I n v e r t e r / C h a r g e r

Atom

• 600VA simulated sine wave inverter

• Built-in transformer

• Wide input voltage range

• 10 A standard charging current

• Auto restart while AC is recovering

• Overload, overcharge and short circuit protection

• Cold start function

• Offering LED or LCD front panels for selection

Mighty

• 850VA/1.5K VA simulated sine wave inverter

• Built-in transformer

• Selectable input voltage range for home appliances or personal computers

• 12VDC or 24VDC available

• Selectable charging current : 10A or 20A

• Auto restart while AC is recovering

• Overload, overcharge and short circuit protection

• Generator compatible

•Cold start function

Inverter/Charger Selection Guide

MODEL

CAPACITY

INPUT

Voltage

Atom 600

600 VA / 420 W

Mighty 850

850 VA / 600 W

Mighty 1.5K

1500 VA / 1050 W

Acceptable Voltage Range

Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Transfer Time

Waveform (Batt. Mode)

BATTERY

Battery Voltage

Floating Charge Voltage

Low Battery Alarm Voltage @ 50% Load

Shutdown Voltage

Overcharge Protection

Maximum Charge Current

PROTECTION

Full Protection

INDICATORS

100 - 290 VAC

12 VDC

13.7 VDC ± 2%

10.6 VDC ± 2%

9.9 VDC ± 2%

14.5 VDC ± 2%

10 A

230 VAC

180-260 VAC (For Personal Computers)

100-300 VAC (For Home Appliances)

50Hz/60Hz (Auto Sensing)

230V ±10%

20 ms (typical)

Simulated Sine wave

12 VDC

13.7 VDC ± 2%

10.6 VDC ± 2%

9.9 VDC ± 2%

24VDC

27.4 VDC ± 2%

21.2 VDC ± 2%

19.8 VDC ± 2%

15.0 VDC ± 2%

10 A or 20 A (Selectable)

30.0 VDC ± 2%

Overload, overcharge, and short circuit protection

LCD Display

LED

Display

Line Mode

Battery Mode

Fault

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

359 x 97 x 147

5.1

0℃ to 50℃

-15℃ to 50℃

Product specifications are subject to change without further notice

Line Mode, Battery Mode, Load Level, Battery Level, Input Voltage,

Output Voltage, Overload, Fault and Low Battery

Green lighting

Yellow flashing

Red lighting

9.0

289 x 290 x 127

0 to 90% Relative Humidity(Non-condensing)

0℃ to 40℃

-15℃ to 70℃

12.0

Advancing Power

2

I n v e r t e r / C h a r g e r

Axpert MS

• Pure sine wave inverter

• Selectable input voltage range for home appliances and personal computers

• Selectable charging current

• Auto restart while AC is recovering

• Overload and short circuit protection

• Generators & Computer-related devices compatible

• Smart battery charger design for optimized battery performance

• Cold start function

Axpert MS Inverter Selection Guide

MODEL Axpert MS 700

CAPACITY

INPUT

700 VA / 500 W

Voltage

Selectable Voltage Range

230 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50/60 Hz (Auto sensing) Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

1400 VA

230VAC ± 5%

Axpert MS 1.2K

1200 VA / 840 W

2400 VA

Transfer Time

90%

10 ms (For Personal Computers)

20 ms (For Home Appliances)

Pure sine wave Waveform (Batt. Mode)

BATTERY & AC CHARGER

Battery Voltage

Floating Charge Voltage

Low Battery Alarm Voltage

12 VDC

13.5 VDC

11.5 VDC

10.5 VDC

15 VDC

Shutdown Voltage

Overcharge Protection

Maximum AC Charge Current

PROTECTION

Full Protection

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Product specifications are subject to change without further notice

10 A or 15 A

4.5

Overload and short circuit protection

289 x 290 x 127

0 to 90% Relative Humidity (Non-condensing)

0℃ to 50℃

-15℃ to 70℃

10 A or 20 A

4.8

3

www.voltronicpower.com

I n v e r t e r / C h a r g e r

+Nova Modular Inverter/Charger

• Modular scalable design up to 8 units

• Power factor 1

• 3-in-1: inverter, AC/DC charger or PV charger

• Hot-swappable design simplifies installation and maintenance

• Automatic load sharing on AC and DC output

• High efficiency

• Overload and short circuit protection

Description

+Nova is a compact and scalable power module support up to 20KW power. It’s designed with bi-direction concept which can be set as either AC/DC, DC/DC charger or DC/AC inverter. With up to 8 power modules, it can be separated to operate in different operation mode to meet diverse power requirement.

+Nova is designed with hot-swappble inverter/charger module which ensure low MTTR, reduction in service cost and meets the future expansion demands.

Multifunction Operating

Pure Inverter System

External

Battery packs

BATTERY

8 DC/AC inverters

Max. output power for loads:20KW

Hybrid System

Utility

Solar Input

External

Battery packs

BATTERY

2 AC/DC Chargers

2 PV Chargers

4 DC/AC Inverters

2 AC/DC chargers, 2 PV chargers, 4 DC/AC inverters

Max. AC/DC charger capacity: 120Amp

Max. PV charger capacity: 120Amp

Max. output power for loads: 10KW

Inverter Charger System

Utility

External

Battery packs

BATTERY

4 AC/DC Chargers

4 DC/AC Inverters

4 AC/DC chargers, 4 DC/AC inverters

Max. AC/DC charger capaity: 240Amp

Max. output power for loads: 10KW

Super Charger System

4 AC/DC Chargers

Utility

Solar Input

4 PV Chargers

External

Battery packs

BATTERY

4 AC/DC chargers, 4 PV chargers

Max. AC/DC charger capacity: 240Amp

Max. PV charger capacity: 240Amp

Advancing Power

4

I n v e r t e r / C h a r g e r

+Nova Modular Inverter/Charger Selection Guide

MODEL

CAPACITY

SET AS DC/AC INVERTER

DC INPUT

Nominal DC Voltage

+Nova

2500VA/2500W

48VDC

Operating Voltage Range

Voltage Ripple

40VDC ~ 60VDC

2.0mV

Peak to Peak Noise

Inrush Current

AC OUTPUT

Nominal Voltage

AC Voltage Regulation

Frequency Range

Peak Efficiency

Harmonic Distortion

150mV up to 100MHz

< 2 x Irated

220/230/240 VAC (selectable)

± 2% (max.)

50Hz ± 0.1Hz

> 93%

< 3% THD (Linear Load)

< 5% THD (Non-linear Load)

> 150% for 5 secs, >110% for 10 secs

<5% at 50-100% load

Overload Capability

Load Sharing

SET AS AC/DC CHARGER

AC INPUT

Nominal Voltage

Operating Voltage Range

Frequency Range

DC OUTPUT

Nominal Voltage

Max. Charging Current

Charging Method

SET AS DC/DC (PV) CHARGER

PV INPUT

Maximum Open Circuit Voltage

MPPT Voltage Range

Maximum Charging Current

DC OUTPUT

Nominal Voltage

Max. Charging Current

Charging Method

GENERAL

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Safety

Noise Level

Product specifications are subject to change without further notice

230 VAC

185 VAC ~ 265 VAC

50Hz/60Hz (Auto sensing)

54 VDC

60A

3-step algorithm

400VDC

200VDC ~ 370VDC

60A

54 VDC

60A

3-step algorithm

409 x 215 x 88

6

5% ~ 95% RH (No condensing)

-20°C to 60°C

IEC60950

Less than 50dB @ 1 Meter

5

www.voltronicpower.com

S o l a r C h a r g e C o n t r o l l e r

PWM Solar Charge Controller

• 12VDC or 24VDC available

• Multi-stage charging method

• Lightweight design

SCC-PWM-120W

SCC-PWM-240W

SCC-PWM-360W

SCC-PWM-720W

SCC-PWM-600W

SCC-PWM-1200W

PWM Solar Charge Controller Selection Guide

MODEL

INPUT

Maximum PV Array Open

Circuit Voltage

SCC-PWM-120W SCC-PWM-240W SCC-PWM-360W SCC-PWM-600W SCC-PWM-720W SCC-PWM-1200W

25 VDC 50 VDC 75 VDC 75 VDC 75 VDC 75 VDC

120 W

10 A

240 W 360 W

30 A

600 W

50 A

720 W

30 A

1200 W

50 A

Maximum PV Array Power

Maximum Current

OUTPUT

Nominal Battery Voltage

Connected Battery Type

Maximum Charging Current

Ripple Voltage

12 VDC

10 A

24 VDC 12 VDC 12 VDC

Sealed lead acid battery

30 A 50 A

< ± 1 V

24 VDC

30 A

24 VDC

50 A

Charging Method

Two stages: bulk and floating 1 / floating 2

Three stages: bulk, abs cv, floating

INDICATORS

LED Display Green LED indicating charging status

PHYSICAL

Dimension, D X W X H (mm)

Net Weight

Connector

Type of Mechanical Protection

ENVIRONMENT

Operating Temperature

Storage Temperature

76.5 x 60 x 30.8

160 g

Altitude

Product specifications are subject to change without further notice

91.6 x 75 x 30.8

240 g

100 x 85 x 40.5

320 g

Input/Output terminal block

IP 31

-20°C to 55°C

-40°C to 75°C

0 ~ 3000 m

91.6 x 75 x 30.8

240 g

100 x 85 x 40.5

320 g

Advancing Power

6

S o l a r C h a r g e C o n t r o l l e r

MPPT Solar Charge Controller

SCC-MPPT 300W

• Intelligent Maximum Power Point Tracking technology

• Built-in DSP controller with high performance

• Automatic battery voltage detection (Only for 600W and 3KW)

• Battery temperature sensor (BTS) automatically provides temperature compensation (Only for 3KW)

• Three-stage charging optimizes battery performance

• Auto load-detection

• Multifunction LCD displays detailed information

• Reverse polarity protection for solar panel and battery

• Overcharge and overload protection

• Suitable for different battery types

SCC-MPPT 600W/

SCC-MPPT 850W

SCC-MPPT 3KW

Standalone Solar Power System:

Solar panel

External battery packs

Inverter

SCC-MPPT

Combined MPPT technology and DSP controller, SCC-MPPT will convert best voltage to charge battery based on varied temperature.

Compared to traditional solar charge controller, it allows your solar panels to operate at their optimum power output voltage, providing higher efficiency up to 98% with lower power loss.

Integrated SCC-MPPT with inverter, solar panel, and external battery packs, it will become a standalone solar power system to generate green power for your home appliances. SCC-MPPT will convert solar power to charge external batteries, and then provide power to home appliances via inverter.

Home appliances

MPPT Solar Charge Controller Selection Guide

MODEL

INPUT

MPPT Range @ Operating Voltage

Maximum PV Array Open Circuit Voltage

Maximum PV Array Power

Maximum Current

OUTPUT

Nominal Battery Voltage

SCC-MPPT 300W SCC-MPPT 600W

15 VDC ~ 33 VDC 15 VDC ~ 33 VDC

50 VDC

300 W

50 VDC

300 W

18 A

SCC-MPPT 850W

30 VDC ~ 66 VDC 45 VDC ~ 88 VDC

75 VDC

600 W

98VDC

850 W

17A

SCC-MPPT 3KW

60 VDC ~ 115 VDC

145VDC

800W 1600W 3200W

50 A

Connected Battery Type

Maximum Charging Current

Maximum Efficiency

Charging Method

PROTECTION

Overload Protection

Overcharge Protection

Polarity Reversal Protection @

Solar Cell & Battery

INDICATORS

LCD Panel

LED Display

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (Kgs)

Type of Mechanical Protection

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Altitude

12 VDC

135 x 170 x 57.5

0.92

Product specifications are subject to change without further notice

12 VDC

25 A 20A

98%

Three stages: bulk, absorption, and floating

> 110% : audible alarm

Yes

Yes

12 VDC 24 VDC 48 VDC

Sealed lead acid, AGM or

Gel

60 A

LCD panel indicating solar power, load level, battery voltage/capacity, charging current, and fault conditions

Three indicators for solar, charging, and load status

220 x 170 x 57.5

1.85

IP 43

-20°C to 55°C

-40°C to 75°C

24 VDC

Sealed lead acid, vented, Gel, NiCd battery

0 ~ 100% RH (No condensing)

0 ~ 3000 m

36 VDC

315 x 165 x 128

4.5

IP 31

5 ~ 95% RH (No condensing)

0°C to 55°C

-15°C to 60°C

7

www.voltronicpower.com

O n - G r i d I n v e r t e r

EnerSolar On-Grid Inverter

EnerSolar 1.5KW/2KW

• 1.5KW/2KW/3KW/5KW on-grid PV inverter

• Advanced DSP control technology delivers accurate data

• Smart independent MPPTs to enhance overall efficiency

• Up to 96% high conversion efficiency

• Modulized design for easy maintenance

• Industrial-grade components used for robust operation

• Data log up to 15 years

• IP 65 protection for outdoor and harsh environment

• 5-year product warranty

• Free monitoring software

EnerSolar 3KW

EnerSolar 5KW

EnerSolar On-Grid Inverter Selection Guide

MODEL

INPUT(DC)

Max. DC Power

Maximum DC Voltage

MPP Voltage Range

Nominal DC Voltage

Start-up Voltage / Initial Feeding Voltage

Maximum Input Current

EnerSolar 1.5KW

EnerSolar 2KW

1650 W

450 VDC

2200 W

500 VDC

150 VDC ~ 400 VDC 200 VDC ~ 450 VDC

360 VDC

120VDC / 150VDC

1 x 11A

EnerSolar 3KW EnerSolar 5KW

3300 W

500 VDC

5000 W

500 VDC

250 VAC ~ 500 VDC

1 x 13A

180 VDC ~ 500 VDC

370 VDC

125VDC / 150VDC

2 x 15A

1 / A:1 2 / A:1;B:1 Number of MPP Trackers / Strings per MPP Tracker

OUTPUT(AC)

AC Nominal Power

Maximum AC Apparent Power

Nominal AC Voltage

AC Voltage Range

AC Grid Frequency

Nominal Output Current

Power Factor @ Rated Power

EFFICIENCY

Maximum Efficiency

European Efficiency @

Nominal Voltage & 100% Load

PROTECTION

DC Reverse-Polarity Protection

Ground Fault Monitoring

Grid Monitoring

AC Short Circuit Protection

Over Current Protection

PHYSICAL

Dimension,DxWxH(mm)

Net Weight (kgs)

INTERFACE

Intelligent Slot

1500 W

1600 VA

6.6 A

30 A

11.5

ENVIRONMENT

Humidity

Operating Temperature

Altitude

COMPLIANCE

Standard

*The AC Voltage Range may vary depending on different country grid standard

**Power derating 1% every 100 m when altitude is over 1000m.

Product specifications are subject to change without further notice.

1 / A:1

96%

95%

136.5 x 268.5 x 410

2000 W

2100 VA

8.7A

30 A

11.5

230 VAC

184-264 VAC*

50 Hz / 60 Hz

> 0.99

Yes

Yes

Yes

Yes

0 ~ 100% RH (No condensing)

VDE-AR-N 4105

VDE 0126-1-1

-25°C to 60°C

0 ~ 1000 m**

3000 W

3000 VA

13 A

97.0%

96.0%

30 A

160 x 270 x 450

15.0

USB & RS-232 card / Option: SNMP card and Modbus card

CE, VDE-AR-N 4105, VDE-0126-1-1, IEC62109

4600 W

4600 VA

20 A

97.0%

96.0%

50 A

182 x 308 x 515

20.0

Advancing Power

8

O n - G r i d I n v e r t e r w i t h E n e r g y S t o r a g e

InfiniSolar: On-Grid Inverter with Energy Storage

Innovative and Cost-effective Power Solution

‧On-Grid Inverter with Energy Storage

‧Self-consumption and Feed-in to the grid

‧Programmable supply priority for PV, Battery or Grid

‧User-adjustable battery charging current suits different types of

batteries

‧Programmable multiple operations modes: Grid tie, Off grid,

and grid-tie with backup

‧Built-in timer for various mode of on/off operation

‧Multiple communication for USB, RS-232, Modbus and SNMP

‧Monitoring software for real time status display and control

InfiniSolar 2KW/3KW Plus InfiniSolar 5KW InfiniSolar 3-phase 10KW

InfiniSolar is a flexible and intelligent hybrid inverter which utilizes solar power, AC utility, and battery power source to supply continuous power.

It’s a simple and smart solar power storage system for home users to either store energy into battery and wait for night time usage or use for self-consumption first depending on demands. Priority for power source can be programmed and set up through smart software. During night time or power failure, it will automatically extract power from battery. In this way, it will reduce the dependence on the utility.

Feed-in to grid

Utility power input

Solar Power input

Discharging

Charging

Feed-in is not only choice

In comparison with conventional grid-tie inverter, InfiniSolar is able to not only feedin power to grid but also store solar power to battery for future usage and directly power to the loads.

Save money by discharging battery for self-consumption first

InfiniSolar can save money by using battery energy first when PV energy is low. Until battery energy is low, InfiniSolar will extract AC power from the grid.

Power backup when AC failed

InfiniSolar can operate as an off-grid inverter to provide continuous power even without the grid.

It’s perfect power solution for remote regions or temporary AC power source such as camping or flea market.

Conventional Way

Solar PV array

Inverter

Utility

Solar PV array

Battery

Solar PV array

Battery

Solar PV array

Battery

No need

Utility

Load

Utility

Load

Innovative Way

Utility

Load

9

www.voltronicpower.com

O n - G r i d I n v e r t e r w i t h E n e r g y S t o r a g e

InfiniSolar 2KW/3KW On-grid Inverter with Energy Storage Selection Guide

MODEL

PHASE

RATED OUTPUT POWER

MAXIMUM CHARGING POWER

GRID-TIE OPERATION

PV INPUT (DC)

Maximum PV Input Power

Nominal DC Voltage / Maximum DC Voltage

Start-up Voltage / Initial Feeding Voltage

MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

GRID OUTPUT (AC)

Nominal Output Voltage

Output Voltage Range

Nominal Output Current

Power Factor

EFFICIENCY

Maximum Conversion Efficiency (DC/AC)

European [email protected] Vnominal

OFF-GRID OPERATION

AC INPUT

AC Start-up Voltage/Auto Restart Voltage

Acceptable Input Voltage Range

Maximum AC Input Current

PV INPUT (DC)

Maximum DC Voltage

MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage

Output Waveform

Efficiency (DC to AC)

HYBRID OPERATION

PV INPUT (DC)

Nominal DC Voltage / Maximum DC Voltage

Start-up Voltage / Initial Feeding Voltage

MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

GRID OUTPUT (AC)

Nominal Output Voltage

Output Voltage Range

Nominal Output Current

AC INPUT

AC Start-up Voltage / Auto Restart Voltage

Acceptable Input Voltage Range

Maximum AC Input Current

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage

Efficiency (DC to AC)

BATTERY & CHARGER

Nominal DC Voltage

Maximum Charging Current

GENERAL

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

INTERFACE

Communication Port

Intelligent Slot

ENVIRONMENT

Humidity

Operating Temperature

Altitude

InfiniSolar 2KW

2000 W

1200 W

2250W

300 VDC / 350 VDC

80 VDC / 120 VDC

150 VDC ~ 320 VDC

1 / 1 x 15 A

101/110/120/127 VAC

88 - 127 VAC*

18 A

95%

94%

60 - 70 VAC / 85 VAC

80 - 130 VAC

350 VDC

150 VDC ~ 320 VDC

1 / 1 x 15 A

101/110/120/127 VAC

90%

300 VDC / 350 VDC

80 VDC / 120 VDC

150 VDC ~ 320 VDC

1 / 1 x 15 A

101/110/120/127 VAC

88-127 VAC*

18 A

60 - 70 VAC / 85 VAC

80 - 130 VAC

101/110/120/127 VAC

90%

0 to 40°C

1-phase in / 1-phase out

> 0.99

30 A

Pure Sinewave

30 A

48 VDC

Default 25A, 5A - 25A (Adjustable)

107 x 438 x 480

15.5

RS-232/USB

Optional SNMP, Modbus, and AS-400 cards available

0 ~ 90% RH (No condensing)

0 ~ 1000 m**

InfiniSolar Plus 3KW

3000 W

1200 W

4500W

360 VDC / 500 VDC

116 VDC / 150 VDC

250 VDC ~ 450 VDC

1 / 1 x 18 A

208/220/230/240 VAC

184 - 264.5 VAC*

13 A

96%

95%

120 - 140 VAC / 180 VAC

170 - 280 VAC

500 VDC

250 VDC ~ 450 VDC

1 / 1 x 18 A

202/208/220/230/240 VAC

93%

360 VDC / 500 VDC

116 VDC / 150 VDC

250 VDC ~ 450 VDC

1 / 1 x 18 A

202/208/220/230/240 VAC

184 - 264.5 VAC*

13 A

120 - 140 VAC / 180 VAC

170 - 280 VAC

202/208/220/230/240 VAC

93%

0 to 40°C

*These figures may vary depending on different AC voltage and country requirements.

**Power derating 1% every 100 m when altitude is over 1000m.

Product specifications are subject to change without further notice.

VDE-AR-N 4105

VDE 0126-1-1

AS4777, AS/NZS3100

NRS-097-2-1

Advancing Power

10

O n - G r i d I n v e r t e r w i t h E n e r g y S t o r a g e

Inifinisolar 5KW On-grid Inverter with Energy Storage Selection Guide

MODEL

PHASE

RATED OUTPUT POWER

InfiniSolar 5KW

1-phase in / 1-phase out

5000 W

MAXIMUM CHARGING POWER

GRID-TIE OPERATION

PV INPUT (DC)

Maximum PV Input Power

Nominal DC Voltage / Maximum DC Voltage

Start-up Voltage / Initial Feeding Voltage

MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

GRID OUTPUT (AC)

Nominal Output Voltage

Output Voltage Range

Nominal Output Current

Power Factor

EFFICIENCY

Maximum Conversion Efficiency (DC/AC)

European [email protected] Vnominal

OFF-GRID OPERATION

AC INPUT

AC Start-up Voltage/Auto Restart Voltage

Acceptable Input Voltage Range

Maximum AC Input Current

PV INPUT (DC)

Maximum DC Voltage

MPP Voltage Range / Full Load MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage

Output Waveform

Efficiency (DC to AC)

HYBRID OPERATION

PV INPUT (DC)

Nominal DC Voltage / Maximum DC Voltage

Start-up Voltage / Initial Feeding Voltage

MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

GRID OUTPUT (AC)

Nominal Output Voltage

Output Voltage Range

Nominal Output Current

AC INPUT

AC Start-up Voltage / Auto Restart Voltage

Acceptable Input Voltage Range

Maximum AC Input Current

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage

4800 W

10000W

720 VDC / 900 VDC

225 VDC / 250 VDC

250 VDC ~ 850 VDC

2 / 2 x 10.0A

230 VAC

184 - 265 VAC*

21 A

> 0.99

> 96%

> 95%

120 - 140 VAC / 180 VAC

170 - 280 VAC

40A (Include Loads and Charging)

900 VDC

350 VDC ~ 850 VDC

2 / 2 x 10.0A

230 VAC

Pure Sinewave

91%

720 VDC / 900 VDC

320 VDC / 350 VDC

350 VDC ~ 850 VDC

2 / 2 x 10.0A

230 VAC

184 - 265 VAC*

21A

120 - 140 VAC / 180 VAC

170 - 280 VAC

40A

230 VAC

Efficiency (DC to AC)

BATTERY & CHARGER

Nominal Battery Voltage

Battery Shutdown Voltage

Maximum Charging Current

Absorption Charger Voltage

Floating Charger Voltage

Battery Overcharge Protection

GENERAL

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

INTERFACE

92%

48 VDC

Default 42 VDC ,40-50 VDC (Adjustable)

Default 60A, 5A - 100A (Adjustable)

Default 56 VDC, 50 - 60 VDC (Adjustable)

Default 54 VDC, 50 - 60 VDC (Adjustable)

62 VDC

550 x 438 x 120

16

Communication Port

Intelligent Slot

ENVIRONMENT

Humidity

Operating Temperature

RS-232/USB

Optional SNMP, Modbus, and AS-400 cards available

0 ~ 90% RH (No condensing)

-10 to 55°C

Altitude 0 ~ 1000 m*

*These figures are based on VDE-4105 standard. All figures may vary depending on different AC voltage and country requirements.

*Power derating 1% every 100 m when altitude is over 1000m

Product specifications are subject to change without further notice.

90%

48 VDC

Default 42 VDC, 40 - 54VDC (Adjustable)

Default 60A, 5A - 100A (Adjustable)

Default 56 VDC, 50 - 64 VDC (Adjustable)

Default 54 VDC, 50 - 64 VDC (Adjustable)

66 VDC

VDE-AR-N 4105

VDE 0126-1-1

11

www.voltronicpower.com

O n - G r i d I n v e r t e r w i t h E n e r g y S t o r a g e

Inifinisolar 10KW Three Phase On-grid Inverter with Energy Storage Selection Guide

MODEL

PHASE

RATED OUTPUT POWER

MAXIMUM CHARGING POWER

GRID-TIE OPERATION

PV INPUT (DC)

Maximum PV Input Power

Nominal DC Voltage / Maximum DC Voltage

Start-up Voltage / Initial Feeding Voltage

MPP Voltage Range / Full Load MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

GRID OUTPUT (AC)

Nominal Output Voltage

Output Voltage Range

Nominal Output Current

Power Factor

EFFICIENCY

Maximum Conversion Efficiency (DC/AC)

European [email protected] Vnominal

OFF-GRID OPERATION

AC INPUT

AC Start-up Voltage/Auto Restart Voltage

Acceptable Input Voltage Range

Maximum AC Input Current

PV INPUT (DC)

Maximum DC Voltage

MPP Voltage Range / Full Load MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage

Output Waveform

Efficiency (DC to AC)

HYBRID OPERATION

PV INPUT (DC)

Nominal DC Voltage / Maximum DC Voltage

Start-up Voltage / Initial Feeding Voltage

MPP Voltage Range / Full Load MPP Voltage Range

Number of MPP Trackers / Maximum Input Current

GRID OUTPUT (AC)

Nominal Output Voltage

Output Voltage Range

Nominal Output Current

AC INPUT

AC Start-up Voltage / Auto Restart Voltage

Acceptable Input Voltage Range

Maximum AC Input Current

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage

Efficiency (DC to AC)

BATTERY & CHARGER

Nominal DC Voltage

Maximum Charging Current

GENERAL

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

INTERFACE

Communication Port

Intelligent Slot

ENVIRONMENT

Humidity

Operating Temperature

Altitude

InfiniSolar Three Phase 10KW

3-phase in / 3-phase out

10000 W

9600 W

14850W

720 VDC / 900 VDC

320 VDC / 350 VDC

350 VDC ~ 850 VDC / 400 VDC ~ 800 VDC

2 / 2 x 18.6A

230 VAC (P-N) / 400 VAC (P-P)

184 - 265 VAC per phase

14.5 A per phase

> 0.99

> 96%

> 95%

120 - 140 VAC per phase / 180 VAC per phase

170 - 280 VAC per phase

40A

900 VDC

350 VDC ~ 850 VDC / 400 VDC ~ 800 VDC

2 / 2 x 18.6A

230 VAC (P-N) / 400 VAC (P-P)

Pure Sinewave

91%

720 VDC / 900 VDC

320 VDC / 350 VDC

350 VDC ~ 850 VDC / 400 VDC ~ 800 VDC

2 / 2 x 18.6A

230 VAC (P-N) / 400 VAC (P-P)

184 - 265 VAC per phase

14.5 A per phase

120 - 140 VAC per phase / 180 VAC per phase

170 - 280 VAC per phase

40A

230 VAC (P-N) / 400 VAC (P-P)

91%

48 VDC

Default 60A, 10A - 200A (Adjustable)

622 x 500 x 167.5

45

RS-232/USB and CAN Interface

Optional SNMP, Modbus, and AS-400 cards available

0 ~ 90% RH (No condensing)

-10 to 55°C

0 ~ 1000 m*

*Power derating 1% every 100 m when altitude is over 1000m

Product specifications are subject to change without further notice.

VDE-AR-N 4105

VDE 0126-1-1

Advancing Power

12

O f f - G r i d I n v e r t e r

Axpert KS Off-Grid Inverter

Axpert KS 1K Axpert KS 2K/3K Axpert KS 4K/5K

Remote panel

• Pure sine wave inverter

• Selectable input voltage range for home appliances and personal computers

• Selectable charging current based on applications

• Configurable AC/Solar input priority via LCD setting

• Compatible to mains voltage or generator power

• Parallel operation with up to 6 units only available for

4KVA/5KVA

• Auto restart while AC is recovering

• Overload and short circuit protection

• Smart battery charger design for optimized battery performance

• Cold start function

• Optional remote panel available

Off-grid inverter with PWM solar charge controller

1

Solar Power and AC Power available

2

Solar Power and AC Power not available

Solar power

Solar power

Generator or

Generator or

Utility

BATTERY

External

Battery packs

Home Appliances

Utility

BATTERY

External

Battery packs

Home Appliances

Axpert KS Off-Grid Selection Guide

MODEL

Axpert KS 1K

Rated Power 1000VA / 800W

INPUT

Voltage

Axpert KS 2K

2000VA/1600W

Selectable Voltage Range

Axpert KS 3K

3000VA / 2400W

Axpert KS 4K

4000VA / 3200W

230 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50 Hz/60 Hz (Auto sensing) Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

Waveform

BATTERY

Battery Voltage

2000VA

90%

12 VDC

4000VA

230VAC ± 5 %

6000VA

93%

10 ms (For Personal Computers)

20 ms (For Home Appliances)

Pure sine wave

24 VDC

8000VA

48 VDC

Axpert KS 5K

5000VA / 4000W

10000VA

27 VDC

31 VDC

54 VDC

60 VDC

Floating Charge Voltage

Overcharge Protection

SOLAR CHARGER & AC CHARGER

Maximum PV Array Open Circuit Voltage

Standby Power Consumption

Maxmum Solar Charge Current

Maximum AC Charge Current

Maximum Charge Current

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

13.5 VDC

15.5 VDC

50VDC

1 W

50A

20 A

95 x 240 x 316

Product specifications are subject to change without further notice.

5.0

50 A

6.4

60VDC

2 W

50A

30 A

100 x 272 x 355

6.9

9.8

5% to 95% Relative Humidity(Non-condensing)

0°C - 55°C

-15°C - 60°C

105VDC

2W

50 A

60 A

110 A

120 x 295 x 468

9.8

13

www.voltronicpower.com

O f f - G r i d I n v e r t e r

Axpert MKS Off-Grid Inverter

• Pure sine wave inverter

• Built-in MPPT solar charge controller

• Selectable input voltage range for home appliances and personal computers

• Selectable charging current based on applications

• Configurable AC/Solar input priority via LCD setting

• Compatible to mains voltage or generator power

• Auto restart while AC is recovering

• Overload and short circuit protection

• Smart battery charger design for optimized battery performance

• Cold start function

• Parallel operation with up to 6 units only available for

4KVA/5KVA

• Optional remote panel available

Axpert MKS 1K / 2K / 3K Axpert MKS 4K / 5K

Remote panel

Axpert MKS Off-Grid Inverter Selection Guide

MODEL

Rated Power

Axpert MKS

1K-24

Axpert MKS

1K-48

Axpert MKS

2K-24

Axpert MKS

3K-24

Axpert MKS

3K-48

Axpert MKS

4K

Axpert MKS

5K

1000VA/800W 1000VA/1000W 2000VA/1600W 3000VA/2400W 3000VA/2400W 4000VA/3200W 5000VA/4000W

INPUT

Voltage

Selectable Voltage Range

Frequency Range

OUTPUT

AC Voltage Regulation

(Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

2000VA

90% - 93%

230 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50 Hz/60 Hz (Auto sensing)

230VAC ± 5%

4000VA 6000VA

93%

10 ms (For Personal Computers) ; 20 ms (For Home Appliances)

8000VA

Waveform

BATTERY

Battery Voltage

Pure sine wave

Floating Charge Voltage

Overcharge Protection

24 VDC

27 VDC

31 VDC

20 A

25A

48 VDC

54 VDC

62 VDC

24 VDC

27 VDC

31 VDC

24 VDC

27 VDC

31 VDC

48 VDC

54 VDC

62 VDC

SOLAR CHARGER & AC CHARGER

Maximum PV Array Power

MPPT Range @ Operating

Voltage

Maximum PV Array Open

Circuit Voltage

Maximum Solar Charge Current

600 W

75 VDC

25A

900 W

102 VDC

18 A

600 W

75 VDC

25A

600 W 900 W

30VDC ~ 66VDC 60VDC ~ 88VDC 30VDC ~ 66VDC 30VDC ~ 66VDC 60VDC ~ 88VDC

75 VDC

25A

102 VDC

18 A

Maximum AC Charge Current

Maximum Charge Current

15 A

18 A

30 A

30A

30 A

30A

15 A

18 A

Maximum Efficiency

Standby Power Consumption

AC charger and solar charger can’t work at the same time.

98%

2 W

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs) 6.8

100 x 272 x 355

7.0

7.4

5% to 95% Relative Humidity(Non-condensing)

0°C - 55°C

-15°C - 60°C

48 VDC

54 VDC

60 VDC

3000 W

145 VDC

60 A

60 A

120A

120 x 295 x 468

11

10000VA

60VDC ~115VDC

Product specifications are subject to change without further notice

Advancing Power

14

O f f - G r i d I n v e r t e r

Axpert EX Off-Grid Inverter

• Pure sine wave inverter

• Enhance AC charger to 60A

• Wide battery input range

• Selectable input voltage range for home appliances and personal computers

• Selectable high power charging current

• Configurable AC/Solar input priority via LCD setting

• Compatible to mains voltage or generator power

• Auto restart while AC is recovering

• Overload and short circuit protection

• Smart battery charger design for optimized battery performance

• Cold start function

Axpert EX Off-Grid Inverter Selection Guide

MODEL

Rated Power

Axpert EX 1.5K-12

1500VA/1200W

INPUT

Voltage

Selectable Voltage Range

Axpert EX 1.5K-24

220/230/240 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50 Hz/60 Hz (Auto sensing) Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

220/230/240VAC ± 5%

3000VA

90% ~ 93%

10 ms (For Personal Computers)

20 ms (For Home Appliances)

Pure sine wave Waveform

BATTERY

Battery Voltage

Floating Charge Voltage

12 VDC

13.5 VDC

24 VDC

27 VDC

32 VDC Overcharge Protection

SOLAR CHARGER & AC CHARGER

Maximum PV Array Open Circuit Voltage

Maxmum Solar Charge Current

Maximum AC Charge Current

Maximum Charge Current

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Product specifications are subject to change without further notice

16 VDC

50 VDC

50 A

60A

110A

100 x 272 x 355

6.6

75 VDC

5% to 95% Relative Humidity(Non-condensing)

-20°C to 55°C

-30°C to 60°C

Axpert EX 3K-24

3000VA/2400W

6000VA

15

www.voltronicpower.com

O f f - G r i d I n v e r t e r

Axpert MEX Off-Grid Inverter

• Pure sine wave inverter

• Built-in MPPT solar charge controller

• Enhance AC charger to 60A and solar charger to 40A

• Wide battery input range

• Selectable input voltage range for home appliances and personal computers

• Selectable high power charging current

• Configurable AC/Solar input priority via LCD setting

• Compatible to mains voltage or generator power

• Auto restart while AC is recovering

• Overload and short circuit protection

• Smart battery charger design for optimized battery performance

• Cold start function

Axpert MEX Off-Grid Inverter Selection Guide

MODEL

Rated Power

Axpert MEX 1.5K-12

1500VA/1200W

Axpert MEX 1.5K-24 Axpert MEX 3K-24

3000VA/2400W

INPUT

Voltage

Selectable Voltage Range

230 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50 Hz/60 Hz (Auto sensing) Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

230VAC ± 5%

3000VA

90% ~ 93%

10 ms (For Personal Computers)

20 ms (For Home Appliances)

Pure sine wave

6000VA

Waveform

BATTERY

Battery Voltage 12 VDC 24 VDC

27 VDC

32 VDC

Floating Charge Voltage

Overcharge Protection

SOLAR CHARGER & AC CHARGER

Maximum PV Array Power

MPPT Range @ Operating Voltage

Maximum PV Array Open Circuit Voltage

Maximum Solar Charge Current

Maximum AC Charge Current

Maximum Charge Current

Maximum Efficiency

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Product specifications are subject to change without further notice

13.5 VDC

16 VDC

500W

15 VDC ~ 80 VDC

100 VDC

40A

60A

100A

98%

100 x 272 x 355

7.0

1000W

30 VDC ~ 80 VDC

5% to 95% Relative Humidity(Non-condensing)

-20°C to 55°C

-30°C to 60°C

Advancing Power

16

O f f - G r i d I n v e r t e r

Axpert MKS Plus Off-Grid Inverter

• Pure sine wave inverter

• Built-in MPPT solar charge controller

• Selectable input voltage range for home appliances and personal computers

• Selectable charging current based on applications

• Configurable AC/Solar input priority via LCD setting

• Compatible to mains voltage or generator power

• Auto restart while AC is recovering

• Overload and short circuit protection

• Smart battery charger design for optimized battery performance

• Cold start function

• Optional remote panel available

Remote panel

Axpert MKS Plus Off-Grid Inverter Selection Guide

MODEL

Rated Power

INPUT

Voltage

Selectable Voltage Range

Axpert MKS 2K-24 Plus

2000VA/1600W

Axpert MKS 2K-48 Plus

2000VA/1600W

Axpert MKS 3K-24 Plus

3000VA/2400W

Axpert MKS 3K-48 Plus

3000VA/2400W

120 VAC or 230 VAC 230 VAC

95-140 VAC or 170-280 VAC (For Personal Computers)

65-140 VAC or 90-280 VAC (For Home Appliances)

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50 Hz/60 Hz (Auto sensing) Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

Waveform

BATTERY

Battery Voltage

Floating Charge Voltage

Overcharge Protection

SOLAR CHARGER & AC CHARGER

Maximum PV Array Power

MPPT Range @ Operating Voltage

Maximum PV Array Open Circuit

Voltage

Maximum Solar Charge Current

Maximum AC Charge Current

Maximum Efficiency

Standby Power Consumption

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

110/120 VAC ± 5% (User selectable) or 230VAC ± 5%

4000VA

90% - 93%

10 ms (For Personal Computers)

20 ms (For Home Appliances)

Pure sine wave

24 VDC

27 VDC

31 VDC

1500 W

30~ 115 VDC

20 A or 30 A

Product specifications are subject to change without further notice

48 VDC

54 VDC

62 VDC

3000 W

60 ~ 115 VDC

10 A or 15 A

145 VDC

60A

98%

2 W

140 x 295 x 479

11.5

24 VDC

27 VDC

31 VDC

1500 W

30~ 115 VDC

30 A

5% to 95% Relative Humidity(Non-condensing)

0°C - 55°C

-15°C - 60°C

230VAC ± 5%

6000VA

48 VDC

54 VDC

62 VDC

3000 W

60 ~ 115 VDC

15 A

17

www.voltronicpower.com

O f f - G r i d I n v e r t e r

Axpert Plus Duo/Tri Off-Grid Inverter

Axpert Plus Duo 1.5K / 3K

Axpert Plus Duo 5K/

Axpert Plus Tri 5K

• Pure sine wave inverter

• Built-in 2 or 3 strings of MPPT solar charge controller depending on models

• Enhanced AC charger to 60A

• Wide battery input range

• Selectable input voltage range for home appliances and personal computers

• Selectable high power charging current

• Configurable AC/Solar input priority via LCD setting

• Compatible to mains voltage or generator power

• Auto restart while AC is recovering

• Overload and short circuit protection

• Smart battery charger design for optimized battery performance

• Cold start function

• Optional SNMP card

Axpert Plus Duo 1.5KVA/3KVA/5KVA and Axpert Plus Tri 5KVA Inverter/Charger Specification

MODEL

Rated Power

Axpert Plus Duo

1.5K-12

Axpert Plus Duo

1500VA/1200W

1.5K-48

Axpert Plus Duo

3K-24

Axpert Plus Duo

3000VA/2400W

3K-48

Axpert Plus Duo

5K

Axpert Plus Tri

5000VA/4000W

5K

INPUT

Voltage

Selectable Voltage Range

Frequency Range

OUTPUT

AC Voltage Regulation

(Batt. Mode)

Surge Power

Efficiency (Peak)

Transfer Time

Waveform

BATTERY

Battery Voltage

Floating Charge Voltage

12 VDC

13.5 VDC

Overcharge Protection 16 VDC

SOLAR CHARGER & AC CHARGER

1000W Maximum PV Array Power

MPPT Range @ Operating

Voltage

Maximum PV Array Open

Circuit Voltage

Maximum Solar Charge

Current

Maximum AC Charge

Current

Maximum Charge Current

15~80 VDC

80A

140 A

3000VA

Maximum Efficiency

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Product specifications are subject to change without further notice

48 VDC

54 VDC

62 VDC

2000W

60 ~ 90 VDC

40A

100 A

100 VDC

6000VA

90% ~ 93%

10 ms (For Personal Computers)

20 ms (For Home Appliances)

Pure sine wave

30~80 VDC

124 x 272 x 400

8.0

230 VAC

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50 Hz/60 Hz (Auto sensing)

24 VDC

27 VDC

32 VDC

2000W

80A

140 A

230VAC ± 5%

60A

98%

48 VDC

54 VDC

62 VDC

5% to 95% Relative Humidity(Non-condensing)

-20°C to 55°C

-30°C to 60°C

2000 W

60 ~ 90 VDC

40A

100 A

48 VDC

54 VDC

60 VDC

6000W

120A

180 A

16

10000VA

60~115Vdc

145 VDC

48 VDC

54 VDC

60 VDC

9000W

194 x 295 x 455

180A

240 A

17

Advancing Power

18

O f f - G r i d I n v e r t e r

Alfa Off-Grid Inverter

LCD Display Panel

Alfa-P5000-48

Alfa-P3000-24

Boost and buck AVR

An inverter with built-in AVR provides clean and stable power by correcting the under or over voltages which may be harmful to your precious electronic devices.

• Flexible mechanical design

A unique LCD panel design facilitates panel switch easily. This flexible form factor allows the inverter to be simply set on the table or easily mounted on a wall.

Voltage Fluctuations Stable Voltage

Alfa with AVR

Built-in solar charger

Alfa series offers two kinds of solar charger: PWM and MPPT solar chargers.

Model Solar charger Type Consideration

Alfa-P PWM Cost effective

Alfa-M MPPT High efficiency

• Suitable for home appliances and

personal computers

Alfa inverter is allowed to configure input voltage range to suite different appliances from electronic devices to sensitive computers.

• User-configurable setting from LCD panel

Alfa is designed to offer highly flexibility for user operation.

Via LCD operation, users can configure AC/solar charging priority, battery charging current, and acceptable input voltage range.

• Intelligent communication

Alfa offers intelligent slot perfect for SNMP or USB/RS-232 serial card. Integrated with monitoring software, it provides smart monitoring system.

Compatible to mains voltage or generator power

Alfa series is able to connect to either utility or generator. This feature will expand application areas where utility is not accessible.

19

www.voltronicpower.com

O f f - G r i d I n v e r t e r

Alfa Off-Grid Inverter Selection Guide

MODEL

Rated Power

INPUT

Voltage

Selectable Voltage Range

Frequency Range

OUTPUT

AC Voltage Regulation (Batt. Mode)

Alfa-P3000-24

3000VA/2400W

Alfa-M3000-24

230 VAC

Alfa-P5000-48

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

50 Hz/60 Hz (Auto sensing)

5000VA/4000W

Alfa-M5000-48

AC Voltage Regulation (AVR Mode)

Surge Power

Efficiency (Peak)

Transfer Time

Waveform

BATTERY

Battery Voltage

Floating Charge Voltage

Overcharge Protection

SOLAR CHARGER & AC CHARGER

Maximum PV Array Open Circuit Voltage

Maximum PV Array Open Circuit Voltage

Maxmum Solar Charge Current

PWM

75 VDC

50 A

Maximum AC Charge Current

Maximum Charge Current

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

80 A

12

Storage Temperature

Product specifications are subject to change without further notice

6000VA

24 VDC

27 VDC

32 VDC

30 A

340 x 380 x 88

230VAC ± 5%

230VAC ± 10%

90% ~ 93%

10 ms (For Personal Computers)

20 ms (For Home Appliances)

MPPT

100 VDC

40 A

70 A

13

Pure sine wave

PWM

105 VDC

50 A

110 A

16

10000VA

48 VDC

54 VDC

60 VDC

60 A

420 x 397 x 120

5% to 95% Relative Humidity(Non-condensing)

-10°C to 55°C

-15°C to 60°C

MPPT

145 VDC

60 A

120 A

17

Advancing Power

20

O f f - G r i d I n v e r t e r

Lobo Solar

• Simulated sine wave inverter

• Accepts utility and solar input at the same time

• Built-in 50A PWM solar charger

• Wide input voltage range

• 10 A or 20 A standard AC charging current

• LCD display for comprehensive information

• Overload, short circuit and reverse polarity protection

Quantum Solar

• Simulated sine wave inverter

• Sensitivity input selector (UPS mode & inverter mode) for personal computers and home appliances

• Accepts utility and solar input at the same time

• Wall-mounting for saving space

• 10 A or 20 A standard AC charging current

• Built-in 50A PWM solar charger

• Adjustable battery charging voltage

• Generators compatible

• Overload, short circuit and reverse polarity protection

Lobo Solar Inverter Selection Guide

MODEL

CAPACITY

INPUT

Voltage

Lobo Solar 1.2K

1200 VA / 720 W

230 VAC

Lobo Solar 2.4K

2400 VA / 1440 W

90-280VAC

Frequency Range

OUTPUT

60Hz or 50 Hz (Auto sensing)

230 VAC ±10%

Transfer Time

60 Hz or 50 Hz ±1 Hz

20ms typical

Simulated Sine Wave

BATTERY

Battery Voltage 12VDC 24VDC

Rechargeable lead-acid and deep discharge battery

90~280 VAC

>11Vdc >22Vdc DC Start Voltage

AC CHARGER

14.3VDC ±2%

13.7VDC ±2%

28.6VDC ±2%

27.4VDC ±2%

10A or 20A

SOLAR CHARGER

40 VDC

15~18 VDC

60 VDC

30~32 VDC

50A

PROTECTION

Full Protection

PHYSICAL

Overload, short circuit and reverse polarity protection

300 x 360 x 88

Net Weight (kgs) 6.3

7.6

OPERATING ENVIRONMENT

Humidity 0 to 90% Relative Humidity (Non-condensing)

Operating Temperature

Storage Temperature

0℃ to 40℃

-15℃ to 50℃

Product specifications are subject to change without further notice

Quantum Solar Inverter Selection Guide

MODEL Quantum Solar 1.2K

Quantum Solar 2.4K

1200 VA / 720 W 2400 VA / 1440 W CAPACITY

INPUT

Voltage

Acceptable Voltage Range

Frequency Rang

OUTPUT

230 VAC

170-280 VAC (UPS Mode )

90-280 VAC (INV. Mode)

60Hz or 50 Hz (auto sensing)

230VAC ±10%

Transfer Time

Waveform (Batt. Mode)

BATTERY

Battery Voltage

Acceptable Battery Type

60 Hz or 50 Hz ±1 Hz

20ms typical

Simulated Sine Wave

12VDC 24VDC

Rechargeable lead-acid and deep discharge battery

90~280 VAC

>11VDC >22VDC DC Start Voltage

AC CHARGER

Floating Charge Voltage

Maximum Charge Current

SOLAR CHARGER

14.3VDC ±2%

13.7VDC ±2%

10A or 20A

28.6VDC ±2%

27.4VDC ±2%

Operating Voltage Range

Maxmum Solar Charge

Current

PROTECTION

Full Protection

PHYSICAL

40 VDC

15~18 VDC

50A

60 VDC

30~32 VDC

Overload, short circuit and reverse polarity protection

293 x 231.5 x 82.5

Net Weight (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

2.5

2.8

0 to 90% Relative Humidity (Non-condensing)

0℃ to 40℃

-15℃ to 50℃

Product specifications are subject to change without further notice

21

www.voltronicpower.com

S e l e c t i o n G u i d e

Solar Inverter Selection Guide

EnerSolar InfiniSolar

Power rating 1.5KW/2KW/3KW 5KW 2KW/3KW 5KW

Phase

Topology

Output Waveform

Feeding to grid

Accept AC power source

Solar charger

Single Phase

On-grid

Pure sine wave

1x MPPT

Single Phase

On-grid

Pure sine wave

2 x MPPT

Single Phase

Hybrid

Pure sine wave

1 x MPPT

Single Phase

Hybrid

Pure sine wave

2 x MPPT

Parallel connection

AC/solar priority setting

Software SolarPower SolarPower

SolarPower

SolarPower

10KW

3-Phase

Hybrid

Pure sine wave

2 x MPPT

SolarPower

Power rating

Phase

Axpert

KS

Axpert

MKS

Axpert

EX

Axpert

MEX

Axpert

MKS Plus

Axpert

Plus Duo

1KVA-5KVA 1KVA-5KVA 1.5KVA/3KVA 1.5KVA/3KVA 2KVA/3KVA 1.5KVA/3KVA

Alfa

3KVA

/ 5KVA

Lobo

Solar

1.2KVA

/ 2.4KVA

Quantum

Solar

1.2KVA

/ 2.4KVA

Single phase Single phase Single phase Single phase Single phase Single phase Single phase Single phase Single phase

Topology

Off-grid Off-grid Off-grid Off-grid Off-grid Off-grid Off-grid Off-grid Off-grid

Output waveform

Pure sine wave

Pure sine wave

Pure sine wave

Pure sine wave

Pure sine wave

Pure sine wave

Pure sine wave

Simulated sine wave

Simulated sine wave

Accept AC power source

Built-in AC charger*

Solar charger

Solar charger capability*

Parallel connection

• • • • • • • • •

1K-3KVA:

10A ~ 30A

4K/5K: 60A

PWM

1K-3K:

15A ~ 30A

4K/5K: 60A

1 x MPPT

60A

PWM

60A

1 x MPPT

10A ~ 30A

1 x MPPT

60A

2 x MPPT

Alfa-P: 50A

Alfa-M3000: 40A

Alfa-M5000: 60A

Alfa-P: PWM

Alfa-M: 1 x

MPPT

10A or 20A

PWM

10A or 20A

PWM

50A

1K-3K:

18A ~ 25A

4K/5K:

60A

50A 40A 60A 40A ~ 80A

Alfa-P: 50A

Alfa-M:

40A ~ 60A

50A 50A

Only for 4K/5K

Only for 4K/5K

Only for 5K

Wide input voltage range

AC/solar priority setting

Selectable

Selectable

Selectable

Selectable

Selectable

Selectable

Selectable

Selectable Selectable

Software

WatchPower WatchPower WatchPower WatchPower WatchPower WatchPower WatchPower

*This table is for reference only. For detailed AC charger size, please check model specsheet directly.

Advancing Power

22

A c c e s s o r y

Remote Monitoring & Management

SNMP Web Card

SNMP Web Card

• Allows control and monitoring of multiple inverters through

RJ-45 network connection

• Real-time dynamic graphs of UPS data (voltage, frequency, load level, battery level)

• Warning notifications via audible alarm, broadcast, mobile messenger, e-mail and SNMP traps

• Historic data log stored in centralized PC database

• Simple firmware upgrade with one click

• Password security protection and remote access management

• Supports optional environmental monitoring detector for temperature, humidity and smoke

Modbus Card

Modbus Card

• Real-time control and monitoring of multiple inverters via

RS-485 communication port

• Supports Modbus RTU protocol

• Provides MODBUS functions including read Holding Registers and write Registers

• Provides surge protection

Modbus Box

Modbus Box

• Supports to monitor off-grid inverter through modbus interface

• Implements MODBUS RTU protocol

• Integrated with WatchPower software

• Supports Axpert series inverter

Modbus Web Box

• Embedded with web server

• Supports to monitor and operate up to 247 modbus devices

• Ideal monitoring solution for medium-sized solar farm

• Supports EnerSolar and InfiniSolar series inverters

Modbus Web Box

Monitoring Software

SolarPower SolarPower Pro WatchPower

SolarPower is a solar inverter monitoring software. It can monitor multiple devices via

USB and Serial port at the same time. The major functions of SolarPower monitoring software include data log for device, power generation statistics, alarm messages, fault messages and parameter setting for devices.

SolarPower Pro is a solar inverter monitoring software to monitor up to 247 devices via

modbus or SNMP interface. It also provides web browser capability in a networked environment. The major functions of SolarPower

Pro monitoring software include data log for devices, power generation statistics, alarm messages, fault messages, and parameter setting for devices.

Watc h Powe r i s a n o f f - gr i d i nve r te r monitoring software which can monitor multiple Axpert devices via serial port at the same time. The major functions include data log for devices, alarm and fault recording.

Besides, it also can configure advanced parameters such as charger source priority, output source priority, AC input range and battery type based on diverse applications.

23

www.voltronicpower.com

I n v e r t e r

Axpert GS Inverter

• Pure sine wave inverter

• Isolation design between input and output for safety guarantee

• Lightweight, stainless steel, and anodised aluminium casing

• Low power consumption for energy saving

• Over-temperature, DC reverse polarity and short circuit protection

• Low/High battery alarm and protection

DC/AC inverter without charger

AC/DC

AC Output

External Battery packs

DC Input

BATTERY

Appliances

Axpert GS Inverter Selection Guide

MODEL

Rated Power

INPUT

Nominal DC Voltage

Cold Start Voltage

Acceptable Voltage Range

Axpert GS 2K

2000VA/1600W

Low DC Warning Voltage

@ load <20%

@ 20% ≦ load < 50%

@ load ≧ 50%

Low DC Warning Return Voltage

@ load <20%

@ 20% ≦ load < 50%

@ load ≧ 50%

Low DC Cut-off Voltage

@ load <20%

@ 20% ≦ load < 50%

@ load ≧ 50%

Efficiency

No Load Power Consumption

Saving Mode Power Consumption

OUTPUT

AC Voltage Regulation (Batt. Mode)

Surge Power

Waveform

PHYSICAL

Dimension, D X W X H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Operating Temperature

Storage Temperature

Product specifications are subject to change without further notice

4000VA

4.3

24 VDC

23 VDC

21 VDC ~ 29 VDC

22.0 VDC

21.4 VDC

20.2 VDC

23.0 VDC

22.4 VDC

21.2 VDC

21.0 VDC

20.4 VDC

19.2 VDC

> 90 %

< 20 W

< 10 W

230VAC ± 5%

Pure sine wave

82 x 232 x 369

Axpert GS 3K

3000VA/2400W

5% to 95% Relative Humidity (Non-condensing)

0°C - 55°C

-15°C - 60°C

6000VA

4.3

Advancing Power

24

I n v e r t e r

Telecom Inverter

Telecom-N 1K / Telecom-P 1K

Telecom-M 2K

Telecom-M 3K

Telecom Inverter Selection Guide

MODEL

CAPACITY

AC INPUT

Nominal Voltage

Nominal Frequency

AC Input Voltage Range

AC Frequency Range

Power Factor

DC INPUT

Nominal Voltage

Rated Current

DC Input Voltage Range

Reflected Relative Noise Current

Reflected Relative Psophometrically

Weighted Noise Current

AC OUTPUT

Output Voltage

Voltage Regulation

Frequency Range (Synchronized Range)

Frequency Range (Batt. Mode)

Current Crest Ratio

Harmonic Distortion

Transfer

Time

Online Mode to Battery Mode

Online Mode to ECO Mode

Waveform (Online Mode & Battery Mode)

AC CHARGER

Output Voltage (Floating volatge)

Maximum AC Charge Current

SOLAR CHARGER (Option)

Solar Charger Type

Maximum PV Array Power

MPPT Range @ Operating Voltage

Maximum Solar Charge Current

Maximum Charge Current

(AC Charger Plus Solar Charger)

EFFICIENCY

Online Mode

ECO Mode

Battery Mode (Meet requirement of Reflected

Relative Noise Current)

Battery Mode (Typical)

INDICATORS

Display

ALARM

Battery Mode

Low Battery

Overload

Fault

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

ENVIRONMENT

Humidity

Operating Temperature

Noise Level

MANAGEMENT

RS-232/USB/RS-485

20A

91%

96%

85%

87%

• True double conversion with microprocessor control

• Microprocessor control optimizes reliability

• Durable design for Telecom applications

• AC input power factor correction

• AC output power factor 0.8

• Wide AC input voltage (110 V – 300 V)

• Generator compatible

• Priority mode setting: ECO mode (AC bypass), Online mode (AC inverter) and

Battery mode (DC inverter)

• DC isolation design

• DC reverse protection (Only apply for Telecom-P 1K and Telecom-M 2K/3K models)

• AC charger capacity up to 6A for Telecom-P 1K and 10A for Telecom-M 2K/3K

• Optional solar charger capacity up to 25A for Telecom-P 1K and 60A for

Telecom-M 2K/3K

• Built-in RS232/USB/RS485 communication

• Dry contact communication for industrial remote control (only apply for

Telecom-N 1K)

Telecom-N 1K

1000 VA / 800 W

Telecom-P 1K

N/A

N/A

220/230/240VAC

50/60 Hz (Auto sensing)

110-300 VAC (Based on load at 50%) ; 160-300VAC (Based on load at 100%)

40Hz ~ 70 Hz

0.99 @ Nominal Voltage (100% load)

LED for Online mode, Battery mode, ECO mode, and Fault indicators

227 x 440 x 44

5

Choose one

-48VDC

40~60VDC

<10%

<1%

Telecom-M 2K

2000 VA / 1600 W

Sounding every 4 seconds

Sounding every second

Sounding twice every second

Continously sounding

38A

220/230/240VAC

± 1%

47~ 53 Hz or 57 ~ 63 Hz

50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz

3:1

3 % THD (Linear Load) ; ≦ 5 % THD (Non-linear Load)

Zero

4 ms (Typical)

Pure Sinewave

6A

PWM

1.25KW

105VDC

25A

31A

330 x 440 x 44

6

54.7 VDC ±1%

10A

MPPT

3KW

60A

70A

91%

96%

88%

90%

145VDC

LCD for Operation status, Load level, DC level,

AC Input/Output voltage,and Fault conditions

9.5

0-90 % Relative Humidity (non-condensing)

-5- 45°C

Less than 50dBA @ 1 Meter

380 x 440 x 88

RS-232/USB or RS-485

Supports Windows 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC

Telecom-M 3K

3000 VA / 2400 W

57A

10A

MPPT

3KW

60A

70A

91%

96%

88%

90%

10

Dry Contact

Signals for AC input normal and fault alarms

*Product specifications are subject to change without further notice

N/A

25

www.voltronicpower.com

S o l a r L i g h t i n g S o l u t i o n

SolaLight

• 3W solar panel included

• Built-in Ultra-light LED

• 2 sets of 12V LED Bulbs included

• Built-in USB charger port for mobile device

• Built-in Lithium-ion Battery (>4000mAh)

Package Contents:

x 1

3W Solar Panel x 1

Power Pack x 2

LED Bulb

Solalight Lighting Solution Specification

MODEL

Power Consumption by LED Bulb

Solar Input Range

USB Output

INDICATORS

Battery Full

Battery Charging

Low Battery

BATTERY & CHARGER

Battery Type

Battery Voltage

Constant Charging Voltage

Shutdown Voltage

Charging Current

Typical Charging Time

OPERATING ENVIRONMENT

Operating Temperature

Relative Humidity

Product specifications are subject to change without further notice

SolaLight

1.2W/each

5~8 VDC

5VDC 1A

Green LED lighting

Red LED lighting

Green LED flashing

Lithium-ion

3.6 VDC

4.2 VDC

3 VDC

Via Solar Panel: 0.5A

Via Micro USB: 1A

Via Solar Panel: 9 hours

Via Micro USB: 4 hours

0- 40°C (non-condensing)

0-90 %

Running Time

= 12hrs

= 6hrs

= 12hrs

26

S o l a r L i g h t i n g S o l u t i o n

SolaPalm Lighting Solution

• 70W DC UPS

• 3 sets DC-powered outlets for energy saving bulbs

• 1 x 12V DC output connector for DC fan

• Accept either PWM solar charger or AC charger

• Optional 3 x 5V USB charger ports for mobile phones

• Off mode charging

• Overload protection in battery mode and short circuit protection

• 3-step charging design for extended battery life

• Optional lamp holder with 2m cable

Devices:

Mobile Phone Bulb lighting

DC Fan

3 x energy saving bulbs

DC Fan

Mobile phone charging

Utility (AC input)

24W PV module charging

External battery

SolaPalm Lighting Solution Specification

MODEL

CAPACITY

PV INPUT

Maximum PV Array Open Circuit Voltage

Maximum Solar Charging Current

AC INPUT

Nominal Voltage

Nominal Frequency

OUTPUT

Output Voltage (AC Mode)

2-pin Sockets Output Voltage (Batt. Mode)

Waveform (Batt. Mode)

DC Connector

USB Charger (option)

BATTERY & CHARGER

Battery Type and Numbers

Battery Voltage

Floating Voltage

Shutdown Voltage

Typical Recharge Time

Total Charging Current*

PROTECTION

Full Protection

PHYSICAL

Dimension, D x W x H (mm)

Net Weight (kgs)

OPERATING ENVIRONMENT

Humidity

Noise Level

*Total charging current includes solar charger and AC charger.

Product specifications are subject to change without further notice

SolaPalm 70

70 W

30 VDC

2 A

230 VAC

50/60 Hz (Auto sensing)

230 VDC

160-230 VDC ± 10%

DC Output

12VDC 2A x 1pc

5VDC 1A x 3pcs

12V 7Ah x 1 (Optional external battery)

12 VDC

13.7V ±1.5%

11V

8 hours recover to 90% capacity

1 A or 2 A (Selectable)

Overload Protection and short circuit protection

229 x 110 x 123.5

3.8

0-90 % RH @ 0- 40°C (non-condensing)

Less than 40dB

27

www.voltronicpower.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
