection
3 pole AC inlet IEC320-C14
Class I power (with earth pin)
Protections: Short circuit / Overload /
Over voltage / Over temp.
• Fully enclosed plastic case
• 2 color LED indicator for charging status
• 2 years warranty
Model No.
GC220A12 - Ƒ
GC220A24- Ƒ
GC220A48- Ƒ
ƒ = R7B, AD1 ;
GC330 Series
Model No.
GC330A36-C4P
GC330A48-C4P
R7B= 4 pin power din, AD1= Anderson connector
54
Output
Effi.
13.6V, 13.5A
89.0%
27.2V, 8A
92.5%
54.4V, 4A
93.0%
R7B= 4 pin power din, AD1= Anderson connector
Output
40.8V, 8A
54.4V, 6A
Effi.
93.5%
93.5%
Industrial Adaptor
12~24W Single Output and Interchangeable Type
Features
• Interchangeable AC plugs (plug kit sold seperately)
• Universal AC input / Full range
• No load power consumption <0.3W
• ErP step 2 compliant (Level V)
• Meet EISA 2007 (Energy Independence and Security Act)
• Class I I p o w e r ( w i t h o u t e a r t h p i n )
• Protections: Short circuit / Over voltage / Overload
• Fully enclosed plastic case
• LED indicator for power on
• Pass LPS
• Approvals:
UL / CUL / TUV / CCC / RCM / CB / FCC / CE
Ź GE12 70.7x 40x 38.8 mm
• 2 years warranty
Ź GE18/24 81x 43x 40.5 mm
General Specification (Please refer to www.meanwell.com for detail spec.)
AC in p u t v o l t a g e ra n g e
9 0 ~2 6 4 VAC / 0 . 4 A f o r GE1 2 ; 90 ~ 2 6 4 VA C / 0 . 7 A f o r G E 1 8 / 2 4
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 4 0 A a t 1 0 0 VAC; 8 0A a t 2 3 0 VA C
Over load p ro t e c t i o n
Hiccup mode, auto-recovery
Over vo l t a g e p ro t e c t i o n
115%~135% rated output voltage
S etu p , r i s e , h o l d u p t i me
4000ms, 100ms, 30ms at 230VAC input
W ithstan d v o l t a g e
I / P-O/ P: 4 2 4 2 VDC, 1 m i n u t e
W o r kin g t e mp e ra t u re
-1 0 ~+5 0 °C (re f e r t o o u t p u t d e r a t in g cu r ve )
S afety st a n d a rd s
UL 6 0 9 5 0 -1 , CSA2 2 . 2 , EN6 0 9 50 - 1 , G B 4 9 4 3 , A S / N ZS 6 0 9 5 0 . 1 a p p r o ve d
E MC stand a rd s
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 - 2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, FC C p a r t 1 5 cla ss B , G B 9 2 5 4
L ength o f o u t p u t c a b l e
150cm of AW M2468, 20AWG for GE12; 150cm of AW M2468, 18AWG for GE18/24
S tan d ar d D C p l u g
P1J: 2.1øx5.5øx11mm / C+, tuning fork type (refer to page 60 for DC plug list)
W a ll-mounte d (Inte rc ha nge a ble Ty pe )— 2 4 W
Wa ll- m o u n ted ( In t er changeabl e Type) —12W
Order No.
(Main body)
Output
Tol.
R&N
Effi.
Order No.
(Main body)
Output
Tol.
R&N
GE12I05-P1J
5V, 0~2.00A
±5%
50mV
74%
GE24I05-P1J
5V, 0~3.00A
±5%
50mV
76.5%
GE12I07-P1J
7.5V, 0~1.33A
±5%
75mV
77%
GE24I07-P1J
7.5V, 0~2.00A
±5%
75mV
79.5%
GE24I09-P1J
9V, 0~2.22A
±5%
100mV
81.5%
GE24I12-P1J
12V, 0~2.00A
±3%
120mV
82.5%
GE24I15-P1J
15V, 0~1.60A
±3%
150mV
84.0%
GE24I18-P1J
18V, 0~1.33A
±3%
180mV
84.0%
GE24I24-P1J
24V, 0~1.00A
±3%
240mV
85.0%
GE24I48-P1J
48V, 0~0.50A
±3%
300mV
85.0%
GE12I09-P1J
9V, 0~1.33A
±5%
100mV
79%
GE12I12-P1J
12V, 0~1.00A
±3%
120mV
81%
GE12I15-P1J
15V, 0~0.80A
±3%
150mV
82%
GE12I18-P1J
18V, 0~0.83A
±3%
180mV
83%
GE12I24-P1J
24V, 0~0.625A
±3%
240mV
83%
ź
źInterchangeable
Wa ll- m o u n t ed (Int er changeabl e Type) —18W
Order No.
(Main body)
Output
Tol.
R&N
Effi.
GE18I05-P1J
5V, 0~2.40A
±5%
50mV
75%
GE18I07-P1J
7.5V, 0~1.73A
±5%
75mV
79%
GE18I09-P1J
9V, 0~2.00A
±5%
100mV
81%
GE18I12-P1J
12V, 0~1.50A
±3%
120mV
82%
GE18I15-P1J
15V, 0~1.20A
±3%
150mV
84%
GE18I18-P1J
18V, 0~1.00A
±3%
180mV
84%
GE18I24-P1J
24V, 0~0.75A
±3%
240mV
85%
GE18I48-P1J
48V, 0~0.375A
±3%
300mV
85%
Effi.
AC Inlet Plug
AC Plug Type
AC Plug Order No.
Australian Type
U.K. Type
AC Plug-AU
AC Plug-UK
AC Plug Type
AC Plug Order No.
European Type
U.S. Type
AC Plug-EU
AC Plug-US
Note: Main body unit and AC plug should be ordered seperately; The main body
needs to be used along with any of the AC plug.
55
Industrial Adaptor
5~15W Single Output
6W Green Power Adaptor
•
•
•
•
Universal AC input / Full range
No load power consumption < 0.3W
ErP step 2 compliant (Level V)
Meet EISA 2007 (Energy
Independence and Security Act)
• 2 pole US / European type plug
• Class II power (without earth pin)
GS06U
5W Green USB Adaptor
• Protections: Short circuit / Overload /
Over voltage
• Pass LPS
• Fully enclosed plastic case
• Approvals:
UL / CUL / CB/ F CC/ CE f o r G S 0 6 U
TUV/ CB/ FCC/ CE f o r GS06 E
• 2 years warranty
• Universal AC input / Full range
• No load power consumption < 0.3W
• GS05U-USB: Meet EISA 2007(Energy
Independence and
GS05U-USB
Security Act)
41.86x 32.76x 23.8 mm
GS05E-USB: ErP step 2 compliant
• Compact size
• 2 pole US / European type plug
• Class II power (without earth pin)
• Protections: Short circuit / Overload
Over voltage / Over temp.
• Pass LPS
GS05E-USB
• Fully enclosed plastic case
41.54x 30.5x 20 mm
• 2 years warranty
AC input voltage range ...... 90~264VAC ; 127~370VDC
Overload protection ........... 105%~135% rated output power, hiccup mode,
auto-recovery
Over voltage protection ..... 105%~200% rated output voltage, hiccup mode,
auto-recovery
Withstand voltage ............. I/P-O/P: 4242VDC, 1 minute
Working temperature ......... -20~+50° C (refer to output derating curve)
Safety standards ............... U Type: UL60950-1, CSA22.2 approved
E Type: TUV EN60950-1 approved
EMC standards ................. FCC part15 class B(U Type); EN55022 class B(E Type)
Standard DC plug .............. USB Type A
GS06E
32x 66x 42.5 mm
32x 66x 42.5 mm
AC input voltage range .... 90~264VAC ; 127~370VDC
AC inrush current(max.) .. Cold start, 50A at 230VAC
Overload protection ........ Hiccup mode, auto-recovery
Over voltage protection ... Clamp by zener diode >120%
Withstand voltage ........... I/P-O/P: 4242VDC, 1minute
Working temperature ....... 0~+50°C (refer to output derating curve)
Safety standards ............. UL60950-1, CSA 22.2, TUV EN60950-1
EMC standards .... EN55022, EN61000-3-2,3, EN61000-4-2,3,4,5,6,11, FCC part 15 class B
Length of output cable ..... 180cm of UL1185, 20AWG
Order No.
Ou t p u t
5V, 0~1.00A
GS06 -1P1J
7.5V, 0~0.80A
GS06 -11P1J
GS06 -2P1J
9V, 0~0.66A
12V, 0~0.50A
GS06 -3P1J
15V, 0~0.40A
GS06 -4P1J
GS06 -5P1J
18V, 0~0.33A
24V, 0~0.25A
GS06 -6P1J
GS06 -8P1J
48V, 0~0.125A
= U : A m e r ic a n 2 P ; E : Eu ro p e a n 2 P
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
Tol.
±5%
±5%
±5%
±3%
±3%
±3%
±2%
±2%
R&N
50mV
80mV
80mV
100mV
120mV
150mV
180mV
200mV
Order No.
GS05U-USB
GS05E-USB
Effi.
68%
74%
75%
77%
78%
78%
82%
84%
Universal AC input / Full range
No load power consumption < 0.3W
ErP step 2 compliant (Level V)
Meet EISA 2007 (Energy
Independence and Safety Act)
• 2 pole US / European type plug
• Class II power (without earth pin)
GS12U
65x 47x 26.5 mm
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
GS15A
100x 58.5x 32.8 mm
GS15B
100x 58.5x 32.8 mm
GS15U
34x 71x 50 mm
GS15E
34x 71x 50 mm
AC input voltage range ..... 90~264VAC ; 127~370VDC
AC inrush current(max.) .... Cold start, 50A at 230VAC
Overload protection ........... Hiccup mode, auto-recovery
Over voltage protection ..... Clamp by zener diode > 120%
Withstand voltage ............. I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ......... 0~+50°C (refer to output derating curve)
Safety standards .............. UL60950-1, CSA 22.2, TUV EN60950-1 approved
EMC standards ................. EN55022-B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,11,FCC part 15 class B
Length of output cable ....... 180cm of UL1185, 18AWG
Standard DC plug .............. P1J: 2.1øx5.5øx11mm / C+, tuning fork type
(refer to page 60 for DC plug list)
65x 47x 26.5 mm
AC input voltage range .... 90~264VAC ; 127~370VDC
AC inrush current(max.) .. Cold start, 45A at 230VAC
Overload protection ......... Hiccup mode, auto-recovery
Over voltage protection ... 115%~135% clamp by zener diode
Withstand voltage ........... I/P-O/P: 3kVAC, 1minute
Working temperature ....... 0~+50°C (refer to output derating curve)
Safety standards ............. UL60950-1, CSA 22.2, BSMI CNS14336, TUV EN60950-1
EMC standards ............... EN55022, EN61204-3, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11, FCC part15 class B
R&N
75mV
90mV
90mV
120mV
150mV
180mV
200mV
Effi.
69%
71%
15W Green Power Adaptor
GS12E
T ol .
±5%
±4%
±4%
±3%
±3%
±3%
±3%
R&N
90mV
80mV
Universal AC input / Full range
• Protections:
No load power consumption < 0.3W
Short circuit / Overload /
Over voltage
ErP step 2 compliant (Level V)
• Fully enclosed plastic case
Meet EISA 2007 (Energy
• Approvals:
Independence and Security Act)
UL/CUL/TUV/CB/FCC/CE for GS15A/B
• Pass LPS
TUV/CB/FCC/CE for GS15E
UL/CUL/CB/FCC/CE for GS15U
• 2 years warranty
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• Pass LPS
• Fully enclosed plastic case
• Approvals:
UL/CUL/BSMI/CB/FCC for GS12U
TUV/CB/CE for GS12E
• 2 years warranty
Or der N o .
Output
GS 12 0 5 - P 1I
5V, 0~2.00A
GS 12 0 7 - P 1I
7.5V, 0~1.60A
GS 12 0 9 - P 1I
9V, 0~1.33A
GS 12 1 2 - P 1I
12V, 0~1.00A
GS 12 1 5 - P 1I
15V, 0~0.80A
GS 12 1 8 - P 1I
18V, 0~0.67A
GS 12 2 4 - P 1I
24V, 0~0.50A
= U: A m e r ic a n 2 P ; E : Eu ro p e a n 2 P
Tol.
±4%
±4%
•
•
•
•
12W Green Power Adaptor
•
•
•
•
Output
5V, 0~1A
5V, 0~1A
Order No.
Ou t p u t
5.0V, 0~2.40A
GS15 -1P1J
7.5V, 0~1.60A
GS15 -11P1J
GS15 -2P1J
9.0V, 0~1.66A
12V, 0~1.25A
GS15 -3P1J
15V, 0~1.00A
GS15 -4P1J
GS15 -5P1J
18V, 0~0.83A
24V, 0~0.62A
GS15 -6P1J
GS15 -8P1J
48V, 0~0.31A
= A:IEC320-C14 ; B: IEC320-C8
E : E u r o p e a n 2 P ; U : A m e r ica n 2 P
Effi.
76.0%
78.5%
78.5%
78.5%
80.0%
80.0%
80.5%
ƒ
56
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
Tol.
±5%
±5%
±5%
±3%
±3%
±3%
±2%
±2%
R&N
50mV
80mV
80mV
80mV
100mV
120mV
150mV
240mV
Effi.
75%
78%
80%
80%
80%
81%
83%
85%
Industrial Adaptor
18~36W Single Output
GS18/25A
GS18/25B
GS18/25/36U
GS18/25/36E
93x 54x 36 mm
79x 54x 33 mm
79x 54x 33 mm
79x 54x 33 mm
Features
Universal AC input / Full range
No load power consumption < 0.3W
ErP step 2 compliant (Level V)
Meet EISA 2007 (Energy Independence and Security Act)
NR Ca n compl i ant f or A / U t y pe
2 p o l e USA / EU R O pl ug or I E C320- C14/ C8
Class II pow er (w i thout ear t h pin) f or B / E / U t y pe
Class I pow er (w i t h ear t h pin) only f or A t y pe
• Protections: Short circuit / Overload / Over voltage
Fully enclosed plastic case
L E D i n d i c a t o r f o r p o w e r o n ( e x c e p t f o r GS 3 6 )
Pass LPS
Approvals:
A type: UL / CUL / TUV / BSMI / CCC / PSE / CB / FCC / CE
B type: UL / CUL / TUV / BSMI / CCC / CB / FCC / CE
U type: UL / CUL / BSMI / CB / FCC
E type: TUV / CB / CE
• 2 years warranty
•
•
•
•
•
•
•
•
•
•
•
General Specification (Please refer to www.meanwell.com for detail spec.)
Or der N o .
GS1 8
GS 2 5
A C in p u t v o l t a g e ra n g e
AC in r us h c u rre n t ( ma x . )
9 0 ~2 6 4 VAC / 0 . 5 A
Co l d s t a rt , 4 5 A a t 2 3 0 VAC
9 0 ~ 2 6 4 VA C / 0 . 7 A
GS 3 6
C o ld st a r t , 6 0 A a t 2 3 0 VA C
110%~250% rated output voltage,
hiccup mode, auto-recovery
Over load p ro t e c t i o n
105%~150% rated output voltage, hiccup mode, auto-recovery
Over vo l t a g e p ro t e c t i o n
W ithstan d v o l t a g e
W o r kin g t e mp e ra t u re
105%~135% rated output voltage, clamp by zener diode
I / P-O/ P: 4 2 4 2 VDC, 1 m i n u t e
0 ~+5 0 °C (re f e r t o o u t p u t d e ra tin g cu r ve )
- 2 0 ~ + 5 0 °C ( r e f e r t o o u t p u t d e r a t in g c u r v e )
A t y p e : UL 6 0 9 5 0 -1 , CSA 2 2 . 2 , TU V E N 6 0 9 5 0 - 1 , B S M I C N S 1 4 3 3 6 , P S E J6 0 9 5 0 - 1 ( G S 1 8 A / G S 2 5 A - 5 V ~ 2 8 V o n l y ),
CCC GB4 9 4 3 approved
B type: UL 6 0 9 5 0 -1 , CSA 2 2 . 2 , TU V E N 6 0 9 5 0 - 1 , B S M I C N S 1 4 3 3 6 , C C C G B 4 9 4 3 a p p r o ve d
U t y p e : UL 6 0 9 5 0 , CSA2 2 . 2 , BSM I C N S 1 4 3 3 6 a p p r o ve d
E t y p e : TUV EN6 0 9 5 0 -1 a p p ro ve d
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 -2, 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11( A / B / E t yp e ) , FC C p a r t 1 5 cla ss B ( A / B / U t y p e ) ,
CNS1 3 4 3 8 (A/ B/ U t y p e ), GB9 2 5 4 ( A / B t yp e )
S afety st a n d a rd s
E MC stand a rd s
L ength o f o u t p u t c a b l e
S tan d ar d D C p l u g
120cm of 16AWG for 5~12V ;
1 0 0 cm o f U L 11 8 5 , 1 6 AW G
180cm of UL1185, 18AWG for 15~48V
P1 J : 2 . 1 øx 5 . 5 ø x 11 m m / C+, t u n in g f o r k t yp e ( r e f e r t o p a g e 6 0 f o r D C p lu g list )
Desktop / Wall-mounted — 18W
Order No.
GS18
GS18
GS18
GS18
GS18
GS18
Ƒ05-P1J
Ƒ07-P1J
Ƒ09-P1J
Ƒ12-P1J
Ƒ15-P1J
Ƒ18-P1J
Output
5V, 0~3.00A
7.5V, 0~2.00A
9V, 0~2.00A
12V, 0~1.50A
15V, 0~1.20A
18V, 0~1.00A
Tol.
±5%
±5%
±5%
±3%
±3%
±3%
TU V
Rh ei nl an d
Prod uct Sa fe ty
R&N
50mV
80mV
80mV
80mV
100mV
150mV
Order No.
Effi.
79.5%
82.0%
83.0%
85.0%
85.0%
85.0%
Ƒ24-P1J
GS18 Ƒ28-P1J
GS18 Ƒ48-P1J
Ƒ =A / B / U / E
GS18
Output
24V, 0~0.75A
Order No.
Ƒ05-P1J
Ƒ07-P1J
Ƒ09-P1J
Ƒ12-P1J
Ƒ15-P1J
Ƒ18-P1J
Output
5V, 0~4.00A
7.5V, 0~2.93A
9V, 0~2.77A
12V, 0~2.08A
15V, 0~1.66A
18V, 0~1.38A
Tol.
±2%
R&N
50mV
80mV
80mV
80mV
100mV
150mV
Effi.
78.5%
81.5%
82.5%
84.5%
84.5%
84.5%
Tol.
±5%
±5%
±3%
R&N
90mV
90mV
100mV
Effi.
76.5%
81.5%
84.5%
Effi.
86.0%
28V, 0~0.64A
±2%
240mV
86.5%
±2%
240mV
87.0%
Class I — A: IEC320-C14
Class II — B: IEC320-C8, U: American 2P, E: European 2P
TU V
Rh ei nl an d
Prod uct Sa fe ty
Tol.
±5%
±5%
±5%
±3%
±3%
±3%
R&N
180mV
48V, 0~0.375A
Desktop / Wall-mounted — 25W
GS25
GS25
GS25
GS25
GS25
GS25
PS
E
Order No.
Ƒ24-P1J
GS25 Ƒ28-P1J
GS25 Ƒ48-P1J
Ƒ =A / B / U / E
GS25
Output
24V, 0~1.04A
PS
E
Tol.
±2%
R&N
180mV
Effi.
85.5%
28V, 0~0.89A
±2%
240mV
85.5%
48V, 0~0.52A
±2%
240mV
87.0%
Class I — A: IEC320-C14
Class II — B: IEC320-C8, U: American 2P, E: European 2P
Wall-mounted — 36W
Order No.
GS36
GS36
GS36
Ƒ05-P1J
Ƒ09-P1J
Ƒ12-P1J
Output
5V, 0~4.50A
9V, 0~3.50A
12V, 0~3.00A
Order No.
Output
24V, 0~1.50A
GS36 24-P1J
48V, 0~0.75A
GS36 48-P1J
= U / E ; U: American 2P, E: European
Ƒ
57
Ƒ
Ƒ
Tol.
±2%
±2%
2P
R&N
180mV
240mV
Effi.
85.5%
87.5%
Industrial Adaptor
40~120W Single Output
Features
GS40 / GS60
GS90
GS120
125x 50x 31.5 mm
145x 60x 32 mm
167x 67x 35 mm
• Universal AC input / Full range
• No load power consumption <0.3W for GS40/60;
< 0 . 5 W f o r GS 9 0 / 1 2 0
• ErP step 2 compliant (Level V)
• Meet EISA 2007 (Energy Independence and
Security Act)
• NRCan compliant
• MEPS compliant
• Built-in active PFC function for GS90/120
• 3 pole AC inlet IEC320-C14
• Class I p o w e r ( w i t h e a r t h p i n )
• P rotections: Short circuit / Over voltage / Overload /
Over temp. (except for GS40)
• Fully enclosed plastic case
• LED indicator for power on
• Pass LPS (except for GS120)
• 2 years warranty
General Specification
TU V
Rh ei nl an d
Prod uct Sa fe ty
PS
E
(except for 48V)
Or der N o .
GS4 0
AC in p u t v o l t a g e ra n g e
AC in r us h c u rre n t ( ma x . )
Ra n g e
Over load
Type
p r otection
Over vo l t a g e p ro t e c t i o n
S etu p , r i s e , h o l d u p t i me
W ithstan d v o l t a g e
W o r kin g t e mp e ra t u re
S afety st a n d a rd s
E MC stand a rd s
9 0 ~2 6 4 VAC / 1 . 0 A
90~264VAC / 1.4A 90~ 2 6 4 VA C / 2 . 0 A
8 5 ~ 2 6 4 VA C / 1 . 4 A
Co l d s t a rt , 6 5 A a t 2 3 0 VAC
C o ld st a r t , 7 0 A a t 2 3 0 VA C
105%~150% rated output power
110%~150%
105%~160%
Hiccup mode, auto-recovery
105%~135% rated output voltage
1000ms, 30ms, 50ms at 230VAC input
1000ms, 20ms, 20ms at 230VAC input
2000ms, 30ms, 20ms at 230VAC input
I / P-O/ P: 3 k VAC, I / P-FG: 2 k VA C , O / P - FG : 0 . 5 kVA C
I / P - FG : 3 kVA C
-3 0 ~+6 0 °C
- 3 0 ~ + 5 0 °C
- 3 0 ~ + 7 0 °C
UL 6 0 9 5 0 -1 , TUV EN6 0 9 5 0 -1 , B S M I C N S 1 4 3 3 6 , C C C G B 4 9 4 3 , P S E J6 0 9 5 0 - 1 ( e xce p t f o r 4 8 V ) approved
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 - 2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, C N S 1 3 4 3 8 , G B 9 2 5 4 , FC C p a r t 1 5 cla ss B
L ength o f o u t p u t c a b l e
GS40:
100cm
180cm
GS60:
100cm
100cm
180cm
S tan d ar d D C p l u g
(refer to page 60 for DC plug list)
GS6 0
GS 9 0
of UL1185, 16AWG for 5~15V;
of UL1185, 18AWG for 18~48V
of UL2464, 16AWG for 5~9V;
of UL1185, 16AWG for 12~15V;
of UL1185, 18AWG for 18~48V
GS120
100cm of UL1185, 14AWG for 12~15V;
120cm of UL1185, 16AWG for 19~48V
R7B: Power DIN 4P with lock type
P1M:
P1J:
P1M: 2.5øx5.5øx11mm/C+,
2.1øx5.5øx11mm / C+, tuning fork type 2.5øx5.5øx11mm / C+, tuning fork type
tuning fork type (20~48V only)
Desktop (IEC 320-C14 / Class IŇ:
Desktop (IEC 320-C14 / Class IŇ:
Order No.
Tol.
R&N
Effi.
5V, 0~6.00A
±5%
100mV
81.0%
7.5V, 0~6.00A
±5%
100mV
85.5%
9V, 0~6.00A
±5%
100mV
87.5%
GS60A12-P1J
12V, 0~5.00A
±3%
100mV
88.0%
GS60A15-P1J
15V, 0~4.00A
±3%
100mV
88.5%
GS60A18-P1J
18V, 0~3.33A
±3%
150mV
88.5%
GS60A24-P1J
24V, 0~2.50A
±3%
180mV
90.0%
GS60A48-P1J
48V, 0~1.25A
±2.5%
240mV
92.0%
Order No.
Output
Tol.
R&N
Effi.
GS40A05-P1J
5V, 0~5.00A
±5%
100mV
80.5%
GS60A05-P1J
85.5%
GS60A07-P1J
GS60A09-P1J
GS40A07-P1J
GS40A09-P1J
7.5V, 0~5.34A
9V, 0~4.45A
±5%
±5%
100mV
100mV
85.0%
GS40A12-P1J
12V, 0~3.34A
±3%
100mV
89.0%
GS40A15-P1J
15V, 0~2.67A
±3%
100mV
89.5%
GS40A18-P1J
18V, 0~2.22A
±3%
150mV
90.0%
GS40A24-P1J
24V, 0~1.67A
±2.5%
180mV
91.0%
GS40A48-P1J
48V, 0~0.84A
±2.5%
240mV
92.0%
Output
Tol.
Order No.
R&N
Output
Desktop (IEC 320-C14 / Class IŇ:
Desktop (IEC 320-C14 / Class IŇ:
Order No.
120cm of UL2464, 18AWGx4C
Output
Tol.
R&N
Effi.
Effi.
GS120A12-R7B
12V, 0~8.5A
±5%
80mV
87.5%
GS120A15-R7B
15V, 0~7.0A
±5%
120mV
89.0%
20V, 0~6.0A
±5%
150mV
89.0%
GS90A12-P1M
12V, 0~6.67A
±5%
80mV
88.0%
GS90A15-P1M
15V, 0~6.00A
±5%
100mV
89.0%
GS90A19-P1M
19V, 0~4.74A
±4%
150mV
89.0%
GS90A24-P1M
24V, 0~3.75A
±3%
180mV
89.5%
GS90A48-P1M
48V, 0~1.87A
±2%
240mV
91.0%
Ƒ
GS120A24- Ƒ
GS120A48- Ƒ
Ƒ= P1M, R7B
GS120A20-
58
24V, 0~5.0A
±3%
180mV
90.0%
48V, 0~2.5A
±2%
240mV
91.0%
Industrial Adaptor
160~280W Single Output
Features
•
•
•
•
GS160
GS220
GS280
175x 72x 35 mm
210x 85x 46 mm
220x 95x 46 mm
•
•
•
•
•
•
•
•
•
•
Universal AC input / Full range
No load power consumption<0.5W
ErP step 2 compliant (Level V)
Meet EISA 2007 (Energy Independence and
Security Act)
NRCan compliant
MEPS compliant
Built-in active PFC function
3 pole AC inlet IEC320-C14
Class I p o w e r ( w i t h e a r t h p i n )
Fanless design
Protections: Short circuit / Overload /
Over voltage / Over temperature
Fully enclosed plastic case
LED indicator for power on
2 years warranty
General Specification
TU V
Rh ei nl an d
Prod uct Sa fe ty
PS
E
(except for 48V)
Or der N o .
GS1 6 0
GS220
GS280
AC in p u t v o l t a g e ra n g e
8 5 ~2 6 4 VAC ; 1 2 0 ~3 7 0 VDC
90~264VAC ; 127~370VDC
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 1 2 0 A a t 2 3 0 VAC
Over load
p r otection
Ra n g e
105%~135% rated output power
Type
Hiccup mode, auto-recovery
Over vo l t a g e
p r otection
Ra n g e
105%~135% rated output power
Type
Shut down o/p voltage, re-power on to recover
Ho ld u p t i me
20ms at full load
W ithstan d v o l t a g e
I / P-O/ P: 3 k VA C, 1 m i n u t e
W o r kin g t e mp e ra t u re
-3 0 ~+7 0 °C
S afety st a n d a rd s
UL60950-1, TUV EN60950-1, BSMI CNS14336, CCC GB4943, PSE J60950-1(except for 48V) approved
E MC stand a rd s
EN5 5 0 2 2 c l a s s B, EN6 1 0 0 0 -3 - 2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, FC C p a r t 1 5 cla ss B , C N S 1 3 4 3 8 , G B 9 2 5 4
L ength o f o u t p u t c a b l e
120cm of UL2464, 18AWGx4C
S tan d ar d D C p l u g
(refer to page 60 for DC plug list)
16ms at full load
- 3 0 ~ + 6 0 °C ( r e f e r t o o u t p u t d e r a t in g cu r ve )
100cm of UL2464, 16AWGx4C
4P/6.35mm pitch, AMP 1-480702-0 (power supply side);
AMP 1-480703-0(customer side)
R7 B: Po we r DI N 4 P wi t h l o c k typ e
Desktop (IEC320-C14/Class I) Ň160W
Desktop (IEC320-C14/Class I) Ň280W
Order No.
Output
Tol.
R&N
Effi.
Order No.
Output
Tol.
R&N
Effi.
GS160A12-R7B
12V, 0~11.5A
±5%
80mV
89.0%
GS280A12-C4P
12V, 0~18.5A
±5%
120mV
89. 0%
GS160A15-R7B
15V, 0~9.6A
±5%
100mV
90.0%
GS280A15-C4P
15V, 0~16A
±5%
120mV
89. 5%
GS160A20-R7B
20V, 0~8.0A
±4%
150mV
92.0%
GS280A20-C4P
20V, 0~13A
±4%
150mV
92. 0%
GS160A24-R7B
24V, 0~6.67A
±3%
180mV
92.5%
GS280A24-C4P
24V, 0~11.67A
±3%
280mV
93. 0%
GS160A48-R7B
48V, 0~3.34A
±3%
240mV
94.0%
GS280A48-C4P
48V, 0~5.84A
±2%
280mV
94. 0%
Des kto p (IEC320-C14/Class I) Ň220W
Order No.
Output
Tol.
R&N
Effi.
GS220A12-R7B
12V, 0~15.0A
±5%
80mV
90.0%
GS220A15-R7B
15V, 0~13.4A
±5%
100mV
90.0%
GS220A20-R7B
20V, 0~11.0A
±4%
150mV
92.0%
GS220A24-R7B
24V, 0~9.20A
±3%
180mV
93.5%
GS220A48-R7B
48V, 0~4.60A
±2%
240mV
94.5%
Q.A.
Who can provide you better services and be a trustworthy
partner in the power industry?
— "MEAN WELL" tries to be —
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at [email protected] for information of your local
distributors.
59
Industrial Adaptor
25~50W Triple Output
50W AC-DC Triple Output
25W AC-DC Triple Output
• Fixed switching frequency and
• Universal AC input / Full range
regulation
• Protections: Short circuit / Overload /
Over voltage / Over temp. • Topology: Top switch circuit
• LED indicator for power on
• Fully enclosed plastic case
• 1 year warranty
147x 76x 43 mm
• 3 pole AC inlet IEC320-C14
• Class I power (with earth pin)
• Protections: Short circuit / Overload /
Over voltage
• Fully enclosed plastic case
• LED indicator for power on
• 1 year warranty
AC input voltage range ...... 90~264VAC / 1.6A
AC inrush current(max.) .... Cold start, 40A at 230VAC
Overload protection .......... Hiccup mode, auto-recovery
Over voltage protection ..... 110%~140% for +5V output
Hold up time .................... 12ms at full load
P25A
P 25B
108x 67x 36 mm
108x 67x 36 mm
Withstand voltage ............. I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1 minute
AC input voltage range ...... 90~264VAC / 0.8A
Working temperature ......... 0~+40°C (refer to output derating curve)
AC inrush current(max.) .... Cold start, 60A at 230VAC
Safety standards .............. UL1950, TUV EN60950-1 approved
Overload protection .......... Hiccup mode, auto-recovery
EMC standards ................. EN55022 class B, EN61000-3-2,3,
Over voltage protection ..... 110%~140% of +5V output
EN61000-4-2,3,4,5,6,11
Setup, rise, hold up time ... 200ms, 50ms, 16ms at full load
Length of output cable ...... 120cm of UL2464
Withstand voltage ............. I/P-O/P:3kVAC, I/P-FG:1.5kVAC , 1 minute
Standard DC plug.............. R1B: DIN 5P
Working temperature ......... 0~+40°C (refer to output derating curve)
O r de r N o.
Safety standards ............... UL1950, CSA 22.2, TUV EN60950-1 approved
Out put
P50A13D-R1B
EN61000-4-2,3,4,5,6,11
Output
Order No.
P25A14E-R1B
Tol.
R&N
Effi.
Max.
5V, 0.5~2.5A
±5%
50mV
72%
25W
12V, 0.1~0.8A
±5%
100mV
-12V, 0.1~0.3A
±3%
100mV
5V, 0.5~2.5A
±5%
50mV
15V, 0.1~0.5A
±5%
100mV
-15V, 0.1~0.3A
±3%
100mV
P25B13D-R1B
P25B14E-R1B
Tol.
Effi.
Max.
72%
25W
5V, 0.5~2.5A
±5%
50mV
12V, 0.1~0.8A
±5%
100mV
-12V, 0.1~0.3A
±3%
100mV
5V, 0.5~2.5A
±5%
50mV
100mV
±6%
50mV
15V, 0.5~1.5A
±10%
100mV
-15V, 0.1~0.5A
±12%
100mV
Optiona l DC Plug Lis t
15V, 0.1~0.5A
±5%
100mV
-15V, 0.1~0.3A
±3%
100mV
A
OD
5.5
5.5
5.5
5.5
B
ID
2.1
2.1
2.5
2.5
C
L
9.5
11.0
9.5
11.0
P 2I
P2J
P2L
P2M
A
OD
5.5
5.5
5.5
5.5
B
ID
2.1
2.1
2.5
2.5
C
L
9.5
11.0
9.5
11.0
Type
A
B
C
P2S
(S761K)
5.53
2.03
12.06
Type
P 1I
P1J
P1L
P1M
Lock Style
74%
50W
±12%
5V, 0.5~4.0A
25W
R&N
74%
-12V, 0.1~0.5A
25W — T ri p l e o u t p u t ( I EC 3 2 0 -C8 / Cl a s s I I)
Output
50W
50mV
100mV
Barrel Style
Order No.
72%
±6%
Tuning Fork Style
74%
Ma x .
±10%
Length of output cable ....... R1B: DIN 5P
P25A13D-R1B
Effi.
5 V, 0 . 5 ~ 4 . 0 A
P50A14E-R1B
25W — Tri p l e o u t p u t ( I E C 3 2 0 -C1 4 / Cl a s s I)
R&N
12V, 0.5~2.0A
EMC standards ................. EN55022 class B, EN61000-3-2,3,
Standard output cable ....... 150cm of UL2464
Tol .
25W
DIN 5 Pin
We prvide specification, drawing, test report and more
information, please visit our website —
http://www.meanwell.com
Type
Type
R1B
To satisfy our customers is our goal —
• High Quality
• Low Cost
• Prompt Delivery
• Best Service
DIN 4 Pin with lock
Type
R7B
48hrs delivery—
We keep enough stock for 95% of standard models at our
2400m 2 warehouse. We can arrange prompt delivery within
48hrs.
1
2
3
4
5
Pin Assignment
Single
Triple
COM
COM
COM
COM
Vout
+5V
COM
-Vout
Vout
+Vout
Pin Assignment
PIN No.
Output
1
+Vout
2
GND
3
GND
4
+Vout
ź 0 L QL PXP RU GH U TXD QW L W \ L V Y D U L H G I RU GL I I H U H QW PRG H O V 60
Medical Adaptor
30~50W Single Output
Features
MES30A
M E S 30B
M E S 30C
MES50A
108x 67x 36 mm
108x 67x 36 mm
108x 67x 36 mm
147x 75.5x 43.2 mm
• Universal AC input / Full range
• Medical safety approved (2xMOPP)
• Class I ( w i t h e a r t h p i n ) f o r M E S 3 0 A /3 0 C/5 0 A
Class I I ( w i t h o u t e a r t h p i n ) f o r M E S 30 B
• Optional lock type DC plug
• Protections: Short circuit / Over voltage /
Overload / Over temperature
• Low leakage current ”ȝ$”ȝ$IRU0(6
• Fully enclosed plastic case
• Topology: Top switch circuit
• LED indicator for power on
• 2 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Or der N o .
MES3 0 A
MES30B
MES30C
MES50A
A C in p u t v o l t a g e ra n g e
9 0 ~2 6 4 VAC / 0 . 8 A
9 0 ~ 2 6 4 VA C / 1 . 5 A
AC in r us h c u rre n t ( ma x . )
Co l d s t a rt , 3 5 A a t 2 3 0 VA C
C o ld st a r t , 9 0 A a t 2 30 VA C
Over load p ro t e c t i o n
Hiccup mode, auto-recovery
Over vo l t a g e p ro t e c t i o n
110%~140% rated output voltage
S etu p , r i s e , h o l d u p t i me
300ms, 50ms, 16ms at full load
W ithstan d v o l t a g e
I / P-O/ P: 5 6 5 6 VDC, I / P-F G : 2 8 2 8 V D C , 1 m in u t e f o r M E S 3 0 A / 3 0 C / 5 0 A
I / P-O/ P: 5 6 5 6 VDC, 1 m i n ut e f o r M E S 3 0 B
W o r kin g t e mp e ra t u re
0 ~+6 5 °C (re f e r t o o u t p u t d e r a t in g cu r ve )
S afety st a n d a rd s
ANSI / AAM I ES6 0 6 0 1 -1 , TU V E N 6 0 6 0 1 - 1 , I E C 6 0 6 0 1 - 1 a p p r o ve d
E MC stan d a rd s
EN55011 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN60601-1-2 medical level
S tan d ar d o u t p u t c a b l e
120cm for 3.3~7.5V ; 180cm for 9~48V
S tan d ar d o u t p u t p l u g
(refer to p a g e 6 0 f o r DC p lu g l i s t )
P1J: 2.1øx5.5øx11mm / C+, tuning fork type
R1 B: p o we r Di n 5 P f o r M E S 5 0 A 3 . 3 ~ 7 . 5 V o n ly
110%~150% rated output voltage
Desktop (IEC 320-C6 / Class IŇ:
Desktop (IEC 320-C14 / Class IŇ:
Order No.
Output
Tol.
R&N
Effi.
Order No.
Output
MES30A-0P1J
3.3V, 0~5.00A
±8%
30mV
56%
MES30C-0P1J
3.3V, 0~5.00A
MES30A-1P1J
5V, 0~5.00A
+8%, -5%
30mV
70%
MES30C-1P1J
5V, 0~5.00A
MES30A-1-1P1J
Tol.
R&N
Effi.
±8%
30mV
56%
+8%, -5%
30mV
70%
7.5V, 0~3.33A
±4%
40mV
72%
MES30C-1-1P1J
7.5V, 0~3.33A
±4%
40mV
72%
MES30A-2P1J
9V, 0~3.33A
±4%
50mV
74%
MES30C-2P1J
9V, 0~3.33A
±4%
50mV
74%
MES30A-3P1J
12V, 0~2.50A
±3%
50mV
76%
MES30C-3P1J
12V, 0~2.50A
±3%
50mV
76%
MES30A-4P1J
15V, 0~2.00A
±2%
60mV
78%
MES30C-4P1J
15V, 0~2.00A
±2%
60mV
78%
MES30A-5P1J
18V, 0~1.66A
±2%
70mV
78%
MES30C-5P1J
18V, 0~1.66A
±2%
70mV
78%
MES30A-6P1J
24V, 0~1.25A
±2%
80mV
80%
MES30C-6P1J
24V, 0~1.25A
±2%
80mV
80%
MES30A-7P1J
28V, 0~1.07A
±2%
100mV
80%
MES30C-8P1J
48V, 0~0.62A
±2%
100mV
82%
MES30A-8P1J
48V, 0~0.62A
±2%
100mV
82%
Desktop (IEC 320-C14 / Class IŇ:
Desktop (IEC 320-C8 / Class IIŇ:
Order No.
Output
MES30B-0P1J
3.3V, 0~5.00A
MES30B-1P1J
5V, 0~5.00A
Order No.
Output
Tol.
3.3V, 0~7.50A
Tol.
R&N
Effi.
MES50A-0R1B
±8%
30mV
56%
MES50A-1R1B
+8%, -5%
30mV
70%
MES50A-1-1R1B
R&N
Effi.
±10%
50mV
60%
5V, 0~7.50A
±6%
50mV
67%
7.5V, 0~5.33A
±5%
75mV
70%
7.5V, 0~3.33A
±4%
40mV
72%
MES50A-2P1J
9V, 0~5.00A
±5%
90mV
72%
MES30B-2P1J
9V, 0~3.33A
±4%
50mV
74%
MES50A-3P1J
12V, 0~4.16A
±3%
100mV
74%
MES30B-3P1J
12V, 0~2.50A
±3%
50mV
76%
MES50A-4P1J
15V, 0~3.33A
±3%
100mV
75%
MES30B-4P1J
15V, 0~2.00A
±2%
60mV
78%
MES50A-5P1J
18V, 0~2.77A
±3%
150mV
78%
MES30B-5P1J
18V, 0~1.66A
±2%
70mV
78%
MES50A-6P1J
24V, 0~2.08A
±2%
150mV
78%
MES30B-6P1J
24V, 0~1.25A
±2%
80mV
80%
MES50A-7P1J
28V, 0~1.78A
±2%
150mV
80%
MES30B-8P1J
48V, 0~0.62A
±2%
100mV
82%
MES50A-8P1J
48V, 0~1.04A
±2%
200mV
80%
MES30B-1-1P1J
61
Medical Adaptor
GSM06U
GSM06E
Features
•
•
•
•
•
•
•
6~36W Single Output
GSM18/25/36B
Universal AC input / Full range
Medical safety approved(2xMOPP)
No l o a d pow er consumpt ion < 0. 1W ( < 0. 3W f or G S M 06 )
ErP step 2 compliant (Level V)
Meet EISA 2007 (Energy Independence and Security Act)
2 p o l e USA / EU R O pl ug or I E C320- C8
Class I I pow er (w i t hout ear t h pin)
General Specification
GSM18/25/36U
Optional lock type DC plug
Protections: Short circuit / Overload / Over voltage
/RZOHDNDJHFXUUHQWȝ$
L E D i n d i c a t o r f o r p o w e r o n ( e x c e p t f o r GS M 0 6 )
C e r t i f i c a t e s : B t y p e : U L / C U L / T U V / C B / F C C / CE
U type: UL / CUL / CB / FCC
E type: TUV / CB / CE
• 3 years warranty
(Please refer to www.meanwell.com for detail spec.)
•
•
•
•
•
Or der N o .
AC in p u t v o l t a g e ra n g e
AC in r us h c u rre n t ( ma x . )
GSM 0 6
90~264VAC / 0.18A
Co l d s t a rt , 3 0 A a t 2 3 0 VAC
GSM 1 8
80~2 6 4 VA C / 0 . 5 A
Co l d st a r t , 5 0 A a t 2 3 0 VA C
Over load p ro t e c t i o n
>105% rated output
power, auto-recovery
105%~150% rated output power,
hiccup mode, auto-recovery
Over vo l t a g e p ro t e c t i o n
S etup, r i s e , h o l d u p t i me
W ith stan d v o l t a g e
W or king t e mp e ra t u re
S afety st a n d a rd s
E MC stan d a rd s
Len g th o f o u t p u t c a b l e
S tandar d D C p l u g
D im en sion ( L x W x H ) ( mm)
GSM18/25/36E
GSM25
8 0 ~ 2 6 4 VA C / 0 . 7 A
GSM36
8 0 ~ 2 6 4 VA C / 0 . 9 A
105%~170% rated output power
110%~140%
105%~135% rated output voltage, shut down o/p voltage, re-power on to recover
1000ms, 50ms, 12ms
500ms, 30ms, 16ms at 230VAC input
I / P-O/ P: 5 6 5 6 VDC
I / P- O / P : 4 kVA C
0 ~+5 0 °C
-3 0~ + 6 0 °C ( r e f e r t o o u t p u t d e r a t in g cu r ve )
B type(except for GSM06): A N S I / A A MI E S 6 0 6 0 1 - 1 , TU V E N 6 0 6 0 1 - 1 / 6 0 6 0 1 - 1 - 11 a p p r o ve d
U type: ANSI / AAM I ES6 0 6 0 1 -1 a p p r o ve d
E type: TUV EN6 0 6 0 1 -1 / 6 0 6 0 1 - 1 - 11 a p p r o ve d
B t ype(except for GSM06): E N 55011 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61204-3,
EN60601-1-2 medical level, FCC Part 15 class B
U t y p e : F CC Pa rt 1 5 c l a s s B
E t y p e : EN5 5 0 11 c l a s s B, EN6 1 00 0 - 3 - 2 , 3 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8 , 11, E N 6 1 2 0 4 - 3 , E N 6 0 6 0 1 - 1 - 2 m e d ic a l l e v e l
120cm of UL1185, 16AWG for
120cm of UL1185, 16AWG for 5~9V;
180cm of UL2468, 24AWG
5~9V; 180cm of UL1185,
180cm of UL1185, 18AWG for 12~48V
16AWG for 12~48V
P1J: 2.1øx 5.5øx 11mm / C+, tuning fork type (refer to page 60 for DC plug list)
32x 66x 42.5
79x 54x 33
Wall-mounted — 6W
Or der
GSM06
GSM06
GSM06
GSM06
GSM06
No .
Ƒ05-P1J
Ƒ06-P1J
Ƒ07-P1J
Ƒ09-P1J
Ƒ12-P1J
Ou t p ut
5V, 0~1.00A
6V, 0~1.00A
7.5V, 0~0.80A
9V, 0~0.66A
12V, 0~0.50A
Tol .
±5%
±5%
±5%
±5%
±3%
R&N
50mV
50mV
80mV
80mV
100mV
Effi.
68%
74%
74%
76%
77%
Tol.
R&N
Effi.
±5%
±5%
±5%
±3%
±3%
60mV
80mV
80mV
120mV
120mV
81%
83%
84%
86%
87%
Tol.
R&N
Effi.
±5%
±5%
±5%
±3%
±3%
60mV
80mV
80mV
120mV
120mV
81%
83%
84%
86%
87%
Tol.
R&N
Effi.
±5%
±5%
±5%
±3%
±3%
60mV
80mV
80mV
120mV
120mV
81%
83%
84%
86%
87%
Order No.
Ou t p u t
Tol.
15V, 0~0.40A
±3%
GSM06 15-P1J
GSM06 18-P1J
18V, 0~0.33A
±3%
24V, 0~0.25A
±2%
GSM06 24-P1J
= U / E ; U : A m e r ica n 2 P ; E : E u r o p e a n 2 P
Ƒ
Ƒ
Ƒ
Ƒ
R&N
120mV
150mV
180mV
Effi.
79%
80%
82%
R&N
Effi.
87%
87%
88%
Desktop / Wall-mounted — 18W
Order No.
GSM18
GSM18
GSM18
GSM18
GSM18
Ƒ05-P1J
Ƒ07-P1J
Ƒ09-P1J
Ƒ12-P1J
Ƒ15-P1J
Output
5V,
7.5V,
9V,
12V,
15V,
0~3.00A
0~2.00A
0~2.00A
0~1.50A
0~1.20A
Order No.
Ƒ
Ƒ
Ƒ
Output
Tol.
GSM18 18-P1J
18V, 0~1.00A
±3%
150mV
GSM18 24-P1J
24V, 0~0.75A
±2%
180mV
GSM18 48-P1J
48V, 0~0.375A
±2%
240mV
=B / U / E ;
B : I E C 3 2 0 - C 8 , U : A m e r ica n 2 P, E : E u r o p e a n 2 P
Ƒ
Desktop / Wall-mounted — 25W
Order No.
GSM25
GSM25
GSM25
GSM25
GSM25
Ƒ05-P1J
Ƒ07-P1J
Ƒ09-P1J
Ƒ12-P1J
Ƒ15-P1J
Output
5V,
7.5V,
9V,
12V,
15V,
0~4.00A
0~2.93A
0~2.77A
0~2.08A
0~1.66A
Order No.
Ƒ
Ƒ
Ƒ
Output
Tol.
R&N
GSM25 18-P1J
18V, 0~1.38A
±3%
150mV
GSM25 24-P1J
24V, 0~1.04A
±2%
180mV
GSM25 48-P1J
48V, 0~0.52A
±2%
240mV
=B / U / E ;
B : I E C 3 2 0 - C 8 , U : A m e r ica n 2 P, E : E u r o p e a n 2 P
Ƒ
Effi.
87%
87%
88%
Desktop / Wall-mounted — 36W
Order No.
GSM36
GSM36
GSM36
GSM36
GSM36
Ƒ05-P1J
Ƒ07-P1J
Ƒ09-P1J
Ƒ12-P1J
Ƒ15-P1J
Output
5V,
7.5V,
9V,
12V,
15V,
0~4.50A
0~4.32A
0~4.00A
0~3.00A
0~2.40A
Order No.
Output
Tol.
R&N
GSM36 18-P1J
18V, 0~2.00A
±3%
150mV
24V, 0~1.50A
±2%
180mV
GSM36 24-P1J
48V, 0~0.75A
±2%
240mV
GSM36 48-P1J
=B / U / E ;
B : I E C 3 2 0 - C 8 , U : A m e r ica n 2 P, E : E u r o p e a n 2 P
Ƒ
62
Ƒ
Ƒ
Ƒ
Effi.
87%
87%
88%
Medical Adaptor
ATX Power
40~60W AC-DC Single Output
•
•
•
•
•
•
•
•
•
•
125x 50x 31.5 mm
•
•
•
•
200~300W Industrial ATX PC Power Supply
Universal AC input / Full range
Medical safety approved (2xMOPP)
No load power consumption < 0.1W
ErP step 2 compliant (Level V)
Meet EISA 2007 (Energy independence
and security act)
3 pole AC inlet IEC320-C14
High efficiency up to 91%
Class I power (with earth pin)
Optional lock type DC plug
Protections:
Short circuit / Overload / Over voltage /
Over temp.(GSM60A)
/RZOHDNDJHFXUUHQWȝ$
Fully enclosed plastic case
LED indicator for power on
3 years warranty
• Universal AC input / Full range
• Low profile for 1U/2U rack system
• Built-in active PFC function
• Protections: Short circuit / Overload /
Over voltage
• With power good and fail signal
output
•
•
• PS-ON signal input
• 24V/3A output with 7A peak
capability (IPC-300B)
• 2 years warranty
Hold up time .................... 16ms min. at full load and 115VAC
Overload protection .......... 105%~150% shut off, AC recycle to re-start
Over voltage protection ..... 110%~140% rated output voltage for CH1~CH3
AC input voltage range ...... 80~264VAC / 1.0A for GSM40
80~264VAC / 1.4A for GSM60
Withstand voltage ............. I/P-O/P, I/P-FG:1.5kVAC, 1minute
Working temperature ........ -10~+60° C (refer to output derating curve)
AC inrush current(max.) .... Cold start, 65A at 230VAC
Overload protection .......... 105%~160% rated output power, auto-recovery
Safety standards .............. UL60950-1, TUV EN60950-1 approved
EMC standards ................ EN55022 class B, EN61000-3-2,-3
Over voltage protection ..... 105%~135% rated output voltage
Setup, rise, hold up time .... 1000ms, 30ms, 50ms at 230VAC input
EN61000-4-2,3,4,5,6,8,11
Withstand voltage ............. I/P-O/P: 4kVAC, I/P-FG: 2kVAC, O/P-FG: short
Safety standards .............. ANSI/AAMI ES60601-1, TUV EN60601-1 approved
EMC standards ................. EN55011 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11, EN61204-3,
Model No.
Output
Tol.
R&N
Effi.
Max.
IPC-200
3.3V, 0~15A
±5%
50mV
74.5%
200W
5V, 1~25A
±5%
50mV
12V, 1~13A
±7%
120mV
75%
250W
75%
300W
80%
300W
EN60601-1-2 medical level, FCC Part 15 class B
Standard output cable ...... GSM40: 100cm of UL2464, 16AWG for 5V/7.5V
100cm of UL1185, 16AWG for 9V/12V
150cm of UL1185, 16AWG for 15~48V
GSM60: 100cm of UL2464, 16AWG for 5~15V
IPC-250
150cm of UL1185, 16AWG for 18~48V
Standard DC plug.............. P1J: 2.1ø x5.5ø x11mm / C+, tuning fork type
(refer to page 60 for DC plug list)
GS M40 S e ri e s
Order No.
Output
Tol.
R&N
Effi.
GSM40A05-P1J
5V, 0.1~5.00A
±5%
100mV
81.0%
GSM40A07-P1J
7.5V, 0.1~5.34A
±5%
100mV
85.5%
GSM40A09-P1J
9V, 0.1~4.45A
±5%
100mV
GSM40A12-P1J
12V, 0.1~3.34A
±3%
100mV
±8%
100mV
±10%
120mV
5VSB, 0~2.0A
±5%
50mV
3.3V, 0~20A
±5%
50mV
5V, 1~25A
±5%
50mV
12V, 1~15A
±7%
120mV
-5V, 0~0.5A
±8%
100mV
-12V, 0.1~1.0A
±10%
120mV
±5%
50mV
3.3V, 0~20A
±5%
50mV
86.0%
5V, 1~30A
±5%
50mV
88.0%
12V, 1~18A
±7%
120mV
-5V, 0~0.5A
±8%
100mV
-12V, 0.1~1.0A
15V, 0.1~2.67A
±3%
100mV
88.5%
GSM40A18-P1J
18V, 0.1~2.22A
±3%
150mV
89.5%
GSM40A24-P1J
24V, 0.1~1.67A
±2.5%
180mV
90.0%
GSM40A48-P1J
48V, 0.1~1.84A
±2.5%
240mV
91.0%
Tol.
R&N
Effi.
IPC-300A
IPC-300B
GS M60 S e ri e s
Output
-5V, 0~0.5A
-12V, 0.1~1.0A
5VSB, 0~2.0A
GSM40A15-P1J
Order No.
• Forced air cooling by built-in DC fan
• Remote sence on CH1, CH2
240x 83x 40 mm (200 / 250W)
260x 83x 40 mm (300W)
GSM60A05-P1J
5V, 0.1~6.00A
±5%
100mV
81.5%
GSM60A07-P1J
7.5V, 0.1~6.00A
±5%
100mV
86.0%
GSM60A09-P1J
9V, 0.1~6.00A
±5%
100mV
87.5%
GSM60A12-P1J
12V, 0.1~5.00A
±3%
100mV
88.0%
GSM60A15-P1J
15V, 0.1~4.00A
±3%
100mV
88.5%
GSM60A18-P1J
18V, 0.1~3.33A
±3%
150mV
89.0%
GSM60A24-P1J
24V, 0.1~2.50A
±3%
180mV
90.0%
GSM60A48-P1J
48V, 0.1~1.25A
±2.5%
240mV
91.0%
±10%
120mV
5VSB, 0~2.0A
±5%
50mV
24V, 0~3.0A
±5%
240mV
5V, 1~30A
±5%
50mV
12V, 1~18A
±7%
120mV
-5V, 0~0.5A
±8%
100mV
-12V, 0.1~1.0A
±10%
120mV
±5%
50mV
5VSB, 0~2.0A
Customer Satisfaction —
Today's effort, tomorrow's reward. Continuously improve
CQTS to satisfy customer is our goal.
48hrs delivery—
We keep enough stock for 95% of standard models at our
2400m 2 warehouse. We can arrange prompt delivery within
48hrs.
63
Security Series
35~100W Single and Dual Output
35W, 50W, 75W Single Output
• Universal AC input / Full range
• Protections: Short circuit / Overload
/ Over voltage / Battery
polarity (by fuse)
• Cooling by free air convection
60W Single Output with Battery Charger (UPS Function)
• LED indicator for power on
• No load power consumption <0.75W
• Temperature compensation function
(by external thermistor)
• 100% full load burn-in test
• 2 years warranty
103.4x 62x 37 mm
101.6x 50.8x 29 mm
SCP-35
99x 97x 36 mm
SCP-50
SCP-75
129x 98x 38 mm
159x 97x 38 mm
• Universal AC input / Full range
• 4"x 2" compact size
• Protections: Short circuit / Overload /
Over voltage
• Battery low protection / Battery reverse
polarity protection by fuse
• Alarm signal for AC OK and Battery low
• Cooling by free air convection
• 100% full load burn-in test
• Case available(PSC-60x-C)
• 2 years warranty
AC input voltage range .......... 90~264VAC; 127~370VDC
AC inrush current ................. Cold start, 30A at 115VAC, 60A at 230VAC
DC adjustment range ............ CH1, 13.8V: 12~15V; 27.6V: 24~29V
Overload protection .............. 105%~150% hiccup mode, auto-recovery
Over voltage protection ......... CH1: 105%~135% rated output voltage
Withstand voltage ................. I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ............. -20~+70° C (refer to output derating curve)
Safety standards .................. UL60950-1, TUV EN60950-1 approved
EMC standards ..................... EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Connection .......................... 3+6P/ 3.96mm pitch, JST: B3P/B6P-VH
Packing ............................... 0.13kg ; 96pcs / 13.5kg / 0.89CUFT (PCB)
0.29kg ; 45pcs / 14.0kg / 0.67CUFT (case)
AC input voltage range ...... 85~264VAC/ 120~370VDC
AC inrush current .............. Cold start, 45A
DC adjustment range ......... 95%~115% rated output voltage
Overload protection ........... 120%~165%, hiccup mode, auto-recovery
Model No.
Over voltage protection ...... 120%~140%, rated output voltage
Setup, rise, hold up time .... 500ms, 30ms, 50ms at full load and 230VAC
Withstand voltage ............. I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ......... -20~+60°C (refer to output derating curve)
Safety standards ............... UL60950-1 approved
EMC standards ................. EN55022 class B, EN61000-3-2,3,
PSC-60A
ƒ
PSC-60B
ƒ
Output
13.8V, 0~4.3A
13.8V, 0~1.50A
Tol.
R&N
Effi.
Max.
±1%
120mV
84%
59W
240mV
84%
59W
(Charger)
27.6V, 0~2.15A
±1%
27.6V, 0~0.75A
(Charger)
ƒ = blank, -C ;
Blank: PCB Type, -C: Enclosed Type
100W Single Output with Battery Charger (UPS Function)
EN61000-4-2,3,4,5,6,8,11, EN55024,
EN61000-6-1
Connection ...................... I/P: 3 poles, O/P: 2 poles screw terminal
Packing ............................ 0.37kg ; 45pcs / 17.7kg / 1CUFT (SCP-35)
0.45kg ; 30pcs / 14.5kg / 0.95CUFT (SCP-50)
0.5kg ; 30pcs / 16.0kg / 1CUFT (SCP-75)
S CP -35 S e ri e s
Model No.
Output
Tol.
R&N
Effi.
Max.
SCP-35-12
13.8V, 0~2.6A
±2%
120mV
83%
36W
SCP-35-24
27.6V, 0~1.4A
±1%
200mV
86%
39W
Model No.
Output
Tol.
R&N
Effi.
Max.
SCP-50-12
13.8V, 0~3.6A
±2%
120mV
81%
50W
SCP-50-24
27.6V, 0~1.8A
±1%
200mV
85%
50W
Model No.
Output
Tol.
R&N
Effi.
Max.
SCP-75-12
13.8V, 0~5.4A
±2%
120mV
81%
75W
SCP-75-24
27.6V, 0~2.7A
±1%
200mV
85%
75W
130x 85x 37 mm
127x 76.2x 31 mm
S CP -50 S e ri e s
• Universal AC input / Full range
• 5"x3" compact size
• Protections: Short circuit / Overload /
Over voltage
• Battery low protection / Battery reverse
polarity protection by fuse
• Relay contact signal for AC OK and
battery low
• Cooling by free air convection
• 100% full load burn-in test
• Case available(PSC-100x-C)
• 2 years warranty
AC input voltage range ........ 90~264VAC; 127~370VDC
AC inrush current ................ Cold start, 35A at 115VAC, 70A at 230VAC
DC adjustment range ........... CH1, 13.8V: 12~15V; 27.6V: 24~29V
Overload protection ............. 105%~150% hiccup mode, auto-recovery
Over voltage protection ........ CH1: 105%~135% rated output voltage
Withstand voltage ................ I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ............-20~+70° C (refer to output derating curve)
Safety standards ................. UL60950-1, TUV EN60950-1 approved
EMC standards ....................EN55022 class B, EN61000-3-2,3,
S CP -75 S e ri e s
EN61000-4-2,3,4,5,6,8,11
Connection ......................... 3+8P/ 3.96mm pitch, 4P/2.5mm pitch,
JST:B3P/B8P-VH, B4B-XH
Packing .............................. 0.23kg ; 63pcs / 15.5kg / 1.35CUFT (PCB)
0.44kg ; 32pcs / 15.0kg / 0.64CUFT (case)
We are a TQM (Total Quality Management) company
and ISO-9001 certified since 1994.
Model No.
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at [email protected] for information of your local
distributors.
Tol.
R&N
Effi.
Max.
±1%
100mV
86%
100W
13.8V, 0~2.5A
(Charger)
100mV
88%
101W
PSC-100A
ƒ
PSC-100B
ƒ
27.6V, 0~3.50A
±1%
27.6V, 0~1.25A
(Charger)
ƒ = blank, -C ;
64
Output
13.8V, 0~7.0A
Blank: PCB Type, -C: Enclosed Type
Security Series
55~155W Single and Dual Output
55W 1~2 Output with Battery Charger
CASE: 901
159x 97x 38 mm
155W 1~2 Output with Battery Charger and PFC Function
• Universal AC input / Full range
• Protections: Short circuit / Overload /
Over voltage
• Battery low protection
(except for ADS series)
• DC alarm signal (optional)
• Cooling by free air convection
• Fixed switching frequency at 45kHz
• Approvals: UL / CUL / TUV / CB / CE
• 100% full load burn-in test
• 2 years warranty
CASE: 906B
199x 110x 50 mm
• Universal AC input / Full range
• PF>[email protected] and full load
• Protections: Short circuit / Overload /
Over voltage
• Battery low protection
(except for ADS series)
• Cooling by free air convection
• Fixed switching frequency at 134kHz
• Approvals: UL / CUL / TUV / CB / CE
• 100% full load burn-in test
• 2 years warranty
AC input voltage range ..... 88~264VAC; 124~370VDC
AC input voltage range .......... 88~264VAC; 124~370VDC
AC inrush current ................. Cold start, 20A at 115VAC, 40A at 230VAC
DC adjustment range ............ 12V, 24V: ±10%
AC inrush current ............. Cold start, 20A at 115VAC, 40A at 230VAC
DC adjustment range ........ 12V, 24V, 48V: ±10%
13.8V: 12~14.5V; 27.6V: 24~29V; 54V: 48~58V
13.8V: 12~14.5V; 27.6V: 24~29V
Overload protection .............. 105%~150% hiccup mode, auto-recovery
Over voltage protection ......... CH1: 105%~135% rated output voltage
Setup, rise, hold up time ....... 800ms, 50ms, 80ms at full load and 230VAC
Overload protection .......... CH1,2: 105%~135%, charger: 0.51~0.9A;
constant current limiting, auto-recovery
Over voltage protection .... CH1: 115%~135% rated output voltage
Withstand voltage ................. I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1minute
Working temperature ............. -10~+60°C (refer to output derating curve)
Setup, rise, hold up time ... 1000ms, 90ms, 24ms at full load and 230VAC
Safety standards .................. UL60950-1, TUV EN60950-1 approved
EMC standards ..................... EN55022 class B, EN61000-3-2,3,
Working temperature ........ -10~+60° C (refer to output derating curve)
EN61000-4-2,3,4,5,6,8,11
Connection .......................... 8P/ 8.25mm pitch terminal block
Packing ............................... 0.57kg ; 24pcs / 13.7kg / 0.75CUFT
EMC standards ................ EN55022 class B, EN61000-3-2,3,
Withstand voltage ............ I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1minute
Safety standards .............. UL60950-1, TUV EN60950-1 approved
EN61000-4-2,3,4,5,6,8,11
Connection ...................... 8P/ 9.5mm pitch terminal block
Packing ........................... 1.0kg ; 16pcs / 16.0kg / 0.95CUFT
S in g le O u t p u t w i t h 5 V , 4 A DC-DC Co nv e rte r
Model No.
Output
Tol.
R&N
Effi.
Max.
S i ngl e O ut put w i t h 5 V , 3 A D C - D C C onv e r t e r
ADS-5512
12V, 0~4.0A
±1%
100mV
76%
51W
Model No.
Output
Tol.
R&N
Effi.
Max.
5V, 0~4.0A
±3%
100mV
24V, 0~2.5A
±1%
100mV
79%
58W
ADS-15512
12V, 0~12.5A
±2%
150mV
77%
153W
5V, 0~4.0A
±3%
100mV
5V, 0~3.00A
±3%
100mV
24V, 0~6.50A
±1%
150mV
82%
154W
5V, 0~3.00A
±3%
100mV
48V, 0~3.20A
±1%
240mV
82%
154W
5V, 0~3.00A
±5%
100mV
ADS-5524
S in g le O u t p u t w i t h B a t t ery Cha rg e r (UPS Func ti on)
Model No.
Output
Tol.
R&N
AD-55A
13.8V, 0~4.0A
±1%
13.4V, 0~0.23A
(Charger)
AD-55B
27.6V, 0~2.0A
±1%
26.5V, 0~0.16A
(Charger)
ADS-15524
Effi.
Max.
100mV
71%
51W
100mV
74%
54W
ADS-15548
S i ngl e O ut put w i t h B a t t e r y C ha r ge r ( U P S Func t i on)
Du al Out p u t w i t h B a t t e ry Cha rg e r (UPS F unc ti on)
Model No.
ADD-55A
Output
13.8V, 0~3.50A
5V, 0~4.00A
ADD-55B
Tol.
R&N
Effi.
Max.
±1%
100mV
71%
53W
±3%
100mV
13.4V, 0~0.23A
(Charger)
27.6V, 0~2.00A
±1%
150mV
±3%
150mV
5V, 0~4.00A
26.5V, 0~0.16A
Model No.
Output
Tol.
R&N
Effi.
Max.
AD-155A
13.8V, 0~11.5A
±2%
150mV
80%
152W
13.3V, 0~0.50A
(Charger)
150mV
84%
152W
240mV
84%
157W
AD-155B
AD-155C
74%
55W
27.6V, 0~5.50A
±1%
27.1V, 0~0.50A
(Charger)
54.0V, 0~2.70A
±1%
53.5V, 0~0.50A
(Charger)
D ua l O ut put w i t h B a t t e r y C ha r ge r ( U P S Func t i on)
(Charger)
Model No.
ADD-155A
Block Diagram
Output
13.8V, 0~10.5A
5V, 0~3.00A
ADD-155B
ADD-155C
R&N
Effi.
Max.
±1%
150mV
78%
153W
±3%
100mV
81%
153W
81%
150W
13.3V, 0~0.50A
(Charger)
27.6V, 0~5.00A
±1%
200mV
5V, 0~3.00A
±3%
100mV
27.1V, 0~0.50A
(Charger)
54.0V, 0~2.50A
±1%
240mV
±5%
100mV
5V, 0~3.00A
53.5V, 0~0.20A
65
Tol.
(Charger)
DC/DC Converter
0 . 5 ~ 1 W M o d u l e Ty p e
0.5W DC-DC Regulated Single Output
•
•
•
•
•
•
•
•
•
•
0.89"x 0.39"x 0.33"
1W DC-DC Unregulated Single Output
1000VDC I/O isolation
Internal SMD technology
Built-in EMI filter
Protection: Short circuit
Cooling by free air convection
Non-conductive plastic case
Dual in line package
100% full load burn-in test
Low cost, high reliability
2 years warranty
M ech an ism
•
•
•
•
•
•
•
•
•
•
0.89"x 0.39"x 0.33"
P i n C onf i gur a tion
1000VDC I/O isolation
Internal SMD technology
Built-in EMI filter
Protection: Short circuit
Cooling by free air convection
Non-conductive plastic case
Dual in line package
100% full load burn-in test
Low cost, high reliability
2 years warranty
Mechanism
Unit: mm(inch)
Pin Config u ra tio n
Unit: mm(inch)
Pin No.
Output
Pin No.
Output
1 & 16
+Vin
1 & 16
+Vin
6 & 11
-Vout
6 & 11
-Vout
7 & 10
+Vout
7 & 10
+Vout
8 & 9
-Vin
8 & 9
-Vin
Voltage set point accuracy.... ±2% (typical)
Voltage set point accuracy ... ±2% (max.)
Line regulation ................... ±1% (max.)
Line regulation ................... ±1.2% (max.) for 1% input variation
Load regulation .................. ±1% (max.)@10~100% load
Load regulation .................. ±8% (max.)@20~100% load
Input reflected ripple ........... 120mVp-p
Input reflected ripple .......... 120mVp-p
Efficiency .......................... 60% (typical)
Efficiency .......................... 83% (typical)
Short circuit protection ........ Continuous, auto-recovery
Short circuit protection ....... Momentary
Switching frequency ........... 50kHz (min.)
Switching frequency ........... 50kHz (min.)
I/O isolation voltage ........... 1000VDC (min.)
I/O isolation voltage ........... 1000VDC (min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
I/O isolation resistance ....... 0ȍPLQ#9'&
Isolation capacitance .......... 80pF (max.)
Isolation capacitance .......... 80pF (max.)
Working temperature ........... -25°C to +60°C (no derating), +71°[email protected]% load
Working temperature .......... -25°C to +60°C (no derating), +71° C @80% load
Storage temperature ........... -25°C to +105°C
Storage temperature ........... -25° C to +105° C
Temp. Coefficient ............... ±0.03% / °C (max.)
Temp. Coefficient ............... ±0.03% / °C (max.)
Case material ..................... non-conductive plastic
Case material .................... non-conductive plastic
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
Output
(VDC)
Current
(mA)
SRS-0505
5±10%
5
100
100
SUS01L-05
SRS-0509
5±10%
9
56
100
SUS01L-09
5±10%
5
200
100
5±10%
9
111
100
SRS-0512
5±10%
12
42
100
SUS01L-12
5±10%
12
84
100
SRS-0515
5±10%
15
34
100
SUS01L-15
5±10%
15
67
100
SRS-1205
12±10%
5
100
SRS-1209
12±10%
9
56
100
SUS01M-05
12±10%
5
200
100
100
SUS01M-09
12±10%
9
111
100
SRS-1212
12±10%
12
SRS-1215
12±10%
15
42
100
SUS01M-12
12±10%
12
84
100
34
100
SUS01M-15
12±10%
15
67
100
SRS-2405
24±10%
5
100
100
SUS01N-05
24±10%
5
200
100
SRS-2409
SRS-2412
24±10%
9
56
100
SUS01N-09
24±10%
9
111
100
24±10%
12
42
100
SUS01N-12
24±10%
12
84
100
SRS-2415
24±10%
15
34
100
SUS01N-15
24±10%
15
67
100
SRS-4805
48±10%
5
100
100
SUS01O-05
48±10%
5
200
100
SRS-4809
48±10%
9
56
100
SUS01O-09
48±10%
9
111
100
SRS-4812
48±10%
12
42
100
SUS01O-12
48±10%
12
84
100
SRS-4815
48±10%
15
34
100
SUS01O-15
48±10%
15
67
100
Model No.
66
Input
(VDC)
R&N
(mVp-p)
DC/DC Converter
1 W M o d u l e Ty p e
1W DC-DC Unregulated Single Output
1W DC-DC Unregulated Single and Dual Output
• 1000VDC I/O isolation
• 3000VDC I/O isolation
• Internal SMD technology
• Internal SMD technology
• Protection: Short circuit
• Protection: Short circuit
•
•
•
•
• Cooling by free air convection
• Non-conductive plastic case
• SMD package style
• 100% full load burn-in test
• Low cost, high reliability
• Low cost, high reliability
0.60"x 0.295"x 0.255"
• 1 year warranty
Pin No.
Output
-Vin
+Vin
NC
-Vout
+Vout
NC
NC
NC
15.24
12. 7
7
TOP VIEW
1
2
3
2.54
Voltage set point accuracy .......... ±8% (max.)
8
5
4.25
12 11 10
6. 5
Pin No.
1
2
3
4
5
6
7
8
Unit: mm(inch)
7. 5
Unit: mm(inch)
Pin Configuration
Mechanism
Pin Configuration
11.2 MA X
Mechanism
• 1 year warranty
6.25
0.50"x 0.30"x 0.24"
Cooling by free air convection
Non-conductive plastic case
SMD package style
100% full load burn-in test
1.27
6
0. 6±0.05
0.25
1
2
3
5
6
7
8
10
11
12
Output
Single
-Vin
+Vin
NC
-Vout
NC
NC
+Vout
NC
NC
NC
Voltage set point accuracy ........... ±8% (max.)
Line regulation ........................... ±1.2% (max.) for 1% input variation
Line regulation ........................... ±1.2% (max.) for 1% input variation
Load regulation .......................... ±8% (max.)@20~100% load
Input reflected ripple ................... 100mVp-p
Load regulation .......................... ±8% (max.)@20~100% load
Efficiency .................................. 75% (typical)
Efficiency .................................. 79% (typical)
Short circuit protection ................ Momentary
Short circuit protection ................ Momentary
Switching frequency .................... 100kHz (typical)
Switching frequency ................... 100kHz (typical)
I/O isolation voltage ................... 1000VDC (min.)
I/O isolation voltage ................... 3000VDC (min.)
I/O isolation resistance ............... 0ȍPLQ#9'&
I/O isolation resistance ............... 0ȍPLQ#9'&
Working temperature .................. -40°C to +85°C
Working temperature .................. -40° C to +85° C
Storage temperature ................... -40°C to +105°C
Storage temperature ................... -40° C to +105° C
Temp. Coefficient ....................... ±0.03% / °C (max.)
Temp. Coefficient ....................... ±0.03% / ° C (max.)
Case material ............................ non-conductive plastic
Case material ............................ non-conductive plastic
Safety standards ........................ UL60950-1 approved
Safety standards ........................ UL60950-1, CSA C22.2 approved
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
Model No.
SBT01L-05
5±10%
5
200
100
SFT01L-05
Input
(VDC)
5±10%
SBT01L-09
5±10%
9
111
100
SFT01L-09
SBT01L-12
5±10%
12
84
100
SFT01L-12
SBT01L-15
5±10%
15
67
100
SBT01M-05
12±10%
5
200
100
100
SBT01M-09
12±10%
9
111
Dual
-Vin
+Vin
NC
COM
-Vout
NC
+Vout
NC
NC
NC
SBT01M-12
12±10%
12
84
100
SBT01M-15
12±10%
15
67
100
Output
(VDC)
5
Current
(mA)
200
5±10%
9
111
100
5±10%
12
84
100
SFT01L-15
5±10%
15
67
100
SFT01M-05
12±10%
5
200
100
SFT01M-09
12±10%
9
111
100
SFT01M-12
12±10%
12
84
100
SFT01M-15
12±10%
15
67
100
DET01L-05
Input
(VDC)
5±10%
Output
(VDC)
±5
Current
(mA)
±100
R&N
(mVp-p)
100
DET01L-09
5±10%
±9
±56
100
Model No.
We provide specification, drawing, test report and more
information, please visit our website —
http://www.meanwell.com
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at [email protected] for information of your local
distributors.
67
R&N
(mVp-p)
100
DET01L-12
5±10%
±12
±42
100
DET01L-15
5±10%
±15
±33
100
DET01M-05
12±10%
±5
±100
100
DET01M-09
12±10%
±9
±56
100
DET01M-12
12±10%
±12
±42
100
DET01M-15
12±10%
±15
±33
100
DC/DC Converter
1 W M o d u l e Ty p e
1W DC-DC Unregulated Single Output
1W DC-DC Regulated Single Output
0.77"x 0.28"x 0.4"
1000VDC I/O isolation
Internal SMD technology
Built-in EMI filter
Protection: Short circuit / Overload
Cooling by free air convection
Non-conductive plastic case
Single in line package
100% full load burn-in test
Low cost, high reliability
2 years warranty
Mechanism
• 1 5 0 0 V D C I / O iso la t ion
• Operating temperature range
-40~85 o C w it h o u t d e r a t i n g
• Internal SMD technology
• Built-in EMI filter
• Protection: Short circuit
• Cooling by free air convection
• Non-conductive plastic case
• Dual in line package for SMA01
• 100% full load burn-in test
• Industry standard pinout
• 2 years warranty
0.46"x 0.24"x 0.4"
0.5"x 0.4"x 0.28"
Pin Configuration
Mechanism
Unit: mm(inch)
Pin Configuration
11.6 (0.46)
Output
1
2
4
6
+Vout
-Vin
-Vout
+Vout
FRONT
VIEW
10.14 (0.40)
Pin No.
6.10 (0.24)
•
•
•
•
•
•
•
•
•
•
1.2 (0.05)
1 2 3 4
BOTTON VIEW
3.81 (0.15)
Unit: mm(inch)
2.54 (0.10)
S MU01
Pin No.
Output
1
-Vin
2
+Vin
3
-Vout
4
+Vout
12.7 (0.50)
3.81 (0.15)
Case material ..................... non-conductive plastic
EMC .................................. Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
Output
(VDC)
Current
(mA)
7
0.25 (0.01)
5
R&N
(mVp-p)
SPR01L-05
5±10%
5
200
100
SPR01L-09
5±10%
9
100
100
SPR01L-12
5±10%
12
84
100
SPR01L-15
5±10%
15
67
100
SPR01M-05
12±10%
5
200
100
SPR01M-09
12±10%
9
100
100
SPR01M-12
12±10%
12
84
100
SPR01M-15
12±10%
15
67
100
SPR01N-05
24±10%
5
200
100
SPR01N-09
24±10%
9
100
100
SPR01N-12
24±10%
12
84
100
SPR01N-15
24±10%
15
67
100
SPR01O-05
48±10%
5
200
100
SPR01O-09
48±10%
9
100
100
SPR01O-12
48±10%
12
84
100
SPR01O-15
48±10%
15
67
100
0.5 (0.02)
Unit: mm(inch)
S MA01
Pin No.
Output
1
-Vin
4
+Vin
5
+Vout
7
-Vout
Voltage set point accuracy ..... ±2% (max.)
Line regulation ...................... ±1.2% (max.) for 1% input variation
Load regulation ..................... ±8% (max.)@20~100% load
Input reflected ripple ............. 100mVp-p
Efficiency ..............................80% (typical)
Short circuit protection ...........Momentary
Switching frequency ...............100kHz (min.)
I/O isolation voltage .............. 1500VDC (min.)
I/O isolation resistance .......... 0ȍPLQ#9'&
Isolation capacitance ............. 80pF (max.)
Working temperature ............. -40~+85° C (no derating)
Storage temperature ............. -55° C to +125° C
EMC .................................... Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
Input
Output
Current
R&N
Model No.
(VDC)
(VDC)
(mA)
(mVp-p)
SMU01L-05
5±10%
5
200
100
SMU01L-09
5±10%
9
110
100
SMU01L-12
5±10%
12
84
100
SMU01L-15
5±10%
15
67
100
I/O isolation resistance ........ 0ȍPLQ
Isolation capacitance .......... 80pF (max.)
Working temperature ........... -25~+71°C (refer to output derating curve)
Storage temperature ............ -25°C to +105°C
Temp. Coefficient ................ ±0.03% / °C (max.)
Input
(VDC)
BOTTON
VIEW
4
5.08 (0.2)
Overload protection ............. >110% hiccup mode, auto-recovery
Short circuit protection ........ Continuous, auto-recovery
Switching frequency ............ 50kHz (min.)
I/O isolation voltage ............ 1000VDC (min.)
Model No.
SIDE VIEW
7.62 (0.30)
Voltage set point accuracy ... ±2% (typical)
Line regulation .................... ±1% (max.)
Load regulation ................... ±1% (max.)@10~100% load
Efficiency ........................... 65% (typical)
10.16 (0.40)
7.1 (0.28)
7.62 (0.30)
1
SMU01M-05
SMU01M-09
SMU01M-12
SMU01M-15
12±10%
12±10%
12±10%
12±10%
5
9
12
15
200
110
84
67
100
100
100
100
SMU01N-05
SMU01N-09
SMU01N-12
SMU01N-15
24±10%
24±10%
24±10%
24±10%
5
9
12
15
200
110
84
67
100
100
100
100
SMA01L-05
SMA01L-09
SMA01L-12
SMA01L-15
Input
(VDC)
5±10%
5±10%
5±10%
5±10%
Output
(VDC)
5
9
12
15
Current
(mA)
200
110
84
67
R&N
(mVp-p)
100
100
100
100
SMA01M-05
SMA01M-09
SMA01M-12
SMA01M-15
12±10%
12±10%
12±10%
12±10%
5
9
12
15
200
110
84
67
100
100
100
100
SMA01N-05
SMA01N-09
SMA01N-12
SMA01N-15
24±10%
24±10%
24±10%
24±10%
5
9
12
15
200
110
84
67
100
100
100
100
Model No.
68
DC/DC Converter
2 ~ 3 W M o d u l e Ty p e
2~3W DC-DC Regulated Single Output
2~3W DC-DC Unregulated Single Output
0.77"x 0.28"x 0.4"
0.77"x 0.30"x 0.4"
•
•
•
•
•
•
•
•
•
•
3000VDC I/O isolation
Internal SMD technology
Built-in EMI filter
Protection: Short circuit
Cooling by free air convection
Non-conductive plastic case
Single in line package
100% full load burn-in test
Low cost, high reliability
2 years warranty
Mechanism
• 2:1 wide input range
• 4:1 wide input range (option)
f o r S PA 0 2
• 1 0 0 0 V D C I / O iso la t ion
• 3 0 0 0 V D C I / O iso la t ion ( o p t i o n )
f o r S PA 0 2
• Built-in remote ON/OFF control
• Built-in EMI filter
• Protection: Short circuit / Overload
• Cooling by free air convection
• Non-conductive plastic case
• Single in line package
• 100% full load burn-in test
• Modified models available:
output 3.3V / 9V
• 2 years warranty
0.86"x 0.36"x 0.44"
Pin Configuration
Unit: mm(inch)
Mechanism
Pin No.
Output
1
2
5
7
+Vin
-Vin
-Vout
+Vout
Pin Configuration
Unit: mm(inch)
7.1 (0.28) for SPU02
7.5 (0.30) for SPU03
Voltage set point accuracy ... ±2% (max.)
Line regulation .................... ±1.2% (max.) for 1% input variation
Load regulation ................... ±8% (max.)@20~100% load
Efficiency ........................... 83% (typical) for SPU02; 88% (typical) for SPU03
Short circuit protection ........ Momentary
Switching frequency ............ 100kHz (min.) for SPU02; 60kHz (min.) for SPU03
I/O isolation voltage ............ 3000VDC (min.)
I/O isolation resistance ........ 0ȍPLQ
Isolation capacitance ........... 80pF (max.)
Working temperature ........... -40~+71°C (refer to output derating curve) for SPU02
-40~+90°C(refer to output derating curve) for SPU03
Storage temperature ........... -40°C to +105°C
Temp. Coefficient ................ ±0.03% / °C (max.)
Case material ..................... non-conductive plastic
EMC .................................. Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
Model No.
Input
(VDC)
Output
(VDC)
R&N
(mVp-p)
5
Current
(mA)
400
SPU02L-05
5±10%
SPU02L-12
5±10%
12
167
100
SPU02L-15
5±10%
15
133
100
SPU02M-05
12±10%
5
400
100
SPU02M-12
12±10%
12
167
100
SPU02M-15
12±10%
15
133
100
SPU02N-05
24±10%
5
400
100
SPU02N-12
24±10%
12
167
100
SPU02N-15
24±10%
15
133
100
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
SPU03L-05
5±10%
5
600
50
SPU03L-12
5±10%
12
250
50
SPU03L-15
5±10%
15
200
50
12±10%
5
600
50
SPU03M-12
12±10%
12
250
50
SPU03M-15
12±10%
15
200
50
SPU03N-05
24±10%
5
600
50
SPU03N-12
24±10%
12
250
50
SPU03N-15
24±10%
15
200
50
Output
1
2
3
5
6
7
8
-Vin
+Vin
R.C.
N.C.
+Vout
-Vout
N.C.
Voltage set point accuracy .... ±2% (max.)
Line regulation ..................... ±0.5% (max.)
Load regulation .................... ±0.5% (max.)@10~100% load
Efficiency ............................. 82% (typical)
Short circuit protection .......... Continuous, auto-recovery
Overload protection .............. 150%~250%, auto-recovery
Switching frequency ............. 100KHz (min.)
I/O isolation voltage .............. 1000VDC (min.)
I/O isolation resistance ......... 0ȍPLQ
Isolation capacitance ............ 80pF (max.)
Working temperature ............. -40~+85° C (refer to output derating curve)
Storage temperature ............. -40° C to +105° C
Temp. Coefficient ................. ±0.03% / °C (max.)
Case material ....................... non-conductive plastic
EMC .................................... Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
Model No.
100
SPU03M-05
Pin No.
SPA02E-05
SPA02E-12
SPA02E-15
SPA02A-05
SPA02A-12
SPA02A-15
SPA02B-05
SPA02B-12
SPA02B-15
SPA02C-05
SPA02C-12
SPA02C-15
Model No.
SPB03E-05
SPB03E-12
SPB03E-15
SPB03A-05
SPB03A-12
SPB03A-15
SPB03B-05
SPB03B-12
SPB03B-15
SPB03C-05
SPB03C-12
SPB03C-15
69
Input
(VDC)
4.5~9
4.5~9
4.5~9
9~18
9~18
9~18
18~36
18~36
18~36
36~72
36~72
36~72
Output
(VDC)
5
12
15
5
12
15
5
12
15
5
12
15
Current
(mA)
400
150
120
400
167
133
400
167
133
400
167
133
R&N
(mVp-p)
60
60
60
60
60
60
60
60
60
60
60
60
Input
(VDC)
4.5~9
4.5~9
4.5~9
9~18
9~18
9~18
18~36
18~36
18~36
36~72
36~72
36~72
Output
(VDC)
5
12
15
5
12
15
5
12
15
5
12
15
Current
(mA)
600
250
200
600
250
200
600
250
200
600
250
200
R&N
(mVp-p)
50
60
60
50
60
60
50
60
60
50
60
60
DC/DC Converter
3 ~ 6 W M o d u l e Ty p e
3W DC-DC Regulated Single and Dual Output
•
•
•
•
•
•
•
•
•
•
•
1.25"x 0.8"x 0.48"
5~6W DC-DC Regulated Single and Dual Output
2:1 wide input range
4:1 wide input range (option)
1000VDC I/O isolation
3000VDC I/O isolation (option)
Built-in EMI filter
Protection: Short circuit / Overload
Cooling by free air convection
Five-sided shield metal case
100% full load burn-in test
Low cost, high reliability
2 years warranty
Mechanism
•
•
•
•
•
•
•
•
•
•
•
1.25"x 0.8"x 0.48"
Pin Configuration
2:1 wide input range
4:1 wide input range(option)
1000VDC I/O isolation
3000VDC I/O isolation(option)
Built-in EMI filter
Protection: Short circuit / Overload
Cooling by free air convection
Five-sided shield metal case
100% full load burn-in test
Low cost, high reliability
2 years warranty
Pin Configuration
Mechanism
Unit: mm(inch)
Unit: mm(inch)
0.6+0.1/-0(0.024)
Pin No.
2&3
9
11
14
16
2 2& 23
Output
Single Dual
-Vin
-Vin
NC
COM
NC
-Vout
+Vout +Vout
-Vout
COM
+Vin
+Vin
0.6+0.1/-0(0.024)
Pin No.
2&3
9
11
14
16
2 2& 23
Voltage set point accuracy .... ±2% (max.)
Line regulation ..................... ±0.5% (max.)
Load regulation .................... ±0.5% (max.)@10~100% load
Efficiency ............................ 82% (typical)
Short circuit protection ......... Continuous, auto-recovery
Overload protection ............. 160%~250%, auto-recovery
I/O isolation voltage ............. 1000VDC (min.)
I/O isolation resistance ........ 0ȍPLQ#9'&
Isolation capacitance ............ 80pF (max.)
Working temperature ............ -40~+71°C (refer to output derating curve)
Storage temperature ............. -40°C to +105°C
Temp. Coefficient ................. ±0.03% / °C (max.)
Case material ...................... Five-sided shield metal case
EMC ................................... Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
S in g le O u t p u t
Output
Single Dual
-Vin
-Vin
NC
COM
NC
-Vout
+Vout +Vout
-Vout
COM
+Vin
+Vin
Voltage set point accuracy ..... ±2% (max.)
Line regulation ...................... ±0.5% (max.)
Load regulation ..................... ±0.5% (max.)@20~100% load
Efficiency ..............................85% (typical)
Short circuit protection ...........Continuous, auto-recovery
Overload protection ............... 150%~250%, auto-recovery
I/O isolation voltage .............. 1000VDC (min.)
I/O isolation resistance .......... 0ȍPLQ#9'&
Isolation capacitance ............. 80pF (max.)
Working temperature ..............-40~+71°C (refer to output derating curve)
Storage temperature .............. -40° C to +105° C
Temp. Coefficient .................. ±0.03% / °C (max.)
Case material ....................... Five-sided shield metal case
EMC .................................... Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
S i ngl e O ut put
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
SCW03A-05
9~18
5
600
50
SCW03A-12
9~18
12
250
60
SCW03A-15
9~18
15
200
60
SCW03B-05
18~36
5
600
50
SCW03B-12
18~36
12
250
60
SCW03B-15
18~36
15
200
60
SCW03C-05
36~72
5
600
50
SCW03C-12
36~72
12
250
60
SCW03C-15
36~72
15
200
60
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
DCW03A-05
9~18
±5
±300
50
Model No.
DCW03A-12
9~18
±12
±125
60
DCW03A-15
9~18
±15
±100
60
DCW03B-05
18~36
±5
±300
50
DCW03B-12
18~36
±12
±125
60
DCW03B-15
18~36
±15
±100
60
DCW03C-05
36~72
±5
±300
50
DCW03C-12
36~72
±12
±125
60
DCW03C-15
36~72
±15
±100
60
DCW05A-05
DCW05A-12
DCW05A-15
DCW05B-05
DCW05B-12
DCW05B-15
DCW05C-05
DCW05C-12
DCW05C-15
Model No.
SCW05A-05
SCW05A-09
SCW05A-12
SCW05A-15
SCW05B-05
SCW05B-09
SCW05B-12
SCW05B-15
SCW05C-05
SCW05C-09
SCW05C-12
SCW05C-15
Du al Out p u t
Input
(VDC)
9~18
9~18
9~18
9~18
18~36
18~36
18~36
18~36
36~72
36~72
36~72
36~72
Output
(VDC)
5
9
12
15
5
9
12
15
5
9
12
15
Current
(mA)
1000
556
470
400
1000
556
470
400
1000
556
470
400
R&N
(mVp-p)
50
60
60
60
50
60
60
60
50
60
60
60
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~72
36~72
36~72
Output
(VDC)
±5
±12
±15
±5
±12
±15
±5
±12
±15
Current
(mA)
±500
±230
±190
±500
±230
±190
±500
±230
±190
R&N
(mVp-p)
50
60
60
50
60
60
50
60
60
D ua l O ut put
70
DC/DC Converter
5 ~ 8 W M o d u l e Ty p e
8W DC-DC Regulated Single and Dual Output
5W DC-DC Regulated Single and Dual Output
•
•
•
•
•
•
•
•
•
•
•
2"x 1"x 0.44"
2:1 wide input range
4:1 wide input range(option)
1000VDC I/O isolation
3000VDC I/O isolation(option)
Built-in EMI filter
Protection: Short circuit / Overload
Cooling by free air convection
Six-sided shield metal case
100% full load burn-in test
Low cost, high reliability
2 years warranty
Mechanism
• 2:1 wide input range
• 1 0 0 0 V D C I / O iso la t ion
• Built-in EMI filter
• Protection: Short circuit / Overload
• Cooling by free air convection
• Five-sided shield metal case
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
1.25"x 0.8"x 0.48"
Pin Configuration
(0.44)
Unit: mm(inch)
Pin No.
25.4 (1.00)
1
2
3
4
5
50.8 (2.00)
Output
Single Dual
+Vin
+Vin
-Vin
-Vin
+Vout +Vout
No Pin COM
-Vout -Vout
0.6+0.1/-0(0.024)
Output
(VDC)
5
Current
(mA)
1000
R&N
(mVp-p)
50
Line regulation ..................... ±0.5% (max.)
Load regulation .................... ±0.5% (max.)@20~100% load
Efficiency ............................ 82% (typical)
Short circuit protection ......... Continuous, auto-recovery
Overload protection ............. 110%~250%, auto-recovery
I/O isolation voltage ............. 1000VDC (min.)
I/O isolation resistance ......... 0ȍPLQ#9'&
Isolation capacitance ........... 250pF (max.)
Working temperature ............ -40~+71° C (refer to output derating curve)
Storage temperature ............ -40° C to +105° C
SLW05A-05
SLW05A-09
9~18
9
556
60
SLW05A-12
9~18
12
417
60
SLW05A-15
9~18
15
333
60
SLW05B-05
18~36
5
1000
50
SLW05B-09
18~36
9
556
60
SLW05B-12
18~36
12
417
60
SLW05B-15
18~36
15
333
60
SLW05C-05
36~72
5
1000
50
SLW05C-09
36~72
9
556
60
SLW05C-12
36~72
12
417
60
SLW05C-15
36~72
15
333
60
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
DLW05A-05
9~18
±5
±500
50
Model No.
DCW08A-05
DCW08A-12
DCW08A-15
DCW08B-05
DCW08B-12
DCW08B-15
DCW08C-05
DCW08C-12
DCW08C-15
Temp. Coefficient ................. ±0.03% / °C (max.)
Case material ..................... Five-sided shield metal case
EMC .................................. Compliance to EN55022 class B,
S i ngl e O ut put
Model No.
SCW08A-05
SCW08A-12
SCW08A-15
SCW08B-05
SCW08B-12
SCW08B-15
SCW08C-05
SCW08C-12
SCW08C-15
D u al Out p u t
DLW05A-12
9~18
±12
±208
60
9~18
±15
±167
60
DLW05B-05
18~36
±5
±500
50
DLW05B-12
18~36
±12
±208
60
DLW05B-15
18~36
±15
±167
60
DLW05C-05
36~72
±5
±500
50
DLW05C-12
36~72
±12
±208
60
DLW05C-15
36~72
±15
±167
60
Output
Single Dual
-Vin
-Vin
NC
COM
NC
-Vout
+Vout +Vout
-Vout
COM
+Vin
+Vin
Voltage set point accuracy .... ±2% (max.)
Input
(VDC)
9~18
DLW05A-15
Pin No.
2&3
9
11
14
16
2 2& 23
Voltage set point accuracy ... ±2% (max.)
Line regulation ................... ±0.2% (max.)
Load regulation .................. ±0.5% (max.)@10~100% load
Efficiency .......................... 85% (typical)
Short circuit protection ....... Continuous, auto-recovery
Overload protection ............ 160%~250%, auto-recovery
I/O isolation voltage ........... 1000VDC (min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
Working temperature .......... -25~+71°C (refer to output derating curve)
Storage temperature ........... -25°C to +105°C
Temp. Coefficient ............... ±0.03% / °C (max.)
Case material .................... Six-sided shield metal case
EMC ................................. Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
S ingle O u t p u t
Model No.
Pin Configuration
Mechanism
Unit: mm(inch)
EN61000-4-2,3,4,5,6,8, FCC part15 class B
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~72
36~72
36~72
Output
(VDC)
5
12
15
5
12
15
5
12
15
Current
(mA)
1600
670
533
1600
670
533
1600
670
533
R&N
(mVp-p)
50
60
60
50
60
60
50
60
60
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~72
36~72
36~72
Output
(VDC)
±5
±12
±15
±5
±12
±15
±5
±12
±15
Current
(mA)
±800
±335
±267
±800
±335
±267
±800
±335
±267
R&N
(mVp-p)
50
60
60
50
60
60
50
60
60
D ua l O ut put
71
DC/DC Converter
1 0 ~ 1 2 W M o d u l e Ty p e
10W DC-DC Regulated Single and Dual Output
•
•
•
•
•
•
•
•
•
•
•
2"x 1"x 0.44"
12W DC-DC Regulated Single and Dual Output
2:1 wide input range
4:1 wide input range(option)
1000VDC I/O isolation
3000VDC I/O isolation (option)
Built-in EMI filter
Protection: Short circuit / Overload
Cooling by free air convection
Six-sided shield metal case
100% full load burn-in test
Low cost, high reliability
2 years warranty
Mechanism
Pin Configuration
(0.44)
Mechanism
Pin No.
25.4 (1.00)
1
2
3
4
5
50.8 (2.00)
Output
Single Dual
+Vin
+Vin
-Vin
-Vin
+Vout +Vout
No Pin COM
-Vout -Vout
SKE10A-05
SKE10A-12
SKE10A-15
SKE10A-24
SKE10B-05
SKE10B-12
SKE10B-15
SKE10B-24
SKE10C-05
SKE10C-12
SKE10C-15
SKE10C-24
Output
(VDC)
5
12
15
24
5
12
15
24
5
12
15
24
Current
(mA)
2000
840
666
420
2000
840
666
420
2000
840
666
420
0.6+0.1/-0
(0.024)
DKE10A-05
DKE10A-12
DKE10A-15
DKE10A-24
DKE10B-05
DKE10B-12
DKE10B-15
DKE10B-24
DKE10C-05
DKE10C-12
DKE10C-15
DKE10C-24
Input
(VDC)
9~18
9~18
9~18
9~18
18~36
18~36
18~36
18~36
36~72
36~72
36~72
36~72
Output
(VDC)
±5
±12
±15
±24
±5
±12
±15
±24
±5
±12
±15
±24
Current
(mA)
±1000
±420
±333
±210
±1000
±420
±333
±210
±1000
±420
±333
±210
Pin No.
1
1
2&3
9
11
14
16
2 2& 23
2.54(0.1)
5.08(0.2)
Output
Single Dual
R.C
R.C
-Vin
-Vin
NC
COM
NC
-Vout
+Vout +Vout
-Vout
COM
+Vin
+Vin
Voltage set point accuracy ... ±2% (max.)
Line regulation ................... ±0.5% (max.)
Load regulation .................. ±0.5% (max.)@20~100% load
Efficiency ........................... 85% (typical)
Short circuit protection ........ Continuous, auto-recovery
Overload protection ............ 110%~180%, auto-recovery
I/O isolation voltage ............ 1500VDC (min.)
I/O isolation resistance ........ 0ȍPLQ#9'&
Working temperature ........... -40~+71°C (refer to output derating curve)
Storage temperature ........... -40° C to +105° C
Temp. Coefficient ................ ±0.03% / °C (max.)
R&N
(mVp-p)
50
60
60
80
50
60
60
80
50
60
60
80
Case material ..................... Five-sided shield metal case
EMC .................................. Compliance to EN55022 class A,
EN61000-4-2,3,4,5,6,8, FCC part15 class A
S i ngl e O ut put
SCW12A-05
Input
(VDC)
9~18
Output
(VDC)
5
Current
(mA)
2400
R&N
(mVp-p)
50
SCW12A-12
9~18
12
1000
60
SCW12A-15
9~18
15
800
60
SCW12B-05
18~36
5
2400
50
Model No.
Du al Out p u t
Model No.
Pin Configuration
Unit: mm(inch)
Voltage set point accuracy ... ±2% (max.)
Line regulation ................... ±0.3% (max.)
Load regulation .................. ±0.5% (max.)@10~100% load
Efficiency ........................... 85% (typical)
Short circuit protection ........ Continuous, auto-recovery
Overload protection ............ 160%~250%, auto-recovery
I/O isolation voltage ............ 1000VDC (min.)
I/O isolation resistance ........ 0ȍPLQ#9'&
Working temperature ........... -25~+71°C (refer to output derating curve)
Storage temperature ........... -25°C to +105°C
Temp. Coefficient ................ ±0.03% / °C (max.)
Case material ..................... Six-sided shield metal case
EMC .................................. Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
S in g le O u t p u t
Input
(VDC)
9~18
9~18
9~18
9~18
18~36
18~36
18~36
18~36
36~72
36~72
36~72
36~72
2:1 wide input range
1 5 0 0 V D C I / O iso la t io n
Built-in remote ON/OFF control
Built-in EMI filter
Protection: Short circuit / Overload
Cooling by free air convection
Five-sided shield metal case
100% full load burn-in test
Low cost, high reliability
Modified models available:
output 2.5V / 3.3V
• 2 years warranty
1.25"x 0.8"x 0.48"
Unit: mm(inch)
Model No.
•
•
•
•
•
•
•
•
•
•
R&N
(mVp-p)
50
60
60
80
50
60
60
80
50
60
60
80
SCW12B-12
18~36
12
1000
60
SCW12B-15
18~36
15
800
60
SCW12C-05
36~72
5
2400
50
SCW12C-12
36~72
12
1000
60
SCW12C-15
36~72
15
800
60
DCW12A-05
Input
(VDC)
9~18
Output
(VDC)
±5
Current
(mA)
±1200
R&N
(mVp-p)
50
DCW12A-12
9~18
±12
±500
60
DCW12A-15
9~18
±15
±400
60
DCW12B-05
18~36
±5
±1200
50
DCW12B-12
18~36
±12
±500
60
D ua l O ut put
Model No.
72
DCW12B-15
18~36
±15
±400
60
DCW12C-05
36~72
±5
±1200
50
DCW12C-12
36~72
±12
±500
60
DCW12C-15
36~72
±15
±400
60
DC/DC Converter
1 5 W M o d u l e Ty p e
15W DC-DC Regulated Single Output
15W DC-DC Regulated Single and Dual Output
•
•
•
•
•
•
•
•
•
•
•
• 1"x1" compact size
• 2:1 wide input range
• 1500VDC I/O isolation
• High efficiency up to 88%
• Built-in remote ON/OFF control
• Built-in EMI filter
• Trimming output (±10%)
• Protections: Short circuit / Overload
1"x 1"x 0.39"
2"x 1"x 0.44"
/ Over voltage
• Cooling by free air convection
2:1 wide input range
4:1 wide input range(option)
1 0 0 0 V D C I / O iso la t ion
3 0 0 0 V D C I / O iso la t ion ( o p t i o n )
Built-in EMI filter
Protection: Short circuit / Overload
Cooling by free air convection
Six-sided shield metal case
100% full load burn-in test
Low cost, high reliability
2 years warranty
• 100% full load burn-in test
Mechanism
Pin Configuration
Mechanism
• Low cost, high reliability
• 2 years warranty
Unit: mm(inch)
Pin Configuration
Pin No.
1
2
3
4
5
Unit: mm
12.7
(0.50)
10.16
10.16
(0.40)
(0.40)
5
Pin No.
1
2
3
4
5
6
4
20.32 (0.80)
25.04 (1.00)
6
1.0 DI A
(0.04±0.005)
1
2
2.54
(0.10)
5.08
3
7.62
2.54
(0.30)
(0.10)
5.8
9.9
(0.23)
(0.39)
Output
+Vin
-Vin
R.C
-Vout
Trim
+Vout
Output
Single Dual
+Vin
+Vin
-Vin
-Vin
+Vout +Vout
No Pin COM
-Vout -Vout
Voltage set point accuracy ... ±2% (max.)
Line regulation .................... ±0.2% (max.)
Load regulation ................... ±0.5% (max.)@10~100% load
Efficiency ........................... 82% (typical)
Short circuit protection ......... Continuous, auto-recovery
(0.20)
25.4 (1.00)
Overload protection ............. 110%~250%, auto-recovery
I/O isolation voltage ............. 1000VDC (min.)
I/O isolation resistance ........ 0ȍPLQ#9'&
Working temperature ............ -40~+71° C (refer to output derating curve)
Storage temperature ............ -40° C to +105° C
Voltage set point accuracy ... ±2% (max.)
Line regulation ................... ±0.5% (max.)
Load regulation .................. ±0.5% (max.) @10%~100% load
Overload protection ............ 110%~180%, auto-recovery
Temp. Coefficient ................ ±0.03% / °C (max.)
Case material ..................... Six-sided shield metal case
EMC ................................... Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
S i ngl e O ut put
Over voltage protection ....... Clamp by TVS diode
Efficiency .......................... 88% (typical)
I/O isolation voltage ............ 1500VDC(min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
Working temperature .......... -40~+80°C(refer to output derating curve)
Model No.
Storage temperature ........... -55°C to 100°C
SKA15A-033
SKA15A-05
SKA15A-12
SKA15A-15
SKA15B-033
SKA15B-05
SKA15B-12
SKA15B-15
SKA15C-033
SKA15C-05
SKA15C-12
SKA15C-15
Case Material .................... Six-sided shield metal case
EMC .................................. Compliance to EN55022 class A,
EN61000-4-2,3,4,5,6,8, FCC part15 classA
Model No.
Input
(VDC)
Output
(VDC)
Current
(A)
R&N
(mVp-p)
SKM15A-05
9~18
5
3.00
50
SKM15A-12
9~18
12
1.25
60
SKM15A-15
9~18
15
1.00
60
SKM15B-05
18~36
5
3.00
50
SKM15B-12
18~36
12
1.25
60
SKM15B-15
18~36
15
1.00
60
SKM15C-05
36~75
5
3.00
50
SKM15C-12
36~75
12
1.25
60
SKM15C-15
36~75
15
1.00
60
Input
(VDC)
9~18
9~18
9~18
9~18
18~36
18~36
18~36
18~36
36~72
36~72
36~72
36~72
Output
(VDC)
3.3
5
12
15
3.3
5
12
15
3.3
5
12
15
Current
(mA)
3000
3000
1250
1000
3000
3000
1250
1000
3000
3000
1250
1000
R&N
(mVp-p)
50
50
60
60
50
50
60
60
50
50
60
60
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~72
36~72
36~72
Output
(VDC)
±5
±12
±15
±5
±12
±15
±5
±12
±15
Current
(mA)
±1500
±625
±500
±1500
±625
±500
±1500
±625
±500
R&N
(mVp-p)
50
60
60
50
60
60
50
60
60
D ua l O ut put
Model No.
DKA15A-05
DKA15A-12
DKA15A-15
DKA15B-05
DKA15B-12
DKA15B-15
DKA15C-05
DKA15C-12
DKA15C-15
To Satisfy our customers is our goal —
• High Quality
• Low Cost
• Prompt Delivery
• Best Service
73
DC/DC Converter
1 5 ~ 3 0 W M o d u l e Ty p e
15W DC-DC Regulated Single and Dual Output
•
•
•
•
•
•
•
•
•
•
•
2"x 2"x 0.43"
20~30W DC -DC Reg ulated Sing le O u t p u t
2:1 wide input range
4:1 wide input range(option)
1000VDC I/O isolation
3000VDC I/O isolation(option)
Built-in EMI filter
Protections: Short circuit / Overload
Cooling by free air convection
Six-sided shield metal case
100% full load burn-in test
Low cost, high reliability
2 years warranty
Mechanism
SKA20
•
•
•
•
•
•
•
2"x 1"x 0.44"
SKM30
Pin Configuration
2"x 1"x 0.44"
•
•
•
•
•
2"x 1" compact size
2:1 wide input range
1500VDC I/O isolation
Built-in remote ON/OFF control
Built-in EMI filter
Trimming output (±10%)
Protections:
Short circuit / Overload /
Input and output over voltage
Cooling by free air convection
Six-sided shield metal case
100% full load burn-in test
Low cost, high reliability
2 years warranty
Unit: mm(inch)
20.4 (0.80)
SKE15A-05
SKE15A-12
SKE15A-15
SKE15A-24
SKE15B-05
SKE15B-12
SKE15B-15
SKE15B-24
SKE15C-05
SKE15C-12
SKE15C-15
SKE15C-24
Output
(VDC)
5
12
15
24
5
12
15
24
5
12
15
24
Current
(mA)
3000
1250
1000
625
3000
1250
1000
625
3000
1250
1000
625
R&N
(mVp-p)
50
60
60
80
50
60
60
80
50
60
60
80
Input
(VDC)
9~18
9~18
9~18
9~18
18~36
18~36
18~36
18~36
36~72
36~72
36~72
36~72
Output
(VDC)
±5
±12
±15
±24
±5
±12
±15
±24
±5
±12
±15
±24
Current
(mA)
±1500
±625
±500
±313
±1500
±625
±500
±313
±1500
±625
±500
±313
R&N
(mVp-p)
50
60
60
80
50
60
60
80
50
60
60
80
DKE15A-05
DKE15A-12
DKE15A-15
DKE15A-24
DKE15B-05
DKE15B-12
DKE15B-15
DKE15B-24
DKE15C-05
DKE15C-12
DKE15C-15
DKE15C-24
3
25.4(1.00)
Pin No.
SIDE
VIEW
11.2(0.44)
SKA20
Output
S K A 20
SKM30
1
+Vin
+Vin
2
-Vin
-Vin
3
+Vout
R.C.
4
Trim
+Vout
5
-Vout
-Vout
6
R.C.
Trim
SKM30
Voltage set point accuracy .... ±2% (max.)
Line regulation .................... ±0.2% (max.)
Load regulation ................... ±0.5% (max.)@10~100% load
Efficiency ............................ 89.5% (typical) for SKA20
90% (typical) for SKM30
Short circuit protection ......... Continuous, auto-recovery
Overload protection .............. 110%~180%, auto-recovery
I/O isolation voltage ............. 1500VDC (min.)
I/O isolation resistance ......... 0ȍPLQ#9'&
Working temperature ............ -40~+85°C (refer to output derating curve) for SKA20
-40~+75°C (refer to output derating curve) for SKM30
EMC .................................... Compliance to EN55022 class A,
EN61000-4-2,3,4,5,6,8, FCC part15 class A
SKA20 Series
Model No.
SKA20A-05
SKA20A-12
SKA20A-15
SKA20B-05
SKA20B-12
SKA20B-15
SKA20C-05
SKA20C-12
SKA20C-15
Du al Out p u t
Model No.
4
10.2
(0.40)
Voltage set point accuracy ... ±2% (max.)
Line regulation ................... ±0.3% (max.)
Load regulation .................. ±0.5% (max.)@10~100% load
Efficiency ........................... 85% (typical)
Short circuit protection ........ Continuous, auto-recovery
Overload protection ............. 160%~250%, auto-recovery
I/O isolation voltage ............ 1000VDC (min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
Working temperature ........... -25~+71° C (refer to output derating curve)
Storage temperature ........... -25°C to +105°C
Temp. Coefficient ................ ±0.03% / °C (max.)
Case material ..................... Six-sided shield metal case
EMC ...................................Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
S in g le O u t p u t
Input
(VDC)
9~18
9~18
9~18
9~18
18~36
18~36
18~36
18~36
36~72
36~72
36~72
36~72
2 1
BOTTOM
VIEW
20.32(0.80)
6
5
Model No.
Unit: mm(inch)
5.8
(0.23)
7.62 5.08
(0.30) (0.20)
15.24(0.60)
1
2
3
4
5
Pin Configuration
Mechanism
Output
Single Dual
+Vin
+Vin
-Vin
-Vin
+Vout +Vout
No Pin COM
-Vout -Vout
50.8(2.00)
Pin No.
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~75
36~75
36~75
Output
(VDC)
5
12
15
5
12
15
5
12
15
Current
(mA)
4000
1666
1333
4000
1666
1333
4000
1666
1333
R&N
(mVp-p)
50
60
60
50
60
60
50
60
60
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~75
36~75
36~75
Output
(VDC)
5
12
15
5
12
15
5
12
15
Current
(A)
6
2.5
2
6
2.5
2
6
2.5
2
R&N
(mVp-p)
90
120
120
90
120
120
90
120
120
SKM30 Series
Model No.
SKM30A-05
SKM30A-12
SKM30A-15
SKM30B-05
SKM30B-12
SKM30B-15
SKM30C-05
SKM30C-12
SKM30C-15
74
DC/DC Converter
2 5 ~ 3 0 W M o d u l e Ty p e
30W DC-DC Regulated Single Output
25~30W DC-DC Regulated Dual and Triple Output
• 2:1 wide input range
•
•
•
•
•
•
•
•
•
•
•
•
• 1000VDC I/O isolation
• Built-in remote ON/OFF control
• Built-in EMI filter
• Trimming output (±10%)
• Protections: Short circuit / Overload
/ Over voltage
• Cooling by free air convection
• Compact size, high efficiency
2"x 2"x 0.63"
2"x 2"x 0.82"
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
2:1 wide input range
4:1 wide input range(option)
1000VDC I/O isolation
Built-in remote ON/OFF control
Built-in EMI filter
Trimming output (±10%) for dual output
Protections: Short circuit / Overload
Cooling by free air convection
Six-sided shield metal case
100% full load burn-in test
Low cost, high reliability
1 years warranty
Pin Configuration
Mechanism
Unit: mm(inch)
Mechanism
Pin Configuration
Pin No.
Unit: mm
1
2
3
4
5
6
7
8
Pin No.
Output
1
+Vin
2
-Vin
3
No Pin
4
Control ON/OFF
5
No Pin
6
+Vout
7
-Vout
8
Trim
Output
Dual
Triple
R.C.
R.C.
No Pin
No Pin
-Vin
-Vin
+Vin
+Vin
+Vout
+Vout
COM
+5V
-Vout
COM
Trim
-Vout
Voltage set point accuracy .... ±2% (max.)
Line regulation .................... ±0.5% (max.) for dual output;
±1% (max.) for triple output
Load regulation ................... ±0.5% (10~100% load)(Dual)
±5% (20~100% load)(Triple)
Efficiency ............................ 83% (typical)
Short circuit protection ......... Continuous, auto-recovery
Overload protection .............. 110%~250%, auto-recovery
I/O isolation voltage ............. 1000VDC (min.)
I/O isolation resistance ......... 0ȍPLQ#9'&
Working temperature ............ -40~+85°C (refer to output derating curve)
Storage temperature ............ -40° C to +105° C
Temp. Coefficient ................. ±0.03% / °C (max.)
Case material ...................... Six-sided shield metal case
EMC .................................... Compliance to EN55022 class B,
EN61000-4-2,3,4,5,6,8, FCC part15 class B
D ua l O ut put
Voltage set point accuracy ... ±2% (max.)(±3% for 3.3VDC models)
Line regulation ................... ±1% (max.)
Load regulation .................. ±1% (max.) @10~100% load
Overload protection ............ Over 105% power limiting, auto-recovery
Over voltage protection ....... 115%~150% rated output voltage
Efficiency (typical) .............. 80% for 12V input
83% for 24V input
85% for 48V input
I/O isolation voltage ............ 1000VDC(min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
Working temperature .......... -25~+85° C (refer to output derating curve)
Storage temperature ........... -25° C to +85° C
DKA30A-05
DKA30A-12
DKA30A-15
Input
(VDC)
9~18
9~18
9~18
Output
(VDC)
±5
±12
15
Current
(mA)
±2500
±1250
±1000
R&N
(mVp-p)
100
100
100
DKA30B-05
DKA30B-12
DKA30B-15
18~36
18~36
18~36
±5
±12
±15
±2500
±1250
±1000
100
100
100
DKA30C-05
DKA30C-12
DKA30C-15
36~72
36~72
36~72
±5
±12
±15
±2500
±1250
±1000
100
100
100
Output
(VDC)
+5 / ±12
+5 / ±15
Current
(mA)
3500 / ±310
3500 / ±250
R&N
(mVp-p)
100
100
Model No.
Case Material .................... Six-sided shield metal case
EMC .................................. Compliance to EN55022 class B,
EN61000-4-2,3,4,6,8
Packing ............................. 0.1kg ; 150pcs / 15.8kg / 0.97CUFT
Model No.
Input
(VDC)
Output
(VDC)
Current
(A)
R&N
(mVp-p)
SDM30-12S3
9~18
3.3
5.0
75
SDM30-12S5
9~18
5
5.0
75
SDM30-12S12
9~18
12
2.1
100
SDM30-12S15
9~18
15
1.7
100
SDM30-24S3
18~36
3.3
5.0
75
SDM30-24S5
18~36
5
5.0
75
Model No.
SDM30-24S12
18~36
12
2.5
100
TKA30A-B
TKA30A-C
Input
(VDC)
9~18
9~18
TKA30B-B
TKA30B-C
18~36
18~36
+5 / ±12
+5 / ±15
3500 / ±310
3500 / ±250
100
100
TKA30C-B
TKA30C-C
36~72
36~72
+5 / ±12
+5 / ±15
3500 / ±310
3500 / ±250
100
100
SDM30-24S15
18~36
15
2.0
100
SDM30-48S3
36~72
3.3
5.0
75
SDM30-48S5
36~72
5
5.0
75
SDM30-48S12
36~72
12
2.5
100
SDM30-48S15
36~72
15
2.0
100
Tr i pl e O ut put
75
DC/DC Converter
4 0 ~ 6 0 W M o d u l e Ty p e
50W DC-DC Regulated Single Output
40~60W DC-DC Regulated Single Output
•
•
•
•
•
•
•
•
•
• 2"x1" compact size
• 2:1 wide input range
• 1500VDC I/O isolation
• High efficiency up to 92%
SKA40
• Built-in remote ON/OFF control
2"x 2"x 0.43"
• Built-in EMI filter
• Trimming output (±10%)
• Protections:
2"x 1"x 0.54"
Short circuit / Overload /
Input and output over voltage
• Cooling by free air convection
• Six-sided shield metal case
• 100% full load burn-in test
SKA60
22"x 2"x 0.43"
• Low cost, high reliability
•
• 2 years warranty
Mechanism
Pin Configuration
Mechanism
•
•
•
•
2"x2" compact size
2:1 wide input range
1500VDC I/O isolation
High efficiency up to 93%
Built-in remote ON/OFF control
Built-in remote sense
Built-in EMI filter
Trimming output (±10%)
Protections:
Short circuit / Overload /
Input and output over voltage
Cooling by free air convection
100% full load burn-in test
Low cost, high reliability
Output 3.3V/9V models available for
SKA40
Output 3.3V available for SKA60
2 years warranty
Pin Configuration
Unit: mm(inch)
Unit: mm(inch)
50.8 (2.00)
Pin No.
Output
1
+Vin
13.7 (0.54)
2
-Vin
5.8 (0.23)
3
R.C.
4
+Vout
5
-Vout
6
Trim
Voltage set point accuracy ... ±2% (max.)
Line regulation ................... ±0.5% (max.)
Load regulation .................. ±0.5% (max.) @10~100% load
Overload protection ............ 110%~180%, auto-recovery
Over voltage protection ....... Clamp by TVS diode
Efficiency (typical)................ 92% for SKA40; 93% for SKA60
I/O isolation voltage ............ 1500VDC(min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
Working temperature .......... -40~+80°C(refer to output derating curve) for SKA40
-40~+70°C(refer to output derating curve) for SKA60
Storage temperature ........... -55° C to +105° C
Case Material .................... Six-sided shield metal case
EMC .................................. Compliance to EN55022 class A,
EN61000-4-2,3,4,5,6,8, FCC part15 classA
Voltage set point accuracy .... ±2% (max.)
Line regulation .................... ±0.2% (max.)
Load regulation ................... ±0.5% (max.) @ 10~100% load
Efficiency ............................ 92% (typical)
Short circuit protection ......... Continuous, auto-recovery
Overload protection .............. 110%~180%, auto-recovery
I/O isolation voltage ............. 1500VDC (min.)
I/O isolation resistance ......... 0ȍPLQ#9'&
Working temperature ............ -40~+75°C (refer to output derating curve)
Model No.
Storage temperature ............ -55°C to +125°C
SKA40A-05
SKA40A-12
SKA40A-15
SKA40B-05
SKA40B-12
SKA40B-15
SKA40C-05
SKA40C-12
SKA40C-15
Temp. Coefficient ................. ±0.03% / °C (max.)
Case material ...................... Six-sided shield metal case
EMC .................................... Compliance to EN55022 class A,
EN61000-4-2,3,4,5,6,8, FCC part15 class A
SKM50B-05
Input
(VDC)
18~36
Output
(VDC)
5
Current
(A)
10
R&N
(mVp-p)
60
SKM50B-12
18~36
12
4.17
80
SKM50B-15
18~36
15
3.33
100
SKM50C-05
36~75
5
10
60
SKM50C-12
36~75
12
4.17
80
SKM50C-15
36~75
15
3.33
100
Model No.
Output
R.C.
-Vin
+Vin
-R.S
+R.S
+Vout
-Vout
Trim
25.4 (1.0)
10.16 (0.4)
20.32 (0.8)
5.08 (0.2)
15.24 (0.6)
45.72 (1.8)
Pin No.
1
2
3
4
5
6
7
8
Model No.
SKA60A-05
SKA60A-12
SKA60A-15
SKA60B-05
SKA60B-12
SKA60B-15
SKA60C-05
SKA60C-12
SKA60C-15
76
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~75
36~75
36~75
Output
(VDC)
5
12
15
5
12
15
5
12
15
Current
(A)
7.00
3.33
2.67
7.00
3.33
2.67
7.00
3.33
2.67
R&N
(mVp-p)
60
80
100
60
80
100
60
80
100
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~75
36~75
36~75
Output
(VDC)
5
12
15
5
12
15
5
12
15
Current
(A)
12
5
4
12
5
4
12
5
4
R&N
(mVp-p)
60
80
100
60
80
100
60
80
100
DC/DC Converter
7 5 ~ 1 0 0 W M o d u l e Ty p e
75W DC-DC Half-Brick Regulated Single Output
100W DC-DC Half-Brick Regulated Single Output
• Half-brick size (2.28"x 2.4"x 0.5")
with industry standard pin out
• 2:1 wide input range
• 1500VDC I/O isolation
• High efficiency up to 89%
• Built-in remote ON/OFF control
• Built-in remote sense
• Trimming output (±10%)
• Protections:
Short circuit / Over current /
Over voltage / Over temperature
• Five-sided shield metal case
• Output 2.5V / 3.3V / 15V available
• Optional heatsink available
• 3 years warranty
• Half-brick size (2.28"x 2.4"x 0.5")
with industry standard pin out
• 2:1 wide input range
• 1500VDC I/O isolation
• High efficiency up to 89%
• Built-in remote ON/OFF control
• Built-in remote sense
• Trimming output (±10%)
• Protections:
Short circuit / Over current /
Over voltage / Over temperature
• Five-sided shield metal case
• Output 2.5V / 3.3V / 15V available
• Optional heatsink available
• 3 years warranty
2.28"x 2.4"x 0.5"
Mechanism
2.28"x 2.4"x 0.5"
Pin Configuration
Unit: mm(inch)
Pin No.
Output
1
2
3
4
5
6
7
8
9
+Vin
R.C.
Case
-Vin
-Vout
-R.S.
Trim
+R.S.
+Vout
Mechanism
Voltage set point accuracy ... ±1% (max.)
Line regulation ................... ±0.2% (max.)
Load regulation .................. ±0.2% (max.)
Over current protection ....... 110%~150%, auto-recovery
Over voltage protection ....... 115%~140% rated output voltage, clamp by TVS diode
Over temperature protection .... 100 O C±5 O C of case temperature
Efficiency .......................... 89% (typical)
I/O isolation voltage ............ 1500VDC(min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
Working temperature .......... -40~+100°C of case temp.(refer to output derating curve)
Storage temperature ........... -55~+105° C
Safety standards ................ UL60950-1 approved
Case Material .................... Five-sided shield metal case
EMC .................................. Compliance to EN55022 class A with external
components(refer to "EMC suggestion circuit"),
EN61000-4-2,3,4,5,6,8
Model No.
MHB75-12S05
MHB75-12S12
MHB75-12S24
MHB75-24S05
MHB75-24S12
MHB75-24S24
MHB75-48S05
MHB75-48S12
MHB75-48S24
Input
(VDC)
9~18
9~18
9~18
18~36
18~36
18~36
36~75
36~75
36~75
Output
(VDC)
5
12
24
5
12
24
5
12
24
Current
(A)
15
6.25
3.13
15
6.25
3.13
15
6.25
3.13
Pin Configuration
Unit: mm(inch)
Pin No.
Output
1
2
3
4
5
6
7
8
9
+Vin
R.C.
Case
-Vin
-Vout
-R.S.
Trim
+R.S.
+Vout
Voltage set point accuracy ... ±1% (max.)
Line regulation ................... ±0.2% (max.)
Load regulation .................. ±0.2% (max.)
Over current protection ....... 110%~140%, auto-recovery
Over voltage protection ....... 115%~140% rated output voltage, clamp by TVS diode
Over temperature protection ..... 100 O C±5 O C of case temperature
Efficiency .......................... 89% (typical)
I/O isolation voltage ............ 1500VDC(min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
Working temperature .......... -40~+100° C of case temp.(refer to output derating curve)
Storage temperature ........... -55~+105° C
Safety standards ................ UL60950-1 approved
Case Material .................... Five-sided shield metal case
EMC .................................. Compliance to EN55022 class A with external
components(refer to "EMC suggestion circuit"),
EN61000-4-2,3,4,5,6,8
R&N
(mVp-p)
75
100
240
75
100
240
75
100
240
Model No.
MHB100-24S05
MHB100-24S12
MHB100-24S24
MHB100-48S05
MHB100-48S12
MHB100-48S24
Input
(VDC)
18~36
18~36
18~36
36~75
36~75
36~75
Output
(VDC)
5
12
24
5
12
24
Current
(A)
20
8.3
4.17
20
8.3
4.17
Heat Sink for MHB Series
Order No.
M-C308
(Vertical Fins)
M-C091
(Horizontal Fins)
M-C092
(Horizontal Fins)
Mechanical
Note: Power module and heat sink should be ordered seperately; The heat sinks can be used with MHB75/100/150 series.
77
R&N
(mVp-p)
100
150
240
100
150
240
DC/DC Converter
150W Module Type / 5W On Board Type
5W DC-DC Regulated Single Output
150W DC-DC Half-Brick Regulated Single Output
• 4:1 wide input range
• Half-brick size (2.28"x 2.4"x 0.5")
• 1000VDC I/O isolation
with industry standard pin out
• 2:1 wide input range
• Built-in EMI filter
•
•
•
•
2.28"x 2.4"x 0.5"
• Protections: Short circuit / Overload /
1500VDC I/O isolation
High efficiency up to 89%
Built-in remote ON/OFF control
Built-in remote sense
Over voltage
• Built-in remote ON/OFF control
• Cooling by free air convection
• 100% full load burn-in test
1.6"x 1"x 0.327"
• Trimming output (±10%)
• Low cost, high reliability
• Protections:
• 2 years warranty
Short circuit / Over current /
Over voltage / Over temperature
Mechanism
• Five-sided shield metal case
Pin Configuration
Unit: mm(inch)
• Output 2.5V / 3.3V / 15V available
• Optional heatsink available
• 3 years warranty
Mechanism
Pin Configuration
Output
1
2
3
4
5
6
7
8
9
+Vin
R.C.
Case
-Vin
-Vout
-R.S.
Trim
+R.S.
+Vout
6 (0.236)
Pin No.
Output
1
2
3
4
5
+Input
-Input(GND)
+Vout
-Vout
Control
8.3(0.327)
Unit: mm(inch)
Pin No.
Voltage set point accuracy ... ±2.0% (max.)
Line regulation ................... ±1.0% (max.)
Load regulation .................. ±1~±2% (max.)@10~100% load
Efficiency ........................... 85% (typical)
Short circuit protection ........ Continuous, auto-recovery
Voltage set point accuracy ... ±1% (max.)
Overload protection ............ Over 105% power limiting, auto-recovery
Line regulation ................... ±0.2% (max.)
I/O isolation voltage ............ 1000VDC
Load regulation .................. ±0.2% (max.)
I/O isolation resistance ........ 0ȍPLQ#9'&
Over current protection ....... 110%~150%, auto-recovery
Working temperature ........... -25~+70° C (refer to output derating curve)
Over voltage protection ....... 115%~140% rated output voltage, clamp by TVS diode
Storage temperature ........... -40~+85° C
Over temperature protection ..... 100° C ±5° C of case temperature
Temp. Coefficient ................ ±0.03% / ° C
Efficiency .......................... 89% (typical)
Safety standards ................. IEC60950-1 CB approved by TUV
I/O isolation voltage ............ 1500VDC(min.)
I/O isolation resistance ....... 0ȍPLQ#9'&
EMC standards ................... EN55022 class B, EN61000-4-2,3,4,5,6,8
Working temperature .......... -40~+100° C of case temp.(refer to output derating curve)
Packing .............................. 0.007kg ; 700pcs / 5.9kg / 0.97CUFT
Storage temperature ........... -55~+105° C
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
NSD05-12S3
9.2~36
3.3
1200
75
components(refer to "EMC suggestion circuit"),
NSD05-12S5
9.2~36
5
1000
75
EN61000-4-2,3,4,5,6,8
NSD05-12S12
9.2~36
12
420
75
Safety standards ................ UL60950-1 approved
Case Material .................... Five-sided shield metal case
EMC .................................. Compliance to EN55022 class A with external
Model No.
MHB150-48S05
NSD05-12S15
9.2~36
15
330
75
Input
(VDC)
Output
(VDC)
Current
(A)
R&N
(mVp-p)
NSD05-48S3
18~72
3.3
1200
75
36~75
5
30
100
NSD05-48S5
18~72
5
1000
75
MHB150-48S12
36~75
12
12.5
150
NSD05-48S12
18~72
12
420
75
MHB150-48S24
36~75
24
6.25
240
NSD05-48S15
18~72
15
330
75
We prvide specification, drawing, test report and more
information, please visit our website —
http://www.meanwell.com
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at [email protected] for information of your local
distributors.
48hrs delivery—
We keep enough stock for 95% of standard models at our
2400m 2 warehouse. We can arrange prompt delivery within
48hrs.
78
DC/DC Converter
1 0 ~ 1 5 W O n B o a r d Ty p e
15W DC-DC Regulated Single and Dual Output
10W DC-DC Regulated Single and Dual Output
• 4:1 wide input range
• 1000VDC I/O isolation
• Protections: Short circuit / Overload /
Over voltage
• Built-in EMI filter
• Built-in remote ON/OFF control
• Cooling by free air convection
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
2"x 1"x 0.394"
Mechanism
• 4:1 wide input range
• 1500VDC I/O isolation
• Protections: Short circuit / Overload /
Over voltage
• Built-in EMI filter
• Output voltage trimming function
• Built-in remote ON/OFF control
• Cooling by free air convection
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
2"x 1.5"x 0.387"
Pin Configuration
Mechanism
Unit: mm(inch)
Pin No.
1
2
3
4
5
6
Output
Single
+Input
-Input
(GND)
+Out
NC
-Out
Control
Pin Configuration
Unit: mm(inch)
Dual
+Input
-Input
(GND)
+Out
Common
-Out
Control
Pin No.
1
2
3
4
5
6
7
8
Voltage set point accuracy .......... ±2% (max.)
Line regulation ........................... ±1% @10~100% load
Load regulation .......................... ±1~±3% @10~100% load
Output
Single
+Vin
-Vin
No Pin
Control
No Pin
+Vout
-Vout
Trim
Dual
+Vin
-Vin
No Pin
Control
+Vout
Common
-Vout
Trim
Voltage set point accuracy .......... ±2% (max.)
Line regulation ........................... ±1% @10~100% load
Load regulation .......................... ±1~±3% @10~100% load
Efficiency .................................. 85% (typical)
Efficiency .................................. 80% (typical)
Short circuit protection ............... Continuous, auto-recovery
Over voltage protection ............... [email protected]~150%
Short circuit protection ............... Continuous, auto-recovery
Over voltage protection ............... [email protected]~150%
Shutdown idle current ................. 20mA
Shutdown idle current ................. 20mA
I/O isolation voltage ................... 1000VDC
I/O isolation resistance ............... 0ȍPLQ#9'&
Working temperature .................. -25~+70° C
Storage temperature ................... -40~+85° C
I/O isolation voltage ................... 1500VDC
I/O isolation resistance ............... 0ȍPLQ#9'&
Working temperature .................. -25~+70° C
Storage temperature ................... -40~+85° C
Temp. coefficient ........................ ±0.03% / ° C
Temp. coefficient ........................ ±0.03% / ° C
Safety standards ........................ UL60950-1 approved
EMC standards .......................... EN55022 class B, EN61000-4-2,3,4,6,8
Packing ..................................... 0.02kg ; 300pcs / 7.0kg / 0.97CUFT
S ingle O u t p u t
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
NSD10-12S3
9.8~36
3.3
2500
75
NSD10-12S5
9.8~36
5
2000
75
NSD10-12S9
9.8~36
9
1100
NSD10-12S12
9.8~36
12
830
NSD10-12S15
9.8~36
15
NSD10-48S3
22~72
NSD10-48S5
NSD10-48S9
Safety standards ........................ UL60950-1 approved
EMC standards .......................... EN55022 class B, EN61000-4-2,3,4,6,8
Packing ..................................... 0.03kg ; 180pcs / 6.4kg / 0.97CUFT
S i ngl e O ut put
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
75
NSD15-12S3
9.4~36
3.3
3750
100
75
NSD15-12S5
9.4~36
5
3000
75
670
75
NSD15-12S12
9.4~36
12
1250
75
3.3
2500
75
NSD15-12S15
9.4~36
15
1000
75
22~72
5
2000
75
NSD15-48S3
18~72
3.3
3750
100
22~72
9
1100
75
NSD15-48S5
18~72
5
3000
75
NSD10-48S12
22~72
12
830
75
NSD15-48S12
18~72
12
1250
75
NSD10-48S15
22~72
15
670
75
NSD15-48S15
18~72
15
1000
75
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
Model No.
Input
(VDC)
Output
(VDC)
Current
(mA)
R&N
(mVp-p)
NSD10-12D5
9.8~36
±5
±50~1000
75
NSD15-12D5
9.4~36
±5
±70~1500
100
NSD10-12D12
9.8~36
±12
±20~420
75
NSD15-12D12
9.4~36
±12
±30~620
100
NSD10-12D15
9.8~36
±15
±16~330
75
NSD15-12D15
9.4~36
±15
±20~500
100
NSD10-48D5
22~72
±5
±50~1000
75
NSD15-48D5
18~72
±5
±70~1500
100
18~72
±12
±30~620
100
18~72
±15
±20~500
100
D ua l O ut put
D u al Ou t p u t
NSD10-48D12
22~72
±12
±20~420
75
NSD15-48D12
NSD10-48D15
22~72
±15
±16~330
75
NSD15-48D15
79
DC/DC Converter 12.5~60W On Board Type / 5~15W PCB Type
5W Single Output DC-DC Converter
12.5~60W Single Output Non-isolated DC-DC Converter
•
•
•
•
•
•
Non-isolated, fix-frequency at 250kHz
3:1 wide input range for 5~15V output
±2% output voltage accuracy
High efficiency up to 96%
Built-in remote ON/OFF control
Compact size
• 2:1 wide input range
• 2000VAC I/O isolation
• Protections: Short circuit / Overload /
Over voltage / Over temp.
• Cooling by free air convection
• Economical open frame design
• Protections: Short circuit / Overload /
Over voltage
• 2 years warranty
NID30
NID60
2"x 0.512"x 0.421"
Line and load regulation ... ±1.0% (max.)
Overload protection ......... >105% fold back current limiting, auto-recovery
Over voltage protection .... 115%~135% rated output voltage
Withstand voltage ............ I/P-O/P: 2kVAC, I/P-FG: 1.5kVAC, 1 minute
Isolation resistance .......... 0ȍPLQ#9'&
Working temperature ........ -10~+60° C (refer to output derating curve)
Safety standards ............. Meet LVD
EMC standards ................ EN55022 class B, EN61000-4-2,3,4,6,8
Connection ..................... 3P, 2P / 3.96mm pitch, Molex 5285-03, 5273-02
Packing ........................... 0.05kg ; 120pcs / 6.25kg / 1.0CUFT
NID30 S e ri e s
Pin Configuration
Unit: mm(inch)
Pin No.
Output
1, 2,3,4
5,6
7,8
9,10
11
+Vout
COM
+Vin
N.C.
R.C.
Model No.
PSD-05-5
PSD-05-12
PSD-05-24
NID60 S e ri e s
Mechanism
Pin Configuration
Unit: mm(inch)
Output
5V, 0~1.0A
12V, 0~0.45A
24V, 0~0.22A
R&N
50mV
100mV
150mV
Effi.
75%
78%
78%
15W Single Output DC-DC Converter
Pin No.
Output
1, 2,3,4
5,6
7,8
9,10
11
+Vout
COM
+Vin
N.C.
R.C.
•
•
•
•
Built-in EMI filter, low ripple noise
100% full load burn-in test
Low cost, high reliability
2 years warranty
94x 49x 25 mm
Line and load regulation .... ±1.0% (max.)
Overload protection .......... 105%~150% hiccup mode, auto-recovery
Over voltage protection ..... 115%~135% rated output voltage
Withstand voltage ............. I/P-O/P: 2kVAC, I/P-FG: 1.5kVAC, 1 minute
Isolation resistance ........... 0ȍPLQ#9'&
Working temperature ......... -10~+60° C (refer to output derating curve)
Safety standards .............. Meet LVD
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Connection ...................... 3P, 2P / 3.96mm pitch, JST B3P/B2P-VH
Packing ........................... 0.081kg ; 120pcs / 10.72kg
Working temperature .................. -25~+65° C (refer to derating curve)
Storage temperature ................... -25~+105° C
Temp. coefficient ........................ ±0.03% / ° C
N ID30 S e ri e s
Model No.
Input
R&N
Effi
NID30S24-05
20~53V
5V, 0~2.50A
100mV
91%
NID30S24-12
20~53V
12V, 0~2.50A
120mV
95%
NID30S24-15
20~53V
15V, 0~2.00A
150mV
96%
NID30S48-24
30~53V
24V, 0~1.25A
200mV
93%
Model No.
PSD-15A-5
PSD-15A-12
PSD-15A-24
PSD-15B-5
PSD-15B-12
PSD-15B-24
PSD-15C-5
PSD-15C-12
PSD-15C-24
NID60 S e ri e s
Output
Input
36~72V
36~72V
36~72V
• 2:1 wide input range
• 2000VAC I/O isolation
• Protections: Short circuit / Overload /
Over voltage / Polarity
Voltage set point accuracy .......... ±2% (max.)
Line regulation ........................... ±0.5%
Load regulation .......................... ±0.5% @ 10~100% load
Efficiency .................................. 96% (typical)
Short circuit protection ............... Continuous, auto-recovery
Overload protection .................... 120%~300%, auto-recovery
Over voltage protection ............... Clamp by TVS Diode
Output
Built-in EMI filter, low ripple noise
100% full load burn-in test
Low cost, high reliability
2 years warranty
75x 40x 20 mm
2"x 1.024"x 0.421"
Mechanism
•
•
•
•
Model No.
Input
R&N
Effi
NID60S24-05
20~53V
5V, 0~4.0A
100mV
90%
NID60S24-12
20~53V
12V, 0~4.0A
120mV
95%
NID60S24-15
20~53V
15V, 0~4.0A
150mV
96%
NID60S48-24
30~53V
24V, 0~2.5A
200mV
95%
80
Input
9.2~18V
9.2~18V
9.2~18V
18~36V
18~36V
18~36V
36~72V
36~72V
36~72V
Output
5V, 0~3.0A
12V, 0~1.25A
24V, 0~0.6A
5V, 0~3.0A
12V, 0~1.25A
24V, 0~0.6A
5V, 0~3.0A
12V, 0~1.25A
24V, 0~0.6A
R&N
50mV
100mV
100mV
50mV
100mV
100mV
50mV
100mV
100mV
Effi.
74%
67%
72%
78%
78%
78%
78%
78%
79%
DC/DC Converter
30~45W PCB Type / 15~25W Enclosed
30W Single Output DC-DC Converter
15W Single Output DC-DC Converter
• 2:1 wide input range
• Protections: Short circuit / Overload /
Over voltage / Reverse
polarity
• 1500VAC I/O isolation
• Cooling by free air convection
• Built-in EMI filter, low ripple noise
• 100% full load burn-in test
• Low cost, high reliability
101.6x 50.8x 30 mm
• 2 years warranty
DC adjustment range ....... 5V: 4.5~5.5V, 12V: 11~13.5V, 24V: 22~26V
Line and load regulation .. ±1% (max.)
Overload protection ........ 105%~150% hiccup mode, auto-recovery
•
•
•
•
CASE: 931A
DC adjustment range ......... 5V: 4.75~5.5V, 12V: 10.8~13.2V,
24V: 21.6~26.4V
Line and load regulation .... ±0.5% (max.)
Overload protection .......... 105%~160% hiccup mode, auto-recovery
Over voltage protection ..... 115%~135% rated output voltage
Withstand voltage ............. I/P-O/P: 2kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ......... -10~+60° C (refer to output derating curve)
Safety standard ................ Meet LVD
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ........................... 0.18kg ; 60pcs / 11.8kg
Over voltage protection ... 115%~150% rated output voltage
Withstand voltage ........... I/P-O/P: 1.5kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ....... -20~+60° C (refer to output derating curve)
EMC standards ............... EN55022 class B, EN61000-4-2,3,4,6,8, EN55024
Connection ..................... 3P, 4P / 3.96mm pitch, JST B3P/B4P-VH-B
Model No.
Input
Output
R&N
Effi.
PSD-30A-05
9~18V
5V, 0~5.0A
100mV
77%
PSD-30A-12
9~18V
12V, 0~2.5A
120mV
77%
PSD-30A-24
9~18V
24V, 0~1.25A
150mV
78%
PSD-30B-05
18~36V
5V, 0~5.0A
100mV
79%
PSD-30B-12
18~36V
12V, 0~2.5A
120mV
80%
PSD-30B-24
18~36V
24V, 0~1.25A
150mV
83%
PSD-30C-05
36~72V
5V, 0~5.0A
100mV
80%
PSD-30C-12
36~72V
12V, 0~2.5A
120mV
82%
PSD-30C-24
36~72V
24V, 0~1.25A
150mV
83%
Model No.
SD-15A-5
SD-15A-12
SD-15A-24
SD-15B-5
SD-15B-12
SD-15B-24
SD-15C-5
SD-15C-12
SD-15C-24
45W Single Output DC-DC Converter
127x 76x 30 mm
CASE: 905
DC adjustment range ......... 5V: 4.5~5.5V, 12V: 10.8~13.2V,
24V: 21.6~26.4V
Line and load regulation .... ±1% (max.)
Overload protection .......... 105%~160% shut down, re-power on to recover
Over voltage protection ..... 115%~135% rated output voltage
Withstand voltage ............. I/P-O/P: 1.5kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ......... -10~+60° C (refer to output derating curve)
Safety standards ............... EN60950-1 CB approved by TUV
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8, EN55024
Connection ....................... 2P, 6P / 3.96mm pitch, Molex 5277-02, 5273-06
Packing ........................... 0.19kg ; 72pcs / 15.6kg / 1.35CUFT
Input
Output
R&N
Effi.
PSD-45A-05
9.2~18V
5V, 0~6.0A
100mV
74%
PSD-45A-12
9.2~18V
12V, 0~2.5A
120mV
78%
PSD-45A-24
9.2~18V
24V, 0~1.25A
150mV
79%
PSD-45B-05
18~36V
5V, 0~9.0A
100mV
77%
PSD-45B-12
18~36V
12V, 0~3.75A
120mV
82%
PSD-45B-24
18~36V
24V, 0~1.875A
150mV
85%
PSD-45C-05
37~72V
5V, 0~9.0A
100mV
80%
PSD-45C-12
37~72V
12V, 0~3.75A
120mV
83%
PSD-45C-24
37~72V
24V, 0~1.875A
150mV
86%
Input
9.2~18V
9.2~18V
9.2~18V
18~36V
18~36V
18~36V
36~72V
36~72V
36~72V
Output
5V, 0~3.0A
12V, 0~1.25A
24V, 0~0.625A
5V, 0~3.0A
12V, 0~1.25A
24V, 0~0.625A
5V, 0~3.0A
12V, 0~1.25A
24V, 0~0.625A
R&N
100mV
120mV
150mV
100mV
120mV
150mV
100mV
120mV
150mV
Effi.
68%
72%
70%
76%
76%
77%
75%
79%
78%
25W Single Output DC-DC Converter
• 2:1 wide input range
• Protections: Short circuit / Overload /
Over voltage / Reverse
polarity
• Cooling by free air convection
• Built-in EMI filter, low ripple noise
• 100% full load burn-in test
• Fixed switching frequency at 96kHz
• Low cost
• 2 years warranty
Model No.
78x 51x 28 mm
•
•
•
•
2:1 wide input range
2000VAC I/O isolation
Cooling by free air convection
Protections: Short circuit / Over load /
Over voltage
Built-in EMI filter, low ripple noise
100% full load burn-in test
Low cost, high reliability
2 years warranty
99x 97x 36 mm
• 2:1 wide input range
• 1500VAC I/O isolation
• Protections: Short circuit / Overload /
Over voltage
• Built-in EMI filter, low ripple noise
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
DC adjustment range ........ 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V
Line and load regulation .... ±0.5% (max.)
Overload protection .......... 105%~150% hiccup mode, auto-recovery
Over voltage protection ..... 115%~165% rated output voltage
Withstand voltage ............. I/P-O/P: 2kVAC, I/P-FG: 1.5kVAC, 1 minute
Isolation resistance ........... 0ȍPLQ#9'&
Working temperature ......... -10~+60° C (refer to output derating curve)
Safety standards .............. Meet LVD
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ............................ 0.38kg ; 45pcs / 17.8kg / 0.9CUFT
Model No.
SD-25A-5
SD-25A-12
SD-25A-24
SD-25B-5
SD-25B-12
SD-25B-24
SD-25C-5
SD-25C-12
SD-25C-24
81
Input
9.2~18V
9.2~18V
9.2~18V
19~36V
19~36V
19~36V
36~72V
36~72V
36~72V
Output
5V, 0~5.0A
12V, 0~2.1A
24V, 0~1.1A
5V, 0~5.0A
12V, 0~2.1A
24V, 0~1.1A
5V, 0~5.0A
12V, 0~2.1A
24V, 0~1.1A
R&N
100mV
120mV
150mV
100mV
120mV
150mV
100mV
120mV
150mV
Effi.
71%
72%
75%
72%
75%
78%
74%
78%
81%
DC/DC Converter
50~200W Enclosed Single Output
150W Single Output DC-DC Converter
50W Single Output DC-DC Converter
CASE: 901
159x 97x 38 mm
• 2:1 wide input range
• 1500VAC I/O isolation
• Protections: Short circuit / Over load /
Over voltage
• Built-in EMI filter, low ripple noise
• Cooling by free air convection
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
(D type)
CASE: 906
DC adjustment range ......... 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V
Line and load regulation .... ±0.5% (max.)
Overload protection ........... 105%~150% hiccup mode, auto-recovery
Over voltage protection ...... 115%~165% rated output voltage
Withstand voltage ............. I/P-O/P: 1.5kVAC, I/P-FG: 1.5kVAC, 1 minute
Isolation resistance ........... 0ȍPLQ#9'&
Working temperature ......... -10~+60°C (refer to output derating curve)
Safety standard ................ Meet LVD
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ............................ 0.53kg ; 24pcs / 12.7kg / 0.75CUFT
Model No.
Input
Output
R&N
Effi.
SD-50A-5
9.2~18V
5V, 0~10A
100mV
70%
SD-50A-12
9.2~18V
12V, 0~4.2A
120mV
72%
SD-50A-24
9.2~18V
24V, 0~2.1A
150mV
74%
SD-50B-5
19~36V
5V, 0~10A
100mV
73%
SD-50B-12
19~36V
12V, 0~4.2A
120mV
75%
SD-50B-24
19~36V
24V, 0~2.1A
150mV
80%
SD-50C-5
36~72V
5V, 0~10A
100mV
76%
SD-50C-12
36~72V
12V, 0~4.2A
120mV
78%
SD-50C-24
36~72V
24V, 0~2.1A
150mV
83%
199x 110x 50 mm
DC adjustment range ........ 12V: 11~16V, 24V: 23~30V
Line regulation ................. ±0.5% (max.)
Load regulation ................ ±0.5% (max.)
Overload protection .......... 105%~135% hiccup mode, auto-recovery
Over voltage protection ..... 130%~165% rated output voltage
Withstand voltage ............. I/P-O/P: 1.5kVAC, I/P-FG: 1.5kVAC, 1 minute
Isolation resistance .......... 0ȍPLQ#9'&
Working temperature ......... -10~+60° C (refer to output derating curve)
Safety standards .............. Meet LVD, EN60950-1 CB approved by TUV
(D type only)
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ............................ 0.86kg ; 16pcs / 14.5kg / 0.95CUFT
Model No.
SD-150B-12
SD-150B-24
SD-150C-12
SD-150C-24
SD-150D-12
SD-150D-24
Input
19~36V
19~36V
36~72V
36~72V
72~144V
72~144V
(SD-200C-24) (D type)
CASE: 902
199x 98x 38 mm
• 2:1 wide input range
• 1500VAC I/O isolation
• Protections: Short circuit / Overload /
Over voltage
• Built-in EMI filter, low ripple noise
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
Model No.
Input
Output
R&N
Effi.
19~36V
5V, 0~20A
100mV
74%
SD-100B-12
19~36V
12V, 0~8.5A
120mV
75%
SD-100B-24
19~36V
24V, 0~4.2A
150mV
78%
SD-100C-5
36~72V
5V, 0~20A
100mV
75%
SD-100C-12
36~72V
12V, 0~8.5A
120mV
77%
SD-100C-24
36~72V
24V, 0~4.2A
150mV
81%
SD-100D-5
72~144V
5V, 0~20A
100mV
76%
SD-100D-12
72~144V
12V, 0~8.5A
120mV
80%
SD-100D-24
72~144V
24V, 0~4.2A
150mV
83%
R&N
120mV
150mV
120mV
150mV
120mV
150mV
Effi.
75%
77%
77%
80%
79%
82%
• 2:1 wide input range
• 1500VAC I/O isolation
• Protections: Short circuit / Overload /
CASE: 912H
215x 115x 50 mm
Over voltage / Over temp.
• Cooling by free air convection
• 100% full load burn-in test
• 2 years warranty
DC adjustment range ........ 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V,
48V: 43~53V
Voltage tolerance.............. ±2% (max.)
Overload protection .......... 105%~135% shut off, re-power on to recover
Over voltage protection ..... 110%~167% rated output voltage
Withstand voltage ............. I/P-O/P: 1.5kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ......... -20~+60° C (refer to output derating curve)
Safety standards .............. Meet LVD, EN60950-1 CB approved by TUV
(D type only)
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ........................... 1.1kg ; 12pcs / 14.4kg / 0.92CUFT
DC adjustment range ........ 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V
Line regulation ................. ±0.5% (max.)
Load regulation ................ ±0.5% (max.)
Overload protection .......... 105%~135% hiccup mode, auto-recovery
Over voltage protection ..... 115%~165% rated output voltage
Withstand voltage ............. I/P-O/P: 1.5kVAC, I/P-FG: 1.5kVAC, 1 minute
Isolation resistance ........... 0ȍPLQ#9'&
Working temperature ......... -10~+60°C (refer to output derating curve)
Safety standards .............. Meet LVD, EN60950-1 CB approved by TUV ( D type only )
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ........................... 0.65kg ; 20pcs / 13.8kg / 0.8CUFT
SD-100B-5
Output
12V, 0~12.5A
24V, 0~6.3A
12V, 0~12.5A
24V, 0~6.3A
12V, 0~12.5A
24V, 0~6.3A
200W Single Output DC-DC Converter
100W Single Output DC-DC Converter
(D type)
• 2:1 wide input range
• 1500VAC I/O isolation
• Protections: Short circuit / Over load /
Over voltage
• Built-in EMI filter, low ripple noise
• Cooling by free air convection
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
Model No.
SD-200B-5
SD-200B-12
SD-200B-24
SD-200B-48
SD-200C-5
SD-200C-12
SD-200C-24
SD-200C-48
SD-200D-5
SD-200D-12
SD-200D-24
SD-200D-48
82
Input
19~36V
19~36V
19~36V
19~36V
36~72V
36~72V
36~72V
36~72V
72~144V
72~144V
72~144V
72~144V
Output
5V, 0~34.0A
12V, 0~16.7A
24V, 0~8.40A
48V, 0~4.20A
5V, 0~40.0A
12V, 0~16.7A
24V, 0~8.40A
48V, 0~4.20A
5V, 0~40.0A
12V, 0~16.7A
24V, 0~8.40A
48V, 0~4.20A
R&N
100mV
120mV
150mV
200mV
100mV
120mV
150mV
200mV
100mV
120mV
150mV
200mV
Effi.
79%
82%
85%
86%
81%
84%
86%
86%
82%
82%
84%
90%
DC/DC Converter
350~1000W Enclosed Single Output
350W Single Output DC-DC Converter
1000W Single Output DC-DC Converter
• 4:1 & 2:1 wide input range
(D type)
• 2:1 wide input range
• 2000VAC I/O Isolation
• 1500VAC I/O isolation
• Protections: Short circuit / Over load /
• Protections: Short circuit / Overload /
Over voltage / Over temp.
Over voltage / Over temp.
• Forced air cooling by built-in DC fan
• Forced air cooling by built-in DC fan
• 100% full load burn-in test
CASE: 912B
215x 115x 50 mm
• High power density 10.7W/inch 3
• 1U low profile 41mm
• 2 years warranty
CASE: 952B
DC adjustment range ..... 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V,
48V: 43~53V
Voltage tolerance .......... ±2% (max.)
Overload protection ....... 105%~135% shut off, re-power on to recover
Over voltage protection .. 110%~167% rated output voltage
Withstand voltage .......... I/P-O/P: 1.5kVAC, I/P-FG: 1.5kVAC, 1 minute
Working temperature ...... -20~+60°C (refer to output derating curve)
Safety standards ........... Meet LVD, EN60950-1 CB approved by TUV
(D type only)
EMC standards .............. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ........................ 1.1kg ; 12pcs / 14.4kg / 0.92CUFT
Model No.
SD-350B-5
SD-350B-12
SD-350B-24
SD-350B-48
SD-350C-5
SD-350C-12
SD-350C-24
SD-350C-48
SD-350D-5
SD-350D-12
SD-350D-24
SD-350D-48
Input
19~36V
19~36V
19~36V
19~36V
36~72V
36~72V
36~72V
36~72V
72~144V
72~144V
72~144V
72~144V
Output
5V, 0~57.0A
12V, 0~27.5A
24V, 0~14.6A
48V, 0~7.30A
5V, 0~60.0A
12V, 0~27.5A
24V, 0~14.6A
48V, 0~7.30A
5V, 0~60.0A
12V, 0~29.2A
24V, 0~14.6A
48V, 0~7.30A
R&N
100mV
120mV
150mV
200mV
100mV
120mV
150mV
200mV
100mV
120mV
150mV
200mV
215x 115x 50 mm
• Built-in remote sense function
• 3 years warranty
DC adjustment range ........ 12V: 11~15V, 24V: 23~30V, 48V: 46~60V
Line regulation ................. ±0.5% (max.)
Load regulation ................ ±0.5% (max.)
Overload protection .......... 105%~125% constant current limiting,
shut off after 5 sec., re-power on to recover
Over voltage protection ..... 130%~160% rated output voltage
Effi.
74%
80%
80%
84%
76%
81%
81%
82%
78%
83%
87%
89%
Withstand voltage ............. I/P-O/P: 2kV, I/P-FG: 1.5kV, 1 minute
Isolation resistance ........... 0ȍPLQ#9'&
Working temperature ......... -20~+60° C (refer to output derating curve)
Safety standards .............. IEC60950-1 CB approved by TUV
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ........................... 1.94kg ; 6pcs / 12.6kg / 0.99CUFT
• 4:1 & 2:1 DC input range
• DC input active surge current limiting
• Protections: Short circuit / Overload /
Over voltage / Over temp./
Input polarity
• 2000VAC I/O Isolation
• Forced air cooling by built-in DC fan
with fan speed control function
• Output OK signal
• Built-in remote ON/OFF control
• Built-in remote sense function
• 3 years warranty
12V: 11~15V, 24V: 23~30V, 48V: 46~60V
±0.5% (max.)
±0.5% (max.)
105%~125% constant current limiting, shut off after
5 sec., re-power on to recover
Over voltage protection ..... 130%~160% rated output voltage
Withstand voltage ............. I/P-O/P: 2kV, I/P-FG: 1.5kV, 1 minute
Isolation resistance ........... 0ȍPLQ#9'&
Working temperature ......... -20~+60°C (refer to output derating curve)
Safety standards .............. IEC60950-1 CB approved by TUV
EMC standards ................. EN55022 class B, EN61000-4-2,3,4,6,8
Packing ............................ 1.15kg ; 12pcs / 14.8kg / 0.92CUFT
Input
19~72V
19~72V
19~72V
72~144V
72~144V
72~144V
Output
12V, 0~40A
24V, 0~21A
48V, 0~10.5A
12V, 0~40A
24V, 0~21A
48V, 0~10.5A
R&N
150mV
150mV
150mV
150mV
150mV
150mV
Model No.
Input
Output
R&N
Effi.
SD-1000L-12
19~72V
12V, 0~60A
150mV
84%
SD-1000L-24
19~72V
24V, 0~40A
150mV
88%
SD-1000L-48
19~72V
48V, 0~21A
150mV
90%
SD-1000H-12
72~144V
12V, 0~60A
150mV
85%
SD-1000H-24
72~144V
24V, 0~40A
150mV
89%
SD-1000H-48
72~144V
48V, 0~21A
150mV
92%
•
•
•
•
•
DC adjustment range ........
Line regulation .................
Load regulation ................
Overload protection ..........
Model No.
SD-500L-12
SD-500L-24
SD-500L-48
SD-500H-12
SD-500H-24
SD-500H-48
• Output OK signal
• 12V / 0.25A auxiliary output
• Built-in remote ON/OFF control
500W Single Output DC-DC Converter
CASE: 912A
295x 127x 41 mm
•
•
•
•
•
•
•
•
Effi.
86%
88%
89%
87%
89%
90%
•
•
83
Universal AC input / Full range
Bui l t-i n acti ve PFC functi on
No load power consumption < 0.5W at remote OFF
High efficiency up to 96%
Protections:
Short circuit / Over current / Over voltage / Over temp.
Vo & I o adjustable
Withstand 5G vibration test
-40~+70 ° C wi de operati ng range
Fanless design
Aluminum case and potted with heat-conducted glue
LED i ndi cator for power on
Desi gn refer to UL60950-1, TUV EN60950-1
Output models:
12V / 15V / 20V / 24V / 30V / 36V / 42V / 48V / 54V
Dimension (LxWxH): 275x 145x 45 mm
5 years warranty
DC/DC Converter
100~300W Railway Single Output
Features
•
•
•
•
•
•
•
•
•
RS D- 3 0 0
RSD-2 0 0
RSD-1 5 0
RSD-100
•
•
General Specification (Please refer to www.meanwell.com for detail spec.)
Mo d el N o .
R SD-1 0 0
L in e r eg u l a t i o n ( ma x . )
±0.5%
Load r eg u l a t i o n ( ma x . )
±1%
Over lo ad
pr o tectio n
RS D - 1 5 0
Compliance to EN50155 railway standard
2:1 wide input range
4000VDC I/O isolation
Protections:
Short circuit / Overload / Over voltage /
Input reverse polarity / Over temp.(RSD-150/200/300)
Cooling by free air convection
Built-in constant current limiting circuit
1U low profile
All using 105° C long life electrolytic capacitors
Half encapsulated
100% full load burn-in test
3 years warranty
RSD-200
RSD-300
Ra n g e
105%~135%
Type
Constant current limiting, recovers automatically after fault condition is removed
Over vol t a g e p ro t e c t i o n
115%~135% Shut down O/P voltage, re-power on to recover
W ith stan d v o l t a g e
I / P-O/ P: 4 k VDC, I / P-F G: 2 . 5 k VDC , O / P - FG : 2 . 5 kV D C , 1 m in u t e
Iso latio n re s i s t a n c e
0 ȍ P L Q # 9'&
W or king t e mp e ra t u re
-4 0 ~+7 0 °C (re f e r t o o u t p u t d e ra t in g cu r ve )
S afety st a n d a rd s
M e e t I EC6 0 9 5 0 -1 (LV D)
E MC stan d a rd s
EN5 5 0 2 2 c l a s s B, EN5 0 1 2 1 -3 -2 , E N 6 1 0 0 0 - 4 - 2 , 3 , 4 , 5 , 6 , 8
R ailway s t a n d a rd
EN5 0 1 5 5 / I EC6 0 5 7 1
115%~140%
D im en sion ( L x W x H ) ( mm)
161x68x36
189x77x36
191x86x40
216x97x40
P ackin g
24pcs / 15.4kg
15pcs / 13kg
12pcs / 12.3kg
12pcs / 15.3kg
100W
Model No.
RSD-100B-5
RSD-100B-12
RSD-100B-24
RSD-100C-5
RSD-100C-12
RSD-100C-24
RSD-100D-5
RSD-100D-12
RSD-100D-24
RSD-100
Input
14.4~33.6V
14.4~33.6V
14.4~33.6V
28.8~67.2V
28.8~67.2V
28.8~67.2V
57.6~154V
57.6~154V
57.6~154V
Output
5V, 0~20A
12V, 0~8.4A
24V, 0~4.2A
5V, 0~20A
12V, 0~8.4A
24V, 0~4.2A
5V, 0~20A
12V, 0~8.4A
24V, 0~4.2A
R&N
100mV
120mV
150mV
100mV
120mV
150mV
100mV
120mV
150mV
150W
Model No.
RSD-150B-5
RSD-150B-12
RSD-150B-24
RSD-150C-5
RSD-150C-12
RSD-150C-24
RSD-150D-5
RSD-150D-12
RSD-150D-24
Input
14.4~33.6V
14.4~33.6V
14.4~33.6V
28.8~67.2V
28.8~67.2V
28.8~67.2V
57.6~154V
57.6~154V
57.6~154V
Output
5V, 0~30A
12V, 0~12.5A
24V, 0~6.3A
5V, 0~30A
12V, 0~12.5A
24V, 0~6.3A
5V, 0~30A
12V, 0~12.5A
24V, 0~6.3A
R&N
100mV
120mV
150mV
100mV
120mV
150mV
100mV
120mV
150mV
Effi.
89%
90%
90%
90%
92%
91%
90%
92%
91%
RSD-200
Input
14.4~33.6V
14.4~33.6V
14.4~33.6V
28.8~67.2V
28.8~67.2V
Output
12V, 0~16.7A
24V, 0~8.4A
48V, 0~4.2A
12V, 0~16.7A
24V, 0~8.4A
R&N
120mV
150mV
180mV
120mV
150mV
Input
Output
R&N
28.8~67.2V
48V, 0~4.2A
180mV
91%
RSD-200D-12
57.6~154V
12V, 0~16.7A
120mV
91%
RSD-200D-24
57.6~154V
24V, 0~8.4A
150mV
91%
RSD-200D-48
57.6~154V
48V, 0~4.2A
180mV
91%
300W
RSD-150
200W
Model No.
RSD-200B-12
RSD-200B-24
RSD-200B-48
RSD-200C-12
RSD-200C-24
Effi.
88.0%
89.0%
89.0%
89.0%
91.0%
91.0%
89.5%
91.0%
90.0%
Model No.
RSD-200C-48
Effi.
89%
89%
89%
91%
91%
84
Effi.
RSD-300
Model No.
Input
Output
R&N
Effi.
RSD-300B-5
14.4~33.6V
5V, 0~42A
100mV
89.0%
RSD-300B-12
14.4~33.6V
12V, 0~22.5A
120mV
89.5%
RSD-300B-24
14.4~33.6V
24V, 0~11.3A
150mV
90.0%
RSD-300B-48
14.4~33.6V
48V, 0~5.7A
180mV
91.5%
RSD-300C-5
28.8~67.2V
5V, 0~42A
100mV
90.5%
RSD-300C-12
28.8~67.2V
12V, 0~25A
120mV
91.0%
RSD-300C-24
28.8~67.2V
24V, 0~12.5A
150mV
91.5%
92.0%
RSD-300C-48
28.8~67.2V
48V, 0~6.3A
180mV
RSD-300D-5
57.6~154V
5V, 0~42A
100mV
90.0%
RSD-300D-12
57.6~154V
12V, 0~25A
120mV
91.5%
RSD-300D-24
57.6~154V
24V, 0~12.5A
150mV
91.5%
RSD-300D-48
57.6~154V
48V, 0~6.3A
180mV
91.5%
RSD-300E-5
21.6~50.4V
5V, 0~42A
100mV
88.0%
RSD-300E-12
21.6~50.4V
12V, 0~25A
120mV
90.0%
RSD-300E-24
21.6~50.4V
24V, 0~12.5A
150mV
91.0%
RSD-300E-48
21.6~50.4V
48V, 0~6.3A
180mV
91.0%
89.0%
RSD-300F-5
43.2~100.8V
5V, 0~42A
100mV
RSD-300F-12
43.2~100.8V
12V, 0~25A
120mV
91.0%
RSD-300F-24
43.2~100.8V
24V, 0~12.5A
150mV
91.0%
RSD-300F-48
43.2~100.8V
48V, 0~6.3A
180mV
91.5%
19" Rack Power
1000~18000W Single Output
1000W 1U Rack Power System
•
•
•
•
•
•
•
•
Universal AC input / Full range
Built-in 5V/0.3A standby power
Built-in active PFC function
Protections: Short circuit / Overload
Over voltage / Over temp.
Forced air cooling by built-in DC fan
High power density 10.7W/inch 3
1U low profile: 44mm
Output voltage can be trimmed
between 90% ~ 110% of the rated
output voltage
• Universal AC input / Full range
• Withstand 300VAC surge for 5 secs.
• Built-in 5V/0.3A, 12V/0.8A
auxiliary power
• Built-in active PFC function
• Protections:
Short circuit / Overload / Over voltage
Input under voltage / Over temp.
• Forced air cooling by built-in DC fan
• Internal OR-ing FET
• High power density 21.4W/inch 3
• 1U low profile: 44mm
• Active current sharing up to 3000W
(3 units) in one 19" rack, 3 racks
max. can be operated in parallel
(up to 8 units)
• Remote control for single unit
• Built-in remote sense function
• Hot-swap operation
• Internal OR-ing diode
• AC OK and DC OK signal output
2
• Optional I C serial data bus
• 3 years warranty
RCP-1000
CASE: 952A
295x 127x 41 mm
2000W 1U Rack Power System
RCP-2000
RCP-1U
CASE: 974A
295x 127x 41 mm
350.8x 483.6x 44 mm
Output
1 2 V, 0 ~6 0 A
2 4 V, 0~4 0 A
4 8 V, 0~2 1 A
RCP-1U
ƒ= I: AC i n l e t ; T: t e rm i n a l b l o c k
ƒ
Tol.
±1%
±1%
±1%
R&N
150mV
200mV
300mV
Effi.
81%
87%
89%
1 9 " 1 U ra c k f o r RCP-1 0 0 0 s e ri e s
Control and Monitor Unit for RCP-1000
• 1U low profile
• 19-inch rack mounting
• I 2C decoder, control and monitor up
to 3 RCP-1000- -C units
• Suitable for all kinds of RCP-1000
output (12V,24V,48V)
• Digital meters for output voltage,
output current, and internal
temperature on front panel
ƒ
RKP-1U
350.8x 483.6x 44 mm
AC input voltage range ........ 90~264VAC
DC adjustment range ........... -12%~+15% rated output voltage
Overload protection ............. 105%~125% constant current limiting,
shut off after 5 sec., re-power on to recover
Over voltage protection ....... 120%~145% rated output voltage
Setup, rise, hold up time ...... 1500ms, 60ms, 10ms at full load and 230VAC
Withstand voltage ............... I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1 minute
Working temperature ........... -40~+70° C (refer to output derating curve)
Safety standards ................ UL60950-1, TUV EN60950-1 approved
EMC standards ................... EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11, EN61000-6-2
heavy industry level
Packing .............................. 2kg (single unit of RCP-2000)
11.5kg (empty rack)
AC input voltage range ........ 90~264VAC
DC adjustment range ........... ±3% rated output voltage
Overload protection ............. 105%~125% constant current limiting,
auto-recovery
Over voltage protection ....... 110%~135% rated output voltage
Setup, rise, hold up time ...... 1000ms, 60ms, 16ms at full load and 230VAC
Withstand voltage ............... I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1 minute
Working temperature ........... -20~+60°C (refer to output derating curve)
Safety standards ................ UL60950-1, TUV EN60950-1 approved
EMC standards ................... EN55022 class B, EN61204-3,
EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11,
EN61000-6-2 heavy industry level
Packing .............................. 1.91kg (single unit of RCP-1000)
12.3kg (empty rack)
Model No.
RCP -10 0 0 - 1 2
R CP -10 0 0 - 2 4
RCP -10 0 0 - 4 8
• Active current sharing up to 6000W
(3 units) in one 19" rack, 3 racks
max. can be operated in parallel
(up to 9 units)
• Remote control for single unit
• Built-in remote sense function
• Hot-swap operation
• PMBus serial communication
• AC OK and DC OK signal, fan fail,
OTP alarm signal
• 3 years warranty
Model No.
RCP-2000-12
RCP-2000-24
RCP-2000-48
Output
1 2 V, 0 ~ 1 0 0 A
2 4 V, 0 ~ 8 0 A
4 8 V, 0 ~ 4 2 A
RKP-1U
1 9 " 1 U r a ck f o r R C P - 2 0 0 0 S e r ie s;
= I: A C in le t ; T: t e r m in a l b lo ck
ƒ
Tol.
±2%
±1%
±1%
R&N
1 5 0 mV
200mV
3 0 0 mV
Effi.
86.0%
90.5%
92.0%
ƒ
Control and Monitor Unit for RCP-2000
• 1U low profile
• 19-inch rack mounting
• Control and monitor up to 32
RCP-2000 units
• Front panel LCD and buttons for
on-site service without PC
• Alarm/event log with time and date
• Easy wire connections on rear side
• Potentiometer for adjusting output
voltage of RCP-1000 unit on front
panel
• Relay contacts and LED indicators
for AC fail, DC fail, and over
temperature warning
• Removable fixing accessory
• 3 years warranty
• Windows-based PC communication
software
• USB, RS-232 or Ethernet interface
for PC connection locally or remote
monitoring and control via GSM modem
• 4 user programmable relay outputs for
traditional remote or warning
• 3 years warranty
ƒ-CMU1
RKP-CMU1
RKP-1U
147.5x 127x 41 mm
350.8x 486.6x 44 mm
440x 68x 44 mm
AC input voltage range ... 90~264VAC
AC inrush current ........... Cold start, 30A at 115VAC, 50A at 230VAC
Relay contact rating ....... 30VDC, 1A
Working temperature ...... -20~+60°C (refer to output derating curve)
Safety standards ............ Design refer to UL60950-1, TUV EN60950-1
Withstand voltage .......... I/P-O/P:3kVAC, I/P-FG:1.5kVAC, O/P-FG:0.5kVAC
Isolation resistance .........I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC
EMC standards .............. EN55022 class B, EN61000-3-2,3,
EN61000-4-2,3,4,5,6,8,11
Contection .................... Screw DIN terminal for AC input and relay
contact output; D-Type right angle 25 positions
for communication port
Model No.
RCP-MU
DC input voltage range ...... 12~15VDC
DC input current ................ 1A at 12VDC, 0.8A at 15VDC
Output relay contact .......... 4 user programmable relay
Working temperature ......... -25~+70° C (refer to output derating curve)
Safety standards ............... UL60950-1, TUV EN60950-1 approved for
RKP-1U -CMU1
Withstand voltage .............. I/P-O/P:3kVAC, I/P-FG:1.5kVAC
Isolation resistance ........... I/P-O/P, I/P-FG: 100M Ohms / 500VDC
EMC standards ................. EN55022 class B, EN61000-3-2,3, EN61000-42,3,4,5,6,8,11, EN61000-6-1 light industry level
ƒ
Model No.
Application
RKP-CMU1
Control and monitor RCP-2000 series (single unit of RKP-CMU1)
RKP-1U -CMU1 Control and monitor RCP-2000 series (19" rack with RKP-CMU1)
Application
Control and monitor RCP-1000 series
ƒ
85
LED Series
A
fter 7 years of endeavor to develop LED power supplies for various
LED applications, MEAN WELL’s LED power family has become
the second largest product line. In order to make users easily get the
product information they need and considering the sales channel might
be different, we split LED power family from this catalog and put the
product information on a separate LED catalog. Please contact with our
sales representative to request for our new LED catalog or visit our
website: www.meanwell.com/product/led/led.html.
HLG/HLG-C series
40W~320W
• 95% high efficiency / PFC / IP65~67 / 277VAC /
4kV surge / 3-in-1 dimming(B-type)
• C.C. output with high output voltage >60VDC
for HLG-C series
• Suitable for outdoor LED lighting
• 5 years warranty
LPF series 16W~90W
• 91% high efficiency / PFC / IP67 / 277VAC /
Class II input / 3-in-1 dimming(D-type) /
Class 2
• Suitable for indoor LED lighting
• 5 years warranty
HVG/HVGC series 65W~150W
• 180~480VAC/96W, 180~528VAC/65W&150W
• 91.5% high efficiency / PFC / IP65~67 /
3-in-1 dimming (B-type)
• Suitable for outdoor LED lighting
• 5 years warranty
PLN/HLN series 20W~96W
• 91% high efficiency
• PFC / 277VAC / IP64 / Class 2 /
3-in-1 dimming (HLN-B type)
• Suitable for indoor LED lighting
• PLN: 2 years warranty ; HLN: 3 years warranty
HBG series 96W~240W
• Circular shape metal case
• 93.5% high efficiency / PFC / IP65~67 / 277VAC /
4kV surge / 3-in-1 dimming(B-type)
• Suitable for high bay lighting
• 5 years warranty
•
•
•
•
CLG series 60W~150W
• 91% high efficiency / PFC / IP65~67 / 277VAC /
4kV surge
• Suitable for outdoor LED lighting
• 3 years warranty
PCD/PLD series 16W~60W
• PFC / AC phase-cut dimming / Work with
leading edge and trailing edge TRIAC dimmers
• Non AC dimming for PLD-16/25/40/60
• Suitable for indoor LED lighting
• 3 years warranty
CEN series 60W~96W
• 91% high efficiency / PFC / IP66 / 277VAC /
4kV surge / Class 2
• Suitable for outdoor LED lighting
• 3 years warranty
PLM series 12W~40W
• Class II input / PFC / 277VAC /
Plastic case / Low cost
• Push terminal style of I/O
• Suitable for indoor LED lighting
• 2 years warranty
HSG series
LP series 18W~150W
• IP67 / Class II input / Class 2 (18W~60W)
• Suitable for indoor LED lighting
• 2 years warranty
•
•
•
•
PLC series
70W
Rectangular metal case
PFC / IP65 / 277VAC / Class 2
Suitable for outdoor LED lighting
3 years warranty
30W~96W
89% high efficiency / PFC / Class 2
Screw terminal style of I/O
Suitable for indoor LED lighting
2 years warranty
LCM series 25W~60W
‡KLJKHI¿FLHQF\3)&a9$&3ODVWLFFDVH
• Multiple stage C.C. level selectable by DIP switch
• 0~10VDC, PWM, push dimming / DALI interface
• Suitable for indoor LED lighting
• 3 years warranty
APV/APC series 12W~35W
• Class II input / Class 2 / Low cost
• C.V. mode for APV series ;
C.C. mode for APC series
• Suitable for indoor LED lighting
• 2 years warranty
PLP/HLP series 20W~80W
• PFC / PCB type / 277VAC / Class 2 /
3-in-1 dimming (HLP)
• Suitable for LED lighting (built-in type)
• PLP: 2 years warranty ; HLP: 3 years warranty
LDD/LDH series DC/DC C.C. LED Driver
• LDD: 300 / 350 / 500 / 600 / 700 / 1000 / 1200mA
LDH: 350 / 500 / 700 / 1050mA
• High efficiency up to 97%
• LDD: pin, wire, or SMD style for choice
LDH: pin or wire style for choice
• 3 years warranty
86
Inverter Series
M
EAN WELL pr ov ides f ull r ange of DC/ A C i n v e r t e r f r o m 1 0 0 W ~ 3 0 0 0 W w i t h
various options to fulfill the growth of alternative energy related applications.
This product family includes solar inverter, true sine wave inverter, and modified sine wave
inverter, which are highly efficient, energy-saving, low power consumption, and approved by global
safety/EMC certificates per UL, E-mark, CE, and FCC. Considering the sales channel might be different,
we split the inverter power family from this catalog and put the product information on a separate Inverter
catalog. Please contact with our sales representative for our new Inverter catalog or visit our website:
www.meanwell.com/product/inverter/inverter01.html .
Modified Sine Wave
A301 / A302 series
True Sine Wave
TS series
100~2500W
• 2 times high surge power for motor related
applications
• Advanced digital control by microprocessor
• High efficiency up to 92%
• Low THD
• Standby saving mode to conserve
energy for 700~3000W
• High frequency design
• Input and output fully isolation
• Low power consumption (standby)
• Optional remote ON/OFF control for 1000~2500W
• Built-in USB interface and without fan for 100W
True Sine Wave with Solar Charger Function
TN series
200~3000W
Inverter Remote Controller
IRC series
1500~3000W
• 2 times high surge power for motor related applications
• Advanced digital control by microprocessor
• Selectable UPS & energy saving mode
• AC bypass / Built-in AC and solar charger
• Low THD, fast transfer time
• Optional monitoring software and
connection cable
• Wall-mounted and control panel assembly acceptable
• Built-in ON/OFF button
• LED indicators for remote ON/OFF, abnomal and power
saving mode
• Equipped with 10FT cable, optional for 25FT or 50FT
• Connect directly to the remote socket of inverter ;
no power supply needed
• Suitable series:
IRC1: TS-700 / 1000 / 1500 / 3000; TN-1500 / 3000
IRC2: TS-700 / 1000 / 1500 / 3000
IRC3: TN-1500 / 3000
87
Case Drawing
901
905
Unit:mm
902
Unit:mm
906
Unit:mm
Unit:mm
903
907
Unit:mm
Unit:mm
88
Case Drawing
910A
916A
916B
Unit:mm
Unit:mm
R.C.±
+V ADJ.
ʇ916A: without cooling fan / 916B: with cooling fan
912
919A
Unit:mm
915A
Unit:mm
920A
Unit:mm
Unit:mm
89
Case Drawing
926A
Unit:mm
931A
Unit:mm
Unit:mm
63.5
127
927A
929A
Unit:mm
932A
928A
Unit:mm
Unit:mm
9.5
1
2
3.5
2-
M3
82
3
40
8
4
55
5
3.5
40.5
5
20.5
5
88.5
99
6.5
87
90
3
74
35
28
18
2-M
17.5
3.5
3.5
Case Drawing
935A
941B
Unit:mm
Unit:mm
920A
943A
939A
Unit:mm
Unit:mm
254
19
38
63.5
12.5
147.5
4-M4
254
19
12.25
147.5
4-M4
127
101.5
Air flow
direction
946A
940A
Unit:mm
Unit:mm
171.5
19
171.5
19
38
63.5
12.5
278
Air flow
direction
152.4
177.8
4-M4
15.65
4-M4
91
Case Drawing
952B
977A
Unit:mm
41
127
Unit:mm
978A
963A
Unit:mm
Unit:mm
971A
980A
Unit:mm
Unit:mm
92
Case Drawing
986A
995A
Unit:mm
Unit:mm
!
987A
996A
Unit:mm
Unit:mm
998A
988
Unit:mm
Unit:mm
93
Case Drawing
999A
206A
Unit:mm
203A
Unit:mm
207A
Unit:mm
Unit:mm
205A
208A
Unit:mm
94
Unit:mm
Case Drawing
956 (MDR-10/20)
992A (SDR-120)
Unit:mm
962A (MDR-40/60)
979A(SDR-240)
Unit:mm
973A (MDR-100)
Unit:mm
Unit:mm
984A (SDR-480)
Unit:mm
Unit:mm
95
Accessories
DIN Rail Accessories
Mounting Accessories
2-F3x4 ISO
2-F3x4 ISO
2-F3x4 ISO
2-F3x4 ISO
ITEM
Order No.
Case
Model
DRL-01
903
905
931
932
971
S-40, D-30, T-30, .....
S-15, S-25, .....
RS-25, NES-15
RS-35, NES-25
RS-15
DRL-02
901
902
906
915
916
920
S-50, S-60, D-60, .....
S-100, S-100F, SD-100, ....
S-150, SD-150, D-120, .....
SP-100, .....
SP-150, SP-200, .....
SP-75, .....
SP-240, HRP ( G ) -300
DRL-03A
DRP-01
DRP-01A
DRP-02
980
987
901, 902
903, 906
931, 932
203
205
978
999
905 / 915
916 / 920
928
DRP-03
DRP-01
DRL-01~03
DRP-04
203
205
978
999
ITEM
Order No.
MHS012
MHS013
All models
Case
Model
206, 207
912, 915
916, 935
939, 940
977, 980
982, 986
987, 995
919
926
HDP-190, RSP-200/320,
S-201, S-320,
S-350, SP-100,
SP-150, SP-200,SP-320,
SE-450/1000, MP450/650/1000,
SP-240, HRP-300/450/600,
RSP-2400/3000
PSP-500, SP-750,
SE-600
MHS014
212
952
RSP-750
RSP-1000, SD-1000
MHS025
910
SP-500, PSP-600.....
MHS026
943
RSP-1500
MHS027
971
931
RS-15
RS-25
TBC-05
901
903
905
932
220
901
903
905
906
227A
SD-50, S-60
S-40, NES-50, RS-75
S-25, SD-25, NES-35, RS-50
NES-25, RS-35
RSP-75
D/ID-60, NE D/T-75, RD-85,
NE S -100, RS-100, T- 60
S -100F, RD-125, NES-150,
RS -150, S D-100, HRP-200
NE D/T-50, RD/RID-65, T-40
N E D / T-3 5 , R D - 5 0
S -150, S C-150, SD-150
RS P -100
TBC-08
901
906
AD-155, ADD/ADS-155
D/T/Q-120
TBC-09
207
RSP-200/320
RSD-100 / 150 / 200 / 300
TBC-07
S-15, S-25, ... / SP-100, ...
SP-150, SP-200, .. / SP-75, ...
USP-225, .....
902
TBC is the cover for
terminal block
All models
RSD-100 / 150 / 200 / 300
96
General Information
Quotation
Ŷ Most of our standard products are available and in stock through our global authorized distributors. Please
contact your local distributor for prompt service. Please let us know if you are unable to find Mean Well's
distributor information in your local area.
Ŷ Written quotations are valid for 60 days from the date quoted unless otherwise specified. Customers are
responsible for all banking related charges outside of Taiwan.
Order
Ŷ Orders must be placed to Mean Well by mail, e-mail, or fax. Please do not place your order by phone. For
international business, Mean Well will provide order confirmations with scheduled delivery dates. If you fail to
receive an order confirmation within 2 working days, please reconfirm your order.
Ŷ Minimum order amounts per shipment are determined by our local distributor's stock capability. Please contact
our sales representative for details.
Ŷ We encourage customers to place long-term orders. However, order cancellations or reschedules must be made
45 days prior to the scheduled shipping date.
Delivery
Ŷ For our standard products, Mean Well usually keeps around 2-8 weeks safety stock (based on the past 3 months
sales record) for prompt delivery of small / medium quantity orders. For large quantity or new product orders,
3-5 weeks lead-time is needed.
Return
Ŷ All returned goods must have a RMA (return material authorization) number marked on each carton. Contact
Mean Well for a RMA number. All goods must be shipped as ''freight prepaid'' unless confirmed by our sales
representatives.
Warranty
Ŷ Products found to be defective within 30 days from the date of receipt can be returned for credit or exchange.
After the initial 30 days, Mean Well will repair the goods according to our warranty period. Contact Mean Well
for further information on credit or a RMA number. Goods should be shipped as ''freight prepaid'' to Mean Well
and Mean Well will repair and return the defective units (freight prepaid) within 7 working days. If the warranty
period has expired, a repair fee (depends on the condition of the product) will be charged.
Ŷ If customers do the repair by themselves, Mean Well can provide reasonable quantity of free components for
repair purpose.
Attention
Ŷ We make every effort to ensure the accuracy of information in the catalog. If there is any discrepancy between
the data presented in our catalog and the SPEC, the SPEC sheets should take precedence (please refer to
www.meanwell.com for the latest SPEC information). We cannot take any responsibility of any consequence
arising due to error or change in specification. We suggest customers conduct a sample test for evaluation and
approval before placing a formal order.
Ŷ For continuing product improvement, Mean Well reserves the right to revise any information in this catalog
without further notification.
The EMC directive applies to component power supplies
Ŷ Mean Well ensures that all of the power supplies with CE declaration are designed to meet EMC directives and
are verified by an independent certified lab agent with a test report prepared. However, there are 2 categories
for power supplies: One is a stand-alone power supply, such as laboratory power supplies which can be tested
under EMC individually. The other category is a component power supply such as an enclosed power supply and
open PCB power supply. These power supplies are considered a component which will be installed into a final
equipment. Since EMC performance is affected by the final installation of a product, Mean Well cannot guarantee
that the final equipment will meet EMC directives. Final product manufacturers must re-confirm that their product
meets EMC directives.
RoHS Announcement
Ŷ To minimize the environmental impact and take more responsibility to the earth we live, MEAN WELL applies
manufacturing that complies with Directive 2002/95/EC of the European Parliament - RoHS (Restriction
of Hazardous Substances) since Sep. 2005. Please refer to the declaration on our web site for more detail
information.
M E A N W E L L PROD UCT CATA LOG
Taiwan
‫ځ‬ቛЋຽ۵Њѣࢨ̳Φ
M E A N W E L L E N T E R P R IS ES C O., LTD.
2 4 8 9 1! າ Δξ̣۵ડ̣ᝋˬྮ 2 8ཱི
No . 2 8 , W u q uan 3 rd Rd., W u g u Dis t .,
Ne w Tai p e i C i t y 2 4 89 1 , Ta iw a n ( R.O. C .)
௚˘ በ ཱིĈ3 4 4 9 1 0 7 5
Te l : + 8 8 6 - 2 - 2 2 9 9 - 6 1 0 0 ( r e p . )
Fa x : + 8 8 6 - 2 - 2 2 9 9 - 6 2 0 0 ( r e p . )
+886-2-2298-0818(sales)
E-m a i l: i nf o @me anw ell. com
h t t p : / / w w w. m e a n w e l l . c o m
U.S.A .
MEAN WELL USA , INC.
4 4 0 3 0 Fr e m o n t B l v d . , Fr e m o n t ,
C A 9 4 5 3 8 , U. S . A .
Te l : + 1 - 5 1 0 - 6 8 3 - 8 8 8 6
Fa x : + 1 - 5 1 0 - 6 8 3 - 8 8 9 9
E-m a i l: i nf o @me anw ellu s a .com
h t t p : / / w w w. m e a n w e l l u s a . c o m
E ur op e
ME A N W ELL EU R OP E B . V.
La n gs d e We r f 8 , 1 1 8 5 X T Am s t elv een ,
Th e Ne t he rland s
Te l : + 3 1 - 2 0 - 7 5 8 - 6 0 0 0
Fa x : + 3 1 - 2 0 - 7 5 8 - 6 0 0 1
E-m a i l: i nf o @me anw ell. eu
h t t p : / / w w w. m e a n w e l l . e u
Chi n a
‫ځ‬ቛ)ᇃэ*࿪̄ѣࢨ̳Φ
MEAN WELL (GUANGZHOU) ELECTRONICS CO., LTD.
ᇃ э ξ ͇ ‫ ګ‬ડ ‫ ࣿ ڌ‬ᗉ เ Յ ̂ ྽ ག щ ̍ ຽ ๩A ഏ 2 ሁ
2 n d F l o o r, N o .A B u il din g, Yu e an I n d. Par k ,
H u an gc u n R o ad, Do n gpu Town , Tian h e Dis t r ic t ,
Guangzhou, China
Po s t C o d e : 5 1 0 6 6 0
Te l : + 8 6 - 2 0 - 2 8 8 7 - 1 2 0 0 4 0 0 - 0 2 0 - 1 2 0 0 (Һ ; ෱ ࿪ ྖ)
Fa x : + 8 6 - 2 0 - 8 2 0 1 - 0 5 0 7
E- m ail :in fo @ m e an we l l .c o m .c n
h t t p : / / w w w. m e a n w e l l . c o m . c n
ᛂэ‫ځ‬ቛࡊԫѣࢨ̳Φ
SUZHOU MEAN WELL TECHNOLOGY CO., LTD.
ѯ ᛂ ࠷ ᛂ э ξ ࠹ ‫ ݱ‬ડ เ ₚ ᗉ ም ว ̍ ຽ ๩ ‫ ڌ‬፜ ઉ ϔ ྮ7 7ཱི
N o .7 7 , J ian - M in g R d. Do n g- Q iao ,
Pan -Yan g I n d. Par k , H u an g- Dai Town ,
Xian g- C h e n g Dis t r ic t , Su zh o u , J ian g- Su , C h in a
Po s t C o d e : 2 1 5 1 5 2
Te l : + 8 6 - 5 1 2 - 6 5 0 8 - 8 6 0 0
Fa x : + 8 6 - 5 1 2 - 6 5 0 8 - 8 7 0 0
E- m ail :in fo @ m e an we l l .c c
h t t p : / / w w w. m e a n w e l l . c c
Ple ase C o n tact Your Loc a l Dis tribut or
www.meanwell.com
2013 O c t o b e r
This catalog is printed
with soy ink
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
