Quick Tab - Product Locator

Plastic Enclosures

Pages 2-47

Diecast Aluminum Enclosures

Pages 48-59

Sealed Diecast Aluminum Enclosures

Pages 60-71

General Purpose Metal Enclosures

Pages 72-99

Accessories, Technical Data & Index

Pages 100-112

©

CANADA

Guelph, Ontario (519) 822-2960

St. Laurent, Quebec (514) 343-9010

USA

Cheektowaga, NY (716) 651-0086 www

.ham

mondm fg.com

EUROPE

Basingstoke, UK +44 1256 812812

AUSTRALASIA

Queenstown, SA, Australia +61 8 8240 2244

1

Plastic

Watertight Flat Lid

Pages 4-5

Watertight Clear Lid

Pages 6-7

Flanged Lid

Pages 18-21

Contents - Plastic

Wallmount & Handheld

Page 35

Bottom Flange

Pages 22-23

Hand Held

Pages 36-37

Watertight Styled Lid

Pages 8-9

“T” - Display Case

Pages 24-25

Miniature

Pages 10-11

Hand Held Instrument

Pages 26-29

Sloped Console

Pages 38-41

Instrument Case

Pages 42-46

Translucent

Pages 12-13

Heavy Duty

Pages 30-33

Potting Boxes

Page 47

Mutlipurpose

Pages 14-17

©

CANADA

Guelph, Ontario (519) 822-2960

St. Laurent, Quebec (514) 343-9010

USA

Cheektowaga, NY (716) 651-0086

Heavy Duty Watertight

Page 34 www

.ham

mondm fg.com

EUROPE

Basingstoke, UK +44 1256 812812

AUSTRALASIA

Queenstown, SA, Australia +61 8 8240 2244

3

Watertight Flat Lid - (1554 Series)

KEY FEATURES

• Electronic instrument enclosures, designed for mounting printed circuit boards or DIN rail mounted components.

• Molded in general purpose ABS plastic or polycarbonate material.

• The general purpose ABS plastic carries a UL flammability rating of UL94HB. Not recommended for outdoor use.

• The polycarbonate material carries a UL flammability rating of UL94 5V and is suitable for outdoor use.

• Color is light gray (RAL 7035)

• Gasketed lid with two piece “tongue & groove” construction provides protection against access of oil, dust and water.

• Designed to meet IP66 & NEMA 4, 4X, 12 & 13 ratings

• Gasket is factory poured using high temperature U.L. listed - silicone rubber gasket material.

• Lid is secured with self captivating M4 stainless steel machine screws (included), threaded into integral stainless steel

bushings (for repetitive assembly & disassembly).

• All stainless steel hardware to avoid corrosion caused by dissimilar metals.

• Lid and mounting holes are located outside of the gasket seal.

• Heavy duty 16 gauge galvanized steel panels available (see chart)

• Internal features are maximized for mounting options:

- Internal DIN rail mounting tabs molded in all except the 1554CGY & 1554C2GY

- Threaded (M3) integral brass inserts & standoffs designed for M3.5 or #6 self tapping screws for P.C. board or

inner panel mounting in all but the smallest size (1554BGY & 1554B2GY)

- Vertical P.C. card guides (for 1.5 mm thick P.C. boards) are molded in all but the smallest size (1554BGY &

1554B2GY)

ACCESSORIES

Panels

Heavy duty panel for mounting components. Galvanized 16 ga.

steel. Includes mounting hardware.

See table (facing page) for part numbers
