Underfloor Electric Heating System with uncoupling/vapor management/load distribution and waterproof properties.

Advances in tile manufacturing in the past few decades have improved the quality and choices available to the consumer. New colors, new materials, larger format, thinner tiles and digital printing have all contributed to a steady growth of the use of tile as a surface. When compared to other flooring options such as carpeting and wood floors, tiles are normally preferred because they are easy to clean, resilient, and hygienic. Unfortunately ceramic tile and natural stone, if not installed properly, are subject to cracking, delamination, and are cold to the touch. Use of electrical floor heating can minimize the cold, but submits the tile assembly to additional stress that can lead to cracking and delamination.

Traditionally most electric floor heating, and anti-fracturing membrane manufacturers have recommended covering the electrical heating cables with a self-leveling cement layer or a thin-set layer followed by an uncoupling crack isolating membrane and then finally installing the tiles. This process needlessly increases time, difficulty, thickness, height differentials, weight, and cost of the overall installation.

2 PROGRESS PROFILES - PRODESO HEAT SYSTEM

The patented PRODESO HEAT SYSTEM by Progress Profiles combines the benefit of an underlayment membrane with the comfort and convenience of electrical floor heating. The Prodeso

Heat Membrane can be installed over the entire subfloor as an uncoupling, crack isolating and waterproofing membrane. The Prodeso Heat Cable is then installed in the areas where heat is desired.

Once the Prodeso Heat Cable is installed you can begin tiling immediately, no waiting is necessary.

PRODESO HEAT MEMBRANE is a polypropylene uncoupling, crack isolation, waterproofing membrane, with rounded square shaped reliefs. These reliefs form channels specially designed to embed and hold the PRODESO HEAT CABLE. PRODESO HEAT MEMBRANE has a polypropylene thermo welded woven underneath to increase the bond between the subfloor and the membrane.

PRODESO HEAT MEMBRANE ADVANTAGES

Uncoupling: PRODESO HEAT MEMBRANE compensates for the longitudinal movement between the subfloor and the tile preventing breakage and making it possible to install underfloor electric heating even on problematic substrates such as wood and cracked substrates.

UNCOUPLING

VAPOUR MANAGEMENT

Vapor Management: PRODESO HEAT MEMBRANE unique and patented design allows for air pockets to form between the subfloor and the membrane itself. Excess moisture from the substrate will find its way to these air pockets and create a vapor cycle. This vapor cycle will balance the vapor content of the substrate, protecting the tile from potential damage and making it possible to install underfloor electric heating even on substrates that are not perfectly cured or are moisture sensitive such as wood, concrete, and gypsum based subfloors.

WATERPROOFING

LOAD DISTRIBUTION

Waterproofing: PRODESO HEAT MEMBRANE is a

Polypropylene membrane and as such is naturally waterproof. For indoor installations in areas that are prone to water damage such as bathrooms and kitchens, the perimeter, corners, and seams of the PRODESO HEAT MEMBRANE need to be waterproofed utilizing PROBAND 150/250 waterproofing foil tape (doublesided Polypropylene foil tape) and

Unmodified Thin-Set ANSI

A118.1

Load distribution: PRODESO HEAT MEMBRANE unique and patented designs allows loads to be evenly distributed from the tile covering to the subfloor. Each rounded square relief has a central cavity shaped like an inverted pyramid. When filled with thin-set this inverted pyramid becomes an incompressible structure.

These cavities act like pillars in a building support structure, evenly distributing and transferring the load from the tile floor to the subfloor below.

Electrical Floor Heating cables need to be installed by qualified and licensed installers in accordance with this manual PLUS local and national codes. ALL electrical connection need to be executed by a licensed electrician in accordance with local and national codes.

PROGRESS PROFILES - PRODESO HEAT SYSTEM 3

The benefit of underfloor heating systems have been known for many years but the PRODESO HEAT SYSTEM has additional advantages:

PRODESO HEAT MEMBRANE uncoupling properties make it possible to install under-tile electrical heat over plywood and other problematic subfloors.

• Thanks to the thinness of the PRODESO HEAT MEMBRANE (5.5mm

/ 1/4 inch) it’s the ideal choice when the new tile floor meets an existing surface and height difference is a concern.

• The lightweight system assembly makes it the perfect choice when the load limits of the subfloor are a concern.

• Low thermal inertia guarantees the heat is rapidly and efficiently transferred to the tiles above for immediate warmth and comfort.

• Being able to customize the exact area where to install the heating cable optimizes your comfort while minimizing the overall cost.

• Drastic savings in installation time, effort and cost, combined with the comfort of electric radiant heat makes the PRODESO HEAT SYSTEM the obvious choice for any new or remodeling project.

PRODESO HEAT SYSTEM is durable and requires NO maintenance.

PRODESO HEAT SYSTEM SECTION

4

5

6

1

2

3

Tiles (Ceramic or natural stone)

Adhesive

PRODESO HEAT MEMBRANE

PRODESO HEAT CABLE

Adhesive

Subfloor

Index

6 PRODESO HEAT SYSTEM

Installed Over Wood Subfloor.

Indoor tile floor installation of ceramic or natural stone over a structurally sound wood based subfloor.

8 PRODESO HEAT SYSTEM

Installed Over Cement Based Subfloor.

Indoor tile floor installation of ceramic or natural stone over a structurally sound cement based subfloor.

10 PRODESO HEAT SYSTEM

Installed Over Gypsum Based

Underlayment.

Indoor tile floor installation of ceramic or natural stone over a structurally sound anhydrite based underlayment.

12 PRODESO HEAT SYSTEM

Installed Over Pre-existing Vinyl Flooring.

Indoor tile floor installation of ceramic or natural stone over an existing structurally sound vinyl floor.

13 Waterproofing

13 Expansion Joints

14 Installation

19 Products

22 Test Log

23 Warranty

Wood

Wood subfloor considerations and installation details

Wood and its derivatives are commonly used in today’s construction. All wood materials expand, contract, bend, and flex with changes in temperature, humidity, and load in the surrounding environment. These deformations can be seasonal or due to an isolated incident such as a plumbing accident, and will naturally occur over the life of a building structure.

UNCOUPLING

VAPOR MANAGEMENT

WATERPROOFING

LOAD DISTRIBUTION

PRODESO HEAT SYSTEM properties provide a solution for these challenges.

PRODESO HEAT MEMBRANE will compensate for relative longitudinal movement between the

Sub-floor and the tiles eliminating the major cause of tile cracking and delamination making it possible to install underfloor electric heating on wood substrates. PRODESO HEAT MEMBRANE eliminates the need for the second layer of Plywood with the exception of Natural Stone tile installations.

Wood is particular sensitive to relative moisture changes in their environment.

PRODESO HEAT

MEMBRANE unique and patented design allows for air pockets to form between the subfloor and the membrane itself. These air pockets allow for a vapor cycle to form and balance the vapor content of the subfloor assembly, increasing the mechanical and structural property of the wood subfloor.

Wood structures are particularly sensitive to variation in humidity in their environment.

PRODESO HEAT

MEMBRANE is made of polypropylene, a completely waterproof substance, that will protect the wood subfloor from water damages to ensure a long lasting installation. For areas prone to flood please follow the waterproofing instructions on page 17.

PRODESO HEAT MEMBRANE unique and patented designs allows loads to be evenly distributed from the tile covering to the subfloor. Each rounded square relief has a central cavity shaped like an inverted pyramid. When filled with thin-set this inverted pyramid becomes an incompressible structure. These cavities act like pillars in a building support structure, evenly distributing and transferring the load from the tile floor to the subfloor below.

PRODESO HEAT MEMBRANE

The uncoupling membrane is laid directly over the entire surface intended for tile installation. The heating cable is then installed in the areas where heat is desired using the channels formed between the rounded square reliefs. It’s NOT necessary to use self-leveling cement to cover and protect the wire before starting tile installation. This results in significant savings of material, time, cost and overall weight. Tile installation can start immediately after installing the heated cable.

WOOD

STRUCTURE

Joists

Single or double layer of plywood or OSB

Unmodified thin-set mortar

(ANSI A118.1)

Prodeso Heat

Membrane

Ceramic tiles or natural stone

Latex modified

Portland cement mortar

(ANSI A118.11)

Prodeso Heat

Cable

6 PROGRESS PROFILES - PRODESO HEAT SYSTEM

WOOD SUBFLOORS (OSB OR PLYWOOD)

SPACING

Joist/i-beam /floor trusses

Osb plywood layers Tile type

16.0" OC OSB OR PLYWOOD

19.2" OC OSB OR PLYWOOD

24.0" OC OSB OR PLYWOOD

Single

Single

Double

Ceramic/Porcelain

Ceramic/Porcelain

Ceramic/Porcelain

16.0" OC OSB OR PLYWOOD

19.2" OC OSB OR PLYWOOD

24.0" OC OSB OR PLYWOOD

Double

Double

Double

Natural Stone

Natural Stone

Natural Stone

Min. Tile size

2" x 2"

2" x 2"

2" x 2"

2" x 2"

2" x 2"

2" x 2"

Minimum subfloor thickness

19/32" 5/8" Nominal with 1/8" gap

23/32" or 3/4" Nominal with 1/8” gap

23/32" or 3/4" Nominal with 1/8” gap

19/32" 5/8" Nominal with 1/8" gap

23/32" or 3/4" Nominal with 1/8” gap

23/32" or 3/4" Nominal with 1/8” gap

• Minimum thickness for additional underlayment 3/8” or 10mm.

• Underlayment: APA C-C PLUGGED EXTERIOR

• Additional Underlayment is required for Joist/I-Beam /Floor Trusses spaced more than 19.2” for any type of tile.

• Additional Underlayment is required for all types of natural stone regardless of Joist/I beam/Floor trusses spacing.

• Underlayment 1/2” (13mm) or thinner: Fasteners Spacing 4” ( 102mm ) around the perimeter and 6” (152mm) in the field.

• Underlayment thicker than 1/2” (13mm): Fasteners spacing 6” (152mm ) around the perimeter and 6” in the field.

• Seams, perimeters, and corners need to be sealed with Pro Band 150/250 when water migration is expected.

• Seams, perimeters, and corners need to be sealed with Pro Band 150/250 when a waterproof installation is necessary.

WOOD SUBFLOORS (OSB OR PLYWOOD) SETTING AND GROUTING MATERIALS

Adhesive to fix PRODESO HEAT MEMBRANE to subfloor Latex Modified Portland Cement Mortar (ANSI A118.11)

Adhesive to fix Tiles to PRODESO HEAT MEMBRANE Unmodified thin-set mortar – ( ANSI A118.1 )

GROUT Polymer-modified cement grout (ANSI A118.3 A118.6, A118.7, A118.8 )

WOOD SUBFLOORS (OSB OR PLYWOOD) ANSI INSTALLATION SPECIFICATION

TILE FIXING ANSI (108.5)

GROUTING ANSI (A108.6 A108.9 A108.10)

EXPANSION JOINTS:

PRODESO HEAT does NOT eliminate the need for movement joints, including perimeter joints, within the tiled surface.

Movement joints must be installed in accordance with industry standards and norms TCNA EJ171, and TTMAC 301 MJ.

SUBSTRATE PREPARATION

Wood panels need to be properly fastened and secured to framing structure.

Wood panels need to be clean of dust, residue, wax, oil, and grease.

Wood panels need to be levelled before the installation of PRODESO HEAT MEMBRANE.

Remove all exposed nails, screws, fasteners, and debris.

PROGRESS PROFILES - PRODESO HEAT SYSTEM 7

Cement

Cement based subfloor considerations and installation details

Thermal expansion, shrinkage, and any other relative movement between a cement based screed and the tiles assembly above will subject the tile assembly to stress. This stress can ultimately cause cracking and delamination. Tile installers cannot always be certain of the curing stage of the cement based subfloor in addition cracks may be already present or develop over time.

UNCOUPLING

VAPOR MANAGEMENT

WATERPROOFING

LOAD DISTRIBUTION

PRODESO HEAT SYSTEM properties below provide a solution for these challenges.

The unique and patented design of PRODESO HEAT MEMBRANE allows for uncoupling and crack isolation to take place in the tile assembly while embedding the heating cable for radiant floor heating.

PRODESO HEAT MEMBRANE compensates for the longitudinal movement between the subfloor and the tile preventing breakage and making it possible to install underfloor electric heating even on cracked or not completely cured cement screeds.

PRODESO HEAT MEMBRANE design allows for air pockets to be formed between the subfloor and the membrane itself. Excess moisture from the substrate will find its way to these pockets and create a vapor cycle. This vapor cycle will balance the vapor content of the substrate protecting the tile surface and the substrate from undesired damages and allows for tile installation immediately after the slabs is ready for foot traffic.

PRODESO HEAT MEMBRANE is made of polypropylene, a completely waterproof substance, that will protect the cement subfloor from water damages to ensure a long lasting installation. waterproof properties has 2 major functions.

1. Slow-down the curing of the fresh cement slab preventing cracking and curling.

2. Prevent water and other substances from reaching the cement subfloor and the possible damages to the screed and the tile floor.

For areas prone to flood please follow the waterproofing instructions on page 17.

PRODESO HEAT MEMBRANE unique and patented designs allows loads to be evenly distributed from the tile covering to the subfloor. Each rounded square relief has a central cavity shaped like an inverted pyramid. When filled with thin-set this inverted pyramid becomes an incompressible structure. These cavities act like pillars in a building support structure, evenly distributing and transferring the load from the tile floor to the subfloor below.

PRODESO HEAT SYSTEM is the ideal solution to install ceramic and natural stone tiles on cement slabs even not perfectly cured or cracked.

PRODESO HEAT MEMBRANE uncoupling membrane is laid directly over the entire surface intended for tile installation, the heating cable is then installed in the areas where heat is desired using the channels formed between the rounded square reliefs. It’s

NOT necessary to use self-leveling cement based to cover/protect the wire before starting tile installation. This results in saving material/weight/time/cost. Tile installation can start immediately after installing the heated cable.

CEMENT BASED

SLAB

Cement based slab

Unmodified thin-set mortar

ANSI 118.1

Prodeso Heat

Membrane

Ceramic tiles or natural stone

Latex Modified

Portland Cement Mortar

(ANSI A118.11)

Prodeso Heat

Cable

8 PROGRESS PROFILES - PRODESO HEAT SYSTEM

Installing tiles on a cement based subfloor presents many challenges.

The following table illustrates the difference in thermal expansion between a cement subfloor and the tiles surface…

TILE SURFACE MATERIAL

Ceramic

Marble

Granite

THERMAL EXPANSION RATIO

6 times the thermal expansion of cement

7 times the thermal expansion of cement

9 times the thermal expansion of cement

CEMENT SUBFLOOR SETTING AND GROUTING MATERIALS

Adhesive to fix PRODESO HEAT MEMBRANE to subfloor Latex Modified Portland Cement Mortar (ANSI A118.11)

Adhesive to fix Tiles to PRODESO HEAT MEMBRANE

GROUT

Unmodified thin-set mortar - ( ANSI A118.1 )

Polymer-modified cement grout (ANSI A118.3 A118.6, A118.7, A118.8 )

CEMENT SUBFLOOR ANSI INSTALLATION SPECIFICATION

TILE FIXING ANSI (108.5)

GROUTING ANSI (A108.6 A108.9 A108.10)

• Cement Based Substrate must be compact and structurally sound

• Cracks and Fissure in the substrate need to present only longitudinal movement (NO VERTICAL MOVEMENT)

• Debris, dust, wax, grease, and oil residue must be removed or abraded/scored to offer better bond to the thin set.

• Minimum Tile Size 2” x 2” ( 50mm x 50mm )

• Seams, perimeters, and corners need to be sealed with Pro Band 150/250 when water migration is expected.

• Seams, perimeters, and corners need to be sealed with Pro Band 150/250 when a waterproof installation is necessary.

EXPANSION JOINTS:

PRODESO-HEAT does NOT eliminate the need for movement joints, including perimeter joints, within the tiled surface.

Movement joints must be installed in accordance with industry standards and norms TCNA EJ171, and TTMAC 301 MJ.

PROGRESS PROFILES - PRODESO HEAT SYSTEM 9

Gypsum based underlayment

PRODESO HEAT SYSTEM installed over

Gypsum based underlayment

Gypsum based underlayment or more properly anhydrite based substrate present many advantages, but also a few challenges to the tile installer. CaSO4 calcium sulfate is the component of anhydrite based underlayment and when in contact with water could lead to the formation of ettringite (hydrate calcium aluminium sulfate), which could cause an increase in volume. Anhydrite based underlayment need to be waterproofed if any exposure to water or moisture throughout the life of the installation is possible. Please follow underlayment manufacture direction for proper preparation and primer application before fixing PRODESO HEAT MEMBRANE to the anhydrite based underlayment.

Anhydrite based underlayment need to be applied to a structural subfloor (Cement based subfloor or wood based subfloor. For subfloor preperation see page 9-10).

UNCOUPLING

VAPOR MANAGEMENT

WATERPROOFING

LOAD DISTRIBUTION

PRODESO HEAT SYSTEM properties below provide a solution for these challenges.

The unique and patented design of PRODESO HEAT MEMBRANE allows for uncoupling and crack isolation to take place in the tile assembly while embedding the heating cable for radiant floor heating.

PRODESO HEAT MEMBRANE compensates for the longitudinal movement between the subfloor and the tile preventing cracking and delamination even on Gypsum based subfloor.

PRODESO HEAT MEMBRANE unique and patented design allows for air pockets to be formed between the subfloor and the membrane itself. Excess moisture from the substrate will find its way to these pockets and create a vapor cycle. This vapor cycle will balance the vapor content of the substrate protecting the tile surface and the substrate from undesired damages.

Gypsum based subfloor are particularly sensitive to variation in humidity in their environment. It is particularly important to prevent reintroducing moisture into a gypsum based substrate.

PRODESO

HEAT MEMBRANE waterproof properties prevents water and other substances from reaching the anhydrite based underlayment and the possible damages to the tile floor.

PRODESO HEAT MEMBRANE unique designs allows to evenly distribute load from the floor to the subfloor. Each rounded square relief has a central cavity shaped like an inverted pyramid. When filled with thin set this inverted pyramid become an incompressible structure that like pillars will evenly distribute and transfer the load from the tile floor to the subfloor.

GYPSUM BASED

UNDERLAYMENT

PRODESO HEAT SYSTEM is the ideal solution to install ceramic and natural stone tiles on anhydrite based underlayment.

PRODESO HEAT MEMBRANE uncoupling membrane is laid directly over the entire surface intended for tile installation, the heating cable is then installed in the areas where heat is desired using the channels formed between the rounded square reliefs.

It’s NOT necessary to use self-leveling cement based to cover/ protect the wire before starting tile installation. This results in saving material/weight/time/cost. Tile installation can start immediately after installing the heated cable.

Anhydrite underlayment

Unmodified thin-set mortar

(ANSI A118.1)

Prodeso Heat

Membrane

Ceramic tiles or natural stone

Unmodified Thin-Set

Mortar ( ANSI A118.1)

Prodeso Heat

Cable

10 PROGRESS PROFILES - PRODESO HEAT SYSTEM

ANHYDRITE BASED UNDERLAYMENT SETTING AND GROUTING MATERIALS

Adhesive to fix PRODESO HEAT MEMBRANE to subfloor Unmodified thin-set mortar - ( ANSI A118.1)

Adhesive to fix Tiles to PRODESO HEAT MEMBRANE

GROUT

Unmodified thin-set mortar - ( ANSI A118.1)

Polymer-modified cement grout (ANSI A118.3 A118.6, A118.7, A118.8)

ANHYDRITE BASED UNDERLAYMENT ANSI INSTALLATION SPECIFICATION

TILE FIXING ANSI (108.5)

GROUTING ANSI (A108.6 A108.9 A108.10)

Anhydrite based underlayment must be installed over a compact and structurally sound subfloor

• Gypsum underlayment maxium relative humidity must be 2% or less.

• Follow gypsum manufacturer installation instructions, requirements and warnings.

• Debris dust and oil residue must be removed or abraded/scored to offer better bond to the thin set.

• Minimum Tile Size 2” x 2” ( 50mm x 50mm )

• Seams, perimeters, and corners need to be sealed with Pro Band 150/250 when water migration is expected.

• Seams, perimeters, and corners need to be sealed with Pro Band 150/250 when a waterproof installation is necessary.

• PRODESO-HEAT does NOT eliminate the need for movement joints, including perimeter joints, within the tiled surface.

Movement joints must be installed in accordance with industry standards and norms TCNA EJ171, and TTMAC 301 MJ.

PROGRESS PROFILES - PRODESO HEAT SYSTEM 11

Existing vinyl floor

Indoor tile floor installation of ceramic or natural stone over an existing structurally sound vinyl floor

Vinyl floor tiles are a non-supporting layer over a supporting subfloor typically wood or cement. Supporting subfloor preparation and consideration are identical as per application without the Vinyl floor.

ADDITIONAL CONSIDERATIONS INSTALLATION OVER

EXISTING VINYL FLOOR:

• Vinyl floor needs to secured and flat over the entire surface.

• Single vinyl floor ONLY (Multiple layer of vinyl floor need to be removed)

• If foam or any cushioning mat had previously been installed, the vinyl floor needs to be removed entirely and PRODESO HEAT MEMBRANE will be fixed directly to the subfloor.

• Vinyl floor need to be clean of debris, dust, oil, grease, and wax substance.

• Outside perimeter secured vinyl flooring is NOT acceptable for direct installation of

PRODESO

HEAT MEMBRANE as it may cause undesired stress to the tile assembly.

• To adhere PRODESO HEAT MEMBRANE to existing vinyl floor please use Fast-setting latex

modified thin set. ANSI A118.4 or A118.15

PRODESO-HEAT does NOT eliminate the need for movement joints, including perimeter joints,

within the tiled surface. Movement joints must be installed in accordance with industry standards

and norms TCNA EJ171, and TTMAC 301 MJ.

OVER EXISTING VINYL FLOOR SETTING AND GROUTING MATERIALS

Adhesive to fix PRODESO HEAT MEMBRANE to subfloor Fast Setting Latex Modified thin set (ANSI A118.4 - A118.15)

Adhesive to fix Tiles to PRODESO HEAT MEMBRANE

GROUT

Unmodified thin-set mortar (ANSI A118.1)

Polymer-modified cement grout (ANSI A118.3 A118.6, A118.7, A118.8)

OVER EXISTING VINYL FLOOR ANSI INSTALLATION SPECIFICATION

TILE FIXING ANSI (108.5)

GROUTING ANSI (A108.6 A108.9 A108.10)

• Minimum Tile Size 2” x 2” ( 50mm x 50mm )

• Seams, perimeters, and corners need to be sealed with Pro

Band 150/250 when water migration is expected.

• Seams, perimeters, and corners need to be sealed with Pro

Band 150/250 when a waterproof installation is necessary.

• PRODESO-HEAT does NOT eliminate the need for movement joints, including perimeter joints, within the tiled surface.

Movement joints must be installed in accordance with industry standards and norms TCNA EJ171, and TTMAC 301 MJ.

EXISTING VINYL FLOOR

Joists

Vinyl Flooring

Unmodified thin-set mortar

(ANSI A118.1)

Prodeso Heat

Membrane

Ceramic tiles or natural stone

Fast Setting Latex

Modified thin set

(ANSI A118.4 - A118.15)

Prodeso Heat

Cable

12 PROGRESS PROFILES - PRODESO HEAT SYSTEM

Waterproofing - Movement/Expansion joints

Waterproofing

Tile surfaces (Ceramic and Natural Stone) are preferred and chosen because of their Beauty, Color, Design, Finish, and Texture. Tile surfaces are used for both floor and walls in a variety of project from residential, commercial, hospitality, institutional, health care and industrial. The use of tile has become so extensive that tile installers find themselves facing new challenge every day. Water penetration can cause extensive damages to the tile assembly itself as well the subfloor and the floors underneath the tile assemblies. Waterproofing is required under and around tubs and showers. It’s also recommended to waterproof tile assemblies that can possibly be exposed to considerable amount of water because of flooding.

Waterproofing the tile assembly is cheaper and safer than repairing water damages.

PRODESO HEAT MEMBRANE, is a Polypropylene membrane and as such is naturally waterproof. For indoor installations in areas that are prone to water damage, the corners and seams of the PRODESO HEAT MEMBRANE need to be waterproofed utilizing PROBAND 150/250 waterproofing foil tape (doublesided Polypropylene foil tape) and Unmodified Thin-Set ANSI A118.1.

Movement/Expansion joints

Any tile surface assembly cross section is made of several different materials, Tiles,

Wood, Screw, Cement, Anhydrite, Adhesives, Beams and more. All these different materials contract and expand in different ways when temperature, moisture and load change, causing stress in the overall tile assembly and ultimately cracks and possibly delamination of the tiles. Ceramic and Natural Stone Tiles are rigid and are not capable to compensate for movements. An expansion/movement joint is the part of the assembly designed to absorb the stress on the assembly by allowing movement.

PRODESO HEAT MEMBRANE does NOT eliminate the need for expansion/ movement joints, including perimeter joints, within the tiled surface. Movement joints must be installed in accordance with industry standards and norms TCNA EJ171, and

TTMAC 301 MJ.

Expansion/Movement Joint Placement

• Perimeter Joint need to be installed around the entire installation perimeter.

• Surface Joint: 16’-20’ (4.9meters - 6.1meter) in both direction.

Reduce separation by 25% if exposed to direct sunlight, heating cable or moisture.

• Surface Joint near any structural element (columns, beams, stairways), doorways.

• Structural Joint when 2 separate supporting structure meet under the tile

or the underlayment.

• Areas enclosed within joint should be a rectangle with ratio between each dimension

not to exceed 1: 1.5.

PROGRESS PROFILES - PRODESO HEAT SYSTEM 13

Installation

Preparation

• Before laying

PRODESO HEAT MEMBRANE

make sure that the substrate

is load bearing, compact, flat and free of oils, greases and waxes which could

prevent proper adhesion.

• Before laying

PRODESO HEAT MEMBRANE

make sure that the substrate

is in accordance with local and national building codes and norms.

• In case of a wood based substrate check that the panels are properly secured.

• In the case of vinyl flooring, make sure that the underlying structure is sound

and suitable for the intended use and that the vinyl flooring is securely attached.

• In case of anhydrite based underlayment verify that the moisture content

is less than 2%.

Mortar Required for fixing PRODESO HEAT MEMBRANE to substrate.

50lbs ( 22.70Kg) for 100ft2 (9.3 m2 ) using 1/4” x 3/8” (6 mm x 10 mm) square or U-notched trowel

Laying the membrane

1

Apply a compatible adhesive to the substrate using a suitable trowel.

Apply PRODESO HEAT MEMBRANE, previously cut, on the adhesive.

2 3

Press the membrane evenly with a roller or a plastic flat trowel.

Warning:

If heavy mechanical loads are foreseen

(frequent passages), it is recommended to protect the laid membrane with wooden planks to ensure proper bonding.

4

Check coverage of

PRODESO HEAT

MEMBRANE; in case of partial coverage, increase the amount of adhesive or its fluidity.

Lay the next sheet of

PRODESO HEAT

MEMBRANE making sure to align it with the previous one, without overlapping. Align the square reliefs to facilitate the installation of the heating cables.

5

14 PROGRESS PROFILES - PRODESO HEAT SYSTEM

Heating cables

Warnings

Before installation, the user and/or installer must read, understand and adhere strictly to the instructions below.

• Any deviation from the instruction below will completely void the manufacturer warranty and liability.

• The instruction below are intended to avoid personal injury and/or property damage.

• The Heating Cable must be installed by qualified personnel and all electrical connections must be performed by a qualified electrician

according to local and national building codes and norms.

• A dedicated circuit must be used to power Electric Heating Cable. Dedicated circuit breaker need to be clearly identified and labeled on

the circuit breaker panel.

• The heating cables must be grounded in accordance with local and national electric codes.

• Any modification or tampering of the heating cable will completely void the manufacturer warranty and liability.

• Do not energize the cable when on the spool; this could damage the cable and cause a fire.

• The hot section of the heating cable must be installed entirely below the flooring.

• Use heating cables only for electric underfloor tile heating.

• Compliance with following standard is mandatory CANADA: CAN/CSA-C22.2 No. 130-03 USA UL 1673 and ANSI/IEEE 515.1-2005

• Thermostat must be compliant with following standard CANADA: C22.2 No. 24-93 USA UL 873

• Lay the cables with a spacing not less than minimum spacing suggested and recommended by the cable manufacturer and in any

case not to exceed 12watt/square foot. Lower spacing may cause a fire or damage the flooring.

• NEVER use a cable designed for 110V/120V with 208V/220V/240V power.

• Never cut/shorten/modify the heating cable; it will change the electrical characteristics of the cables and possibly cause overheating

and a fire.

• Avoid bending the heating cable with a radius of curvature less than 3.5 times its outside diameter otherwise you may damage the

insolation and integrity of the wire.

• Do not lay heating cables under walls.

• The minimum application temperature of the cable is 32F or ZERO ° C.

PRODESO HEAT CABLE tests

For other heating cable manufacturers please follow each specific manufacture testing procedures.

Before installing the electric heating cable you need to perform a series of tests, to ensure that the heating cable is working and will performed as specified by the manufacturer. These tests must be repeated after installation of the cable and again after installation of the flooring. This is to ensure that the electrical heating cables has not been damaged during the installation.

To run the tests you need to have a multimeter and a megohmmeter.

Test 1: Electric heating cable resistance measurement

To measure the electrical resistance of the heating cable, you must connect a multimeter to its two power leads and set it for resistance measurement. If the measured resistance in ohms varies significantly (over 10%) from the resistance value printed on the spool, it may mean that:

a) the cable is damaged

b) the measuring instrument is not set or set incorrectly

The value of resistance in ohms measured must be logged in the “Test Log “(page 22).

Test 2: Continuity between the ground cable and the two conductors

The two power leads are separated from the ground cable by an insulator that prevents any contact with them. To verify that there is no contact between the ground cable and the two conductors, you must perform a continuity test; using a multimeter set to the function for continuity, connect the ground cable to a conductor. The measured value must be recorded in the “Test Log

“(page 22).

Test 3: Insulation resistance Measurement between power leads and ground cable

This test is designed to detect very small “holes” in the insulating layer that separates the power leads from the ground cable.

These small holes are often not detected during the continuity test because they are not necessarily short circuits between the cable conductors and ground cable. Although these holes are very small, they may cause current leakage to ground, which detected by the ground fault circuit interrupter, located in the thermostat or panel mount, thus disabling the floor heating system.

To measure the insulation resistance between the power leads and the ground cable, you must connect a megohmmeter, calibrated to 1000 V, to a cable conductor and ground cable. If there is no current leakage, insulation resistance between the power leads and the ground cable must be equal to or greater than 1 Gigaohms (1 Gigaohms = 1 G ohms = 1000 M ohms =

1000 Mega ohms). The measured value must be logged in the “Test Log” (page 22).

Floor temperature sensor testing

Connect a multimeter, calibrated to 10 K Ω + / - 2 set for current reading, to the two conductors of the floor temperature sensor and measure its resistance at room temperature. The resistance of the floor temperature sensor varies depending on the ambient temperature in an inversely proportional way or the lower the temperature, the greater the resistance of the floor temperature sensor. Record the value of the testing obtained in the “ Test Log” , making sure is in compliance with the values indicated in this manual (page 22).

PROGRESS PROFILES - PRODESO HEAT SYSTEM 15

Installation

Laying the heating cables

Warnings: Do not run the heating cables under walls, cabinets, furniture, and appliances.

1 2

Before removing the cable from the spool, you need to conduct the first set of tests required and write the values obtained in the “Test Log”

(page 22).

Insert the cold heating cable and floor temperature sensors inside a corrugated pipe from the base of the wall to the thermostat electrical box.

3

Insert the heating cable in the membrane using minimum spacing suggested by cable manufacturer.

Two reliefs spacing will result in a heating cable spacing of 2

1

/

2

” (63.5 mm)

Three reliefs spacing will result in a heating cable spacing of 3

3

/

4

” (95 mm)

Smaller spacing would cause overheating, which may damage the assembly structure.

4 5 6

Be careful not to damage the cables, particularly during installation.

Install the floor temperature sensors exactly in the center between two cables and at a distance of at least 2 ft (60cm) from the wall.

Do not cross sensor cables with heating cables.

It is recommended to install a second temperature sensor as a backup in case the primary fails throughout the life of the installation.

Record the exact position of the sensors.

After installation of heating cables, repeat all the tests and record the values obtained in the

“Test Log” (page 22).

Warnings:

• During installation of the heating cables,

leave space for the placement of the floor

temperature sensors.

• The maximum length of a straight line run

for each individual path is 3 m - 9 ft.

• The cable must be installed at a minimum

distance of 20 cm - 8 in from other heat

sources (fireplaces) and 15 cm - 6 in from

waist drains.

NEVER exceed 15 watts per square foot NEVER cross heating cables

16 PROGRESS PROFILES - PRODESO HEAT SYSTEM

Waterproofing

The following steps are required only in case waterproofing is necessary:

Warning: Be careful not to damage the heating cable with the notched trowel while applying the adhesive to the membrane.

1 2 3

Apply Unmodified Thin-Set ANSI A118.1 along the joints between two adjacent sheets with the flat side of the trowel, 4” (100mm) each side of the joint), making sure to fill the cavities of the membrane, leaving a thin layer of adhesive on top of the reliefs.

Fix PROBAND 150/250 tape to Unmodified

Thin-Set ANSI A118.1 following the joint. Using a flat trowel apply strong and even pressure along PROBAND 150/250 to ensure sealing.

Smooth over to avoiding and eliminate bends and folds.

Apply the Unmodified Thin-Set ANSI A118.1 to the corner (wall and floor) with a 3/16”X 3/16”

(4 mm x 4 mm) notched trowel to a width of about 4” (100mm).

4

5 6

Fix

PROBAND 150/250 tape to Unmodified

Thin-Set ANSI A118.1 following the perimeter joint. Inside and outside corners can be cut from

PROBAND 150/250 tape, but pre-cut corners

(

PRBI and PRBE) are also available on page 20.

Using a flat trowel apply strong and even pressure along

PROBAND 150/250 to ensure sealing.

Apply

Unmodified Thin-Set ANSI A118.1 along the perimeter floor with the flat side of the trowel, to a width of about 4” (100mm).

Particular attention must be paid to fill the cavities of the Prodeso Heat membrane and leaving a thin layer of adhesive on top of the reliefs. Apply the

Unmodified Thin-Set ANSI

A118.1 to the perimeter wall with a 3/16”X 3/16”

(4 mm x 4 mm ) notched trowel to a width of about 4” (100mm).

Fix

PROBAND 150/250 tape to Unmodified

Thin-Set ANSI A118.1 following the perimeter joint.

Warning:

When using PROBAND 150/250, PROBAND

FIX is to be used in the place of Unmodified

Thin-Set ANSI A118.1 for non-cement based substrates.

7

Using a flat trowel apply strong and even pressure along PROBAND 150/250 to ensure sealing. Smooth over to avoiding and eliminate bends and folds.

PROGRESS PROFILES - PRODESO HEAT SYSTEM 17

Installation

Laying the tiles

Warning: Be careful while applying the adhesive on the membrane not to damage the heating cable with the flat/notched trowel.

Mortar Required for fixing Tile to PRODESO HEAT MEMBRANE.

50lbs (22.70Kg) for 40/50 ft2 (3.7 m2 / 4.6 m2) using 1/4” x 3/8” (6 mm x 10 mm) square or U-Notched trowel

50lbs (22.70Kg) for 30/40 ft2 (2.8 f2/ 3.7m2) using .” X .” (12.5mmX12.5mm ) square or U-Notched trowel.

1 2

Tiles can be immediately laid after the installation of the heating cables is completed. Using the flat side of the trowel fill with Unmodified thin set mortar (ANSI A118.1) the cavities of the membrane. Apply additional of the same mortar with a notched trowel over according to the tile size.

Carefully lay the tiles and press them on the layer of adhesive. If a layer of skin has formed, remove it and apply it again.

Occasionally remove and check some tiles, to ensure full back coverage.

3

Warning:

Full back coverage may vary depending on the consistency of the adhesive, the angle of inclination of the notched trowel and the flatness of the substrate. If full back coverage is not achieved, remove the tile and apply new adhesive paying attention to the consistency of the Thin set and its application. In case of large format tiles 12”12” and larger is recommended to back butter each tile before laying them.

After laying the tiles, repeat all the tests and record the values obtained in the “Test Log”

(page 22).

4

18 PROGRESS PROFILES - PRODESO HEAT SYSTEM

Mortar Required for fixing Tile to PRODESO HEAT MEMBRANE.

50lbs (22.70Kg) for 40/50 ft2 (3.7 m2 / 4.6 m2) using 1/4” x 3/8” (6 mm x 10 mm) square or U-Notched trowel

50lbs (22.70Kg) for 30/40 ft2 (2.8 f2/ 3.7m2) using .” X .” (12.5mmX12.5mm ) square or U-Notched trowel.

Products

PRODESO HEAT

MEMBRANE

Is a polypropylene membrane, with rounded square shaped reliefs, that form channels specially designed to embed and hold the electric heating cable. The down facing side has a polypropylene thermo-welded woven layer to increase its bond to the subfloor.

• Flexible heating zone selection

• Cost and time saving installation

• Waterproofing

• Uncoupling

• Vapor management

• Support load distribution

• Small height increase 5.5mm (1/4 inch)

WARNING: Store in a cool and dry place avoiding direct sunlight and heat sources. Read the technical details prior to application; in the case of special applications, we recommend you consult our technical department.

UNCOUPLING WATERPROOFING MEMBRANE FOR ELECTRIC HEATING - 15/5 M2

PRODESO HEAT MEMBRANE

Article

Width. roll

L x H ML

Tot. m2

PDESH 151/A PRODESO HEAT MEMBRANE 1 m x 15 m

1 m x 5 m

15

5

PDESH 051/A PRODESO HEAT MEMBRANE

*

= Upon request

*

PRODESO HEAT CABLE

Is an electric heating cable especially designed for

Prodeso Heat Membrane. Cable separation of 3 3/4”.

PRODESO HEAT CABLE

Article Length Area

PDHCB 120 16

PDHCB 120 27

PDHCB 120 32

PDHCB 120 38

PDHCB 120 43

PDHCB 120 64

PDHCB 120 83

PDHCB 120 92

52,9 ft - 17,0 m

88,2 ft - 26,9 m

105,8 ft - 32,2 m

124,1 ft - 37,8 m

141,1 ft - 43,0 m

212,9 ft - 64,9 m

275,5 ft - 82,0 m

303,0 ft - 92,0 m

120 Volts

16,0 ft

32,0 ft

42,6 ft

64,4 ft

2

- 6,0 m

2

83,3 ft

2

2

2

2

- 1, 5 m

26,7 ft

2

- 2, 5 m

2

- 3,0 m

- 4,0 m

- 7,7 m

2

37,5 ft

2

- 3, 5 m

2

2

2

91,7 ft

2

- 8, 5 m

2

2

PDHCB 120 102 336,9 ft - 102,0 m 101,9 ft

2

- 9, 5 m

2

PDHCB 240 21

PDHCB 240 32

PDHCB 240 53

PDHCB 240 75

70,6 ft - 21,5 m

105,8 ft - 32,2 m

176,3 ft - 53,7 m

248,2 ft - 75,7 m

240 Volts

21,4 ft

53,3 ft

2

2

- 2,0 m

32,0 ft

2

- 3,0 m

2

- 5,0 m

75,1 ft

2

- 7,0 m

2

2

2

PDHCB 240 129 425,8 ft - 129,8 m 128,8 ft

2

- 12,0 m

2

PDHCB 240 167 551,0 ft - 167,9 m 166,7 ft

2

- 15,5 m

2

PDHCB 240 204 673,8 ft - 205,4 m 203,8 ft

2

- 18,9 m

2

PDHCB 240 269 816,2 ft - 249,0 m 247,1 ft

2

- 22,9 m

2

Total

Power

203 W

338 W

405 W

475 W

540 W

815 W

1055 W

1160 W

1290 W

270 W

405 W

675 W

950 W

1630 W

2110 W

2580 W

3240 W

Average Power

W/ft

2

- W/m

2

Ampere

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

4,5

6,8

8,8

9,7

10,7

1,7

2,8

3,4

4,0

6,8

8,8

10,7

13,1

1,1

1,7

2,8

4,0

PRODESO HEAT

THERMOSTAT KIT

Consists of a programmable digital thermostat, recessed box, corrugated tube, metal cap for temperature sensor and two floor temperature sensors.

PRODESO HEAT THERMOSTAT KIT

Article

PDHTSK 230V PRODESO HEAT THERMOSTAT KIT INCLUDING ACCSSORIES

PROGRESS PROFILES - PRODESO HEAT SYSTEM 19

Products

PROBAND 150/250

ROLLS IN HDPE E PP

PROBAND 150/250 is a waterproof polyethylene tape with a non woven fleece sheet on both sides, which ensures adhesion.

AREA OF USE

• Use

Construction of perimeter joints and between adjacent sheets of

PRODESO HEAT SYSTEM.

• Don’t use

On bituminous coverings, for waterproofing walking and exposed surfaces,on inverted roof insulation made of insulating panels or lightened screeds. With adhesives containing solvents.

WARNING

Store in a cool and dry place avoiding direct sunlight and heat sources.

Read the technical details prior to application; in the case of special applications, we recommend you consult our technical department.

Interior and exterior preformed polyethylene corners with a non woven sheet on both sides, which ensures adhesion.

Rolls in HDPE and PP – thickness 0,4 mm - 1/64” in

PROBAND 150/250

Article Roll width H mm x L LM

PRBPE 1505

PRBPE 1530

150 x 5

150 x 30

PRBPE 2505

PRBPE 2530

250 x 5

250 x 30

H in. x L ft.

6” x 16’ 5”

6” x 98’ 5”

10” x 16’ 5”

10” x 98’ 5”

Rolls/Pack

10

6

5

3

PREFORMED CORNERS

Interior and exterior preformed polyethylene corners with a non woven sheet on both sides, which ensures adhesion.

AREA OF USE

Use

Internal and external for

• Don’t use

PRODESO HEAT SYSTEM.

On bituminous coverings, for waterproofing walking and exposed surfaces, on inverted roof insulation made of insulating panels or lightened screeds. With adhesives containing solvents.

WARNING

Store in a cool and dry place avoiding direct sunlight and heat sources.

Read the technical details prior to application; in the case of special applications, we recommend you consult our technical department.

Preformed corners in HDPE and PP thickness 0,40 mm

PREFORMED CORNERS

Article H x L mm

PRBI (internal)

PRBE (external)

150 X 150

150 X 150

H x L in.

6” x 6”

6” x 6”

Pcs/Pack

10

10

EXTERNAL CORNER

INTERNAL CORNER

20 PROGRESS PROFILES - PRODESO HEAT SYSTEM

PROBAND BU

BUTYLE TAPE

Is a butyl adhesive tape coated on one side with a woven polypropylene sheet, alkali resistant which ensures high adhesion.

AREA OF USE

• Use

Construction of perimeter joints with the

PRODESO HEAT SYSTEM in case of non cement based supports.

• Don’t use

On dirty, loose and wet surfaces.

WARNING

Store in a cool and dry place avoiding direct sunlight and heat sources. Read the technical details prior to application; in the case of special applications, we recommend you consult our technical department.

Thickness:

1 mm - 1/32” in.

PROBAND BU

Article H: Roll

(mm)

L: Roll

(LM)

PRBBU 7515 75 15

Roll

H in. x L ft

3” x 49’ 5”

Rolls/

Pack

2

PROBAND FIX

WATERPROOF MONOCOMPONENT SEALANT

PROBAND FIX

is a moisture-curing sealant for waterproof sealing with high adhesion and elasticity for PROBAND 150 / 250 tape with non cement based supports.

AREA OF USE

• Use

Balconies, terraces, bathrooms, kitchens, saunas, swimming pools and exterior surfaces.

Suggestions for installation:

Cement surfaces must be cleaned from dust oil and grease, dry and free from any rising moisture, free of loose or imperfectly fixed residues such as cement, lime and paint, which must be totally removed. In case of contact with eyes, rinse immediately with water and consult a doctor.

Avoid contact with skin and keep out of reach of children.

WARNING

Store in a cool and dry place avoiding direct sunlight and heat sources. Read the technical details prior to application; in the case of special applications, we recommend you consult our technical department.

Pack of 12 cartridges

PROBAND FIX

Article Colour

PRBFXB White

PRBFXG Grey

B - White G - Grey

Cartridge

290

290

PROBAND FIX

Technical data

Appearance

Temperature range for application

Temperature range

Curing

Commissioning

White or gray thixotropic paste

+ 5 °C / + 40 °C

- 40 °C / + 90 °C

≈ 2 MM / 24 H

≈ 7 Days

PROGRESS PROFILES - PRODESO HEAT SYSTEM 21

Test Log

Register of tests carried out on the heating cable.

Project:

Authorised Installer:

Identification N° Manufacturer’s values

Resistance measurement of the electric heating cable

Before installation

Date of installation:

Date of start-up:

After cable installation After tile installation

Two conductors and ground braid continuity test

Infinity (I) or overload (OL)

Insulation resistance test between conductor cables and ground braid

Equal to or greater than

1 Gigaohms*

Floor temperature sensors test

Temperature

20

25

30

°C

10

15

68

77

86

°F

50

59

Resistance

Kohms

18

14,7

12,1

10

8,3

PRODESO HEAT CABLE

Article Length

PDHCB 120 16

PDHCB 120 27

PDHCB 120 32

PDHCB 120 38

PDHCB 120 43

PDHCB 120 64

PDHCB 120 83

PDHCB 120 92

PDHCB 120 102

PDHCB 240 21

PDHCB 240 32

PDHCB 240 53

PDHCB 240 75

PDHCB 240 129

PDHCB 240 167

PDHCB 240 204

PDHCB 240 269

Area

120 Volts

52,9 ft - 17,0 m

88,2 ft - 26,9 m

105,8 ft - 32,2 m

124,1 ft - 37,8 m

16,0 ft

26,7 ft

32,0 ft

37,5 ft

2

2

2

2

- 1, 5 m

- 2, 5 m

- 3,0 m

- 3, 5 m

2

2

2

2

141,1 ft - 43,0 m

212,9 ft - 64,9 m

275,5 ft - 82,0 m

303,0 ft - 92,0 m

42,6 ft

64,4 ft

83,3 ft

91,7 ft 2

2

2

2

- 4,0 m

- 6,0 m

- 7,7 m

- 8, 5 m

2

2

2

2

336,9 ft - 102,0 m 101,9 ft 2 - 9, 5 m 2

240 Volts

70,6 ft - 21,5 m

105,8 ft - 32,2 m

176,3 ft - 53,7 m

248,2 ft - 75,7 m

21,4 ft 2 - 2,0 m 2

32,0 ft 2 - 3,0 m 2

53,3 ft 2 - 5,0 m 2

75,1 ft 2 - 7,0 m 2

425,8 ft - 129,8 m 128,8 ft 2 - 12,0 m 2

551,0 ft - 167,9 m 166,7 ft 2 - 15,5 m 2

673,8 ft - 205,4 m 203,8 ft 2 - 18,9 m 2

816,2 ft - 249,0 m 247,1 ft 2 - 22,9 m 2

Total

Power

203 W

338 W

405 W

475 W

540 W

815 W

1055 W

1160 W

1290 W

270 W

405 W

675 W

950 W

1630 W

2110 W

2580 W

3240 W

Average Power

W/ft

2

- W/m

2

Ampere

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

12,7 - 136,3

4,5

6,8

8,8

9,7

10,7

1,7

2,8

3,4

4,0

6,8

8,8

10,7

13,1

1,1

1,7

2,8

4,0

22 PROGRESS PROFILES - PRODESO HEAT SYSTEM

Certified installer:

Warranty

Progress Profiles Prodeso Heat System 10 Year Limited Warranty

COVERAGE AND CONDITIONS: Subject to the conditions and limitations as stated hereinafter, Progress Profiles* warrants that Progress Profiles – PRODESO HEAT

SYSTEM (The “Product”)** will meet all composition and performance criteria for a period of ten (10) years from the date of purchase only when the Product is used and installed in accordance with the terms and conditions of the PRODESO HEAT Installation Handbook and industry standard guidelines that are not in conflict with the

Handbook in effect at the time of installation. Efflorescence is a natural occurrence with cementations setting materials and is therefore not considered to be a defective condition and is not covered by this warranty. Tile/Grout cracking due to structural movement or failure, excessive deflection or other failure in the substrate is also not covered by this warranty. Progress Profiles will consider this warranty null and void and will refuse any claim if:

1. Unsuitable/faulty/damaged building materials were used for the any part of the overall construction and installation. It is the responsibility of owner/builders/installers to select suitable and appropriate building materials in accordance with all state and local building codes.

2. Supporting structure and/or subfloor fail.

3. ANY PRODESO HEAT Component was subjected to misuse/abuse or was improperly stored or maintained.

4. ANY Prodeso Heat Component was NOT installed in accordance with this manual and local/state codes.

5. ANY PRODESO HEAT Component was altered or modified.

6. ANY PRODESO HEAT Component was used in an application other than that for which the product was intended, including outdoor applications.

7. If the identifying tag on the heating cable has been removed.

8. If the owner fail to present a proof of purchase with cost of installation and date.

9. If owner fails to identify all installers of allegedly failed assembly.

10. If the owner fails to present an accurate and complete test log (Heating Cable and Temperature Sensor) completed by the installer at time of installation.

RESOLUTION: If the Product fails to meet this warranty Progress Profiles, at its election may choose to a) Reinstall or replace the failed portion of the floor covering assembly. b) Pay an amount not to exceed the original square foot cost of the installation of the floor covering assembly verified to be defective. Floor covering assembly is defined to include all Prodeso Heat materials (e.g. matting and heating cables), non-reusable flooring surfaces, and the appropriate setting and grouting materials.

Due to conditions beyond the control of PROGRESS PROFILES, PROGRESS PROFILES cannot guarantee or warrant an exact match to the remaining/existing tile, stone, or other covering materials used in the installation. (e.g., color and shade availability, discontinuation, normal wear and tear of the tile covering). In such events, at

PROGRESS PROFILES election, substantially similar materials may be substituted. This warranty does not cover scratches, dents, corrosion or discoloration caused by excessive heat, chemical cleaning products and abrasive agents. This warranty does not cover the cost of disconnection or installation.

DISCLAIMER: THE ABOVE WARRANTY CONSTITUTES PROGRESS PROFILES EXCLUSIVE WARRANTY. THERE ARE NO OTHER WARRANTIES, EXPRESS OR

IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. PROGRESS PROFILES EXCLUDES AND IN NO

EVENT SHALL HAVE ANY LIABILITY FOR LOST PROFITS OR ANY OTHER INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE, EXEMPLARY, OR CONSEQUENTIAL

DAMAGES, ARISING OUT OF OR OTHERWISE CONNECTED TO FAILURE OF THE PRODUCTS OR FLOORING SYSTEM OF WHICH THEY ARE PART, NOR MISUSE

OF THE PRODUCTS OR FLOORING SYSTEM, REGARDLESS OF ANY STRICT LIABILITY, ACTIVE OR PASSIVE NEGLIGENCE OF PROGRESS PROFILES, AND

REGARDLESS OF THE LEGAL THEORY (CONTRACT OR TORT OR EXTRA CONTRACTUAL OR OTHER), NOR FROM ACTS OF WAR, TERRORISM, OVERVOLTAGE,

FAULTY AND NEGLIGENT PENETRATION OF THE SYSTEM, FIRES, EXPLOSIONS, ACTS OF GOD, INTENTIONAL ACTS OF DESTRUCTION OR ANY LOSSES DUE

TO STRUCTURAL FAILURE OR ATHER CAUSES UNRELATED TO THE PRODUCTS OR DELAYS, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES.

THIS WARRANTY IS GIVEN IN LIEU OF ANY OTHER WARRANTY EXPRESSED OR IMPLIED. THE REMEDIES CONTAINED HEREIN ARE THE ONLY REMEDIES

AVAILABLE FOR BREACH THIS WARRANTY. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS; SOME STATES AND PROVINCES DO NOT ALLOW

DISCLAIMERS OR OTHER RESTRICTIONS OF IMPLIED WARRANTIES SO SOME OF THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

TRANSFERABILITY: This limited warranty extends ONLY to the original end-user ( OWNER ) and is not assignable or transferable, unless approved in writing by an

Officer of Progress Profiles.

MODIFICATION TO WARRANTY: The above warranty may not be changed or modified except in writing, signed by an officer of PROGRESS PROFILES. This written warranty is your exclusive warranty from PROGRESS PROFILES and represents the SOLE REMEDY available to any owner of PRODESO HEAT SYSTEM. This limited warranty is effective for PROGRESS PROFILES PRODESO HEAT SYSTEM installed after January 1, 2014.

CLAIMS ON THIS LIMITED WARRANTY: TUnder this Limited Warranty, the Owner/End User must notify in writing of a claim Progress Profiles within 30 days of any alleged defect in the Product covered by this Limited Warranty. Original Owner/End User must provide proof of purchase including cost of installation and the contact information of all installers in order for the claim to be accepted. Progress Profiles reserves the rights to inspect verify proper installation as per this handbook and alleged failed and defective conditions.

APPROVED HEATING CABLES: PRODESO HEAT MEMBRANE can be used with other heating cables NOT manufactured by Progress Profiles. Please contact

Progress Profiles at [email protected] or visit our website www.progressprofiles.com for an updated list of approved heating cables and related manufacturers.

RESTRICTIONS FOR APPROVED HEATING CABLES:

ALL approved Heating Cables MUST be installed as per cable manufacturer instructions non in conflict with the latest version of the PRODESO HEAT SYSTEM

HANDBOOK. Compliance with following standards is mandatory CANADA: CAN/CSA-C22.2 No. 130-03 USA UL 1673 and ANSI/IEEE 515.1-2005

Thermostats must be compliant with following standards CANADA: C22.2 No. 24-93 USA UL 873

Use 2 ½” or 3 ¾” wire spacing. Do NOT exceed under any circumstances 15watt/square foot maximum. Maximum continuous operating wire temperature not to exceed

38.8°C / 102°F. INDOOR APPLICATIONS ONLY

Progress Profiles PRODESO HEAT MEMBRANE 10 Year Limited Warranty.

WARRANTY FOR PRODESO HEAT MEMBRANE INSTALLED WITH APPROVED HEATING CABLES ( NON PRODESO HEAT CABLE ).

In case a owner/installer decides to install PRODESO HEAT MEMBRANE with an heating cable other that PRODESO HEAT CABLE, Progress Profiles LIMITED

WARRANTY for the PRODESO HEAT SYSTEM above will apply only to the PRODESO HEAT MEMBRANE properties and performance of, UNCOUPLING, VAPOR

MANAGEMENT, WATERPROOFING and LOAD DISTRIBUTION. At NO time and under NO circumstances Progress Profiles will be liable or responsible for any failures caused by the electrical heat cable itself or any components sold by another manufacturer other than Progress Profiles.

All North America Claims shall be sent to:

Progress Profiles America Inc.

Attention: Warranty Claim Department

4 Middlebury Boulevard (Unit 14)

Randolph, New Jersey 07869

U.S.A

*For the purpose of this warranty

Progress Profiles

shall provide the warranty for the Product for end users located in the United States and in Canada. This warranty is limited to sales and use of the Product in the United States and Canada.

**Progress Profiles - PRODESO HEAT SYSTEM (the “Product”) is defined to include: PRODESO HEAT MEMBRANE, PRODESO HEAT CABLE, PRODESO HEAT

THERMOSTAT KIT.

PROGRESS PROFILES - PRODESO HEAT SYSTEM 23

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
