ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
1
2
IP CAMERA
Page 4
™ FW-1130D/DW
™ FW-1131DV
™ FW-1161SE
™ FW-1173DS
™ FW-1173MM
™ FW-1175DS
™ FW-1170
™ FW-1177DE
VIDEO ENCODER Box type IP camera
Vandal Dome Outdoor
PTZ Vandal Outdoor
H.264 Box type IP camera
H.264 Mega Pixel camera
H.264 Vandal Dome outdoor
H.264 VGA / PIR camera
H.264 PTZ WDR outdoor
Page 20
™ FW-3150
™ FW-3450
™ FW-3850
™ FW-3170
VIDEO RECORDER
1CH Video I/O – Audio / Control
4CH Video I/O – Audio / Control
8CH Video I/O – Audio / Control
H.264 1CH Video I/O
Page 28
™ FW-5050
™ FW-5170
™ FW-eNVR
™ FW-MANAGER
HYBRID : Video encoder + Recorder 8CH Network Video Recorder
8CH Network Video Recorder
(High Performance)
Raid Mass storage Unit
PC-Based Recorder software
Page 36
™ FW-5450
™ FW-5850
CMS : CENTRAL MANAGEMENT SOLUTIONS
™ CMS-iSense
4CH / 12CH Hybrid recorder
8CH / 8CH Hybrid recorder
Page 40
Central Management Software
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
3
Network camera for professional IP surveillance
Network Camera
FW-1130D with
fixed 4mm Lens
Model No : FW-1130(D/W/DW)
Superior Day / Night function
Optional (Sony EXview HAD CCD (D&N - 0.003lux, F1.2))
Wireless LAN
Optional (Built-in wireless LAN interface; IEEE 802.11b/g)
POE (Power Over Ethernet)
Built-in Power Over Ethernet; IEEE 802.3af
M-JPEG / MPEG-4 with 2 way audio
FW-1130DW with auto IRIS
and vari-focal Lens
M-JPEG/MPEG-4 simultaneous dual stream
Synchronized 2 way audio is supported with M-JPEG and MPEG-4
1ch Video-output / 1ch Audio-input / 1ch Audio-output
Full frame rate
Up to 30/25 fps (NTSC/PAL) @ 4CIF, simplex
Channel based user permission
Channel based multi level protection for live-cast,
PTZ, DO and audio
Top level event services
Easy installation and management
Provided with installation wizard application
Full web based management
Rear view
Shipped without lens
** User can adopt any lens which has CS mount
** Supports Auto-Iris lens
4
Integrated Network Video since 1999
Supports service triggered by various events
Multi-window motion detection
Pre- and post-image alarm buffering
Video
compression
Audio
compression
ADPCM IMA 8Kbps
Analog
channels
1ch Video-output (loop-through)
1ch Audio input / 1ch audio output
Compression
Level
6 levels (low compression / highest / high / normal / low / lowest)
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
Live Casting
Up to 30 fps @ 4CIF when simplex
Network
through-put
control
Frame rate control / Bandwidth control / CBR
Audio support
Full duplex live audio
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ
protocols from Pelco, Vicon, Kalatel,Sony, Panasonic, Canon,
Honeywell and etc
UART support
Alarm
management
System
integration
features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback & PTZ
[Service]
Image upload service / notification service
Installation
and
maintenance
Configuration : installation wizard, HTTP, telnet and console
Upgrade firmware : HTTP, telnet & ftp (Firmware is available at
www.flexwatch.com)
Misc.
Transmit serial input data with video
Different time zones are supported
Date and time can be synchronized with an external NTP server
Live-cast for up to 32 clients
System
hardware
32bit RISC Processor / Embeded Linux / 32MByte SDRAM / 8MByte
Flash
DC 12V/500mA, 32~122 F (0~50 C), 20~80% RH
Approvals
MIC, FCC, CE, RoHS
Accessories
CD with installation wizard / User's manual / Quick installation
manual / SMPS DC 12V(800mA) [AC100~240V, 50/60Hz] / Power
cord / LAN cable / Mounting brackets / Connector kit
Connectors
1 composite output (75 ohm/Hi-Z)
10/100 BaseT Ethernet (auto-sensing)
1 opto-coupled inputs or 1 digital inputs (NC/NO selectable)
1 relay outputs
1 audio input / 1 audio output
Reset button for factory default
2 serial port (COM: RS-232, AUX: RS-232 or RS-485)
Image sensor
1/3” 410K Sony Super HAD CCD
1/3” 410K Sony EXview HAD CCD (Optional)
Resolution: 480 TV Lines
S/N ratio: 46dB or more (AGC OFF)
Electronic shutter speed :
1/60 ~ 1/100,000 sec (NTSC)
1/50 ~ 1/100,000 sec (PAL)
White Balance: ATW
Lens
Shipped without lens
CS mount
Minimum
illumination
Color: 0.5 Lux (F1.2, Super HAD) / 0.3 Lux (F1.2, EXview)
B*W: 0.2 Lux (F1.2, Super HAD) / 0.003 Lux (F1.2, EXview)
settings
BLC (Back Light Compensation)
AGC (Auto Gain Control)
ELC (Electronic Level Control)
FLK (Flicker Less)
Wireless
interface
IEEE 802.11b/g Built-in wireless (optional)
Power Over
Ethernet
IEEE 802.3af Built-in POE
Dimension
85(W) x 150(D) x 50(H) (in mm)
Weight
380g (0.84 lbs)
M-JPEG / MPEG-4 (simultaneous dual stream)
Console
By-pass command to control UART device
X10 device command to control device over power line
Modem (Support PSTN, ISDN or GSM)
[Trigger]
Video loss / Video recovered / Motion detection (144 area) / 1 alarm
input / Boot finished / Serial input / Schedule / Trigger combination is
possible
[Service]
Image holding service (Max 2.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm output
Dynamic IP
support
IP notification by e-mail
AOIPTM (Always On-IP, http://www.aoip.co.kr)
Security
Channel based user password protection for Live-cast, PTZ, Alarmoutput and Audio
Software
(default Web
interface)
Live-cast and PTZ control through Web browser with audio
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later /
Pentium III 500 MHz or above or equivalent AMD / 64MByte RAM or
above)
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128 & 256 ch (sold separately, 9ch
freeware available)
Full-featured PC NVR with matrix functionality
(Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above
/ 256MByte RAM or above / 64MByte video memory or above /
CDROM )
5
Vari-focal Day/Night 3-Axis Vandal Dome IP Camera
Network Dome Camera
Model No : FW-1131DV
Front view
Vandal proof / weather proof
IP66-rated
1000 kg (2200 lbs) impact-resident casing
Polycarbonate clear dome glass
Superior Day / Night function
Sony EXview HAD CCD (D&N - 0.003lux, F1.2)
POE (Power Over Ethernet)
Built-in Power Over Ethernet; IEEE 802.3af
3-Axis
Viewing angles are available regardless
of where the camera is installed
M-JPEG / MPEG-4 with 2 way audio
M-JPEG/MPEG-4 simultaneous dual stream
Synchronized 2 way audio is supported with M-JPEG and MPEG-4
1ch Video-output / 1ch Audio-input / 1ch Audio-output
Bottom view
Full frame rate
Up to 30/25 fps (NTSC/PAL) @ 4CIF, simplex
Channel based user permission
Channel based multi level protection for live-cast,
PTZ, DO and audio
Supports service triggered by various events
Multi-window motion detection
Pre- and post-image alarm buffering
Easy installation and management
Provided with installation wizard application
Full web based management
We are providing several type of brackets (optional).
Flush mount
Wall mount
Wall mount
** Color and shape may change without user s consent.
6
Integrated Network Video since 1999
Top level event services
Video
compression
Audio
compression
ADPCM IMA 8Kbps
Analog
channels
1ch Video-output (loop-through)
1ch Audio input / 1ch audio output
Compression
Level
6 levels (low compression / highest / high / normal / low / lowest)
Resolution
Live Casting
System
integration
features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback & PTZ
[Service]
Image upload service / notification service
Installation
and
maintenance
Configuration : installation wizard, HTTP, telnet and console
Upgrade firmware : HTTP, telnet & ftp (Firmware is available at
www.flexwatch.com)
Misc.
Transmit serial input data with video
Different time zones are supported
Date and time can be synchronized with an external NTP server
Live-cast for up to 32 clients
System
hardware
32bit RISC Processor / Embeded Linux / 32MByte SDRAM / 8MByte
Flash
DC 12V/500mA, 32~122 F (0~50 C), 20~80% RH
Approvals
MIC, FCC, CE, RoHS
Accessories
CD with installation wizard / User's manual / Quick installation
manual / SMPS DC 12V(800mA) [AC100~240V, 50/60Hz] / Power
cord / LAN cable / Mounting brackets / Connector kit
Connectors
1 composite output (75 ohm/Hi-Z)
10/100 BaseT Ethernet (auto-sensing)
1 opto-coupled inputs or 1 digital inputs (NC/NO selectable)
1 relay outputs
1 audio input / 1 audio output
Reset button for factory default
2 serial port (COM: RS-232, AUX: RS-232 or R
Image sensor
1/3” 410K Sony EXview HAD CCD
Resolution: 480 TV Lines
S/N ratio: 46dB or more (AGC OFF)
Electronic shutter speed :
1/60 ~ 1/100,000 sec (NTSC)
1/50 ~ 1/100,000 sec (PAL)
White Balance: ATW
Lens
Auto IRIS & Vari-focal 3.8 - 9.5 mm
Minimum
illumination
Color: 0.5 Lux (F1.2)
B*W: 0.005 Lux (F1.2)
M-JPEG / MPEG-4 (simultaneous dual stream)
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
Up to 30 fps @ 4CIF when simplex
Network
through-put
control
Frame rate control / Bandwidth control / CBR
Audio support
Full duplex live audio
PTZ support
Not supported (fixed dome type)
UART support
Console
By-pass command to control UART device
X10 device command to control device over power line
Modem (Support PSTN, ISDN or GSM)
Alarm
management
[Trigger]
Video loss / Video recovered / Motion detection (144 area) / 1 alarm
input / Boot finished / Serial input / Schedule / Trigger combination is
possible
[Service]
Image holding service (Max 2.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm output
Dynamic IP
support
IP notification by e-mail
AOIPTM (Always On-IP, http://www.aoip.co.kr)
Security
Channel based user password protection for Live-cast, PTZ, Alarmoutput and Audio
settings
BLC (Back Light Compensation)
AGC (Auto Gain Control)
ELC (Electronic Level Control)
FLK (Flicker Less)
Software
(default Web
interface)
Live-cast and PTZ control through Web browser with audio
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium
III 500 MHz or above or equivalent AMD / 64MByte RAM or above)
Casing
IP66-rated, 1000 kg (2200 lbs) impact-resident casing
Polycarbonate clear dome glass
Metal base
Supports 16, 25, 36, 64, 128 & 256 ch (sold separately, 9ch freeware
available)
Full-featured PC NVR with matrix functionality
(Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above
/ 256MByte RAM or above / 64MByte video memory or above /
CDROM
Power Over
Ethernet
IEEE 802.3af Built-in POE
Software
(FW-Manager
3.xx)
Dimension
145(D) x 120(H) (in mm)
Weight
970g (2.14 lbs)
7
High-speed PTZ dome camera in IP66 outdoor housing
Network Dome Camera
Model No : FW-1161SE
Dust- & Drip-proof
IP66 approvals
Tempered aluminum housing with clear vandal-resident bubble
300x Zoom
30x auto-focus optical zoom / 10x digital zoom / Smart zoom
High performance Pan/Tilt
Pan/Tilt angle: 360O (endless) / 92O (auto flip)
Max speed: Pan-360O/sec / Tilt-200O/sec @preset mode
Preset: 250 presets, swing, group
0.0007 lux
0.4 lux, 0.1 lux(D&N), 0.0007 lux(DSS) / F1.6
DIS (Digital Image Stabilizer)
DIS reduces the variation on the image caused by wind or tremor
M-JPEG / MPEG-4 with 2 way audio
M-JPEG/MPEG-4 simultaneous dual stream
Synchronized 2 way audio is supported with M-JPEG and MPEG-4
1ch Audio-input / 1ch Audio-output
Full frame rate
Up to 30/25 fps (NTSC/PAL) @ 4CIF, simplex
Channel based user permission
Top level event services
Supports service triggered by various events
Multi-window motion detection
Pre- and post-image alarm buffering
Easy installation and management
Provided with installation wizard application
Full web based management
Other dome features
DSS (Digital Slow Shutter)
ICR (Day & Night)
BLC (Back Light Compensation)
SSNR (Noise Reduction at Low Light)
8
Integrated Network Video since 1999
Channel based multi level protection for live-cast,
PTZ, DO and audio
Video
compression
System
integration
features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback & PTZ
[Service]
Image upload service / notification service
Installation
and
maintenance
Configuration : installation wizard, HTTP, telnet and console
Upgrade firmware : HTTP, telnet & ftp (Firmware is available at
www.flexwatch.com)
Misc.
Transmit serial input data with video
Different time zones are supported
Date and time can be synchronized with an external NTP server
System
hardware
32bit RISC Processor / Embeded Linux / 32MByte SDRAM / 8MByte
Flash
AC 24V/1.0A, 32~122 F (0~50 C), 20~80% RH
Approvals
MIC, FCC, CE, RoHS, IP66
Accessories
CD with installation wizard / User's manual / Quick installation
manual / Transformer AC 24V(1.5A) [AC100~240V, 50/60Hz] /
Power cord / LAN cable / Mounting brackets / Connector kit
Connectors
10/100 BaseT Ethernet (auto-sensing)
1 opto-coupled inputs or 1 digital inputs (NC/NO selectable)
1 relay outputs
1 audio input / 1 audio output
Reset button for factory default
2 serial port (COM: RS-232, AUX: Built-in PTZ)
Image sensor
1/4”Sony 410K Super HAD CCD
Resolution: 520 TV Lines
S/N ratio: 50dB or more (AGC OFF)
Electronic shutter speed :
1/60 ~ 1/100,000 sec (NTSC)
1/50 ~ 1/100,000 sec (PAL)
White Balance: ATW (indoor: 3,000K~6,500K / outdoor:
1,800K~10,500K),AWC,MWB
Lens
IRIS control: Auto & Manual
F1.4-30, f=3.3 mm wide to 99.0 mm tele
Angle of view: 2.3~62.0 horizontal
Shutter speed: Auto or 1/120~1/60,000 sec
Minimum
illumination
Color: 0.4 Lux (F1.6)
D&N: 0.1 Lux (F1.6)
DSS( Digital Slow Shutter) : 0.0007 Lux (F1.6)
settings
DIS (Digital Image Stabilizer)
DSS (Digital Slow Shutter)
SSNR (Noise Reduction at Low Light)
ICR (Day & Night)
AGC (Auto Gain Control)
BLC (Back Light Compensation)
Dimension
216.8 (D) x 289.2(H) (in mm)
Weight
5.5Kg (12.11 lbs)
M-JPEG / MPEG-4 (simultaneous dual stream)
Audio
compression
ADPCM IMA 8Kbps
Analog
channels
1ch Video-output / 1ch Audio input / 1ch audio output
Compression
Level
6 levels (low compression / highest / high / normal / low / lowest)
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
Live Casting
Up to 30 fps @ 4CIF when simplex
Network
through-put
control
Frame rate control / Bandwidth control / CBR
Audio
support
Full duplex live audio
PTZ support
Max Speed: Pan 360°/sec, Tilt 200°/[email protected] mode
Rotation Angle: Pan 360°(endless), Tilt: 92° (auto flip)
Optical zoom: x30, Digital zoom: x10
250 Preset Positions, Swing, Group, 16 privacy zone
UART
support
Console
By-pass command to control UART device
X10 device command to control device over power line
Modem (Support PSTN, ISDN or GSM)
Alarm
management
[Trigger]
Video loss / Video recovered / Motion detection (144 area) / 1 alarm
input / Boot finished / Serial input / Schedule / Trigger combination is
possible
[Service]
Image holding service (Max 2.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm output
Dynamic IP
support
IP notification by e-mail
AOIPTM (Always On-IP, http://www.aoip.co.kr)
Security
Channel based user password protection for Live-cast, PTZ, Alarmoutput and Audio
Software
(default Web
interface)
Live-cast and PTZ control through Web browser with audio
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium
III 500 MHz or above or equivalent AMD / 64MByte RAM or above)
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128 & 256 ch (sold separately, 9ch freeware
available)
Full-featured PC NVR with matrix functionality
(Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above
/ 256MByte RAM or above / 64MByte video memory or above /
CDROM )
9
Network Camera for professional IP surveillance
H.264/MJPEG Network Camera
FW-1173DS is a stand-alone IP camera which has web server and real time operation system.
It delivers real time live video at a rate up to 30fps over the TCP/IP network. FW-1173 supports H.264 Video
Compression standard, so that less network bandwidth and storage space required for video. Motion JPEG is also
supported for maximum flexibility and integration possibilities.
FW-1173DS delivers High Video quality at maximum 30 fps in different resolution. Traditionally, the analog
video signal from the analog camera causes a “tearing” effect due to the fact even and odd fields are slightly
displaced with time interval. Contrary to the traditional analog cameras, FW-1173DS adopts progressive mode
processing to remove interlace defect of CCD Camera module, FW-3170 makes it possible to monitor in vivid and
critical image, especially for the fast moving areas.
Auto Day & Night, and DSS (Digital slow shutter) to view object under low light condition are specific of
the camera performance. Built-in motion detection, pre/post alarm buffer, RS-232/RS-485 interface for serial input
device, X10 device and advanced alarm notification interface for e-mail, FTP and third party program are some of
key features.
POE (Power over Ethernet) functions are also supported to optimize flexible installation and scalability. It
is widely used as a surveillance system for unmanned facilities, retail stores, accommodations, gas stations, etc.
Having an advantage of flexibility of network video devices and digital interfacing to other systems, and it is also
interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
H.264 /MJPEG, IP Camera
H.264 / MJPEG encoding & transmission
2-way audio communication
Auto Day / Night function
Sony Super HAD CCD
Color, Min. 0.3 Lux, B&W, Min. 0.002lux(DSS), F1.6
The best Video Quality
Vivid live video monitoring
No tearing effect on a moving area
Shipped without lens
Dual Streaming & High Performance
Simultaneous ‘dual streaming mode’ for both MJPEG & H.264 in
different resolutions
Max. 30/25fps (NTSC/PAL) live view @D1
Applications
FW-1173DS is high performance camera to
meet professional video application with
supreme video quality.
z
Franchise / Branch office Monitoring
z
SOHO / Home Security
z
Unmanned Facility Remote Surveillance
z
Serial Device / POS integrated Application
COMPATIBILITY
Supported by various well known CMS applications
(Refer to our website for more information about partners)
Channel-based User Permission
Channel based multi level protection
For live-cast PTZ, DO and audio
POE (Power Over Ethernet)
Optional Built-in Power over Ethernet: IEEE 802.3af)
10
Technical Specifications
1173DS Network Camera
Video Encoding
Video channels
MJPEG / H.264 (simultaneous dual stream)
Analog 1 Input channels & 1 Output Channel (loop through).
System
Integration
Features
[Protocol]
HTTP, RTP/RTSP, Multicast, 3GPP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE,
SMTP, DHCP, NTP, uPNP, and etc.
[SDK]
Open HTTP API / ActiveX for live cast with audio & PTZ
[Service]
Image upload / notification service / special service for POS integration
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Compression
H.264 & MJPEG : 6 levels (low compression / highest / high / normal / low /
lowest)
Misc.
OSD (On-Screen Display) / Time-stamp on video
Transmit serial input data with video
Support NTP server
Quick Time & VLC media player compatible
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF – 160x112 (NTSC) / 160x144 (PAL)
System hardware
32bit RISC CPU / Embedded Linux / 128MByte SDRAM / 8MByte Flash
Live Casting
Streaming 1 video channels with full duplex live audio
Up to 30/25 [email protected] 4CIF (KB) when simplex
Power
Power Supply - SMPS 12V (800mA) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt, 500mA
8 bit PCM, Sampling rates 8KHz, Mono Audio
Approvals
MIC,FCC, CE, RoHS
Audio channels
1ch audio-in & 1ch audio-out
Dimension /
Weight
84 (W) x 110 (D) x 35 (H) (in mm)
0.214Kg without Power Supply
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols from
Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
External
Interface
1ch video inputs & 1 composite output (75 ohm/Hi-Z)
10/100-Base-T Ethernet (auto-sensing)
1 photo-coupled or 1 digital inputs (NC/NO selectable), 1 relay outputs
1 audio input / 1 audio output
2 serial ports (COM: RS-232, AUX: RS-232 or RS-485)
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem Support
( ISDN, PSTN and GSM )
Working
Environment
Temperature : 32~122 F (0~50 OC)
Humidity : 20~80% RH
Audio
Encoding
Bandwidth
Management
Frame rate control / Bandwidth control / CBR / VBR
Image sensor
1/3”Sony 410K Super HAD CCD
Resolution: 540 TV Lines
S/N ratio: 50dB or more(AGC OFF, Weight ON)
Electronic shutter speed:
X128 ~ 1/120,000 sec (NTSC)
X128 ~ 1/120,000 sec(PAL)
Sens-up limit is selectable / Flickerless
White Balance: ATW/AWC/Manual(1,800K ~10,500K),AWC,MWB
Alarm
Management
(for 1 analog
channels)
[ Trigger Condition ]
Video loss / Video recovered / Motion detection (144 area) /
1ch alarm inputs / Boot finished / Serial input / Schedule
[ Alarm Service ]
Image holding service (Max 15.5MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm outputs
Lens
Shipped without lens
CS mount
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Setting
BACKLIGHT(OFF/LOW/MIDDLE/HIGH)
AGC(OFF/LOW/MIDDLE/HIGH)
LENSE(MANUAL/DC)
SHUTTER(ESC/MANUAL/Flicker Less)
WHITE BALANCE(ATW/AWC/MANUAL)
DNR(Dynamic Noise Reduction)
Minimum
illumination
Color: 0.3 Lux (F1.6)
B*W:0.002 Lux (Sens-up: x128)
Power Over
Ethernet
IEEE 802.3af (optional module)
Dynamic IP
Dynamic IP service using www.ipcctvdns.com
Support
Software
(default
Web interface)
Live-cast, PTZ control, search through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later )
Software
(FW-Manager 3.xx)
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
* All specifications are subject to change without prior notice.
Accessory
POE module
Sold separately
11
Megapixel Network Camera for professional IP surveillance
H.264/MJPEG Megapixel Network Camera
FW-1173MM is a stand-alone 1.3 Megapixel IP camera which has web server and real time operation
system. It delivers real time live video at a rate up to [email protected] over the TCP/IP network. FW-1173MM supports
H.264 Video Compression standard, so that less network bandwidth and storage space required for video. Motion
JPEG is also supported for maximum flexibility and integration possibilities.
FW-1173MM also delivers High quality Video at 15 fps at SXGA(1280x1024) in progressive mode.
Traditionally, the analog video signal from the analog camera causes a “tearing” effect due to the fact even and odd
fields are slightly displaced with time interval. Contrary to the conventional analog cameras, FW-1173MM has
progressive scan CMOS , and makes it possible to monitor vivid and crystal clear image.
FW-1173MM is supported by various well known CMS application partners. It is able to monitor, recode,
and playback by FlexWATCH’s CMS application as well as various famous ones. More CMS partners is added now.
(For more information about the partners, refer to the web site.)
POE (Power over Ethernet) functions are also supported to optimize flexible installation and scalability. It
is widely used as a surveillance system for unmanned facilities, retail stores, accommodations, gas stations, etc.
Having an advantage of flexibility of network video devices and digital interfacing to other systems, and it is also
interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
H.264 /MJPEG, Dual Stream IP Camera
H.264 / MJPEG Dual encoding & transmission
2-way adio communication
1.3Mega pixel CMOS Camera Module
The best possible Video Quality
High (1280 X 1024 Pixel ) Resolution
No tearing effect on a moving area
High Performance Streaming Engine
Shipped without lens
Max. 15fps liveview @ SXGA
Max. 30fps liveview @ VGA
Max. 32 simultaneous users’ connection
Low latency transmission
COMPATIBILITY
Applications
FW-1173MM is high performance camera to
meet professional video application with
supreme video quality.
z
Franchise / Branch office Monitoring
z
SOHO / Home Security
z
Unmanned Facility Remote Surveillance
z
Serial Device / POS integrated Application
Supported by various well known CMS applications
Transmission Protocol Compatibility
( HTTP, RTP/RTSP, unicast/multicast Transmission )
Channel-based User Permission
Channel based multi level protection
for live-cast PTZ, DO and audio
Various Advanced network service module
( ftp, e-mail, event notification by sophisticated conditions )
POE (Power Over Ethernet)
Optional Power Over Ethernet: IEEE 802.3af
12
Technical Specifications
Video Encoding
Video channels
Compression
Resolution
MJPEG / H.264 (simultaneous dual stream)
Analog 1 Input channels & 1 Output Channel (loop through).
H.264 & MJPEG : 6 levels (low compression / highest / high / normal / low /
lowest)
SXGA - 1280x1024
VGA - 640x480
CIF – 320x240
1173MM Network Camera
System
Integration
Features
[Protocol]
HTTP, RTP/RTSP, Multicast, 3GPP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE,
SMTP, DHCP, NTP, uPNP, and ETC
[SDK]
Open HTTP API / ActiveX for live cast with audio & PTZ
[Service]
Image upload / notification service / special service for POS integration
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Misc.
OSD (On-Screen Display) / Time-stamp on video
Transmit serial input data with video
Support NTP server
Quick Time & VLC media player compatible for live view
System hardware
32bit RISC CPU / Embedded Linux / 128MByte SDRAM / 8MByte Flash
QCIF – 160x112
Live Casting
Streaming 1 video channels with full duplex live audio
Up to max.
[email protected] 4CIF (KB) , [email protected] when simplex
Power
Power Supply - SMPS 12V (800mA) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt,
500mA
Audio
Encoding
8 bit PCM, Sampling rates 8KHz, Mono Audio
Approvals
MIC,FCC, CE, RoHS
Audio channels
1ch audio-in & 1ch audio-out
Dimension /
Weight
84 (W) x 110 (D) x 35 (H) (in mm)
0.214Kg without Power Supply
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols from
Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
External
Interface
1ch video inputs & 1 composite output (75 ohm/Hi-Z)
10/100-Base-T Ethernet (auto-sensing)
1 photo-coupled or 1 digital inputs (NC/NO selectable), 1 relay outputs
1 audio input / 1 audio output
2 serial ports (COM: RS-232, AUX: RS-232 or RS-485)
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem Support
( ISDN, PSTN and GSM )
Working
Environment
Temperature : 32~122 F (0~50 OC)
Humidity : 20~80% RH
Bandwidth
Management
Frame rate control / Bandwidth control / CBR / VBR
Image sensor
1/3”(5:4) Micron Progressive Scan CMOS
Active imager size : 4.6mm(H) x 3.7mm(V), 5.9mm diagonal
Active pixels : 1280H x 1024V
Pixel size : 3.6 x 3.6μm
Color filter array RGB Bayer pattern
Shutter type Electronic rolling shutter (ERS)
Responsivity 1.0 V/lux-sec (550nm)
SNR MAX 44dB
Alarm
Management
(for 1 analog
channels)
[ Trigger Condition ]
Video loss / Video recovered / Motion detection (144 area) /
1ch alarm inputs / Boot finished / Serial input / Schedule
[ Alarm Service ]
Image holding service (Max 15.5MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm outputs
Lens
Shipped without lens
CS mount
No Iris Control
For Mega Pixel Sensor
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Setting
LENSE(MANUAL)
No Iris Control
Dynamic IP
Support
Dynamic IP service using www.ipcctvdns.com
Minimum
illumination
2-10000 lux, F1.8
Software
(default
Web interface)
Live-cast, PTZ control, search through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later )
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
Power Over
Ethernet
IEEE 802.3af Built-in wireless(optional)
Software
(FW-Manager 3.xx)
* All specifications are subject to change without prior notice.
Accessory
POE module
Sold separately
13
Vandal Dome IP Camera for professional IP surveillance
H.264/MJPEG Vandal Dome Network
FW-1175DS
is a Vandal and Weather proof Fixed Dome IP camera with IP66 standard to provide
maximum protection in tough environment. FW-1175DS supports simultaneous H.264 and MJPEG Video
Compression, so that less network bandwidth and storage space required.
FW-1175DS delivers High Video quality at maximum 30 fps in different resolution. Traditionally, the analog
video signal from the analog camera causes a “tearing” effect due to the fact even and odd fields are slightly
displaced with time interval. Contrary to the traditional analog cameras, FW-1175DS adopts progressive mode
processing to remove interlace defect of CCD Camera module, FW-1175DS makes it possible to monitor in vivid and
critical image, especially for the fast moving areas.
Auto Day & Night, and DSS (Digital slow shutter) to view object under low light condition are specific of
the camera performance. Built-in motion detection, pre/post alarm buffer, RS-232/RS-485 interface for serial input
device, X10 device and advanced alarm notification interface for e-mail, FTP and third party program are some of
key features.
POE (Power over Ethernet) functions are also supported to optimize flexible installation and scalability. It
is widely used as a surveillance system for unmanned facilities, retail stores, accommodations, gas stations, etc.
Having an advantage of flexibility of network video devices and digital interfacing to other systems, and it is also
interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
Vandal proof / Weather proof
IP66-rated
1000 kg (2200lbs) impact-resident casing
Polycarbonate dome glass
H.264 /MJPEG, IP Camera
H.264 / MJPEG encoding & transmission
2-way audio communication
Front View
Auto Day / Night function
Sony Super HAD CCD
Color, Min. 0.3 Lux, B&W, Min. 0.002lux(DSS), F1.6
The best Video Quality
We are providing several types of brackets
(optional).
Flush mount
mount
Wall mount
Wall
Vivid live video monitoring
No tearing effect on a moving area
Dual Streaming & High Performance
Simultaneous ‘dual streaming mode’ for both MJPEG & H.264 in
different resolutions
Max. 30/25fps (NTSC/PAL) live view @D1
COMPATIBILITY
Supported by various well known CMS applications
(Refer to our website for more information about partners)
** Color and shape may change without prior notice.
POE (Power Over Ethernet)
14
Technical Specifications
1175DS Network Camera
Video Encoding
MJPEG / H.264 (simultaneous dual stream)
Video channels
Analog 1 Output Channel (loop through).
System
Integration
Features
[Protocol]
HTTP, RTP/RTSP, Multicast, 3GPP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE,
SMTP, DHCP, NTP, uPNP, and etc.
[SDK]
Open HTTP API / ActiveX for live cast with audio & PTZ
[Service]
Image upload / notification service / special service for POS integration
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Compression
H.264 & MJPEG : 6 levels (low compression / highest / high / normal / low /
lowest)
Misc.
OSD (On-Screen Display) / Time-stamp on video
Transmit serial input data with video
Support NTP server
Quick Time & VLC media player compatible
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF – 160x112 (NTSC) / 160x144 (PAL)
System hardware
32bit RISC CPU / Embedded Linux / 128MByte SDRAM / 8MByte Flash
Live Casting
Streaming 1 video channels with full duplex live audio
Up to 30/25 [email protected] 4CIF (KB) when simplex
Power
Power Supply - SMPS 12V (800mA) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt, 600mA
8 bit PCM, Sampling rates 8KHz, Mono Audio
Approvals
MIC,FCC, CE, RoHS
Audio channels
1ch audio-in & 1ch audio-out
Dimension /
Weight
145pi x 120 (H) (in mm)
About 0.885Kg without Power Supply
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols from
Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
External
Interface
1ch video inputs & 1 composite output (75 ohm/Hi-Z)
10/100-Base-T Ethernet (auto-sensing)
1 photo-coupled or 1 digital inputs (NC/NO selectable), 1 relay outputs
1 audio input / 1 audio output
2 serial ports (COM: RS-232, AUX: RS-232 or RS-485)
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem Support
( ISDN, PSTN and GSM )
Working
Environment
Temperature : 32~122 F (0~50 OC)
Humidity : 20~80% RH
Audio
Encoding
Bandwidth
Management
Frame rate control / Bandwidth control / CBR / VBR
Image sensor
1/3”Sony 410K Super HAD CCD
Resolution: 540 TV Lines
S/N ratio: 50dB or more(AGC OFF, Weight ON)
Electronic shutter speed:
X128 ~ 1/120,000 sec (NTSC)
X128 ~ 1/120,000 sec(PAL)
Sens-up limit is selectable / Flickerless
White Balance: ATW/AWC/Manual(1,800K ~10,500K),AWC,MWB
Alarm
Management
(for 1 analog
channels)
[ Trigger Condition ]
Video loss / Video recovered / Motion detection (144 area) /
1ch alarm inputs / Boot finished / Serial input / Schedule
[ Alarm Service ]
Image holding service (Max 15.5MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm outputs
Lens
Auto IRIS & Vari-focal 3.8-9.5 mm
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Setting
BACKLIGHT(OFF/LOW/MIDDLE/HIGH)
AGC(OFF/LOW/MIDDLE/HIGH)
LENSE(MANUAL/DC)
SHUTTER(ESC/MANUAL/Flicker Less)
WHITE BALANCE(ATW/AWC/MANUAL)
DNR(Dynamic Noise Reduction)
Minimum
illumination
Color: 0.3 Lux (F1.6)
B*W:0.002 Lux (Sens-up: x128)
Power Over
Ethernet
IEEE 802.3af (optional module)
Dynamic IP
Dynamic IP service using www.ipcctvdns.com
Support
Software
(default
Web interface)
Live-cast, PTZ control, search through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later )
Software
(FW-Manager 3.xx)
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
* All specifications are subject to change without prior notice.
Accessory
PWE module
is basically included.
15
H.264/MJPEG VGA Network Camera
Low-cost VGA Network Camera for IP surveillance
FW-1170 is a cost-effective compact IP camera for monitoring from small and mid-sized business. It delivers
real time live video at a rate up to [email protected] over the TCP/IP network. FW-1170 supports H.264 Video
Compression standard, so that less network bandwidth and storage space required for video. Motion JPEG is also
supported for maximum flexibility and integration possibilities.
FW-1170 is able to work with built-in PIR sensor to detect objects in the dark circumstance. It also delivers
High quality Video at 30 fps at VGA in progressive mode. Traditionally, the analog video signal from the analog
camera causes a “tearing” effect due to the fact even and odd fields are slightly displaced with time interval.
Contrary to the conventional analog cameras, FW-1170 has progressive scan CMOS, and makes it possible to
monitor vivid and crystal clear image.
FW-1170 is supported by various well known CMS application partners. It is able to monitor, recode, and
playback by FlexWATCH’s CMS application as well as various famous ones. More CMS partners are added now.
(For more information about the partners, refer to the web site.)
POE (Power over Ethernet) functions are also supported to optimize flexible installation and scalability. It
is widely used as a surveillance system for unmanned facilities, retail stores, accommodations, gas stations, etc.
Having an advantage of flexibility of network video devices and digital interfacing to other systems, and it is also
interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
Compact IP Camera with PIR Sensor
Cost-effective small IP Camera for small & mid-sized businesses
PIR sensor for detection object in dark circumstance
H.264 /MJPEG, Dual Stream IP Camera
H.264 / MJPEG Dual encoding & transmission
2-way audio communication
VGA CMOS Camera Module
The best possible Video Quality
Vivid live video monitoring
No tearing effect on a moving area
Dual Streaming & High Performance
Simultaneous ‘dual streaming mode’ for both MJPEG & H.264 in
different resolutions
Max. 30 live view @VGA
COMPATIBILITY
Supported by various well known CMS applications
Transmission Protocol Compatibility
( HTTP, RTP/RTSP, unicast/multicast Transmission )
Channel-based User Permission
(UNIT : mm)
Channel based multi level protection
for live-cast PTZ, DO and audio
Various Advanced network service module
( ftp, e-mail, event notification by sophisticated conditions )
Dimension
16
Technical Specifications
1170 Network Camera
Video Encoding
MJPEG / H.264 (simultaneous dual stream)
System
Integration
Features
[Protocol]
HTTP, HTTPS, RTP/RTSP, Multicast, 3GPP, TCP/IP, ARP, ICMP, Telnet, Ftp,
PPPoE, SMTP, DHCP, NTP, uPNP, and ETC
[SDK]
Open HTTP API / ActiveX for live cast with audio & PTZ
[Service]
Image upload / notification service / special service for POS integration
Video channels
Built-in BT-656 Video Signal
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Resolution
VGA - 640x480
CIF – 320x240
QCIF – 160x120
Misc.
Transmit serial input data with video
Support NTP server
Quick Time & VLC media player compatible for live view
Live Casting
Streaming 1 video channels with full duplex live audio
Up to max [email protected] VGA when simplex
System hardware
32bit RISC CPU / Embedded Linux / 128MByte SDRAM / 8MByte Flash
Audio
Encoding
8 bit PCM, Sampling rates 8KHz, Mono Audio
Power
Power Supply - SMPS 12V (800mA) [AC100~240V, 50/60Hz]
Power Consumption – DC12Volt, 600mA
Audio channels
1ch audio-in & 1ch audio-out
Approvals
MIC,FCC, CE, RoHS
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols from
Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
Dimension /
Weight
64 (W) x 113 (D) x 47 (H) (in mm)
0.16Kg without Power Supply
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem Support
( ISDN, PSTN and GSM )
External
Interface
10/100-Base-T Ethernet (auto-sensing)
1 photo-coupled or 1 digital inputs (NC/NO selectable), 1 relay outputs
1 PIR Input
1 audio output
1 serial port (COM: RS-232)
Bandwidth
Management
Frame rate control / Bandwidth control / CBR / VBR
Working
Environment
Temperature : 32~122 F (0~50 OC)
Humidity : 20~80% RH
Alarm
Management
(for 1 analog
channels)
[ Trigger Condition ]
Video loss / Video recovered / Motion detection (144 area) /
1ch alarm inputs / Boot finished / Serial input / Schedule
[ Alarm Service ]
Image holding service (Max 15.5MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm outputs
Image sensor
1/4 inch optical format CMOS type
Sensitivity : 1500 mV/lux.sec
MAX Active pixel resolution: 652x488
S/N ratio: 46dB
White Balance: AWB
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Lens
FOCAL LENGTH : 4.3mm
BACK FOCAL LENGTH : 6.3mm
APERTURE : F2.0
ANGLE OF VIEW : 78’, 61’ (Diagonal)
Dynamic IP
Support
Dynamic IP service using www.ipcctvdns.com
Setting
LENSE(MANUAL)
No Iris Control
Software
(default
Web interface)
Live-cast, PTZ control, search through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later )
Minimum
illumination
4-10000 lux
Software
(FW-Manager 3.xx)
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
Power Over
Ethernet
IEEE 802.3af Built-in wireless(optional)
* All specifications are subject to change without prior notice.
Accessory
POE module
Sold separately
17
Motorized
FW-1177DE / Network Dome Camera
High-speed
FW-1177DE is a stand-alone PTZ network camera which has built-in PAN/TILT/ZOOM camera, web server
and real time operation system. With powerful PTZ feature, you can remotely move camera to any direction or zoom
in/out the object from anywhere though standard web browser. It delivers real time live videos at a rate up to 30fps
over the TCP/IP network.
Pan/Tilt/Zoom
Fast PAN/TILT, Superb 444x zoom (37X Optical, 12X Digital zoom) and up to 250 presets function enable you to
easily focus camera to the target location and zoom up the object with simple mouse click.
Network
Day & Night camera function, IR Sensitivity, WDR (Wide Dynamic Range) for clear image view under back light
situation and DSS (Digital slow shutter) to view object under low light condition are specific of the camera
performance. Built-in motion detection, up to 15.5M pre/post alarm buffer, RS-232/RS-485 interface for serial input
device, X10 device and advanced alarm notification interface for e-mail, FTP and third party program are some of
key features.
It is widely used as a surveillance system for unmanned facilities, retail stores, accommodations, gas stations, etc.
Camera
Having an advantage of flexibility of network video devices and digital interfacing to other systems, and it is also
interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
Superb Zoom and Camera performance
444x zoom (37x auto-focus optical / 12x digital), Day & Night, 0.7
lux, 0.1 lux (D&N), 0.0001 lux (DSS) /F1.6
(Optional : 30x optical,& 23x optical)
High speed Pan/Tilt with 250 presets
Pan/Tilt angle 360° (endless) / 92° (auto flip)
Max speed: Pan-360°/sec, Tilt-240°/sec at Preset mode
WDR(Wide Dynamic Range)
Different exposure for different objects in a scene to enable object
in both bright and dark areas to be visible.
Progressive Frame Mode
Provide D1 resolution image without distortion
EIS(Electric Image Stabilizer)
Reduces the variation on the image caused by wind or tremor
M-JPEG / H.264 with 2 way audio
M-JPEG/H.264 simultaneous dual stream
Synchronized 2 way audio is supported with M-JPEG and
H.264 1ch Audio-input / 1ch Audio-output
High Performance of video transmission
Up to 30/25 fps(NTSC/PAL)@4CIF, simplex
Vandal & weather proof
Weather proof (IP66) outdoor housing using die cast aluminium
and anti-vandal PC(polycarbonate) dome cover that can withstand
high impact with heater & blower for external or any tough
environment.
Dimension
18
Technical Specifications
1177DE Network Dome Camera
Video Encoding
Video channels
Software
(FW-Manager
3.xx)
MJPEG / H.264 (simultaneous dual stream)
System
Integration
Features
1ch Video-output.
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
[Protocol]
HTTP, RTP/RTSP, Multicast, 3GPP, TCP/IP, ARP, ICMP, Telnet, Ftp,
PPPoE, SMTP, DHCP, NTP, uPNP, and etc.
[SDK]
Open HTTP API / ActiveX for live-cast with audio & PTZ
[Service]
Image upload service / notification service
Compression
H.264: 6 levels (low compression / highest / high / normal / low / lowest),
MJEPG: 1 level (highest)
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp (Firmware is available at
www.flexwatch.com)
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF – 176x112 (NTSC) / 176x144 (PAL)
Misc.
Transmit serial input data with video
Different time zones are supported
Date and time can be synchronized with an external NTP server
Live Casting
Up to 30/25 [email protected] CIF (12.5KB) when simplex
System
hardware
32bit RISC CPU / Embedded Linux / 128MByte SDRAM / 8MByte Flash
AC 24V/1.0A, 32~122F(0~50C), 20~80% RH
Network
through-put
control
Frame rate control / Bandwidth control / CBR
Approvals
MIC,FCC, CE, RoHS, IP66
Audio
Encoding
8 bit PCM, Sampling rates 8KHz, Mono Audio
Accessories
CD with installation wizard / User’s manual / Quick installation manual /
Transformer AC 24V(1.5A)[AC100~240V, 50/60Hz] / Power cord / LAN
cable / Mounting brackets / Connector kit
External
Interface
10/100 Base T Ethernet(auto-sensing)
1 opto-coupled inputs or 1 digital inputs (NC/NO selectable)
1 relay outputs
1 audio input / 1 audio output
Reset button for factory default
2 serial port (COM: RS-232, AUX: Built-in PTZ)
Audio channels
1ch Audio input / 1ch Audio
Full duplex live audio.
O
PTZ support
O
Max Speed: Pan 360 /sec, Tilt 200 /[email protected] mode
Rotation Angle: Pan 360 O (endless), Tilt: 92 O (auto flip)
Optical zoom x30, Digital zoom x10
250 Preset Positions, Swing, Group, 16 privacy zone.
Image sensor
1/4”Sony 410K Super HAD CCD
Resolution: 520 TV Lines
S/N ratio: 50dB or more(AGC OFF)
Electronic shutter speed:
1/60 ~ 1/100,000 sec (NTSC)
1/50 ~ 1/100,000 sec(PAL)
White Balance: ATW(indoor: 3,000K~6,500K
~10,500K),AWC,MWB
IRIS control: Auto & Manual
F1.4-30, f=3.3mm wide to 99.0mm tele
Angle of view: 2.3 ~ 62.0 horizontal
Shutter speed: Auto or 1/120 ~ 1/60,000 sec
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem Support
( ISDN, PSTN and GSM )
Lens
Alarm
Management
[ Trigger]
Video loss / Video recovered / Motion detection (144 area) /
1 alarm inputs / Boot finished / Serial input / Schedule / Trigger
combination is possible.
[ Alarm]
Image holding service (Max 15.5MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm outputs
Setting
DIS (Digital Image Stabilizer)
DSS (Digital Slow Shutter)
SSNR (Noise Reduction at Low Light)
ICR (Day & Night)
AGC (Auto Gain Control)
BLC (Back Light Compensation)
Dynamic IP
support
Dynamic IP service using www.ipcctvdns.com
Minimum
illumination
Color: 0.7 Lux (F1.6)
D&N: 0.1 Lux (F1.6)
DSS(Digital Slow Shutter):0.0001 Lux(F1.6)
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Dimension
216.8 (D) x 289.2 (H)(in mm)
Software
(default
Web interface)
Live-cast, PTZ control, search through Web browser with audio
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later/Pentium lll
500MHz or above or equivalent AMD / 64MByte RAM or above /
CDROM)
Weight
5.5Kg(12.11 lbs)
/
outdoor:
1,800K
Accessory
FSC-30EWP
*Basically included
FSC-20ECP
FSC-20PMA
FSC-20ECP
FSC-20ICB
19
Gateway to IP-surveillance for analog CCTV system
Network Video Server
Model No : FW-3150
1-channel video server
1ch Video-input / 1ch Video-output, Loop-through
1ch Audio-input / 1ch Audio-output
M-JPEG / MPEG-4 with 2 way audio
M-JPEG/MPEG-4 simultaneous dual stream
Synchronized 2 way audio is supported with M-JPEG and MPEG-4
Full frame rate
Up to 30/25 fps (NTSC/PAL) @ 4CIF, simplex
Channel based user permission
Channel based multi level protection for live-cast,
PTZ, DO and audio
Top level event services
Supports service triggered by various events
Multi-window motion detection
Pre- and post-image alarm buffering
Easy installation and management
Provided with installation wizard application
Full web based management
FW-3150 can convert not only analog video, but serial command
into a networked data.
Analog video extension
FlexWATCH makes it possible to overcome limit of analog CCTV cabling. We have
NMD(Network Media Decoder) which is a counter part of NVS(Network Video
Server) or NC(Network Camera). It convert network video into analog NTSC/PAL
signal. With this solution, you can monitor remote site and control remote PTZ
without a PC. And your analog DVR can record video from remote site.
Analog
PTZ
camera
FW-3150
Network
media
decorder
Analog
video
DVR
Analog
monitor
RS 485
RS 485
CCTV
keyboard
Analog video
20
Integrated Network Video since 1999
Applications
Video
compression
M-JPEG / MPEG-4 (simultaneous dual stream)
Audio
compression
ADPCM IMA 8Kbps
Analog
channels
1ch Video input / 1ch Video-output (loop-through)
1ch Audio input / 1ch audio output
Compression
Level
6 levels (low compression / highest / high / normal / low / lowest)
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
Live Casting
Up to 30 fps @ 4CIF when simplex
Network
through-put
control
Frame rate control / Bandwidth control / CBR
Audio
support
Full duplex live audio
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols
from Pelco, Vicon, Kalatel,Sony, Panasonic, Canon, Honeywell and
etc
UART
support
Alarm
management
Console
By-pass command to control UART device
X10 device command to control device over power line
Modem (Support PSTN, ISDN or GSM)
[Trigger]
Video loss / Video recovered / Motion detection (144 area) / 1 alarm
input / Boot finished / Serial input / Schedule / Trigger combination is
possible
[Service]
Image holding service (Max 2.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm output
Dynamic IP
support
IP notification by e-mail
AOIPTM (Always On-IP, http://www.aoip.co.kr)
Security
Channel based user password protection for Live-cast, PTZ, Alarmoutput and Audio
Software
(default Web
interface)
Live-cast and PTZ control through Web browser with audio
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium
III 500 MHz or above or equivalent AMD / 64MByte RAM or above)
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128 & 256 ch (sold separately, 9ch freeware
available)
Full-featured PC NVR with matrix functionality
(Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above /
CDROM )
System
integration
features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback & PTZ
[Service]
Image upload service / notification service
Installation
and
maintenance
Configuration : installation wizard, HTTP, telnet and console
Upgrade firmware : HTTP, telnet & ftp (Firmware is available at
www.flexwatch.com)
Misc.
Transmit serial input data with video
Different time zones are supported
Date and time can be synchronized with an external NTP server
Live-cast for up to 32 clients
System
hardware
32bit RISC Processor / Embeded Linux / 32MByte SDRAM / 8MByte
Flash
DC 12V/450mA, 32~122 F (0~50 C), 20~80% RH
Approvals
MIC, FCC, CE, RoHS
Accessories
CD with installation wizard / User's manual / Quick installation
manual / SMPS 12V(800mA) [AC100~240V, 50/60Hz] / Power cord /
LAN cable / Connector kit
Connectors
1 video inputs & 1 composite output (75 ohm/Hi-Z)
10/100 BaseT Ethernet (auto-sensing)
1 opto-coupled inputs or 1 digital inputs (NC/NO selectable)
1 relay outputs
1 audio input / 1 audio output
Reset button for factory default
2 serial port (COM: RS-232, AUX: RS-232 or RS-485)
Dimension
84(W) x 122 (D) x 35(H) (in mm)
Weight
300 (0.66 lbs)
21
Gateway to IP-surveillance for analog CCTV system
Network Video Server
Model No : FW-3450
4-channel video server
4ch Video-input / 1ch Video-output, Loop-through (Quad-view)
4ch Audio-input / 1ch Audio-output
M-JPEG / MPEG-4 with 2 way audio
M-JPEG/MPEG-4 selectable dual stream
Synchronized 2 way audio is supported with M-JPEG and MPEG-4
Rear view
Full frame rate
Up to 120/100 fps (NTSC/PAL) @ CIF, 12.5KB, simplex
Channel based user permission
Channel based multi level protection for live-cast,
PTZ, DO and audio
Top level event services
Supports service triggered by various events
Multi-window motion detection
Pre- and post-image alarm buffering
Easy installation and management
Provided with installation wizard application
Full web based management
Quad video output for loop-through
For analog monitor display at local site
19" rack mount
19" rack mount kit
We are providing 19" rack mount kit for FW-3450 which could contain
2 pieces of FW-3450. There are a cooling fan and a SMPS for whole
unit in the middle.
19" 1U rack mount kit
* Sold separately
22
Integrated Network Video since 1999
19" rack mount kits are available
Video
compression
M-JPEG / MPEG-4
Audio
compression
ADPCM IMA 8Kbps
Analog
channels
4ch Video input / 1ch Video-output (loop-through, Quad)
4ch Auido input / 1ch audio output
Compression
Level
6 levels (low compression / highest / high / normal / low / lowest)
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
Live Casting
Up to 120 fps @ CIF (12.5KB) when simplex
Network
through-put
control
Frame rate control / Bandwidth control / CBR
Audio
support
Full duplex live audio
PTZ support
UART
support
Alarm
management
Software
(default Web
interface)
Live-cast and PTZ control through Web browser with audio
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium
III 500 MHz or above or equivalent AMD / 64MByte RAM or above)
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128 & 256 ch (sold separately, 9ch freeware
available)
Full-featured PC NVR with matrix functionality
(Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above /
CDROM )
System
integration
features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback & PTZ
[Service]
Image upload service / notification service
Installation
and
maintenance
Configuration : installation wizard, HTTP, telnet and console
Upgrade firmware : HTTP, telnet & ftp (firmwares are available at
www.flexwatch.com)
Misc.
Timestamp on video
Transmit serial input data with video
Different time zones are supported
Date and time can be synchronized with an external NTP server
Live-cast for up to 32 clients
System
hardware
32bit RISC Processor / Embeded Linux / 64MByte SDRAM / 8MByte
Flash
DC 12V/1.5A, 32~122 F (0~50 C), 20~80% RH
Approvals
MIC, FCC, CE, RoHS
Accessories
CD with installation wizard / User's manual / Quick installation manual
/ SMPS 12V(3A) [AC100~240V, 50/60Hz] / Power cord / LAN cable
Connectors
4 video inputs & 1 composite output, Quad display (75 ohm/Hi-Z)
10/100 BaseT Ethernet (auto-sensing)
4 opto-coupled inputs or 4 digital inputs (NC/NO selectable)
4 relay outputs
4 audio input / 1 audio output
Reset button for factory default
2 serial port (COM: RS-232, AUX: RS-232 or RS-485)
Dimension
140(W) x 155 (D) x 45(H) (in mm) / 19" 1U Rack mount kit
Weight
600 g(1.32 lbs)
Built-in PTZ device protocol with more than 30 different PTZ protocols
from Pelco, Vicon, Kalatel,Sony, Panasonic, Canon, Honeywell and
etc
Console
By-pass command to control UART device
X10 device command to control device over power line
Modem (Support PSTN, ISDN or GSM)
[Trigger]
Video loss / Video recovered / Motion detection (144 area) / 4 alarm
inputs / Boot finished / Serial input / Schedule / Trigger combination is
possible
[Service]
Image holding service (Max 23.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 4 alarm outputs
Dynamic IP
support
IP notification by e-mail
AOIPTM (Always On-IP, http://www.aoip.co.kr)
Security
Channel based user password protection for Live-cast, PTZ, Alarmoutput and Audio
23
IP video server for converting Analog CCTV to IP-Surveillance
FW-3850 / 8ch Network Video Server
8ch Video Server, FW-3850 is a stand-alone 8 channel network video server which transmits
the crisp real time live video and audio over the TCP/IP network. The FlexWATCH® FW-3850 has 8 internal
composite video, audio and DI/DO inputs. Users can access and see the live-images from 8 cameras through
standard Web browser over the LAN or Internet at anytime from anywhere.
The FlexWATCH® Network Video Server (NVS) extends your existing analog CCTV or DVR systems into IP
surveillance.
It's basically same as a Network Camera except does not have built-in camera. Besides it is designed
to connect analog video signals from CCTV cameras or DVR loop-through, and digitizes analog video signals and
sends digital images directly over the IP network, such as a LAN, intranet or Internet.
All the functions and services
of a network video server can be managed remotely via the network. Users can change the system configurations
using a remote web browser or a CMS S/W.
The FlexWATCH® NVS is affordable for sites that can be expanded from fixed analog channels to additional network
cameras. It is widely used as a surveillance system for unmanned facilities, retail stores, accommodations, gas
stations, etc. Having an advantage of flexibility of network video devices and digital interfacing to other systems, and
it is also interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
MJPEG/MPEG-4, 8ch Video Sever
MJEPG / MPEG-4 supports selectively
8ch Video-input / 1ch Video-output, Loop-through
8ch Audio-input / 1ch Audio-output
Diverse I/O
8 DI/DO port, RS-485/232 for PTZ
Multiplexed composite video output for 8ch
High Performance
120/100fps (NTSC/PAL) live view @CIF
Channel-based User Permission
Applications
Channel based multi level protection for live-cast, PTZ,
DO and audio
Top level of Event Services
FW-3850 is specially designed to meet high-end video
application covering a small-mid size area with various
types of analog CCTV-cameras for live-casting over the
TCP/IP network.
Followings are recommended application area,
Triggered by various events, conditions & schedule
Multi-window motion detection
Pre- and Post- image alarm buffering
Diverse I/O
8 Audio In / 1 Audio Out
8 DI/DO port, RS-485/232 for PTZ
Multiplexed composite video output for 8ch
z
Franchise / Branch office Monitoring
z
SOHO / Home Security
z
Unmanned Facility Remote Surveillance
19” Rack mountable
z
Serial Device / POS integrated Application
1U-size 19” rack mount kit is available!
24
Technical Specifications
3850 Network Video Server
Video Encoding
Video channels
MJPEG / MPEG-4 Video stream recording
Analog 8 Input channels & 1 Output Channel.
Dynamic IP
support
IP notification by e-mail
AOIP (Always On-IP, http://www.aoip.co.kr)
Software
(default
Web interface)
Live-cast, PTZ control through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later )
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
Compression
MPEG-4: 6 levels (low compression / highest / high / normal / low /
lowest), MJEPG: 1 level (highest)
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
System
Integration
Features
[Protocol]
HTTP, HTTPS, RTP/RTSP, Multicast, 3GPP, TCP/IP, ARP, ICMP, Telnet,
Ftp, PPPoE, SMTP, DHCP, NTP, uPNP, and etc.
[SDK]
Open HTTP API / ActiveX for live-cast with audio
[Service]
Image upload / notification service / special service for POS integration
Live Casting
Streaming 8 video channels with full duplex live audio
Up to 120/100 [email protected] CIF (12.5KB) when simplex
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Audio
Encoding
G.723 (4-bit, 8KHz)
Misc.
OSD (On-Screen Display) / Time-stamp on video
Transmit serial input data with video
Support NTP server
System
hardware
32bit RISC CPU / Embedded Linux / 64MByte SDRAM / 8MByte Flash
Audio channels
8ch audio-in & 1ch audio-out
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols
from Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
Power
Power Supply - SMPS 12V (3A) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt, Normal : 1.5A, Peak : 1.6A
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem Support
( ISDN, PSTN and GSM )
Approvals
FCC, CE, RoHS
Network
Frame rate control / Bandwidth control / CBR / VBR
Dimension /
Weight
215 (W) x 290 (D) x 44(H) (in mm)
1.4Kg(3.08lbs) without Power Supply
Alarm
Management
(for 8 analog
channels)
[ Trigger Condition ]
Video loss / Video recovered / Motion detection (144 area) /
8ch alarm inputs / Boot finished / Serial input / Schedule
[ Alarm Service ]
Image holding service (Max 19.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 8 alarm outputs
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
External
Interface
Working
Environment
8ch video inputs & 1 composite output, 3x3 Multiplexed display (75
ohm/Hi-Z)
10/100-Base-T Ethernet (auto-sensing)
8 photo-coupled or 8 digital inputs (NC/NO selectable), 8 relay outputs
8 audio input / 1 audio output
2 serial ports(COM: RS-232, AUX: RS-232 or RS-485 of RS-422)
Temperature : 41~122 F (5~50 OC)
Humidity : 20~80% RH
Accessory
19" 1U rack mount kit
Sold separately
25
IP video server for converting Analog CCTV to IP-Surveillance
H.264/MJPEG 1-CH Network Video Server
1ch Video Server, FW-3170 is a stand-alone 1 channel network video server to transmit
the supreme video and audio data over the TCP/IP network. FW-3170 supports H.264 Video Compression
standard, so that much less network bandwidth and storage space are required for video. Motion JPEG is also
supported for maximum flexibility and integration possibilities.
FW-3170 delivers High Video quality at maximum 30 fps in different resolution. Traditionally, the analog
video signal from the analog camera causes a “tearing” effect due to the fact even and odd fields are slightly
displaced with time interval. FW-3170 converts the interlaced image from conventional analog camera into a
progressive quality image. FW-3170 makes it possible to monitor fast moving images in vivid and crystal clear
quality
The FlexWATCH® Network Video Server not only extends your existing analog CCTV or DVR systems
into IP surveillance, but also enhances the existing one. FlexWATCH® is supported by many well known CMS
partners, so it is possible to benefit from various CMS application. FlexWATCH®‘s 10-year experience and higher
performance is open to your qualified existing security systems.
The FlexWATCH® NVS (Network Video Server) is affordable for sites that can be expanded from fixed
analog channels to additional network cameras. It is widely used as a surveillance system for unmanned
facilities, retail stores, accommodations, gas stations, etc. Having an advantage of flexibility of network video
devices and digital interfacing to other systems, and it is also interoperated with various applications like as POS,
Access Control, and Building Automation.
Key Features
H.264 /MJPEG, 1ch Video Server
H.264 / MJPEG encoding & transmission
2-way audio communication
The best possible Video Quality
Vivid live video monitoring
No tearing effect on a moving area
Dual Streaming & High Performance
Simultaneous ‘dual streaming mode’ for both MJPEG &
H.264 in different resolutions
Max. 30/25fps (NTSC/PAL) live view @D1
Diverse I/O
Applications
FW-3170 is designed to meet the professional video
application by giving existing analog systems to the
TCP/IP network connectivity in LAN or WAN.
Followings are recommended application area,
z
Franchise / Branch office Monitoring
z
SOHO / Home Security
z
Unmanned Facility Remote Surveillance
z
Serial Device / POS integrated Application
1ch Video-input / 1ch Video-output, Loop-through
1ch Audio-input / 1ch Audio-output
1 DI/DO port,
RS-485/232 for PTZ
COMPATIBILITY
Supported by various well known CMS applications
(Refer to our website for more information about partners)
Channel-based User Permission
Channel based multi level protection
for live-cast PTZ, DO and audio
26
Technical Specifications
3170 Network Video Server
Video Encoding
MJPEG / H.264 (simultaneous dual stream)
Dynamic IP
support
Dynamic IP service using www.ipcctvdns.com
Video channels
Analog 1 Input channels & 1 Output Channel (loop through).
Software
(default
Web interface)
Live-cast, PTZ control, search through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later )
Compression
H.264 & MJPEG : 6 levels (low compression / highest / high / normal / low
/ lowest)
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF – 176x112 (NTSC) / 176x144 (PAL)
System
Integration
Features
[Protocol]
HTTP, RTP/RTSP, Multicast, 3GPP, TCP/IP, ARP, ICMP, Telnet, Ftp,
PPPoE, SMTP, DHCP, NTP, uPNP, and ETC
[SDK]
Open HTTP API / ActiveX for live cast with audio & PTZ
[Service]
Image upload / notification service / special service for POS integration
Live Casting
Streaming 1 video channels with full duplex live audio
Up to 30/25 [email protected] 4CIF (KB) when simplex
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Audio
Encoding
8 bit PCM, Sampling rates 8KHz, Mono Audio
Misc.
OSD (On-Screen Display) / Time-stamp on video
Transmit serial input data with video
Support NTP server
Quick Time & VLC media player compatible for live view
Audio channels
1ch audio-in & 1ch audio-out
System
hardware
32bit RISC CPU / Embedded Linux / 128MByte SDRAM / 8MByte Flash
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols
from Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
Power
Power Supply - SMPS 12V (800mA) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt, 500mA
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem Support
( ISDN, PSTN and GSM )
Approvals
MIC,FCC, CE, RoHS
Bandwidth
Management
Frame rate control / Bandwidth control / CBR / VBR
Dimension /
Weight
84 (W) x 110 (D) x 35 (H) (in mm)
0.214Kg without Power Supply
Alarm
Management
(for 1 analog
channels)
[ Trigger Condition ]
Video loss / Video recovered / Motion detection (144 area) /
1ch alarm inputs / Boot finished / Serial input / Schedule
[ Alarm Service ]
Image holding service (Max 15.5MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 1 alarm outputs
External
Interface
1ch video inputs & 1 composite output (75 ohm/Hi-Z)
10/100-Base-T Ethernet (auto-sensing)
1 photo-coupled or 1 digital inputs (NC/NO selectable), 1 relay outputs
1 audio input / 1 audio output
2 serial ports (COM: RS-232, AUX: RS-232 or RS-485)
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Working
Environment
Temperature : 32~122 F (0~50 OC)
Humidity : 20~80% RH
* All specifications are subject to change without prior notice.
Application
®
FW-3170, 1channel Network Video Server can convert not only analog video, but also serial command into a networked data, FlexWATCH
makes it possible to overcome limit of analog CCTV cabling.
You can monitor and control site in the remote PC and using Network Media Decoder
that is the counterpart of network video server, you can view and control with conventional analog device.
PC (Web Viewer)
Monitor
FW-3170
PTZ Camera
Internet
CCTV
Keyboard
Network Media
Decoder
27
Network Video Recorder for IP camera audio visual stream
IP-8Ch Network Video Recorder
IP-8ch Network Video Recorder, FW-5050 is a stand-alone 8 channel network
video recorder. FW-5050, fully IE browser enabled network video recorder, can display, record and playback the real
time MJPG, MPEG4 and H.264 video streams transmitted from any FlexWATCH® IP cameras and video servers
over TCP/IP network. It also supports multi-vendors’ IP cameras and Video Servers such as Axis, Panasonic,
Mobotix, Arecont Vision*, IQinvision, Vivotek and so on.
FW-5050 is based on Unified Communication Protocol. Compared with other NVR (s/w or h/w based)
products, FW-5050 requires only single TCP port for remote live view, playback and configuration. It minimizes
network configuration burden and realizes much easier way for video management. By accessing FW-5050 locally
or remotely, IP cameras connected to FW-5050 can be viewed and controlled.
FW-5050 is affordable for a surveillance system for unmanned facilities, retail stores, accommodations,
gas stations, etc. Having an advantage of flexibility of network video devices and digital interfacing to other systems,
and it is also interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
Multi-Vendor Supports
Axis, Panasonic, Mobotix, Arecont, IQinvision, Vivotek, etc
Unified Communication Protocol
Single TCP port only for view, playback and control
MJPEG/MPEG-4/H.264 NVR
Applications
MJEPG / MPEG-4 / H.264 supports selectively
8ch simultaneous streams
FW-5050 is specially designed to meet high-end video
application covering a small-mid size area with various
types of IP cameras and video servers
Followings are recommended application area,
High Performance
z
Franchise / Branch office Monitoring
z
SOHO / Home Security
Channel based multi level protection for live-cast, PTZ, DI/DO
and audio control
z
Unmanned Facility Remote Surveillance
z
Serial Device / POS integrated Application
Maximum 60 fps recording at D1 resolution
Simultaneous recording, live, playback and backup
Channel-based User Authentication
19” Rack mountable
1U-size 19” rack mount kit is available!
Supported Vendors
Some of models are under the integration. Please contact www.flexwatch.com for the details
28
Technical Specifications
5050 Network Video Recorder
Video channels
1 ~ 8 IP cameras
HDD management
Disk full notification / Periodic notification via e-mail
HDD error notification via e-mail
HDD error notification using beep sound (for local area notification)
IP camera Brand
FlexWATCH, Axis, Mobotix, Panasonic is supported now.
Arecont vision, IQinVision, and Vivotek, etc.
Please make sure the supported compression format according to the
brand
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Recording
storage
Supports up to 1.5TB HDD by 1 SATA (After update Firmware 4.0)
Anti-vibration & air-cooling system
Dynamic IP
support
Dynamic IP service using www.ipcctvdns.com
Recording
[Video Recording]
MJPEG / MPEG-4 / H.264
Max 60 fps at D1 resolution
[Audio Recording]
G.723 (4-bit, 8KHz), ADPCM IMA and so on
[Data Recording]
POS, ATM, Video Analytics, Access Control and various serial devices
Please make sure the recording streams according to the brand
Software
(default Web
interface)
Live-cast, PTZ control, search and playback through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium III
500 MHz or above or equivalent AMD / 64MByte RAM or above)
Live Casting
8 channels of video, audio and data
Software
(Multi-NVR Player)
Optional (freeware available)
Search and playback video with audio from registered NVR
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium III
500 MHz or above or equivalent AMD / 64MByte RAM or above)
Bandwidth
Management
Frame rate control / Bandwidth control
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128, 256ch
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
Recording
condition
Based on the multiple combination of date / time / alarm using ‘AND’ &
‘OR’ condition
Alarm can be generated by motion detection and by a trigger from
digital inputs
System
Integration
Features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP, uPNP,
and ETC
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback, & PTZ
[Service]
Image upload / notification service / special service for POS integration
Recording
frame rate
2 step frame rate (fast on event / Slow on continuous recording mode)
Up to 120 fps in CIF (12.5 KB) when simplex
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Search
Based on the multiple combination of date / time / event using ‘AND’ &
‘OR’ condition
Misc.
Support NTP server
Playback
Forward, reverse, fast forward, fast reverse, single step forward, single
step backward
System hardware
32bit RISC CPU / Embedded Linux / 64MByte SDRAM / 8MByte Flash
Synchronized
playback
8 channels can be played simultaneously
Power
Power Supply - SMPS 12V (5A) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt, Normal : 1.5A, Peak : 3.0A
Backup
Video data can be backed up to a remote computer
In AVI format / FJP format (FlexWATCH AV clip format)
Approvals
FCC, CE, RoHS
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols
from Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
All 8 channels support PTZ controls
Proxy Supported
All Interface to network device through only one standard Web Interface
Video Proxy
Audio Proxy
PTZ Proxy
DI/DO Proxy
LAN
10/100-base-T Ethernet Interface
Dimension /
Weight
215 (W) x 280 (D) x 44(H) (in mm)
1.5Kg (3.3lbs) without Power Supply & HDD
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem
Support ( ISDN, PSTN and GSM )
Working
Environment
Temperature : 41~122 F (5~50 OC)
Humidity : 20~80% RH
* All specifications are subject to change without prior notice
29
High-performance Network Video Recorder for Network camera
IP-8Ch Network Video Recorder
IP-8ch Network Video Recorder, FW-5071 is a stand-alone 8 channel highperformance network video recorder. FW-5071, fully IE browser enabled network video recorder, can display, record
and playback the real time MJPEG, MPEG4 and H.264 video streams transmitted from any FlexWATCH® IP
cameras and video servers over TCP/IP network. It also supports multi-vendors’ IP cameras and Video Servers such
as Axis, Panasonic, Mobotix, Arecont Vision*, IQinvision, Vivotek and so on.
FW-5071 is based on Unified Communication Protocol. Compared with other NVR (s/w or h/w based)
products, FW-5071 requires only single TCP port for remote live view, playback and configuration. It minimizes
network configuration burden and realizes much easier way for video management. By accessing FW-5071 locally
or remotely, IP cameras connected to FW-5071 can be viewed and controlled.
FW-5071 is affordable for a surveillance system for unmanned facilities, retail stores, accommodations,
gas stations, etc. Having an advantage of flexibility of network video devices and digital interfacing to other systems,
and it is also interoperated with various applications like as POS, Access Control, and Building Automation.
Key Features
High Performance
Maximum 120 fps recording at D1 resolution
Maximum 60 fps display at D1
Simultaneous recording, live, playback and backup
Multi-Vendor Supports
Axis, Panasonic, Mobotix, Arecont, IQinvision, Vivotek, etc
Applications
Unified Communication Protocol
Single TCP port only for view, playback and control
FW-5071 is specially designed to meet high-end video
application covering a small-mid size area with various
types of IP cameras and video servers
Followings are recommended application area,
z
Franchise / Branch office Monitoring
z
SOHO / Home Security
z
Unmanned Facility Remote Surveillance
z
Serial Device / POS integrated Application
MJPEG/MPEG-4/H.264 NVR
MJEPG / MPEG-4 / H.264 supports selectively
8ch simultaneous streams
Channel-based User Authentication
Channel based multi level protection for live-cast, PTZ,
DI/DO and audio control
Supported Vendors
30
Technical Specifications
Flex
5071 Network Video Recorder
Video channels
1 ~ 8 IP cameras
HDD management
Disk full notification / Periodic notification via e-mail
HDD error notification via e-mail
HDD error notification using beep sound (for local area notification)
IP camera Brand
FlexWATCH, Axis, Mobotix, Panasonic is supported now.
Arecont vision, IQinVision, and Vivotek, etc.
Please make sure the supported compression format according to the
brand
Security
Channel based user password protection for live-cast, PTZ, alarm output
and audio
Recording
storage
Supports up to 1.5TB HDD by 1 SATA (After update Firmware 4.0)
Anti-vibration & air-cooling system
Dynamic IP
support
Dynamic IP service using www.ipcctvdns.com
Recording
[Video Recording]
MJPEG / MPEG-4 / H.264
Max 120 fps at D1 resolution
[Audio Recording]
G.723 (4-bit, 8KHz), ADPCM IMA and so on
[Data Recording]
POS, ATM, Video Analytics, Access Control and various serial devices
Please make sure the recording streams according to the brand
Software
(default Web
interface)
Live-cast, PTZ control, search and playback through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium III
500 MHz or above or equivalent AMD / 64MByte RAM or above)
Live Casting
8 channels of video, audio and data
Software
(Multi-NVR Player)
Optional (freeware available)
Search and playback video with audio from registered NVR
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium III
500 MHz or above or equivalent AMD / 64MByte RAM or above)
Bandwidth
Management
Frame rate control / Bandwidth control
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128, 256ch
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above )
Recording
condition
Based on the multiple combination of date / time / alarm using ‘AND’ &
‘OR’ condition
Alarm can be generated by motion detection and by a trigger from
digital inputs
System
Integration
Features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP, uPNP,
and ETC
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback, & PTZ
[Service]
Image upload / notification service / special service for POS integration
Recording
frame rate
2 step frame rate (fast on event / Slow on continuous recording mode)
Up to 120 fps at DI (23 KB) when simplex
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Search
Based on the multiple combination of date / time / event using ‘AND’ &
‘OR’ condition
Misc.
Support NTP server
Playback
Forward, reverse, fast forward, fast reverse, single step forward, single
step backward
System hardware
32bit RISC CPU / Embedded Linux / 128MByte SDRAM / 8MByte Flash
Synchronized
playback
8 channels can be played simultaneously
Power
Power Supply - SMPS 12V (5A) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt, Normal : 1.0 Peak : 1.8
Backup
Video data can be backed up to a remote computer
In AVI format / FJP format (FlexWATCH AV clip format)
Approvals
FCC, CE, RoHS
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols
from Pelco, Vicon, Kalatel, Sony, Panasonic, Canon, Honeywell, etc
All 8 channels support PTZ controls
Proxy Supported
All Interface to network device through only one standard Web Interface
Video Proxy
Audio Proxy
PTZ Proxy
DI/DO Proxy
LAN
10/100/1000-base-T Ethernet Interface
Dimension /
Weight
140 (W) x 224 (D) x 44(H) (in mm)
0.95Kg (2.1lbs) without Power Supply & HDD
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line, Modem
Support ( ISDN, PSTN and GSM )
Working
Environment
Temperature : 41~122 F (5~50 OC)
Humidity : 20~80% RH
* All specifications are subject to change without prior notice
Network Diagram
Live view, playback & control
through NVR
(video, audio & data)
Browsers
Internet
FW-5071
Router
POS/ATM,
Video Analytics,
Serial device
31
High Availability Disk-based Video Storage Solution
Enterprise NVR Series with RAID storage
1. Product Overview
FlexWATCH eNVR (FW-eNVR) provides a long-term storage and retrieval solution for video and audio as part of a
FlexWATCH network video installation. Comprised of three key components; management software, a server platform,
and RAID storage, FW-eNVR scales to handle an unlimited number of cameras and users.
FW-eNVR receives MPEG-4 and MJPEG video across the network from FlexWATCH series IP encoders including the
NVS (Network Video Server), NC (Network Camera). Because FW-eNVR is network-based, it is fundamentally different
from conventional digital video recorders (DVRs) and video cassette recorders (VCRs). NVRs can be securely positioned
anywhere on the network, whereas DVRs and VCRs are co-located where the coax from the cameras terminates. A FWeNVR server has a single gigabit ethernet connection coming in, whereas DVRs and VCRs have one connection for each
camera input. This simplification in cabling is a major driver in the adoption of network-based video.
2. Features
All-in-one solution (Comprised a server platform, RAID storage and management software)
Max 64 channels
Recording up to 1920 fps @CIF, NTSC (= 64x30)
Display up to 1080 fps (depends on encoding type and data bandwidth)
Dynamic IP support (AOIP)
Supports all FlexWATCH® above v3.10 (except RTOS version)
3. H/W specification
[RAID controller]
CPU : Intel 80321 64bit RISC
Cache : 512MB
RAID level support: 0,1,3,5,0+1,6 & JBOD
Host channel : Ultra320 x 1
Volume Management : Yes
4. S/W specification
Windows 2003 Professional
FW-Manager 64 channel version
FW-eNVR12
2U / 12 tray
32
worldwide
Integrated Network Video since 1999
[Server platform]
Hot swappable tray
2U Rack / 8 tray (Model: FW-eNVR08)
2U Rack / 12 tray (Model: FW-eNVR12)
3U Rack / 16 tray (Model: FW-eNVR16)
CPU : Intel Quad Core Xeon 2.0GHz, 4MB cache, 1333MHz FSB
Memory: 3GB DDR-2 533/667MHz DIMM
Ethernet port: 2 Gigabit Ethernet Card.
PSU : Hot swap 500W x 2
FlexWATCH® eNVR - Enterprise NVR Series with RAID storage
CPU
Quad core Intel Xeon 2.0G, single processor
Memory
3GByte DDR2 533/667 FBDIMM
Ethernet
Gigabit Ethernet x 2
Storage
Interface
SATA-2 (NCQ support)
Tray
Hot swap tray (8 / 12 / 16)
Power Supply
Hot swap 500W x 2
RAID
controller
on backplane
CPU: Intel 80321 64bit RISC
RAID Level: 0,1,3,5,0+1,6 and JBOD
Host channel: Ultra320 x 1
Cache: 512 MByte
Volume management: YES
Environmental
50~101 F (10~40 C), 10~85% non-condensing RH
Power
consumption
AC 90V ~ 264V Full range, 8A ~ 4A, 47Hz / 63Hz
Dimension
FW-eNVR08:88(H)x482(W)x740(D)mm/3.46(H)x18.98(W)x29.13(D)inch
FW-eNVR12:88(H)x482(W)x740(D)mm/3.46(H)x18.98(W)x29.13(D)inch
FW-eNVR16:133(H)x482(W)x740(D)mm/5.24(H)x18.98(W)x29.13(D)inch
Weight
FW-eNVR08: 25.2kgs / 55.44Lbs w/o HDD
FW-eNVR12: 27.2kgs / 59.84Lbs w/o HDD
FW-eNVR16: 23.3kgs / 51.26Lbs w/o HDD
* Up to 1920 fps recording @ CIF, NTSC
* Up to 1080 fps display (depends on encoding type and data bandwidth)
Camera
display
* Drag & drop display configuration
* Multiple camera group
* Sequential display
* Hot spot (alarm popup) display
Status display
* Show server connection, alarm and recording
* Show system log message
Search
* Immediate access using recording profile
* Based on the multiple combination of date / time / event using 'AND'
& 'OR' condition
Playback
Support VCR like interface
(forward, reverse, fast forward, fast reverse, single step forward, single
step backward)
Synchronized
playback
9 channels can be played simultaneously
Backup
Video data can be backed up to a remote computer
In AVI format / FJP format (FlexWATCH AV clip format)
Audio support
Full duplex live audio
PTZ support
* PTZ panel, On-image PTZ control, Joystick support
* PTZ Preset triggered by event
* PTZ Touring support
HDD
management
Disk full notification via e-mail
Periodic notification via e-mail
HDD error notification via e-mail
Dynamic IP
support
Register FlexWATCH behind dynamic IP
AOIPTM (Always On-IP, http://www.aoip.co.kr)
M-JPEG / MPEG-4
Audio
recording
ADPCM IMA 8Kbps / G.723, 4 bit , 8KHz, Mono
Video
channels
* Support all FlexWATCH video server and network camera
* 64 network video channels
Storage
capacity
(physical size)
Recommended configuration: RAID5 & 1 hot spare (Required space for
management including OS and file system - about 0.8TB)
[ Model: FW-eNVR08 ]
750GB HDD: storage x 7 + hot spare x 1 = 4.49TB
1.00TB HDD: storage x 7 + hot spare x 1 = 5.95TB
[ Model: FW-eNVR12 ]
750GB HDD: storage x 11 + hot spare x 1 = 7.49TB
1.00TB HDD: storage x 11 + hot spare x 1 = 9.99TB
[ Model: FW-eNVR16 ]
750GB HDD: storage x 15 + hot spare x 1 = 10.49TB
1.00TB HDD: storage x 15 + hot spare x 1 = 13.99TB
Software
(FW-Manager)
* Full-featured PC NVR with matrix functionality
* Search and playback video with audio
OS
Windows 2003 Professional
Approvals
FC, CE, RoHS, IRAB
Accessaries
User's manual / Power cord / LAN cable
FW-eNVR08
2U / 8 tray
FW-eNVR16
3U / 16 tray
33
manufacturer
Integrated Network Video since 1999
Video
recording
Performance
FlexWATCHTM Manager
NETWORK DIGITAL VIDEO RECORDING SOLUTION
Globally and Locally manage remote
digital video over the TCP/IP network
Works with all FlexWATCHTM network camera or video server series
Control server connected either Static IP or Dynamic IP address
Up to 10 concurrent access to the video from FwManager or FwManager Remote viewer
Multiple Camera support up to 256 cameras (S/W Model dependent)
Multiple camera grouping and sequential display
On-image or Control panel based Pan/Tilt/Zoom control
PTZ Auto positioning by event and 16 preset support
Highlighted camera view with System log
Powerful recording option by event, motion detection, Schedule and forced recording
option
Powerful search option by frame, time, motion detection and event
Multiple channel search and simultaneous playback
Remote playback of archived video
System log viewer and complier for archiving
File rename and AVI file conversion of archived video
Password protected system access
34
Specification
Supporting Video server
• All FlexWATCHTM network Camera
and video server series with firmware
version 2.0 or above
Display & Recording performance
NETWORK DIGITAL VIDEO RECORDING SOLUTION
• Display only : Max up to 120fps
• Recording only : up to 600fps
• Display & Recording : up to 580fps
for recording & 120fps for display
Camera Display
• Drag & drop camera display
• Multiple Camera group mode &
Sequential display of Camera group
• Highlighted camera view with
system log message
PTZ Device Control
• On-image PTZ and Dialog control
panel option
• Up to 16 preset option
• PTZ Auto positioning on alarm
condition
Video Recording
• Event, software Motion Detecion &
Schedule and forced recording option.
• 2 preset area for Motion filtering
• Use video Database
Video Search and play back
• Search by Schedule, Motion, Event
• Simultaneous multiple channel
playback
• Remote playback archived video in
the FwManager PC over the TCP/IP
network
File Back up
• Archived video file rename option
• AVI file conversion to view archived
video with Window media player.
Server Status window
• Show server status, Alarm status and
recording status through server status
window
System log
• User definable system log message
• System log view and compiler
• Playback by system log
Security level
Alarm Notice
• Password protected system access.
• PC sound been alarm when event is
• system configuration by Admin level
happened
and system monitoring by user level
• Camera status bar blinking in Red when
recording or alarm is triggered.
FwManager Client program
• Bundle software only to view multiple
Disk Management
stream and playback archived video in
• Support PC HDD or network HDD
the FwManager PC
• Disk Circluation option / Pause at full
option
Applications
FW-Manager can unlimitedly used when it is combined with FlexWATCHTM network camera series and other supporting
product from Seyeon Technology. Following could be recommended application area with FW-Manager.
• Centralized local facility monitoring and recording such as Building, Airport, Plant, Dam and Shipyard.
• Centralized remote facility monitoring over the Internet such as Unmanned facility of Telco, Chain store, Gas Station,
Branch Office & construction site.
• Security Alarm Company for visual security and alarm verification.
• System Integration for small to large sized facility
35
Hybrid recording system for analog and networked audio-visual
Network Video Recorder / POS NVR solution
Model No : FW-5450
M-JPEG / MPEG-4 with 2 way audio
MPEG-4 for time-lapse recording
M-JPEG for alarm triggered recording
Audio recording and playback with M-JPEG and MPEG-4
Front view
Hybrid
Supports 4 analog channels and 12 networked channels
Quadplex
Simultaneous recording, live-casting, playback and backup
Full frame rate
Up to 120/100 fps (NTSC/PAL) live-casting @ CIF, 12.5KB, simplex
Up to 120/100 fps (NTSC/PAL) recording @ CIF, 12.5KB, simplex
FlexWATCH POSTM
POS/NVR surveillance platform
Supports ALOHA, RetailPro, Xpient, Squirrel, WAND
Integration is still going on.
Secure & ample storage
Supports up to 750GB of SATA HDD
78 days of CIF-12.5KB video at 1fps from 8 channels
Anti-vibration and air-cooling system
Easy installation and management
Provided with installation wizard application
Full web based management
Quad video output for loop-through
19" rack mount
19" rack mount kits are available
Applications
FW-5450 is an ideal system, wherever secure distribute on-site
recording and live-casting over an IP network is required.
POS (FlexWATCH POSTM)
Franchise
Branch office
SOHO
Unmanned facility
36
Integrated Network Video since 1999
For analog monitor display at local site
Video
recording
M-JPEG / MPEG-4
Audio
recording
ADPCM IMA 8Kbps
Video
channels
Hybrid 16 video channels
(analog 4 channels / network 12 channels)
Recording
storage
HDD
management
Disk full notification via e-mail
Periodic notification via e-mail
HDD error notification via e-mail
HDD error notification using beep sound (for local area notification)
Dynamic IP
support
IP notification by e-mail
AOIPTM (Always On-IP, http://www.aoip.co.kr)
Support upto 750GB HDD by 1 SATA (Seagate brand)
Anti-vibration & air-cooling system
Security
Channel based user password protection for live-cast, PTZ, alarm
output and audio
Compression
Level
6 levels (low compression / highest / high / normal / low / lowest)
Software
(default Web
interface)
Live-cast, PTZ control, search and playback through Web browser
with audio
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium
III 500 MHz or above or equivalent AMD / 64MByte RAM or above)
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
Software
(Multi-NVR
Player)
Optional (freeware available)
Search and playback video with audio from registered FW5450
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium
III 500 MHz or above or equivalent AMD / 64MByte RAM or above)
Software
(FW-Manager
3.xx)
Supports 16, 25, 36, 64, 128 & 256 ch (sold separately, 9ch freeware
available)
Full-featured PC NVR with matrix functionality
(Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above /
256MByte RAM or above / 64MByte video memory or above /
CDROM )
System
integration
features
[Protocol]
HTTP, TCP/IP, ARP, ICMP, Telnet, Ftp, PPPoE, SMTP, DHCP, NTP
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback & PTZ
[Service]
Image upload service / notification service
Installation
and
maintenance
Configuration : installation wizard, HTTP, telnet and console
Upgrade firmware : HTTP, telnet & ftp (firmwares are available at
www.flexwatch.com)
Misc.
Timestamp on video
Transmit serial input data with video
Different time zones are supported
Data and time can be synchronized with an external NTP server
Live-cast for up to 32 clients
Playback for up to 30 clients
System
hardware
32bit RISC Processor / Embeded Linux / 64MByte SDRAM / 8MByte
Flash
DC 12V/1.5A~3A(pick), 32~122 F (0~50 C), 20~80% RH
Approvals
MIC, FCC, CE, RoHS
Accessaries
CD with installation wizard / User's manual / Quick installation manual
/ SMPS 12V (5A) [AC100~240V, 50/60Hz] / Power cord / LAN cable
Connectors
4 video inputs & 1 composite output Quad display (75 ohm/Hi-Z)
10/100 BaseT Ethernet (auto-sensing)
4 opto-coupled inputs or 4 digital inputs (NC/NO selectable)
4 relay outputs
4 audio input / 1 audio output
Reset button for factory default
2 serial port (COM: RS-232, AUX: RS-232 or RS-485)
Dimension
215(W) x 280 (D) x 45(H) (in mm) / 19" 1U Rack mount kit
Weight
1.34Kg(2.95 lbs) wo HDD
Live Casting
Streaming 16 video channels with full duplex live audio
Up to 120 fps @ CIF (12.5KB) when simplex
Network
through-put
control
Frame rate control / Bandwidth control / CBR
Recording
condition
Based on the multiple combination of date / time / alarm using 'AND'
& 'OR' condition
Alarm can be generated by motion detection and by a trigger from
digital inputs
Recording
frame rate
2 step frame rate (fast on event / slow on timelapse mode)
Up to 120 fps @ CIF (12.5KB) when simplex
Search
Based on the multiple combination of date / time / event using 'AND'
& 'OR' condition
Playback
Support VCR like interface
(forward, reverse, fast forward, fast reverse, single step forward,
single step backward)
Synchronize
d playback
9 channels can be played simultaneously
Backup
Video data can be backed up to a remote computer
In AVI format / FJP format (FlexWATCH AV clip format)
Audio
support
Full duplex live audio
All 16 channel support audio (if supported)
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ protocols
from Pelco, Vicon, Kalatel,Sony, Panasonic, Canon, Honeywell and
etc
All 16 channels support PTZ control
UART
support
Console
By-pass command to control UART device
X10 device command to control device over power line
Modem (Support PSTN, ISDN or GSM)
Alarm
management
(For 4 analog
channels)
[Trigger]
Video loss / Video recovered / Motion detection (144 area) / 4 alarm
inputs / Boot finished / Serial input / Schedule / Trigger combination is
possible
[Service]
Image holding service (Max 19.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 4 alarm outputs
37
Hybrid recording system for analog and networked audio-visual
Hybrid Network Video Recorder
8ch NVR, FW-5850
is a stand-alone, Hybrid Network Video Recorder which provides full feature
of video server and recorder. It can transmit, record, and playback the real time MJPEG, MPEG4 and H.264 video
stream not only from directly connected analog cameras but also the remote IP-cameras or video-servers that
registered to NVR. The FW-5850 has 8 internal composite video inputs and supports additional 8 external network
channels of IP camera or video server. Besides, FW-5850 can works with other IP cameras and video servers such
as Axis, Panasonic, Mobotix, Arecont Vision*, IQinvision*, Vivotek* and so on.
FW-5850 is based on Unified Communication Protocol. Compared with other NVR(software based and
hardware based) products, FW-5450 requires only single TCP port for remote live view, playback and configuration.
It minimizes network configuration burden and realizes much easier way for video management. By accessing FW5850 locally or remotely, other IP cameras as well as FlexWATCH’s one connected to FW-5850 can be viewed and
controlled.
The FlexWATCH® NVR is affordable for sites that can be expanded from fixed analog channels to
additional network cameras. The FlexWATCH NVR is widely used as a surveillance system for unmanned facilities,
retail stores, accommodations, gas stations, etc. Having an advantage of flexibility of network video devices and
digital interfacing to other systems, the NVR is also interoperated with various applications like as POS, Access
Control, and Building Automation.
Key Features
Hybrid NVR system
8 analog and 8 networked channels
Up to 120/100fps (NTSC/PAL) liveview @CIF
Simultaneous recording, live, playback and backup
Multi-Vendor Supports
Axis, Panasonic, Mobotix, IQinvision, Arecont vision,
Vivotek, FlexWATCH, etc
Unified Communication Protocol
Single TCP port only for view, playback and control
Applications
FW-5850 is an ideal system, wherever secure distribute onsite recording and live-casting over the IP network is
required.
z
Franchise / Branch office Monitoring
z
SOHO / Home Security
z
Unmanned Facility Remote Surveillance
z
Serial Device / POS integrated Application
MJPEG/MPEG-4/H.264 NVR
MJPEG / MPEG-4 / H.264 supports selectively
16ch simultaneous streams
Diverse I/O
8 Audio In / 1 Audio Out
8 DI/DO port, RS-485/232 for PTZ
Multiplexed composite video output for 8ch.
Add-on service
User defined serial device integration as a default
POS data integrations optionally
Rack mountable
1U size suitable for 19” rack
Supported Vendors
38
Technical Specifications
5850 Network Video Recorder
Video channels
IP camera Brand
Recording
storage
Recording
Hybrid 16 video channels
(Analog 8 channels / Network 8 channels)
Analog channels are compressed by MPEG4
Network channels are MJPEG/MPEG/H.264
FlexWATCH, Axis, Mobotix, Panasonic is supported now.
Arecont vision, IQinVision, and Vivotek, etc.
Please make sure the supported compression format
according to the brand
Supports up to 1.5TB HDD by 1 SATA (After update
Firmware 4.0)
Anti-vibration & air-cooling system
[Video Recording]
MJPEG / MPEG-4 / H.264 Video stream recording
Max 120 fps at CIF resolution
[Audio Recording]
G.723 (4-bit, 8KHz) stream recording
[Data Recording]
POS, ATM, Video Analytics, Access Control and various
serial devices
Alarm
Management
(for 8 analog
channels)
[ Trigger Condition ]
Video loss / Video recovered / Motion detection (144 area) /
8ch alarm inputs / Boot finished / Serial input / Schedule
[ Alarm Service ]
Image holding service (Max 19.2MByte pre-post alarm buffer)
Image upload service through E-mail / FTP (support pre & post)
Notification service through TCP / UDP / HTTP / 8 alarm outputs
HDD management
Disk full notification / Periodic notification via e-mail
HDD error notification via e-mail
HDD error notification using beep sound (for local area notification)
Security
Channel based user password protection for live-cast, PTZ, alarm output and audio
Dynamic IP
support
Dynamic IP service using www.ipcctvdns.com
Resolution
4CIF - 704x480 (NTSC) / 704x576 (PAL)
2CIF - 704x240 (NTSC) / 704x288 (PAL)
CIF - 352x240 (NTSC) / 352x288 (PAL)
QCIF - 176x112 (NTSC) / 176x144 (PAL)
Software
(default Web
interface)
Live-cast, PTZ control, search and playback through Web browser
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium III 500 MHz
or above or equivalent AMD / 64MByte RAM or above)
Live Casting
Streaming 8 video channels with full duplex live audio
Up to 120 [email protected] CIF (12.5KB) when simplex
Software
(Multi-NVR Player)
Optional (freeware available)
Search and playback video with audio from registered FW-5850
(Minimum PC requirement - XP, 2000, Vista / IE 6.x or later / Pentium III 500 MHz
or above or equivalent AMD / 64MByte RAM or above)
Bandwidth
Management
Frame rate control / Bandwidth control / CBR / VBR
Software
(FW-Manager 3.xx)
Supports 16, 25, 36, 64, 128, 256ch ( 9ch freeware available)
Full-featured PC NVR with matrix functionality
( Minimum PC requirement - XP, 2000 / Pentium IV 1.6GHz or above / 256MByte
RAM or above / 64MByte video memory or above )
Recording
condition
Based on the multiple combination of date / time / alarm
using ‘AND’ & ‘OR’ condition
Alarm can be generated by motion detection and by a trigger
from digital inputs
System
Integration
Features
[Protocol]
HTTP, TCP/IP, RTP/RTSP, Multicast, 3GPP, ARP, ICMP, Telnet, Ftp, PPPoE,
SMTP, DHCP, uPNP, NTP (Some of protocols are only for built-in module)
[SDK]
Open HTTP API / ActiveX for live-cast with audio, playback, & PTZ
[Service]
Image upload / notification service / special service for POS integration
Recording
frame rate
2 step frame rate (fast on event / Slow on continuous
recording mode)
Up to 120 fps in CIF (12.5KB) when simplex
Installation and
maintenance
Configuration: installation wizard, HTTP, telnet and console.
Upgrade firmware: HTTP, telnet & ftp
Search
Based on the multiple combination of date / time / event
using ‘AND’ & ‘OR’ condition
Misc.
OSD (On-Screen Display) / Time-stamp on video
Transmit serial input data with video
Support NTP server
Quick Time and VLC media player compatible for live view (built-in module)
Playback
Forward, reverse, fast forward, fast reverse, single step
forward, single step backward
System hardware
32bit RISC CPU / Embedded Linux / 64MByte SDRAM / 8MByte Flash
Synchronized
8 channels can be played simultaneously
Power
Power Supply - SMPS 12V (5A) [AC100~240V, 50/60Hz]
Power Consumption - DC12Volt, Normal : 2.0A, Peak : 3.5A
Backup
Video data can be backed up to a remote computer
In AVI format / FJP format (FlexWATCH AV clip format)
Approvals
FCC, CE, RoHS
PTZ support
Built-in PTZ device protocol with more than 30 different PTZ
protocols from Pelco, Vicon, Kalatel, Sony, Panasonic,
Canon, Honeywell, etc
All 16 channels support PTZ controls
External Interface
8ch video inputs & 1 composite output, 3x3 Multiplexed display (75 ohm/Hi-Z)
10/100-Base-T Ethernet (auto-sensing)
8 photo-coupled or 8 digital inputs (NC/NO selectable), 8 relay outputs
8 audio input / 1 audio output
2 serial ports (COM: RS-232, AUX: RS-232 or RS-485)
Audio support
8ch audio-in & 1ch audio-out
Dimension /
Weight
215 (W) x 290 (D) x 44(H) (in mm)
1.71Kg(3.77lbs) without Power Supply & HDD
UART support
Console, By-pass command to control UART device
X10 device command to control device over power line,
Modem Support ( ISDN, PSTN and GSM )
Working
Environment
Temperature : 41~122 F (5~50 OC)
Humidity : 20~80% RH
* All specifications are subject to change without prior notice
Accessory
19" 1U rack mount kit
Sold separately
39
•CMS (Centralized Management System)
•CMS-3rd party
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
40
CMS (Centralized Management System)
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
41
CMS (Centralized Management System)
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
42
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
43
CMS 3rd party
with access control
CMS 3rd party with access control
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
44
CMS 3rd party
with access control
CMS 3rd party with access control
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
45
CMS 3rd party with touch screen
• Customized touch screen
-
-
ALFATECH engineering experts provides
customized touch screen application which
can be applied to CMS security solution
using open architecture.
Experts supports touch screen system
integration for customer oriented solution
•
•
•
•
•
•
•
•
•
•
Full compatibility with security CMS
Cost effective & user convenience
Programming level support
Full customized by user requirement
Timely implement
Integrate existing solutions
Web / Exe / Flash type available
Fancy GUI, Advertisement available
Any resolution available
10 inches to 100 inches screen
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
46
CMS (Centralized Management System)
With customizable system
using 3rd Party
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
47
Technical solution division – [email protected]
ALFA&OMEGA ELECTRIC,S.E • P.O Box 1788, Bayamon, Puerto Rico • WWW.ALFATECHSOLUTIONS.COM
• Tel : (787)-799-7059 • (787)-797-5950 • [email protected]
48
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
