owner

s manual

MODEL 53097-1

3 BEFORE YOU

PROCEED

4 SAFETY

PRECAUTIONS

5 TOOLS, SUPPLIES,

AND REQUIRED

EQUIPMENT

6 ANATOMY OF

YOUR REVO

7 QUICK START:

GETTING UP TO

SPEED

8 TRAXXAS TQ

i

RADIO SYSTEM

16 THE TRX 3.3

RACING ENGINE

30 DRIVING

YOUR REVO

31 BASIC TUNING

ADJUSTMENTS

37 MAINTAINING

AND STORING

YOUR REVO

39 ADVANCED TUNING

ADJUSTMENTS

43 TQ

i

ADVANCED

TUNING GUIDE

INTRODUCTION

Thank you for choosing a Traxxas Revo. We believe you have purchased the finest, most technologically advanced R/C monster truck available. Revo proudly demonstrates Traxxas’ passionate commitment innovation, ultimate performance, and unmatched engineering. Revo’s radically advanced suspension, chassis, and transmission design takes performance to a higher level. Now with larger TRX 3.3 Racing Engine, Revo pushes the performance envelope even further with relentless, over-the-top horsepower. We’ve engineered the Revo to allow you to experience power, control, and responsiveness that surpasses anything else you’ve driven.

The new TRX 3.3 Racing Engine is the most powerful engine of its size ever available in a Ready-To-Run truck. Advanced engineering and design, along with thousands of hours of testing, puts the

TRX 3.3 in a class by itself. Each part of the TRX 3.3 - from the air filter on the slide carburetor, to the tip on the dyno-tuned exhaust system - has been carefully engineered to provide maximum power over the broadest rpm range.

Traxxas was the first with standard on-board electric starting.

The EZ-Start has evolved into an incredibly advanced and reliable starting solution, featuring thermal protection for the motor and built-in diagnostics to monitor the condition of the glow plug.

Traxxas Support

Traxxas support is with you every step of the way. Refer to the next page to find out how to contact us and what your support options are.

Quick Start

This manual is designed with a Quick

Start path that outlines the necessary procedures to get your model up and running in the shortest time possible. If you are an experienced R/C enthusiast, you will find it helpful and fast.

Be sure and read through the rest of the manual to learn about important safety, maintenance, and adjustment procedures. Turn to page 7 to begin.

Revo 3.3’s OptiDrive ® electronic shift module uses advanced microprocessor control to sense vehicle speed and optimize forward and reverse shifting. This revolutionary, patent-pending system allows the transmission to be lighter with fewer moving parts for reduced inertial mass and greater torque handling.

OptiDrive provides constant drive engagement for seamless, responsive acceleration.

We know you’re excited about getting your new Revo on the road, but it’s very important that you take some time to read through the Owners Manual. This manual contains all the necessary setup, break-in, tuning, and operating procedures that allow you to unlock the incredible performance and adjustment potential that Traxxas engineers designed into Revo. Even if you are an

experienced R/C enthusiast, it’s important to read and follow the procedures in this manual. Revo contains new technologies in the engine, suspension, and transmission operation that you may not be familiar with. Pay particular attention to the fuel and break-in requirements for the engine. The advanced design of the TRX 3.3 Racing Engine has a special break-in procedure that has been developed and proven to produce the best-performing engine possible. Using traditional or old-fashioned procedures could reduce engine performance and longevity.

Revo is made to be a complete package that starts with the highest level of engineering and is equipped stock with the most powerful

Ready-To-Race ® engine available. We want you to feel confident that you own the best-performing truck in the market and that it is backed by a team of professionals who aim to provide the highest level of factory support possible. Revo is about experiencing total performance and satisfaction, not just with your truck, but also with the company that stands behind it.

Thank you again for going with Traxxas. We work hard every day to assure you the highest level of customer satisfaction possible.

We truly want you to enjoy your new Revo!

2 • REVO 3.3

BEFORE YOU PROCEED

Carefully read and follow all instructions in this and any accompanying materials to prevent serious damage to your model. Failure to follow these instructions will be considered abuse and/or neglect.

Before running your model, look over this entire manual and examine the model carefully. If for some reason you decide it is not what you wanted, then do not continue any further. Your hobby

dealer absolutely cannot accept a model for return or exchange after it has been run.

Warnings, Helpful Hints, & Cross-References

Throughout this manual, you’ll notice warnings and helpful hints identified by the icons below. Be sure to read them!

An important warning about personal safety or avoiding damage to your model and related components.

Special advice from Traxxas to make things easier and more fun.

Refers you to a page with a related topic.

Technical support is available Monday through Friday from 8:30am to 9:00pm central time. Technical assistance is also available at

Traxxas.com. You may also e-mail customer support with your question at [email protected] Join thousands of registered members in our online community at Traxxas.com.

Traxxas offers a full-service, on-site repair facility to handle any of your Traxxas service needs. Maintenance and replacement parts may be purchased directly from Traxxas by phone or online at www.BuyTraxxas.com. You can save time, along with shipping and handling costs, by purchasing replacement parts from your local dealer.

Do not hesitate to contact us with any of your product support needs.

We want you to be thoroughly satisfied with your new model!

REGISTERING YOUR MODEL

In order to serve you better as our customer, please register your product within 10 days of your purchase online at Traxxas.com/register.

T r a x x a s . c o m / r e g i s t e r

SUPPORT

If you have any questions about your model or its operation, call the Traxxas Technical Support line toll-free at:

1-888-TRAXXAS (1-888-872-9927)*

Traxxas

6200 Traxxas Way

McKinney, Texas 75070

Phone: 972-549-3000

Toll-free 1-888-TRAXXAS

Internet

Traxxas.com

E-mail: [email protected]

Entire contents ©2014 Traxxas.

Traxxas, Ready-To-Race, Ready-

To-Win, Revo 3.3 and ProGraphix are trademarks or registered trademarks of Traxxas. Other brand names and marks are the property of their respective holders and are used only for purposes of identification. No part of this manual may be reproduced or distributed in print or electronic media without the express written permission of

Traxxas. Specifications are subject to change without notice.

FCC Compliance

This device contains a module that complies with the limits for a Class B digital device as described in part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

The limits for a Class B digital device are designed to provide reasonable protection against harmful interference in residential settings. This product generates, uses and can radiate radio frequency energy, and, if not operated in accordance with the instructions, may cause harmful interference to radio communications. The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Canada, Industry Canada (IC)

This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device.

Radio Frequency (RF) Exposure Statement

This equipment complies with radio frequency exposure limits set forth by FCC and Industry Canada for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of

20 centimeters between the radiator and your body or bystanders and must not be co-located or operated in conjunction with any other antenna or transmitter.

*Toll-free support is available to U.S. residents only.

REVO 3.3 • 3

Skill Level = Myriad Semi Bold

1 2 3 3+ 4 5 manual should be strictly followed to ensure safe

sensibly and with care, and it will be exciting, safe, and fun for you and those around you. Failure to operate your Revo in a safe and responsible manner may result in property damage and serious injury. The precautions outlined in this manual should be strictly followed to help ensure safe operation. You alone must see that the instructions are followed and the precautions are adhered to.

operation of your model.

IMPORTANT POINTS TO REMEMBER

This model is not intended for use by children (minors) under 16 years of age without the supervision of a responsible and knowledgeable adult.

• Revo is very fast! The Revo is intended for experienced users with a high level of skill.

The TRX 3.3 Racing Engine is extremely powerful and may require skilled driving to maintain control. Children under 16 years of age and inexperienced drivers should not operate the Revo without the supervision of a responsible and knowledgeable

(experienced) adult.

Model engine fuel is dangerous and highly poisonous.

Always follow all directions and precautions printed on the fuel container. Model engine fuel is poisonous to humans and animals. Drinking the fuel can cause blindness and death. Handle with care and respect.

• Model engine fuel, especially when in a fuel dispensing bottle, may look like a cool drink to a child.

Keep all fuel out of the reach of children at all times. Do not place fuel containers on the ground where children can reach them while you are driving.

• Model engine fuel is flammable. Never allow smoking, sparks, heat or flame in the presence of fuel or fuel vapors.

• The engine, brakes, and exhaust system may become extremely hot during use.

Be careful not to touch the parts, especially when refueling or stopping the engine.

Model requires detailed setup, and/or maintenance procedures with required support equipment.

Previous experience with radio controlled models is mandatory. This model is capable of very high speeds and requires a high level of skilled driving control.

1

engine exhaust. Always run your Revo outdoors, in a well-ventilated area. Never run the engine indoors.

• Do not operate your Revo at night, or anytime your line of sight to the model may be obstructed or impaired in any way.

• Never operate your Revo in crowds of people or busy pedestrian areas. Revo is very fast and could cause injury to those unaware of its presence. Keep small children at a safe distance away from the operating area.

• Because Revo is controlled by radio, it is subject to radio interference from many sources beyond your control. Since radio interference can cause momentary loss of control, always allow a safety margin in all directions around your model to prevent collisions.

• Do not kink the antenna wire. Kinks in the antenna wire will reduce range.

• The engine can be loud. If the noise makes you uncomfortable, wear ear protection.

Be considerate of your neighbors by not running your model early in the morning or late in the evening.

• Do not cut the antenna “stinger” or any other part of the antenna wire. Cutting the antenna will reduce range.

• Extend the antenna as far as possible for maximum range. It is not necessary to extend the antenna wire out of the body, but wrapping or coiling the antenna wire should be avoided.

• Do not allow the antenna wire to extend outside the body without the protection of an antenna tube, or the antenna wire may incur crash damage that could reduce range.

Most importantly, use good common sense at all times.

BATTERIES AND BATTERY CHARGING

BELOW TEXT HAS BEEN UPDATED on 3-14-07

Kent wants maintenance text to be at the END of the paragraph.-- KB

is your responsibility to charge and care for the battery packs properly. In addition to your battery and charger instructions, here are some more tips to keep in mind.

Choose the Model That is Right For You.

For individual Models

• Use the supplied charger to charge the included battery. See “Charging

the EZ-Start Battery” on page 21.

• Do not charge batteries inside of an automobile. Do not charge batteries while driving in an automobile. The charger is equipped with a long cord intended to allow the battery to be charged outside of an automobile when using the automobile’s auxiliary power socket. If the cord will not reach outside of the automobile, find another power source.

• Never leave batteries to charge unattended.

• Allow the battery pack to cool off before charging.

• Do not use battery packs that have been damaged in any way. Do not use battery packs that have damaged wiring, exposed wiring, or a damaged connector as this may create the risk of fire.

• Children should have responsible adult supervision when charging and handling batteries.

• Never charge batteries on wood, cloth, carpet or on any other flammable material.

These models are capable of very high speeds and require an even higher level of skilled driving control. Models require detailed setup, and/or maintenance procedures with required support equipment.

• Do not operate the charger in a cluttered space, or place objects on top of the charger or battery.

• If a battery gets hot to the touch during the charging process

(temperature greater than 140°F / 60°C), disconnect the battery from the charger and discontinue charging immediately.

• Always store battery packs safely out of the reach of children and pets.

• Do not expose the charger to water or moisture.

• Do not disassemble the charger.

• Only use approved chargers for Nickel Metal Hydride (NiMH) battery packs. Do not exceed the maximum charge rate of 1 amp.

• Do not short-circuit the battery pack. This may cause burns and severe damage to the battery pack.

• Do not burn or puncture the batteries. Toxic materials could be released.

If eye or skin contact occurs, flush with water.

• Store the battery pack in a dry location, away from heat sources and direct sunlight.

• NiMH batteries must be recycled or disposed of properly.

No previous experience with radio controlled models is required.

Model requires a minimum of setup, maintenance, or support equipment.

Previous experience with radio controlled models is recommended.

Model requires a higher level of setup, maintenance, or support equipment.

Previous experience with radio controlled models is mandatory. This model is capable of high speeds, requiring experienced driving control. Model requires detailed setup, and/or maintenance procedures with required support equipment.

Previous experience with radio controlled models is mandatory. This model is capable of very high speeds and requires an even higher level of skilled driving control. Model requires detailed setup, and/or maintenance procedures with required support equipment.

For Expert Drivers Only. This product is capable of extreme speed and acceleration! It carries our highest skill level rating and is intended for expert drivers only. Experience with nitro-powered radio controlled models is required!

Recycling Your Traxxas Power Cell NiMH Battery

Traxxas strongly encourages you to recycle your Power Cell NiMH battery when it has reached the end of its useful life.

Do not throw your battery in the trash

. All Power Cell NiMH battery packs display the RBRC (Rechargeable

Battery Recycling Corporation) icon, indicating they are recyclable. To find a recycling center near you, ask your local hobby dealer or visit www.

call2recycle.org.

4 • REVO 3.3

TOOLS, SUPPLIES, AND REQUIRED EQUIPMENT

Your Revo comes with a set of specialty metric tools. You’ll need to purchase other items, available from your hobby dealer, to operate and maintain your model.

SUPPLIED TOOLS AND EQUIPMENT

Shock wrench

8mm slipper clutch wrench

5mm turnbuckle wrench

Suspension multi-tool

4-way wrench

Glow plug wrench

Extra glow plug

17mm wheel wrench

1.5mm “L” wrench 2.0mm “T” wrench 2.5mm “L” wrench 2.5mm “T” wrench

Long Travel rocker and spring set

Extra oiled air filter set

(pre-filter and primary filter)

1200MAH

R

X

6V NiMH

SP1

136 1-R 00

Ma de in C hin

Suspension tuning shims and hollow balls

NiMH battery charger*

RX (receiver) charger adapter

NiMH 7.2V battery pack

RX battery power pack

(installed in model)

Fuel dispensing bottle

REQUIRED TOOLS AND EQUIPMENT

(sold separately)

10% quart - #5010

20% quart - #5020

33% quart - #5030

10% gallon - #5060

20% gallon - #5070

33% gallon - #5080

Traxxas Top Fuel

see page 20

4 AA alkaline batteries

After-run oil to protect the engine from corrosion

Small flat-blade screwdriver for tuning (1/8 inch blade)

Air filter oil

Traxxas part #5263

For more information on radio system batteries, see Use the

Right Batteries on page 10.

Recommended Equipment

These items are not required for the operation of your model, but are a good idea to include in any R/C toolbox:

• Safety glasses

• Traxxas Ultra Premium Tire

Glue, part #6468 (CA glue)

• Hobby knife

• Side cutters and/or needle nose pliers

• Philips screwdriver

• Soldering iron

REVO 3.3 • 5

ANATOMY OF THE REVO 3.3

EZ-Start Motor

Roll Hoop

TRX 3.3 Racing Engine

see pg. 17 for details

Exhaust Header

Fuel Line

Pressure Line

EZ-Start Plug

Bumper Mount

Pipe Hanger

Body Mount Post

Tuned Pipe

Engine Shut-off Clamp

Fuel Tank

Driveshaft (Half Shaft)

Fuel Cap

6 • Revo 3.3

Access Plug

(for two-speed adjustment)

Throttle/

Brake Servo

(inside box)

Air Filter

Shifting Servo

(inside box)

Shift Rod

Spur Gear

(under roll hoop)

Slipper Clutch

(under roll hoop)

Chassis

Fuel Cap

Handle

Transmission

Disc Brake

Receiver Box

Antenna

5-cell RX Power Pack

(inside box)

Brake Tension

Adjuster

Charging Jack

(underneath)

Hex Hub

Pivot Ball

Axle Carrier

Steering Servo

Suspension Arm

Push Rod

Rocker

Skid Plate

Bumper

Differential

(under chassis)

Bulkhead

(under chassis)

Oil Shock (Damper)

Spring Pre-load Adjuster

Steering Servo

On/Off Switch

Toe Link (Turnbuckle)

OptiDrive

Electronic

Shift Module

QUICK START: GETTING UP TO SPEED

The following guide is an overview of the procedures for getting your Revo running, from opening the box to breaking in and tuning your engine. Refer to the pages indicated for details on each step. Look for the Quick Start logo on the bottom corners of Quick Start pages.

1. Read the safety precautions on page 4

For your own safety, understand where carelessness and misuse could lead to personal injury.

9. Fill the fuel tank • See page 21

Use your fuel-dispensing bottle to fill the tank.

2. Charge the EZ-Start battery pack • See page 23

The EZ-Start requires a fully charged 7.2-volt battery pack (included).

10. Connect the EZ-Start to the model • See page 24

Learn the proper way to use the EZ-Start electric starting system.

3. Charge the RX Power Pack • See page 10

The 5-cell receiver battery is already installed in the truck.

11. Start the engine • See page 25

Learn to use the correct starting procedure for your TRX 3.3.

4. Install batteries in the transmitter • See page 10

Revo requires 4 AA alkaline batteries for the transmitter

(sold separately).

5. Install the EZ-Start battery • See page 24

Install and connect a charged 7.2-volt battery pack in the EZ-Start controller.

6. Turn on the radio system • See page 11

Make a habit of turning the transmitter on first, and off last.

12. Break-in your engine • See page 25-26

Follow the break-in instructions exactly to ensure the best-performing, longest-lasting engine.

13. Tune your engine • See page 27

Learn how to set the fuel mixture needles for optimum engine performance.

7. Check servo operation • See page 12

Make sure the throttle, shifting, and steering servos are working correctly.

8. Range test the radio system • See page 13

Follow this procedure to make sure your radio system works properly at a distance and that there is no interference from outside sources.

14. Drive your Revo • See page 30

Learn to use the two-speed function on your truck, along with important driving precautions.

15. Maintain your Truck • See pages 37-38

Follow these critical steps to maintain the performance of your

Revo and keep it in excellent running condition.

The Quick Start Guide is not intended to replace the full operating instructions available in this manual.

Please read this entire manual for complete instructions on the proper use and maintenance of your Revo.

Look for the Quick Start logo at the bottom of

Quick Start pages.

REVO 3.3 • 7

To prevent loss of radio range do not kink or cut the black wire, do not bend or cut the metal tip, and do not bend or cut the white wire at the end of the metal tip.

Correct

No No No

Learn terms related to the TRX 3.3 Racing Engine beginning on page 18.

8 • REVO 3.3

TRAXXAS TQ

i

RADIO SYSTEM

INTRODUCTION

Your model includes the latest Traxxas TQi 2.4GHz transmitter with

Traxxas Link ™ Model Memory. The transmitter’s easy-to-use design provides instant driving fun for new R/C enthusiasts, and also offers a full compliment of pro-level tuning features for advanced users

– or anyone interested in experimenting with the performance of their model. The steering and throttle channels feature adjustable

Exponential, End Points, and Sub-Trims. Steering and braking Dual

Rate are also available. Many of the next-level features are controlled by the Multi-Function knob, which can be programmed to control a variety of functions. The detailed instructions (page 43) and Menu

Tree (page 46) included in this manual will help you understand and operate the advanced functions of the new TQi radio system. For additional information and how-to videos, visit Traxxas.com.

RADIO SYSTEM TERMINOLOGY

Please take a moment to familiarize yourself with these radio and power system terms. They will be used throughout this manual.

A detailed explanation of the advanced terminology and features of your new radio system begins on page 43.

2.4GHz Spread Spectrum – This model is equipped with the latest

R/C technology. Unlike AM and FM systems that require frequency crystals and are prone to frequency conflicts, the TQ 2.4GHz system automatically selects and locks onto an open frequency, and offers superior resistance to interference and “glitching.”

Current - Current is a measure of power flow through the electronics, usually measured in amps. If you think of a wire as a garden hose, current is a measure of how much water is flowing through the hose.

Frequency band - The radio frequency used by the transmitter to send signals to your model. This model operates on the 2.4GHz directsequence spread spectrum.

mAh – Abbreviation for milliamp hour. A measure of the capacity of the battery pack. The higher the number, the longer the battery will last between recharges.

Neutral position - The standing position that the servos seek when the transmitter controls are at the neutral setting.

NiCad - Abbreviation for nickel-cadmium. The original rechargeable hobby pack, NiCad batteries have very high current handling, high capacity, and can last up to 1000 charging cycles. Good charging procedures are required to reduce the possibility of developing a

“memory” effect and shortened run times.

NiMH - Abbreviation for nickel-metal hydride. Rechargeable NiMH batteries offer high current handling, and much greater resistance to the “memory” effect. NiMH batteries generally allow higher capacity than NiCad batteries. They can last up to 500 charge cycles.

A peak charger designed for NiMH batteries is required for optimal performance.

Receiver - The radio unit inside your model that receives signals from the transmitter and relays them to the servos.

Servo - Small motor units in your model that operates the steering, throttle, and shifting mechanisms.

Transmitter - The hand-held radio unit that sends throttle and steering instructions to your model.

Trim - The fine-tuning adjustment of the neutral position of the servos, made by adjusting the throttle and steering trim knobs on the face of the transmitter. Note: The Multi-Function knob must be programmed to serve as a throttle trim adjustment.

3-channel radio system - The TQi radio system, consisting of the receiver, the transmitter, and the servos. The system uses three channels: one to operate the throttle, one to operate the steering and one to shift.

RADIO SYSTEM PRECAUTIONS

• Do not kink the receiver’s antenna wire. Kinks in the antenna wire will reduce range.

• DO NOT CUT any part of the receiver’s antenna wire. Cutting the antenna will reduce range.

• Extend the antenna wire in the model as far as possible for maximum range. It is not necessary to extend the antenna wire out of the body, but wrapping or coiling the antenna wire should be avoided.

• The antenna wire must be installed into the antenna tube to protect it from getting cut or damaged, which will reduce range.

When installing the antenna wire into the antenna tube, be careful not to kink the wire by pressing it against the antenna tube cap.

The antenna wire should extend to just below or to within onehalf inch below the cap.

TRAXXAS TQ

i

RADIO SYSTEM

TRAXXAS TQ

i

RADIO SYSTEM

Your Revo is equipped with the TQi radio system. The TQi is a 3-channel system that provides control for up to three outputs. Revo is equipped with two high-torque steering servos connected via dual Channel 1 outputs. The TQi works in conjunction with the OptiDrive

®

Electronic Shift Module to monitor and control the input and output signals for the throttle and shifting servos (channels). The OptiDrive monitors the voltage of the on-board RX Power Pack. The

“Function” LED will flash red if the battery voltage is too low.

TRANSMITTER AND RECEIVER

REVO WIRING DIAGRAM

Set Button

Red/Green Status LED

see page 44 for more info

Throttle Neutral

Adjust

Steering Wheel

Charging Jack

(to charger)

Mad e in

Ch ina

R

X

RX Power Pack

5-cell NiMH

Battery

SP1

136

1-R

00

Menu Button

Antenna

On/Off

Switch

Telemetry

Voltage Wire

Connects the V/T port to any open receiver port.

Temp

Sensor

Steering

Trim

Multi-Function

Knob

Shift

Switch

Throttle

Trigger

Sensor Expansion

Port

Receiver

Voltage Sensor

RPM Sensor

Link

Button

LED

Steering Servo - CH1

OptiDrive Throttle - CH2

OptiDrive Shift - CH3

From Voltage/Temp Senor Port - CH4

RPM Sensor Port - RPM

Voltage/Temp Senor Port - V/T

OptiDrive ESM

(Electronic Shift

Module)

* Not used

Steering

Servos

Shifting Servo

(micro servo)

Power Switch

Battery Compartment

Traxxas Link

Wireless Module

To Transmission

(OptiDrive sensor)

Throttle Servo

If the transmitter status LED doesn’t light green, check the polarity of the batteries. If you see any other flashing signal from the LED, refer to the chart on page 44 to identify the code.

When rechargeable batteries begin to lose their charge, they will fade much faster than alkaline dry cells. Stop immediately at the first sign of weak batteries. Never turn the transmitter off when the battery pack is plugged in. The model could run out of control.

REVO 3.3 • 9

If the radio system doesn’t appear to work when the transmitter and receiver switches are turned on, check for correct battery installation.

Use the Right Batteries

Your transmitter uses AA batteries. Use new alkaline batteries. Do not use rechargeable AA cells to power the TQi transmitter, as they will not provide sufficient voltage for optimum transmitter performance.

Caution: Discontinue running your model at the first sign of weak batteries (flashing red light on the transmitter) to avoid losing control.

TRAXXAS TQ

i

RADIO SYSTEM

INSTALLING TRANSMITTER BATTERIES

Your TQi transmitter uses 4 AA batteries. The battery compartment is located in the base of the transmitter.

1. Remove the battery compartment door by pressing the tab and sliding the door open.

2. Install the batteries in the correct orientation, as indicated in the battery compartment.

3. Reinstall the battery compartment door and snap it closed.

4. Turn on the transmitter and check the status LED for a solid green light.

If the status LED flashes red, the transmitter batteries may be weak, discharged or possibly installed incorrectly. Replace with new batteries. The status LED does not indicate the charge level of the battery pack installed in the model.

CHARGING THE RECEIVER BATTERY

To power the radio system in the truck, your Revo 3.3 is equipped with the RX Power Pack, a rechargeable 5-cell NiMH battery pack.

The RX Power Pack must be fully charged before running the truck.

Use the supplied Molex adapter to connect the battery pack to the included 2amp DC charger. The charger uses sophisticated voltagedetection circuitry to monitor the battery and automatically stop charging when the pack has reached maximum capacity. Revo

3.3 has a built-in charging jack, so you do not have to remove the battery pack from the model for charging. Follow these steps to fully charge the receiver battery before operating your model:

1. Plug the Molex end of the included adapter into the charger. Plug the charger into a 12-volt automotive auxiliary power socket. The charger is compatible with 12-volt automotive auxiliary power sockets only. The LED on the charger will glow red to indicate it is ready to charge a battery.

Do not charge batteries inside of an automobile. Read the

Safety Precautions section of this guide.

2. Plug the black connector of the adapter into the charging jack located under the right front of the truck. The charging jack is protected by a rubber plug.

3. The charger’s LED will flash green, indicating that charging has begun. The flashing green LED on the charger indicates the charge progress.

CHARGE PROGRESS

4. When the battery is fully charged, the LED will light solid green.

See page 23 for more information on charger

LED codes.

x1

1 green flash 0 - 25% charged

x2

2 green flashes 25% - 50% charged

x3

3 green flashes 50% - 75% charged

x4

4 green flashes 75% or more charged

Solid green LED 100% charged

5. Unplug the charger from the power socket, and unplug the adapter from the charger and the model. Replace the rubber plug over the charging jack on the truck.

3

,

4

10 • REVO 3.3

TRAXXAS TQ

i

RADIO SYSTEM

BATTERY CARE

Some precautions should be taken to maintain the performance of the rechargeable NiMH receiver pack in your model. Improper use of the battery pack could result in personal injury or damage to your truck.

• Only use approved chargers for NiMH battery packs (such as the

Traxxas EZ-Peak Plus, part #2933). Do not exceed the maximum charge rate of 1 amp.

• Do not short-circuit the battery pack. This may cause burns and severe damage to the battery pack

• Do not burn or puncture the batteries. Toxic materials could be released. If eye or skin contact occurs, flush with water.

• Store the battery pack in a dry location, away from heat sources and direct sunlight.

• NiMH batteries must be recycled or disposed of properly.

• Do not completely discharge the RX Power Pack or you could damage it. Do not use dischargers on the pack. Store the battery with at least 25% charge. Stop running and recharge at the first indication of reduced voltage.

• After connecting a fully-drained battery to the charger, it may take up to 15 seconds for the charger to sense the battery and begin to charge. To start charging immediately, plug the battery pack into the charger and then plug the charger into the wall socket.

RADIO SYSTEM RULES

• Always turn your TQi transmitter on first and off last. This procedure will help to prevent your model from receiving stray signals from another transmitter, or other source, and running out of control. Your model has electronic fail-safes to prevent this type of malfunction, but the first, best defense against a runaway model is to always turn the transmitter on first, and off last.

• In order for the transmitter and receiver to bind to one another, the receiver in the model must be turned on within 20 seconds of turning on the transmitter. The transmitter LED will flash fast red indicating a failure to link. If you miss it, simply turn off the transmitter and start over.

• Always have the transmitter and receiver turned on before you start the engine. Never turn the radio system off while the engine is running. The on/off switch in the model only turns the receiver on and off. It does not turn off the engine.

Always use new or freshly charged batteries for the radio system.

Weak batteries will limit the radio signal between the receiver and the transmitter. Loss of the radio signal can cause you to lose control of your model.

1

2

3

Always turn your transmitter on first.

Always turn your receiver on second.

Then start your engine.

Remember, always turn the

TQ transmitter on first and off last to avoid damage to your model.

Automatic Failsafe

The TQi transmitter and receiver are equipped with an automatic failsafe system that does not require user programming. In the event of signal loss or interference, the throttle will return to neutral and the steering will hold its last commanded position. If failsafe activates while you are operating your model, determine the reason for signal loss and resolve the problem before operating your model again.

6

REVO 3.3 • 11

To prevent losing control of your model, it is important to stop at the first sign of a weak receiver battery. Visible warning signals include sluggish steering response and shortened radio range.

In addition, the OptiDrive is equipped with a low-voltage indicator and a failsafe circuit.

When the voltage of the receiver battery drops below 4.3 volts, the “Function” LED on the

OptiDrive will flash red. If the voltage drops below 4.3 volts for more than 2 seconds, the

OptiDrive ignores throttle and shift signals and applies neutral

(failsafe mode). Steering will still be operational and the

“Function” LED on the OptiDrive will flash red. The OptiDrive will stay in failsafe mode until the power is turned off or the receiver battery voltage rises above 4.3 volts for more than 2 seconds. Anytime the “Function”

LED flashes red, it is time to stop and recharge your battery pack.

Do not try to continue running your model with weak receiver batteries on board.

TRAXXAS TQ

i

RADIO SYSTEM

RADIO SYSTEM CONTROLS

RADIO SYSTEM BASIC ADJUSTMENTS

Throttle Neutral Adjustment

The throttle neutral adjustment is located on the transmitter face and controls the forward/reverse travel of the throttle trigger. Change the adjustment by pressing the button and sliding it to the desired position. There are two settings available:

50/50: Allows equal travel for both acceleration and reverse.

70/30: Allows more throttle travel (70%) and less reverse travel (30%).

We strongly recommend to leave this control in its factory location until you become familiar with all the adjustments and capabilities of your model.

Note: 50/50 is the default factory setting. To change the throttle neutral adjust position, turn the transmitter off before adjusting the neutral position.

Steering Trim

The electronic steering trim located on the face of the transmitter adjusts the neutral

(center) point of the steering channel.

Multi-Function Knob

The Multi-Function knob can be programmed to control a variety of functions. From the factory, the Multi-Function knob controls steering sensitivity, also known as exponential or “expo.” When the knob is turned counterclockwise all the way to the left (default position), expo is off and steering sensitivity will be linear (the most commonly used setting). Turning the knob clockwise will “add expo” and decrease the steering sensitivity in the initial range of steering wheel travel left or right from center.

For more detail on steering exponential, refer to pages 13-14.

USING THE RADIO SYSTEM

The TQi Radio System has been pre-adjusted at the factory. The adjustment should be checked before running the model, in case of movement during shipping. Here’s how:

1. Turn the transmitter switch on. The status LED on the transmitter should be solid green (not flashing).

2. Turn on the receiver switch in the model. The switch is located on the receiver/battery compartment.

3. Position the Revo so that its front wheels are off the ground.

Make sure your hands are clear of the moving parts of the model.

4. Turn the steering wheel on the transmitter back and forth and check for rapid operation of the steering servo. Also, check that the steering mechanism is not loose or binding. If the steering operates slowly, check for weak receiver batteries.

5. When looking down at the model, the front wheels should be pointing straight ahead.

If the wheels are turned slightly to the left or right, slowly adjust the steering trim control on the transmitter until they are pointing straight ahead.

7

12 • REVO 3.3

TRAXXAS TQ

i

RADIO SYSTEM

6. Operate the throttle trigger on the transmitter and check for rapid operation of the throttle servo. When the throttle trigger is pulled back, the carburetor should open. When the throttle trigger is pushed all the way forward, the brake should lock.

7. Once adjustments are made, turn off the receiver on your model, followed by the hand-held transmitter.

Range-Testing the Radio System

Before each running session with your model, you should range-test your radio system to ensure that it operates properly.

1. Turn on the radio system and check its operation as described in the previous section.

2. Have a friend hold the model with the engine off.

3. Walk away from the model with the transmitter until you reach the farthest distance you plan to operate the model.

4. Operate the controls on the transmitter once again to be sure that the model responds correctly.

5. Do not attempt to operate the model if there is any problem with the radio system or any external interference with your radio signal at your location.

Higher

Speeds Require Greater Distance

The faster you drive your model, the more quickly it will near the limit of radio range. At 60mph, a model can cover 88 feet every second! It’s a thrill, but use caution to keep your model in range. If you want to see your model achieve its maximum speed, it is best to position yourself in the middle of the truck’s running area, not the far end, so you drive the truck towards and past your position.

In addition to maximizing the radio’s range, this technique will keep your model closer to you, making it easier to see and control.

No matter how fast you drive your model, always leave adequate space between you, the model, and others. Never drive directly toward yourself or others.

TQi Binding Instructions

For proper operation, the transmitter and receiver must be electronically ‘bound.’ This has been done for you at the factory.

Should you ever need to re-bind the system or bind to an additional transmitter or receiver, follow these instructions. Note: You will need to open the receiver box to access the receiver. The receiver must be connected to a 4.8-6.0v (nominal) power source for binding and the transmitter and receiver must be within 5 feet of each other.

1. Press and hold the transmitter’s SET button as you switch transmitter on. The transmitter’s LED will flash red slowly.

Release the SET button.

2. Press and hold the receiver’s LINK button as you switch on the model on. Release the LINK button.

3. When the transmitter and receiver’s LEDs turn solid green, the system is bound and ready for use. Confirm that the steering and throttle operate properly before driving your model.

Steering Sensitivity (Exponential)

The Multi-Function knob on the TQi transmitter has been programmed to control Steering Sensitivity (also known as exponential). The standard setting for Steering Sensitivity is

“normal (zero exponential),” with the dial full left in its range of travel. This setting provides linear servo response; the steering servo’s movement will correspond exactly with the input from the transmitter’s steering wheel. Turning the knob clockwise from center will result in “negative exponential” and decrease steering sensitivity by making the servo less responsive near neutral, with increasing sensitivity as the servo nears the limits of its travel range. The farther you turn the knob, the more pronounced the change in steering servo movement will be. The term “exponential” comes from this effect; the servo’s travel changes exponentially relative to the input from the steering wheel. The exponential effect is indicated as a percentage—the greater the percentage, the greater the effect. The illustrations below show how this works.

Normal Steering Sensitivity (0% exponential)

In this illustration, the steering servo’s travel (and with it, the steering motion of the model’s front wheels) corresponds precisely with the steering wheel. The ranges are exaggerated for illustrative purposes.

When the engine is running, do not use throttle trim from the transmitter to adjust the engine idle speed.

Always use the idle speed adjustment screw (see page

17) on the carburetor.

8

REVO 3.3 • 13

To prevent loss of radio range, do not kink or cut the black wire, do not bend or cut the metal tip, and do not bend or cut the white wire at the end of the metal tip.

Correct

No No No

TRAXXAS TQ

i

RADIO SYSTEM

Decreased Steering Sensitivity (Negative Exponential)

By turning the Multi-Function knob clockwise, the steering sensitivity of the model will be decreased. Note that a relatively large amount of steering wheel travel results in a smaller amount of servo travel. The farther you turn the knob, the more pronounced the effect becomes. Decreased steering sensitivity may be helpful when driving on low-traction surfaces, when driving at high speed, or on tracks that favor sweeping turns where gentle steering inputs are required. The ranges are exaggerated for illustrative purposes.

Turning Range at Transmitter

Effective Turning

Range on Model

Experiment! Try varying degrees of exponential. It’s easy to go back to “zero” if you don’t like the effect. There’s no wrong way to adjust exponential. Any setting that makes you more comfortable with your model’s handling is the “right setting.”

SETTING UP THE ANTENNA

The receiver antenna has been setup and installed from the factory. The antenna is secured by a 4x5mm set screw. To remove the antenna tube, simply remove the set screw with the included 2mm wrench.

Antenna

Tip

When installing the antenna, first slide the antenna wire into the bottom of the antenna tube until the white tip of the antenna is at the top of the tube under the black cap.

Next insert the antenna tube into the mount; then, install the set screw

Antenna

Tube

Antenna

Nut

next to the antenna tube. Use the supplied 2mm wrench to tighten the screw just until the antenna tube is securely in place. Do not overtighten. Do not bend or kink the antenna wire! See the sidebar

for more information.

PROGRAMMING THE OPTIDRIVE

®

ESM

The OptiDrive ESM electronically monitors vehicle speed and controls forward and reverse shifting. Controlling the shift action electronically rather than by mechanical systems reduces the number of components in the transmission. The transmission weighs less, there is lower rotational mass for quicker acceleration, and there is constant drive engagement for smooth power delivery.

The OptiDrive module prevents the transmission from changing directions while the truck is in motion. The truck must be completely stopped to change directions, regardless of the position of the shift selector switch on the transmitter. The OptiDrive module is preset at

the factory. If the transmitter throttle trim adjustment is changed, or an aftermarket servo is installed, then the OptiDrive module will need to be re-programmed.

1. The engine must be shut off. The radio system must be on (receiver and transmitter).

2. Set the TQi Transmitter to its factory default shift settings:

A. Turn transmitter off.

B. Hold both MENU and SET.

C. Turn transmitter on.

D. Release MENU and SET. The transmitter LED will blink red.

E. Press SET to clear settings. The LED will turn solid green and the transmitter is restored to default.

Note: DO NOT reverse the servos after programming the OptiDrive.

If settings were changed after programming the OptiDrive, it will have to be reprogrammed.

3. With the throttle at neutral, press and hold the

SET button until the Function LED flashes green twice and then release the button immediately.

You are now in programming mode.

14 • REVO 3.3

4. Pull the transmitter throttle trigger to the full throttle position. Hold it there until the Function LED flashes green three times.

Note: The throttle servo will not move during programming even though it is connected to the controller.

5. Release the transmitter throttle trigger allowing it to return to neutral. The

Function LED will turn solid green, indicating that the shifting servo is OK to shift and the programming has been completed. The controller is now programmed and ready to go!

Note: If the Function LED does not turn solid green in this step, it may be necessary to readjust the throttle linkage so that the throttle trim is as close to the center “0” setting as possible when the carburetor is closed.

• If the transmitter throttle settings are changed, it will be necessary to complete the programming sequence again.

• If the SET button is released before the Function LED flashes green twice in step 3, the OptiDrive will return to the normal operation mode.

• If you experience any problems during programming, turn the receiver off, then on again, and repeat the programming steps.

For instructions on how to use the OptiDrive with aftermarket radio systems, or to access advanced programming options, visit

Traxxas.com.

TRAXXAS TQ

i

RADIO SYSTEM

Large adjustments to the throttle trim and/or throttle linkage may require re-setting the OptiDrive to maintain proper shifting action.

For transmission durability, the OptiDrive ESM limits the model’s reverse speed to about 70% of full throttle.

If settings are changed, and you notice a decrease in forward top speed, you could have the OptiDrive system reversed. Return the TQi to default settings (see page 14) and re-program the OptiDrive

Module. For programming with aftermarket radio systems, please see our website.

OptiDrive Operation

• Green “Function”

Shift allowed

• Red flashing “Function”

Low battery, see pg. 12

• Red “Sensor” a) Sensor, throttle or shift circuit is broken. Possible disconnected or broken sensor, throttle or shift wires. Possible damaged sensor. b) Receiver has lost signal from the transmitter, the OptiDrive has entered fail-safe (throttle and shift servos become unresponsive).

• Blue flashing “Sensor“

Normal operation as vehicle moves. Indicates signal pulse from sensor. Depending on the rotor position, solid blue or off when vehicle is at rest.

REVO 3.3 • 15

Traxxas strongly discourages changing or modifying any part of the TRX 3.3 Racing

Engine. Old tech tips and tricks that may have boosted the power of other engines could seriously diminish the performance of the

TRX 3.3 Racing Engine.

There’s more advanced thinking, development and testing in the stock parts of your TRX 3.3 Racing

Engine than in many aftermarket manufacturer’s performance parts. The TRX

3.3 Racing Engine is already the most powerful engine in its class and may not benefit from average, lowtech, aftermarket bolt on performance items.

THE TRX 3.3 RACING ENGINE

INTRODUCTION

The TRX

®

3.3 Racing Engine is the next generation of TRX nitro power. The larger displacement and advanced porting generate class-leading horsepower while still maintaining the TRX Racing

Engine characteristics of broad, linear power delivery and ease of tuning. Focused engineering and rigorous testing have yielded unprecedented power and uncompromising performance that turns ready-to-run into Ready-To-Race®.

The TRX 3.3 Racing Engine takes a total-system approach. Each part of the engine, from the air filter to the exhaust tip, is carefully engineered to work in harmony with other engine components. Each part complements the next, to extract maximum power. The TRX 3.3

Racing Engine is designed to be tolerant of variations in tuning, and to run successfully through a wide range of variable atmospheric conditions such as changes in temperature, humidity, and altitude.

In order to get the longest engine life and keep the TRX 3.3 Racing

Engine in top running condition, it is very important to perform regular routine maintenance. The number one cause of premature

engine wear and failure is lack of care and maintenance!

BREAK-IN

The TRX 3.3 Racing Engine is manufactured to exacting tolerances and requires a specially-designed break-in procedure to accomplish the final precision fitting of the internal engine components. It is very important that you follow the new break-in procedure as closely as possible to achieve the best performance and longest life from your

TRX 3.3 Racing Engine. Engine break-in will take between one and two hours. Old style break-in procedures, such as idling the engine on the bench for several tanks of fuel or simply running the engine with a very rich fuel mixture for the first 4 tanks of fuel, will not achieve the best results. Follow the easy steps in this manual.

AIR FILTER MAINTENANCE

Dirt is the worst enemy to your engine. A clean air filter is absolutely critical for long engine life. Due to the high performance nature of the TRX 3.3 engine, a tremendous amount of vacuum is created to move a large volume of high velocity air through the carburetor. This model is equipped with a two-stage high performance air filter which requires that the pre-filter stage be cleaned and oiled every hour of operation, and the primary filter be cleaned and oiled every 3-4 hours.

An extra pre-lubed air filter set has been provided with this model to encourage you to maintain the engine’s air filter.

AFTER-RUN MAINTENANCE

Perform after-run maintenance on the engine to prevent corrosion from building up on the internal engine components. The fuel naturally attracts moisture and corrosion can build up very quickly inside the engine if it is not prevented.

A few minutes spent before and after each time you run your model will allow you to enjoy it for a long time to come. Read on for more exciting details about your new engine.

16 • REVO 3.3

TRX 3.3 RACING ENGINE ILLUSTRATED

High-Speed

Needle

Fuel Intake

Air Intake

Carburetor

Flywheel

Crankshaft

Fuel Line

Two-Stage

Air Filter

Idle Speed

Screw

Tuned Pipe

Header

Glow Plug Wire

EZ-Start Plug

Ground Wire

Positive Wire

Negative Wire

Pressure

Line

Engine

Shut-off Clamp

Fuel Tank

THE TRX 3.3 RACING ENGINE

Glow Plug

Head Protector

PowerTune

Head

(Cylinder Head)

EZ-Start

®

Drive Unit

EZ-Start

®

Motor

Low-Speed Needle

Crankcase

Engine Mount

Throttle Arm

Clutch Bell

EZ-Start

Controller

Revo’s fuel tank is equipped with a built-in sintered bronze fuel filter.

REVO 3.3 • 17

18 • REVO 3.3

THE TRX 3.3 RACING ENGINE

TERMS TO KNOW

You’ll find these Nitro R/C engine terms throughout this section of the manual.

.15 - .15 or “15” refers to the displacement of the engine. The TRX 2.5

Racing Engine is .15 cubic inches or 2.5 cubic centimeters (cc). The name “TRX 2.5” is derived from the cc measurement.

.20 - .20 or “20” refers to the size of the engine. The TRX 3.3 is .20 cubic inches or 3.3 cubic centimeters (cc). The name “TRX 3.3” is derived from the cc measurement.

ABC - Abbreviation for aluminum, brass, and chrome. Refers to engine construction that consists of an aluminum piston that slides in a chrome-plated brass sleeve. The TRX 3.3 uses ABC construction.

Air filter - The air filter sits atop the carburetor and prevents harmful dust and dirt from entering the engine. Dirt ingestion is the number one cause of premature engine failure so the engine should never be run without the air filter in place.

BDC - Bottom dead center. The bottom-most position of the engine piston stroke.

Break-in - Break-in is the procedure for running a brand new engine according to specific instructions. This correctly prepares the engine for normal running. The break-in procedure can be different for different makes of engines. Follow the Traxxas directions for breakin exactly.

Carb - Abbreviation for carburetor.

Carburetor - The carburetor atomizes (mixes) the fuel with the air so that the engine can burn it. There are two types of carburetors; slide carbs and barrel carbs. The TRX 3.3 uses the superior slide carburetor design.

Clean-out - Cleaning-out is a condition that occurs when the engine is accelerating and the fuel mixture becomes sufficiently lean to allow the engine to continue into its upper rpm power band. It is usually characterized by a noticeable decrease in blue exhaust smoke and a dramatic increase in engine speed.

Combustion chamber - The combustion chamber is machined into the bottom of the cylinder head. This is where the glow plug ignites the fuel. The shape of the combustion chamber is designed to promote more efficient burning of the fuel.

Connecting rod - The connecting rod transfers the piston motion to the crankshaft. The TRX 3.3 Racing Engine uses a “knife-edged” connecting rod. The aerodynamic, sharpened edges allow it to

“slice” through the pressurized air/fuel mixture inside the crankcase.

Crankcase - The engine’s “body” that contains all of the running mechanical components.

Crankshaft - The main shaft of the engine that holds the reciprocating assembly.

Cooling fins - The cooling fins are milled into the cylinder head and crankcase and cause heat to be drawn away from the engine. Heat is removed when it dissipates into the air passing across the cooling fins. It is important to keep the fins clean of dirt and debris for maximum cooling efficiency.

Cylinder head (head) - The finned aluminum part on top of the engine that is responsible for dissipating most of the engine’s heat.

The combustion chamber is machined into the bottom of the head.

Dyno - Abbreviation for dynamometer. A precise piece of testing equipment that accurately measures engine power and torque output over the engine’s entire rpm range.

EZ-Start - Traxxas on-board electric starting system. The system consists of a hand held starter control unit and an on-board gearbox with an electric motor to spin the engine.

Fit - Usually refers to the fit of the piston and sleeve. If the fit is tight, the piston will feel very tight at top of the sleeve (top dead center), and the engine will have good sealing and compression. If the fit is loose, compression will be low and both the piston and sleeve should be replaced.

Flame-out - Occurs when the engine stops running at high rpm.

Usually the fault of an excessively lean fuel mixture or glow plug failure.

Fuel - (10%, 20%, 33%) The TRX 3.3 must have model engine fuel to run. Traxxas Top Fuel

is recommended. Fuel is sold in quarts and gallons from hobby dealers. The 10%, 20% and 33% labeling refers to the percentage of nitromethane contained in the fuel.

Fuel mixture - The ratio of fuel to air as determined by the needle settings of the carburetor.

Fuel tubing (fuel line) - The thick silicone tubing that carries fuel from the fuel tank to the carburetor.

Glow plug - The glow plug is located in the cylinder head at the top of the combustion chamber. It contains an element that glows red hot when voltage is applied. When the engine is being started, the heat from the glow plug ignites the fuel mixture and starts the combustion process.

Glow plug driver - This tool clips onto the glow plug and supplies the required voltage to light the glow plug element. It is also called an igniter. EZ-Start equipped engines do not require this separate tool.

Header - The aluminum tube that connects the exhaust system to the engine exhaust port. The length and diameter of the header must be carefully selected to extract the most power from the engine.

THE TRX 3.3 RACING ENGINE

High-speed needle (HSN) - Adjusts the carburetors fuel/air mixture at high throttle openings.

Idle speed - The speed (rpm) the engine runs at when the transmitter’s throttle trigger is at neutral.

Idle speed screw (ISS) - Located on the carburetor body. This screw adjusts the idle rpm of the engine.

Lean - A running condition where the engine is not getting enough fuel (for the available air). Symptoms include engine overheating, or the engine runs for a short time and then stalls, particularly at high speed. This is a dangerous condition that should be corrected immediately or it can ruin your engine.

Leaning the mixture - Turning either the high-speed and/or lowspeed needle(s) clockwise to decrease the amount of fuel the engine receives.

Low-speed needle (LSN) - Needle valve that controls the fuel mixture at low throttle openings.

Needle valve - Valve consisting of a tapered needle that closes against a corresponding seat to regulate fuel flow.

Nitro - Abbreviation for nitromethane, a component of model engine fuel that improves fuel combustion and power output. Nitro also refers to a class of R/C powered by model engines instead of electric.

Nitro content - The amount of nitromethane used in the fuel. Usually measured as a percentage of the total fuel volume. Traxxas engines are optimized to use 10-20% nitro. 33% nitro may be used for racing.

Nitromethane - Nitromethane is a component in the fuel that increases power from the combustion process up to a point.

Engines are generally optimized to use a range of nitro content for the best power.

O-ring - Rubber “O”-shaped ring used as a sealing gasket.

Pipe - Abbreviation for the tuned exhaust pipe on a nitro engine.

See “Tuned Pipe”.

Piston - The piston is the internal engine part that is attached to the upper end of the connecting rod and moves up and down in the cylinder sleeve. The precise fit between the piston and the sleeve creates a seal that allows the engine to have the required compression for combustion.

Port - Ports are openings in the sleeve that allow atomized fuel to enter the combustion chamber and burned exhaust gases to exit.

The shape and location of the ports are a large factor in controlling the engine timing and power output.

Pre-filter - The outer air filter element in a two-stage air filter. This provides the first level of air filtration for the engine. The majority of dirt and debris will be stopped by this filter. Clean, re-oil, and replace this filter after every hour of run time. Always use both the pre-filter and primary filter.

Primary filter - The inner air filter element in a two-stage air filter.

This provides a second level of air filtration after the pre-filter removes the majority of dirt and debris. Clean, re-oil, and replace this filter after every 3 - 4 hours of run time. Always use both the pre-filter and primary filter.

Priming - Manually causing fuel to move from the fuel tank up to the carburetor. This is sometimes necessary after the engine has been sitting for a long period of time and all of the fuel has drained back to the tank. On a Traxxas model this is done by holding your finger over the exhaust tip for one or two seconds while the engine is starting.

Punch - A term that refers to how quickly the model responds to throttle input or how quickly it accelerates.

Rich - A running condition where the engine is getting too much fuel for the available air. It is better to run an engine slightly rich to increase engine life. Excessively rich mixtures cause the engine to have sluggish performance with exaggerated blue smoke and unburned fuel coming from the exhaust.

rpm - Abbreviation for revolutions per minute (how many times the engine crankshaft spins in a minute).

Sleeve - Internal engine part that contains the piston. The precise fit between the sleeve and the piston creates a seal that allows engine to have the required compression for combustion. The sleeve in a

TRX engine is made of brass and is then hard-chrome plated.

Slide carburetor - The throttle on a slide carburetor closes and opens by sliding a barrel in and out of the carburetor body. This type of carburetor is preferred for performance use because it provides a less restrictive “straight-through” air path than the barrel carburetor design.

Stall - When the engine stops running, usually due to an incorrect fuel mixture setting or running out of fuel.

TDC - Top dead center. The top-most position of the engine piston stroke.

Tuned pipe - The tuned exhaust pipe usually consists of a speciallyshaped metal or composite chamber with baffles that is designed to enhance the power output of the engine.

Wear-in - Fitment process that occurs during engine break-in where internal engine parts develop an even more precise matched fit through actual use under controlled circumstances.

WOT - Abbreviation for wide-open throttle.

REVO 3.3 • 19

DANGER! Model engine fuel is poisonous to humans and animals. Drinking the fuel can cause blindness and death. Handle with care and respect. Keep fuel out of reach of small children at all times! While driving, do not leave your fuel dispensing bottle on the ground where a child could have access to it.

Follow fuel label warnings.

20 • REVO 3.3

THE TRX 3.3 RACING ENGINE

THE FUEL

Use the Right Fuel

It’s imperative that you use the correct fuel in your

TRX 3.3 Racing Engine for maximum performance and engine life. Traxxas Top Fuel ® should be used to ensure correct engine lubrication, performance, and ease of tuning. Traxxas Top Fuel has been proven in thousands of engines, so you can count on it every day for great performance.

• Top Fuel is the only fuel which is 100% certified for use in Traxxas engines.

• Traxxas Top Fuel is made with just the right balance of the highest grade natural and synthetic lubricants to allow excellent throttle response and the best top-end performance, without sacrificing long-term durability.

• All of the components in the fuel are carefully selected from the best materials available and then custom blended to match the metallurgy and temperature characteristics of Traxxas engines.

You may use 10%, 20% or 33% nitro-content fuel. Try to use the same percentage all the time, avoid switching back and forth between fuels. We recommend that if you break in your engine on

20% fuel that you stick with that percentage. If you do move to a higher or lower percentage, make sure you readjust your fuel mixture to compensate (see below).

Choosing a Nitro Percentage

A commonly asked question is “what is the difference between 10%,

20%, and 33% fuels?” Increasing the nitro in the fuel is almost like adding extra oxygen to the combustion process. It burns more efficiently, improves combustion, and delivers more power. When increased nitro is used, more of the other fuel components are then required inside the combustion chamber to maintain the perfect air/fuel ratio. Therefore, overall fuel mixtures need to be richened slightly (on the high speed needle, about 3/4 of a turn counterclockwise when changing from 20% to 33%, about 1/2 of a turn counterclockwise when changing from 10% to 20%). This allows greater fuel flow through the engine and promotes cooler running, even at the maximum lean settings.

If 33% improves power, then it seems that the highest nitro content available (beyond 33%) should always be used in the engine. In reality, there are practical limitations. Engines are designed to run best within a range of nitro percentages. How the engine is ported, the size of the combustion chamber and other factors determine how much nitro can be efficiently used in the engine. The TRX 3.3 Racing Engine responds exceptionally well to a maximum of 33% nitro, returning cooler temps, more power, and a smoother throttle response. For those who want to run higher nitro, 33% Top Fuel is the optimum nitro percentage for the

TRX 3.3 Racing Engine. Increasing the nitro beyond 33% can introduce the need for engine modifications (ports, head shimming, etc.) to avoid starting and tuning difficulties. There are limits to how much nitro an engine can effectively use to make more power. Lower nitro percentages have their own advantages. Nitro is an expensive component in the fuel so 10% nitro blend is more economical for the sport user. 10% also provides greater latitude with the needle settings for easier tuning.

When using Traxxas Top Fuel, using higher nitro percentages does not cause the engine to wear out faster. 33% Top Fuel contains the same quality lubrication package as 10 and 20% Top Fuel. Some non-Traxxas high-percentage nitro racing fuels do sacrifice some lubrication in attempts to increase performance. We urge you to not take chances with your engine investment and use Top Fuel for consistent performance and long engine life.

What about Other Fuels?

Can other brands of fuel be used besides Top Fuel? There are other fuels that can provide satisfactory performance; however there could be long-term costs in the form of decreased engine performance, loss of tuning ease, and shorter engine life. Only use fuels that contain both castor and synthetic oil.

Everyone has an opinion or a claim to make about fuel. The engineering team at Traxxas has spent years developing TRX Racing

Engines. No one knows more about the specific fuel requirements of

Traxxas engines, than Traxxas engineers. We strongly urge you not to take chances with your engine investment and use the Traxxas fuel made for the TRX 3.3 Racing Engine.

Handling the Fuel

Follow all directions and warnings on the fuel can.

• Keep the fuel tightly capped at all times. Some components in the fuel can evaporate very quickly and upset the balance of the fuel.

• Do not store unused fuel in the fuel dispenser. Immediately return fresh unused fuel back into the fuel can.

• Do not mix old and new fuel. Never mix different fuel brands together.

• Store the fuel in a cool dry location, away from any source of heat, ignition, or combustion.

• Read and follow the safety precautions on page 4 in this manual.

THE TRX 3.3 RACING ENGINE

Filling the Fuel Tank

Use a fuel dispensing bottle (Traxxas Top Fueler, included) to put fuel into Revo’s fuel tank. To fill the fuel bottle, squeeze the air out, insert the dispenser tip into the fuel can, and release your grip on the bottle. As the bottle expands, fuel will be drawn into it.

To fill your model, pull up on the fuel cap handle, insert the tip of the fuel bottle, and squeeze to dispense the fuel.

THE AIR FILTER

The TRX 3.3 Racing Engine in this model is equipped with a specially designed two-stage air filter to deliver maximum filtering efficiency and performance while protecting your engine from dust and dirt during extended operating conditions. Use only the supplied filter. You will

not improve engine performance by switching to an aftermarket

filter, and you may risk engine damage due to poor filtration.

The two-stage TRX Racing Filter consists of the following components:

1. A rubber filter Base

2. A 3-piece plastic housing

3. A “pre-filter” element

4. A “primary” filter element

You must clean the outer pre-filter after every hour of run time, even if the filter looks clean. The primary filter element inside must be cleaned after 3-4 hours of run time. These intervals include

the break-in time. Clean your air filter after break-in. Dust (which is often too fine to see) and dirt constantly move through the filter anytime the engine is running. Even if you can’t see dirt on the filter, it is present inside the foam after any amount of run time. If you exceed the recommended cleaning intervals, your engine will be damaged. Engine damage or wear due to dirt ingestion is easy to detect, and one of the top causes of premature engine failure.

Pre-Filter Cleaning Instructions (every hour of run time)

1. Remove the clip from the air filter and remove from the metal hanger. Remove the air filter assembly from the carburetor bore by pulling the entire filter assembly firmly to the side to release it.

Do not pull straight up.

2. Remove the pre-filter element.

3. Clean the pre-filter element by thoroughly washing the foam element in hot soapy water

(dishwashing detergent works well). Repeat twice.

Pull to the side to remove assembly

4. Thoroughly dry the pre-filter element with a clean towel.

5. Oil the foam element with air filter oil. Use Traxxas filter oil (part#

5263) or a high-quality, special-purpose foam filter oil like what is used for off-road motorcycle and ATV engines. This type of filter oil is available at motorcycle pro-shops. Apply a total of 24 drops of

Traxxas air filter oil, evenly distributed between the top, bottom and sides of the filter element. Squeeze the filter element repeatedly to help spread the oil throughout. The filter element should be evenly colored by the oil. Even color indicates that the oil is spread evenly.

Do not squeeze out excess oil. Note: Do not use the air filter oil for anything other than the air filter. It is not meant to be a lubricant.

6. Reassemble the filter and install it on the engine. Make sure the rubber filter neck fits securely on the carb with no gaps or air leaks.

Primary Filter Cleaning Instructions (every 3 - 4 hours of run time)

1. Remove the clip from the air filter and remove from the metal hanger. Remove the air filter

Pull to the side to remove assembly

assembly from the carburetor bore by pulling the entire filter assembly firmly to the side to release it. Do not pull straight up.

2. Remove the pre-filter element.

3. Remove the 3x6mm screw in the end of the filter housing.

Remove the front housing and the primary filter element.

4. Clean the filter parts by thoroughly washing in hot soapy water

(dishwashing detergent works well). Repeat twice for the foam filter elements.

5. Thoroughly dry the foam pre-filter and primary filter elements with a clean towel. Dry the remaining filter parts.

6. Oil the foam pre-filter with 24 drops of air filter oil, and the primary filter element with 30 drops of air filter oil.

7. Reassemble the filter and install it on the engine. Make sure the rubber filter neck fits securely on the carb with no gaps or air leaks.

9

REVO 3.3 • 21

See page 28 for more information on how air density affects engine tuning.

A “turn” refers to tightening (“turning in”) or loosening (“turning out”) mixture needles. A “full turn” refers to turning the needle 360°, so a “1/2 turn” would be 180°, a “1/4 turn” would be 90°, and so on.

Start

Full Turn

360°

1/8 Turn

45°

3/4 Turn

270°

1/4 Turn

90°

1/2 Turn

180°

THE TRX 3.3 RACING ENGINE

THE CARBURETOR

Understanding the Carburetor adjustments

The carburetor performs several functions. It controls the engine’s speed by restricting the intake of air and fuel into the engine. It atomizes the fuel (suspends the fuel droplets in the air) and also controls the air/fuel ratio of the mixture entering the engine (how much air for a given amount of fuel).

To help provide a better understanding of engine tuning and why it’s

Air

necessary, the following is a brief explanation of the air/fuel combustion process that takes place inside the engine.

Fuel

In order to create the cylinder pressure that results in power, the engine burns the air/fuel mixture. Both air and fuel, in correct amounts, are needed for proper combustion. It is the carburetor’s job to mix the air and fuel together

(atomize the fuel), in the correct proportion for the best possible combustion. This is the ideal air/fuel ratio. The ideal air/fuel ratio required for the engine remains roughly constant. Due to variations in atmospheric conditions (temperature, humidity, altitude etc.) fuel flow adjustment valves (called fuel mixture needles) are required to meter the fuel and maintain the ideal air/fuel ratio in these everchanging conditions. For example, colder air is more dense (more air molecules) for a given volume of air and therefore requires more fuel

(more fuel molecules) to maintain the correct air/fuel ratio. Warmer air is less dense (fewer air molecules) and therefore needs less fuel to maintain the correct air/fuel ratio. The tuning needles are there to adjust how much fuel is made available for the carburetor to mix with the available air

(atomization).

Cold Air (More Dense) (Warm Air) Less Dense

THE FUEL MIXTURE NEEDLES

The amount of fuel metered and atomized by the carburetor is controlled by the two mixture needles, the high-speed needle and the low-speed needle. The low-speed needle is used to meter the fuel used by the engine at idle and low rpm (part-throttle) engine speed.

The high-speed needle is used to meter the fuel when the throttle is open from part throttle to wide-open throttle (WOT). Two needles on the TRX 3.3 Racing Engine provide precise control of the air/fuel ratio across the engine’s entire rpm range.

The maximum possible fuel flow is always controlled by the high-speed needle. It works like the main water

Water Valve

(Controls Overall Flow)

High Speed Needle

Richen

valve on a garden hose. Turn it clockwise to close the valve, counter-clockwise to open it. When the throttle is at idle or partially open, the low-speed needle meters the fuel flow at the

Water Nozzle

(Controls Fine Flow)

Low Speed Needle

outlet (needle seat) where the fuel enters the carburetor venturi. This second valve acts like the spray nozzle at the end of the garden hose in our example. When you accelerate from idle, the throttle opens and the low-speed needle is pulled away from the needle seat. This allows more fuel to flow with the increased air flow. As the throttle is increased, the low-speed needle is pulled completely away from the needle seat leaving it fully open. At that point, fuel metering is entirely controlled by the high-speed needle. Again, using our water hose example, when the spray nozzle at the end of our garden hose is fully open, then the main water valve can be used to adjust how fast the water flows.

The engine’s performance is directly linked to the fuel mixture.

Richening the fuel mixture increases the amount of fuel in the air/fuel mixture ratio and leaning the fuel mixture decreases the amount of fuel in the air/fuel mixture ratio.

• Slightly lean fuel mixtures deliver stronger, more efficient combustion and more power, but with less lubrication.

• Slightly rich fuel mixtures deliver cooler running and more lubrication but with slightly less power.

22 • REVO 3.3

THE TRX 3.3 RACING ENGINE

Lean

Tuning the engine means finding the perfect balance between the two; excellent power to meet your needs while maintaining good lubrication for long engine life. The optimal fuel

mixture setting is rich to provide a safety margin against having a lean condition if some variable changes

(such as the temperature from one day to the next).

Rich

General fuel mixture settings are measured by the number of turns the needles are turned out from fully closed. The fuel mixture settings have been pre-set from the factory to typical break-in settings. Do not readjust your carburetor from the factory settings until after the engine is started and running, and you have been able to observe the engine running to assess what minor adjustments may be required to compensate for fuel, temperature, and altitude. Adjustments are usually made in 1/8 or 1/16-turn increments. If the engine sticks at top dead center (TDC), see page 38 for instructions on freeing the engine.

The Idle Speed Adjustment

The idle speed screw controls the closed position of the throttle slide.

When the throttle servo is in its neutral position, the throttle slide should be stopped against the idle adjustment screw. Always use the idle speed adjusting screw to control engine idle. Do not use the throttle trim on the transmitter to adjust idle speed. The idle speed should be set as low as possible and still maintain reliable running.

EZ-START ELECTRIC STARTING SYSTEM

The Traxxas EZ-Start brings the convenience of push-button electric engine starting to your Revo. The EZ-Start consists of a hand-held control unit and an on-board motorized starter.

• Power for the EZ-Start system comes from a 7.2-volt rechargeable battery pack installed in the hand-held control unit.

• The engine glow plug is heated automatically by the EZ-Start system, eliminating the need to keep up with a separate glow plug igniter.

• The voltage to the glow plug is kept constant, regardless of the load placed on the starter by the starter motor.

• The “Glow Plug” LED (light emitting diode) on the control unit indicates the condition of the glow plug.

• The “Motor” LED indicates the status of the EZ-Start electric starter motor.

• The cush drive mechanism in the drive unit prevents damage to the gears caused by engine kickback.

• Smart Start ™ protection circuitry prevents damage to the motor by cutting power if the load on the motor or other electronics exceeds safe limits.

Charging the EZ-Start Battery

The included charger can be used to charge the included EZ-Start battery pack.

Do not charge batteries inside of an automobile. Read the Safety Precautions section of this guide.

1. Plug the charger into a 12-volt automotive

auxiliary power socket. The charger is compatible with 12-volt automotive auxiliary power sockets only. The LED on the charger will glow red to indicate it is ready to charge a battery.

1

2

Disconnected

3. Disconnect the battery when charging is

complete. When the battery is fully charged, the LED will light solid green. The battery will be warm in your hand.

Disconnect the battery.

Connected

2. Connect the battery to begin charging. Plug the battery into the charger. The charger’s

LED will flash green, indicating that charging has begun. The flashing green LED on the charger indicates the charge progress.

3

Charged

CHARGE PROGRESS x1

1 green flash 0 - 25% charged

x2

2 green flashes 25% - 50% charged

x3

3 green flashes 50% - 75% charged

x4

4 green flashes 75% or more charged

Solid green LED 100% charged

CHARGER LED INDICATION MEANING

Solid Red LED

Slowly Flashing Green LED

Solid Green LED

Ready for Charging

Charging (see Charge Progress chart)

Battery Fully Charged

Flashing Red LED Charger error

Note: If there is a problem with the battery, such as a short circuit, the charger’s LED will flash red. Disconnect the battery and unplug the charger from its power source to clear the error. Determine the cause of the error before continuing.

See Tuning Your TRX 3.3

Racing Engine on page 27 for complete information on adjusting the air/fuel mixture and idle speed.

Factory Needle Settings

If your factory preset carburetor adjustments have been tampered with, use the following settings:

• Set the high-speed needle to

4 turns out from closed.

• Set the low-speed needle so the screw head (red in Fig. A) is flush (even) with the end of the slide (yellow in Fig. A).

Fig. A

Low Speed

Needle Adjustment

Always use the factory settings for initial starting.

Only use these settings when the factory settings have been lost.

Higher nitro requires a richer fuel mixture. When running

33% fuel, richen your high speed needle 3/4 turn if previously running 20% nitro and then re-tune the engine for maximum performance.

2

REVO 3.3 • 23

Using Other Chargers

Another convenient option for charging the included battery is an AC peakdetecting charger that plugs directly into an AC wall outlet. It contains special peak-detection circuitry that automatically shuts the charger off when the battery is fully charged.

Caution: Never use a

15-minute timed charger to recharge your model’s battery packs. Overcharging may result, causing damage to the battery packs.

When the EZ-Start controller is in protection mode, wait at least three minutes before attempting to start the engine, to give the starter motor time to cool.

It’s normal for your EZ-Start controller to become warm after repeated use.

THE TRX 3.3 RACING ENGINE

Installing the EZ-Start Battery

1. Press the tab in the end of the battery compartment door to open (A).

2. Plug a fully charged 7.2-volt battery pack into the connector inside (B).

B

3. Twist the battery two or three times to twirl the battery plug wires. This helps hold the wire and battery in place when the battery is installed in the compartment (C).

D

C

4. Install the battery into the compartment and press the wires securely into place.

5. Snap the battery compartment door back on and lock the end tab (D).

A

Using the EZ-Start

Your EZ-Start controller plugs into a 4-prong receptacle in the center of the bed on your Revo 3.3. When the red button on the controller is pressed, the EZ-Start motor begins to spin the engine and power from the control unit heats the glow plug. Assuming all settings and preparations are correct, the engine should start almost immediately.

Each of the two status indicator LEDs on the handheld control unit, the Motor LED and the Glow Plug

LED, should light green while starting. If either LED fails to light while starting, there is a fault indicated with that function.

If the Glow Plug LED fails to light, the glow plug may be bad, or the glow plug wire may be damaged or disconnected.

If the Motor LED fails to light and the starter fails to operate, then the EZ-Start is in protection mode.

Protection Mode

The EZ-Start uses Smart Start

technology to monitor the condition of the system and detect failures. The controller monitors the load being placed on the EZ-Start motor. If the load becomes excessive, the system shuts off power to the motor to prevent costly damage to the motor and the controller. This may occur, for example, if the engine floods with fuel during starting. The starter spins at first but when excessive fuel in the combustion chamber begins to lock up the engine, the starter motor slows under the heavier load. This causes the protection circuit to shut off the power to the motor. Allow at least

3 minutes for the starter motor to cool and the circuit to automatically reset before continuing. Use the time to find and eliminate the condition that caused the excessive load on the starter motor.

Use a Strong Starter Battery

A weak starter battery, or one that has not been fully charged, may not deliver enough power to crank the engine over at the appropriate rpm to keep the piston from sticking at top dead center (TDC). A new engine will typically have a tight fit between the piston and the top of the sleeve. This is a tapered fit, and a tight piston sleeve fit on initial startup is desirable for those who want the best-performing engine.

Make sure you are using a good quality battery pack that is fully charged (new batteries usually require several charge cycles to reach peak voltage and full capacity). This is especially important with a new engine that needs to be broken in. If the engine sticks at TDC, see page 38 for instructions on freeing the engine.

Shutting Off The Engine

Turning off the switch for the radio will not shut off the engine. To shut off the engine, use the shut-off clamp on the fuel line. Squeeze the clamp closed to shut off the fuel supply to the engine. Don’t forget to release it when you restart the engine.

Avoid shutting off the engine by placing your finger over the exhaust outlet, especially if you are through driving for the day. This will leave more unburned fuel in the engine that could lead to harmful corrosion. Always be careful not to touch the exhaust pipe after

running, it can become very hot.

24 • REVO 3.3

5

,

10

THE TRX 3.3 RACING ENGINE

BREAKING IN YOUR TRX 3.3 RACING ENGINE

The TRX 3.3 Racing Engine uses a ringless, aluminum-brass-chrome

(ABC) piston/sleeve construction. This type of engine design relies on a very precise running fit between the piston and sleeve for cylinder sealing. Engine break-in is necessary to allow the piston and sleeve

to develop an extremely precise fit and optimum cylinder sealing.

Therefore, proper engine break-in is critical to achieving the fastest, most reliable engine performance.

Allow yourself about 1 to 1½ hours to complete the break-in procedure.

The engine break-in period will take 5 tanks of fuel in a Revo. The break-in time is not the time to impress your friends with your new Revo. You must

wait until the engine is fully broken in before attempting sustained

high speed running. Patience and careful attention during break-in will reward you with the best-performing TRX 3.3 Racing Engine possible.

During break-in, your engine may appear to malfunction with symptoms like stalling, inconsistent performance, and fouled glow plugs. These are simply the normal “break-in pains” engines sometimes go through. They will disappear once your engine is fully broken in.

Many owners report not experiencing any of these symptoms with TRX

Racing Engines. We recommend replacing the glow plug with a new

one (included) after the engine break in procedure.

Engine Break-in Procedure

The focus during break-in is to vary and limit the engine speed. This will be accomplished by accelerating and stopping at different rates for the first 5 tanks of fuel. As the engine begins to break-in, the duration and intensity of the acceleration will gradually increase. Sustained high-

speed running is not permitted until the 6th tank of fuel. Perform the initial break-in on a large, flat, paved surface. Revo is very fast and by

tanks 4 and 5 you will need plenty of room for the truck to run in.

Apply all throttle and braking actions gently. Abrupt acceleration or braking could cause the engine to stall unnecessarily.

• Special break-in fuels are not recommended. Use the same fuel you plan to use everyday.

• If possible, avoid breaking-in the engine on extremely hot or cold days

(see page 27).

• Pay careful attention to the fuel level. Do not allow the fuel tank to run completely empty. An extremely low fuel level causes the mixture to run too lean. This could result in a burned glow plug or extremely high engine temperatures.

Do not attempt to break in the TRX 3.3 Racing Engine by idling it on a stand. This will produce poor results.

• Keep extra Traxxas glow plugs handy. The break-in process can cause deposits to form on the plug leading to plug failure.

• Change or clean your air filter after break-in.

• Follow the instructions exactly for each of the first 5 tanks of fuel.

Starting Your TRX 3.3 Racing Engine for the First Time

Before you start your TRX 3.3 Racing Engine for the first time, make sure you have read all instructions and precautions in this manual. Pay close

attention to the tank-by-tank break-in instructions in the next section, and make sure you have read and understood them before you run your engine.

Your engine must be at room temperature (70°F or 21° C) or above the

first time you start it. If it’s cooler than room temperature outside, remove all fuel and keep your Revo indoors until you’re ready to start it and then take it outside. If it’s colder than 45°F, special considerations should be made. See cold weather break-in on page 27. We do not recommend running the model in temperatures below 35°F.

1. Turn on the radio system (see page 11).

2. Make sure the throttle trigger on the transmitter is in the idle (neutral) position.

3. Connect the EZ-Start controller according to the instructions on page 24.

4. Press the starter button in short two-second bursts and watch for fuel moving through the fuel line up to the carburetor. Watch closely! The fuel moves very fast. If the fuel doesn’t move through the line within 5 seconds, prime the engine by briefly (one or two seconds) covering the exhaust outlet with your finger and pressing the EZ-Start button until the fuel is just visible in the carburetor fuel line. Watch carefully! If the engine is primed too

long, it will flood with fuel and stop turning.

5. Once fuel reaches the carburetor, the engine should quickly start and idle.

6. Disconnect the EZ-Start controller from the model.

7. Proceed with the engine break-in.

8. Do not rev your engine with no load (wheels off the ground).

If your engine doesn’t start, go online to Traxxas.com/support. If your factory fuel mixture settings have been altered, refer to page 22. If you still have problems, contact Traxxas Customer Support at 1-888-TRAXXAS or [email protected]

See Important Points to

Remember on page 4 for other precautions.

Never run your Revo indoors.

Since the TRX 3.3 Racing

Engine exhaust fumes are harmful, always run your model outdoors, in a wellventilated area.

Your TRX 3.3 Racing Engine doesn’t usually require priming.

If you do need to prime your engine, watch the fuel line carefully to avoid flooding your engine. See page 38 for information on clearing a flooded engine.

Factory Needle Settings:

Your carburetor is preset at the factory to give the correct air-to-fuel ratio and idle speed for engine break-in. Do not adjust the carburetor unless you observe a poor running condition that requires correction (see page 23 for stock settings).

Higher nitro requires a richer fuel mixture. When running

33% fuel, richen your high speed needle 3/4 turn if previously running 20% nitro and then re-tune the engine for maximum performance. See page 20 for more information.

11

,

12

REVO 3.3 • 25

High Altitude Operation:

If you live in a high altitude region (5000 or more feet above sea level), the lower air density may require you to lean your high-speed fuel mixture slightly from the factory break in settings. Try this if you are experiencing difficult starting or extremely sluggish engine performance at high altitude.

As you gain experience in the hobby, you may discover that many people have differing opinions on what is the proper procedure to break-in a model engine.

Only use the Traxxas break-in procedure. Other break-in procedures could result in a weak, damaged, or otherwise poor performing engine.

The procedure outlined here was extensively tested and proven to yield better performing engines than other “common” break-in methods. Even if you have years of experience using model engines, please do not ignore this caution!

THE TRX 3.3 RACING ENGINE

Tank 1

1. Drive the model with the body off.

2. Driving procedure: Gently pull the throttle trigger to 1/4 throttle

over a 2-second count. Then gently apply the brake to stop.

Count the two seconds out while accelerating: one thousand one, one thousand two, and then stop. Operate the throttle trigger as smoothly as you can. Repeat this starting and stopping procedure

until the first tank of fuel is nearly empty.

3. Look for thick blue smoke exiting the exhaust outlet. If there is no smoke, richen the high-speed needle 1/4 turn, by turning the needle counterclockwise.

4. When the fuel tank is nearly empty, shut off the engine by pinching the fuel line connected to the carburetor (use the installed clamp).

5. Let the engine cool for 15 minutes.

Note: If at any point the engine cuts out or stalls during gentle acceleration, richen the high-speed needle 1/4 turn by turning the needle counterclockwise.

Tank 2

1. From tank 2 forward, Revo should be driven with the body on.

2. Driving procedure: Gently pull the throttle trigger to 1/2 throttle

over a 2-second count. Then gently apply the brake to stop. Count the two seconds out while accelerating: one thousand one, one thousand two, and then stop. Repeat this starting and stopping

procedure until the second tank of fuel is nearly empty.

3. When the fuel tank is nearly empty, shut off the engine and let it cool for 15 minutes.

Tank 3

1. Driving procedure: Gently pull the throttle trigger to 1/2 throttle

over a 3-second count. Then gently apply the brake to stop. Count the three seconds out while accelerating: one thousand one, one thousand two, one thousand three, and then stop. Repeat this

starting and stopping procedure until the third tank of fuel is nearly empty.

TANK

1

4

5

2

3

THROTTLE

1/4

1/2

1/2

Full

Full

TIME

2 seconds

2 seconds

3 seconds

3 seconds

5 seconds

COOL

15 minutes

15 minutes

-

-

-

2. As the engine loosens, the idle speed may increase and cause the model to try to creep forward when stopped. Reduce the idle speed by turning the idle adjustment (see page 17) on the carburetor counterclockwise.

3. When the fuel tank is nearly empty, shut off the engine and refuel.

From here on, you do not need to let the engine cool between tanks.

Tank 4

1. Driving procedure: Gently pull the throttle trigger to full throttle

over a 3-second count. Then gently apply the brake to stop. Count the three seconds out while accelerating: one thousand one, one thousand two, one thousand three, and then stop. Repeat this

starting and stopping procedure until the fourth tank of fuel is nearly empty.

2. Apply the throttle gradually! Your finger should not reach full throttle until the end of the three-second count. Revo may try to shift into second gear. If it does, reduce the throttle input. Do not let Revo shift out of first gear.

3. Keep your driving smooth and consistent.

4. When the fuel tank is nearly empty, shut off the engine and refuel.

Tank 5

1. Driving procedure: Gently pull the throttle trigger to full throttle

over a 3-second count, hold for 2 more seconds, and then

gently apply the brake to stop. Count the five seconds out while accelerating. Repeat this starting and stopping procedure until the

fifth tank of fuel is nearly empty.

2.

The model should now be shifting into second gear. If it is not, try turning the high-speed needle clockwise 1/8 turn to lean the fuel mixture slightly and test for shifting.

3. When the fuel tank is nearly empty, shut off the engine and refuel.

Tank 6

STOP!

Clean your air filter before you proceed. Refer to the instructions on page 21. During the sixth tank of fuel, the engine can be tuned for general performance use. Proceed to the next section in this manual.

BODY

Off

On

On

On

On

NOTES

Apply throttle gradually.

Apply throttle gradually.

Reduce idle speed if necessary.

Do not allow shifting to high gear.

Accelerate over 3 second count, hold for 2 seconds.

26 • REVO 3.3

THE TRX 3.3 RACING ENGINE

Winter Break-in Tips

During the break-in process, the piston and sleeve wear into each other to form a precise fit. The engine needs to heat up to a temperature around 200 to 215°F to allow the piston and sleeve to achieve this fit properly. A precise fit between these two components is critical for proper compression, and optimum performance. If the engine runs too cold during break-in, the piston and sleeve will not expand to their appropriate sizes for break-in, and this can lead to premature wear of these components. This wear may not become apparent until after winter has past, and the engine is operated under warmer running conditions.

• Warm the engine to approximately room temperature by removing all fuel and storing the vehicle inside at room temperature until just before starting the engine. An extremely cold engine can become difficult to start.

• After the engine is running, it is important to keep the temperature of the engine up around 200 to 215°F during break-in. In weather below 45°F, the TRX 3.3 Racing Engine will tend to run at lower temperatures between 160 to 180°F (when tuned at proper break-in mixture settings). This is too cool for break-in. Do not lean the fuel

mixture to increase engine temperature! This will also decrease lubrication and cause your piston/sleeve to wear prematurely.

• Wrap the cooling head with a paper towel, clean rag or sock to help keep the engine running around the recommended 200 to 215 break-in temp. If too much heat is contained, the engine can actually run too hot. Make sure that you monitor the engine’s temp closely for the first couple of tanks until you get the right amount of cover for the cooling head. This will, of course, depend on your current weather conditions. Adjusting the cover up and down, exposing more or fewer cooling fins, is a convenient way to regulate engine temps.

• For owners that do not have access to a temperature probe, a drop of water on the cooling head (around the glow plug area) can be used to estimate the engine’s temperature. The drop of water should slowly sizzle for approximately 6 to 8 seconds if the engine is around 200 to

210°F. If the water sizzles for only a few seconds, then it is likely that it is over 220°F, and needs to cool down. If the water takes a long time or does not evaporate at all, then the engine is too cool.

• We do not recommend that you operate your engine below 35°

Fahrenheit. If you insist on running your vehicle below 35°F, be aware that nitro engines may be very difficult to start and tune at extremely cold temperatures. Also, at temperatures below freezing, nitro fuel can actually begin to gel up, and this can be harmful to the engine.

Follow the remaining break-in procedures as outlined in this Owners

Manual. This, along with the steps listed above, will ensure a good breakin for your new nitro engine, and provide many hours of enjoyment.

TUNING YOUR TRX 3.3 RACING ENGINE

The engine’s performance depends on the fuel mixture. Turn the mixture needles clockwise to lean the fuel mixture and counterclockwise to richen it. Leaning the fuel mixture will increase engine power up to the engine’s mechanical limits.

Never run the engine too lean

(not enough fuel flow).

Never lean the engine so far that it begins to cutout or stall. Leaning the engine beyond the safe allowable limits will result in poor performance and almost certain engine

damage. Indications of an overly lean mixture include:

Cutting out or sudden loss of power during acceleration.

• Overheating (temperature beyond 270° F at the glow plug).

• Little or no blue smoke coming from the exhaust.

If any of these conditions are present, stop immediately and richen the high speed mixture 1/4 turn. The engine will probably be slightly rich at that setting and you can then retune for performance. Always tune for performance by starting rich and moving leaner toward the ideal setting. Never try to tune from the lean side. There should always be a light stream of blue smoke coming from the exhaust.

When tuning for performance, watch closely to notice when there is no longer any increase in speed or power when the high-speed mixture is lean.

If you lean the high-speed mixture to the point that the engine cuts-out, hesitates, or stalls, you are well into the danger zone and engine damage is likely. Richen the high-speed needle 1/4 turn and retune.

For your convenience, the low-speed needle has a positive stop that prevents it from being over tightened and damaging the needle and seat. This also provides an easy way to gauge how many turns out from closed the low-speed needle adjustment is set to.

13

REVO 3.3 • 27

When adjusting the low speed fuel mixture, it is very important to make several high-speed runs with Revo between adjustments to clear out any excess fuel.

Perform the pinch test immediately after. If the engine is allowed to idle for a long period of time, it could “load up” with fuel and give you an inaccurate measurement from your pinch test.

Higher nitro requires a richer fuel mixture. When running

33% fuel, richen your high speed needle 3/4 turn if previously running 20% nitro and then re-tune the engine for maximum performance. See page 20 for more information

THE TRX 3.3 RACING ENGINE

Before you begin tuning, the engine should be warmed up to its normal operating temperature and running slightly rich. All final tuning adjustments must be made to the engine at its normal operating temperature. You can tell the engine is running rich by noting any of the following:

• Sluggish acceleration with blue smoke coming from the exhaust.

• Revo may not shift into second gear.

• There is unburned fuel spraying from the exhaust tip.

• Leaning the high-speed fuel mixture increases performance.

High-Speed Fuel Mixture Adjustment

With the engine warm and running at a rich setting, gradually lean the high-speed fuel mixture in 1/16 turn increments. Make several highspeed passes after each adjustment to clear out the engine and note any change in performance. The TRX 3.3 is extremely powerful. Remember to apply the throttle gradually to prevent wheelies or loss of control.

Continue this procedure until there is no longer any performance improvement. If any one of the following conditions occurs, the fuel

mixture is already past the maximum safe lean setting:

1.

There is no longer any performance improvement.

2.

The engine begins to cut out at high speed (Danger!).

3.

There is a sudden loss of power during acceleration (Danger!).

4.

The engine begins to overheat. Symptoms of overheating include:

• Steam or smoke coming from the engine (not exhaust).

• Hesitation or stalling during acceleration.

• Popping or clattering sound when decelerating (detonation).

• Fluctuating idle speed.

• Temperature measurement above 270° F at the glow plug (A temperature reading above 270° alone does not necessarily indicate overheating. Look for other symptoms of overheating combined with temperature for a more accurate warning).

Richen the fuel mixture to the optimum setting by richening the high-speed needle at least 1/8 turn counterclockwise and retest. This setting will extend engine component life.

Low-Speed Fuel Mixture Adjustment

The low-speed mixture is always set after the high-speed needle is correctly adjusted. The low-speed mixture is set using the “pinch test”:

1.

Once the engine is warm, do several high-speed runs to confirm that the high-speed needle is set correctly.

2. Bring the vehicle in and pinch closed the fuel line going into the carburetor (use the engine shut-off clamp). The engine should run for

2-3 seconds, speed up, and then shut off.

3. If the engine runs longer than 3 seconds, then lean the low-speed needle 1/16 turn, make several more high-speed runs, and retest.

4. If the engine shuts off immediately without speeding up, then richen the low-speed needle 1/8 turn, make several more high-speed runs, and retest.

When the low-speed needle is set correctly, the engine’s throttle response should be very quick, even to the point of making it difficult to keep Revo from doing a wheelie when you accelerate!

Fuel Mixture Adjustment Chart

If the...

is..

then the air density is...

Humidity Lower

Higher

Slightly more dense

Slightly less dense

Pressure

(barometer)

Lower Less dense

Higher More dense

Temperature

Lower More dense

Altitude

Nitro %

Higher Less dense

Lower More dense

Higher Less dense

Lower -

Higher adjust (correct) the fuel mixture to be...

Slightly richer

Slightly leaner

Leaner

Richer

Richer

Leaner

Richer

Leaner

Leaner

Richer

28 • REVO 3.3

THE TRX 3.3 RACING ENGINE

Idle Speed Adjustment

Once the high and low-speed mixtures have been set, reduce the idle speed to the minimum reliable idle speed. Remember, this adjustment should be made while the engine is running at normal operating temperature.

1. Turn the throttle trim on the transmitter so the brakes are applied (note its original position). This ensures that the throttle slide is resting against the idle adjustment screw.

2. Turn the screw counterclockwise to reduce the idle speed, or clockwise to increase it. The idle speed should be set as low as possible while still maintaining reliable running characteristics.

3. Reset the throttle trim on the transmitter to its original position.

Fine-Tuning the Carburetor

After fine-tuning your TRX 3.3 Racing Engine at the end of the breakin procedure, no major adjustments to the fuel mixture are usually necessary. Make note of the temperature, humidity, and barometric pressure at the time you finished fine tuning your carburetor. Current weather conditions can be found online from national websites, local TV news websites, and television. This information will be considered your baseline setting.

You may need to adjust your carburetor needles to compensate for changes in temperature and barometric pressure (air density) from day to day. Generally, you’ll need to richen the fuel mixture when the weather is colder than your baseline temperature and the air density is higher. Lean the fuel mixture when weather is warmer than your baseline temperature and the air density is lower. The chart below provides general guidelines on how weather conditions affect air density when they move higher or lower than your baseline setting (see page 22 for detailed info on how air density affects mixture settings).

Tuning the Engine by Temperature

Your model is equipped with a temperature sensor to indicate the engine’s temperature on the dashboard of the Traxxas Link application (available

separately, see page 43). Engine temperature can be used as an effective tuning aid when you understand the relationship between engine temperature and ambient temperature. The engine operating temperature, when tuned for maximum performance, will vary according to atmospheric conditions, engine load, gauge accuracy, and many other factors. The atmospheric condition that has the most influence on engine temperature is air temperature. Expect the engine temperature to vary almost in direct proportion to air temperature. Assuming you tuned the engine for the same maximum performance each day, the engine will run about twenty degrees hotter when it’s ninety degrees outside than it would in seventy-degree weather. For this reason, we cannot give you a definitive temperature range that indicates the best possible engine tuning.

There is NO optimal temperature that can be used as a target to deliver the best engine tuning. Do not rely on a temp gauge alone to tune your engine. Tune the engine by paying very close attention to how it responds to changes in fuel mixture (more smoke/less smoke, fast/sluggish, reliable/stalling, smooth sound/ muffled

sound, etc). Once the engine is tuned, then observe the temperature.

The Traxxas Link application’s dashboard temperature gauge can aid you in tuning by giving you a relative indication of how your adjustments are affecting the engine and to help prevent you from reaching excessive engine temperatures. For example, as you lean the fuel mixture, the engine performance will increase along with the temperature. If you continue to lean the fuel mixture and the temperature increases but the engine performance does not change, then you have exceeded the maximum safe lean setting. Make note of the engine temperature.

Generally, try to keep your engine from exceeding 270°F when measured at the glow plug. If necessary, increase airflow to the engine by cutting out the rear of the windshield. In some situations, the engine may perform very well with no stalling, lagging, or hesitation at temperatures above

270°F, particularly in very hot climates.

If richening the fuel mixture to bring the temperature down to 270°F results in poor, sluggish performance (engine never cleans out) then return the engine back to a satisfactory state of tune based on how it sounds and performs (always with a visible stream of blue smoke coming from the exhaust)-. If engine temperature is exceeding 270°F with proper cooling and no signs of abnormal running, then avoid running the engine at its maximum lean setting. Watch closely for any signs of overheating.

Richen the fuel mixture slightly to provide a safety margin of additional cooling lubrication. Symptoms of overheating include:

• Steam or smoke coming from the engine (not exhaust).

• Hesitation or stalling during acceleration.

• Popping or clattering sound when decelerating (detonation).

• Fluctuating idle speed.

REVO 3.3 • 29

30 • REVO 3.3

14

DRIVING YOUR REVO

INTRODUCTION

Your TRX 3.3 Racing Engine is broken in, the fuel mixture is balanced, and the idle is set…now it’s time to have some fun! Before you go on, here are some important precautions to keep in mind.

Don’t run your Revo in water, mud, snow, or wet grass.

It’s tempting, but water and mud are easily drawn through the air filter and will severely damage the engine. Small amounts of moisture can cause electronics to fail and loss of control over your Revo.

• The TRX 3.3 Racing Engine is extremely powerful. Remember to apply the throttle gradually to prevent wheelies or loss of control.

• Don’t hold Revo off the ground and rev the engine excessively with no load on the engine. This practice could result in internal engine damage. Avoid over revving the engine when Revo is airborne after a jump.

• Avoid excessive high-speed running for extended periods of time or over long distances. This could cause the engine to build up enough speed to exceed maximum safe RPM limits.

• Don’t drive your Revo with drive train damage of any kind.

The engine could be damaged due to overloads caused by drivetrain friction, or over-revving caused by loose or missing parts.

• Don’t tow anything with your Revo. The engine is cooled by airflow created by speed. Towing creates a high load on the engine, and at the same time limits cooling of the engine due to low vehicle speed.

• If your Revo gets stuck, stop driving immediately. Move the vehicle and then continue driving.

• Never turn off the radio system while the engine is running. The truck could run out of control.

Driving Tips

• Monster trucks by design have a high center of gravity that requires a different driving technique. To prevent rollovers, slow down as you approach turns and then apply moderate throttle through the turns. This technique will help Revo grab the surface and turn sharper.

• Do not apply brakes and turn the wheel at the same time. You could tip the truck over.

• When jumping, apply some throttle while Revo is in the air to keep the truck’s nose up and land level on all four wheels. Be careful not to over-rev the engine or land at full throttle. Either could seriously damage your Revo. If the nose of the truck is too high, then quickly tap the brake to level the truck in the air.

• Drive over large obstacles (such as curbs and rocks) at an angle, instead of head on. This will allow the suspension to articulate and absorb the impact much easier.

• Change or clean the pre-filter element in your air filter after each hour of running. Change or clean the primary filter element every

3 - 4 hours of running. This is critical for the life of your engine.

Running time includes the engine break-in period.

BASIC TUNING ADJUSTMENTS

This tuning and setup guide is separated into two sections- Basic and Advanced. Revo does not require any specialized knowledge or understanding of its unique suspension and drive train to perform typical, everyday setup and track tuning adjustments. Adjustment procedures for alignment, spring rate, damping, steering, and ride height are covered in the basic tuning section. Adjustments for the gear ratio, two-speed shift point, slipper clutch, and brake are also covered. In most cases, the basic information is all that is needed to tune Revo to perform well on a variety of surfaces.

Revo was engineered to provide sophisticated additional tuning options well beyond the basics that allow expert users to extract the maximum performance from the truck. The advanced tuning section

(beginning on page 39) covers topics such as optional suspension rockers, roll center adjustment, caster adjustment, bump steer tuning, differential setup, and fine tuning the two-speed gear ratios. Make sure you fully understand the basic adjustments before experimenting with the advanced adjustments. Improper combinations of adjustments can adversely affect the performance of the truck, resulting in poor handling. If you don’t know why you are changing an adjustment then you should leave it at its factory setting. Also included are instructions for using the Long Travel rockers and springs supplied with Revo. The Long Travel rockers allow extreme suspension travel for rock crawling and rough, large-scale terrain. The Long Travel rockers allow the suspension to operate at its extreme mechanical limits and are recommended for advanced users.

SUSPENSION TUNING

Springs

The front and rear springs on Revo have different spring rates. The rear springs are about 10% stiffer than the front springs. The spring’s pre-load tension can be adjusted by turning the spring pre-load adjuster. Adjusting the pre-load changes the suspension sag. Suspension sag basically defines how much the suspension compresses when the truck is at rest. Adjust the pre-load so that the suspension compresses about one third of its full suspension travel

(see illustration). If suspension sag is severe and requires a large increase of the spring pre-load to compensate, then a firmer spring should be used. Firmer springs (supplied) must be used when the

Long Travel rocker arms are installed.

Use a stiffer spring to reduce sag, reduce body lean, control brake dive, and provide a firmer, more responsive overall feel. If Revo is lightened significantly for racing applications, softer springs will be necessary to allow the suspension to sag properly. Heavier configurations will

Compression 2/3

require stiffer springs.

Ride height is adjusted by changing the length or position of the pushrods

Ride Height

Sag (Droop) 1/3

Axle Centerline at Max Compression

Axle Centerline at Ride Height

Axle Centerline at Max Sag

in the lower suspension arms. See the next section for ride height adjustments. The suspension sag and spring pre-load should be readjusted anytime the springs are removed and/or replaced.

Optional springs available from Traxxas are listed below. Refer to your parts list for a complete part number listing. Higher rate springs are stiffer. Springs can be identified by dots of color on one end.

90mm Travel

Dot Color

Yellow

White

Spring Rate

14.8 lb/in (2.6 N/mm)

16.6 lb/in (2.9 N/mm)

Orange

18.3 lb/in (3.2 N/mm)

(Standard Front)

Green

(Standard Rear)

20.0 lb/in (3.5 N/mm)

Gold

Tan

Black

21.7 lb/in (3.8 N/mm)

23.4 lb/in (4.1 N/mm)

25.1 lb/in (4.4 N/mm)

120mm Travel

Dot Color

Silver

(Standard Front)

Spring Rate

28.0 lb/in (4.9 N/mm)

Pink

Blue

(Standard Rear)

30.8 lb/in (5.4 N/mm)

33.7 lb/in (5.9 N/mm)

Purple

36.5 lb/in (6.4 N/mm)

Note: 90mm travel springs are not recommended for use with the Long Travel rockers.

Ride Height Adjustment

The rocker arm suspension uses push rods on each suspension arm.

Changing the length and/or position of the push rod adjusts the ride height without affecting or compromising other suspension parameters. For example, you can raise and lower the ride height without changing up/down travel distribution, changing springs, or affecting your progressive rate. This feature is unique to Revo and is extremely beneficial in a racing environment where you can achieve a low center of gravity (by lowering the ride height) without losing any suspension capability. Increasing the ride height will increase ground clearance for rough terrain.

The ride height of the model can be changed by mounting the push rod in a different hole in the lower suspension arm. From the factory, the

REVO 3.3 • 31

Important: The shocks are assembled at the factory with a center-to-center distance (between the rod end balls) of 87mm. Any time the shocks are removed and disassembled, this distance should be checked to ensure proper operation of the suspension.

87mm

32 • REVO 3.3

BASIC TUNING ADJUSTMENTS push rod comes installed in the inner hole of the lower suspension arm’s push rod mount. If the push rod is mounted in the outer hole, the ride height decreases.

The ride height can be finely tuned by adjusting the sag of the suspension. Do not

attempt to make large changes to the ride height by adjusting the spring pre-

load on the shock bodies. If

Increases

Ride Height

Decreases

Ride Height

suspension sag is severe and requires a large increase of the spring pre-load to compensate, then a firmer spring should be used. The lowest ride height can be achieved by removing the blue spacers from the push rod and installing the push rod in the outermost hole of the lower suspension arm’s push rod mount.

The optional included Long Travel rocker arms are designed to be used only with the push rods installed in the hole labeled “LT” (the middle hole of the lower suspension arm’s push rod mount). Any minor adjustments to the ride height are accomplished by adjusting the spring pre-load.

Adjusting the Pivot Ball Caps

The pivot ball caps should be adjusted so that the pivot balls operate freely in the axle carriers with no excess play. Use the provided four-way suspension multi-tool to tighten or loosen the pivot ball cap.

Shock Oil

The 4 oil-filled aluminum shocks (dampers) effectively control the suspension movement by preventing the wheels and tires from continuing to “bounce” after rebounding from a bump. Changing the oil in the shocks can vary the suspension damping effect. Changing the oil to a higher viscosity oil will increase damping. Lowering the viscosity of the oil will cause the suspension damping to be reduced. Damping should be increased (with higher viscosity oil) if the model is bottoming easily over jumps. Damping should be decreased (with thinner viscosity oil) if the model is hopping over small bumps and feels unstable. The viscosity of shock oil is affected by extremes in operating temperature; an oil of certain viscosity will become less viscous at higher temperatures and more viscous at lower temperatures. Operating in regions with cold temperatures may require lower viscosity oil. From the factory, the shocks are filled with SAE-30W silicone oil. Only use

100% silicone oil in the shock.

Replacing Shock Oil

The shocks have to be removed from the vehicle and disassembled to change the oil.

1. Remove the lower spring retainer and shock spring.

2. Remove the upper shock cap using the shock wrench and the suspension multi-tool.

3. Empty the used shock oil from the shock body.

4. Fill the shock with new silicone shock oil up to the top of the shock body.

5. Slowly move the piston up and down (always keeping it submerged in oil) to release the air bubbles. Let the shock sit for a few minutes to allow any remaining air bubbles to surface.

6. Slowly thread the upper cap with the installed shock bladder onto the shock body with the suspension multi-tool. The excess oil will bleed out of the small hole in the shock cap.

7. Tighten the shock cap until snug. Use the included steel shock wrench to hold on to the shock body while tightening.

BASIC TUNING ADJUSTMENTS

ALIGNMENT SETTINGS

The alignment settings are critical for optimizing the performance of Revo. Adjust your alignment as carefully and precisely as you possibly can.

Toe Adjustment

The wheels can be adjusted to point straight ahead or have a toein or toe-out setting. To help you remember, look down at your feet.

For toe-in, your feet point towards each other. For toe-out, your feet point away from each other.

The toe angle of the front wheels can be adjusted by varying the length of the toe links that connect the steering linkage to the front axle carriers. The toe angle of the rear wheels can be adjusted by varying the length of the metal toe links that connect the rear bulkheads to the rear axle carriers. The front toe links and rear toe links are equipped with turnbuckles. The lengths of the toe links can be adjusted by turning them with the included 5mm

Traxxas wrench.

Toe Base Factory Settings

Front: 0-degrees

Rear: 1-degree toe-in each side

Threads

Right-hand

(Normal)

Decrease

Length

Increase

Length

Under certain conditions, toe-in can be increased to a maximum of

3-degrees. To avoid potential interference of suspension components with the Long Travel rockers installed, see the maximum alignment limits table on page 34.

Static Camber Adjustment

The wheels can be set to have either positive or negative camber (see illustration below). The camber angle changes as the wheel moves up and down through its range of travel. Static camber is the camber angle at the wheel when the vehicle is set at its normal, stationary ride height.

The suspension pivot balls located in the axle carriers adjust the static camber. The pivot balls are protected by blue dust plugs. To adjust your static camber, insert the supplied 2.5 mm hex wrench through the slit in the dust plug and engage the end of the pivot ball (compressing the suspension until the arms are parallel to the ground will allow for easier hex wrench engagement). The upper pivot ball is normally screwed all the way in. Negative camber is achieved by screwing the pivot ball of the lower control arm out. Note:

When camber is changed, the toe angle of the wheel has to be reset.

Static Camber Base Factory Settings

Front: 1-degree negative camber each side

Rear: 1-degree negative camber each side

Positive camber

Negative camber

A camber gauge (available at your local hobby shop) can be a useful tool for alignment setting.

All of the toe links are installed on the truck so that the left hand thread indicators point to the same direction. This makes it easier to remember which way to turn the wrench to increase or decrease toe link length (the direction is same at all four corners). Note that the groove in the hex indicates the side of the toe link with the left-hand threads.

REVO 3.3 • 33

34 • REVO 3.3

BASIC TUNING ADJUSTMENTS

Maximum Alignment Limits (using stock push rod length)

Revo’s maximum toe and camber alignment settings can be limited by the ride height setting. Do not exceed the maximum limits or you could experience interference between suspension components.

The ride height is controlled by where the push rod is installed in the lower suspension arm. First determine which of the following configurations you are using:

a. Stock Configuration – When the pushrod is in the inner position of the lower control arm.

b. Lowered Configuration - When the pushrod is in the middle position of the lower control arm.

c. On-Road Configuration - The lowest configuration. When the pushrod is in the outermost position of the lower control arm.

d. Long Travel Configuration – When the pushrod is in the middle position of the lower control arm with the optional Long Travel rockers installed.

Front Suspension

The following are suggested maximum settings for the front suspension in order to avoid interference between suspension components:

Configuration

Stock

Lowered

On-Road

Long travel

Available

Camber

(degrees)

+3 to -1

+3 to -5

+3 to -5

+3 to -1

Available Toe

(degrees)

Toe In Toe Out

1 1

3

3

1

3

3

1

Rear Suspension

The following are suggested maximum settings for the rear suspension for all configurations. Toe out is not normally used on the rear of Revo.

Configuration

All

Available

Camber

(degrees)

+3 to -5

Available Toe

(degrees)

Toe In Toe Out

3 2

TRANSMISSION TUNING

Adjusting the Slipper Clutch

Your Revo is equipped with an adjustable Torque-Control

™ slipper clutch. The slipper clutch is integrated into the main spur gear on the transmission (see page

6). The slipper clutch is adjusted by loosening the spring-loaded locknut on the slipper shaft. Use the supplied 8mm open-end metric wrench. To tighten or loosen the slipper nut, insert the 2.0mm hex wrench into the hole in the end of the slipper shaft. This locks the shaft for adjustments.

Turn the adjustment nut clockwise to tighten (less slippage) and counter-clockwise to loosen (more slippage). The slipper clutch has two functions:

1. Limiting the engine’s torque output to the wheels to prevent wheelspin on low traction surfaces and help to prevent damage to the gears in the transmission during on-throttle landings.

2. Protecting the drivetrain from sudden impact or shock loads (such as landing from a jump with the engine at full throttle).

From the factory, the slipper clutch is set for minimal slippage to protect the drivetrain from shock loads. On slippery, low traction surfaces such as a hard-packed, dry racetrack you may benefit from loosening the slipper adjustment nut to allow for more clutch slippage. This will make the truck easier and more forgiving to drive by helping to reduce the amount of wheel spin. Loosening the slipper adjustment can also improve performance on extreme high traction surfaces by preventing the front end from lifting off of the ground when accelerating. Make slipper adjustments in small 1/8 turn increments.

The maximum tight setting for the slipper is just at the point where there is little or no tire slippage on a high traction surface such as carpet or a prepared racetrack. The slipper should not be tightened to the point that clutch slippage is completely eliminated. Do not overtighten the slipper nut or you could damage the slipper bearings, pressure plates, or other components.

BASIC TUNING ADJUSTMENTS

Adjusting the Two-Speed Transmission

Revo comes equipped with an adjustable two-speed transmission.

When the shift point on the transmission is adjusted correctly, it will maximize acceleration and improve drivability. Use a 2mm hex wrench to adjust the shift point. To make the adjustment, the engine must be off (not running).

1. Shift the transmission into forward gear (shift button down).

2. Remove the rubber access plug from the top of the transmission housing.

3. While looking through the opening, rotate the spur gear to align the cutout (notch) on the internal twospeed clutch drum with the opening.

4. Hold the spur gear and slowly roll the truck forward until the hex on the black adjustment set screw becomes visible in the opening. Note: the truck will only roll forward (not backwards) when the spur gear is held stationary.

5. Insert the 2.0mm hex wrench through the clutch drum and into the adjustment screw.

6. Turn the adjustment screw 1/8 turn counter clockwise to lower the shift point (shifts sooner). Be careful not to loosen the adjustment screw too much or you may cause the screw and spring to fall out (requiring major disassembly and repair). Turn the adjustment screw

Shift

Sooner

clockwise for later shifts.

7. Reinstall the rubber access plug to prevent dirt from entering the transmission. Do not put oil or other lubricants into the transmission through the two-speed adjustment access hole.

8. Check performance by running a test lap after each adjustment. On a small race track with many tight turns, try setting the shift point later so that the truck only shifts into second gear on the main straightaway. This will prevent an unexpected shift in the middle of a turn. On larger tracks it may be necessary to allow earlier shifts for increased speed.

Adjusting the Spur Gear/Clutch Bell Gear Mesh

The ideal spur gear/clutch bell gear mesh for

Revo is 0.1mm. To set the gear mesh, place a strip of standard letter/A4 size copy or printer paper (about 0.1mm thick) between the mating teeth. Loosen the two horizontal engine mount screws and slide the engine mount up to push the clutch bell gear against the spur gear so that the that the paper is not too tight to pull out or too loose that it will fall out. Tighten the two horizontal engine mount screws securely. When the paper is removed, you should feel only the slightest amount of play between the gears (almost none) and there should be no binding or friction.

Changing the Spur Gear

1. Remove the four cap head screws that secure the engine to the engine mount.

2. Remove the button head screw that secures the pipe hanger to the rear body mount.

3. Carefully remove the engine and exhaust system from the spur gear area to allow enough room to remove the spur gear.

4. Remove the three screws on the slipper clutch assembly using a 2.5mm hex wrench. Slide the spur gear off of the slipper shaft. If the spur gear is too tight on the shaft, gently pry on the back of the gear with a flat screw driver to loosen it.

Repeat the above steps in reverse order to install the new spur gear.

DUAL SERVO STEERING SYSTEM

Revo uses dual digital waterproof steering servos and a single heavy-duty servo saver for powerful, responsive steering. To prevent unnecessary receiver battery drain, it is important to make sure that the servos are “at rest” when the steering is at neutral. If one servo is out of adjustment, then both servos will work against each other, fighting to find center. If the steering servos buzz or whine when the servos are powered and in the neutral position with no load on the front wheels, the servo linkage(s) should be adjusted.

Adjusting The Steering System

1. Remove the servo horns and steering links from the servos.

Disconnect the steering links from the servo saver.

REVO 3.3 • 35

Increasing Steering Travel

The Revo has the ability to increase the “throw” of the steering system and maximize steering travel. To increase the steering travel, move the steering linkages to the outer holes of the servo horns. Readjust the length of steering linkage to compensate for the servo horn position change so the servo horn is at a 7-degree offset.

Linkages

The maximum travel setting will cause the steering to be more sensitive and can increase the chance of rollover with the stock suspension setup. The following steps are recommended to improve steering stability:

1. Move the push rod to the center hole of the lower suspension arm’s push rod mount.

2. Lower the shock preload to 2mm on the front shocks and 4.5 mm on the rear shocks.

BASIC TUNING ADJUSTMENTS

2. Adjust both the steering links to be the exact same length (41.8mm - use “Steering Link Length Template” below to set length).

41.8 mm

Steering Link Length Template

3. Switch on the power to the receiver and the transmitter.

4. Adjust the steering trim on the transmitter to the neutral “0” position.

5. Connect one end of a steering link to the steering servo saver arm and the other end to the servo horn.

6. Position the steering servo saver arm perpendicular to the centerline of the vehicle.

7. While holding the steering servo saver arm in the position mentioned in step 6, install the servo horn onto the servo so that the steering link is parallel with the centerline of the vehicle. This will automatically set the servo horn at the 7-degree offset shown in the illustration.

8. Install the second servo horn on the other side following the same procedure.

9. Fine-tune the length of the second steering link to eliminate any load on the steering system in the neutral position. Remove one steering link screw from the servo horn. Adjust the steering link until the hole in the servo horn and hollow ball line up then reinstall the screw (see illustration).

If you are using aftermarket servos, it is important to use servo horns designed for Revo. Optional steering servo horns are sold separately for use with non-Traxxas servos.

Servo Saver Tuning

An optional stiffer spring is available for the servo saver when using servos with metal gear sets (see parts list for details). Do not use this spring with standard Traxxas high-torque servos.

BRAKE SETUP & ADJUSTMENT

Revo is equipped with a disc brake that rides on the yoke of the transmission’s front output shaft. The brake is preset at the factory and should not require attention. As the brake material wears, future adjustments may be necessary.

Brake Shoulder Screw Adjustment

The two shoulder bolts that secure the brake pads to the transmission

0.5mm

gap

housing may need to be adjusted periodically as the brake material wears down. They should be tightened so a 0.50mm (.020”) gap exists between the disk and the brake pad (on the transmission side). Adjust in one of the following ways:

1. Use a 0.50mm feeler gauge between the brake pad insert and brake disk.

2. Push the outer brake pad firmly against the inner pad with your finger, sandwiching the brake disk between the brake calipers.

Tighten the brake shoulder bolts until they just barely touch the brake pads. Do not over tighten these fasteners or you could damage the brake calipers. Loosen each of the shoulder bolts by 1 turn.

Brake Linkage Adjustment

When correctly adjusted, the brake linkage spring should barely touch the rod guide when the servo is in the neutral position (closed throttle). This will ensure no brake drag

Brake

Linkage

Spring

Less Brake

during operation of the vehicle. The brake adjustment knob can be threaded away from the spring for less braking power if desired.

Do not adjust the knob to apply pressure against the spring while the servo is in the neutral position. This will induce brake drag and cause undesirable handling.

Front of Truck

The position of the z-bend from the factory is in the middle position of the servo horn.

Changing this position will affect the way the brake force is applied. The brake adjustment knob will need to be readjusted if this position is changed.

Brake Pad Wear and Replacement

During normal use the brake pads should wear at a relatively slow rate.

However, if the brake pads wear down close to the metal pad holders, they should be replaced. Any more wear than this could cause damage to the brake parts and improper operation of the brake system.

36 • REVO 3.3

MAINTAINING AND STORING YOUR REVO

Your Revo requires timely maintenance in order to stay in top running condition. Neglecting the maintenance could allow dirt, deposits,

and moisture to build up inside the engine leading to internal engine

failure. The following procedures should be taken very seriously.

After each hour of running:

• Clean and re-oil the air filter. The instructions for this procedure are on page 21. We cannot stress enough the value of cleaning your air

filter at the scheduled intervals. The cleanliness and condition of your air filter directly influences the running life span of your engine.

Do not skip air filter maintenance!

• Clean the outside of the engine of accumulated dirt, oil, and grime.

Accumulated grime will decrease the engine’s ability to cool itself.

• To maintain optimum radio system performance, the RX Power Pack

(receiver battery) should be recharged after each hour of runtime.

• Tighten the wheel nuts (especially on the left side). Use the included

17mm wheel nut wrench.

After each running session:

• Perform after-run maintenance on the engine. This clears the engine of destructive moisture and other corrosive deposits. This is extremely important for the life of the engine. Read on for after-run maintenance procedures.

• Inspect the gears for wear, broken teeth, or debris lodged between the teeth

• Inspect the vehicle for obvious damage or wear. Look for:

1. Loose or missing screws

2. Cracked, bent, or damaged parts

3. Cut or loose wiring

4. Cut or kinked fuel lines

5. Signs of fuel leakage

Other periodic maintenance:

• Connecting rod: The connecting rod should be replaced when the piston and sleeve are replaced. Also replace the piston wrist pin and

G-clip whenever the connecting rod is replaced. As with other internal engine components, connecting rod life depends engine’s usage and the quality and frequency of the engine maintenance. Inspect the connecting rod after 3-gallons of fuel have been used.

• Slipper clutch pads (friction material): Under normal use, the friction material in the slipper clutch should wear very slowly. If the thickness of any one of the slipper clutch pads is 1.8mm or less, the friction disc should be replaced. Measure the pad thickness using calipers or measuring against the diameter of the 1.5 and 2.0mm hex wrenches provided with the model.

Minimum pad thickness, 1.8mm

• Piston/sleeve: The life of the piston and sleeve will vary greatly with how the engine is used and maintained. The piston and sleeve should be replaced when they no longer seal effectively (loss of compression). Symptoms include the engine being difficult to start when warm, stalling when warm, and stalling when throttle is suddenly closed to idle.

Replace the wrist pin and G-clip whenever the piston and sleeve are replaced.

After-run Procedure

You must perform after-run maintenance on your

Traxxas engine whenever the model will be stored for longer than a few hours. Taking the time to prepare your engine for storage will reward you with longer engine life, easier starting, and better performance.

When a nitro engine is shut off, some excess unburned fuel remains in the engine. The methanol in model engine fuel is hygroscopic, which means it easily attracts and absorbs moisture. This moisture can cause rust and corrosion on the steel engine parts (crankshaft, bearings, wrist pin and starter shaft) if the fuel is not removed from the engine. There are after run oil products available from your hobby dealer or you can use WD-40 ™ , a common household lubricant. To ensure your TRX 3.3 Racing Engine is protected from internal corrosion, use the following procedure:

1. Whenever possible, shut off the engine by pinching the fuel line closed. This allows most of the excess fuel to be consumed by the engine. Be sure the throttle is in the idle position. You may have to pinch the fuel line closed for several seconds before the engine stops.

2. Completely empty the fuel tank. Use your fuel-dispensing bottle to suck out the old fuel. Do not mix the old fuel with your fresh fuel supply. If you leave fuel in the tank, transporting or handling your

Revo may cause fuel to run into the engine.

If the engine is worn or damaged enough to require replacing the piston, sleeve, or connecting rod, consider exchanging your old engine for a brand new engine with

Traxxas Power Up. It could save you time and effort.

Details are in your model’s documentation package.

The TRX 3.3 Racing Engine is designed to be easy to rebuild. Critical engine components such as the crankcase, crankshaft, and engine bearings are made to extremely high quality standards and should under normal circumstances outlast multiple sets of pistons, sleeves, connecting rods, and wrist pins

(reciprocating assemblies).

It could be more economical for you to continue to use your good bearings and crankshafts, and simply replace the reciprocating assembly as needed. Engine assembly is not difficult, and replacing the reciprocating assembly does not require any special tools or skills.

15

REVO 3.3 • 37

Denatured alcohol (available from home centers and paint supply stores) in a spray bottle is an extremely effective cleaner. Be sure to wear safety glasses and gloves when working with denatured alcohol.

Be sure to follow proper maintenance and storage procedures to avoid damage to your engine and other components of your Revo.

Don’t put the fuel from your tank back into your fuel jug. Dispose of it properly, following city or county regulations.

Always wear eye protection when using compressed air or spray cleaners and lubricants.

MAINTAINING AND STORING YOUR REVO

3. With the fuel tank empty and the throttle at the idle position, try to start the engine. The engine will most likely start and run for a few seconds as it uses up any fuel remaining in the engine and fuel lines.

4. Once the engine stops, clean the outside of the engine with compressed air or spray motor cleaner. Once the engine is clean and dry, remove the glow plug power wire, glow plug, and air filter.

5. Open the throttle fully and spray a one-second burst of WD-40 into the carburetor and into the glow plug hole (Caution! Wear safety glasses to prevent spray from getting into your eyes). If you are using after-run oil, follow the manufacturer’s instructions.

6. Place a rag or paper towel over the engine to catch any WD-40 or after-run oil that may come out the carburetor or glow plug hole.

7. Connect the EZ-Start controller to the model and spin the engine for

10 seconds.

8. Remove the rag or paper towel and repeat steps 5–7 two more times.

9. Clean and re-oil the air filter so it will be ready for use next time. See page 21 for air filter maintenance instructions.

10. Replace the glow plug, reconnect the glow plug power wire, and reinstall the air filter.

Clearing a Flooded Engine

If the engine is primed for too long during startup, then it can become flooded with fuel. When the engine is flooded it will no longer turn due to excess fuel in the combustion chamber preventing upward movement of the piston. Use the following procedure to clear a flooded engine:

1. Remove the blue glow plug wire.

2. Remove the glow plug and gasket with the glow plug wrench supplied with your model. A 5/16 or 8mm nut driver will also work.

3. Turn the model upside down and plug in the EZ-Start controller.

4. Push the EZ-Start button for several seconds to clear the engine of excess fuel. Do not look into the glow plug hole while the

engine is spinning or you could spray fuel into your face!

5. Turn the model over and reinstall the glow plug and gasket.

6. Reconnect the blue glow plug wire to the glow plug.

7. Reconnect the EZ-Start controller.

8. Do not prime the engine. Pull the throttle to 1/2 throttle and push the

EZ-Start button. The engine should start immediately.

Piston stuck at “top dead center” (TDC)

“Top dead center” is the position where the piston is at the very top of the tapered sleeve. Occasionally an engine can get “stuck” at this position. This is most likely to happen on new engines during break-in, but can also happen at other times. If the engine is stuck at TDC, use the following procedure to release the piston from the sleeve:

Top Dead Center

1. Remove the glow plug using the included tool or

8mm (5/16”) nut driver and verify that the piston is at the top of its stroke.

2. Turn the Revo over and locate the flywheel through the cutout in the chassis. Insert a flat blade screwdriver as shown between the chassis and flywheel. Using the chassis for leverage, rotate the flywheel counterclockwise by pressing down on the screwdriver. The flywheel will turn, unsticking the piston from the sleeve.

3. Put two or three drops of light machine oil into the glow plug hole to lubricate the piston and sleeve. Do not use too much oil. Excess oil will hydro-lock the engine. Verify the starter will spin the engine with the glow plug out.

4. Rotate the flywheel so the piston is at bottom dead center and replace the glow plug with gasket. Reconnect the blue glow plug wire.

Bottom Dead Center

5. You should now be able to start the engine with the EZ-Start.

If you have questions or need technical assistance, call Traxxas at

1-888-TRAXXAS

(1-888-872-9927) (U.S. residents only)

38 • REVO 3.3

ADVANCED TUNING ADJUSTMENTS

This advanced tuning guide will take you one step further into the cutting edge technology that has been designed into Revo. Follow the instructions provided here to take advantage of Revo’s maximum performance potential.

SUSPENSION AND ALIGNMENT SETTINGS

Caster Adjustment

The caster angle of the front suspension may be used to adjust the understeer (push)/oversteer handling characteristics of the model. Generally, increasing the caster angle will move the truck towards an oversteer condition

(more traction on the front tires, less on the rear tires). Decreasing the caster angle will create a tendency towards understeer (pushing in the turns). From the factory, the front suspension is set to a caster angle of

10-degrees. The rear caster angle is not adjustable. The caster angle of the front suspension can be adjusted from 5° to 15°. Adjust the caster by positioning the caster adjustment shims on the upper control arms of the front suspension as shown in the table to the right.

Caster adjustment shims (2 front, 2 rear)

Ground plane

Caster

5.0°

7.5°

10.0°

12.5°

15.0°

10°

Number & Position of Caster Adjustment

Shims (Front Upper Control Arm)

In Front of

Hinge Pin Boss

None

One

Two

Three

Four

Behind Hinge

Pin Boss

Four

Three

Two

One

None

Caster Angle, and Bump Steer

Bump steer is unwanted change in the steering angle of the front wheels as the suspension travels up and down. It can result in unstable and unpredictable handling. Bump steer is affected by the position of the outer toe link end on the axle carrier. From the factory, the toe links are positioned so that bump steer is virtually eliminated (about 3/100 of a degree through the entire range of travel). When the caster angle is changed, the outer toe link end should be repositioned on the axle carrier to maintain zero bump steer geometry. Adjustment is achieved using the shims and hollow balls provided with the vehicle. Refer to the Bump Steer

Elimination chart on page 40, and look up your caster angle setting to find the correct position for the outer toe links. Positioning the toe-links correctly will maintain the original factory geometry and eliminate the unwanted steering angle changes caused by bump steer.

Roll Center

There are two holes on the bulkheads to mount each upper suspension arm. The roll center of the vehicle can be raised by

Upper Control Arm

Upper Mounting Holes

mounting the upper control arm in the lower of the two holes. This will effectively increase the roll stiffness of the vehicle (similar to installing

Upper Control Arm

Lower Mounting Holes

swaybars). Adding roll resistance to one end of the vehicle will tend to add traction to the opposite end. For example, increasing roll resistance in the rear by installing the upper arms in the lower holes will provide more traction for the front wheels and potentially more steering. Installing the upper arms in the lower holes on the front and rear will increase overall roll resistance without changing the handling balance. The arms are installed in the upper position in the front and lower position in the rear from the factory to make the truck easier and more forgiving to drive and less likely to traction roll in turns. Changing the arm positions should be reserved for track tuning. Note: When the upper suspension arms are moved to a different hole, the front outer toe link ends and rear toe control links should be repositioned to eliminate bump steer. Refer to the Bump Steer

Elimination chart on page 40, and look up your suspension combination

(caster angle and roll center position) to find the correct position for the front outer toe links and the rear toe control links. Adjustment is achieved using the shims and hollow balls provided with the vehicle.

Rockers (Progressive Rate/ Suspension Travel)

One of the most exciting aspects of Revo’s suspension is the inboard shock (damper) arrangement that uses pivoting rockers to translate vertical wheel travel into linear shock motion. The rockers can be changed to increase or decrease the maximum wheel travel and also to change the progressive rate of the suspension.

The progressive rate determines how much the force at the wheel produced by the springs being compressed (wheel force) will vary with suspension travel (or vertical travel of the wheel). On a progressive suspension arrangement, the wheel force will increase at a faster and faster rate as the suspension is compressed. It feels as though the shock spring gets progressively stiffer the more you compress the suspension.

On a linear suspension arrangement, the wheel force increases linearly as the suspension is compressed. The spring does not feel any stiffer, even when the suspension is fully compressed. This provides a very “plush” feeling suspension with seemingly bottomless suspension travel.

REVO 3.3 • 39

When using Long Travel rockers, a correspondingly thicker shock oil (or pistons with smaller diameter bypass holes) should also be used to ensure a proper relationship between the spring and damping forces.

40 • REVO 3.3

ADVANCED TUNING ADJUSTMENTS

Rocker Arm

Progressive 1

Progressive 2

Progressive 3

Long Travel

Total Travel

90mm

(60mm up / 30mm down)

90mm

(60mm up / 30mm down)

90mm

(60mm up / 30mm down)

120mm

(80mm up / 40mm down)

Progressive Rate

Low

Medium

High

Low

A total of four different rocker arm sets are available for Revo. All rocker arms except the Long Travel rocker arms will allow the wheel to travel a total of 90mm in the vertical direction. From the ride height position, the wheel will be able to travel 60mm in the upward direction (bump), and

30mm in the downward direction (droop). The Long Travel rocker arm increases total travel to 120mm. The progressive rate can be increased or decreased by installing different rocker arm sets. The rockers are labeled

Progressive 1 to Progressive 3. Progressive 1 rockers will provide a low progressive rate that maintains consistent damping force across through the whole range of suspension travel. These are best for extremely rough terrain that requires maximum suspension articulation. Progressive 3 rockers use high progressive rate that will improve high-speed cornering on smooth surfaces by providing a firmer feel. Body roll, brake dive and rear squat will also be reduced. Always change all four rockers as a complete set. Do not mix rates and travel.

Using rockers with lower progressive rate may require the use of stiffer springs to maintain proper spring pre-load and ride height. The spring pre-load adjuster on each shock is designed for minor adjustments. If the adjuster needs to be turned all the way down (compressing the spring) in order to maintain proper ride height, then the next stiffer spring should be used.

The chart below demonstrate the effect of the various rocker arms on wheel force as the suspension is compressed. On the progressive rate, wheel force is light at first and increases as the suspension is compressed.

Progressive Rate Travel 20

18

16

14

12

10

8

6

4

2

0

10 20 30 40 50

Wheel Travel

60 70 80 90

Constant Rate Travel

Bump Steer Elimination Chart

The illustrations and the following table detail the position of the outer toe link end for various caster and roll center settings to eliminate bump steer. The shims and the hollow balls used to adjust bump steer are provided with your vehicle.

FRONT

Outer Toe Link End Setup

Caster

5° 7.5° 10° 12.5° 15°

Control Arm

Mounting Hole on

Front Bulkhead

Standard

Hollow Ball

Thin Shim

Thick Shim

Upper

Lower

Thin Shim

Standard

Hollow Ball

Thick Shim

Tall Center

Hollow Ball

Thick Shim

Standard

Hollow Ball

Thin Shim

Thick Shim

Thin Shim

Standard

Hollow Ball

Outer Toe Link

End Setup

REAR

When the rear upper control arms are mounted in the lower of its two mounting holes in the bulkhead (roll center), the tall center hollow ball should be used as shown.

Tall Lower

Hollow Ball

Tall Center

Hollow Ball

(stock)

Upper

Lower

Upper

Lower

Upper

Lower

Upper

Control Arm

Mounting Hole on

Rear Bulkhead

Upper

Lower

ADVANCED TUNING ADJUSTMENTS

SHOCK TUNING

Multi-tool Shock Functions

Shock Pistons

The shock pistons can be replaced with the available optional pistons to vary the amount of damping.

Optional pistons with bypass holes that are larger or smaller (1, 2, or

3) than the factory installed stock pistons can be used to decrease or increase damping respectively.

Change the pistons if you only have one weight of shock oil available to you. From the factory, Revo is equipped with #1 pistons in the front and #2 pistons in the rear.

A. Tighten/Loosen Upper Cap

Shock disassembly

The shocks must be removed from the vehicle and disassembled to change the pistons. Use the shock exploded views included with the model to aid in the assembly process.

B. Tighten/Loosen Lower Cap

1. Remove the spring and lower spring retainer from the shock.

2. Remove the shock cap (A) and empty the shock body of shock oil.

3. Remove the lower cap (B) and the X-ring from the shock body.

4. Use side cutters to grip the shock

C. Remove/Install Rod End

shaft just above the rod end (C). Remove the rod end from the shock shaft using the suspension multi tool (C).

5. Remove the shock shaft with piston from the shock body out through the top of the shock body.

Shock assembly

1. Replace the stock piston with desired optional piston. Be careful not to lose the small washer located below the piston.

2. Position the new piston onto the shock shaft above the small washer. Grip the threads of the shaft with side cutters or needlenose pliers and tighten the nut with the 4-way wrench to secure the assembly.

Piston Installation/Removal

3. Insert the shock shaft assembly through the shock body until the piston bottoms out.

4. Lubricate the shaft and X-ring with silicone oil.

5. Install the X-ring over the shaft and into the bore of the shock body.

6. Install the lower cap using the suspension multi tool (B).

7. Slide the bump stop onto the shaft.

8. Grip the shaft close to the threads with needle nose pliers or side cutters and thread the rod end onto the shock shaft until the rod end bottoms out (C).

9. Fill the shock with new silicone shock oil up to the top of the shock body. Slowly move the piston up and down (always keeping it submerged in oil) to release the air bubbles. Let the shock sit for a few minutes to allow any remaining air bubbles to surface.

10. Slowly thread the upper cap with the installed shock bladder onto the shock body with the suspension multi tool (A). The excess oil will bleed out of the small hole in the shock cap. Tighten the shock cap until snug. Use the included steel shock wrench to hold onto shock body while tightening.

11. Reinstall the spring and lower retainer.

TRANSMISSION AND DIFFERENTIAL TUNING

Adjusting the Gear Ratio

The gear ratio on Revo can be adjusted for different conditions that may require either increased acceleration or increased top speed. Adjusting the gear ratio is accomplished by changing the clutch bell on the engine and/or the spur gear (slipper clutch gear) on the transmission. From the factory, Revo is equipped with a 14-tooth clutch bell and a 38-tooth spur gear. This combination will provide a good balance of acceleration and top speed. Optional spur gears and clutch bell gears are listed on your parts list. Refer to the chart on page 42 for possible gearing combinations.

Adjusting the Two-Speed Ratios

Revo is equipped to allow adjustment to the two-speed by installing optional close and wide-ratio gearsets. This requires transmission removal and disassembly (see Traxxas.com for detailed instructions). The close ratio gearsets will reduce top speed slightly but will provide more powerful acceleration by reducing engine rpm loss when shifting from

1st gear to 2nd gear. The wide ratio gear set is installed in the Revo 3.3.

The additional horsepower and torque output of the TRX 3.3 engine provides seamless shifting even with the larger gap between first and second gears.

Shock Piston Hole Sizes

Piston 1: 1.10 mm

Piston 2: 1.00 mm

Piston 3: 0.95 mm

Never slide the threads on the shock rod past the X-ring seal when it is installed and compressed by the bottom cap of the shock. Doing so will damage the seal and cause shock oil to leak.

REVO 3.3 • 41

Use higher viscosity

(thicker) oil for:

• More power to the wheels with the most traction.

• Racing on low-traction smooth surfaces .

• Better performance for climbing on uneven terrain.

Using lower viscosity

(thinner) oil for:

• More power to the wheels with least traction.

• Racing on low-traction rough surfaces.

42 • REVO 3.3

ADVANCED TUNING ADJUSTMENTS

The following gear ratio chart shows the available combinations with optional spur gears, clutch bells, and two-speed gear sets.

Gear Ratio Chart

With 14T Clutch Bell

2nd gear sets

17T/39T

(Standard)

16T/40T

(Close)

18T/38T

(Wide)

Gear

# of Spur Gear Teeth

36 38 40

1st 24.21

25.55

26.90

2nd 16.79

17.72

18.66

1st 24.21

25.55

26.90

2nd 18.30

19.31

20.33

1st 24.21

25.55* 26.90

2nd 15.45

16.31* 17.17

With 15T Clutch Bell

(standard)

# of Spur Gear Teeth

2nd gear sets

17T/39T

(Standard)

16T/40T

(Close)

18T/38T

(Wide)

Gear 36 38 40

1st 22.59

23.85

25.10

2nd 15.67

16.54

17.41

1st 22.59

23.85

25.10

2nd 17.08

18.03

18.97

1st 22.59

23.85

25.10

2nd 14.42

15.22

16.02

With 16T Clutch Bell

2nd gear sets

17T/39T

(Standard)

16T/40T

(Close)

18T/38T

(Wide)

# of Spur Gear Teeth

Gear 36 38 40

1st 21.18

22.36

23.54

2nd 14.69

15.51

16.32

1st 21.18

22.36

23.54

2nd 16.01

16.90

17.79

1st 21.18

22.36

23.54

2nd 13.52

14.27

15.02

With 17T Clutch Bell

2nd gear sets

17T/39T

(Standard)

16T/40T

(Close)

18T/38T

(Wide)

Gear

1st

# of Spur Gear Teeth

36 38 40

19.94

21.04

22.15

2nd 13.83

14.60

15.36

1st 19.94

21.04

22.15

2nd 15.07

15.90

16.74

1st 19.94

21.04

22.15

2nd 12.72

13.43

14.14

*stock configuration out of the box

Tuning The Sealed Gear Differentials

Revo’s front and rear gear differentials allow the left and right wheels to spin at different speeds while turning so that the tires do not scuff or skid.

This decreases the turning radius and increases steering performance.

The performance of the differentials can be tuned for different driving conditions and performance requirements. The differentials are filled with silicone differential fluid, and are sealed to maintain consistent long-term performance. Changing the oil in the differential with either lower or higher viscosity oil will vary the performance characteristics of the differentials. Changing to a higher viscosity oil in the differential will reduce the tendency for engine power to be transferred to the wheel with the least traction. You may notice this when making sharp turns on slick surfaces. The unloaded wheels on the inside of the turn have the least traction and tend to spin up to extremely high rpms. Higher viscosity (thicker) oil causes the differential to act like a limited-slip differential, distributing more equal power to the left and right wheels.

Revo will generally benefit from higher viscosity oil when climbing, rock crawling, or racing on low traction surfaces. Note: Heavier oil will allow power to be transferred even with one or more tires off the ground. This can make the vehicle more likely to overturn.

From the factory, both the differentials are filled with SAE 30,000W viscosity silicone oil. Only use silicone oil in the differentials. Traxxas sells SAE 10,000W and SAE 50,000W viscosity oil (see your parts list). The differentials have to be removed from the vehicle and disassembled to change/replace oil.

Installing the Long Travel Rockers

Use the exploded views included with the model to aid in the installation process. All of the rockers have labels identifying their proper location;

RF (right front), LF (left front), RR (right rear), and LR (left rear). Note: The exhaust system must be removed to access the rear rocker arms.

1. Remove shock absorbers

Remove the screws that secure the shocks to the chassis shock mounts, and to the rocker arms.

2. Install Long Travel shock springs

Replace all four of the 90mm travel shock springs with the four 120mm

Long Travel shock springs. The front shock springs are indicated by a silver dot, and the rear shock springs are indicated by a blue dot.

3. Install Long Travel rockers

Replace the 90mm travel rockers with the Long Travel rockers by removing the four 4x6 buttonhead cap screws from the rocker pivot posts. Remove the 5x11 ball bearings from the rockers. Install the same

5x11 ball bearings in the Long Travel rockers. Secure the Long Travel rockers to the pivots with the same 4x6 buttonhead cap screws.

4. Remove the blue spacers before installing the push rods

The blue spacers must be removed from all four of the suspension push rods. Install the push rods into the middle position (marked LT) on the lower suspension arms.

5. Reinstall shock absorbers

Reinstall all four shock absorbers back into their respective locations.

If you have questions or need technical assistance, call Traxxas at

1-888-TRAXXAS

(1-888-872-9927) (U.S. residents only)

TQ

i

ADVANCED TUNING GUIDE

The model’s TQi transmitter is equipped with the Traxxas Link Wireless

Module. This innovative accessory transforms your iPhone® or iPod touch® into a powerful tuning tool that equips your TQi with an intuitive, highdefinition, full-color graphical user interface.

Traxxas Link

The powerful Traxxas Link app (available in the Apple App Store) gives you complete control over the operation and tuning of your Traxxas model with stunning visuals and absolute precision. With the installed Traxxas Link telemetry sensors on the model, Traxxas Link displays real-time data such as speed, RPM, temperature, and battery voltage.

Intuitive iPhone and iPod touch interface

Traxxas Link makes it easy to learn, understand, and access powerful tuning options. Control

Drive Effects settings such as steering and throttle sensitivity; steering percentage; braking strength; and throttle trim by simply touching and dragging the sliders on the screen.

Real-Time Telemetry

With the installed telemetry sensors, the Traxxas Link dashboard comes to life showing you speed, battery voltage, RPM, and temperature. Set threshold warnings and log maximums, minimums, or averages. Use the recording function to document your dashboard view, with sound, so that you can keep your eyes on your driving and not miss a single apex.

Tap and slide to adjust Steering Sensitivity,

Throttle Trim, Braking Percent, and more!

The customizable Traxxas Link dashboard delivers real-time rpm, speed, temperature, and voltage data.

Manage up to 30 Models with Traxxas Link

The TQi radio system automatically keeps track of what vehicles it has bound to and what settings were used for each--up to 30 models total! Traxxas Link provides a visual interface to name the models, customize their settings, attach profiles, and lock them into memory. Simply choose a model and any previously bound transmitter, power them up, and start having fun.

Pairing the TQi transmitter with the Traxxas Link Wireless Module and the Traxxas Link App® for the first time:

1. Turn the transmitter switch on.

A

2. Open the Traxxas Link App on your mobile device. Touch the

Garage button, and then touch the Wireless Module button (A).

3. Press the button on the Traxxas

Link Wireless Module. The blue

LED on the module will blink (B).

B

C

4. Within 10 seconds, touch the “Search for Traxxas Link

Wireless Module” button on your mobile device (C).

D

5. The Bluetooth® icon in the status bar will turn blue, and the blue LED on the module will glow solid blue (D).

6. The Traxxas Link Wireless Module and the Traxxas Link App are now paired, and will automatically connect when the transmitter is turned on and the app is running.

TRAXXAS LINK MODULE LED CODES

LED Color / Pattern

Blue LED off

Name

Connecting mode

Notes

Traxxas Link App is not running on a paired device.

Slow blue

(0.5 sec on / 0.5 sec off)

Solid blue

Pairing mode

Connected

See above for information on pairing the module with Traxxas Link App.

See page 12 for information on how to use your transmitter controls.

TRAXXAS • 43

Throttle Trim Seek Mode

When the Multi-Function knob is set to throttle trim, the transmitter remembers the throttle trim setting. If the throttle trim knob is moved from the original setting while the transmitter is off, or while the transmitter was used to control another model, the transmitter ignores the actual position of the trim knob. This prevents the model from accidentally running away. The LED on the face of the transmitter will rapidly blink green and the throttle trim knob

(Multi-Function knob) will not adjust the trim until it is moved back to its original position saved in memory. To restore throttle trim control, simply turn the

Multi-Function knob either direction until the LED stops blinking.

Failsafe

Your Traxxas radio system is equipped with a built-in failsafe function that returns the throttle to its last saved neutral position in the event of a signal loss. The LED on the transmitter and the receiver will rapidly flash red.

Starting Over:

Restoring Factory Defaults

When programming your TQi transmitter, you may feel the need to start over with a clean slate. Follow these simple steps to restore the factory settings:

1. Turn transmitter off.

2. Hold both MENU and SET.

3. Turn transmitter on.

4. Release MENU and SET. The transmitter LED will blink red.

5. Press SET to clear settings. The

LED will turn solid green and the transmitter is restored to default.

44 • REVO 3.3

TQ

i

ADVANCED TUNING GUIDE

Available Tuning Adjustments

The following items can be adjusted most easily using your mobile device and the Traxxas Link application. All the features described below may also be accessed using the menu and set buttons on the transmitter and observing signals from the LED. An explanation of the menu structure follows on page 46.

Your Traxxas transmitter has a programmable Multi-Function knob that can be set to control various advanced transmitter functions

(set to Steering Sensitivity by default, see page 13). Experiment with the settings and features to see if they can improve your driving experience.

Steering Percentage (Dual Rate)

The Multi-Function knob can be set to control the amount

(percentage) of servo travel applied to steering. Turning the Multi-

Function knob fully clockwise will deliver maximum steering throw; turning the knob counter-clockwise reduces steering throw (note: turning the dial counter-clockwise to its stop will eliminate all servo travel). Be aware that the steering End Point settings define the servo’s maximum steering throw. If you set Steering Percentage to

100% (by turning the Multi-Function knob fully clockwise), the servo will travel all the way to its selected end point, but not past it. Many racers set Dual Rate so they have only as much steering throw as they need for the track’s tightest turn, thus making the model easier to drive throughout the rest of the course. Reducing steering throw can also be useful in making a model easier to control on hightraction surfaces, and limiting steering output for oval racing where large amounts of steering travel are not required.

Throttle Sensitivity (Throttle Exponential)

The Multi-Function knob can be set to control Throttle Sensitivity.

Throttle Sensitivity works the same way as Steering Sensitivity as described on page 13, but applies the effect to the throttle channel.

Only forward throttle is affected; brake/reverse travel remains linear regardless of the Throttle Sensitivity setting.

Steering and Throttle End Points

The TQi transmitter allows you to choose the limit of the servo’s travel range (or its “end point”) independently for left and right travel (on the steering channel) and throttle/brake travel (on the throttle channel). This allows you to fine-tune the servo settings to

TRANSMITTER LED CODES

LED Color / Pattern

Solid green

Slow red (0.5 sec on / 0.5 sec off)

Flashing fast green (0.1 sec on / 0.15 sec off)

Flashing medium red (0.25 sec on / 0.25 sec off)

Flashing fast red (0.125 sec on / 0.125 sec off)

Programming Patterns

or x

8 x 8

Counts out number (green or red) then pauses

Fast green 8 times

Fast red 8 times

RECEIVER LED CODES

LED Color / Pattern

Solid green

Slow red (0.5 sec on / 0.5 sec off)

Flashing fast red (0.125 sec on / 0.125 sec off)

Name

Normal Driving Mode

Binding

Throttle Trim Seek Mode

Low Battery Alarm

Link Failure / Error

Notes

See page 12 for information on how to use your transmitter controls.

See page 13 for more information on binding.

Turn the Multi-Function knob right or left until the LED stops flashing.

See sidebar for more information.

Put new batteries in the transmitter. See page 10 for more information.

Transmitter and receiver are no longer bound. Turn the system off and then back on to resume normal operation. Find source of the link failure (ie out of range, low batteries, damaged antenna).

Current menu position

Menu setting accepted (on SET)

Menu SET invalid

See Menu Tree for more information.

User error such as trying to delete a locked model.

Name

Normal Driving Mode

Binding

Fail-Safe / Low Voltage Detect

Notes

See page 12 for information on how to use your transmitter controls.

See page 13 for more information on binding.

Consistent Low Voltage in the receiver triggers Fail-Safe so there is enough power to center the throttle servo before it completely loses power.

TQ

i

ADVANCED TUNING GUIDE prevent binding caused by the servo moving steering or throttle linkages (in the case of a nitro model) farther than their mechanical limits. The end point adjustment settings you select will represent what you wish to be the servo’s maximum travel; the Steering Percentage or

Braking Percentage functions will not override the End

Point settings.

Steering and Throttle Sub-Trim

The Sub-Trim function is used to precisely set the neutral point of the steering or throttle servo in the event that simply setting the trim knob to “zero” does not completely center the servo. When selected, Sub-

Trim allows finer adjustment to the servo output shaft’s position for precise setting of the neutral point. Always set the Steering Trim knob to zero before making final adjustment (if required) using Sub-Trim. If Throttle Trim has been previously adjusted, the Throttle Trim will need to be reprogrammed to “zero” before making final adjustment using Sub-Trim.

Braking Percentage

The Multi-Function knob may also be set to control the amount of brake travel applied by the servo in a nitropowered model. Electric models do not have a servooperated brake, but the Braking Percentage function still operates the same way in electric models. Turning the

Multi-Function knob full clockwise will deliver maximum brake throw; turning the knob counter-clockwise reduces brake throw (Note: Turning the dial counter-clockwise to its stop will eliminate all brake action).

Throttle Trim

Setting the Multi-Function knob to serve as throttle trim will allow you to adjust the throttle’s neutral position to prevent unwanted brake drag or throttle application when the transmitter trigger is at neutral. Note: Your transmitter is equipped with a Throttle Trim Seek mode to prevent accidental runaways. See the sidebar for more information.

Setting Lock

Once you’ve adjusted all of these settings the way you like them, you may want to disable the Multi-Function knob so none of your settings can be changed. This is especially handy if you operate multiple vehicles with a single transmitter via Traxxas Link Model Memory.

Multiple Settings and the Multi-Function Knob

It is important to note that settings made with the

Multi-Function knob are “overlaid” on top of each other.

For example, if you assign the Multi-Function to adjust

Steering Percentage and set it for 50%, then reassign the knob to control Steering Sensitivity, the transmitter will “remember” the Steering Percentage setting.

Adjustments you make to Steering Sensitivity will be applied to the 50% steering throw setting you selected previously. Likewise, setting the Multi-Function knob to

“disabled” will prevent the knob from making further adjustments, but the last setting of the Multi-Function knob will still apply.

TRAXXAS LINK MODEL MEMORY

Traxxas Link Model Memory is an exclusive, patentpending feature of the TQi transmitter. Each time the transmitter is bound to a new receiver, it saves that receiver in its memory along with all the settings assigned to that receiver. When the transmitter and any bound receiver are switched on, the transmitter automatically recalls the settings for that receiver. There is no need to manually select your vehicle from a list of model memory entries.

Model Lock

The Traxxas Link Model Memory feature can store up to thirty models (receivers) in its memory. If you bind a thirty-first receiver, Traxxas Link Model Memory will delete the “oldest” receiver from its memory (in other words, the model you used the longest time ago will be deleted). Activating Model Lock will lock the receiver in memory so it cannot be deleted.

You may also bind multiple TQi transmitters to the same model making it possible to pick up any transmitter and any previously bound model in your collection and simply turn them on and drive. With Traxxas Link Model Memory, there is no need remember which transmitter goes with which model and there is never a need to have to select any model from a list of model memory entries. The transmitter and receiver do it all for you automatically.

To activate Model Lock:

1. Switch on the transmitter and receiver you wish to lock.

2. Press and hold MENU. Release when the status LED blinks green.

3. Press MENU three times. The status LED will blink green four times repeatedly.

4. Press SET. The status LED will blink green in single- flash intervals.

5. Press SET once. The status LED will blink red once repeatedly.

6. Press MENU once, the LED will blink red twice repeatedly.

7. Press SET, the LED will blink rapidly green.

The memory is now locked. Press MENU and SET to return to driving mode.

Note: To unlock a memory, press SET twice at step 5.

The LED will blink rapidly green to indicate the model is unlocked. To unlock all models, press MENU twice at step 6 and then press SET.

To delete a model:

At some point, you may wish to delete a model you nolonger drive from the memory.

1. Switch on the transmitter and receiver you wish to delete.

2. Press and hold MENU. Release when the status LED blinks green.

3. Press MENU three times. The status LED will blink green four times repeatedly.

4. Press SET once. The status LED will blink green once repeatedly.

5. Press MENU once. The status LED will blink green twice repeatedly.

6. Press SET. The memory is now selected to be deleted.

Press SET to delete the model. Press and hold MENU to return to driving mode.

REVO 3.3 • 45

TQ

i

ADVANCED TUNING GUIDE

MENU TREE

The menu tree below shows how to navigate through the TQi transmitter’s various settings and functions.

Press and hold MENU to enter the menu tree, and use the following commands to navigate through the menu and select options.

MENU: When you enter a menu, you always start at the top. Press MENU to move down the menu tree. When you reach the bottom of the tree, pressing MENU again will return you to the top.

SET: Press SET to move across the menu tree and select options. When an option is committed to the transmitter’s memory, the status LED will rapidly blink green.

BACK: Press both MENU and SET to go back one level in the menu tree.

EXIT:

Press and hold MENU to exit programming.

Your selected options will be saved.

ECHO: Press and hold SET to activate the “echo” function. Echo will “play back” your current position on the Menu Tree, should you lose your place. For example: If your current position is Steering Channel End Points, holding SET will cause the LED to blink green twice, green once, and then red three times. Echo will not alter your adjustments or change your position in the programming sequence.

Below is an example of how to access a function in the menu tree. In the example, the user is setting the Multi-Function knob to be a steering Dual Rate control.

To set the Multi-Function knob to control STEERING DUAL RATE (%):

1. Switch the transmitter on

2. Press and hold MENU until the green LED lights. It will blink in single intervals.

3. Press SET. The red LED will blink in single intervals to indicate Steering

Dual Rate has been selected.

4. Press MENU twice. The red LED will blink three times repeatedly to indicate Steering Percentage has been selected.

5. Press SET to select. The green LED will blink 8 times fast to indicate successful selection.

6. Press and hold MENU to return to driving mode.

46 • REVO 3.3

Enter Programming

Press and hold

MENU for 3 seconds

1

Multi-Function Knob

One Blink Green

2

Press

MENU

Channel Setup

Two Blinks Green

3

4

Press

MENU

Press

MENU

Mode Selection

Three Blinks Green

Traxxas Link

Four Blinks Green

Press

SET

Press

SET

Press

MENU

Press

SET

Press

SET

1

2

3

Press MENU to move through options.

Press SET to select an option.

1

Steering Sensitivity (Expo)

One Blink Red

2

Throttle Sensitivity (Expo)

Two Blinks Red

3

Steering % (Dual Rate)

Three Blinks Red

4

Braking %

Four Blinks Red

5

6

Throttle Trim

Five Blinks Red

Knob Disabled

Six Blinks Red

Steering (Channel 1)

One Blink Green

Throttle (Channel 2)

Two Blinks Green

Shift (Channel 3)

Three Blinks Green

Press

SET

Press

SET

Press

SET

Press SET to select an option.

1

Electric

One Blink Red

2

Press

MENU

Nitro

Two Blinks Red

Note: The transmitter is “live” during programming so you can test the settings real time without having to exit the menu tree.

Press MENU to move through options.

Press SET to select an option.

1

Servo Reversing

One Blink Red

Press SET to reverse servo direction.

2

Sub-Trim

Two Blinks Red

Use knob to adjust sub-trim. Press SET to save.

3

End Points

Use steering wheel to

Three Blinks Red

adjust. Turn right to desired end point, press set to save.

Turn left to desired endpoint and press set to save.

To reset max throw: Let go of controls and press SET.

4

Reset End Points

Four Blinks Red

Press SET to restore factory default endpoints.

1

2

Press

MENU

Model Locking

One Blink Green

Delete Model

Two Blinks Green

Press

SET

Press

SET

1

2

3

1

Servo Reversing

One Blink Red

Press SET to reverse servo direction.

2

Sub-Trim

Two Blinks Red

Use knob to adjust subtrim. Press SET to save.

3

End Points

Use trigger to adjust. Pull

Three Blinks Red

back to desired end point, press set to save. Push forward to desired endpoint and press set to save.

To reset max throw: Let go of controls and press SET.

4

Reset End Points

Four Blinks Red

Press SET to restore factory default endpoints.

1

Servo Reversing

One Blink Red

1

Unlock

One Blink Red

Lock

Two Blinks Red

Unlock All

Three Blinks Red

Confirm Deletion

One Blink Red

Set Multi-Function knob for STEERING

SENSITIVITY (Expo)

Set Multi-Function knob for THROTTLE

SENSITIVITY (Expo)

Set Multi-Function knob for STEERING

DUAL RATE (%)

Set Multi-Function knob for BRAKING

PERCENTAGE (%)

Set Multi-Function knob for

THROTTLE TRIM

Press/hold MENU

green LED blinks

Press/hold MENU

green LED blinks

Press/hold MENU

green LED blinks

Press/hold MENU

green LED blinks

Press SET

red LED blinks

Press SET

red LED blinks

Press SET

red LED blinks

Press SET

red LED blinks

Press/hold MENU

green LED blinks

Press SET

red LED blinks

To LOCK the

Multi-Function knob

Press/hold MENU

green LED blinks

To REVERSE the direction of

STEERING servo

Press/hold MENU

green LED blinks

To set the SUB TRIM of the STEERING servo

Press/hold MENU

green LED blinks

To set the END

POINTS of the

STEERING servo

Press/hold MENU

green LED blinks

To reset the END

POINTS of STEERING servo to defaults

Press/hold MENU

green LED blinks

To REVERSE the direction of

THROTTLE servo

Press/hold MENU

green LED blinks

To set the SUB TRIM of the THROTTLE servo

Press/hold MENU

green LED blinks

To set the END

POINTS of the

THROTTLE servo

Press/hold MENU

green LED blinks

To reset the END

POINTS of THROTTLE servo to defaults

Press/hold MENU

green LED blinks

To REVERSE the direction of SHIFT servo

Press/hold MENU

green LED blinks

Press SET

red LED blinks x 2

Press MENU

green LED blinks (x2)

Press MENU

x 2 green LED blinks (x2) x 2

Press MENU

green LED blinks (x2) x

2

Press MENU

red LED blinks (x2) x 2

Press MENU

green LED blinks (x2)

Press MENU

x 2 green LED blinks (x2) x 2

Press MENU

green LED blinks (x2) x

2

Press MENU

red LED blinks (x2) x 2

Press MENU

green LED blinks (x2) x 8

Press SET to confirm

green LED blinks (x8) x

2

Press MENU to confirm

red LED blinks (x2) x 3

Press MENU twice

red LED blinks (x3)

Press/hold MENU

returns to driving mode x

8

Press SET to select

green LED blinks (x8) x 8

Press SET to select

green LED blinks (x8) x 4

Press MENU 3 times

red LED blinks (x4) x 8

Press SET to select

green LED blinks (x8)

Press/hold MENU

returns to driving mode

Press/hold MENU

returns to driving mode

Press/hold MENU

returns to driving mode x 5

Press MENU 4 times

red LED blinks (x5) x

6

Press MENU 5 times

red LED blinks (x6) x 8

Press SET to select

green LED blinks (x8) x

8

Press SET to lock

green LED blinks (x8)

Press/hold MENU

returns to driving mode

Press SET

green LED blinks

Press SET

green LED blinks

Press SET

green LED blinks

Press SET

green LED blinks

Press SET

red LED blinks

Press SET

red LED blinks

Press SET

red LED blinks

Press/hold MENU

returns to driving mode x 8

Press SET to reverse servo direction

Press MENU

x red LED blinks (x2)

2 x 3

Press MENU twice

red LED blinks (x3) x

4

Press MENU 3 times

red LED blinks (x4)

Press SET

green LED blinks

Press SET

green LED blinks

Press SET

red LED blinks x 2

Press MENU

green LED blinks (x2)

Press MENU

x 2 green LED blinks (x2)

Press SET

red LED blinks

Press SET

red LED blinks

Press SET

green LED blinks

Press SET

green LED blinks

Press SET

green LED blinks x 2

Press MENU

green LED blinks (x2) x

2

Press MENU

green LED blinks (x2) x 3

Press MENU twice

green LED blinks (x3)

Press SET

red LED blinks

Press SET

red LED blinks

Press SET

red LED blinks

Adjust the Multi-

Function knob until the

LED turns solid green.

MENU TREE FORMULAS

To select functions and make adjustments to the TQi transmitter without referencing the menu tree, turn your transmitter on, find the function in the left column you wish to adjust, and simply follow the corresponding steps.

Press/hold MENU

returns to driving mode

Use Multi-Function

knob to set neutral

Turn steering

wheel to desired max left and right travel x

8

Press SET

to reset end points x 8

Press SET to reverse servo direction

Press SET

x to save position

8 x 8

Press SET

to save each position

Press/hold MENU

returns to driving mode

Press/hold MENU

returns to driving mode

Press MENU

x red LED blinks (x2)

2 x 3

Press MENU twice

red LED blinks (x3) x

4

Press MENU 3 times

red LED blinks (x4) x 8

Press SET to reverse servo direction

Use Multi-Function

knob to set neutral

Use throttle

trigger to set desired max throttle or brake x

8

Press SET

green LED blinks (x8)

Press/hold MENU

returns to driving mode

1

Always turn your transmitter on first.

Press/hold MENU

returns to driving mode

Turn steering wheel

to test settings

Press SET

x to save position

8

Press SET to save

Use trigger to test

Press/hold MENU

returns to driving mode

IF END POINTS

ARE OK:

Press/hold MENU

returns to driving mode

IF END POINTS

NEED TO BE

CHANGED:

Press SET

and repeat steps 6-8

Press/hold MENU

returns to driving mode

IF END POINTS

ARE OK:

Press/hold MENU

returns to driving mode

IF END POINTS

NEED TO BE

CHANGED:

Press SET

and repeat steps 7-9

REVO 3.3 • 47

140902 KC2226-R00

owner

s manual

MODEL 53097-1

6200 Traxxas Way, McKinney, Texas 75070

1-888-TRAXXAS

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
