Product Guide 2008
®
Building Networks for People
2008
Product Guide
Hexachrome Orange
®
Building Networks for People
D-Link Corporation, No. 289 Xinhu 3rd Road, Neihu, Taipei 114, Taiwan
Foreword
D-Link, a global leader in networking business, has been developing networking products for over 21 years to
improve the lives of people by providing business, broadband, consumer, and digital home solutions. D-Link has
been the market leader in SOHO and SMB networking, holding a lead market share of 24.4% worldwide¹. The
Company has established itself as a worldwide name among networking products and technology, being recognized
by BusinessWeek in both their list of “Top 100 Information Technology Companies,” and also being ranked ninth for
“The Best Returns.” Most recently, D-Link has earned 5-star certification from TÜV Rheinland, which recognizes not
only D-Link’s brand value, but also its social responsibilities as a leading networking company.
Business Solutions
D-Link delivers a wide range of powerful networking solutions that are designed to create exceptional value for
businesses at the enterprise, departmental, and workgroup processing levels. D-Link offers powerful solutions for
upgrading to 10-Gigabit Ethernet and 802.11n draft WLAN. Its metro network, multilayer campus, and
award-winning xStack switches provide powerful performance, flexible deployment, security, and centralized
management suitable for any business environment, while its industry’s unique unified wired and wireless switching
solutions seamlessly integrate wired and wireless LAN together.
D-Link xStack switches, operating in conjunction with D-Link NetDefend Unified Threat Management (UTM)
firewalls, have helped create robust network security for protecting businesses from both internal and external
threats. D-Link’s network security appliances running the NetDefend security operating system have obtained the
highest level of ICSA Labs firewall certification (Firewall 4.1 with Corporate Level), and have now also satisfied the
stringent testing criteria of IPSec 1.2 Enhanced Certification.
Awards & Accolades
PC User Magazine
Best Buy Award
July 2007
INTEROP Japan
DGS-3200-10 Switch
Best of INTEROP Show Award
June 2007
BenchmarkReviews.com
DNS-323 Network Storage Enclosure
& DIR-655 Xtreme N Router
Golden Tachometer Award
August 2007
Review Lab
Network Storage Enclosure DNS-323
Recommended Product Award
November 2007
PC Magazine
DIR-655 Xtreme N Wireless Router
Editors’ Choice Award
May 2007
TÜV Rheinland
TÜV Rheinland Star* Award
Highest 5-star Certification
October 2007
Broadband Solutions
D-Link develops and builds the equipment that service providers need to offer reliable high-speed communication.
Providing more than just a source of communication for users, broadband service providers today offer users
applications such as network storage, integrated voice and video, and IP Surveillance. VoIP is also establishing
itself as a cost-effective option for utilizing network convergence, promoting users to voice services on their IP VPN.
The new wireless standard IEEE 802.16 WiMAX will play an important role in networking, and D-Link will be
shipping a complete line of WiMAX products in 2008.
D-Link’s wide range of broadband offerings, including xDSL, PON devices, new generation IAD, IPTV, and VoIP
related solutions, allows service providers to customize systems to the specific needs of subscribers in every
category to accommodate Internet bandwidth and content. D-Link’s in-depth research and development make it
possible to provide innovative solutions for today that can assimilate to the future needs of tomorrow’s markets.
Consumer & Digital Home Solutions
D-Link brings the digital home closer to consumers from around the world for productivity and entertainment. It
incorporates cutting-edge network technology into next-generation solutions, which includes storage, IP
surveillance, multimedia, gaming, VoIP, enhanced high-speed Powerline, and UWB related products. D-Link
enables users to connect to a wide range of devices for seamless interoperability that can be accessed anytime,
anywhere. The advanced communication products of D-Link can stream data wirelessly throughout the home and
remotely control various devices.
The interactive home based on IP solutions is the next step for the evolution of the digital home concept, bringing
technology within reach of all consumers. D-Link’s progress in products, like storage, digital media players, IP
surveillance, gaming and video conferencing for consumers, will enable it to develop automated network solutions
that enhance the lives of digital home consumers.
ChannelPartner
Preferred Vendor 2008 for Network
and Telecommunication
February 2008
International CES
DSM-750, DUB-2240, DGL-4500
and DSM-210
Innovations Honoree Designation
November 2007
PC Magazine
Service & Quality 2007
Readers’ Choice
November 2007
PC Authority
A-List & Labs Test Award
November 2007
Environmental Responsibility
D-Link recognizes its responsibility towards its business growth and society, constantly adjusting and innovating
technology to meet the needs of both the consumers and the environment. The Company has been actively working
to reduce energy consumption, achieving certifications such as Energy Star and RoHS compliance, and developing
Green Ethernet products to help protect the Earth. D-Link progressively works to create solutions that benefit both
users and the environment, working towards a brighter future.
¹ Source: In-Stat 2007 Q3
BusinessWeek
Top 100 List Information Technology Companies
Top Ten Companies That Deliver The Best Returns
July 2007
Computer Power User Magazine
DIR-655 Xtreme N Wireless Router
Best Networking Device
November 2007
TABLE OF CONtENtS
Broadband
ADSL2/2+ IP DSLAM-------------------------------------------------------------2
ADSL2/2+ Modems & Routers-------------------------------------------------4
Cable Modems----------------------------------------------------------------------7
VDSL2 Modems, Routers & Switches----------------------------------------8
GE PON ONU & OLT Switches---------------------------------------------- 10
VoIP Phone Adapters, Routers & Gateways------------------------------ 12
IP Phones-------------------------------------------------------------------------- 16
IP PBX------------------------------------------------------------------------------ 18
Broadband Routers-------------------------------------------------------------- 19
VPN Routers---------------------------------------------------------------------- 20
Wireless Networking
Wireless G------------------------------------------------------------------------- 22
Wireless 108G-------------------------------------------------------------------- 25
Wireless 108AG------------------------------------------------------------------ 28
Wireless N------------------------------------------------------------------------- 30
Xtreme N--------------------------------------------------------------------------- 32
RangeBooster N, RangeBooster N 650------------------------------------ 34
2.4GHz/5GHz Dual Band Antennas ---------------------------------------- 35
2.4GHz Antennas---------------------------------------------------------------- 36
Antenna Cable Kits-------------------------------------------------------------- 36
Antenna Cable Assemblies---------------------------------------------------- 37
Unified Wired/Wireless Switching ------------------------------------------- 38
Bluetooth Personal Area Network------------------------------------------- 41
Wireless USB--------------------------------------------------------------------- 42
Mobile Communication
3G/3.5G Mobile Adapters & Routers---------------------------------------- 44
WiMAX Modems, Adapters & Routers------------------------------------- 45
Network Security
SecureSpot SOHO Firewalls-------------------------------------------------- 46
VPN Client Software------------------------------------------------------------ 47
IPS Firewalls---------------------------------------------------------------------- 48
UTM Firewalls--------------------------------------------------------------------- 50
IPS Subscriptions---------------------------------------------------------------- 51
AV Subscriptions----------------------------------------------------------------- 52
WCF Subscriptions-------------------------------------------------------------- 53
Unmanaged Ethernet Switches---------------------------------------------- 54
Unmanaged Gigabit Switches------------------------------------------------ 56
Light Management Switches-------------------------------------------------- 57
Web Smart Switches------------------------------------------------------------ 58
Entry-Level SNMP Ethernet Switches-------------------------------------- 60
Stand-Alone Managed Gigabit Switches---------------------------------- 62
Entry-Level Gigabit Stack------------------------------------------------------ 63
Security Gigabit Switches------------------------------------------------------ 64
Access Layer Ethernet Switches--------------------------------------------- 65
Access Layer Gigabit Stack--------------------------------------------------- 67
Core Gigabit Stack--------------------------------------------------------------- 69
Core Chassis---------------------------------------------------------------------- 72
Redundant Power Supplies--------------------------------------------------- 78
Wired Ethernet
Ethernet Adapters---------------------------------------------------------------- 84
Remote Boot ROM-------------------------------------------------------------- 85
Gigabit Adapters------------------------------------------------------------------ 86
Transceivers----------------------------------------------------------------------- 87
Media Converters---------------------------------------------------------------- 88
Power Over Ethernet (PoE) Adapters & Midspans---------------------- 92
Powerline
Powerline Ethernet Adapters-------------------------------------------------- 93
Peripheral Sharing
KVM Switches--------------------------------------------------------------------- 94
Print Servers----------------------------------------------------------------------- 96
Surveillance
Internet Cameras----------------------------------------------------------------- 98
Internet Cameras Accessories----------------------------------------------- 100
Network Management
D-View 6.0 SNMP Network Management-------------------------------- 102
Video Conference
Video Phones-------------------------------------------------------------------- 103
Storage
Storage Area Networks-------------------------------------------------------- 104
Network Attached Storage---------------------------------------------------- 106
Analog Modems
Dial-up Modems----------------------------------------------------------------- 107
Multimedia
Network Media Players-------------------------------------------------------- 108
PC Camera----------------------------------------------------------------------- 110
USB Adapters & Hubs--------------------------------------------------------- 111
Disclaimers
Every effort has been made to ensure the accuracy of the information in this product guide. However,
D-Link assumes no responsibility for the accuracy of the information. Product information is subject to
change without prior notice. Mention of non-D-Link products or services is for information purposes
only, and constitutes neither an endorsement nor a recommendation. D-Link assumes no responsibility
with regard to the selection, performance or use of these products. All understandings, agreements or
warranties, if any, take place directly between the vendors and the prospective users.
D-Link shall not under any circumstances be liable to any person for any special, incidental, indirect
or consequential damages, including, without limitation, damages resulting from use of or reliance on
the information, loss of profits or revenues or costs of replacement goods, even if D-Link is informed in
advance of the possibility of such damages.
Trademarks
D-Link is a registered trademark of D-Link Corporation and its overseas subsidiaries. D-View, Wireless
G, Wireless N, RangeBooster N, RangeBooster N 650, Xtreme N, Personal Air, SecureSpot, NetDefend,
xStack, SecuriCam, MediaLounge, GamerLounge, GameFuel, VisualStream and QuickMedia are
trademarks of D-Link Corporation and its overseas subsidiaries. All other trade names and trademarks
are properties of their proprietors.
Product specifications are subject to change without prior notice.
Copyright © 2008 D-Link Corporations. All rights reserved.
BROADBAND
Features & Benefits
●Stand-Alone, Stackable and
Chassis-Based Solutions
ADSL2/2+ IP DSLAM
The IP DSLAM (DSL Access Multiplexer) are carrier-class, high performance devices
deployed at the service provider CO (central office) side. They provide IP-based
broadband access services to ADSL subscribers CPE (consumer premise equipment)
in the multi-unit, multi-tenant buildings over the existed telephone line.
The IP DSLAM connect to the service provider’s passive optical network (PON)
through their fiber interface. They cost-effectively deliver high-speed Internet access
or voice/video service through ADSL and Gigabit Ethernet fiber.
●Stand-Alone and Stackable
Devices Can Be Managed as
Single Unit
The IP DSLAM extend the broadband service to the end user where the distance from
central office may up to 5 km (for ADSL) or 6.1 km (for ADSL2+). Line performance
offers rates from 32Kbps to 3 Mbps (upstream), and from 32Kbps to 24Mbps
(downstream).
●Chassis Solution Can
Accommodate Up to 14 Line
Cards
●SNMP/Telnet Management
●CLI with RS-232 Console Port
●IGMP Snooping, Up to 256
Multicast Groups
●802.1Q VLAN, GARP/GVRP
Two categories of IP DSLAM are available for selection. The low-profile rack-mount
IP DSLAM have fixed number of ports and are suitable for connection to smaller
apartment buildings. They are stackable, allowing ISP to easily add ports to meet their
subscriber expansion. The chassis-based IP DSLAM are tailored to meet telecom
carriers’ requirements for high-speed remote access and subscriber aggregation.
They can accommodate a large number of line cards and have high bandwidth
flexible backplane designs, combining a variety of technologies to meet various kinds
of market requirements.
●MAC/IP Filtering, MAC/IPBased ACL Security
●802.1d Spanning Tree
●Traffic Prioritization QoS Based
on 802.1P, Diffserv, MAC/IP,
TCP/UDP
DAS-3216
DAS-3248
16-Port IP DSLAM
48-Port IP DSLAM
●MAC/IP-Based Rate Limiting
●802.3ad Link Aggregation
●BRAS, 802.1x, DHCP Server/
Relay, PPPoE, MPLS, VLANBased VPN, L3 Router, L2TP
●Up to 512 Concurrent VLANs
●Multiple PVC Per Subscriber
Line
● ADSL2/2+ Standard, Annex A
● 16 ADSL Ports with POTS Splitters
● 2 10/1001000BASE-T Gigabit Uplinks
● 10/100/1000BASE-T In-band
Management Port
DAS-3224
DAS-3324
24-Port IP DSLAM
24-Port IP DSLAM
● ADSL2/2+ Standard, Annex A
● 24 ADSL Ports with POTS Splitters
● 2 10/1001000BASE-T Gigabit Uplinks
● 10/100/1000BASE-T In-band
Management Port
D-Link Product Guide 2008
● ADSL2/2+ Standard, Annex A
● 48 ADSL Ports with POTS Splitters
● 2 10/1001000BASE-T Gigabit Uplinks
● 10/100/1000BASE-T In-band
Management Port
● ADSL2/2+ & Long Reach DSL, Annex A
● 24 ADSL Ports with POTS Splitters
● 2 10/100ASE-FX Ethernet Fiber Ports
DAS-3324G
DAS-4192-20
DAS-4672-10
24-Port IP DSLAM
ADSL2+ Line Card
ADSL2+ Line Card
● 48 ADSL Ports
● For DAS-4192
DAS-4192-30
● ADSL2/2+ & Long Reach DSL, Annex A
● 24 ADSL Ports with POTS Splitters
● 2 10/100/1000BASE-T Gigabit Uplinks
DAS-3324M
24-Port IP DSLAM
● ADSL2/2+ & Long Reach DSL, Annex A
● 24 ADSL Ports with POTS Splitters
● 2 Gigabit Uplinks (10/100/1000BASE-T
or 1000BASE-SX/LX)
● Up to 6 Cascaded Units Manageable as
Single Unit
Line Card Dummy Panel
● For DAS-4192
192-Port IP DSLAM
DAS-4672-20
ADSL2+ Line Card
● 48 ADSL Ports
● For DAS-4672
DAS-4192-40
DAS-4672-30
POTS Splitter Card
Line Card Dummy Panel
● 48 Splitter Ports
● For DAS-4192
● For DAS-4672
DAS-4192-50
DAS-4672-40
POTS Splitter Card Dummy Panel
POTS Splitter Card
● For DAS-4192
● 48 Splitter Ports
● For DAS-4672
DAS-4192-60
DAS-4672-50
POTS Splitter Chassis
POTS Splitter Card Dummy Panel
● For DAS-4192
DAS-4192
● 2 Gigabit Uplinks
● For DAS-4672
● For DAS-4672
DAS-4672
672-Port IP DSLAM
● ADSL2/2+ Annex A, B, M, L
● 6-Slot Chassis with Power, Alarm I/O and
Fan Modules
● 4 Open Slots for Line Cards Supporting
up to 192 ADSL Ports
● Redundant Power Support
● Dual Star Architecture
DAS-4192-10
Network Control Card
● 2 Gigabit Uplinks
● For DAS-4192
● ADSL2/2+ Annex A, B, M, L
● 16-Slot Chassis with Power, Alarm I/O
and Fan Modules
● 14 Open Slots for Line Cards Supporting
up to 672 ADSL Ports
● 2 Slots for Redundant Network Control
Cards
● Dual Power Supplies
● Dual Star Architecture
D-Link Product Guide 2008
BROADBAND
Features & Benefits
●ADSL2+ Speeds up to 24Mbps
Downstream, 1Mbps Upstream
» High enough for HDTV, streaming
multimedia, voice over Internet.
» High enough for business use.
●Denial of Service (DoS) Attack
Prevention, Stateful Packet
Inspection (SPI)
» Basic Internet firewall for home and
small business use.
●Parental Control Through Web
Site/Domain Name Blocking
» Protection against Internet abuse at
home and office.
●Priority Queues Quality of
Service
» Smooth transfer of voice, music and
video images over ADSL line for single
user or groups of users.
●Additional USB Interface
» Convenient connection for PC.
» Can be a bit heavy on computer
resources, a little slow in latency terms
(such as a high ping time).
ADSL2/2+ Modems & Routers
The ADSL2+ modems and routers are high-speed Internet connection devices that
provide speeds of up to 24Mbps downstream and 1Mbps upstream. These speeds
are suitable for high-speed multimedia Internet applications such as streaming video
and voice over the Internet.
The standard host interface on the ADSL2+ modems and routers is Ethernet. Combo
modems and combo routers have additional USB ports that offer the convenience of
extra plug-and-play connection to computers. ADSL2+ modem routers are equipped
with built-in ADSL2+ interfaces and are primarily designed for several computers at
home or in an office to share Internet access. In addition to ADSL line sharing, they
also provide basic firewall functions (SPI and DoS prevention), user access security,
and parental control. In addition, they provide Quality of Service (QoS) based on
priority queues, application ports or user-defined classification (e.g. TCP/UDP/ICM)
to prioritize Internet traffic for smooth running of bandwidth-sensitive applications
such as voice and streaming multimedia.
The ADSL2+ wireless modem routers integrate a wireless LAN access point function
for Wi-Fi equipped users to wirelessly connect to the Internet. For the office, ADSL2+
VPN routers offer hardware-based data encryption via embedded 3DES accelerators,
providing users with secure data transfer over the Internet.
The ADSL2+ VoIP modem routers offer integrated VoIP function for Internet phone
connection, while the ADSL2+ ISDN VoIP routers provide additional ISDN interfaces,
and the ADSL2+ ISDN PBX add IP PBX trunk connections for office use.
DSL-320T DSL-380T
DSL-322T DSL-382T
ADSL2+ Modem
ADSL2+ Combo Modem
● ADSL2/2+ Standards, Annex A
● 1 ADSL2+ Port
● 1 10/100BASE-TX Ethernet Port
DSL-2300B/2302B/2304B
DSL-320B/321B
DSL-2320B/2322B/2324B
DSL322B/323B
ADSL2+ Modem
ADSL2+ Combo Modem
● ADSL2/2+ Standards, Annex A (DSL2300B, DSL-2302B, DSL-2304B, DSL320B), Annex B (DSL-321B)
● 10/100BASE-TX Ethernet Connection
to Computer or Router
D-Link Product Guide 2008
● ADSL2/2+ Standards, Annex A
(DSL-322T), Annex B (DSL-382T)
● 1 ADSL2+ Port
● 1 10/100BASE-TX Ethernet Port
● Additional USB Port for Computer
Connection
● ADSL2/2+ Standards, Annex A (DSL2320B, DSL-2322B, DSL-2324B,
DSL322B), Annex B (DSL-323B)
● 1 ADSL2+ Port
● 1 10/100BASE-TX Ethernet Port
● Additional USB Port for Computer
Connection
DSL-520T DSL-580T
ADSL2+ Modem Router
● ADSL2/2+ Standards, Annex A (DSL520T), Annex B (DSL-580T)
● 1 ADSL2+ Port
● 1 10/100BASE-TX Ethernet LAN Port
● QoS Priority Queues
● SPI, DoS Firewall
DSL-2500B/2500U/2502B
DSL-2504B/520B/521B
ADSL2+ Modem Router
DSL-2520B/2520U/2522B
DSL-2524B/526B/527B
ADSL2+ Combo Modem Router
● ADSL2/2+ Standards, Annex A (DSL2520B, DSL-2520U, DSL-2522B, DSL2524B, DSL-526B), Annex B (DSL-527B)
● 1 ADSL2+ Port
● 1 10/100BASE-TX Ethernet LAN Port
● Additional USB Port for Computer
Connection
● QoS Priority Queues
● SPI, DoS Firewall
DSL-2540T DSL-2541T
DSL-2640T DSL-2641T
ADSL2+ Wireless G Modem Router
● ADSL2/2+ Standards, Annex A (DSL2640T), Annex B (DSL-2641T)
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● Integrated 802.11g Wireless LAN
● QoS Priority Queues
● SPI, DoS Firewall
DSL-2640B/2640U/2641B
DSL-2640R/2642B/2643B
ADSL2+ Wireless G Modem Router
ADSL2+ 4-Port Modem Router
● ADSL2/2+ Standards, Annex A (DSL2500B, DSL-2500U, DSL-2502B, DSL2504B, DSL-520B), Annex B (DSL-521B)
● 1 ADSL2+ Port
● 1 10/100BASE-TX Ethernet LAN Port
● QoS Priority Queues
● SPI, DoS Firewall
DSL-522T DSL-582T
ADSL2+ Combo Modem Router
● ADSL2/2+ Standards, Annex A (DSL2540T), Annex B (DSL-2541T)
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● QoS Priority Queues
● SPI, DoS Firewall
DSL-2540B/2540U/2542B
DSL-2543B
● ADSL2/2+ Standards, Annex A (DSL2640B, DSL-2640U, DSL-2642B,
DSL-2640R), Annex B (DSL-2641B,
DSL-2643B)
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● Integrated 802.11g Wireless LAN
● QoS Priority Queues
● SPI, DoS Firewall
DSL-G624M
ADSL2+ Wireless 108G MIMO
Modem Router
ADSL2+ 4-Port Modem Router
● ADSL2/2+ Standards, Annex A (DSL522T), Annex B (DSL-582T)
● 1 ADSL2+ Port
● 1 10/100BASE-TX Ethernet LAN Port
● Additional USB Port for Computer
Connection
● QoS Priority Queues
● SPI, DoS Firewall
● ADSL2/2+ Standards, Annex A (DSL2540B, DSL-2540U, DSL-2542B), Annex
B (DSL-2543B)
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● QoS Priority Queues
● SPI, DoS Firewall
● ADSL2/2+ Standards, Annex A
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● Integrated 802.11g Wireless LAN
(108Mbps Turbo Speed)
● Smart Antenna Technology
● Up to 8 Times Better Wireless Signal
Range
● Port-Based VLAN Security
● SPI, DoS Firewall
D-Link Product Guide 2008
BROADBAND
ADSL2/2+ Modems & Routers
DSL-2740B DSL-2741B
DVA-3060i DVA-3061i
DVA-N3690i DVA-N3691i
ADSL2+ RangeBooster N Modem
Router
ADSL2+ VoIP Modem Router
ADSL2+ VoIP Wireless N Modem
Router
● ADSL2/2+ Standards, Annex A (DSL2740B), Annex B (DSL-2741B)
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● Integrated 802.11n Draft Wireless LAN
● QoS Priority Queues
● SPI, DoS Firewall
DSL-2740R DSL-2741R
ADSL2+ Wireless N Modem
Router
DVA-3340S DVA-3340SB
ADSL2+ 2-Port VoIP Modem
Router
● ADSL2/2+ Standards, Annex A (DVAN3690i), Annex B (DVA-N3691i)
● 1 ADSL2+ Port
● 2 FXS VoIP Ports (SIP Protocol) for
Phone/Fax Connections
● FXO PSTN Lifeline Port
● Integrated Draft 802.11n Wireless LAN
● 4 10/100BASE-TX Ethernet LAN Ports
● USB Port for Printer Sharing
● DECT Cordless Phone Base Module
● QoS Priority Queues
● SPI, DoS Firewall
● Port-Based VLAN Security
DVA-G3342SB
ADSL2+ ISDN VoIP Wireless G
Modem Router
● ADSL2/2+ Standards, Annex A (DSL2740R), Annex B (DSL-2741R)
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● Integrated 802.11n Draft Wireless LAN
● QoS Priority Queues
● SPI, DoS Firewall
DSL-G804V
ADSL2+ Wireless G VPN Modem
Router
● ADSL2/2+ Standards, Annex A
● 1 ADSL2+ Port
● 4 10/100BASE-TX Ethernet LAN Ports
● Integrated 802.11g Wireless LAN
● 3DES Accelerator for Secure VPN Data
Transfer on Internet
● QoS Priority Queues
● SPI, DoS Firewall
D-Link Product Guide 2008
● DSL2/2+ Standards, Annex A (DVA3060i), Annex B (DVA-3061i)
● 1 ADSL2+ Port
● 1 FXS VoIP Port (SIP Protocol) for
Phone/Fax Connection
● FXO PSTN Lifeline Port
● 1 10/100BASE-TX Ethernet LAN Port
● QoS Priority Queues
● SPI, DoS Firewall
● ADSL2/2+ Standards, Annex A (DVA3340S), Annex B (DVA-3340SB)
● 1 ADSL2+ Port
● 2 FXS VoIP Ports (SIP Protocol) for
Phone/Fax Connections
● FXO PSTN Lifeline Port
● 4 10/100BASE-TX Ethernet LAN Ports
● USB Port for Computer Connection
● QoS Priority Queues
● SPI, DoS Firewall
● Port-Based VLAN Security
DVA-G3670B/G3671B/G3672B
ADSL2+ VoIP Wireless G Modem
Router
● ADSL2/2+ Standard, Annex B
● 1 ADSL2+ Port
● 1 ISDN Port
● 2 FXS VoIP Ports (SIP Protocol) for 2
Telephone/Fax Connections
● FXO (PSTN) Lifeline Port
● Integrated 802.11g Wireless LAN
● 4 10/100BASE-TX Ethernet LAN Ports
● USB Port for Computer Connection
● QoS Priority Queues
● SPI Firewall
DVA-G3342SC
ADSL2+ ISDN Wireless G
VoIP PBX
● ADSL2/2+ Standards, Annex A (DVAG3670B, DVA-G3672B), Annex B (DVAG3671B)
● 1 ADSL2+ Port
● 2 FXS VoIP Ports (SIP Protocol) for
Phone/Fax Connections
● FXO PSTN Lifeline Port
● Integrated 802.11g Wireless LAN
● 4 10/100BASE-TX Ethernet LAN Ports
● USB Port for Printer Sharing
● QoS Priority Queues
● SPI, DoS Firewall
● Port-Based VLAN Security
● ADSL2/2+ Standard, Annex B
● 1 ADSL2+ Port
● 1 ISDN Port Supporting Up to 8 ISDN
Phone Connections
● 2 FXS VoIP Ports (SIP Protocol) for 2
Telephone/Fax Connections
● FXO (PSTN) Lifeline Port
● IP PBX TK
● Integrated 802.11g Wireless LAN
● 4 10/100BASE-TX Ethernet LAN Ports
● USB 2.0 Port for Printer Connection
● QoS Priority Queues
● SPI Firewall
BROADBAND
Features & Benefits
●DOCSIS/EuroDOCSIS 2.0
Standards
» Latest cable modem standard.
»B
ackward compatible with earlier
DOCSIS/EuroDOCSIS 1.0, 1.1
standards equipment.
●DOCSIS/EuroDOCSIS
CableLabs Certified
» Compatibility with all DOCSIS
compatible cable providers.
●High-Speed Internet
Connection
» Maximum downstream speeds: 38Mbps
(64QAM)/43Mbps (256QAM)1
» Maximum upstream speeds: 320, 640,
1280, 2560, 5120kbps (QPSK); 640,
1280, 2560, 5120, 10240kbps (16QAM)1
●Automatic Finding of Send/
Receive Data Channels
» More efficient and effective broadband
connection.
» Clears network congestion to boost
network speeds.
Cable Modems
The cable modems connect computers and remote routers to a broadband network,
providing a standard-based solution for high-speed Internet access. Theses devices bridge
radio-wave-like signals over the cable TV wiring to a standard Ethernet interface. Powered
by TurboDOX bandwidth acceleration software, the cable modems increase download
speeds at up to 20 times for home users’ enjoyment of popular Internet applications, such
as file sharing, audio and video streaming, Internet TV and website uploading.1
D-Link cable modems make broadband connection more efficient and effective by clearing
network congestion, resulting in a boost in download speeds. Users get more out of their
broadband connection with increased bandwidth and enhanced performance. A single
downstream 6MHz television channel may support up to 38Mbps of downstream data
throughput from the cable head end using 64 QAM modulation, or 43Mbps downstream
data using 256QAM modulation technology.
With multiple channels, multiple users support, the cable modems can be used with a
wide range of applications, from residential (PCs, Internet gateways) to telecommuter
(notebooks, portable computers) and SOHO (routers, VoIP gateways).
1
Speeds may vary with Cable Service Operator.
DCM-202
DCM-232
Cable Modem
Cable Modem
●DES Encryption/Decryption
» Protection for data traveling on the TV
network cable.
●Built-in MCNS MIBs
» For SNMP remote management, allows
network management to be carried out
across multi-vendor platforms.
●SNMP v1, v2c, v3 Support
» Easy integration with SNMP-based,
vendor-independent managed network
● DOCSIS 2.0 CableLabs Certified
● EuroDOCSIS 2.0 CableLabs Compliant
● 10/100BASE-TX Ethernet Port
● USB Port
● CATV Coaxial Port
● Supports Windows (Ethernet and USB),
Mac OS & Unix/Linux (Ethernet Only)
● DOCSIS/EuroDOCSIS 2.0 CableLabs
Certified
● 10/100BASE-TX Ethernet Port
● USB Port
● CATV Coaxial Port
● Supports Windows (Ethernet and USB),
Mac OS & Unix/Linux (Ethernet Only)
●Static IP/Dynamic (DHCP) IP
Assignment
DCM-212
DCM-312
» Enables efficient management of IP
allocations.
Cable Modem
Embedded Media Terminal Adapter
1
Speeds may vary with Cable Service Operator.
● DOCSIS/EuroDOCSIS 2.0 CableLabs
Compliant
● 10/100BASE-TX Ethernet Port
● USB Port
● CATV Coaxial Port
● Supports Windows (Ethernet and USB),
Mac OS & Unix/Linux (Ethernet Only)
● DOCSIS/EuroDOCSIS 2.0 Compliant
● Packet Cable 1.5 CableLabs Certified
● Euro Packet Cable 1.5 CableLabs
Compliant
● CATV Coaxial Port
● 2 FXS VoIP Ports (NCS/SIP Protocol) for
2 Telephone Connections
D-Link Product Guide 2008
BROADBAND
Features & Benefits
●Upgrade to VDSL1 Standard
» VDSL2 outperforms VDSL in speed
and phone line distance from central
office (CO) switch to consumer premise
equipment (CPE) modem or router.
» Ideal for voice, video, data, high
definition television (HDTV) and
interactive gaming over the Internet.
●High Performance at Longer
Distance
VDSL2 Modems,
Routers & Switches
VDSL2 (Very-High-Bit-Rate Digital Subscriber Line 2) is an ITU-T G.993.2 standard an
access technology that exploits the existing infrastructure of telephone copper wires
that are present in very home, office building, factory, and public premise. VDSL2 can
be deployed from the telephone company and service provider central offices, from
fiber-fed cabinets located near the customer premises, or within buildings.
VDSL2 is the newest and most advanced standard of DSL broadband wire line
communications. Designed to support the wide deployment of services such as voice,
video, data, high definition television (HDTV) and interactive gaming, VDSL2 enables
operators and carriers to gradually, flexibly, and cost efficiently upgrade existing DSL
infrastructure.
VDSL2 is an enhancement to G.993.1 VDSL that permits the transmission of
asymmetric and symmetric (full-duplex) aggregate data rates many times higher on
the twisted-pair phone wires using a bandwidth up to 30MHz.
» Maximum theoretical speed of 250Mbps
at “source”.
» Speeds of 25Mbps available to most
consumers.
» Speed of 100Mbps available on short
loops (up to 300 m phone line distance).
» Speed decreases as phone line
distance increases from 1 km.
●Interoperable With Existing
Carrier DSL Equipment
» Easy upgrade to systems already
installed over the last decade
●Up to Symmetric 100Mbps
Downstream/50Mbps Upstream
at Shortened Loop Lengths
» Allows operators to offer “super triple
play” of video, Internet and voice
services to compete with services
offered by satellite and cable operators.
» Ideal for HDTV, VoIP and video
conferencing.
» Not limited to short loops or MTU
(Multi-Tenant Units office buildings)/
MDU (Multi-Dwelling Units apartment
buildings and condominiums)
applications; can also be used for
medium range applications.
DSL-6301i
DSL-6540i
VDSL2 Hostless Modem
VDSL2 4-Port Router
● 6-Band VDSL
● 1 VDSL2 Port
● 1 10/100BASE-TX Ethernet LAN Port
DSL-5540C
DSL-6541i
VDSL 4-Port Modem
VDSL2 4-Port Router
● 4-Band DMT-Based Ethernet over VDSL
● 1 VDSL2 Port
● Built-in POTS Splitter
● 1 Analog Phone (POTS) Port
● 4 10/100BASE-TX Ethernet LAN Ports
D-Link Product Guide 2008
● 5-Band DMT-Based Ethernet over VDSL
● 1 VDSL2 Port
● Built-in POTS Splitter
● 4 10/100BASE-TX Ethernet LAN Ports
● NAT, DHCP Server, IP Multicast
● MAC/IP/Port Filtering, DoS/DDoS
Firewall
● 6-Band VDSL2
● 1 VDSL2 Port
● 4 10/100BASE-TX Ethernet LAN
Ports
● USB Port for Printer Sharing
● NAT, DHCP Server, IP Multicast
● QoS Priority Queues
● SPI, DoS Firewall
DSL-6640i
DEV-3418
DEV-3710I
VDSL2 Wireless G Router
VDSL 16-Port Switch
VDSL2 8-Port Switch
● Same as DSL-6540i but with Integrated
802.11g Wireless LAN
DSL-6741i
VDSL2 Wireless N Router
● 4-Band DMT-Based Ethernet over VDSL
● 16 VDSL Ports
● 16 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● IGMP, Multicast, VLAN, 802.1p QoS,
Traffic Segmentation, Spanning Tree
● VLAN/MAC/IP-Based Filter
● MAC/IP-Based ACL
● Link Aggregation
DEV-3418DC
VDSL 16-Port Switch
● 6-Band VDSL2
● 1 VDSL2 Port
● Integrated Draft 802.11n Wireless LAN
● 4 10/100BASE-TX Ethernet LAN Ports
● 1 USB Printer Port
● NAT, DHCP Server, IP Multicast
● QoS Priority Queues
● SPI, DoS Firewall
● 5-Band DMT-Based Ethernet over VDSL2
● 8 VDSL2 Ports
● 8 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● IGMP, Multicast, VLAN, 802.1p QoS,
Traffic Segmentation, Spanning Tree
● VLAN/MAC/IP-Based Filter
● MAC/IP-Based ACL
● Link Aggregation
DEV-3718I
VDSL2 16-Port Switch
● Same as DEV-3418 but with DC Input
Power
DEV-3426
VDSL2 24-Port Switch
DVA-N6671i
VDSL2 Wireless N VoIP Router
● 5-Band DMT-Based Ethernet over VDSL2
● 16 VDSL2 Ports
● 16 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● Software Functions Same as DEV-3710I
DEV-3726I
● 6-Band VDSL2
● 1 VDSL2 Port
● 2 FXS VoIP Ports (SIP Protocol) for
Phone/Fax Connections
● FXO PSTN Lifeline Port
● Integrated Draft 802.11n Wireless LAN
● 4 10/100BASE-TX Ethernet LAN Ports
● NAT, DHCP Server, IP Multicast
● QoS Priority Queues
● SPI, DoS Firewall
● 4-Band DMT-Based Ethernet over VDSL2
● 24 VDSL2 Ports
● 24 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● Software Functions Same as DEV-3418
DEV-3426DC
VDSL2 24-Port Switch
● Same as DEV-3426 but with DC Input
Power
VDSL2 24-Port Switch
● 5-Band DMT-Based Ethernet over VDSL2
● 24 VDSL2 Ports
● 24 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● Software Functions Same as DEV-3710I
D-Link Product Guide 2008
BROADBAND
Features & Benefits
●Cost Saving Solution for
Service Providers
» Multiple SFF or SC Gigabit PON ports
» Multiple Ethernet or combo Gigabit
10/100/1000BASE-T/SFP end-user
ports
» SFF or SC 802.3ah Standard OLT
Downlink Ports
» Each OLT port can support up to 32
ONU
» Up to 1.25Gbps between OLT and ONU
» OTL ports can support up to 20km fiber
cable lengths
●Flexible/Secure Configuration/
Management
» Local RS-232 out-of-band CLI
»R
emote in-band SNMP/Telnet support
» SNMP, MIB interface and D-View
network management system support
» Firmware upgrade via FTP or TFTP
GE PON ONU & OLT Switches
Gigabit Ethernet Passive Optical Network (GE PON) devices deliver high-speed
voice, data and video services to residential and business subscribers. They present
a high-speed, Fiber-To-The-Home/Building (FTTH/FTTB) and extremely costeffective alternative to conventional access equipment, reducing points of failure and
simplifying network architecture.
D-Link’s PON consists of central office nodes, called an optical line terminal (OLT),
user nodes, called optical network units (ONU). Between them are the fibers and
splitters. The ONU terminate the PON and provide Ethernet interfaces to the endusers. The OLT provide the interface between the PON and the backbone network.
They complete the end-to-end last mile with up to 1Gbps of bandwidth to residential
and business customers.
D-Link’s PON switches provide Point to Multi-Point connection from the Central
Office’s (CO) Optical Line Terminal (OLT) with single strand fibers going out to
passive optical splitters where signal are multiplied to different lines. Combining
the economic benefits of Gigabit Ethernet Optical Network (GE PON) with built-in
switching functionalities, these devices provide the platform for bandwidth-intensive,
high margin applications including Internet TV, HDTV, voice and gaming
The GE-PON service delivers up to 1Gbps speed over optical fiber wiring. The OLT
convert GE-PON different interfaces to trunk interfaces. Each OLT can provide multiple
10/100/1000BASE-T/SFP combo interfaces as trunk interfaces, and supports L2
switch function. Each GE-PON interface can accommodates up to 32 ONU through
the optical splitter.
●Redundancy
» Chassis solution supports line card,
control card, power supply hot swap
capability
» Switch solution supports Dual
Configuration
●Advanced Functions for GEPON Service Offering
» OAM remote loopback test
» 802.1D Bridge function
» Up to 2000 MAC addresses for each
PON interface
» 802.1Q VLAN security/traffic
segmentation
» QoS with multiple 802.1p-based priority
levels
» TOS to CoS
» Rate Limiting capability
» IGMP v2
» ICMP
» Dual Configuration support (for GE PON
switches)
DPN-301
DPN-301L
GE PON ONU
GE PON ONU
● 1 1000BASE-LX PON Port (SC
Connector)
● 1 10/100/1000BASE-T Port
● PON Port Supports Up to 10 km
Single-Mode Fiber Cable Length
D-Link Product Guide 2008
10
● 1 1000BASE-LX PON Port (SC
Connector)
● 1 10/100/1000BASE-T Port
● PON Port Supports Up to 20 km
Single-Mode Fiber Cable Length
DPN-301T
GE PON ONU
● 1 1000BASE-LX PON Port (SC
Connector)
● 1 10/100/1000BASE-T Port
● 1 CATV RF Connector
● PON Port Supports Up to 10 km SingleMode Fiber Cable Length
DPN-304
GE PON ONU
● 1 1000BASE-LX PON Port (SC
Connector)
● 4 10/100BASE-TX Ports
● PON Port Supports Up to 10 km SingleMode Fiber Cable Length
DPN-3012-E
L2 GE PON OLT Switch
● 4/8/12 1000BASE-LX PON Ports (SFF
SC Connectors)
● 4 Combo 10/100/1000BASE-T/SFP Ports
● PON Port Supports Up to 20 km SingleMode Fiber Cable Length
● RJ-45 and RS-232 Console Ports
11
D-Link Product Guide 2008
BROADBAND
Feature & Benefits
●Save Long Distance /
International Phone Charges
» Make calls using subscribed Internet
broadband line already installed at
home or office.
» No incurring toll charges from telephone
companies.
» Pay only small charges for VoIP phone
forwarding services.
●SIP Protocol Support
» Industry’s latest Voice over the IP
network protocol
» Compatible with popular SIP Internet
phone services.
VoIP Phone Adapters,
Routers & Gateways
The VoIP phone adapters, routers and gateways allow homes and businesses to take
advantage of their DSL/cable modem connection to make inexpensive Internet phone
calls. Through broadband connection, these devices allow users to access voice and
fax services over the Internet to significantly reduce the cost of international and long
distance calls.
The VoIP phone adapters and routers are made for homes and small offices, and
typically have one or two phone ports. For large offices, the gateways can have up
to 32 phone ports for a large number of users to make simultaneous Internet phone
calls. The gateways are categorized into two different types: station gateways and
trunk gateways. The station gateways have FXS phone ports that connect to regular
phone sets, Ethernet WAN ports that connect to DSL/cable modems and built-in router
function/Ethernet LAN ports for convenient computer connection. The trunk gateways
are equipped with FXO ports, which can connect to PBX, key telephone systems or
PSTN phone lines for analog voice, and Ethernet LAN ports which connect to office
LAN (IP networks) for VoIP data. The combo gateways provide both FXS and FXO
ports for flexible application.
●Combination FXS/FXO Port
Support
» Flexible gateway deployment for
enterprises and ISP.
●PSTN Lifeline Phone Port
» Uninterrupted phone/fax communication
with or without the Internet.
» Relays outgoing phone calls to PSTN
automatically in case of a power outage
at, or when VoIP service is disconnected
●Quality of Service (QoS)
» Prioritized transmission for voice
packets over the Internet.
» Minimized interruption to voice
transmission/reception due file transfer,
web surfing and other Internet uses.
DVG-2101S
DVG-2101SP
1-Port VoIP Telephone Adapter
1-Port VoIP Telephone Adapter
●Extensive Call Feature Support
» Generally includes Call Transfer, Call
Hold, Call Waiting, Caller ID Display,
3-Way Conference functions.
» Allows service providers to offer these
functions to their subscribers.
» Provided that their telephone sets
support these functions, callers can take
advantage of the features offered
●Multi-Language Interactive
Voice Response (IVR)
» Configuration of individual phone
connection by directly using the phone
set.
●Built-in Routing/Firewall
Functions
» Allows users to surf the web while
making Internet phone calls.
» Sharing of Internet connection among a
group of computers.
» DoS attack prevention firewall protection
for connected computers.
D-Link Product Guide 2008
12
● 1 FXS Port
● 1 Ethernet WAN Port
●Automatic Call Redirect (ACR)
Table
» Lists emergency numbers such as
police/ambulance service, and special
telephone numbers and redirects to
the PSTN line when dialing to these
number is made.
● 1 FXS Port
● 1 PSTN Lifeline Port
● 1 Ethernet WAN Port
DVG-5102SP
2-Port VoIP Telephone Adapter
●Call Detailed Records
» Allow users to view call duration, time
and date of call and call latency.
● 2 FXS Ports
● 1 PSTN Lifeline Port
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● NAT Router with DHCP Server,
Parental Control
DVG-5121SP
DVG-5401SP
DVG-G5402SP
2-Port VoIP Telephone Adapter
1-Port VoIP Router
VoIP Wireless Router
● 2 FXS Ports
● 1 PSTN Lifeline Port
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Built-in Router with Access & Parental
Control
● 802.1Q VLAN Tag & Voice VLAN Security
● 1 FXS Port
● 1 PSTN Lifeline Port
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router with Access Control, DoS
Firewall
● 2 FXS Ports
● 1 PSTN Lifeline Port
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Integrated 802.11g Wireless LAN
● Built-in Router with Access Control, DoS
Firewall
DPH-50U
DVG-1102S
DVG-5802S
VoIP USB Telephone Adapter
2-Port VoIP Router
Wireless N VoIP Router
● USB Connection to PC
● 1 PSTN Port to Regular Phone Set
● 1 PSTN Port to Wall Phone Line
● Receive/Make PSTN & VoIP Phone Calls
on Regular Phone Set
● Use Skype & QQ Softphone for PC to PC
& PC to Phone Calls
● 3-Way Conference, Call Forwarding &
Toll Bypassing 1
● VoIP Call Forward to Remote PSTN
Phone Set/Cell Phone & Vice Versa
● Can Connect to DECT, 2.4GHz, 900MHz
Cordless Phones
● Phone Conversation Recording Capability
● Can Auto-Detect & Hold Incoming PSTN
& VoIP Calls 1
● 2 FXS Ports
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Built-in Router
● 2 FXS Ports
● 1 Gigabit WAN Port
● 8 Gigabit LAN Ports
● Built-in Router with DoS and SPI Firewall
● Integrated Draft 802.11n Wireless LAN
DVG-5402SP
2-Port VoIP Router
DVG-1401SP
1-Port VoIP Router
● 1 FXS Port
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router
● PSTN Lifeline Port
● 2 FXS Ports
● 1 PSTN Lifeline Port
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router with Access Control, DoS
Firewall
13
D-Link Product Guide 2008
BROADBAND
VoIP Phone Adapters,
Routers & Gateways
DVG-5004S
DVG-2032S
DVG-3016S
4-Port VoIP Station Gateway
32-Port VoIP Station Gateway
16-Port VoIP Trunk Gateway
● 32 FXS Ports in 2 RJ-21 Connectors
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Call Detailed Records
● Multi-Language Interactive Voice
Response
● 16 FXO Ports in 1 RJ-21 Connector
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Call Detailed Records
● Multi-Language Interactive Voice
Response
● 4 FXS Ports
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router & Firewall
● Call Detailed Records
● Multi-Language Interactive Voice
Response
DVG-5008S
DVG-6004S
DVG-3032S
8-Port VoIP Station Gateway
4-Port VoIP Trunk Gateway
32-Port VoIP Trunk Gateway
● 8 FXS Ports
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router & Firewall
● Call Detailed Records
● Multi-Language Interactive Voice
Response
● 4 FXO Ports
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router & Firewall
● Call Detailed Records
● Multi-Language Interactive Voice
Response
● 32 FXO Ports in 2 RJ-21 Connectors
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Call Detailed Records
● Multi-Language Interactive Voice
Response
DVG-2016S
DVG-6008S
DVG-7022S
16-Port VoIP Station Gateway
8-Port VoIP Trunk Gateway
4-Port VoIP Station/Trunk
Gateway
● 16 FXS Ports in 1 RJ-21 Connector
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Call Detailed Records
● Multi-Language Interactive Voice
Response
D-Link Product Guide 2008
14
● 8 FXO Ports
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router & Firewall
● Call Detailed Records
● Multi-Language Interactive Voice
Response
● 2 FXS Ports
● 2 FXO Ports
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router & Firewall
● Call Detailed Records
● Multi-Language Interactive Voice
Response
DVG-7044S
DVG-4032S
8-Port VoIP Station/Trunk Gateway
32-Port VoIP Station/Trunk Gateway
● 4 FXS Ports
● 4 FXO Ports
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router & Firewall
● Call Detailed Records
● Multi-Language Interactive Voice
Response
DVG-7062S
8-Port VoIP Station/Trunk Gateway
● 16 FXS Ports, 16 FXO Ports (in 2 RJ-21
Connectors)
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Call Detailed Records
● Multi-Language Interactive Voice
Response
1
unctions’ availability depends on phone sets’ capabilities and
F
telephone service providers’ offering, which may come with or
without additional charges.
● 6 FXS Ports
● 2 FXO Ports
● 1 Ethernet WAN Port
● 4 Ethernet LAN Ports
● Built-in Router & Firewall
● Call Detailed Records
● Multi-Language Interactive Voice
Response
DVG-4088S
16-Port VoIP Station/Trunk Gateway
● 8 FXS Ports, 8 FXO Ports (in 1 RJ-21
Connector)
● 1 Ethernet WAN Port
● 1 Ethernet LAN Port
● Call Detailed Records
● Multi-Language Interactive Voice
Response
15
D-Link Product Guide 2008
BROADBAND
Features & Benefits
●Make Phone Calls Worldwide
» Call virtually anywhere through the
Internet.
●Easy to Use
» Look and feel like ordinary phone sets.
» Easy installation and configuration
through web-based interface.
●Superior Sound
» Echo Cancellation, Comfort Noise
Generation, Voice Activity Detection
and Dynamic Jitter Buffer features for
excellent sound quality.
●Convenient Phone Features
» Numerous useful phone functions
supported, including Call Transfer,
Forward and Hold, 3-Way Conference,
Speed Dial/Phone Book, Caller ID
Display and LCD screen.1
●Voice VLAN Support
» Isolates callers’ voice communication so
it cannot be tapped over the network.
IP Phones
The IP phones allow Internet subscribers to take advantage of their DSL/cable modem
connection to make inexpensive Internet phone calls. By utilizing the IP phones with
a VoIP service plan, home and business users have the potential to dramatically
reduce local and long distance telephone charges compared to a standard telephone
service.
The IP phones combine the industry’s latest Voice over the IP network (VoIP)
technology with advanced communication features, and are compatible with industrywise phone service. They give callers the advantages of VoIP, while retaining the
same look and feel of the familiar analog telephones.
The IP phones are stand-alone devices and do not require connection to computers
to operate. They provide Ethernet ports for direct attachment to DSL/cable modems,
or to home or office routers with Internet connection. Once they are connected to
the Internet, these IP phones are ready for users to make and receive calls. The IP
phones incorporate Quality of Service (QoS) and other VoIP features to ensure that
voice received through the Internet is the same as or even surpasses that received
on the ordinary phone.
The Wi-Fi phones are IP phones with built-in WLAN interfaces. They provide the
freedom of wireless connectivity and the benefits of Voice over IP (VoIP) all in one sleek
portable flip-style phone. With a growing number of Wi-Fi hotspots and metropolitan
areas deploying low-cost or free high-speed Internet connection, and widespread use
of LAN switches supporting 802.11 wireless LAN in enterprise networks, mobile users
will have more places to use the Wi-Fi phones. Applications include making Internet
phone calls at an Internet cafe, from a car or truck in a parking lot equipped with hot
spots, or in an office building while roaming around different floors.
●802.1P Priority Queues Support
» Streamlines traffic so web browsing and
Internet download will not interfere with
voice traffic and degrade Internet phone
quality.
●Extra LAN Port
» For connection to PC’s Ethernet
interface; allows callers to talk on the
IP Telephone while browsing web sites,
send e-mail, transfer files and do other
network tasks.
DPH-140S
DPH-150S
●SIP Protocol Support
IP Telephone
IP Phone
» Industry’s latest Voice over the IP
network protocol
» Compatible with popular SIP Internet
phone services.
1 Functions’ availability depends on phone sets’
capabilities and telephone service providers’ offering,
which may come with or without additional charges.
D-Link Product Guide 2008
16
● Speakerphone with Comprehensive
Keypad
● 10/100BASE-TX Ethernet Connection
to DSL/Cable Modem
● Second 10/100BASE-TX Connection
to PC
● LCD to Display Caller ID & Address
Book
● 10 Memory Speed Dial Keys
● Speakerphone with Comprehensive
Keypad
● 10/100BASE-TX Ethernet Connection
to DSL/Cable Modem
● Second 10/100BASE-TX Connection
to PC
● LCD to Display Caller ID & Address
Book
● 12 Dial (CCITT) Keypad
DPH-150SE
DPH-400SEDM
IP Phone
Extended Dial Module
● Speakerphone with Comprehensive
Keypad
● 10/100BASE-TX PoE Ethernet Port to
802.3af PoE Switch
● Second 10/100BASE-TX Connection to PC
● LCD to Display Caller ID & Address Book
● 12 Dial (CCITT) Keypad
● 12 Memory Speed Dial Keys
● 802.3af PoE Support
● Key Pad for Speed Dial Numbers,
Abbreviated Codes, Programmable
Features Assignment
● Attachable to DPH-400S or DPH-400SE
IP Phone
DPH-400S
IP Phone
● Speakerphone with Comprehensive
Keypad
● 10/100BASE-TX Ethernet Connection to
DSL/Cable Modem
● LCD to Display Caller ID & Address Book
● Supports 4 SIP Accounts Registration
● Attachable to Optional Extended Dial
Module
DPH-400SE
Cordless IP Phone
● Speakerphone with Comprehensive
Keypad
● 10/100BASE-TX PoE Ethernet Port to
802.3af PoE Switch
● LCD to Display Caller ID & Address Book
● Supports 4 SIP Accounts Registration
● Attachable to Optional Extended Dial
Module
● 802.3af PoE Support
17
D-Link Product Guide 2008
BROADBAND
Features & Benefits
●SIP Protocol Support
» Industry’s latest Voice over the IP
network protocol
» Compatible with popular SIP Internet
phone services.
●All Essential Telephony
Features Provided
» Call forwarding, call hold, hold music,
find me-follow me, voice mail, IVR/autoattendant, customizable greetings.
» Incoming calls are directed by integrated
auto-attendant and hunt groups to assist
callers to their destinations.
» Can utilize standard phone lines via an
external phone line gateway or Internet
Telephony services.
IP PBX
The IP PBX (Private Branch Exchange) equipment unifies the voice network with
data applications, using the office LAN as the platform to connect IP phones to the
call manager. These devices offer a cost-effective alternative to the traditional analog
PBX, as owners do not have to maintain two separate networks for voice and data.
Moving and adding an employee to a phone system is as simple as unplugging a
telephone and plugging it to a new location, without the need for costly service calls
from legacy PBX vendors.
The IP PBX uses VoIP protocol to establish connections between users, and combine
the features of traditional PBX with the networking advantages of IP devices. These
devices use the SIP PBX technology to provide a new architecture for business
communication, enabling organization-wide management support and extensive
features such as multi-party conference calls, Interactive Voice Response (IRV) and
voice mail.
●Easy Expansion
» Phone extensions can be located
anywhere with Internet access.
» Can add multiple IP PBX units to
increase number of extensions or unite
a company that has many locations
under a single PBX system.
» Additional extensions can be easily
added via license codes.
●Convenient Web-Based
Management
» Administrator can assign each extension
a profile of telephony features that
allows the best match for a user’s job
function.
» Individual users can fine-tune their
assigned profile via the web to match
their daily business schedule.
DVX-1000
●Integrated Conference Bridge
IP PBX
» No need for expensive external phone
conference hardware and service.
» Users can schedule and invite parties to
conferences via web configuration.
» Conference notifications are sent out by
e-mail, which include phone numbers
and access codes.
●MD5 SIP authentication
encryption encoder
» Prevents hackers from breaching the
system.
●Integrated DoS/IDS Firewall
» Intrusion detection and protection
against denial of service attacks.
D-Link Product Guide 2008
18
● 25 IP Phone Line Extensions
● Supports 25 Simultaneous Inbound/
Outbound Calls
● Supports Multiple Users across Multiple
Sites
● External Analog Trunk Gateways can be
added for Standard Phone Use
● Can be Cascaded Together through LAN
Ports to Provide More Phone Extensions
● Integrated Conference Bridge & Firewall
BROADBAND
Features & Benefits
●Internet Sharing for Home/
SOHO
●10/100BASE-TX Ethernet
Connection to DSL/Cable
Modem
●Multiple 10/100BASE-TX
Ethernet Ports for Computer
Connection
●MAC/IP Address-Based User
Access Control
●SPI Firewall, DoS Attack
Prevention
●URL Filtering, Domain
Blocking, Scheduling Parental
Control
Broadband Routers
These broadband routers are affordable gateways that connect to DSL or cable modems
for sharing of Internet connection among a group of home or office computers. Combining
basic Internet gateway functions with firewall protection and user access control, they offer
homes and small offices a cost-effective way to install a secure Internet link to the outside
world.
DI-604
DI-704P
4-Port Router
4-Port Router with Parallel
Printer Port
● 1 Ethernet WAN Port, 4 Ethernet LAN Ports
● Built-in Firewall, Parental Control
DIR-100
4-Port Router
● 1 Ethernet WAN Port, 4 Ethernet LAN Ports
● IGMP, QoS for VoIP Traffic, On-Line Games
● Built-in Firewall, Parental Control
DI-604UP
● 1 Ethernet WAN Port, 4 Ethernet LAN Ports
● Parallel Printer Port
● Printer Sharing Supports Windows, Mac
OS, Linux
● Built-in Firewall, Parental Control
DI-707P
7-Port Router With Parallel Printer
Port
4-Port Router with USB Printer Port
● 1 Ethernet WAN Port, 4 Ethernet LAN Ports
● USB Port for Printer Connection
● Printer Sharing Supports Windows, Mac
OS, Unix LPR
● Built-in Firewall, Parental Control
DIR-120
● 1 Ethernet WAN Port, 7 Ethernet LAN Ports
● Parallel Printer Port
● Printer Sharing Supports Windows, Mac
OS, Linux
● Built-in Firewall, Parental Control
DI-LB604
4-Port Load Balancing Router
4-Port Router with USB Printer Port
● 1 Ethernet WAN Port, 4 Ethernet LAN Ports
● USB Port for Printer Connection
● Printer Sharing Supports Windows, Mac
OS, Unix LPR
● IGMP, QoS for VoIP Traffic, On-Line Games
● Built-in Firewall, Parental Control
● 2 Ethernet WAN Port, 4 Ethernet LAN Ports
● Outbound Load Balance by Bytes,
Packets & Session
● Auto Backup Connection
● Built-in Firewall, Parental Control
● Email & Syslog Alerts
19
D-Link Product Guide 2008
BROADBAND
Features & Benefits
●Ideal VPN Implementation for
SMB
» Securely connects remote offices and
remote users using DSL/cable modem
Internet access rather than expensive
dedicated WAN links or long-distance
remote dial links.
» Increases the reach of company
network without significantly expanding
its infrastructure
●IPSec-Based VPN
» Proven remote access technology used
by most organizations today.
» Connections established using VPN
client software preinstalled on user
desktop, primarily useful on companymanaged desktops.
●Data Tunnels & Encryption
» High levels of security through IPSec/
PPTP/L2TP tunnels, policy-based
content filtering (tunnel rule policies) and
authentication technologies to protect
data from unauthorized access.
» DES/3DES, SHA-1, DM5 multiple
encryption algorithms to safeguard data
against thieves during transmission over
the Internet.
●Integrated Routing, QoS,
Multicast Functions
» Delivers latency-sensitive voice/video,
terminal services and other traffic types
while preserving transport reliability and
quality over Internet-based VPN.
VPN Routers
The VPN routers provide IPSec security for Virtual Private Network applications,
enabling two Internet-connected remote sites to act as if they were part of a single
LAN. Branch offices can deploy these routers to connect to head offices or trusted
suppliers. Remote offices can also install these routers to let telecommuters (mobile
users working outside of the office or workers sending in e-mail and reports from
home) to transfer sensitive information with company networks. Such information can
be securely transmitted over the Internet without the fear of being intercepted by
thieves.
In a site-to-site connection, two remote routers equipped with IPSec VPN are deployed
at each end of the Internet connection. In a telecommuter-to-office connection, the
remote user runs a VPN client software program on a PC to connect to the office
network installed with a VPN router.
The VPN routers provide VPN IPSec tunnels to remote sites or end-user clients,
allowing the remote sites and mobile telecommuters to securely transfer sensitive
information with company networks without the fear of being intercepted over the
Internet. The routers provide VPN accelerators to perform data encryption/decryption
to relieve the loading of the routers’ own CPU for execution of other tasks and to
enhance the routers’ overall performance.
D-Link VPN routers are VPNC-certified, and can connect to any third-party VPNCcertified VPN routers at the remote site. For site-to-remote client connection, D-Link
VPN routers work with any VPNC-certified client software. As part of a total solution,
D-Link provides VPN Client Software (part number DS-601 and DS-605) for remote
users to run on a Windows-based PC.
At affordable prices, D-Link VPN routers can also be deployed at homes, so users
working away from home can securely access files and data on their own desktops’
hard disks over the Internet from anywhere on the planet.
VPNC
CERTIFIED
Basic
Interop
●Built-in Firewall
» Domain blocking/URL filtering for
parental control.
» SPI firewall and DoS attack prevention.
» Event log file and email to notify
administrator of unusual events.
●VPNC Certified
» Site-to-site connection works with any
D-Link or third-party VPNC-certified
VPN router.
» Site-to-remote client connection works
with D-Link VPN Client software (DS601/605) or any VPNC-certified client
software.
DI-804HV
DI-808HV
4-Port VPN Router
8-Port VPN Router
● 10/100BASE-TX Ethernet Connection
to DSL/Cable Modem
● 4 10/100BASE-TX Ethernet Ports for
Computer Connection
● RS-232 COM Port for Backup ISDN/
Analog Modem Connection
● VPNC Certified
D-Link Product Guide 2008
20
● 10/100BASE-TX Ethernet Connection
to DSL/Cable Modem
● 8 10/100BASE-TX Ethernet Ports for
Computer Connection
● RS-232 COM Port for Backup ISDN/
Analog Modem Connection
● VPNC Certified
DIR-130
DIR-330
8-Port VPN Router
Wireless G VPN Router
● Powerful CPU/VPN Accelerator for High
VPN Performance
● AES, HMAC-SHA1, HMAC-MD5
Encryption Support
● 10/100BASE-TX Ethernet Connection to
DSL/Cable Modem
● 8 10/100BASE-TX Ethernet Ports for
Computer Connection
● VPNC Certified
DI-824VUP
● Powerful CPU/VPN Accelerator for High
VPN Performance
● AES, HMAC-SHA1, HMAC-MD5
Encryption Support
● Built-in 802.11g Wireless LAN
● 10/100BASE-TX Ethernet Connection to
DSL/Cable Modem
● 4 10/100BASE-TX Ethernet Ports for
Computer Connection
● Easy Setup Using Windows Connect Now
Via USB Port
● VPNC Certified
Wireless G VPN Router
● 10/100BASE-TX Ethernet Connection to
DSL/Cable Modem
● Built-in 802.11g Wireless LAN
● 4 10/100BASE-TX Ethernet Ports for
Computer Connection
● USB/Parallel Printer Ports
● Printer Sharing Supports Windows, Mac
OS
● RS-232 COM Port for Backup ISDN/
Analog Modem Connection
● VPNC Certified
21
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● 802.11g Standard
» Most widely used industry standard in
WLAN.
●2.4GHz Frequency Band
» Popular radio frequency band currently
available for public use in most
countries.
Wireless G
The Wireless G products comply with the 802.11g wireless LAN standard and use the
popular 2.4GHz frequency band, which is available for public use in most countries.
Wireless G is backward compatible with legacy 802.11b wireless equipment, ensuring
compatibility with a wide range of wireless devices.
This cost-effective wireless product line is ideal for home and business users needing
an affordable high-speed wireless network. It provides data transfer rates of up to
54Mbps suitable for most home and SOHO applications, complete network access
security, privacy protection and data encryption including WEP, WPA and WPA2
personal and enterprise security.
●Up to 54Mbps Data Transfer
Rate
» Decentbandwidth for wireless transfer
of Internet surfing, file download,
multimedia, voice and video.
●Compatible with 802.11b
Devices
» Seamless integration with earlier
standard wireless devices.
» Preservation of past investments in
earlier standard wireless hardware and
applications.
DWL-G122
DWA-610
Wireless G USB Adapter
Wireless G CardBus Adapter
●64/128-Bit WEP Data
Encryption
» Protection of wireless data traveling in
the air that are sent by the users.
●WPA EAP/PSK, WPA2 EAP/PSK
with TKIP, AES Support
» Wireless LAN security including data
encryption keys and user authentication
for network access.
» Keeps out intruders located next door,
upstairs or downstairs.
» Advanced encryption and security
schemes for business environments.
●WPS Certified
» Wi-Fi Protected Setup (WPS) provides
easy security setup for wireless clients
from an AP or router. The AP and
routers provide a WPS click button
from a PC screen and a WPS push
buttons from the devices themselves to
let administrators broadcast settings to
clients, eliminating the need for clients
to manually key in encryption keys
and settings to establish connection to
network.
●Workgroup Bridge (WDS) with AP
» This operation mode allows an AP to
act as wireless hub and a bridge at the
same time.
●WISP Client Router
● USB Cable & Cradle Provided
● Supports Windows, Mac OS, Linux
● 32-Bit Bus Interface to PC
● Supports Windows, Linux
DWA-110
DWL-G510
Wireless G USB Adapter
Wireless G PCI Adapter
● USB Cable & Cradle Provided
● Supports Windows, Mac OS, Linux
● For Desktop PC
● Supports Windows, Linux
DWL-G630
DWA-510
Wireless G CardBus Adapter
Wireless G PCI Adapter
» This operation mode lets wireless Internet
service (WISP) subscribers share Internet
connection with Ethernet-enabled
computers without the need for an extra
router.
●WISP Repeater
» This operation mode lets WISP
subscribers share Internet connection
with wireless computers without any
extra router.
D-Link Product Guide 2008
22
● 32-Bit Bus Interface to PC
● Supports Windows, Linux
● For Desktop PC
● Supports Windows, Linux
DAP-1150
DI-524
DI-524UP
Wireless G Access Point
Wireless G 4-Port Router
Wireless G 4-Port Router
● Operable in AP, Wireless Client or
Repeater
● Wi-Fi Protected Setup (WPS)
● For Indoors Use
● 4 10/100BASE-TX Ethernet LAN Ports
● QoS Traffic Prioritization
● Parental Control, SPI Firewall
● 4 10/100BASE-TX Ethernet LAN Ports
● USB Port for Printer Sharing Under
Windows, Mac OS, Unix LPR
● QoS Traffic Prioritization
● Parental Control, SPI Firewall
DAP-1160
DIR-300 DIR-301
DWL-G730AP
Wireless G Access Point
Wireless G 4-Port Router
Wireless G Pocket Router/AP
● Operable in 7 Modes: Access Point,
Wireless Client, WDS, WDS with AP,
Wireless Repeater, WISP Client Router
or WISP Repeater
● 2 10/100BASE-TX Ethernet Ports for
LAN and Computer Connection
● For Indoors Use
● 4 10/100BASE-TX Ethernet LAN Ports
● QoS Traffic Prioritization
● Parental Control, SPI Firewall
DWL-2700AP
DIR-320
Wireless G Outdoors Access Point
Wireless G 4-Port Router
● Dual 5dBi Dipole Antennas
● Power over Ethernet (PoE)
● Plenum-Rated Housing
● Operable in AP, WDS or WDS With AP
Mode
● Up to 54Mbps Wireless Speed
● 8 SSID, 802.1Q VLAN Security
● AP Grouping for Bandwidth
Enhancement
● SNMP Manageable
● Pocket-Sized, Lightweight, Ideal for
Traveling
● Operable in AP, Wireless Router or
Wireless Client Mode
● Can Be Powered Directly From PC’s
USB Port
● Traveling Case & Power Adapter
Provided
● 4 10/100BASE-TX Ethernet LAN Ports
● USB 2.0 for WCN and Printer Connection
● USB Printer Sharing Supporting
Windows, Mac OS, Unix LPR
● QoS Traffic Prioritization
● Parental Control, SPI Firewall
23
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● VGA and DVI-D Output
Support
» Compatible with most projectors and
monitors currently in use or sold in the
market.
Wireless G
Presentation Gateways
The Wireless G Presentation Gateways allow business users to connect projector
screens with confidence and enjoy a new presentation experience. Presenters can
connect wirelessly to a projector or monitor to display presentations, applications,
and images from several notebooks or desktops without connecting additional bulky
wires. With just a few clicks users can begin their presentation in style and impress
clients. These gateways reduce the amount of downtime in meetings associated with
multiple presenters and let everybody enjoy a productive presentation experience.
●Multiple Format Support
» Can handle any format file such as
PowerPoint, Excel, and Word sent by
presenters to projector or monitor from
their PC.
●Audio Output Jack
» Presenterscan connect speakers
to projector or monitor to liven up
presentations with stereo sound.
DPG-2100
●Integrated Ethernet Port
» Presenters can connect gateway to
existing network for Internet access, and
integrate content from the web to their
presentations.
Wireless G Presentation Gateway
●Software Installs Directly From
Gateway
» No need to insert CD in laptop to install
client software.
» Client software installs directly into PC
through wireless network, no cable
required.
●Multiple Presenter Support
» Seamless delivery of presentations for
multiple users by way of simple Connect/
Disconnect button
●No Need for Wireless Access
Point
» Presenter’s PC can directly connect
wirelessly to gateway.
» Groups can conduct presentations
at hotels or public places where no
network infrastructure is available.
● Supports VGA, DVI-D Monitor Outputs
● Up to XGA (1024 x 768) Monitor
Resolution
● Audio Output
● Integrated 802.11g Wireless LAN
● Multiple Connections From 10
Presenters*
● Internet Connection Access **
● Compact Size for Easy Placement
● Supports Windows
* One connection at a time.
** For currently connected user only.
D-Link Product Guide 2008
24
WIRELESS
NEtwORKING
Features & Benefits
● Up to 108Mbps Data Transfer
Rate
» 108Mbps Turbo mode wireless speed
when operating with other 108G and
108AG devices.
» High bandwidth for wireless transfer
of Internet surfing, file download,
multimedia, voice and video.
Wireless 108G
The Wireless 108G complies with the 802.11g wireless LAN standard but offers data
transfer rates of up to 108Mbps in the Turbo mode when operating with other D-Link
108G or 108AG wireless products. Using the 2.4GHz frequency band, Wireless 108G
is ideal for home and office users implementing high-bandwidth applications such as
Internet phone, audio/video streaming, on-line gaming and large file transfer over the
wireless network. With high data transfer rates and compatibility with other 2.4GHz
WLAN, Wireless 108G is the ideal upgrade solution to a fast technology that also protects
users’ past investments in hardware.
●Compatible With 802.11b/g
Devices
» Seamless integration with earlier
801.11b standard wireless devices and
wireless G devices.
» Preservation of past investments in
earlier standard wireless hardware and
applications.
●64/128/152-Bit WEP Data
Encryption
» Protection of wireless data traveling in the
air that are sent by users.
DWL-G132
DWA-620
Wireless 108G USB Adapter
Wireless 108G CardBus Adapter
●WPA EAP/PSK, WPA2 EAP/PSK
With TKIP, AES Support
» Wireless LAN security including data
encryption keys and user authentication
for network access.
» Keeps out intruders located next door,
upstairs or downstairs.
» Advanced encryption and security
schemes for business environments.
●WDS Wireless Bridge
» This operation mode allows an AP to act
as a wireless hub and a wireless bridge
at the same time.
● USB Extension Cable & Cradle Provided
● Supports Windows OS
● 32-Bit Bus Interface to PC
● Supports Windows, Linux
DWA-120
DWL-G680
Wireless 108G USB Adapter
Wireless 108G CardBus Adapter
●WPS Certified
» Wi-Fi Protected Security (WPS)
provides easy security setup for wireless
clients from an AP or router. The AP
and routers provide a WPS click button
from a PC screen and a WPS push
buttons from the devices themselves to
let administrators broadcast settings to
clients, eliminating the need for clients
to manually key in encryption keys
and settings to establish connection to
network.
● USB Extension Cable & Cradle Provided
● Supports Windows OS
● Dual High Gain Antennas
● Extended Wireless Operation Range
● Supports Windows OS
DWL-G650
DWL-G520
Wireless 108G CardBus Adapter
Wireless 108G PCI Adapter
● 32-Bit Bus Interface to PC
● Supports Windows, Linux
● For Desktop PC
● Supports Windows, Linux
25
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Wireless 108G
DWA-520
DWL-2200AP
DWL-3260AP
Wireless 108G PCI Adapter
Wireless 108G Access Point
Wireless 108G Access Point
● For Desktop PC
● Supports Windows, Linux
DWL-G550
● 802.3af PoE Support
● 5dBi High Gain Antenna
● Operable as AP (Wireless Connectivity
for Computers), WDS (Wireless Bridge)
or WDS with AP
● Multiple SSID, 802.1Q VLAN Tagging
● SNMP Manageable
● For Indoors Use
Wireless 108G PCI Adapter
DWL-3200AP
Wireless 108G Access Point
● 802.3af PoE Support
● Smoke Detector Shape, Ceiling
Mounting
● Integrated Antenna, Connector for
Optional External Antenna
● Operable in AP, WDS or WDS with AP
Mode
● Multiple SSID/VLAN, 802.1Q VLAN
Tagging
● Rouge AP Detection, AP Grouping
(Load Balancing)
● WMM for QoS
● SNMP Management Through D-View
DAP-3220
Wireless 108G Exterior Access
Point
● 5dBi High Gain Antenna
● Extended Wireless Operation Range
● Supports Windows OS
DWL-2100AP
Wireless 108G Access Point
● Operable as Wireless Client, AP
(Wireless Connectivity for Computers),
WDS (Wireless Bridge), WDS with AP
or Repeater (Signal Range Extension)
● AP Grouping (Load Balancing)
● STA Partitioning, 802.1Q VLAN,
Multiple SSID
● WMM (Wireless QoS)
● SNMP Manageable
● For Indoors Use
D-Link Product Guide 2008
26
● 802.3af PoE Support, Plenum-Rated
Housing
● Dual 5dBi Gain Antennas
● Operable in AP, WDS or WDS With AP
Mode
● Multiple SSID/VLAN, 802.1Q VLAN
Tagging
● Rouge AP Detection, WMM for QoS
● SNMP Management Through D-View
● For Indoors Use
● 802.3af PoE Support
● Die-cast, Watertight Housing
● Integrated 9dBi Patch Antenna
● Connector for Optional External
Antenna
● Built-in Heater with Temperature
Sensor
● Operable in Wireless Client, AP, WDS
or WDS with AP Mode
● Multiple SSID/VLAN, 802.1Q VLAN
Tagging
● Rouge AP Detection, AP Grouping
(Load Balancing)
● WMM for QoS
● Management Through AP Manager II,
SNMP D-View
DI-624
Wireless 108G 4-Port Router
● 4 10/100BASE-TX Ethernet LAN Ports
● QoS Traffic Prioritization
● Parental Control, SPI Firewall
DIR-400
Wireless 108G 4-Port Router
● 4 10/100BASE-TX Ethernet LAN Ports
● QoS Traffic Prioritization
● Parental Control, SPI Firewall
DI-624S
Wireless 108G Storage Router
DI-624S
● Allows Creation of Personal Web Server
● Multiple Functions: Files/Storage
Sharing, FTP Server, Printer Sharing,
UPnP Audio/Video Server
● Firewall: DoS Prevention, SPI, Intrusion
Detection, Event Log
● QoS Traffic Prioritization
● 2 USB 2.0 Ports for Hard Disks/Printer
Connection
● 4 10/100BASE-TX Ethernet LAN Ports
27
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● Dual-band Operation
» Simultaneous operation in 802.11b/g
2.4GHz and 802.11a 5GHz frequency
bands.
» Morewireless bandwidth available for
use.
» Networkcan be segmented according to
frequency band.
●Up to 108Mbps Data Transfer
Rate
» 108Mbps Turbo mode wireless speed
when operating with other 108G or
108AG devices.
» High bandwidth for wireless transfer
of Internet surfing, file download,
multimedia, voice and video.
Wireless 108AG
The Wireless 108AG employs both the 5GHz and 2.4GHz frequencies, incorporating
802.11a, 802.11b and 802.11g wireless LAN standards to make it compatible with
virtually all existing 802.11 networks. This wireless LAN series provides the most
expanded user bandwidth available in a wireless device. It offers data transfer rates
of up to 108Mbps in the Turbo Mode in either the 2.4GHz or 5GHz bands when
operating with other D-Link Wireless 108AG products, and in the 2.4GHz band when
operating with other D-Link Wireless 108G products. 1Hundreds of wireless clients
can connect to this network, using any one of its non-overlapping channels.
Through the user access control function in wireless routers and access points,
network administrators can segment users on the wireless network by frequency
band. Users who require special networking privilege access to sensitive company
data, video conferencing, or connectivity to specific departments may, for example,
use the 802.11a channels, while other employees may use the 802.11b and 802.11g
channels. This type of user segmentation optimizes the performance of the routers
and access points, and delivers the best network experience to each set of users.
●64/128/152-Bit WEP Data
Encryption
» Protectionof wireless data traveling in
the air that are sent by users.
●WPA EAP/PSK, WPA2 EAP/PSK
With TKIP, AES Support
» Wireless LAN security including data
encryption keys and user authentication
for network access.
» Keeps out intruders located next door,
upstairs or downstairs.
» Advanced encryption and security
schemes for business environments.
DWL-AG132
DWL-AG530
Wireless 108AG USB Adapter
Wireless 108AG PCI Adapter
●WPS Certified
» Wi-Fi Protected Security (WPS)
provides easy security setup for wireless
clients from an AP or router. The AP
and routers provide a WPS click button
from a PC screen and a WPS push
buttons from the devices themselves to
let administrators broadcast settings to
clients, eliminating the need for clients
to manually key in encryption keys
and settings to establish connection to
network.
● 2.4GHz and 5GHz Dual Band Operation
● USB Connection with USB Extension
Cable & Cradle Provided
● Supports Windows OS
DWL-AG660
DI-784
Wireless 108AG CardBus Adapter
Wireless 108AG 4-Port Router
● 2.4GHz and 5GHz Dual Band
Wireless Connection for Notebook/
Laptop PC
● Supports Windows, Linux
D-Link Product Guide 2008
28
● 2.4GHz and 5GHz Dual Band Wireless
Connection for Desktop PC
● Supports Windows, Linux
● 2.4GHz and 5GHz Dual Band
Operation
● DoS Prevention, SPI, Intrusion
Detection, Event Log
● MAC-Based Access Control
● Domain/URL Filtering Parental Control
● 4 10/100BASE-TX Ethernet LAN Ports
DWL-7100AP
DWL-7700AP
Wireless 108AG Access Point
Wireless AG Outdoors Access Point
● 2.4GHz and 5GHz Dual Band Operation
● Operable in AP, WDS, WDS With AP, or
Repeater Mode 2
● WLAN STA Partitioning
● SNMP Manageable
● Indoors Use
DWL-8200AP
Wireless 108AG Access Point
● 2.4GHz and 5GHz Dual Band Operation
(Up to 54Mbps)
● Dual 5dBi Dipole Antennas
● 802.3af Power Over Ethernet (PoE) (PoE
Base Unit Provided)
● Plenum-Rated Housing
● Operable in AP, WDS or WDS With AP
Mode
● Multiple SSID, 802.1Q VLAN, WLAN STA
Partitioning
● SNMP Manageable
108Mbps Turbo mode operation on 5GHz frequency
band not allowed in EU countries.
2
WDS and repeater modes on 5GHz frequency band
not allowed in EU countries.
1
● 2.4GHz and 5GHz Dual Band Operation
● Plenum-Rated Housing
● Dual 10/100BASE-TX Ethernet Ports
(One Port With 802.3af PoE)
● Dual Ethernet Ports With Separate SSID
Can Simultaneously Connect to Wired
Network
● Dual 5dBi Gain 5GHz Antennas, 2.5dBi
Gain 2.4GHz Antennas
● 802.1Q VLAN
● Operable in AP, WDS or WDS With AP
Mode
● SNMP Management Through D-View
● Indoors Use
29
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● Draft 802.11n WLAN
Specifications
» Latest high-performance wireless
technology.
Wireless N
Wireless N uses the draft 802.11n specifications and delivers real world performance
many times faster than an 802.11g wireless connection. Users can connect a Wireless
N router to a cable or DSL modem to create a secure wireless network to share
photos, files, music, video, printers, and network storage throughout a home or office.
With a built-in intelligent QoS Engine, Wireless N routers provides a better Internet
experience by keeping digital phone calls (VoIP), streaming multimedia applications
and online gaming smooth and responsive.
●Superior Wireless Speed
» Data transfer rates up to 300Mbps
- many times faster than current 802.11g
wireless devices.
» Suitable for Internet HDTV, streaming
video, online games, voice, and MP3
music.
●Superior Signal Coverage
Range
» Wirelessoperation range many times
farther than the current 802.11g devices
» Signalreception/transmission at greater
distances.
●Compatible with 802.11b/g and
802.11a/b/g
» Single-band 802.11n draft devices
operate in superior speed and range
in 2.4GHz frequency band and are
backward compatible with 802.11a/b/g
devices.
» Dual-band 802.11n draft devices
operate in superior speed and range
in both 2.4GHz and 5GHz frequency
ranges while are also backward
compatible with existing 802.11a/b/g
devices.
» Preservation of past investments in
earlier standard wireless hardware and
applications.
●Automatic Channel Selection
» The device senses the least used
or non-occupied channels within the
frequency band and automatically
makes them available for wireless
clients’ connection.
DWA-130
DAP-2553
Wireless N USB Adapter
Wireless N Switchable Dual Band
PoE Access Point
●User Limit Control
» Administrators can set limit to the
number of simultaneous wireless
client connections to an AP or router to
prevent the network performance from
any drastic degradation.
●64/128-Bit WEP Data
Encryption
» Protection of wireless data traveling in
the air that are sent by the users.
●WPA EAP/PSK, WPA2 EAP/PSK
with TKIP, AES Support
» Wireless LAN security including data
encryption keys and user authentication
for network access.
» Keeps out intruders located next door,
upstairs or downstairs.
» Advanced encryption and security
schemes for business environments.
D-Link Product Guide 2008
30
● 2 Integrated Antennas to Boost Signal
Strength
● Supports Windows
● WPS Certified
» Wi-Fi Protected Setup (WPS) provides
easy security setup for wireless clients
from an AP or router. The AP and
routers provide a WPS click button
from a PC screen and a WPS push
buttons from the devices themselves to
let administrators broadcast settings to
clients, eliminating the need for clients
to manually key in encryption keys
and settings to establish connection to
network.
● User-Selectable 2.4GHz or 5GHz
Frequency Band Operation
● Automatic Channel Selection
● Transmit Power Control
● 802.3af PoE Support
● 3 Dipole Antennas to Boost Signal
Strength
● Operable as Wireless Client, AP
(Wireless Connectivity for Computers),
WDS (Wireless Bridge), or WDS with
AP
● Multiple SSID, 802.1Q VLAN
● WMM (Wireless QoS)
DAP-2590
DIR-615
Wireless N Switchable Dual
Band PoE Access Point
Wireless N Router
● 1 10/100BASE-TX Ethernet WAN Port
● 4 10/100BASE-TX Ethernet LAN Ports
● MAC/IP-Based Access Control
● Parental Control, SPI Firewall
● Security Functions Can Be Configured
by Users
DKT-400
● User-Selectable 2.4GHz or 5GHz
Frequency Band Operation
● Automatic Channel Selection
● Transmit Power Control
● User Limit Control
● 802.3af PoE Support, Plenum-Rated
Housing
● 3 Dipole Antennas to Boost Signal
Strength
● Operable as Wireless Client, AP
(Wireless Connectivity for Computers),
WDS (Wireless Bridge), or WDS with AP
● Multiple SSID, 802.1Q VLAN
● WMM (Wireless QoS)
Wireless N Starter Kit
● Includes 1 DIR-615 Wireless N Router
and 1 DWA-140 Wireless N USB Adapter
DIR-605
Wireless N Router
● 1 10/100BASE-TX Ethernet WAN Port
● 4 10/100BASE-TX Ethernet LAN Ports
● MAC/IP-Based Access Control
● Parental Control, SPI Firewall
31
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● Draft 802.11n WLAN
Specifications
» Latest high-performance wireless
technology.
Xtreme N
Xtreme N uses the draft 802.11n specifications and 3 x 3 antenna designs to
deliver real world performance of up to 14 times faster than 802.11g devices, and
an operation range six times farther than 802.11g. Users can connect an Xtreme N
router to a cable or DSL modem to create a fast, secure wireless network to share
photos, files, music, video, printers, and network storage throughout a home or office.
With a built-in award-winning QoS Engine, Xtreme N provides an outstanding Internet
experience by keeping wireless digital phone calls (VoIP), streaming multimedia and
online gaming smooth and responsive.
●Superior Wireless Speed
» Data transfer rates up to 14 times
faster than the current 802.11g wireless
devices, suitable for Internet DHTV,
streaming video, online games, voice,
and MP3 music.
●Superior Signal Coverage
Range
DWA-652
DWA-552
Xtreme N CardBus Adapter
Xtreme N PCI Adapter
» Wirelessoperation range up to 6
times farther than the current 802.11g
devices, enables reception from greater
distances.
●Compatible with 802.11b/g and
802.11a/b/g
» Single-band 802.11n draft devices
operate in superior speed and range
in 2.4GHz frequency band and are
backward compatible with 802.11a/b/g
devices.
» Dual-band 802.11n draft devices
operate in superior speed and range
in both 2.4GHz and 5GHz frequency
ranges while are also backward
compatible with existing 802.11a/b/g
devices.
» Preservation of past investments in
earlier standard wireless hardware and
applications.
● Multiple Reception and Transmission
Antennas to Boost Signal Strength
● Supports Windows
● 3 Dipole Antennas to Boost Signal
Strength
● Supports Windows
DWA-643
DWA-556
Xtreme N ExpressCard Adapter
Xtreme N PCIe Express Adapter
●Automatic Channel Selection
» The device senses the least used
or non-occupied channels within the
frequency band and automatically
makes them available for wireless
clients’ connection.
●User Limit Control
» Administrators can set limit to the
number of simultaneous wireless
client connections to an AP or router to
prevent the network performance from
any drastic degradation.
● Multiple Reception and Transmission
Antennas to Boost Signal Strength
● Supports Windows
●64/128-Bit WEP Data
Encryption
● WPS Certified
» Protection of wireless data traveling in
the air that are sent by the users.
●WPA EAP/PSK, WPA2 EAP/PSK
with TKIP, AES Support
» Wireless LAN security including data
encryption keys and user authentication
for network access.
» Keeps out intruders located next door,
upstairs or downstairs.
» Advanced encryption and security
schemes for business environments.
D-Link Product Guide 2008
32
» Wi-Fi Protected Setup (WPS) provides
easy security setup for wireless clients
from an AP or router. The AP and
routers provide a WPS click button
from a PC screen and a WPS push
buttons from the devices themselves to
let administrators broadcast settings to
clients, eliminating the need for clients
to manually key in encryption keys
and settings to establish connection to
network.
● 3 Dipole Antennas to Boost Signal
Strength
● Supports Windows
DWA-160
Xtreme N Dual Band USB
Adapter
● 2.4GHz and 5GHz Dual Band
Operation
● Multiple Reception and Transmission
Antennas to Boost Signal Strength
● Supports Windows, Linux
DAP-1522
DIR-855
Xtreme N Duo Wireless
Bridge/Access Point
Xtreme N Duo Media Router
● Can Operate in either 2.4GHz or 5GHz
Frequency Band
● Operable as AP or Bridge
● Both AP and Bridge Modes Support Dual
Frequency Bands
● 4 Integrated 10/100/1000BASE-TX LAN
Ports
● DFS2 Compliant
● WPS Certified
● 2.4GHz and 5GHz Dual Band Operation
● High-Performance CPU
● Gigabit WAN Port, 4 Gigabit LAN Ports
● 3 Dipole Antennas to Boost Signal
Strength
● WMM & StreamEngine Intelligent QoS
Technology
● MAC/IP-Based Access Control
● Domain/URL Filtering, Scheduling
Parental Control
● SPI Firewall
● USB 2.0 Port for Windows Connect Now
(WCN) Setup
DIR-655
DGL-4500
Xtreme N Gigabit Router
Xtreme N Gaming Router
● High-Performance CPU
● Gigabit WAN Port, 4 Gigabit LAN Ports
● 3 Dipole Antennas to Boost Signal
Strength
● WMM & StreamEngine Intelligent QoS
Technology
● MAC/IP-Based Access Control
● Domain/URL Filtering, Scheduling
Parental Control
● SPI Firewall
● USB Port for Windows Connect Now
(WCN) Setup
● User-Selectable 2.4GHz or 5GHz
Frequency Band Operation
● High-Performance CPU
● Gigabit WAN Port, 4 Gigabit LAN Ports
● 3 Dipole Antennas to Boost Signal
Strength
● WMM & Intelligent Game Traffic
Prioritization GameFuel Engine
● MAC/IP-Based Access Control
● Domain/URL Filtering, Scheduling
Parental Control
● SPI Firewall
● USB 2.0 Port for Windows Connect Now
(WCN) Setup
33
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● Draft 802.11n WLAN
Specifications
» Latest high-performance wireless
technology.
●Superior Wireless Speed
» Data transfer rates up to 650% faster
than the current 802.11g wireless
devices for RangeBooster N 650, and
up to 300Mbps for RangeBooster N.
» Suitable for Internet HDTV, streaming
video, online games, voice, and MP3
music.
RangeBooster N,
RangeBooster N 650
RangeBooster N 650 uses the draft 802.11n specifications and 3 x 3 or 2 x 3 antenna
design to deliver real world performance of up to 650% faster than an 802.11g
wireless connection. Users can connect a RangeBooster N 650 router to a cable or
DSL modem to create a secure wireless network to share photos, files, music, video,
printers, and network storage throughout a home or office. With a built-in awardwinning QoS Engine, RangeBooster N 650 provides a better Internet experience by
keeping digital phone calls (VoIP) and online gaming smooth and responsive.
RangeBooster N also employs the draft 802.11 n specifications, but uses the 2 x 2
antenna design to deliver up to 300Mbps data transfer rate and a signal range up to
four times farther than 802.11g.
●Superior Signal Coverage
Range
» Wirelessoperation range up to 5 times
farther than the current 802.11g devices
for RangeBooster N 650, and 4 times
farther than the current 802.11g devices
for RangeBooster N; signal reception/
transmission at greater distances.
●Compatible with 802.11b/g
Devices
» Seamless integration with current and
earlier standard wireless devices.
» Preservation of past investments in
earlier standard wireless hardware and
applications.
●User Limit Control
» Administrators can set limit to the
number of simultaneous wireless
client connections to an AP or router to
prevent the network performance from
any drastic degradation.
DWA-645
DWA-642
RangeBooster N 650 CardBus
Adapter
RangeBooster N CardBus
Adapter
●64/128-Bit WEP Data
Encryption
» Protection of wireless data traveling in
the air that are sent by the users.
●WPA EAP/PSK, WPA2 EAP/PSK
with TKIP, AES Support
» Wireless LAN security including data
encryption keys and user authentication
for network access.
» Keeps out intruders located next door,
upstairs or downstairs.
» Advanced encryption and security
schemes for business environments.
●WPS Certified
» Wi-Fi Protected Setup (WPS) provides
easy security setup for wireless clients
from an AP or router. The AP and
routers provide a WPS click button
from a PC screen and a WPS push
buttons from the devices themselves to
let administrators broadcast settings to
clients, eliminating the need for clients
to manually key in encryption keys
and settings to establish connection to
network.
D-Link Product Guide 2008
34
● 2 Reception Antennas, 3 Transmission
Antennas to Boost Signal Strength
● Supports Windows
● 2 Integrated Antennas to Boost Signal
Strength
● Supports Windows
DWA-547
DWA-542
RangeBooster N 650 PCI Adapter
RangeBooster N PCI Adapter
● 3 Dipole Antennas to Boost Signal
Strength
● Supports Windows
● 2 Dipole Antennas to Boost Signal
Strength
● Supports Windows
DWA-140
DAP-1353
DIR-635
RangeBooster N USB Adapter
RangeBooster N 650 Access Point
RangeBooster N 650 Router
● 2 Integrated Antennas to Boost Signal
Strength
● Supports Windows, Linux
ANTENNAs
● 3 Dipole Antennas to Boost Signal
Strength
● MAC/IP-Based Access Control
● Domain/URL Filtering, Scheduling
Parental Control, SPI Firewall
● 4 10/100BASE-TX Ethernet LAN Ports
● USB Port for Windows Connect Now
(WCN) Setup
● 3 Dipole Antennas to Boost Signal
Strength
● Operable as Wireless Client, AP, WDS,
WDS with AP, or AP Repeater
● User Limit Control
● Multiple SSID, 802.1Q VLAN
● WMM (Wireless QoS)
2.4 GHz / 5 GHz Antennas
ANT24-1800
ANT24-1801
ANT24-2100
ANT70-0800
ANT70-0801
ANT70-1000
ANT70-1800
2.4GHz
2.4GHz
2.4GHz
2.4GHz/5GHz
2.4GHz/5GHz
2.4GHz/5GHz
2.4GHz/5GHz
Directional
Directional
Directional
Omni-Directional
Omni-Directional
Directional
Directional
Indoor/Outdoor
Indoor/Outdoor
Outdoor
2.4GHz: 8dBi
5GHz: 8dBi
2.4GHz: 8dBi
5GHz: 10dBi
2.4GHz: 14dBi
5GHz: 18dBi
Outdoor
Outdoor
Outdoor
Indoor/Outdoor
18dBi
18dBi
21dBi
2.4GHz: 8dBi
5GHz: 8dBi
-
-
-
2.4GHz: 700 m/350 m/100 m 2.4GHz: 700 m/350 m/100 m 2.4GHz: 800 m/400 m/150 m
5GHZ: 1 km/ 500 m/ 200 m 5GHZ: 1 km/ 500 m/ 200 m 5GHZ: 1.2 km/ 600 m/ 250 m
-
8 km/ 6 km/ 1.5 m
8 km/ 6 km/ 1.5 km
12 km/ 9 km/ 2.5 m
2.4GHz: 800 m/450 m/150 m 2.4GHz: 800 m/450 m/150 m 2.4GHz: 1k m/500 m/200 m
5GHZ: 1 km/ 500 m/200 m
5GHZ: 1 km/ 500 m/200 m
5GHZ: 1.5 km/ 700 m/300 m
2.4GHz: 6 km/4.5 km/1 km
5GHZ: 8 km/5 km/1.5 km
H 15 V 15
H 15 V 15
H5V8
2.4GHz: H 360 V 15
5GHz: H 360 V 15
2.4GHz: H 360 V 15
5GHz: H 360 V 15
2.4GHz: H 58 V 55
5GHz: H 45 V 45
2.4GHz: H 30 V 30
5GHz: H 15 V 15
-
-
-
-
-
-
-
N-Jack
N-Jack
N-Jack
N-Jack
N-Jack
N-Jack
N-Jack
Included
Included
Included
Included
Included
Included
Included
50 cm
50 cm
3m
50 cm
50 cm
50 cm
50 cm
Wall/Pole
Pole
Pole
Pole
Pole
Pole
Pole
-
-
-
-
-
-
-
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
35
D-Link Product Guide 2008
WIRELESS
NEtwORKING
ANTENNA
2.4 GHz Antenna
Antennas
2.4GHz
Antenna
ANT24-0401
ANT24-0500
ANT24-0501
ANT24-0501C
ANT24-0502
ANT24-0600
DWL-R60AT
2.4GHz
2.4GHz
2.4GHz
2.4GHz
2.4GHz
2.4GHz
2.4GHz
Omni-Directional
Omni-Directional
Omni-Directional
Omni-Directional
Omni-Directional
Directional
Directional
Indoor Ceiling
Indoor/Outdoor
Indoor
Indoor
Indoor
Indoor
Indoor
3.5dBi
5dBi
5dBi
5dBi
5dBi
6dBi
6dBi
250 m/100 m/40 m
500 m/ 250 m/60 m
500 m/ 200 m/50 m
500 m/ 200 m/60 m
500 m/ 200 m/60 m
600 m/350 m/ 80 m
600 m/350 m/ 80 m
-
1.5 km/ 1.3 km/ 200 m
-
-
-
-
-
H 360 V 120
H 360 V 32
H 360 V 36
H 360 V 36
H 360 V 40
H 68 V 80
H 70 V 85
-
30 cm
150 cm
-
-
150 cm
-
N-Jack
RP-SMA Plug
RP-SMA Plug
RP-SMA Plug
RP-SMA Plug
RP-SMA Plug
-
-
-
-
-
-
-
-
-
SMA Jack
Optional
-
3m
2m
Wall/Desktop/Magnetic Attached to AP/Router
-
Ceiling
Pole
-
ANT24-SP
-
-
-
-
-
-
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
-
-
-
-
-
Attached to AP/Router
Wall/Desktop/Magnetic Attached to AP/Router
Notes:
1.Extended range reference based on RF-output power 17dBmn (indoor AP), 23dBm (outdoor AP) with default cable loss.
2.Transmission distance range based on two antennas of the same specs with default cable loss.
3. Effective range based on EIRP (Effected Isotropic Radiation Power = device output power + antenna gain - cable loss).
HPBW: Half Power Beam Width, H: horizontal plane pattern, V: ver tical plane pattern
Actual range subject to change due to users' physical environment. All figures are for reference only.
Antenna Cable Kits
Access Point
Oversall
System Loss
Product Number
Jumper Cable
Surge Arrestor
ANT24-ODU03M
-
-
LMR200
0.3M
0.6dB
ANT24-ODU1M
-
-
LMR400
1M
0.6dB
ANT24-ODU3M
-
-
LMR400
3M
1.0dB
LMR400
3M
2.0dB
RP-TNC
Multi-brand
ANT24-DLK3M
D-Link Product Guide 2008
36
Low Loss Cable
Application
2.4
GHz Antenna
Antennas
2.4GHz
ANT24-0700
ANT24-0700C
ANT24-0800
2.4GHz
2.4GHz
2.4GHz
Omni-Directional
Omni-Directional
Indoor
Indoor
7dBi
7dBi
500 m/ 250 m/60 m
ANT24-1200
ANT24-1201
ANT24-1400
ANT24-1500
2.4GHz
2.4GHz
2.4GHz
2.4GHz
2.4GHz
Directional
Directional
Directional
Directional
Directional
Omni-Directional
Omni-Directional
Indoor/Outdoor
Indoor/Outdoor
Indoor
Outdoor
Outdoor
Outdoor
Indoor
8dBi
8.5dBi
12dBi
12dBi
14dBi
15dBi
1.8dBi
600 m/300 m/70 m
700 m/ 350 m/100 m
800 m/ 500 m/150 m
1.5 m/ 1.2 m/500 m
-
-
-
500 m/400 m/200 m /
100 m/5 m **
-
-
2 km/ 1 km/ 400 m
2.5 km/ 1.5 km/ 600 m
-
3 km/ 2.5 km/ 1 Km
6 km/ 4.5 km/ 1 Km
4 km/ 2.5 km/ 500 m
-
H 360 V 24
H 360 V 24
H 360 V 15
H 70 V 65
H 80 V 23
H 50 V 50
H 30 V 30
H 360 V 8
H 360 V 70
150 cm
150cm
-
30cm
-
30 cm
30 cm
-
1.2 m
RP-SMA Plug
RP-SMA Plug
N-Jack
N-Jack
SMA Jack
N-Jack
N-Jack
N-Jack
PR-SMA Plug
-
Included
Included
-
Included
Included
Included
-
-
-
50 cm
3m
3m
50 cm
50 cm
3m
-
Wall/Desktop/Magnetic
Attached to AP/Router
Pole
Wall/Pole
Window/Wall
Wall/Pole
Wall/Pole
Pole
Desktop
-
-
-
-
-
-
-
-
-
-
-
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
-
-
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
ANT24-CB Series
ANT24-ODU Series
ANT24-DLK Series
-
-
ANT24-0801
ANT24-0230
2.4GHz *
* Use with 802.11n draft wireless AP, router or adapter
** Approximate range at 1/11/54/108/270Mbps
Antenna Cable Assemblies
Cable Type
Cable Length
N-male to N-female
3m
N-male to N-female
6m
N-male to N-female
9m
SMA-male to SMA-female
3m
N-male to SMA-female
3m
N-male to SMA-female
50 cm
All outdoor antennas
include the following:
50cm pigtail (0.83db lose/meter)
N-male to RP-SMA plug
ANT24-SP
Lightning Surge Arrestor/Protector
37
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● Centralized Management
» Consistent user authentication and
security policies. Easy identification of
failed AP, easy swapping with new AP.
●Pre-Set Configuration
» Security can be pre-set and RF
channels auto-adjusted for each AP.
When an AP is removed or added,
switch automatically configures new AP
with same configuration of replaced unit.
Sensitive information not locally stored
at the AP.
●Comprehensive Security
» WEP,WPA/WPA2 data encryption,
802.1Q VLAN, up to 8 SSID per
wireless frequency band.
●Tracking/Maintenance of User
Authentication
» Continuous connection for each wireless
user, better network security.
●Fast Roaming
» Wireless signals roamed not only across
to AP connected to same switch, but
also across AP connected to different
switches, using inter-switch roaming.
Unified Access Wired/
Wireless Switching
Wireless switching - an evolution in wireless LAN - is designed to simplify installation
and enhance the effectiveness of a medium-sized or large Wi-Fi network. It allows
businesses to install a high-performance, secure, manageable and scalable unified
wired/wireless network.
Wireless switching consists of one or multiple switches, and multiple wireless access
points (AP). The switches are core units that consolidate the security, manage the
bandwidth and maintain the intelligence of the entire wireless network. In addition to
monitoring users’ identities and maintaining their authentication as they roam, these
switches can configure and control all aspects of the AP, including: RF channel and
power management, wireless traffic segmentation, AP roaming and load balancing,
rouge AP detection and AP access security. The AP can be dispersed throughout
a site and directly attached to these switches, or indirectly connected through any
Ethernet switch.
Traffic from wireless users is roamed not only across to the access points, but
also among the peer wireless switches. In addition to intra-switch roaming, roaming
across different subnets is also supported for secure wireless connection across
multiple departments in a large enterprise. As roaming is through the Ethernet cable
at the fast Gigabit speed, traffic bottlenecks are minimized and overall network
performance is enhanced.
The AP, no matter where installed, are automatically discovered and centrally
managed. As users move around the wireless network, all data information,
translation, authentication paths and user tracking are executed on the switch end
to provide network administrators with a consolidated and secure wireless system.
●Gigabit Connection
» Fast signal roaming across AP at Gigabit
speed. More difficult for thieves to
intercept when signals are roamed via
Ethernet cables.
●Converged LAN/WLAN
Deployment
» No restriction on port usage. Any switch
port can be used for wired or wireless
purposes.
●Easy Deployment
» All switch ports support 802.3af PoE.
AP supports 802.3af PoE, can be
installed on high walls or ceilings away
from AC power outlets. Switch’s rackmount design allows it to be hidden in
equipment rack.
●Scalable Expansion
» Each switch can manage up to 48 AP. Up
to 4 switches can be gradually added in a
peer-to-peer configuration as more AP are
deployed.
●Rogue AP Detection
» Identification of intruding AP for
administrators to take proper actions.
D-Link Product Guide 2008
38
● Flexible Deployment
» In a unified LAN/WLAN deployment,
D-Link’s wireless switching architecture
allows the switches to be placed deep
inside an existing wired network, say
in a data center, to protect current
investments in infrastructure. Wireless
traffic is tunneled to the switches for
centralized data forwarding decision. An
alternative would be to put the switches
at the network edge for minimized users’
distance from the AP, flexible scalability
and distributed peer-to-peer WLAN
switching.
DES-1228P
24-Port PoE Ethernet Switch
● 24 PoE 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP for
Uplink to LAN
● 2 10/100/1000BASE-T Ports
● Can Manage Up to 24 DWL-3140AP
Access Points
DWL-3140AP
DWL-3500AP
DEM-410X
Wireless G Access Point
Wireless Unified 108G Access Point
1-Port 10-Gigabit Module
● 802.11g 2.4GHz WLAN Standard
● Up to 108Mbps Wireless Speed
● PoE, WMM Support
● Connects to/Managed by DES-1228P
Switch
● Low Profile ID, True Omni-Antenna
Design
● Smoke Detector Shape, Ceiling Mounting
DWS-3024
24-Port Wireless Switch
● 24 PoE Gigabit Ports
● 4 Combo SFP for Fiber Connection to
LAN
● Can Manage Up to 48 DWL-3500AP/
8500AP Access Points
● Fast Gigabit-Speed Roaming
● Inter-Subnet Roaming Between Switches
● Expandable to 4 Peer DWS-3024/3026
Wireless Switches
● Optional Redundant Power Supply
● SNMP Manageable
● 1 XFP Slot
● For Use with DWS-3026 Switch
● 802.11g 2.4GHz WLAN Standard
● Up to 108Mbps Wireless Speed
● Plenum-Rated Housing with PoE Support
● Dual 5dBi Gain Antennas
● WMM QoS
● Rouge AP Detection
● AP Load Balancing
● WLAN STA Partitioning
● Connects Directly to DWS-3024/3026
Wireless Switch or Indirectly Through
LAN Switch
● Can Also Be Deployed as Stand-Alone AP
DWL-8500AP
Wireless Unified 108AG Dual
Band Access Point
DEM-410CX
1-Port 10-Gigabit Module
● 1 CX4 Port
● For Use with DWS-3026 Switch
108Mbps Turbo mode operation on 5GHz frequency
band not allowed in EU countries.
1 DWS-3026
24-Port Wireless Switch
● 2 Open Slots for 10-Gigabit Uplinks to
LAN Backbone/Servers
● Can Manage Up to 48 DWL-3500AP/
8500AP Access Points
● All Other Functions Same as DWS-3024
● 802.11a/g 2.4GHz/5GHz Dual Band
Operation
● Up to 108Mbps Wireless Speed 1
● Plenum-Rated Housing with PoE Support
● Dual 5dBi Gain Antennas
● WMM QoS
● Rouge AP Detection
● AP Load Balancing
● WLAN STA Partitioning
● Connects Directly to DWS-3024/3026
Wireless Switch or Indirectly Through
LAN Switch
● Can Also Be Deployed as Stand-Alone AP
39
D-Link Product Guide 2008
WIRELESS
NEtwORKING
D-Link Product Guide 2008
40
Unified Access Wired/
Wireless Switching
WIRELESS
NEtwORKING
Features & Benefits
● Bluetooth Profile Compliance
» Interoperability with vendorindependent, Bluetooth standardcompliant devices.
●Up to 2.1Mbps Wireless
Transfer Rate (Bluetooth 2.0)
» Up to 723.2 Kbps basic data rate,
enhanced rate up to 2.1Mbps
(asymmetrical) or 1.5Mbps
(symmetrical). Asymmetrical rates are
used for data transfer (PC to mobile
phone or PC to web); symmetrical rates
are used for voice (mobile phone to
headset).
» Decent speed within a convenient range
between Bluetooth-enable devices.
Bluetooth Personal Area Network
For those without Wi-Fi at home, at school, in the office or outdoor, Bluetooth provides
a convenient and cost-effective wireless networking solution. Applications include web
access on PDA and laptops at unconnected locations, wireless network printer sharing
and wireless access to Ethernet LAN servers and Internet/Intranet services from
Bluetooth-enabled devices.
D-Link Bluetooth 2.0 offers up to 2.1Mbps asymmetrical and 1.5Mbps symmetrical data
transfer rates - three times the speed of Bluetooth devices using the earlier 1.x standards.
Operating on the globally available 2.4GHz radio frequency, Bluetooth 2.0 is backward
compatible with Bluetooth 1.1 and 1.2 devices and transfers data with them using the
lower Bluetooth 1.1/1.2 transmission speeds.
Low power consumption is designed into D-Link Bluetooth; a result is a very low power
demand on the portable devices. This saves the battery power while giving users the
freedom to roam among the Bluetooth-enabled devices.
●Up to 10 or 20 Meters’
Operation Range
» Operation range depends on antenna
capability.
●128-Bit Data Encryption
» Security protection for data transferred
in the air among Bluetooth-enable
devices.
●Adaptive Frequency Hopping
(AFH) Function (Bluetooth 1.2,
2.0)
» Uses Enhanced Inquiry Scan for
immediate Frequency Hopping
Synchronization (FHS) response.
» Automatically selects any unused
frequency channels to establish a
connection.
» Maintains a high level of connection
when operating in environments where
2.4GHz Wi-Fi devices are also present.
DBT-122
DBT-900AP
USB Bluetooth Adapter
Bluetooth-to-Ethernet Access Point
● Bluetooth 2.0 Class 2 Compliant
● Up to 2.1Mbps Asymmetrical, 1.5Mbps
Symmetrical Transfer Rates
● USB 2.0 Connection to PC
● Adaptive Frequency Hoping (AFH)
Function
● Internal Antenna With Up to 10 m
Operating Range1
● 128-Bit Encryption
● Supports Windows, Mac OS
● Bluetooth 1.1 Class 2 Compliant
● Up to 723Kbps Transfer Rate
● Enables Bluetooth Devices to Access
Services on Ethernet Networks (E-Mail,
File Transfer, Internet Logon)
● Ethernet Connection with DHCP
Assignments
● User Access Authorization/Authentication
● Simultaneous Access to Internet/Intranet
● External Antenna With Up to 20 m
Operating Range1
● 56-Bit Data Encryption
● Works Seamlessly With Computers &
PDA2
Environmental factor may adversely affect range.
Computers and PDAs connecting to DBT-900AP must be
Bluetooth-enabled with PAN Profile support.
1
2
41
D-Link Product Guide 2008
WIRELESS
NEtwORKING
Features & Benefits
● Ultra-Wideband Frequency,
Low Energy Level
» 3.1GHz to 10.6 GHz radio transmission
range.
» Limited transmit power of -41dBm/MHz.
» Provides dramatic channel capacity at
short range that limits interference.
●Convenient Wireless
Connection
» Digitals camcorders can play justrecorded videos on an HDTV without
troublesome wiring.
» Portable MP3 player can stream audio
to surround sound speakers from
anywhere in the room.
» Mobile computer can wirelessly connect
to a digital projector in a conference
room to deliver presentation.
» Digital pictures can be sent to a USB
printer without any cable.
» PC can wirelessly connect to printer,
scanner or external storage from a USB
port.
» Future products such as Camera
and Printers will have Wireless USB
connectivity built-in, making Wireless
USB networking even more compelling.
●No Interference with Other
Appliances’ Radio Frequencies
» Wireless USB doesn’t interfere largely
with other more traditional ‘narrow band’
and continuous carrier wave uses in the
same frequency band.
» Ensuresco-existence with other
wireless network and home appliances.
» Regulatory settings in different countries
should provide efficient use of scarce
radio bandwidth while enabling both
high data rate personal-area network
(PAN) wireless connectivity and longerrange, low data rate applications as well
as radar and imaging systems.
●Certified Wireless USB
» Ensures interoperability with other
Wireless USB supported devices.
Wireless USB
D-Link Wireless USB brings convenience and mobility to high-speed interconnects
in devices throughout the digital home and office. It uses the Ultra-Wideband (UWB)
technology based on the WiMedia standard, and is designed for low-power, shortrange, wireless personal area networks (WPAN).
Wireless USB enables wireless connection of multiple devices for transmission of
video, audio and other high-bandwidth data. It uses the short-range radio technology
to complement other longer range radio technologies such as Wi-Fi and WiMAX,
and cellular wide area communications. Its combination of broader spectrum and
lower power improves speed and reduces interference with other wireless spectra.
Wireless USB relays data from a host device to other devices in the immediate area
of up to 10 meters.
DUB-1210
Wireless USB Adapter
● USB 2.0 Port
● For Desktop and Notebook PC
Connection
● Supports Windows
DUB-2240
DUB-9240
Wireless USB Hub
Wireless USB Starter Kit
● 4 USB 2.0 Type A (Downstream) for
USB Device Connection
● 1 USB Type B (Cable Association)
D-Link Product Guide 2008
42
● Includes 1 DUB-1210 Wireless USB
Adapter & 1 DUB-2240 Wireless USB
Hub
MOBILE
COmmUNIcAtION
3g / 3.5G Mobile
WiMAX communication
3G Mobilecommunication
WiMAX communication
Wi-Fi
Wi-Fi Access
WiMAX
WirelessRouter
WiMAX
BaseStation
1
2
3
4
DIR-461
DIR-655
Phone
43
D-Link Product Guide 2008
MOBILE
COmmUNIcAtION
Features & Benefits
● Wireless Networking on the Go
» Creation of wireless network for coworkers to remote access office network
from a remote site.
» Wireless Internet access for passengers
on train, bus or boat.
●Mobile Video Transmission
» Direct connection of video cameras to
high-speed 3G/3.5G services to upload
pictures from a web camera as the car
is driven around.
3g / 3.5G Mobile Adapters & Routers
The 3G/3.5G mobile adapters and routers provide broadband access for mobile
workgroups. Instead of connecting to a DSL or cable landline, they use the 3G/3.5G
services of mobile network operators. These adapters and routers are ideal for mobile
PC users, work teams, emergency response units, and corporate commute vehicles
that need to provide an Internet connection while on the move. As they are affordable
in price, they can also be used by 3G/3.5G service subscribing consumers to connect
to the Internet or set up hot spots without being tied to a single location. They allow
users to access private networks away from the office where a cable or DSL Internet
connection is not available.
DWM-652
HSDPA/UMTS/EDGE/GPRS/GSM 3.5G Mobile ExpressCard
●Internet Access from 3G/3.5G
Service Subscribers
» ShareInternet among home users
where DSL or cable broadband wired
connection is not available.
●Emergency/Mobile
Applications
» Ideal for mobile users in press media,
finance/construction industries, police/
emergency rescue teams, impromptu
LAN parties at airports, hotels,
convention halls.
● Downstream Data Rates: 7.2M/3.6M/1.8M/1.2M/384Kbps *
● Upstream Data Rates: Up to 384Kbps *
● GSM Band (GSM/GPRS/EDGE): 850, 900, 1800, 1900MHz
● UMTS Band (WCDMA/HSDPA): 850, 1900, 2100MHz
● Automatic HSDPA-WCDMA-GPRS Handover
● Radio Mode Selection: 3G/3.5G for WCDMA/HSDPA, 2G Only for GSM/GPRS/EDGE,
2G+3G/3.5G dual-mode
● Supported Interfaces: ExpressCard, USB Adapter Provided, PCMCIA Adapter Optional
DIR-451
DIR-450
UMTS/HSDPA 3G Mobile Router
EVDO 3G Mobile Router
● 32-Bit CardBus Slot for Insertion of 3G
Internet PC Card
● Compatible with UMTS and HSDPA
Standard Mobile Networks
● UMTS: Up to 2Mbps Download 384Kbps
Upload Internet Speed*
● HSDPA: Up to 7.2Mbps Download
384Kbps Upload Internet Speed*
● Integrated 802.11g Wireless LAN (Up to
108Mbps Turbo Speed)
● 4 10/100BASE-TX Ethernet Ports for
Computer Connection
● USB 2.0 Port for Windows Connect Now
(WCN) Setup
● WPA EAP/PSK, WPA2 EAP/PSK, TKIP,
AES, 64/128/152-Bit WEP WLAN Security
● MAC/IP Address-Based User Access
Control
● SPI Firewall Protection
● 32-Bit CardBus Slot for Insertion of 3G
Internet PC Card
● Compatible with EV-DO Standard Mobile
Networks
● Up to 2.4Mbps Download 153Kbps
Upload Internet Speed*
● Integrated 802.11g Wireless LAN (Up to
108Mbps Turbo Speed)
● 4 10/100BASE-TX Ethernet Ports for
Computer Connection
● USB 2.0 Port for Windows Connect Now
(WCN) Setup
● WPA EAP/PSK, WPA2 EAP/PSK,
TKIP, AES, 64/128/152-Bit WEP WLAN
Security
● MAC/IP Address-Based User Access
Control
● SPI Firewall Protection
* Speed depends on 3G or 3.5G card and operator’s offering.
D-Link Product Guide 2008
44
MOBILE
COmmUNIcAtION
Features & Benefits
● Broadband Access
» WiMAX as the “last mile” connectivity at
high data rates.
» Broadband access to places where it
has been economically unavailable.
●Disaster Relief
» Providing broadband access to help
regenerate communication when all
communication infrastructure was
destroyed.
WiMAX modems,
Adapters & Routers
D-Link WiMAX adapters and routers provide wireless mobile long-range connection,
covering many kilometers of spectrum to deliver Internet connection to WiMAX end
users. These adapters are portable units and connect PC users through a PCMCIA or
USB interface to WiMAX Base Stations deployed by WiMAX Internet Service Providers.
Similarly, the WiMAX routers connect a group of users to WiMAX Base Stations also
deployed by WiMAX ISP. PC users in turn connect to the WiMAX routers through 802.11
Wi-Fi wireless or 802.3u Ethernet interfaces.
D-Link WiMAX provides standard-based broadband services for mobile operators. It
is based on the 802.16e-2005 standard and uses the OFDMA PHY as the interface
technology. It employs Mobile WiMAX implementations and smart antenna subsystems
for guaranteed signal transmission and reception. It can be used to deliver both fixed and
mobile applications to wide-ranging situations.
●IEEE 802.16e-2005 Standard
» Latest industry specifications ensure a
high level of interoperability with other
WiMAX products.
» Lower frequencies used for inherent
signal attenuation and improved range
and in-building penetration.
●Integrated Wi-Fi Sub-systems
» Shorter range wireless access system of
a few hundreds of meters’ radius, using
free unlicensed spectrum to provide
access to a broadband network.
» Wi-Fi used by end-users to access their
own network, which may or may not be
connected to the Internet.
DIR-460
WiMAX Modem
● Mobile Broadband Connection for Workgroups
● Dual Dipole Antennas to Boost Signal Strength
● 10/100BASE-TX Ethernet for Router or PC Host Connection
● USB 2.0 Port
DWM-110
DIR-462
WiMAX USB Adapter
WiMAX VoIP Router
●Integrated Internet Phone
(VoIP)
» Voice communication over the Internet
WiMAX broadband connection at no
phone charge or nominal fee.
●Versatile Applications
» Connecting Wi-Fi hotspots with each
other and to other parts of the Internet.
» Providing a wireless alternative to
cable and DSL for last mile broadband
access.
» Providing high-speed data and
telecommunications services.
» Providing a diverse source of Internet
connectivity as part of a business
continuity plan. If a business has a fixed
and a wireless Internet connection,
especially from unrelated providers, they
are unlikely to be affected by the same
service outage.
» Providing nomadic connectivity.
● Mobile Broadband Connection for
Notebook and Desktop PC
● Multiple Embedded Antennas to Boost
Signal Strength
● Supports Windows
DIR-461
WiMAX Router
● Mobile Broadband Connection for
Workgroups
● Dual Dipole Antennas to Boost Signal
Strength
● Integrated 802.11g Wireless LAN
● Integrated Voice over Internet
Communication (2 FXS Ports, SIP
Protocol)
● Built-in 4-Port Ethernet Switch for Wired
LAN Connection
● USB 2.0 Port for Windows Connect Now
DIR-610
WiMAX CardBus Adapter
● Mobile Broadband Connection for
Workgroups
● Dual Dipole Antennas to Boost Signal
Strength
● Integrated 802.11g Wireless LAN
● Built-in 4-Port Ethernet Switch for Wired
LAN Connection
● USB 2.0 Port for Windows Connect Now
● Mobile Broadband Connection for
Notebook PC
● Dual Dipole Antennas to Boost Signal
Strength
● Supports Windows
45
D-Link Product Guide 2008
SECURESPOT FirewallS
Features & Benefits
● Easiest Installation
» SECURESPOT provides the industry’s
easiest installation, Plug n’ Play security
for the entire home.
» Works with any home broadband
Ethernet router (Cable or DSL),
Windows and Mac OS.
●Unique Character
» Single box with a thin client on each PC
vs. multiple software applications on
each PC.
» All the necessary required functions:
parental controls, usage blocking and
reporting.
SECURESPOT is an all-in-one home Internet security device with parental controls.
Designed for the consumers that need greater network security, but who would rather
avoid the complications of software-based security, this device combines the functions
of several different security software applications in a single box with the easiest
installation. SECURESPOT addresses every kind of threat parents are worried about,
and provides constantly monitored and updated Internet protection services.
SECURESPOT is ideal for:
● Families with high-speed Internet access and multiple PCs.
● Parents that want to monitor and protect their children from certain websites and
web content. It can block usage by time schedule.
● Small businesses with up to ten employees.
●Thin Client on PC
» Protectionservices travel with the LAN
PCs. No matter where the PCs go,
they are protected as long as they are
connected to the Internet.
●Total Network Security
» Three levels of security: 1) on the web,
2) at the SECURESPOT device, 3) thin
client application on each PC.
» Includes one year of protection for all
services on up to four PCs, renewable
annually.
» Easier to manage than multiple licenses
for multiple programs on multiple PCs.
» Includes: Parental Control; Pop-Up
Blocker; Anti-Virus Scanning and
Protection; Spam Blocker; Anti-Spyware
Scanning and Protection; Identity Theft
Protection; Usage Reports; Block Usage
by Time Schedule; Manage Network
Security Settings of all PCs from a
Single Location.
» Protection software is automatically
updated and SECURESPOT is always
up-to-date.
» Customizable security services to suit
personal preferences.
●No Degradation of PC
Performance
DSD-150
SECURESPOT
» SECURESPOT uses less system
resources than multiple programs.
●Expandability
» SECURESPOT protects unlimited
additional PCs on home network
(additional license required).
●VoIP Accelerator
● Firewall Protection for Home/SOHO
● 10/100BASE-TX Ethernet WAN Port
● 10/100BASE-TX Ethernet LAN Port
● VoIP Accelerator
● Parental Control, Pop-Up & Spam
Blocker
● Anti-Virus Scanning & Protection
● Anti-Spyware Scanning & Protection
● Identity Theft Protection
● Includes One Year of Protection
Services for 4 PC
» QoS support to optimize upstream
bandwidth for VoIP Internet phone.
D-Link Product Guide 2008
46
VPN Client Software
Features & Benefits
● Secure IPSec Client Internet
Connection
● Protects Against Thieves for
Private Data Traveling On Internet
● Connects Remote, Home Users to
Office Network
● Allows Organizations to Build
End-to-End Secure Connectivity
for Mobile Employees/
Telecommuters
The VPN Client Software is a versatile and economical IPSec client program to secure
a VPN connection from a remote user to an office network terminated with an IPSec
gateway, such as a D-Link VPN router or NetDefend integrated services firewall. The
connection can be established over a wired or wireless network, the public Internet or a
private network.
Running on a Windows-based PC, this software complies with IPSec standards and
meets the highest security requirements. It provides an integrated personal firewall shields
against attacks from the Internet. The software uses standard IPSec implementation with
advanced 3DES/AES encryption and provides NAT transparency to work with most home
gateways and NAT routers. It supports RADIUS authentication for access screening from
a centralized user database at the office network side.
● Easy-to-Deploy Windows-Based
Software
● Standard-Based IPSec Tunneling
● Advanced 3DES/AES Data
Encryption
● Supports All D-Link VPN IPSec
Routers & NetDefend Firewalls
DS-601 / DS-605
Network Security VPN Client
● Available in 2 Versions
● DS-601: Single User’s License
● DS-605: 5 Users’ License
● VPNC-Certified
47
D-Link Product Guide 2008
IPS Firewalls
The IPS (Intrusion Prevention System) firewalls provide an all-in-one business-class security solution with integrated functions including
firewall, load balance, fault tolerance, content filtering, user authentication, Denial of Service (DoS) protection, Virtual Private Network
(VPN) remote connection and malicious internal traffic prevention. These firewalls come with multiple user-configurable interfaces,
including high-speed Gigabit ports, for flexible, bottleneck-free network deployments linking different workgroups and enterprises
together.
D-Link NetDefend firewalls adopt a unique IPS technology - component-based signatures, which are built to recognize and protect
against all varieties of known and unknown attacks, and which can address all critical aspects of an attack or potential attack including
payload, NOP sled, infection, and exploits. In terms of signature coverage, the IPS database includes attack information and data from
a global attack sensor-grid and exploits collected from public sites such as the National Vulnerability Database and Bugtrax. These
firewalls deliver high quality IPS signatures by constantly creating and optimizing NetDefend signatures via the D-Link Auto-Signature
Sensor System. Without overloading existing security appliances, these signatures ensure a high ratio of detection accuracy and the
lowest ratio of false positives.
To minimize any impact of a disaster on an entire network, D-Link NetDefend firewalls include a special feature called ZoneDefense - a
mechanism that operates seamlessly with D-Link xStack switches to perform proactive network security. ZoneDefense automatically
quarantines infected computers on the network and prevents them from flooding the network with malicious traffic.
D-Link NetDefend firewalls can be remotely managed via a web-based interface or through a dedicated VPN connection. They include
flexible features to monitor and maintain a healthy and secure network, such as e-mail alerts, system log and real-time statistics.
Multiple replicated databases are deployed worldwide
to maximize performance and availability.
2. A global database is queried for the
category of the web page.
2b. If the database does not contain the
requested information, the web page
is downloaded by the database and
analyzed using several techniques.
1. User requests a
web page.
Public web server.
3. If granted by the corporate surfing policy, the user
will gain access to the requested website.
Surfing Policy
Adult: Blocked / Shopping: Blocked / News: Allowed
D-Link Product Guide 2008
48
NetDefend IPS Firewall
DFL-200
For SOHO
DFL-210
For Workgroups &
Branch Offices
DFL-800
For Small
Businesses
DFL-1600
For Medium-Sized
Businesses
DFL-2500
For Enterprises
1 Ethernet WAN
1 Ethernet DMZ
4 Ethernet LANs
1 Ethernet WAN
1 Ethernet DMZ
(User-Configurable)
4 Ethernet LANs
2 Ethernet WANs
1 Ethernet DMZ
7 Ethernet LANs
6 User-Configurable
Gigabit Ports
8 User-Configurable
Gigabit Ports
Firewall Throughput
VPN Throughput
Concurrent Sessions
Policies
50Mbps
10Mbps
3,000
500
80Mbps
25Mbps
12,000
500
150Mbps
60Mbps
25,000
1,000
320Mbps
120Mbps
400,000
2,500
600Mbps
300Mbps
1,000,000
4,000
Transparent Mode
NAT, PAT
Dynamic Routing Protocol
H.323 NAT Traversal
Application Layer Gateway (ALG)
Proactive Network Security
Proxy ARP
OSPF
OSPF
OSPF
ZoneDefense
ZoneDefense
ZoneDefense
IGMP v3
IGMP v3
IGMP v3
IGMP v3
All Methods
All Methods
All Methods
All Methods
100
300
1,200
2,500
***
***
***
IPS Firewall
Function/Feature
Interface
System
Performance
Firewall System
(ICSA Certified)
Networking
VPN
(ICSA Certified)
Traffic Balancing/
Sharing
Bandwidth
Management
Ethernet: 10/100BASE-TX Ports
Gigabit: 10/100/1000BASE-T Ports
DHCP Server/Client
DHCP Relay
Policy-Based Routing
802.1q VLAN
IP Multicast
Encryption Methods
DES/3DES/AES Only
(DES/3DES/AES/Twofish/Blowfish/CAST-128)
80
Dedicated VPN Tunnels **
PPTP/L2TP Server
Hub and Spoke
IPSec NAT Traversal
Dead Peer Detection
Outbound Load Balancing *
Server Load Balancing
Policy-based Load Sharing
Traffic Redirect When Fail-Over
When DMZ Configured as WAN 2
Policy-Based Traffic Shaping
Guaranteed Bandwidth
Maximum Bandwidth
Priority Bandwidth
Dynamic Bandwidth Limit Balancing
DiffServ
In trusion Detection
& Prevention
(IPS/IDP)
Email Security
Protocol Anomaly Detection
Automatic Signature Update
DoS/DDoS Protection
Attack Alarm Via Email
Advanced IPS/IDP Subscription
Email Blacklist/Exempt List Filtering
Anti-Spam
Email Rate Protection
Email Size Protection
High Availability
Information
Security
Active-Passive HA mode
Device Failure Detection
Stateful Failover (Firewall & VPN)
Notification on Failover
IM/P2P Application Support
***
* Function available in future firmware upgrade.
** Include PPTP, L2TP and IPSec tunnels; all included VPN tunnels are licensed.
***Supported IM/P2P applications include Aimini, AOL, Ares P2P, BitTorrent, Direct Connect, eMule, Gnutella, Google Talk, IRC, KaZaA, MSN,
WinMX, Yahoo! Messenger (Based on Advanced IPS signature database).
49
D-Link Product Guide 2008
UTM Firewalls
The NetDefend UTM firewalls incorporate an Intrusion Prevention System (IPS), gateway Anti-Virus (AV), and Web Content Filtering
(WCF) for superior Layer 7 content inspection protection. These firewalls use a hardware accelerator approach to increase IPS and
AV throughput, and a web surfing control database containing millions of URLs for WCF. IPS, Anti-Virus and URL database real-time
update services protect enterprise networks from application exploits, network worms, malicious code attacks, and provide everything
businesses need to manage employee Internet access behavior. Maintaining an effective defense against the various threats originating
from the Internet requires that all three databases used by the UTM firewalls are kept up-to-date. In order to provide a robust defense,
D-Link offers NetDefend Firewall UTM Services which include distinct NetDefend service updates for each aspect of network defenses:
IPS, Anti-Virus, and WCF. NetDefend Firewall UTM Services ensure that each of the UTM firewall’s service databases is always
accurate and current.
The UTM firewalls feature:
●Real-time AntiVirus Gateway Inspection (AV)
●Automatic signature update
●Web Content Filtering (WCF)
● Professional Intrusion Prevention System (IPS)
● Zero Day Attack protection
● Low-cost licensing using per-firewall service maintenance
The UTM firewalls are shipped with 12 months’ Intrusion Prevention System (IPS)
subscription, 12 months’ Anti-Virus (AV) subscription, and 90 days’ Web Content Filtering
(WCF) subscription - free of charge. Upon expiration of these free subscription services,
users can extend their subscriptions by purchasing NetDefend UTM subscriptions for
selective services.
UTM Firewall
DFL-260
For Workgroup & Branch Office
DFL-860
For Small Business
1 WAN
1 DMZ (User-Configurable)
4 LAN
2 WAN
1 DMZ
7 LAN
80Mbps
25Mbps
12,000
500
150Mbps
60Mbps
25,000
1,000
Function/Feature
Interface
System
Performance
Firewall System
(ICSA Certified)
Networking
VPN
(ICSA Certified)
Traffic Balancing/
Sharing
Bandwidth
Management
10/100BASE-TX Ethernet Ports
Firewall Throughput
VPN Throughput
Concurrent Sessions
Policies
Transparent Mode
NAT, PAT
Dynamic Routing Protocol
H.323 NAT Traversal
Application Layer Gateway (ALG)
Proactive Network Security
OSPF
ZoneDefense
DHCP Server/Client
DHCP Relay
Policy-Based Routing
802.1q VLAN
IP Multicast
Encryption Methods
Dedicated VPN Tunnels **
PPTP/L2TP Server
Hub and Spoke
IPSec NAT Traversal
IGMP v3
IGMP v3
DES, 3DES, AES, Twofish, Blowfish, CAST-128
100
DES, 3DES, AES, Twofish, Blowfish, CAST-128
300
When DMZ Configured as WAN 2
Outbound Load Balancing *
Server Load Balancing
Policy-based Load Sharing
Traffic Redirect When Fail-Over
Policy-Based Traffic Shaping
Guaranteed Bandwidth
Maximum Bandwidth
Priority Bandwidth
Dynamic Bandwidth Limit Balancing
DiffServ
Email Security
Information
Security
Intrusion Detection
& Prevention
(IPS/IDP)
Web Content
Filtering
Anti-Virus
Email Blacklist/Exempt List Filtering
Anti-Spam
Email Rate Protection
Email Size Protection
IM/P2P Application Support
***
***
URL Blacklist/Exempt List
Java, Cookie, ActiveX, VB
URL Blacklist/Exempt List
Java, Cookie, ActiveX, VB
Protocol Anomaly Detection
Automatic Pattern Update
DoS, DDoS Protection
Attack Alarm via Email
URL Based
Active Content Handling
Real-Time Intelligent Database
Over 30 Filtering Categories
Real Time AV Scanning
Unlimited File Size
Scans VPN Tunnels
Supported Compression File
Signature Licensor
Automatic Pattern Update
D-Link Product Guide 2008
Kaspersky
50
Kaspersky
* Available in future firmware upgrade
** Include PPTP, L2TP and IPSec tunnels;
all included VPN tunnels are licensed.
***Supported IM/P2P applications include
Aimini, AOL, Ares P2P, BitTorrent, Direct
Connect, eMule, Gnutella, Google Talk,
IRC, KaZaA, MSN, WinMX, Yahoo!
Messenger (Based on Advanced IPS
signature database).
Intrusion Prevention
System (IPS) Subscriptions
Features & Benefits
● Focus on Attack Payload, not
Attackers or IP Addresses
» In-depth inspection of data from Layer 2
to Layer 7 protecting against both false
positives and false negatives
» Prevention of various types of networkbased threats with a high degree of
accuracy
●IM and P2P Management
» Signatures to manage Instant
Messaging (IM) and Peer-to-Peer (P2P)
applications in the network
●Zero Day Attack Protection
» Captureof variations of attacks and
stealthy malicious traffic to prevent
outbreaks of these threats without
creating unnecessary new signatures
while still protecting against Zero-Day
attacks
●Continuous Automatic
Signature Updates
» All IPS signatures are continuously
updated automatically and made
available through D-Link update servers
worldwide
» Keeps users’ IPS signature database as
current as possible at the outside of new
threats
The IPS service for D-Link NetDefend firewall adopts component-based signatures, which
are built to recognize and protect against all varieties of known and unknown attacks, and
which address all critical aspects of an attack or potential attack including payload, NOP
sled, infection, and exploits. In terms of signature coverage, the IPS database includes
attack information and data from a global attack sensor-grid and exploits collected from
public sites such as the National Vulnerability Database and Bugtrax.
IPS signatures are constantly created and optimized signatures via the Auto-Signature
Sensor System. Without overloading existing security appliances, IPS signatures ensure a
high ratio of detection accuracy and the lowest ratio of false positives.
NetDefend users need to register their firewall to receive IPS update service from the
NetDefend Center. The current status of all registered products will be presented, including
Model Names, MAC addresses, Serial Numbers, Registration dates, and IPS Service
Expiration dates.
The NetDefend Center includes a “NetDefend Live” service for users. NetDefend Live
is a platform for providing information about potential security breaches and associated
advisories. When D-Link Security Center discovers new exploits and releases new
signatures, associated security advisories will be simultaneously updated. This update
frequency is provided on an around-the-clock basis. The main purpose of NetDefend Live
is to help users know more about new signatures and vulnerabilities. MIS departments
can use NetDefend Live as reference to uproot threats and patch vulnerabilities within the
enterprise before they are exploited. With NetDefend firewalls as the first line of defense
and NetDefend Live as the second, D-Link helps customers to counteract emerging
network threats promptly, before they have an impact on business.
●Comprehensive IPS Signature
Database
» Protects system against network attacks
using over 1,800 signatures as well as
protocol anomaly inspection
●Complete IPS Signature
Advisory
» Complete IPS logs with vulnerability
ID numbers, severity levels, attack
descriptions, and recovery solutions
» Enable MIS personnel to know about
and respond quickly to network attacks
DFL-210-IPS-12
1 Year IPS Subscription for DFL-210 Firewall
DFL-800-IPS-12
1 Year IPS Subscription for DFL-800 Firewall
DFL-1600-IPS-12
1 Year IPS Subscription for DFL-1600 Firewall
DFL-2500-IPS-12
1 Year IPS Subscription for DFL-2500 Firewall
DFL-260-IPS-12
1 Year IPS Subscription for DFL-260 UTM Firewall
DFL-860-IPS-12
1 Year IPS Subscription for DFL-860 UTM Firewall
51
D-Link Product Guide 2008
Anti-Virus (AV) Subscriptions
Features & Benefits
● Up-to-date Protection
» D-Link firewall AV defenses rely on
Kaspersky Labs, the market leader in
AV signature creation to provide the
fastest response to the most dangerous
viruses, Trojans, worms, and spyware
programs.
●Optimized Performance
» Built-in extreme-performance AV
acceleration engine that allows D-Link’s
UTM firewalls to perform with a much
higher throughput than other anti-viruscapable UTM firewalls on the market.
●Streaming-based Pattern
Matching
» Streaming-basedscan engine
inspection of all payloads and matches
the signature packet-by-packet.
File-based AV protection will never
encounter file-size limitation since DLink firewalls do not need to store whole
files in memory for inspection purposes.
D-Link NetDefend UTM firewalls implement stream-based virus scanning technology
without first caching incoming files, thus increasing inspection performance and
easing network bottleneck nightmares while enabling powerful virus defense
capabilities.
D-Link’s firewalls use virus signatures from the known, respected antivirus company
Kaspersky Labs to provide users with prompt signature updates and reliable,
accurate antivirus signatures. Using a built-in extreme-performance AV acceleration
engine together with stream-based virus scanning technology, NetDefend UTM
firewalls block viruses and malware before they ever reach the network’s desktops
or mobile devices. NetDefend firewalls create a safer network environment for
companies of all sizes, from SMB to enterprises.
• Real-Time AntiVirus Gateway Inspection (AV)
• Professional Intrusion Prevention System (IPS)
• Automatic Signature Update
• Zero Day Attack Protection
• Web Surfing Management (WCF)
• Low Cost Licensing Using Per-Firewall Service Maintenance
●Fast Response Time
» All anti-virus signatures are updated
hourly and made available through
D-Link update servers worldwide, and
emergency signature releases protect
against the latest, most virulent virus
variations.
Anti-Virus
Web Content Filtering
Intrusion Prevention System
●Comprehensive Anti-Virus
Signature Database
» Proactive signature database protection
for each system against network worms,
Trojans, and spyware with over 2,000
signatures covering all Wild List threats
and thousands of well-known OS
exploits and application vulnerabilities.
User Authentication
High Performance
D-Link UTM Firewall
Traffic Shaping
Hardware Acceleration Technology
High Port Density
» Complete anti-virus logs with issue
dates, behavior and technical details
enable MIS personnel to know about
and then respond immediately to virus
threats and infections.
52
Availability
ZoneDefense Technology
●Complete Anti-Virus Signature
Advisory
D-Link Product Guide 2008
VPN
Load Balancing
DFL-260-AV-12
1 Year AV Subscription for DFL-260 UTM Firewall
DFL-860-AV-12
1 Year AV Subscription for DFL-860 UTM Firewall
Web Content Filtering (WCF)
Subscriptions
Features & Benefits
● Global Index Servers
» Global index servers maintain
databases of millions of URLs and
collect real-time website information
about latest sites in order to keep data
as current as possible.
» Multiple servers worldwide enhance
performance and maximize service
availability wherever a NetDefend
firewall is installed.
●Performance Optimized
» Multiple index servers to enhance
performance capacity and maximize
service availability.
» Categories of recently visited websites
are cached locally in each UTM
firewall to maximize performance for
subsequent requests.
NetDefend Web Content Filtering (WCF) service enforces access protection and
management policy in terms of Internet resource allocation for your organization.
It helps MIS monitor, manage, and control employee usage of and access to the Internet,
and puts management back in control, enabling a more business-orientated and cost
effective use of sometimes scarce Internet resources.
Organizations gain significant cost savings through:
1)A reduction in wasted staff time by reducing inappropriate web surfing.
2)Reduced Internet access costs and bandwidth savings by limiting and controlling nonbusiness related uses, thus improving network response.
3)Reducing legal exposure to workplace conflicts and liabilities (e.g. sexual harassment
cases or child pornography and the adverse publicity that such incidents can
generate).
4)Reduced costs in recovering from attacks as much less inappropriate content will even
be allowed to enter the network.
●Tight Integration with other
D-Link Security Gateway
Subsystems
» Allowsusers to define highly-granular
policies for allowing or disallowing where
and when access to certain types of
websites are permitted.
» Differentpolicies can be applied to any
combination of users, interfaces, and IP
networks.
●Static White and Black Lists
» Define websites that will be explicitly
allowed or blocked, independent of their
classification.
» 32 default classification groups in
NetDefend UTM firewalls to allow
network administrators to control
Internet usage.
●Active Content Handling
» Can strip potential malicious objects,
such as Java applets, JavaScripts/
VBScripts, ActiveX objects and cookies,
all of which are popular methods for
hacker attacks.
●Cost-Effective Web Content
Filtering
» Priced per firewall instead of per user,
so enterprise-level organizations do
not need to contemplate large TCO for
licensing in order to manage the surfing
privileges of all employees.
» One subscription can provide web
surfing control for an entire organization.
DFL-260-WCF-12
1 Year WCF Subscription for DFL-260 UTM Firewall
DFL-860-WCF-12
1 Year WCF Subscription for DFL-860 UTM Firewall
53
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
●10/100BASE-TX Ports Support
10/100Mbps Auto-Sensing Dual
Speeds
Unmanaged
Ethernet Switches
These unmanaged Ethernet switches are Layer 2 switching devices that provide plugand-play connection for homes and small businesses. They use the copper twistedpair wires as the network cable, and support full/half duplex operation for 10/100Mbps
speeds, full duplex operation for Gigabit uplink ports. These switches provide 802.3x
flow control for reliable data transfer, and auto MDI/MDIX to eliminate the need for
cross over cables and simplify installation.
●Use Inexpensive Copper
Twisted-Pair Wires as Network
Cable
●Support Full/Half Duplex
Operation
●Support 802.3x Flow Control
for Reliable Data Transfer
DES-1005D
DES-1016D
5-Port Ethernet Switch
16-Port Ethernet Switch
●Auto MDI/MDIX Plug-and-Play
Connection
●10/100/1000BASE-T Gigabit
Uplinks to Servers and
Network Backbone
● 5 10/100BASE-TX Ports
● 1Gbps Switch Capacity
● Powered through External Power
Adapter
DES-1008D
DES-1024D
8-Port Ethernet Switch
24-Port Ethernet Switch
● 8 10/100BASE-TX Ports
● 1.6Gbps Switch Capacity
● Powered through External Power
Adapter
54
● 24 10/100BASE-TX Ports
● 4.8Gbps Switch Capacity
● Metal Casing
● Internal Power Supply
● Mounting Kit for 19-Inch Standard
Equipment Racks
DES-1008F
DES-1016R+
8-Port Ethernet Switch
16-Port Ethernet Switch
● 8 10/100BASE-TX Ports
● 1 100BASE-FX Port (SC Connector)
Supporting 2 km Multi-Mode Fiber
● 1.6Gbps Switch Capacity
● Powered through External Power
Adapter
D-Link Product Guide 2008
● 16 10/100BASE-TX Ports
● 3.2Gbps Switch Capacity
● Metal Casing
● Internal Power Supply
● Mounting Kit for 19-Inch Standard
Equipment Racks
● 16 10/100BASE-TX Ports
● 1 Open Slot for Optional Fiber Ports
● 3.2Gbps Switch Capacity
● 19-Inch Rack-Mount Metal Casing
● Internal Power Supply
DES-1024R+
DES-1050G
24-Port Ethernet Switch
48-Port Ethernet Switch
● 24 10/100BASE-TX Ports
● 1 Open Slot for Optional Fiber Ports
● 4.8Gbps Switch Capacity
● 19-Inch Rack-Mount Metal Casing
● Internal Power Supply
● 48 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Ports
● 13.6Gbps Switch Capacity
● 19-Inch Rack-Mount Metal Casing
● Internal Power Supply
DES-102F
2-Port Fiber Ethernet Module
● Optional Module for DES-1016R+, DES1016R+ Switches
● 2 100BASE-FX Ports (SC Connectors)
● Supports 2 km Multi-Mode Fiber
● 0.4Gbps Switch Capacity
DES-1026G
24-Port Ethernet Switch
● 24 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 8.8Gbps Switch Capacity
● 19-Inch Rack-Mount Metal Casing
● Internal Power Supply
DES-1048
48-Port Ethernet Switch
● 48 10/100BASE-TX Ports
● 9.6Gbps Switch Capacity
● 19-Inch Rack-Mount Metal Casing
● Internal Power Supply
55
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
●10/100/1000BASE-T
Gigabit Ports Support
10/100/1000Mbps Auto-Sensing
Speeds
Unmanaged Gigabit
Switches
These unmanaged Gigabit switches are Layer 2 switching devices that provide
plug-and-play connection for homes and small businesses. Connecting to the
existing low-cost Cat. 5 copper twisted-pair wires as the transmission media, these
switches allow users to instantly upgrade desktop computers and servers to Gigabit
capability without having to install new, expensive fiber cables. They support full
duplex operation, provide 802.3x flow control for reliable data transfer, and auto
MDI/MDIX to eliminate the need for cross over cables and simplify installation.
●Decrease Energy Costs
through Reduction of Power
Consumption
●Automatically Power Down
Ports that Have No Link
DGS-1005D
5-Port Gigabit Switch
●Budget Power Output for
Different Ethernet Cable
Lengths
●Use Inexpensive Copper
Twisted-Pair Wires as Network
Cable
●Cost-Effective Alternative to
Fiber Cable
●Support Full Duplex Operation
●Support 802.3x Flow Control
for Reliable Data Transfer
● 5 10/100/1000BASE-T Ports
● 10Gbps Switch Capacity
● Powered through External Power
Adapter
DGS-1008D
DGS-1016D
8-Port Gigabit Switch
16-Port Gigabit Switch
●Auto MDI/MDIX Plug-and-Play
Connection
●Comply with Regulations
Regarding Use of Recyclable
Packaging and Hazardous
Materials
* Comply with Regulations Requiring Use of Energy
Efficient Power Adapters
● 10/100/1000BASE-T Ports
● 16Gbps Switch Capacity
● Powered through External Power
Adapter
DGS-1008TL
DGS-1024D
8-Port Gigabit Switch
24-Port Gigabit Switch
● 8 10/100/1000BASE-T Ports
● 16Gbps Switch Capacity
● Metal Casing
● Internal Power Supply
● Mounting Kit for Installation in 19-Inch
Equipment Racks
D-Link Product Guide 2008
56
● 16 10/100/1000BASE-T Ports
● 32Gbps Switch Capacity
● Metal Casing
● Internal Power Supply
● Mounting Kit for Installation in 19-Inch
Equipment Racks
● 24 10/100/1000BASE-T Ports
● 48Gbps Switch Capacity
● Metal Casing
● Internal Power Supply
● Mounting Kit for Installation in 19-Inch
Equipment Racks
LAN SwItcHES
Features & Benefits
● Port Mirroring for Traffic
Monitoring
● 802.1q VLAN, Port-based
VLAN for Enhanced Security/
network Performance
Light Management
Switches
These light management switches present a cost-effective solution for small workgroups
to set up a network with easy fine-tuning of performance and security. They provide
functions similar to the Web-Smart switches and important for bandwidth-intensive
applications such as priority queues and VLAN enable users to implement Quality of
Service (QoS) and security without having to go through complex network management.
In addition, these light management switches also provide Command Line Interfaces
(CLI) for experienced IT personnel to do quick settings.
● Port-based QoS
● Web-based Configuration and
SmartConsole
● MIB Support for SNMP
Management
● CLI, Telnet Support
DES-2108
8-Port L2 Ethernet Switch
● 8 10/100BASE-TX Ports
● 1.6Gbps Switch Capacity
57
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
● SmartConsole Utility
» Easy access to the switch from a local
PC.
» No need to type in any IP address or
subnet, all switches connected on the
network are displayed on the screen for
instant access.
●Web-Based Users’ Interface
» Allows switch access from any location
on the network or from a remote site,
using a web-browser.
» Allows extensive switch configuration
setting, which can be backed up for
duplication in other switches
●Built-in MIB
» Switches can be polled for information
about their status. Traps of abnormal
events can be sent out.
» Switches can be integrated with other
third-party devices for management in
an SNMP environment.
Web Smart Switches
The Web Smart switches are cost-effective LAN switches designed mainly to
enhance the performance and security of small business networks. They provide
many advanced features while maintaining the ease-of-use and basic cost
characteristics of the unmanaged switches. Businesses with limited IT resources
can deploy these switches to set up a manageable network without having to go
through complex SNMP management.
The Web Smart switches can be configured from any network computer through
an Internet browser, dispensing users of the need to set up consoles and connect
console cables. All switches are automatically discovered and displayed on a
network topology. From a network station, network administrators can monitor
network status and statistics and receive traps of system events or port errors.
The Web Smart switches with 802.3af Power over Ethernet (PoE) carry electric
power over the Ethernet cables. These switches are useful for surveillance and
wireless networks, where cameras and access points typically need to be located at
out-of-the-way locations, such as on the ceilings or rooftops, for maximum coverage.
By transmitting remote power through the standard network cabling, these PoE
switches provide a centralized power source for IP phones, cameras and wireless
AP, eliminating the need for individual power cabling to these devices.
●Complete Layer 2 Managed
Switch Functions
» Include IGMP snooping, port
mirroring, Spanning Tree and port
trunks, important functions enhance
performance and network resiliency.
TM
●VLAN Support
» 802.1Q VLAN Tagging enhances
network security and performance.
●Quality of Service Support
» 802.1p Priority Queues enables users
to run streaming multimedia and VoIP
applications.
●Network Access Security
» MAC address filters to screen access to
network.
» 802.1X port-based authentication
allows the network to be configured with
external RADIUS servers.
●Safeguard Engine
» Prevents ARP broadcast storm and
protocol-based attacks.
» ASIC is used to execute this prevention
task to offload switch’s CPU workload.
DES-1228
DES-1228P
24-Port Ethernet Switch
24-Port PoE Ethernet Switch
●Power Saving
» Automatically Power Down Ports that
Have No Link.
● 24 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Ports
● 12.8Gbps Switch Capacity
D-Link Product Guide 2008
58
● 24 10/100BASE-TX Ports
(All Ports with 802.3af PoE)
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Ports
● 12.8Gbps Switch Capacity
DES-1250G
DGS-1248T
48-Port Ethernet Switch
48-Port Gigabit Switch
● 48 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 13.6Gbps Switch Capacity
● 48 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 96Gbps Switch Capacity
DES-1252
48-Port Ethernet Switch
● 48 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Ports
● 17.6Gbps Switch Capacity
DGS-1216T
16-Port Gigabit Switch
● 16 10/100/1000BASE-T Ports
● 2 Combo SFP Slots
● 32Gbps Switch Capacity
DGS-1224T
24-Port Gigabit Switch
● 24 10/100/1000BASE-T Ports
● 2 Combo SFP Slots
● 48Gbps Switch Capacity
59
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
● Affordable Enterprise Features
» Include IP-MAC-port binding user
access screening, traffic segmentation,
802.1Q VLANs, 802.1X port-based/
MAC-based access control, external
RADIUS server authentication support.
» 802.1D Spanning Tree/802.1w Rapid
Spanning Tree, STP loopback detection
and broadcast storm control for network
resilience.
» 802.3ad Link Aggregation port trunks for
switch cascading and server link.
Entry-Level SNMP
Ethernet Switches
These managed Layer 2 Ethernet switches provide an entry-level SNMP
management solution for businesses. Workgroups looking for an advanced yet
affordable solution can deploy these switches to bring managed Ethernet connection
to their desktops.
These switches include more advanced software features than similar devices of
the same class. These features allow administrators to set up a secure network and
fine-tune the workgroup performance. For inter-workgroup connection, the switches
provide fiber uplinks to connect together groups of users in, for example, different
classrooms or departments spread across on a campus or between buildings.
Supporting D-Link’s Single IP Management, these switches can be easily configured
with any switches supporting D-Link’s Single IP Management, including the xStack
core switches, for integration with a more comprehensive network structured with
backbone and centralized high-speed servers.
●Complete Set of Access
Control List (ACL)
(for DES-3028, 3028P, 3052, 3052P only)
» Up to 256 profiles, 256 rules for
individual switch ports or range of ports.
» ACL rules can be based on switch port,
VLAN ID, 802.1p Priority Queues, MAC
address, IPv4 address, DSCP, protocol
type, TCP/UDP port, user-defined
packet content and time-based ACL.
●CPU Interface Filtering
» Filters out vicious packets in internal
network and prevents them from
reaching and overwhelming switch’s
CPU.
DES-3010G
DES-3010FL
8-Port L2 Ethernet Switch
8-Port L2 Ethernet Switch
●Quality of Service
» Multi-level packet classification based
on 802.1p Priority Queues, TOS, DSCP
and MAC addresses.
●Bandwidth Control
» Fine granularity to define limits down to
64Kbps segments for each port.
» When applied to control of broadcast
storms infected with virus, can limit
level of damage a virus attack can do to
network.
» IGMP snooping to control multicast
transmission.
» Port mirroring to facilitate diagnostics.
●DHCP Auto-Configuration
» Network administrators can pre-set
configurations and save them in TFTP
server.
» Individual switches can boot their
IP from server and load in pre-set
configurations.
● 8 10/100BASE-TX Ports
● 1 10/100/1000BASE-T Gigabit Port
● 1 SFP Slot for Fiber Gigabit
● 5.6Gbps Switch Capacity
● 8 10/100BASE-TX Ports
● 1 100BASE-FX Port (SC Connector,
15 km Single-Mode Fiber Transmission
Distance)
● 1 10/100/1000BASE-T Gigabit Port
● 3.8Gbps Switch Capacity
DES-3010F
DES-3016
8-Port L2 Ethernet Switch
16-Port L2 Ethernet Switch
●Single IP Management
» Multiple switch units can be managed
as a single object (a virtual stack), all
units identified by a single IP address.
» Network administrators can see Tree
View of members of the virtual stack
and network topology showing locations
of the units and their link information.
D-Link Product Guide 2008
60
● 8 10/100BASE-TX Ports
● 1 100BASE-FX Port (SC Connector,
2 km Multi-Mode Fiber Transmission
Distance)
● 1 10/100/1000BASE-T Gigabit Port
● 3.8Gbps Switch Capacity
● 16 10/100BASE-TX Ports
● 3.2Gbps Switch Capacity
DES-3018
DES-3052
DEM-301T
16-Port L2 Ethernet Switch
48-Port L2 Ethernet Switch
1-Port 10/100/1000Mbps Module
● 16 10/100BASE-TX Ports
● 2 Open Slots for Optional Fiber Ethernet
or Gigabit Uplinks
● 7.2Gbps Switch Capacity
● 48 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 17.6Gbps Switch Capacity
● 1 10/100/1000BASE-T Gigabit Port
● For use with DES-3018 & DES-3026
Switches
DES-3026
DES-3052P
DEM-301G
24-Port L2 Ethernet Switch
48-Port L2 PoE Ethernet Switch
1-Slot SFP Module
● 24 10/100BASE-TX Ports
● 2 Open Slots for Optional Fiber Ethernet
or Gigabit Uplinks
● 8.8Gbps Switch Capacity
● 48 802.3af PoE 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 17.6Gbps Switch Capacity
DES-3028
DEM-201F
24-Port L2 Ethernet Switch
1-Port 100BASE-FX Module
● 24 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 12.8Gbps Switch Capacity
● 1 100BASE-FX Port (SC Connector)
● 2 km Multi-Mode Fiber Transmission
Distance
● For use with DES-3018 & DES-3026
Switches
DES-3028P
DEM-201FL
24-Port L2 PoE Ethernet Switch
1-Port 100BASE-FX Module
● 24 802.3af PoE 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 12.8Gbps Switch Capacity
● 1 SFP Slot
● For use with DES-3018 & DES-3026
Switches
● 1 100BASE-FX Port (SC Connector)
● 15 km Single-Mode Fiber Transmission
Distance
● For use with DES-3018 & DES-3026
Switches
61
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
● Affordable Enterprise Features
» Include 802.1Q VLANs, 802.1X portbased access control, and external
RADIUS server authentication support.
» 802.1D Spanning Tree/802.1w
Rapid Spanning Tree/802.1s Multiple
Spanning Tree and broadcast/Multicast/
Unicast storm control for network
resilience.
» 802.3ad Link Aggregation port trunks for
switch cascading and server link.
» IGMP snooping to control multicast
transmission.
» Port mirroring to facilitate diagnostics.
Stand-Alone Managed Gigabit Switches
These stand-alone SNMP managed Gigabit switches are powerful and versatile
switches that provide Gigabit connection to the departmental desktops. These
switches eliminate network bottlenecks and give network administrators the
capability to fine-tune performance and set up security. They support standards
based network management protocols (SNMP/RMON/ BOOTP1/Telnet/Web) and
can be easily integrated with most third-party network management products.
These switches provide advanced features to facilitate the deployment of
applications across a departmental network, such as VoIP, streaming media, and
multicast content delivery (IP video, software deployment etc). With high Gigabit
port densities and multiple SFP support, these switches can easily adapt to changes
in users’ media requirements without the need to perform expensive upgrades.
●Quality of Service
» Packet prioritization based on 802.1p
Priority Queues for smooth traffic for
voice and multimedia applications.
» Bandwidth control
●Redundant Power Supply
Support
» Switch can be connected to optional
external power supply for redundant
power backup.
D-Link Product Guide 2008
62
DGS-3024
DGS-3048
24-Port L2 Gigabit Switch
48-Port L2 Gigabit Switch
● 24 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 48Gbps Switch Capacity
● 48 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 96Gbps Switch Capacity
LAN SwItcHES
Features & Benefits
● Fault Tolerant Ring Stacking
» Any broken link between two units in a stack
will not affect inter-switch traffic as the traffic is
redirected toward the opposite direction.
● High-Speed Physical Stacking
» Two stacking ports on the back of each switch,
each port providing up to 5Gbps (10Gbps in
full-duplex mode) data transfer rate.
» Shared 20Gbps Ring stacking topology, ample
bandwidth for intra-stack traffic traveling
through the stacking cables.
● Scalable Expansion
» Up to 6 switch units per stack, up to 288 Gigabit
ports per stack
» Switch units can be gradually added as network
need grows.
» No interruption to network service or current
configuration as switch units are added to the
stack.
● Affordable Enterprise Features
» Include private VLAN, 802.1Q VLAN, GVRP,
802.1X port-based/MAC-based access
control.
» 802.1D Spanning Tree/802.1w Rapid
Spanning Tree/802.1s Multiple Spanning
Tree, loopback detection and broadcast storm
control for network resilience.
» 802.3ad Link Aggregation port trunks for stack
cascading and server link.
● Complete Set of Access Control
List (ACL)
» Up to 15 profiles, max 240 rules shared by all
profiles.
» ACL rules can be based on switch port, VLAN
ID, 802.1p Priority Queues, MAC address, IP
address, DSCP, protocol type, TCP/UDP port
and time-based ACL.
Entry-Level Gigabit Stack
These managed Layer 2 Gigabit switches provide an entry-level SNMP management
solution for businesses. Workgroups looking for a flexible, advanced yet affordable solution
can deploy these switches to bring managed Gigabit connection to their desktops.
These switches provide high Gigabit port densities, SFP fiber options and physical
stacking. The stacking feature offers scalable expansion: switches can be stacked up
to 6 units or 288 Gigabit ports per stack on a per-need basis to accommodate network
growth. The two stacking ports on the back of each switch provide 5Gbps per-port
bandwidth (10Gbps in full-duplex mode) for physical Ring stacking in a fault-tolerant
topology. Expansion beyond a single stack is possible using Gigabit port trunks between
stacks, or from stack to network backbone and server paths.
These switches include more advanced software features than similar devices of
the same class, allowing administrators to set up a secure network and fine-tune the
workgroup performance. These features include a complete set of Access Control List,
multi-level packet classification for Quality of Service and bandwidth management.
DGS-3100-24
24-Port L2 Gigabit Switch
● 24 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 2 Stacking Ports
● 68Gbps Switch Capacity
DGS-3100-24P
DGS-3100-48
24-Port L2 PoE Gigabit Switch
48-Port L2 Gigabit Switch
● Quality of Service
» Multi-level packet classification based on
802.1p Priority Queues, TOS, DSCP, IP/MAC
addresses and TCP/UDP port number.
● Bandwidth Control
» Fine granularity to define limits down to
64Kbps segments for each port.
» Port and Flow-based bandwidth control.
● Multicasting
» IGMP and MLD snooping to control multicast
transmission.
»Port mirroring to facilitate diagnostics.
● Safeguard Engine
● 24 802.3af PoE 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 2 Stacking Ports
● 68Gbps Switch Capacity
DGS-3100-24TG
DGS-3100-48P
24-Port L2 Gigabit Switch
48-Port L2 PoE Gigabit Switch
» Prevents ARP broadcast storm and protocolbased worm/virus attacks.
» ASIC is used to execute this prevention task to
offload switch’s CPU workload.
● Pre-set Configuration File
» Administrators can pre-set configurations
and save them as configuration files in TFTP
server for download to switches.
● DHCP Auto-Configuration
● 48 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 2 Stacking Ports
● 116Gbps Switch Capacity
» Administrators can pre-set configuration in
DHCP server for application in switches when
they fetch their IP from this server.
● 8 10/100/1000BASE-T Ports
● 16 SFP Slots
● 2 Stacking Ports
● 68Gbps Switch Capacity
● 48 802.3af PoE 10/100/1000BASE-T
Ports
● 4 Combo SFP Slots
● 2 Stacking Ports
● 116Gbps Switch Capacity
63
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
● Security Switch for
Enterprises and Remote
Branch Offices
» Integrated malicious traffic and
performance degradation prevention
functions.
» Quiet fan less ventilation suitable for
desktop installation. (DGS-3200-10)
●Full L2 Features
» Up to 4K of VLAN groups.
» J umbo Frame support up to 10,240
bytes.
» MLD snooping v1/v2.
» Loopback detection ensures resilience
while preventing network performance
from degradation.
●Comprehensive Network
Security
» 802.1x authentication, Web-Based
Access Control (WAC), MAC-Based
Access Control (MAC), IP-MAC-Port
Binding.
» D-Link Safeguard engine prevents ARP
broadcast storm and protocol-based
attacks.
» SSH/SSL.
» Microsoft NAP and D-Link ZoneDefense
support.
Security Gigabit
Switches
The Security Gigabit Switches offer a new generation of intelligence and defense
displayed through the delivery of its high performance, flexible expansion, and robust
security. They execute firm network security and come with ACL functionalities,
which secure the internal IT network against external viruses from invading the
LAN. Built on fan-less technology, these compact switches produce and emit less
heat and noise than the standard switches, and are ideal for office environments or
circumstances that require undisturbed silence.
These switches offer a complete list of endpoint security features to add confidence
and assurance towards your network. They come with user-based identity control by
implementing host-based 802.1x authentication/authorization, along with clientless
Web-based Access Control (WAC) and MAC-based Access Control (MAC) for easy
deployment. ACL user-defined functionality secures the internal IT network against
viruses and worms from invading the LAN to provide better security. IP-MAC-Port
Binding prevents ARP spoofing and man-in-middle attacks by disabling users from
manually configuring their own IP or MAC address, and allowing administrators to
assure that the IP information on the Syslog server or firewall log is correct. Other
security features like port security and traffic segmentation provide granular control
to business environments, allowing administrators to enhance network security.
D-Link’s joint security provides admission control and real-time defense through
Microsoft’s NAP (Network Access Protection) and D-Link’s ZoneDefense
respectively. D-Link’s built-in ZoneDefense technology allows businesses to
integrate their switch with D-Link’s NetDefend firewall to implement full coverage
and a proactive security architecture.
●Quality of Service
» 8 priority queues supporting 802.1p and
multi-layer CoS.
●Traffic Monitoring/Bandwidth
Control
» Traffic segmentation, per-flow bandwidth
control.
» Broadcast storm control.
» Port Mirroring.
●IPv6 Support
» Can interoperate with IPv6
implementations.
DGS-3200-10
DGS-3200-16
10-Port L2 Security Gigabit Switch
16-Port L2 Security Gigabit Switch
● 8 10/100/1000BASE-T Ports
● 2 Combo 10/100/1000BASE-T/SFP
Ports
● 20Gbps Switch Capacity
D-Link Product Guide 2008
64
● 14 10/100/1000BASE-T Ports
● 2 Combo 10/100/1000BASE-T/SFP
Ports
● 32Gbps Switch Capacity
LAN SwItcHES
Features & Benefits
● Full Layer 2 Functions
» 802.1Q VLAN, LACP Port Trunk, STP/
RSTP/MSTP.
●Enhanced Layer 2+ Functions
(DES-3528/52 & DES-3800 Series)
» Layer 3 Routing: up to 128 Static
Routes (IPv4/v6).
» IPv6 tunneling.
●Layer 3 Protocol Support
» RIP, OSPF, VRRP (DES-3800 series only)
●Multicast Support
» IGMP Snooping.
» IGMP v3, DVMRP, PIM-DM/SM (DES3800 series).
» MLD Snooping.
●Quality of Service (QoS)
» 802.1p Priority Queues, L2/L3/L4 MultiLayer CoS.
Access Layer
Ethernet Switches
These Ethernet switches comprise the departmental access layer that can be seamlessly
integrated with the core of a network. Ideal for deployment at the network edge closer to
workstations for maximum scalability, these switches provide desktop users secure and
smooth access to a network and its servers while allowing them to be easily integrated
with other departmental workgroups via the core network backbone.
The access layer switches deliver performance, flexible expansion, robust security, and
multi-layer Quality of Service (QoS). Supporting D-Link’s Single IP Management, these
switches can be easily stacked and configured with any switches supporting D-Link’s
Single IP Management, including the xStack core switches, to form part of a multilevel network structured with backbone and centralized high-speed servers. Without
any stacking cable, cable distance barrier and physical stacking method limitations, an
access layer stack can comprise units that are located anywhere on the same network
domain, eliminating the possibility of any single point of failure.
The access layer switches can be Layer 2 or Layer 3 switches. The Layer 2 switches
provide packet switching for departmental users while leaving higher level packet routing
to the core switches. The Layer 3 switches blend L2 packet switching with dynamic L3
IP routing to relieve the core switches of some workload and remove unnecessary traffic
from the network backbone and the server paths.
™
●Traffic Management
» Traffic Segmentation, Granular Bandwidth
Control, Broadcast Storm Control.
» Jumbo Frame.
●Security
» Port Security, L2/L3/L4 ACL, 802.1x
Port/MAC-based Access Control, IPMAC-Port Binding, RADIUS/TACACS+
Authentication, SSH, SSL, 802.1x Guest
VLAN.
» MAC-based/Web-based Access Control
(MAC/WAC).
» Voice VLAN. (DES-3528/52 Series)
» Double VLAN (DES-3528/52 & DES3800 series).
DES-3526
DES-3528
24-Port L2 Ethernet Switch
24-Port L2+ Ethernet Switch
●Safeguard Engine
» Prevents ARP broadcast storm and
protocol-based attacks.
» ASIC is used to execute this prevention
task to offload switch’s CPU workload.
●ZoneDefense
» Operates with D-Link NetDefend firewalls,
automatically quarantines infected
workstations and prevent them from
flooding the network with malicious traffic.
●Administration
» Single IP Management, SNMP v1/v2c/
v3, Web Management, Port Mirroring,
CLI, Telnet, TFTP, Dual Image, BOOTP/
DHCP relay, DHCP Relay Option 82,
DHCP Auto Configuration, System log.
● 24 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 8.8Gbps Switch Capacity
● 24 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 2 Stacking Ports *
● 12.8Gbps Switch Capacity
DES-3526DC
DES-3528DC
24-Port L2 Ethernet Switch
24-Port L2+ Ethernet Switch
●Physical Ring Stacking
» Cross-Stack Trunking/Mirroring (DES3528/52 Series).
●Redundant Power Supply
Support
» Optional external power supply for
redundant power backup.
●D-View SNMP Management
» Management software module provided
for management under D-View.
● 24 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 8.8Gbps Switch Capacity
● Internal DC Power Supply
● 24 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 2 Stacking Ports *
● 12.8Gbps Switch Capacity
● Internal DC Power Supply
65
D-Link Product Guide 2008
LAN SwItcHES
Access Layer
Ethernet Switches
DES-3528P
DES-3552
DES-3828DC
24-Port L2+ PoE Ethernet Switch
48-Port L2+ Ethernet Switch
24-Port L3 Ethernet Switch
● 24 802.3af PoE 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 2 Stacking Ports *
● 12.8Gbps Switch Capacity
● 48 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 2 Stacking Ports *
● 17.6Gbps Switch Capacity
● 24 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 12.8Gbps Switch Capacity
● Internal DC Power Supply
DES-3528G
DES-3552P
DES-3828P
24-Port L2+ Ethernet Switch
48-Port L2+ PoE Ethernet Switch
24-Port L3 PoE Ethernet Switch
● 24 10/100BASE-TX Ports
● 4 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● SFP also Supports 100BASE-FX
Ethernet Fiber
● 2 Stacking Ports *
● 12.8Gbps Switch Capacity
● 48 802.3af PoE 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 2 Stacking Ports *
● 17.6Gbps Switch Capacity
● 24 802.3af PoE 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 12.8Gbps Switch Capacity
DES-3550
DES-3828
DES-3852
48-Port L2 Ethernet Switch
24-Port L3 Ethernet Switch
48-Port L3 Ethernet Switch
● 48 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 13.6Gbps Switch Capacity
● 24 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 12.8Gbps Switch Capacity
● 48 10/100BASE-TX Ports
● 2 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T/SFP
Gigabit Uplinks
● 17.6Gbps Switch Capacity
* Stacking ports can also be used as 10/100/1000BASE-T Gigabit uplinks; total Gigabit uplinks remain as 4.
D-Link Product Guide 2008
66
LAN SwItcHES
Features & Benefits
● Fault Tolerant Ring Stacking
» Any broken link between two units in a stack
will not affect inter-switch traffic, as intrastack traffic is redirected toward the opposite
direction.
●High-Speed Physical Stacking
» Open slots for 10-Gigabit modules to use as
stacking ports. Each stacking port provides
20Gbps full-duplex operation.
» Shared 40Gbps full-duplex per stack, ample
bandwidth for intra-stack traffic.
●Scalable Expansion
» Up to 12 units, 576 Gigabit ports per stack.
» Switch units and optional 10-Gigabit modules
can be gradually added as network need grows.
●Trunking & Mirroring Across
Stack
Access Layer Gigabit
Stack
These Gigabit switches comprise the enhanced Layer 2+ access layer stack designed
for departmental Gigabit connection. Ideal for deployment at the network edge closer to
workstations for maximum scalability, these switches can be seamlessly integrated with
Layer 3 core switches through the optional 10-Gigabit uplinks to form part of a multi-layer
network structured with high-speed backbone and centralized servers.
Optional 10-Gigabit modules can be installed in the open slots to create a physical stack.
Up to 12 units can be stacked together to create 576 Gigabit ports. Users can install
one or two 10-Gigabit ports as stacking interfaces, depending on whether the linear or
fault-tolerant Ring stacking is implemented. Each stacking interface provides 20Gbps
full duplex transmission on the cost-effective coaxial cable. Modules with single 10Gigabit XFP can also be installed in any of the open slots for uplink to servers or a fiber
backbone.
Alternatively, an enhanced Layer 2+ access layer Gigabit switch can operate as a standalone device. Embedded with Single IP Management capability, a stand-alone switch
can form part of a virtual stack, where intra-stack traffic flows through the usual network
wires, doing away with the costly stacking cables. Without stacking cables, cable distance
barriers and physical stacking limitations, a virtual stack can comprise units that are
located anywhere on the network to minimize the impact of any single point of failure.
» Allows trunking and mirroring to span multiple
switch units in the stack.
™
●10-Gigabit Uplinks
» Open slots for optional 10-Gigabit modules for
uplinks to network servers and backbone.
●Full Layer 2 Functions
» 802.1Q VLAN, Double VLAN, LACP Port
Trunking, STP/RSTP/MSTP.
●Enhanced Layer 2+ Functions
» Layer 3 Routing: up to 128 Static Routes
(IPv4/v6).
» IPv6 tunneling.
●Multicast Support
» 802.1p Priority Queues (8 queues), L2/L3/L4
Multi-Layer CoS.
●Traffic Management
» Traffic Segmentation, Bandwidth Control
Down to 64Kbps, Broadcast Storm Control,
Jumbo Frame.
●Security
» IP-MAC-Port Binding Port Security, L2/L3/L4
ACL, RADIUS/TACACS+ Authentication, SSH,
SSL, 802.1X Port/MAC-based access control,
MAC-based/Web-based Access Control
(MAC/WAC), CPU Interface Filtering.
●Safeguard Engine
» IGMP Snooping, MLD Snooping.
●Quality of Service (QoS)
●ZoneDefense
» Prevents ARP broadcast storm and protocolbased attacks.
» ASIC is used to execute this prevention task to
offload switch’s CPU workload.
» Operates with D-Link NetDefend firewalls,
automatically quarantines infected
workstations and prevent them from flooding
the network with malicious traffic.
DGS-3426
24-Port L2+ Gigabit Switch
●IPv6 Ready Logo Phase 1
» Core functions such as IPv6 Specification,
Neighbor Discovery, Address Autoconfiguration and Internet Control Message
Protocol (ICMPv6) are included.
» Can interoperate with other IPv6
implementations.
●Administration
» Single IP Management, SNMP v1/v2c/
v3, Web Management, Port Mirroring,
CLI, Telnet, TFTP, Dual Image, BOOTP/
DHCP relay, DHCP Relay Option 82,
DHCP Auto Configuration, System log.
● 24 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 2 Open Slots for 10-Gigabit Uplink
Modules
● 88Gbps Switching Capacity
DGS-3426P
24-Port L2+ Gigabit Switch
●Redundant Power Supply
Support
» Optional external power supply for
redundant power backup.
●D-View SNMP Management
» Management software module provided
for management under D-View.
● 24 802.3af PoE10/100/1000BASE-T
Ports
● 4 Combo SFP Slots
● 2 Open Slots for 10-Gigabit Uplink
Modules
● 88Gbps Switching Capacity
67
D-Link Product Guide 2008
LAN SwItcHES
DGS-3427
DEM-410CX
24-Port L2+ Gigabit Switch
1-Port 10-Gigabit Module
● 24 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 3 Open Slots for 10-Gigabit Uplink
Modules
● 108Gbps Switching Capacity
● 1 CX4 Port
● For Use with DGS-3426, DGS-3426P,
DGS-3427 & DGS-3450 Switches
DGS-3450
DEM-CB300CX
48-Port L2+ Gigabit Switch
Twin-Axial Copper Cable
● 48 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 2 Open Slots for 10-Gigabit Uplink
Modules
● 136Gbps Switching Capacity
● 3 Meters’ Cable Length
● For Use with DEM-410CX Module
DEM-410X
1-Port 10-Gigabit Module
● 1 XFP Slot
● For Use with DGS-3426, DGS-3426P,
DGS-3427 & DGS-3450 Switches
D-Link Product Guide 2008
Access Layer
Gigabit Stack
68
LAN SwItcHES
Features & Benefits
● Fault Tolerant Ring Stacking
» No interruption to service of entire stack
if any link between two units is broken,
as stack traffic is redirected toward
opposite direction.
●High-Speed Physical Stacking
» Each stacking port provides 20Gbps
full-duplex operation.
» Shared 40Gbps full-duplex band width
per stack.
●Scalable Expansion
» Up to 12 units, 576 Gigabit ports per
stack.
●Trunking & Mirroring Across
Stack
» Allows trunking and mirroring to span
multiple switch units in the stack.
●10-Gigabit Uplinks
» Open slots for optional 10-Gigabit
modules for uplinks to network servers
and backbone.
●Complete Layer 2 Functions
Core Gigabit Stack
These switches comprise the network core devices that combine performance with
scalable flexibility and versatile management. They offer physical Ring stacking, fault
tolerance, optional 10-Gigabit uplinks, Layer 3 packet routing and robust security/QoS
-- all the features are typically found in the more expensive chassis-based solutions.
Optional 10-Gigabit modules can be installed in the open slots to create a physical stack.
Up to 12 units can be stacked together to create 576 Gigabit ports. Users can install
one or two 10-Gigabit ports as stacking interfaces, depending on whether the linear or
fault-tolerant Ring stacking is implemented. Each stacking interface provides 20Gbps
full duplex transmission on the cost-effective coaxial cable. Modules with single 10Gigabit XFP can also be installed in any of the open slots for uplink to servers or a fiber
backbone.
Alternatively, a core Gigabit switch can operate as a stand-alone device. Embedded with
Single IP Management capability, a stand-alone switch can form part of a virtual stack,
where intra-stack traffic flows through the usual network wires, doing away with the costly
stacking cables. Without stacking cables, cable distance barriers and physical stacking
limitations, a virtual stack can comprise units that are located anywhere on the network
to minimize the impact of any single point of failure.
These switches implement the most advanced set of multi-layer L2/L3/L4 features in
the xStack series to ensure that critical network services like VoIP, ERP, Intranet and
video conference are securely and well served. Powerful management tools including
SNMP, RMON, sFlow and web-based interfaces allow administrators to perform most
management and configuration tasks effectively and with ease.
» 802.1Q VLAN, Double VLAN, LACP
Trunking, STP/RSTP/MSTP.
™
●Layer 3 Functions
» RIP v1/v2/ng, OSPF, VRRP.
»U
p to 256 IPv4 Static Routes, 128 IPv6
Static Routes.
●Multicast Support
» IGMP Snooping, MLD Snooping, IGMP
v1/v2/v3, DVMRP, PIM-DM/SM.
●Quality of Service
» 802.1p, 8 priority queues, L2/L3/L4 MultiLayer CoS.
●Traffic Management
» Traffic Segmentation, Bandwidth Control
Down to 64Kbps, Broadcast Storm
Control, Jumbo Frame.
●Security
» IP-MAC-Port Binding Port Security,
L2/L3/L4 ACL, RADIUS/TACACS+
Authentication, SSH/SSL, 802.1X
Port/MAC-based access control, MACbased/Web-based Access Control
(MAC/WAC), CPU Interface Filtering.
●Safeguard Engine
» Prevents ARP broadcast storm and
protocol-based attacks.
» ASIC is used to execute this prevention
task to offload switch’s CPU workloa
●ZoneDefense
» Operates with D-Link NetDefend
firewalls, automatically quarantines
infected workstations and prevent them
from flooding the network with malicious
traffic.
● IPv6 Ready Logo Phase 1
» Core functions such as IPv6
Specification, Neighbor Discovery,
Address Auto-configuration and Internet
Control Message Protocol (ICMPv6) are
included.
» Caninteroperate with other IPv6
implementations.
DGS-3612
●Administration
12-Port L3 Gigabit Switch
» Single IP Management, SNMP v1/v2c/
v3, sFlow, Web Management, Port
Mirroring, CLI, Telnet, TFTP, Flash File
System, BOOTP/DHCP relay, DHCP
Auto-Configuration, System Log.
●Redundant Power Supply
Support
» Optionalexternal power supply for
redundant power backup.
●D-View SNMP Management
» Management software module provided
for management under D-View.
● 12 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 24Gbps Switching Capacity
69
D-Link Product Guide 2008
LAN SwItcHES
Core Gigabit Stack
DGS-3612G
DGS-3650
DEM-CB300CX
12-Port L3 Gigabit Switch
48-Port L3 Gigabit Switch
Twin-Axial Copper Cable
● 12 SFP Slots
● 4 Combo 10/100/1000BASE-T Ports
● 24Gbps Switching Capacity
● 48 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 2 Open Slots for 10-Gigabit Uplink
Modules
● 136Gbps Switching Capacity
DGS-3627
DEM-410X
24-Port L3 Gigabit Switch
1-Port 10-Gigabit Module
● 24 10/100/1000BASE-T Ports
● 4 Combo SFP Slots
● 3 Open Slots for 10-Gigabit Uplink
Modules
● 108Gbps Switching Capacity
● 1 XFP Slot
● For use with DGS-3627, DGS-3627G,
DGS-3650 Switches
DGS-3627G
DEM-410CX
24-Port L3 Gigabit Switch
1-Port 10-Gigabit Module
● 24 SFP Slots
● 4 Combo 10/100/1000BASE-T Ports
● 3 Open Slots for 10-Gigabit Uplink
Modules
● 108Gbps Switching Capacity
D-Link Product Guide 2008
70
● 1 CX4 Port
● For use with DGS-3627, DGS-3627G,
DGS-3650 Switches
● 3 Meters’ Cable Length
● For use with DEM-410CX Module
LAN SwItcHES
Core Gigabit Stack
Deploying xStack Switches in an Enterprise Network
Deploying xStack Switches in a Carrier Network
71
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
● 9-Slot Chassis
» 1 CPU & Management module.
» 8 card Slots for user-selectable port modules.
●High Port Density
» Users can select port modules to install
maximum: 16 10-Gigabit slots for fiber SR,
LR transceivers; 96 RJ-45, SX or LX Gigabit
ports; 96 100BASE-FX fiber Ethernet ports; or
128 10/100Mbps Ethernet ports.
●Layer 2 Functions
» 802.1Q VLAN, LACP Trunking, STP/RSTP/
MSTP.
●Layer 3 Routing/Redundancy
» RIP, OSPF, VRRP.
●Multicast Support
» IGMP Snooping, IGMP v3, DVMRP, PIM-DM/
SM.
Core Chassis
These chassis-based switches provide configuration flexibility and performance
necessary for deployment of a cost-effective enterprise, backbone and campus
network. They provide a high density of Gigabit ports, 10-Gigabit support, high
switch fabric capacity, fault tolerance, Quality of Service (QoS), and network security
critical for enterprise applications.
Users can configure each chassis with up to 96 Gigabit ports, 16 10-Gigabit
ports, 192 10/100Mbps Ethernet ports, 96 100Base-FX fiber Ethernet ports, or a
combination of these. With 8 line card slots and a wide range of selectable port
types, users can easily add and change modules to suit their requirements.
Using standards-based routing, the chassis provides instant support for Windows,
Unix and Internet environments. Built-in wire-speed non-blocking switch fabric
provides hardware-based packet filtering/forwarding.
The switch implements an advanced set of multi-layer L2/L3/L4 features to ensure
that critical network services like VoIP, ERP, Intranet and video conference are
securely and well served. Powerful management tools including SNMP, RMON
and web-based interfaces allow administrators to perform most management and
configuration tasks effectively and with ease.
™
●Quality of Service
» 802.1p Priority Queues (8 queues), L2/L3/L4
Multi-Layer CoS.
●Traffic Management
» Traffic Segmentation, Bandwidth Control down
to 1Mbps, Broadcast Storm Control, Jumbo
Frame.
●Security
» Port Security, L2/L3/L4 ACL, RADIUS/
TACACS+ Authentication, SSH/SSL, 802.1X
Port/MAC-based access control, CPU
Interface Filtering..
DES-6500
DES-6504
9-Slot L3 Chassis Switch
12-Port Fiber Ethernet Module
●Safeguard Engine
» Prevents ARP broadcast storm.
» ASIC is used to execute this prevention task to
offload switch’s CPU workload.
●Administration
» Single IP Management, SNMP v1/v2c/v3,
Web Management, Port Mirroring, CLI, Telnet,
TFTP, Dual Image, BOOTP/DHCP relay,
System Log
● 12 100BASE-FX Ports (SFF (LC)
Connectors)
● Supports up to 2 km Multi-Mode Fiber
Cable Length
●Redundant Power Supply
Support
» Optional power supply installable in chassis
for redundant power backup.
●D-View SNMP Management
» Management software module provided for
management under D-View.
D-Link Product Guide 2008
72
● CPU/Management Module Installed
in Slot 1
● 8 Open Slots for Port Modules
● 160Gbps Switch Capacity
● 2 Slots for 2 DES-6511 Redundant
Power Supply Units (1 DES-6511
Power Supply Unit Pre-Installed in
Chassis)
● Up to 96 Gigabit Ports
● Up to 16 10-Gigabit Ports
● Up to 192 10/100BASE-TX Ports
● Up to 96 100BASE-FX Ports
DES-6508
16-Port 10/100Mbps Module
● 16 10/100BASE-TX Ports (RJ-45
Connectors)
DES-6510
DES-6507
24-Port 10/100Mbps Module
12-Port Combo Gigabit Module
● 24 10/100BASE-TX Ports (RJ-21
Connectors)
● 10 10/100/1000BASE-T Gigabit Ports
● 2 Combo 10/100/1000BASE-T or SFP
DES-6509
12-Slot SFP Module
DES-6506
24-Port Patch Panel Module
● 12 SFP Slots
DES-6512
● Patch Panel for 24 RJ-45 Ports
● For Use with DES-6510 Port Module
DES-6505
8-Port Fiber Gigabit Module
2-Port 10-Gigabit Module
● 2 XFP Slots
DES-6511
Redundant Power Supply
● 8 1000BASE-SX Gigabit Ports (SC
Connector)
● Supports up to 550 m Multi-Mode Fiber
Cable Length
● Input: 90 to 264 VAC, 47 to 63 Hz
● Output: 3.4VDC, 4 to 80A; 12VDC, 0.1
to 2A
● Up to 2 of this Power Supply Unit can be
installed in a DES-6500 Chassis
73
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
● Deployable as Core or Edge
Switch
» Core switch provides numerous high-speed
fiber backbones for a campus and central
office network.
» Aggregation switch can provide high port
density connections to workstations in an
office environment, or to subscribers’ CPE
in a densely populated Ethernet metro area
network.
●Distribution Switching Method
» Each line card can perform L2/3/4 on-board
packet switching without relying on the control
card.
» The switch synchronizes the switching and
routing information between the control card
and the line cards to map out the fastest data
transfer path
●Dual Redundant Backup/LoadSharing Control Modules
» Each control module is equipped with its own
switch fabric hardware and management agent.
» Two modules can perform redundant backup
and sharing of network traffic load and
management tasks.
●802.1X Access Control-based
Accounting
» Enables period accounting, multiple
accounting and statistics and RADIUS server
support.
» Enables carriers to implement complete
Ethernet-based Internet services to home
customers..
These chassis-based switches offer end-to-end connectivity and granular application
control for enterprise campus and metropolitan area networks (MAN). They are
ideal for deployment in environments where uninterrupted running of network
applications and a high level of performance, security and control are required.
Featuring a flexible modular architecture and industry standard compliance, these
switches provide scalable expansion and a high level of investment protection for
businesses and telecom carriers to deploy Gigabit and 10-Gigabit packet switching
and routing for office networking and Ethernet-based Internet services to the
homes.
These switches feature minimum or zero network downtime, robust security and
real-time running of bandwidth-intensive applications. Equipped with high-speed
switch fabrics, redundant backup/load sharing capability and advanced software
functions including complete IPv6 support, these switches provide the performance,
high availability and future-proof architecture suitable for applications of not just
today but well into the future.
These switches provide not only network access security but also protection against
virus and worm attacks. Access security is provided through comprehensive policybased ACL, port security, IP-MAC-Port binding features and Defeat IP Scan, while
attacks hidden behind control protocols are thwarted to prevent the switch’s CPU
from being overwhelmed with unnecessary tasks which can cause degradation to
a network’s performance. These switches extend security to network management
via such functions as SSH v2 and SNMP v3 with authentication and encryption of
management traffic.
●Advanced Service Engine
(ASE)
●Rate Limiting Control
» Bandwidth restriction applicable to categories
of subscribers.
» Useful for carriers offering services to home
users in a metropolitan Ethernet network.
●High Resiliency Provided
through Software Features
» Basic functions include: 802.1D/w/s Spanning
Tree, 802.3ad Link Aggregation/Backup
Redundancy.
» Advanced functions include Rapid Ether Ring
Protection (RERP) and VRRP support.
●Robust Security
» Advanced L2/L3/L4 ACL.
» IP-MAC-Port Binding.
» Virus/Malicious Traffic Flooding Prevention.
» CPU Protection Policy (CPP) prevents
degradation of switch’s performance.
●Bandwidth Management
D-Link Product Guide 2008
74
» Enables support of advanced Multi-Protocol
Label Switching (MPLS), NAT or IPFIX
functions.
» Enables enterprises and service providers to
build next-generation intelligent networks that
deliver a wide variety of advanced, valueadded services over a single infrastructure.
●Multi-Protocol Label Switching
(MPLS)
» MPLS is independent of access
technologies.
» Can be integrated seamlessly over
any existing infrastructure, such as
IP, Frame Relay, ATM, or Ethernet.
Subscribers’ differing access links
can be aggregated on an MPLS
edge without changing their current
environments.
●Layer 3 IP Packet Routing with
Network Address Translation
(NAT)
» Rate Limiting for end-users/subscribers’ CPE.
» Granular Bandwidth Control down to 64Kbits
for Ingress and Egress traffic.
Core Chassis
» Dynamic IP address generation for users on
a campus LAN or Internet subscribers on an
Ethernet metro area network services.
» Allows the switch to be deployed for endto-end services without incurring the cost of
attaching external routers to packet switching
devices.
●IPv6 Ready
» Supports IPv6 manageability, routing
and multicasting.
●Complete Management
Support
» Telnet/CLI/SNMP v1, v2c, v3 support.
» RMON monitoring.
» System/alert information, interface
management.
» 802.1v Protocol VLAN, Super VLAN,
Private VLAN, Double VLAN.
» L3 protocol-based policies.
» Port mirroring/traffic redirection.
DES-7206
7200-CM2
7200-ASE3
6-Slot Chassis
Control Module
Advanced Service Engine
● Advanced Service Engine for MPLS
Support
● 192Gbps Switch Capacity
● For Use with 10-Slot Chassis
7200-CM3
● 2 Slots for Dual Control Modules
● 4 Slots for User-Selectable Port Modules
● 2 Slots for Redundant Backup Power
Supplies
● 1 Slot for Fan Module
● Includes 7200-1200AC Power Supply
and 7206-Fan Module
DES-7210
10-Slot Chassis
Control Module
7200-ASE4
Advanced Service Engine
● Advanced Service Engine Supports up to
192K Hardware Routing Entries
7200-24
● 96Gbps Switch Capacity
● Supports Advanced Service Engine (ASE)
● For Use with 6-Slot Chassis
24-Port Gigabit Module
7200-CM4
Control Module
● 12 10/100/1000BASE-TX Ports
● 12 Combo 10/100/1000BASE-T/SFP
Ports
7200-24G
● 192Gbps Switch Capacity
● Supports Advanced Service Engine (ASE)
● For Use with 10-Slot Chassis
● 2 Slots for Dual Control Modules
● 8 Slots for User-Selectable Port Modules
● 2 Slots for Redundant Backup Power
Supplies
● 1 Slot for Fan Module
● Includes 7200-1200AC Power Supply
and 7210-Fan Module
7200-CM1
Control Module
24-Port Gigabit Module
7200-ASE1
Advanced Service Engine
● Advanced Service Engine for IPFIX
Support
7200-ASE2
● 12 SFP Slots
● 12 Combo 10/100/1000BASE-T/SFP
Ports
7200-48
48-Port 10/100/1000BASE-T Module
Advanced Service Engine
● 96Gbps Switch Capacity
● For Use with 6-Slot Chassis
● Advanced Service Engine for IPFIX
Support
● 44 10/100/1000BASE-T Ports
● 4 Combo 10/100/1000BASE-T/SFP Ports
75
D-Link Product Guide 2008
LAN SwItcHES
Core Chassis
7200-2XG
7200-1200DC
7210-Fan
2-Port 10-Gigabit Module
Redundant DC Power Supply
Fan Module
● 2 XFP Slots
7200-4XG
4-Port 10-Gigabit Module
● 1200W Power Output
7200-2000AC
● 4 XFP Slots
Redundant AC Power Supply
7200-24P
24-Port PoE 10/100/1000BASE-T
Module
● 12 802.3af PoE 10/100/1000BASE-T
Ports
● 12 Combo 10/100/1000BASE-T/SFP
Ports
● 2000W Power Output
7200-2000DC
Redundant DC Power Supply
7200-48P
48-Port PoE 10/100/1000BASE-T
Module
● 44 802.3af PoE 10/100/1000BASE-T
Ports
● 4 Combo 10/100/1000BASE-T 802.3af
PoE/SFP Ports
● 2000W Power Output
7206-Fan
Fan Module
7200-1200AC
Redundant AC Power Supply
● For Use with 6-Slot Chassis
● 1200W Power Output
D-Link Product Guide 2008
76
● For Use with 10-Slot Chassis
DES-7200 Series Chassis Switch Modules
CPU Engine
7200-CM1
DES-7206
DES-7210
√
√
7200-CM2
7200-CM3^
√
√
7200-CM4^
DES-7206
DES-7210
7200-ASE1**
√
√
7200-ASE2**
√
√
7200-ASE3**
√
√
7200-ASE4**
√
√
7200-24
√
√
7200-24G
√
√
7200-24P
√
√
7200-48
√
√
7200-48P
√
√
7200-2XG
√
√
7200-4XG
√
√
7200-1200AC
√
√
7200-1200DC
√
√
7200-2000AC
√
√
7200-2000DC
√
√
Advanced Service Engine
LAN Interface Module
Power Supply
Fan Tray Module
7206-Fan
√
√
7210-Fan
* Figures are based on the usage of 2 control modules.
^ Support Advanced Service Engine(ASE)
** Available in future
DES-7200 Series Maximum Port Density
DES-7206
DES-7210
10/100/1000Base-T Port
192
384
10/100/1000Base-T Ports with PoE
192
384
SFP Slot
96
192
10-Gigabit Ethernet XFP Slot
16
32
Interface Type
77
D-Link Product Guide 2008
LAN SwItcHES
Features & Benefits
● Connect to Ethernet and
Gigabit Switches
● Provide Backup Power for
Switch’s Built-in Power Supply
● Can be Installed as StandAlone Power Supply Units or
Mounted in 19-Inch Multi-Slots
Chassis
Redundant Power
Supplies
These redundant power supplies (RPS) connect to the D-Link Ethernet or Gigabit
switches to provide backup power for the built-in power supply units inside the
switches. The redundant power supplies can be installed as stand-alone power
supply units, or mounted in a DPS-900 or DPS-800 chassis. The chassis has
multiple slots that can accommodate several redundant power supply units, and
can be mounted in a standard 19-inch equipment rack. All RPS units have solid
metal case housing and LED status indicators. As they are independent units, they
are hot swappable when used with the chassis.
DPS-200
DPS-500DC
AC Redundant Power Supply
DC Redundant Power Supply
● Maximum 60 Watts’ Output Power
● 90 to 264 Volts, 47 to 63Hz AC Input
Range
● Over Current Protection
● Can be mounted in DPS-800 or
DPS-900 Chassis
● Maximum 140 Watts’ Output Power
● Over Current Protection
● Can be mounted in DPS-800 or
DPS-900 Chassis
● Hot Swappable When Installed
in Chassis
● Solid Metal Case Housing
● LED Status Indicators
DPS-300
DPS-600
AC Redundant Power Supply
AC Redundant Power Supply
● Maximum 90 Watts’ Output Power
● 90 to 264 Volts, 47 to 63Hz AC Input
Range
● Over Current Protection
● Can be mounted in DPS-800 or
DPS-900 Chassis
DPS-500
DPS-800
AC Redundant Power Supply
2-Slot Chassis
● Maximum 140 Watts’ Output Power
● 90 to 264 Volts, 47 to 63Hz AC Input
Range
● Over Current Protection
● Can be mounted in DPS-800 or
DPS-900 Chassis
D-Link Product Guide 2008
78
● Maximum 500 Watts’ Output Power
● 90 to 264 Volts, 47 to 63Hz AC Input
Range
● Over Current Protection
● 19-Inch Width for Mounting in Standard
Equipment Racks
● 2 Slots Accommodating 2 RPS Units
● 19-Inch Width for Mounting in
Standard Equipment Racks
Redundant Power Supply & LAN Switch Compatibility
Switch
RPS
DPS-200 (60 Watts)
DPS-300 (90 Watts)
DPS-500 (140 Watts)
DPS-600 (500 Watts)
DES-3528
DES-3528P
DES-3528G
DES-3552
DES-3552P
DES-3526
DES-3550
DES-3828
DES-3828P
DES-3852
DGS-3024
DGS-3048
DGS-3100-24
DGS-3100-24TG
DGS-3100-24P
DGS-3100-48
DGS-3100-48P
DGS-3224TGR
DGS-3312SR
DGS-3426
DGS-3427
DGS-3450
DGS-3612
DGS-3612G
DGS-3627
DGS-3627G
DGS-3650
DPS-900
DPS-CB400
8-Slot Chassis
Power Cable
● 8 Slots Accommodating 8 RPS Units
● 19-Inch Width for Mounting in Standard
Equipment Racks
● Power Cable for DPS-200, DPS-300 &
DPS-500 RPS
● 4 Meter’s Cable Length
79
D-Link Product Guide 2008
LAN SwItcHES
Managed Ethernet Switches
Layer
Max. Port 10/100
Density
Ports
1000BASE-T
Ports
SFP
100BASE-FX
Ports
Open
Slots
Stacking Stackable Static
Routing
Ports
Units
Dynamic
Routing
VLAN
Groups
ACL
DES-3010G
L2
10
8
_
1
1
_
_
_
_
_
_
255
_
DES-3010F
L2
10
8
_
1
_
1
_
_
_
_
_
255
_
DES-3010FL
L2
10
8
_
1
_
1
_
_
_
_
_
255
_
DES-3016
L2
16
16
_
_
_
_
_
_
_
_
_
255
_
DES-3018
L2
18
16
_
_
_
_
_
255
_
DES-3026
L2
26
24
_
_
DES-3028
L2
28
24
_
DES-3028P
DES-3052
DES-3052P
DES-3528
DES-3528DC
DES-3528G
DES-3528P
DES-3552
DES-3552P
DES-3526
L2
L2
L2
L2+
L2+
L2+
L2+
L2+
L2+
L2
28
52
52
28
28
28
28
52
52
26
24
24
48
_
48
24
24
24
24
48
48
48
24
_
26
24
_
DES-3550
L2
50
48
_
DES-3828
L3
28
24
_
24
_
DES-3828P
DES-3852
L3
L3
28
28
52
24
24
48
_
(1)
Combo Por ts
(2)
Optional Por ts
802.3af PoE function is integrated into 10/100Mbps por ts
(4)
2
(2)
2
(2)
2
2
(2)
2
(2)
2
(2)
2
_
_
_
_
255
2
(1)
2
(4)
_
_
_
_
_
4K
2
(1)
2
(4)
_
_
_
_
_
4K
2
(1)
2
(4)
_
_
_
_
_
4K
2
(1)
2
(4)
_
_
_
_
_
4K
2
(1)
2
(4)
_
_
4K
2
(1)
2
(4)
_
_
4K
(4)
_
_
4K
2
(4)
_
2
(4)
_
2
(4)
_
4
4
4
4
4
(6)
_
48
(2)
4
(3)
_
L2
L3
(3)
_
24
2
4
_
DES-3526DC
DES-3828DC
(3)
PoE
Ports
2
8
2
(5)
2
(5)
8
_
4K
2
(5)
8
_
4K
2
(5)
8
_
4K
2
(1)
2
(1)
2
(1)
_
_
_
_
_
_
255
2
2
(1)
_
_
_
_
_
_
255
2
2
(1)
_
_
_
_
_
_
255
2
2
(1)
_
_
_
_
4K
2
(1)
_
_
_
_
4K
2
(1)
_
_
_
_
4K
2
(1)
_
_
_
_
4K
4
2
2
2
If SFP slots are configured with 100BA SE-FX transceivers
Stacking por ts are for dual-purpose st acking/1000BASE-T connection and counted as par t of the 4 built-in 10/100/1000Mbps por ts
(6)
1-8 10/100 Mbps por ts suppor t up to 30w. The rest of the por ts suppor t 802.3af (up to 15.4w)
(7)
DES-3528G can only stack with other DES-3528G
(5)
D-Link Product Guide 2008
80
8
( 7)
2
4
2
(3)
4
8
(5)
(1)
4
(6)
4
(1)
2
(5)
Single
IP
Mgmt
Managed Gigabit Switches
DGS-3312SR
Layer
Max. Port
Density
L3
12
10/100/
1000
Ports
4,8
(2)
SFP
4
(2)
Stacking Stackable 10-Gigabit Static
Routing
Ports
Units
Ports
PoE
Ports
Other
Ports
Open
Slots
_
_
2
12
(2)
_
VLAN
Groups
ACL
Single
IP
Mgmt
(1)
,8
_
_
_
_
_
_
_
_
255
_
_
_
_
1,12
(2)
Dynamic
Routing
255
DGS-3024
L2
24
24
4
(1)
DGS-3048
L2
48
48
4
(1)
_
_
_
_
_
_
_
_
255
DGS-3100-24
L2
24
24
4
(1)
_
_
_
2
6
_
_
_
256
_
DGS-3100-24P
L2
24
24
4
(1)
_
_
2
6
_
_
_
256
_
DGS-3100-48
L2
48
48
4
(1)
_
_
2
6
_
_
_
256
_
DGS-3100-48P
L2
48
48
4
(1)
_
_
2
6
_
_
_
256
_
DGS-3200-10
L2
10
10
2
(1)
_
_
_
_
_
_
_
_
4K
2
(1)
_
_
_
_
_
_
_
_
4K
4
(1)
_
_
2
(2)
_
4K
4
(1)
2
(2)
_
4K
_
_
_
4K
_
4K
DGS-3200-16
DGS-3426
DGS-3426P
L2
L2+
L2+
16
26
26
16
24
24
24
(3)
_
48
24
(3)
(3)
2
(2)
2
(2)
3
2
(2)
12
3
(2)
2
(2)
12
2
(2)
2
_
2
12
12
DGS-3427
L2+
27
24
4
(1)
(1)
DGS-3450
L2+
50
48
4
(1)
_
_
2
DGS-3612
L3
12
12
4
(1)
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
DGS-3612G
DGS-3627
L3
L3
12
27
4
(1)
24
(1)
DGS-3627G
L3
27
4
DGS-3650
L3
50
48
DES-6500
L3
192
96
(2)
12
4
(1)
24
4
(1)
96
(2)
_
192,64
(5)
4K
4K
3
2
(2)
3
2
(2)
12
3
(2)
4K
2
2
(2)
12
2
(2)
4K
8
_
12
_
3
(2)
4K
16
(2)
4K
(1)
Combo por ts
Optional por ts
802.3af PoE function is integrated into 10/100/1000Mbps por ts
(4)
Star stacking: 6 DGS-3324SR, DXS-3326GSR or DXS-3350SR units + 1 DGS-3324SRi stacking master; Ring stacking: 12 units
(5)
Up to 192 10/100Mbps optional por ts, 64 100BASE-FX optional por ts, 64 1000BASE-SX optional por ts
(6)
1 DGS-3312SR stacking master + 12 DES-3226S or DES-3326SR units.
(2)
(3)
81
D-Link Product Guide 2008
LAN SwItcHES
xStack Network Solution
Network Edge
Layer2 Switch
Layer3 Gigabit
Stackable Switch
Layer3 PoE Switch
Layer3 Gigabit Switch
TRUNK
Layer2 Switch
TRUNK
TRUNK
TRUNK
10 Gigabit Fibre Optic Uplink
Layer3 Gigabit
Stackable Switch
Network Core
Layer3 PoE Switch
TRUNK
Layer3 Gigabit
Star Stack
Layer3 Gigabit
Ring Stack
TRUNK
Server Farm
10 Gigabit Fibre
Optic Uplink
Layer3 Chassis Switch
Back-up trunk link
REDUNDANT STP LINK
Layer3 Gigabit
Star Stack
Server Farm
TRUNK
TRUNK LINKS
10/100/1000Mbps
10Gbps
D-Link Product Guide 2008
82
Single IP Management - Control up to 32 Devices via One IP Address
Server Farm
Server Farm
1000Mbps
1000Mbps
Commander Switch
Uplink
1000Mbps
1000Mbps
1000Mbps
Uplink
1000Mbps
Client Switch
1000Mbps
Uplink
Client Switch
Uplink
1000Mbps
1000Mbps
Client Switch
Client Switch
Uplink
1000Mbps
1000Mbps
Client Switch
1000Mbps
Layer3 Core
L2 Resiliency
L3 Redundancy
Layer2 Edge
L2 Resiliency
L2 Resiliency
83
D-Link Product Guide 2008
WIRED
EtHERNEt
Features & Benefits
Ethernet Adapters
More than just for simple network interface, D-Link Ethernet adapters are designed
for the workstations to operate in a secure network environment. They provide many
software functions to make workstations an integrated part of a managed network.
The Ethernet server adapters provide the necessary bandwidth for server deployment
for fast access by workstations. These adapters provide multiple ports with port trunk
supporting load balancing and backup links for mission critical applications with
redundancy that maximizes network uptime.
● Full/Half Duplex Operation
● 802.3x Flow Control in FullDuplex
● ACPI Wake-On-LAN Power
Management
DFE-528TX
Ethernet PCI Adapter
● Optional Remote Boot
Function
● 10/100BASE-TX Port
● Supports Windows, NetWare, Unix,
Mac OS
DFE-530TX
DFE-538TX
Ethernet PCI Adapter
Ethernet PCI Adapter
vEx
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● 802.1x Port-Based Authentication
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, IBM
LAN, Sun PC-NFS, FTP PC/TCP,
Linux
vFx
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● 802.3x Flow Control Full-Duplex Mode
Support
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, IBM
LAN, FTP PC/TCP, SCO Open, Linux
DFE-550TX
Advanced Ethernet PCI Adapter
DFE-530TX+
Ethernet PCI Adapter
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, Linux,
Mac OS, Packet Driver, NDIS Driver
D-Link Product Guide 2008
84
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● IP Multicast
● 802.1Q VLAN, 802.1p Priority Queues
● SNMP Support
● Desktop Management Interface (DMI)
Driver Provided
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, IBM
LAN, Sun PC-NFS, FTP PC/TCP, SCO
OpenServer, NCSA, Linux
DFE-580TX
4-Port Ethernet Server PCI
Adapter
● 4 10/100BASE-TX Ports
● 800Mbps Server-to-Switch Port Trunk
● Per-Port Load Balance/Fault Tolerance
● Dynamic Fail Over Function in Backup
Mode
● 802.1p Priority Queues
● Supports in Windows, Linux
DFE-551FX
Fiber Ethernet PCI Adapter
Remote Boot ROM
The remote boot ROM are optional chips that can be plugged onto the adapters for
remote boot from boot servers. This function allows users to deploy the Ethernet adapters
in diskless workstations and configure them with access security. Diskless workstations
are useful for deployment at public network sites such as schools and libraries. These
workstations cannot boot by themselves; users need to key in their passwords to remote
boot up the system from a boot server.
DFE-530+R
DFE-551P
RPL Boot ROM
PXE Boot ROM
● For Use with DFE-530TX+ Ethernet PCI
Adapter vFX
DFE-530+P
DFE-554C
PXE Boot ROM
RPL Boot ROM
● For Use with DFE-530TX+ Ethernet PCI
Adapter vFX
DFE-690TXD
Ethernet CardBus Adapter
● For Use with DFE-550TX Ethernet PCI
Adapter vC3
DFE-534R3
DFE-554CP
RPL Boot ROM
PXE Boot ROM
● For Use with DFE-530TX Ethernet PCI
Adapter
● 100BASE-FX SC Port
● Up to 2 km Multi-Mode Fiber Cable
Distance
● ACPI Wake-On-LAN Power Management
● 802.1Q VLAN, 802.1P Priority Queues
● Socket for Optional Remote Boot ROM
● Supports Windows, Mac OS, NetWare,
Linux
● For Use with DFE-551FX Ethernet PCI
Adapter
● For Use with DFE-550TX Ethernet PCI
Adapter vC3
DFE-534P3
DGE-528R
PXE Boot ROM
RPL/PXE Boot ROM
● For Use with DFE-530TX Ethernet PCI
Adapter
● For Use with DGE-528T Gigabit PCI
Adapter
DFE-538R
RPL Boot ROM
● For Use with DFE-538TX Ethernet PCI
Adapter vF1
DFE-538P
PXE Boot ROM
● For Use with DFE-538TX Ethernet PCI
Adapter vF1
DFE-551R
● 10/100BASE-TX Port
● 32-bit CardBus Interface to PC Host
● Supports Windows, NetWare, NCSA,
Linux
RPL Boot ROM
● For Use with DFE-551FX Ethernet PCI
Adapter
85
D-Link Product Guide 2008
WIRED
EtHERNEt
Features & Benefits
● PCI Express 4x Interface
» 2Gbps data addressing for higher
throughput.
» Ideal for servers, storage and system
area networks (SAN).
» Lower system level power requirements.
» Backward compatible with PCI and
PCI-X addressing, allows all existing
applications and Operating Systems to
function unchanged.
» Hot-swappable, can replace adapter
without turning OFF server.
Gigabit Adapters
The Gigabit adapters bring Gigabit network speed to the desktop PC and servers.
On the high-end are the fiber Gigabit PCI Express x4 high-performance adapters
that let businesses take advantage of the PCI Express (PCIe) slots of their servers to
enhance network performance with fiber-optic connectivity. The adapters’ dedicated
input/output (I/O) bandwidth PCIe ensures priority performance without bus sharing
for Gigabit Ethernet connectivity in fiber-optic networks.
For workstations, the copper Gigabit adapters provide an inexpensive alternative
solution to the fiber-optic. Using the existing low-cost Cat. 5 copper twisted-pair
network cable as the transmission media, these adapters allow desktops computers to
instantly upgrade to Gigabit capability without requiring installation of new, expensive
fiber cables.
●Full-Duplex Mode
» Doubles network data transfer rate
to 2Gbps, providing servers with
bottleneck-free paths for server-client
applications.
●802.3x Flow Control
» Operatingin full-duplex mode,
minimizes data packet loss between
server and Gigabit switch
DGE-528T
DGE-660TD
Copper Gigabit PCI Adapter
Copper Gigabit CardBus Adapter
●Wake-On-LAN Power
Management
» Allows network administrators to power
ON/OFF computers from remote sites.
» Useful for application in secure network
environments such as in a school or
public library.
●On-Board Screening of VLAN
Tagged Ethernet Frames
» Allows administrators to configure
workstations and servers with Virtual
LAN security or traffic segmentation.
●802.1p Priority Queues Support
» Allows workstations and servers to run
time-sensitive applications such as voice
and video.
● 10/100/1000BASE-T Port
● Supports PCI 33/66MHz Clock Speed
● 8KB Transmit/64KB Receive FIFO to
Reduce PC Overheads
● ACPI Wake-On-LAN Power
Management
● 802.1Q VLAN Tagging
● Supports Windows, NetWare, Linux,
Mac OS
DGE-530T
DGE-560SX
Copper Gigabit PCI Adapter
Fiber Gigabit PCI Express x4
Adapter
● 10/100/1000BASE-T Port
● ACPI Wake-On-LAN Power
Management
● 802.1p Priority Queue, 802.1Q VLAN
● Built-in MIB for SNMP Management
● Supports Windows, NetWare, Linux,
Mac OS
D-Link Product Guide 2008
86
● 10/100/1000BASE-T Port
● 32-bit CardBus Interface to PC Host
● 8KB Transmit/64KB Receive FIFO to
Reduce PC Overheads
● Low Laptop PC Battery Power
Consumption
● Supports Windows, NetWare, NDIS
● 1000BASE-SX SC Port
● PCI-E 1.0a Interface With 2.5GHz
Signaling
● Up to 550 m Multi-Mode Fiber Cable
Length
● ACPI 2.0 Power Management
● 9K Bytes Jumbo Frame
● 802.1p Priority Queue, 802.1Q VLAN
● Built-in MIB for SNMP Management
● Laser Eye Safety Certified
● Supports Windows, Linux
WIRED
EtHERNEt
Transceivers
SFP Transceivers
DEM-311GT
DEM-312GT2
DEM-310GT
DEM-314GT
DEM-315GT
DGS-712
DEM-210
DEM-211
Multi-Mode Fiber
Multi-Mode Fiber
Single-Mode Fiber
Single-Mode Fiber
Single-Mode Fiber
Cat. 5 Twisted-Pair
Single-Mode Fiber
Multi-Mode Fiber
50/125um or 62.5/125um
Multi-Mode
62.5/125um
Multi-Mode
9/125um
Single-Mode
9/125um
Single-Mode
9/125um
Single-Mode
-
9/125um
Single-Mode
50/125um or 62.5/125um
Multi-Mode
550 m
2 km
10 km
50 km
80 km
100 m
15 km
2 km
Standard
802.3z 1000BASE-SX
802.3z 1000BASE-SX
802.3z 1000BASE-LX
802.3z 1000BASE-LX
802.3z 1000BASE-LX
802.3ab 1000BASE-T
802.3u 100BASE-FX
802.3u 100BASE-FX
Data Rate
1 Gbps
1 Gbps
1 Gbps
1 Gbps
1 Gbps
1 Gbps
100Mbps
100Mbps
Port Type
LC
LC
LC
LC
LC
RJ-45
LC
LC
850 nm
1310 nm
1310 nm
1550 nm
1550 nm
-
1310 nm
1310 nm
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
Cable
Fiber Type
Max. Cable Length
Wave Length
Power Support
Wavelength Division Multiplexing (WDM)
Bi-Directional SFP Transceivers
DEM-330T
DEM-330R
DEM-331T
DEM-331R
Single-Mode Fiber
Single-Mode Fiber
Single-Mode Fiber
Single-Mode Fiber
9/125 um
9/125 um
9/125 um
10 km
10 km
40 km
40 km
Standard
1000BASE-LX
1000BASE-LX
1000BASE-LX
1000BASE-LX
Data Rate
1 Gbps
1 Gbps
1 Gbps
1 Gbps
Port Type
LC
LC
LC
LC
TX: 1550 nm
RX: 1310 nm
TX: 1310 nm
RX: 1550 nm
TX: 1550 nm
RX: 1310 nm
TX: 1310 nm
RX: 1550 nm
3.3V
3.3V
3.3V
3.3V
DEM-422XT
DEM-423XT
Cable
Fiber Type
Max. Cable Length
Wave Length
Power Support
9/125 um
XFP Transceivers
DEM-421XT
Cable
Fiber Type
Max. Cable Length
Multi-Mode Fiber
Single-Mode Fiber
Single-Mode Fiber
50/125um or 62.5/125um
Multi-Mode
9/125um Single Mode
9/125um Single Mode
300 m
10 km
40 km
Standard
802.3ae 10GBASE-SR
802.3ae 10GBASE-LR
802.3ae 10GBASE-ER
Data Rate
10Gbps
10Gbps
10Gbps
Port Type
LC
LC
LC
Wave Length
850 nm
1310 nm
1550 nm
Power Support
3.3V/5V
3.3V/5V
3.3V/5V
87
D-Link Product Guide 2008
WIRED
EtHERNEt
Features & Benefits
● Convert Signals on TwistedPair Copper Cables to Signals
on Fiber Cables
● Convert Signals on Multi-Mode
Fiber Cables to Signals on
Single-Mode Fiber Cables
● Extend Network Distance to
Various Lengths
● No Budget Loss
● Minimal Reflection
● LLR Enable/Disable
● Fiber Auto-Negotiation/Manual
● Can Be Used as Stand-Alone
Converters or Installed in
Standard Rack-Mount Chassis
● Redundant Power Supply
Option for Chassis-Based
Configuration
● Optional Management Module
to Manage Media Converters
Installed in Chassis
Media Converters
The media converter converts signals for transmission on one type of cable to signals
for transmission on another type of cable. This allows IT personnel to connect longer
distance fiber cables between devices that are designed only for shorter distance
cables, such as the Cat. 5 twisted-pair cable.
The WDM media converters use the Wavelength Division Multiplexing (WDM)
single wavelength single-fiber technology for connection to avoid budget losses.
These media converters are used in pair; each pair combines transmission (Tx) and
reception (Rx) signals into one fiber strand using two wavelengths.
Each media converter is housed in a solid metal case, complete with LED status
indicators and AC to DC power adapter. It can be used as stand-alone converter, or
installed in a chassis. In case it is installed in the chassis, the metal case must be
removed and the PC board is slid into a chassis slot. The chassis’s power supply will
be used instead of the media converters’ own AC to DC power adapters. All media
converters are hot swappable when used with the chassis.
A management option is available for installation in the chassis with. The management
module lets users monitor in real-time the status of all media converters and power
supplies in the chassis. It also sends out alarms to alert users of abnormal situations.
Management follows industry standards, including SNMP and http, allowing users to
monitor and manage from a third-party SNMP management workstation or via a web
browser.
DMC-300M
DMC-515SC
Twisted-Pair to Fiber Ethernet
Media Converter
Twisted-Pair to Fiber Ethernet
Media Converter
● Converts 10/100BASE-TX to
100BASE-FX Signals
● Extends Network Distance Up to 2 km
on Multi-Mode Fiber Cable
● MT-RJ Fiber Connector
DMC-300SC
DMC-530SC
Twisted-Pair to Fiber Ethernet
Media Converter
Twisted-Pair to Fiber Ethernet
Media Converter
● Converts 10/100BASE-TX to
100BASE-FX Signals
● Extends Network Distance Up to 2 km
on Multi-Mode Fiber Cable
D-Link Product Guide 2008
88
● Converts 10/100BASE-TX to
100BASE-FX Signals
● Extends Network Distance Up to 15
km on Single-Mode Fiber Cable
● Converts 10/100BASE-TX to
100BASE-FX Signals
● Extends Network Distance Up to 30
km on Single-Mode Fiber Cable
DMC-560SC
DMC-805G
DMC-1530SC
Twisted-Pair to Fiber Ethernet
Media Converter
Twisted-Pair to Fiber Gigabit Media
Converter
Twisted-Pair to Fiber Ethernet
Smart Media Converter
● Converts 10/100BASE-TX to 100BASEFX Signals
● Extends Network Distance Up to 60 km
on Single-Mode Fiber Cable
DMC-615SC
Fiber to Fiber Ethernet Media
Converter
● Converts 100BASE-FX Multi-Mode Fiber
to 100BASE-FX Single-Mode Fiber
Signals
● Extends Network Connection Up to 15
km on Single-Mode Fiber Cable
DMC-700SC
Twisted-Pair to Fiber Gigabit Media
Converter
● Converts 1000BASE-T Gigabit TwistedPair to 1000BASE-SX Gigabit Fiber
Signals
● Extends Network Distance Up to 550 m
on Multi-Mode Fiber Cable
● Link Pass-Through Function
● Converts 1000BASE-T Twisted-Pair to
1000BASE-SX/LX Gigabit Fiber Signals
● SFP Slot for of User-Selectable Fiber
Transceiver
● Extends Network Connection to Various
Lengths Depending on SFP Transceiver
Capability
● Link Pass-Through Function
● Converts 10/100BASE-TX to 100BASEFX Fiber Signals
● Extends Network Distance Up to 30 km
on Single-Mode Fiber Cable
● Provides Intelligent Functions Such as
LLCF, LLR
● Link Pass-Through Function
DMC-810SC
DMC-1580SC
Twisted-Pair to Fiber Gigabit
Media Converter
Twisted-Pair to Fiber Ethernet
Smart Media Converter
● Converts 1000BASE-T Gigabit TwistedPair to 1000BASE-LX Gigabit Fiber
Signals
● Extends Network Distance Up to 10 km
on Single-Mode Fiber Cable
● Link Pass-Through Function
● Converts 10/100BASE-TX to 100BASEFX Fiber Signals
● Extends Network Distance Up to 80 km
on Single-Mode Fiber Cable
● Provides Intelligent Functions Such as
LLCF, LLR
● Link Pass-Through Function
DMC-820SC
DMC-920R
Twisted-Pair to Fiber Gigabit
Media Converter
Twisted-Pair to Fiber Ethernet
WDM Media Converter
● Converts 1000BASE-T Gigabit TwistedPair to 1000BASE-LX Gigabit Fiber
Signals
● Extends Network Distance Up to 20 km
on Single-Mode Fiber Cable
● Link Pass-Through Function
● Converts 10/100BASE-TX to 100BASEFX Fiber Signals
● Uses in Pair With DMC-920T or
Equivalent Device
● Extends Network Distance Up to 20 km
on Single-Mode Fiber Cable
89
D-Link Product Guide 2008
WIRED
EtHERNEt
Media Converters
DMC-920T
DMC-1000
DMC-1002
Twisted-Pair to Fiber Ethernet
WDM Media Converter
Media Converter Chassis
Management Module
● Converts 10/100BASE-TX to
100BASE-FX Fiber Signals
● Uses in Pair With DMC-920R or
Equivalent Device
● Extends Network Distance Up to 20
km on Single-Mode Fiber Cable
DMC-1910R
Twisted-Pair to Fiber Gigabit
WDM Media Converter
● 16 Bays to House Up to 16 Media
Converters
● Standard 19-Inch Rack-Mountable
● Hot Swapping of Media Converters
● Hot Swappable Redundant Power
Supply
● Power Redundancy & Power Isolation
● 1 Universal Internal AC to DC Power
Supply Provided
● Second AC to DC Power Supply for
Load-Sharing Purposes (Optional)
● Media Converter Power Isolation for
Electrical Isolation From Each Bay
DMC-1001
Redundant Power Supply
● Converts 1000BASE-T Gigabit TwistedPair to 1000BASE-LX Gigabit Fiber
Signals
● Uses in Pair With DMC-1910T or
Equivalent Device
● Up to 15 km Single-Mode Fiber Cable
Length
DMC-1910T
● 90 to 260 VAC/47 to 63 Hz AutoSwitching Input Power
● Power Overload Protection
● Load Sharing Support When 2 of This
RPS Installed in DMC-1000 Chassis
● SNMP/Web-Based Standards
● 10/100BASE-TX Ethernet & RS-232
Console Ports
● Real-Time Display of Link, Speed,
Duplex Status of Media Converters
● Menu-Driven Terminal Program for
Management via Console Port or
Telnet
● Built-in SNMP Agent
● Supported Traps: Cold start, Warm
Start, Authentication Fail, Power Fail,
Fan Fail, Module Insertion, Module
Pullout, Port Link Down, Port Link Up
● Factory Reset & Remote Software
Reboot
● Remote Setting of Configurations
of Smart Media Converters (LLCF
Enable, LLR Enable, Port Enable,
Auto-Negotiation Enable)
● Configuration Setting Upload/
Download Through TFTP/Web
● TFTP/Web-Based Firmware Upgrade
Stand-Alone Media Converters
Twisted-Pair to Fiber Gigabit
WDM Media Converter
The stand-alone media converters are stand-alone devices that plug directly to the
network switches, installed independently of any media converter chassis. They are
cost-effective devices that convert twisted-pair Ethernet cable signals to fiber Ethernet
cable signals.
DFE-855
Twisted-Pair to Fiber Ethernet Media Converter
● Converts 1000BASE-T Gigabit TwistedPair to 1000BASE-LX Gigabit Fiber
Signals
● Uses in Pair With DMC-1910R or
Equivalent Device
● Up to 15 km Single-Mode Fiber Cable
Length
D-Link Product Guide 2008
90
● Converts 10/100BASE-TX to 100BASE-FX Signals
● Extends Network Distance Up to 2 km on Multi-Mode Fiber Cable
Media Converters
Media Type
Conversion
Max. Cable
Length
Network
Speed
Fiber
Connector
Wave
Length
Sensitivity
Power
Budget
DMC-300M
Copper to
Multi-Mode Fiber
2 km
100Mbps
MT-RJ
1300 nm
-23.5 dB
-14 dB
-31 dB
7.5 V
DMC-300SC
Copper to
Multi-Mode Fiber
2 km
100Mbps
SC
1300 nm
DMC-515SC
Copper to
Single-Mode Fiber
-23.5 dB
-14 dB
-31 dB
7.5 V
15 km
100Mbps
SC
1310 nm
-20 dB
0 dB
-32 dB
12 V
DMC-530SC
Copper to
Single-Mode Fiber
30 km
100Mbps
DMC-560SC
Copper to
Single-Mode Fiber
SC
1310 nm
-15 dB
-8 dB
-34 dB
19 V
60 km
DMC-615SC
Multi-Mode to
Single-Mode Fiber
100Mbps
SC
1310 nm
-5 dB
0 dB
-35 dB
30 V
DMC-700SC
Copper to
Multi-Mode Fiber
15 km
100Mbps
SC
1310 nm
-15 dB
-8 dB
-31 dB
16 V
550 m
1Gbps
SC
850 nm
-9.5 dB
-4 dB
-12.5dB
3V
Copper to
Fiber
-
1Gbps
SFP Slot
-
-
-
-
-
DMC-810SC
Copper to
Single-Mode Fiber
10 km
1Gbps
SC
1300 nm
-9.5 dB
-3 dB
-14.4 dB
4.9 V
DMC-920R
Copper to
Single-Mode Fiber
20 km
100Mbps
SC
Tx: 1310 nm
Rx: 1550 nm
-15 dB
-7 dB
-32 dB
17 V
DMC-920T
Copper to
Single-Mode Fiber
20 km
100Mbps
SC
Tx: 1550 nm
Rx: 1310 nm
-18 dB
-7 dB
-32 dB
14 V
DMC-1530SC
Copper to
Single-Mode Fiber
30 km
100Mbps
SC
1310 nm
-15 dB
-8 dB
-34 dB
19 V
DMC-1580SC
Copper to
Single-Mode Fiber
80 km
100Mbps
SC
1550 nm
-5 dB
0 dB
-35 dB
30 V
DMC-1910R
Copper to
Single-Mode Fiber
15 km
1Gbps
LC
Tx: 1310 nm
Rx: 1550 nm
-9 dB
-3 dB
-21 dB
12 V
DMC-1910T
Copper to
Single-Mode Fiber
15 km
1Gbps
LC
Tx: 1550 nm
Rx: 1310 nm
-9 dB
-3 dB
-21 dB
12 V
DFE-855
Copper to
Multi-Mode Fiber
2 km
100Mbps
SC
1310 nm
-19 dB
-14 dB
-34 dB
5V
Media Converter
DMC-805G
Min. Tx Power Max. Tx Power
(Launch Power) (Launch Power)
91
D-Link Product Guide 2008
POwER OVER
EtHERNEt
Features & Benefits
● Standard 110-240VAC
Conversion to Low-Voltage DC
Power
» Use existing LAN cables to power
network devices.
» A single Cat. 5 or better cable can carry
both Ethernet data and DC power.
» Simplify network hardware integration
and power management.
» Network devices do not need to confine
to locations near power outlets.
PoE Adapters & Midspans
Power Over Ethernet (PoE) adapters and midspans are designed to help simplify
network maintenance and deployments at offices, factories and Wi-Fi hot spots. They
allow surveillance cameras and wireless access points to be installed on building
rooftops, ceilings or high walls for maximum coverage. Cameras and wireless access
points can be placed up to 100 meters away from the power sources. It is at these
places that wall AC outlets are inaccessible and providing power to these locations is
difficult and expensive.
PoE adapters and midspans are also handy for Internet telephone installation at
offices, eliminating the need to individually power each IP phone. By transmitting
remote power through the standard network cabling, these adapters do away with the
need for an AC outlet at each device location. Only a single Ethernet cable is run to
each IP phone, camera or wireless AP, instead of separate power and data cables.
●Central Power Source
Provision to Entire LAN
Infrastructure
» Network accessories can be scattered
around and connected to single PoE
midspan or PoE switch.
» Network devices do not need to confine
to locations near power outlets.
» Eliminate time and cost of installing
separate power cabling and providing
dedicated, uninterrupted power supply
for each individual network device.
DWL-P200
Power Over Ethernet Adapter
●Guaranteed Power Protection
Against Unforeseen
Emergencies
» PoE midspans and PoE switches can
be connected to Uninterruptible Power
Supply (UPS).
» Continuous operation for all connected
network devices during power failures.
● Transmits Power Up to 100 m1
● Selectable 5VDC or 12VDC Power
Output
● Power Surge Protection
● Includes Base Unit & Terminal Unit
● No Need to Connect to PoE Switch
DWL-P50
DWL-P1012
Power Over Ethernet Adapter
12-Port Power Over Ethernet
Midspan
● 802.3af PoE Standard Compliance
● Transmits Power Up to 100 m1
● Selectable 5VDC or 12VDC Power
Output
● Power Surge Protection
● Connects to 802.3af Compliant PoE
Switch or Midspan
D-Link Product Guide 2008
92
● 12 802.3af PoE Ports
● Management Through Web Browser
or Web Smart Utility
● PoE Port Grouping & Scheduling
● 19-Inch Rack Size for Installation in
Equipment Racks
POwERLINE
Features & Benefits
● High Transmission Rate
» The latest generation of D-Link
Powerline adapters (DHP-300) can
deliver data transfer rates of up to
200Mbps.
» Ideal for streaming video and music
from PC or storage servers in other
rooms to High-Definition TV and Media
Players in living room.
Powerline Ethernet Adapters
Powerline transmits data on the electrical wiring and does not require any new network
cables. Because power outlets are located on nearly every wall of a house, users can
easily connect the network and share Internet access. It is ideal for connecting home
network entertainment components normally located near a power outlet. Any Ethernetready devices, such as broadband routers, computers, High Definition TV, digital video
recorders, game consoles, Internet cameras, print servers and D-Link Media Players can
be added to a home network.
Powerline can be used to extend a Wi-Fi network in the home or small office building.
A pair of Powerline adapters can link two wireless locations without the need to run
Ethernet cables. Combined with a broadband cable/DSL connection, every room with
electrical outlets will have easy access to high-speed Internet connection.
●Quality of Service Support
» Video, Internet phone and on-line
games won’t experience glitches while
file downloads or web surfing are taking
place.
●Uses Different AC Frequencies
» Household appliances’ electrical current
doesn’t interfere with the data network.
●Data Encryption/Net ID
Security
» Keep out intruders in the same building.
» Isolate home or office network from
users in other apartments on the same
floor that share the building electrical
wiring.
●802.1Q VLAN Tag
» Network isolation to prevent Internet
phone from being tapped.
DHP-200
DHP-300
Powerline Ethernet Adapter
Powerline HD Ethernet Adapter
●HomePlug 1.0 Standard
● 4 to 21MHz Frequency Band
● AC Power Prongs
● 10/100BASE-TX Ethernet Port
● Enhanced 85Mbps Data Transfer
● 56-Bit DES Data Encryption
●2 to 32MHz Frequency Band
●AC Power Prongs
●10/100BASE-TX Ethernet Port
●200Mbps Data Transfer
●3DES Data Encryption
DHP-201
DHP-301
Powerline Ethernet Starter Kit
Powerline HD Ethernet Starter Kit
●Includes 2 DHP-200 Powerline Ethernet
Adapters
●Includes 2 DHP-300 Powerline HD
Ethernet Adapters
93
D-Link Product Guide 2008
PERIpHERAL
SHARING
Features & Benefits
● Save Money & Desktop Space
» Users with two PCs who need to use
them at the same time can control their
computers from a set of keyboard,
monitor and mouse.
» Users of small laptop computers can
connect a better, bigger monitor to
connect both computers.
» Useful for home users, test labs and IT
personnel.
●Auto-Scan Connected Servers/
Computers
» Automatic refreshing to see if connected
computers are still “alive”.
KVM Switches
The Keyboard, Video, Mouse (KVM) switches allow users to control of several
computers or servers through a single keyboard, monitor and mouse. The computers
and servers are connected to a KVM switch. From a single console, users can switch
back and forth among the computers with a push of a button or hot keys. It’s a very
cost-effective way to control multiple computers that do different tasks.
The KVM switch over IP provides remote KVM access via a LAN or an Internet
connection to a server. Designed for server control, this appliance integrates KVM,
network connection and external modem support in a one-box solution.
DKVM-2K
2-Port KVM Switch
●Audible Signaling
» Audible feedback for confirmation
while switching back and forth between
connected computers.
●Audio Socket
» Allows two connected PC to share a
single set of speakers.
» Connects to a headphone.
●Flexible Computer Selection
Methods
» Users can select a connected computer
by pushing a button on the KVM switch
or by pressing a combination of “hot
keys” on the keyboard.
● KVM Ports
● PS/2 Keyboard & Mouse Support
● 2 Sets of KVM Cables Attached to KVM
Switch
KVM-121
2-Port KVM Switch
●Direct Power Input from
Connected Computers
» No need to attach an external power
adapter or power cable to the KVM
switch.
● 2 KVM Ports
● PS/2 Keyboard & Mouse Support
● Audio Socket to Connect to Audio
Device
● 2 Sets of KVM Cables Attached to KVM
Switch
KVM-221
2-Port USB KVM Switch
● 2 KVM Ports
● Audio Socket to Connect to Audio
Device
● USB Keyboard & Mouse Support
● 2 Sets of KVM with Audio Cables
Attached to KVM Switch
D-Link Product Guide 2008
94
DKVM-2KU
2-Port KVM Switch with USB
Port
● 2 KVM Ports
● 1 USB 2.0 Port to Share USB Device
between 2 Connected PCs
● PS/2 Keyboard & Mouse Support
● 2 Sets of KVM Cables Attached to
KVM Switch
DKVM-2U
DKVM-4U
DKVM-16
2-Port USB KVM Switch
4-Port USB KVM Switch
16-Port KVM Stackable Switch
● 2 KVM Ports
● USB Keyboard & Mouse Support
● 2 Sets of KVM Cables Attached to KVM
Switch
● 4 KVM Ports
● USB Keyboard & Mouse Support
● 2 Sets of KVM Cables Provided
DKVM-4K
DKVM-8E
4-Port KVM Switch
8-Port KVM Stackable Switch
● 16 KVM Ports
● Stackable to 8 Units per Stack
● Stackable With 8-Port DKVM-8E Switch
● 19-Inch Equipment Rack-Mountable
● PS/2 Keyboard & Mouse Support
● 2 Sets of KVM Cable Provided
● 1 Set of KVM Stacking Cable Provided
● External Power Adapter
DKVM-IP1
1-Port KVM Switch Over IP
● 4 KVM Ports
● PS/2 Keyboard & Mouse Support
● 2 Sets of KVM Cables Provided
● 8 KVM Ports
● Stackable to 8 Units per Stack
● Stackable With 16-Port DKVM-16
Switches
● 19-Inch Equipment Rack-Mountable
● PS/2 Keyboard & Mouse Support
● 2 Sets of KVM Cable Provided
● 1 Set of m KVM Stacking Cable Provided
● External Power Adapter
● For Remote Control of Servers
● 1 KVM Port Connection to Server
● Ethernet Port for LAN or Internet
Connection
● RS-232 Modem Port for Backup
● PS/2 Keyboard & Mouse Support
● USB 2.0 Port for Remote Connection to
Server Hard Disk
● 256-Bit SSL Encryption for Data
Encryption over Internet
● Can Connect to Other KVM Switches to
Expand KVM Port Density
95
D-Link Product Guide 2008
PERIpHERAL
SHARING
Features & Benefits
● Multi-Function Equipment
Support
» Multifunction printers are equipment with
printing, scanning and faxing functions.
» Scanning support allows users to use
these printers to scan documents and
send the output files to a user computer
or server.
» Faxing support allows users to send
fax message from a workstation to the
printer for transmission.
●IPP (Internet Printing Protocol)
Support
» IP address can be set in a print server
for remote users to output print files to
the printer from a remote place.
●HP PJL Bi-directional Printer
Communication Protocol
Support (for Parallel Printer
Ports)
Print Servers
The print servers allow users to share printers over the network through simple,
transparent printing operation. Tested with a wide range of different printer models,
D-Link print servers offer a high level of compatibility. They support multiple network
Operating Systems, including Windows, Mac OS and Linux, giving users the flexibility
of installing their print servers regardless of the network environment.
The single-port print servers are cost-effective for both large offices and small
workgroups. For homes and the small office with just one printer to share, these
single-port devices save costs. For large offices with many printers scattered at
different places, users can plug a single-port print server to each of these printers and
share them on the network.
The multi-port print servers have a number of printer ports, so users don’t need to
install a separate print server for each printer that they want to share. Where printers
are closely placed together, it makes sense to buy a print server that offers multiple
printer ports. Each of the printers can be attached to a port of the same print server
through a printer cable. Multi-port print servers are equipped with powerful CPU and
abundant RAM buffers, so even when all printers are printing at the same time, users
will not experience any degradation of performance.
The multifunction print servers allow users to take advantage of the scanning and fax
functions of the multifunction printers. These print servers will take care of sending
output scanned files to specified network destinations. Fax messages from users’
computers can also be sent to the print server for transmission from the printer.
» Using this protocol, a print server can
collect information and report the status
of the attached printer.
●User Access Control
» Useful for office environments and multiport printers; this function allows the
network administrator to set access to
the printer.
●Windows-Based Administration
Program
» Easy setup and management of print
jobs.
●Built-in MIB
» Print servers can be managed in an
SNMP environment.
DP-301P+
DP-301U
Single-Port Parallel Print Server
Single-Port USB Print Server
● Parallel Printer Port
● Connects to Network through
10/100BASE-TX Port
● IPP Remote Printing
● User Access Control
● Supports Windows, Mac OS, Unix
● Directly Connects to Printer’s Parallel
Port, No Printer Cable Required
D-Link Product Guide 2008
96
● USB 2.0 Port
● Connects to Network through
10/100BASE-TX Port
● IPP Remote Printing
● Supports Windows, Mac OS, Unix,
NetWare
DP-G310
DP-G321
Single-Port Wireless G USB Print
Server
3-Port Wireless G Print Server
● USB 2.0 Port
● 10/100BASE-TX Ethernet and 802.11g
Wireless Network Connection
● IPP Remote Printing
● User Access Control
● Web-Based Configuration
● Supports Windows, Mac OS, NetWare,
Linux, Unix
● 2 USB 2.0 Ports, 1 Parallel Printer Port
● 10/100BASE-TX Ethernet and 802.11g
Wireless Network Connection
● IPP Remote Printing
● User Access Control
● Supports Windows, Mac OS, NetWare,
Linux, Unix
DP-300U
DPR-1260
3-Port Print Server
4-Port Wireless 108G USB Print
Server
● 1 USB 2.0 Port, 2 Parallel Printer Ports
● 10/100BASE-TX Ethernet Network Port
● Supports Windows, Mac OS, Linux, Unix,
NetWare
● 4 USB 2.0 Ports
● 802.11g Wireless Speed Up to 108Mbps
● 10/100BASE-TX Ethernet Port
● Ethernet Port Can Also Act as Bridge Port
for Wireless LAN
● Supports Scanning Function of MultiFunction Equipment
● Supports Windows
DP-300+
DPR-1061
3-Port Print Server
3-Port Print Server
● 1 Serial Port, 2 Parallel Printer Ports
● 10/100BASE-TX Ethernet Network Port
● IPP Remote Printing
● User Access Control
● Supports Windows, Mac OS, Unix
● 2 USB 2.0 Ports, 1 Parallel Printer Port
● 10/100BASE-TX Ethernet Port
● Supports Scanning and Fax Functions of
Multi-Function Equipment
● Supports GDI Printers
● Supports Windows
97
D-Link Product Guide 2008
SURVEILLANcE
Features & Benefits
● Digital Zoom
» Using the zoom function provided by the
surveillance software running on a PC,
viewers can zoom up captured video 4
times for display of details
●Optical Zoom Auto Focus/Auto
Iris Lens
Internet Cameras
The Internet cameras let users watch and listen remotely from anywhere. They
connect to an Ethernet wired and wireless network at home, in a building, factory or
campus, and via broadband to the Internet. Equipped with versatile features such
as video zoom, low-light image capture, audio/video recording and multi-camera
monitoring, these cameras provide a comprehensive security system for surveillance
of home and business premises.
The cameras are designed as stand-alone systems complete with CPU and integrated
web servers, and do not need to hook up to any computers. Once connected to the
network, users can use the IP address built inside the camera to access it and view
live streaming video.
» Viewers can zoom up captured video 18
times for clarity far greater than digital
zooms alone.
» Higher level of details necessary to
identify people, license plate numbers,
etc.
D-ViewCam 2.0 surveillance software is provided to let users to set up parameters,
configure and manage the cameras. It also lets users view multiple cameras on a
single computer or TV screen at a central location. Images can be recorded to the
computer’s hard drive. The cameras can be connected to external alarms and sensors,
and users can set up automatic e-mail alerts that are sent through the Internet.
●3GPP Support
The Internet camera supports motion-detected recording to save disk space and
eliminate the time otherwise wasted to view the entire record. Image playback
consumes little time with triggered-event browsing and fast database searching.
» Live camera feed of camera can be
pulled from a 3G cellular network using
a cell phone or PDA with 3G video
player.
» From anywhere within a 3GPP service
area, users can monitor a home or office
in real time while walking or driving.
●Motion Detection Recording
» Instead of recording 24 hours a day, 7
days a week, images can be recorded
to a computer hard drive only when
motions are detected.
» Saves disk space, eliminates time
wasted to view unnecessary images.
●Recording to NAS
» Video and sound can recorded
directly to a Network Attached Storage
(NAS) such as an external hard drive
connected to an Ethernet or 802.11
wireless network.
» No need to turn on the power of a PC
24 hours a day for standby recording.
The Pan/Tilt/Zoom (PTZ) Internet cameras provide angle movement and zoom
controllable from a web interface for monitoring of all angles with closed up details.
Using the 2-way audio Internet cameras, users can view and listen from a remote
place while talking to a person at the camera site through a speaker attached to the
camera.
The day-and-night Internet cameras are equipped with high-quality CCD sensors,
low-light and no light capabilities for capture of sharp video in any environment.
Accessories such as illuminators, optical auto-IRIS lens and LED lens can be attached
to these cameras for use at night.
With the alarm-triggered global reaction function, the camera software can send
alarms to the system to trigger other cameras and security equipment to react in a
global manner. The cameras supporting Power over Ethernet can be placed on high
ceilings or in hidden places where AC outlets are not available.
●Triggered Event Browsing
» Playback of recorded video consumes
little time using fast database searching.
●Multiple Camera Site Display
on Single Screen
» Viewing of up to 32 camera sites on a
single computer or TV screen at one
central location.
» Viewer can select any of the displayed
camera site and zoom up the captured
video.
●UPnP Support
» Computers running Windows can
automatically recognize all installed
cameras and add them to the network.
» Cameras can be accessed and viewed
from any network place as a device on
the network.
D-Link Product Guide 2008
98
●DDNS Support
» Users can assign an easy-to-remember name
and domain to the camera.
» Can remote access the camera without
having to remember its IP address, even if the
Internet Service Provider has changed it.
●Power over Ethernet Support
» Camera can be placed on a ceiling or
roof and connect to a 802.3af Ethernet
switch; no need to connect to an AC
power source, no need to run power
cable.
» No need for AC power adapter;
camera can be easily concealed or
camouflaged.
Internet Cameras
DCS-910
DCS-920
DCS-2102 DCS-2120 DCS-2121 DCS-3110 DCS-3410 DCS-3415 DCS-3420 DCS-5220 DCS-5230 DCS-5300 DCS-5300G DCS-5610
DCS-6110 DCS-6410 DCS-6620 DCS-6620G DCS-7410 DCS-7411
Hardware Features
Megapixel
Megapixel
CCD
CMOS
CMOS
Fixed
C/CS Mounted C/CS Mounted
CCD
CCD
CMOS
Fixed
C/CS Mounted
Fixed
Megapixel
CMOS
Fixed
Option
−
Option
−
−
−
−
−
−
−
−
−
Option
−
Option
−
−
−
−
−
−
−
−
−
−
−
−
−
18X
−
−
−
−
−
2.6X
−
−
10X
10X
−
Manual 3X
Built-in
Built-in
Built-in
Built-in
Built-in
Built-in
Built-in
Built-in
Built-in
−
Built-in
Built-in
Built-in
−
−
−
−
−
−
−
−
802.11g
802.11n
−
802.11g
−
−
−
−
802.11g
−
−
−
−
BNC
−
−
AV
AV
AV
−
BNC
AV
AV
BNC
BNC
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
Sensor
CMOS
CMOS
Lens Type
Fixed
Fixed
Megapixel
CMOS
Fixed
Day/Night Lens
−
−
−
−
−
Option
Auto IRIS Lens
−
−
−
−
−
Option
Optical Zoom
−
−
−
−
−
Microphone
−
−
Built-in
Built-in
Built-in
Audio In
−
−
−
−
−
Audio Out
−
−
Wireless LAN
−
802.11g
−
802.11g
802.11g
Sensor I/O Interfaces
−
−
−
−
−
TV Output
−
−
−
−
−
−
BNC
−
Remote Control
−
−
−
−
−
−
−
−
Motorized Pan/Tilt
−
−
−
−
−
−
−
−
RS-485 Interface
−
−
−
−
CMOS
Fixed
−
CCD
CCD
CMOS
CCD
CCD
CCD
CCD
CCD
Fixed
Fixed
Fixed
Fixed
Fixed
Fixed
Fixed
Fixed
−
−
−
−
802.11g
802.3af PoE
−
−
−
−
Input Power
5VDC/2.5A
5VDC/2.5A
5VDC/2.5A
5VDC/2.5A
−
−
−
−
−
−
30fps
30fps
30fps
30fps
30fps
30fps
30fps
30fps
30fps
−
−
4X
4X
4X
4X
4X
4X
4X
−
−
IP66 Water/Dust Proof
CCD
Fixed
IR Built-in (25M) IR Built-in (40M)
−
−
−
−
−
−
5VDC/2.5A 12VDC/1.25A 12VDC/1.25A 12VDC/1.25A 12VDC/1.5A 12VDC/1.5A 12VDC/1.25A 12VDC/1.5A 12VDC/1.5A 12VDC/1.5A 12VDC/1.25A 12VDC/1.25A 12VDC/1.5A 12VDC/1.5A 12VDC/1.25A 12VDC/1.25A
−
−
−
−
−
−
−
−
−
−
−
−
30fps
30fps
30fps
30fps
30fps
30fps
30fps
30fps
30fps
30fps
30fps
4X
4X
4X
4X
4X
4X
4X
10X
10X
4X
4X
−
−
−
−
−
−
−
−
−
−
−
−
−
−
32
32
32
32
32
32
−
−
Software Features
−
MJPEG Video Format
MPEG4 Video Format
Max. Frame Rate
Digital Zoom
Java Support
Motion Detection
−
−
*
*
Recording to NAS
−
−
Audio Recording
−
−
Video Output to 3GPP
−
−
Max. Cameras
Displayable
on PC/TV Screen
32
32
E-mail Notification
Schedule Recording
to Hard Drive
−
−
32
32
32
32
32
32
32
32
32
−
32
32
32
UPnP Installation
DDNS Support
Enable/Disable LED
Indicators
* Motion detection available through software
99
D-Link Product Guide 2008
SURVEILLANcE
Features & Benefits
● IR Illuminators & IR Lens /
Vari-focal Lens Useful for
Diverse Applications
● Certified for Water Resistance/
Dust-Proof Protection
● Outdoor Enclosure with Builtin Heater/Blower for Protection
against Heat/Cold Temperature
Internet Camera
Accessories
D-Link’s SecuriCam IP camera accessories let users protect homes and businesses
by maximizing the full potential of the D-Link Internet cameras. They provide costeffective solutions for diversity of application. The IR illuminator and IR lens can be
used for both day and night surveillance, while the vari-focal CS mount lens provides
easy installation without the need to change the lens for particular applications.
The Internet camera outdoor enclosures protect the Internet camera from the rigors
of outdoor use. These fixed-type enclosures include heavy-duty, angle-adjustable
mounting brackets that can be used to secure the camera on a vertical or horizontal
surface. These enclosures maximize the full potential of the Internet cameras to
secure and protect homes and business buildings.
● Power Supply Built Into
Outdoor Enclosure for Easy
Cable Management
● Angle-Adjustable Mounting
Brackets
● Vertical or Horizontal
Installation
DCS-10
DCS-20
IR Illuminator
IR Lens
● 20 x IR-LEDs
● Night vision illumination: up to 10 m
Distance
● IP68 Certified for Water Resistance and
Dust-Proof Operation
● Power On Auto-control Under 10 lux
● Dimensions: 50 (O) x 60 (D) mm
● For Use with DCS-3110, DCS-3410,
DCS-3420 Cameras
D-Link Product Guide 2008
100
● CS-Mounted IR Fixed Lens
● 12 x 850nM Infrared LEDs
● Focus Length: F6.0 / F2.0, up to 10 m
Distance
● Power On Auto-control Under 10 lux
● Dimensions: 58.6 (O) x 24 (D) mm
● For Use with DCS-3110, DCS-3410,
DCS-3420 Cameras
DCS-25
DCS-60
Vari-focal Lens
Outdoor Enclosure
● CS-Mounted Vari-focal Auto Iris Lens
● For 1/3-inch & 1/4-inch Sensors with IR
Connection
● Focus Length: F3.5 - 8.0mm / F1.4 to 360
● Iris/Focus Control: DC Drive & Manual
Focus
● View Angle: 95 to 42 Degrees
● Dimensions: 36 (O) x 52.3 (D) mm
● For Use with DCS-3110, DCS-3410,
DCS-3420 Cameras
● IP44 Certified for Water Resistance and
Dust-Proof Operation
● Integrated Heater and Blower for
Camera to Operate in Wider Range of
Temperature
● Built-In Power Supply to Simplify
Installation
● Aluminum Housing
● For Use with DCS-3110, DCS-3220,
DCS-3410, DCS-3420 Cameras
DCS-45
DCS-70
Outdoor Enclosure
Outdoor Enclosure
● Thermal Barrier Design to Withstand
Temperature Fluctuations
● With Flip Open Top for Easy Installation
● Aluminum Housing with Steel Bracket
● FFor Use with DCS-3110, DCS-3220,
DCS-3410, DCS-3420 Cameras
DCS-50
Outdoor Enclosure
● IP66 Certified for Water Resistance and
Dust-Proof Operation
● Dome Type Enclosure
● Integrated Heater and Blower for
Camera to Operate in Wider Range of
Temperature
● Built-In Power Supply to Simplify
Installation
● Aluminum Housing with Smoked Acrylic
Cover
● For Use with PTZ Cameras
● IP66 Certified for Water Resistance and
Dust-Proof Operation
● Built-In Power Supply to Simplify
Installation
● Aluminum Housing
● For Use with DCS-3110, DCS-3220,
DCS-3410, DCS-3420 Cameras
101
D-Link Product Guide 2008
NEtwORK
MANAGEmENt
Features & Benefits
● Layer 3 Utilities
» Include IP forwarding, RIP 2, OSPF, IP
MRoute, DVMRP and PIM functions for
management switches and advanced
routers in enterprise networks.
●Topology Generator
» Creates detailed diagrams and
schematics for network design and
layout planning.
●SNMP v3 Support
» For major MIBs including MIB II, IF- MIB
(RFC2233), Entity MIB (RFC2737),
Bridge 802.1D(RFC1493), RMON,
802.1P (RFC2674) and 802.1Q
(RFC2674).
●Trap Events
» Trap/Alarm notification by e-mail and
sound.
» Notifications based on severity.
» Customizable trap messages.
●Domain Management
» Allows administrators to categorize
network devices into single or multiple
domains.
●Multiple Views
» Supports tree and list views for viewing
devices in the domain.
●Resource Management
» Manage, add, or remove network device
resources from/to a topology.
●Device Customization
D-View 6.0 SNMP Network Management
D-View 6.0 SNMP Network Management System is a comprehensive standardsbased management tool designed to centrally manage critical network characteristics
such as availability, reliability, resilience and security in a consistent way. Flexible
and versatile, this software accommodates a wide range of D-Link devices, including
wireless bridges and access points, multi-layer switches, remote routers, OLT/
ONU devices and broadband CO devices. D-View provides useful tools to allow
network administrators to effectively manage device configurations, fault tolerance,
performance and security.
D-View is organized into a vendor-independent platform and user plug-in modules.
The platform consists of several main components, namely the Domain Manager,
NetMap Manager, Topology Generator, Batch Configuration, MIB utilities, Net Toolbox
and Performance Monitor. The components can be loaded or unloaded according to
the users’ need. Plug-in modules are for the D-Link devices that the administrators
want to manage. When a device is selected for management, D-View will look for that
device’s plug-in module and display its image on the screen.
Users can create a topology map to graphically represent planned or existing
networks to aid network design. D-View periodically polls network devices to monitor
the status. Users can customize their diagrams with selected icons and bitmap files
used for the background. When a topology map is opened, D-View will discover the
devices connected on the network and display their icons on the map. D-View 6.0
can recognize a device’s standard (SNMP or non-SNMP), its type (router, switch
or wireless LAN) and its network domain. The protocols used in polling for device
discovery are SNMP and ICMP. For remote network devices, traps are sent to them
to obtain status information.
Users can also manage non-D-Link devices that do not have plug-in modules. DView provides a MIB compiler for users to compile MIB files supplied by the vendors
of these devices into a system recognizable format. After compilation, D-View loads
them into the database. The compiler can communicate with these devices, enabling
the administrator to get the values currently stored in the devices or to set new values
for specific MIB objects. All MIBs are converted into a graphic tree view, with which
the administrator can use the MIB Browser to manage the devices. As non-D-Link
devices do not have plug-in modules for installation in D-View, this software can
simulate the device panels to create user interface graphics.
» Include customized network devices
by manually entering device type
information.
●MIB Compiler
» Powerful, easy-to-use MIB Compiler
and Browser for more effective and
efficient network management
» Manage third-party devices.
DV-600P
DV-600S
●Client-Server Architecture
D-View 6.0 Professional Version
D-View 6.0 Standard Version
» For Professional version only.
●Batch Configuration
» For both Standard and Professional
versions.
● SNMP Network Management Software
● Supports Client-Server Architecture
D-Link Product Guide 2008
102
● SNMP Network Management Software
VIDEO CONFERENcE
Features & Benefits
● Real-Time Face-to-Face Video
Conference
» Watch live video and see friends’ faces
while talking over the Internet.
●Quality Audio/Video
» Video display at up to 30 frames per
second at 352 x 288 pixels (CIF) or 176
x 144 pixels (QCIF).
» Speakerphone with jitter buffer,
echo cancellation and comfort noise
generation to match or surpass normal
phone quality.
●TV Connection
» Videophones without LCD screen
connect to living room TV sets to display
video.
» Videophones with integrated LCD can
connect to TV too for large screen
display.
» Callers can get full screen view or
picture-in-picture view.
» PAL or NTSC TV format support (factory
set).
Video Phones
These video phones are unique appliances from D-Link that combine voice and video
transmission/reception over the broadband Internet. These phones integrate CMOS
cameras into them to capture and send speakers’ faces to the opposite sides, so callers
can watch each other’s actions while talking.
Designed for home and office use, these appliances provide a low-cost video conference
solution that operates without the need for any computer hardware and software. At two
remote places, users simply plug two videophones to the Internet to talk face-to-face
anywhere in the world.
D-Link videophones use the industry-standard H.323 protocol for video streaming
over the Internet. They can connect to any devices that use this standard for video
conferencing, and not just to other D-Link
videophones. For face-to-face talks, users
can also connect D-Link videophones to
other devices that use the popular Microsoft
web-based NetMeeting.
DVC-1000
Videophone
●Remote Control
» Answer incoming videophone calls and
initiate new ones from TV screen.
» View caller ID on TV screen
» View auto-IP-mapping phone book and
select number (caller IP address) on TV
screen.
» Adjust remote view or self view.
●External Speaker Connection
» Can use built-in speaker or external
speakers for better sound.
● Connects to TV Set
● Connects to DSL/Cable Modem Through
Ethernet Port
●Convenient PSTN and Internet
Phone
» Default connection is to normal
telephone (PSTN) when the phone is
picked up to dial out.
» Users press “Broadband” button and
select destination from Speed-Dial List
to initiate a video conference call.
» Videophones accept both PSTN and
VoIP incoming calls
Wireless G Videophone
● Connects to TV Set
● Connects to DSL/Cable Modem or
Broadband Router Through Ethernet Port
or Integrated 802.11g Wireless LAN
DVC-2000
● 75° Diagonal Field of View for Wider
Coverage
● High Quality Glass Lens Elements
● 2.9mm Focal Length
● 5.5mm Back Focal Length
● 63° Horizontal, 50° Vertical
● For Use With DVC-1000, DVC-1100
Video Phones
DVC-20
Varifocal Lens
Desktop Videophone
●Integrated Wi-Fi Interface
» Callers can sit anywhere at home or in
the office and talk on the phone.
» TV does not need to be placed near the
phone line or DSL modem.
Wide Angle Focal Lens
DVC-1100
●Quality of Service (QoS)
Support
» Prioritized Internet traffic handling for
smooth image and voice transmission/
reception.
DVC-10
● Integrated 5-Inch Color TFT LCD
● Connects to DSL/Cable Modem Through
Ethernet Port
● Can Connect to TV Set Through Video
Out Interface
● Wide Angle View for Wider Coverage or
“Zoom In” View for a Close-Up
● High Quality Glass Lens Elements
● 2 x 4-8mm Focal Lens
● 66° to 63° Horizontal, 38° to 20° Vertical,
66° to 33° Diagonal
● For Use With DVC-1000, DVC-1100
Video Phones
103
D-Link Product Guide 2008
StORAGE
Features & Benefits
● Embedded Centralized
Storage Management
» Embedded IP-SAN Device Manager
(IDM) allows monitoring and control of
SAN via SMI-S (Storage Management
Initiative) command set.
» Embedded secure server for remote
configuration/monitoring of SAN storage
subsystems.
●Advanced Management
Features
» Additional advanced features for efficient
management of network storage and
optimal performance.
●Adaptive/Persistent Cache
Management
» Provides write-back, write-through, write
coalescing, multi-stream read-ahead on
a volume basis.
» Optimizes cache utilization and
performance in an application
dependent manner.
●VLAN Zoning
» 802.1Q VLAN tagging to segregate
traffic into isolated zones for secure
access.
» Jumbo frames to improve network
throughput/reduce CPU overhead.
●QoS
» 802.1p Priority Queues for timesensitive packets.
●Volume Virtualization
» Storage management software stack for
volume virtualization utilizing concept of
storage extents.
» Fundamental building blocks to enable
RAID, online capacity expansion,
volume migration.
» Drives of dissimilar sizes can be used to
create volumes.
» Growth can occur without volume
migration or reconstruction.
» Single drives can contain multiple and
divergent RAID technologies.
» Volume structure can provide
infrastructure for Snapshot copies.
●RAID Support
» RAID Levels 0, 1, 1+0, 5 and JBOD
(striped sets, mirrored sets, striped
mirrored sets, parity sets and JBOD)
Storage Area Networks
These Storage Area Networks (SANs) are designed to provide a reliable network
data storage solution for customers in entry-level and SMB segments. Utilizing a 10Gigabit iSCSI System-on-a-Chip (SoC) solution that can handle over 65,000 I/Os per
second and capable of supporting over 11TB raw capacity using high-capacity hard
drives, these SANs can easily be implemented as near line storage to supplement
primary IP network storage solution or be used as a basic backup and recovery device.
This evolutionary advancement in performance is a testament to the tightly integrated
xStack Storage architecture and is a sharp contrast to the discrete implementation of
competing products.
SAN has been traditionally reserved for Fiber Channel networks until the recent
introduction of iSCSI that extends this powerful yet simple centralized backend
(behind server-based) storage system to IP networks. By utilizing existing Ethernet
technology, the cost associated with separate host bus adapters and the perGigabyte cost for storage is significantly reduced. IP SAN based on iSCSI technology
can leverage existing and familiar Ethernet standards to provide speeds of up to
1160MBytes bandwidth.
D-Link SAN Array implements multiple Gigabit ports and supports IEEE 802.3ad Link
Aggregation Groups (LAG) for full offload capability so that multiple ports can be
grouped together for increased throughput and redundancy.
D-Link SANs also provide the industry’s first built-in, fully integrated 10-Gigabit
interface, providing up to 1160MBytes bandwidth and a high performance alternative
to the multi-Gigabit Fiber Channel.
By utilizing a SoC design, D-Link SANs combine both networking and storage functions
into a single specialized Application Specific Integrated Circuit (ASIC). The SoC
solution combines 10-Gigabit iSCSI, TCP & IP offload, embedded processors, and a
storage virtualization firmware stack onto a single chip. The tight integration of these
functions eliminate interoperability, timing, and support issues found in competitive
products that offer “discrete implementation” wherein a chassis, a main motherboard,
a RAID storage controller, iSCSI software or controller, network interface cards, and
operating system software are picked separately and then assembled. D-Link SANs
outperform these discrete implementations and do so at a lower price point. They also
deliver mission critical data quickly with state-of-the-art reliability.
The SAN platform features 15 hot swappable Serial ATA (SATA) disk drive bays
supporting over 11TB raw capacity using 750GB hard drives (and even higher capacity
hard drives as they are introduced) in RAID level 0, 1, 1+0 and 5 configurations.
Users can quickly deploy a SAN using inexpensive SATA disk drives and depending
on their growing storage needs, they can simply add more drives.
Recommended Hard Drives
The Seagate Barracuda ES family of enterprise class SATA hard drives provides high
performance with very high reliability for business critical applications.
ST3250620NS 250GB
ST3400620NS 400GB
ST3500630NS 500GB
ST3750640NS 750GB
●Micro Rebuilds
» Protection against unresponsive SATA
commands by forcing a response within a
preset time limit.
●Online Capacity Expansion and
RAID Level Migration
D-Link Product Guide 2008
104
™
» Volumes can be expanded and/or migrated
to other RAID levels while online and with
minimal impact on users. For example, a
mirror volume of two drives can easily be
converted to a parity volume of three or more
drives while users continue to access this
storage.
DSN-2100
DSN-3400
Gigabit iSCSI SAN Array
10-Gigabit iSCSI SAN Array
● Entry-Level Nearline Storage Solution
● Integrated iSCSI System-on-a-Chip
(SoC)
● 4 10/100/1000BASE-T Ports
● 8 Drive Bays
● Over 6TB Capacity with 750GB Hard
Drives
● Embedded Disk Controller Supporting
RAID Levels 0, 1, 1+0, 5 & JBOD
● Up to 425MB Bandwidth
● 256MB to 4GB (256MB Standard) Cache
Memory
● 72 hrs Full Charge Battery Backup for
Cache
● Can Be Used as Replacement of DirectAttached Storage (DAS) Drives
● Fiber Nearline Storage Solution
● Integrated iSCSI System-on-a-Chip
(SoC)
● 1 10-Gigabit Port
● 15 Drive Bays
● Over 11TB Capacity with 750GB Hard
Drives
● Embedded Disk Controller Supporting
RAID Levels 0, 1, 1+0, 5 & JBOD
● Up to 1,160Mbytes Bandwidth
● 256MB to 4GB (256MB Standard) Cache
Memory
● 72 hrs Full Charge Battery Backup for
Cache
DSN-3200
Gigabit iSCSI SAN Array
● Mid-Range Nearline Storage Solution
● Integrated iSCSI System-on-a-Chip
(SoC)
● 8 10/100/1000BASE-T Ports
● 15 Drive Bays
● Over 11TB Capacity with 750GB Hard
Drives
● Embedded Disk Controller Supporting
RAID Levels 0, 1, 1+0, 5 & JBOD
● Up to 850MB Bandwidth
● 256MB to 4GB (256MB Standard) Cache
Memory
● 72 hrs Full Charge Battery Backup for
Cache
105
D-Link Product Guide 2008
StORAGE
Features & Benefits
● Network File Sharing
Network Attached Storage (NAS)
These Network Attached Storage (NAS) are compact storage devices that can be
easily connect to a home or office network, or to the Internet. Ideal for disk and file
sharing, these devices provide the hardware reliability and interoperability with major
operating systems. They come with embedded software for ready file access that
saves users the cost of buying separate OS software and the trouble of installing it.
» Share documents, music, photos,
videos across home/office network or on
Internet.
» Create central network point for backing
up valuable files.
●Compact Size & Low Cost
» Much smaller desktop size than PCbased servers.
» Can be deployed at a fraction of the cost
of a PC-based server.
●Ready for Operation
DNS-313
DNS-323
1-Bay Network Storage Enclosure
2-Bay Network Storage
Enclosure
» Integrated OS software, no need to
purchase and install separate software.
» Transparent multi-platform file sharing is
easily accessible at system power-on.
●UPnP AV Compatible
» Stream music, photos and video to
UPnP AV compatible network media
players.
●Built-in iTune and FTP Server
» Access stored music, video and other
files locally or over the Internet.
●High Speed Access
» For SATA network storage, RAID 0
combines both drives in a “striped”
configuration, enabling speeds up to
23Mbps read, 15Mbps write.
» Gigabit connection can increase these
speeds to 184Mbps read, 120Mbps
write.
●Flexible Drive Modes for SATA
Drives
» Standard mode to create 2 separately
accessible hard drives.
» JBOD mode combines both drives for
maximum space efficiency.
» RAID 0 combines both drives in “striped”
configuration for highest performance.
» RAID 1 provides redundancy drive
backup.
● 1 Open Bay for 3.5-Inch SATA Hard
Drive
● USB 2.0 Port for PC Connection
● 10/100/1000BASE-T Gigabit Network
Connection
● Built-in iTunes and FTP Servers
● Operates in Windows Environment
● Can Be Used as a Network Attached
Storage (NAS) or a Portable Hard Drive
(DAS) Directly Attachable to PC USB
Port
DNS-321
DNS-343
2-Bay Network Storage Enclosure
4-Bay Network Storage
Enclosure
●Power Management
» Helps conserve energy and extend hard
drive life
●Real-Time Backup
» Instant protection of storage data
without the need to manually back up
files and folders.
●User Access Control
» Administrators can set up different
storage permissions for different users
and groups
D-Link Product Guide 2008
106
● 2 Open Bays for 3.5-Inch SATA Hard
Drives
● USB 2.0 Print Server Port
● 10/100/1000BASE-T Gigabit Network
Connection
● Built-in FTP Server
● Supports Standard, JBOD, RAID 0,
RAID 1 Drive Modes
● Operable in Windows, Mac OS and
Linux Environments
● 2 Open Bays for 3.5-Inch SATA Hard
Drives
● 10/100/1000BASE-T Gigabit Network
Connection
● Built-in FTP Server
● Supports Standard, JBOD, RAID 0,
RAID 1 Drive Modes
● Operable in Windows, Mac OS and
Linux Environments
● 4 Open Bays for 3.5-Inch SATA Hard
Drives
● USB 2.0 Port for Printer and UPS
Connection
● 10/100/1000BASE-T Gigabit Network
Connection
● OLED Display Screen
● Built-in FTP Server
● Supports Standard, JBOD, RAID 0,
RAID 1, RAID 5 Drive Modes
● Operable in Windows, Mac OS and
Linux Environments
ANALOG MODEmS
Features & Benefits
● Latest V.92 Standard
Compliance
● Hardware Modems With OnBoard Components to Offload
Host PC’s Communication
Tasks
● Low-Cost Software Modems
for PC With Faster Processors
● Bundled BVRP Fax Software
to Send/Receive Fax
Dial-up Modems
Supporting line speeds of up to 56Kbps (receive rates) and 48Kbps (transmit rates), the
analog modems connect into the phone line to establish a dial-up Internet link. These
low-cost dial-up modems allows home users to surf the Internet or access e-mail without
the need for DSL, cable modem or ISDN subscriptions.
Complying with industry standards, the analog modems perform data compression
and error correction for fast and reliable transmission/reception. In addition to Internet
connection, these modems also support fax transfer, with transmission/reception rates
of up to 14.4Kbps.
DFM-562I
Analog Modem PCI Adapter
● V.92/V.90 Standards
● MIC Microphone & Speaker Jacks for
Loud Speaker Connection
● 2 RJ-11 Phone Jacks (to Phone Line &
Phone Set)
● Supports Windows
DFM-562E
Analog Modem
DFM-562IS
Analog Modem PCI Adapter
● Software Modem
● V.92/V.90 Standards
● 2 RJ-11 Phone Jacks (to Phone Line &
Phone Set)
● Supports Windows
DFM-560EL
● V.92/V.90 Standards
● RS-232 Serial Interface to PC
● MIC Microphone & Speaker Jacks for
Voice
● Supports Windows
● Powered Through External Power
Adapter
DU-562M
USB Analog Modem
Analog Modem
● V.90 Standard
● RS-232 Serial Interface to PC
● Supports Windows
● Powered Through External Power
Adapter
● Software Modem
● V.92/V.90 Standards
● USB Interface to PC
● Supports Telephone Answering Machine
(TAM)
● Supports Windows
● USB Bus Power, No External Power
Supply Required
107
D-Link Product Guide 2008
MULtImEDIA
Features & Benefits
● Streaming Multimedia to Home
Entertainment Center
» Stream Media Content from PC or
Network Storage to Entertainment
Center
» Listen to Digital Music on Stereo System
» View Digital Photos, Slideshows, Video
on TV
» Integrated 802.11g Wireless Connection
» Can Connect Through Ethernet
Interface
» Enjoy MP3 music, digital photos and
video footages in the comfort of the
living room.
●TV Screen Menu Selection via
Remote Control
» Users select file folders and file types
(JPEG, MPEG-4, etc.) in PC hard drive
to share; Media Player adds them to its
on-screen menu
» Use remote control to select and play.
Network Media Players
The Network Media Players unite a home network with the home entertainment
center, allowing users to share, access, and enjoy digital multimedia in the comfort
of the living room. They connect to the TV and let users access digital media content
stored on the PC or a network attached storage, browse music files, watch videos
and view digital photos. They also allow users to access on-line media contents on
the TV through a home broadband Internet connection. Users can listen to highquality digital music on a stereo system, share digital photos with friends and family,
and watch their favorite high-definition digital videos on a TV screen.
The Network Media Players support high-definition video in Windows Media Video 9
(WMV9), MPEG-2, MPEG-4, DivX® and DVR-MS formats. Users can enjoy videos
with resolutions up to 720p/1080i for the best picture quality from HDTV using an HDMI
connection, or connect to standard televisions using SCART or Composite Video
cables. Certain models (the DSM-510, for example) are DivX Certified, allowing users
to play DivX encoded movies (DivX format compressed video files) with exceptionally
high visual quality.
The Audio Adapters connect to flash drives, PC or hard drives to play digital sound.
They come with convenient remote control and can connect wirelessly to the Internet
to play broadcast radio programs and music. For quality sound, they can connect to
stereo systems. These appliances have sleek desktop design, suitable for placing in
the living room.
●Transparent Operation
» All file/folder sharing and streaming take
place behind the scene.
» Family members can work on programs
on computer while others are watching
digital video on TV screen.
●High-Definition Multimedia
Interface (HDMI)
» Connect to High-Definition TV for
pure sound and images of up to 1080
interlace resolution.
●Supported Audio Formats
» MP3 (up to 320kps)
» WMA (PCM only)
» AIFF
» WAV
» Ogg Vorbis
» WMV9
» MPEG 1
» MPEG 2
» MPEG 4
» Xvid with MP3 or CPM
» AVI (MPEG-4 Layer only)
DSM-320RD
Media Player
» M3U
» PLS
●Supported Subtitle Format
» SRT
» MP3 (Up to 320Kbps)
» WAV & AIFF (PCM only)
» WMA
» Ogg Vorbis JPEG (Grayscale, RGB,
YCbCy only)
» JPEG 2000
» BMP
● Supported Image Formats
» JPEG (Grayscale, RGB, YCbCy only)
» BMP (non-compressed)
» PNG
» TIFF (RGB only)
» JPEG 2000
» GIF
D-Link Product Guide 2008
●Audio Playlist Formats
●Audio/Image/Video
●Supported Video Formats
108
●UPnP AV & WCN Support
» IntelNetworked Media Product
Requirements (NMPR) compliance,
seamless integration with other UPnP
AV media devices.
» WindowsConnect Now (WCN)
simplifies configuration of all wireless
appliances.
● RCA/AV Audio Output
● RCA/AV Video Output
● S-video Output
● Component Video (or SCART Interface
for Europe)
● Optical Digital Audio Output with 5.1
Channel Audio Support
● Coax Digital Audio Output
● 802.11g Wireless Interface
● 10/100BASE-TX Ethernet Interface
● Built-in DVD Player Supporting DVD,
VCD, SVCD, CD, MP3 Formats
● Built-in Card Reader Supporting SD,
Compact Flash (Type I/II) and MMC
Formats
DSM-510
DSM-120
DSM-750
HD Media Player
Audio Adapter
Media Center Extender
● HDMI Interface
● Component Video (or SCART for Europe)
● Composite Audio and Video Output
● Optical Digital Audio Output
● Supports WMV9 Video Format
● DIVX ® Certified
● 802.11g Wireless Interface
● 10/100BASE-TX Ethernet Interface
● 2 USB Ports to Connect to Flash Drive
& PC
● Compartment for 2.5-Inch IDE Hard Drive
● Plays MP3 Music from Flash Drive, PC or
Attached Hard Drive
● Plays Internet Music & Radio Programs
● 802.11g Wireless Interface
● 10/100BASE-TX Ethernet Interface
● Optical Digital Audio Output
● Composite Audio Output
DSM-520
DPG-1200
HD Media Player
PC-on-TV Media Player
● HDMI Interface
● Component Video (or SCART for Europe)
● Composite Audio and Video Output
● S-Video Output
● Coax Digital Audio Output
● Optical Digital Audio Output
● Supports WMV9 Video Format
● 802.11g Wireless Interface
● 10/100BASE-TX Ethernet Interface
● Dual User Modes: Extender for Windows
Media Center and D-Link MediaLounge
● D-Link MediaLounge Mode Enables
Direct Access of Music, Photos, Video
from PCs, Network Attached Storage or
USB Flash Drives
● HDMI, Component Video, S-Video,
Composite Audio/Video
● Optical Digital Audio, Coax Digital Audio
● Dual Band 802.11a/g/Draft n Wireless
Interface
● 10/100BASE-TX Ethernet Interface
● Windows Connect Now via USB Flash
Drive
● Watch Movies, View Photos on TV
screen, Listen to Music Playing on
Computer
● VGA Video, Component Video
● Composite Audio/Video
● 802.11g Wireless Interface
● 10/100BASE-TX Ethernet Interface
109
D-Link Product Guide 2008
MULtImEDIA
Features & Benefits
● Internet PC Camera
» Useful for video chats, video e-mail,
personal surveillance, personal album
and remote tutorial over Internet.
» Can record digital video directly to a
PC’s hard drive and edit photos.
PC Cameras
The PC cameras are fully contained units with all the necessary hardware to capture
video for transmission over the Internet. These cameras connect to the PC’s USB
interface and draw power directly from the PC’s USB bus. Ideal for use with laptop
and portable computers, this camera can be used for video chats, video e-mail,
personal surveillance, personal album and remote tutorial. Software is provided to
record digital video directly to a PC’s hard drive and edit photos.
●Fully Contained Units
» Include all necessary hardware to
capture video for transmission over the
Internet.
●Connect to PC’s USB Port
» No need to plug in power adapter.
DSB-C120
DSB-C320
100K Pixel PC Camera
330K Pixel PC Camera
● 352 x 288 Resolution
● Color CMOS Sensor
● 24-Bit RGB Colors
● USB Connection to Computer
● Clip Provided for Mounting on Laptop
Computer or Monitor Screen
D-Link Product Guide 2008
110
● 640 x 840 Resolution
● Color CMOS Sensor
● 64 Million Colors
● Up to 30fps @ QVGA
● Built-in Microphone
● USB Connection to Computer
● Clip Provided for Mounting on Laptop
Computer or Monitor Screen
MULtImEDIA
USB Adapters & Hubs
The USB adapters and USB hubs provide plug-and-play connection for multimedia devices and peripherals. The USB hubs allow up
to 127 USB devices to be daisy chained. They offer increased functionality with additional bandwidth, allowing more peripherals to be
added to computers. They also support over-current detection for connected devices.
For older computers not equipped with USB ports, users can insert upgrade adapters to add USB ports to the computer system.
DUB-A2
DUB-C2
DUB-H4
2-Port USB 2.0 PCI Adapter
2-Port USB 2.0 CardBus Adapter
4-Port USB 2.0 Hub
● 2 USB 2.0 Downstream (Type A) Ports
● USB-IF Certified
● Supports Windows
● 2 USB 2.0 Downstream (Type A) Ports
● Supports Windows, Mac OS
● 4 USB 2.0 Type A Downstream Ports
● 1 USB 2.0 Type B Upstream Port
● USB-IF Certified
● Supports Windows, Mac OS
● 1.8 m USB Cable Provided
● Powered Through External AC Power
Adapter
DU-520
DUB-104
DUB-H7
5-Port USB 2.0 PCI Adapter
4-Port USB 2.0 Hub
7-Port USB 2.0 Hub
● 5 USB 2.0 Downstream (Type A) Ports
● USB-IF Certified
● Supports Windows, Mac OS
● 4 USB 2.0 Type A Downstream Ports
● 1 USB 2.0 Type A Upstream Dongle
● Built-in Compartment to Hold Fold-up
Dongle
● USB-IF Certified
● Supports Windows, Mac OS
● Slim Pocket-Sized, Lightweight, Easy to
Carry
● USB Bus Powered
● Optional External Power Adapter
● 7 USB 2.0 Type A Downstream Ports
● 1 USB 2.0 Type B Upstream Port
● USB-IF Certified
● Supports Windows, Mac OS
● 1.8 m USB Cable Provided
● Powered Through External AC Power
Adapter
111
D-Link Product Guide 2008
INDEX
7200-1200AC-------------------------------------------76
7200-1200DC-------------------------------------------76
7200-2000AC-------------------------------------------76
7200-2000DC-------------------------------------------76
7200-24--------------------------------------------------75
7200-24G------------------------------------------------75
7200-24P------------------------------------------------76
7200-2XG------------------------------------------------76
7200-48--------------------------------------------------75
7200-48P------------------------------------------------76
7200-4XG------------------------------------------------76
7200-ASE1----------------------------------------------75
7200-ASE2----------------------------------------------75
7200-ASE3----------------------------------------------75
7200-ASE4----------------------------------------------75
7200-CM1-----------------------------------------------75
7200-CM2-----------------------------------------------75
7200-CM3-----------------------------------------------75
7200-CM4-----------------------------------------------75
7206-Fan------------------------------------------------76
7210-Fan------------------------------------------------76
ANT24-0230--------------------------------------------37
ANT24-0401--------------------------------------------36
ANT24-0500--------------------------------------------36
ANT24-0501--------------------------------------------36
ANT24-0501C------------------------------------------36
ANT24-0502--------------------------------------------36
ANT24-0600--------------------------------------------36
ANT24-0700--------------------------------------------36
ANT24-0700C------------------------------------------37
ANT24-0800--------------------------------------------37
ANT24-0801--------------------------------------------37
ANT24-1200--------------------------------------------37
ANT24-1201--------------------------------------------37
ANT24-1400--------------------------------------------37
ANT24-1500--------------------------------------------37
ANT24-1800--------------------------------------------35
ANT24-1801--------------------------------------------35
ANT24-2100--------------------------------------------35
ANT24-CB03N-----------------------------------------37
ANT24-CB06N-----------------------------------------37
ANT24-CB09N-----------------------------------------37
ANT24-DLK3M----------------------------------------36
ANT24-ODU03M--------------------------------------36
ANT24-ODU1M----------------------------------------36
ANT24-ODU3M----------------------------------------36
ANT70-0800--------------------------------------------35
ANT70-0801--------------------------------------------35
ANT70-1000--------------------------------------------35
ANT70-1800--------------------------------------------35
D-Link Product Guide 2008
112
DAP-1150-----------------------------------------------23
DAP-1160-----------------------------------------------23
DAP-1353-----------------------------------------------35
DAP-1522-----------------------------------------------33
DAP-2553-----------------------------------------------30
DAP-2590-----------------------------------------------31
DAP-3220-----------------------------------------------26
DAS-3216------------------------------------------------2
DAS-3224------------------------------------------------2
DAS-3248------------------------------------------------2
DAS-3324------------------------------------------------2
DAS-3324G----------------------------------------------3
DAS-3324M----------------------------------------------3
DAS-4192------------------------------------------------3
DAS-4192-10--------------------------------------------3
DAS-4192-20--------------------------------------------3
DAS-4192-30--------------------------------------------3
DAS-4192-40--------------------------------------------3
DAS-4192-50--------------------------------------------3
DAS-4192-60--------------------------------------------3
DAS-4672------------------------------------------------3
DAS-4672-10--------------------------------------------3
DAS-4672-20--------------------------------------------3
DAS-4672-30--------------------------------------------3
DAS-4672-40--------------------------------------------3
DAS-4672-50--------------------------------------------3
DBT-122-------------------------------------------------41
DBT-900AP---------------------------------------------41
DCM-202-------------------------------------------------7
DCM-212-------------------------------------------------7
DCM-232-------------------------------------------------7
DCM-312-------------------------------------------------7
DCS-10------------------------------------------------- 100
DCS-20------------------------------------------------- 100
DCS-25------------------------------------------------- 101
DCS-45------------------------------------------------- 101
DCS-50------------------------------------------------- 101
DCS-60------------------------------------------------- 101
DCS-70------------------------------------------------- 101
DCS-910-------------------------------------------------99
DCS-920-------------------------------------------------99
DCS-2102-----------------------------------------------99
DCS-2120-----------------------------------------------99
DCS-2121-----------------------------------------------99
DCS-3110-----------------------------------------------99
DCS-3410-----------------------------------------------99
DCS-3415-----------------------------------------------99
DCS-3420-----------------------------------------------99
DCS-5220-----------------------------------------------99
DCS-5230-----------------------------------------------99
DCS-5300-----------------------------------------------99
DCS-5300G---------------------------------------------99
DCS-5610-----------------------------------------------99
DCS-6110-----------------------------------------------99
DCS-6410-----------------------------------------------99
DCS-6620-----------------------------------------------99
DCS-6620G---------------------------------------------99
DCS-7410-----------------------------------------------99
DCS-7411-----------------------------------------------99
DEM-201F-----------------------------------------------61
DEM-201FL---------------------------------------------61
DEM-210-------------------------------------------------87
DEM-211-------------------------------------------------87
DEM-301T-----------------------------------------------61
DEM-301G----------------------------------------------61
DEM-310GT--------------------------------------------87
DEM-311GT---------------------------------------------87
DEM-312GT2-------------------------------------------87
DEM-314GT--------------------------------------------87
DEM-315GT--------------------------------------------87
DEM-330R----------------------------------------------87
DEM-330T-----------------------------------------------87
DEM-331R----------------------------------------------87
DEM-331T-----------------------------------------------87
DEM-410X---------------------------------------- 39, 70, 68
DEM-410CX------------------------------------- 39, 70, 68
DEM-421XT---------------------------------------------87
DEM-422XT---------------------------------------------87
DEM-423XT---------------------------------------------87
DEM-CB300CX------------------------------------ 68, 70
DES-1005D---------------------------------------------54
DES-1008D---------------------------------------------54
DES-1008F----------------------------------------------54
DES-1016D---------------------------------------------54
DES-1016R+-------------------------------------------54
DES-102F-----------------------------------------------55
DES-1024D---------------------------------------------54
DES-1024R+-------------------------------------------55
DES-1026G---------------------------------------------55
DES-1048-----------------------------------------------55
DES-1050G---------------------------------------------55
DES-1228-----------------------------------------------58
DES-1228P----------------------------------------- 38, 58
DES-1250G---------------------------------------------59
DES-1252-----------------------------------------------59
DES-2108-----------------------------------------------57
DES-3010G---------------------------------------------60
DES-3010F----------------------------------------------60
DES-3010FL--------------------------------------------60
DES-3016-----------------------------------------------60
DES-3018-----------------------------------------------61
DES-3026-----------------------------------------------61
DES-3028-----------------------------------------------61
DES-3028P---------------------------------------------61
DES-3052-----------------------------------------------61
DES-3052P---------------------------------------------61
INDEX
DES-3526-----------------------------------------------65
DES-3526DC-------------------------------------------65
DES-3528-----------------------------------------------65
DES-3528DC-------------------------------------------65
DES-3528G---------------------------------------------66
DES-3528P---------------------------------------------66
DES-3550-----------------------------------------------66
DES-3552-----------------------------------------------66
DES-3552P---------------------------------------------66
DES-3828-----------------------------------------------66
DES-3828DC-------------------------------------------66
DES-3828P---------------------------------------------66
DES-3852-----------------------------------------------66
DES-6500-----------------------------------------------72
DES-6504-----------------------------------------------72
DES-6505-----------------------------------------------73
DES-6506-----------------------------------------------73
DES-6507-----------------------------------------------73
DES-6508-----------------------------------------------72
DES-6509-----------------------------------------------73
DES-6510-----------------------------------------------73
DES-6511------------------------------------------------73
DES-6512-----------------------------------------------73
DES-7206-----------------------------------------------75
DES-7210-----------------------------------------------75
DEV-3418-------------------------------------------------9
DEV-3418DC--------------------------------------------9
DEV-3426-------------------------------------------------9
DEV-3426DC--------------------------------------------9
DEV-3710l------------------------------------------------9
DEV-3718l------------------------------------------------9
DEV-3726l------------------------------------------------9
DFE-528TX---------------------------------------------84
DFE-530+R---------------------------------------------85
DFE-530+P---------------------------------------------85
DFE-530TX---------------------------------------------84
DFE-530TX+--------------------------------------------84
DFE-534R3---------------------------------------------85
DFE-534P3----------------------------------------------85
DFE-538R-----------------------------------------------85
DFE-538P-----------------------------------------------85
DFE-538TX---------------------------------------------84
DFE-550TX---------------------------------------------84
DFE-551FX---------------------------------------------85
DFE-551R-----------------------------------------------85
DFE-551P-----------------------------------------------85
DFE-554C-----------------------------------------------85
DFE-554CP---------------------------------------------85
DFE-580TX---------------------------------------------85
DFE-690TXD-------------------------------------------85
DFE-855-------------------------------------------------90
DFL-200-------------------------------------------------49
DFL-210-------------------------------------------------49
DFL-210-IPS-12---------------------------------------51
DFL-260-------------------------------------------------50
DFL-260-AV-12----------------------------------------52
DFL-260-IPS-12---------------------------------------51
DFL-260-WCF-12-------------------------------------53
DFL-800-------------------------------------------------49
DFL-800-IPS-12---------------------------------------51
DFL-860-------------------------------------------------50
DFL-860-AV-12----------------------------------------52
DFL-860-IPS-12---------------------------------------51
DFL-860-WCF-12-------------------------------------53
DFL-1600------------------------------------------------49
DFL-1600-IPS-12-------------------------------------51
DFL-2500------------------------------------------------49
DFL-2500-IPS-12-------------------------------------51
DFM-560EL------------------------------------------- 107
DFM-5621--------------------------------------------- 107
DFM-5621S------------------------------------------- 107
DFM-562E--------------------------------------------- 107
DGE-528R-----------------------------------------------85
DGE-528T-----------------------------------------------86
DGE-530T-----------------------------------------------86
DGE-560SX---------------------------------------------86
DGE-660TD---------------------------------------------86
DGL-4500-----------------------------------------------33
DGS-712-------------------------------------------------87
DGS-1005D---------------------------------------------56
DGS-1008D---------------------------------------------56
DGS-1008TL-------------------------------------------56
DGS-1016D---------------------------------------------56
DGS-1024D---------------------------------------------56
DGS-1216T---------------------------------------------59
DGS-1224T---------------------------------------------59
DGS-1248T---------------------------------------------59
DGS-3024-----------------------------------------------62
DGS-3048-----------------------------------------------62
DGS-3100-24TG--------------------------------------63
DGS-3100-24-------------------------------------------63
DGS-3100-24P-----------------------------------------63
DGS-3100-48-------------------------------------------63
DGS-3100-48P-----------------------------------------63
DGS-3200-10-------------------------------------------64
DGS-3200-16-------------------------------------------64
DGS-3426-----------------------------------------------67
DGS-3426P---------------------------------------------67
DGS-3427-----------------------------------------------68
DGS-3450-----------------------------------------------68
DGS-3612-----------------------------------------------69
DGS-3612G---------------------------------------------70
DGS-3627-----------------------------------------------70
DGS-3627G---------------------------------------------70
DGS-3650-----------------------------------------------70
DHP-200-------------------------------------------------93
DHP-201-------------------------------------------------93
DHP-300-------------------------------------------------93
DHP-301-------------------------------------------------93
DI-524----------------------------------------------------23
DI-524UP------------------------------------------------23
DI-604----------------------------------------------------19
DI-604UP------------------------------------------------19
DI-624----------------------------------------------------27
DI-624S--------------------------------------------------27
DI-704P--------------------------------------------------19
DI-707P--------------------------------------------------19
DI-784----------------------------------------------------28
DI-804HV------------------------------------------------20
DI-808HV------------------------------------------------20
DI-824VUP----------------------------------------------21
DI-LB604------------------------------------------------19
DIR-100--------------------------------------------------19
DIR-120--------------------------------------------------19
DIR-130--------------------------------------------------21
DIR-300--------------------------------------------------23
DIR-301--------------------------------------------------23
DIR-320--------------------------------------------------23
DIR-330--------------------------------------------------21
DIR-400--------------------------------------------------27
DIR-450--------------------------------------------------44
DIR-451--------------------------------------------------44
DIR-460--------------------------------------------------45
DIR-461--------------------------------------------------45
DIR-462--------------------------------------------------45
DIR-605--------------------------------------------------31
DIR-610--------------------------------------------------45
DIR-615--------------------------------------------------31
DIR-635--------------------------------------------------35
DIR-655--------------------------------------------------33
DIR-855--------------------------------------------------33
DKT-400-------------------------------------------------31
DKVM-2K------------------------------------------------94
DKVM-2KU---------------------------------------------94
DKVM-2U------------------------------------------------95
DKVM-4K------------------------------------------------95
DKVM-4U------------------------------------------------95
DKVM-8E------------------------------------------------95
DKVM-16------------------------------------------------95
DKVM-IP1-----------------------------------------------95
DMC-300M----------------------------------------------88
DMC-300SC--------------------------------------------88
DMC-515SC--------------------------------------------88
113
D-Link Product Guide 2008
INDEX
DMC-530SC--------------------------------------------88
DMC-560SC--------------------------------------------89
DMC-615SC--------------------------------------------89
DMC-700SC--------------------------------------------89
DMC-805G----------------------------------------------89
DMC-810SC--------------------------------------------89
DMC-820SC--------------------------------------------89
DMC-920R----------------------------------------------89
DMC-920T-----------------------------------------------89
DMC-1000-----------------------------------------------90
DMC-1001-----------------------------------------------90
DMC-1002-----------------------------------------------90
DMC-1530SC------------------------------------------89
DMC-1580SC------------------------------------------89
DMC-1910R---------------------------------------------90
DMC-1910T---------------------------------------------90
DNS-313----------------------------------------------- 106
DNS-321----------------------------------------------- 106
DNS-323----------------------------------------------- 106
DNS-343----------------------------------------------- 106
DP-300+-------------------------------------------------97
DP-300U-------------------------------------------------97
DP-301P+-----------------------------------------------96
DP-301U-------------------------------------------------96
DP-G310-------------------------------------------------97
DP-G321-------------------------------------------------97
DPG-1200--------------------------------------------- 109
DPG-2100-----------------------------------------------24
DPH-50U------------------------------------------------13
DPH-140S-----------------------------------------------16
DPH-150S-----------------------------------------------16
DPH-150SE---------------------------------------------17
DPH-400S-----------------------------------------------17
DPH-400SE---------------------------------------------17
DPH-400SEDM----------------------------------------17
DPN-301-------------------------------------------------10
DPN-301L-----------------------------------------------10
DPN-301T-----------------------------------------------11
DPN-304-------------------------------------------------11
DPN-3012-E--------------------------------------------11
DPR-1061-----------------------------------------------97
DPR-1260-----------------------------------------------97
DPS-200-------------------------------------------------78
DPS-300-------------------------------------------------78
DPS-500-------------------------------------------------78
DPS-500DC---------------------------------------------78
DPS-600-------------------------------------------------78
DPS-800-------------------------------------------------78
DPS-900-------------------------------------------------79
DPS-CB400---------------------------------------------79
DS-601---------------------------------------------------47
D-Link Product Guide 2008
114
DS-605---------------------------------------------------47
DSB-C120--------------------------------------------- 110
DSB-C320--------------------------------------------- 110
DSD-150-------------------------------------------------46
DSL-320B------------------------------------------------4
DSL-320T------------------------------------------------4
DSL-321B------------------------------------------------4
DSL-322B------------------------------------------------4
DSL-322T------------------------------------------------4
DSL-323B------------------------------------------------4
DSL-380T------------------------------------------------4
DSL-382T------------------------------------------------4
DSL-520B------------------------------------------------5
DSL-520T------------------------------------------------5
DSL-521B------------------------------------------------5
DSL-522T------------------------------------------------5
DSL-526B------------------------------------------------5
DSL-527B------------------------------------------------5
DSL-580T------------------------------------------------5
DSL-582T------------------------------------------------5
DSL-2300B----------------------------------------------4
DSL-2320B----------------------------------------------4
DSL-2322B----------------------------------------------4
DSL-2324B----------------------------------------------4
DSL-2500B----------------------------------------------5
DSL-2500U----------------------------------------------5
DSL-2502B----------------------------------------------5
DSL-2504B----------------------------------------------5
DSL-2520B----------------------------------------------5
DSL-2520U----------------------------------------------5
DSL-2522B----------------------------------------------5
DSL-2524B----------------------------------------------5
DSL-2540B----------------------------------------------5
DSL-2540T-----------------------------------------------5
DSL-2540U----------------------------------------------5
DSL-2541T-----------------------------------------------5
DSL-2542B----------------------------------------------5
DSL-2543B----------------------------------------------5
DSL-2640B----------------------------------------------5
DSL-2640R----------------------------------------------5
DSL-2640T-----------------------------------------------5
DSL-2640U----------------------------------------------5
DSL-2641B----------------------------------------------5
DSL-2641T-----------------------------------------------5
DSL-2642B----------------------------------------------5
DSL-2643B----------------------------------------------5
DSL-2740B----------------------------------------------6
DSL-2741B----------------------------------------------6
DSL-2740R----------------------------------------------6
DSL-2741R----------------------------------------------6
DSL-3202B----------------------------------------------4
DSL-3204B----------------------------------------------4
DSL-5540C----------------------------------------------8
DSL-6301i------------------------------------------------8
DSL-6540i------------------------------------------------8
DSL-6541i------------------------------------------------8
DSL-6640i------------------------------------------------9
DSL-6741i------------------------------------------------9
DSL-G624M---------------------------------------------5
DSL-G804V----------------------------------------------6
DSM-120----------------------------------------------- 109
DSM-320RD------------------------------------------ 108
DSM-510----------------------------------------------- 109
DSM-520----------------------------------------------- 109
DSM-750----------------------------------------------- 109
DSN-2100--------------------------------------------- 105
DSN-3200--------------------------------------------- 105
DSN-3400--------------------------------------------- 105
DU-520------------------------------------------------- 111
DU-562M---------------------------------------------- 107
DUB-104----------------------------------------------- 111
DUB-1210-----------------------------------------------42
DUB-2240-----------------------------------------------42
DUB-9240-----------------------------------------------42
DUB-A2------------------------------------------------ 111
DUB-C2------------------------------------------------ 111
DUB-H4------------------------------------------------ 111
DUB-H7------------------------------------------------ 111
DV-600P----------------------------------------------- 102
DV-600S----------------------------------------------- 102
DVA-3060i------------------------------------------------6
DVA-3061i------------------------------------------------6
DVA-3340S----------------------------------------------6
DVA-3340SB--------------------------------------------6
DVA-6541i------------------------------------------------8
DVA-G3342SB------------------------------------------6
DVA-G3342SC------------------------------------------6
DVA-G3670B--------------------------------------------6
DVA-G3671B--------------------------------------------6
DVA-G3672B--------------------------------------------6
DVA-N3690i---------------------------------------------6
DVA-N3691i---------------------------------------------6
DVA-N6671i---------------------------------------------9
DVC-10------------------------------------------------- 103
DVC-20------------------------------------------------- 103
DVC-1000--------------------------------------------- 103
DVC-1100--------------------------------------------- 103
DVC-2000--------------------------------------------- 103
DVG-1102S---------------------------------------------13
DVG-1401SP-------------------------------------------13
DVG-2016S---------------------------------------------14
DVG-2032S---------------------------------------------14
DVG-2101S---------------------------------------------12
DVG-2101SP-------------------------------------------12
INDEX
DVG-3016S---------------------------------------------14
DVG-3032S---------------------------------------------14
DVG-4032S---------------------------------------------15
DVG-4088S---------------------------------------------15
DVG-5004S---------------------------------------------14
DVG-5008S---------------------------------------------14
DVG-5102SP-------------------------------------------12
DVG-5121SP-------------------------------------------13
DVG-5401SP-------------------------------------------13
DVG-5402SP-------------------------------------------13
DVG-5802S---------------------------------------------13
DVG-6004S---------------------------------------------14
DVG-6008S---------------------------------------------14
DVG-7022S---------------------------------------------14
DVG-7044S---------------------------------------------15
DVG-7062S---------------------------------------------15
DVG-G5402SP-----------------------------------------13
DVX-1000-----------------------------------------------18
DWL-G520----------------------------------------------25
DWL-G550----------------------------------------------26
DWL-G630----------------------------------------------22
DWL-G650----------------------------------------------25
DWL-G680----------------------------------------------25
DWL-G730AP------------------------------------------23
DWL-P50------------------------------------------------92
DWL-P200----------------------------------------------92
DWL-P1012---------------------------------------------92
DWL-R60AT--------------------------------------------36
DWM-110------------------------------------------------45
DWM-652------------------------------------------------44
DWS-3024-----------------------------------------------39
DWS-3026-----------------------------------------------39
DWA-110------------------------------------------------22
DWA-120------------------------------------------------25
DWA-130------------------------------------------------30
DWA-140------------------------------------------------35
DWA-160------------------------------------------------32
DWA-510------------------------------------------------22
DWA-520------------------------------------------------26
DWA-542------------------------------------------------34
DWA-547------------------------------------------------34
DWA-552------------------------------------------------32
DWA-556------------------------------------------------32
DWA-610------------------------------------------------22
DWA-620------------------------------------------------25
DWA-642------------------------------------------------34
DWA-643------------------------------------------------32
DWA-645------------------------------------------------34
DWA-652------------------------------------------------32
DWL-2100AP------------------------------------------26
DWL-2200AP------------------------------------------26
DWL-2700AP------------------------------------------23
DWL-3140AP------------------------------------------39
DWL-3200AP------------------------------------------26
DWL-3260AP------------------------------------------26
DWL-3500AP------------------------------------------39
DWL-7100AP------------------------------------------29
DWL-7700AP------------------------------------------29
DWL-8200AP------------------------------------------29
DWL-8500AP------------------------------------------39
DWL-AG132--------------------------------------------28
DWL-AG530--------------------------------------------28
DWL-AG660--------------------------------------------28
DWL-G122----------------------------------------------22
DWL-G132----------------------------------------------25
DWL-G510----------------------------------------------22
KVM-121-------------------------------------------------94
KVM-221-------------------------------------------------94
ECB-ANT240500--------------------------------------37
ECB-ANT240800--------------------------------------37
ECB-ANT241200--------------------------------------37
115
D-Link Product Guide 2008
Foreword
D-Link, a global leader in networking business, has been developing networking products for over 21 years to
improve the lives of people by providing business, broadband, consumer, and digital home solutions. D-Link has
been the market leader in SOHO and SMB networking, holding a lead market share of 24.4% worldwide¹. The
Company has established itself as a worldwide name among networking products and technology, being recognized
by BusinessWeek in both their list of “Top 100 Information Technology Companies,” and also being ranked ninth for
“The Best Returns.” Most recently, D-Link has earned 5-star certification from TÜV Rheinland, which recognizes not
only D-Link’s brand value, but also its social responsibilities as a leading networking company.
Business Solutions
D-Link delivers a wide range of powerful networking solutions that are designed to create exceptional value for
businesses at the enterprise, departmental, and workgroup processing levels. D-Link offers powerful solutions for
upgrading to 10-Gigabit Ethernet and 802.11n draft WLAN. Its metro network, multilayer campus, and
award-winning xStack switches provide powerful performance, flexible deployment, security, and centralized
management suitable for any business environment, while its industry’s unique unified wired and wireless switching
solutions seamlessly integrate wired and wireless LAN together.
D-Link xStack switches, operating in conjunction with D-Link NetDefend Unified Threat Management (UTM)
firewalls, have helped create robust network security for protecting businesses from both internal and external
threats. D-Link’s network security appliances running the NetDefend security operating system have obtained the
highest level of ICSA Labs firewall certification (Firewall 4.1 with Corporate Level), and have now also satisfied the
stringent testing criteria of IPSec 1.2 Enhanced Certification.
Awards & Accolades
PC User Magazine
Best Buy Award
July 2007
INTEROP Japan
DGS-3200-10 Switch
Best of INTEROP Show Award
June 2007
BenchmarkReviews.com
DNS-323 Network Storage Enclosure
& DIR-655 Xtreme N Router
Golden Tachometer Award
August 2007
Review Lab
Network Storage Enclosure DNS-323
Recommended Product Award
November 2007
PC Magazine
DIR-655 Xtreme N Wireless Router
Editors’ Choice Award
May 2007
TÜV Rheinland
TÜV Rheinland Star* Award
Highest 5-star Certification
October 2007
Broadband Solutions
D-Link develops and builds the equipment that service providers need to offer reliable high-speed communication.
Providing more than just a source of communication for users, broadband service providers today offer users
applications such as network storage, integrated voice and video, and IP Surveillance. VoIP is also establishing
itself as a cost-effective option for utilizing network convergence, promoting users to voice services on their IP VPN.
The new wireless standard IEEE 802.16 WiMAX will play an important role in networking, and D-Link will be
shipping a complete line of WiMAX products in 2008.
D-Link’s wide range of broadband offerings, including xDSL, PON devices, new generation IAD, IPTV, and VoIP
related solutions, allows service providers to customize systems to the specific needs of subscribers in every
category to accommodate Internet bandwidth and content. D-Link’s in-depth research and development make it
possible to provide innovative solutions for today that can assimilate to the future needs of tomorrow’s markets.
Consumer & Digital Home Solutions
D-Link brings the digital home closer to consumers from around the world for productivity and entertainment. It
incorporates cutting-edge network technology into next-generation solutions, which includes storage, IP
surveillance, multimedia, gaming, VoIP, enhanced high-speed Powerline, and UWB related products. D-Link
enables users to connect to a wide range of devices for seamless interoperability that can be accessed anytime,
anywhere. The advanced communication products of D-Link can stream data wirelessly throughout the home and
remotely control various devices.
The interactive home based on IP solutions is the next step for the evolution of the digital home concept, bringing
technology within reach of all consumers. D-Link’s progress in products, like storage, digital media players, IP
surveillance, gaming and video conferencing for consumers, will enable it to develop automated network solutions
that enhance the lives of digital home consumers.
ChannelPartner
Preferred Vendor 2008 for Network
and Telecommunication
February 2008
International CES
DSM-750, DUB-2240, DGL-4500
and DSM-210
Innovations Honoree Designation
November 2007
PC Magazine
Service & Quality 2007
Readers’ Choice
November 2007
PC Authority
A-List & Labs Test Award
November 2007
Environmental Responsibility
D-Link recognizes its responsibility towards its business growth and society, constantly adjusting and innovating
technology to meet the needs of both the consumers and the environment. The Company has been actively working
to reduce energy consumption, achieving certifications such as Energy Star and RoHS compliance, and developing
Green Ethernet products to help protect the Earth. D-Link progressively works to create solutions that benefit both
users and the environment, working towards a brighter future.
¹ Source: In-Stat 2007 Q3
BusinessWeek
Top 100 List Information Technology Companies
Top Ten Companies That Deliver The Best Returns
July 2007
Computer Power User Magazine
DIR-655 Xtreme N Wireless Router
Best Networking Device
November 2007
Product Guide 2008
®
Building Networks for People
2008
Product Guide
Hexachrome Orange
®
Building Networks for People
D-Link Corporation, No. 289 Xinhu 3rd Road, Neihu, Taipei 114, Taiwan
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
