2016
Animal Health
EQUIPMENT CATALOG
Midmark Customer Experience
Midmark Customer Experience personnel are available
to serve your needs from 8:00 AM - 5:00 PM, Monday
through Friday (EST).
1-800-MIDMARK
Fax: 1-877-725-6495
For equipment information or order placement, contact
Customer Experience by pressing 8, then 108911.
For Casework order placement or information, contact
Casework Project Coordinators by pressing 8, then
108914. Fax: 1-800-365-2499
Midmark Technical Service
Midmark Technical Service personnel are available to
serve your needs from 8:00 AM - 5:00 PM Monday
through Friday (EST). Call 1-800-MIDMARK, press 8,
then 108925.
Better Patient Care.
Better Business.™
Midmark has the solution for taking the best care of
your patients and your bottom line. Midmark meets the
needs and opportunities of today’s veterinarians through
a combination of fully integrated product lines, superior
quality, online and in-clinic training, technical support and
client educational tools.
Anesthesia & Monitoring Products
Call 1-800-MIDMARK, press 8, then 108750.
For Dental X-ray Products
Call 1-800-MIDMARK, press 8, then 108125.
Midmark Academy
RK ACADEMY
MIDMA
Continuing Education for the
Veterinary Professional
SM
1-800-360-2186
midmarkacademy.com
RK ACADEMY
RK ACADEMY
MIDMA
MIDMA
Anesthesia
Contents
Color Coding Chart
Seating
International Color Coding
®
Tables
Maintenance Kits, Anesthesia Machine
19
Masks, Small Animal Anesthesia
16
Matrx VME2® 4
Matrx VMR®6-7
Matrx VMS®3
Matrx VMS Plus®2
Matrx® Wall Mount, Tabletop Systems
5,7
Mayo Tray Cart
14
Monitor Mounts
55
Monitoring54-56
Non-rebreathing Anesthesia Systems
6-7
Occlusion Valve
19
Prophy Angles
43
Resuscitators23
Revive-A-Pet®23
Rubber Goods
21
Scaler Tips
44
Scavengers, Veterinary Anesthetic Gas
10-11
Sterilizers & Accessories
57-58
Stools37-39
Tables, Wet/Prep/Exam, Lift Tables, Dry Exam
32-36
Ultrasonic Cleaners & Accessories
59-61
Urolithiasis Probes
44
Vaporizer Service Center
9
Vaporizers, VIP 3000®8
Ventilator, Matrx Model 3000
12
Ventilator Accessories
13
X-ray, Dental
45-50
Casework/
Carts/Cabinets
Absorber Quick Release Conversion Kit
19
Anesthesia Machines
Matrx VME2 4
Matrx VMR®7
Matrx VMS®3
Matrx VMS® Plus
2
Non-rebreathing Systems
6-7
Wall Mount, Tabletop Systems
5
Autoclaves & Accessories
57-58
Ayres Non-rebreathing System
20
Breathing Circuits
20
Burs43
Canis Major® Lift Tables
33-34
Carts28-30
Casework
24-27, 31
Chairs40
CO2 Absorbent
11
Color Chart-Casework
31
Color Chart-Chairs/Stools
40
Cylinder Mounting Blocks
14
Dental Accessories
42-44
Dental Delivery Systems
41
Dental Training Network
51
Dental X-ray
45-51
Dual Gas Supply Tee
14
Endotracheal Tubes, Sterile
17
Flowmeters, Replacement Oxygen
15
Fluid Warmer, IV
23
Hose Assemblies
22
Induction Chambers, Small Animal
16
Laryngoscope Blades and Handles
18
Laryngoscope Blade Kits, Disposable
18
Lift Tables
33-34
Lights52-53
®
64
Warranty Information
62-63
Dental
Ordering Information
Lighting
Matrx Veterinary Anesthesia Machines are manufactured in the United
States for a variety of countries according to several domestic and
international gas color coding standards. All products pictured in this
catalog are of standard ANSI (USA) color coding with the appropriate
part numbers of your country or ISO standard listed for your
convenience. All products shipped will be manufactured according to
the part number specified at the time of purchase.
CountryN2OO2
United States/Japan
Canada
Standard ISO
Blue
Green
BlueWhite
Blue
White
Instrument
Processing
Pricing and product availability in this catalog supersede information in all other catalogs. Products and prices are subject to change or discontinuation
without prior notice. Midmark prices that are in effect when your order is received will be honored even if the items are temporarily out of stock.
Monitoring
®
Small Animal Anesthesia Machines
Matrx VMS® Plus
The Matrx VMS® Plus provides more functionality with two
shelves for convenient placement of monitors and equipment.
Its dual vaporizer mounting capability allows you to easily switch
from one vaporizer to another.
•
Includes occlusion valve and starter pack of Sodasorb® LF
•
Dual view oxygen flowmeter—glass tube with a scale reading from 0.2 to 4 LPM—quickly switch from standard
to magnified view at the touch of a finger
•
Easy-to-view inhalation/exhalation valves allow easy
monitoring of respiration for patient safety
•
Automatic air intake valve—opens to provide room air to
patient if contents of breathing bag are depleted
•
Oxygen flush
•
1500 cc CO2 absorber with “Quick Release” lever
feature for easy absorbent replacement (accepts
prepack canisters or 1350 gm loose absorbent)
5YEAR
WARRANTY
•
Dome-type inhalation and exhalation valves – no tools needed to disassemble
•
Scavenging/adjustable pressure limiting valve
•
-60 to +60 cm H2O pressure gauge
•
15 mm and 22 mm diameter corrugated breathing circuits
•
One and two liter breathing bags
•
Chrome portable stand with 5-leg spider base and casters
•
Convenient monitor shelves
•
Accepts Matrx VIP 3000® and TEC 3 vaporizers
(one mounting kit included)
•
Dual vaporizer mount capability
•
Oxygen low-flow flowmeter add-on capability
91800081 Matrx VMS Plus (USA)$3,205.00
91800075 Matrx VMS® Plus (ISO/Canadian)
®
Top Shelf 22 1/2" W x 6 1/2" D
Bottom Shelf 22 1/2" W x 13" D
91800709 Low Flow O2 Kit (USA)$862.00
91800707 Low Flow O2 Kit (ISO/Canadian)$862.00
91800129 IV Holder Kit$164.00
91305187 Mounting Kit for second Vaporizer$37.00
ACCESSORIES
91800129
®
Note: For Matrx VIP 3000 Vaporizers, turn to page 8.
For cylinder mount blocks, turn to page 14.
2
ISO 9001:2008
FM 538523
91800081
Anesthesia
Matrx VMS®
The Matrx VMS Small Animal Anesthesia Machine is a long-time
favorite of veterinary professionals. It is designed for safe, simple
and controllable small animal inhalation anesthesia. Optional
shelves available.
®
•
Includes occlusion valve and starter pack of Sodasorb® LF
•Dual view oxygen flowmeter—glass tube with a scale
reading from 0.2 to 4 LPM—quickly switch from standard to
magnified view
•Easy-to-view inhalation/exhalation valves allow easy
monitoring of respiration for patient safety
•Automatic air intake valve—opens to provide room air to
patient if contents of breathing bag are depleted
•Oxygen flush
5YEAR
WARRANTY
•1500 cc CO2 absorber with “Quick Release” lever feature for
easy absorbent replacement (accepts prepack canisters or
1350 gm loose absorbent)
•Dome-type inhalation and exhalation valves—no tools
needed to disassemble
•Scavenging/adjustable pressure limiting valve
•-60 to +60 cm H2O pressure gauge
•15 mm and 22 mm diameter corrugated breathing circuits
•One- and two-liter breathing bags
•Chrome portable stand with 5-leg spider base and casters
•Accepts Matrx VIP 3000 and TEC 3 vaporizers
(mounting kit included)
®
•Oxygen low-flow flowmeter add-on capability
91800003
91800003 91800070 91800042 20232800
Matrx VMS® (USA)$2,955.00
Matrx VMS® (ISO/Canadian)
Matrx VMS® Wall Mount (USA)
Matrx VMS® Canis Major® Mount
$2,955.00
(swing arm included)
40165601
Swing Arm Mount for VMS®
to Canis Major® Wet Table
$525.00
91800709 Low Flow O2 Kit (USA)$862.00
91800138 Quick Release Conversion Kit$175.00
93305007 Post Mount Assembly$305.00
91805140
91805141
(for adding 2nd vaporizer)
91800167 VMS® to VMS® Plus Conversion Kit$820.00
91805140 Tray Shelf for Matrx VMS®$279.00
91805141 Ventilator Shelf for Matrx VMS®$422.00
91805146 Mayo Tray (1)$60.00
ACCESSORIES
®
20232800
(Table not included)
Note: For Matrx VIP 3000 Vaporizers, turn to page 8.
For cylinder mount blocks, turn to page 14.
ISO 9001:2008
FM 538523
3
Matrx VME2®
The Matrx VME2® places all your anesthesia equipment on
one sleek, compact post. Optional add-on components allow
you to add shelves, second flowmeter, second vaporizer,
occlusion valve with safety relief and/or an emergency air
intake valve.
•Dual view oxygen flowmeter—glass tube with a scale reading from 0.2 to 4LPM—quickly switch from standard to magnified view at the touch of a finger
5YEAR
•Easy-to-view inhalation/exhalation valves allow easy monitoring of respiration for patient safety
WARRANTY
•Oxygen flush
•1100 cc CO2 absorber and starter pack of Sodasorb® LF
•Dome-type inhalation and exhalation valves—no tools needed to disassemble
• Scavenging/adjustable pressure limiting valve
• -60 to +60 cm H2O pressure gauge
•
15 mm and 22 mm diameter corrugated breathing circuits
• One- and two-liter breathing bags
• Portable stand with 5-leg spider base and casters
91805111
• Convenient accessory shelf
• Accepts Matrx VIP 3000® and TEC 3 vaporizers
(single mounting kit included)
91805111 Matrx VME2® (USA)$2,158.00
91805112 Matrx VME2® (ISO/Canadian)
20232900 Matrx VME2® Canis Major® Mount
$2,158.00
(swing arm included)
40165602
Swing Arm Mount for VME2®
to Canis Major® Wet Table
$525.00
91805142
91805143
91805144
93805114
91805117
91805118
91805121
20232900
(Table not included)
93805114 Occlusion Valve $145.00
91805117 Dual Flowmeter Mount Kit$185.00
91805118 Dual Vaporizer Mount Kit$349.00
91805121 Emergency Air Intake
Valve and Dome Kit
$182.00
91805142 Matrx VME2® Tray Shelf$310.00
91805143 Matrx VME2® Ventilator Shelf$317.00
91805144 Slot Shelf$180.00
91805146 Mayo Tray (1)$60.00
ACCESSORIES
®
Note: For Matrx VIP 3000 Vaporizers, turn to page 8.
For cylinder mount blocks, turn to page 14.
4
ISO 9001:2008
FM 538523
Anesthesia
Wall/Tabletop Systems
5
YEAR
WARRANTY
Matrx VMS® Wall Mount
Our most popular anesthesia machine is available in a wall
mount configuration.
•
Includes occlusion valve and starter pack of Sodasorb® LF
•
Simple to install
•
Small surface area design
•
Pivot arm rotates 130 degrees and extends to 8" from wall
•
Accepts Matrx VIP 3000® or TEC 3 vaporizers
(mounting kit included)
91800042 Matrx VMS® Wall Mount (USA)$2,955.00
91800166 Matrx VMS® Wall Mount (ISO)
91800709 Low Flow O2 Kit (USA)$862.00
91800186 Vaporizer Wall Mount Kit (USA)$299.00
(for adding 2nd vaporizer)
ACCESSORIES
®
Note: For Matrx VIP 3000 Vaporizers, turn to page 8.
91800042
(Vaporizer sold separately)
5
Matrx VME2® Tabletop/Wall Mount System
YEAR
WARRANTY
Flexibility and performance at a low price.
•
Light weight – 16 lb
•
Compact design: 18 1/8" x 16 1/4" x 7 1/2" (HxWxD)
•
Convenient carry handle with soft vinyl grip
•
Accepts VIP 3000® or TEC 3 vaporizers (mounting kit included)
•
0.2 to 4 LPM dual view oxygen flowmeter with standard and
magnified views
•
1100 cc CO2 absorber and starter pack of Sodasorb® LF
•
Rubber foot pads help prevent scratching of countertop
•
Breathing circuit package included
•
Optional wall mount kit is available
•
Low flow model replaces the 0.2 to 4 LPM flowmeter
with a 0-1000 cc oxygen flowmeter
91800094 Matrx VME2® Tabletop$2,293.00
91800121 Matrx VME2® Tabletop (ISO/Canadian)
91800220 Low Flow Matrx VME2® Tabletop (USA)$2,293.00
91800266 Low Flow Matrx VME2® Tabletop (ISO/Canadian)
91800103 Optional Wall Mount Kit$168.00
91800094
(Vaporizer sold separately)
93805114 Occlusion Valve$145.00
ACCESSORIES
®
Note: For Matrx VIP 3000 Vaporizers, turn to page 8.
ISO 9001:2008
FM 538523
5
Non-rebreathing Anesthetic Delivery Systems
Matrx VMR® Low-flow
Non-rebreathing Systems
Designed for safe, simple and controllable inhalation anesthesia
for rats, small rodents, exotics and patients weighing less than
5 lb (2.27 kg). The Matrx VMR® provides rapid control of
anesthetic depth with little resistance to respiration.
• Non-rebreathing anesthetic delivery system
5YEAR
WARRANTY
•
Dual-view oxygen flowmeter—glass tube with a scale that
reads from 0-1000 cc/min—quickly switch from standard to
magnified view at the touch of a finger
•
Includes Isoflurane or Sevoflurane Matrx VIP 3000®
vaporizer, well-fill or key-fill style
•
Tabletop models feature a built-in handle and rubber feet
•
Standard flow (.2-4 LPM) and Wall Mount models also
available
Matrx VMR w/Isoflurane Well-Fill Vaporizer
®
91800218 91800236 (USA)$2,525.00
(ISO/Canadian)
Matrx VMR w/Isoflurane Key-Fill Vaporizer
®
91800219 (USA)$2,810.00
91800237 (ISO/Canadian)
Matrx VMR w/Sevoflurane Well-Fill Vaporizer
®
91800218
91800261 (USA)$2,525.00
91800262 (ISO/Canadian)
Matrx VMR Wall Mount
®
91800223 Matrx VMR® Wall Mount
with Isoflurane Well-Fill Vaporizer (USA)$2,525.00
91800224 Matrx VMR® Wall Mount
with Isoflurane Key-Fill Vaporizer (USA)$2,810.00
6
Anesthesia
Matrx VMR® Low-flow Tabletop
Non-rebreathing System
91805060 Matrx VMR® Tabletop with Isoflurane Well-Fill Vaporizer (USA)
$2,525.00
91805061 Matrx VMR® Tabletop with Sevoflurane Well-Fill Vaporizer (USA)
$2,525.00
94805059 Matrx VMR® Tabletop Assembly (USA)$1,261.00
91806300 Matrx VMR® Tabletop (ISO)
$1,261.00
O2 Flowmeter Assembly for VMR
®
92805097 (USA)$723.00
91805098 (ISO/Canadian)
91805100 .2-4 LPM Add-on Kit (USA)$928.00
ACCESSORIES
Note: For cylinder mount blocks, turn to page 14.
91805060
ISO 9001:2008
FM 538523
7
Vaporizers
Matrx VIP 3000® Vaporizer
5YEAR
The choice of veterinary professionals for accurate anesthesia
delivery under all conditions, the Matrx VIP 3000® Veterinary
Vaporizer uses proven design principles to ensure output
concentration is virtually unaffected by flow rate, temperature
variations, duration of use, liquid level or back pressure fluctuation
within its clinical range.
•
Automatic flow rate and temperature compensation
•
Large, easy-to-read dial
•
Integrated safety lock to prevent unintentional engagement
•
Large sight glass for at-a-glance liquid level monitoring
•
Choice of agent-specific models for Isoflurane or Sevoflurane
91305430 Isoflurane VIP 3000® – Well-Fill
$1,380.00
For use with Isoflurane. 0.5% – 5.0% at 1/2% intervals.
WARRANTY
91305430
91305507
91305418
91305418 Isoflurane VIP 3000® – Key-Fill$1,650.00
For use with Isoflurane. 0.5% – 5.0% at 1/2% intervals.
Includes Key-fill Adapter 91305421
91305507 Sevoflurane VIP 3000® – Well-Fill$1,380.00
For use with Sevoflurane. 0.25% – 8.0% at 1% intervals.
40140201 Sevoflurane VIP 3000® – Key-Fill$1,650.00
For use with Sevoflurane. 0.25% – 8.0% at 1% intervals.
Includes Key-fill Adapter 10566000
Vaporizer mounting hardware is included with
each Matrx® anesthesia machine.
Easy-to-Read Detent Dial
Simple-to-Use Fill Port
MOUNTING KITS
002-1844-00 For Matrx VMS®/VMC/VML®$58.00
91305187 For Matrx VME®/VMS® Plus/VME2®$37.00
93305007 Post Mount Assembly$305.00
C
®
(For adding 2nd vaporizer to Matrx VMS )
D
B
ACCESSORIES
91305421 (A) Isoflurane Key-Fill Adapter$265.00
A
10566000 (B) Sevoflurane Key-Fill Adapter$265.00
92305072 (C) FS-2A Inlet Tubing Adapter$48.00
92305073 (D) FS-2 Outlet Tubing Adapter$46.00
91315075 7/16" OD x 1/4" ID Hose$1.00/in.
91800186
Vaporizer Wall Mount$299.00
ISO 9001:2008
FM 538523
8
Anesthesia
Vaporizer Service
Factory Service for Accurate, Reliable Operation
To assure continued accuracy and reliability, every Matrx VIP 3000® and TEC 3
vaporizer should be serviced and calibrated annually. Service includes:
•
Complete disassembly and cleaning
•
Ultrasonic bath to clean internal metal parts
•
Calibration and adjustment of Thermo Control
•
Reassembly with new seals and wick*
•
Cleaning/polishing of exterior parts
Vaporizers ARE NOT field serviceable. Disassembly or
service by anyone other than an authorized Factory Service
Technician may result in damage or subsequent unsafe
operation of the vaporizer.
* If additional parts are required, you will be contacted with an estimate.
Our Vaporizer Service Center is staffed with highly qualified service
technicians using state-of-the-art equipment. The Matrx VIP 3000
Vaporizer is a sophisticated device and under no circumstance should
be tampered with or disassembled by anyone other than an authorized
vaporizer service technician. These units ARE NOT field serviceable.
®
Matrx VXP Vaporizer
Exchange Program
TM
1YEAR
WARRANTY
Simple, convenient and effective
If your vaporizer has been manufactured or serviced in
the last 5 years, contact your dealer and request a Matrx
VXP™ vaporizer. You will receive a TEC 3 type
vaporizer for the agent you specify (Isoflurane or
Sevoflurane). Simply exchange your TEC 3 vaporizer
with the Matrx VXP™ vaporizer and return it to the
Midmark Vaporizer Service Center in the shipping
carton in which you received your Matrx VXP™ unit.
When you receive your Matrx VXP™ vaporizer, mount
it on your machine and you’re ready to go. Enjoy no
down time and the confidence of a cleaned, calibrated
and tested vaporizer.
The Matrx VXP™ Vaporizer you receive has undergone
the complete Midmark Vaporizer Service Center protocol.
Service
For complete details on vaporizers requiring service or
availabiliy of rental vaporizers, contact your local
veterinary dealer.
Midmark Corporation
Vaporizer Service Center
Plant B, St. Rt. 47 West, Versailles, OH 45380 USA
1-800-MIDMARK, ext. 108911
For vaporizer service outside the United States and Canada,
please contact the Midmark Vaporizer Service Center.
R/R-ISO VAP Isoflurane Vaporizer Service $453.00
R/R-SEVO VAP Sevoflurane Vaporizer Service $453.00
91305535 Isoflurane VXP™ Well-fill Vaporizer$453.00
91305534 Isoflurane VXP™ Key-fill Vaporizer$453.00
91305537 Sevoflurane VXP™ Well-fill Vaporizer$453.00
10601700 Sevoflurane VXP™ Key-fill Vaporizer$453.00
9
Scavengers/CO2 Absorbent
Matrx® Veterinary Anesthetic
Gas Scavenger
The Matrx® Veterinary Anesthetic Gas Scavenger offers reliable
active scavenging of waste anesthetic gas. It is designed to
meet current ASTM and ANSI standards and is available in a
post mount or wall mount configuration. Each wall or post
mount scavenger unit will scavenge the waste anesthetic gas
from one anesthesia machine.
Portable—post mount scavenger comes complete with 20 ft.
(6 m) of 32 mm tubing, 5 ft. (1.5 m) of 19 mm tubing and post
mount hardware.
Wall mount scavenger comes complete with 2 ft. (.6 m) of
32 mm tubing, 18 ft. (5.5 m) of 19 mm tubing and wall
mount hardware.
•
Designed to meet current ASTM and ANSI standards
•
Available in post mount or wall mount configurations
•
Quiet operation
•
Can be used with a ventilator or oxygenator
•
Easy to install, compact design with few parts
•
Standard 19 mm inlet connection
•
Power on/off switch with indicator light
•
Low voltage (12V DC) operation
Portable-Post Mount 91515178
91515178 Post Mount Veterinary Scavenger (1.75" diameter fittings will fit most
stand mounted anesthesia machines)
$999.00
91515181 Post Mount Veterinary Scavenger
(Euro-230V/50Hz)
$999.00
91515179 Wall Mount Veterinary Scavenger$999.00
91515182 Wall Mount Veterinary Scavenger (Euro-230V/50Hz)
$999.00
91515169 Post Mount Replacement Tubing Kit$182.00
91515170 Wall Mount Replacement Tubing Kit$77.00
65939600 Scavenging Hose, Magenta, 19 mm ID
(Please order in 12" increments)
$.25/in.
65939700 Scavenging Hose, Magenta, 32 mm ID $1.00/in.
Scavenger Interface
94805173 Scavenger Interface Without Mount
$1,140.00
94805172 Scavenger Interface Column Mount
$1,140.00
94805171 Scavenger Interface Wall Mount
24" VAC Quick Connect
$1,375.00
94805170 Scavenger Interface Wall Mount
24" VAC DISS
$1,375.00
10
Wall Mount 91515179
Anesthesia
Matrx® Central Scavenger
Keep your mind free to focus on caring for your patients,
not on scavenging excess anesthetic gas. The Matrx® Central
Scavenger safely removes waste gas from your clinic without
the cost or hassle of charcoal canister replacement.
40162800
•
Replace charcoal canisters forever with an active gas
scavenging system that quietly and consistently keeps
you safe
•
Scavenge waste gas from up to 4 anesthesia machines
•
Easily expand the system to cover up to 12 anesthesia
machines without significant expense
•
Keep your clinic neat and tidy without bulky interface
devices attached to the anesthesia machines
•
Simple installation process and flexible design ensures your
scavenging system will be successfully installed
•
Unparalleled service and support to give you peace of mind
40162800 Matrx® Central Scavenger
$2,000.00
(for up to four anesthesia machines)
20236000 Expansion Kit $432.00
(for up to four additional anesthesia machines)
Sodasorb® CO2 Absorbent
The
next generation of CO2 absorbent with safety you can see,
Sodasorb® LF is reliable, safe and user friendly. It's specifically
formulated to safely absorb CO2 while inhibiting the production
of compound A, carbon monoxide and heat from desiccation.
Unlike traditional absorbents, the Sodasorb® LF color change is
permanent once exhausted and it does not revert back to its
original color.
•
Unique, pellet shape reduces caustic dust making for
cleaner equipment and faster change-outs
•
Minimal resistance to gas flow
•
May be used in conjunction with all commonly utilized
anesthetic agents including Isoflurane, Sevoflurane,
Desflurane, Enflurane and Halothane
•
Proven safety record ensures the comfort and well-being of
both patients and staff
•Sodasorb® LF is available in convenient pre-pak cartridges,
canister-pak bags and jugs; standard Sodasorb® is avalable in
pre-pak cartridges, canister-pak bags and five gallon pails.
002-1761-00Sodasorb® LF Canister-pak Bag, Case of 12$119.00
002-1763-00Sodasorb® LF Pre-pak Cartridge, Case of 12$162.00
002-1762-00 Standard Sodasorb® Canister-pak Bag,
Case of 12
$98.00
002-1764-00 Standard Sodasorb® Pre-pak Cartridge,
Case of 12
$133.00
002-1765-00Standard Sodasorb® Five Gallon Pail
$98.00
002-1909-00 Sodasorb® LF Jug, Case of 3$107.00
11
Ventilators
Matrx® Model 3000 Small Animal
Anesthesia Ventilator
An electronically controlled, time-cycled, pressure-limited
ventilator, the Matrx® Model 3000 replaces the breathing
bag to provide smooth, even delivery of anesthesia. Designed
specifically for veterinary practice, the Model 3000 assures a
constant volume for each delivered breath, regardless of patient
compliance and airway resistance. Easy-to-use controls make
operation simple and convenient.
•
Replaces the breathing bag
•
Precise control of anesthetic state allows lower levels
of anesthesia for more responsive patients, more
economical operation with blood CO2, and pH levels
closer to normal
•
More economical use of supply gas (oxygen,
nitrogen or clean dry air)
•
Interchangeable bellows adapt to animals from
1 kg to 300 kg—no tools required
•
Maximum working pressure limit (MWPL)
adjustable from 10-60 cm H2O
•
Dual airway pressure alarms signal any breath
exceeding preset maximum or minimum
•
Optional low supply gas alarm signals supply
gas pressure below 35 psi
•
Adapts easily to all anesthesia circuits with
out-of-circuit vaporizers
•
Respiratory rates from 6-40 breaths per minute
at inspiratory flow rates from 0-100 LPM
•
Tidal volumes (TV) from 20-3,000 cc
•
Built-in scavenging port
91806001 Model 3000 $4,195.00
with 300-1600 ml bellows and bellows housing
Approximate Patient Weight Range 30-264 lb (14-120 kg)
91806002 Model 3000 $4,400.00
with 0-300 ml bellows, bellows housing and adapter
Approximate Patient Weight Range Up to 66 lb (30 kg)
91806003 Model 3000 $4,650.00
with1600-3000 ml bellows and bellows housing only
Approximate Patient Weight Range 154-660 lb (70-300 kg)
Note: All versions of the Matrx Model 3000 Anesthesia Ventilator
include Model 3000 controller, bellows base assembly, pressure
sensing tube and tee, driving gas tube, power cord, spare fuse and
operating manual.
®
NOTE:
For ease of installation, use an existing gas supply as
the driving gas. Please order one demand wye and
supply hose.
Demand Wye
91806022 DISS O2, Green$109.00
91806029 DISS O2, White$109.00
Supply Hose
91806031 DISS O2, FxF, 4 ft., Green$80.00
91806032 DISS O2, FxF, 4 ft., White$80.00
12
Anesthesia
Ventilator Accessories
Bellows
A
C
91806021 0-300 ml Attachment$593.00
(Includes: Bellows, Adapter and Housing)
91806026 (A) 0-300 ml Bellows$248.00
91806027 (B) 0-300 ml Bellows Adapter$151.00
B
91806028 (C) 0-300 ml Bellows Housing$314.00
91806042 300-1600 ml Bellows$269.00
91806044 300-1600 ml Bellows Housing$345.00
91806043 1600-3000 ml Bellows$356.00
91806045 1600-3000 ml Bellows Housing$464.00
F
G
D
Demand Wye
E
91806022 (D) DISS O2, Green$109.00
91806029 (E) DISS O2, White (Int’l Version)$109.00
91806023 (F) DISS O2 90°, Green$131.00
91806030 (G) DISS O2 90°, White (Int’l Version)$131.00
Supply Hose
H
91806031 (H) DISS O2, FxF, 4 ft., Green$80.00
J
K
B
91806032 (I) DISS O2, FxF, 4 ft., White (Int’l Version)$80.00
Stands
91806033 (J) 5 Leg, 42" w/Casters and Mounting Plate$332.00
I
91806034 (K) 5 Leg, 37" w/Casters and Bushing Mount$326.00
Mounting Arms/Plates
91805151 Mounting Arm w/Plate for VMC$339.00
91805152 Mounting Arm w/Plate and
Extension for VMS®$254.00
93805128 Mounting Plate$118.00
91805154 Mounting Arm$77.00
91805155 Mounting Arm Extension $108.00
91805152
L
Adapters
R
M
91806025 (L) DISS O2 90° MxF Adapter$14.00
Replacement Parts
N
P
91806038 (M) O-Ring, Base to Housing$34.00
91806039 (N) O-Ring, Bellows Adapter$24.00
91806040 (P) O-Ring, Base to Pop-Off Valve$16.00
91806041 (R) Super O Lube$47.00
91806048 Pressure Sampling Tee$54.00
91806049 Clear Corrugated Tubing 22 mm x 36" $13.00
13
Anesthesia Accessories
Cylinder Mounting Blocks
Small “E” or “D” size cylinder mounting blocks with
single-stage regulators are available to complete your portable
system. Includes high-pressure hoses and cylinder wrench.
For Matrx VMS®, Matrx VMS® Plus, Matrx
VME2® and Matrx VMC, Five-Leg Base
(Not for use on Matrx VME®)
93305369 1 Cylinder O2 (USA)$551.00
94305384 1 Cylinder O2 (ISO)
94305370 2 Cylinders O2 (USA)$719.00
94305383 2 Cylinders O2 (ISO)
93305369 for O2
94305370 for (2) O2
94305371 1 Cyl. O2 /1 Cyl. N2O (USA)$1,325.00
94305372 1 Cyl. O2 /1 Cyl. N2O (ISO)
65932200 Replacement "T" Handle$16.00
91120014 “E” or “D” Cylinder Seals, pkg. of Five
$58.00
VME® Oxygen Cylinder Restraint
77000799 Cylinder Restraint/Regulator Kit
for 1 Cylinder of O2 $470.00
91120014
Dual Gas Supply Tee
The dual gas supply tee, complete with check valves, connects
to the gas inlet on the back of the flowmeter and allows for
simultaneous hook up of the gas hose from a cylinder mounting
block and the outlet station from your central gas supply system
or large cylinders.
92315266 Oxygen$213.00
92315266
Mayo Tray Cart
91805145 Mayo Tray Cart w/2 trays $663.00
91805146 Mayo Tray (1) $60.00
91805145
14
Anesthesia
Oxygen Flowmeters
For VMS®/VMS® Plus/VME2®/VML®
Standard View
Magnified View
Scale reads from .2 to 4 LPM for the VMS®, VMS® Plus and
VME2®, and 1 to 10 LPM for the VML®. Dual view flowmeters
quickly switch from standard to magnified view at the touch of
a finger.
Matrx VMS O2 Flowmeter Assembly with Flush
®
91800206 91800207 (USA)$862.00
(ISO/Canadian)
Matrx VMS Plus/VME2 O2 Flowmeter Assy. with Flush
®
91800203 91800204 ®
(USA)$862.00
(ISO/Canadian)
Matrx VML O2 Flowmeter Assembly with Flush
®
91800254 91800255 (USA)$862.00
(ISO/Canadian)
Low Flow O2 Kit
91800709 (USA) ( 0-1000cc)$862.00
Dual Flowmeter Mount - VME2
®
91805117 $185.00
15
Small Animal Induction Chambers
An excellent addition to conventional inhalation anesthesia
procedures, the Small Animal Induction Chambers are
available in four sizes to accommodate cats, small dogs,
birds, mice and other small patients.
• Available in 45 liter, 18 liter, 5.25 liter and 1.5 liter sizes
• Constructed of .22" (5.6 mm) impact resistant acrylic
• Inlet port accepts standard 22 mm breathing tube or
15 mm connector
20220601
93800038
93805107
93805106
• Outlet port accepts standard 19 mm scavenging tube or
15 mm connector
• Sliding, self-locking top has stops to prevent unintentional
removal of lid
• Scratch-resistant feet
• Includes a hook-up kit to connect vaporizer to inlet port
20220601 45 Liter Induction Chamber$515.00
93800038 18.5 Liter Induction Chamber$335.00
93805107 5.25 Liter Induction Chamber$310.00
93805106 1.5 Liter Induction Chamber$305.00
93805139 Set of 18.5, 5.25 & 1.5 L Chambers
$675.00
93800132 Repl. 18.5 L Chamber with Cover$255.00
92800131 Inlet Port Hook Up Kit$94.00
ApproximateDimensions
Volume
45 Liter
20" L x 12" W x 12" H (51 cm x 30.5 cm x 30.5 cm)
18.5 Liter
16" L x 8" W x 10.5" H (41 cm x 20 cm x 27 cm)
5.25 Liter
11" L x 5.75" W x 7" H (28 cm x 14.5 cm x 18 cm)
1.5 Liter
7.5" L x 5.5" W x 4" H (19 cm x 14 cm x 10 cm)
Scavenger Tubing (19 mm) available on page 10.
Small Animal Anesthesia Masks
Available in sizes to fit all feline and canine patients, these
high-quality plastic masks feature a 15 mm connector, clear
cone for full visualization, and a highly flexible, replaceable
rubber diaphragm for a leak-free fit.
Masks with Diaphragm
91351400 Set of 5 Masks (1each of below)$263.00
93805027 Small Feline Mask$48.00
93805028 Medium Feline Mask$48.00
93805029 Large Feline Mask$48.00
93815026 Small Canine Mask$56.00
93815028 Large Canine Mask$56.00
Mask
Outer Dia.
Replacement Diaphragms
Small Feline
1-3/4"(44 mm)7/8"(22 mm)15/16"(24 mm)
91815014 Small Feline$31.00
Medium Feline 2-1/4"(57 mm)1-3/16"(30 mm)1-1/8"(29 mm)
91815015 Medium Feline$31.00
91815016 Large Feline$31.00
91815017 Small Canine$31.00
91815018 Large Canine$31.00
16
Inner Dia.
Cone Depth
Large Feline
2-3/8"(60 mm)1-5/16"(33 mm)1-3/8" (35 mm)
Small Canine
3-7/16"(87 mm)1-3/16"(30 mm)2-7/8"(73 mm)
Large Canine
5-1/8"(130 mm)2-1/8"(54 mm)4-3/4"(121 mm)
Anesthesia
Sterile Endotracheal Tubes
Superior cuff design helps you prepare for correct intubations
every time. The thin, large diameter cuff conforms to uneven
tracheal surfaces and maintains a proper low pressure seal.
A high-compliance cuff lies close to the tube, improving
visualization prior to inflation.
Uncuffed Endotracheal Tubes
91316526
91316527
91316528
91316529
91316530
91316531
91316532
91316533
91316534
91316535
91316536
Uncuffed
(2.0 mm)$5.00
(2.5 mm)
(3.0 mm)
(3.5 mm)
(4.0 mm)
(4.5 mm)
(5.0 mm)
(5.5 mm)
(6.0 mm)
(6.5 mm)
(7.0 mm)
Cuffed Endotracheal Tubes
91316537 91316551 91316538 91316539 91316540 91316541 91316542 91316543 91316544 91316545 91316546 91316547 91316548 91316549 91316550 (3.0 mm)$5.00
(3.5 mm)
(4.0 mm)
(4.5 mm)
(5.0 mm)
(5.5 mm)
(6.0 mm)
(6.5 mm)
(7.0 mm)
(7.5 mm)
(8.0 mm)
(8.5 mm)
(9.0 mm)
(9.5 mm)
(10.0 mm)
Cuffed
17
LED Laryngoscope Blades
93315450 93315451 93315452 93315453 93315468 93315469 93315470 93315471 93315472 Miller
(A) Macintosh Size 1 (87 mm)$90.00
(B) Macintosh Size 2 (108 mm)
(C) Macintosh Size 3 (128 mm)
(D) Macintosh Size 4 (159 mm)
(E) Miller Size 0 (75 mm)
(F) Miller Size 1 (102 mm)
(G) Miller Size 2 (155 mm)
(H) Miller Size 3 (195 mm)
(I) Miller Size 4 (205 mm)
Macintosh
I
A
H
B
G
Laryngoscope Handles and Bulbs
Designed to accept both Macintosh and Miller blades. Handles
are available in a choice of three sizes. Chrome-plated stainless
steel construction.
C
F
91315278 Standard – accepts 2 “C” size batteries$58.00
020-0354-00 Short handle – accepts 2 “AA” size batteries
$60.00
E
91315280 Large Replacement Lamps (pkg of 5)$32.00
(Macintosh 3 & 4, Miller 3 & 4)
91315281 Small Replacement Lamps (pkg of 5)$38.00
(Macintosh 1 & 2, Miller 0, 1 & 2)
Disposable LED Laryngoscope Blade Kit
System features interchangeable, disposable laryngoscope
blades with a medium reusable handle. The disposable
stainless steel blades are offered in Macintosh sizes 2, 3 and 4 as
well as Miller sizes 0,1, 2 and 3.
91315601 Disposable Blade Kit with Reusable Handle
$237.00
Disposable Laryngoscope Blades
91315602
91315603
91315604
91315605
91315606
91315607
91315608
Disposable Size 2 Macintosh Blade, each $20.00
Disposable Size 3 Macintosh Blade, each
Disposable Size 4 Macintosh Blade, each
Disposable Size 0 Miller Blade, each
Disposable Size 1 Miller Blade, each
Disposable Size 2 Miller Blade, each
Disposable Size 3 Miller Blade, each
91315601
18
D
Anesthesia
Matrx® Occlusion Valve
With Safety Relief
Instructions for Occlusion Valve with Safety Relief
P/N 93805144
Attach occlusion valve with safety relief between Matrx Dome and APL valve as shown.
The Matrx® Occlusion Valve with Safety Relief Assembly allows
you to simply and quickly close the breathing circuit to allow
you to bag (sigh) the patient.
• Easily attaches to your Matrx® anesthesia machine,
no tools required
• Constructed of long-lasting anodized aluminum
• Safety relief feature (25-30 cm H2O) prevents unsafe
pressure build-up in the anesthesia circuit/patient
• Simply operated by the push of a single silicone
activation button
Occlusion Valve with Safety Relief attaches
®
easily between the Matrx Exhalation Valve
Dome and APL Valve as shown.
• Included with each Matrx VMS® and VMS® Plus Anesthesia
Machine
93805114 Occlusion Valve with Safety Relief$145.00
Absorber Quick Release Conversion Kit
Easily convert a thumb nut version absorber to a convenient
quick release absorber. Simple flip lever locking mechanism
allows you to easily seal the absorber canister. Compatible with
anesthesia machines manufactured by Fraser Harlake, Ohmeda
and Matrx Medical.
®
91800138 Quick Release Conversion Kit$175.00
Go from a thumb nut style absorber (left), to a quick release
absorber (right).
Maintenance Kit
All the parts you need for routine anesthesia machine
maintenance in one part number—easy and affordable.
Save money versus purchasing each item separately.
91303015 Maintenance Kit
®
®
for Matrx VMS , VMS Plus, VMC$132.00
91303016 Maintenance Kit
®
for Matrx VME -Stand Mount$208.00
91303017 Maintenance Kit
®
®
for Matrx VME2 , VME -Tabletop$100.00
91303015
19
Ayres Non-rebreathing System with
Scavenger Adapter
C
D
Connects in seconds to any Matrx anesthesia machine.
Designed especially for the small animal patient with less than
15 lb (6.8 kg) body weight, it provides minimal dead space and
less resistance to flow as compared to a full-circle system.
®
E
F
A
94515185 Ayres System Complete$208.00
Replacement Parts
B
92305073 (A) FS-2 Outlet Adapter$46.00
91315075 (B) Black Rubber Tubing 7/16" OD x 1/4" ID hose
Must order 48" length
H
G
B
$1.00/in.
94515185
92315080 (C) “T” Tube Adapter$56.00
92316019 (D) Breathing Tube$56.00
92305098 (E) Bag to Tube Adapter$31.00
91800194 (F) 1L Bag with Scavenger Adapter$81.00
91305439 (G) Scavenger Adapter$56.00
91815246 (H) Tube Connector x 19 mm x 15 mm$32.00
92800173 1L Bag w/Hole, No Scav. Adapter$40.00
Breathing Circuits
Designed to maximize patient safety and user convenience.
A 360-degree connector rotation eliminates tubing twists or
kinks. Unique Z-wave tubing provides superior flexibility.
002-1705-00 22 mm Diameter$23.00
91316419 15 mm Diameter w/1 Liter Breathing Bag$29.00
91316419
Unilimb Rebreathing Circuit
Unique tube-within-a-tube design enhances performance
and convenience.
• Aids in heat and moisture retention, speeding patient
recovery time
•
Unique design reduces clutter of multiple tubes
91316417 Unilimb Rebreathing Circuit 40"$31.00
91316431 Unilimb Rebreathing Circuit 60"$32.00
91316432 Unilimb Rebreathing Circuit 72"$33.00
91316435 Pedi Unilimb Rebreathing Circuit 40"$31.00
20
91316417
002-1705-00
Anesthesia
Matrx® Veterinary Rubber Goods
C
(A) Corrugated Breathing Tubes
A
92316018 VMS®/VMC/VME® – 12" (30 cm)$50.00
92316020 VMS®/VMC/VME® – 40" (102 cm)$67.00
20221100 * VML® – 72" (183 cm)$122.00
Note: VML® breathing tube is semi-translucent,
not black rubber.
(B) Black Tubing
B
91315075 7/16" OD x 1/4" ID$1.00/in
(11 mm OD x 6 mm ID)$0.27/cm
91315076 1/2" OD x 5/16" ID$1.00/in
(13 mm OD x 8 mm ID)$0.27/cm
E
D
(C) Breathing Bags
91316047 1/2 Liter$36.00
91316041 1 Liter$36.00
91316042 2 Liter$36.00
91316043 3 Liter$36.00
91316044 4 Liter$36.00
91316045 5 Liter$36.00
93815401 15 Liter*$442.00
93815400 30 Liter*$504.00
®
* 15/30 L breathing bags and tubes for the VML have a 2" (5 cm) ID opening.
(D) Breathing Circuit Accssories
91315088 VMS®/VMC/VME® Inhaler “Y”$6.00
93815403 VML® Inhaler “Y”$374.00
10008200 VML® Inhaler “Y” Retaining Ring$113.00
(Included w/ 93815403)
(E) Straight Mask Adapter
91315091 15 mm – 22 mm$62.00
VML® Endo Tube Connectors
92805421 22 mm$67.00
92805425 25 mm
92805434 30 mm
92805435 40 mm
21
Matrx® Hose Assemblies
Quality color-coded, nylon reinforced hoses with chrome-plated
brass fittings.
Female DISS x Ohio Male QC
92305126 (O2)
92305127 (N2O)
$80.00 + $2.50/ft.
$80.00 + $2.50/ft.
O2 Hose Assembly
92305126* Female DISS x Ohio Male QC (USA)
$80.00 + $2.50/ft.
92305291* Female DISS x Ohio Male QC (ISO)
$80.00 + $2.50/ft.
92305110* Female DISS x Female DISS (USA)
$71.00 + $2.50/ft.
DISS Female x Puritan Male
92305122 (O2)
92305123 (N2O)
$179.00 + $2.50/ft.
$179.00 + $2.50/ft.
92305297* Female DISS x Female DISS (ISO)
$71.00 + $2.50/ft.
92305118* Female DISS x Ohio Female QC (USA)
$134.00 + $2.50/ft.
Vacuum Hose Assembly
92305248* Female DISS x Female DISS (USA)
$71.00 + $2.50/ft.
DISS Female x Chemetron (NCG) Male
92305120 (O2)
92305121 (N2O)
$192.00 + $2.50/ft.
$192.00 + $2.50/ft.
92305353* Female DISS x Ohio Female QC (USA)
$132.00 + $2.50/ft.
N2O Hose Assembly
92305127* Female DISS x Ohio Male QC (USA/ ISO)
$80.00 + $2.50/ft.
92305111* Female DISS x Female DISS (USA/ ISO)
$71.00 + $2.50/ft.
DISS Female x Schrader Male
92305124 (O2)
92305125 (N2O)
$137.00 + $2.50/ft.
$137.00 + $2.50/ft.
92305119* Female DISS x Ohio Female QC (USA/ ISO)
$132.00 + $2.50/ft.
DISS Female x Oxequip Male
* Specify Hose Length
Matrx hoses are custom made to order.
Please specify hose length in feet when placing your order.
®
92305205 (O2)
92305206 (N2O)
$248.00 + $2.50/ft.
$248.00 + $2.50/ft.
DISS Female x DISS Female
92305110 (O2)
92305111 (N2O)
$71.00 + $2.50/ft.
$71.00 + $2.50/ft.
DISS Female x Hand-I-Twist DISS Female
92305288 (O2)
92305289 (N2O)
22
$74.00 + $2.50/ft.
$74.00 + $2.50/ft.
Anesthesia
Resuscitation/Fluid Warming
Revive-A-Pet®
Revive-A-Pet is just what you need for emergency response
situations. Kits are available in two sizes and contain a
Disposable Resuscitator, Animal Mask Kit, Oxygen Supply
Tubing, Physiological Parameter List and Carry Case.
®
®
90000 Small Revive-A-Pet $302.00
90001 Large Revive-A-Pet $302.00
for animals weighing less than 66 lb (30kg)
®
for animals weighing more than 66 lb (30kg)
91351400 Replacement Mask Set$263.00
Includes 1 each: small feline, medium feline,
large feline, small canine and large canine mask
91150010 Oxygen Supply Tubing (7 feet)$2.00
LSP Disposable Resuscitator
Reliable, efficient ventilation with patient protection. Features
latex-free non-deforming bag, pressure relief valve on small
and X-small models, and connector for optional pressure
manometer or PEEP valve. Includes mask, oxygen supply
tubing and oxygen reservoir. Large—patients over 55 lb
(25 kg), Small—patients between 16 and 55 lb (7.3-25 kg)
and X-Small—patients less than 16 lb (7.3 kg).
91350666 Large Disposable BVM w/Bag Reservoir$44.00
91350667 Small Disposable BVM w/Bag Reservoir$44.00
91350668 X-Small Disposable BVM w/Bag Reservoir$44.00
i-Warm IV Fluid Warmer
TM
An economical fluid warmer with temperature display for
standard IV sets. Safely infuse fluids at body temperature
rather than room temperature to reduce risk of hypothermia.
•
•
•
•
•
•
•
•
•
•
•
Portable and lightweight
Convenient hanging strap to hang unit on IV pole
Current temperature displayed in Fahrenheit or Celsius
Temperature overheating protection
Indicators for warming (orange), power (green) and
overheating (red)
Reduces prep time to warm fluid
Can monitor temperature second to second
Reduces patients’ discomfort due to cold fluid
Compatible with standard IV sets
Not recommended for use with blood products
1-year warranty
VF-4 i-Warm™ IV Fluid Warmer$449.00
23
Midmark Casework
Midmark casework is the right choice for your clinic.
Whether you're remodeling or building a new clinic,
our casework not only improves clinic efficiency, it also
enhances the look of your clinic for years to come.
Midmark also offers casework design services.
Contact Casework Project Coordinators at
1-800-MIDMARK, ext. 8108914.
Veterinary Treatment Chase
Our space-saving casework chase design allows you
to have the equipment you need, where you need it,
without sacrificing floor space. Let us help you create
the most efficient, effective space possible.
24
Midmark Modular Casework is well-suited to withstand
the rigors of animal healthcare environments.
Casework/
Carts/Cabinets
• Seamless polystyrene drawers with rounded corners and
one-piece construction allow drawers to contain spills and
are easy to clean
Seamless Polystyrene Drawers
• Steel frame construction delivers long life and consistent
door and drawer performance along with a flexible shell
design to allow for changing configurations
• Hidden, German-engineered, 110-degree steel hinges give
a distinct, clean look to the casework
• Adjustable, self-cleaning ball bearing glides allow the
drawers to slide in and out smoothly every time
Steel Frame Construction
• EPA-registered* anti-microbial pulls and surfaces help
complement your current asepsis procedures.
• Seamless, polymer-covered panels provide a durable
surface that resists spilled fluids and chemicals and can be
cleaned with no surface degradation
Adjustable, Self-Cleaning
Ball Bearing Glides
Seamless Panels
Anti-microbial Pulls
and Countertops
*EPA Registration Numbers 84542-7 and 087753-CT-001
25
Exam Room Casework Solutions
Midmark Casework can be
designed especially for your
clinic by our in-house project
coordinators. We will design an
efficient exam room workflow with
your choice of how you want to
interact with your patients
and clients.
Midmark has a wide range of exam
table solutions including our popular
Canis Major Lift Table. We also offer
fixed-height island and peninsula
tables, with and without overhang,
in 48" and 60" lengths plus our new
fold down exam table.
®
See pages 34-36 for details.
26
Treatment Room Casework Solutions
Casework/
Carts/Cabinets
Create the perfect solution for your treatment
room with our wide range of optons. We can
help you design a practical, efficient space that's
specific to your needs.
Midmark casework is more
durable than wood and laminate
casework and is warmer in
aappearance than stainless
steel. Plus, Midmark Casework is
designed to integrate seamlessly
with other Midmark equipment.
27
Midmark Mobile Cabinets
Midmark mobile treatment cabinets have all of the same
safe, efficient features as our casework with the ability to
move them where you need them.
Mobile Treatment Cabinet M2
33"H x 27"W x 18"D (2) 4" Drawers & (2) Doors
• Serenity panel style w/flare handles
• Shipping Weight: 155 lb
* Shown with Kydex
contour top
®
Product Information
Step 1: Configuration
List Price
M2
Step 2. Depth
1 18" Deep
$1,415
Step 3. Option Package
A 60 mm Casters
$0
B 4" Quiet Casters
$50
C 60 mm Casters & Keyed Locks
$125
D 4" Quiet Casters & Keyed Locks
$175
Step 4. Casework Finish*
XXX Solid Color Cabinet Finish (Excludes PVC-Free)
$0
XXX Woodgrain, Metallic & PVC-free Cabinet Finish
$167
Step 5. Countertop Type
KCNKydex Contour Top
$0
®
SEB Soft Edge Bumper Top
$338
SEH Soft Edge Handle Top (29"W)
$436
Configuration Example: M21A.791.KCN
$1,415
*See page 31 for Casework Finish
Color-Specific Part Number Explanation:
M21A . 791 . KCN
Specific Model Number (M2)
28
18"
Options (60 mm Casters)
Casework Finish (Frost)
Top Surface (Kydex )
®
Casework/
Carts/Cabinets
Mobile Treatment Cabinet M4
33"H x 27"W x 18"D (3) 4" Drawers & (1) 8" Drawer
• Serenity panel style w/flare handles
• Shipping Weight: 152 lb
* Shown with soft edge
bumper top
Product Information
Step 1: Configuration
List Price
M4
Step 2. Depth
1 18" Deep
$1,623
Step 3. Option Package
A 60 mm Casters
$0
B 4" Quiet Casters
$50
C 60 mm Casters & Keyed Locks
$125
D 4" Quiet Casters & Keyed Locks
$175
Step 4. Casework Finish*
XXX Solid Color Cabinet Finish (Excludes PVC-Free)
$0
XXX Woodgrain, Metallic & PVC-free Cabinet Finish
$167
Step 5. Countertop Type
KCNKydex Contour Top
$0
®
SEB Soft Edge Bumper Top
$338
SEH Soft Edge Handle Top (29"W)
$436
Configuration Example: M41A.791.SEB
$1,961
*See page 31 for Casework Finish
Color-Specific Part Number Explanation:
M41A . 791 . SEB
Specific Model Number (M2)
18"
Options (60 mm Casters)
Casework Finish (Frost)
Top Surface (Soft Edge Bumper Top)
29
Mobile Treatment Cabinet M5
33"H x 27"W x 18"D (5) 4" Drawers
• Serenity panel style w/flare handles
• Shipping Weight: 159 lb
* Shown with soft edge
handle top
Product Information
Step 1: Configuration
List Price
M5
Step 2. Depth
1 18" Deep
$1,817
Step 3. Option Package
A 60 mm Casters
$0
B 4" Quiet Casters
$50
C 60 mm Casters & Keyed Locks
$125
D 4" Quiet Casters & Keyed Locks
$175
Step 4. Casework Finish*
XXX Solid Color Cabinet Finish (Excludes PVC-Free)
$0
XXX Woodgrain, Metallic & PVC-free Cabinet Finish
$167
Step 5. Countertop Type
KCNKydex Contour Top
$0
®
SEB Soft Edge Bumper Top
$338
SEH Soft Edge Handle Top (29"W)
$436
Configuration Example: M51A.791.SEH
$2,253
*See page 31 for Casework Finish
Color-Specific Part Number Explanation:
M51A . 791 . SEH
Specific Model Number (M2)
30
18"
Options (60 mm Casters)
Casework Finish (Frost)
Top Surface (Soft Edge Handle Top)
Casework Style Guide
Casework/
Carts/Cabinets
Panel
Styles:
*Available in Pebble Grey or
Pebble Grey PVC-free only
Transcend
Renew
Handle
Inserts:
Cove
Serenity
Pinnacle
*Renew
235 - Blueberry/Pacific Blue
230 - Moss
239 - Cashmere Blue/Sky
231 - Navy
246 - Terra Cotta/Canyon
238 - Fossil Grey
244 - Arctic
312 - Black/Raven Wing
232 - Shadow
216 - Pebble Grey
237 - Tea Green/Olivine
234 - Clay
242 - Silver Sage/Spruce
229 - Perfect Plum
233 - Dusty Blue
Handle
Styles:
Bent with
Anti-microbial
Copper
Bent
Edge
Flare
Arc
Casework
Finishes:
791 · Frost
216 · Pebble Grey 649 · Whisper
795 · Flax
798 · Path
793 · Pebble Grey
794 · Dune
796 · Nest
Metallic
Casework
Finishes:
Laminate
Countertop
Finishes:
PVC Free
490 · Fawn
805 · Pearl
Essence
800 · Radiance 799 · Sediment
797 · Hewn
804 · Venus Silver 806 · Earthen
Bronze
459 · Acorn
802 · Storm
803 · Henna
801 · Timber
487 · Earth
807 · Flat Iron
362 · Concrete Stone
443 · Kalahari Topaz
354 · Bronze Legacy
711 · Colorado Slate
447 · Mystique Marine
274 · Pebble Grey
453 · Milano Quartz
290 · Green Tigris
360 · Evening Tigris
364 · Graphite Nebula
Solid surface countertops also available. Please call 1-800-MIDMARK to request more information.
31
Midmark Treatment Tables
Wet Treatment Table
This table features a standard 36" height that easily integrates
with Midmark Casework, giving your treatment area a uniform
and aesthetically pleasing look. The table leverages our best-inclass casework designs. The wet tub is excellent for all treatment and dental procedures. The removable hair trap and easy
clean drain make maintenance a breeze.
•
•
•
•
•
•
•
•
•
•
•
Wall mount capability
18-gauge steel, more durable than wood laminates,
withstand the most rigorous clinical work
Load capacity is 300 lb
Internal modular design allows you to customize door
and drawer configurations to suit your needs
Casework features all the benefits of Midmark design
such as steel hinges, seamless drawers and adjustable
ball bearing glides
Baked-on epoxy finish means no rusting due to
water exposure
The perpendicular orientation allows for access to both long
sides
Optional goose-neck faucet and sprayer attachment makes
post procedure clean up a cinch
Available in Midmark casework colors including woodgrain
option (additional charge)
48" or 60"L x 25"W x 36"H
One end open for plumbing
WT82.R312.A (Black inserts (312) shown)
Note: One end open for plumbing unless
island configuration is specified at time of order.
Additional configurations available. Contact your
Midmark representative for details.
Tables With Faucet And Sprayer Included
Tables With Faucet And Sprayer NOT Included
WT12.RXXX.A
WT22.RXXX.A
WT32.RXXX.A
WT42.RXXX.A
WT52.RXXX.A
WT62.RXXX.A
WT72.RXXX.A
WT82.RXXX.A WT10.RXXX.A
WT20.RXXX.A
WT30.RXXX.A
WT40.RXXX.A
WT50.RXXX.A
WT60.RXXX.A
WT70.RXXX.A
WT80.RXXX.A 48" Right, 4 Drawer Renew
$3,299.00
48" Left, 4 Drawer Renew
$3,299.00
48" Right, 3 Drawer Renew
$3,007.00
48" Left, 3 Drawer Renew
$3,007.00
60" Right, 4 Drawer Renew
$3,452.00
60" Left, 4 Drawer Renew
$3,452.00
60" Right, 3 Drawer Renew
$3,152.00
60" Left, 3 Drawer Renew$3,152.00
48" Right, 4 Drawer Renew $2,657.00
48" Left, 4 Drawer Renew
$2,657.00
48" Right, 3 Drawer Renew $2,365.00
48" Left, 3 Drawer Renew
$2,365.00
60" Right, 4 Drawer Renew $2,810.00
60" Left, 4 Drawer Renew
$2,810.00
60" Right, 3 Drawer Renew $2,510.00
60" Left, 3 Drawer Renew$2,510.00
Call for pricing, colors and options.
"XXX" denotes insert color. See page 31 for chart.
ACCESSORIES
9A583000
Stainless Steel Grate Cover
48" Table$246.00
9A583001 Stainless Steel Grate Cover
60" Table$276.00
Backflow Prevention
32
002-1355-00
Backflow Preventer
(if required by local codes)
$282.00
016-1320-00
Faucet/sprayer combo with
built-in vacuum breaker
(if required by local codes)
$986.00
Canis Major® Wet
The Canis Major® Wet Dental/Treatment table is the first adjustable-height lifting wet table. It incorporates many of the design
features of our Canis Major® Exam Lift Tables with the benefit of
a shallow treatment tub and grate.
Grate Cover
Table lowers to within 9.5" of the floor and rises to 44" high
•
Load capacity is 300 lb
•
Tabletop moves independently of the back
•
Freestanding, requires no bolting to floor or wall and is
completely finished including the back
•
Extremely sturdy and well balanced
•
Convenient two piece grate with optional filler grate available
•
The completely sealed units ensure a remarkably quiet
actuator operation and require no internal maintenance
•
Perpendicular cantilever design allows for access to both
long sides so staff may sit with legs and feet directly under
the tabletop to reduce fatigue, especially when performing
ergonomically challenging dental prophys
•
An internal sensor and diaphragm pump automatically drain
the treatment tub. A unique, easily-accessible hair trap
located under the tabletop eliminates clogging
•
Includes an 8-foot, lightweight water temperature controlled
sprayer for easy cleanup
•
Fully assembled and ready for hook-up and immediate use
•
Optional, automatic weight averaging scale is accurate to
50 grams at the lowest level so it’s excellent not only for dogs
and cats but kittens, exotics and other small species too
•
115V AC, 60 Hz, 10 AMP
•
45" Model is 62"L x 30"W x 60"H
•
60" Model is 77"L x 30"W x 60"H
CMDT-45
Canis Major® Wet Table, 45"
without Scale$9,641.00
CMDT-60
Canis Major® Wet Table, 60"
without Scale
$9,641.00
CMDT-WS-45 Canis Major Wet Table, 45"
with Scale$11,480.00
®
CMDT-WS-60 Canis Major® Wet Table, 60"
with Scale$11,480.00
CMDT-GC-45 Grate Cover, 45"$248.00
Note: Shown with Canis Major Anesthesia Mount
®
®
and Matrx VMS (also available for Matrx VME2 ).
See pages 3 and 4 for pricing.
®
CMDT-GC-60 Grate Cover, 60"$248.00
002-1486-00 4" Filler Grate$175.00
33
Tables
4" Filler Grate
•
Canis Major® Dry
Canis Major Exam Lift Tables are the finest veterinary lift
devices on the market. Ask anyone who owns one.
®
•
Table lowers completely to the floor and rises to 44" high
•
Load capacity is 300 lb
•
The perpendicular orientation allows for access to both long
sides allowing you to be eye-to-eye with your client
•
Only the tabletop moves, unlike other units where the
tabletop and back move as one piece, so the Canis Major®
scale display remains at the same level no matter the
position of the table
•
Includes safety features that disable the down switches (of
which you have three, two hand toggles and a foot switch)
if anything is encountered under the table
•
Freestanding, requires no bolting to floor or wall and is
completely finished including the back
•
Extremely sturdy and well balanced
•
Includes a warm, non-skid Stat-Mat so pets have a
less-stressful experience than with slick, cold stainless
steel alone
•
Both hand and foot operated motion controls
•
Delivered fully assembled and ready for immediate use
•
Plug-and-play technology—no messy wires
•
The completely sealed units ensure a remarkably quiet
actuator operation and require no internal maintenance
•
Optional, automatic weight averaging scale is accurate
to 50 grams at the lowest level so it’s excellent not only
for dogs and cats but kittens, exotics and other small
species too
•
115V AC, 60 Hz, 10 AMP
•55-1/2"L x 25-1/2"W x 60"H
CMWO Canis Major® Dry Table without Scale$6,483.00
CMWS Canis Major® Dry Table with Scale$7,507.00
34
Prep and Exam Tables
Island Exam or Treatment Table
The Midmark Fixed Height Island Exam/Treatment Table is
perfect for your exam or treatment room. The table features
a toe-kick base panel that wraps around the entire table,
allowing you to approach your patient without obstruction.
Choose from 44" and 59" lengths, a variety of tops in
stainless steel or laminate and many door and drawer
combinations, including custom designs to meet your needs.
Wrap around toe-kick provides unobstructed access to
your patient
•
Sturdy 18-gauge steel construction with baked-on
epoxy finish gives your treatment center a long lasting,
professional and aesthetically pleasing look
IT1.RXXX.A
44” Island –Left: 3-4”Drawers,
1-8” Drawer; Right: 1-4” Drawer,
Door w/ shelf$2,268.00
IT2.RXXX.A
44” Island -Left: 1-4” Drawers,
Door w/shelf; Right – 3-4” Drawers,
1-8” Drawer$2,268.00
IT3.RXXX.A
44” Island -Left: 3-4” Drawers,
1-8” Drawer; Right: Door w/shelf IT4.RXXX.A
44” Island- Left: Door w/shelf;
Right: 3-4” Drawers,
1-8” Drawer$1,990.00
IT5.RXXX.A
44” Island -Left: 3-4” Drawers,
1-8” Drawer; Right: 3-4” Drawers,
1-8” Drawer $2,949.00
IT6.RXXX.A
59” Island- Left: 3-4” Drawers,
1- 8” Drawer; Center: Door with
Trash Chute; Right: 1-4” Drawer,
Door w/ shelf
$2,499.00
IT7.RXXX.A
59” Island -Left: Door with Trash
Chute; Center: 3-4” Drawers,
1-8” Drawer; Right: Door w/shelf
$2,325.00
IT8.RXXX.A
59” Island - Left: 3-4” Drawers,
1-8” Drawer; Center: 3-4” Drawers,
1-8” Drawer; Right: Door with
Trash Chute
$3,202.00
Tables
•
IT1.R233.A (Dusty Blue inserts (233) shown)
$1,990.00
Call for pricing, colors and options.
"XXX" denotes insert color. See page 31 for chart.
35
Peninsula Exam Table
Tables without knee space/overhang
DT2.R233.A (Dusty Blue inserts
(233) shown)
18"
DT1.RXXX.A
48" Right, Door, 3 Drawer
$1,864.00
DT2.RXXX.A
48" Left, Door, 3 Drawer
$1,864.00
DT5.RXXX.A
60" Right, Door, 3 Drawer, 3 Drawer
$2,691.00
DT6.RXXX.A
60" Left, Door, 3 Drawer, 3 Drawer
$2,691.00
Tables with knee space/overhang
DT3.RXXX.A
48" Right, Door, 3 Drawer
$1,679.00
DT4.RXXX.A
48" Left, Door, 3 Drawer
$1,679.00
DT7.RXXX.A
60" Right, Door, 3 Drawer
$1,854.00
DT8.RXXX.A 60" Left, Door, 3 Drawer
$1,854.00
Call for pricing, colors and options.
"XXX" denotes insert color. See page 31 for chart.
DT4.R233.A (Dusty Blue inserts
(233) shown)
Fold Down Table
The unique fold down design of our wall-mounted folding
exam table features a stationary stainless steel work surface
perfect for charts, instruments and client education materials.
Plus, a special "gas-assist" lifting mechanism makes raising
and lowering the table a breeze. Midmark tables are designed
to enhance your workflow and make you, your patients and
clients as comfortable as possible.
•
Overall length: 42", length with tabletop folded down: 16"
•
Width: 24"
•
Patient Weight Capacity: 125 lb
•
Optional Traction Mat is also available
8012-00-001 Fold Down Exam Table$1,025.00
9A549001
Traction Mat Accessory$126.00
*Optional mounting bracket (sold
seperately for $352) or additional
backing structure may be required
for steel stud applications.
Please contact your Midmark
representative with questions.
Note: All Prep/Exam Table prices include stainless steel tops. Call for pricing on other top options.
36
Stools
270 Adjustable Stool
271 Adjustable Stool
•
Black composite five leg base
• Black composite five leg base
•
Stool weight: 15 lb
(Weight capacity: 300 lb)
• Stool weight: 20 lb
(Weight capacity: 225 lb)
• Shipping weight: 20 lb
• Shipping weight: 25 lb
270-001-XXX 270 Adjustable Stool
Basic Stool, Manually Adjustable$128.00
271-001-XXX 271 Adjustable Stool
Basic Stool w/Back, Manually Adjustable$193.00
1 - See color code chart on page 40.
1 - See color code chart on page 40.
272 Air Lift Stool
273 Air Lift Stool
• Black composite five leg base
• Black composite five leg base
•
• Stool weight: 20 lb
(Weight capacity: 225 lb)
1
Seating
Stool weight: 15 lb
(Weight capacity: 300 lb)
1
• Shipping weight: 20 lb
• Shipping weight: 25 lb
272-001-XXX 272 Air Lift Stool
Basic Stool, Pneumatically Adjustable$174.00
273-001-XXX 273 Air Lift Stool
Basic Stool w/Back, Pneumatically Adjustable$247.00
1 - See color code chart on page 40.
1 - See color code chart on page 40.
274 Doctor’s Stool
275 Doctor’s Stool
• Chrome five leg base
• Chrome five leg base
• Stool weight: 15 lb
(Weight capacity: 350 lb)
• Stool weight: 20 lb
(Weight capacity: 225 lb)
• Shipping weight: 20 lb
•
274-001-XXX 274 Adjustable Stool
Basic Stool, Manually Adjustable$286.00
275-001-XXX 275 Adjustable Stool
Basic Stool with back, Manually Adjustable$372.00
1 - See color code chart on page 40.
1 - See color code chart on page 40.
1
1
1
Shipping weight: 25 lb
1
37
276 Air Lift Stool
277 Air Lift Stool
• Chrome five leg base
• Chrome five leg base
•
• Stool weight: 20 lb
(Weight capacity: 225 lb)
Stool weight: 15 lb
(Weight capacity: 350 lb)
• Shipping weight: 20 lb
• Shipping weight: 25 lb
276-001-XXX 276 Air Lift Stool
Basic stool, pneumatically adjustable$529.00
277-001-XXX 277 Air Lift Stool
Basic stool with back, $650.00
pneumatically adjustable
1
1 - See color code chart on page 40.
1
1 - See color code chart on page 40.
278 Air Lift Surgeon Stool
279 Air Lift Surgeon Stool
• Chrome five leg base
• Chrome five leg base
• Foot operated
• Hand operated
• Stool weight: 30 lb
(Weight capacity: 225 lb)
• Stool weight: 30 lb
(Weight capacity: 225 lb)
• Shipping weight: 35 lb
• Shipping weight: 35 lb
278-001-XXX 278 Air Lift Stool
Basic stool with foot release
Pneumatically adjustable
279-001-XXX 279 Air Lift Stool
Basic stool, pneumatically adjustable$868.00
1
1
$1,085.00
1 - See color code chart on page 40.
1 - See color code chart on page 40.
ACCESSORIES
9A366001-XXX
Backrest Kit$123.00
ADDITIONAL CHARGES FOR PLANT INSTALLED OPTIONS
Ultra-Premium Upholstery$52.00
9A367001 Foot Ring, Field Installed$117.00
27X-002-XXX Set of Soft Rubber Casters$36.00
(not available on foot release models)
9A368001 6" Lab Height Ext. Kit$83.00
27X-003-XXX Set of Glides$0.00
(not available on foot release models)
(not available on foot release models)
27X-004-XXX Set of Locking Casters$15.00
27X-005-XXX Auto Locking Casters$91.00
1
1
1
1
1
38
Dental Doctor’s Stool
•
Contoured set with raised front
•
Waterfall front edges
•
Up to twelve degrees of forward tilt
•
One lever adjustment for locking seat and backrest tilt
•
Ratcheted backrest for height adjustment without knobs
•
Cylinder Height: Tall - 20.9" to 28.7"; Standard - 16.5" to 22";
Short - 15.25" to 18.3"
•
Seat Size: Standard - 17.5" x 16.5"; Small - 16.25" x 16"
153811 Dental Doctor’s Stool
$639.00
* Specify cylinder height
(Tall, Standard, Short) when ordering
See color code chart on page 40.
OPTIONS
154135 Upcharge for Ultra-Premium Upholstery,
Standard Colors$126.00
153820
Adjustable Armrests
Seating
154136 Upcharge for Special (non-standard)
Upholstery Colors$58.00
$157.00
Dental Technician’s Stool
• Contoured seat with raised front
•
Waterfall front edges
•
Ratchet release body support with height adjustment
(specify Right or Left Arm, Left Arm shown)
•
Integrated footrest, automatically adjusts with seat height
•
Cylinder Height: 21.7" to 27.5"
•
Seat Size: 16.25" x 16"
153812 Dental Technician’s Stool
$744.00
See color code chart on page 40.
OPTIONS
154135 Upcharge for Ultra-Premium
Upholstery, standard colors$126.00
154136 Upcharge for Special (non-standard)
Upholstery Colors$58.00
153821
Short Cylinder - 17.8" to 20.8"
(Available only less footrest)
153822
Adjustable Lumbar Support
(factory installed)
$44.00
$166.00
(shown with optional lumbar support)
39
Chairs/Color Chart
680 Upholstered Side Chair
Available with or without arms; black frame, specify
upholstery color.
• Chair weight: 20 lb
• Shipping weight: 30 lb
• 400 pound patient weight capacity
• Leveling feet
• Kick-back leg wall saver design
680-001-XXX Chair without arms$304.00
680-002-XXX Chair with arms$340.00
1
1
1 - See color code chart below.
OPTIONS
Standard Ultra-Premium Upholstery Upcharge$84.00
Color-Specific
Stool Number Chart
XXX – XXX – XXX
Specific Model Number
Options
Color Designation
Example
270-001-235
270 Adjustable Stool – Blueberry Upholstery
Ritter Colors
216Pebble Grey
229Perfect Plum
230Moss
231Navy
232Shadow
233Dusty Blue
234Clay
312Black
40
Solid Premium
Colors
Pattern Premium
Colors
Ultra-Premium
Colors
235Blueberry
236Silver Sage
237Tea Green
238Fossil Grey
239Cashmere Blue
240Terra Cotta
312 Black
247Belagio
248Siena
249Tuscany
250Firenze
251Capri
252Treviso
228Ultra-Raven Wing
241 Ultra-Pacific Blue
242 Ultra-Spruce
243Ultra-Olivine
244 Ultra-Arctic
245 Ultra-Sky
246 Ultra-Canyon
VetPro® 1000
The VetPro 1000 Mobile Dental Delivery System from Midmark
uses our exclusive, oil-free technology. That means there is no oil
to contaminate your handpieces, providing a clean, dry, aseptic
work environment for you, your staff and your patients. And best
of all—no more oil changes! That’s better for your staff and better
for the environment.
®
•
Integrated oil-free compressor means no worries because
it eliminates potential oil exposure to patients and messy
changes! You will also have to replace your handpieces less
often because there is no degradation from oil contamination.
•
Handpieces automatically activate when removed from
holders allowing you to focus on the patient.
•
High and low speed handpieces included.
• Integrated Acteon Satelec® Piezo Scaler saves valuable space
and improves efficiency during the procedure.
Standard Midwest 4-Hole connection type
•
Optional fiber-optics enables proper lighting
•
Quickly toggle between the dual 1-liter water bottles
with a flick of a switch without de-pressurizing the system.
•
External quick connects for water and air make
setup easy
•
Medical grade casters allow you to position the cart
where you need it
•
115V AC
•
10' hospital grade powercord
•
18.5"D x 23"W x 36.5"H
®
8000-003 VetPro 1000 with non-lighted integrated scaler
and fiber optics
Dental
•
$7,644.00
®
8000-007S VetPro 1000 $9,495.00
with integrated LED scaler and 2 position
fiber optic swivel high speed handpieces
®
8000-008 VetPro 1000 $8,325.00
with integrated LED scaler and
fiber optics
VetPro 1000
with optional Dental Suction Accessory
(9A560001) installed
®
®
8000-008SVetPro 1000 with integrated LED scaler
and fiber optic swivel high speed
handpiece
$8695.00
®
9A477001 Antimicrobial fabric cover for VetPro 1000 $149.00
*All dental delivery systems include high and low speed handpieces,
®
VetPro Bur Starter Kit and starter supply of Prophy Angles.
®
9A560001 VetPro Dental Suction Accessory (In-clinic installation required)
$399.00
41
VetPro® Dental Handpieces
VetPro® High Speed
Get a handpiece designed for the rigors of veterinary dentistry.
• Ceramic bearings for lower maintenance, extended life and
quiet operation (routine lubrication not required)
• Debris-Shield™ bearing shield system minimizes entry
of debris into bearing
• Super-small Head Size
VetPro Fiber Optic highspeed
• Light Weight
handpiece, 002-1275-1276
• Fast Cutting Power
®
• Reduced Contra Angle
• Ergonomic Comfort For Smooth Control
• No-Slip Grip
• Push Button Bur Changing
• Optional Fiber Optics
• Optional 360-degree swivel for improved ergonomics
• Electro-Polished Stainless Steel Handles Last Longer,
Easier to Maintain
• Manufactured in the U.S.A.
• 1-year Warranty (90 day on chuck)
VetPro Fiber Optic Swivel high
®
speed handpiece and coupler
002-1996-00
002-1996-00 VetPro® Swivel High Speed Handpiece
and Coupler w/ Fiber Optics$898.00
002-1275-00VetPro® High Speed
$436.00
002-1276-00VetPro High Speed w/ Fiber Optics
$519.00
®
002-1432-00VetPro Handpiece Cleaner/Conditioner $31.00
®
VetPro® Low Speed
• Ceramic bearings for lower maintenance, extended life and
quiet operation (routine lubrication not required)
• Swivel for Reduced Hand Fatigue
• Small and Lightweight
• Smooth, Quiet Operation at 0-5,000 RPM
• Prophy Heads Slip In and Out, Quickly and Easily
• Accepts all 3/32" Burs and Doriot Heads
• Manufactured in the U.S.A.
• 1-year Warranty
002-1277-00VetPro® Low Speed w/ Swivel Adapter$764.00
VetPro Low speed w/ swivel adapter,
®
002-1277-00
002-1277-01VetPro® Low Speed Handpiece Motor $349.00
0-20,000 RPM (Additional nose cone required: 016-1605-00, 016-1605-01)
016-1605-00
Nose Cone, 1:1 (For use w/ 002-1277-01) $165.00
016-1605-01
Nose Cone, 4:1 (For use w/ 002-1277-01) $214.00
002-1432-00VetPro® Handpiece Cleaner/Conditioner $31.00
42
Meisinger Burs
TM
Meisinger™ tungsten carbide instruments should be your
choice in burs.
•
•
•
•
Functional precision tooling
Above average concentricity
Outstanding efficiency and long endurance
Made of high density fine grain metal
016-1204-00 016-1204-01 016-1204-02 016-1204-05 016-1204-06 016-1204-07 016-1204-03 016-1204-04 016-1204-09
016-1204-08 #2
#2 Round, 5/pk.
$9.00
#4 Round, 5/pk. $9.00
#6 Round, 5/pk. $9.00
#36 Inverted Cone, 5/pk.
$9.00
#558 Cross Cut Straight Fissure, 5/pk.
$9.00
#558L Cross Cut Straight Fissure, 5/pk. $9.00
#701 Cross Cut Tapered Fissure, 5/pk. $9.00
#701L Cross Cut Tapered Fissure, 5/pk. $9.00
#831F Diamond Football, Fine, 5/pk.
$47.00
#869LF Diamond Torpedo, Fine, 5/pk. $47.00
#558L
#4
#6
#701
#701L
#36
#831F
#558
#869LF
(shown larger than actual size)
VetPro® Bur Starter Kit
Contains one of each standard bur and labeled autoclavable
holder.
002-1158-00
$49.00
Dental
Rodent Dental Bur Kit
002-1664-00
016-1204-10 016-1204-11 Rodent Dental Bur Kit for use with VetPro
low-speed handpiece (002-1277-01)
and 1:1 nose cone (016-1605-00).
$149.00
Replacement diamond Disc,
Med Grit, #930D $30.00
Replacement diamond Bur,
Extra Long, 60 mm
$30.00
®
002-1158-00
002-1664-00
Classic Elite Prophy Angles
Classic Elite disposable prophy angles are known for their
stability, performance and feel. The Elite prophy cups are
designed with spiral ridges on the inside and outside of the cup
to provide exceptional stain removal, allow better interproximal
cleaning and reduce splatter. Try the Elite and experience the
difference! The cups are soft, petite and latex-free.
002-1279-00 Classic Elite prophy angles, 10 pack$10.00
002-1279-01 Classic Elite prophy angles (200 pc)$175.00
002-1159-00
002-1160-00
A. Autoclavable Prophy Angle
B. Prophy Cups, 10/pk.
$35.00
$3.00
B
A
43
Acteon Satelec® Scaling Tips
Made from the best alloys, exclusive to Satelec®, using
patented procedures.
• Corrosion resistant
• Autoclavable
No. 1
No. 2
No. 10P
•
Calibration: each tip is individually tested and “tuned” using
the latest in ultrasonic calibration techniques.
•
Spray Control System (SCS): more powerful cavitation, better spray control and perfectly-controlled vibration energy at the
end of the instrument.
• Color Coding System (CCS tips): inserts are color coded to
show their recommended power range.
No. 10Z
No. H3
016-1203-00 016-1203-03 016-1203-04 016-1203-01 016-1203-02 Universal, Tip No. 1
Voluminous Calculus, Tip No. 2
Shallow Pockets, Tip No. 10P
Subgingival, Tip No. 10Z
Periodontics, Micro Universal Curette, Tip No. H3
$115.00
$115.00
$115.00
$137.00
$137.00
*For a complete listing of tips available for the Acteon Satelec
®
Scaler visit midmarkanimalhealth.com/store.
B
Acteon Urolithiasis Probes
Use ultrasonics to quickly and efficiently break up the stones
located in the urethra. Urolithiasis probes are compatible with
the Satelec ultrasonic scalers used in the VetPro® dental delivery
systems and are connected to the scaler handpiece in the same
way as scaling tips.
®
A
C
(not shown to scale)
44
016-1203-05 016-1203-07 016-1203-06 002-1238-00 A. Dog Probe Short - L:102 mm
B. Dog Probe Long - L:156 mm
C. Cat Probe
Kit 3 Veterinary Urolithiasis Probes - Dog Short/Dog Long/Cat
$115.00
$115.00
$115.00
$285.00
VetPro® Digital Dental X-ray Systems
VetPro® DC
VetPro® DC is a high frequency, veterinary-specific dental
X-ray designed to meet the needs of digital imaging. Exceptional
image quality with digital sensors, phosphor plates and all types
of film; 0.4 mm focal spot; 60, 65 or 70 kV; 4,5,6 or 7 mA;
unique LCD display and menu; 30 pre-programmed technique
settings; tube head positioning handle; and control panel that
can be mounted in a separate location. 56", 66", 76" and 82" or
mobile systems available. 2-year warranty.
WALL MOUNTED
P7017V-P
P7018V-P
76" arm $6,289.00
(sensor not included, see pg. 51)
82" arm
(sensor not included, see pg. 51)
ASAW-GT
Laptop Tray for wall mounted X-ray$432.00
$6,397.00
MOBILE
P7017VMMobile
$7,340.00
ASAM-GT
Laptop Tray for mobile X-ray
ASAM-GT/L
Laptop with Imaging Software
and Laptop Tray
30-A2040
Handswitch (comes with all units)
WARRX1
X-ray Factory Warranty Extension -$520.00
One Year
WARRX2
X-ray Factory Warranty Extension -$940.00
Two Years
$1,833.00
Dental
$432.00
$103.00
Not available through all Midmark authorized dealers.
45
VetPro® DR Digital Sensor System
The durable VetPro® DR delivers fast, clean images for
diagnosis and client education. 19 mm x 19 mm pixel size, 26 lp/
mm theoretical resolution and 4,096 levels of grey give you
superior soft-tissue visualization, crown and root definition, and
low noise.
No-Hassle installation: VetPro® DR uses the latest USB 2.0
technology. Simply connect the USB cable to your PC, use the
quick calibration flash drive to prepare your sensor, and your
system is ready to take high quality digital images.
• Cable is Kevlar® reinforced for exceptional durability
• Hermetically sealed, waterproof design means no problems
during routine cleaning
• Advanced CMOS technology delivers outstanding image
quality
• High speed USB 2.0 connection captures images 37% faster
• Rounded corners means easier positioning in tight spaces
for better capture of roots
• 2-year warranty
• Optional Sensor Safe® Extended Care Program protects
your sensor investment against damage not covered by the manufacturer's warranty, for five years
• Integrates with Avimark Practice Management Software
®
46
XSVS-01
#1 Sensor System, 3 meter cable
$8,573.00
XSVS-01/L
Same as above w/laptop & software
$9,883.00
XSVS-02
#2 Sensor System, 3 meter cable
$9,993.00
XSVS-02/L
Same as above w/laptop & software $11,304.00
XSVN-01
#1 Sensor System, .9 meter cable
$8,573.00
XSVN-01/L
Same as above w/laptop & software
$9,883.00
XSVN-02
#2 Sensor System, .9 meter cable
$9,993.00
XSVN-02/L
Same as above w/laptop & software $11,304.00
500-432
Sanitary Sheaths, 500/pk.—Size 1
$198.00
500-433
Sanitary Sheaths, 500/pk.—Size 2
$198.00
WARRS1
Sensor Factory Warranty Extension -
1 Year
$2,267.00
WARRS2
Sensor Factory Warranty Extension -
2 Years
$4,367.00
SS-630
Sensor Safe Extended Care Program
$1,285.00
VetPro® CR Dental Radiography
Reader
The compact VetPro® CR Dental Radiography Reader is a fast,
full-featured and easy-to-use dental imaging solution that
requires very little maintenance. It features a touch screen
display and an automatic retracting tray that keeps the reader
and phosphor plates clean to prevent image artifacts.
The included Progeny® Imaging Software provides fast
acquisition, optimized processing and easy management of
images. These software features, along with lifetime technical
support and unlimited software upgrades, are included free
of charge.
• Size 2 and 4c imaging plates are included with the unit—sizes
0,1,2,3 and 4c available for purchase
• Auto calibration ensures stability and consistency
• Built-in erase function
• Easy-to-use LCD touch screen interface
• Easy-to-position, reusable imaging plates
XPVZ-01
VetPro® CR System
XPVZ-01/L
VetPro® CR System; Laptop
$11,304.00
XPVZ-01/S2
VetPro® CR System; VetPro® #2 sensor
$17,987.00
CR-FP-13-001
IP Storage Box
$155.00
CR-FP-12-030
Imaging Plate Starter Kit - Veterinary Contains: 4
x size 2 IP and 1 x IP size 4c
$240.00
CR-FP-12-012
Size 0 Imaging Plate Kit Contains: 4 x IP size 0
$165.00
CR-FP-12-013
Size 1 Imaging Plate Kit Contains: 4 x IP size 1
$165.00
CR-FP-12-014
Size 2 Imaging Plate Kit Contains: 4 x IP size 2
$165.00
CR-FP-12-015
Size 3 Imaging Plate Kit Contains: 4 x IP size 3
$165.00
CR-FP-12-016
Size 4c Imaging Plate Kit Contains: 1 x IP size 4c
$120.00
CR-FP-12-020
Hygienic Bags Size 0 Box of 100 pcs
$42.00
CR-FP-12-021
Hygienic Bags Size 1 Box of 100 pcs
$42.00
CR-FP-12-022
Hygieninc Bags Size 2 Box of 100 pcs
$42.00
CR-FP-12-023
Hygienic Bags Size 2 Box of 300 pcs
$105.00
CR-FP-12-024
Hygienic Bags Size 3 Box of 100 pcs
$63.00
CR-FP-12-025
Hygienic Bags Size 4c Box of 100 pcs
$63.00
$9,993.00
Dental
47
Imaging Software
Our imaging software makes image capture simple. Select a
tooth or tooth set to be imaged, and then click Acquire. Simple!
•Industry leading image quality
•Powerful, no-hassle software
•Intuitive and logical interface
•Simplified acquisition
•DICOM formatted images
•Back Up and Restore feature
•22 practical and useful tools
•Create your own custom templates
•Bridges with most major practice management programs
•Store any digital image
• Integrates with Avimark Practice Management Software
®
Use your VetPro® DR or CR Systems with our own easy to use
imaging software. Look and formatting are familiar and easy to
learn. Acquire, enhance and store images with ease. Our
software features canine and feline tooth templates organized
using the Triadan System, is DICOM compliant, and able to
work with leading practice management systems and PACS
servers.
Canine
Feline
48
VetPro® Complete Digital Dental
Radiography Systems
Whether your clinic is equipped with film, fully digital or a
combination of both, we feel you should have the freedom to
choose what you are most comfortable using without sacrificing the
quality, service and support that you've come to expect from the
Midmark brand. That's why we provide you with multiple imaging
options and the training and support you need to get the best use
of your equipment. Imaging software integrates with Avimark
Practice Management Software.
®
VetPro DR Complete
DCV7-G2A/H/S1 76" arm, #1 sensor$14,756.00
DCV7-G2A/H/S2 76" arm, #2 sensor$16,211.00
DCV8-G2A/H/S2 82" arm, #2 sensor
$16,312.00
30-A2040
Handswitch (comes with all units)
ASAW-GT
Laptop Tray for wall mounted X-ray$432.00
$103.00
DCVM-G0A /H/S1 Mobile, #1 sensor$15,305.00
DCVM-G0A /H/S2 Mobile, #2 sensor$16,724.00
ASAM-GT
Laptop Tray for Mobile X-ray
WARRX1
X-ray Factory Warranty Extension -$520.00
One Year
WARRX2
X-ray Factory Warranty Extension -$940.00
Two Years
$432.00
Dental
VetPro CR Complete
DPVM-G0A/H/XP
VetPro DC Mobile; handswtich;
VetPro CR
$16,724.00
DPVM-G0A/H/L/XP
VetPro DC Mobile; handswtich;
Laptop w/laptop tray;
VetPro CR $17,737.00
DCVM-G0A/H/S2/L/XPVetPro Complete Mobile;
handswitch; #2 Sensor;
laptop w/laptop tray;
VetPro CR$23,710.00
DPV7-G2A/H/XP
VetPro DC 76" reach
w/2-stud mount; handswtich;
VetPro CR$16,211.00
DPV8-G2A/H/XP
VetPro DC 82" reach
w/2-stud mount; handswitch;
VetPro CR $16,312.00
49
VetPro® DR Complete Mobile
Imaging Station
A complete mobile digital dental imaging solution—everything
you need for clean, clear diagnostic dental images, right at the
point of care.
•
VetPro® Complete Mobile Digital Dental Imaging System
with #2 Sensor
•
Laptop computer pre-loaded with our own easy-to-use
software. Ready-to-use laptop means no software
installation hassels
•
Laptop Tray mounts directly to the column of the VetPro®
Mobile—computer is easily accessible, no more walking to
a remote computer
•
Integrated #2 sensor—safe and accessible—software is
ready to accept images from your VetPro® DR sensor
•
Special package pricing saves you money vs. buying
individual components
•
Integrates with Avimark Practice Management Software
®
VetPro ® Complete Mobile$17,737.00
Imaging Station with laptop,
laptop tray, #2 sensor
and imaging software
ASAM-GT
Laptop Tray for Mobile Station$432.00
30-08158
Laptop with Imaging Software $1,514.00
ASAM-GT/L
Laptop with Imaging Software $1,833.00
and Laptop Tray
DCVM-G0A/H/S2/L
®
Not available through all Midmark authorized dealers.
50
Midmark Academy (Dental Training and Education Network)
SM
Comprehensive, hands-on, half-day training performed
in your clinic by a member of the Midmark Animal Health
Training and Education Network.
RK ACADEMY
MIDMA
Dental X-ray Positioning Training
RK ACADEMY
MIDMA
RK ACADEMY
MIDMA
This dental X-ray training will get you up and running with your
new VetPro® equipment faster than you ever thought possible.
Training topics include:
•VetPro® X-ray generator usage
• Digital imaging software training
• X-ray positioning techniques for both canine and feline
patients
• How to overcome common positioning errors
• Proper maintenance and storage techniques
Veterinary Technicians who complete this session will earn 4
hours of CE credits for Dental Radiography Positioning Training.
4 CE Credit Hours!*
VI-CSP
RK ACADEMY
MIDMA
Dental X-ray Positioning Training$1,150**
Cleaning, Probing and Charting
Training
RK ACADEMY
MIDMA
RK ACADEMY
MIDMA
Training topics include:
• Preparation—including rinse, before and after photos, proper
attire and safety
• Execution—including tools, sub/supra gingival scaling,
polishing, probing and charting
• Instrument cleanup, maintenance and care
• Common pathology
• Anatomy review and Triadan numbering system
• Probing technique
• Hands-on practice of prep, scaling and polishing, probing
and charting
4 CE Credit Hours!*
*These programs were reviewed and approved by the AAVSB RACE program
for 4 hours of continuing education in jurisdictions which recognize AAVSB
RACE approval. Please contact the AAVSB RACE program if you have any
comments/concerns regarding a program's validity or relevancy to the
veterinary profession. Provider #436.
• Proper use and maintenance of your VetPro® high-speed
system
Veterinary Technicians who complete this session will earn 4
hours of CE credits* for Dental Cleaning, Probing and Charting
Training.
VI-CPC Cleaning, Probing and Charting Training$1,150**
**Pricing for Continental U.S. only.
51
Dental
This training will help participants become familiar with best
practices for dental cleaning, probing and charting.
Procedure Lights
255 LED Procedure Light
Single Ceiling Mount
•
Significantly more light intensity than similar products at
7,500 footcandles, an excellent color rendering index of 95
out of 100, and a color temperature of 4,400 K.
•
Easily position the light precisely where you want it, and it
stays there—no drifting!
•
16 LEDs reflecting evenly off of 1,040 reflective facets will
reduce the disruption of shadows while you work,
producing an even distribution of light for uninterrupted
illumination.
•
Turn the light on/off and adjust light intensity from controls
on each side of the light head.
•
LEDs have 100-times longer life than most halogen lamps
while consuming less energy, resulting in significant savings
year after year.
•
Sleek contours, a sealed light head and an autoclavable
handle help to save maintenance time and increase
product life.
•
IEC/ES 60601-1, CAN/CSA C22.2 60601-1, 60601-2-41,
CE Medical Device Directive, RoHS European Directive
255-021 255 Single Mount, 8' (2.4m) ceiling$2,950
255-022 255 Single Mount, 9' (2.7m) ceiling$2,950
255 LED Mobile Procedure Light
255-025 255 Mobile Procedure Light$2,950
Ceiling Mount Adapter Kit
•
To convert an 8' or 9' system to a 10' mount height
•
One required per light arm
002-1865-00
10' Ceiling Mount Adapter Kit $313
9A584001
Conversion Kit With Cover $131
The following model numbers are recommended based on the
following ceiling heights (measured from the bottom of the ceiling
surface to the floor).
Under 8'
255-025
Mobile Procedure Light
8' to 9' 255-021, 255-023
8' Single or Dual Light
9' to 10'
255-022, 255-024
9' Single or Dual Light
Above 10' 255-025, 002-1865-00
52
Mobile Procedure
Light or 10' Ceiling Mount Adapter Kit
255 LED Procedure Light
Dual Ceiling Mount
255-023 255 Double Mount, 8' (2.4m) ceiling$5,900
255-024 255 Double Mount, 9' (2.7m) ceiling$5,900
255 LED Procedure Light
Wall Mount
255-026 255 Wall Mount$3,975
Exam Light
250 LED Exam Light
Lighting
STANDARD FEATURES
• LED technology for up to 25,000 hours of
useful life
• 45% less energy consumed than equivalent
halogen lights
• 4,000 K color temperature
• 1,800 footcandle intensity (19,375 lux)
• UL6060-1 and CAN/CSA C22.2 No. 601.1-M90
• Exam light weight: 20 lb
• Shipping weight: 25 lb
250-002 LED Exam Light
9A274001 Caster Base Accessory
$370.00
$46.00
53
Multiparameter Monitoring
Cardell® Touch
Accuracy and reliability at your fingertips. Midmark has
designed the precision and consistency you expect from the
Cardell® name into a fast, light and intuitive touch screen vital
signs monitor.
Above all, an anesthesia monitor should be safe, reliable and
user-friendly. The Cardell® Touch is highly advanced, yet easy to
use. With veterinary specific algorithms and exclusive Cardell®
Blood Pressure Technology, the Touch is the latest innovation
from the most trusted name in veterinary vital signs monitoring.
• 10.5" touchscreen makes patient set up faster and easier or
use the traditional-style buttons located below the screen
• Redesigned menus and improved controls allow for intuitive
navigation
• Smaller, lighter form factor allows for easy transportation
without sacrificing visibility
• World Class Cardell® BP, Nellcor™ SpO2 and upgrade to
CO2 monitoring at any time by adding a Masimo sidestream
or mainstream CO2 module
• Masimo Multigas available
• Enhanced ECG data export capabilities
• USB port for downloading patient data
• Customizable alarm settings for up to three users
Back View
Optional Printer Shown
• Optional integrated 3-channel graphical printer
• 2-year warranty
8013-001
8013-002
8013-003
8013-004
002-1895-00
002-1896-00
002-1745-00
002-1746-00
Cardell Touch with Printer$5,895.00
Cardell Touch without Printer$5,695.00
Cardell Touch with Invasive BP and Printer$7,495.00
Cardell Touch with Invasive BP, no Printer$7,295.00
Masimo Mainstream CO2 Module$2,388.00
Masimo Sidestream CO2 Module$2,388.00
Masimo Mainstream Multigas for Touch$7,999.00
Masimo Sidestream Multigas for Touch$7,999.00
®
®
®
®
Cable Side
Additional monitoring accessories are available
at midmarkanimalhealth.com/store
For monitor mounts, see page 56.
54
Mainstream
Sidestream
Monitor Mounts
Rolling stands and other mounting options are
available to help protect your investment.
Rolling stands allow you to easily move your monitor
around a room or between hospital locations.
All rolling stands feature a storage basket for
accessories and user manuals.
8008-001
8008-002 8008-003
8008-004
9A465001
9A465002 9A465004
9A465005
9A465006
9A465007
9A465008
Mobile Stand for Max-12$504.00
Mobile Stand for 9400/9500/Touch Monitors$504.00
Monitor Mount for Max-12$504.00
for Canis Major® Table
Monitor Mount for 9400/9500/Touch$504.00
for Canis Major® Table
Monitor Mount for Max-12 for VMS® Plus$163.00
Monitor Mount for 9400/9500/Touch$163.00
for VMS® Plus
Monitor Mount, Pole, for 9400/9500/Touch $163.00
for VMS®
Monitor Mount, Stud, for Max-12
$163.00
Monitor Mount, Stud, for 9400/9500/Touch$163.00
Monitor Mount, Wall, for Max-12
$163.00
Monitor Mount, Wall, for 9400/9500/Touch$163.00
Mobile Stand
VMS®
VMS® Plus
Monitoring
55
Midmark Academy Anesthesia Monitoring Training
SM
Anesthesia Monitoring 101
RK ACADEMY
MIDMA
RK ACADEMY
MIDMA
RK ACADEMY
MIDMA
Our comprehensive, hands-on, half-day, anesthesia
monitoring training is provided in your clinic by a
member of the Midmark Animal Health Training and
Education Network.
This training from Midmark Animal Health will help participants
become familiar with best practices for operating and
maintaining their anesthetic and monitoring equipment.
Training topics include:
• Anesthesia machine theory of operation, function of
components and flow of gases
• Proper equipment maintenance for long-term performance
and better patient outcomes
• Overview of ACVAA anesthetic monitoring guidelines for small
animals
• Five parameter, hands-on monitoring including circulation,
oxygenation and ventilation
4
CE Credit Hours!*
• How vital signs are measured and what the readings mean
Veterinarians and credentialed technicians who complete this
session will earn 4 hours of CE credits* for Anesthesia
Monitoring 101.
VI-AMT Anesthesia Monitoring 101$1,150**
RK ACADEMY
MIDMA
RK ACADEMY
MIDMA
RK ACADEMY
MIDMA
Anesthesia Monitoring 201
Building on the skills of our 101 lab, our 201 course is
provided in your clinic by a member of the Midmark
Animal Health Training and Education Network.
Following the prerequisite Anesthesia Monitoring 101 dry lab,
this course will help participants learn the keys to completing a
successful anesthetic case.
Training topics include:
• Review of ACVAA/AAHA monitoring/anesthesia guidelines
• Setting up the patient for an anesthetic case
• Balanced anesthesia/pain management best practices
• Troubleshooting vital signs readings and anesthetic
complications
4 CE Credit Hours!*
*This program was reviewed and approved by the AAVSB RACE program for 4 hours
of continuing education in jurisdictions which recognize AAVSB RACE approval. Please
contact the AAVSB RACE program if you have any comments/concerns regarding this
program’s validity or relevancy to the veterinary profession. Provider #436.
**Prices vary for clinics located outside the Continental United States.
56
• Developing an anesthesia record-keeping plan
Veterinarians and credentialed technicians who complete this
session will earn 4 hours of CE credits* for Anesthesia
Monitoring 201.
VI-AMT2 Anesthesia Monitoring 201$1,150**
To set up your training session or if you have any questions,
please contact your local distributor representative or call
1-800-360-2186.
Midmark Sterilizers
M9 and M11 UltraClave® Automatic Sterilizers
• Fast and easy use for efficient instrument processing
• Maximum space utilization
• Reliability and effectiveness for infection control
assurance
• Four pre-set cycles and two
user-programmable cycles
• Patented automatic-opening door for efficient
instrument drying
M11 UltraClave® Automatic Sterilizer
Our Largest Standard Tabletop Sterilizer
• Automatic Door
• Chamber size: 11" x 18" (28 cm x 45.7 cm)
• 115 VAC, 50/60 Hz, 15 Amps
• Meets UL 61010-1, IEC 61010-2-040
• Meets CAN/CSA C22.2 No. 61010-1, CSA C22.2 No. 61010-2040-07 Part 2-040
• ASME Certified
• Sterilizer weight: 99 lb (44.9 kg)
• Shipping weight: 131 lb (59.4 kg)
M11-033 Midmark M11 UltraClave®$5,995.00
M9 UltraClave® Automatic Sterilizer
• Automatic Door
• Chamber size: 9" x 15" (22.9 cm x 38.1 cm)
• 115 VAC, 50/60 Hz, 15 Amps
• Meets UL 61010-1, IEC 61010-2-040
• Meets CAN/CSA C22.2 No. 61010-1, CSA C22.2 No. 61010-2040-07 Part 2-040
• ASME Certified
• Sterilizer weight: 73 lb (33.1 kg)
• Shipping weight: 81 lb (36.7 kg)
M9-033
Midmark M9 UltraClave®$5,131.00
Instrument
Processing
57
Midmark Sterilizer Accessories
Cool Hand
Pouch Rack
Tool
External Condensing
Tank
Printer
Deep Tray
Horizontal Cassette
Rack
Vertical
Cassette
Rack
M9•• • ••
M11•• • •• ••
Racks
9A226001
(A) Pouch Rack $66.00
9A215001
(B) M11 Horizontal Cassette Rack Holds Four Large and Four
Small Cassettes $176.00
9A215002
A: Pouch Rack
12"L x 4.5"W x 3"H
B: Horizontal Cassette Rack
15.2"L x 8.6"W x 8"H
(C) M11 Vertical Cassette Rack Holds Four Large and Four
Small Cassettes $176.00
C: Vertical Cassette Rack
15.5"L x 9.25"W x 8.75"H
Accessories
9A307001
9A259001
(E) Cool Handtool
(Tray and Cassette Removal Tool) $34.00
(F) Impact Dot Matrix Printer 002-0396-00 (G) SpeedClean
(One 16 oz. Bottle) $582.00
E: Cool Handtool
8.5"L
$24.00
002-0396-05 One Case SpeedClean
(Twelve 16 oz. Bottles)$125.00
G: SpeedClean
8"H
F: Impact Dot Matrix Printer
7.5"L x 4.4"W x 2.25"H
58
The Midmark Soniclean uses an industrial type ultrasonic stack transducer that allows the unit to
perform quietly. Tiny cavitation bubbles are produced with the higher frequency, allowing the bubbles
to penetrate smaller crevices. This results in a powerfully quiet ultrasonic cleaner.
®
The Midmark Soniclean is extremely easy to operate—simply load your instruments and set the timer.
®
• The side-mounted external drain is accessible and easy to use
• Two size options
• Chemical resistant plastic body
Soniclean® Ultrasonic Cleaners
Soniclean® M250 Ultrasonic Cleaner
• Tank Capacity: 2.5 gal (9.51 L)
• Tank Size: 11.5" x 9.5" x 6" (29.21 x 24.13 x 15.24 cm)
• Overall Size: 16" x 15.5" x 14.5" (40.64 x 39.37 x 36.83 cm)
• Soniclean weight: 14 lb (6.4 kg)
• Shipping weight: 20 lb (9.1 kg)
• CSA Listed, TUV & FCC Registered
Does not include required safety basket accessory,
see page 61.
M250-001
Midmark M250 Ultrasonic Cleaner$1,601.00
Instrument
Processing
59
Soniclean® M550 Ultrasonic Cleaner
• Tank Capacity: 5.5 gal (20.81 L)
• Tank Size: 19.5" x 11.5" x 6" (49.53 x 29.21 x 15.24 cm)
•
Overall Size: 24" x 18" x 14.5" (60.96 x 45.72 x 36.83 cm)
• Soniclean® weight: 26 lb (11.7 kg)
• Shipping weight: 40 lb (18.1 kg)
• CSA Listed, TUV & FCC Registered
Does not include required safety basket accessory,
see page 61.
M550-001
Midmark M550 Ultrasonic Cleaner$3,047.00
Soniclean® Ultrasonic Cleaner Accessories
Ultrasonic Cleaning Solutions
9A296001
Midmark General
Purpose Cleaner (32 oz.)$66.00
9A297001
Midmark Tartar and
Stain Remover (32 oz.)$66.00
9A298001
Midmark Enzymatic Cleaner (32 oz.)$66.00
Cassette Rack
9A295001
M250 Cassette Rack
Holds Three Large IMS Cassettes
9A407001
$228.00
M550 Cassette Rack
Holds Six Large IMS Cassettes$288.00
M250 Cassette Rack Shown
60
Accessory Kit
Includes safety basket, beakers, beaker positioning
cover with rings and beaker lids.
9A285001
M150 Accessory Kit$294.00
9A286001
M150 Accessory Kit with Half Basket$275.00
9A287001
M250 Accessory Kit$421.00
9A288001
M250 Accessory Kit with Half Basket$303.00
9A289001M550 Accessory Kit$712.00
M150 Accy Kit Shown
Safety Basket
9A290001
Safety Basket for M150$161.00
9A292001
Safety Basket for M250$305.00
9A294001
Safety Basket for M550$378.00
M250 Safety Basket Shown
Half Basket
9A291001
Half Basket for M150$145.00
9A293001
Half Basket for M250$147.00
M250 Half Basket Shown
Instrument
Processing
61
Midmark Animal Health Limited Warranty
SCOPE OF WARRANTY
Midmark Corporation (“Midmark”) warrants to the original retail
purchaser that it will repair or replace components of the animal
health products manufactured by Midmark (except for products and
components not warranted under “Exclusions”) that are defective in
material or workmanship under normal use and service. The sole
remedy under this limited warranty is the repair or replacement, at
Midmark’s option, of the applicable products or components. This
limited warranty shall only apply to defects that: (i) are reported to
Midmark within the applicable warranty period; and (ii) are
determined to exist upon examination by Midmark. This limited
warranty extends only to the original retail purchaser of a product,
and is not transferable or assignable.
APPLICABLE WARRANTY PERIOD
The applicable warranty period for each Midmark product
commences on the date of delivery to the original retail purchaser of
the product and shall continue for the period specified in the
attached Warranty Guide, which Warranty Guide is expressly
incorporated herein. References in the Warranty Guide to specific
component warranty periods are in place of and supersede the
generally applicable warranty period for the product under which
the component is listed.
OBTAINING WARRANTY SERVICE
Warranty service must be obtained through either Midmark or an
authorized dealer in the Midmark product line for which warranty
service is requested. Midmark may be contacted for warranty
service inquiries or issues via email at www.midmark.com, by mail
to Midmark Corporation, 60 Vista Drive, Versailles, Ohio 45380, or
by phone at: 1-800-MIDMARK.
It is the retail purchaser’s obligation to arrange for delivery of a
product to Midmark or one of its authorized dealers for warranty
service, which delivery shall be at retail purchaser’s expense. It is
also the retail purchaser’s obligation to comply with the warranty
service instructions provided either by Midmark or its authorized
dealer. The retail purchaser must provide Midmark with completed
warranty registration information within thirty (30) days after
purchase in order to obtain the benefits of this limited warranty.
EXCLUSIONS
This limited warranty does not cover and Midmark shall not be liable
for the following:
(1) defects, damage, or other conditions caused, in whole or in part,
by misuse, abuse, negligence, alteration, accident (including animal
acts of any kind), freight damage, tampering, or failure to seek and
obtain repair or replacement in a timely manner;
(2) matching of color, grain, or texture except to commercially
acceptable standards;
(3) changes in color caused by natural or artificial light;
(4) products which are not installed, used, and properly cleaned and
maintained as required in the installation and operation manuals for
the applicable product (imaging product must be installed by a
certified Midmark installer);
(5) products considered to be of a consumable nature;
62
(6) accessories or parts not manufactured by Midmark;
(7) specially manufactured products;
(8) charges by anyone (including Midmark’s authorized dealers) for
adjustments, repairs, replacement parts, installation, or other work
performed upon or in connection with such products which are not
expressly authorized in writing in advance by Midmark;
(9) costs and expenses of routine maintenance and cleaning;
(10) all sinks, faucets, and plumbing accessories;
(11) representations and warranties made by any person or entity
other than Midmark; and
(12) with respect to software that is a product or a component
thereof, that the software will be error free, can be used without
problems or interruptions, or will be free from vulnerability to
intrusion or attack by viruses or other methods.
EXCLUSIVE REMEDY; CONSEQUENTIAL DAMAGES
DISCLAIMER
Midmark’s only obligation under this limited warranty is the repair or
replacement of defective parts. Midmark shall not be liable for and
hereby disclaims any direct, special, indirect, incidental, exemplary
or consequential damages or delays including, but not limited to,
damages for loss of profits or income, loss of use, downtime, cover,
and employee or independent contractor wages, payments, and
benefits. This disclaimer shall survive any failure or asserted failure of
the essential purpose of this limited warranty or its remedies
specified herein.
NO AUTHORIZATION
No person or firm is authorized to create or approve for Midmark
any other obligation or liability in connection with Midmark products.
WARRANTY DISCLAIMER
THIS LIMITED WARRANTY IS MIDMARK’S ONLY WARRANTY AND
IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
MIDMARK MAKES NO IMPLIED WARRANTIES OF ANY KIND
INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE.
STATUTE OF LIMITATIONS
No action may be brought against Midmark for breach of this limited
warranty, an implied warranty, if any, or for any other claim arising
out of or relating to the products, more than ninety (90) days
following expiration of the warranty period. In the event multiple
warranty periods exist with respect to a product, the ninety (90) day
period provided for herein shall begin to run from expiration of the
warranty period for the component to which the claim relates.
SEVERABILITY
In the event any provision of this limited warranty is determined to
be invalid or otherwise unenforceable: (i) the provision shall be
enforced in a manner that closest holds to its intent, while at the
same time curing the invalidity or unenforceability, and (ii) the
balance of this limited warranty, being severable, shall not be
affected in the event the provision that is invalid or unenforceable
cannot be enforced in any respect.
Animal Health Products Warranty Guide
Warranty
Product Description
Period
Product Description
Casework
Sterilization and Instrument Processing
1. Midmark Modular and Exam Room Casework
a. Plastic, Laminate, and Solid Surface Counter Tops
b. Task Light Ballast
2. All Other Midmark Casework Products
3. Integra™ Steri-Centers, Consoles, Cabinets,
Storage Units and Other Products
a. Plastic, Laminate, and Solid Surface Counter Tops
b. Task Light Ballast
4.Artizan® Streamline-Centers™, Stations, Consoles, Benches and Other Products
a. Plastic, Laminate, and Solid Surface Counter Tops
b. Task Light Ballast
5. Midmark Steri-Centers
a. Plastic, Laminate, and Solid Surface Counter Tops
b. Task Light Ballast
5 years
1 year
3 years
5 years
5 years
1 year
3 years
5 years
1 year
3 years
5 years
1 year
3 years
Dental Delivery Systems
1.VetPro® Dental Delivery Systems and Stations
a. “Kink-Valve” Module
b. Replacement Parts and Accessories
2.VetPro® Dental Handpieces
a. High Speed Chuck
2 years
10 years
90 days
1 year
90 days
Exam and Treatment Tables
1. Canis Major® Lift Tables
2. Exam, Prep and Treatment Tables
1 year
1 year
Lighting
1. Midmark Procedure Lights, Spotlights, Exam
lights
1 year
Monitoring
1.Cardell® Touch
a. Masimo IRMA Mainstream and ISA Sidestream
and LoFlo Sidestream CO2 Modules
b. Masimo Multigas Module
c. Batteries and Temperature Probes
d. Nellcor V-SAT SpO2 Sensors
e. Printer Batteries and ECG Esophageal Probes
f. Blood Pressure Cuffs, CO2 Sample Lines and
Adapters, and ECG Cable/Wire Sets
TM
2 years
TM
2 years
2 years
1 year
9 months
6 months
*
Seating
1. Surgery Stools
2. Lift Stools
3. Adjustable Stools
4. Dental Doctor and Assistant Stools
1 year
1 year
1 year
2 years
1. Midmark M9 and M11 Automatic Sterilizers
2.Soniclean® Ultrasonic Cleaners
Warranty
Period
1 year
2 years
Carts and Cabinets
1. Treatment Cabinets
2. Mobile Desks
1 year
1 year
Imaging
(Must be installed by a certified Midmark installer.)
1.VetPro® Complete
2.VetPro® DC
3.VetPro® DR
4.VetPro® CR
2 years
2 years
2 years
1 years
Anesthesia Machines
1.Matrx® Anesthesia Machines
2. Plastic, Rubber and Disposable Parts and Products
3. Midmark Serviced (used)
5 years
*
6 months
Anesthesia Machines (Parts and Accessories)
1.Matrx and other Anesthesia Accessories (Including,
but not limited to, cylinder mounting blocks, induction
chambers, and gas supply components) 1 year
a. Plastic, Rubber and Disposable Parts and Products
(Including, but not limited to, breathing bags, breathing
tubes and endotracheal tubes.)
*
®
Scavenging
1.Matrx® Central Scavenger
2.Matrx® Wall/Post Mount Single Scavenger
5 years
1 year
Vaporizers
1. VIP 3000® Vaporizers
2. VXP™ Vaporizers
3. Midmark Serviced (Used) Vaporizers
5 years
1 year
1 year
Ventilators and Accessories
1.Matrx® Model 3000 Anesthesia Ventilators
1 year
Fluid Warmers
1. iWarm™ IV Fluid Warmer
1 year
*The warranty as to these products or components only applies if
such products or components are defective in material or
workmanship at the time of delivery to the original retail purchaser
and such defects are reported to Midmark within three (3) days
from the date of delivery.
This Warranty Guide is not the entire warranty. Please see the
applicable Limited Warranty for all other terms, conditions, and
limitations.
63
Ordering Information
Midmark Product Ordering Notes
1. ORDERING
Please include the following with your order:
• Quantity
• Part number
• Description
• Signature of person placing the order
• Approximate shipping date required
• Method of transportation
• Purchase order number
Model number and name of item must be specified on purchase order.
Minimum Order - $25.
2. SPECIAL DESIGN
Orders for equipment of special design, construction, finish or upholstery are
not subject to cancellation after your acceptance of our acknowledgement.
Special design products, custom design cabinets and special upholstery
WILL NOT be accepted for credit.
3. RETURN OF MERCHANDISE
Authorization must be obtained for the return of any item. If return is
authorized, transportation charges must be prepaid. Items returned for
credit are subject to a charge of 25% or more to cover inspection,
reconditioning and repackaging. Anesthesia accessory returns are not
accepted for rubber goods over 30 days old, rubber goods not in original,
sealed package and all hoses. Goods without a Return Goods Authorization
(RA) and merchandise more than 90 days old (from Midmark invoice date) are
also not accepted for return.
Note: Certain items are non-refundable: Specials, Midmark Casework, Ritter
Casework, Care Exchange Workstations, Discontinued Items or Parts, Custom
or Non-standard Colors, Service Upholstery and Service Parts if value is less than
$50.
TM
4. FREIGHT DAMAGE
It is the consignee's responsibility to count and inspect upon receiving.
Merchandise arriving with external damage should be described on Proof
of Delivery, Delivery Receipt or Bill of Lading. In case of concealed damage,
consignee must contact the carrier within 15 days after receipt and claims
for damage instituted.
5. IMPROVE PRODUCT QUALITY
Midmark Corporation reserves the right to change design and construction
without notice.
6. ORDER CHANGES
Any requested changes to an order within 5 days of the scheduled/
acknowledged ship date will result in an extension to the scheduled ship
date. The new ship date will be re-scheduled/acknowledged based on
the extent of the changes requested.
7. CASEWORK ORDER CHANGES
Any order changed within 3 weeks prior to the scheduled ship date will
result in a change of ship date and may incur additional costs. Any order
cancelled within ten days before the scheduled shipping date will be
charged a 20% cancellation charge.
64
8. SPECIAL ORDER REQUIREMENTS
Any order requiring special deviation from standard products will carry the
following disclaimer:
We hereby accept and acknowledge the above captioned order provided,
however, because of the special nature of this order in that this equipment is
being supplied upon special design specifications, special materials, and/or
field modification, as per your request, the standard warranties of Midmark
on its products are not applicable to the order, and this acceptance and
acknowledgement is conditioned upon your indemnification and promise to
hold Midmark, its officers, employees and agents, harmless in respect to
any and all warranty claims, damages, both direct and consequential,
expenses, costs, and any liability arising from the use of or relating to this
special equipment.
9. ANESTHESIA SERVICE AND REPAIR POLICY
Midmark offers evaluation and repair service on Matrx® anesthesia
equipment. Products returned for repair require a return authorization (RA).
Contact Customer Experience at 1-800-643-6275, press 8 then 108911, to
obtain an RA number. Send the product freight prepaid.
Vaporizers returned for servicing also require an RA. A purchase order
number must accompany the vaporizer. Subsequent to servicing, each
vaporizer has a separate service and performance record established which
is placed on file in the Midmark Vaporizer Service Center in Versailles, Ohio.
Should the need arise to verify that your equipment has been maintained to
manufacturer’s specifications, we will be happy to supply this information.
10. IMAGING ORDER INFORMATION
Imaging products are not available through all Midmark authorized dealers.
Please contact Midmark Animal Health Customer Experience if you need
assistance locating an authorized dealer in your area.
65
Midmark Corporation
Tampa Facility
1700 South Patterson Boulevard
Suite 400
Dayton, Ohio 45409
10010 N. Dale Mabry Highway
Suite 110
Tampa, FL 33618
Customer and Technical Services:
Tel: 1-800-MIDMARK (1-800-643-6275)
Fax: 1-877-725-6495
midmark.com
Tel: 1-800-MIDMARK (1-800-643-6275)
Fax: 1-813-264-6218
Lincolnshire Facility
Versailles Facility
675 Heathrow Drive
Lincolnshire, IL 60069
60 Vista Drive
Versailles, OH 45380
Tel: 1-800-MIDMARK (1-800-643-6275)
Fax: 1-847-415-9801
Tel: 1-800-MIDMARK (1-800-643-6275)
Fax: 1-877-725-6495
Better Patient Care. Better Business.™
midmarkanimalhealth.com
Trade Name Notification Canis Major, Matrx, VMS, VMS Plus, VMC, VME, VME2, VMR, VML, VIP
3000, VXP, Revive-A-Pet, VetPro, Cardell, UltraClave, and Soniclean are trademarks or registered
trademarks of Midmark Corporation or its subsidiaries. Satelec, Acteon, Kydex, Athena Champion, Little
Pro and Meisinger are all trademarks or registered trademarks of their respective companies. Other
products or services may be trademarks or registered trademarks of their respective companies.
CARB 93120.2 Phase 2 Compliant
© 2009 Midmark Corporation • Products subject to improvement changes without notice • Litho in U.S.A. • 007-0739-00 Rev. I1 (2/16)
Midmark is an ISO 13485 and ISO 9001 Certified Company.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
