M0175-71C-216 Model: Watts M-57

M0175-71C-216 Model: Watts M-57
Model:
M0175-71C-216
Multi-Tap Standard Metal Halide
Input Volts
120
208
240
277
Operating
1.85
1.10
0.90
0.80
Open Circuit
1.45
0.90
0.75
0.70
Starting
1.40
0.80
0.70
0.65
5
3
3
3
Circuit Type
175 Watts
M-57
60 Hz
CWA
Wiring Diagram
CWA
Power Factor
> 90%
Regulation
Line Volts
+ / - 10%
Lamp Watts
+10%
-10%
Line Current (Amps)
Recommended Fuse
Dimensional Diagram
UL Temperature Ratings
Insulation Class
H(180C)
Coil Temperature Code
B
C
C
B
< 80C
< 85C
< 85C
< 80C
215
215
215
215
60
104
120
135
min
1.1
0.7
0.5
0.5
max
1.8
1.1
0.9
0.9
Benchtop Coil Rise
Input Watts
Nominal Open Circuit Volts
320
Current Crest Factor
1.65
Input Voltage at Lamp Dropout
Min. Ambient Starting Temp.
-20F -30C
High Potential Test (Volts)
1 Minute
1650
1 Second
2000
Open Circuit Volatge Test (Volts)
Open Circuit Voltage
290 - 360
Input Current
Short Circuit Current Test (Amps)
Secondary Current
Regulatory
1.55 - 1.95
Input Current
min
1.1
0.6
0.5
0.5
max
1.7
1.0
0.9
0.7
Core and Coil Specifications
Dimension "A"
2.4
Dimension "B"
3.8
Weight (lbs.)
RoHS
7
Lead Lengths (in.)
12
Capacitor Specifications
Microfarads
10
Volts (min.)
400
Round DRY
Case Size (in.)
1.6
Height (in.)
3.7
Temp Rating - C
100
Starter Specifications
HI Model No.
NOT USED
BTL
Temp Rating ( C)
N/A
N/A
Rev. Date:
2/9/2012
Test Ref.: Validation
Pt. Ref.: 1093-910363-XXX
Specifications subject to change without notice.
Howard Lighting Products
Phone: 1-800-956-3456
P.O. Box 1590
Fax: (601) 422-1652
Laurel, MS 39441
www.howardlightingproducts.com
