Dear Shooter

:~

\.

I,

~0

.........

After the many successes in national and international matches, it surely was not difficult to decide on an Anschutz Match Rifle. You will have a lot of fun and if you concentrate, as a successful shooter must, you will follow in the footsteps of the leaders in this game of skill.

As you know it is not the rifle but the shooter who must do the job. This booklet is meant to give you some useful hints in order that you may become more familiar with your

Model 54 Anschutz Match Rifle. By learning the operation and the proper core of your rifle, you and your Anschutz become a team.

Please remember that we are behind you as for as the performance and precision of your

Anschutz rifle is concerned.

If you toke core of your rifle, it will enable you to reach the winning scores you desire.

Therefore "Good Luck"

from

J. G.

Anschutz

Index

2

2

15

16

17

18

11

12

13

14

19

20

25

9

10

7

8

5

6

3

4

Index

Decades of Labor

The barrel

-

The Stock

Match Triggers

How to disassemble the Bolt

How the Reassemble the Bolt

Anschutz Micro Sight with scale

Adjusting the Micro Sight

Zero Setting of the Special Micro Sight

Anschutz Microsight and adjustment

Accessories

Front Sight and Extension

Two Rifles using one stock

Small Bore Rifle Care

Zimmerstutzen Care

Anschutz Match Air Rifle

Spare Parts List for Mod. 54

The Anschutz Action Mod. 54

Notes

Anschutz Rifles and their Success

De odes of labor

.

It has taken many years of collecting pofessional know how to reach this goal. The great love for rifle competition has made the Anschutz Rifle what it is today. Many long hours and sleepless nights have been spent so that every desirable design feature could be tested and retested.

We can now say, with humble pride that

Anschutz manufactures the worlds best known match rifles. For this we are thankful to the men and women who are doing such a fine job at our plant. Your Anschutz rifle is the result of dedicated craftsmen, years of experience, and the finest steel in the world.

3

I i i

~

Ir

~t

JI

r

The "nschutz

Barre

The barrel steel used by Anschutz is of the best grade especially selected for Rifle barrels. Such are of maximum weight which allow a balance of the rifle which is very much in its favor and give such fine accuracy never thought possible up to now.

Each one has 8 Lands of the most exact sculpture and all standard .22 cartridges of any reliable make will give good results.

Many Gun editors have men-

~ tioned this in their reports to the Shooter.

Below shows octuol size 50.shot

~.

group fired ot 50 meters (55 yords) ot the Internotionol Smoll-

Bore Torget.

Such groups ore routine for Anschutz.Model

54

..

(9)

9

I

The Anschutz

Butts~ck,;

Only well seasoned walnut will go into a stock for your Anschutz Rifle. Stock length, Shape, Cheekrest and the anatomic pistol grip are the result of many years of tests by prominent Shooters. Particular attention was given to different size of men as well as various shooting positions.

All stocks ar~ rubbed .dow.n and oiled but not polished. A polished stock will slide too easy and a scratch will show up at once. A few drops of oil rubbed in from time to time is always a good idea.

4l~

The

Anschutz 2-stage HAIR

Match trigger No. 1404-U8

The ANSCHUTZ 2.stoge hoir motch trig.

ger requires two odiustments: By loos.

ening (onti.clockwise) or tightening (clock.

wise) the trigger spring odjustment screw

No. 28, the length of trove I of the first stoge con be shortened or lengthened occordingly.

By meons of the trigger pull lever screw No. 25 the degree of engogement of the cotch link No. 23 in coni unction with the cotch No. 27, con be odjusted.

By loosening screw No. 25 (onti.clockwise) the sensitivity is reduc.

ed ond by tightening (clockwise) increosed.

At the ultimote point of engogement the seor is held ot only 0 few 1/100 mm. However, it should be noted thot too fine on odiustment will couse uncertainty of cooking ond if reversed will couse drog ond creep of the trigger.

Trigger No. 20 moy be moved for occomodotion of 0 smoll or lorge hondo

The Anschutz 3 Ibs one stage Match trigger No. 1411-U8

Eoch 3 Ibs trigger is foctory reguloted to 0 pull of 3 Ibs. To increose the weight of pull turn screw No. 28 clockwise. To remove the creep of the trigger, it hos to be odiusted in the opposite woy like two stoge hoir trigger.

Trigger No. 20 moy be moved for occomodotion of 0 smoll or lorge hondo

The Anschutz combined double set/single trigger mechanism

No. 5039

The combined double setlsingle trigger hos two possibilities.

It con be used os

0 supersensitive single trigger ond olso os 0 2-stoge hoir trigger, in the loiter cose the odiustment being the some like the normol ANSCHUTZ 2-stoge hoir

Motch trigger.

Using the single trigger only the odjustment is os follows: Push trigger level No. 200 forword the trigger level 20 is set ond reody for use.

To increose sensitivity, the trigger spring odjustment screw No. 28 must be turn.

ed onti.clockwise.

It is odvisable to turn this screw so for that the trigger goes off by itself.

then turn screw clockwise by 0 quorter turn to produce 0 very fine pull. Trigger No. 20 moy be moved for occomodation of 0 small or large hondo

II

-20

5

The Bolt

The Anschutz Lock has..bee

ept purposely heavy and is £ tl)

, finest construcJ.i.o~T11e bolt and cam are ground in to gi~~it that sa!jp...fe-eting when in motion and has two locks. The ~irg s fet110cks the firing pin and also the bolt handle. When ~afetY

IS in safe position the bolt cannot be opened. The firinli/'pin I's kept as light as possible and travels at lightning speed ver the shortest space for instant ignition.

\

,

..,

------..

A

How to disassemble the Bolt

,Push back on left side

-o

~ toCk the bolt stop an remove bolt (1IIustra Ib~ No.1)

2.TurncC\l,[1terciock

bolt hanCileand the

safety in

~ r.ections

as pe lion No.2.

osite dilustra-

L

3

2

1/

-.....

-

1,0

"

-.......

!

.~

."'~ out all parts towar !; the top as illustration

No.3 and4.

4

..

~~

-..

L.

11-

if----

"'-

.::.~

~~~~

.

~

~

,

i

I

~

I

'

6

B

""----

Re - Assembling of Bolt

j

There assembling is accomplished by followin the procedure revers stated under A.

z

d

's

A. Put bolt handle b ck in place, make

sljte

the locking pin ~titers in the second "otch to keep the sit in the firing pin free (see illustrationS).

/

B. Put firg pin in place.

C. Put ~olt nut with safety in .I.place, pull safety apa bolt handle apart nd push safety down

(see illustration No.6).

....

'-

5

7

8

The Anschutz

Micro Sight

For the Anschutz Match Rifle there is a choice of 2 sights the No.

6702 Micro sight with scale or the Micro sight Na. 6700. The rear sight is mounted on a rail which slides on the grooved receiver bridge.

Two knurled pressure screws are provided for locking the rail to the receiver.

The receiver sight is adjustable to obtain desired eye-distance.

Peep sight discs may be had with various apertures such as 1,1 and 1,2 m/m diam. Any other size may be ordered special. The small size is recommended for strong light and the larger one when less light is available.

Adjusting the Micro Sight

How to adjust the Anschutz Micro Sight Na.

6702. It is a well known fact that the Anschutz

No. 6702 holds its adjustment due to its precise click arrangement from click to click at 50 meters about 2,5 m/m per click adjustment (1/6minute) at 100 meters about 5 m/m per click

.

No. 6702

If shot is high turn elevation screw to the right.

If shot

is low turn to the left.

I

Iltl

For best results we recommend the No. 6702

Anschutz Special Micrometer Sight with scale preferable to use in connection with the new

INTERNATIONAL SMALL BORE Target.

9

10 d c

'0)

.~

Zero Setting of the Micro Sight

At normal weather

wind and light condi-

tion-torget in your Anschutz at Dead Center.

Then proceed os follows:

A) Loosen up the 2 retoining screws of the two indicotors, set the windage indicator exactly on the centerline morking and the elevation indicator exoctly at the distance

(For Example if it is 50 Meters on 50) ond tighten the lock screws.

B) There is underneath the Knurled Knobs far elevation and windoge a lock screw to be opened up sufficiently to ollow the lifting of both Knurled Knobs to be turned without click, easy setting.

C) Turn so thot the number "0" (Zero) is visible in the direction of the shooter, ollow

Knob to drop back.

D) Tighten up both lock screws.

Now your Micro Sight is zeroed in for Normal shooting range.

Anschutz Micro sight No. 6700 adjustment.

The No. 6700 is a precision instrument of fine quality.

1) Elevation the adjustment knob has stops.

From stop to stop there is at 50 meter

2,5 m/m and at 100 meter 5 m/m elevation difference.

2) Windage is controlled by two Knurled set screws working os a teom. This eliminates any chonge of the sight setting not wanted.

These two set screws have 6 surfaces.

From surface to surface are to be figured a change of 2,5 m/m for 50 meters distance and 5 m/m for 100 meters.

In between setting con be made as found necessory as there are na clicks. If the rifle shoots to the right, releose left screw ond tighten up the right side screw and the some reversed procedure if rifle shoots to the left.

,.

No.

6700

11

(i)

Front Sights

Aperture Type

No. 6522-3

I

\1

12

@

.

-.

Orthocolor

Yellow Lens

No. 7860

Front Sights

Post Type

No. 6522-5

.

Peep sight discs

No. 6700-5

Rubber disc

No. 6700-20 are available in various apertures. The most

popular are 1,1 and 1,2 m/m and are always in stock. Other sizes on special order.

The small aperture is for strong sunlight and larger one for poor light.

fits on to the peep sight steel disc.. It has a grooved protection tube which the shooter is able to cut off groove by groove depending the length required.

In the inside a optical lens or a yellow sunfilter may be set.

has two types of interchangeable inserts one with a square post and one with a round aperture.

The post type may be had in 5 different sizes 1,7, 2,0, 2,3, 2,6 and 3,4 m/m width.

The round aperture sight can be furnished in sizes 1,7 to 5,5 m/m each 0,1 m/m more in size.

However, experience has proved that such round apertures with a small hole are bad for the eye and do cause errors in Shooting. For this reason for 50 meters at the Internatianal

Small Bore Target a round aperture should not be smaller than 3,5 m/m and for 100 meters

2,9 m/m.

The design of the Globe front sight serves as a front sight protector as well as a light control and the insert can be changed by.

releasing the lock screw. If the light is very

I strong two cylindrical extensions can be attached as illustrated.

(Order No. 6525/26).

.~:.~"-'

~

The Anschutz Spirit-Level

The ANSCHUTZ Spirit-level (for Front Sight

Anti.Glore

Tubes

6522-1) enables the shooter to correct imme-

No. 6525/26

diately his position before firing each single round.

The ANSCHUTZ Spirit-level is inserted into the Globe Foresight and can be easily turned in such a manner that when aiming with the rifle in a comfortable position the bubble of the spirit-level equalizes above the pOinter'

In this position the spirit-level is set by means

of a careful turn of the screw. A. clockwise.

The Anschutz Iris gives yau 8 different apertures 0,8--1,7 m/m which gives you the facility to shoot under any light condition. You don't need to carry any further various discs as the Iris opens like a camera shutter and is always perfectly

Sling

i

it

!.

I l.

..

""

Iris-Disc No. 6711

round due to its unique construction.

The Anschutz Sling Strap for the Shooter so important may be had for right hand or heft hand. Through the setting of the loop which is covered with special

No. 7400

rubber a firm grip of the arm sling is assured and makes it easy to make any further correction instantly and without any difficulty.

Specially desirable for prone and in knee position shooting.

13

:~f7)

.

Small Bore Rifle Care

Two Rifles in one stock with Anschutz. 22 lR and Zimmerstutzen Barreled Action Cal. 4 mm

[

~.=!;

--

~

No. 4401 The Cleaning Rod Guide

14

When you purchased an Anschutz Match Rifle you have become a member of the" Anschutz" System which gives you a further possibility to enlarge your selection of shooting equipment.

For Example

I.

Purchasing an extra Super Match stock your Model 54 Match

Rifle becomes a special rifle for participation in any International Matches.

2. The purchase of a Zimmerstutzen barreled Action will fit the same Buttstock which gives you an Indoor Match Rifle of the finest quality.

There is simply nothing better anywhere.

3. The Anschutz Indoor Match Rifle also known as the Zimmerstutzen can be transformed instantly into a .22 LR Match Rifle by purchasing a Model 54 Match barreled action.

The advantages are always the same fit, shooting all year around, same weight and sights.

You save as you need only one set of sights.

When changing over always make sure to tighten the rear assembly screw first, then the front assembly screw.

Again in the same turn tighten both screws good and tight.

Be sure that the top of front assembly screw and abuttment corresponding hole and rabbet plate are of the action.

not in touch with the

,..

Before starting always dry swab the barrel of your Rifle.

After you are through shooting it is always best to clean and oil your rifle.

Remove the bolt, to avoid damaging it is always best to insert a cleaning Rod Guide as the No.

breech.

4401 illustrated above in the

If there is some

Gun Flannel use it as otherwise erly.

it will not take

Push the cleaning the grooves proprod forward until the beginning can be seen at the muzzle.

In case you pushed the cleaning plug through all the way never try to pull back.

Just dismount the plug and then withdraw the Rod. Renew patch until it stays clean, then spray on a few drops of good gun oil and swab the barrel once more. Never use steel or wire brushes, never scratch around in the barrel, always a full length stroke.

15

<.

"\f

II

I

-,

"- '''III

'

',~

~~

\

,

~.

11 r~'~

~

Zimmerstutzen Core

I

'

16

Again we advise ta clean aut the barrel and swab dry before starting to shoot.

After you are finished shooting clean out the barrel of your Zimmerstutzen.

We supply with each Zimmerstutzen a cleaning outfit consisting of

1 Cleaning Rod

1 Brass Brush

1 Bristle Brush

1 Rod Tip

Remove as above the bolt and insert a wooden cleaning Rod

Guide No.

4401.

The residues of the Zimmer ammo require a brass brush for cleaning whatever there is still left then in the follow barrel.

with a patch

Follow to up with remove an oil soaked patch.

Never use steel brushes at any time.

The outside tube of the Zimmerstutzen barrel never needs cleaning as it has a slot underneath to allow escape for any residues.

ANSCHUTZ Motch Air Rifle Mod. 220

Col. .177 (4,5 mm)

~

~

1.

No recoil on firing due to the new system of compensating

(Only after the pellet has left the barrel is the force of the plunger compression.

striking thus giving the some feeling as shooting with a small the cylinder wall noticed; bore target rifle.)

2. Distance between sights, 31'/2 inches.

Fixed barrel, the line of sight being always constant in comparison with a "breakdown" air rifle where the foresight is moved every tima the rifle is cocked.

The sight and tunnel foresight with elements,

ANSCHUTZ micrometer used with the ANSCHUTZ peep.

Model 54 small bore Target Rifles, can also be used with this Match Air Rifle.

This is most economical rifles.

for the shooter as the some set of sights can be used with both

3. The rifle is cocked by means of a lever placed of the side of the air chamber.

By a patented control of compression a constant pull has been achieved thus eliminating prone, kneeling or fatigue standing to the arms and affording positions.

So the easy cocking whether

ANSCHUTZ

Match Air Rifle beco.

in mes the ideal training and Match weapon for 3-position competitions.

4.

Easy to load by a self locking loading plotform-

S. Stack: Some shape as the ANSCHUTZ long fore.end

swivel plate for the sling

Model swivel

54 small adjustment.

bore target

It is also rifle, possible with to use other plate etc.

accessories such as the polmrest, sling and interchangeable Hook heel

6.

An excellent balance.

-

Total match trigger weight: approx.

mechanism positioned

9'/2 Ibs. - Overall at a point for perfect length:

45 inches.

7.

It is unnecessary

new improved material.

to lubricate the air chamber or plunger due to the use of

8. The ANSCHUTZ stock for Left.Handed

Match Air Rifle is also available shooters.

with cocking action and

9. As a result of the excellent method of loading and, design bore forget rifle, the discriminating both Match and training purposes.

precision of the ANSCHUTZ Match Air Rifle, the adopted from the ANSCHUTZ marksman has at last a perfect

Mod.

54 small weapon for

17

18

SPARE PARTS LIST FOR.

TARGET RiflE

MODel 54 SUPER MATCH CAl.

.22

LONG RiflE

~

'

~

75-

..:

: ,~'

:

.

:

::

16.j

.

.

. 6J

~"':

,

..

:;:

::

1" i~

~~

.

..""

1

'1'C).~,~

/"

"

Q

'O~~

.!".J!;"-"{j)"

-.,~"

4

9'

,-. .m

~..

~

£""),

~

"~'

/;~.

.~

~1~

.

J9

'~"--~""'-:

71

'."

~~'6

I'

",,-,.

-'-'~1

'qI,,'-..,~f'

~

~""

13:

~

:~

, ~, 't._~JO

J86

~J1

J5,'

AJ6

.

;,J<,.

:

2

.

'

'2, "..~...

~'

,.1~

~.,;

~

,

;'6f: i .'J

''-7J

19

21T\f..~6,,-'..::'\17

,

'

'ZS

'

Z210 ~

'-"...

YJ"

'"

~i

!61

,-

:-'~'J

66

~

<iIIi'SS

'

.....

No

,...

)

I

2

"

10

12

:,

,.

t

:

""c~.'.

:::::=~~~

"'."

11 n

~.'~'~

21 ...... I,..~

....""

"",

..trocOOf'''''''O

~:'~::-IodII""

:~ "'""0""'.100........".

U t:::::::........

,..,...

~:~: n

,.

,.

)0

:::::.:...;it _.

21 :~~.....

)2

"

...-

.......-.d'>e""".'''''''',

:3.~~-"I''''

)1

31

~::::::

~='

"

::

::::::....;",

'0"

'10

U

'--' ..."'-' u

..

~i:~~;r;:'~~";"':';~~~.

::;.::" "".",

..',..

~~:::-:::..

g

n

_"",,,..10'.

""'''.''''od,w...It'.''''.........................

,-,~"""""~,,,'.C""".'.

od,wIIOIt'.............oo....-

n

,.

HI...

""""1 w-

"'.""",

*

"

::

::

"",.""."",.

No"

.1..

610010

:?~~:"::::;i:~~!-:~~~II

'w"""'.'.''''''.

.nl

.m

.'"

~f:.~o~...~":,~:7:':.:':'~.

"I_..' r.~::'.~"w:;':'l~

_I

-.001-.-

...":::i:. "I_..,

....,. ...

JI'i'j'

The Anschutz Action Mod. 54

15

I

81,

63 41

I

75 79

I

31

A Short Final Word

Hoving now become familiar with your new Anschulz Match Rifle, you are now ready to devote the many hours of practice which are necessary for you to reach the championship grade.

Toke your lime, practice with your friends or in your basement with the Zimmerstutzen insert. Consider our well intended instructions as on aid to your practice.

On the following pages keep a record of good and bod scores. In this way you con see your progress.

ONE MORE CAUTION! Never aim a rifle at anyone loaded or not. Follow the rules as established by your organization.

Never aim at a bird, it is better to feed them in the winter.

AND ONE MORE

REQUEST.Please tell your friends that you are satisfied with your Anschutz Model 54. In case you habe any suggestion or improve men Is you wont us to consider just let us know.

Once more LOTS OF LUCK!

Cordially yours

J. G.

Anschutz

19

I

'I

-

~

.f

",.

~IJ

-'\r

I .. L

:\.

[r

-

ANSCHUTZ rifles have proved their accuracy and excellent workmaship in many smallbore competitions throughout the world

World Championships 1958 in Moscow

with ANSCHUTZ

4 world chompionships in smallbore competition further: 2 second places 4 third places

European Championships 1959 in Milan

with ANSCHUTZ

3 world records

S European Championships (Gold Medals)

4 Silver Medals and many morc other great successes

Olympic Games 1960 in Rome

Half of the Small bare Target Marksmen from all aver the world shot in Rome with ANSCHUTZ

Olympic Match

Gold Medal

Silver Medal

Bronze Medal

3.Position

Malch

Branze Medal

Germany

America

Venezuela

Germany with ANSCHUTZ with ANSCHUTZ with ANSCHUTZ with ANSCHUTZ

How can you miss with an

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
