Epson DS-560 User`s guide

DS-560 User's Guide
Contents
DS-560 User's Guide ................................................................................................................................... 7
Scanner Basics............................................................................................................................................ 8
Scanner Parts Locations ...................................................................................................................... 8
Scanner Parts.................................................................................................................................. 8
Scanner Buttons and Lights........................................................................................................... 10
Page Separation Lever.................................................................................................................. 12
User Replaceable Epson Scanner Parts and Accessories ................................................................. 12
Changing the Power Off and Sleep Timer Settings ............................................................................ 13
Loading Originals......................................................................................................................................
Loading Originals in the Input Tray.....................................................................................................
Loading Multiple Sizes of Originals in the Input Tray .....................................................................
Original Document Loading Capacity ............................................................................................
Loading Plastic Cards in the Input Tray..............................................................................................
Plastic Card Loading Capacity.......................................................................................................
Loading Special Documents...............................................................................................................
Large or Thick Original Loading Capacity......................................................................................
15
15
18
21
22
26
26
31
Wi-Fi Networking ....................................................................................................................................... 33
Connection Mode Switch.................................................................................................................... 33
Manual Network Connection Setup .................................................................................................... 33
Connecting to an Existing Wi-Fi Network .......................................................................................... 34
Manually Connecting to a Wi-Fi Router Using EpsonNet Config ................................................... 35
Setting Up Network Scanning........................................................................................................ 36
Determining the Scanner's IP Address ..................................................................................... 38
Direct Wi-Fi Mode Setup .................................................................................................................... 38
Enabling a Direct Wi-Fi Connection ............................................................................................... 39
Using WPS to Set Up a Direct Wi-Fi Connection ........................................................................... 40
Wi-Fi Protected Setup (WPS)............................................................................................................. 41
Using WPS to Connect to a Network ............................................................................................. 41
Using WPS PIN Mode to Connect to a Network ............................................................................ 42
Epson DocumentScan App for iOS/Android....................................................................................... 44
3
Using the Network Interface Unit........................................................................................................ 44
Network Interface Unit Control Panel ............................................................................................ 45
Connecting the Network Interface Unit .......................................................................................... 45
Scanning to Network Computers from the Network Interface Unit - Windows ............................... 45
Scanning .................................................................................................................................................... 47
Starting a Scan from a Scanner Button .............................................................................................. 47
Assigning Start Button Settings or Scan Jobs................................................................................ 47
Scanning with Document Capture Pro and Document Capture.......................................................... 48
Scanning with Epson Scan................................................................................................................. 51
Available Image Adjustments ........................................................................................................ 53
Scanning Special Projects.................................................................................................................. 54
Scanning Two Originals onto One Sheet (Stitching Images) ......................................................... 54
Scanning Multi-Page Originals as Separate Files - Windows ........................................................ 57
Convert Scanned Documents to Editable Text (OCR)................................................................... 59
Scanning Using OCR - Windows .............................................................................................. 59
Scanning Using OCR - OS X .................................................................................................... 61
Scanning to a SharePoint Server or Cloud Service ....................................................................... 63
Cleaning and Transporting Your Scanner...............................................................................................
Cleaning Your Scanner ......................................................................................................................
Cleaning Inside Your Scanner............................................................................................................
Checking the Scanner Roller Counter ................................................................................................
Replacing the Scanner Rollers ...........................................................................................................
Resetting the Scanner Roller Counter ...........................................................................................
Transporting Your Scanner ................................................................................................................
66
66
66
69
70
76
77
Solving Problems ......................................................................................................................................
Scanner Light Status ..........................................................................................................................
Solving Scanning Problems ...............................................................................................................
Scanner Does Not Turn On or Turns Off Unexpectedly.................................................................
Scanner Button Does Not Work as Expected ................................................................................
Scanning Software Does Not Operate Correctly ...........................................................................
Cannot Start Epson Scan ..............................................................................................................
Original Feeds Incorrectly in Scanner............................................................................................
Original Jams in Scanner...............................................................................................................
79
79
81
81
81
82
83
84
84
4
Scanning is Slow ........................................................................................................................... 86
Cannot Scan Over a Network ........................................................................................................ 87
Scanner Cannot Connect to a Wireless Router or Access Point ................................................... 88
Solving Scanned Image Quality Problems ......................................................................................... 89
Back of Original Image Appears in Scanned Image ...................................................................... 89
Scanned Characters are Blurry ..................................................................................................... 90
Characters are not Recognized During Conversion to Editable Text (OCR) ................................. 90
Ripple Patterns Appear in an Image .............................................................................................. 91
Spots or Lines Appear in All Scanned Images............................................................................... 91
Scanned Image Edges are Cropped ............................................................................................. 93
When to Uninstall Your Scanner Software ......................................................................................... 93
Uninstalling Scanner Software - Windows ..................................................................................... 93
Uninstalling Scanner Software - OS X ........................................................................................... 94
Where to Get Help.............................................................................................................................. 95
Technical Specifications .......................................................................................................................... 97
Windows System Requirements ........................................................................................................ 97
Mac System Requirements ................................................................................................................ 97
General Specifications ....................................................................................................................... 98
Dimension Specifications ................................................................................................................... 99
Network Interface Specifications ........................................................................................................ 99
Electrical Specifications ..................................................................................................................... 99
Environmental Specifications ........................................................................................................... 100
USB Interface Specifications............................................................................................................ 101
Safety and Approvals Specifications ................................................................................................ 101
Notices .....................................................................................................................................................
Important Safety Instructions............................................................................................................
Restrictions on Copying ...................................................................................................................
Default Delay Times for Power Management for Epson Products....................................................
Trademarks ......................................................................................................................................
Copyright Notice...............................................................................................................................
Open Source Software License ...................................................................................................
Info-ZIP Copyright and License ...................................................................................................
libTIFF Software Acknowledgment..............................................................................................
5
102
102
104
104
105
105
106
109
110
libjpeg-turbo................................................................................................................................. 111
A Note Concerning Responsible Use of Copyrighted Materials................................................... 112
Copyright Attribution .................................................................................................................... 112
6
DS-560 User's Guide
Welcome to the DS-560 User's Guide.
For a printable PDF copy of this guide, click here.
7
Scanner Basics
See these sections to learn about the basic features of your scanner.
Scanner Parts Locations
User Replaceable Epson Scanner Parts and Accessories
Changing the Power Off and Sleep Timer Settings
Scanner Parts Locations
See these sections to identify the parts on your scanner.
Scanner Parts
Scanner Buttons and Lights
Page Separation Lever
Parent topic: Scanner Basics
Scanner Parts
8
1
Scanner cover
2
Page separation lever
3
Edge guides
4
Input tray extension
5
Input tray
6
Cover open lever
7
Output tray
8
Output tray extension
1
Kensington security slot
2
USB port
3
Connect button
4
Power inlet
5
Connection mode switch
9
1
AC adapter
2
Power cord
3
USB cable
Parent topic: Scanner Parts Locations
Scanner Buttons and Lights
Buttons
10
1
The
power button
2
The
stop button
3
The
start button
Lights
1
The ! error light
2
The Status light
Parent topic: Scanner Parts Locations
11
Page Separation Lever
You can scan plastic cards, folded documents, envelopes, or any document that requires an optional
carrier sheet by adjusting the position of the page separation lever.
Move the separation lever to this position only when scanning plastic cards, folded documents,
envelopes, or any document that requires an optional carrier sheet.
Leave the separation lever in this position when scanning standard single- or multiple-page
documents to prevent paper jams.
Parent topic: Scanner Parts Locations
Related topics
Loading Originals
User Replaceable Epson Scanner Parts and Accessories
You can purchase genuine Epson accessories at epson.com (U.S. sales) or epson.ca (Canadian sales).
You can also purchase accessories from an Epson authorized reseller. To find the nearest one, call 800GO-EPSON (800-463-7766).
12
Part
Part number
Carrier sheet
B12B813431
Roller assembly kit
B12B813561
Network Interface Unit
B12B808441
Parent topic: Scanner Basics
Changing the Power Off and Sleep Timer Settings
You can use the Epson Scan Settings utility to change the time period before the scanner enters sleep
mode and turns off automatically.
1. Do one of the following to access the Epson Scan Settings utility:
• Windows 8.x: Navigate to the Apps screen and select EPSON Scan Settings.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
Epson, then EPSON Scan, then click EPSON Scan Settings.
• OS X: Open the Applications folder, then open the Epson Software folder and double-click the
EPSON Scan Settings icon.
2. Click Energy Saving.
3. Enter the time period you want before the scanner goes to sleep as the Sleep Timer setting.
4. Enter the time period you want before the scanner turns off automatically as the Power Off Timer
setting.
5. Click OK.
13
Parent topic: Scanner Basics
14
Loading Originals
Follow the instructions here to load your originals into the scanner.
Loading Originals in the Input Tray
Loading Plastic Cards in the Input Tray
Loading Special Documents
Loading Originals in the Input Tray
You can load originals that meet the document specifications in the input tray.
Caution: Do not load photos, or valuable original documents or artwork, directly into the input tray. This
may wrinkle or damage the original. Load these originals using an optional carrier sheet.
1. Open the input tray and pull up its extension.
2. Pull out the output tray and open its extension.
15
3. Slide the input tray edge guides all the way out.
4. Check to make sure that the page separation lever is in the position shown here.
Note: To prevent paper jams, keep the lever in this position for most types of documents.
16
5. If you are loading a multi-page document, fan your stack of originals and tap them gently on a flat
surface to even the edges.
6. Slide your originals into the input tray as shown until they meet resistance. Make sure the printed
side is face down and top edge first.
Note: If you are loading a paper business card, load it horizontally.
17
7. Slide the edge guides against the edges of the original.
Loading Multiple Sizes of Originals in the Input Tray
Original Document Loading Capacity
Parent topic: Loading Originals
Related references
Page Separation Lever
Related topics
Scanning
Loading Multiple Sizes of Originals in the Input Tray
You can load a mixture of originals at different sizes that meet the document specifications in the input
tray.
Caution: Do not load photos, or valuable original documents or artwork, directly into the input tray. This
may wrinkle or damage the original. Load these originals using an optional carrier sheet.
1. Open the input tray and pull up its extension.
18
2. Pull out the output tray and open its extension.
3. Slide the input tray edge guides all the way out.
19
4. Check to make sure that the page separation lever is in the position shown here.
Note: To prevent paper jams, keep the lever in this position for most types of documents.
5. Load the originals in the input tray in descending order of paper size with the largest at the back and
the smallest at the front.
Note: If you are loading a paper business card, load it horizontally.
20
6. Slide the edge guides against the edges of the widest document.
Parent topic: Loading Originals in the Input Tray
Related references
Original Document Loading Capacity
Original Document Loading Capacity
You can load original documents that meet these specifications in your scanner.
Paper type
Paper size
Paper weight
Loading capacity
Plain paper
Letter (8.5 × 11 inches
[216 × 279 mm])
13 to 56 lb
(50 to 210 g/m²)
13 lb (50 g/m²): 70 sheets
Fine paper
Recycled paper
21 lb (80 g/m²): 50 sheets
A4 (8.3 × 11.7 inches
[210 × 297 mm])
35 lb (130 g/m²): 30
sheets
Legal (8.5 × 14 inches
[216 × 356 mm])
56 lb (210 g/m²): 15
sheets
A5 (5.8 × 8.2 inches
[148 × 210 mm])
Loading capacity may
vary depending on the
paper type.
A6 (4.1 × 5.8 inches
[105 × 148 mm])
B5 (7.2 × 10.1 inches
[182 × 257 mm])
Paper business cards
Business cards
Up to 56 lb
(210 g/m²)
15 cards loaded
horizontally
Note: You can load original documents of different sizes, up to this size: Letter (8.5 × 11 inches
[216 × 279 mm]). However, do not load different-sized large or thick originals, or valuable original
documents or artwork.
Caution: Do not load the following types of originals in the scanner, or they may be damaged or may
damage the scanner:
• Thermal paper
• Coated paper
• Originals with uneven surfaces, such as embossed documents
21
• Photos
• Originals with wet ink
• Ripped, curled, or wrinkled originals
• Originals containing staples or paper clips
• Originals with holes, other than standard hole-punched originals
• Originals that are bound
• Originals with carbon paper backing
• Transparencies
• Glossy originals
• Carbon-less paper
• Perforated originals
• Originals with labels or stickers
Parent topic: Loading Originals in the Input Tray
Loading Plastic Cards in the Input Tray
You can load plastic cards that meet the card specifications in the input tray.
1. Open the input tray and pull up its extension.
22
2. Pull out the output tray and open its extension.
3. Slide the input tray edge guides all the way out.
23
4. Load one plastic card horizontally in the input tray as shown, sliding it in until it meets resistance.
Make sure the printed side is facedown and top edge first.
Note: Do not load a plastic card vertically.
24
5. Slide the edge guides against the edges of the plastic card.
6. Set the page separation lever to the position shown here.
Note: To prevent paper jams, make sure to set the separation lever back to its original position when
scanning standard single- or multi-page documents.
25
Plastic Card Loading Capacity
Parent topic: Loading Originals
Related references
Page Separation Lever
Related topics
Scanning
Plastic Card Loading Capacity
You can load plastic cards that meet these specifications in your scanner.
Type
Plastic cards, including embossed cards (ISO7810 compliant)
Size
2.1 × 3.3 inches (56 × 85.6 mm)
Thickness
Up to 0.05 inch (1.24 mm) thick, including any embossing
Loading capacity
1 plastic card at a time
Loading direction
Horizontal
Note: Plastic cards with glossy surfaces may not scan properly.
Parent topic: Loading Plastic Cards in the Input Tray
Loading Special Documents
You can load a single envelope or large, thick, or folded original in the input tray. Make sure the original
meets the specifications for special originals before loading it.
1. Open the input tray and pull up its extension.
26
2. Pull out the output tray and open its extension.
3. Slide the input tray edge guides all the way out.
27
4. Do one of the following to load your original:
• Load a large or thick original or an envelope in the input tray as shown. Make sure the printed side
is facedown and top edge first.
• For a folded original, fold and load the original as shown.
28
Caution: Do not load the document with the open side facing down.
• For a photo or an irregularly-shaped original, use an optional carrier sheet to load the document.
Do the following to load the document into the carrier sheet:
• If the original is smaller than the carrier sheet, insert it in the center of the sheet with the printed
side facedown and the top facing the arrow on the sheet.
• If the original is larger than the carrier sheet, fold it in half with the sides to be scanned facing
out. Position the right side of the original faceup with the top facing the arrow on the sheet.
5. Slide the original into the scanner until it meets resistance.
29
6. Slide the edge guides against the edges of the sheet.
7. Set the page separation lever to the position shown here.
Note: To prevent paper jams, make sure to set the separation lever back to its original position when
scanning standard single- or multi-page documents.
30
Large or Thick Original Loading Capacity
Parent topic: Loading Originals
Related references
Page Separation Lever
Related topics
Scanning
Large or Thick Original Loading Capacity
You can load large, thick, or folded originals, or envelopes, that meet these specifications in your
scanner.
Note: You can load only one large, thick, or folded original, or envelope at a time.
31
Paper type
Paper size
Paper weight
Loading capacity
Plain paper, fine
paper, or recycled
paper
Width:
13 to 35 lb (50 to
130 g/m²)
1 sheet
2 to 8.5 inches (52 to
215.9 mm)
Length:
Windows: 2 to 36 inches (52 to
914.4 mm)
OS X: 2 to 16.5 inches (50.8 to
420.1 mm)
Folded plain paper,
Unfolded minimum size:
fine paper, or recycled
A6 (4.1 × 5.8 inches
paper
[105 × 148 mm])
13 to 35 lb (50 to
130 g/m²)
Unfolded maximum size:
Legal (8.5 × 14 inches
[216 × 356 mm])
Envelopes
Up to 0.015 inch (0.38 mm)
thick
—
Irregularly shaped
originals
Up to this size: A4 (8.3 × 11.7
inches [210 × 297 mm])
13 to 35 lb (50 to
130 g/m²)
(load only in a carrier
sheet)
Parent topic: Loading Special Documents
32
Wi-Fi Networking
See these sections to use your scanner over a Wi-Fi network.
Connection Mode Switch
Manual Network Connection Setup
Connecting to an Existing Wi-Fi Network
Direct Wi-Fi Mode Setup
Wi-Fi Protected Setup (WPS)
Epson DocumentScan App for iOS/Android
Using the Network Interface Unit
Connection Mode Switch
The position of the connection mode switch determines which method you can use to connect the
scanner to a wireless network or device, or to a computer.
Connection mode
Description
Wi-Fi
Connects to a Wi-Fi router or access point (requires additional network
setup steps, see link at end of topic)
AP mode
Creates a local Wi-Fi network that allows other devices to connect directly
to the scanner
USB
Connects to a computer via a USB cable
Parent topic: Wi-Fi Networking
Manual Network Connection Setup
If the software installation process did not result in a Wi-Fi connection between your scanner and a
router or access point, do the following to manually connect to a network:
1. Connect your scanner to your computer using a direct Wi-Fi connection.
2. Enter the network settings for your router or access point using EpsonNet Config.
33
3. Set up your computer to scan to the networked scanner.
Follow the links here for instructions on each procedure.
Parent topic: Wi-Fi Networking
Related tasks
Enabling a Direct Wi-Fi Connection
Manually Connecting to a Wi-Fi Router Using EpsonNet Config
Setting Up Network Scanning
Connecting to an Existing Wi-Fi Network
You can set up your scanner to communicate with your computer using a wireless router or access point.
The wireless router or access point can be connected to your computer over a wireless or wired network.
1
Epson scanner
2
Wireless router or access point
3
Computer with a wireless interface
34
4
Computer
5
Internet
6
Ethernet cable (used only for wired connection to the wireless router or access point)
Manually Connecting to a Wi-Fi Router Using EpsonNet Config
Setting Up Network Scanning
Parent topic: Wi-Fi Networking
Manually Connecting to a Wi-Fi Router Using EpsonNet Config
You can use EpsonNet Config to connect the scanner to an existing Wi-Fi network on a router or access
point.
Note: You must have a computer with a wireless adapter to set up the connection.
1. Set the connection mode switch on the scanner to the AP mode position.
2. Turn on the scanner.
3. Connect the computer to the scanner using a direct Wi-Fi connection.
4. Do one of the following to start EpsonNet Config:
• Windows 8.x: Navigate to the Apps screen and select EpsonNet Config.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
EpsonNet > EpsonNet Config > EpsonNet Config.
• OS X: Open the Applications folder, select Epson Software > EpsonNet > EpsonNet Config >
EpsonNet Config.
5. Select your scanner from the list and click Configuration.
6. Select Network Interface > Network > Basic (Wireless).
7. Select the following settings for your infrastructure connection:
• Communication mode: Select Infrastructure.
• SSID: Enter the SSID of the wireless router or access point.
• Security level: Select the wireless connection's security level.
• WEP Settings or WPA Settings: Enter the wireless connection's security key.
8. Click Transmit.
35
9. Open the Device menu and select Quit.
10. Turn off the scanner.
11. Disconnect the computer or device's direct Wi-Fi connection, then connect the computer or device to
the router or access point.
12. Set the connection mode switch on the scanner to Wi-Fi.
13. Turn on the scanner.
When the Status light on the scanner stays on, the connection is established.
14. Set up network scanning on your computer.
Parent topic: Connecting to an Existing Wi-Fi Network
Related tasks
Setting Up Network Scanning
Setting Up Network Scanning
You can set up network scanning using one of these methods:
• through a direct connection to your scanner
• through a connection with the optional Epson Network Interface Unit
Note: Make a note of the IP address or host name of the Network Interface Unit or scanner so you can
enter it in these steps.
1. Do one of the following:
• Manually configure your scanner to connect to your network
• Connect the Epson Network Interface Unit to your scanner and verify they are working properly.
36
2. Do one of the following to start Epson Scan Settings:
• Windows 8.x: Navigate to the Apps screen and select EPSON Scan Settings.
• Windows (other versions): Click
Scan > EPSON Scan Settings.
or Start > All Programs or Programs > EPSON > EPSON
• OS X: Open the Applications folder, click Epson Software, and click EPSON Scan Settings.
3. Select your scanner from the Select Scanner list.
4. Select the Network setting and click Add.
You see a screen like this:
37
5. Do one of the following:
• Under Search for addresses, select the IP address of your Network Interface Unit or scanner,
and click OK.
• Select the Enter address setting, type in the IP address or host name of your Network Interface
Unit or scanner, and click OK.
6. Click the Test button to check the connection.
You see a confirmation message.
7. Click OK to save your settings and close Epson Scan Settings.
Determining the Scanner's IP Address
Parent topic: Connecting to an Existing Wi-Fi Network
Determining the Scanner's IP Address
If you have multiple scanners on your network, you need to know the IP address of the scanner when
setting up network scanning.
1. Do one of the following to start EpsonNet Config:
• Windows 8.x: Navigate to the Apps screen and select EpsonNet Config.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
EpsonNet > EpsonNet Config > EpsonNet Config.
• OS X: Open the Applications folder and select EPSON Software > EpsonNet > EpsonNet
Config > EpsonNet Config.
2. Find your scanner in the list and write down the IP address.
Parent topic: Setting Up Network Scanning
Direct Wi-Fi Mode Setup
You can set up your scanner to communicate directly with your computer or another device without
requiring a wireless router or access point. If your product is not already connected to a wireless
38
network, it enters access point mode and the scanner itself acts as the network access point for up to 4
devices.
1
Epson scanner
2
Computer with a wireless interface
3
Other wireless device
Enabling a Direct Wi-Fi Connection
Using WPS to Set Up a Direct Wi-Fi Connection
Parent topic: Wi-Fi Networking
Enabling a Direct Wi-Fi Connection
You can enable a direct Wi-Fi connection to allow direct communication between your scanner and
computer or other devices without a wireless router or access point.
Before you begin, note the SSID and password shown on the label on the back of the scanner.
39
1. Set the connection mode switch on the scanner to AP mode.
2. Open the input tray and turn on the scanner.
3. From your computer or device, search for and select the SSID shown on the label on the back of the
scanner.
4. Enter the password shown on the label on the back of the scanner.
The Status light on the scanner stays on, indicating that the scanner is connected to the network.
Parent topic: Direct Wi-Fi Mode Setup
Using WPS to Set Up a Direct Wi-Fi Connection
You can use Wi-Fi Protected Setup (WPS) to create a direct Wi-Fi connection to a WPS-enabled
computer or device.
1. Set the connection mode switch on the scanner to AP mode.
2. Open the input tray and turn on the scanner.
40
3. Press and hold the Connect button for at least 3 seconds until the Status and ! error lights flash
alternately.
The scanner enters standby mode for WPS connection for two minutes.
4. Press the WPS button on your computer or device, or enable the WPS feature.
When the Status light on the scanner stays on, the connection is established.
Parent topic: Direct Wi-Fi Mode Setup
Wi-Fi Protected Setup (WPS)
If your network uses a WPS-enabled wireless router or access point, you can quickly connect your
scanner to the network using Wi-Fi Protected Setup (WPS).
Note: To check if your router is WPS-enabled, look for a button labeled WPS on your router or access
point. If there is no hardware button, there may be a virtual WPS button in the software for the device.
Check your network product documentation for details.
Using WPS to Connect to a Network
Using WPS PIN Mode to Connect to a Network
Parent topic: Wi-Fi Networking
Using WPS to Connect to a Network
If you have a WPS-enabled wireless router or access point, you can use Wi-Fi Protected Setup (WPS) to
connect your scanner to the network.
41
1. Set the connection mode switch on the scanner to Wi-Fi.
2. Open the input tray and turn on the scanner.
3. Press and hold the Connect button on the scanner for at least 3 seconds, then release it when the
Status and ! error lights flash alternately.
The scanner enters standby mode for WPS connection for two minutes.
4. Press the WPS button on your router or access point.
The Status light on the scanner stays on, indicating that the scanner is connected to the network.
5. Set up network scanning on your computer.
Parent topic: Wi-Fi Protected Setup (WPS)
Related tasks
Setting Up Network Scanning
Using WPS PIN Mode to Connect to a Network
If you have a WPS-enabled wireless router or access point that supports PIN mode, you can use Wi-Fi
Protected Setup (WPS) PIN mode to connect your scanner to the network.
42
1. Set the connection mode switch on the scanner to AP mode.
2. Open the input tray.
3. Press and hold the Connect button and press the
power button to turn on the scanner.
4. Hold the Connect button until the Status and ! error lights flash alternately.
The scanner enters standby mode for WPS connection for two minutes.
5. Enter the PIN code 01234565 on the wireless router or access point within two minutes.
The Status light on the scanner stays on, indicating that the scanner is connected to the network.
6. Turn off the scanner.
43
7. Set the connection mode switch on the scanner to Wi-Fi.
8. Turn on the scanner.
The Status light on the scanner stays on, indicating that the scanner is connected to the network.
9. Set up network scanning on your computer.
Parent topic: Wi-Fi Protected Setup (WPS)
Related tasks
Setting Up Network Scanning
Epson DocumentScan App for iOS/Android
You can use the Epson DocumentScan app to scan from a network scanner to an iOS or Android device
over a direct Wi-Fi connection.
You can find more information about Epson DocumentScan by searching for the app on the App Store
(iOS) or Google Play (Android).
Parent topic: Wi-Fi Networking
Related tasks
Enabling a Direct Wi-Fi Connection
Using WPS to Set Up a Direct Wi-Fi Connection
Using the Network Interface Unit
See these sections to use the optional Epson Network Interface Unit to scan over a network.
Network Interface Unit Control Panel
Connecting the Network Interface Unit
Scanning to Network Computers from the Network Interface Unit - Windows
Parent topic: Wi-Fi Networking
44
Network Interface Unit Control Panel
1
The
2
The LCD screen (displays status, operations, and error messages)
3
The
settings button (selects product settings, network settings, and maintenance options)
4
The
Reset button (returns the LCD to the default screen)
5
The
Stop button (cancels scanning)
6
The OK button and arrows (use the arrows to highlight an option and the OK button to select it)
7
The
power button (turns the unit on and off)
start button (starts scanning when networking is enabled)
Parent topic: Using the Network Interface Unit
Connecting the Network Interface Unit
See the documentation that came with the optional Epson Network Interface Unit for instructions on
connecting it to your scanner.
Parent topic: Using the Network Interface Unit
Scanning to Network Computers from the Network Interface Unit - Windows
You can scan to a network computer directly from the Network Interface Unit (Windows only). You first
set up a scan job in Document Capture Pro and then select the computer you want to send the scanned
file to.
45
1. Start a scan job using Document Capture Pro.
2. Press the OK button on the Network Interface Unit.
3. On the LCD screen of the Network Interface Unit, select the computer you want to send the scanned
file to and press the OK button.
Note: If your scanner is part of a group, make sure to set the computer to the same group or it will
not show up on the LCD screen.
4. If you set up a password in Document Capture Pro, enter the password at the prompt.
5. Select a scan job and press the OK button.
6. Press the
start button on the scanner.
Your original is scanned and the file is sent to the network computer you selected.
Parent topic: Using the Network Interface Unit
46
Scanning
You can scan original documents or photos and save them as digital files.
Starting a Scan from a Scanner Button
Scanning with Document Capture Pro and Document Capture
Scanning with Epson Scan
Scanning Special Projects
Starting a Scan from a Scanner Button
You can scan using a button on your scanner. This automatically starts the scanning program you have
assigned to the button.
Your product automatically selects suitable default scan settings, but you can view or change them as
necessary.
Note: Document Capture Pro (Windows) and Document Capture (OS X) do not support scanning from
the scanner button over a wireless network. Launch Epson Scan before scanning from the scanner
button.
1. Make sure you installed the scanner software and connected the scanner to your computer or
network.
2. Load an original in your scanner.
3. Press the
start button.
The image is scanned and saved to the folder you have specified.
Note: If your product is connected via USB, you can use Document Capture Pro (Windows) or
Document Capture (OS X) to change the default scan settings when you scan using the start
button.
Assigning Start Button Settings or Scan Jobs
Parent topic: Scanning
Assigning Start Button Settings or Scan Jobs
You can view or change the default scan settings when you scan using the start button. You do this
using the Document Capture Pro (Windows) or Document Capture (OS X) program.
47
1. Start Document Capture Pro or Document Capture on a computer connected to the scanner.
2. Click the
Manage Job icon from the toolbar at the top of the window.
3. On the Job Management window, click Add or the + icon.
4. Enter a name for the new job, then select the settings you want to view or change and change the
settings as necessary, and click OK.
Note: See the Help information in Document Capture Pro or Document Capture for details.
5. Do one of the following:
• Windows: On the Job Management window, click Event Settings.
• OS X: Click the
icon at the bottom of the window, then click Event Settings.
6. Select the job that you want to assign to the
start button from the pull-down menu.
7. Click OK.
Parent topic: Starting a Scan from a Scanner Button
Scanning with Document Capture Pro and Document Capture
When you scan with Document Capture Pro (Windows) or Document Capture (OS X), the program
automatically saves your scanned file on your computer in the folder you specify. You can select
settings, preview, and change the scanned file settings as necessary.
Note: The settings may vary, depending on the software version you are using. See the Help information
in Document Capture or Document Capture Pro for details.
1. Do one of the following to start Document Capture Pro (Windows) or Document Capture (OS X):
• Windows 8.x: Navigate to the Apps screen and select Document Capture Pro.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
EPSON Software, then select Document Capture Pro.
• OS X: Open the Applications folder, select the Epson Software folder, and select Document
Capture.
48
You see a window like this:
2. Click the
Scan icon.
49
You see a window like this:
Note: If you want to use a scan job that you created instead, select it from the Job list in the
Document Capture Pro or Document Capture window, click the
Start Job button, and skip the
rest of these steps.
3. Select any displayed scan settings you want to use.
Note: See the Help information in Document Capture Pro or Document Capture for details.
4. If you want to select detailed scan settings, do one of the following:
• Windows: Click Detailed Settings. Select any displayed scan settings you want to use and click
OK.
• OS X: Close the Scan window. Open the Scan menu at the top of the screen and select Displays
the EPSON Scan Setup Screen. Click the
Scan icon. Select any displayed scan settings you
want to use and click OK.
50
5. Click Scan.
You see a preview of your scan in the Document Capture Pro (Windows) or Document Capture
(OS X) window.
6. If you would like to scan additional originals and add them to the current captured images, click the
Add Page button and repeat steps 2 through 5.
7. Check the scanned images and edit them as necessary.
8. Click one of the Destination icons to choose where to send your scanned files. (If you cannot see all
of the icons below, click the arrow next to the icons.)
9. Depending on the destination you chose, click OK or Send to complete the operation.
Parent topic: Scanning
Related tasks
Scanning with Epson Scan
Related topics
Loading Originals
Scanning with Epson Scan
Epson Scan automatically saves your scanned file on your computer in the format and folder you
specify. You can select settings, preview, and change the scanned file settings as necessary.
1. Do one of the following to start Epson Scan:
• Windows 8.x: Navigate to the Apps screen and select EPSON Scan under EPSON or EPSON
Software.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
EPSON or EPSON Software and click EPSON Scan.
• OS X: Open the Applications folder, open the Epson Software folder, and double-click the
EPSON Scan icon.
51
You see a window like this:
2. Select options for each of the scan settings on the screen.
3. If necessary, click the Preview button.
Epson Scan previews your original, and displays the result in a separate Preview window. The
scanner also ejects the page.
4. Reload the page in the scanner.
52
5. Click the Image Adjustment tab and select any of the image adjustment settings you want to use.
Before making adjustments, click the image or scan area in the Preview window.
6. Click Scan.
You see the File Save Settings window.
7. Change any of the necessary file save settings and click OK.
Epson Scan scans your original, and saves the file in the selected folder or opens it in your scanning
program. If the file was saved directly to your computer, you see the file in the Windows Explorer or OS X
Finder, where you can view and print the image, if desired.
Available Image Adjustments
Parent topic: Scanning
Related topics
Loading Originals
Available Image Adjustments
You can select these options from the Image Adjustments tab in Epson Scan.
Note: Not all adjustment settings may be available, depending on the Image Type setting.
Select the Image Option checkbox to access additional settings.
Unsharp Mask
Makes the edges of certain image areas clearer. Turn off this option to leave softer edges.
Descreening
Removes the ripple pattern that might appear in subtly shaded image areas, such as skin tones. This
option improves results when scanning magazines or newspapers. (The results of descreening do not
appear in the preview image, only in your scanned image.)
Text Enhancement
Sharpens the appearance of letters in text documents.
Auto Area Segmentation
Makes grayscale images clearer and text recognition more accurate by separating the text from the
graphics.
Dropout
The scan will not pick up the color you select. This setting is only available if you select an Image
Type of Grayscale or Black & White.
53
Color Enhance
Enhances the red, green, or blue shades in the scanned image.
Brightness
Adjusts the overall lightness and darkness of the scanned image.
Contrast
Adjusts the difference between the light and dark areas of the overall scanned image.
Parent topic: Scanning with Epson Scan
Scanning Special Projects
Your product's scanning software offers various options to help you quickly complete special scan
projects.
Scanning Two Originals onto One Sheet (Stitching Images)
Scanning Multi-Page Originals as Separate Files - Windows
Convert Scanned Documents to Editable Text (OCR)
Scanning to a SharePoint Server or Cloud Service
Parent topic: Scanning
Scanning Two Originals onto One Sheet (Stitching Images)
You can scan both sides of a double-sided or folded original with Epson Scan's Stitch Images settings.
1. Load your original in the scanner.
2. Do one of the following to start Document Capture Pro (Windows) or Document Capture (OS X):
• Windows 8.x: Navigate to the Apps screen and select Document Capture Pro.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
EPSON Software, then select Document Capture Pro.
• OS X: Open the Applications folder, select the Epson Software folder, and select Document
Capture.
54
You see a window like this:
3. Do one of the following to access the Epson Scan settings:
• Windows: Click the
Scan icon, then click Detailed Settings.
• OS X: Open the Scan menu at the top of the screen and select Displays the EPSON Scan Setup
Screen. Click the
Scan icon.
55
You see an Epson Scan window like this:
4. Select Double-Sided as the Document Source setting.
5. Select the original document size as the Size setting.
6. Select one of the following as the Stitch Images setting:
• Top&Bottom: Places the scanned images one above the other.
• Left&Right: Places the scanned images side by side.
56
7. With Windows, click OK.
8. Click Scan.
The scanned image is displayed.
Note: If the scanned images are not stitched together correctly, click Configuration on the Epson
Scan window and select the Binding Position (for Double-Sided Scanning) setting on the
Document tab.
Parent topic: Scanning Special Projects
Related tasks
Loading Originals in the Input Tray
Loading Special Documents
Scanning Multi-Page Originals as Separate Files - Windows
You can use Document Capture Pro (Windows only) to scan multi-page originals as separate scanned
files. You indicate where you want the new scanned files to start by inserting a blank page or barcode
between the pages of your original.
Note: The settings may vary, depending on the software version you are using. See the Help information
in Document Capture Pro for details.
1. Load a multi-page original with blank pages or barcodes inserted where you want to start a new
scanned file.
2. Do one of the following to start Document Capture Pro:
• Windows 8.x: Navigate to the Apps screen and select Document Capture Pro.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
EPSON Software, then select Document Capture Pro.
57
You see this window:
3. Click the
Scan icon.
4. Select any displayed scan settings you want to use.
Note: See the Help information in Document Capture Pro for details.
5. Click Scan.
You see a preview of your scan in the Document Capture Pro window.
6. Click one of the Destination icons to choose where to send your scanned files. (If you cannot see all
of the icons below, click the arrow next to the icons.)
7. Click File Name & Separation Settings.
8. Select Apply job separation and click Separation Settings.
58
9. Select the method you used to separate the originals, select a folder name specification and click
OK.
10. Select any additional settings from the File Name Settings dialog and click OK.
11. Select any additional settings and click OK or Send.
Your originals are saved into separate files and folders as specified by your settings.
Parent topic: Scanning Special Projects
Related topics
Loading Originals
Convert Scanned Documents to Editable Text (OCR)
You can scan a document and convert the text into data that you can edit with a word processing,
spreadsheet, or HTML-editing program. This process is called OCR (Optical Character Recognition).
To scan and use OCR, you need to install an OCR program, such as ABBYY FineReader.
Scanning Using OCR - Windows
Scanning Using OCR - OS X
Parent topic: Scanning Special Projects
Scanning Using OCR - Windows
You can use the ABBYY FineReader OCR program to convert scanned documents to editable text.
1. Load your original in the scanner.
2. Do one of the following to open ABBYY FineReader:
• Windows 8.x: Navigate to the Apps screen and select ABBYY FineReader 9.0 Sprint.
• Windows (other versions): Click
or Start > All Programs or Programs > ABBYY
FineReader 9.0 Sprint > ABBYY FineReader 9.0 Sprint.
59
You see a window like this:
3. Select the language used in the document you are going to scan as the Document Language
setting.
4. Click the icon that corresponds with the program or format you want to scan to.
5. If you see the Select Scanner window, select your product and click OK.
Note: Do not select a WIA option for your product; it will not work correctly.
You see the scan settings window.
6. Select your scan settings.
7. Click Preview and adjust the area you want to scan, if necessary.
8. Click Scan.
Note: To scan a multi-page document, select settings in the Multi-Page Scanning section and click
Scan for each page.
9. When you are finished scanning, click Close.
60
Your document is scanned and processed into editable text, then you see the Save As window.
10. Select a name and a file format for your document and click Save.
The file is saved and then opened in an application associated with the file type you selected, if
available on your system.
Parent topic: Convert Scanned Documents to Editable Text (OCR)
Related topics
Loading Originals
Scanning Using OCR - OS X
You can use the ABBYY FineReader OCR program to convert scanned documents to editable text.
1. Load your original in the scanner.
2. Open the Applications folder and click the ABBYY FineReader Sprint icon.
61
You see a window like this:
3. Open the Get Images From pop-up menu and select your product.
4. Select the language used in the document you are going to scan as the Document Language
setting.
5. Select the type of document you are going to scan.
Epson Scan starts in the last scan mode you used.
6. Select your scan settings and click Scan.
Your document is scanned and you see the Epson Scan window while your document is converted
to editable text.
62
7. Click Close to close the Epson Scan window and Preview window, if necessary.
You see the Save Converted File As window:
8. Click the Save button.
The file is saved and then opened in an application associated with the file type you selected, if
available on your system.
Parent topic: Convert Scanned Documents to Editable Text (OCR)
Related topics
Loading Originals
Scanning to a SharePoint Server or Cloud Service
You can use Document Capture Pro (Windows) or Document Capture (OS X) to upload scanned images
to a SharePoint server or a cloud service.
1. Do one of the following to start Document Capture Pro (Windows) or Document Capture (OS X):
• Windows 8.x: Navigate to the Apps screen and select Document Capture Pro.
• Windows (other versions): Click
or Start, and select All Programs or Programs. Select
EPSON Software, then select Document Capture Pro.
• OS X: Open the Applications folder, select the Epson Software folder, and select Document
Capture.
63
You see a window like this:
2. Click the
Scan icon.
3. Select any displayed scan settings you want to use.
Note: See the Help information in Document Capture Pro or Document Capture for details.
4. Click Scan.
You see a preview of your scan in the Document Capture Pro or Document Capture window.
5. Click one of the cloud service Destination icons to choose where to save your scanned file. (If you
cannot see all of the icons below, the service software may not be installed, or you need to click the
arrow next to the icons.)
•
Web Folder (WebDAV)
•
Microsoft SharePoint server (Windows only)
•
Evernote
64
•
Microsoft OneNote
•
Google Drive
•
SugarSync
You see the Transfer Settings window.
6. Enter any required information to set up the destination. If you have previously created a saved
setting for the destination, select it from the drop-down list.
7. Adjust any save settings, then click OK, Send, or Print, depending on the destination.
Your originals are scanned and uploaded to the indicated server.
Parent topic: Scanning Special Projects
Related topics
Loading Originals
65
Cleaning and Transporting Your Scanner
See these sections if you need to clean or transport your scanner.
Cleaning Your Scanner
Cleaning Inside Your Scanner
Checking the Scanner Roller Counter
Replacing the Scanner Rollers
Transporting Your Scanner
Cleaning Your Scanner
To keep your product working at its best, you should clean it several times a year.
Caution: Do not use a hard brush, alcohol, or paint thinner to clean the product or you may damage it.
Do not use oil or other lubricants inside the product or let water get inside it. Do not open the product's
outer case.
1. Turn off the scanner and unplug the AC adapter.
2. Disconnect any connected cables.
3. Clean the outer case with a soft, dry cloth. Do not use liquid or chemical cleansers.
Note: If the outer case still requires additional cleaning, use a slightly damp cloth to wipe the outer
case. Then wipe the case with a soft, dry cloth.
Parent topic: Cleaning and Transporting Your Scanner
Cleaning Inside Your Scanner
Clean your scanner regularly to make sure that no dust builds up on the glass scanning surfaces. Dust
can cause spots or lines in your scanned images.
Caution: Do not use a hard brush, alcohol, or paint thinner to clean the product or you may damage it.
Do not use oil or other lubricants inside the product or let water get inside it.
1. Turn off the scanner and unplug the AC adapter.
2. Disconnect any connected cables.
66
3. Pull down on the cover open lever and open the scanner cover.
4. Use a soft, dry cloth to wipe off any dust or dirt on the rollers inside the scanner cover.
67
5. Wipe off any dust or dirt on the pickup rollers.
6. Plug in the AC adapter and press the
power button to turn on the scanner.
7. Hold down the start button for at least two seconds, and press the start button several times to
rotate the rollers shown here. Wipe off any dust or dirt on the rollers as they rotate.
8. Turn off the scanner and unplug the AC adapter.
68
9. Wipe off any dust or dirt on the glass scanning surfaces using a soft, dry cloth. If the glass surface is
stained with grease or some other hard-to-remove material, use a small amount of glass cleaner on
a soft cloth to remove it. Wipe off all remaining liquid.
Caution: Do not spray glass cleaner directly on the scanning surfaces. Be careful not to place too
much force on the glass.
10. Close the scanner cover.
11. Plug in the AC adapter and turn on the scanner.
Parent topic: Cleaning and Transporting Your Scanner
Checking the Scanner Roller Counter
Check the scanner roller counter to determine when your rollers need to be replaced. When you replace
the scanner rollers, reset the scanner roller counter so you know when you may need to replace the
rollers again.
1. Make sure the scanner is turned on and connected to your computer.
2. Do one of the following to open Epson Scan Settings:
• Windows 8.x: Navigate to the Apps screen and select EPSON Scan Settings.
• Windows (other versions): Click
Scan > EPSON Scan Settings.
or Start > All Programs or Programs > EPSON > EPSON
69
• OS X: Open the Applications folder, click Epson Software, and click EPSON Scan Settings.
3. Click Maintenance.
You see a screen like this:
4. You can check the scanner roller counter by reading the number in the Number of Scans field. If the
number of scans exceeds the Life Cycle of the rollers, it is time to replace the rollers.
5. Click OK.
Parent topic: Cleaning and Transporting Your Scanner
Replacing the Scanner Rollers
Replace the scanner rollers after you have scanned 100,000 times. Check the scanner roller counter to
see when you need to replace the rollers.
1. Turn off the scanner.
2. Unplug the AC adapter.
3. Disconnect any connected cables.
70
4. Pull down on the cover open lever and open the scanner cover.
5. Squeeze the tab on the right side of the pickup roller cover and open the cover.
71
Caution: Do not place too much force on the arm inside the cover when replacing the pickup roller.
6. Slide the pickup rollers to the right and remove them.
72
7. To install the new lower pickup roller, align the notches on the roller and slide it to the left.
8. To install the new upper pickup roller, align the notches on the roller and slide it to the left. Make sure
the smaller roller is on the bottom.
Caution: Do not touch the surface of the rollers.
9. Close the pickup roller cover.
Note: If you are not able to close the cover, the pickup rollers are not installed correctly. Remove the
rollers and reinstall them, then try to close the cover again.
73
10. Press down on the separation roller cover latch inside the scanner cover and pull down the cover to
open it.
Caution: Be careful not to apply too much force when opening the cover.
11. Press in on the separation roller to release it, then slide the roller to the side and remove it.
12. Pull the release tab on the separation roller and remove it from the spindle.
74
13. Slide the new separation roller onto the spindle as shown. Make sure that the notches on the roller
and spindle align properly.
Note: Check that there are no gaps between the roller and spindle. You hear a click when the roller
is firmly locked into place.
14. Align the notches on the spindle and the scanner, then slide the separation roller into the scanner
and gently push it into place. You hear a click when the roller is correctly aligned and locked into
place.
75
15. While applying gentle pressure on the separation roller, close the separation roller cover.
Note: If you are not able to close the cover, the roller is not installed correctly. Remove the roller and
reinstall it, then try to close the cover again.
16. Close the scanner cover.
17. Plug in the AC adapter and turn on the scanner.
Reset the roller counter after replacing the rollers.
Resetting the Scanner Roller Counter
Parent topic: Cleaning and Transporting Your Scanner
Related references
User Replaceable Epson Scanner Parts and Accessories
Related tasks
Checking the Scanner Roller Counter
Resetting the Scanner Roller Counter
When you replace the scanner rollers, reset the scanner roller counter so you know when you may need
to replace the rollers again.
1. Make sure the scanner is turned on and connected to your computer.
2. Do one of the following to open Epson Scan Settings:
• Windows 8.x: Navigate to the Apps screen and select EPSON Scan Settings.
• Windows (other versions): Click
Scan > EPSON Scan Settings.
or Start > All Programs or Programs > EPSON > EPSON
• OS X: Open the Applications folder, click Epson Software, and click EPSON Scan Settings.
3. Click Maintenance.
76
You see a screen like this:
4. Click Reset.
The number of scans changes to 0 (zero).
5. Click OK.
Parent topic: Replacing the Scanner Rollers
Related tasks
Replacing the Scanner Rollers
Transporting Your Scanner
If you need to ship your product, transport it a long distance, or store it for an extended period, prepare it
for transportation as described here.
1. Turn off the scanner and unplug the AC adapter.
2. Disconnect any connected cables.
3. Close the input tray and the output tray.
Note: Make sure the output tray is securely closed.
77
4. Place the scanner in its original packing materials, if possible, or use equivalent materials with
cushioning around the product.
Parent topic: Cleaning and Transporting Your Scanner
78
Solving Problems
Check these sections for solutions to problems you may have using your product.
Scanner Light Status
Solving Scanning Problems
Solving Scanned Image Quality Problems
When to Uninstall Your Scanner Software
Where to Get Help
Scanner Light Status
You can often diagnose problems with your scanner by checking its lights.
Lights
1
The ! error light
2
The Status light
79
Light status
Condition/solution
The Status light is on
The scanner is turned on and ready to scan.
The Status light is flashing
blue
The scanner is scanning or initializing. Wait for the Status light to stop
flashing before turning off the scanner.
The ! error light is on
An error has occurred. Try the following:
• Check the scanner connection to your computer to make sure it is
secure.
• Make sure the scanner cover is closed and there is no jammed paper
inside.
• If the ! error light is still on, turn off the scanner, then turn it on again.
If the error continues, the scanner may be malfunctioning. Contact
Epson for support.
The ! error light and the
Status light (blue) are
flashing alternately
The scanner firmware is updating. Do not turn off the scanner or
disconnect any cables until the status lights have stopped flashing.
The ! error light and the
Status light are flashing at
the same time
A paper jam or a double feed has occurred. Remove any paper loaded
in the input tray. If the lights continue to flash, a scanner error may have
occurred. Turn the scanner off and then back on again. If the error
continues, contact Epson for support.
The Status light is flashing
white
The scanner is connecting to a wireless network.
The ! error light and the
Status light (white) are
flashing alternately
The product is in a standby state for Wi-Fi Protected Setup (WPS)
connection or the firmware is being updated.
Parent topic: Solving Problems
Related references
Original Jams in Scanner
Where to Get Help
Related topics
Loading Originals
Scanning
Wi-Fi Networking
80
Solving Scanning Problems
Check these solutions if you have problems scanning with your product.
Scanner Does Not Turn On or Turns Off Unexpectedly
Scanner Button Does Not Work as Expected
Scanning Software Does Not Operate Correctly
Cannot Start Epson Scan
Original Feeds Incorrectly in Scanner
Original Jams in Scanner
Scanning is Slow
Cannot Scan Over a Network
Scanner Cannot Connect to a Wireless Router or Access Point
Parent topic: Solving Problems
Scanner Does Not Turn On or Turns Off Unexpectedly
If the scanner does not turn on or if it turns off unexpectedly, try these solutions:
• Make sure the AC adapter is securely connected to the scanner and to a working electrical outlet.
• If the scanner turns off unexpectedly, you may need to adjust the Power Off Timer setting.
Parent topic: Solving Scanning Problems
Related tasks
Changing the Power Off and Sleep Timer Settings
Scanner Button Does Not Work as Expected
If the scanner button does not start the correct program or perform the correct action, try these solutions:
• Make sure Document Capture Pro (Windows) or Document Capture (OS X) is installed correctly. If
necessary, uninstall and reinstall it.
• Make sure you have assigned the correct job to the scanner button and change it, if necessary.
• If you selected Keep Blocking in a Windows Security Alert window during or after installation of
Document Capture Pro, unblock the EEventManager Application program in the Windows security
settings; see Windows help for details.
• Check the status of the lights and make sure the scanner is ready to scan.
• Make sure the connection mode switch is set correctly.
81
• When using a wireless connection, start Epson Scan on your computer before scanning from the
product.
• Document Capture Pro (Windows) and Document Capture (OS X) do not support using the button to
scan over a wireless connection. Connect the scanner using a USB cable.
• With OS X, make sure you are logged in as the user who installed the scanner software. Other users
must run Epson Scanner Monitor in the Applications folder before using the button to scan.
Parent topic: Solving Scanning Problems
Related tasks
Assigning Start Button Settings or Scan Jobs
Scanning Software Does Not Operate Correctly
If your scanning software does not operate correctly, try these solutions:
• Make sure your computer has adequate memory and meets the system requirements for your
operating system.
• Make sure your computer is not running in a power-saving mode, such as sleep or standby. If so,
wake your system and restart your scanning software.
• Make sure the scanner is turned on.
• Make sure the connection between the scanner and your computer is secure.
• If you upgraded your operating system but did not reinstall your scanning software, try reinstalling it.
• If you are scanning using OS X, make sure no other Epson scanner drivers are installed. If other
drivers are installed, uninstall them, then reinstall this scanner's software.
• If you are using a TWAIN-compliant program, make sure that the correct product is selected as the
Scanner or Source setting.
Parent topic: Solving Scanning Problems
Related concepts
When to Uninstall Your Scanner Software
Related references
Windows System Requirements
Mac System Requirements
82
Cannot Start Epson Scan
If you cannot start Epson Scan, try these solutions:
• Make sure your scanner is turned on and any interface cables are securely connected at both ends.
• Make sure Epson Scan is selected in your scanning program.
• Make sure your computer is not running in a power-saving mode, such as sleep or standby. If so,
wake your system and restart Epson Scan.
• If you connected the scanner using a USB cable, make sure it is connected directly to your computer
or through only one USB hub.
• Check the connection setting and test the connection using Epson Scan Settings:
• Windows 8.x: Navigate to the Apps screen and select EPSON Scan Settings. Make sure the
correct Connection setting is selected, then click the Test button.
• Windows (other versions): Click
or Start > All Programs or Programs > EPSON > EPSON
Scan > EPSON Scan Settings. Make sure the correct Connection setting is selected, then click
the Test button.
• OS X: Open the Applications folder, click Epson Software, and click EPSON Scan Settings.
Make sure the correct Connection setting is selected, then click the Test button.
• Make sure you do not have multiple versions of Epson Scan installed. If you do, uninstall both versions
and install one version.
• If you upgraded your operating system but did not reinstall Epson Scan, try reinstalling it.
• If you are using a TWAIN-compliant program, make sure that the correct product is selected as the
Scanner or Source setting.
Parent topic: Solving Scanning Problems
Related concepts
When to Uninstall Your Scanner Software
Related references
Windows System Requirements
Mac System Requirements
83
Original Feeds Incorrectly in Scanner
If you have problems feeding originals in your scanner, try these solutions:
• If multiple pages feed at once, try the following:
• Make sure the paper separation lever is in the lower position.
• Remove the originals, fan the edges to separate the sheets, if necessary, and reload them.
• Load only originals that meets the specifications for your scanner.
• Clean inside the scanner and replace the roller assembly kit, if necessary.
• If you see a double feed error in the Epson Scan window or the Document Capture Pro window
(Windows only), start Epson Scan, select Configuration, select the Detect Double Feed setting, and
select Standard as the Paper Thickness setting. If the error persists, deselect the Detect Double
Feed setting.
Note: For OS X, only Epson Scan displays double feed errors. Document Capture for OS X does not
include this setting.
Parent topic: Solving Scanning Problems
Related tasks
Cleaning Inside Your Scanner
Related topics
Loading Originals
Original Jams in Scanner
If an original has jammed inside the scanner, follow these steps:
1. Turn off your scanner.
2. Remove all originals from the input tray.
84
3. Pull down the cover open lever and open the scanner cover.
4. Gently pull out any jammed originals from inside the scanner.
85
5. Gently pull out any jammed originals from the output tray.
6. Close the scanner cover.
7. Carefully follow all loading instructions when you reload originals.
Parent topic: Solving Scanning Problems
Related tasks
Cleaning Inside Your Scanner
Related topics
Loading Originals
Scanning is Slow
If scanning becomes slow, try these solutions:
• Scan your original at a lower resolution, if possible.
• Make sure your system meets the requirements for your operating system. If you are scanning a highresolution image, you may need more than the minimum requirements, such as a Hi-Speed USB port.
If necessary, increase your system's memory.
86
• If you are running virus protection or other security software, exclude the TWAIN.log files from
monitoring or set the TWAIN.log file as read only (Windows). See your virus protection or security
software instructions for details. The TWAIN.log file is saved in the following locations:
• Windows XP: C:\Documents and Settings\(user name)\Local Settings\Temp
• Windows (other versions): C:\Users\(user name)\AppData\Local\Temp
Parent topic: Solving Scanning Problems
Related references
Windows System Requirements
Mac System Requirements
Cannot Scan Over a Network
If you cannot start Epson Scan for scanning over a network, try these solutions:
• If you cannot scan from the start button on the scanner, make sure you restarted your computer
after installing the scanning software. Make sure the Event Manager program is not being blocked by
your firewall or security software. Also start Epson Scan before scanning with the start button.
• Document Capture Pro (Windows) and Document Capture (OS X) do not support starting a scan from
the scanner button over a wireless network. Launch Epson Scan before scanning from the scanner
button.
• If you are scanning a large original at a high resolution, a network communication error may occur. Try
scanning again at a lower resolution.
• If network communication was interrupted while starting Epson Scan, exit Epson Scan, wait a few
seconds, and restart it. If Epson Scan cannot restart, turn off your scanner, turn it back on, and try
restarting Epson Scan again.
• Check the connection setting and test the connection using Epson Scan Settings:
Windows 8.x: Navigate to the Apps screen and select EPSON Scan Settings. Make sure the
Connection setting is set to Network, then click the Test button.
Windows (other versions): Click
or Start > All Programs or Programs > EPSON > EPSON
Scan > EPSON Scan Settings. Make sure the Connection setting is set to Network, then click the
Test button.
OS X: Open the Applications folder, click Epson Software, and click EPSON Scan Settings. Make
sure the Connection setting is set to Network, then click the Test button.
• Make sure the option selected as the Timeout Setting in the Epson Scan Settings program is long
enough to complete scanning over a network.
87
• You may need to disable the firewall and any anti-virus software on your wireless router or access
point.
• If you see the message "Network product is not available: currently being used by user", there may be
a communication error between the scanner and computer. Restart the scanner.
• Epson Scan does not support networks that use only IPv6. Use Epson Scan on a network that
supports IPv4.
• If the Firewall function is active on Windows XP or later, the scanner may not be discovered by Epson
Scan Settings. Open Epson Scan Settings, click Add, and enter the IP address for your scanner.
Parent topic: Solving Scanning Problems
Related topics
Wi-Fi Networking
Scanner Cannot Connect to a Wireless Router or Access Point
If your scanner has trouble finding or connecting to a wireless router or access point, try these solutions:
• If you are connecting the scanner via Wi-Fi Protected Setup (WPS), make sure you press the WPS
button on the router or access point within 2 minutes of activating WPS on your scanner.
• Make sure to place your scanner within contact range of your router or access point. Avoid placing
your scanner near a microwave oven, 2.4 GHz cordless phone, or large metal object, such as a filing
cabinet.
Note: If you are using a 5 GHz wireless router, set the router to operate in dual band (2.4 GHz and 5
GHz) mode. See your router documentation for instructions.
• Verify that your router or access point is operating correctly by connecting to it from your computer or
another device.
• You may need to disable the firewall and any anti-virus software on your wireless router or access
point.
• Check to see if access restrictions, such as MAC address filtering, are set on the router or access
point. If access restrictions are set, add your scanner's MAC address to your router's address list. To
obtain your scanner's MAC address, check the label on the back of your scanner. Then follow the
instructions in your router or access point documentation to add the address to the list.
• If your router or access point does not broadcast its network name (SSID), follow the instructions that
came with your scanner to enter your wireless network name manually.
88
• If your router or access point has security enabled, determine the kind of security it is using and any
required password or passphrase for connection. Then make sure to enter the exact WEP key or WPA
passphrase correctly.
• Check if your computer is restricting the available wireless channels. If so, verify that your wireless
access point is using one of the usable channels and change to a usable channel, if necessary.
• If you connected your scanner to a Windows computer using a direct Wi-Fi connection and it
automatically selected Access Point Mode, you may have trouble accessing a low-priority Internet
connection. Check the network connection or adapter settings in the Windows Control Panel and set
the Internet metric setting to 100 for your version of the Internet Protocol.
• The scanner may not be able to communicate with a computer with multiple network interfaces.
Disable all network interfaces except for the interface connected to the scanner.
• Enable the DHCP function on the access point or router.
• Check that the scanner's IP address is set correctly.
Parent topic: Solving Scanning Problems
Related topics
Wi-Fi Networking
Solving Scanned Image Quality Problems
Check these sections if a scanned image on your computer screen has a quality problem.
Back of Original Image Appears in Scanned Image
Scanned Characters are Blurry
Characters are not Recognized During Conversion to Editable Text (OCR)
Ripple Patterns Appear in an Image
Spots or Lines Appear in All Scanned Images
Scanned Image Edges are Cropped
Parent topic: Solving Problems
Back of Original Image Appears in Scanned Image
If an image from the back of a thin original appears in your scanned image, make sure you selected the
correct Image Type setting for your original and select the Text Enhancement setting in Epson Scan.
Parent topic: Solving Scanned Image Quality Problems
Related references
Available Image Adjustments
89
Related tasks
Scanning with Epson Scan
Scanned Characters are Blurry
If characters in your scanned images are blurry, try these solutions:
• Make sure you do not move the scanner or original while scanning.
• Operate the scanner on a flat, stable surface.
• Adjust these Epson Scan settings (if available) and try scanning again:
• Select the Text Enhancement setting.
• Adjust the Threshold setting.
• Increase the Resolution setting.
Parent topic: Solving Scanned Image Quality Problems
Related references
Available Image Adjustments
Related tasks
Scanning with Epson Scan
Characters are not Recognized During Conversion to Editable Text (OCR)
If characters in your scanned images are not recognized during OCR conversion, try these solutions:
• Make sure your original is straight.
• Adjust these Epson Scan settings (if available) and try scanning again:
• Select Text Enhancement
• Select the correct Image Type setting
• Adjust the Threshold setting
• Set the scanning resolution between 200 and 600 dpi.
• If you are using OCR software, check the manual for any additional adjustments.
• Try using another software program, such as ABBYY FineReader, as the OCR engine. Start Epson
Scan and click File Save Settings. Select PDF as the File Type and click Options. Click the Text
tab. Make sure Fine Reader is selected as the OCR Engine setting and click OK twice. Try your scan
again using Epson Scan.
90
Parent topic: Solving Scanned Image Quality Problems
Related concepts
Convert Scanned Documents to Editable Text (OCR)
Related references
Available Image Adjustments
Related tasks
Scanning with Epson Scan
Ripple Patterns Appear in an Image
You may see a ripple pattern (called a moiré) in scanned images of printed documents. This is caused
by interference from differing pitches in the scanner's screen and your original's halftone screen. To
reduce this effect, adjust these Epson Scan settings (if available) and try scanning again:
• Select the Descreening setting.
• Select a lower Resolution setting.
Parent topic: Solving Scanned Image Quality Problems
Related references
Available Image Adjustments
Related tasks
Scanning with Epson Scan
Spots or Lines Appear in All Scanned Images
If spots or lines appear in all your scanned images, follow these steps to clean the scanner glass:
1. Turn off the scanner.
2. Unplug the AC adapter.
3. Disconnect any connected cables.
91
4. Pull down on the cover open lever and open the scanner cover.
5. Wipe off any stains on the glass scanning surfaces using a soft, dry cloth.
Note: If the glass surfaces are stained with grease or some other hard-to-remove material, use a
small amount of glass cleaner on a soft cloth to remove it. Wipe off all remaining liquid.
Caution: Do not spray glass cleaner directly on the scanning surfaces. Be careful not to place too
much force on the glass.
92
6. Close the scanner cover.
7. Plug in the AC adapter.
Parent topic: Solving Scanned Image Quality Problems
Related tasks
Cleaning Inside Your Scanner
Scanned Image Edges are Cropped
If the edges of a scanned image are cropped, try the following solutions:
• Select Auto Detect as the Size setting (Epson Scan) or the Document Size setting (Document
Capture Pro or Document Capture).
• Adjust the cropping area shown in the Crop Margins for Size "Auto" setting in Epson Scan.
• Document Capture Pro (Windows): Select Detailed Settings from the Scan window. Click
Configuration and select the Document tab. Adjust the cropping area shown in the Crop Margins
for Size "Auto" setting.
• Document Capture (OS X): Open the Scan menu and select Display the EPSON Scan Setup
Screen. Click the
Scan button. Select Main Settings from the Scan window. Click
Configuration and select the Document tab. Adjust the cropping area shown in the Crop Margins
for Size "Auto" setting.
Parent topic: Solving Scanned Image Quality Problems
Related tasks
Scanning with Document Capture Pro and Document Capture
Scanning with Epson Scan
When to Uninstall Your Scanner Software
If you have a problem that requires you to uninstall and re-install your software, follow the instructions for
your operating system.
Uninstalling Scanner Software - Windows
Uninstalling Scanner Software - OS X
Parent topic: Solving Problems
Uninstalling Scanner Software - Windows
You can uninstall and then re-install your scanner software to solve certain problems.
93
1. Turn off the scanner.
2. Disconnect any interface cables.
3. Do the following to uninstall each of your scanning software programs, then follow any on-screen
instructions:
• Windows 8.x: Navigate to the Apps screen and select Control Panel > Programs > Programs
and Features. Select the scanner software program and click Uninstall/Change.
• Windows 7 or Windows Vista: Open the Windows Control Panel utility. Select Programs and
Features. (In Classic view, select Programs and click Uninstall a program.) Select the scanner
software program and click Uninstall/Change.
• Windows XP: Open the Windows Control Panel utility. Double-click Add or Remove Programs.
Select the scanner software program and click Change/Remove.
4. Restart your computer, then see the Start Here sheet to re-install your software.
Note: If you find that re-installing your scanner software does not solve a problem, contact Epson.
Parent topic: When to Uninstall Your Scanner Software
Uninstalling Scanner Software - OS X
In most cases, you do not need to uninstall your scanner software before re-installing it. However, you
can download the Uninstaller utility from the Epson support website to uninstall your scanner software as
described here.
Note: If you find that re-installing your scanner software does not solve a problem, contact Epson.
1. To download the Uninstaller utility, visit the Epson download site (U.S. downloads or Canadian
downloads).
2. Follow the instructions on the screen to install the Uninstaller utility.
3. Quit all applications currently running on your Mac.
4. Double-click the Uninstaller icon.
5. In the Epson Uninstaller screen, select the checkbox for each software program you want to
uninstall.
6. Click Uninstall.
7. Follow the on-screen instructions to uninstall the software.
94
8. To reinstall your scanner software, see the Start Here sheet for instructions.
Parent topic: When to Uninstall Your Scanner Software
Where to Get Help
If you need to contact Epson for technical support services, use the following support options.
Internet Support
Visit Epson's support website at epson.com/support (U.S.) or epson.ca/support (Canada) for solutions to
common problems. You can download drivers and documentation, get FAQs and troubleshooting
advice, or email Epson with your questions.
Speak to a Support Representative
Before you call Epson for support, please have the following information ready:
• Product name
• Product serial number (located on a label on the product)
• Proof of purchase (such as a store receipt) and date of purchase
• Computer configuration
• Description of the problem
Then call:
• U.S.: (562) 276-4382, 6 AM to 8 PM, Pacific Time, Monday through Friday, and 7 AM to 4 PM, Pacific
Time, Saturday
• Canada: (905) 709-3839, 6 AM to 8 PM, Pacific Time, Monday through Friday, and 7 AM to 4 PM,
Pacific Time, Saturday
Days and hours of support are subject to change without notice. Toll or long distance charges may
apply.
Note: For help using any other software on your system, see the documentation for that software for
technical support.
Purchase Supplies and Accessories
You can purchase genuine Epson accessories at epson.com (U.S. sales) or epson.ca (Canadian sales).
You can also purchase accessories from an Epson authorized reseller. To find the nearest one, call 800GO-EPSON (800-463-7766).
95
Parent topic: Solving Problems
96
Technical Specifications
These sections list the technical specifications for your scanner.
Note: Epson offers a recycling program for end of life products. Please go to this site for information on
how to return your products for proper disposal.
Windows System Requirements
Mac System Requirements
General Specifications
Dimension Specifications
Network Interface Specifications
Electrical Specifications
Environmental Specifications
USB Interface Specifications
Safety and Approvals Specifications
Windows System Requirements
Make sure your system meets these requirements before using it with your scanner.
System
Microsoft Windows 8.x, Windows 7, Windows Vista, Windows XP
Home Edition, Windows XP Professional Edition, Windows XP
Professional x64 Edition
Interface
External USB port (Type A)
Display
Color monitor with 800 × 600 resolution or higher and 24-bit color
(Full Color)
Parent topic: Technical Specifications
Mac System Requirements
Make sure your system meets these requirements before using it with your scanner.
System
OS X 10.10.x, 10.9.x, 10.8.x, 10.7.x, 10.6.x, 10.5.8
(Fast user switching on OS X is not supported.)
97
Interface
Macintosh USB
Display
Color monitor with 800 × 600 resolution or higher and millions of
colors
Note: Epson Scan does not support the UNIX File System (UFS) for OS X. Install Epson Scan on a disk
or in a partition that does not use UFS.
Parent topic: Technical Specifications
General Specifications
Scanner type
Sheet feed, one pass duplex color scanner
Photoelectric device
1 line CMOS Contact Image Sensor (CIS)
Effective pixels
5,100 × 21,600 pixels at 600 dpi
Document size
Windows maximum: 8.5 × 36 inches (215.9 × 914.4 mm)
OS X maximum: 8.5 × 16.5 inches (215.9 × 420.1 mm)
Minimum: 2 × 2 inches (50.8 × 50.8 mm)
Paper input
Facedown loading
Paper output
Facedown ejection
Paper capacity
50 sheets of paper at 21 lb (80 g/m2) weight
Scanning resolution
600 dpi (main scan)
600 dpi with Micro Step (sub scan)
Output resolution
50-1200 dpi (in increments of 1 dpi)
Image data
16 bits per pixel per color internal
1 to 8 bits per pixel per color external
Interface
One Hi-Speed USB port
Light source
RGB LED
Parent topic: Technical Specifications
98
Dimension Specifications
Height
11.7 inches (297 mm)
Width
6 inches (152 mm)
Depth
6.1 inches (153 mm)
Weight
Approx. 5.7 lb (2.6 kg)
Note: Dimensions do not include projecting parts.
Parent topic: Technical Specifications
Network Interface Specifications
Wireless LAN standard
IEEE 802.11 b/g/n
Wireless security
WPA-PSK (TKIP/AES); WPA2 compliant
WEP (64/128 bit)
Frequency band
2.4 GHz
Communication mode
Infrastructure mode
Direct connection (access point mode)
Note: Wireless LAN standard complies with either IEEE 802.11 b/g or IEEE 802.11 b/g/n, depending on
purchase location.
Parent topic: Technical Specifications
Electrical Specifications
Scanner
Note: Check the label on the scanner and the AC adapter for voltage information. Power consumption
varies depending on operating conditions or whether an option is installed.
Rated input voltage
DC 24 V
99
Rated input current
1.37 A
Rated input frequency
50 to 60 Hz
Power consumption
USB connection:
Operating: Approx. 18 W
Ready mode: Approx. 7 W
Sleep mode: Approx. 1.6 W
Power off mode: 0.4 W
Power consumption
Wireless connection:
Operating: Approx. 19 W
Ready mode: Approx. 8 W
Sleep mode: Approx. 3 W
Power off mode: 0.4 W
AC Adapter
AC adapter model
A441H
Rated input voltage
AC 100 to 240 V
Rated input current
AC 0.6 to 0.3 A
Rated input frequency
50 to 60 Hz
Rated output voltage
DC 24 V
Rated output current
1.37 A
Parent topic: Technical Specifications
Environmental Specifications
Temperature
Operating: 41 to 95 °F (5 to 35 °C)
Storage: –13 to 140 °F (–25 to 60 °C)
Humidity
Operating: 10 to 80% RH
(non-condensing)
Storage: 10 to 85% RH
100
Operating conditions
Ordinary office or home conditions
Note: Avoid operating the scanner in direct sunlight, near a strong light source, or in extremely dusty
conditions.
Parent topic: Technical Specifications
USB Interface Specifications
Interface type
Universal Serial Bus Specification Revision 2.0
Electrical standard
Full Speed mode (12 Mbits per second) and Hi-Speed mode (480
Mbits per second) of Universal Serial Bus Specification Revision 2.0
Connector type
One Type B port
Parent topic: Technical Specifications
Safety and Approvals Specifications
Scanner
United States
EMC: FCC part 15 Subpart B Class B
Canada
EMC: CAN/CSA-CEI/IEC CISPR 22 Class B
AC Adapter
United States
Safety: UL60950-1
EMC: FCC part 15 Subpart B Class B
Canada
Safety: CAN/CSA C22.2 No. 60950-1
EMC: CAN/CSA-CEI/IEC CISPR 22 Class B
Parent topic: Technical Specifications
101
Notices
Check these sections for important notices about your scanner.
Note: Epson offers a recycling program for end of life products. Please go to this site for information on
how to return your products for proper disposal.
Important Safety Instructions
Restrictions on Copying
Default Delay Times for Power Management for Epson Products
Trademarks
Copyright Notice
Important Safety Instructions
Follow these safety instructions when setting up and using the scanner:
• Read all these instructions, and follow all warnings and instructions marked on the scanner.
• Place the scanner close enough to the computer for the interface cable to reach it easily.
• Do not use with wet hands.
• When connecting this product to a computer or other device with a cable, ensure the correct
orientation of the connectors. Each connector has only one correct orientation. Inserting a connector
in the wrong orientation may damage both devices connected by the cable.
• Do not insert objects into any opening as they may touch dangerous voltage points or short out parts.
Beware of electrical shock hazards.
• Place the product on a flat, stable surface that extends beyond the base of the product in all directions.
If you place the product by the wall, leave at least 3.9 inches (10 cm) between the back of the product
and the wall. The product will not operate properly if it is tilted at an angle.
• After replacing consumable parts, dispose of them correctly following the rules of your local authority.
Do not disassemble them.
• Do not place or store the scanner outdoors, in a car, near excessive dirt or dust, water, heat sources,
or in locations subject to shocks, vibrations, condensation, high temperature or humidity, direct
sunlight, strong light sources, or rapid changes in temperature or humidity.
• Never disassemble, modify, or attempt to repair the scanner or a scanner option by yourself except as
specifically explained in this guide.
102
Caution: Radio waves from this product may adversely affect the operation of medical equipment,
airplanes, or automatically controlled devices, such as pacemakers, automatic doors, or fire alarms.
When using this product near such devices or inside a medical facility, follow the directions from
authorized staff members at the facility, and follow all posted warnings and directions on the device to
avoid causing an accident.
AC Adapter
• Do not place or store the AC adapter outdoors, in a car, near excessive dirt or dust, water, heat
sources, or in locations subject to shocks, vibrations, condensation, high temperature or humidity,
direct sunlight, strong light sources, or rapid changes in temperature or humidity.
• Place the scanner and the AC adapter near an electrical outlet where the adapter can be easily
unplugged.
• The AC power cord should be placed to avoid abrasions, cuts, fraying, crimping, and kinking.
• Do not place objects on top of the AC power cord and do not allow the AC adapter or the power cord
to be stepped on or run over. Be particularly careful to keep the AC power cord straight at the end and
the point where it enters the AC adapter.
• Use only the AC adapter that comes with your scanner. Using any other adapter could cause fire,
electrical shock, or injury.
• The AC adapter is designed for use with the scanner with which it was included. Do not attempt to use
it with other electronic devices unless specified.
• Use only the type of power source indicated on the AC adapter's label, and always supply power
directly from a standard domestic electrical outlet with the AC adapter that meets the relevant local
safety standards.
• Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on
and off.
• If you use an extension cord with the scanner, make sure the total ampere rating of the devices
plugged into the extension cord does not exceed the cord's ampere rating. Also, make sure the total
ampere rating of all devices plugged into the wall outlet does not exceed the wall outlet's ampere
rating.
• Never disassemble, modify, or attempt to repair the AC adapter, scanner, or scanner option by
yourself except as specifically explained in the scanner's guides.
• If damage occurs to the plug, replace the cord set or consult a qualified electrician. If there are fuses in
the plug, make sure you replace them with fuses of the correct size and rating.
• Unplug the scanner and the AC adapter, and refer servicing to qualified service personnel under the
following conditions: The AC adapter or plug is damaged; liquid has entered the scanner or the AC
103
adapter; the scanner or the AC adapter has been dropped or the case has been damaged; the
scanner or the AC adapter does not operate normally or exhibits a distinct change in performance. (Do
not adjust controls that are not covered by the operating instructions.)
• Unplug the scanner and the AC adapter before cleaning. Clean with a damp cloth only. Do not use
liquid or aerosol cleaners.
• If you are not going to use the scanner for a long period, be sure to unplug the AC adapter from the
electrical outlet.
Parent topic: Notices
Restrictions on Copying
Observe the following restrictions to ensure responsible and legal use of your scanner.
Copying of the following items is prohibited by law:
• Bank bills, coins, government-issued marketable securities, government bond securities, and
municipal securities
• Unused postage stamps, pre-stamped postcards, and other official postal items bearing valid postage
• Government-issued revenue stamps, and securities issued according to legal procedure
Exercise caution when copying the following items:
• Private marketable securities (stock certificates, negotiable notes, checks, etc.), monthly passes,
concession tickets, etc.
• Passports, driver's licenses, warrants of fitness, road passes, food stamps, tickets, etc.
Note: Copying these items may also be prohibited by law.
Restriction on disassembling and decompiling
You may not disassemble, decompile or otherwise attempt to derive the source code of any software
included with this product.
Parent topic: Notices
Default Delay Times for Power Management for Epson Products
This product will enter sleep mode after a period of nonuse. This is to ensure that the product meets
Energy Star standards of energy efficiency. More energy savings can be achieved by setting the time to
sleep to a shorter interval.
Parent topic: Notices
104
Trademarks
EPSON® is a registered trademark and EPSON Exceed Your Vision is a registered logomark of Seiko
Epson Corporation.
Mac and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.
Android and Google Drive are trademarks of Google, Inc.
App Store is a service mark of Apple Inc.
General Notice: Other product names used herein are for identification purposes only and may be
trademarks of their respective owners. Epson disclaims any and all rights in those marks.
Parent topic: Notices
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Seiko Epson Corporation. The information contained herein is
designed only for use with this Epson product. Epson is not responsible for any use of this information as
applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third
parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of:
accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this
product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation's operating and
maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any
options or any consumable products other than those designated as Original Epson Products or Epson
Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic
interference that occurs from the use of any interface cables other than those designated as Epson
approved Products by Seiko Epson Corporation.
This information is subject to change without notice.
Open Source Software License
105
Info-ZIP Copyright and License
libTIFF Software Acknowledgment
libjpeg-turbo
A Note Concerning Responsible Use of Copyrighted Materials
Copyright Attribution
Parent topic: Notices
Open Source Software License
1) This product includes open source software programs listed in Section 6) according to the license
terms of each open source software program.
2) We provide the source code of the GPL Programs, LGPL Programs and Apache License Program
(each is defined in Section 6) until five (5) years after the discontinuation of same model of this product.
If you desire to receive the source code above, contact Epson as described in the User's Guide. You
shall comply with the license terms of each open source software program.
3) The open source software programs are WITHOUT ANY WARRANTY; without even the implied
warranty of MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. See the license
agreements of each open source software program for more details, which are described in OSS.pdf on
your scanner software CD.
4) OpenSSL toolkit
This product includes software developed by the OpenSSL project for use in the OpenSSL Toolkit
(http://www.openssl.org/).
This product includes cryptographic software written by Eric Young ([email protected]).
5) The license terms of each open source software program are described in OSS.pdf on your scanner
software CD.
6) The list of open source software programs which this product includes are as follows.
GNU GPL
This product includes the open source software programs which apply the GNU General Public License
Version 2 or later version ("GPL Programs").
The list of GPL Programs:
base-passwd-3.5.7
busybox-1.2.2.1
ifupdown-0.6.8
106
kernel-2.6.18
lsp-arm-versatile926ejs-2.6.18_pro500
module-init-tools-3.2pre1
mount-2.12
net-tools-1.60
netbase-4.29
psmisc-21.5
readline-libs-5.0
sysvinit-2.86
udev-0.093
udhcp 0.9.8cvs20050124-5
util-linux-2.12
usb8786
GNU LGPL
This product includes the open source software programs which apply the GNU Lesser General Public
License Version 2 or later version ("LGPL Programs").
The list of LGPL Programs:
uclibc-0.9.29
libusb-libs-0.1.12
zeroconf 0.6.1-1
iksemel 1.4
Apache License
This product includes the open source software program "Bonjour" which apply the Apache License
Version2.0 ("Apache License Program").
Bonjour License
This product includes the open source software program "Bonjour" which applies the terms and
conditions provided by owner of the copyright to the "Bonjour".
Net-SNMP license
107
This product includes the open source software program "Net-SNMP" which applies the terms and
conditions provided by owner of the copyright to the "Net-SNMP".
OpenSSL License/Original SSLeay License
This product includes the open source software program "OpenSSL toolkit" which applies the license
terms of OpenSSL License and Original SSLeay License.
BSD License (Berkeley Software Distribution License)
This product includes the open source software programs which apply the Berkeley Software
Distribution License ("BSD Programs").
The list of BSD Programs:
busybox-1.2.2.1
util-linux-2.12
mount-2.12
mvlutils-2.8.4
netkit-ftp-0.17
netkit-base-0.17
portmap-5beta
Sun RPC License
This product includes the open source software programs which apply the Sun RPC License ("Sun RPC
Programs").
The list of Sun RPC Programs:
busybox- 1 .2.2.1
netkit-inetd-0.17
portmap-5beta
TCP Wrappers license
This product includes the open source software program "libwrap-libs-7.6" which applies the terms and
conditions provided by owner of the copyright to the "TCP Wrappers".
libncurses license
This product includes the open source software program "libncurses-5.4" which applies the terms and
conditions provided by owner of the copyright to the "libncurses".
busybox license
108
This product includes the open source software program "busybox- 1.2.2.1" which applies the terms and
conditions provided by owner of the copyright to the "busybox".
linux-ftpd license
This product includes the open source software program "linux-ftpd-0.17" which applies the terms and
conditions provided by owner of the copyright to the "linux-ftpd".
SHA1license
This product includes the open source software program "SHA1" which applies the terms and conditions
provided by owner of the copyright to the "SHA1".
ARC4 license
This product includes the open source software program "ARC4" which applies the terms and conditions
provided by owner of the copyright to the "ARC4".
json_parserlicense
This product includes the open source software program "json_parser" which applies the terms and
conditions provided by owner of the copyright to the "json_parser".
MD5license
This product includes the open source software program "MD5" which applies the terms and conditions
provided by owner of the copyright to the "MD5".
AESlicense
This product includes the open source software program "AES" which applies the terms and conditions
provided by owner of the copyright to the "AES".
Parent topic: Copyright Notice
Info-ZIP Copyright and License
This is version 2007-Mar-4 of the Info-ZIP license. The definitive version of this document should be
available at ftp://ftp.info-zip.org/pub/infozip/license.html indefinitely and a copy at http://www.infozip.org/pub/infozip/license.html.
Copyright (c) 1990-2007 Info-ZIP. All rights reserved.
For the purposes of this copyright and license, "Info-ZIP" is defined as the following set of individuals:
Mark Adler, John Bush, Karl Davis, Harald Denker, Jean-Michel Dubois, Jean-loup Gailly, Hunter
Goatley, Ed Gordon, Ian Gorman, Chris Herborth, Dirk Haase, Greg Hartwig, Robert Heath, Jonathan
Hudson, Paul Kienitz, David Kirschbaum, Johnny Lee, Onno van der Linden, Igor Mandrichenko, Steve
P. Miller, Sergio Monesi, Keith Owens, George Petrov, Greg Roelofs, Kai Uwe Rommel, Steve
109
Salisbury, Dave Smith, Steven M. Schweda, Christian Spieler, Cosmin Truta, Antoine Verheijen, Paul
von Behren, Rich Wales, Mike White.
This software is provided "as is," without warranty of any kind, express or implied. In no event shall InfoZIP or its contributors be held liable for any direct, indirect, incidental, special or consequential damages
arising out of the use of or inability to use this software.
Permission is granted to anyone to use this software for any purpose, including commercial applications,
and to alter it and redistribute it freely, subject to the above disclaimer and the following restrictions:
1. Redistributions of source code (in whole or in part) must retain the above copyright notice, definition,
disclaimer, and this list of conditions.
2. Redistributions in binary form (compiled executables and libraries) must reproduce the above
copyright notice, definition, disclaimer, and this list of conditions in documentation and/or other materials
provided with the distribution. The sole exception to this condition is redistribution of a standard
UnZipSFX binary (including SFXWiz) as part of a self-extracting archive; that is permitted without
inclusion of this license, as long as the normal SFX banner has not been removed from the binary or
disabled.
3. Altered versions--including, but not limited to, ports to new operating systems, existing ports with new
graphical interfaces, versions with modified or added functionality, and dynamic, shared, or static library
versions not from Info-ZIP--must be plainly marked as such and must not be misrepresented as being
the original source or, if binaries, compiled from the original source. Such altered versions also must not
be misrepresented as being Info-ZIP releases--including, but not limited to, labeling of the altered
versions with the names "Info-ZIP" (or any variation thereof, including, but not limited to, different
capitalizations), "Pocket UnZip," "WiZ" or "MacZip" without the explicit permission of Info-ZIP. Such
altered versions are further prohibited from misrepresentative use of the Zip-Bugs or Info-ZIP e-mail
addresses or the Info-ZIP URL(s), such as to imply Info-ZIP will provide support for the altered versions.
4. Info-ZIP retains the right to use the names "Info-ZIP," "Zip," "UnZip," "UnZipSFX," "WiZ," "Pocket
UnZip," "Pocket Zip," and "MacZip" for its own source and binary releases.
Parent topic: Copyright Notice
libTIFF Software Acknowledgment
Copyright © 1988-1997 Sam Leffler
Copyright © 1991-1997 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this software and its documentation for any purpose
is hereby granted without fee, provided that (I) the above copyright notices and this permission notice
appear in all copies of the software and related documentation, and (ii) the names of Sam Leffler and
Silicon Graphics may not be used in any advertising or publicity relating to the software without the
specific, prior written permission of Sam Leffler and Silicon Graphics.
110
THE SOFTWARE IS PROVIDED "AS-IS" AND WITHOUT WARRANTY OF ANY KIND, EXPRESS,
IMPLIED OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER OR NOT
ADVISED OF THE POSSIBILITY OF DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING OUT
OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
Parent topic: Copyright Notice
libjpeg-turbo
Copyright (C) 1991-2012 Thomas G. Lane, Guido Vollbeding
Copyright (C) 1999-2006 MIYASAKA Masaru
Copyright (C) 2009 Pierre Ossman for Cendio AB
Copyright (C) 2009-2013 D. R. Commander
Copyright (C) 2009-2011 Nokia Corporation and/or its subsidiary(-ies)
Redistribution and use in source and binary forms, with or without modification, are permitted provided
that the following conditions are met:
• Redistributions of source code must retain the above copyright notice, this list of conditions and the
following disclaimer.
• Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other materials provided with the distribution.
• Neither the name of the libjpeg-turbo Project nor the names of its contributors may be used to endorse
or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS",
AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR CONTRIBUTORS BE LIABLE
FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR
TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF
THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Parent topic: Copyright Notice
111
A Note Concerning Responsible Use of Copyrighted Materials
Epson encourages each user to be responsible and respectful of the copyright laws when using any
Epson product. While some countries' laws permit limited copying or reuse of copyrighted material in
certain circumstances, those circumstances may not be as broad as some people assume. Contact your
legal advisor for any questions regarding copyright law.
Parent topic: Copyright Notice
Copyright Attribution
© 2015 Epson America, Inc.
1/15
CPD-40192R1
Parent topic: Copyright Notice
112

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
