Invitation for Bids

Moving Equipment

Moultonborough, NH

March 18, 2010

Karel A. Crawford, Chairman

Board of Selectmen

Table of Contents

Advertisement…………………………………………..… 3

Scope of Work or Specifications and Conditions……… 4

Bid Forms……………………………………………….… 6

Exhibit A …………………………………………………. 12

Exhibit B …………………………………………….…… 15

Exhibit C ……………………………………………….… 17

Exhibit D …………………………………………….…… 18

2

PLEASE POST

TOWN OF MOULTONBOROUGH

Invitation for Bids

Sealed bids for the provision of various items of motorized equipment/vehicles will be accepted until 4:00 p.m. on Thursday, March 18, 2010 in the Offices of the SelectBoard, 6 Holland Street, PO Box 139,

Moultonborough, NH 03254. They will be opened and publicly read aloud at 7:00 p.m. that evening or as soon thereafter as the SelectBoard’s agenda allows. You may bid one or more items.

Item 1:

Wood Chipper w/12” jaws, Tier 3 Diesel Motor mounted on trailer frame

Item 2:

2010 Ford F550 cab & chassis w/dump body plow package and slide in sander

Item 3:

2010 Police Patrol Cruiser

Item 4:

2010 Rubber Tired Backhoe w/excavation/ditching/loader bucket(s) Tier 3 Diesel Motor

You will provide a quote for a trade-in allowance of certain equipment on each item. Items 1, 2, and 3 are an all cash purchase. Item 4 is to be provided under a lease/purchase agreement. A detailed package with information on the equipment to be delivered, the conditions thereof, and bid forms, is available at www.moultonboroughnh.gov

(click on Paid, Volunteer and Contract Openings) or said offices during normal business hours.

The bid on each item is to be submitted in a separate sealed envelope marked, Bid for Motorized

Equipment, March 18, 2010, and the item number you are submitting on. If mailed, each bid should be in a separate sealed envelope similarly marked to protect against the actual bid being opened in error. Any questions with respect to this invitation must be received, in writing by mail (above address), by email

( [email protected]

), or fax (603.476.5835) by Carter Terenzini, Town Administrator, no later than 4:00 p.m. on March 11, 2010. It is the bidder’s responsibility to view and account for any addendums relating to this request. These will be posted on the Town web site no later than 4:00 p.m. on

March 15, 2010.

The town reserves the right to reject any and all bids, and waive any minor or non-material informalities, if deemed to be in its best interests.

Karel A. Crawford, Chairman/s/

Board of Selectmen

Posted: Town Bulletin Boards (7)

SAU

Advertised: Meredith News & Carroll County Independent 02/25/10 & 03/04/10

Manchester Union Leader: Same Dates

Mailed: Vendors List

3

Web: Craigslist;

winnipesaukee

.com

; NHLGC

4

Scope of Work or Specifications and Conditions

1.) General Description of the Project, Materials and Quantities

The Town will procure four pieces of motorized equipment:

Item 1:

Wood Chipper w/12” jaws, Tier 3 Diesel Motor mounted on trailer frame

Item 2:

2010 Ford F550 cab & chassis w/dump body, plow package and slide in sander

Item 3:

2010 Police Patrol Cruiser

Item 4:

2010 Rubber Tired Backhoe w/excavation/ditching/loader bucket(s) Tier 3 Diesel Motor

You will provide a quote for a trade-in allowance of certain equipment on each item. Items 1, 2, and 3 are an all cash purchase. Item 4 is to be provided under a lease/purchase agreement.

Item 1 is a cash acquisition.

You will quote on the equipment, as specified, with and without a trade in. The trade in is a

1989 Eager Beaver Chipper w/8” jaw & 4 cylinder diesel motor. It is currently in regular use.

Item 2 is a cash acquisition.

You will quote on the vehicle, as specified, with and without a trade in. The trade in is a

1997 GMC 2500 ¾ ton 4x4 pick-up truck w/8’ Fisher plow (159K+/- miles) gas powered. It is currently in limited use

Item 3 is a cash acquisition.

You will quote on the vehicle, as specified, with and without a one or two vehicles being traded in. The two trade ins are (a) a

2006 Ford Crown Victoria Police

Interceptor (114k+/- miles) which is currently sidelined with a transmission problem. s) and (b) a 2005

Ford Crown Victoria Police Interceptor (113k+/- miles) which is currently in regular use.

Item 4 is a lease purchase.

You are quoting the actual monthly lease payments on an even monthly amortization schedule over the five year term of the lease. The final purchase price is $1.

You will quote on the equipment, as specified, with and without a trade in. The trade in is a 1989 Case 580

Super L 4*4 backhoe w/thumb/wrist/ditching bucket (5k+/- hrs). It is currently in regular use.

The lease will have an annual “escape” clause in it in case the Town Meeting does not approve the annual funding. There is no known event of this happening in the past.

2.) Specifications & Certification

Item 1:

See Attachment A

Item 2:

See Attachment B

Item 3:

See Attachment C

5

Item 4:

See Attachment D

*Important Note:

If you are submitting a bid that varies in any of the equipment or accessories asked for, you must submit an explanation of this. Explain which Item # you vary on and why.

* Important Note:

If the specification sheet calls for you to fill in the particulars on any of the equipment so that we may compare manufacturers, you must do so.

3.) Delivery Location and Timing

All items fully furnished and equipped as specified, are to be delivered to the Moultonborough

Highway Garage off Moultonborough Neck Road.

You must specify the number of calendar days, from placement of our order, it will take you to deliver the time. Please note below if any equipment is to remain in continued use until the time it is traded in.

4.) Term of Contract

N/A

5.) General Conditions

a.) The Trade in against Item 1 will remain in continued, but limited, use until the date of delivery of the new equipment. b.) The Trade in against Item 2 will be taken out of service until such time as we accept delivery of the new equipment. c.) The Trade in against Item 3 will be taken out of service until such time as we accept delivery of the new equipment. d.) The Trade in against Item 4 will remain in continued use until the date of delivery of the new equipment. If you cannot deliver the new Backhoe within sixty (60) days of an order being placed, you will be required to loan a Backhoe to us for our use that will perform within the same range as the one we are requesting. e.) If you are in default of this contract you will be given ten (10) days notice to cure the default.

You will have an additional ten (10) days to cure the default. If you do not do so we may cancel the contract. f.) Any cash payment due to you will be paid upon delivery. Any lease payment due to you will be paid starting thirty (30) days after the commencement of the lease, and then every month thereafter.

6

g.) The term “days” shall mean calendar days. h.) Bidders must include a n amortization schedule showing the principal remaining after each lease payment. The Town reserves the right to pay the balance due at any time and terminate the remaining portion of the lease though completing the purchase. i.) Reserved: If the Town chooses to trade in one or both pieces of moving equipment against the new grader, the monthly lease payment will be reduced by the percentage of the dollar value of the piece(s) being traded in divided by the piece being acquired. j.) Unless otherwise specified, you must provide the standard factory warranty as specified by the manufacturer. j.) You must have a factory approved service facility within 50 miles of Moultonborough for

Items 2, and 3 and within 75 miles for Items 1 & 4.

6.) Questions and Supplements

Any questions with respect to this invitation must be received, in writing by mail (above address), fax (603.476.5835) or email ( [email protected]

), by Carter Terenzini, Town

Administrator, no later than 4:00 p.m. on March 11, 2010.

*Important Note:

The answers, and any other changes or supplements to this document, will be posted on the Town web site as an Addendum no later than 4:00 p.m. on Monday, March 15,

2010. It is the bidder’s responsibility to check and verify any such changes in order to account for them in their bid.

7.) Viewing of Trade-In(s)

You may view the Trade-Ins by making prior arrangements with Mr. Scott Kinmond, Road

Agent/Director of Public Works. You may contact him by email at [email protected]

or by phone at 1.603.253.7445.

8.) Bid Due Date and Methods of Delivery

Bids will be accepted until 4:00 p.m. on Thursday, March 18, 2010 in the Offices of the

SelectBoard, 6 Holland Street, PO Box 139, Moultonborough, NH 03254. They will be opened and publicly read aloud at 7:00 p.m. that evening or as soon thereafter as the SelectBoard’s agenda allows.

The bid on each item is to be submitted in a separate sealed envelope marked, Bid for Motorized

Equipment, March 18, 2010, and the item number you are submitting on. If mailed, each bid should be in a separate sealed envelope marked, similarly marked to protect against the actual bid being opened in error.

7

Town of Moultonborough

Moving Equipment

Bid Form

(Please Print or Type)

Name of Bidder:

Address:

Contact Person:

_________________________________________________

_________________________________________________

_________________________________________________

______________________

Telephone

_________________________________________________

Email

ATTENTION:

Ms. Karel A. Crawford, Chairman

Board of Selectmen

PO Box 139

Moultonborough, NH 03254

Dear Ms. Crawford:

_______________________

Fax

Having examined the documentation provided with the subject Invitation for Bids the undersigned proposes to furnish all materials as requested in accordance with the subject documents.

The undersigned acknowledges Addenda # ________________________________________

(If none, write none).

If I am notified my proposal is accepted within forty five (45) days of the bids having been opened, I will execute a contract for the work within fourteen (14) days thereafter.

I propose to provide the following Items for the following unit pricing:

Important Note:

If you are not bidding on one of the items write the words “No Bid” In each of the appropriate blank spaces.

8

Item Price

1.) Wood Chipper w/12” jaws, Tier 3 Diesel Motor mounted on trailer frame

A. As specified $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

B. Tr ade in of

1989 Eager Beaver Chipper w/8” jaw & 4 cylinder diesel motor.

$_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

Time for Delivery:

I will deliver this equipment within __________ days (In Figures) of your placement of your order.

2.) 2010 Ford F550 cab & chassis w/dump body, plow package and slide in sander

A. Ford F550 as specified $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

B. Trade in of 1997 GMC against A $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

Time for Delivery:

I will deliver this equipment within __________ days (In Figures) of your placement of your order.

C. Ford F550 w/ Option #1 Package $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

D. Trade in of 1997 GMC against C $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

9

(In Words)

Time for Delivery:

I will deliver this equipment within __________ days (In Figures) of your placement of your order.

E. Ford F550 w/ Option #2 Package $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

F. Trade in of 1997 GMC against E $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

Time for Delivery:

I will deliver this equipment within __________ days (In Figures) of your placement of your order.

3.) 2010 Police Interceptor

A. As specified $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

B. Trade in of 2006 Ford Crown Victoria against A

$_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

C. Trade in of 2005 Ford Crown Victoria against A

$_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

Time for Delivery:

I will deliver this equipment within __________ days (In Figures) of your placement of your order.

4.)

2010 Rubber Tired Backhoe w/excavation/ditching/loader bucket(s) Tier 3 Diesel Motor

A. As specified $_________________

(In Figures)

10

__________________________________ Dollars and _________ Cents

(In Words)

Important Note:

This is a monthly lease price, including all principal and interest, for an even amortization on a five year lease.

B. Trade in of

1989 Case 580 Super L 4*4 backhoe against A.

$_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

Important Note:

This is a monthly lease price, including all principal and interest, for an even amortization on a five year lease if we trade in the 1989 Case.

C. Quote the monthly amount Item A. is reduced for every $1,000 that we apply in cash to reduce the amortized capital value of the equipment.

$_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

C. Quote the monthly amount Item B. is reduced for every $1,000 that we apply in cash to reduce the amortized capital value of the equipment.

$_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

D. Trade in of 1997 GMC against C $_________________

(In Figures)

__________________________________ Dollars and _________ Cents

(In Words)

Time for Delivery:

I will deliver this equipment within __________ days (In Figures) of your placement of your order.

I understand that the town reserves the right to reject any and all bids, and waive any minor or non-material informalities, if deemed to be in its best interests.

11

I understand that the Town may hold my bid for forty five (45) days prior to awarding a contract.

I certify, under the penalties of perjury, that (1) I have had an opportunity to view the full bid package and am aware it was my responsibility to perform my own due diligence appropriate to submitting this proposal, (2) I am fully authorized to submit this bid, (3) I have not engaged in discussions, negotiations, or collusion with any person to determine what my bid will be and (4) that I, to the best of my knowledge and belief, have paid all taxes, fees, assessments, betterments or other municipal charges that I owe to the Town of Moultonborough or have payment agreement in place or have filed an appeal over the same.

_________________________________________________

Signature of Bidder

_________________________________________________

Title of Bidder

Signed this ________day of ___________________, ______________.

Corporate

Seal

12

EXHIBIT A

The following specifications are designed to describe a hand fed pocket drum disc style chipper with hydraulic feed wheels, which is to be a heavy duty industrial grade machine. It shall produce dimensional, landscape quality chip with a 12” (31 cm) chipping capacity. The unit shall comply with applicable requirements of the vehicle code and OSHA. All visual warning devices and decals shall be applied.

I. ENGINE

a.

Tier III Diesel Engine b.

Horsepower: Minimum of 80 hp c.

Displacement: 4.5 liter or larger d.

Alternator: 75 amp minimum e.

Fuel Tank: 22 gallon minimum f.

Engine warranty: Minimum of 5 yrs g.

Air Cleaner indicator

II. DIMENSIONS

a.

Length: 17' 7" maximum b.

Height: 8'2" maximum c.

Width: 6' d.

Weight: 6,300 maximum

III. INSTRUMENT PANEL

a.

Hour Meter b.

Start switch, hand throttle c.

Ammeter d.

Electronic Fuel Gauge- Optional

IV. TRAILER: a. Frame

1.

Rectangular steel tubing 2' X 4"X 3/16" minimum or larger

2.

Heavy duty center beam (4"x4") preferred

3.

All welds continuous, both sides and top and bottom

4.

Lockable tool box, mounted to frame

b. Tongue:

1.

2 1/2 " Pintle hitch

2.

Tongue jack with stationary foot pad

3.

Telescoping tongue with minimum of 12" adjustment

4.

Appropriate safety chains with tensile strength to meet GVW

c. Axle:

1.

Single axle: minimum of 6000 lb or GVW equivalent

2.

Equipped with electric brakes and brake away actuator

d. Tires/Wheels:

1.

Minimum of: (2) 225/75R/15 with 6 bolt rims

2.

Wheels protected by fenders and splash guards

3.

Set of wheel chocks and chock holders

e. Electrical:

1.

Four Function LED Tail lights to meet ICC regulations, all wires protected

2.

Amber flashing safety lights in addition to tail lights

3.

7-pin round electrical connector

Meets Deviates

13

14

for access to the anvil by using valve provided. A locking pin shall be provided.

c. Bottom Feed Wheel:

1.

Same as Tope Feed wheel design.

2.

Bottom feed wheel shall be driven by a hydraulic motor solidly connected to the feed wheel shaft. The assembly shall be enclosed by metal guards.

VIII. HYDRAULIC SYSTEM:

a.

Tank: Minimum 13 gallon with sight gauge, lockable cap, clean out port for maintenance. b.

Hydraulic system filter spin on type. c.

Hydraulic motors d.

Hydraulic control valve for manual operation of infeed system. e.

Safety bar: Feed bar at infeed chute with forward, neutral and reverse feed system positions. Safety bar has stops for forward and reverse positions to protect hydraulic valve spool. f.

Unit equipped with a reversing automatic feed system. g.

Unit shall be equipped with a heavy duty 3/16" cable winch.

IX. COLOR

a.

Manufacture standard color

X. Misc.

a.

Safety / operation manual or DVD disc. b.

Service Manual

c.

Set-up and delivery to Moultonborough Public Works Facility.

Please explain all deviations:

15

EXHIBIT B

Yes

Yes

No 2010 Ford F-550 4X4 DRW Cab & Chassis

141" Wheel base

Forest Green metallic

Vinyl bucket seats or 40/CNSL/40 (L)

Preferred equipment package- (660A)

XL Trim

Air Condition

AM/FM stereo- clock

6.7L V8 Diesel

6-speed auto transmission (W/PTO Option)

225 Max Trac

4:88 LTD Slip

XL Décor Package

Pwr equip group (90L)

Front License plate bracket

19500 GVWR Package

Molded Black step

Engine block heater

50 state emission

Jack

Art Axle tank

Dual Alternator

Front Grille Cover

Trailer / Snow Plow prep package

Battery Upgrade (86H)

Hydro Boost Brake

Brake Controller

No OPTION #1; Accessories

“Air Flo” 9’ Dump body 3-4 yd , Stainless Steel sander body with ,

24” cab protector w/ window screen

34” Center conveyor w/ cover plate rear spreader

Quick latch tailgate

Mud flaps front and rear of rear tires

Safety prop/back-up alarm

ICC Lights and reflectors

Body painted Gloss “Black”

20 Ton Single cylinder hoist,

Transmission PTO pump central hydraulics system to

16

Yes

operate dump hoist, front plow, wing and functions; include sander control and plumbing to Spreader.

Strobe/LED light package (front 360 degrees, 2-rear facing)

Manual Crank & mesh net tarp

½” Plate w/ combo receiver hitch, D-rings and trailer plug

Front hitch with DA lift cylinder,

Plow Lights

Front wing post with slide and trip hinge.

Rear-wing weldment.

Sectional Valve for all functions, cab controls

FTP108 Power Angle Plow

HP108 Right hand wing with full trip arms

2FFL12 sander controls.

No OPTION #2; Accessories

9’ Dump body 3-4 yd steel dump body

24” cab protector w/ window screen

Quick latch tailgate

Mud flaps front and rear of rear tires

Safety prop/back-up alarm

ICC Lights and reflectors

Body painted Gloss “Black”

20 Ton Single cylinder hoist,

Transmission PTO pump central hydraulics system to operate dump hoist, front plow, wing and functions; include sander control and plumbing to

Spreader.

Strobe/LED light package (front 360 degrees, 2-rear facing)

Manual Crank & mesh net tarp

½” Plate w/ combo receiver hitch, D-rings and trailer plug

Front hitch with DA lift cylinder,

Plow Lights

Front wing post with slide and trip hinge.

Rear-wing weldment.

Sectional Valve for all functions, cab controls

FTP108 Power Angle Plow

HP108 Right hand wing with full trip arms

2FFL12 sander controls.

3-4 yd stainless steel hydraulic sander

17

EXHIBIT C

2010 Ford Crown Victoria Police Interceptor 3.27 Axle (720A)

Color: White

Cloth: Charcoal Black

Options

1)

478 Courtesy Lamp Disable

2)

525 Cruise Control

3)

45C Limited Slip Differential

4)

61K Heated Mirrors

5)

51A Drivers Side Spot Lamp

6)

96B Color Keyed Body Side Front Door Moldings Uninstalled shipped in trunk

7)

948 Rear Power Windows Delete-Drivers Switches only

8)

67BRear Door Handles-Inoperative

9)

21A Power Drivers Seat

10)

53M Radio Suppression Package

11)

432 Fleet Keyed Alike (Code 1284)

12)

Extended 3 Year 1000,000 Mile base care Warranty $50 Deductable

18

EXHIBIT D

Rubber Tire 4x4 Loader/Backhoe

MACHINE SPECIFICATIONS

The loader backhoe shall be equipped with the following features and/or specifications:

ENGINE

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

ELECTRICAL

Y___N___

Y___N___

Y___N___

4-cylinder, turbocharged diesel engine with a minimum 90 net horsepower at 2,000 RPM.

Engine displacement of 274 cubic inches or greater

Minimum SAE net torque rating of 280 ft-lbs at 1,400 RPM

Minimum torque rise at rated speed of 45%

Engine to be Tier III certified per Federal Emissions Standards

Direct high pressure common rail fuel injection

Internal oil cooler

Integral water pump

Engine shall be equipped with a suction fan

Aspirated dual-stage air cleaner

Cast iron oil pan design

Poly-V belt for fan and alternator

Automatic self-adjusting belt tensioner

Vertical spin-on engine oil filter

Cold weather starting aid Type:_________________

110v Engine Coolant Heater (100 watts)

Liquid cooled engine

Equipped with cruise control

500-hour engine oil change interval

12-volt electrical system

Minimum 90-amp alternator

Cold weather grid heater with dual 12-volt __________cold cranking amp batteries

FULLY SYNCHRONIZED TRANSMISSION

Y___N___ Torque converter drive with a fully synchronized transmission

Y___N___

Y___N___

Four forward speeds

Four reverse speeds

Y___N___

Y___N___

Y___N___

Minimum forward travel speed of _____________ with standard tires

Electric forward/reverse shuttle shift

Planetary transmission gears

Y___N___

Y___N___

Clutch disconnect button on shift lever

Clutch disconnect button on loader control lever

The powershift transmission shall provide the following:

Y___N___

Y___N___

Minimum of four forward and three reverse speeds

Auto shift function for ease of operation

19

POWER TRAIN

Y___N___

Y___N___

Y___N___

The loader backhoe power train shall be componentized.

Steering shall be hydrostatic

Heavy duty axles with brakes that can be serviced without removing the axle from the frame

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

On-the-go electro-hydraulic rear differential lock engagement

Lube-for-life drive shaft cross bearings

A single fill and check point for rear axle shall be standard equipment

Limited slip differentials in the front axle

Conventional differentials in the rear axle

Front axle with a minimum 77 inch fixed tread with 12.5 / 80 x 18 tires

On-the-go electrical four-wheel drive engagement

Front and rear axles with outboard planetaries

Single, double-rod steering cylinder

Steering cylinder located behind the axle

Lube-for-life drive shaft cross bearings

The axle load rating shall be:

Y___N___

Y___N___

Front Axle (4wd) maximum static – 62,000 lbs minimum. Yours:______________

Rear Axle maximum static – 67,000 lbs minimum. Yours;_____________

Y___N___

Y___N___

Y___N___

Y___N___

Front Axle (4wd) dynamic operating – 47,426 lbs minimum.. Yours;_______________

Rear Axle dynamic operating – 49,494 lbs minimum. Yours;______________

Front Axle (4wd) static operating – 18,969 lbs minimum. Yours;_______________

Rear Axle static operating – 19,798 lbs minimum. Yours;__________________

BRAKES

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Fully hydraulic, multiple wet disk brakes

Low effort, power boosted, oil cooled brakes

Brakes operated by two, suspended brake pedals

Maintenance-free and self-adjusting

Spring applied, hydraulically released parking brake

LOADER AND LINKAGE FEATURES

Y___N___

Y___N___

Y___N___

The loader arms shall be heavy duty and in-line, tool carrier design w/ 3 function hydraulics w/ aux plumbing to front

Arch design for short turning circle

Y___N___

Y___N___

Dual parallel lift cylinders

Cushioned loader cylinders

Ride control as standard equipment

The loader linkage shall have the following features:

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Dual parallel bucket cylinders

Single bucket cylinder

Cushioned bucket cylinders

Bucket cylinders with reverse linkage

Dual cast dump links to bucket

Full bucket rollover for dozing

20

Y___N___

Y___N___

Y___N___

Full bucket rollover for stability in backhoe operation

Automatic bucket self-leveling

Return-to-dig

LOADER BUCKET

The loader bucket shall be a minimum of 92 inches wide with a 1.25 cubic yard minimum

Y___N___ capacity., with bolt on cutting edge and skid plates

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Rear bucket rolled wrapper

Pre-drilled edge

Heavy duty lifting eyes

Bucket position indicator

Minimum SAE dump cylinder breakout force of 9,480 pounds force. Yours;__________

Minimum SAE lift capacity to full height of 6,182 pounds. Yours;____________

Minimum SAE dump clearance of 9 feet 2 inches at full height and 45 degree dump angle

Minimum SAE dump reach of 30 inches at full height and 45 degree dump angle

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Minimum hinge pin height of 11 feet. Yours;______________

Minimum dig depth below ground of 1.3 inches. Yours;_______________

Maximum loader lowering time (power down) of _____ seconds

Maximum loader lowering time (return-to-dig) of ______ seconds

Maximum bucket dumping time of _____ seconds

Maximum bucket raising time to full height of ______ seconds

BACKHOE AND CONTROLS

Y___N___ The backhoe boom shall be cast and have a five-year warranty

Y___N___

Y___N___

Y___N___

Y___N___

Grease pins in the swing tower to boom base

Replaceable bushings in the swing tower to boom base mounting pins

Boom width maximum of 11 inches

Mechanical bucket coupler

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Extendible exterior dipper stick

Extendible dipper stick can be pinned to prevent movement

Internal bolt-on, replaceable wear strip for extendible dipper stick

Minimum 900-pound front-mounted counterweight. Yours:________________

Stabilizers fully retractable within the width of the tires

Over-center backhoe design for improved balance during transport and roading

Integrated hydraulic backhoe coupler with in-cab controls

Pro Control system to provide precise control and eliminate over-swing

Pilot Controls shall be standard equipment

A control pattern change switch mounted on the pilot control column shall be included

Pilot controls must have wrist, infinite distance adjustments with reach of the operator

Pilot Controls shall be equipped with "auto up" stabilizers

BACKHOE BUCKET

Y___N___ The backhoe bucket shall be heavy duty

Y___N___ 24" Digging bucket quick attach

Y___N___

Y___N___

Y___N___

36" Ditching/shaping bucket quick attach

Will fit older model backhoes

Pin-on teeth

21

OPERATING WEIGHTS

Y___N___

Lightest configuration weight to equal ___________ lbs - machine equipped with 4WD,

ROPS canopy, vinyl air suspension seat, 92 inch general purpose loader bucket, 24 inch universal backhoe bucket, extendahoe dipperstick, ____________ rear tires, 12.5 X 80/18 front tires, single battery, flip over stabilizer pads, ________ lb counterweight, no operator

Heaviest configuration weight to equal _____________ lbs - machine equipped with 4WD, cab, cloth air suspension seat, 92 inch 4in1 loader bucket, 24 inch universal backhoe bucket, extendahoe dipperstick, _______________ rear tires, dual batteries, flip over stabilizer pads,

_______ lb counterweight, no operator Y___N___

TRACTOR DIMENSIONS

Y___N___

Y___N___

Maximum wheel base of 84.5 inches

Maximum transport height of 11 feet 4 inches

Y___N___

Y___N___

Y___N___

BACKHOE

Maximum overall transport width of 7 feet 9 inches

Maximum height of 8 feet 11 inches to top of cab / 9 feet 2 inches to top of canopy

Maximum height to top of exhaust stack of 9 feet 2 inches

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Minimum SAE dig depth with over-center backhoe for 24-inch flat bottom of 14 feet 8 inches

(retracted). Yours;___________

Minimum SAE dig depth with over-center backhoe for 24-inch flat bottom of 18 feet 2 inches

(extended) Yours;___________

Minimum digging force, bucket cylinder, 12,821 pounds force. Yours:______________

Minimum digging force, dipper cylinder 7,784 pounds force (retracted) / 5,635 (extended)

Maximum stabilizer spread in work position of 11 feet 4 inches

Y___N___

Y___N___

Y___N___

Minimum boom lift capacity at 10 feet of 2,700 lb (retracted) / 1,875 lb (extended).

Yours:________

Minimum boom lift capacity at 12 feet of 2,575 lb (retracted) / 1,850 lb (extended).

Yours;___________

Minimum dipper lift capacity at 10 feet of 4,190 lb (retracted) / 2,700 lb (extended).

Yours;_____________

Minimum dipper lift capacity at 12 feet of 4,360 pounds (retracted) / 2,680 lb (extended).

Yours;_______________ Y___N___

OPERATOR ENVIRONMENT

Y___N___

Y___N___

The loader backhoe shall have a cab with two doors

Minimum of four isolation mounts

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Insulation for maximum temperature and sound control

Air Conditioning & Heat

Sun Visor shade

AM/FM/WB Stereo w/ digital clock

Sound level maximum of 72 dBa

Suspended brake pedals

Suspended accelerator

Electro-hydraulic differential lock

22

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Transmission shift lever within easy reach of the operator and integrated clutch disconnect button

All glass surfaces free of rubber moldings

Front and rear windshield wipers

Interior dome light

Interior rear view mirror

2- external heated rear view mirrors

Retractable seat belt

Air Ride seat

Built-in molded cup holder

Front console storage area

Single handle loader control with top-mounted clutch cut-out button

Auxiliary loader hydraulic control built into the single handle loader control

Forward/reverse power shuttle lever mounted on the steering column

Parking brake switch located within easy reach to the right of the operator

Operator warning system that alerts the operator with an audible alarm when the parking brake is applied and the operator engages the forward/reverse lever

Instrumentation located to the right of the operator

Minimum of one accessory power plugs

The loader backhoe cab also shall have the following for backhoe operation:

Y___N___ Easy-to-swing seat to access backhoe controls

Y___N___

Y___N___

Y___N___

HYDRAULICS

Audible alarm to alert operator of transmission engagement when swinging seat

Rotary throttle control located within easy reach to the left of the operator

Auto-up stabilizer controls located together to permit one-hand operation

Y___N___

Y___N___

The loader backhoe hydraulics shall be closed center and allow for smooth loader and backhoe operation.

Variable volume, axial piston pump that is transmission mounted

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Total pump flow to be _______GPM at __________ psi available to the loader valve and backhoe valve

Allows operation of optional hand-held hydraulic tools

Anti-cavitation valves in the dipper and loader circuit

Pilot-operated check valves for stabilizers

Anti-rebound valve for backhoe swing precision

Factory installed backhoe auxiliary hydraulics to be of a uni-direction or bi-direction design with adjustable flow control Y___N___

SERVICEABILITY

Y___N___

Y___N___

The loader backhoe shall be easy to service from ground level.

Tilt hood that permits access to the engine with the loader arms raised or lowered

Y___N___

Y___N___

Y___N___

Y___N___

Y___N___

Minimum 40-gallon side-mounted fuel tank

Minimum hydraulic system (total) fill of _____ gallons

Minimum transmission total system fill of ________ quarts (4WD)

Minimum engine oil fill (with filter) of ________ quarts

Minimum __________-gallon hydraulic reservoir (with filter)

23

Y___N___

Y___N___

Y___N___

Y___N___

WARRANTY

Y___N___

Y___N___

Y___N___

Minimum window washer reservoir fill of ________ quarts

Lube for life drive line components

Remote front axle pivot lubrication fitting

________ hour service interval for engine oil

Full machine warranty of 12 months, unlimited hours

48 month or 5,000 hrs extended warranty for Full Machine

36 months / 10,000 hrs extended warranty for Structure-All" Structure component coverage

ADDITIONAL OPTIONS

Y___N____

Y___N____

Wain Roy Hydraulic Backhoe Wrist

Wain Roy Hydraulic Jaw bucket

Y___N____

Y___N____

Y___N____

Y___N____

Y___N____

Werk-Brau Multi-use hydraulic thumb for use w/ 24" bucket (Aux. elect over Hydraulic)

Quick detach front loader bucket w/aux hydraulics on loader arms for attachments

Total Machine Controls - Electric over hydraulic design

Pilot Controls

Front Fenders

24

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
