Samsung STB-340PCM Installation manual
Samsung STB-340PCM is a corner mount accessory designed for Samsung Speed Dome Cameras. It offers flexible installation options allowing you to position your camera at various angles. This versatility makes it suitable for monitoring corners, intersections or wide areas. Its durable construction ensures reliable support for your camera, providing stable and secure footage.
PDF
Download
Document
Advertisement
Advertisement
Before attempting to operate this product, please read the instructions carefully. SPD-3750T/3750/3700T/3700/3350/3310/2510 Speed Dome Camera Accessories Installation Manual STH-380PO/STH-370PO/STH-360PO STH-370PI/STH-370PE STB-370PC/STH-270PWV/STB-496PPV STB-25PF/STB-30PF/STB-350PPM STB-330PPM/STB-340PCM/STB-270B Cautions and Warnings for Use Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products. The Eco mark represents Samsung Techwin's will to create environment-friendly products, and indicates that the product satisfies the EU RoHS Directive. Thank you for purchasing our products. This product is to be used for the installation of the Samsung Speed Dome Camera series: SPD-3750T, 3700T, 3750, 3700, 3350, 3310, and 2510. Before installation, please read the user’s manual carefully. - Note that you need to carefully read all contents related to safety and application methods before installation. - When using the product, the cautions/warnings, usage directions, operating methods, and instructions must all be observed. - The power and cable connections should be made by a product installation specialist. - Do not connect and use these accessories to products other than the Samsung Speed Dome Camera Series. - The locations for installing the accessory housing should be strong enough to fully secure the accessories. All installations need to be carried out by experienced engineers. - Do not use it for purposes other than the installation mentioned above. - For product inquiries, please contact the retail shop where you bought the camera. The use of equipment such as an aerial ladder while providing after-sales service shall be at your expense. 2 SPEED DOME CAMERA ACCESSORIES Table of Contents 1. Product Category …………………………………………………………………… 4 1.1. Housing Accessories… ………………………………………………………… 4 1.2. Interface Mounting Accessories………………………………………………… 5 1.3. Mounting Bracket Accessories… ……………………………………………… 5 2. Speed Dome Camera Installation Category… ……………………………………… 7 3. Pendant Type Installation…………………………………………………………… 8 3.1 Wall Mount Type Installation… ………………………………………………… 8 * Camera Wiring Diagram … ………………………………………………… 12 3.2 Ceiling Mount Type Installation… …………………………………………… 15 3.3 Indoor Flange Mount Type Installation … …………………………………… 17 4. On-Ceiling Mount Type Installation… …………………………………………… 21 5. Indoor Flush Mount Type Installation… ………………………………………… 25 6. Mounting Accessory Installation… ……………………………………………… 30 Product External Dimensions… …………………………………………………… 34 Product Specification… …………………………………………………………… 36 Contents By Product Model STH-380PO… ………………………………………………………………………… 8 STH-370PO… ………………………………………………………………………… 8 STH-370PI… ………………………………………………………………………… 8 STH-370PE… ……………………………………………………………………… 25 STH-360PO… ………………………………………………………………………… 8 STH-270PWV… ……………………………………………………………………… 8 STB-496PPV………………………………………………………………………… 15 STB-370PC… ……………………………………………………………………… 17 STB-350PPM… …………………………………………………………………… 30 STB-340PCM… …………………………………………………………………… 30 STB-330PPM… …………………………………………………………………… 30 STB-30PF…………………………………………………………………………… 15 STB-270B…………………………………………………………………………… 30 STB-25PF…………………………………………………………………………… 17 SPEED DOME CAMERA ACCESSORIES 3 Product Category ■ 1. Product Category ■ 1.1. Housing Accessories STH-380PO/STH-370PO/STH-360PO : "Outdoor housing” with a built-in install base for the Samsung Speed Dome Camera. STH-380PO : Ultra Low-Temperature Heavyweight(-40℃~50℃) STH-370PO : Low-Temperature Heavyweight(-20℃~50℃) STH-360PO : Low-Temperature Lightweight(-20℃~50℃) Product Category ■ 1.2. Interface Mounting Accessories STB-370PC :“On-Ceiling Install Base Mount” for the Samsung Speed Dome Camera. ■ 1.3. Mounting Bracket Accessories STH-270PWV : This “Wall Type Mount” is used for the installation of STH-380PO,STH-370PO,STH-360PO,STH-370PI and STB-25PF of the Samsung Speed Dome Camera. STH-370PI : "Indoor Housing” with a built-in install base for the Samsung Speed Dome Camera. STB-496PPV : This “Ceiling Type Mount” is used for the installation of STH-380PO,STH-370PO,STH-360PO,STH-370PI and STB-25PF of the Samsung Speed Dome Camera. STH-370PE : “Indoor Flush Mount" with a built-in install base for the Samsung Speed Dome Camera. STB-25PF : This “Indoor Flange” for the Samsung Speed Dome Camera is useful to install the camera without a housing. 4 SPEED DOME CAMERA ACCESSORIES SPEED DOME CAMERA ACCESSORIES 5 Product Category STB-30PF : “Ceiling Type Flange” for the Samsung Speed Dome Camera. Speed Dome Camera Installation Category ■ 2. Speed Dome Camera Installation Category Pendant Type STB-350PPM : Parapet Mount” for the installation of indoor or outdoor housing of Samsung Speed Dome Camera STB-330PPM Wall Type Mount Ceiling Type Mount Indoor Flange Type Mount : “Pole Mount” for the Samsung Speed Dome Camera. On-Ceiling Mount Type STB-340PCM : “Corner Mount” for the Samsung Speed Dome Camera. Indoor Flush Mount Type STB-270B : "Setup Box" for the Samsung Speed Dome Camera. 6 SPEED DOME CAMERA ACCESSORIES SPEED DOME CAMERA ACCESSORIES 7 Pendant Type Installation STH-380PO/370PO/370PI/360PO STH-380PO/370PO/370PI/360PO ■ 3. Pendant Type Installation Pendant Type Installation 1. Securing Wall Bracket and Wiring As shown in the picture, secure the wall bracket to the wall, and then pull the wires out of the bracket. Please note that the STH-380PO housing requires an additional installation of the fan heater adapter enclosed with the product. ■ 3.1 Wall Mount Type Installation Fan Heater Adaptor (STH-380PO Only) Camera Adaptor ✽ To store the adaptor, the STB-270B Setup Box (Page 31) can be used. Notes • Do not connect the camera to a power outlet until the installation is complete. Supplying power in the middle of the installation may cause fire or damage the product. • STH-370PO requires an additional installation of the fan heater adapter enclosed with the product. Connecting the fan heater to a power outlet used for the camera can cause fire or accidents. 2. Preparing Housing Open the hinged door at the bottom of the housing. Hold the knob on the hinged door to open. STH-380PO STH-370PO STH-360PO STH-370PI STH-270PWV 8 SPEED DOME CAMERA ACCESSORIES Knob 3. Connecting Housing and Bracket To prevent the housing from falling down during the installation process, hook the safety cable on the bracket loop as shown in the picture. SPEED DOME CAMERA ACCESSORIES 9 Pendant Type Installation Fan Heater Connector (Model: STH-370PO) STH-380PO/370PO/370PI/360PO STH-380PO/370PO/370PI/360PO Fan Heater Adaptor (STH-380PO Only) Pendant Type Installation 5. Securing Housing Check if the housing is properly attached to the bracket, secure the housing to the bracket with the enclosed screws. Camera Adaptor 6. Wiring Terminal Cables Connect the cables to the terminal block on the hinged door. Once the wiring is successful, close the hinged door. Notes • The STH-380 housing’s fan heater connector must be connected to its dedicated adapter enclosed with the product. • Make sure to hook the safety cable on the bracket loop before connecting the housing. • Neglecting this caution may expose you to injury caused by a fallen housing. 4. Assembling Housing and Bracket After hooking the safety cable, fit the housing into the fixture grooves on the bracket as shown in the picture. When attaching, locate the "Samsung" logo on the housing facing the center front. ✽ For the location of the wiring pins, please refer to the “Camera Wiring Diagram” on the next page. Logo 10 SPEED DOME CAMERA ACCESSORIES SPEED DOME CAMERA ACCESSORIES 11 Pendant Type Installation Pendant Type Installation Video Output Alarm STH-380PO/370PO/370PI/360PO STH-380PO/370PO/370PI/360PO ✽ Camera Wiring Diagram This wiring diagram indicates the connection between the interface board and external equipment. For wiring Samsung Techwin’s Speed Dome Camera and the accessories, please refer to the Speed Dome Camera user’s manual. 7. Preparing Camera Once the camera wiring is successful, prepare the camera. Every housing-typed camera except the flush model is provided with a dome cover first detach the dome cover from the camera. 8. Setting Up Camera DIP Switches DIP switches for communication and ID protocols are located on the bottom of the camera. For the switch settings, refer to the appendix of this manual. Alarm Output Protocol(SW2) ID(SW1) Fan Heater Connector Alarm Input Communications and AUX Power Supply 9. Connecting Camera Safety Cable and Attaching Camera Carefully attach the camera to the mount following the alignment guide marks as shown in the picture. First hook the camera's safety cable on the mount, and then attach the camera. The safety cable is coiled inside the install base. As shown in the leftward picture, pull out the safety cable from the install base and then hook it to the mount. AC24V 2.5A Power Input Ground Refer to the below Control Signal Connection diagram Safety Cable Alignment Direction Guides AUX Output Alignment Directions Control Signal Connection · RS485 Communications Camera D+ D- · RS422 Communications Camera D+ DTX+ TX- 12 Controller or DVR TXD+ TXDController or DVR TXD+ TXDRXD+ RXD- SPEED DOME CAMERA ACCESSORIES Alignment Direction Guides Notes • The maximum capacity of the alarm and AUX output terminals is DC30V 2A. • Connecting the power connector and GND incorrectly to the NC/NO and COM ports can cause a short circuit which may lead to fire and damage the camera. ✽ To attach the camera to the mount, refer to the alignment guide marks as shown in the picture. Notes • Make sure to first hook the camera's safety cable to the mount before proceeding. Otherwise you may be exposed to serious injury caused by a fallen camera. SPEED DOME CAMERA ACCESSORIES 13 Pendant Type Installation STH-380PO/370PO/370PI/360PO STH-380PO/370PO/370PI/360PO ✽ To attach or detach the camera, refer to the picture. * Attaching the camera: Hold up the camera and push it to the mount as shown in the picture. Push the camera until you hear a “click”. * Detaching the camera: To detach the camera, pull the camera downward while pushing the unlock buttons on the camera upward. Pendant Type Installation ■ 3.2 Ceiling Mount Type Installation This guideline is based on the installation of the ceiling flange STB-30PF. Unlock Button UNLOCK To attach the camera To detach the camera 10. Assembling Dome Cover Once the camera is successfully attached, secure the mount with the transparent dome cover. Next, turn on the power. 11. Dome Cover Setting Once the installation is complete, please optimize the camera focus settings. On the camera’s OSD Menu, set the Dome Cover setting to Outdoor. (Directory: Main Menu/Camera Setting/Others) Others 14 Sync Stabilizer ③ Image Adj Freeze Dome Cover INTERNAL OFF OFF Outer SPEED DOME CAMERA ACCESSORIES STH-380PO STH-370PO STH-360PO STH-370PI STB-496PPV STB-30PF SPEED DOME CAMERA ACCESSORIES 15 Pendant Type Installation Pendant Type Installation STH-380PO/370PO/370PI/360PO STH-380PO/370PO/370PI/360PO ■ 3.3 Indoor Flange Mount Type Installation Camera Adaptor Fan Heater Adaptor (STH-380PO Only) This guideline is based on the installation of the indoor flange STB-25PF and the ceiling exposed mount STB-370PC. Sealing Tape SPSS32A/SCH40 Size Pipe STB-30PF PF 1 1/4" 1. Preparing Pipe and Ceiling Bracket STB-30PF requires a SPSS32A/SCH40-sized pipe as shown in the picture. Assemble the screw taps, and then wind a sealing tape around the screw barrel to prevent water leakage. Please note that the STH-380PO housing requires an additional installation of the fan heater adapter enclosed with the product. Notes • Using unsealed screw taps can cause the product to fall down or allow water leakage that may lead to fire or damage the product. Sealing tape is not enclosed with the product, and needs to be purchased at your expense. 2. Assembling STB-30PF and Pipe After sealing the screw taps, assemble the STP-30PF flange securely to the pipe. Notes • Do not connect the camera to a power outlet until the installation is complete. Supplying power in the middle of the installation may cause fire or damage the product. ✽ For the next installation procedures, refer to the “Wall Type Housing” installation from step 2. 16 SPEED DOME CAMERA ACCESSORIES STB-370PC STB-30PF STB-25PF STB-496PPV STB-30PF SPEED DOME CAMERA ACCESSORIES 17 Pendant Type Installation STH-380PO/370PO/370PI/360PO STH-380PO/370PO/370PI/360PO 1. Assembling Flange and Ceiling Exposed Mount (STB-370PC) Wind sealing tape around the barrel of the screw taps, and then secure the STP-25PF flange securely to the mount with the enclosed screws. Pendant Type Installation Notes • Do not connect the camera to a power outlet until the installation is complete. Supplying power in the middle of the installation may cause fire or damage the product. 4. Wiring Terminal Cables Connect the cables to the terminal block on the hinged door. Once the wiring is successful, close the hinged door. Alignment Directions Knob 2. Opening Hinged Door Open the hinged door at the bottom of the housing. Hold the knob on the hinged door to open. 3. Assembling Mount and Flange First hook the safety cable on the mount, and then fit the housing into the fixture groove on the bracket as shown in the picture. Once the housing is safely attached to the bracket, secure the housing with the enclosed screws. ✽ For the location of the wiring pins, please refer to the “Camera Wiring Diagram” on Page 12. 5. Setting Up Camera DIP Switches DIP switches for communication and ID protocols are located on the bottom of the camera. For the switch settings, refer to the appendix of this manual. ID(SW1) Protocol(SW2) CLOSE 18 SPEED DOME CAMERA ACCESSORIES SPEED DOME CAMERA ACCESSORIES 19 Pendant Type Installation STH-380PO/370PO/370PI/360PO 6. Attaching Camera Carefully attach the camera to the mount following the alignment guide marks as shown in the picture. First hook the camera's safety cable on the mount, and then attach the camera. The safety cable is coiled inside the install base. As shown in the leftward picture, pull out the safety cable from the install base and then hook it to the mount. On-Ceiling Mount Type Installation ■ 4. On-Ceiling Mount Type Installation This guideline is based on the installation of the indoor flange STB-370PC. Alignment Direction Guides Safety Cable Alignment Direction Guides STB-370PC Alignment Directions ✽ To attach the camera to the mount, refer to the alignment guide marks as shown in the picture. Notes • Make sure to first hook the camera's safety cable to the mount before proceeding. Otherwise you may be exposed to serious injury caused by a fallen camera. ✽ To attach or detach the camera, refer to the picture. * Attaching the camera: Hold up the camera and push it to the mount as shown in the picture. Push the camera until you hear a “click”. * Detaching the camera: To detach the camera, pull the camera downward while pushing the unlock buttons on the camera upward. Unlock Button UNLOCK To attach the camera 20 SPEED DOME CAMERA ACCESSORIES To detach the camera STB-370PC SPEED DOME CAMERA ACCESSORIES 21 On-Ceiling Mount Type Installation 1. Attaching Template and Installing STB-370PC Attach the enclosed template to the ceiling, then drill a hole in the ceiling according to the diameter marked on the template. Drop the camera cables down from the ceiling through the hole. Next, install the Install Base STB-370PC to the ceiling as shown in the picture. Before installing the exposed bracket, open the hinged door at the bottom of the bracket as shown in the picture. Hold the knob on the hinged door to open. Knob 3. Setting Up Camera DIP Switches DIP switches for communication and ID protocols are located on the bottom of the camera. For the switch settings, refer to the appendix of this manual. ID(SW1) Protocol(SW2) STB-370PC STB-370PC Template On-Ceiling Mount Type Installation 5. Connecting Camera Safety Cable and Attaching Camera Carefully attach the camera to the mount following the alignment guide marks as shown in the picture. First hook the camera's safety cable on the mount, and then attach the camera. The safety cable is coiled inside the install base. As shown in the leftward picture, pull out the safety cable from the install base and then hook it to the mount. Safety Cable Alignment Direction Guides Alignment Direction Guides 2. Wiring Terminal Cables Connect the cables to the terminal block on the hinged door. For the location of the wiring pins, please refer to the “Camera Wiring Diagram” on Page 12. Once the wiring is successful, close the hinged door. Alignment Directions ✽ To attach the camera to the mount, refer to the alignment guide marks as shown in the picture. Notes • Do not connect the camera to a power outlet until the installation is complete. Supplying power in the middle of the installation may cause fire or damage the product. 22 SPEED DOME CAMERA ACCESSORIES Notes • Make sure to first hook the camera's safety cable to the mount before proceeding. Otherwise you may be exposed to serious injury caused by a fallen camera. SPEED DOME CAMERA ACCESSORIES 23 On-Ceiling Mount Type Installation ✽ To attach or detach the camera, refer to the picture. * Attaching the camera: Hold up the camera and push it to the mount as shown in the picture. Push the camera until you hear a “click”. * Detaching the camera: To detach the camera, pull the camera downward while pushing the unlock buttons on the camera upward. Indoor Flush Mount Type Installation ■ 5. Indoor Flush Mount Type Installation This guideline is based on the installation of the flush mount STH-370PE. Unlock Button STB-370PC UNLOCK To detach the camera STH-370PE To attach the camera STH-370PE 24 SPEED DOME CAMERA ACCESSORIES SPEED DOME CAMERA ACCESSORIES 25 Indoor Flush Mount Type Installation 1. Attaching Flexible Adaptor To feed the cables through a pipe to a flush housing, attach the flexible adaptor enclosed with the product. To attach the flexible adaptor, the install base must be disassembled as shown in the picture. To disassemble the install base, unscrew the 3 screws on the bottom. Silicon Cap Indoor Flush Mount Type Installation 4. Preparing Housing Open the hinged door at the bottom of the housing. While pressing the spring lock (1), hold up the lid to open (2). Knob Adaptor Nut Flexible Adaptor 5. Inserting the flush housing Arrange the cables and eyebolts as shown in the picture, and then insert the housing into the ceiling hole. Install Base(STB-370PC) disassembly Hanger Bolt Fixing Nut Eyebolt Elbo bracket Eyebolt STH-370PE STH-370PE 2. Attaching Template Attach the enclosed template to a desired location on the ceiling. Drill 3 holes of 50 mm diameter in 120-degree intervals following the marks on the template, and then drill one 200 mm hole in the center of the template. 3. Wiring and Arranging Anti-fall Eyebolts Attach the enclosed turnbuckle and eyebolts inside the ceiling, and then drop the camera cables down from the ceiling through the hole. Turnbuckle 6. Securing Screws or Internal Supports Two fixture methods are available for the flush mount: screw through or inner support. Depending on the situation, select one of the two methods. The inner support method unfolds the supports inside the mount when 3 screws on the mount surface are fastened. Eyebolt Template Φ200 mm Ceiling Template Notes • Do not connect the camera to a power outlet until the installation is complete. Supplying power in the middle of the installation may cause fire or damage the product. 26 SPEED DOME CAMERA ACCESSORIES Screw Through Type Inner Support Type SPEED DOME CAMERA ACCESSORIES 27 Indoor Flush Mount Type Installation 7. Arranging Camera Cables and Closing Hinged Door Connect the cables to the terminal block on the hinged door. For the location of the wiring pins, please refer to the “Camera Wiring Diagram” on Page 12. Once the wiring is successful, close the hinged door. Indoor Flush Mount Type Installation Notes • Make sure to first hook the camera's safety cable to the mount before proceeding. Otherwise you may be exposed to serious injury caused by a fallen camera. 8. Setting Up Camera DIP Switches DIP switches for communication and ID protocols are located on the bottom of the camera. For the switch settings, refer to the appendix of this manual. 10. Assembling Dome Cover Once the camera is successfully attached, secure the mount with the transparent dome cover. ID(SW1) Protocol(SW2) Notes 9. Attaching Camera Carefully attach the camera to the mount following the alignment guide marks as shown in the picture. First hook the camera's safety cable on the mount, and then attach the camera. The safety cable is coiled inside the install base. As shown in the leftward picture, pull out the safety cable from the install base and then hook it to the mount. Safety Cable CLOSE OPEN STH-370PE STH-370PE • Be careful to not scratch the transparent cover during the assembly. Scratched dome covers may decrease the graphics quality and overall performance of the camera. ✽ To attach or detach the camera, refer to the picture. * Attaching the camera: Hold up the camera and push it to the mount as shown in the picture. Push the camera until you hear a “click”. *D etaching the camera: To detach the camera, pull the camera downward while pushing the unlock buttons on the camera upward. Alignment Direction Guides Unlock Button Alignment Direction Guides UNLOCK Alignment Directions ✽ To attach the camera to the mount, refer to the alignment guide marks as shown in the picture. 28 SPEED DOME CAMERA ACCESSORIES To attach the camera To detach the camera SPEED DOME CAMERA ACCESSORIES 29 Mounting Accessory Installation ■ 6. Mounting Accessory Installation Mounting Accessory Installation ■ STB-270B(Setup Box) This guideline is to be used for the installation of mounting accessories for the Samsung Speed Dome Camera series. 1. U sing self drilling screws, secure the install bracket. 2. F ill unwanted wire holes with mount caps. Secure the mount cap with the mount cap fastener. MOUNT CAP MOUNT CAP FASTENER 3. P lace the setup box on the install bracket as shown in the picture. STH-370PE STB-350PPM STB-330PPM 4. U sing hexagon bolts, fasten the setup box to the bracket. Next feed the camera cables into the setup box through the hole in the cover. STB-340PCM 30 SPEED DOME CAMERA ACCESSORIES STB-270B 5. F eed the camera cables through the wall bracket and secure the bracket using 4 screws. 6. L astly, fasten the screws using a hexagon wrench to secure the bracket to the setup box. SPEED DOME CAMERA ACCESSORIES 31 Mounting Accessory Installation Mounting Accessory Installation ■ STB-330PPM (Paul Mount) ■ STB-350PPM (Parapet Mount) Compatible Models : STB-270PWV+STH-380PO/370PO/360PO/370PI Compatible Models : STB-30PF+STH-380PO/370PO/360PO/370PI Wall type mount 1. Secure the pole to the mount using a wire or cable. 2. U se 4 1/4" screws to secure the STH-270PWV pole mount to the wall. 1. D rill 8 anchor bolt holes on the wall according to the holes in the parapet mount. 2. U sing a tool, insert anchor bolts and then set the parapet mount on the bolts. Use 8 nuts to fasten the bolts. 1/4" SCREW : 4EA Parapet mount Anchor bolt 8EA ■ STB-340PCM (Corner Mount) 3. F eed the cable through the pipe to the other end of the pipe. 4. Set PPE on the parapet mount. Compatible Models : STB-270PWV+STH-380PO/370PO/360PO/370PI Anchor bolt 8EA Corner mount 1. D rill 8 anchor bolt holes on the wall according to the holes in the corner mount. 2. U sing a tool, insert anchor bolts and then set the corner mount on the bolts. Use 8 nuts to fasten the bolts. 3. Use 1/4" screws to secure the STH-270PWV to the corner. Wall type mount PIPE 5. Wind the cable to the direction shown in the picture, and then assemble the PPE cover using screws. 6. Adjust the pipe direction, and then secure the pipe using screws. 7. Install the camera. 1/4" SCREW : 4EA 32 SPEED DOME CAMERA ACCESSORIES SPEED DOME CAMERA ACCESSORIES 33 Product External Dimensions ■ Wall Mounting Product External Dimensions Unit : mm ■ Ceiling Mounting ■ Ceiling Exposed Mounting 34 SPEED DOME CAMERA ACCESSORIES Unit : mm ■ Indoor Flush Mounting SPEED DOME CAMERA ACCESSORIES 35 Product Specifications Product Specifications Model Item Operating Temperature Range STH-380PO STH-370PO STH-370PI STH-370PE STH-360PO -40℃~50℃ -20℃~50℃ -10℃~50℃ -10℃~50℃ -20℃~50℃ 0 to 90%RH 1 to 90%RH 0 to 90%RH (non-condensing) (non-condensing) Housing Housing Housing Embedded Housing ALDC 12 ALDC 12 ALDC 12 E.G.I (1.2t) AL Outdoor Outdoor Outdoor Housing Outdoor Ring Ring Ring Ring Ring Materials ALDC 12 ALDC 12 ALDC 12 ABS ALDC 12 Decoration Decoration Decoration Decoration Decoration Dome Poly Dome Poly Dome Poly Dome Poly Cover Carbonate Cover Carbonate Cover Carbonate Cover Carbonate SAFETY SUS WIRE (Φ1.2x (1EA) 2000) Turn Eye Bolt Components Buckle1EA 2EA (mm) WIRE JOINT(4EA) Silicon cap(1EA) DC12V DC12V DC12V 0.06A 0.06A 0.06A Operating Operating Operating Temp Temp Temp Fan(2EA) Fan(2EA) Fan(1EA) More than More than More than 45℃ 45℃ 45℃ Less than Less than Less than Miscellaneous 10℃ 10℃ 10℃ AC 24V AC 24V AC 24V 46W 33W 33W Operating Operating Operating Heater Heater Heater Temp Temp Temp less than less than less than 10℃ 10℃ 10℃ Antivibration/ Waterp IP 67 IP 67 IP 67 IP 66 roof Weight (Net) 3.2kg 3.2kg 3.2kg 740g 2.1kg Weight 4.2kg 4.2kg 4.1kg 1.2kg 3.2kg (Gross) Dimensions Φ242x284.5 Φ242x284.5 Φ242x284.5 Φ190x188.5 Φ242x284.5 (mm) Humidity 0 to 90%RH 0 to 90%RH Model Item Operating Temperature Range STB-25PF STB-270B -40℃~50℃ -40℃~50℃ -10℃~50℃ -10℃~50℃ -40℃~50℃ 0 to 90%RH (non-condensing) Housing E.G.I 2.0t Flange Adaptor AL Housing 1 to 90%RH (non-condensing) DOOR ALDC 12 FRONT BASE ALDC 12 HOUSING INSTALL BRACKET C.R.2.0t JOINT 1EA MOUNT ALDC 12 Ceiling Bracket E.G.I. 2.0t Miscellaneous Screw (4EA) Screw (3EA) Antivibration/ Waterproof Weight (Net) Weight (Gross) Dimensions (mm) Operating Temperature Range Model Item Operating Temperature Range Humidity Materials Components (mm) Antivibration/ Waterproof Weight (Net) Weight (Gross) Dimensions (mm) Operating Temperature Range SPEED DOME CAMERA ACCESSORIES STB-370PC Wall Type Mount Miscellaneous 36 STB-496PPV 0 to 90%RH (non-condensing) Humidity Materials Components (mm) STH-270PWV Self Drilling Screw #8xL38 (FZY) PH MS M4xL14 0 to 90%RH 0 to 90%RH (non-condensing) (non-condensing) Ceiling On-Ceiling ALDC12 ALDC 12 Installation Flange Ceiling SPPS32A COVER PC+ABS Pipe /SCH 40 Ceiling Bracket E.G.I. 2.0t COVER PC+ABS Ceiling SPCC Plate Self Drilling Screw Screw Screw BH MS (4EA) #8xL38 (3EA) M3xL6 (FZY) Screw PH MS (3EA) M4xL14 Ceiling Support SUS Screw (3EA) PH MS M4x8 SUS MOUNT CAP 5EA Hexagon Bolt Screw (6EA) #8x38 (FZY) 4EA 1.3kg 1.8kg 935g 420g 3kg 1.3kg 2kg 1.4kg 490g 3.3kg 270x175x140 150x496 Φ183x48.5 183x37 218x182x92.5 STB-30PF STB-340PCM STB-330PPM STB-350PPM -40℃~50℃ -40℃~50℃ -40℃~50℃ -40℃~50℃ 0 to 90%RH (non-condensing) Ceiling ALDC 12 Flange Ceiling E.G.I. 2.0t Bracket 0 to 90%RH (non-condensing) 0 to 90%RH (non-condensing) 0 to 90%RH (non-condensing) Corner Bracket SPCC Pole Bracket SPCC Parapet Pipe PF 1 1/4 (32A) 380g 1.3kg 580g Parapet Plate SUS Pipe Cover SUS Set Anchor-6 1/4" (8EA) Screw M16x20(SUS) (2EA) Screw PH MS (2EA) M13x10(SUS) 8kg 126x66 306x194x185 185x155x48 680x930x63 Screw (3EA) PH MS M4xL14 Screw (4EA) Set Anchor-6 (8EA) 1/4" Screw (4EA) 1/4" 1/4" SPEED DOME CAMERA ACCESSORIES 37 MEMO MEMO SALES NETWORK • AMSUNG TECHWIN CO.,LTD. S 145-3, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-120, Korea TEL : +82-31-740-8151~8 FAX : +82-31-740-8145 • AMSUNG TECHWIN AMERICA,LTD. S 1480 Charles Willard St. Carson, CA 90746, UNITED STATES TEL : +1-310-632-1234 FAX : +1-310-632-2195 • AMSUNG OPTO-ELECTRONICS UK,LTD. S Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey Surrey KT16 OPS TEL : +44-1932-45-5308 FAX : +44-1932-45-5325 www.samsungtechwin.com www.samsungcctv.com VAN 08. 12 ">
