REALISE YOUR CREATIVE VISION WITH THE CANON EOS SYSTEM
12
Lens Range
Canon Lens Technology
EF Lens Specifications
EF Lens Accessories
12
14
16
17
SPEEDLITES
18
Speedlite Range
Speedlite Technology
Wireless Flash Photography
Speedlite Accessories
18
20
22
24
POWER
SUPPLIES
25
Today, the EOS system includes an ever-expanding interchangeable range of 35mm and digital camera bodies, lenses and
accessories. Compatibility extends beyond SLRs and lenses, encompassing digital still and digital video formats, making EOS
the most comprehensive image capture system available today. With an ever-growing range of SLRs, Canon brings the EOS
advantage to all photographers: amateurs who want exceptional results with the simplicity of point-and-shoot operation,
professionals who require a specialised tool to help bring their creative vision into focus, and everyone in between.
Only Canon EOS camera owners have access to the world’s largest selection of autofocus lenses with technologies such
as ultrasonic, high-speed AF and Image Stabilizer, as well as numerous other accessories including Speedlite flash units with
Canon’s E-TTL flash exposure system, Power Drive Boosters, dedicated photo printers, remote controllers and much, much more.
If you already own an EOS camera, you can stimulate and broaden your creativity by taking advantage of the many system
accessories available for your camera. If you haven’t tried EOS yet, come and see what you’ve been missing. Creative power
is what EOS is all about ... today and tomorrow!
