16-Bit, 8-Channel Simultaneous Sampling Data Acquisition System ADAS3023 Data Sheet

16-Bit, 8-Channel Simultaneous Sampling Data Acquisition System ADAS3023 Data Sheet

Data Sheet

FEATURES

Ease-of-use, 16-bit complete data acquisition system

Simultaneous sampling selection of 2, 4, 6, and 8 channels

Differential input voltage range: ±20.48 V maximum

High impedance 8-channel input: >500 MΩ

High input common-mode rejection: 95.0 dB

User-programmable input ranges

On-chip 4.096 V reference and buffer

No latency/pipeline delay (SAR architecture)

Serial 4-wire 1.8 V to 5 V SPI-/SPORT-compatible interface

40-lead LFCSP package (6 mm × 6 mm)

−40°C to +85°C industrial temperature range

APPLICATIONS

Multichannel data acquisition and system monitoring

Process control

Power line monitoring

Automated test equipment

Patient monitoring

Spectrum analysis

Instrumentation

GENERAL DESCRIPTION

The ADAS3023 is a complete 16-bit successive approximationbased analog-to-digital data acquisition system. This device is capable of simultaneously sampling up to 500 kSPS for two channels, 250 kSPS for four channels, 167 kSPS for six channels, and 125 kSPS for eight channels manufactured on the Analog

Devices, Inc., proprietary iCMOS® high voltage industrial process technology.

The ADAS3023 integrates eight channels of low leakage track and hold, a programmable gain instrumentation amplifier

(PGIA) stage with a high common-mode rejection offering four differential input ranges, a precision low drift 4.096 V reference and buffer, and a 16-bit charge redistribution successive approximation register (SAR) analog-to-digital converter (ADC). The

ADAS3023 can resolve differential input ranges of up to ±20.48 V when using ±15 V supplies.

16-Bit, 8-Channel Simultaneous

Sampling Data Acquisition System

ADAS3023

DIFF TO

COM

IN0

IN1

IN2

IN3

IN4

IN5

IN6

IN7

COM

FUNCTIONAL BLOCK DIAGRAM

VDDH AVDD DVDD VIO RESET PD

TRACK

AND

HOLD

PGIA

ADAS3023

VSSH AGND DGND REFx

Figure 1.

LOGIC/

INTERFACE

BUF

PulSAR

ADC

REF

Table 1. Typical Input Range Selection

Single-Ended Signals 1

Input Range, V

IN

0 V to 1 V

0 V to 2.5 V

0 V to 5 V

0 V to 10 V

±1.28 V

±2.56 V

±5.12 V

±10.24 V

1

See Figure 39 and Figure 40 in the Analog Inputs section for more

information.

CNV

BUSY

CS

SCK

DIN

SDO

REFIN

The ADAS3023 simplifies design challenges by eliminating signal buffering, level shifting, amplification and attenuation, common-mode rejection, settling time, or any of the other analog signal conditioning challenges, yet allows for smaller form factor, faster time to market, and lower costs.

The ADAS3023 is factory calibrated and its operation is specified from −40°C to +85°C.

Rev. A

Document Feedback

Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.

Trademarks and registered trademarks are the property of their respective owners.

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.

Tel: 781.329.4700 ©2013–2014 Analog Devices, Inc. All rights reserved.

Technical Support www.analog.com

ADAS3023

TABLE OF CONTENTS

Features .............................................................................................. 1



Applications ....................................................................................... 1



Functional Block Diagram .............................................................. 1



General Description ......................................................................... 1



Revision History ............................................................................... 2



Specifications ..................................................................................... 3



Timing Specifications .................................................................. 6



Absolute Maximum Ratings ............................................................ 9



ESD Caution .................................................................................. 9



Pin Configuration and Function Descriptions ........................... 10



Typical Performance Characteristics ........................................... 12



Terminology .................................................................................... 17



Theory of Operation ...................................................................... 19



Overview ...................................................................................... 19



Operation ..................................................................................... 19



Transfer Functions...................................................................... 20



REVISION HISTORY

2/14—Rev. 0 to Rev. A

Changes to Table 2 ............................................................................ 5

Changes to Figure 38 ...................................................................... 21

5/13—Revision 0: Initial Version

Data Sheet

Typical Application Connection Diagram .............................. 21



Analog Inputs ............................................................................. 21



Voltage Reference Input/Output .............................................. 22



Power Supply ............................................................................... 24



Power Dissipation Modes .......................................................... 24



Conversion Modes ..................................................................... 25



Digital Interface .............................................................................. 26



Conversion Control ................................................................... 26



RESET and Power-Down (PD) Inputs .................................... 26



Serial Data Interface ................................................................... 27



General Timing .......................................................................... 28



Configuration Register .............................................................. 29



Packaging and Ordering Information ......................................... 30



Outline Dimensions ................................................................... 30



Ordering Guide .......................................................................... 30



Rev. A | Page 2 of 32

Data Sheet ADAS3023

SPECIFICATIONS

VDDH = 15 V ± 5%, VSSH = −15 V ± 5%, AVDD = DVDD = 5 V ± 5%; VIO = 1.8 V to AVDD, Internal Reference V

REF

= 4.096 V, f

S

=

500 kSPS, all specifications T

MIN

to T

MAX

, unless otherwise noted.

Table 2.

Parameter

RESOLUTION

ANALOG INPUT (IN0 to IN7, COM)

Input Impedance

Operating Input Voltage Range 2

Differential Input Voltage Ranges, V

IN

THROUGHPUT

Conversion Rate

Transient Response 3

DC ACCURACY

No Missing Codes

Integral Linearity Error

Differential Linearity Error

Transition Noise

Gain Error 4

Gain Error Match, Delta Mean

Gain Error Temperature Drift

Offset Error

4

Offset Error Match, Delta Mean

Offset Error Temperature Drift

AC ACCURACY 5

Signal-to-Noise Ratio

Signal-to-Noise + Distortion (SINAD)

Test Conditions/Comments

Z

V

V

IN

IN

INX

, on any single pin

− COM

PGIA gain = 0.2, V

IN

PGIA gain = 0.4, V

IN

= 40.96 V p-p

= 20.48 V p-p

PGIA gain = 0.8, V

IN

= 10.24 V p-p

PGIA gain = 1.6, V

IN

= 5.12 V p-p

Two channels

Four channels

Six channels

Eight channels

Full-scale step

PGIA gain = 0.2, 0.4, or 0.8, COM = 0 V

PGIA gain = 1.6, COM = 0 V

All PGIA gains, COM = 0 V

PGIA gain = 0.2 or 0.4

PGIA gain = 0.8

PGIA gain = 1.6

External reference, all PGIA gains

External reference, all PGIA gains

External reference, PGIA gain = 0.2, 0.4, or 0.8

External reference, PGIA gain = 1.6

External reference, PGIA gain = 0.2

External reference, PGIA gain = 0.4

External reference, PGIA gain = 0.8

External reference, PGIA gain = 1.6

External reference, PGIA gain = 0.2, 0.4, 0.8, or 1.6 −15

External reference, PGIA gain = 0.2 or 0.4, IN0 to IN7 0

External reference, PGIA gain = 0.8, IN0 to IN7

External reference, PGIA gain = 1.6, IN0 to IN7

0

0

Internal reference

−0.05

−65

−85

−10

0

0

0

0

0

16

−2.5

−3

−0.95

−0.075

Min

16

500

VSSH + 2.5

−5V

REF

−2.5V

REF

−1.25V

REF

−0.625V

REF

Typ Max

Unit

Bits

VDDH − 2.5 V

+5V

REF

+2.5V

REF

V

V

+1.25V

REF

V

+0.625V

REF

V

1

±1

±1

−35

−45

0

130

±1

0.5

1.5

2.5

500

250

167

125

820

+2.5

+3

±0.5 +1.25

6

7

10

+0.075

+0.05

1

2

+12

+12

+10

250

+15

2

3

5

%FS ppm/°C ppm/°C

LSB

LSB

LSB

LSB

LSB ppm/°C ppm/°C ppm/°C

LSB

LSB

LSB

LSB

LSB

%FS kSPS kSPS kSPS kSPS ns

Bits f

IN

= 1 kHz, COM = 0 V

PGIA gain = 0.2

PGIA gain = 0.4

PGIA gain = 0.8

PGIA gain = 1.6 f

IN

= 1 kHz, two, four, six, and eight channels

PGIA gain = 0.2

PGIA gain = 0.4

PGIA gain = 0.8

PGIA gain = 1.6

90.0

89.5

87.5

85.0

89.5

89.0

87.0

84.0

91.5

91.0

89.0

86.5

91.0

90.5

88.5

86.0 dB dB dB dB dB dB dB dB

Rev. A | Page 3 of 32

ADAS3023

Parameter

Dynamic Range

Total Harmonic Distortion

Spurious-Free Dynamic Range

Channel-to-Channel Crosstalk

DC Common-Mode Rejection Ratio

(CMRR)

−3 dB Input Bandwidth

INTERNAL REFERENCE

REFx Pins

Output Voltage

Output Current

Temperature Drift

Line Regulation

Internal Reference

Buffer Only

REFIN Output Voltage 6

Turn-On Settling Time

EXTERNAL REFERENCE

Voltage Range

Current Drain

DIGITAL INPUTS

Logic Levels

V

IL

V

IH

V

IL

V

IH

I

IL

I

IH

DIGITAL OUTPUTS 7

Data Format

V

OL

V

OH

POWER SUPPLIES

VIO

AVDD

DVDD

VDDH

VSSH

Test Conditions/Comments

f

IN

= 1 kHz, −60 dB input

PGIA gain = 0.2

PGIA gain = 0.4

PGIA gain = 0.8

PGIA gain = 1.6 f

IN

= 1 kHz, all PGIA gains f

IN

= 1 kHz, all PGIA gains f

IN

= 1 kHz, all channels inactive

All channels

PGIA gain = 0.2

PGIA gain = 0.4

PGIA gain = 0.8

PGIA gain = 1.6

−40 dBFS

T

A

= 25°C

T

A

= 25°C

REFEN bit = 1

REFEN bit = 0, REFIN pin = 2.5V

AVDD = 5 V ± 5%

AVDD = 5 V ± 5%

T

A

= 25°C

C

REFIN

, C

REF1

, C

REF2

= 10 µF||0.1 µF

REFEN bit = 0

REFx input, REFIN = 0 V

REFIN input (buffered) f

S

= 500 kSPS

VIO > 3 V

VIO > 3 V

VIO ≤ 3 V

VIO ≤ 3 V

I

SINK

= +500 µA

I

SOURCE

= −500 µA

VDDH > input voltage + 2.5 V

VSSH < input voltage − 2.5 V

Rev. A | Page 4 of 32

Data Sheet

Min

91.0

90.5

88.0

86.0

Typ Max

92

91.5

89.5

87.0

−100

105

95

95.0

95.0

95.0

95.0

8 dB dB dB dB

MHz

4.088

2.495

±5

±1

20

4.096 4.104

250

4

2.5

100

2.505

4.000

−0.3

0.7 × VIO

−0.3

0.9 × VIO

−1

−1

4.096 4.104

2.5

100

2.505

+0.3 × VIO

VIO + 0.3

+0.1 × VIO

VIO + 0.3

+1

+1

VIO − 0.3

Twos complement

0.4

V

V

V

V

µA

µA

V

V

µA

V

V

1.8

4.75

4.75

14.25

−15.75

5

AVDD + 0.3 V

5.25 V

5

15

5.25

15.75

−15 −14.25

V

V

V

V

µA ppm/°C ppm/°C

μV/V ppm

V ms dB dB dB dB dB

Unit 1

dB dB

Data Sheet ADAS3023

Parameter

I

VDDH

I

VSSH

I

AVDD

I

DVDD

I

VIO

Power Supply Sensitivity

Test Conditions/Comments

Two channels

Four channels

Six channels

Min

Eight channels

PD = 1

Two channels

Four channels

−5.5

−6.5

Six channels

Eight channels

All PGIA gains, PD = 1

All PGIA gains, PD = 0, reference buffer enabled

−10.0

−10.0

All PGIA gains, PD = 0, reference buffer disabled

All PGIA gains, PD = 1

All PGIA gains, PD = 0

All PGIA gains, PD = 1

All PGIA gains, PD = 0, VIO = 3.3 V

All PGIA gains, PD = 1

External reference, T

A

= 25°C

PGIA gain = 0.2 or 0.4, VDDH/VSSH = ±15 V ± 5%

PGIA gain = 0.8, VDDH/VSSH = ±15 V ± 5%

PGIA gain = 1.6, VDDH/VSSH = ±15 V ± 5%

PGIA gain = 0.2 or 0.4, AVDD, DVDD = ±5 V ± 5%

PGIA gain = 0.8, AVDD, DVDD = ±5 V ± 5%

PGIA gain = 1.6, AVDD, DVDD = ±5 V ± 5%

Typ Max

5.0

6.0

9.5

5.5

7.0

10.5

9.5

10.0

10.5

−5.0

−5.5

−8.5

−8.5

10.0

16.0 17.0

100

15.5

2.5 3

100

1.0

10.0

±0.1

±0.2

±0.4

±1.0

±1.5

±2.5

TEMPERATURE RANGE

Specified Performance T

MIN

to T

MAX

−40 +85 °C

1

The LSB unit means least significant bit. The weight of the LSB, referred to input, changes depending on the input voltage range. See the Programmable Gain section

for the LSB size.

2

Full-scale differential input ranges of ±2.56 V, ±5.12 V, ±10.24 V, and ±20.48 V are set by the configuration register.

3 If using the external multiplexer in front of the ADAS3023 , it must be switched at least 820 ns prior to the rising edge of CNV.

4

See the Terminology section. These parameters are specified at ambient temperature with an external reference. All other influences of temperature and supply are

5 measured and specified separately.

All ac specifications expressed in decibels are referenced to the full-scale input range (FSR) and are tested with an input signal at 0.5 dB below full scale, unless

6 otherwise specified.

This is the output from the internal band gap reference.

7

There is no pipeline delay. Conversion results are available immediately after a conversion is completed.

LSB

LSB

LSB

LSB

LSB

LSB mA

µA mA

µA mA

µA

Unit 1

mA mA mA mA

µA mA mA mA mA

µA mA

Rev. A | Page 5 of 32

ADAS3023 Data Sheet

TIMING SPECIFICATIONS

VDDH = 15 V ± 5%, VSSH = −15 V ± 5%, AVDD = DVDD = 5 V ± 5%, VIO = 1.8 V to AVDD, Internal Reference V

REF

= 4.096 V, f

S

=

500 kSPS, all specifications T

MIN

to T

MAX

, unless otherwise noted.

1

Table 3.

Parameter

TIME BETWEEN CONVERSIONS

Warp 2 Mode, CMS = 0

Two Channels

Four Channels

Six Channels

Eight Channels

Normal Mode (Default), CMS = 1

Two Channels

Four Channels

Six Channels

Eight Channels

CONVERSION TIME: CNV RISING EDGE TO DATA AVAILABLE

Warp Mode, CMS = 0

Two Channels

Four Channels

Six Channels

Eight Channels

Normal Mode (Default), CMS = 1

Two Channels

Four Channels

Six Channels

Eight Channels

CNV

Pulse Width

CNV High to Hold Time (Aperture Delay)

CNV High to BUSY/SDO2 Delay

SCK

Period

Low Time

High Time

SCK Falling Edge to Data Remains Valid

SCK Falling Edge to Data Valid Delay

VIO > 4.5 V

VIO > 3 V

VIO > 2.7 V

VIO > 2.3 V

VIO > 1.8 V

CS/RESET/PD

CS/RESET/PD Low to SDO D15 MSB Valid

VIO > 4.5 V

VIO > 3 V

VIO > 2.7 V

VIO > 2.3 V

VIO > 1.8 V

CS/RESET/PD High to SDO High Impedance

CNV Rising to CS t

EN t

DIS t

CCS t

CNVH t

AD t

CBD

Symbol

t

CYC t

CONV t

SCK t

SCKL t

SCKH t

SDOH t

SDOV

5

10

Min

8.0

2.1

4.1

2.0

4.0

6.0

6.1

8.1

4 t

SDOV

+ 3

5

5

Typ

2

1485 1630

2850 3340

4215 5000

5580 6700

1575 1720

2940 3430

4305 5090

5670 6790

520

Max

1000

1000

1000

1000

1000

1000

1000

1000

24

25

37

12

18

7

8

10

15

20

25 ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns ns

Unit

µs

µs

µs

µs

µs

µs

µs

µs ns ns ns ns ns ns ns ns ns

Rev. A | Page 6 of 32

Data Sheet

Parameter

DIN

DIN Valid Setup Time from SCK Falling Edge

DIN Valid Hold Time from SCK Falling Edge

Symbol

t

DINS t

DINH

RESET/PD HIGH PULSE t

RH

1

2

See Figure 2 and Figure 3 for load conditions.

Exceeding the maximum time has an effect on the accuracy of the conversion (see the Conversion Modes section).

Circuit and Voltage Diagrams

I

OL

500µA

Min

4

4

5

Typ

ADAS3023

Max Unit

ns ns ns

TO SDO

C

L

50pF

1.4V

500µA I

OH

Figure 2. Load Circuit for Digital Interface Timing

70% VIO

30% VIO t

DELAY

2V OR VIO – 0.5V

1

0.8V OR 0.5V

2 t

DELAY

2V OR VIO – 0.5V

1

0.8V OR 0.5V

2

1

2V IF VIO > 2.5V; VIO – 0.5V IF VIO < 2.5V.

2

0.8V IF VIO > 2.5V; 0.5V IF VIO < 2.5V.

Figure 3. Voltage Levels for Timing

Rev. A | Page 7 of 32

ADAS3023

Timing Diagrams

SOC

Data Sheet

SOC SOC

POWER

UP

PHASE

CNV t

CONV

CONVERSION (n)

EOC t

CYC

NOTE 1

ACQUISITION (n + 1)

NOTE 2

CONVERSION (n + 1)

EOC

NOTE 1

ACQUISITION (n + 2) t

CNVH

NOTE 4 t

AD

NOTE 3 CS

SCK

DIN

SDO

NOTE 2

1 16 1

CFG (n + 2)

CH0 CH1

16 1 16 1 16 1

CFG (n + 3)

CH0 CH1

16 1 16

CH7 CH7

BUSY/

SDO2 t

CBD

DATA (n) DATA (n + 1)

NOTES

1. DATA ACCESS CAN ONLY OCCUR AFTER CONVERSION. BOTH CONVERSION RESULT AND THE CFG REGISTER ARE UPDATED AT THE END OF THE CONVERSION (EOC).

2. A TOTAL OF 16 SCK FALLING EDGES ARE REQUIRED FOR CONVERSION RESULT. AN ADDITIONAL 16 EDGES AFTER THE LAST CONVERSION RESULT ON BUSY READS BACK THE CFG ASSOCIATED

WITH CONVERSION.

3. CS CAN BE HELD LOW OR CONNECTED TO CNV. CS IS SHOWN WITH FULL INDEPENDENT CONTROL.

4. FOR OPTIMAL PERFORMANCE, DATA ACCESS SHOULD NOT OCCUR DURING THE SAMPLING INSTANT. A MINIMUM TIME OF AT LEAST THE APERATURE DELAY, t

AD, SHOULD LAPSE PRIOR TO DATA ACCESS.

Figure 4. General Timing Diagram with BUSY/SDO2 Disabled

SOC SOC SOC

EOC t

CYC

EOC t

CONV

POWER

UP

PHASE

CONVERSION (n)

NOTE 1

ACQUISITION (n + 1) CONVERSION (n + 1)

NOTE 1

ACQUISITION (n + 2)

CNV t

CNVH

NOTE 4 t

AD

CS NOTE 3

1 16 1 16 1 16 1 16 1 16 1 16 1 16 1 16

NOTE 2

SCK

DIN

SDO

BUSY/

SDO2

CFG (n + 2)

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

CFG (n + 3)

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

DATA (n)

NOTES

1. DATA ACCESS CAN ONLY OCCUR AFTER CONVERSION. BOTH CONVERSION RESULT AND THE CFG REGISTER ARE UPDATED AT THE END OF THE CONVERSION (EOC).

DATA (n + 1)

2. A TOTAL OF 16 SCK FALLING EDGES ARE REQUIRED FOR CONVERSION RESULT. AN ADDITIONAL 16 EDGES AFTER THE LAST CONVERSION RESULT ON BUSY READS BACK THE CFG ASSOCIATED

WITH CONVERSION.

3. CS CAN BE HELD LOW OR CONNECTED TO CNV. CS IS SHOWN WITH FULL INDEPENDENT CONTROL.

4. FOR OPTIMAL PERFORMANCE, DATA ACCESS SHOULD NOT OCCUR DURING THE SAMPLING INSTANT. A MINIMUM TIME OF AT LEAST THE APERATURE DELAY, t

AD, SHOULD LAPSE PRIOR TO DATA ACCESS.

Figure 5. General Timing Diagram with BUSY/SDO2 Enabled

Rev. A | Page 8 of 32

Data Sheet

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter Rating

Analog Inputs/Outputs

INx, COM to AGND

REFx to AGND

VSSH − 0.3 V to VDDH + 0.3 V

AGND − 0.3 V to AVDD + 0.3 V

REFIN to AGND

REFN to AGND

Ground Voltage Differences

AGND, RGND, DGND

Supply Voltages

VDDH to AGND

VSSH to AGND

AVDD, DVDD, VIO to AGND

ACAP, DCAP, RCAP to AGND

Digital Inputs/Outputs

CNV, DIN, SCK, RESET, PD, CS to DGND

SDO, BUSY/SDO2 to DGND

Internal Power Dissipation

Junction Temperature

Storage Temperature Range

Thermal Impedance

θ

JA

(LFCSP)

θ

JC

(LFCSP)

AGND − 0.3 V to +2.7 V

±0.3 V

±0.3 V

–0.3 V to +16.5 V

+0.3 V to −16.5 V

−0.3 V to +7 V

−0.3 V to +2.7 V

−0.3 V to VIO + 0.3 V

−0.3 V to VIO + 0.3 V

2 W

125°C

−65°C to +125°C

44.1°C/W

0.28°C/W

ADAS3023

Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

ESD CAUTION

Rev. A | Page 9 of 32

ADAS3023

PIN CONFIGURATION AND FUNCTION DESCRIPTIONS

IN0

IN1

IN2

IN3

AGND

IN4

IN5

IN6

IN7

COM

9

10

7

8

5

6

3

4

1

2

PIN 1

INDICATOR

ADAS3023

TOP VIEW

(Not to Scale)

30 AGND

29 AGND

28 AVDD

27 DVDD

26 ACAP

25 DCAP

24 AGND

23 AGND

22 DGND

21 DGND

Data Sheet

NOTES

1. CONNECT THE EXPOSED PAD TO VSSH.

Figure 6. Pin Configuration

Table 5. Pin Function Descriptions

Pin No. Mnemonic

Type 1 Description

1 to 4

6 to 9

5, 14, 23,

24, 29,

30, 40

10

IN0 to IN3

IN4 to IN7

AGND

COM

AI

AI

P

AI

Input Channel 0 to Input Channel 3.

Input Channel 4 to Input Channel 7.

Analog Ground. Connect AGND to the system analog ground plane.

11

12

13

15

16

17

18

19

20

21, 22

25

26

CS

DIN

RESET

PD

SCK

VIO

SDO

DI

DI

DI

DO

BUSY/SDO2 DO

CNV

DGND

DCAP

ACAP

DI

P

DI

P

P

P

IN0 to IN7 Common Channel Input. Input Channel IN0 to Input Channel IN7 are referenced to a common point. The maximum voltage on this pin is ±10.24 V for all PGIA gains.

Chip Select. Active low signal. Enables the digital interface for writing and reading data. Use the CS pin when sharing the serial bus. For a dedicated and simplified ADAS3023 serial interface, tie CS to DGND or CNV.

Data Input. DIN is the serial data input for writing the 16-bit configuration (CFG) word that is clocked into the device on the SCK rising edges. The CFG is an internal register that is updated on the rising edge of the next end of a conversion pulse, which coincides with the falling edge of BUSY/SDO2. The CFG register is written into the device on the first 16 clocks after conversion. To avoid corrupting a conversion due to digital activity on the serial bus, do not write data during a conversion.

Asynchronous Reset. A low-to-high transition resets the ADAS3023 . The current conversion, if active, is aborted and the CFG register is reset to the default state.

Power-Down. A low-to-high transition powers down the ADAS3023 , minimizing the device operating current. Note that PD must be held high until the user is ready to power on the device. After powering on the device, the user must wait 100 ms until the reference is enabled and then wait for the completion of one dummy conversion before the device is ready to convert. Note that the RESET pin remains low for

100 ns after the release of PD. See the Power-Down Mode section for more information.

Serial Clock Input. The DIN and SDO data sent to and from the ADAS3023 are synchronized with SCK.

Digital Interface Supply. Nominally, it is recommended that VIO be at the same voltage as the supply of the host interface: 1.8 V, 2.5 V, 3.3 V, or 5 V.

Serial Data Output. The conversion result is output on this pin and synchronized to the SCK falling edges. The conversion results are presented on this pin in twos complement format.

Busy/Serial Data Output 2. The converter busy signal is always output on the BUSY/SDO2 pin when CS is logic high. If SDO2 is enabled when CS is brought low after the EOC, the SDO outputs the data. The conversion result is output on this pin and synchronized to the SCK falling edges. The conversion results are presented on this pin in twos complement format.

Convert Input. A conversion is initiated on the rising edge of the CNV pin.

Digital Ground. Connect DGND to the system digital ground plane.

Internal 2.5 V Digital Regulator Output. Decouple DCAP, an internally regulated output, using a 10 μF and a 0.1 μF local capacitor.

Internal 2.5 V Analog Regulator Output. This regulator supplies power to the internal ADC core and to all of the supporting analog circuits, except for the internal reference. Decouple this internally regulated output (ACAP) using a 10 μF capacitor and a 0.1 μF local capacitor.

Rev. A | Page 10 of 32

Data Sheet ADAS3023

Pin No. Mnemonic

Type 1 Description

27

28

31

32

33, 34

35

36, 37

38

39

DVDD

AVDD

RCAP

P

P

P

REFIN Internal 2.5 V Band Gap Reference Output, Reference Buffer Input, or Reference Power-Down Input.

REF1 and REF2 must be tied together externally. See the Voltage Reference Input/Output section for

more information.

REF1, REF2 AI/O Reference Input/Output. Regardless of the reference method, REF1 and REF2 need individual decoupling using external 10 μF ceramic capacitors connected as close to REF1, REF2, and REFN as

possible. See the Voltage Reference Input/Output section for more information.

RGND

REFN

P

P

Digital 5 V Supply. Decouple the DVDD supply to DGND using a 10 μF capacitor and 0.1 μF local capacitor.

Analog 5 V Supply. Decouple the AVDD supply to AGND using a 10 μF capacitor and 0.1 μF local capacitor.

Internal 2.5 V Analog Regulator Output. RCAP supplies power to the internal reference. Decouple this internally regulated output (RCAP) using a 10 μF capacitor and a 0.1 μF local capacitor.

VSSH

VDDH

EP

P

P

N/A

Reference Supply Ground. Connect RGND to the system analog ground plane.

Reference Input/Output Ground. Connect the 10 μF capacitors that are on REF1 and REF2 to the REFN pins, then connect the REFN pins to the system analog ground plane.

High Voltage Analog Negative Supply. Nominally, the supply of VSSH is −15 V. Decouple VSSH using a

10 μF capacitor and a 0.1 μF local capacitor. Connect the exposed pad to VSSH.

High Voltage Analog Positive Supply. Nominally, the supply of VDDH is 15 V. Decouple VDDH using a

10 μF capacitor and a 0.1 μF local capacitor.

Exposed Pad. Connect the exposed pad to VSSH.

1 AI = analog input, AI/O = analog input/output, DI = digital input, DO = digital output, P = power, and N/A means not applicable.

Rev. A | Page 11 of 32

ADAS3023

TYPICAL PERFORMANCE CHARACTERISTICS

VDDH = 15 V, VSSH = −15 V, AVDD = DVDD = 5 V, VIO = 1.8 V to AVDD, unless otherwise noted.

2.0

1.5

FOR ALL PGIA GAINS

INL MAX = 0.875

INL MIN = –1.216

400000

350000

PGIA GAIN = 0.4

f

S

= 500kSPS

INTERNAL REFERENCE

325285

1.0

300000

0.75

0.50

0.25

0

–0.25

–0.50

0.5

0

–0.5

–1.0

–1.5

–2.0

0 8192 16384 24576 32768

CODE

40960 49152 57344 65536

Figure 7. Integral Nonlinearity (INL) vs. Code for All PGIA Gains

1.00

–0.75

–1.00

0

FOR ALL PGIA GAINS

DNL MAX = 0.794

DNL MIN = –0.661

8192 16384 24576 32768

CODE

40960 49152 57344 65536

Figure 8. Differential Nonlinearity (DNL) vs. Code for All PGIA Gains

400000

350000

PGIA GAIN = 0.2

f

S

= 500kSPS

INTERNAL REFERENCE

300000

278780

250000

200000

190408

150000

100000

50000

0

0 0 0 83

23813

6909

7 0 0

250000

200000

150000

100000

50000

0

0 0 0

962

74640

97631

Data Sheet

1481

1

400000

350000

PGIA GAIN = 0.8

f

S

= 500kSPS

INTERNAL REFERENCE

300000

250000

200000

248346

188714

150000

100000

50000

0

0 0 201

18671

43158

908 2

0 0

CODE IN HEX

Figure 10. Histogram of a DC Input at Code Center, PGIA Gain = 0.4

0 0

CODE IN HEX

Figure 11. Histogram of a DC Input at Code Center, PGIA Gain = 0.8

400000

350000

PGIA GAIN = 1.6

f

S

= 500kSPS

INTERNAL REFERENCE

300000

250000

200000

185455

171423

150000

100000

50000

0

0 6 450

9497

70413

56261

6254 238

3

CODE IN HEX

Figure 9. Histogram of a DC Input at Code Center, PGIA Gain = 0.2

CODE IN HEX

Figure 12. Histogram of a DC Input at Code Center, PGIA Gain = 1.6

Rev. A | Page 12 of 32

Data Sheet

60

50

40

30

20

14 15 13 13

11

10

3

5

6

2

3

2

3

0

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

REFERENCE DRIFT (ppm/°C)

Figure 13. Reference Drift, Internal Reference

60

50

46

40

30 28

–100

–120

–140

–160

0

20

13

10

0

2

1

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

REFERENCE BUFFER DRIFT (ppm/°C)

Figure 14. Reference Buffer Drift, Internal Reference

0

–20

–40

–60

PGIA GAIN = 0.2

f

S f

IN

= 500kSPS

= 1.12kHz

SNR = 91.3dB

SINAD = 91.3dB

THD = –110.6dB

SFDR = 106.6dB

INTERNAL REFERENCE

–80

250 50 100 150

FREQUENCY (kHz)

200

Figure 15. 1 kHz FFT, PGIA Gain = 0.2

–80

–100

–120

–140

–160

0

0

–20

–40

–60

ADAS3023

PGIA GAIN = 0.4

f

S

= 500kSPS f

IN

= 1.12kHz

SNR = 91.2dB

SINAD = 91.1dB

THD = –107.0dB

SFDR = 106.0dB

INTERNAL REFERENCE

50 100 150

FREQUENCY (kHz)

200

Figure 16. 1 kHz FFT, PGIA Gain = 0.4

PGIA GAIN = 0.8

f

S

= 500kSPS f

IN

= 1.12kHz

SNR = 89.7dB

SINAD = 89.6dB

THD = –104.0dB

SFDR = 105.0dB

INTERNAL REFERENCE

250

0

–20

–40

–60

–80

–100

–120

–140

–160

0

0

–20

–40

–60

–80

–100

–120

–140

–160

0

50 100 150

FREQUENCY (kHz)

200

Figure 17. 1 kHz FFT, PGIA Gain = 0.8

PGIA GAIN = 1.6

f

S

= 500kSPS f

IN

= 1.12kHz

SNR = 87.3dB

SINAD = 87.2dB

THD = –103.0dB

SFDR = 106.0dB

INTERNAL REFERENCE

50 100 150

FREQUENCY (kHz)

200

Figure 18. 1 kHz FFT, PGIA Gain = 1.6

250

250

Rev. A | Page 13 of 32

ADAS3023

–80

CH1, 2 ACTIVE CHANNELS, 500kSPS, PGIA GAIN = 0.8

CH3, 4 ACTIVE CHANNELS, 200kSPS, PGIA GAIN = 0.8

CH4, 6 ACTIVE CHANNELS, 100kSPS, PGIA GAIN = 0.8

CH4, 8 ACTIVE CHANNELS, 100kSPS, PGIA GAIN = 0.2

CH4, 8 ACTIVE CHANNELS, 100kSPS, PGIA GAIN = 0.4

–85

–90

–95

–100

–105

100

CH4, 8 ACTIVE CHANNELS, 100kSPS, PGIA GAIN = 0.8

CH4, 8 ACTIVE CHANNELS, 100kSPS, PGIA GAIN = 1.6

1k 10k

FREQUENCY (Hz)

100k

Figure 19. Crosstalk vs. Frequency

110

100

1M

PGIA GAIN = 0.2

PGIA GAIN = 0.4

PGIA GAIN = 0.8

PGIA GAIN = 1.6

90

80

70

60

50

40

1 10 100

FREQUENCY (Hz)

1k

Figure 20. CMRR vs. Frequency

10k

11.0

10.5

10.0

9.5

9.0

8.5

8.0

7.5

7.0

6.5

6.0

5.5

5.0

4.5

4.0

3.5

3.0

2.5

2.0

10

VDDH = 15V

6 ACTIVE CHANNELS, PGIA GAIN = 1.6

8 ACTIVE CHANNELS, PGIA GAIN = 1.6

6 ACTIVE CHANNELS, PGIA GAIN = 0.2

8 ACTIVE CHANNELS, PGIA GAIN = 0.2

4 ACTIVE CHANNELS, PGIA GAIN = 1.6

4 ACTIVE CHANNELS, PGIA GAIN = 0.2

2 ACTIVE CHANNELS, PGIA GAIN = 1.6

2 ACTIVE CHANNELS, PGIA GAIN = 0.2

100 1000

THROUGHPUT (kSPS)

Figure 21. VDDH Current vs. Throughput

Data Sheet

–6.0

–6.5

–7.0

–7.5

–8.0

–8.5

–9.0

–9.5

–2.0

–2.5

–3.0

–3.5

–4.0

–4.5

–5.0

–5.5

–10.0

–10.5

–11.0

10

2 ACTIVE CHANNELS, PGIA GAIN = 0.2

2 ACTIVE CHANNELS, PGIA GAIN = 1.6

4 ACTIVE CHANNELS, PGIA GAIN = 0.2

4 ACTIVE CHANNELS, PGIA GAIN = 1.6

8 ACTIVE CHANNELS, PGIA GAIN = 0.2

8 ACTIVE CHANNELS, PGIA GAIN = 1.6

VSSH = –15V

6 ACTIVE CHANNELS, PGIA GAIN = 0.2

6 ACTIVE CHANNELS, PGIA GAIN = 1.6

100 1000

THROUGHPUT (kSPS)

Figure 22. VSSH Current vs. Throughput

17

16

15

14

20

AVDD = 5V

19

18

INTERNAL REFERENCE

13

12

EXTERNAL REFERENCE

11

10

10 100

THROUGHPUT (kSPS)

Figure 23. AVDD Current vs. Throughput

2.0

1.7

1.4

1.1

0.8

0.5

10

3.5

DVDD = 5V

3.2

2.9

2.6

2.3

100

THROUGHPUT (kSPS)

Figure 24. DVDD Current vs. Throughput

1000

1000

Rev. A | Page 14 of 32

Data Sheet

100

98

96

94

92

90

88

86

84

82

80

CH1, PGIA GAIN = 0.4,

CH2, PGIA GAIN = 0.8,

CH5, PGIA GAIN = 0.8,

CH3, PGIA GAIN = 1.6, f f

S

= 500kSPS f

S

= 250kSPS

S

= 125kSPS f

S

= 167kSPS

TEMPERATURE (°C)

Figure 25. SNR vs. Temperature

–100

–105

–110

–115

–80

–85

–90

–95

CH1, PGIA GAIN = 0.4,

CH2, PGIA GAIN = 0.8,

CH5, PGIA GAIN = 0.8,

CH3, PGIA GAIN = 1.6, f

S

= 500kSPS f f

S

= 250kSPS f

S

= 125kSPS

S

= 167kSPS

–120

TEMPERATURE (°C)

Figure 26. THD vs. Temperature

0

–1

2

1

–2

–3

–4

–5

5

4

3

PGIA GAIN = 0.2

EXTERNAL REFERENCE f

S

= 125kSPS

T

A

= 25°C

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 27. Normalized Offset Error Drift, PGIA GAin = 0.2

ADAS3023

0

–1

–2

–3

–4

–5

2

1

5

4

3

PGIA GAIN = 0.4

EXTERNAL REFERENCE f

T

S

= 125kSPS

A

= 25°C

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 28. Normalized Offset Error Drift, PGIA Gain = 0.4

0

–1

–2

–3

–4

–5

2

1

5

4

3

PGIA GAIN = 0.8

EXTERNAL REFERENCE f

T

S

= 125kSPS

A

= 25°C

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 29. Normalized Offset Error Drift, PGIA Gain = 0.8

0

–2

–4

–6

–8

–10

4

2

10

8

6

PGIA GAIN = 1.6

EXTERNAL REFERENCE f

T

S

= 125kSPS

A

= 25°C

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 30. Normalized Offset Error Drift, PGIA Gain = 1.6

Rev. A | Page 15 of 32

ADAS3023

5

4

3

PGIA GAIN = 0.2

EXTERNAL REFERENCE f

S

= 125kSPS

T

A

= 25°C

0

–1

–2

–3

–4

–5

2

1

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 31. Normalized Gain Error Drift Error, PGIA Gain = 0.2

0

–1

–2

–3

–4

–5

2

1

5

4

3

PGIA GAIN = 0.4

EXTERNAL REFERENCE f

S

= 125kSPS

T

A

= 25°C

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 32. Normalized Gain Error Drift Error, PGIA Gain = 0.4

Data Sheet

0

–1

–2

–3

–4

–5

2

1

5

4

3

PGIA GAIN = 0.8

EXTERNAL REFERENCE f

T

S

= 125kSPS

A

= 25°C

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 33. Normalized Gain Error Drift Error, PGIA Gain = 0.8

0

–2

–4

–6

–8

–10

4

2

10

8

6

PGIA GAIN = 1.6

EXTERNAL REFERENCE f

T

S

= 125kSPS

A

= 25°C

CH0

CH4

CH1

CH5

CH2

CH6

CH3

CH7

TEMPERATURE (°C)

Figure 34. Normalized Gain Error Drift Error, PGIA Gain = 1.6

Rev. A | Page 16 of 32

Data Sheet

TERMINOLOGY

Operating Input Voltage Range

Operating input voltage range is the maximum input voltage range, including common-mode, which can be applied to the input channels, IN0 to IN7, and COM.

Differential Input Voltage Range

Differential input voltage range is the maximum differential full-scale input range. The value changes according to the selected programmable gain setting.

Channel Off Leakage

Channel off leakage is the leakage current with the channel turned off.

Channel On Leakage

Channel on leakage is the leakage current with the channel turned on.

Common-Mode Rejection Ratio (CMRR)

CMRR is computed as the ratio of the signal magnitude of the converted result, referred to input, in the converted result to the amplitude of the common modulation signal applied to an input pair, expressed in decibels. CMRR is a measure of the ability of the ADAS3023 to reject signals, such as power line noise, that are common to the inputs. This specification is tested and specified for all input channels, IN0 to IN7, with respect to COM.

Transient Response

Transient response is a measure of the time required for the

ADAS3023 to properly acquire the input after a full-scale step function is applied to the system.

Least Significant Bit (LSB)

The LSB is the smallest increment that can be represented by a converter. For a fully differential input ADC with N bits of resolution, the LSB expressed in volts is

LSB

(V) =

2

V

2

REF

N

Integral Nonlinearity Error (INL)

INL refers to the deviation of each individual code from a line drawn from negative full scale through positive full scale. The point used as negative full scale occurs ½ LSB before the first code transition. Positive full scale is defined as a level 1½ LSB beyond the last code transition. The deviation is measured from

the middle of each code to the true straight line (see Figure 37).

Differential Nonlinearity Error (DNL)

In an ideal ADC, code transitions are 1 LSB apart. DNL is the maximum deviation from this ideal value. DNL is often specified in terms of resolution for which no missing codes are guaranteed.

ADAS3023

Offset Error

Ideally, the MSB transition occurs at an input level that is ½ LSB above analog ground. The offset error is the deviation of the actual transition from that point.

Gain Error

Ideally, the last transition (from 011 … 10 to 011 … 11) occurs for an analog voltage 1½ LSB below the nominal full scale. The gain error is the deviation in LSB (or percentage of full-scale range) of the actual level of the last transition from the ideal level after the offset error is removed. Closely related is the fullscale error (also in LSB or percentage of full-scale range), which includes the effects of the offset error.

Aperture Delay

Aperture delay is the measure of the acquisition performance. It is the time between the rising edge of the CNV input and the point at which the input signal is held for a conversion.

Dynamic Range

Dynamic range is the ratio of the rms value of the full scale to the total rms noise measured with a −60 dBFS input signal applied to the inputs. The value for dynamic range is expressed in decibels.

Signal-to-Noise Ratio (SNR)

SNR is the ratio of the rms value of the actual input signal to the rms sum of all other spectral components below the Nyquist frequency, excluding harmonics and dc. The value for SNR is expressed in decibels.

Signal-to-(Noise + Distortion) Ratio (SINAD)

SINAD is the ratio of the rms value of the actual input signal to the rms sum of all other spectral components below the Nyquist frequency, including harmonics but excluding dc. The value for

SINAD is expressed in decibels.

Total Harmonic Distortion (THD)

THD is the ratio of the rms sum of the first five harmonic components to the rms value of a full-scale input signal expressed in decibels.

Spurious-Free Dynamic Range (SFDR)

SFDR is the difference, in decibels, between the rms amplitude of the input signal and the peak spurious signal.

Rev. A | Page 17 of 32

ADAS3023

Channel-to-Channel Crosstalk

Channel-to-channel crosstalk is a measure of the level of crosstalk between any channel and all other channels. The crosstalk is measured by applying a dc input to the channel under test and applying a full-scale, 10 kHz sine wave signal to all other channels.

The crosstalk is the amount of signal that leaks into the test channel expressed in decibels.

Data Sheet

Reference Voltage Temperature Coefficient

The reference voltage temperature coefficient is derived from the typical shift of output voltage at 25°C on a sample of devices at the maximum and minimum reference output voltage (V

REF

) measured at T

MIN

, T

A

(25°C), and T

MAX

expressed in ppm/°C.

TCV

REF

( ppm/

°

C )

=

V

V

REF

REF

(

Max

(

25

°

C

)

×

) –

V

REF

(

T

MAX

(

Min

)

T

MIN

)

×

10

6 where:

V

REF

(Max) is the maximum V

REF

at T

MIN

, T

A

(25°C), or T

MAX

.

V

REF

(Min) is the minimum V

REF

at T

MIN

, T

A

(25°C), or T

MAX

.

V

REF

(25°C) = V

REF

at 25°C.

T

MAX

= +85°C.

T

MIN

= −40°C.

Rev. A | Page 18 of 32

Data Sheet

THEORY OF OPERATION

OVERVIEW

The ADAS3023 is a 16-bit, 8-channel simultaneous system on a single chip that integrates the typical components used in a data acquisition system in one easy to use, programmable device. It is capable of converting two channels simultaneously up to 500,000 samples per second (500 kSPS) throughput. The ADAS3023 features

• High impedance inputs

• High common-mode rejection

• An 8-channel, low leakage track and hold

• A programmable gain instrumentation amplifier (PGIA) with four selectable differential input ranges from ±2.56 V to ±20.48 V

• A 16-bit PulSAR® ADC with no missing codes

• An internal, precision, low drift 4.096 V reference and buffer

The ADAS3023 uses the Analog Devices patented high voltage

iCMOS process allowing up to a ±20.48 V differential input voltage range when using ±15 V supplies, which makes the device suitable for industrial applications.

The device is housed in a small 6 mm × 6 mm, 40-lead LFCSP package and can operate over the industrial temperature range of

−40°C to +85°C. A typical discrete multichannel data acquisition system containing similar circuitry requires more space on the circuit board than the ADAS3023 . Therefore, advantages of the

ADAS3023 solution include a reduced footprint and less complex design requirements, leading to faster time to market and lower costs.

OPERATION

The analog circuitry of the ADAS3023 consists of a high impedance, low leakage, track-and-hold PGIA with a high common-mode rejection that can accept the full-scale differential voltages of ±2.56 V, ±5.12 V, ±10.24 V, and ±20.48 V (see

Figure 15). The

ADAS3023 can be configured to sample two, four, six, or eight channels simultaneously.

ADAS3023

The ADAS3023 offers true high impedance inputs in a differential structure and rejects common-mode signals present on the inputs.

This architecture does not require additional input buffers (op amps) that are usually required for signal buffering, level shifting, amplification, attenuation, and kickback reduction when using switched capacitor-based SAR ADCs.

Digital control of the programmable gain setting of each channel input is set via the configuration (CFG) register.

The conversion results are output in twos complement format on the serial data output (SDO) and through an optional secondary serial data output on the BUSY/SDO2 pin. The digital interface uses a dedicated chip select (CS) to control data access to and from the ADAS3023 together with a BUSY/SDO2 output, asynchronous reset (RESET), and power-down (PD) inputs.

The internal reference of the ADAS3023 uses an internal temperature compensated 2.5 V output band gap reference, followed by a precision buffer amplifier to provide the 4.096 V high precision system reference.

All of these components are configured through a serial (SPIcompatible), 16-bit CFG register. Configuration and conversion results are read after the conversions are completed.

The ADAS3023 requires a minimum of three power supplies

+15 V, −15 V, and +5 V. Internal low dropout regulators provide the necessary 2.5 V system voltages that must be decoupled externally via dedicated pins (ACAP, DCAP, and RCAP). The

ADAS3023 can be interfaced to any 1.8 V to 5 V digital logic family using the dedicated VIO logic level voltage supply (see

Table 9).

A rising edge on the CNV pin initiates a conversion and changes the ADAS3023 from track to hold. In this state, the ADAS3023 performs the analog signal conditioning and conversion. When the signal conditioning is completed, the ADAS3023 returns to the track state while, at the same time, quantizes the sample. This two-tiered process satisfies the necessary settling time requirement and achieves a fast throughput rate of up to 500 kSPS with 16-bit accuracy.

VDDH AVDD DVDD VIO RESET

DIFF TO

COM

IN0

IN1

IN2

IN3

IN4

IN5

IN6

IN7

COM

TRACK

AND

HOLD

PGIA

LOGIC/

INTERFACE

PulSAR

ADC

ADAS3023

BUF

REF

VSSH AGND DGND REFx

Figure 35. Simplified Block Diagram

PD

CNV

BUSY

CS

SCK

DIN

SDO

REFIN

Rev. A | Page 19 of 32

ADAS3023 t

CONV

CNV t

CYC t

ACQ

PHASE

CONVERSION ACQUISITION

Figure 36. System Timing

Regardless of the type of signal, (single-ended symmetric or asymmetric), the ADAS3023 converts all signals present on the enabled inputs and COM pin in a differential fashion identical to an industry-standard difference or instrumentation amplifier.

The conversion results are available after the conversion is complete and can be read back at any time before the end of the next conversion. Avoid reading back data during the quiet period, indicated by BUSY/SDO2 being active high. Because the ADAS3023 has an on-board conversion clock, the serial clock (SCK) is not required for the conversion process; it is only required to present results to the user.

Data Sheet

TRANSFER FUNCTIONS

The ideal transfer characteristic for the ADAS3023 is shown in

Figure 37. The inputs are configured for differential input ranges

and the data outputs are in twos complement format, as listed in

Table 6.

TWOS

COMPLEMENT

STRAIGHT

BINARY

011...111

011...110

011...101

111...111

111...110

111...101

Table 6. Output Codes and Ideal Input Voltages

Description

FSR − 1 LSB

Midscale + 1 LSB

Midscale

Midscale − 1 LSB

−FSR + 1 LSB

−FSR

Differential Analog Inputs, V

REF

= 4.096 V

(32,767 × V

REF

)/(32,768 × PGIA gain)

(V

REF

/(32,768 × PGIA gain))

0

−(V

REF

/(32,768 × PGIA gain))

−(32,767 × V

REF

)/(32,768 × PGIA gain)

−V

REF

× PGIA gain

100...010

100...001

100...000

000...010

000...001

000...000

–FSR

–FSR + 1LSB

–FSR + 0.5LSB

+FSR – 1LSB

+FSR – 1.5LSB

ANALOG INPUT

Figure 37. ADC Ideal Transfer Function

Digital Output Code

(Twos Complement Hex)

0x7FFF

0x0001

0x0000

0xFFFF

0x8001

0x8000

Rev. A | Page 20 of 32

Data Sheet ADAS3023

V

IN

= +5V

ENABLE

C

C

1

12nF

+ +

C

C

2

10pF

R

C

1

100kΩ

RF2

4.22kΩ

C

IN

1µF

+

R

EN

50kΩ

ADP1613

COMP SS

FB

EN

GND

RF1B

47.5kΩ

FREQ

VIN

SW

R

B

0

1Ω

R

S

1

0Ω

L2

47µH

L1

47µH

D2

+

C

OUT

3

4.7µF

+

C2

1µF

1.78Ω

R

FILT

D1

C1

1µF

C

OUT

1

1µF

+

L3

1µF

C

OUT

2.2µF

2

+

C

V

5

1µF

+

R

S

2

DNI

C

SS

1µF

+

Z1

DNI

+15V

+5V

VDDH AVDD DVDD VIO RESET PD

DIFF TO

COM

IN0

IN1

IN2

IN3

IN4

IN5

IN6

IN7

COM

TRACK

AND

HOLD

PGIA

ADAS3023

LOGIC/

INTERFACE

PulSAR

ADC

BUF

VSSH

–15V

AGND DGND

CNV

BUSY

CS

SCK

DIN

SDO

REFIN

REF

REFx

+5V

4.096V

+

+5V

ADR434

AD8031

Figure 38. Complete 5 V, Single-Supply, 8-Channel Data Acquisition System with PGIA

VDDH

TYPICAL APPLICATION CONNECTION DIAGRAM

As shown in Figure 38, the

ADP1613 is used in an inexpensive

SEPIC-Ćuk topology, which is an ideal candidate for providing the ADAS3023 with the necessary high voltage ±15 V robust supplies (at 20 mA) and low output ripple (3 mV maximum) from an external 5 V supply. The ADP1613 satisfies the specification requirements of the ADAS3023 using minimal external components yet achieves greater than 86% efficiency. See the CN-0201 circuit note for complete information about this test setup.

ANALOG INPUTS

Input Structure

The ADAS3023 uses a differential input structure between each of the channel inputs, IN0 to IN7, and a common reference

(COM), all of which sample simultaneously.

Figure 39 shows an equivalent circuit of the inputs. The diodes

provide ESD protection for the analog inputs (IN0 to IN7) and

COM from the high voltage supplies (VDDH and VSSH). Ensure that the analog input signal does not exceed the supply rails by more than 0.3 V because this can cause the diodes to become forward-biased and to start conducting current. The voltages beyond the absolute maximum ratings may cause permanent damage to the ADAS3023

(see Table 4).

INx OR COM

VSSH

C

PIN

TRACK

AND

HOLD

PGIA

AGND

Figure 39. Equivalent Analog Input Circuit

Programmable Gain

The ADAS3023 incorporates a programmable gain instrumentation amplifier (PGIA) with four selectable ranges. The

PGIA settings are specified in terms of the maximum absolute differential input voltage across an input pin and the COM pin, for example INx to COM. The power on and default conditions are preset to the ±20.48 V (PGIA = 11) input range.

Note that because the ADAS3023 can use any input type, such as bipolar single-ended and pseudo bipolar, setting the PGIA is important to make full use of the allowable input span.

Rev. A | Page 21 of 32

ADAS3023

Table 7 describes each differential input range and the corre-

sponding LSB size, PGIA bit settings, and PGIA gain.

Table 7. Differential Input Ranges, LSB Size, and PGIA

Settings

Differential Input Ranges,

INx − COM (V) LSB (μV)

PGIA

CFG

PGIA

Gain

(V/V)

±20.48

±10.24

±5.12

±2.56

625

312.5

156.3

78.13

11

00

01

10

0.2

0.4

0.8

1.6

Common-Mode Operating Range

The differential input common-mode range changes according to the input range selected for a given channel and the high voltage power supplies. Note that the operating input voltage of

any input pin, as defined in the Specifications section, requires

a minimum of 2.5 V of headroom from the VDDH/VSSH supplies or

(VSSH + 2.5 V) ≤ INx/COM ≤ (VDDH – 2.5 V)

The following sections offer some examples of setting the PGIA for various input signals. Note that the ADAS3023 always takes the difference between the INx and COM signals.

Single-Ended Signals with a Nonzero DC Offset

(Asymmetrical)

When a 5.12 V p-p signal with a 2.56 V dc offset is connected to one of the inputs (INx+) and the dc ground sense of the signal is connected to COM, the PGIA gain configuration is set to 01 for the ±5.12 V range because the maximum differential voltage across the inputs is +5.12 V. This scenario uses only half the codes available for the transfer function.

INx+

+5.12V

INx+

5.12V p-p

V

OFF

ADAS3023

V

OFF

0V

COM

COM

Figure 40. Typical Single-Ended Unipolar Input Using Only Half of the Codes

Single-Ended Signals with a 0 V DC Offset (Symmetrical)

Compared with the example in the Single-Ended Signals with a

Nonzero DC Offset (Asymmetrical) section, a better solution

for single-ended signals, when possible, is to remove as much differential dc offset between INx and COM such that the average voltage is 0 V (symmetrical around the ground sense). The differential voltage across the inputs is never greater than

±2.56 V, and the PGIA gain configuration is set for a ±2.56 V range (10). This scenario uses all of the codes available for the transfer function, making full use of the allowable differential input range.

Data Sheet

INx+

INx+

+2.56V

0V 5.12V p-p

ADAS3023

COM

–2.56V

COM

Figure 41. Optimal Single-Ended Configuration Using All Codes

Notice that the voltages in the examples are not integer values due to the 4.096 V reference and the scaling ratios of the PGIA.

The maximum allowed dc offset voltage on the COM input pin

for various PGIA gains in this case is shown in Table 8.

Table 8. DC Offset Voltage on COM Input and PGIA

Settings 1

PGIA Gain (V/V) DC Offset Voltage on COM (V)

0.2

0.4

0.8

1.6

0

0

±5.12

±7.68

1 Full-scale signal on INx.

VOLTAGE REFERENCE INPUT/OUTPUT

The ADAS3023 allows the choice of an internal reference, an external reference using an internal buffer, or an external reference.

The internal reference of the ADAS3023 provides excellent performance and can be used in nearly any application. Setting the reference selection mode uses the internal reference enable bit, REFEN, and the REFIN pin as described in the following

sections (Internal Reference, External Reference and Internal

Buffer, External Reference, and Reference Decoupling).

Internal Reference

The precision internal reference is factory trimmed and is suitable for most applications.

Setting the REFEN bit in the CFG register to 1 (default) enables the internal reference and produces 4.096 V on the REF1 and

REF2 pins; this 4.096 V output serves as the main system reference.

The unbuffered 2.5 V (typical) band gap reference voltage is output on the REFIN pin, which requires an external parallel combination of 10 μF and 0.1 μF capacitors to reduce the noise on the output. Because the current output of REFIN is limited, it can be used as a source when followed by a suitable buffer, such as the AD8031 . Note that excessive loading of the REFIN output lowers the 4.096 V system reference because the internal amplifier uses a fixed gain.

The internal reference output is trimmed to the targeted value of 4.096 V with an initial accuracy of ±8 mV. The reference is also temperature compensated to provide a typical drift of

±5 ppm/°C.

When the internal reference is used, decouple the ADAS3023 ,

as shown in Figure 42. Note that both the REF1 and REF2 con-

nections are shorted together and externally decoupled with

Rev. A | Page 22 of 32

Data Sheet

suitable decoupling on the REFIN output and the RCAP internally regulated supply.

0.1µF 0.1µF 0.1µF

10µF

REFN REF2

10µF

REFN REF1

10µF

REFN REFIN

ADAS3023

loading for op amps usually refers to the ability of the amplifier to remain marginally stable in ac applications but can also play a role in dc applications, such as a reference source.

Keep in mind that the reference source sees the dynamics of the bit decision process on the reference pins and further analysis beyond the scope of this data sheet may be required.

REFERENCE

SOURCE = 4.096V

ADAS3023

BAND

GAP

RCAP

1µF

10µF

0.1µF

10µF

0.1µF

External Reference and Internal Buffer

The external reference and internal buffer are useful where a common system reference is used or when improved drift performance is required.

Setting Bit REFEN to 0 disables the internal band gap reference, allowing the user to provide an external voltage reference (2.5 V typical) to the REFIN pin. The internal buffer remains enabled, thus reducing the need for an external buffer amplifier to generate the main system reference. Where REFIN = 2.5 V and REF1 and

REF2 output 4.096 V, this serves as the main system reference.

For this configuration, connect the external source, as shown in

Figure 43. Any type of 2.5 V reference can be used in this config-

uration (low power, low drift, small package, and so forth) because the internal buffer handles the dynamics of the ADAS3023 reference requirements.

0.1µF 0.1µF 0.1µF

REFERENCE

SOURCE = 2.5V

10µF 10µF 10µF

REFN

Figure 42. 4.096V Internal Reference Connection

REF2 REFN

ADAS3023

REF1

RGND

REFN

BAND

GAP

REFIN

RCAP

1µF

RGND

Figure 43. External Reference Using Internal Buffer

External Reference

For applications that require a precise, low drift, 4.096 V reference, an external reference can be used. Note that in this mode, disabling the internal buffer requires setting REFEN to 0, and driving or connecting REFIN to AGND; thus, both hardware and software control are necessary. Attempting to drive the REF1 and REF2 pins alone prior to disabling the internal buffer can cause source/sink contention in the outputs of the driving amplifiers.

Connect the precision 4.096 V reference directly to REF1 and

REF2, which are the main system reference (see Figure 44); two

recommended references are the ADR434 or ADR444 .

If an op amp is used as an external reference source, take note of the concerns regarding driving capacitive loads. Capacitive

Rev. A | Page 23 of 32

REFN REF2 REFN

ADAS3023

REF1 REFIN

BAND

GAP

RCAP

1µF

RGND

Figure 44. External Reference

Reference Decoupling

With any of the reference topologies described in the Voltage

Reference Input/Output section, the REF1 and REF2 reference

pins of the ADAS3023 have dynamic impedances and require sufficient decoupling, regardless of whether the pins are used as inputs or outputs. This decoupling usually consists of a low ESR capacitor connected to each REF1 and REF2 pin and to the accompanying REFN return paths. Ceramic chip capacitors (X5R, 1206 size) are recommended for decoupling in all of the reference

topologies described in the Voltage Reference Input/Output

section.

The placement of the reference decoupling capacitors plays an important role in system performance. Using thick printed circuit board (PCB) traces, mount the decoupling capacitors on the same side as the ADAS3023, close to the REF1 and REF2 pins. Route the return paths to the REFN inputs that, in turn, connect to the analog ground plane of the system. When it is necessary to connect to an internal PCB, minimize the resistance of the return path to ground by using as many through vias as possible.

Using the shortest distance and several vias, connect the REFN and RGND inputs to the analog ground plane of the system, preferably adjacent to the solder pads. One common mistake is to route these traces to an individual trace that connects to the ground of the system. This can introduce noise, which may adversely affect the LSB sensitivity. To prevent such noise, use

PCBs with multiple layers, including ground planes, rather than using single or double sided boards.

Smaller reference decoupling capacitor values (as low as 2.2 µF) can be used with little impact, mainly on DNL and THD. Furthermore, there is no need for an additional lower value ceramic decoupling capacitor (for example, 100 nF) that is common in decoupling schemes for high frequency noise rejection.

For applications that use multiple ADAS3023 devices or other

PulSAR ADCs, using the internal reference buffer is most effective

ADAS3023 Data Sheet

to buffer the external reference voltage and, thereby, reduce SAR conversion crosstalk.

The voltage reference temperature coefficient (TC) directly affects the full-scale accuracy of the system; therefore, in applications where full-scale accuracy is crucial, care must be taken with the TC. For example, a ±15 ppm/°C TC of the reference changes the full-scale accuracy by ±1 LSB/°C.

POWER SUPPLY

The ADAS3023 uses five supplies: AVDD, DVDD, VIO, VDDH,

and VSSH (see Table 9). Note that the ACAP, DCAP, and RCAP

pins are for informational purposes only because they are the outputs of the internal supply regulators.

VIO is the variable digital input/output supply and allows direct interface with any logic between 1.8 V and 5 V (DVDD supply maximum). To reduce the supplies that are required, VIO can, alternatively, be connected to DVDD when DVDD is supplied from the analog supply through an RC filter. The recommended low dropout regulators are ADP3334 , ADP1715 , ADP7102 , and

ADP7104 for the AVDD, DVDD, and VIO supplies. Note that the user must bring up the ADAS3023 power supplies in the following sequence:

1. VIO

2. VDDH

3. VSSH

4. DVDD

5. AVDD

6. REFx

Table 9. Supplies

Mnemonic Function

AVDD

DVDD

VIO

VDDH

VSSH

ACAP

DCAP

RCAP

Analog 5 V core

Digital 5 V core

Yes

Yes, or can connect to

AVDD

Digital input/output Yes, and can connect to

DVDD (for the 5 V level)

Positive high voltage Yes, +15 V typical

Negative high voltage

Analog 2.5 V core

Digital 2.5 V core

Analog 2.5 V core

Required

Yes, −15 V typical

No, on chip

No, on chip

No, on chip

High Voltage Supplies

The high voltage bipolar supplies, VDDH and VSSH, are required and must be at least 2.5 V larger than the maximum operating input voltage. Specifically, any operating input voltage

(as defined in Table 2) of an input pin requires 2.5 V of headroom

from the VDDH/VSSH supplies or

(VSSH + 2.5 V) ≤ INx/COM ≤ (VDDH − 2.5 V)

Sufficient decoupling of these supplies is also required, consisting of at least a 10 μF capacitor and 100 nF capacitor on each supply.

Core Supplies

The AVDD and DVDD pins supply the ADAS3023 analog and digital cores, respectively. Sufficient decoupling of these supplies is required, consisting of at least a 10 μF capacitor and 100 nF capacitor on each supply. Place the 100 nF capacitors as close as possible to the ADAS3023 . To reduce the number of supplies that are required, supply the DVDD from the analog supply by connecting a simple RC filter between AVDD and DVDD, as shown in

Figure 45.

+5V ANALOG

SUPPLY

10µF

+

+15V

10µF

+

–15V

10µF

+

100nF

100nF

100nF

20Ω

10µF

+

AVDD AGND DVDD DGND

VDDH

VSSH

ADAS3023

VIO

Figure 45. Supply Connections

100nF

100nF

+5V DIGITAL

SUPPLY

+1.8V TO +5V

DIGITAL I/O

SUPPLY

DGND

POWER DISSIPATION MODES

The ADAS3023 offers two power dissipation modes: fully operational mode and power-down mode.

Fully Operational Mode

In fully operational mode, the conversions normally.

Power-Down Mode

ADAS3023 can perform the

To minimize the operating currents of the device when it is idle, place the device in full power-down mode by bringing the PD input high; this places the ADAS3023 into a deep sleep mode in which CNV activity is ignored and the digital interface is inactive.

Refer to the RESET and Power-Down (PD) Inputs section for

timing details. In deep sleep mode, the internal regulators

(ACAP, RCAP, and DCAP) and the voltage reference are powered down.

10µF

+

To reestablish operation, return PD to logic low. Note that, before the device can operate at the specified performance, the reference voltage must charge up the external reservoir capacitor(s) and be allowed the specified settling time. RESET must be applied after returning PD to low to restore the ADAS3023 digital core, including the CFG register, to its default state. Therefore, the desired CFG must be rewritten to the device and one dummy conversion must be completed before the device operation is restored to the configuration programmed prior to PD assertion. Note that when using the internal reference, sufficient time is required to settle it to the nominal value. For a typical connection, it requires 100 ms

to settle to the nominal value (see Figure 41).

Rev. A | Page 24 of 32

Data Sheet

CONVERSION MODES

The ADAS3023 offers two conversion modes to accommodate varying applications, and both modes are set with the conversion mode select bit, CMS (Bit 1) of the CFG register.

Warp Mode (CMS = 0)

Setting CMS to 0 is useful where the full 2-channel throughput of 500 kSPS is required. However, in this mode, the maximum time between conversions is restricted. If this maximum period is exceeded, the conversion result can be corrupted. Therefore, the warp mode is best suited for continuously sampled applications.

ADAS3023

Normal Mode (CMS = 1, Default)

Setting CMS to 1 is useful for all applications where the full

500 kSPS sample rate of the device is not required. In this mode, there is no maximum time restriction between conversions. This mode is the default condition from the assertion of an asynchronous reset. The main difference between the normal mode and warp mode is that the BUSY/SDO2 time, t

CONV

, is slightly longer in normal mode than in warp mode.

Rev. A | Page 25 of 32

ADAS3023

DIGITAL INTERFACE

The ADAS3023 digital interface consists of asynchronous inputs and a 4-wire serial interface for conversion result readback and configuration register programming.

This interface uses the three asynchronous signals (CNV, RESET, and PD) and a 4-wire serial interface comprised of CS, SDO,

SCK, and DIN. CS can also be tied to CNV for some applications.

Conversion results are presented to the serial data output pin

(SDO) after the end of a conversion. The 16-bit configuration word, CFG, is programmed on the serial data input pin, DIN during the first 16 SCKs of any data transfer. This CFG register controls the settings, such as selecting the number of channels to be converted, the programmable gain settings for each channel

group, and the reference choice (see Configuration Register

section for more information).

CONVERSION CONTROL

The CNV input initiates conversions for N enabled channels as defined in the CFG register. The ADAS3023 is fully asynchronous and can perform conversions at any frequency from dc up to

500 kSPS, depending on the settings specified in the configuration register and the system serial clock rate.

CNV Rising—Start of Conversion (SOC)

A rising edge on the CNV changes the state of the ADAS3023 from track mode to hold mode, as well as all that is necessary to initiate a conversion. All conversion clocks are generated internally. After a conversion is initiated, the ADAS3023 ignores other activity on the CNV line (governed by the throughput rate) until the end of the conversion.

While the ADAS3023 is performing a conversion and the BUSY/

SDO2 output is driven high, the ADAS3023 uses a unique 2-phase conversion process, allowing for safe data access and quiet time.

The CNV signal is decoupled from the CS pin, allowing multiple

ADAS3023 devices to be controlled by the same processor. For applications where SNR is critical, the CNV source requires very low jitter, which is achieved by using a dedicated oscillator or by clocking CNV with a high frequency, low jitter clock. For applications where jitter is more tolerable or a single device is in use, tie

CNV to CS. For more information on sample clock jitter and aperture delay, see the MT-007 Mini Tutorial , Aperture Time,

Aperture Jitter, Aperture Delay Time—Removing the Confusion.

Although CNV is a digital signal, take care to ensure fast, clean edges with minimal overshoot, undershoot, and ringing. In addition, avoid digital activity close to the sampling instant because such activity can result in degraded SNR performance.

BUSY/SDO2 Falling Edge—End of Conversion (EOC)

The EOC is indicated by BUSY/SDO2 returning low and can be used as a host interrupt. In addition, the EOC gates data access to and from the ADAS3023 . If the conversion result is not read prior to the next EOC event, the data is lost. Furthermore, if the

CFG update is not completed prior to the EOC, it is discarded and

Rev. A | Page 26 of 32

BUSY

CS t

CCS t

DIS t

EN

Data Sheet

the current configuration is applied to future conversions. This pipeline ensures that the ADAS3023 has sufficient time to acquire the next sample to the specified 16-bit accuracy.

Register Pipeline

The CFG register is written on the first 16 SCKs following the

EOC event, and it is updated on the next EOC event. To ensure that all CFG updates are applied during a known safe instant to the various circuit elements, the asynchronous data transfer is synchronized to the ADAS3023 timing engine using the EOC event. This synchronization introduces an inherent delay between updating the CFG register setting and the application of the configuration to a conversion. This pipeline, from the end of the current conversion (n), consists of a one-deep delay before the CFG setting takes effect. This means that two SOC and EOC events must elapse before the setting (that is, the new channel, gain, and so forth) takes effect. Note that the nomenclature (n),

(n + 1), and so forth is used in the remainder of the following

digital sections (Serial Data Interface, General Timing, and

Configuration Register) for simplicity. Note, however, that there

is no pipeline after the end of a conversion before data can be read back.

RESET AND POWER-DOWN (PD) INPUTS

The asynchronous RESET and PD inputs can be used to reset and power down the ADAS3023 , respectively. Timing details

are shown in Figure 46.

t

RH t

ACQ

SEE NOTE

CNV n – 1 n

RESET/

PD

SDO n – 2 UNDEFINED x

CFG x n + 1 x DEFAULT x

SEE NOTE

NOTES

1. WHEN THE PART IS RELEASED FROM RESET, t

ACQ

MUST BE

MET FOR CONVERSION n IF USING THE DEFAULT CFG

SETTING FOR CHANNEL IN0. WHEN THE PART IS RELEASED

FROM POWER-DOWN, t

ACQ

IS NOT REQUIRED, AND THE FIRST

TWO CONVERSIONS, n AND n + 1, ARE UNDEFINED.

Figure 46. RESET and PD Timing

A rising edge on RESET or PD aborts the conversion process and places SDO into high impedance, regardless of the CS level. Note that RESET has a minimum pulse width (active high) time for setting the ADAS3023

into the reset state. See the Configuration

Register section for the default CFG setting when the

ADAS3023 returns from the reset state. If this default setting is used after

RESET is deasserted (Logic 0), for the conversion result to be valid, a period equal to the acquisition time (t

ACQ

) must elapse before CNV can be asserted; otherwise, if a conversion is initiated, the result is corrupted. In addition, the output data from the previous conversion is cleared upon a reset; attempting

Data Sheet

to access the data result prior to initiating a new conversion produces an invalid result.

Upon the device returning from power-down mode or from a reset when the default CFG is not used, there is no t

ACQ

requirement because the first two conversions from power-up are undefined/ invalid because the one-deep delay pipeline requirement must be satisfied to reconfigure the device to the desired setting.

SERIAL DATA INTERFACE

The ADAS3023 uses a simple 4-wire interface and is compatible with FPGAs, DSPs, and common serial interfaces such as a serial peripheral interface (SPI), QSPI™, and MICROWIRE®. The

t

SCK t

SCKL

CS

SCK t

SCKH t

DIS

ADAS3023

interface uses the CS, SCK, SDO, and DIN signals. Timing signals

for a serial interface are shown in Figure 47.

SDO is activated when CS is asserted. The conversion result is output on SDO and updated on the SCK falling edges. Simultaneously, the 16-bit CFG word is updated, if needed, on the serial data input (DIN). The state of BUSY/SDO2 (Bit 0) determines the output format of the MSB data when SDO is activated after the

EOC. Note that, in Figure 47, SCK is shown as idling high. SCK

can idle high or low, requiring the system developer to design an interface that suits setup and hold times for both SDO and DIN.

t

SDOH t

EN

SDO

(MISO)

DIN

(MOSI) t

SDOV t

DINS t

DINH

Figure 47. Serial Timing

Rev. A | Page 27 of 32

ADAS3023

GENERAL TIMING

Figure 48 and Figure 49 conversion timing diagrams show the

specific timing parameters, including the complete register to conversion and readback pipeline delay. These figures detail the timing from a power up or from returning from a full power down by use of the PD input. When the BUSY/SDO2 output is not enabled after the EOC, the data available on the SDO output

(MSB first) can be read after the16 SCK rising edges in sequential fashion (from Channel 0 (CH0) to Channel 7 (CH7)), as shown

in Figure 48.

SOC

EOC t

CYC

POWER

UP t

CONV

NOTE 1

PHASE CONVERSION (n) ACQUISITION (n + 1)

CNV t

CNVH

NOTE 4 t

AD

NOTE 3 CS

SCK

DIN

SDO

NOTE 2

1 16 1

CFG (n + 2)

CH0 CH1

16 1

CH7

16

SOC

The converter busy signal is always output on the BUSY/SDO2 pin when CS is logic high. When the BUSY/SDO2 output is enabled when CS is brought low after the EOC, the SDO outputs the data of Channel 0 to Channel 3 (CH0, CH1, CH2, and CH3), and the SDO2 outputs the data of Channel 4 to Channel 7 (CH4, CH5,

CH6, and CH7) after 16 SCK rising edges, as shown in Figure 49.

The conversion result output on BUSY/SDO2 pin synchronizes to the SCK falling edges. The conversion results are in twos complement format. Reading or writing data during the quiet conversion phase (t

CONV

) may cause incorrect bit decisions.

SOC

NOTE 2

CONVERSION (n + 1)

EOC

NOTE 1

1 16 1

CFG (n + 3)

CH0 CH1

16

Data Sheet

ACQUISITION (n + 2)

1

CH7

16

CS

SCK

DIN

SDO

BUSY/

SDO2

BUSY/

SDO2 t

CBD

DATA (n) DATA (n + 1)

NOTES

1. DATA ACCESS CAN ONLY OCCUR AFTER CONVERSION. BOTH CONVERSION RESULT AND THE CFG REGISTER ARE UPDATED AT THE END OF THE CONVERSION (EOC).

2. A TOTAL OF 16 SCK FALLING EDGES ARE REQUIRED FOR CONVERSION RESULT. AN ADDITIONAL 16 EDGES AFTER THE LAST CONVERSION RESULT ON BUSY READS BACK THE CFG ASSOCIATED

WITH CONVERSION.

3. CS CAN BE HELD LOW OR CONNECTED TO CNV. CS IS SHOWN WITH FULL INDEPENDENT CONTROL.

4. FOR OPTIMAL PERFORMANCE, DATA ACCESS SHOULD NOT OCCUR DURING THE SAMPLING INSTANT. A MINIMUM TIME OF AT LEAST THE APERATURE DELAY, t

AD, SHOULD LAPSE PRIOR TO DATA ACCESS.

SOC

Figure 48. General Timing Diagram with BUSY/SDO2 Disabled

SOC SOC

EOC t

CYC

EOC t

CONV

POWER

UP

PHASE CONVERSION (n)

NOTE 1

ACQUISITION (n + 1) CONVERSION (n + 1)

NOTE 1

ACQUISITION (n + 2)

CNV t

CNVH

NOTE 4 t

AD

NOTE 3

NOTE 2

1 16 1

CFG (n + 2)

CH0

CH4

CH1

CH5

16 1

CH2

CH6

16 1

CH3

CH7

16 1

CFG (n + 3)

CH0

CH4

16 1

CH1

CH5

16 1

CH2

CH6

16 1

CH3

CH7

16

DATA (n) DATA (n + 1)

NOTES

1. DATA ACCESS CAN ONLY OCCUR AFTER CONVERSION. BOTH CONVERSION RESULT AND THE CFG REGISTER ARE UPDATED AT THE END OF THE CONVERSION (EOC).

2. A TOTAL OF 16 SCK FALLING EDGES ARE REQUIRED FOR CONVERSION RESULT. AN ADDITIONAL 16 EDGES AFTER THE LAST CONVERSION RESULT ON BUSY READS BACK THE CFG ASSOCIATED

WITH CONVERSION.

3. CS CAN BE HELD LOW OR CONNECTED TO CNV. CS IS SHOWN WITH FULL INDEPENDENT CONTROL.

4. FOR OPTIMAL PERFORMANCE, DATA ACCESS SHOULD NOT OCCUR DURING THE SAMPLING INSTANT. A MINIMUM TIME OF AT LEAST THE APERATURE DELAY, t

AD, SHOULD LAPSE PRIOR TO DATA ACCESS.

Figure 49. General Timing Diagram with BUSY/SDO2 Enabled

Rev. A | Page 28 of 32

Data Sheet ADAS3023

CONFIGURATION REGISTER

The configuration register, CFG, is a 16-bit programmable register for selecting all of the user-programmable options of the ADAS3023

(see Table 11).

The register is loaded when data is read back for the first

16 SCK rising edges, and it is updated at the next EOC. Note that there is always a one-deep delay when writing to CFG, and when reading back from CFG, it is the setting associated with the current conversion. required for the user specified CFG to take effect. To ensure the digital core is in the default state, apply an external reset after the deassertion of PD. The default value is CFG[15:0] = 0xFFFF. To read back the contents of the configuration register, CFG, an additional 16 SCKs are provided after all of the channel data have been read, and CFG is made available on the SDO output.

The default CFG settings configure the ADAS3023 as follows:

The default CFG setting is applied when the ADAS3023 returns from the reset state (RESET = high) to the operational state

(RESET = low). Returning from the full power-down state

(PD = high) to an enabled state (PD = low), the default CFG setting is not applied and at least one dummy conversion is

• Overwrites contents of the CFG register.

• Selects the eight input channels mode.

• Configures the PGIA gain to 0.20 (±20.48 V).

• Enables the internal reference.

• Selects normal conversion mode.

• Disables the SDO2 readout mode.

Table 10. Configuration Register, CFG Bit Map; Default Value = 0xFFFF (1111 1111 1111 1111)

15 14 13 12 11 10 9 8 7 6 5 4

CFG INx INx RSV PGIA PGIA PGIA PGIA PGIA PGIA PGIA PGIA

3 2 1 0

RSV REFEN CMS BUSY/SDO2

Table 11. Configuration Register Description

Bit No. Bit Name

15 CFG

[14:13] INx

Description

Configuration update.

0 = keeps current configuration settings.

1 = overwrites contents of register.

Selection of the number of channels to be converted simultaneously.

12 RSV

[11:4] PGIA

1

1

Bit 14

0

0

Bit 13

0

1

0

1

Reserved. Setting or clearing this bit has no effect.

Programmable gain selection (see the Programmable Gain section).

Bit (Odd)

0

0

1

Bit (Even)

0

1

0

6

8

Channels

2

4

PGIA Gain

±10.24 V

±5.12 V

±2.56 V

1

0

3

2

[11:10] PGIA

[9:8]

[7:6]

[5:4]

PGIA

PGIA

PGIA

RSV

REFEN

CMS

1

Sets the gain of IN0.

Sets the gain of IN1.

Sets the gain of IN3 to IN2.

Sets the gain of IN4 to IN7.

1 ±20.48 V (default)

Reserved. Setting or clearing this bit has no effect.

Internal reference (see the Pin Configuration and Function Descriptions and Voltage Reference Input/Output sections).

0 = disables the internal reference. Disable the internal reference buffer by pulling REFIN to ground.

1 = enables the internal reference (default).

Conversion mode selection (see the Conversion Modes section).

0 = uses the warp mode for conversions with a time between conversion restriction.

1 = uses the normal mode for conversions (default).

BUSY/SDO2 Secondary data output control using the BUSY/SDO2 pin.

0 = enables the device

busy status when the CS pin is held high. On the CS falling edge, the MSB of Channel 1 is presented on the BUSY/SDO2 input and subsequent data is presented on the SCK falling edges.

1 = enables the device busy status only (default). All data is transmitted via the SDO pin on the SCK falling edge.

Rev. A | Page 29 of 32

ADAS3023

PACKAGING AND ORDERING INFORMATION

OUTLINE DIMENSIONS

6.10

6.00 SQ

5.90

PIN 1

INDICATOR

0.50

BSC

30

31

0.30

0.25

0.18

EXPOSED

PAD

40

1

PIN 1

INDICATOR

*4.70

4.60 SQ

4.50

Data Sheet

1.00

0.95

0.85

SEATING

PLANE

ORDERING GUIDE

Model 1

ADAS3023BCPZ

ADAS3023BCPZ-RL7

EVAL-ADAS3023EDZ

1 Z = RoHS Compliant Part.

Temperature Range

−40°C to +85°C

−40°C to +85°C

−40°C to +85°C

TOP VIEW

0.45

0.40

0.35

21

20

0.05 MAX

0.02 NOM

COPLANARITY

0.08

0.20 REF

11

10

BOTTOM VIEW

0.25 MIN

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

*COMPLIANT TO JEDEC STANDARDS MO-220-VJJD-5

WITH EXCEPTION TO EXPOSED PAD DIMENSION.

Figure 50. 40-Lead Lead Frame Chip Scale Package [LFCSP_VQ]

6 mm × 6 mm Body, Very Thin Quad

(CP-40-15)

Dimensions shown in millimeters

Package Description

40-Lead Lead Frame Chip Scale Package [LFCSP_VQ]

40-Lead Lead Frame Chip Scale Package [LFCSP_VQ]

Evaluation Board

Package Option

CP-40-15

CP-40-15

Rev. A | Page 30 of 32

Data Sheet

NOTES

ADAS3023

Rev. A | Page 31 of 32

ADAS3023

NOTES

Data Sheet

©2013–2014 Analog Devices, Inc. All rights reserved. Trademarks and

registered trademarks are the property of their respective owners.

D10942-0-2/14(A)

Rev. A | Page 32 of 32

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
