Si5355

Si5355

S i 5 3 5 5

A

N Y

- F

R E Q U E N C Y

1 – 2 0 0 M H

Z

Q

U A D

F

R E Q U E N C Y

8 - O

U T P U T

C

L O C K

G

E N E R A T O R

Features

Generates any frequency from 1 to

200 MHz on each of the 4 output banks

Eight CMOS clock outputs

Guaranteed 0 ppm frequency synthesis error for any combination of frequencies

25 or 27 MHz xtal or 5–200 MHz input clk

Five programmable control pins (output enable, frequency select, reset)

Separate OEB pins to disable individual banks or all outputs

Loss of signal output

Low 50 ps (typ) pk-pk period jitter

Phase jitter: 2 ps rms 12 kHz–20 MHz

Excellent PSRR performance eliminates need for external power supply filtering

Low power: 45 mA (core)

Core VDD: 1.8, 2.5, or 3.3 V

Separate VDDO for each bank of outputs: 1.8, 2.5, or 3.3 V

Small size: 4x4 mm 24-QFN

Industrial temperature range:

–40 to +85 °C

Custom versions available using

ClockBuilder™ web utility

Samples available in 2 weeks

Applications

Printers

Audio/video

Networking

Communications

Storage

Switches/routers

Computing

Servers

OC-3/OC-12 line cards

Description

The Si5355 is a highly flexible clock generator capable of synthesizing four completely non-integer related frequencies up to 200 MHz. The device has four banks of outputs with each bank supporting two CMOS outputs at the same frequency. Using Silicon Laboratories' patented MultiSynth fractional divider technology, all outputs are guaranteed to have 0 ppm frequency synthesis error regardless of configuration, enabling the replacement of multiple clock ICs and crystal oscillators with a single device. Through a flexible web configuration utility called ClockBuilder™ ( www.silabs.com/ClockBuilder ), factory-customized pincontrolled Si5355 devices are available in two weeks without minimum order quantity restrictions. The Si5355 supports up to three independent, pin-selectable device configurations, enabling one device to replace three separate clock ICs.

Ordering Information:

See page 17.

Pin Assignments

Functional Block Diagram

Rev. 1.1 1/13 Copyright © 2013 by Silicon Laboratories Si5355

S i 5 3 5 5

2 Rev. 1.1

Si5355

T

A B L E O F

C

O N T E N TS

Section Page

1. Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Typical Application Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3. Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.1. Input Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

3.2. Breakthrough MultiSynth Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

3.3. Input and Output Frequency Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.4. Multi-Function Control Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.5. Output Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.6. Frequency Select/Device Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.7. Loss-of-Signal Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.8. CMOS Output Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.9. Jitter Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.10. Power Supply Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.11. ClockBuilder Web-Customization Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

4. Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5. Ordering Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

5.1. Evaluation Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

6. Package Outline: 24-Lead QFN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

7. Recommended PCB Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

8. Top Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

8.1. Si5355 Top Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

8.2. Top Marking Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Document Change List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Rev. 1.1

3

S i 5 3 5 5

1. Electrical Specifications

Table 1. Recommended Operating Conditions

(V

DD

= 1.8 V –5% to +10%, 2.5 or 3.3 V ±10%, T

A

= –40 to 85 °C)

Parameter

Ambient Temperature

Core Supply Voltage

Symbol

T

A

V

DD

Test Condition Min

–40

2.97

2.25

Typ

3.3

2.5

Max

85

3.63

2.75

Units

o

C

V

1.71

1.8

1.98

Output Buffer Supply Voltage

V

DDO

1.71

— 3.63

V

Note:

All minimum and maximum specifications are guaranteed and apply across the recommended operating conditions. Typical values apply at nominal supply voltages and an operating temperature of 25 °C unless otherwise noted.

Table 2. DC Characteristics

(V

DD

= 1.8 V –5% to +10%, 2.5 or 3.3 V ±10%, T

A

= –40 to 85 °C)

Parameter

Core Supply Current

Output Buffer Supply Current

High Level Input Voltage

Low Level Input Voltage

Clock Output High Level Output

Voltage

Pn Input Resistance

Symbol

I

DD

I

DDOx

V

V

V

OH

Clock Output Low Level Output Voltage

V

OL

LOS Low Level Output Voltage

V

OLLOS

R

IH

IL

IN

Test Condition

100 MHz on all outputs,

25 MHz refclk

CMOS, 50 MHz

15 pF load

CMOS, 200 MHz

3.3 V VDD0

CMOS, 200 MHz

2.5 V

CMOS, 200 MHz

1.8 V

CLKIN, P1

P4, P5

P2, P3

CLKIN, P1, P2, P3

P4,P5

Pins: CLK0-7

I

OH

= –4 mA

Pins: CLK0-7

I

OL

= +4 mA

I

Pin: LOS

OL

= +3 mA

Min

0.8 x V

DD

0.85

1.6

–0.2

V

DDO

– 0.3

0

Typ

45

6

13

10

7

Max

60

9

18

14

10

3.63

1.3

— 3.63

— 0.2 x V

DD

— 0.3

— —

20

0.3

0.4

Units

mA mA mA mA mA

V

V

V

V

V

V

V

V k

4 Rev. 1.1

Si5355

Table 3. AC Characteristics

(V

DD

= 1.8 V –5% to +10%, 2.5 or 3.3 V ±10%, T

A

= –40 to 85 °C)

Parameter Symbol Test Condition Min

Input Clock

Clock Input Frequency

Clock Input Rise/Fall Time

Clock Input Duty Cycle

T

F

IN

R

/T

DC

F

20–80% V

DD

10–90% V

DD

Input tr/tf within specified limits shown above

Clock Input Capacitance

Output Clocks

C

IN

Clock Output Frequency

Clock Output Frequency Synthesis

Resolution

Output Load Capacitance

Clock Output Rise/Fall Time

Clock Output Rise/Fall Time

Clock Output Duty Cycle

Powerup Time

Output Enable Time

Reset Minimum Pulse Width

Output-Output Skew

F

T

T

F

C

R

O

RES

L

R

/T

/T

DC

T

PU

T

OEB

F

F

T

RESET

T

SKEW

See "3.3. Input and Output

Frequency Configuration" on page 10

0

20 to 80% V

DD

C

L

= 15 pF

,

20 to 80% V

DD

C

L

= 2 pF

,

1

POR to output clock valid

45

–150 Outputs at same frequency, f

OUT

> 5 MHz

10000 cycles*

10000 cycles*

12 kHz to 20 MHz

Period Jitter

Cycle-Cycle Jitter*

Phase Jitter

PLL Loop Bandwidth

J

PPKPK

J

CCPK

J

PH

F

BW

Interrupt Status Timing

CLKIN Loss of Signal Assert Time

CLKIN Loss of Signal Deassert

Time

LOS Rise/Fall Time (20–80%) t t

LOS

LOS_b

T

R

/T

F

C

*Note:

Measured in accordance to JEDEC Standard 65.

L

< 10 pF, pullup < 1 k

0.01

5

40

Typ

2

0

0.45

2.6

0.2

50

50

40

2

1.6

Max

200

2.3

4

60

200

1

15

2.0

0.85

55

2

10

200

+150

5

1

10

75

70

Units

% ms

µs ns ps

MHz ns ns

% pF

MHz ppb pF ns ns ps pk-pk ps pk ps rms

MHz

µs

µs ns

Rev. 1.1

5

6

S i 5 3 5 5

Table 4. Crystal Specifications

Parameter

Crystal Frequency

Symbol

F

XTAL

Test Condition

Option 1

Option 2

Min

Typ

25

Max

Units

MHz

Load Capacitance (on-chip differential)

Crystal Output Capacitance

Equivalent Series Resistance c

L c

L

(supported)*

(recommended)

C

O

ESR 25 MHz

27 MHz

11

17

27

12

18

13

19

5

100

75

MHz pF pF pF

Crystal Drive Level Rating d

L

100 — — µW

*Note:

See "AN360: Crystal Selection Guide for Si533x and Si5355/56 Devices" for how to accommodate a 12 pF crystal C

L

.

Table 5. Thermal Conditions

Parameter

Thermal Resistance Junction to Ambient

Thermal Resistance Junction to Case

Symbol

JA

JC

Test Condition

Still Air

Still Air

Value

37

25

Units

o

C/W o

C/W

Table 6. Absolute Maximum Ratings

1,2,3,4

Parameter

Supply Voltage Range

Input Voltage Range (all pins except pins 1,2,5,6)

Input Voltage Range (pins 1,2,5,6)

Output Voltage Range

Junction Temperature

ESD Tolerance

Latch-up Tolerance

Soldering Temperature (Pb-free profile)

5

Soldering Temperature Time at T

PEAK

(Pb-free profile)

5

Symbol

V

DD

V

I

V

I2

V

O

T

J

HBM

CDM

MM

LU

T

PEAK

T

P

Rating

–0.5 to 3.8

–0.5 to 3.8

–0.5 to 1.3

–0.5 to (V

DD

+ 0.3)

–55 to +150

2.5

550

175

JESD78 Compliant

260

20–40

Units

V

V

V

V o

C kV

V

V o

C sec

Notes:

1.

Permanent device damage may occur if the Absolute Maximum Ratings are exceeded. Functional operation should be restricted to the conditions as specified in the operational sections of this data sheet. Exposure to maximum rating conditions for extended periods may affect device reliability.

2.

24-QFN package is RoHS compliant.

3.

For more packaging information, go to www.silabs.com/support/quality/pages/RoHSInformation.aspx

.

4.

Moisture sensitivity level is MSL3.

5.

The device is compliant with JEDEC J-STD-020.

Rev. 1.1

Si5355

2. Typical Application Circuit

+3.3 V

0.1 uF Power Supply

Decoupling Capacitors

(1 per VDD or VDDOx pin)

Loss Of

Signal

Programmable

Input Pins

7 24 20 16 15 11

+3.3V

1k

Rse

Rse

25 MHz

XTAL

8

LOS

3

12

19

P1

P2

P3

5

P4

6

P5

1

2

4

XA

XB

CLKIN

Si5355

CLK0

CLK1

CLK2

CLK3

CLK4

CLK5

CLK6

CLK7

22

21

18

17

9

14

13

10 x x

Rsh Rsh

Note: See section 3.1 for information on selecting

Rse and Rsh.

4-Port Ethernet Switch/Router

33/66 MHz

MCU/

Processor

25 MHz

25 MHz

25 MHz

25 MHz

125 MHz

Ethernet

Switch

Ethernet

PHY

PHY

Ethernet

PHY

Laser Printer

0.1 uF Power Supply

Decoupling Capacitors

(1 per VDD or VDDOx pin)

+3.3 V

Ethernet

PHY

USB

Controller

7 24 20 16 15 11

Loss Of

Signal

25 MHz

XTAL

+3.3V

1k

Programmable

Input Pins

Note: See section 3.1 for information on selecting

Rse and Rsh.

Rse

Rse

Rsh

8

LOS

3

12

19

P1

P2

P3

5

P4

6

P5

1

2

XA

XB

4

CLKIN

Si5355

CLK0

CLK1

CLK2

CLK3

CLK4

CLK5

CLK6

CLK7

22

21

18 x

17

14 x

13

10 x

9 x

125 MHz

Rsh

48 MHz

66/100 MHz

35.788 MHz

Touchscreen

Controller

Processor

DDR

Memory

Print Head

Paper Tray

Key Pad

LCD Screen

Rev. 1.1

7

S i 5 3 5 5

3. Functional Description

Figure 1. Si5355 Functional Block Diagram

3.1. Input Configuration

The Si5355 input can be driven from either an external crystal or a reference clock. Reference selection is made when the device configuration is specified using the ClockBuilder™ web-based utility available at www.silabs.com/

ClockBuilder . If the crystal input option is used, the Si5355 operates as a free-running clock generator. In this mode of operation the device requires a low-cost 25 or 27 MHz fundamental mode crystal connected across XA and XB

as shown in Figure 2. Given the Si5355’s frequency flexibility, the same 25 or 27 MHz crystal can be reused to

generate any combination of output frequencies. Custom frequency crystals are not required. The Si5355 integrates the crystal load capacitors on-chip to reduce external component count. The crystal should be placed very close to the device to minimize stray capacitance. To ensure stable oscillation, the recommended crystal

specifications provided in Table 4 on page 6 must be followed. See AN360 for additional details regarding crystal

recommendations.

XTAL

Si5355

XA

XB

Figure 2. Connecting an XTAL to the Si5355

For synchronous timing applications, the Si5355 can lock to a 5 to 200 MHz CMOS reference clock. A typical

interface circuit is shown in Figure 3. A series termination resistor matching the driver’s output impedance to the

impedance of the transmission line is recommended to reduce reflections.

Rs

50

Si5355

CLKIN

Figure 3. Interfacing CMOS Reference Clocks to the Si5355

8 Rev. 1.1

Si5355

Control input signals to P4 and P5 cannot exceed 1.3 V, yet also must meet the V

OH

and V

OL

specifications

outlined in Table 2 on page 4. When these inputs are driven from CMOS sources, a resistive attenuator as shown

in the Typical Application Circuits must be used. Suggested standard 1% resistor values for Rse and Rsh are

shown in Table 7.

Table 7. 1% Resistor Values

CMOS Level

1.8 V

2.5 V

3.3 V

Rse (

)

1000

1960

3090

Rsh (

)

1580

1580

1580

3.2. Breakthrough MultiSynth Technology

Next-generation timing architectures require a wide range of frequencies which are often non-integer related.

Traditional clock architectures address this by using a combination of single PLL ICs, 4-PLL ICs and discrete XOs, often at the expense of BOM complexity and power. The Si5355 uses patented MultiSynth technology to dramatically simplify timing architectures by integrating the frequency synthesis capability of 4 phase-locked loops

(PLLs) in a single device, greatly minimizing size and power requirements versus traditional solutions. Based on a fractional-N PLL, the heart of the architecture is a low phase noise, high-frequency VCO. The VCO supplies a high frequency output clock to the MultiSynth block on each of the four independent output paths. Each MultiSynth operates as a high-speed fractional divider with Silicon Laboratories' proprietary phase error correction to divide down the VCO clock to the required output frequency with very low jitter.

The first stage of the MultiSynth architecture is a fractional-N divider which switches seamlessly between the two closest integer divider values to produce the exact output clock frequency with 0 ppm error. To eliminate phase error generated by this process, MultiSynth calculates the relative phase difference between the clock produced by the fractional-N divider and the desired output clock and dynamically adjusts the phase to match the ideal clock waveform. This novel approach makes it possible to generate any output clock frequency without sacrificing jitter performance. Based on this architecture, the output of each MultiSynth can produce any frequency from 1 to

200 MHz.

MultiSynth

Fractional-N

Divider

Phase

Adjust f

VCO

f

OUT

Phase Error

Calculator

Divider Select

(DIV1, DIV2)

Figure 4. Silicon Labs' MultiSynth Technology

Rev. 1.1

9

S i 5 3 5 5

3.3. Input and Output Frequency Configuration

The Si5355 utilizes a single PLL-based architecture, four independent MultiSynth fractional output dividers, and a

MultiSynth fractional feedback divider such that a single device provides the clock generation capability of 4 independent PLLs. Unlike competitive multi-PLL solutions, the Si5355 can generate four unique non-integer related output frequencies with 0 ppm frequency error for any combination of output frequencies. In addition, any combination of output frequencies can be generated from a single reference frequency without having to change the crystal or reference clock frequency between frequency configurations.

The Si5355 frequency configuration is set when the device configuration is specified using the ClockBuilder webbased utility available at www.silabs.com/ClockBuilder . Any combination of output frequencies ranging from 1 to

200 MHz can be configured on each of the device outputs. Up to three unique device configurations can be specified in a single device, enabling the Si5355 to replace 3 different clock generators.

3.4. Multi-Function Control Inputs

The Si5355 supports 5 user-defined input pins (pins 3, 5, 6, 12, 19) that are customizable to support the functions listed below. The pinout of each device is customized using the ClockBuilder utility. This enables the device to be

custom tailored to a specific application. Each of the different functions is described in Table 8.

Pin Function

OEB_ALL

OEB_A

OEB_B

OEB_C

OEB_D

FS0

FS1

RESET

Table 8. Multi-Function Control Inputs Description

Description

Output Enable All.

All outputs enabled when low.

Output Enable Bank A.

CLK0/1 enabled when low.

Output Enable Bank B.

CLK2/3 enabled when low.

Output Enable Bank C.

CLK4/5 enabled when low.

Output Enable Bank D.

CLK6/7 enabled when low.

Frequency Select.

Selects active device frequency plan from factoryconfigured profiles.

Frequency Select.

Selects active device frequency plan from factoryconfigured profiles.

Reset.

Device reset required to change FS[1:0] pin setting.

Assignable Pin Name

P1, P2, P3, P4, or P5

P1, P2, P3, P4, or P5

P1, P2, P3, P4, or P5

P1, P2, P3, P4, or P5

P1, P2, P3, P4, or P5

P2

P3

P1, P3, P4, P5

10 Rev. 1.1

Si5355

3.5. Output Enable

Each of the device’s four banks of CMOS clock outputs can be individually disabled using OEB_A, OEB_B,

OEB_C, and OEB_D for CLK0/1, CLK2/3, CLK4/5, and CLK6/7, respectively. Alternatively, all clock outputs can be disabled using the master output enable OEB_ALL. When a Si5355 clock output bank is disabled, both outputs are driven to an active low state. When one or more banks of clock outputs are enabled or disabled, clock start and stop transitions are handled glitchlessly.

3.6. Frequency Select/Device Reset

The device frequency plan is customized using the ClockBuilder web utility. The Si5355 optionally supports up to three unique, pin-selectable configurations per device, enabling one device to replace up to three separate clock

ICs. To select a particular frequency plan, set the FS pins as outlined below:

For custom Si5355 devices configured to support two frequency plans, the FS1 pin should be set as shown in

Table 9:

Table 9. FS1 Pin Logic for 2 Profile Devices

FS1

0

1

Profile

1

2

For custom Si5355 devices configured to support three frequency plans, the FS1 and FS0 pins should be set as

shown in Table 10:

Table 10. FS1/FS0 Pin Logic for 3 Profile Devices

FS1

0

0

1

1

FS0

0

1

0

1

Profile

Reserved

1

2

3

I f a change is made to the FS pin settings, the device reset pin (RESET) must be held high for the minimum pulse

width specified in Table 3 on page 5 to change the device configuration. The output clocks will be momentarily

squelched until the device begins operation with the new frequency plan.

If the RESET pin is not selected in ClockBuilder as one of the five programmable pins, a power-on reset must be applied for an FS pin change to take effect.

3.7. Loss-of-Signal Alarm

The Si5355 includes an interrupt pin that monitors for both loss of PLL lock (LOL) and loss of input signal (LOS) conditions. The LOS pin is asserted whenever LOL or LOS is true. The LOS condition occurs when there is no input clock to the device. When an input clock is removed, the LOS pin will assert, and the output may drift up to

5%. The LOL condition occurs when there is a reference present but it is off in frequency by a significant amount.

In this condition, the LOS pin will assert and the output will be disabled. When the input clock with an appropriate frequency is reapplied, the LOS pin will de-assert. Note that the LOS pin is an open-drain output.

Rev. 1.1

11

S i 5 3 5 5

3.8. CMOS Output Drivers

The Si5355 has 4 banks of outputs with each bank comprised of 2 clocks for a total of 8 CMOS outputs per device.

Each of the output banks can operate from a different VDDO supply (1.8 V, 2.5 V, 3.3 V), simplifying usage in mixed supply applications. All clock outputs between 1 and 200 MHz are in-phase with minimal output-to-output

skew (see Table 3 on page 5 for specification). When an output bank is disabled using any of the OEB functions,

the clock outputs are stopped low.

The CMOS output driver has a controlled impedance in the range of 42 to 50

which includes an internal 22  series resistor. An external series resistor is not needed when driving 50

 traces. If higher impedance traces are

used then a series resistor may be added. A typical configuration is shown in Figure 5.

Bank A

MultiSynth

Si5355

VDDOA

+1.8V, +2.5V, +3.3V

CLK0

CLK1

50

50

PLL

Bank B

MultiSynth

VDDOB

+1.8V, +2.5V, +3.3V

CLK2

CLK3

50

50

Bank C

MultiSynth

VDDOC

+1.8V, +2.5V, +3.3V

CLK4

CLK5

50

50

Bank D

MultiSynth

VDDOD

+1.8V, +2.5V, +3.3V

CLK6

CLK7

50

50

Figure 5. CMOS Output Driver Configuration

12 Rev. 1.1

Si5355

3.9. Jitter Performance

The Si5355 provides consistently low jitter for any combination of output frequencies. The device leverages a low phase noise single PLL architecture and Silicon Laboratories’ patented MultiSynth fractional output divider technology to deliver excellent jitter performance guaranteed across process, temperature, and voltage. The

Si5355 provides superior performance to conventional multi-PLL solutions which may suffer from degraded jitter performance depending on frequency plan and the number of active PLLs.

3.10. Power Supply Considerations

The Si5355 has 2 core supply voltage pins (V

DD

) and 4 clock output bank supply voltage pins (V

DDOA

–V

DDOD

), enabling the device to be used in mixed supply applications. The Si5355 does not require ferrite beads for power supply filtering. The device has extensive on-chip power supply regulation to minimize the impact of power supply

noise on output jitter. Figure 6 is a curve of additive phase jitter with power supply noise. Note that even when a

significant amount of noise is applied to the device power supply, additive phase jitter is still very small.

10

9

8

7

6

5

4

3

2

1

0

0.0001

VDDO

VDD

0.001

0.01

0.1

Modulation Frequency (MHz)

1

Figure 6. Peak-to-Peak Additive Phase Jitter from 100 mV Sine Wave on Supply

3.11. ClockBuilder Web-Customization Utility

ClockBuilder is a web-based utility available at www.silabs.com/ClockBuilder that allows hardware designers to tailor the Si5355’s flexible clock architecture to meet any application-specific requirements and order custom clock samples. Through a simple point-and-click interface, users can specify any combination of input frequency and output frequencies and generate a custom part number for each application-specific configuration. There are no minimum order quantity restrictions.

ClockBuilder enables mass customization of clock generators. This allows a broader range of applications to take advantage of using application-specific pin controlled clocks, simplifying design while eliminating the firmware development required by traditional I

2

C-programmable clock generators.

Based on Silicon Labs’ patented MultiSynth technology, the device PLL output frequency is constant and all clock output frequencies are synthesized by the four MultiSynth fractional dividers. All PLL parameters, including divider settings, VCO frequency, loop bandwidth, charge pump current, and phase margin are internally set by the device during the configuration process. This ensures optimized jitter performance and loop stability while simplifying design.

Rev. 1.1

13

S i 5 3 5 5

4. Pin Descriptions

Top View

24

XA

1

XB

2

P1

3

CLKIN

4

P4

5

P5 6

7

23

8 9

22 21

10

20

11

19

18 CLK2

17 CLK3

16 VDDOB

15 VDDOC

14

CLK4

12

13

CLK5

Note:

Center pad must be tied to GND for normal operation.

Table 11. Si5355 Pin Descriptions

Pin # Pin Name I/O

1

2

XA

XB

I

External Crystal.

Description

If a 25 or 27 MHz crystal is used as the device frequency reference, connect it across

XA and XB. If an input clock is used on pin 4, this pin should be tied to GND.

I

External Crystal.

If a 25 or 27 MHz crystal is used as the device frequency reference, connect it across

XA and XB. If an input clock is used on pin 4, this pin should be tied to GND.

3

4

P1

CLKIN

I

Multi-Function Input (3.3 V Tolerant).

This pin functions as a multi-function input pin. The pin function (OEB_ALL, OEB_A,

OEB_B, OEB_C, OEB_D, or Reset) is user-selectable at time of configuration using the

ClockBuilder configuration utility.

I

Single-Ended Input Clock.

If a single-ended clock is used as the device frequency reference, connect it to this pin.

This pin functions as a high-impedance input for CMOS clock signals. The input should be dc coupled. If a crystal is used as the device frequency reference, this pin should be tied to GND.

14 Rev. 1.1

Si5355

5

6

7

8

9

10

11

12

13

14

15

16

Table 11. Si5355 Pin Descriptions (Continued)

P4

P5

VDD

LOS

CLK7

CLK6

I

Multi-Function Input.

This pin functions as a multi-function input pin. The pin function (OEB_ALL, OEB_A,

OEB_B, OEB_C, OEB_D, or Reset) is user-selectable at time of configuration using the

ClockBuilder configuration utility. A resistor voltage divider is required when controlled

by a signal greater than 1.3 V. See “2. Typical Application Circuit” for details.

I

Multi-Function Input.

This pin functions as a multi-function input pin. The pin function (OEB_ALL, OEB_A,

OEB_B, OEB_C, OEB_D, or Reset) is user-selectable at time of configuration using the

ClockBuilder configuration utility. A resistor voltage divider is required when controlled

by a signal greater than 1.3 V. See “2. Typical Application Circuit” for details.

VDD Core Supply Voltage.

The device operates from a 1.8, 2.5, or 3.3 V supply. A 0.1 μF bypass capacitor should be located very close to this pin.

O

Loss of Signal.

A typical pullup resistor of 1–4 k

 should be used on this pin.

This pin functions as an input clock signal status pin.

0 = no LOS or LOL condition

1 = LOS or LOL condition

This pin is open drain and requires an external >1 k

 pullup resistor.

O

Output Clock 7.

CMOS output clock. If unused, this pin must be left floating.

O

Output Clock 6.

CMOS output clock. If unused, this pin must be left floating.

VDDOD VDD Clock Output Bank D Supply Voltage.

Power supply for clock outputs 6 and 7. May be operated from a 1.8, 2.5, or 3.3 V supply. A 0.1 μF bypass capacitor should be located very close to this pin. If CLK6/7 are not used, this pin must be tied to VDD or a voltage rail of at least 1.5 V.

P2 I

Multi-Function Input (3.3 V Tolerant).

This pin functions as a multi-function input pin. The pin function (OEB_ALL, OEB_A,

OEB_B, OEB_C, OEB_D, or Frequency Select) is user-selectable at time of configuration using the ClockBuilder configuration utility

CLK5

CLK4

O

Output Clock 5.

CMOS output clock. If unused, this pin must be left floating.

O

Output Clock 4.

CMOS output clock. If unused, this pin must be left floating.

VDDOC VDD Clock Output Bank C Supply Voltage.

Power supply for clock outputs 4 and 5. May be operated from a 1.8, 2.5 or 3.3 V supply. A 0.1 μF bypass capacitor should be located very close to this pin. If CLK4/5 are not used, this pin must be tied to VDD or a voltage rail of at least 1.5 V.

VDDOB VDD Clock Output Bank B Supply Voltage.

Power supply for clock outputs 2 and 3. May be operated from a 1.8, 2.5, or 3.3 V supply. A 0.1 μF bypass capacitor should be located very close to this pin. If CLK2/3 are not used, this pin must be tied to VDD or a voltage rail of at least 1.5 V.

Rev. 1.1

15

S i 5 3 5 5

17

18

19

20

21

22

23

24

GND

PAD

Table 11. Si5355 Pin Descriptions (Continued)

CLK3

CLK2

P3 I

Multi-Function Input (3.3 V Tolerant).

This pin functions as a multi-function input pin. The pin function (OEB_ALL, OEB_A,

OEB_B, OEB_C, OEB_D, Frequency Select, or Reset) is user-selectable at time of configuration using the ClockBuilder configuration utility

VDDOA VDD Clock Output Bank A Supply Voltage.

Power supply for clock outputs 0 and 1. May be operated from a 1.8, 2.5, or 3.3 V supply. A 0.1 μF bypass capacitor should be located very close to this pin. If CLK0/1 are not used, this pin must be tied to VDD or a voltage rail of at least 1.5 V.

CLK1

O

Output Clock 3.

CMOS output clock. If unused, this pin must be left floating.

O

Output Clock 2.

CMOS output clock. If unused, this pin must be left floating.

CLK0

GND

VDD

GND

O

Output Clock 1.

CMOS output clock. If unused, this pin must be left floating.

O

Output Clock 0.

CMOS output clock. If unused, this pin must be left floating.

GND Ground.

Must be connected to system ground. Minimize the ground path impedance for optimal performance of the device.

VDD Core Supply Voltage.

The device operates from a 1.8, 2.5, or 3.3 V supply. A 0.1 μF bypass capacitor should be located very close to this pin.

GND Ground Pad.

This is the large pad in the center of the package. See"7. Recommended PCB Layout" on page 19 for the PCB pad sizes and ground via requirements. The device will not

function unless the ground pad is properly connected to a ground plane on the PCB.

16 Rev. 1.1

Si5355

5. Ordering Guide

Use the ClockBuilder web-based utility available at www.silabs.com/ClockBuilder to specify a unique Si5355 device configuration. ClockBuilder assigns a unique 5-digit code for each unique device configuration and creates an orderable part number. The utility may also be used to order samples, place production orders and look up existing part numbers. In addition, ClockBuilder generates a data sheet addendum for each unique part number that summarizes the device input frequency, output frequencies and other configuration parameters for that specific part number.

Si5355A Bxxxxx

Any-Frequency 1–200 MHz

Quad Frequency

8-Output Clock Generator

G M R

R = tape & reel

Blank = trays (or other)

Contact your Silicon Labs sales representative for details regarding shipment media.

M = RoHS6, Pb-free QFN

G = –40 to +85 o

C

B = product revision B xxxxx = 5-digit custom code assigned to each unique device configuration by

ClockBuilder

5.1. Evaluation Board

Si5356 EVB

Evaluation Board for Si5356 and Si5355

Rev. 1.1

17

S i 5 3 5 5

6. Package Outline: 24-Lead QFN

Figure 7. 24-Lead Quad Flat No-Lead (QFN)

Table 12. Package Dimensions

Dimension Min Nom Max

bbb ccc ddd eee

E

E2

L aaa

A

A1 b

D

D2 e

0.80

0.00

0.18

2.35

2.35

0.30

0.85

0.02

0.25

4.00 BSC.

2.50

0.50 BSC.

4.00 BSC.

2.50

0.40

0.10

0.10

0.08

0.10

0.05

0.90

0.05

0.30

2.65

2.65

0.50

Notes:

1.

All dimensions shown are in millimeters (mm) unless otherwise noted.

2.

Dimensioning and Tolerancing per ANSI Y14.5M-1994.

3.

This drawing conforms to the JEDEC Outline MO-220, variation VGGD-8.

4.

Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.

5.

J-STD-020 MSL rating: MSL3.

6.

Terminal base alloy: Cu.

7.

Terminal plating/grid array material: Au/NiPd.

8.

For more packaging information, go to www.silabs.com/support/quality/pages/RoHSInformation.aspx

.

18 Rev. 1.1

Si5355

7. Recommended PCB Layout

Table 13. PCB Land Pattern

Dimension

P1

P2

X1

Y1

C1

C2

E

Min

2.50

2.50

0.20

0.75

Nom

2.55

2.55

0.25

0.80

3.90

3.90

0.50

Max

2.60

2.60

0.30

0.85

Notes:

General

1.

All dimensions shown are in millimeters (mm) unless otherwise noted.

2.

Dimensioning and Tolerancing per ANSI Y14.5M-1994 specification.

3.

This Land Pattern Design is based on the IPC-7351 guidelines.

4.

Connect the center ground pad to a ground plane with no less than five vias. These 5 vias should have a length of no more than 20 mils to the ground plane. Via drill size should be no smaller than 10 mils. A longer distance to the ground plane is allowed if more vias are used to keep the inductance from increasing.

Solder Mask Design

5.

All metal pads are to be non-solder mask defined (NSMD). Clearance between the solder mask and the metal pad is to be 60 µm minimum, all the way around the pad.

Stencil Design

6.

A stainless steel, laser-cut and electro-polished stencil with trapezoidal walls should be used to assure good solder paste release.

7.

The stencil thickness should be 0.125 mm (5 mils).

8.

The ratio of stencil aperture to land pad size should be 1:1 for all perimeter pins.

9.

A 2x2 array of 1.0 mm square openings on 1.25 mm pitch should be used for the center ground pad.

Card Assembly

10.

A No-Clean, Type-3 solder paste is recommended.

11.

The recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.

Rev. 1.1

19

20

S i 5 3 5 5

8. Top Marking

8.1. Si5355 Top Marking

Si5355

Axxxxx

RTTTTT

YYWW

8.2. Top Marking Explanation

Mark Method:

Line 1 Marking:

Line 2 Marking:

Line 3 Marking:

Line 4 Marking:

Laser

Device Part Number Si5355

A = Frequency and configuration code.

Pin-controlled, any-frequency 1-200 MHz, quad frequency, 8-Output clock generator xxxxx = NVM code for custom factoryprogrammed devices.

See Ordering Guide section in data sheet for more information.

Axxxxx

RTTTTT R = Product revision.

TTTTT = Manufacturing trace code.

Pin 1 indicator.

Circle with 0.5 mm diameter; left-justified

YYWW YY = Year.

WW = Work week.

Characters correspond to the year and work week of package assembly.

Rev. 1.1

Si5355

D

OCUMENT

C

HANGE

L

IST

Revision 0.1 to Revision 0.2

Documentation updated to reflect CLKIN is on pin 4, not pin 3.

Revision 0.2 to Revision 0.3

Added cycle-cycle and phase jitter specifications to

Table 3 on page 5.

Changed period jitter specification from 100 ps to

75 ps pk-pk.

Added Theta JC specification to Table 5 on page 6.

Updated "2. Typical Application Circuit" on page 7.

Added Table 7 on page 9.

Clarified device operation during an input clock loss of signal.

Updated Recommended PCB Layout.

Revision 0.3 to Revision 1.0

Added shipment media information for GM (vs GMR) parts.

Changed Si5356 references to Si5355.

Updated VDDO pin descriptions for unused clock banks. VDDOx associated with an unused clock bank should be tied to > 1.5 V.

Changed the name of output enable/disable control function pins in section 3.5 and Tables 3, 8, and 9 to align better with the actual pin functionality.

Updated Table 2. DC Characteristics.



Added IDDOx specification.



Corrected Pn Input Resistance specification.

Updated Table 3, “AC Characteristics,” on page 5.



Added 10–90% input clock rise/fall time.



Added LOS assert/deassert time.



Added note on jitter test.



Updated 20–80% rise/fall time with C

L

= 15 pF for output clocks to the maximum value of 2.0 ns.



Changed Frequency Synthesis Resolution spec to the correct value of 1ppb max.

Updated recommended crystal parameters in

Table 4 on page 6 to show support for both crystals

rated for either 18 or 12 pF load capacitance.

Updated Table 6 on page 6.



Added Soldering profile specification



Corrected Input Voltage Range (V

I2

) to 1.3 V (max).



Added packaging/RoHS information.

Removed jitter spec from section “3.9. Jitter

Performance” to prevent duplicating specs in

“Table 3. AC Characteristics.”

Removed output-to-output skew spec from section

“3.8. CMOS Output Drivers” text to prevent duplicating specs in “Table 3. AC Characteristics.”

Added Evaluation Board information to the Ordering

Guide.

Revision 1.0 to Revision 1.1

Updated ordering information to refer to revision B silicon.

Updated top marking explanation in Section 8.2

Rev. 1.1

21

ClockBuilder Pro

One-click access to Timing tools, documentation, software, source code libraries & more. Available for

Windows and iOS (CBGo only).

www.silabs.com/CBPro

Timing Portfolio

www.silabs.com/timing

SW/HW

www.silabs.com/CBPro

Quality

www.silabs.com/quality

Support and Community

community.silabs.com

Disclaimer

Silicon Laboratories intends to provide customers with the latest, accurate, and in-depth documentation of all peripherals and modules available for system and software implementers using or intending to use the Silicon Laboratories products. Characterization data, available modules and peripherals, memory sizes and memory addresses refer to each specific device, and

"Typical" parameters provided can and do vary in different applications. Application examples described herein are for illustrative purposes only. Silicon Laboratories reserves the right to make changes without further notice and limitation to product information, specifications, and descriptions herein, and does not give warranties as to the accuracy or completeness of the included information. Silicon Laboratories shall have no liability for the consequences of use of the information supplied herein. This document does not imply or express copyright licenses granted hereunder to design or fabricate any integrated circuits. The products are not designed or authorized to be used within any Life Support System without the specific written consent of Silicon Laboratories. A "Life Support System" is any product or system intended to support or sustain life and/or health, which, if it fails, can be reasonably expected to result in significant personal injury or death. Silicon Laboratories products are not designed or authorized for military applications. Silicon Laboratories products shall under no circumstances be used in weapons of mass destruction including (but not limited to) nuclear, biological or chemical weapons, or missiles capable of delivering such weapons.

Trademark Information

Silicon Laboratories Inc.® , Silicon Laboratories®, Silicon Labs®, SiLabs® and the Silicon Labs logo®, Bluegiga®, Bluegiga Logo®, Clockbuilder®, CMEMS®, DSPLL®, EFM®, EFM32®,

EFR, Ember®, Energy Micro, Energy Micro logo and combinations thereof, "the world’s most energy friendly microcontrollers", Ember®, EZLink®, EZRadio®, EZRadioPRO®, Gecko®,

ISOmodem®, Precision32®, ProSLIC®, Simplicity Studio®, SiPHY®, Telegesis, the Telegesis Logo®, USBXpress® and others are trademarks or registered trademarks of Silicon Laboratories Inc. ARM, CORTEX, Cortex-M3 and THUMB are trademarks or registered trademarks of ARM Holdings. Keil is a registered trademark of ARM Limited. All other products or brand names mentioned herein are trademarks of their respective holders.

Silicon Laboratories Inc.

400 West Cesar Chavez

Austin, TX 78701

USA

http://www.silabs.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
