Constant-Frequency, Current-Mode Step-Up DC-to-DC Controller ADP1621 Data Sheet

Constant-Frequency, Current-Mode Step-Up DC-to-DC Controller ADP1621 Data Sheet

Data Sheet

FEATURES

92% efficiency (no sense resistor required)

±1.0% initial accuracy

IC supply voltage range: 2.9 V to 5.5 V

Power-input voltage as low as 1.0 V

Capable of high supply input voltage (>5.5 V) with an external NPN or a resistor

V

IN

UVLO and 35 mA shunt regulator

External slope compensation with 1 resistor

Programmable operating frequency

(100 kHz to 1.5 MHz) with 1 resistor

Lossless current sensing for switch-node voltage <30 V

Resistor current sensing for switch-node voltage >30 V

Synchronizable to external clock

Current-mode operation for excellent line and load transient responses

10 μA shutdown current

Current limit and thermal overload protection

Soft start in 2048 clock cycles

Supported by ADIsimPower ™ design tool

APPLICATIONS

APD bias

Portable electronic equipment

Isolated dc-to-dc converter

Step-up/step-down dc-to-dc converter

LED driver for laptop computer and navigation system

LCD backlighting

GENERAL DESCRIPTION

The ADP1621 is a fixed-frequency, pulse-width modulation

(PWM), current-mode, step-up converter controller. It drives an external n-channel MOSFET to convert the input voltage to a higher output voltage. The ADP1621 can also be used to drive flyback, SEPIC, and forward converter topologies, either isolated or nonisolated.

The ADP1621 eliminates the use of a current-sense power resistor by measuring the voltage drop across the on resistance of the n-channel MOSFET. This technique, allowed up to a maximum voltage of 30 V at the switch node, maximizes efficiency and reduces cost. For switch-node voltages higher than

30 V or for more accurate current limiting, the CS pin can be connected to a current-sense resistor in the source of the MOSFET.

The slope compensation is implemented by an external resistor, allowing a wide range of external components (inductors and

MOSFETs), and can be chosen for various switching frequencies and input and output voltages.

Constant-Frequency, Current-Mode

Step-Up DC-to-DC Controller

ADP1621

TYPICAL APPLICATION CIRCUIT

V

IN

= 3.3V

L1

4.7µH

D1

C3

1µF

10V

C2

120pF

C4

0.1µF

10V

PIN IN

CS

ADP1621

SDSN

GATE

COMP

PGND

R

COMP

9.09kΩ

C

COMP

1.8nF

FREQ

GND

FB

R

FREQ

31.6kΩ

1%

R

S

80Ω

R1

35.7kΩ

1%

M1

R2

11.5kΩ

1%

C1

47µF

6.3V

C

OUT1

1µF

10V

C

OUT2

10µF

10V

C

OUT3

150µF

6.3V

×2

AGND f

OSC

= 600kHz

C1 = MURATA GRM31CR60J476M

C

OUT3

= SANYO POSCAP 6TPE150M

L1 = TOKO FDV0630-4R7M

M1 = VISHAY Si7882DP

D1 = VISHAY SSA33L

Figure 1. High Efficiency Output Boost Converter in Lossless Mode,

3.3 V Input, 5 V Output (Bootstrapped)

The ADP1621 supply input voltage range is 2.9 V to 5.5 V, although higher input voltages are possible with the use of a small signal NPN pass transistor or a single resistor. The voltage of the power input can be as low as 1 V for fuel cell applications.

The switching frequency is set by an external resistor over a range of 100 kHz to 1.5 MHz and can be synchronized to an external clock by using the SDSN pin. The shutdown quiescent current is less than 10 μA. The ADP1621 has a thermal shutdown feature that shuts down the gate driver when the junction temperature reaches approximately 150°C. The internal soft start circuit limits inrush current at startup. The ADP1621 is available in the 10-lead

MSOP lead-free package and is specified over the −40°C to +125°C junction temperature range.

100

90

80

70

60

50

40

30

0.01

0.1

1

LOAD CURRENT (A)

Figure 2. Efficiency of Circuit Shown in Figure 1

10

V

OUT

= 5V

1A

Rev. D Document Feedback

Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.

Trademarks and registered trademarks are the property of their respective owners.

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.

Tel: 781.329.4700 ©2006–2016 Analog Devices, Inc. All rights reserved.

Technical Support www.analog.com

ADP1621

TABLE OF CONTENTS

Features .............................................................................................. 1

Applications ....................................................................................... 1

General Description ......................................................................... 1

Typical Application Circuit ............................................................. 1

Revision History ............................................................................... 2

Simplified Block Diagram ............................................................... 3

Specifications ..................................................................................... 4

Absolute Maximum Ratings ............................................................ 6

Thermal Resistance ...................................................................... 6

ESD Caution .................................................................................. 6

Pin Configuration and Function Descriptions ............................. 7

Typical Performance Characteristics ............................................. 8

Theory of Operation ...................................................................... 12

Control Loop ............................................................................... 12

Current-Sense Configurations .................................................. 12

Current Limit .............................................................................. 13

Undervoltage Lockout ............................................................... 13

Shutdown ..................................................................................... 13

Soft Start ...................................................................................... 13

Internal Shunt Regulators .......................................................... 13

Setting the Oscillator Frequency and Synchronization

Frequency .................................................................................... 13

Application Information: Boost Converter ................................. 14

ADIsimPower Design Tool ....................................................... 14

REVISION HISTORY

2/16— Rev. C to Rev. D

Changes to Figure 39 and Figure 40 ............................................. 27

10/15—Rev. B to Rev. C

Moved Figure 3 ................................................................................. 3

Changes to Shunt Regulation Voltage Parameter, Table 1 .......... 4

6/12—Rev. A to Rev. B

Change to Features Section ............................................................. 1

Added ADIsimPower Design Tool Section ................................. 14

Change to Table 6 ........................................................................... 30

Updated Outline Dimensions ....................................................... 31

Changes to Ordering Guide .......................................................... 31

Data Sheet

Duty Cycle ................................................................................... 14

Setting the Output Voltage ........................................................ 14

Inductor Current Ripple ............................................................ 14

Inductor Selection ...................................................................... 14

Input Capacitor Selection .......................................................... 15

Output Capacitor Selection ....................................................... 15

Diode Selection ........................................................................... 16

MOSFET Selection ..................................................................... 16

Loop Compensation .................................................................. 17

Slope Compensation .................................................................. 18

Current Limit .............................................................................. 18

Light Load Operation ................................................................ 19

Recommended Component Manufacturers ........................... 19

Layout Considerations ................................................................... 20

Efficiency Considerations ............................................................. 21

Examples of Application Circuits ................................................. 22

Standard Boost Converter—Design Example ........................ 22

Bootstrapped Boost Converter ................................................. 23

SEPIC Converter Circuit ........................................................... 27

Low Voltage Power-Input Circuit ............................................ 27

LED Driver Application Circuits ............................................. 28

Related Devices ............................................................................... 30

Outline Dimensions ....................................................................... 31

Ordering Guide .......................................................................... 31

12/06—Rev. 0 to Rev. A

Changes to Table 1 ............................................................................. 3

Changes to Table 2 ............................................................................. 5

Added Table 3 .................................................................................... 5

Changes to Table 5 .......................................................................... 19

Changes to Ordering Guide .......................................................... 31

7/06—Revision 0: Initial Version

Rev. D | Page 2 of 32
