FORWARD

LISTENING.

Portfolio 15 | 16

2

When talking sound, Denon has always been a forerunner.

For over a century, we‘ve been developing products, leading in technology and design. Improving on what went before, that‘s our benchmark for every year. If you listen to music with a Denon, you can expect nothing less than the best.

So you can keep one thing in mind:

Whatever we‘re up to, it is going forward.

This year’s portfolio defi nitely sets a new landmark in the world of sound. With our

AVRs already known to be top-class, the new X-series takes another huge step. These vibrant powerful units are fully loaded with 3D-sound capabilities, creating a home cinema experience like no other.

As with all our products, there is a lot more to discover, like the all-new Denon

Design Series. We are also introducing a completely new category: HEOS by

Denon. Take a look and see what makes this year‘s line-up our most innovative ever.

Enjoy,

The people at Denon

3

TOMORROW’S SOUNDS.

TODAY.

Content

Content 5

06 BLOCKBUSTING 3D SOUND.

Integrated Network A/V-Receivers

08 AVR-X7200WA

09 AVR-X6200W

10 AVR-X4200W

11 AVR-X3200W

12 AVR-X2200W

13 AVR-X1200W / AVR-X520BT

14 PERFECTION IS STATED.

Blu-ray Universal Players

15 DBT-3313UD

16 MAKE THE LION ROAR AGAIN.

TV-Speakers

18 DHT-T110

19 DHT-S514

20 ORIGIN IS KEY.

Hi-Fi Components

22 DA-300USB

23 DA-10

24 DCD-2020AE / PMA-2020AE

25 DCD-1520AE / PMA-1520AE

26 DCD-720AE / PMA-720AE

27 DCD-520AE / PMA-520AE

28 DNP-730AE

29 DP-300F / DP-200USB / DP-29F / Cartridges

30 D-F109 / D-F109DAB + DRA-F109 +

SC-F109 + DCD-F109

31 D-M40 / D-M40DAB + SC-M40

32 REAL HIFI FOR TODAY‘S LIFESTYLES.

Design Series

34 DRA-100

35 PMA-50 / DCD-50

36 COME AWAY WITH ME.

Portable Bluetooth

®

Speakers

38 ENVAYA

39 ENVAYA MINI

40 ONE, TWO, FREEDOM.

Network Music Systems

42 CEOL RCD-N9 + SC-N9

43 CEOL PICCOLO DRA-N4 + SC-N4

45 CEOL CARINO N2

46 NOTHING ELSE MATTERS.

Headphones

48 AH-MM400

49 AH-MM300

50 AH-MM200

51 AH-C120MA / AH-C50MA

52 AH-GC20

53 AH-W200

55 AH-W150

56 ANYWHERE SOUNDS AMAZING.

HEOS by Denon

59 HEOS 7

60 HEOS 5

61 HEOS 3

63 HEOS 1 / GOPACK

65 HEOS HomeCinema

66 HEOS AMP

67 HEOS LINK

68 SPECIFICATIONS

66

Integrated Network A/V-Receivers

BLOCKBUSTING

3D SOUND.

Be prepared for home entertainment of another kind.

Discover a new cinematic experience with the X-series A/V-Receivers. Dolby Atmos delivers a stunning room-fi lling, eruptive sound with power and depth where every detail comes alive from all directions - even from above. Go for Auro-3D or DTS:X and you‘ll drive your all-around sound sky high.

But the AVRs wouldn‘t be a Denon if there weren‘t more top features. All HDMI outputs support the HDCP 2.2 protocol for transmission of copy-protected 4K video. And speaking of 4K there‘s full rate 4K 60HZ processing with 4:4:4 colour resolution and the ability to upscale content to 4K Ultra HD.

All the latest connectivity options are covered too, with all AVRs able to operate wirelessly as part of your home network and with Bluetooth

®

for streaming music from your smartphone. Are the Denon AVRs ahead of the game again? Well, see for yourself.

8 Integrated Network A/V-Receivers // AVR-X7200WA

AvR-X7200WA

9.2 CHANNEL INTEGRATED NETWORK RECEIVER

Marvel at the new mothership of the Denon AVR fl eet. If you could wish for an AVR that excels in literally every aspect – the AVR-X7200WA is the answer. With its 9 discrete channels delivering 210 Watts each, this amplifi er is a true powerhouse of home cinema. This unit’s abilities are impressive: The lavish 11.2 channel processing capability in tandem with Dolby Atmos, support for Auro-3D and DTS:X and HDCP 2.2 protocol, 4K video processing and scaling, high resolution audio playback and AL32 Processing Multi Channel will give you an earth-shaking home entertainment experience. Needless to say that this fl agship features the complete set of network functionalities.

9.2 channel AV Receiver with 210 W per channel // 11.2 channel processing; 13.2 channel pre-outs // Monolithic amplifi er design (L/R separated) with

Denon custom made transistors // D.D.S.C.-HD32 with AL32 Processing Multi Channel // Built-in WiFi with dual antenna; built-in Bluetooth

®

// 4K 60 Hz full-rate pass-through and 4:4:4 colour resolution, HDR, BT.2020 // Video Scaling of analogue and digital video signal up to 4K 60/50Hz // 8 HDMI inputs (incl. 1 front) and 3 HDMI outputs (2 main + zone out) with full HDCP 2.2 support // Dolby Atmos up to 5.1.2, 5.1.4, 7.1.2, 7.1.4*, 9.1.2* (* with additional 2 ch amplifi er) // DTS:X ready (via fi rmware update) // Auro-3D, Auromatic (up to 10.1 ch*; paid Upgrade) // Audyssey MultEQ XT32 (Pro ready),

Sub EQ and LFC // DSD, FLAC, ALAC and AIFF High Resolution audio streaming // AirPlay, Spotify Connect, Internet Radio // 3 zones / 3 sources //

Front panel USB input

WATCH THIS VIDEO AT denon.eu/avr-x7200wa

Integrated Network A/V-Receivers // AVR-X6200W 9

AvR-X6200W

9.2 CHANNEL INTEGRATED NETWORK RECEIVER

The AVR-X6200W is a powerful 9 channel amplifier with 11.2 channel processing and 13.2 pre-out. A discrete monolithic amplifi er with custom made DHCT (Denon High Current Transistors), to be precise. With an advanced video processing and switching section, the AVR-6200W features full 4K Ultra HD connectivity including 4K scaling,

HDMI 2.0a and HDCP 2.2 compliance. Featuring Dolby Atmos and DTS:X object-based surround sound formats, plus an upgrade option to Auro-3D, the AVR-X6200W is ready for the most complete blockbusting 3D sound. Triple

HDMI outputs with multisource/multi-zone functionality and integrated Audyssey MultEQ XT32/LFC guarantee the ideal calibration of your setup. Featuring dual Wi-Fi antenna and on board Bluetooth

®

, it is perfectly set for all wireless services including Spotify Connect, AirPlay and Internet Radio.

9.2 channel AV Receiver with 205 W per channel // 11.2 channel processing; 13.2 channel pre-outs // Monolithic amplifier design with Denon custom made transistors // D.D.S.C.-HD with AL24 Processing // Built-in WiFi with dual antenna; built-in Bluetooth ® // 4K 60 Hz full-rate pass-through and 4:4:4 colour resolution, HDR, BT.2020 // Video Scaling of analogue and digital video signal up to 4K 60/50 Hz // 8 HDMI inputs (incl. 1 front) and 3

HDMI outputs (2 main + zone out) with full HDCP 2.2 support // Dolby Atmos up to 5.1.2, 5.1.4, 7.1.2, 7.1.4*, 9.1.2* (*with additional 2 ch amplifi er) //

DTS:X ready (via fi rmware update) // Auro-3D, Auromatic (up to 10.1 ch*; paid Upgrade) // Audyssey MultEQ XT32 (Pro ready), Sub EQ and LFC // DSD,

FLAC, ALAC and AIFF High Resolution audio streaming // AirPlay, Spotify Connect, Internet Radio // 3 zones / 3 sources // Front panel USB input

WATCH THIS VIDEO AT denon.eu/avr-x6200w

10 Integrated Network A/V-Receivers // AVR-X4200W

AvR-X4200W

7.2 CHANNEL INTEGRATED NETWORK RECEIVER

Listen to this heayweight of an AVR, and it’s hard to come back down to earth again. The amplifi er features 7 channels with 9.2 processing and 13.2 preout. You can enjoy the Next Generation sound format Dolby Atmos for immaculate audio, even upgrade to Auro-3D and DTS:X. All 8 HDMI 2.0a inputs are capable of handling 4K 60 Hz pass through while the HDMI-outputs support the latest HDCP 2.2 protocol for the transmission of copy-protected 4K video. And the

AVR-X4200W also counts 4K 60 Hz and 1080p upscaling to its qualities. And this is just the start.

7.2 channel AV Receiver with 200 W per channel // 9.2 channel processing; 13.2 channel pre-outs // D.D.S.C.-HD with AL24 Processing // Built-in

WiFi with dual antenna; built-in Bluetooth

®

// 4K / 60 Hz full-rate pass-through and 4:4:4 colour resolution, HDR, BT.2020 // Video Scaling of analogue and digital video signal up to 4K 60/50Hz // 8 HDMI inputs (incl. 1 front) and 3 HDMI outputs (2 main + zone out) with full HDCP 2.2 support // Dolby

Atmos up to 5.1.4 or 7.1.2 (* with additional 2 ch amplifi er) // DTS:X ready (via fi rmware update) // Auro-3D, Auromatic (up to 9.1 ch*; paid Upgrade) //

Audyssey MultEQ XT32 (Pro ready), Sub EQ and LFC // DSD, FLAC, ALAC and AIFF High Resolution audio streaming // AirPlay, Spotify Connect, Internet

Radio // 3 zones / 3 sources // Front panel USB input

WATCH THIS VIDEO AT denon.eu/avr-x4200w

Integrated Network A/V-Receivers // AVR-X3200W 11

AvR-X3200W

7.2 CHANNEL INTEGRATED NETWORK RECEIVER

Ready for action, the AVR-X3200W puts in a thrilling 180 Watts per channel and Dolby Atmos for all encompassing surround sound. Featuring 7 + 1 HDMI 2.0a inputs with the latest HDMI specifi cation and 4K 60 Hz pass through as well as 4K 60 Hz and 1080p upscaling, this receiver also sports a dual Wi-Fi antenna and built-in Bluetooth

®

for wireless services.

7.2 channel AV Receiver with 180 W per channel // Built-in WiFi with dual antenna; built-in Bluetooth

®

// 4K 60 Hz full-rate pass-through and 4:4:4 colour resolution, HDR, BT.2020 // Video Scaling of analogue and digital video signal up to 4K 60/50Hz // 8 HDMI inputs (incl. 1 front) and 2 HDMI outputs with full HDCP 2.2 support // Dolby Atmos (up to 5.1.2) // DTS:X ready (via fi rmware update) // Audyssey MultEQ XT room equalization //

DSD, FLAC, ALAC and AIFF High Resolution audio streaming // AirPlay, Spotify Connect, Internet Radio // ECO mode with off /on/auto setting //

RS232 control, 7.2 ch pre-outs // Front panel USB input

WATCH THIS VIDEO AT denon.eu/avr-x3200w

12 Integrated Network A/V-Receivers // AVR-X2200W

AVR-X2200W

AUGUST 2015

AVR-X2200W

7.2 CHANNEL INTEGRATED NETWORK RECEIVER

Get your sound all fi red up with this receiver. The AVR-X2200W has an impressive amplifi er section of 7 x 150 Watts, while Dolby Atmos, DTS:X preparation and the latest HDMI 2.0a technology with 4K 60 Hz pass through are also on board. Wireless connectivity is covered by dual Wi-Fi antenna and Bluetooth

®

.

7.2 channel AV Receiver with 150 W per channel // Built-in WiFi with dual antenna; built-in Bluetooth ® // 4K 60 Hz full-rate pass-through and 4:4:4 colour resolution // Video Scaling of analogue and digital video signal up to 4K 30/25/24 Hz // 8 HDMI inputs (incl. 1 front) and 2 HDMI outputs with full HDCP 2.2 support // Dolby Atmos (up to 5.1.2) // DTS:X ready (via fi rmware update) // Audyssey MultEQ XT room equalization // DSD, FLAC, ALAC and AIFF

High Resolution audio streaming // AirPlay, Spotify Connect, Internet Radio // ECO mode with off /on/auto setting // Front panel USB input

WATCH THIS VIDEO AT denon.eu/avr-x2200w

Integrated Network A/V-Receivers // AVR-X1200W // AVR-X520BT 13

AvR-X1200W

7.2 CHANNEL INTEGRATED NETWORK RECEIVER

The AVR-X1200W comes with 7 fully discrete channels delivering 145 Watts of power each. With Dolby Atmos builtin and DTS:X ready, this model can handle almost any audio. Its six HDMI inputs with full HDCP 2.2 support are able to handle 4 K 60 Hz pass through. Did we mention it features complete network functionality?

7.2 channel AV Receiver with 145 W per channel // Built-in WiFi with dual antenna; built-in Bluetooth

®

// 4K 60 Hz full-rate pass-through and 4:4:4 colour resolution // 6 HDMI inputs (incl. 1 front) with full HDCP 2.2 support // Dolby Atmos (up to 5.1.2) // DTS:X ready (via fi rmware update) //

Audyssey MultEQ XT room equalization // DSD, FLAC, ALAC and AIFF High Resolution audio streaming // AirPlay, Spotify Connect, Internet Radio //

ECO mode with off /on/auto setting // Front panel USB input

WATCH THIS VIDEO AT denon.eu/avr-x1200w

AvR-X520BT

5.2 INTEGRATED RECEIVER WITH BLUETOOTH

®

It may be the entry-level model but this receiver is still feature-rich. Its 5.2 channels deliver impressive surround sound in our renowned audio quality. And like its bigger siblings it sports full-rate 4 K 60 Hz Ultra HD capabilities.

Get the Denon 500 series remote app and completely control the AVR-X520BT via Bluetooth

®

. This includes streaming your favourite music, of course.

5.2 channel AV Receiver with 130 W per channel // 4K 60Hz full-rate pass-through (3 designated HDMI inputs) // 5 HDMI inputs with full HDCP 2.2 support on 3 HDMI inputs // Built-in Bluetooth

®

// Auto setup by microphone and room EQ // Front panel USB input // Denon Bluetooth

®

Remote

App (Denon 500 Series Remote)

WATCH THIS VIDEO AT denon.eu/avr-x520bt

14

Blu-ray Universal Players

If you‘re looking for the ultimate match, complete your home cinema set-up in a simple yet brilliant way:

Pair your Denon AVR with our awardwinning Universal Audio/Video player.

The DBT-3313UD meets the highest demands in technology and versatility. And that‘s not just what we say:

Numerous tests have proved it over and over again. The robust materials and fully shielded drive mechanism reduce any vibrations that can compromise the picture and sound.

PERFECTION

IS STATED.

Blu-ray Universal Players // DBT-3313UD 15

DBT-3313UD

UNIVERSAL DISC TRANSPORTER

This universal disc player is one talented fellow. Not only does it play Blu-ray, DVD, CD, Super Audio CD and DVD

Audio discs, but it also lets you stream online video from sources like Netfl ix or YouTube to your home cinema set up. With its quality build and its multiple connectivity options it is clearly cut above every rival players.

Universal Blu-ray Disc Transport that also plays DVD, CD, Super Audio CD and DVD-Audio // Denon Link HD for high class digital transmission //

Dual HDMI output and Pure Direct mode // Fully shielded fast loading Denon S.V.H. (Suppress Vibration Hybrid)- mechanism // 4 independent block construction, for faithful playback of audio and video signals // Rigid chassis with double layer top and bottom plate // No fan construction for silent operation // DLNA support for Network streaming (audio/video/photo) // YouTube Leanback streaming and Netfl ix* video on demand support //

Support for DivX Plus HD // Available in black and premium silver // * This feature is not available in all countries.

Tired of the flat sound of your flat TV?

Wondering if you can turn a kitty into a predator? Well, luckily you can.

Our TV solutions may look sleek but they deliver a majestic sound. We had to break a lot of new ground to achieve this. Combining true Denon sound with excellent design - and all to critical acclaim.

To finish with another animal metaphor:

Now it‘s your turn to mount your horse and ride off into a new era of TV sound.

TV-Speakers

MAKE THE LION

AGAIN.

18 TV-Speakers // DHT-T110

DHT-T110

TV SPEAKER BASE

With this one you simply hit the bull’s eye: Clarity of dialogue. Depth of bass. Sharpness of highs. Vibrancy of special eff ects. No matter how fl at your TV’s body is, you’ll have all of this by the score. The new Denon DHT-T110 is a mono piece constructed to tune your TV’s audio in exactly the way it is meant to be heard. This all-in-one sound solution connects with only one cable to your TV and fi ts most TVs up to 50”. By the way, if you can’t get enough of the DHT-

T110’s sound, make it play your favourite songs in Denon quality: it’s an impressive Bluetooth

®

speaker, too.

Great sound with easy TV connectivity // TV up to 27 kg can be placed upon the soundbase // Analogue and digital audio input // Bluetooth

®

apt-X connectivity for portable devices // Sound mode: Dialogue, Movie & Music // Powerful sound without subwoofer due to advanced audio processing //

Aquires codes from existing TV remote // Simple remote included for ease of use // Available in black

WATCH THIS VIDEO AT denon.eu/dht-t110

TV-Speakers // DHT-S514 19

DHT-S514

SOUNDBAR

Ready to enjoy sound that gets you on the edge of your seat? The DHT-S514 soundbar and its fl exible wireless subwoofer will dramatically improve your TV experience. Rich, room-fi lling sound across the complete range: the deep and dramatic bass from the subwoofer, the clear mids and detailed highs from the multi-driver high fi delity soundbar. Amplifi ed with an overall 175 Watts of power, it’s able to make your room shake! Certainly, the crisp sound works just as well at low volume levels. Other features? Dolby Digital and DTS decoding are on board.

A dedicated night mode prevents sudden raise in volume. Sounds good? You bet it does.

Elegant soundbar with powerful, wireless subwoofer // High quality soundbar designed for use with TVs that are 42” or more // Wall and rack mountable (height adjustable feet) // HDMI input and output with ARC, analogue and digital audio input // Bluetooth ® apt-X connectivity for portable devices //

Sound mode: Dialogue, Movie & Music // Acquires codes from existing TV remote // Simple remote included for ease of use // Available in black

Hi-Fi Components

ORIGIN

IS KEY.

While going forward with seven-league boots we always carry our heritage with us. It is the idea to reproduce sound in the exact way the artist intended. That‘s the guiding principle of Denon since the beginning.

When it comes to engineering the best sound, we take it very seriously. There‘s a reason why we called our Hi-Fi products

“precision audio components” in the early years. And our approach hasn‘t changed since.

music. For those music lovers who want to elevate computer-sourced digital audio tracks to purist audiophile levels, there are our stand-alone digital audio converters like the DA-300USB. With its precise and fl awless reproduction of sound it is a

Denon component to the core.

Every Hi-Fi component that carries our name is built in the spirit to deliver the ultimate audio performance. But now and then the way we listen to our favourite music changes. Streaming digital audio from portable devices or computers has become a popular way of enjoying

21

22 Hi-Fi Components // DA-300USB

DA-300USB

HIGH RESOLUTION D/A CONVERTER

Enhance your digitally stored or streamed sounds and listen to them in High-Fidelity quality. Denon’s DA-300USB

D/A converter and headphone amplifier delivers superb sound without compromise. Equipped with a range of advanced digital technologies, the DA-300USB connects via asynchronous USB to the computer and features the ability to decode both PCM (traditional digital audio format) and DSD (Direct Stream Digital – the advanced digital audio format of SACD). For the connection to other digital audio sources, the DA-300USB also features three digital audio inputs – two optical and one coaxial. Featuring audiophile grade construction with the highest quality component parts and circuit design, the DA-300USB delivers a level of sound quality on par with Denon’s highly praised universal disc players.

USB-DAC with USB-B, 1 x coaxial and 2 x optical input // Advanced AL32 Processing + Ultra Precision 192 kHz / 32-bit D/A Converter // USB-B works in asynchronous mode and supports ASIO and WASAPI // DSD2.8 and DSD5.6 native support by DoP (DSD over PCM) // SPDIF input (optical/coaxial) up to 192/24 for upgrading other equipment // DAC Master Design with indepent crystal for 44.1 and 48 kHz // High quality fi x level analogue output for direct connection to a Hi-Fi system // High quality headphone output with volume control // Horizontal and vertical placement – display rotates automatically // Available in silver

Hi-Fi Components // DA-10 23

DA-10

HEADPHONE AMPLIFIER WITH D/A CONVERTER

A world of sound that fi ts in the palm of your hand: The Denon DA-10 is a sound gem that boosts the sound quality of smartphones, tablets and laptops, wherever you are listening. The DA-10 takes the audio signal from your device and by means of digital to analogue conversion, dramatically improves the audio stages. It also allows you to drive higher quality headphones effortlessly. In addition, the DA-10 makes your analogue home Hi-Fi system digitally compatible – you can now enjoy all your stored digital music in the best audio quality. Despite its diminutive size, it delivers Denon High Quality Sound thanks to integrated Advanced AL32 Processing. It adeptly handles high resolution audio up to 192 kHz / 24-bit, comes with DSD 2.8 and 5.6 capabilities, delivering a new level of sound quality from any source. For all your connection needs, USB-A, USB-B micro and AUX input are on board.

Smartphone size portable DAC // High quality headphone amplifi er with volume control // Gain switch to operate with diff erent type of HPs easily //

Best Denon Audio quality for Apple iDevice via USB-A and analogue input // Ultra Precision 192 kHz / 32-bit D/A Converter PCM1795 // Advanced

AL32 processing // USB Micro-B input for direct connectivity to a computer // High Resolution Audio support up to 192/24 and DSD2.8 & 5.6 // Asynchronous mode and support of ASIO and WASAPI // Fixed analogue output mode to upgrade excisting Hi-Fi system // Mini Jack (AUX) analogue input for Android device or portable device // Rechargeable battery lifetime up to 8h // Gold plated HP Jack // Aluminium body (premium silver)

24 Hi-Fi Components // DCD-2020AE // PMA-2020AE

DCD-2020AE

CD/SACD PLAYER WITH USB-DAC

The DCD-2020AE is a masterpiece of sound technology, off ering ultimate quality not just from CD or SACD, but also straight from your computer, thanks to an embedded D/A converter. With 192 kHz / 32-bit conversion and further features like its Advanced AL32 processor, this player guarantees a high resolution treat to expert ears, no matter what source you choose to play from.

Advanced AL32 Processing + Ultra Precision 192 kHz / 32-bit D/A Converter // DAC Master Clock Circuit Design to suppress jitter and noise // Direct

Mechanical Ground Construction to minimize unwanted vibration // Carefully designed construction, minimum signal paths and selected Hi-Fi parts to preserve audio signal purity // Original drive mechanism, the heart of Denon’s digital Disc playback technology, with S.V.H. (Suppress Vibration Hybrid) loader // Engineering concept of complete separation of digital and analogue circuits // Pure Direct Mode // Front USB input: iPod ® / iPhone ® digital compatible // Rear USB-B input: asynchronous mode and 192 kHz / 24-bit capable for direct PC audio streaming // SPDIF input (optical/coaxial) for upgrading other equipment // Available in premium silver

PMA-2020AE

INTEGRATED AMPLIFIER

The top of the range amplifi er by a top of the range brand: The PMA-2020AE is an Ultra High Current amplifi er for the uncompromising music connoisseur. It may look like a heavyweight but its design has been precisely and delicately engineered. With a chassis consisting of six independent blocks, the main transformer has separate power supplies for analogue and digital circuits.

Advanced Ultra High Current (UHC)-MOS Single-Push-Pull Circuit Power Amplifi er // 2 x 160 W (4 ohm) output // Direct Mechanical Ground Construction to minimize unwanted vibration // Chassis construction with 6 independent blocks to eliminate noises // Leakage-cancelling-mounted twin transformers // Main transformer with separate power supplies for analogue and digital circuits // Wider dynamic range playback, supporting a high-grade audio sources // High-grade volume control for precise adjustment // Microprocessor stop mode, for higher sound quality // High performance MM &

MC Phono Equalizer Amp // System remote control unit to control CD player but also amplifi er and network player // Available in premium silver

Hi-Fi Components // DCD-1520AE // PMA-1520AE 25

DCD-1520AE

CD/SACD PLAYER WITH USB-DAC

Thanks to the integrated D/A converter, the DCD-1520AE adds ultra high resolution audio playback directly from digital sources to the list of other audio qualities. Playback of SACD, CD or USB sources reveals a versatile and musical player. All signals pass through Denon’s Advanced AL32 Processing and high dynamic 192 kHz / 32-bit D/A converter. That’s just so DCD-1520AE, isn’t it?

SA-CD, CD playback (MP3, WMA, AAC, WAV support) // Advanced AL32 Processing and high dynamic 192 kHz / 32-bit D/A Converter // DAC mode incl. Asynchronous USB-B and opt. / coax digital in // DSD native support (DoP) // DAC master clock design, to suppress jitter and noise // Power section with digital and analog circuitry isolate from transformer coils // Precision Direct Mechanical Ground Construction, to thoroughly suppress vibration // Denon S.V.H. (Suppress Vibration Hybrid) -mechanism // Front USB input: Made for iPod ® / iPhone ® // System remote control unit to control CD player but also amplifi er and network player // Available in black and premium silver

PMA-1520AE

INTEGRATED AMPLIFIER

With an Advanced Ultra-High Current (UHC)-MOS Single Push-Pull Circuit delivering 2 x 140 Watts, the PMA-1520AE produces utterly transparent and detailed sound. Perfectly matched with the DCD-1520AE, it embodies the essence of stereo.

Advanced Ultra-High Current (UHC)-MOS Single Push-Pull Circuit with 2 x 140 W (4 ohm) // High-current, dynamic power supply, to support high speed and large current fl ow // Direct Mechanical Ground Construction to minimise unwanted vibration // Leakage-cancelling-mounted twin transformers //

Shottky diodes and selected parts // High-grade volume control for precise adjustment // Solid heat sink to suppress vibration caused by resonance point // Microprocessor Stop Mode // Gold-plated speaker terminals // High-performance phono equaliser // Available in black and premium silver

26 Hi-Fi Components // DCD-720AE // PMA-720AE

DCD-720AE

CD-PLAYER

Packed with Denon premium technology including AL32 Processing for crystal clear and detailed sound, this player is truly focussed on the immaculate playback of CDs. Alternatively, connect to a USB source or iDevice using the integrated USB functionality.

AL32 Processing and high-precision 192 kHz / 32-bit D/A converter // DAC-Master Clock design // Pure Direct mode to preserve audio signal purity //

Thoroughly vibration-resistant design with Direct Mechanical Ground Construction // Carefully designed construction to preserve audio signal purity //

Strictly selected parts for high sound quality // Front USB input: iPod ® / iPhone ® digital compatible // MP3 / WMA playback (USB, CD-R/RW) // Aluminium panel design, befi tting the elegance of an audio component // System remote control unit to control CD player but also amplifi er and network player //

Available in black and premium silver

PMA-720AE

INTEGRATED AMPLIFIER

King of the mid-range, the PMA-720AE is a solid and meticulously constructed amplifi er bearing all core elements of the Denon Hi-Fi development department. Its high-speed, high-capacity power supply ensures a steady performance - one of its many features.

Advanced High Current (HC) Single-Push-Pull Circuit with 2 x 85 W (4 ohm) to balance musical detail and power // Wide dynamic range playback, supporting high-grade audio sources // Main transformer with separate power supplies for audio and control circuits // Microprocessor stop mode, for higher sound quality // Thoroughly vibration-resistant design with Direct Mechanical Ground Construction // 2 pair of high quality speaker terminals and

Headphone jack // Phono Equalizer Amp (MM), for connecting an analogue record player // PRE OUT jack, for future upgrades // System remote control unit to control CD player but also amplifi er and network player // Aluminium panel design, befi tting the elegance of an audio component // Available in black and premium silver

Hi-Fi Components // DCD-520AE // PMA-520AE 27

DCD-520AE

CD-PLAYER

This entry model CD-Player is a top performer, too – offering a D/A converter which is capable of delivering

192 kHz / 32-bit sound.

192 kHz / 32-bit D/A converter // DAC-Master Clock design // CD-R/CD-RW playback (MP3, WMA) // Thoroughly vibration-resistant design with Direct

Mechanical Ground Construction // Carefully designed construction to preserve audio signal purity // Minimum signal path design // Strictly selected parts for high sound quality // Folder Mode function, for playing only fi les stored in specifi c folders // Aluminium panel design, befi tting the elegance of an audio component // System remote control unit to control CD player but also amplifi er and network player // Available in black and premium silver

PMA-520AE

INTEGRATED AMPLIFIER

Built to be the perfect match for the CD-Player of the same name, this classy and solidly constructed amplifi er delivers all the basic features and techniques required to create the renowned Denon sound.

Advanced High Current (HC) Single-Push-Pull Circuit with 2 x 70 W (4 ohm) to balance musical detail and power // Wide dynamic range playback, supporting high-grade audio sources // Main transformer with separate power supplies for analogue and digital circuits // Microprocessor stop mode for higher sound quality // Thoroughly vibration-resistant design with Direct Mechanical Ground Construction // 1 pair of high quality speaker terminals //

Phono Equalizer Amp (MM), for connecting an analogue record player // Headphone jack // Eco friendly with Less than 0.3 W at stand-by and auto power off // Aluminium panel design, befi tting the elegance of an audio component // Available in black and premium silver

28 Hi-Fi Components // DNP-730AE

DNP-730AE

NETWORK AUDIO PLAYER

Expand your existing Hi-Fi system and unlock the power of your home network. The Denon DNP-730AE easily connects your Hi-Fi to the virtues of Spotify connect or Internet radio. When delivering music via Wi-Fi, the two diversity antennas guarantee a more reliable connection. Like any Denon, it bears qualities beyond its status: DLNA

1.5 network audio streaming, DSD, FLAC HD, ALAC support, AirPlay wireless streaming and more. All of these processed via a 192 kHz / 32-bit D/A converter, complete with jitter reducer.

DLNA1.5 network audio streaming inclusive high resolution DSD // High quality 192 kHz / 32-bit DAC plus Jitter Reducer // DSD, FLAC HD, WAV, AIFF,

ALAC and Gapless playback // Spotify Connect, Internet Radio and AirPlay for wireless streaming from iDevice // Front USB input for iPhone ® / iPod ® and

USB memory // WiFi (b/g/n) built-in with WiFi Sharing for iOS device and WPS for easy setup // WMM (WiFi Multimedia) // Denon Hi-Fi Remote App for iOS and Android plus REMOTE CONTROL terminal for AMP/CD control // High contrast 3 line OLED display // Available in black and premium silver

Hi-Fi Components // DP-300F // DP-200USB // DP-29F // Cartridges 29

DP-300F

TURNTABLE

Rediscover your old favourites or simply indulge in your love of vinyl with this high-precision turntable.

High-precision diecast aluminium turntable // Refi ned external design with a gloss coating // Fully automatic system for easy operation // Straight tone arm to bring out the maximum performance of cartridges with superior tracing capabilities //

Includes high-grade MM cartridge // Built-in phono equaliser // Manual arm lifter

// Replaceable cartridge (4.5 - 9.5 g) // Dedicated shell // Available in black and premium silver // This model is not necessarily sold in all regions. Please contact a nearby Denon authorised dealer for details and availability.

DP-200USB

TURNTABLE

This time machine lets you convert tracks from vinyl to digital audio fi les via built-in USB functionality.

Import tracks from analogue records to USB memory without a PC // Includes

PC software for editing tracks // High-precision diecast aluminium turntable //

Automated system for easy operation // Built-in phono equalizer // Available in black and premium silver // This model is not necessarily sold in all regions. Please contact a nearby Denon authorised dealer for details and availability.

DL-103

MC CARTRIDGE

DL-110

HIGH OUTPUT

MC CARTRIDGE

DP-29F

TURNTABLE

Need an aff ordable turntable to spin your vinyl - look no further.

High-precision diecast aluminium turntable // Automated system for easy operation // Built-in phono equaliser // Available in premium silver // This model is not necessarily sold in all regions. Please contact a nearby Denon authorised dealer for details and availability.

DL-103R

MC CARTRIDGE

DL-304

MC CARTRIDGE

Cartridges are not available in all countries. For details, please contact the authorized dealer on the back of this catalogue.

30 Hi-Fi Components // D-F109 // D-F109DAB // DRA-F109 // SC-F109 // DCD-F109

D-F109 / D-F109DAB*

MINI COMPONENT SYSTEM

Don’t judge the D-F109 by its diminutive size: this compact system produces serious Hi-Fi sonics. Fully digital sound engineering makes this mini system a top performer. Embedded Ethernet and Wi-Fi functionality let you enjoy a number of benefi ts from AirPlay to Internet radio.

DNP-F109 network Audio player // Network audio player with WiFi and Ethernet connectivity // DLNA 1.5 certifi ed for reliable audio streaming and wide compatibility // AirPlay direct music streaming from iPad

®

, iPhone

®

, iPod touch

®

and iTunes library // “Play to” from WMP12 or higher // Supports

WMA, MP3, WAV, AAC, FLAC, WMA lossless (Transcode) and FLAC HD 192/24 // Internet radio by vTuner // Direct play for iPod

®

/ iPhone

®

via rear

USB // Coaxial digital and analogue output // Denon Remote App for iOS and Android // Available in black and premium silver // DRA-F109 / DRA-

F109DAB* receiver // Simple and straight circuit design // 65 W x 2 (4 ohms) High Power Output // DAB/DAB+ tuner* // Coaxial digital inputs for DNP-

F109 and DCD-F109 // Optical digital input for system expansion (TV or other digital gear) // 2-line front display, to easily identify broadcast stations //

Easy timer setting // Newly developed remote controller // Denon Remote Connector for App control in combination with DNP-F109 // Available in black and premium silver // DCD-F109 CD player // Clean and pure sound // Minimum signal path // Minimum CD pick up signal path // Coaxial digital output // Front USB input: iPod

®

/ iPhone

®

digital compatible // MP3 / WMA playback (USB, CD-R/RW) // Aluminium panel design // 2-line front display, to easily identify music tracks // Denon Remote Connector for App control in combination with DNP-F109 // Available in black and premium silver // SC-F109 Speaker System // 2-Way speaker system with 12 cm woofer and 2.5 cm soft dome tweeter // Crossover network, to separate woofer and tweeter to reproduce the smoothness of natural sound // Born from European sound design and Denon collaboration // * DAB versions and colour combinations are not necessarily sold in all regions. Please contact a nearby Denon authorised dealer for details and availability.

Hi-Fi Components // D-M40 // D-M40DAB // SC-M40 31

D-M40 / D-M40DAB*

MICRO HI-FI SYSTEM

Following in the footsteps of the multi-award winning D-M39, the new D-M40 micro Hi-Fi system delivers an impressive sound performance. The CD Receiver RCD-M40, along with the optimised two-way speaker system

SC-M40 is the latest offspring of Denon’s acclaimed M-Series. It has continually evolved to meet the needs of the modern day audio enthusiast. The latest models come with improved connectivity options such as two digital optical inputs to hook up a TV, set-top box or other digital gear. If you’re looking for impeccable quality in a compact design, here it is.

D-M40 / D-M40DAB* // Updated cosmetic design // “Simple & Straight” circuit design minimizing distortion from the input selector, electronic volume and power amp for sound purity and free of colouration // Triple Noise Reduction Design (T.N.R.D.) to preserve signal purity // High quality headphone amp with gain control // Digitally transmitted audio from iPod

®

/ iPhone

®

(via USB) for best sound quality // iDevice charging even in standby mode // USB port supports MP3, WMA, FLAC, WAV and AAC // 2 optical digital inputs for amplifi ed TV playback or other digital gear // Speaker Optimizer circuit for high quality sound with // SC-M40 speaker system // High Quality Speaker Terminals // Easy-to-use remote control handset // * DAB versions and colour combinations are not necessarily sold in all regions. Please contact a nearby Denon authorised dealer for details and availability.

D-M40

AUGUST 2015

32

Design Series

REAL HIFI

FOR TODAY‘S LIFESTYLES.

33

To transfer our vast audio know-how into new styles brings us a special satisfaction.

You have to take a look at the result: the new

Denon Design Series featuring DCD-50,

PMA-50 and DRA-100. Developed to enjoy sound at the highest level with the latest high-resolution audio sources. And you‘ll agree, this system is a real beauty.

Whatever source you choose, the Denon

Design Series will deal with it elegantly.

34 Design Series // DRA-100

DRA-100

NETWORK RECEIVER

Say hello to the newest entry in the Denon Design Series: The classy DRA-100 Network Receiver.Sporting a sleek aluminium body and two-tone design, it boasts a 2 x 70 Watts digital amplifi er with Advanced AL32 processing, network streaming capabilities, gapless playback and, of course, high resolution audio. Also, an OLED Display, a USB-A connection, two optical and one coaxial input and Spotify Connect are present and correct.

Fully digital Hi-Fi Stereo Network Receiver in an aluminum cabinet // Denon’s award winning sound technology including Advanced AL32 Processing //

Master Clock Design // 2 x 70 W (4 ohms) // Built-in Wi-Fi and Bluetooth

®

// Supports Internet Radio, Apple AirPlay streaming and Spotify Connect //

Supports Hi-res Audio (WAV, FLAC, AIFF 192 kHz / 24-bit, ALAC, DSD 2.8/5.6 MHz) over DLNA // Two optical and one coaxial digital inputs for connectivity of external devices // Front USB-A input for iDevices and USB Mass Storage Devices (supporting WMA, MP3, AAC, WAV 192/24, FLAC 192/24, AIFF

192/24, ALAC, DSD 2.8 / 5.6 MHz) // Auto Standby and low power consumption at stand-by

Design Series // PMA-50 // DCD-50 35

PMA-50

DIGITAL INTEGRATED AMPLIFIER

The PMA-50 integrated amplifi er comes with analogue and digital connectivity. For the best performance from the digital inputs it features Denon’s Advanced AL32 digital audio processing system and off ers Bluetooth

®

Connectivity with NFC and Multi-Point. Streaming your audio from portable devices is a piece of cake. The PMA-50 is even equipped with a dedicated headphone amplifi er circuit. Whichever way you look at it, the Design Series has it all.

High quality sounding Stereo Amplifi er // USB-B DAC for Computer-Direct connectivity and high-resolution audio reproduction // Digital optical / coaxial and analogue inputs // Bluetooth ® aptX ® Low Latency CD quality wireless streaming with NFC pairing // 50 W per channel (4 ohms) Full Digital

Processing Amplifi er // Advanced AL32 Processing // Subwoofer pre-output for system expansion // Dedicated headphone amplifi er circuit //

Horizontal or vertical placement with rotating display // Easy-to-use remote control // Auto Standby and low power consumption at stand-by

DCD-50

CD PLAYER

The DCD-50 is the perfect companion to the PMA-50. Yes, sometimes we can’t stop eyeballing it, too. But despite its striking beauty the DCD-50 also arrives crammed with features. For instance, a high quality D/A conversion block with 192 kHz / 32-bit D/A converter delivers wide dynamic range, along with extremely low noise and distortion.

Its slot-in CD mechanism handles CD audio and MP3 / WMA discs while its rotating display lets you place it both horizontally or vertically.

High quality CD Transporter/Player, best matching with Denon PMA-50 // Slot-in CD mechanism, supporting

CD audio and MP3 / WMA discs // Digital Coaxial output // 192 kHz / 32-bit D/A converter with analogue output (RCA) // High-grade audio components // Horizontal or vertical placement with rotating display // Easyto-use remote control // Auto Standby and low power consumption at stand-by

When the ENVAYA stepped into the spotlight last year, it made a big impact.

It delivered the famous Denon sound but on the move - and was ready to rock the house down. This year we‘d like to introduce its little brother.

Firstly you will be amazed at how a pintsized Bluetooth

®

speaker can produce such a big sound. Then you‘ll be stunned by the quality of sound – and want to take it everywhere you go.

Portable Bluetooth

®

Speakers

COME AWAY

WITH ME.

37

38 Portable Bluetooth

®

Speakers // Envaya

Envaya

PORTABLE PREMIUM BLUETOOTH

®

SPEAKER

If you’ve got it, fl aunt it! What comes out of this is pure audio happiness. Created by Hi-Fi specialists, the Envaya

Portable Bluetooth

®

Speaker delivers an extraordinary sound. Thanks to dual ‘oversized’ proprietary drivers paired with a large passive bass radiator it rocks above and beyond anything that a conventional compact speaker system can come up with. You think we boast too much? We haven’t even started! Check these features: studioquality sound processing, the latest Bluetooth

®

aptX

®

Low Latency streaming technology for CD-quality playback, approx. 10 hours battery life to play from any Bluetooth

®

capable source, integrated NFC ‘pairing’ to easily connect up to 3 devices at the same time, even 8 can be remembered. And hey, there’s even a little eye candy for you: every Envaya

comes with 4 grille cloths in diff erent colours to match your mood.

Denon developed a stereo speaker system with dual 57 mm drivers and a 100 mm passive radiator that are integrated with a suite of patented digital processing technologies to provide extraordinary sound reproduction // Bluetooth

®

aptX

®

Low Latency streaming off ers CD quality audio // NFC

®

Pairing: incredibly fast and easy Bluetooth ® pairing with no buttons to press (requires NFC enabled device) // Integrated Stand: squeeze and pop-out kick-stand with rubber foot for stable placement on any surface // Up to approx. 10 hours rechargeable battery life // Quick charging (2.5 hours) // USB Mobile charging: charges mobile devices on-the-go // AUX input connects any devices with an analogue audio output // 100-240 V power adapter, includes multiple plugs for use throughout the world // Dimensions (W x H x D) 255 x 141 x 47.5 mm // Weight: 1.28 kg // Optional carrying bag available //

Available in black or white with four interchangeable grille cloth covers (lunar, indigo, fandango, and sunset)

WATCH THIS VIDEO AT denon.eu/dsb200

Portable Bluetooth

®

Speakers // Envaya Mini 39

Envaya Mini

PORTABLE PREMIUM BLUETOOTH

®

SPEAKER

Sharply styled, highly gifted – here’s your newest travel companion. The Envaya

Mini Portable Bluetooth

®

Speaker delivers the same Denon sound quality, but in an even more compact, suave, colourful and water resistant package.

It off ers CD quality audio streaming over Bluetooth

®

minimising latency and ‘lipsync’ issues, while widened 3D audio image produces spacious music, movie and gaming soundtracks. So, grab your tablet or smartphone, go to the beach and party! The approx. 6-hour battery life means the music will last all night. Want to invite some friends? You can call them on the spot thanks to a built-in noise-cancelling speaker phone.

Dual 40 mm Full Range Drivers plus 40 x 83 mm passive radiator: off ers you superb sound and punchy bass // NFC Pairing: Incredibly Fast & Easy

Pairing (no buttons touched) // Integrated Microphone with noise cancelling: for speaker phone functionality // Carrying bag included

Network Music Systems

41

The possibilities are endless with the

CEOL audio systems. If you‘re a passionate streamer, you‘ll love the freedom of sound.

The CEOLs have been part of the Denon family for some time now. They have lost nothing of their beauty and are as vital as ever. Whichever music source you choose to spin, the CEOL Network Music Systems get out every bit of sound.

42 Network Music Systems // CEOL

CEOL

NETWORK CD-RECEIVER MUSIC SYSTEM

Is there a network system as beautiful and versatile as this? The Denon CEOL sets the bar so high that winning awards is just the icing on the cake. This year’s set-up is as formidable as ever. With 2 x 65 Watts power output it fi lls your world with music from practically any source: Bluetooth

®

, Wi-Fi, Streaming, Internet Radio, Spotify Connect,

CD, FM and AM radio or whichever device you connect to its USB input. You’re into high resolution audio? Thanks to its support for 192 kHz / 24-bit sounds and FLAC, AIFF or ALAC formats, CEOL is blasting these next generation sounds in striking quality from its dedicated speakers.

Award-winning Denon system audio design with 2 x 65 W steady power output // CD playback including WMA / MP3 (CD-R/RW) and analogue FM and

AM tuner built-in // DLNA1.5 network audio streaming // WiFi (b/g/n) built-in with WiFi Sharing for iOS device and WPS for easy setup // Spotify Connect, Internet Radio and AirPlay // Gapless playback up to 192/24 (WAV, FLAC, AIFF, ALAC) // Bluetooth

®

and NFC for direct wireless streaming // Full

Digital Processing for best audio performance from any source // Front USB input for iPhone

®

/ iPod

®

and USB memory // 2 digital optical input for best sound from a TV or another digital source // High quality acrylic top lid fi nish for an elegance appearance // Denon Hi-Fi Remote App for convenient control via smartphone or tablet // Available in glossy black and white // SC-N9 SPEAKER SYSTEM // Newly designed and voiced 2-way speakers //

Quality push speaker terminal // Available in glossy black and white

WATCH THIS VIDEO AT denon.eu/ceol

Network Music Systems // CEOL Piccolo 43

CEOL Piccolo

NETWORK MUSIC SYSTEM

We may have called it Piccolo but this CEOL is as capable as its slightly bigger sibling. It has the same technical features, network skills, high quality Denon sound and award-winning design but arrives without a CD-drive, analogue radio and with a little less power output. Denon’s acclaimed digital amplifi er design delivers a nonetheless muscular 40 Watts per channel to the two-way hi-fi delity speakers. Enough to create a pure, room fi lling sound. So, don’t call the piccolo small!

Award-winning Denon system audio design with 2 x 40 W steady power output // DLNA1.5 network audio streaming // WiFi (b/g/n) built-in with WiFi

Sharing for iOS device and WPS for easy setup // Spotify Connect, Internet Radio and AirPlay // Gapless playback up to 192/24 (WAV, FLAC, AIFF,

ALAC) // Bluetooth

®

and NFC for direct wireless streaming // Full Digital Processing for best audio performance from any source // Front USB input for iPhone

®

/ iPod

®

and USB memory // Digital optical input for best sound from a TV or another digital source // High quality acrylic top lid fi nish for an elegance appearance // Denon Hi-Fi Remote App for convenient control via smartphone or tablet // Available in glossy black and white // SC-N4 SPEAKER

SYSTEM // Newly designed and voiced 2-way speakers // Quality push speaker terminal // Available in glossy black and white

WATCH THIS VIDEO AT denon.eu/ceol-piccolo

44

Network Music Systems // CEOL Carino 45

CEOL Carino

COMPUTER AND BLUETOOTH

®

AUDIO SYSTEM

Whether you place it horizontally or vertically, the CEOL Carino cannot but show off its winning design. This charming ultra-compact Bluetooth

®

Audio System will dramatically improve audio quality so you can better enjoy music, movies, video and gaming on your computer. It features a USB-B connection as well as Bluetooth

®

aptX

Low Latency and NFC and to keep your desk or shelf clutter-free, cable management is included. Recently developed by our digital engineers, the Carino features DSP EQ processing to perfect the sound.

Cute, compact Computer and Bluetooth ® Audio System // Rear USB-B input for direct connection to PC – no driver installation required // Bluetooth ® aptX Low Latency and NFC for wireless connectivity with PC or smart device // Full Digital Processing Amplifi er for steady output power // Tone control by DSP EQ processing (Wide Sound, Auto Volume Adjust) // Subwoofer pre-out and headphone output // Touch sensitive buttons for easy control //

Horizontal and vertical placement – display rotates automatically // Available in black and white // SC-N2 SPEAKER SYSTEM // Full range speaker + passive radiator for more bass // Dual angle positioning speaker stands // Speaker cable pre-installed for easy and quick setup // Cable management to keep desk clean // Available in black and white

WATCH THIS VIDEO AT denon.eu/ceol-carino

NOTHING ELSE

MATTERS.

Headphones

47

Sometimes to be yourself you just need to get away from the world for a while.

Listen to your music with a pair of Denon headphones and you‘ll be yourself in no time.

48 Headphones // Music Maniac

AH-MM400

OVER-EAR HEADPHONES

Developed to look as stunning as they sound, the earcup housings on Denon’s AH-MM400 are hand-carved from natural American Walnut. Inside these well-shaped cans are 40 mm “free-edge” drivers with advanced carbon/ paper composite blend diaphragms and neodymium magnets – professionally tuned to a fl at EQ for your listening pleasure. With its comfortable circumaural design, the AH-MM400 provides a high degree of passive acoustic isolation, letting you savour your favourite tracks without the interference of distracting background noise. For the complete listening experience a carrying case, Apple remote cable and cables for Android or other mobile devices are included.

Real Wood Housing eliminates resonance of bass-enhanced music // Precision Aluminum construction – Tailored Headband design with a cushioned lining //

Apple remote & integrated microphone (for control of Apple devices*) // Denon Audio Smartphone Application, available for iPhone

®

, iPad

®

or Android phones, Denon’s integrated application suite designed for the Audiophile. App Includes the following functionality: Music Player with ability to create custom playlists / Denon’s Music Community – discover new artists, purchase concert tickets / TuneIn

®

internet radio / EQ to fi ne tune music stored on your smartphone to your taste. // * Some functions may vary on your device (Android™, iPod ® , iPhone ® , iPad ® and others) due to their functional capability.

Headphones // Music Maniac 49

AH-MM300

ON-EAR HEADPHONES

Featuring elegant styling and the latest audio technologies, Denon’s AH-MM300 headphones are professionally tuned to deliver the utmost musical fi delity. With ellipsoid ear cups constructed of fi berglass reinforced composite material they provide both lightweight and high rigidity for resonance-free audio quality. Further accessories include a carrying case, Apple Remote cable and a cable for Android or other mobile devices.

Ceramic fi nished ellipsoid ear cups for smooth acoustic tones // Precision Aluminum construction with fold fl at mechanism // Apple remote & integrated microphone (for control of Apple devices*) // Denon Audio Smartphone Application, available for iPhone ® , iPad ® or Android phones, Denon’s integrated application suite designed for the Audiophile. App Includes the following functionality: Music Player with ability to create custom playlists / Denon’s Music

Community – discover new artists, purchase concert tickets / TuneIn ® internet radio / EQ to fi ne tune music stored on your smartphone to your taste //

* Some functions may vary on your device (Android

, iPod

®

, iPhone

®

, iPad

®

and others) due to their functional capability.

50 Headphones // Music Maniac

AH-MM200

ON-EAR HEADPHONES

Aimed at the serious music listener, Denon’s new AH-MM200 headphones are packed with advanced technologies, and feature proprietary drivers and housings. These supra-oral (on-ear) pieces deliver a smooth, natural and faithful tonal balance that accurately reproduces the sound of the original performance. With a lightweight and compact design, the AH-MM200s are incredibly portable and come with a carrying case, Apple remote cable and a cable for connection to Android and other mobile devices.

Ceramic fi nished ellipsoid ear cups for smooth acoustic tones // Precision Aluminum construction with folding mechanism // Apple remote & integrated microphone (for control of Apple devices*) // Denon Audio Smartphone Application, available for iPhone

®

, iPad

®

or Android phones, Denon’s integrated application suite designed for the Audiophile. App Includes the following functionality: Music Player with ability to create custom playlists / Denon’s Music

Community – discover new artists, purchase concert tickets / TuneIn

®

internet radio / EQ to fi ne tune music stored on your smartphone to your taste //

* Some functions may vary on your device (Android

, iPod

®

, iPhone

®

, iPad

®

and others) due to their functional capability.

Headphones // Critical Listening 51

AH-C120MA

IN-EAR HEADPHONES

So small and yet professionally tuned, Denon’s AH-C120MA in-ear headphones feature 11.5 mm drivers set in premium hybrid-material housing. Boasting an oxygen-free, non-tangle cable, engineered for sound purity, it sports an in-line 1-button remote and microphone for easy control – so you can listen to music and make and receive a call via your smartphone. Also included is a carrying case, silicone ear tips (S, M, L) and Comply

TX-400M foam ear tips.

Hybrid Metal Housing eliminates resonance of bass-enhanced music // Custom Ear Tips for a perfect fi t in Silicon (S, M, L) and Comply ™ Foam included //

1-button remote & integrated microphone (for control of select Android devices and other smartphones*) // Denon Audio Smartphone Application, available for iPhone ® , iPad ® or Android phones, Denon’s integrated application suite designed for the Audiophile. App Includes the following functionality:

Music Player with ability to create custom playlists / Denon’s Music Community – discover new artists, purchase concert tickets / TuneIn

®

internet radio /

EQ to fi ne tune music stored on your smartphone to your taste // * Some functions may vary on your device (Android ™ , iPod ® , iPhone ® , iPad ® and others) due to their functional capability.

AH-C50MA

IN-EAR HEADPHONES

Denon’s AH-C50MA in-ear headphones deliver a studio quality sound experience. With 9 mm drivers, these headphones also feature an in-line one-button remote and microphone for easy smartphone control, as well as clear call conversations and voice recognition commands. Also featured is a carrying case, silicone ear tips (XS, S, M, L) and Comply™ TX-400M foam ear tips.

Custom Ear Tips for a perfect fi t in Silicon (XS, S, M, L) included // 1-button remote & integrated microphone (for control of select Android

devices and other smartphones*) // Denon Audio Smartphone Application, available for iPhone

®

, iPad

®

or Android phones, Denon’s integrated application suite designed for the Audiophile. App Includes the following functionality: Music Player with ability to create custom playlists / Denon’s Music Community – discover new artists, purchase concert tickets / TuneIn

®

internet radio / EQ to fi ne tune music stored on your smartphone to your taste // * Some functions may vary on your device (Android

, iPod

®

, iPhone

®

, iPad

®

and others) due to their functional capability.

52 Headphones // Globe Cruiser

AH-GC20

OVER-EAR HEADPHONES WITH BLUETOOTH

®

No tangled cords, no outside noise. Denon’s Globe Cruiser

AH-GC20 wireless headphones let you listen to your favourite music without any disturbances. Featuring active noise cancellation, this perfect travelling companion reduces ambient noise by 99 %. It also comes equipped with the latest aptX

wireless technology so you can stream music in CD quality. The Bluetooth

®

4.0 Dual Mode makes it possible to connect two devices simultaneously while a two-axis folding design allows for easy stowaway.

40 mm drivers professionally optimized for 99 % noise cancelling ambient noise // Wireless connectivity with CD quality music thanks to Bluetooth ® aptX //

Metal “Spur” hanger design with fold and rotate mechanism // Memory foam ear pads // Integrated controls and microphones using cVc (Clear Voise

Capture) over Bluetooth ® // Multi Point Bluetooth ® for simultaneous connection to 2 compatible devices // Cable and Airline Adaptor Included for in-fl ight use // Carrying Case // Micro USB Charging Cable // Audio Cable

Headphones // Globe Cruiser 53

AH-W200

IN-EAR WIRELESS HEADPHONES

While in training, the right song can be more motivating than a personal trainer. If your fi tness routine is the one time of the day that you get the chance to think, to refl ect, and to focus on yourself, then Denon’s wireless and sweatproof Exercise Freak headphones are the perfect companion. Integrated controls allow you to adjust the volume, play/pause your music and even choose to answer that phone call… or ignore it. The AH-W200 is accompanied with a refl ector on the neckband, anti-microbial silicon ear tips (XS, S, M, L), a USB Micro cable (for charging the battery) and blue mesh carrying case.

Wireless with CD sound quality (Bluetooth

®

aptX) // Integrated controls and microphone for superior mobility, ease-of-use and convenience // Comply

TX-400M foam ear tips and Silicon ear tips (XS, S, M, L) provide advanced noise isolation and superior fi t // Flexible neckband and articulating In-Ear design for superior fi t // Rechargeable battery provides up to fi ve hours listening enjoyment // Integrated amplifi er // Cable included for listening to music in wired mode // Accessories: Leather travel case with karabiner, cable and airline adapter included for in fl ight use

54

Headphones // Exercise Freak 55

AH-W150

WIRELESS FITNESS IN-EAR HEADPHONES

Studies have proven that music enhances athletic performance by as much as 20 %. We know for a 100 % that with Denon’s Exercise Freak

®

in-ear headphones you can listen to music and answer calls without the inconvenience of cables getting in the way of your workout. Furthermore they are super-lightweight, sweat proof, wireless and fi t securely in-ear. Also included: Mesh Carrying Case with Karabiner, a micro USB cable (for charging battery) and diff erent-sized Anti-Microbial silicon ear tips (XS, S, M, L).

Sounds Like You

®

// 11.5 mm drivers professionally tuned to provide a fl at EQ experience // Integrated amplifi er professionally tuned to heart-pounding bass to energize your workout // Bluetooth ® 3.0 Wireless Connectivity with Enhanced Signal Performance // Rechargeable Battery for long workouts

(up to 7 hours) // Fits Like You // Flexible neckband, articulating in-ear design provides superior fi t // Sweat proof earpiece with built-in Denon patentpending air cushion for extreme comfort and ventilation // Anti-microbial Ear Tips reduce build up of bacteria and provide perfect fi t (XS, S, M, L) included //

Moves Like You // Integrated controls & microphone for on-the-go use // Refl ective back band for safe evening workouts // Accessories Included: Mesh

Carrying Case with Karabiner / Micro USB cable (for charging battery) / Anti-Microbial Silicon ear tips (XS, S, M, L)

WATCH THIS VIDEO AT www.denon.eu/ah-w150

TM

HEOS

TEST

WINNER

ANYWHERE

SOUNDS

AMAZING.

It‘s wireless, it‘s limitless, it‘s peerless. The multiroom system HEOS by Denon opens all doors to let in sound. Whether it‘s from your phone, PC, or stereo the sound just travels with you from room to room.

HEOS is not the fi rst multi-room system but it‘s the fi rst by Denon. That means it‘s the fi rst built from more than 100 years experience in sound. HEOS is the product of an obsession with audio and the love of music.

HEOS

PLAY ANY SONG,

IN ANY ROOM.

HEOS is as big as you need it and as great as you expect it to be.

There’s a HEOS for every space, even for the outside.

You want to make your beloved Hi-Fi components wireless? HEOS will oblige! Control is all at your fi ngertips: Just tap the HEOS app and start rockin’.

Play diff erent music in diff erent rooms or the same music in all rooms.

Have fun losing yourself in music. Again and again.

HEOS // HEOS 7 59

HEOS 7

WIRELESS MULTI-ROOM SPEAKER

Bigger is better when it’s time to party. This mighty wireless speaker system is a serious performer for larger rooms.

If you demand the best, biggest and loudest sounds then the HEOS 7 is ready to rock. It plays cloud music, music stored on your phone or tablet, plus USB sources - all in immaculate Denon sound, of course. Sounds like a party already, doesn’t it? Sculpted to deliver a prodigious performance, the HEOS 7 is beautifully fi nished with quality materials, including a brushed metallic apex. It also features a crafted blend of fi ve custom drivers, two passive radiators, fi ve Class D amplifi ers, all of which are controlled with state-of-the-art digital signal processing.

Refi ned cabinet design with genuine brushed metal accents // Amazing volume output capability fi lls even larger spaces with true high fi delity sound //

Stream from your favourite music service such FREE HEOS app // Stream from your favorite music service such as Spotify, Tidal, Deezer, TuneIn ® or

Napster // Stream music stored locally on your iOS or Android smartphone or tablet // A USB jack and auxiliary 3.5 mm analog input jack allow playback from these sources to one or more HEOS players with perfect synchronization // Built-in 3.5 mm headphone jack features auto speaker mute when headphones are connected // Stream music from devices on your home network such as NAS drives and PC and Mac computers // Built-in dual band wireless “N” connects to standard home wireless networks // Ethernet jack for wired network connectivity // Bluetooth ® USB adapter included for wireless audio streaming

WATCH THIS VIDEO AT denon.eu/heos7

60 HEOS // HEOS 5

HEOS 5

WIRELESS MULTI-ROOM SPEAKER

Elegance meets performance. The HEOS 5 is a dazzling midsize speaker delivering a big time performance. It fl oods medium to large rooms with sounds from any source with a processor and an operating system. It also features a well-crafted blend of four custom drivers, one radiator and four Class-D amplifi ers, all of which are controlled with high quality digital signal processing, born in the studio. Engineered by sound experts and made from cool components.

You will hear this in every beat.

Sleek and elegant form factor produces incredibly detailed wide range high fi delity sound // Amazing output from a modestly sized unit // Handle allows easy portability wherever you need great sound // FREE HEOS app // Stream from your favorite music service such as Spotify, Tidal, Deezer, TuneIn

®

or

Napster // Stream music stored locally on your iOS or Android smartphone or tablet // A USB jack and auxiliary 3.5 mm analog input jack allow playback from these sources to one or more HEOS players with perfect synchronization // Stream music from devices on your home network such as NAS drives and PC and Mac computers // Built-in dual band wireless “N” connects to standard home wireless networks // Ethernet jack for wired network connectivity // Handle allows easy portability wherever you need great sound // Bluetooth

®

USB adapter included for wireless audio streaming

WATCH THIS VIDEO AT denon.eu/heos5

HEOS // HEOS 3 61

HEOS 3

WIRELESS MULTI-ROOM SPEAKER

Portable and the perfect place to start. The HEOS 3 was born to perform in small to medium rooms. Its dual custom full-range drivers powered by a two-channel Class D amplifi er pump out rich and clean sound. The HEOS 3 also allows you to place it either horizontally or vertically – while you can even add another speaker to build a stereo pair.

Whatever you decide to do, the HEOS 3 will always look stylish.

Can be positioned horizontally or vertically // FREE HEOS app // Stream from your favorite music service such as Spotify, Tidal, Deezer, TuneIn

®

or

Napster // Stream music stored locally on your iOS or Android smartphone or tablet // A USB jack and auxiliary 3.5 mm analog input jack allow playback from these sources to one or more HEOS players with perfect synchronization // Stream music from devices on your home network such as NAS drives and PC and Mac computers // Built-in dual band wireless “N” connects to standard home wireless networks // Ethernet jack for wired network connectivity // Bluetooth

®

USB adapter included for wireless audio streaming

WATCH THIS VIDEO AT denon.eu/heos3

62

HEOS // HEOS 1 + GoPack 63

HEOS 1

WIRELESS MULTI-ROOM SPEAKER

No wires. No limits. Like to sing in the shower? Here’s your bathroom-rocking sidekick! The HEOS 1 is built for the smallest rooms - and for the biggest space there is: outside. Its compact enclosure is humidity resistant. With the optional GoPack you can listen to your music wherever you want via Bluetooth

®

. With the dual channel Class D digital audio amplifi er your favourite tunes are in capable hands. Synchronizing two HEOS 1 for stereo? Go ahead.

Listen to your favourite music in any room in the home // Sound is optimised via precision acoustical processing algorithms that originated in top recording studios // Use 2 HEOS 1 speakers for stereo, perfectly synchronised // USB jack and analog line input jack lets you connect your device directly //

RJ-45 LAN port for direct connection to the network // Volume up, volume down, power on/off button // AC power adapter included // Optional Go

Pack features a rechargeable lithium-ion battery that delivers up to 6 hours of playback time, a USB Bluetooth ® wireless streaming adapter, a silicone

Splashguard to seal the jacks and ports to protect from splashing water

WATCH THIS VIDEO AT denon.eu/heos1

HEOS 1 Go Pack

WIRELESS ACCESSORY PACK

Take your HEOS 1 anywhere. Twist on the rechargeable battery, switch on Bluetooth

®

and you can listen to your tunes anywhere.

Add the splashguard and you’re free to enjoy the party.

Lithium-ion rechargeable battery pack attaches to HEOS 1 base // Easy twiston/twist-off attachment // Up to 6 hours of playback time on a single charge //

Bluetooth

®

USB adapter included for wireless audio streaming // Unique custom splashguard means never having to worry about accidental splashes from the swimming pool // Listen to your music and charge your smartphone at the same time // Available in black and white

HEOS // HEOS HomeCinema 65

HEOS HomeCinema

WIRELESS SOUNDBAR & SUB

Unleash dramatic movie sound. As TVs get thinner, so does their sound quality. HEOS HomeCinema delivers true widescreen high fidelity audio for maximum enjoyment of TV shows and movies. Not to mention your favourite music tracks as well. How does bi-amplifi ed soundbar with 4 channels of class D digital amplifi cation and high power class D digital amplification for the subwoofer sound to you? Both, soundbar and subwoofer connect wirelessly with each other yet they are inseparable. They always come as a pair.

Dual band high speed “N” Wi-Fi connects to standard wireless home networks // Bi-amplifi ed soundbar with 4 channels of Class D digital amplifi cation.

Subwoofer features dedicated high power Class D digital amplifi cation // Dual rounded rectangular mid-woofer drivers composite Kevlar cones and double magnet motor system // Dual 20 mm treated soft dome tweeters with neodymium magnets deliver extended treble response with wide dispersion //

Advanced DSP processing features a powerful 400 MHz 32-bit fl oating point DSP engine – the same processor found in premium Denon A/V receivers //

Featuring Dolby Digital, Dolby Digital Plus and DTS decoding, HEOS HomeCinema decodes movie and music surround soundtracks into their original discrete channels and applies our advanced proprietary DSP to deliver an immersive Virtual Surround sound experience // Exclusive Virtual Surround processing decodes discrete multi-track surround sound channels and uses advanced psycho-acoustic DSP processing algorithms to deliver an immersive surround sound experience // Dynamic Bass Boost provides advanced frequency and dynamic range tailoring to deliver taut deep bass while preventing distortion due to excessive overload // HDMI input and output features Audio Return Channel for single cable connection from the soundbar to your TV – no need for another audio connection // Coaxial and optical digital inputs and Aux in for wired analog stereo input // Wireless subwoofer can be placed anywhere in the room and features time-aligned DSP processing for precision soundbar/subwoofer audio synchronization // Movie and Music modes let you choose the best audio performance for blockbuster movies and your favorite music tracks // Night Mode lets you listen at reduced volume levels, letting you enjoy the full range audio experience without disturbing other family members // Dialog enhancer improves dialog intelligibility – ideal for movies and TV shows with complex audio soundtracks when it’s often hard to discern what performers are saying // Soundbar features infrared (IR) reception and re-transmission that allows TV remote commands to pass through to the TV when the soundbar is mounted in front of the TV // IR learning function lets you control the Soundbar with your TV remote

66 HEOS // HEOS AMP

HEOS Amp

WIRELESS AMPLIFIER

Let your speakers speak HEOS. Take your satellite system, bookshelf speakers and fl oorstanding speakers and wirelessly fill your HEOS zones with the super sounds you adore, by simply adding the HEOS amp. Featuring advanced Class D digital amplification, the HEOS Amp delivers 100 Watts maximum power per channel. With low distortion and high current capability that provide reliable operation with lower impedance speakers, including

4 ohm models. Even connect a powered subwoofer to the HEOS Amp for additional bass.

100 W per channel Class D amplifi er // Perfect for any speakers; including outdoor, in-ceiling, fl oor standing or bookshelf models // FREE HEOS app //

Stream from your favorite music service such as Spotify, Tidal, Deezer, TuneIn

®

or Napster // Stream music stored locally on your iOS or Android smartphone or tablet // A USB jack, optical digital input and auxiliary 3.5 mm analog input jack allow playback from these sources to one or more HEOS players with perfect synchronization // Stream music from devices on your home network such as NAS drives and PC and Mac computers // Built-in dual band wireless “N” connects to standard home wireless networks // Ethernet jack for wired network connectivity

WATCH THIS VIDEO AT denon.eu/heosamp

HEOS // HEOS LINK 67

HEOS Link

WIRELESS PRE-AMPLIFIER

Turn your stereo into a HEOS zone. Add multi-room audio to an existing music or home theatre system and become the master of sound. Just connect HEOS Link via one cable and you’re ready to go wireless. Control all functions and enjoy extraordinary sound quality from almost any source. Complete control of your multi-room system comes via an app on your mobile phone. So you don’t need to run from room to room adjusting the sound. Although, should you like to operate manually, there are volume and mute controls discreetly placed on the side panel.

High quality D/A conversion // Perfect for any home theater receiver, integrated amplifi er, amplifi er or powered speakers // Analogue, Digital Coax and Fiber Optic outputs // 12 V trigger output for power control of external devices // IR Output for power, volume and source selection of Denon home theater receivers, integrated amplifi ers and music systems // FREE HEOS app // Stream from your favorite music service such as Spotify,Tidal,

Deezer, TuneIn

®

or Napster // Stream music stored locally on your iOS or Android smartphone or tablet // A USB jack, optical digital input and auxiliary

3.5 mm analog input jack allow playback from these sources to one or more HEOS players with perfect synchronization // Stream music from devices on your home network such as NAS drives and PC and Mac computers // Built-in dual band wireless “N” connects to standard home wireless networks //

Ethernet jack for wired network connectivity

WATCH THIS VIDEO AT denon.eu/heoslink

68 Specifications

INTEGRATED NETWORK & SURROUND RECEIvERS

1/2

FEATURES

AVR-X7200WA AVR-X6200W

MULTICHANNEL SURROUND

DTS HD Master / DTS:X

DTS Neo:X / DTS Neural:X

Dolby TrueHD / Dolby Atmos

Dolby ProLogic Il / Dolby Surround

Auro 3D

Audyssey DSX

Multichannel Stereo max. number of processing (preamp) channels

SOUND ENHANCEMENTS

Mono Block Power Amp Construction

Discrete Power Amplifier

D.D.S.C. HD Digital

Pure Direct

High Grade Audio Components

Gold plated RCA terminals

Clock Jitter Reducer

Alpha Processing

Denon Link HD

Audyssey

Audyssey Dynamic EQ / Dynamic Volume

Audyssey LFC

Compressed Audio Restorer

NETWORK

DLNA Certified

Lossy formats: MP3 / WMA / AAC

Lossless formats: FLAC / ALAC / WAV

DSD Audio Streaming

FLAC HD 192/24

WAV 192/24

ALAC 96/24

Gapless playback

Photo streaming (JPEG)

AirPlay audio streaming

Windows PlayTo / Windows8 certified

Internet Radio (vTuner)

Spotify*

Compatible with Remote APP for Smart Phones

Ethernet Ports

WiFi

Bluetooth

®

HDMI

HDMI inputs: back / front

HDCP2.2 support

HDMI outputs: main / zone

Video conversion Analogue -> HDMI

Analogue to HDMI scaling

HDMI to HDMI scaling

GUI Overlay on HDMI

3D signal pass-through

4K signal pass-through / scaling / GUI overlay

HDMI pass-though in standby mode

Picture adjust / Noise reduction

CEC

DSD Audio capability

Audio Return Channel

Auto LipSync

MULTIROOM / CI

Multiroom zones

Zone audio source: HDMI / opt, coax / Network, USB / analog

Zone audio output: speaker / preout

Zone HDMI output from HDMI source

IP control / RS232 control / Web control / App control

Remote In / Out

DC Trigger output

OTHERS

Auto speaker setup by microphone

FL Display

Graphic User Interface - GUI

ISF Certification

GUI languages

Setup Assistent

Quick Select plus / Quick Select

Variable cross over

Optimized Bass Redirection

Bass Sync

ECO Mode

Sleep Timer

• / (upgrade)

- / • (11 ch) (update)

• / •

- / •

• (upgrade)

11.2

• (L/R separated)

• (32-bit)

AL32 Processing Multichannel

MultEQ XT32 (PRO)

• / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

• / •

7 / 1

2 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

3

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

2

• / -

9

Audyssey MultEQ XT32 + PRO

2 lines

Advanced

• / (update)

- / • (11 ch) (update)

• / •

- / •

• (upgrade)

11.2

AL24 Processing Plus

MultEQ XT32 (PRO)

• / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

7 / 1

2 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

• / •

3

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

2

Audyssey MultEQ XT32 + PRO

2 lines

Advanced

9

• / -

-

* Not available in all regions.

AVR-X3200W

-

-

• / (update)

- / • (7 ch) (update)

• / •

- / •

7.1

-

-

-

-

-

-

-

MultEQ XT

• / •

• / •

7 / 1

1 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

2

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

1

-

• / -

9

Audyssey MultEQ XT

1 line

Advanced

AVR-X4200W

• / (update)

- / • (9 ch) (update)

• / •

- / •

• (upgrade)

9.2

-

-

AL24 Processing Plus

MultEQ XT32 (PRO)

• / •

• / •

7 / 1

2 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / ioO

3

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

2

-

• / -

9

Audyssey MultEQ XT32 + PRO

2 lines

Advanced

FEATURES

AVR-X2200W AVR-X1200W

MULTICHANNEL SURROUND

DTS HD Master / DTS:X

DTS Neo:X / DTS Neural:X

Dolby TrueHD / Dolby Atmos

Dolby ProLogic Il / Dolby Surround

Auro 3D

Audyssey DSX

Multichannel Stereo max. number of processing (preamp) channels

SOUND ENHANCEMENTS

Mono Block Power Amp Construction

Discrete Power Amplifier

D.D.S.C. HD Digital

Pure Direct

High Grade Audio Components

Gold plated RCA terminals

Clock Jitter Reducer

Alpha Processing

Denon Link HD

Audyssey

Audyssey Dynamic EQ / Dynamic Volume

Audyssey LFC

Compressed Audio Restorer

NETWORK

DLNA Certified

Lossy formats: MP3 / WMA / AAC

Lossless formats: FLAC / ALAC / WAV

DSD Audio Streaming

FLAC HD 192/24

WAV 192/24

ALAC 96/24

Gapless playback

Photo streaming (JPEG)

AirPlay audio streaming

Windows PlayTo / Windows8 certified

Internet Radio (vTuner)

Spotify*

Compatible with Remote APP for Smart Phones

Ethernet Ports

WiFi

Bluetooth

®

HDMI

HDMI inputs: back / front

HDCP2.2 support

HDMI outputs: main / zone

Video conversion Analog -> HDMI

Analogue to HDMI scaling

HDMI to HDMI scaling

GUI Overlay on HDMI

3D signal pass-through

4K signal pass-through / scaling / GUI overlay

HDMI pass-though in standby mode

Picture adjust / Noise reduction

CEC

DSD Audio capability

Audio Return Channel

Auto LipSync

MULTIROOM / CI

Multiroom zones

Zone audio source: HDMI / opt, coax / Network, USB / analog

Zone audio output: speaker / preout

Zone HDMI output from HDMI source

IP control / RS232 control / Web control / App control

Remote In / Out

DC Trigger output

OTHERS

Auto speaker setup by microphone

FL Display

Graphic User Interface - GUI

ISF Certification

GUI languages

Setup Assistent

Quick Select plus / Quick Select

Variable cross over

Optimized Bass Redirection

Bass Sync

ECO Mode

Sleep Timer

-

-

• / (update)

- / • (7 ch) (update)

• / •

- / •

7.1

-

-

-

-

-

-

-

MultEQ XT

• / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

-

• / •

7 / 1

2 / -

• up to 4K 30/25/24 up to 4K 30/25/24

• / • / •

2

- / - / • / •

• / •

-

• / - / • / •

- / -

-

-

• / -

9

Audyssey MultEQ XT

1 line

Advanced

• / (update)

- / • (7 ch) (update)

• / •

- / •

-

-

7.1

-

-

-

-

-

-

-

-

MultEQ XT

• / •

-

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

5 / 1

1 / -

-

-

-

• / - / -

- / -

-

2

- / - / • / •

• / -

-

• / - / • / •

- / -

-

Audyssey MultEQ XT

1 line

Hybrid GUI

-

9

• / -

-

AVR-X520BT

-

-

-

- / -

-

-

-

5 / -

1 / -

-

• / - / -

-

-

-

-

-

- / - / -

- / - / -

-

-

-

-

-

-

-

Android / iOS

-

-

-

- / -

-

-

-

-

-

-

-

-

-

-

• / -

- / -

• / -

• / -

5.1

-

-

- / •

3

• yes

1 line

GUI

-

-

- / - / - / -

- / -

-

- / - / - / -

- / -

-

FEATURES

AVR-X7200WA AVR-X6200W

MULTICHANNEL SURROUND

DTS HD Master / DTS:X

DTS Neo:X / DTS Neural:X

Dolby TrueHD / Dolby Atmos

Dolby ProLogic Il / Dolby Surround

Auro 3D

Audyssey DSX

Multichannel Stereo max. number of processing (preamp) channels

SOUND ENHANCEMENTS

Mono Block Power Amp Construction

Discrete Power Amplifier

D.D.S.C. HD Digital

Pure Direct

High Grade Audio Components

Gold plated RCA terminals

Clock Jitter Reducer

Alpha Processing

Denon Link HD

Audyssey

Audyssey Dynamic EQ / Dynamic Volume

Audyssey LFC

Compressed Audio Restorer

NETWORK

DLNA Certified

Lossy formats: MP3 / WMA / AAC

Lossless formats: FLAC / ALAC / WAV

DSD Audio Streaming

FLAC HD 192/24

WAV 192/24

ALAC 96/24

Gapless playback

Photo streaming (JPEG)

AirPlay audio streaming

Windows PlayTo / Windows8 certified

Internet Radio (vTuner)

Spotify*

Compatible with Remote APP for Smart Phones

Ethernet Ports

WiFi

Bluetooth

®

HDMI

HDMI inputs: back / front

HDCP2.2 support

HDMI outputs: main / zone

Video conversion Analogue -> HDMI

Analogue to HDMI scaling

HDMI to HDMI scaling

GUI Overlay on HDMI

3D signal pass-through

4K signal pass-through / scaling / GUI overlay

HDMI pass-though in standby mode

Picture adjust / Noise reduction

CEC

DSD Audio capability

Audio Return Channel

Auto LipSync

MULTIROOM / CI

Multiroom zones

Zone audio source: HDMI / opt, coax / Network, USB / analog

Zone audio output: speaker / preout

Zone HDMI output from HDMI source

IP control / RS232 control / Web control / App control

Remote In / Out

DC Trigger output

OTHERS

Auto speaker setup by microphone

FL Display

Graphic User Interface - GUI

ISF Certification

GUI languages

Setup Assistent

Quick Select plus / Quick Select

Variable cross over

Optimized Bass Redirection

Bass Sync

ECO Mode

Sleep Timer

• / (upgrade)

- / • (11 ch) (update)

• / •

- / •

• (upgrade)

11.2

• (L/R separated)

• (32-bit)

AL32 Processing Multichannel

MultEQ XT32 (PRO)

• / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

• / •

7 / 1

2 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

3

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

2

• / -

9

Audyssey MultEQ XT32 + PRO

2 lines

Advanced

• / (update)

- / • (11 ch) (update)

• / •

- / •

• (upgrade)

11.2

AL24 Processing Plus

MultEQ XT32 (PRO)

• / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

7 / 1

2 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

• / •

3

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

2

Audyssey MultEQ XT32 + PRO

2 lines

Advanced

9

• / -

-

AVR-X3200W

-

-

• / (update)

- / • (7 ch) (update)

• / •

- / •

7.1

-

-

-

-

-

-

-

MultEQ XT

• / •

• / •

7 / 1

1 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

2

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

1

-

• / -

9

Audyssey MultEQ XT

1 line

Advanced

AVR-X4200W

• / (update)

- / • (9 ch) (update)

• / •

- / •

• (upgrade)

9.2

-

-

AL24 Processing Plus

MultEQ XT32 (PRO)

• / •

• / •

7 / 1

2 / 1

• up to 4K 60/50 up to 4K 60/50

• / • / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / ioO

3

• (2 ch) / • (2 ch) / • / •

• / •

• / • / • / •

• / •

2

-

• / -

9

Audyssey MultEQ XT32 + PRO

2 lines

Advanced

FEATURES

AVR-X2200W AVR-X1200W

MULTICHANNEL SURROUND

DTS HD Master / DTS:X

DTS Neo:X / DTS Neural:X

Dolby TrueHD / Dolby Atmos

Dolby ProLogic Il / Dolby Surround

Auro 3D

Audyssey DSX

Multichannel Stereo max. number of processing (preamp) channels

SOUND ENHANCEMENTS

Mono Block Power Amp Construction

Discrete Power Amplifier

D.D.S.C. HD Digital

Pure Direct

High Grade Audio Components

Gold plated RCA terminals

Clock Jitter Reducer

Alpha Processing

Denon Link HD

Audyssey

Audyssey Dynamic EQ / Dynamic Volume

Audyssey LFC

Compressed Audio Restorer

NETWORK

DLNA Certified

Lossy formats: MP3 / WMA / AAC

Lossless formats: FLAC / ALAC / WAV

DSD Audio Streaming

FLAC HD 192/24

WAV 192/24

ALAC 96/24

Gapless playback

Photo streaming (JPEG)

AirPlay audio streaming

Windows PlayTo / Windows8 certified

Internet Radio (vTuner)

Spotify*

Compatible with Remote APP for Smart Phones

Ethernet Ports

WiFi

Bluetooth

®

HDMI

HDMI inputs: back / front

HDCP2.2 support

HDMI outputs: main / zone

Video conversion Analog -> HDMI

Analogue to HDMI scaling

HDMI to HDMI scaling

GUI Overlay on HDMI

3D signal pass-through

4K signal pass-through / scaling / GUI overlay

HDMI pass-though in standby mode

Picture adjust / Noise reduction

CEC

DSD Audio capability

Audio Return Channel

Auto LipSync

MULTIROOM / CI

Multiroom zones

Zone audio source: HDMI / opt, coax / Network, USB / analog

Zone audio output: speaker / preout

Zone HDMI output from HDMI source

IP control / RS232 control / Web control / App control

Remote In / Out

DC Trigger output

OTHERS

Auto speaker setup by microphone

FL Display

Graphic User Interface - GUI

ISF Certification

GUI languages

Setup Assistent

Quick Select plus / Quick Select

Variable cross over

Optimized Bass Redirection

Bass Sync

ECO Mode

Sleep Timer

-

-

• / (update)

- / • (7 ch) (update)

• / •

- / •

7.1

-

-

-

-

-

-

-

MultEQ XT

• / •

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

-

• / •

7 / 1

2 / -

• up to 4K 30/25/24 up to 4K 30/25/24

• / • / •

2

- / - / • / •

• / •

-

• / - / • / •

- / -

-

-

• / -

9

Audyssey MultEQ XT

1 line

Advanced

• / (update)

- / • (7 ch) (update)

• / •

- / •

-

-

7.1

-

-

-

-

-

-

-

-

MultEQ XT

• / •

-

• (v1.5)

• / • / •

• / • / •

• (FLAC, WAV, AIFF, ALAC, DSD)

• / •

• (connect)

Android / iOS

5 / 1

1 / -

-

-

-

• / - / -

- / -

-

2

- / - / • / •

• / -

-

• / - / • / •

- / -

-

Audyssey MultEQ XT

1 line

Hybrid GUI

-

9

• / -

-

AVR-X520BT

-

-

-

- / -

-

-

-

5 / -

1 / -

-

• / - / -

-

-

-

-

-

- / - / -

- / - / -

-

-

-

-

-

-

-

Android / iOS

-

-

-

- / -

-

-

-

-

-

-

-

-

-

-

• / -

- / -

• / -

• / -

5.1

-

-

- / •

3

• yes

1 line

GUI

-

-

- / - / - / -

- / -

-

- / - / - / -

- / -

-

Specifications 69

70 Specifications

INTEGRATED NETWORK & SURROUND RECEIvERS

2/2

FEATURES

AVR-X7200WA

INPUTS/OUTPUTS

VIDEO

Composite In / Out

Component In / Out

HDMI In / Out

Multi-Room Video Out: Video / HDMI

AUDIO

Analogue In / Out

Phono (MM) In

Digital in: optical / coaxial

Multi-Room Out: analog / digital

Multichannel Pre Out

Subwoofer Out

7.1 multichannel input

OTHER

Speaker Terminal: Gold plated screw / regular screw

Number of speaker terminals

Speaker A / B

Bi-amp drive

Multi-Room Speaker Terminal

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB

USB Audio / Made for iPod

®

/ Made for iPhone

®

FM Tuner with RDS

SPECIFICATIONS

number of poweramps

Power Output (8 ohm, 20 Hz - 20 kHz, 0.08 % 2 ch Drive)

Power Output (8 ohm, 20 Hz - 20 kHz, 0.05 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 0.7 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 1 % 1 ch Drive)

GENERAL

Available colors: Black / Premium Silver

Metal Front Panel

System Remote Control

Pre-programmed / Learnable / LCD Display

Power Consumption in W

Power consumption No-Sound (ECO on / off) in W

Standby Consumption in W

CEC Standby Consumption in W

Network Standby Consumption in W

Maximum Dimensions

Antenna: Horizontal: (W x D x H) in mm

(Antenna: Vertical: (W x D x H) in mm)

(w/o Antenna: (W x D x H) in mm)

Weight in kg

4+1 / 2

3 / 1

7+1 / 3

• / •

6+1 / -

2 / 2

2 / -

• (13.2) / -

2 (independent)

• / -

11 assignable assignable assignable

• / • / - / • / •

• / • / •

9

-

150 W

190 W

210 W

0.1

0.5

4.5

• / •

RC-1194

• / • / •

780 W

70 W / 125 W

434 x 437 x 195

(434 x 437 x 259)

(434 x 427 x 195)

17.1

AVR-X6200W

• / -

11 assignable assignable assignable

• / • / - / • / •

• / • / •

9

-

140 W

175 W

205 W

4+1 / 2

2 / 1

7+1 / 3

• / •

6+1 / -

2 / 2

2 / -

• (13.2) / -

2 (independent)

-

0.1

0.5

4.5

• / •

RC-1193

• / - / -

730 W

65 W / 110 W

434 x 393 x 167

(434 x 393 x 235)

(434 x 383 x 167)

14.1

AVR-4200W

- / •

11 assignable assignable assignable

• / • / - / • / •

• / • / •

7

-

125 W

165 W

200 W

3+1 / 2

2 / 1

7+1 / 3

• / •

5+1 / -

2 / 2

2 / -

• (13.2) / -

2 (independent)

-

0.1

0.5

2.7

• / •

RC-1193

• / - / -

670 W

55 W / 85 W

434 x 389 x 167

(434 x 389 x 236)

(434 x 379 x 167)

12.6

AVR-X3200W

- / •

7 assignable assignable assignable

- / - / - / • / •

• / • / •

7

105 W

-

135 W

180 W

3 / -

2 / -

7+1 / 2

- / •

2

-

5 / -

-

2 / 2

1 / -

• (7.2) / -

0.1

0.5

2.7

• / -

-

RC-1192

- / - / -

600 W

45 W / 80 W

434 x 388 x 167

(434 x 388 x 237)

11.3

AVR-X7200WA

AVR-X4200W

AVR-X6200W

AVR-X3200W

FEATURES

AVR-X2200W

INPUTS/OUTPUTS

VIDEO

Composite In / Out

Component In / Out

HDMI In / Out

Multi-Room Video Out: Video / HDMI

AUDIO

Analogue In / Out

Phono (MM) In

Digital in: optical / coaxial

Multi-Room Out: analog / digital

Multichannel Pre Out

Subwoofer Out

7.1 multichannel input

OTHER

Speaker Terminal: Gold plated screw / regular screw

Number of speaker terminals

Speaker A / B

Bi-amp drive

Multi-Room Speaker Terminal

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB

USB Audio / Made for iPod

®

/ Made for iPhone

®

FM Tuner with RDS

SPECIFICATIONS

number of poweramps

Power Output (8 ohm, 20 Hz - 20 kHz, 0.08 % 2 ch Drive)

Power Output (8 ohm, 20 Hz - 20 kHz, 0.05 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 0.7 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 1 % 1 ch Drive)

GENERAL

Available colors: Black / Premium Silver

Metal Front Panel

System Remote Control

Pre-programmed / Learnable / LCD Display

Power Consumption in W

Power consumption No-Sound (ECO on / off) in W

Standby Consumption in W

CEC Standby Consumption in W

Network Standby Consumption in W

Maximum Dimensions

Antenna: Horizontal: (W x D x H) in mm

(Antenna: Vertical: (W x D x H) in mm)

(w/o Antenna: (W x D x H) in mm)

Weight in kg

2 / -

1 / -

7+1 / 2

- / -

2

-

4 / -

-

2 / 0

1 / -

• (0.2) / -

- / •

7 assignable assignable assignable

- / - / - / • / •

• / • / •

7

95 W

-

125 W

150 W

• / -

-

RC-1192

- / - / -

500 W

35 W / 75 W

0.1

0.5

2.7

434 x 339 x 167

(434 x 339 x 235)

9.4

AVR-X1200W

- / •

7 assignable assignable assignable

- / - / - / • / •

• / • / •

7

80 W

-

120 W

145 W

2 / 1

- / -

5+1 / 1

- / -

2

-

2 / -

-

2 / 0

- / -

• (0.2) / -

• / -

-

RC-1189

- / - / -

430 W

30 W / 45 W

0.1

0.5

2.7

434 × 339 × 151

(434 x 339 x 215)

8.5

AVR-X520BT

2 / 1

- / -

5+0 / 1

- / -

2

-

2 / -

-

2 / 0

- / -

• (0.2) / -

-

-

-

- / -

5

- / - / - / - / •

• / • (for Bluetooth

®

) / • (for Bluetooth

®

)

5

70 W

-

90 W

130 W

• / -

-

RC-1196

- / - / -

330 W

-

0.3

-

-

434 × 319 × 151

7.5

FEATURES

AVR-X7200WA

INPUTS/OUTPUTS

VIDEO

Composite In / Out

Component In / Out

HDMI In / Out

Multi-Room Video Out: Video / HDMI

AUDIO

Analogue In / Out

Phono (MM) In

Digital in: optical / coaxial

Multi-Room Out: analog / digital

Multichannel Pre Out

Subwoofer Out

7.1 multichannel input

OTHER

Speaker Terminal: Gold plated screw / regular screw

Number of speaker terminals

Speaker A / B

Bi-amp drive

Multi-Room Speaker Terminal

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB

USB Audio / Made for iPod

®

/ Made for iPhone

®

FM Tuner with RDS

SPECIFICATIONS

number of poweramps

Power Output (8 ohm, 20 Hz - 20 kHz, 0.08 % 2 ch Drive)

Power Output (8 ohm, 20 Hz - 20 kHz, 0.05 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 0.7 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 1 % 1 ch Drive)

GENERAL

Available colors: Black / Premium Silver

Metal Front Panel

System Remote Control

Pre-programmed / Learnable / LCD Display

Power Consumption in W

Power consumption No-Sound (ECO on / off) in W

Standby Consumption in W

CEC Standby Consumption in W

Network Standby Consumption in W

Maximum Dimensions

Antenna: Horizontal: (W x D x H) in mm

(Antenna: Vertical: (W x D x H) in mm)

(w/o Antenna: (W x D x H) in mm)

Weight in kg

4+1 / 2

3 / 1

7+1 / 3

• / •

6+1 / -

2 / 2

2 / -

• (13.2) / -

2 (independent)

• / -

11 assignable assignable assignable

• / • / - / • / •

• / • / •

9

-

150 W

190 W

210 W

0.1

0.5

4.5

• / •

RC-1194

• / • / •

780 W

70 W / 125 W

434 x 437 x 195

(434 x 437 x 259)

(434 x 427 x 195)

17.1

AVR-X6200W

• / -

11 assignable assignable assignable

• / • / - / • / •

• / • / •

9

-

140 W

175 W

205 W

4+1 / 2

2 / 1

7+1 / 3

• / •

6+1 / -

2 / 2

2 / -

• (13.2) / -

2 (independent)

-

0.1

0.5

4.5

• / •

RC-1193

• / - / -

730 W

65 W / 110 W

434 x 393 x 167

(434 x 393 x 235)

(434 x 383 x 167)

14.1

AVR-4200W

- / •

11 assignable assignable assignable

• / • / - / • / •

• / • / •

7

-

125 W

165 W

200 W

3+1 / 2

2 / 1

7+1 / 3

• / •

5+1 / -

2 / 2

2 / -

• (13.2) / -

2 (independent)

-

0.1

0.5

2.7

• / •

RC-1193

• / - / -

670 W

55 W / 85 W

434 x 389 x 167

(434 x 389 x 236)

(434 x 379 x 167)

12.6

AVR-X3200W

- / •

7 assignable assignable assignable

- / - / - / • / •

• / • / •

7

105 W

-

135 W

180 W

3 / -

2 / -

7+1 / 2

- / •

2

-

5 / -

-

2 / 2

1 / -

• (7.2) / -

0.1

0.5

2.7

• / -

-

RC-1192

- / - / -

600 W

45 W / 80 W

434 x 388 x 167

(434 x 388 x 237)

11.3

FEATURES

AVR-X2200W

INPUTS/OUTPUTS

VIDEO

Composite In / Out

Component In / Out

HDMI In / Out

Multi-Room Video Out: Video / HDMI

AUDIO

Analogue In / Out

Phono (MM) In

Digital in: optical / coaxial

Multi-Room Out: analog / digital

Multichannel Pre Out

Subwoofer Out

7.1 multichannel input

OTHER

Speaker Terminal: Gold plated screw / regular screw

Number of speaker terminals

Speaker A / B

Bi-amp drive

Multi-Room Speaker Terminal

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB

USB Audio / Made for iPod

®

/ Made for iPhone

®

FM Tuner with RDS

SPECIFICATIONS

number of poweramps

Power Output (8 ohm, 20 Hz - 20 kHz, 0.08 % 2 ch Drive)

Power Output (8 ohm, 20 Hz - 20 kHz, 0.05 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 0.7 % 2 ch Drive)

Power Output (6 ohm, 1 kHz, 1 % 1 ch Drive)

GENERAL

Available colors: Black / Premium Silver

Metal Front Panel

System Remote Control

Pre-programmed / Learnable / LCD Display

Power Consumption in W

Power consumption No-Sound (ECO on / off) in W

Standby Consumption in W

CEC Standby Consumption in W

Network Standby Consumption in W

Maximum Dimensions

Antenna: Horizontal: (W x D x H) in mm

(Antenna: Vertical: (W x D x H) in mm)

(w/o Antenna: (W x D x H) in mm)

Weight in kg

2 / -

1 / -

7+1 / 2

- / -

2

-

4 / -

-

2 / 0

1 / -

• (0.2) / -

- / •

7 assignable assignable assignable

- / - / - / • / •

• / • / •

7

95 W

-

125 W

150 W

• / -

-

RC-1192

- / - / -

500 W

35 W / 75 W

0.1

0.5

2.7

434 x 339 x 167

(434 x 339 x 235)

9.4

AVR-X1200W

- / •

7 assignable assignable assignable

- / - / - / • / •

• / • / •

7

80 W

-

120 W

145 W

2 / 1

- / -

5+1 / 1

- / -

2

-

2 / -

-

2 / 0

- / -

• (0.2) / -

• / -

-

RC-1189

- / - / -

430 W

30 W / 45 W

0.1

0.5

2.7

434 × 339 × 151

(434 x 339 x 215)

8.5

AVR-X520BT

2 / 1

- / -

5+0 / 1

- / -

2

-

2 / -

-

2 / 0

- / -

• (0.2) / -

-

-

-

- / -

5

- / - / - / - / •

• / • (for Bluetooth

®

) / • (for Bluetooth

®

)

5

70 W

-

90 W

130 W

• / -

-

RC-1196

- / - / -

330 W

-

0.3

-

-

434 × 319 × 151

7.5

AVR-X1200W AVR-X2200W

AVR-X520BT

Specifications 71

72 Specifications

BLU-RAY / UNIvERSAL PLAYERS

Technical information

Compatibility: CD / SACD / DVD / DVD-A / Blu-ray Disc

Audio / Video streaming from network

Online contents service: YouTube Leanback / Netflix*

Audio exclusive mode

Quick Start Mode

Video Scaling on HDMI: up to 1080P

3D video support

Compressed Audio Compatibility: WMA / MP3

Decoder: Dolby Digital Plus / Dolby TrueHD / DTS HD

Decoder: DD / DTS / DTS96/24 / SACD

DSD from SACD via HDMI

Multi Channel Down Mix: DD / DTS / SA-CD

CD Compatibility: CD / CD-R/RW / HDCD / SA-CD

DVD Compatibility: DVD-V / DVD-A / DVD-R / DVD-RW (video) / DVD+R/RW

AVCHD / DivX HD / DivX6 / DivX Ultra / DivX plus HD

MP3 / WMA from: CD / DVD / USB

Image Disc Compatibility: JPEG / JPEG HD / Picture CD

Loader mechanism

High Grade Audio Components

Customised Components

Multi layered construction

Gold Plated Cinch

OTHERS

CEC

True 24 Frames Per Second (FPS)

DLNA Certified

Network Audio: MP3 / WMA / AAC / FLAC / WAV

Network static video (JPEG)

Network Video: MPEG / DivX Plus HD / H.264 / WMV

Online contents service: YouTube Leanback / Netflix*

VIDEO: HDMI Out

AUDIO: Analogue Out: 2 ch / 5.1 ch / 7.1 ch (Cinch)

Digital Out: Coax/ Optical

OTHER

Denon Link HD

USB

Ethernet

Flasher IN / OUT

RS232

SPECIFICATIONS

D/A convertion (audio)

Frequency response CD (linear PCM)

Frequency response (SACD, DVD-A)

Signal to Noise Ratio

Dynamic Range: CD / DVD

Total Harmonic Distortion (THD)

GENERAL

Available colors: Black / Premium Silver

Metal Front Panel

Remote Control

Power Supply

Power Consumption in W

Standby Consumption in W

Maximum Dimensions (W x D x H) in mm

Weight in kg

DBT-3313UD

• / • / • / • / •

• / •

• / •

• / • / •

• / • / • / •

• / • / •

• / • / - / •

SVH

• / • / • / • / •

• / • / • / - / •

• / • / •

• / - / -

• (v1.5)

• / • / • / • / •

• / • / • / •

• / •

2

• / - / -

• / -

• / •

192 kHz / 32-bit

2 Hz to 20 kHz

2 Hz - 40 kHz (SA-CD)

120 dB

105 dB

0,0020 %

• / •

RC-1161

AC 100 - 240 V, 50/60 Hz

28

0.3

434 x 295 x 115

6.9

* Service not in all countries available - Subscription required

DBT-3313UD

Tv-SPEAKERS

Technical information

HDMI: ARC / CEC

Digital input: Optical / Coaxial

Analogue input (3.5 mm mini jack)

Simple one wire setup

Bluetooh: A2DP / APT-X

Dolby Digital decoding / DTS

Soundmode: Dialog, Music , Movie

Night listening mode

BassTrac

Wireless Subwoofer

INSTALLATION

Keyhole style wall mount

Tabletop placement

Adjustable foot height (2 x)

TV placement on top

CONTROL

Control buttons

Remote Control

TV remote learning function

IR blaster for extra IR transmitter

Auto input switching

GENERAL

Available color: Black

Standby Consumption in W

Auto Power Off

Dimensions (W x H x D)

Height with foot 1 / foot 2

Weight kg

Subwoofer Dimensions (W x H x D)

Subwoofer Weight kg

-

-

DHT-S514

• (1 x in / 1 x out)

• / •

• / •

0.5

1004 x 80 x 78 mm

98 mm / 110 mm

2.3

172 x 313 x 346 mm

5.9

DHT-T110

-

-

• / •

• / •

• / -

-

-

-

• (up to 27 kg)

4.3

-

-

0.5

608 x 71 x 355 mm

-

Specifications 73

74 Specifications

INTEGRATED AMPLIFIERS

Technical information

Channels

UHC-MOS single push pull circuit

Advanced HC-TR single push pull circuit

LC mounted twin transformer

Wide range amplifier

High current dynamic power supply

Power amp discrete construction

Micro processor auto off

Balance / Bass / Treble / Loudness

OTHER

Shottky diodes

Solid Heat Sinks

Source Direct

Power Amp direct

INPUTS/OUTPUTS

Audio Inputs

Phono Input: MM / MC

Audio Outputs

Pre-out / Main-in

Power Amp Direct IN

Gold Plated Cinch

Speaker A / B

Number of terminals

Remote Control Bus in / out

Headphone Out

SPECIFICATIONS

Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07 %)

Output power 4 Ohm (1 kHz, T.H.D. 0.7 %)

Total Harmonic Distortion

Input Sensitivity: MM

Input Sensitivity: MC

Signal to Noise Ratio: MM/MC

Input Sensitivity: High level

Signal to Noise Ratio: High level

Treble Control

Bass Control

GENERAL

Available colors: Premium Silver / Black

Metal Front Panel

Power Consumption in W

Standby Consumption in W

Auto Power off

Detachable Power Cable

Remote Control

System Remote Function

Maximum Dimensions (W x D x H) in mm

Weight in kg

PMA-2020AE

-

2

• (Advanced)

• / • / • / -

-

2

7

• / •

2

1 / -

• (Separate)

80 W

160 W

0.01 %

2.5 mV / 47 kohm

200 µV / 100 ohm

89 dB / 74 dB

135 mV / 47 kohms

108 dB

± 8 dB at 10 kHz

± 8 dB at 100 Hz

• / -

360

0.2

RC-1179

434 x 435 x 181

24.4

PMA-1520AE

-

2

• (Advanced)

• / • / • / -

• (Separate)

-

2

6

• / •

1

1 / -

70 W

140 W

0.01 %

2.5 mV / 47 kohm

200 µV / 100 ohm

89 dB / 74 dB

125 mV / 47 kohms

108 dB

± 8 dB at 10 kHz

± 8 dB at 100 Hz

• / •

295

0.2

RC-1186

434 x 414 x 135

16.1

PMA-720AE

-

2

-

• / • / • / •

-

2

6

• / -

1

1 / -

-

50 W

85 W

0.01 %

2.5 mV / 47 kohm

-

86 dB / -

110 mV / 30 kohms

107 dB

± 8 dB at 10 kHz

± 8 dB at 100 Hz

• / •

200

0.3

RC-1173

434 x 308 x 121

7.1

PMA-520AE

-

2

-

• / • / • / •

-

-

-

1

6

• / -

1

- / -

-

45 W

70 W

0.02 %

2.5 mV / 47 kohm

-

84 dB / -

110 mV / 30 kohms

105 dB

± 8 dB at 10 kHz

± 8 dB at 100 Hz

• / •

185

0.3

RC-1173

434 x 308 x 121

6.8

PMA-2020AE

PMA-720AE

PMA-1520AE

PMA-520AE

Specifications 75

SA/CD-PLAYERS

Technical information

CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC iPod

®

/ iPhone

®

compatible USB input

AL 32 Processing

DAC Master Clock Design

DAC operation mode: USB / Coax / Optical

Asynchronous mode rear USB

Bit-perfect transmission

USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6

Signal isolator for DAC Mode operation

Extra metal plate for chassis strengthing

Aluminium side panels

OTHER

Display: Dimmer / Off

PLAYBACK

Program Play (CD / SA-CD)

Repeat

Random Play

Start Sound Mode for SA-CD

INPUTS/OUTPUTS

Analogue Out (Cinch)

Digital Optical In / Out

Digital Coaxial In / Out

Sample Rate digital In

Gold plated Cinch

USB Audio (Front) / Made for iPod

®

/ Made for iPhone

®

USB type B input for PC (back)

Asynchronous mode rear USB

Sample Rate USB type B In

USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6

Remote Control Bus in / out

Headphone Out

Headphone Volume Control

SPECIFICATIONS

Mechanism

DAC IC

SA-CD AUDIO

Frequency Response (Cust.)

Dynamic Range (SA)

Signal to Noise Ratio (SA)

Total Harmonic Distortion (SA)

CDDA AUDIO

Frequency Response

Dynamic Range

Signal to Noise Ratio

Total Harmonic Distortion

GENERAL

Available colors: Premium Silver / Black

Metal Front Panel

Remote Control

Power Consumption in W

Standby Consumption in W

Auto power off

Detachable Power Cable

Maximum Dimensions (W x D x H) in mm

Weight in kg

SVH Loader

PCM1795 (192 kHz / 32-bit)

2 Hz - 50 kHz

118 dB

121 dB

0.0008 %

2 Hz - 20 kHz

101 dB

120 dB

0,0015 %

• / -

RC-1179

33

0.2

434 x 335 x 138

13.7

DCD-2020AE

-

-

• / • / • / • / • / -

• (Advanced)

• / • / •

• / •

• / •

2 ch

• / •

• / •

192 kHz / 24-bit

-

-

-

• / • / •

192 kHz / 24-bit

DCD-1520AE

-

-

• / •

• / • / • / • / • / -

• (Advanced)

• / • / •

• / •

• / •

2 ch

• / •

• / •

192 kHz / 24-bit

• / • / •

192 kHz / 24-bit

SVH Loader

PCM1795 (192 kHz / 32-bit)

2 Hz - 50 kHz

113 dB

117 dB

0.001 %

2 Hz - 20 kHz

100 dB

117 dB

0,0018 %

• / •

RC-1186

38

0.2

434 x 331 x 134

8.2

• / •

-

2 ch

- / •

- / -

-

-

-

-

• / • / •

-

DCD-720AE

-

-

-

-

• / • / - / • / • / -

-

-

• / - / -

DCD-520AE

-

-

-

-

-

-

-

• / • / - / • / • / -

-

-

• / •

-

• o

-

-

-

-

-

-

-

2 ch

- / •

- / -

-

-

-

PCM5142, Burr Brown (192 kHz / 32-bit)

-

PCM5102, Burr Brown (192 kHz / 32-bit)

-

-

-

-

2 Hz - 20 kHz

100 dB

112 dB

0,0025 %

• / •

RC-1173

22

0.3

-

434 x 273 x 107

4.1

-

-

-

-

2 Hz - 20 kHz

100 dB

110 dB

0,0030 %

• / •

RC-1173

13

0.3

-

434 x 273 x 107

4.0

DCD-2020AE

DCD-720AE

DCD-1520AE

DCD-520AE

76 Specifications

DESIGN SERIES

Technical information

PMA-50

FEATURES

Channels

Digital in: USB-B / optical / coaxial / USB-A

Sample Rate digital In

USB-A: DSD / WAV / FLAC / AIFF / ALAC

USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6

USB-B PCM sample rate

Asynchronous mode rear USB

Bit-perfect transmission

Ground isolator for DAC Mode operation

AL 32 Processing

DAC Master Clock Design

Bluetooth ® / aptX / NFC

Streaming audio from PC

Wi-Fi / Wired LAN

Internet radio

AirPlay audio streaming

Windows Play to vTuner / Spotify*

DLNA certified

Music Server

DSD-Audio network streaming

Lossy formats: MP3 / WMA / AAC

Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 /

WAV 192/24 / AIFF

Gapless Playback

Remote APP: iDevice / Android

Balance / Bass / Treble / Loudness

OTHER

Vertical Installation

Low Noise OELD display

Source Direct

INPUTS/OUTPUTS

Audio Inputs

Digital in: USB-B / optical / coaxial / USB-A

Audio Outputs

Pre-out / Main-in

Number of terminals

Headphone Out

Headphone Gain Control (low / mid / high)

SPECIFICATIONS

Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07 %)

Output power 4 Ohm (1 kHz, T.H.D. 0.7 %)

Total Harmonic Distortion

Input Sensitivity: High level

Signal to Noise Ratio: High level

Treble Control

Bass Control

GENERAL

Available colors: Premium Silver / Black

Power Consumption in W

Standby Consumption in W

Auto Power off

Detachable Power Cable

Remote Control

Maximum Dimensions (W x D x H) in mm

Weight in kg

30 W

50 W

0.004 %

70 mV

110 dB

± 8 dB at 12 kHz

± 8 dB at 100 Hz

• / -

35

0.2

RC-1202

200 x 238 x 90

2.5

-

-

-

-

-

-

2

• / 2 / • / -

192 kHz / 24-bit

-

• / •

192 kHz / 24-bit

-

-

-

-

• (Advanced)

• / Low Latency / •

-

-

-

• / • / • / -

1

• / 2 / • / -

subwoofer / -

1 pair

DRA-100

-

-

-

-

2

- / 2 / • / •

192 kHz / 24-bit

<= 5.6 / 192 / 192 / 192 / 96

• / •

-

• (Advanced)

• / - / •

• / Connect

• (v1.5)

DLNA (1.5) / WMP11 / Twonky Vision

• / • / •

• / • / • / • / •

• / •

• / • / • / -

-

2

- / 2 / • / •

1 x variable / fix selectable main + subwoofer / -

1 pair

35 W

70 W

0.004 %

130 mV / 22 kohm

110 dB

± 8 dB at 12 kHz

± 8 dB at 100 Hz

• / -

60

0.3

RC-1206

280 x 337 x 104

4.8

PMA-50 DRA-100

DESIGN SERIES

Technical information

DCD-50

FEATURES

CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3

/ AAC

DAC Master Clock Design

Aluminium side panels

OTHER

Display: Dimmer / Off

Playback

Program Play

Repeat

Random Play

INPUTS/OUTPUTS

Analogue Out (Cinch)

Digital Coaxial In / Out

SPECIFICATIONS

Mechanism

DAC IC

Frequency Response

Dynamic Range

Signal to Noise Ratio

Total Harmonic Distortion

GENERAL

Available colors: Premium Silver / Black

Remote Control

Power Consumption in W

Standby Consumption in W

Auto power off

Detachable Power Cable

Maximum Dimensions (W x D x H) in mm

Weight in kg

• / • / - / • / • / -

• / -

2 ch

- / •

Slot in

PCM5102, Burr Brown (192 kHz / 32-bit)

2 Hz - 20 kHz

100 dB

105 dB

0,004 %

• / -

RC-1205

10

0.4

200 x 240 x 86

2.4

DCD-50

Specifications 77

78 Specifications

NETWORK PLAYER

Technical information

Streaming audio from PC

Wi-Fi / Wired LAN

Wi-Fi sharing / WPS

WMM certified

Internet radio

AirPlay audio streaming

Windows Play to vTuner / Spotify*

USB Audio (Front) / Made for iPod

®

/ Made for iPhone

®

DLNA certified

Music Server

Lossy formats: MP3 / WMA / AAC

Lossless formats:

DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24

Gapless Playback

Remote APP: iDevice / Android

App control AMP/CD via Network Player

OTHER

Display

Display: Dimmer / Off

IN/OUTPUTS

iPod ® / iPhone ® compatible USB (front)

USB type B input for PC (back)

Sample Rate USB In

Analogue Out

Ethernet port

Digital Inputs: Coaxial / Optical

Digital Outputs: Coaxial / Optical

Sample Rate digital In

Jitter Reducer

Remote Control Bus in / out

RS232

SPECIFICATIONS

DAC IC

Dual Clock

Frequency response

Dynamic range in dB

Signal-to-noise ratio in dB

Total harmonic distortion

GENERAL

Available colors: Premium Silver / Black

Metal Front Panel

Remote Control

Power Consumption in W

Standby Consumption in W

Detachable Power Cable

Maximum Dimensions (W x D x H) in mm

Weight in kg

* Service not in all countries available - Subscription required

DNP-730AE

• / •

• / •

• / Connect

• / • / •

• (v1.5)

DLNA (1.5) / WMP11 / TwonkyVision

• / • / •

• / • / • / •

• (FLAC, WAV)

• / •

3 line OELD

• / •

-

-

- / -

- / •

-

-

1 x Cinch

PCM1795, 192 kHz / 32-bit

-

2 Hz~50 kHz

101

110

0,0012 %

• / •

RC1197

18

0.2

434 x 297 x 74

2.9

DNP-730AE

TURNTABLES

Technical information

Motor: AC / DC

Drive System: Belt / Direct

Operation: Automatic / Manual

Speed: 33-1/3 & 45 RPM

Wow & flutter

Phono EQ built-in (switchable)

Stylus (MM / MC)

Stylus version

SPECIFICATIONS

Rated Output

Frequency Range

S/N ratio

Rated Output Phono EQ

Frequency Range Phono EQ

GENERAL

Available colors: Premium Silver / Black

Maximum Dimensions (W x D x H) in mm

Weight in kg

CARTRIDGES

Technical information

Type

Output voltage

Frequency range

Output impedance

Weight

DP-300F

- / •

• / -

• / -

• / •

0.10 % (WRMS)

• / -

DSN-85

2.5 mV / 1 kHz

20 Hz - 20 kHz

60 dB

150 mV / 1 kHz

20 Hz - 20 kHz

• / •

434 x 381 x 122

5.5

DL-103

MC

0.3 mV

20 Hz - 45 kHz

40 ohms

8.5 g

DL-103R

MC

0.25 mV

20 Hz - 45 kHz

14 ohms

8.5 g

DP-200USB

- / •

• / -

• / -

• / •

0.15 % (WRMS)

• / -

DSN-84

2.5 mV / 1 kHz

20 Hz - 20 kHz

-

150 mV / 1 kHz

20 Hz - 20 kHz

• / •

360 x 357 x 97

3.2

DL-110

MC

1.6 mV

20 Hz - 45 kHz

160 ohms

4.8 g

DP-29F

- / •

• / -

• / -

• / •

0.15 % (WRMS)

• / -

DSN-82

2.5 mV / 1 kHz

20 Hz - 20 kHz

-

150 mV / 1 kHz

20 Hz - 20 kHz silver / -

360 x 357 x 97

2.8

DL-304

MC

0.18 mV

20 Hz - 75 kHz

40 ohms

7 g

Specifications 79

80

MINI HI-FI SYSTEM

D-F109/D-F109DAB*

Technical information

Receiver

High quality power output

Tuner: DAB / DAB+ / FM (RDS)

Tone Control: Bass / Treble / Balance

Clock

Sleep Timer

Programmable Timer: Once / Daily

INPUTS/OUTPUTS

AUDIO

Analogue In/out

Digital Optical In/Out

Digital Coaxial In / Out

OTHER

Subwoofer PreOut

Speaker Terminal: click fit / Screw

Headphone Out

SPECIFICATIONS

AUDIO SECTION

Power Output (4 ohms, 1 kHz, T.H.D. 0,7 %)

Number of channels

Freq. Response (Analogue In)

DAB SECTION

Receiving Range Band III

TUNER SECTION FM

Frequency Range FM

GENERAL

Available colors: Black / Premium Silver

Remote Control

Power Consumption in W

Standby Consumption in W

Maximum Dimensions (W x D x H) in mm

Weight in kg

DRA-F109

2 x 65 W

- / - / •

• / • / •

• / •

2 / 0

1 / 0

2 / 0

- / •

65 W

2

20 Hz - 20 kHz

-

87.5 Mhz - 108.0 MHz

• / •

RC-1163

48

0.3

250 x 283 x 82

2.6

DRA-F109DAB

2 x 65 W

• / • / •

• / • / •

• / •

2 / 0

1 / 0

2 / 0

- / •

65 W

2

20 Hz - 20 kHz

87.5 Mhz - 108.0 MHz

• / •

RC-1163

48

0.3

250 x 283 x 82

2.6

* DAB version is not necessarily sold in all regions. Please contact a nearby Denon authorised dealer for details and availability.

Technical information

Speaker System

Type

Drivers

Impedance (ohms)

Frequency range

Available colors: Black / Wood

Maximum Dimensions (W x D x H) in mm

Weight in kg

SC-F109

2-way, bass reflex

12 cm bass-mid

2.5 cm dome high

6

45 Hz - 40 kHz

• / •

165 x 234 x 245

3.8 per unit

Technical information

CD-Player

CD Compatibility: CD / CD-R/RW / WMA /

MP3

USB Audio (Front) / Made for iPod

® for iPhone

®

/ Made

INPUTS/OUTPUTS

Digital Outputs: Coaxial / Optical

Remote Control Bus in / out

GENERAL

Available colors: Black / Premium Silver

Remote Control

Power Consumption in W

Standby Consumption in W

Maximum Dimensions (W x D x H) in mm

Weight in kg

DCD-F109

• / • / • / •

• / • / •

• / -

• / • via system RC

25

0.3

250 x 260 x 82

2.8

Technical information

Network Player

Streaming audio from PC

Internet radio vTuner

AirPlay audio streaming

USB Audio (Rear) / Made for iPod

®

/ Made for iPhone

®

Ethernet / WiFi

DLNA certified

Lossy formats: MP3 / WMA / AAC

Lossless formats: FLAC HD 192/24 / ALAC 96/24 / WAV

192/24 / AIFF

Remote APP

IN/OUTPUTS

iPod

®

/ iPhone

®

compatible USB input

Analogue Out

Ethernet port

Digital Outputs: Coaxial / Optical

Remote Control Bus in / out

SPECIFICATIONS

DAC IC

Frequency response

Dynamic range

Signal-to-noise ratio

Total harmonic distortion

GENERAL

Available colors: Black / Premium Silver

Remote Control

Power Consumption in W

Standby Consumption in W

Maximum Dimensions (W x D x H) in mm

Weight in kg

DNP-F109

• / • / •

• / •

• (v1.5)

• / • / •

• / • / • / •

1

1

• / -

AK4424

2 Hz-48 kHz (fs: 96 kHz) 2 Hz-20 kHz (fs: 44.1 kHz)

98 dB

110 dB

0.0035 % (1 kHz, audible band)

• / •

RC-1164

16

0.3

250 x 260 x 82

2.0

DRA-F109

* Service not in all countries available - Subscription required

DNP-F109

DCD-F109

MINI HI-FI SYSTEM

D-M40/D-M40DAB*

Technical information

CD-Receivers

High quality power output

CD Compatibility: CD / CD-R/RW / WMA / MP3

Tuner: DAB / DAB+ / FM (RDS)

USB Audio (Front) / Made for iPod ® / Made for iPhone ®

USB-A: WMA / MP3 / WAV / FLAC / AIFF / ALAC

Tone Control: Bass / Treble / Balance

Clock

Sleep Timer

Programmable Timer: Once / Daily

INPUTS/OUTPUTS

AUDIO

Analogue In/out

Digital Optical In/Out

OTHER

iPod

®

/ iPhone

®

compatible USB input

Subwoofer PreOut

Speaker Terminal: click fit / Screw

Headphone Out

SPECIFICATIONS

AUDIO SECTION

Power Output (6 ohm, 1kHz)

Number of channels

Freq. Response (Analogue In)

DAB SECTION

Receiving Range Band III

TUNER SECTION FM

Frequency Range FM

GENERAL

Available colors: Black / Premium Silver

Remote Control

Power Consumption in W

Standby Consumption in W

Maximum Dimensions (W x D x H) in mm

Weight in kg

- / •

RCD-M40

2 x 30 W

• / • / • / •

- / - / •

• / • / •

• / • / • / • / - / -

• / • / •

• / •

1 / 0

• / -

30 W

2

20 Hz - 20 kHz

-

87.5 Mhz - 108.0 MHz

• / •

RC-1162

70

0.3

210 x 308 x 115

4.0

RCD-M40DAB

2 x 30 W

• / • / • / •

• / • / •

• / • / •

• / • / • / • / - / -

• / • / •

• / •

1 / 0

• / -

- / •

30 W

2

20 Hz - 20 kHz

87.5 Mhz - 108.0 MHz

• / •

RC-1162

70

0.3

210 x 308 x 115

4.0

* DAB version is not necessarily sold in all regions. Please contact a nearby Denon authorised dealer for details and availability.

Technical information

Speaker System

Type

Drivers

Impedance (ohms)

Frequency range

Available colors: Black / Wood

Maximum Dimensions (W x D x H) in mm

Weight in kg

SC-M40

2-way, bass reflex

12 cm bass-mid

2.5 cm dome high

6

45 Hz - 40 kHz

• / •

145 x 234 x 238

3.5 per unit

RCD-M40

81

82 Specifications

USB-DAC

Technical information

DAC operation mode: USB / Coax / Optical

Asynchronous mode rear USB

Bit-perfect transmission

USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6

iPod ® / iPhone ® compatible USB input

DAC chip

AL 32 Processing

DAC Master Clock Design

Vertical installation

Low Noise OELD display

INPUTS/OUTPUTS

Headphone Out

Headphone Volume Control

Headphone Gain Control (low / mid / high)

Analogue Input

Analogue Out (fix / variable)

Digital Optical In / Out

Digital Coaxial In / Out

Sample Rate digital In

Gold plated Cinch

USB type B input for PC (back)

Asynchronous mode rear USB

Sample Rate USB type B In

USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6

SPECIFICATIONS

Frequency Response

Signal to Noise Ratio

Total Harmonic Distortion

Channel Separation

Headphone Power

GENERAL

Available colors: Silver / Black

Remote Control

Auto power off

Detachable Power Cable

Maximum Dimensions (W x D x H) in mm

Weight in kg

DA-300USB

• / • / •

• / •

PCM1795 (192 kHz / 32-bit)

• (Advanced)

-

-

• / -

2 / -

1 / -

192 kHz / 24-bit

192 kHz / 24-bit

2 Hz - 100 kHz

112 dB

0,0018 %

100 dB

50 mW / 32 ohms

• / -

-

• adaptor

170 x 182 x 57 (horizontal)

114 x 182 x 175 (vertictal with foot)

1.5

DA-10

-

-

• / - / -

• / •

PCM1795 (192 kHz / 32-bit)

• (Advanced)

1

• / -

- / -

- / -

-

-

• (micro)

192 kHz / 24-bit

2 Hz - 50 kHz (-3 dB)

108 dB (Volume max, 2 V)

0.003 % (1 kHz, Audible range)

101 dB (1 kHz)

40 mW + 40 mW (32 ohms, 1 % distortion)

18 mW + 18 mW (600 ohms, 1 % distortion)

-

-

• / -

-

634 x 136 x 28

0.23

WIRELESS MUSIC SYSTEM

Technical information

FEATURES

Analogue input (3.5 mm mini jack)

USB Port (service / mobile charging)

Control buttons

Battery Indicator

Battery life

Charge time

Built-in microphones

BLUETOOTH ®

Compatible Bluetooth ® profiles

Supported codecs

NFC bluetooth

®

pairing

Multi-pairing

Multi point

SPECIFICATIONS

Drivers

Amplifier

GENERAL

Available colours: White / Black

Included grille cloth colors:

Lunar / Indigo / Fandango / Sunset

AC charger power supply

Power consumption

Dimensions (W x H x D)

Weight

Envaya

• / • approx. 10 hrs

2.5 hrs

-

8

3

A2DP/AVRCP aptX low latency/AAC/SBC

52 mm x 2 Full Range Driver

100 mm Passive Radiator

High efficiency digital amplifier

• / •

• / • / • / •

Input AC 100-240 V 50 / 60 Hz

Output 13 V / 2.3 A

<0.3 W (Standby)

255 x 141 x 47.5 mm

1.28 kgs

Envaya Mini

• / approx. 6 hrs

2.5 hrs

8

2

A2DP/AVRCP/HFP aptX low latency/AAC/SBC

40 mm x 2 Full Range Driver

40 mm x 83 mm Passive Radiator

High efficiency digital amplifier

• / •

-

-

3 mW (power off)

210 x 54 x 51 mm

0.51 kgs

Specifications 83

84 Specifications

NETWORK MUSIC SYSTEMS

Technical information

High quality power output

CD Compatibility: CD / CD-R/RW / WMA / MP3

Tuner: FM (RDS) / AM

Streaming audio from computer

PC Direct by rear USB-B

Bluetooth ® / aptX / NFC

Internet radio

AirPlay audio streaming

Windows 8 / RT vTuner / Spotify*

USB Audio (Front) / Made for iPod ® / Made for iPhone ®

Ethernet / WiFi

WiFi setup: WPS / WiFi Sharing

DLNA certified

Lossy formats: MP3 / WMA / AAC

Lossless formats: FLAC HD / ALAC / WAV / AIFF

Gapless Playback

WMM (WiFi Multimedia)

Remote APP: iDevice / Android

Tone Control: Bass / Treble / Balance

Speaker Optimizer

Auto Volume Adjust / Wide Sound

Vertical installation

Low Noise OELD display

Clock

Sleep Timer

Programmable Timer: Once / Daily

INPUTS/OUTPUTS

AUDIO

Analogue In/out

Digital Optical In/Out

Rear USB-B

OTHER

iPod

®

/ iPhone

®

compatible USB input

Subwoofer PreOut

Speaker Terminal: push type / Screw

Headphone Out

SPECIFICATIONS

AUDIO SECTION

Power Output (6 ohm, 1 kHz)

Number of channels

Freq. Response (Analogue In)

Signal to Noise Ratio (audio)

Total Harmonic Distortion (audio)

TUNER SECTION FM

Frequency Range FM

Signal to Noise Ratio (Mono/Stereo) FM

Total Harmonic Distortion (Mono/Stereo) FM

GENERAL

Available colors: Black / White

Remote Control

Power Consumption in W

Standby Consumption in W

Maximum Dimensions (W x D x H) in mm

Weight in kg

1 / 0

-

-

• / -

CEOL Carino

-

-

-

-

- / - / -

- / -

- / -

-

-

-

-

-

2 x 20 W

- / - / - / -

- / -

-

• (no driver required)

• / Low Latency / •

-

-

- / -

-

Speaker Optimization

• / •

20 W

2

20 Hz - 20 kHz

86 dB

0.1 (1 kHz / 5 W / 6 ohms)

-

-

-

• / •

RC-1195

15

0.4

175 x 201 x 60

1.5

* Not available in all regions.

Technical information

Speaker

Type

Drivers

Frequency Range

Impedance (ohms)

Available colors: Black / White

Maximum Dimensions (W x D x H) in mm

Weight in kg

SC-N2

2-way, passive

6 cm full range,

7.5 cm passive bass

-

6

• / •

98 x 98 x 105

0.73

1 / 0

1 / 0

-

1

• / -

40 W / 4 ohms

2

20 Hz - 20 kHz

86 dB

0.1 (1 kHz / 5 W / 4 ohms)

-

-

-

• / •

RC-1198

45

0.4

200 x 239 x 90

2.0

CEOL Piccolo

• / •

• / • / •

- / -

-

3 line

• / •

2 x 40 W

- / - / - / -

- / -

-

• / - / •

• / Connect

• / • / •

• / •

• / •

• (v1.5)

• / • / •

• / • / • / •

• (FLAC / WAV / DSD / AIFF / ALAC)

1 / 0

2 / 0

-

1

• / -

60 W / 4 ohms

2

20 Hz - 20 kHz

86 dB

0.1 (1 kHz / 5 W / 4 ohms)

87.5 - 108 MHz

74/70 dB

0.3 / 0.4 %

• / •

RC-1199

55

0.4

280 x 305 x 102

3.3

CEOL

• / •

• / • / •

- / -

-

3 line

• / •

2 x 65 W

• / • / • / •

• / •

-

• / - / •

• / Connect

• / • / •

• / •

• / •

• (v1.5)

• / • / •

• / • / • / •

• (FLAC / WAV / DSD / AIFF / ALAC)

SC-N4

2-way, reflex

10 cm bass-mid,

2.5 cm dome high

70 Hz–20k Hz

6

• / •

134 x 200 x 185

2.0

SC-N9

2-way, reflex

12 cm bass-mid,

2.5 cm dome high

50 Hz–20 kHz

6

• / •

153 x 200 x 233

2.4

HEADPHONES

Technical information

MUSIC MANIAC

Colour

Driver Diameter

Driver Type

Impedance

Sensitivity

Maximum Power Input

Frequency Response

Weight

AH-MM400

American Walnut

40 mm

Dynamic

(Carbon/paper diaphragm

+ Free Edge)

32 ohms

98 dB / mW

1000 mW

10-40,000 (Hz)

310 g

AH-MM300

Black

40 mm

Dynamic

(Carbon/paper diaphragm

+ Free Edge)

32 ohms

96 dB / mW

1000 mW

10-40,000 (Hz)

195 g

AH-MM200

Black / White

30 mm

Dynamic

(Triple layered Diaphragm)

24 ohms

99 dB / mW

1000 mW

10-25,000 (Hz)

130 g

AH-C120MA

Black

11.5 mm

Dynamic

AH-C50MA

Black/Silver

9 mm

Dynamic

32 ohms

106 dB / mW

250 mW

5-24,000 (Hz)

7.37 g (not including cable)

16 ohms

103 dB / mW

100 mW

20-23,000 (Hz)

3.96 g (not including cable)

Technical information

GLOBE CRUISER

Colour

Driver Diameter

Driver Type

Impedance

Sensitivity

Maximum Power Input

Frequency Response

Weight

AH-W200

Silver / Black

11.5 mm

Dynamic

16 ohms

102 dB / mW

250 mW

5-25,000 Hz

23 g

AH-GC20

Black

40 mm

Dynamic

100 Ohm (Power on)

102 dB / mW

1000 mW

5-40,000 Hz

275 g

Technical information

EXERCISE FREAK

Colour

Driver Diameter

Driver Type

Impedance

Sensitivity

Maximum Power Input

Frequency Response

Weight

AH-W150

Blue, Black, Yellow, Orange

11.5 mm

Dynamic

16 ohms

102 dB / mW

250 mW

5-25,000 Hz

23 g

Specifications 85

86 Specifi cations

HEOS

Technical information

HEOS 1

AUDIO SYSTEM

Class D digital amplifiers

Driver speaker system

NETWORKING

Wireless Connectivity: 802.11a/b/g/n networks on 2.4 GHz /

5 GHz bands

Wired Connectivity: Single RJ-45 jack

MUSIC SOURCES

NAS (Network Attached Storage): DLNA

USB Storage

Aux Input

Internet Radio Supported: MP3 / AAC / WMA

Album Art Supported: JPG / PNG / BMP / GIF

Audio Formats Supported: MP3 / WMA / AAC (MPEG4) /

FLAC / WAV

GENERAL

Power Supply: AC 100~240 V / AC 50~60 Hz

Weight

Dimensions (H x W x D) in mm

Product Finish: Black / White

Dual

Dual

• / •

• / • / •

• / • / • / •

• / • / • / • / •

• / •

1.9 kg

189 x 129 x 128

• / •

HEOS 3

Dual

Dual

• / •

• / - / •

• / • / • / •

• / • / • / • / •

• / •

1.9 kg

130 x 272 x 165 (horizontal placement)

• / •

HEOS 5

Four

Four

• / •

• / - / •

• / • / • / •

• / • / • / • / •

• / •

3.0 kg

209 x 294 x 166

• / •

HEOS 7

Five

Five

• / •

• / - / •

• / • / • / •

• / • / • / • / •

• / •

4.5 kg

203 x 479 x 164

• / •

Technical information

HEOS Amp

AUDIO SYSTEM

Class D digital amplifiers

Driver speaker system

Power amplifier Rated output

Impedance

Total Distort: ANALOGUE IN / S/N ratio

Frequency response: 20 Hz to 20 kHz

Analogue output Output level

Sound Formats:

HDMI Input / Output

Digital inputs: optical / coaxial

Digital outputs: optical / coaxial

NETWORKING

Wireless Connectivity: 802.11a/b/g/n networks on 2.4 GHz /

5 GHz bands

Wired Connectivity: Single RJ-45 jack

MUSIC SOURCES

NAS (Network Attached Storage): DLNA

USB Storage

Aux Input

Internet Radio Supported: MP3 / AAC / WMA

Album Art Supported: JPG / PNG / BMP / GIF

Audio Formats Supported: MP3 / WMA / AAC (MPEG4) /

FLAC / WAV

GENERAL

Power Supply: AC 100~240 V / AC 50~60 Hz

Weight

Dimensions (H x W x D) in mm

Product Finish: Black / White

2 ch

-

100 W + 100 W (6 ohms, 1 kHz, T.H.D. 0.7%)

70 W + 70 W (8 ohms, 20 Hz - 20 kHz, T.H.D. 0.05%)

4 – 16 Ω/ohms

0.1 % (1 kHz) / 83 dB

-

-

±1.0 dB

-

• / -

- / -

• / •

• / - / •

• / • / • / •

• / • / • / • / •

• / •

2.8 kg

221 x 93 x 214

Black front panel / sides / silver trim + top panel

HEOS Link

-

-

-

-

-

-

0.01 % (1 kHz) / 90 dB

±0.5 dB

FIX : 2.0 Vrms (10 kΩ / kohms) / Variable

• / -

• / •

• / •

• / - / •

• / • / • / •

• / • / • / • / •

• / •

1.3 kg

155 x 74 x 150

Black front panel / sides / silver trim + top panel

HEOS HomeCinema

4 (bi-amplified soundbar)

2.1 Speaker System

-

-

-

-

-

Dolby Digital (Plus) / DTS Decoding

• / •

• / •

- / -

• / •

-

• / • / •

• / • / • / •

• / • / • / • / •

2.8 kg Soundbar / 6.6 kg Subwoofer

82 x 1017 x 94 Soundbar / 313 x 171.5 x 332 Subwoofer

• / –

HEOS HomeCinema HEOS Amp

Technical information

GENERAL

Playback Time

Weight

Dimensions (H x W x D) in mm

Product Finish: Black / White

HEOS Link

GoPack

up to 6 hours

0.32 kg

33 x 125 x 118

• / •

Design and specifications are subject to change without notice.

• “BD-LIVE” logo is trademark of Blu-ray Disc Association.

• “AVCHD” and the "AVCHD" logo are trademark of Panasonic Corporation and Sony Corporation.

• “x.v.Color” and the “x.v.Color” logo are trademarks of Sony Corporation.

• Dolby, Dolby Atmos, Dolby Surround, and the double-D symbol are trademarks of Dolby Laboratories.

• DTS and DTS Digital Surround are registered trademarks of DTS Technology. DTS:X, and the DTS:X logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries..

• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

• DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.

• Java and all other trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and/or other countries.

• Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

• “BONUSVIEW” is trademark of Blu-ray Disc Association.

• Audyssey MultEQ

®

is a registered trademark of Audyssey Laboratories.

• Audyssey Dynamic EQ ™ is a trademark of Audyssey Laboratories.

• Audyssey Dynamic Volume

is a trademark of Audyssey Laboratories.

• “Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple performance standards.

• Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

• Airplay

®

, iPad

®

,  iPhone

®

, iPod

®

and iPod touch

®

are trademarks of Apple Inc., registered in the U.S. and other countries.

• Denon is a trademark or registered trademark of D&M Holdings, Inc.

• DLNA CERTIFIED

TM

Audio/Video/Image Player.

• DLNA

®

, the DLNA Logo and DLNA CERTIFIED™ are trademarks, service marks, or certification marks of the Digital Living Network Alliance.

• The Bluetooth

®

word mark and logos are registered trademarks owned by Bluetooth

®

SIG, Inc. and any use of such marks by D&M Holdings Inc. is under license.

• The Spotify software is subject to third party licenses found here: www.spotify.com/connect/third-party-licenses

• Other trademarks and trade names are those of their respective owners.

D&M Europe B.V.

Beemdstraat 11,

5653 MA Eindhoven

The Netherlands

Tel. +31 40-25 07 844

Fax +31 40-25 07 802 www.denon.eu

Denon UK

Division of D&M Audiovisual Ltd

Unit 10,

1 Lanyon Quay,

Belfast, BT1 3LG

Northern Ireland www.denon.co.uk

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
