Swing Gate Operators
sWING
GATE
OPERATORS
There is virtually limit to the capabilities of our swing gate
operators; combining industry-leading functionality, worldclass reliability and ease of installation,
CentSys’ swing gate operators truly are in a league of their
own. We have even given special attention to aesthetic
value, ensuring that your gate operator is as good looking
as it is dependable.
This quick selection guide will help you to select the perfect CentSys operator for you or your client’s swing gate by providing the
differentiating features and key specifications of each.
Input voltage 1
Maximum gate leaf width for corresponding gate mass
Typical gate opening time
Maximum daily operations
Domestic
Light-industrial
Onboard multichannel receiver
Interface type
Automatic beam test
R3
R5
VECTOR2 400
VECTOR2 500
IT24N
220V - 240V AC
90V - 240V AC
90V - 240V AC
90V - 240V AC
220V - 240V AC
2m - 250kg
2m - 600kg
2m - 500kg
2m - 600kg
2m -550kg
3.5m - 150kg
3.5m - 260kg
4m - 200kg
4m - 310kg
3.5m - 400kg
11 sec
17 sec
14 sec
17 sec
<20 sec
150
-
100
100
-
-
250
250
250
-
-
-
√
√
-
LED-based
LED-based
LCD
LCD
LED-based
-
-
√
√
-
SWING GATE OPERATOR
quick selection guide
Swing Gate Operator Quick Selection Guide
1. Can operate off a solar supply, consult Centurion Systems (Pty) Ltd for assistance
www.CentSys.com.au
SWING
GATE OPERATOR
quick selection
guide
page 39
Technical Specifications
Product Codes: VECTOR2 400: VEC40002V4_AU, VECTOR2 500: VEC50002V4_AU
Technical Data
The VECTOR2 range of linear swing gate operators are quick and easy to install, provide high push force and operate at rapid
speeds while still allowing for smooth acceleration and deceleration – courtesy of full position control technology.
VECTOR2 400
Input voltage 1
VECTOR2 500
90V 8/ 220V - 240V AC ± 10%, 50Hz
Motor voltage
12V DC
Battery-driven - charger 800mA/2A
Motor power supply 2
Battery charger
Models available
Domestic (D)
CP84E - 800mA @ 13.8V
Light-industrial (L)
VECTOR2 400: VECTOR2 500:
A reliable operator for the majority of domestic swing gate applications
Features an extended stroke for large domestic and light-industrial swing gates
CP84SM - 2A @ 13.8V
Current consumption (mains)
60mA (D)/170mA (L)
Current consumption (motor at rated load)
3A - max
Push force – maximum
250kgf
400mm
Operator stroke
Main Features
500mm
Piston extension/retraction speed
27mm / sec
<14 sec
Gate opening time – typical 7
Mechanical Features
• Diagnostic screens indicating:
• Battery backup
25% (D)/ 50% (L)
Daily operations - maximum
100 (D)/ 250 (L)
• Battery charge level
• Wallbox includes LED Gate Status Output and reliable
Anti-tamper indication
• Fuse blown
Half day
• High current draw
Full day
• High push force to handle large gates and offer greater
reliability in high-wind conditions
• Robust and durable construction extends operating life of the
system
Operations in standby with 7Ah battery 5
• Details of the last transmitter activated
Maximum leaf width for corresponding gate mass
• Health of the drive electronics
Collision sensing
• Currently activated gate inputs
• See Diagnostics Made Easy for further details
• Full position control obviates the need for endstops and
makes the system quick and easy to install
• In-line design for improved aesthetic appeal
Electronic Features
• Onboard gate lock relay – can be configured to provide
either a normally-open or normally-closed output, AC or DC
• Safe anti-crushing protection for greater safety – keep your
children, pets and vehicles out of harm’s way
• Quadra-drive technology – Soft Start and Stop and gate
speed is adjustable in both directions
Key release
Duty cycle - mains present 3,4
• Linear actuator system for quick and easy installation
• Revolutionary centrifugal brake – ensures secure braking
<17 sec
Manual override
• Battery-low
SWING GATE
OPERATORS
VECTOR2
Linear Swing Gate Operators
• Multiple operating features including Intruder-detection
Alarms (a world first)
• Onboard CentSys code-hopping multichannel receiver with
selective add and delete - operate a multitude of functions;
for e.g. operate gate, switch on Pillar Light, Pedestrian
Opening, etc.
70
58
2m - 500kg
4m - 200kg
Electronic
Controller solenoid output rating
2A DC
Operator temperature range
-15°C to + 50°C
Receiver frequency
433MHz
Receiver code storage capacity
64 transmitter buttons
Degree of protection
IP54
Mass of unit packed (excluding battery)
Single kit
8.5kg
9kg
Double kit
14kg
15kg
Width: 1075mm x Depth: 127mm
x Height: 120mm
Width: 1283mm x Depth: 127mm
x Height: 120mm
Packaging dimensions
1. Can operate off a solar supply, consult Centurion Systems (Pty) Ltd for
assistance
2. Can increase battery capacity for longer standby times
• LCD interface for exceptionally easy setup
2m - 750kg
4m - 310kg
3. Based on 25°C ambient temperature and unit not in direct sunlight
4. Based on an operator push force of less than 50% of rated
7. Assumes full stroke of operator is used
8. CP84SM only
D.Domestic
L.Light-industrial
5. Based on double kit excluding infrared Photocells
6. Assumes a 90° opening gate and optimum mounting position
TM
www.CentSys.com.au
linear
sWING GATE
operators
page 41
SWING GATE
OPERATORS
9
4
9
5
1
7
2
5
8
6
3
10
Cabling Requirements
1.
90V / 220V - 240V AC mains cable via mains isolator switch 1(3 core LNE 0,5mm²) 2, or low-voltage 16V AC battery charger supply
(2 core 1,5mm²)
2.
Master Motor (MTR M) or Slave Motor (MTR S) cable (minimum, 2 core 2mm2 + 4 core 0,5mm² multi-stranded) see note
4
6
Optional Wiring (all cable is multi-stranded):
+ 6 core
0.5mm² multi-stranded) or cable from control box to entry panel
3.
Intercom, cable from control box to dwelling (n1
(n2 7 0.5mm² multi-stranded)
4.
Radio receiver cable (3 core 0,5mm2 multi-stranded, optional)
5.
Pedestrian Keyswitch (2 core 0,5mm2 multi-stranded) or optional keypad (3 core 0,5mm2 multi-stranded)
6.
Infrared Photocells or safety edge (3 core 0,5mm2 multi-stranded or 4 core 0.5mm² for CE compliance)
7.
Intercom cable (n2 + 2 core 0,5mm² multi-stranded) to gate station
8.
Electric lock (2 core 1.5mm²)
9.
Pillar Light cable (3 core, size according to power regulations)
7
4
5
10. Inductive loop detector for free-exit (1 core 0.5mm2 multi-stranded - silicone-coated)
1. Mains isolator must be fitted less than 1m from controller
2. Increase cable thickness if Pillar Lights are to be installed
3. Screened cable is always recommended to provide better protection against lightning earth one end of screening
5. For optimum range an external receiver can be mounted on the wall
6. CentSys has available custom VECTOR2 cable order reference: CABLEVEC68
7. Number of cores required by the intercom
4. Domestic charger only
VECTOR2 400: 1400mm extended
VECTOR2 500: 1600mm extended
VECTOR2 400: 400mm stroke
VECTOR2 500: 500mm stroke
95mm
VECTOR2 400: 1000mm retracted
VECTOR2 500: 1100mm retracted
100mm
www.CentSys.com.au
page 43
Technical Specifications
Various kit combinations available - refer to Price List
Technical Data
These robust rotary swing gate operators allow for fast, smooth and quiet operation of the gate.
Mounted separately on a pedestal, the R3 and R5 operators are ideal for gate installations with wide pillars. Besides offering very
safe anti-crushing, the operators support a host of very useful functions for looking after the gate entrance.
R3 Domestic
Input voltage 1
Motor voltage
12V DC
Motor power supply
Battery-driven (standard capacity - 12V 7Ah) 5
Battery charger
• Diagnostic LEDs for easy programming
• Battery backup
• Dedicated Pillar Light Relay
• Rotary arm system – ensures smooth and exceptionally
reliable operation
• The following onboard inputs and outputs are provided:
Electronic Features
• Multiple programmable features – to suit a wide variety of
applications
• Master motor with integrated controller and charger
simplifies the installation
6A
Operator output torque - maximum
95Nm
250Nm
Typical gate opening time (90o)
11 sec
17 sec
Allen key under locked cover with key release
Maximum numbers of operations per day
150
250
Duty cycle – mains present 3,4
20%
50%
Half day
81
34
Full day
64
27
Operations in standby with 7Ah battery 2
Mechanical Features
• Whisper-quiet operation – totally unobtrusive operation
170mA
4A
Manual override
Main Features
• Fast operation – for optimum security and convenience
CP84SM - 2A @ 13.8V 5
60mA
Current consumption (motor at rated load)
R3: The logical choice for domestic gates with large pillars
R5:
This unit is well-suited for large domestic and light-industrial swing gates
• Both wall- and pedestal-mount configurations for greater
flexibility of installations
CP84E – 800mA @ 13.8V
Current consumption (mains)
Models Available
R5 Light-industrial
90V 4 / 220V - 240V AC ± 10%, 50Hz
SWING GATE
OPERATORS
R3 and R5
Rotary Swing Gate Operators
Operations in standby with 40Ah battery 2
Half day
150 6
226
Full day
150 6
219
• Free-exit input
Collision sensing
• Trigger input
Operating temperature range
Electronic
-15°C to +50°C
Receiver type
• Solenoid lock connection
• 12V DC output for auxiliary devices such as external
receivers, gate Photocells, etc.
• Input for infrared Photocells
External
Mass of unit packed (Master - kit with PC Board
and charger, but excluding battery)
Maximum leaf width for corresponding
gate mass
Packaging dimensions (Master - kit with PC Board
and charger, but excluding battery)
• Pedestrian Opening input
• Dedicated Holiday Lockout input
• Fuse-protected
1. Can operate off a solar supply, consult Centurion Systems (Pty) Ltd for
assistance
2. Based on 4m gate, excluding infrared Photocells
• Adjustable Autoclose timer – gate is never left open
unnecessarily
3. Based on 25˚C ambient temperature and unit not in direct sunlight
10.01kg
10.5kg
2m - 350kg
2m - 600kg
3.5m - 350kg
3.5m - 260kg
Width: 370mm x Depth: 260mm x Height: 320mm
4. CP84SM2A only
5. Can increase battery capacity to 40Ah for longer standby times
6. Limited by number of maximum operations per day
TM
TM
R3
www.CentSys.com.au
R5
ROTARY
SWING GATE
operators
page 45
SWING GATE
OPERATORS
9
9
6
8
1
3
2
5
7
11
4
2
10
Cabling Requirements
1.
220V - 240V AC mains cable via double pole mains isolator switch (3 core LNE 1.5mm2 1 SWA
transformer (34V secondary @ 800mA) to battery charger (2 core + earth 1.5mm² Norsk)
2.
Master Motor (MTR M) or Slave Motor (MTR S) cable (minimum, 3 core 2.5mm2 + 3 core 0,5mm² multi-stranded)
2
) or low-voltage cable from
Optional Wiring (all cable is multi-stranded):
+ 6 core
0.5mm² multi-stranded) or cable from control box to entry panel
3.
Intercom, cable from control box to dwelling (n1
(n2 6 0.5mm² multi-stranded)
4.
Infrared Photocells (3 core 0.5mm² multi-stranded)
5.
Access control device (3 core 0.5mm² multi-stranded 4)
6.
Pedestrian Keyswitch (2 core 0.5mm² multi-stranded) or
7.
Keypad (3 core 0.5mm² multi-stranded)
8.
External radio receiver (3 core 0.5mm² multi-stranded 5)
9.
Pillar Lights (3 core LNE SWA 2, size according to power requirements)
6
3
10. Ground loop for free-exit (1 core 0.5mm² multi-stranded - silicone-coated)
11. Electric lock (2 core 1.5mm²)
1. Possibly increase cable thickness if Pillar Lights are to be installed
4. Number of cores and type of cable could vary depending on the brand of access
control system being used
2. SWA - steel wire armoured type of cable must adhere to municipal bylaws and
preferably be screened. Screening provides better protection against lightning earth one end of the screening
5. For optimum range an external radio receiver can be mounted on the wall
6. Number of cores required by the intercom
3. Allows for all features such as Pedestrian Opening, Status LED, etc. to be
operated from the intercom handset inside the dwelling
100mm
220mm
110mm
220mm
234mm
110mm
237mm
337mm
www.CentSys.com.au
page 47
Technical Specifications
Product Code: BEN9591457 / BEN9150039
Technical Data
IT24N
A powerful underground swing gate operator for discerning home owners that do not want to see an operator moving their gates,
the IT24N provides reliable swing gate automation for gates up to 3.5 metres wide without impacting the aesthetic appeal of the
gate. These operators are also ideal for operating gates with limited or sidewall space.
Input voltage 1
Suitable for domestic and light-industrial applications providing safe, quiet and reliable operation.
Operator output torque
360Nm
Gate opening time – typical 3
<20 sec
Duty cycle – mains present 4
50%
Main Features
Motor voltage
Motor power supply 2
Daily operations – maximum
Operating temperature
Mechanical Features
• Hidden from view for greater aesthetic appeal
• Battery backup
• Extremely potent and reliable motor reduction unit for
smooth and dependable operation
Electronic Features
• Multiple operating features – to suit a wide variety of
applications
• Proven lightning protection for greater reliability
• High immunity to noise – not affected by external
interference
• Micro controller platform allows customisation – improved
versatility
• Trigger input with local test button – useful for testing the
operation of the device when a transmitter is not available
• Pedestrian Opening input - prevents unauthorised vehicle
access
• Photocell input – connecting infrared Photocell dramatically
increases the safety of the automated system
• Free-exit input (only opens gate) – ideal for fitting free-exit
ground loops or pushbuttons in townhouse complexes and
high-volume vehicle access applications
• Holiday Lockout input – ensures that gate cannot be opened
when home owners are away
• Timed potential-free contact (e.g. Courtesy Lights)
• Low-voltage switching of potential-free contact
Maximum leaf width for corresponding gate mass
Allowable wind loading – 100% coverage
Degree of protection
Boxed shipping weight
(operator and foundation plate)
Dimensions
220V - 240V AC ± 10%, 50Hz
24V DC
Battery-driven 500mA charger
SWING GATE
OPERATORS
IT24N
Underground Swing Gate Operator
200
-15°C to +50°C
2m – 550kg
3.5m – 400kg
2m – 45km/h
3.5m – 25km/h
IP67
20.5kg
Width: 350mm x Depth: 200mm x Height: 133mm
1. Can operate off a solar supply, consult Centurion Systems (Pty) Ltd for
assistance
2. Battery-driven with two x 7Ah batteries (can be upgraded for longer power
failure autonomy)
3. Assumes a 90° opening gate
4. Based on 25˚C ambient temperature and unit not in direct sunlight
• Selectable/adjustable Autoclose timer (5 – 45 seconds)
• Override of Autoclose timer via trigger input
• Local diagnostic LEDs for easy programming
• Available in 12V and 24V DC variants
• Local and remote multi-function Gate Status LED
TM
TM
www.CentSys.com.au
Underground
SWING GATE
operator
page 49
8
9
6
1
3
3
5
7
11
4
SWING GATE
OPERATORS
9
2
10
Cabling Requirements
1.
220V - 240V AC mains cable via double pole mains isolator switch (3 core LNE 1.5mm2 1 SWA
transformer (34V secondary @ 800mA) to battery charger (2 core + earth 1.5mm² Norsk)
2.
Motor cables (2 core + earth 1.5mm², 3 core 0.5mm², multi-stranded 2)
2
) or low-voltage cable from
Optional Wiring (all cable is multi-stranded):
+ 6 core
0.5mm² multi-stranded) or cable from control box to Entry Panel
3.
Intercom cable from control box to dwelling (n1
(n2 7 0.5mm² multi-stranded)
4.
Photocells (3 core 0.5mm² multi-stranded)
5.
Access control device (3 core 0.5mm² multi-stranded 4)
6.
Pedestrian Keyswitch (2 core 0.5mm² multi-stranded) or
7.
Keypad (3 core 0.5mm² multi-stranded)
8.
External radio receiver (3 core 0.5mm² multi-stranded 5)
9.
Pillar Lights (3 core LNE SWA 2, size according to power requirements)
7
3
10. Inductive loop detector for free-exit (1 core 0.5mm² multi-stranded - silicone-coated 7)
11. Electric lock (2 core 1.5mm²)
1. Possibly increase cable thickness if Pillar Lights are to be installed
5. For optimum range an external radio receiver can be mounted on the wall
2. SWA - steel wire armoured type of cable must adhere to municipal bylaws and
preferably be screened. Screening provides better protection against lightning - earth
one end of the screening
6. Consult manufacturer of loop detector for specific details
7. Number of cores required by the intercom
3. Allows for all features such as Pedestrian Opening, Status LED, etc. to be operated
from the intercom handset inside the dwelling
4. Number of cores and type of cable could vary depending on the brand of access
control system being used
364mm
98mm
152mm
294mm
214mm
www.CentSys.com.au
page 51
G. Pedestrian Keyswitch
Product Code: CP55K
H. POLOphone/G-SPEAK Intercom
Product Code: POLOH00WV1_AU, POLOE2G0V3_AU / GSC0K020V0_AU,
GSC1K020V0_AU
C
H
I
SWING GATE
OPERATORS
Swing Gate Operator Accessories
E
L
N
O
P
Basic key-operated switch for allowing access for
pedestrians.
J
G
M
K
F
A
D
Product Code: SOLO0001V1_AU / LATC0003V1_AU
Proximity reader for allowing access for both pedestrians
and vehicles.
Product Code: CABLEVEC
A. CentSys Photocells
Steel pole for mounting intercom gate station or access
control.
A
K. VECTOR2 Cable
Product Code: Photon wireless photocells: PHOTON1V1_AU;
i5 wired photocells: I5V3_AU
J. Gooseneck
Product Code: XGSN-60000 or XSGN-6GLV0
N
O
P
A
B
I. SOLO/LATTICE Proximity
Access Control
Allows visitors to communicate with people inside in order
to gain access to the property.
L. VECTOR2 Wallbox
Product Code: VECCAD02V5_AU
B. FLUX SA Loop Detector
Product Code: FLUXSA00V1_AU
VECTOR2 cable has been optimised for the VECTOR2
range of swing gate operators to provide reliable
operation time and time again.
A fully weatherproof wall-mounted enclosure for your
VECTOR2 operator’s electronics, providing a neat and
convenient central point of operation.
VECTOR2 Optional Mounting Accessories
Always recommended on any gate automation installation to
increase the safety of the automated system.
Allows free-exit of vehicles from the property (requires ground
loop to be fitted).
M. Gate Adaptor Kit
Product Code: VECGAK00V1
C. Solar Supply
Product Code: ESOLAR20WA/ESOLAR40WA
Alternative means of powering the system – consult
Centurion Systems (Pty) Ltd for details.
D. CentSys Transmitter
Product Code: One-button: TX1NV2433_AU; Two-button: TX2NV433_AU;
Three-button: TX3NV2433_AU; Four-button: TX4NV2433_AU
Incorporates ultra-secure code-hopping technology.
Available in one-, two-, three- and four-button variants.
This kit is used when a need arises to spread the load
absorbed by the gate bracket over a wide area of the
gate surface. The Spreader Plate can be welded between
bars or onto an existing beam. This should be used when
the gate is made of thin-section material, and is highly
recommended for all light-industrial installations.
O. High-Security Kit
Product Code: VEKHSK001V1
E. G-SWITCH-22 GSM Device
Product Code: GSWITCH0V3_AU
N. Mechano Kit
Product Code: VEKMAK00V1
The securing plates in this kit have been designed to
secure to either the standard-, or high-security wall
brackets. The position of the holes in the securing
plate ensures maximum flexibility in selecting the most
appropriate mounting point for the operator.
P. Wall Adaptor Kit
Product Code: VEKWAK00V1
F. SMARTGUARD or SMARTGUARDair
Keypad
Product Code: SK/1BLK_AU, SK/AIRBLK_AU
The High-Security Wall Bracket enables the installer
to spread the load of the cyclic repetition of the gate
opening over a wider wall area, along with providing
more static strength against attempted forced entries.
Allows for monitoring and activating the operator, via your
phone, from anywhere in the world with GSM coverage.
Cost-effective and versatile wired or wireless keypad,
allowing access for pedestrians.
www.CentSys.com.au
The Wall Adaptor Plate spreads the load of the wallbracket over four holes vertically. This kit can be used with
either the standard-, or high-security wall brackets.
The Long Security Plate enables the installer to position
the operator according to the installation tables easily
with a minimum of cutting, grinding and welding.
page 53
SWING GATE
OPERATORS
Swing Gate Operator Kits
Single VECTOR2 400 or 500 Kit
Double VECTOR2 400 or 500 Kit
Product Code: VEC4KITSLIND or VEC5KITSLIND
Product Code: VEC4KITDLIND or VEC5KITDLIND
• 1 x Operator 1
• Mounting hardware
• 1 x Controller A
• 2 x Operators 1
• Mounting hardware
• 1 x Controller A
M
M
• 1 x Wallbox (includes mains isolator and external status
LED indicator board)1 x 7Ah battery F
• 1 x Wallbox (includes mains isolator and external status
LED indicator board)1 x 7Ah battery F
•
•
•
•
•
•
•
•
•
•
1
1
1
1
2
x
x
x
x
x
2A Switch Mode charger H
7Ah battery I
LED External Indicator Board D
Onboard CentSys multichannel receiver
4 button CentSys transmitters E
1
1
1
1
2
x
x
x
x
x
2A Switch Mode charger H
7Ah battery I
LED External Indicator Board D
Onboard CentSys multichannel receiver
4 button CentSys transmitters E
Single R3/R5 Pedestal/Wall-mount Kit
Double R3/R5 Pedestal/Wall-mount Kit
Product Code: Refer to price lists
Product Code: Refer to price lists
•
•
•
•
•
•
•
•
•
•
•
•
1 x Operator 2
Mounting hardware M
1 x Charger (R3: 800mA) G
1 x Charger (R5: 2A Switch Mode)
1 x Controller B
1 x 7Ah / 33Ah battery I
H
2 x Operator 2
Mounting hardware M
1 x Charger (R3: 800mA) G
1 x Charger (R5: 2A Switch Mode)
1 x Controller B
1 x 7Ah / 33Ah battery I
H
Single IT24N kit
Double IT24N kit
Product Code: BENUG24KITS
Product Code: BENUG24KITD
• 1 x Operator (including foundation box, cover plate, and
internal linkages) 3
• 1 x Controller C
• 1 x Wallbox F
• 1 x CP24 24V charger
• 2 x 7Ah battery I
• 2 x Operators (including foundation boxes, cover plates,
and internal linkages) 3
• 1 x Controller C
• 1 x Wallbox F
• 1 x CP24 24V charger
• 2 x 7Ah battery I
1
VECTOR2
A
VECTOR2 controller
2
R3 R5
B
R3 R5 controller
3
IT24N
C
CP77 24V controller
E
CentSys
Transmitter
F
Wallbox
G
800mA
Charger
I
7Ah battery
J
33Ah battery
K
Battery
housing
L
R3 R5 Mounting
hardware
• Square tube - Pedestal-mount only
(R3: 75 x 75mm; R5: 100 x 100mm)
• Wall bracket - Wall-mount only
• Gate bracket
• Drive arm clamp with wedge (includes bolts)
• Connecting pole
• Padlock and padlock shield (optional extras)
D
VECTOR2 LED External
Indicator Board
H
2A Switch Mode
Charger
M
VECTOR2 Mounting
hardware
• Gate bracket
• Pins
• Wall bracket
images are for illustrative purposes only - refer to text
www.CentSys.com.au
page 55
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
