TURCK

Process Automation – Networks

PROFIBUS

®

-DP Selection Guide

AIM

Discrete Input

Discrete Output

Discrete Input & Ouput

Page

H11

H17

H21

FDP20

H33

Repeater

H37

AS-I

H39

BL67

H47

BL20

H49

Cables

H52

Terminating Resistors

H60

H1

Feed Through Receptacles

H61

Bus Tees

H62

Field Wireable Connectors

H63

Receptacles

H64

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA Selection Guide

Cables

H68

Terminating Resistors

H73

Feed Through Connectors

H74

Junctions

H75

Conduit Adapters

H89

Tees

H91

Gender Changers

H92

Surge Suppressor

H93

Field Wireable Tees

H94

Receptacles

H95

Field Wireable Connectors

H103

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H2

TURCK

Process Automation – Networks

PROFIBUS

®

-DP System Description

PROFIBUS-DP is an industrial network protocol that connects field I/O devices in order to eliminate hard wiring. The network connection increases device-level diagnostic capabilities, while also providing high-speed communication between devices.

PROFIBUS-DP is based on the RS-485 serial data transfer standard. In most cases, the termination and physical media rules for PROFIBUS-DP are the same as those required for RS-485 communication. A PROFIBUS-DP network supports up to

126 nodes and virtually an unlimited amount of I/O. The bus uses a trunkline/dropline topology. Power and communication are provided via separate cables, allowing easy segmentation of the power structure to avoid overloading.

PROFIBUS-DP is capable of running at data rates as high as 12 Mbaud. When used at high data rates, the cable drop length from the trunk to a node is severely limited. For example, when used at 12 Mbaud, nodes must be directly connected to the trunk, with no drop length allowed.

Typical System Configuration

BL20 I/O System

FLDP-IOM-88-0002-ST

D

Power Supply

E

E

RSM RKM 50-1M

RSM 2RKM 50

E

RSM RKM 50-1M

PLC & PB Masterontroller

A

Sensor

Valve

E

VB2

C

RSSW RKSW 455-1M

C

RSSW RKSW 455-1M

C

C

RKSW D9T 455-1M

RKSW 45-TR

FLDP IOM-32-0001

FLDP IOM-88-0001

BL67 I/O System

Basic Parts List

A typical PROFIBUS-DP system consists of the following parts:

• A - Master

• B - Slaves

• C - Communication cable

• D - Power supply

• E - Power cable

PROFIBUS-DP stations require a network master (also called a scanner) to interface the stations to the host controller.

TURCK PROFIBUS-DP stations are designed to be fully compatible with PROFIBUS-DP equipment from other manufacturers.

H3

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Cordsets

TURCK offers a complete line of molded PROFIBUS-DP cordsets to facilitate network installation, resulting in a faster start-up and fewer wiring errors. The bus and drop cables are specially designed foil-shielded, high-flex cables with very low inductance and capacitance to minimize propagation delay time. PROFIBUS-DP cables consist of a shielded and twisted data pair with a bare drain wire.

In most cases, connections of the bus cable to the stations are made using 5-pin reverse-key eurofast

®

(M12) connectors. A variety of stations are also available that support D9 type connections. Power for most stations is provided through one or two 5-pin minifast

®

(7/8-16UN) connectors.

TURCK cordsets for the PROFIBUS-DP system are available in standard lengths. Please contact your local sales representative to order custom lengths.

Diagnostics

TURCK network stations provide increased diagnostics over using traditional hard-wired I/O systems. TURCK stations also serve as a buffer between I/O devices and the PROFIBUS-DP network by detecting short circuits without disrupting communication.

The PROFIBUS-DP system includes a provision for special diagnostic data messages. These messages are triggered when a fault occurs at the station (for example a short circuit on a sensor). When the master asks the station for data, the station responds and includes a flag to indicate that diagnostic data is present. The master then asks for the diagnostic data, which is mapped to a special location in the controller's memory.

Addressing

The valid range of PROFIBUS-DP node addresses is 0 to 125. TURCK station's addresses are usually set via rotary dials or switches on the node. Changes to the address settings take effect when the station power is cycled or when the station receives a software reset. Care must be taken to prevent the same address from being assigned to more than one node in a system. Bihl+Wiedemann PROFIBUS-DP to AS-I gateways addresses are set in software using the on-unit display.

Communication Rate/Cycle Time

PROFIBUS-DP specifications define multiple transmission speeds ranging from 9.6 kbaud to 12 Mbaud. All nodes on a network must communicate at the same rate.

The complete cycle time of a PROFIBUS-DP system is affected by several factors:

• Number of nodes being scanned

• Amount of data produced and consumed by the nodes

• Network communication rate

• Cycle time of the control program

All of these factors must be considered when calculating the cycle time of a particular network.

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H4

TURCK

Process Automation – Networks

GSD Files

GSD files contain detailed information about a PROFIBUS-DP device, including I/O data size and the devices configurable parameters. The information in an GSD file, when used with a PROFIBUS-DP configuration tool, guides a user through the steps necessary to configure a device. GSD files are available on the TURCK website (www.turck.com).

Maximum Ratings

The PROFIBUS-DP bus uses a trunkline/dropline topology. The trunk is the main communication cable and requires the appropriate RS-485 termination at both ends of the trunk. Terminating resistors are available as plug-in eurofast

® modules or can be built into the D9 connectors. The length of the trunk depends on the communication rate. Drops or branches off the trunk are allowed, but are greatly limited as the communication rate increases. The table shows the maximum ratings for a trunk at different communication rates.

Communication Rate Max. Segment Length

9.6 kbps

19.2 kbps

93.75 kbps

187.5 kbps

500 kbps

1.5 Mbps

12 Mbps

1200 m

1200 m

1200 m

1000 m

400 m

200 m

100 m

H5

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Notes:

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H6

TURCK

Process Automation – Networks

PROFIBUS-DP AIM™ Stations

TURCK’s Advanced I/O Module (AIM) PROFIBUS stations are extremely rugged stations designed for machine mounting.

These stations allow easy connection of standard I/O devices such as sensors, limit switches, valves and pilot lights to a

PROFIBUS network, typically without a protective enclosure. This is made possible by epoxy-filled station housings, all-metal connectors and visible rotary address switches, among other things.

Mechanical Specifications

TURCK PROFIBUS AIM stations are designed for machine mounting with no separate enclosure or housing necessary.

Quick-disconnect capability, combined with an epoxy-filled housing, creates an extremely durable station that can be mounted in most industrial environments. Detailed environmental specifications are as follows:

• Housing material: Nylon 6

• Connector material: Nickel-plated brass

• Protection level: NEMA 1,3,4,12,13; IEC IP 67

• Operating temperature: FLDP style 0° to +55°C (-40° to +158°F)

• FXDP style -25° to +55°C (-40° to +158°F)

• Vibration: 50 g @ 10 to 500 Hz

Other housing and connector materials available upon request.

The station’s components are identified in the following figure.

Power Connectors

I/O Connectors

Address switches

Network Connectors

H7

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Connectors

PROFIBUS

®

AIM™ stations provide connections for the bus, I/O and auxiliary power.

Bus Connectors

eurofast ®

(M12) (reverse keyed) is the standard bus connector for PROFIBUS AIM stations.

PROFIBUS

eurofast Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

Different I/O connector pinouts are used for different station types. Stations are available with one or two inputs per connector, one or two outputs per connector, or one input and one output per connector. The pin assignments for these styles are:

eurofast Pinouts

Female

1 - V+ (24 VDC)

2 - Signal B (Odd numbered input)

3 - V- (0 VDC)

4 - Signal A (Even numbered input)

5 - N/C

5-Pin

Screw Terminal I/O Connection

AIM stations with part numbers ending in “ST” support screw terminal I/O and bus connections. The screw terminals for these stations are located on the back of the station. The back of the station is also fitted with a foam gasket to allow the station to be mounted to the outside of a cabinet or field I/O box (i.e. motor control center).

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H8

TURCK

Process Automation – Networks

Auxiliary Power Connectors

PROFIBUS

®

AIM™ stations accept one or two 24 VDC power supplies via the minifast

®

(7/8-16UN) connectors located at the top of the station. Stations with only inputs require the U

B both inputs and outputs need both supplies (U

B and the inputs, while U

L and U

L supply to power station electronics and I/O. Stations with

) to be connected. In this case, UB powers the station electronics powers the outputs. For further details, see the individual station entries in this catalog.

minifast Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

Power

Common power ratings for AIM stations include:

• Voltage: 18-30 VDC (both U

B and U

• Input Voltage: 18-30 VDC (From U

B

)

L

)

• Input Signal Current (each input): OFF < 2 mA; ON 4 mA (@ nominal 24 VDC)

• Input Delay: 2.5 ms

Addressing

PROFIBUS AIM stations must have a network address for communication. The address for AIM stations may be set via the visible rotary switches under the clear plastic cover on the front of the station.

The pair of switches represents the address as a decimal number; the left switch being the 10’s multiplier and the right switch the 1’s multiplier. To program the station, rotate the switches with a small slotted screwdriver until the arrows on the switch point to the appropriate numbers for the chosen address. Some stations (with outputs) have a third switch. This switch is used to enable auxiliary power diagnostics. If the switch is on, the loss of output power (U

L

PROFIBUS diagnostic message.

) will trigger a

H9

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Diagnostics

AIM™ stations provide two LEDs for diagnosing communication and power problems.

Bus

• Green: Working properly

• Red: No communication

Power

• Off: No power

• Green: Power present

• Red: U

B present, but U

L missing (stations with outputs only)

There is an additional LED for each I/O point on the station. This LED indicates:

• Off: Point is off

• Green: Point is on

• Red: Point is in short-circuit state (advanced diagnostic stations only)

V

I

V

O

SC

Abbreviations Used in Diagnostic Data Maps

Missing input supply voltage

Missing output supply voltage

Short circuit at the station (or at the particular I/O point if specified)

Connecting Devices to an AIM Station

AIM stations typically provide a eurofast

®

(M12) connection for each I/O point. Standard TURCK I/O cordsets can be used to connect physical devices in the field to the AIM station. Some AIM stations, specifically those with I/O counts greater than eight total points, connect two signals to each connector. If the signals being connected are on the same physical device (for example a sensor with two outputs), a simple four or five-wire cordset can be used for connection.

If the signals are on two separate devices, a splitter can be used to separate the AIM I/O connector into two individual

eurofast connectors. The recommended splitter is wired such that the second signal pin on the AIM station (pin 2) is wired to the default signal pin (pin 4) on the second splitter arm - requiring no special wiring by the user. The splitter is simply plugged into the AIM I/O connector and each arm is plugged into the appropriate I/O devices, as shown:

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H10

TURCK

Process Automation – Networks

Standard Input Stations

FLDP-IM 8-0001

FLDP-IM 16-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <110 mA plus sum of input currents (from U

B

)

• Sensor Current: <500 mA per four inputs (from U

B

)

Power Distribution

• Inputs: U

B power supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• One (...IM 8-0001) or two (...IM 16-0001) LEDs indicates short-circuit for I/O groups

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = NC

5-Pin 5-Pin

H11

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Inputs

Part Number

FLDP-IM 8-0001

FLDP-IM 16-0001

Input Count

8

16

0-7

Connectors

0-7

Pinout

S

2S

per

Inputs Connector Sensor Style

1 PNP

2 PNP

X

X

Input Connectors

S 2S

Data

I/O Map

1

2

Mating cordset:

RK 4.4T-*-RS 4.4T

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

I/O Data Map 1

In

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

Diagnosis

Status

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

SC

I/O Data Map 2

In

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0

1

I-7 I-6 I-5 I-4 I-3 I-2 I-1

I-15 I-14 I-13 I-12 I-11 I-10 I-9

I-0

I-8

Diagnosis

Status

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

SC

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H12

TURCK

Process Automation – Networks

Standard Input Station

FLDP-IM 32-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <110 mA plus sum of input currents (from U

B

)

• Sensor Current: <500 mA per eight inputs (from U

B

)

Power Distribution

• Inputs: U

B power supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• Four LED short-circuits for I/O (groups of eight inputs)

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = NC

5-Pin 5-Pin

H13

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Inputs

Part Number

FLDP-IM 32-0001

Input Count

32 0-15

Connectors

Pinout

2S

per

Inputs Connector Sensor Style

2 PNP X

Input Connectors

2S

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Data

I/O Map

1

I/O Data Map 1

In

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

1 I-15 I-14 I-13 I-12 I-11 I-10 I-9 I-8

2

3

I-23 I-22 I-21 I-20 I-19 I-18 I-17 I-16

I-31 I-30 I-29 I-28 I-27 I-26 I-25 I-24

Diagnosis

Status

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

SC

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H14

TURCK

Process Automation – Networks

Deluxe Input Stations

FXDP-IM 8-0001

FXDP-IM 16-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <70 mA plus sum of input currents (from U

B

)

• Sensor Current: <120 mA per connector (input or pair of inputs) (from U

B

)

Power Distribution

• Inputs: U

B power supply

Mechanical

• Operating Temperature: -25 to +55°C (-13 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit mapped to PROFIBUS diagnostic table, one bit indicating a fault for each connector (input or pair of inputs)

• One bit is mapped to PROFIBUS diagnostic table indicating the status of the power supply

Diagnostics (Physical)

• One LED indicates short-circuit for each I/O point

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = NC

5-Pin 5-Pin

H15

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Inputs

Part Number

FXDP-IM 8-0001

FXDP-IM 16-0001

Input Count

8

16

0-7

Connectors

0-7

Pinout

S

2S

per

Inputs Connector Sensor Style

1 PNP

2 PNP

X

X

X

X

Input Connectors

S 2S

Data

I/O Map

1

2

Mating cordset:

RK 4.4T-*-RS 4.4T

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

I/O Data Map 1

In

Diag

2

3

0

1

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

V

-

-

I

-

-

-

SC

-

-

SC-7 SC-6 SC-5 SC-4 SC-3 SC-2 SC-1 SC-0

I/O Data Map 2

In

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

1 I-15 I-14 I-13 I-12 I-11 I-10 I-9 I-8

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0

1

-

-

-

-

-

-

-

-

-

-

V

I

-

-

-

SC

-

2 -

3

H16

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

Standard Output Stations

FLDP-OM 8-0001

FLDP-OM 8-0002

FLDP-OM 16-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <150 mA (from U

B

)

• Output Current: <500 mA per output (...0001) or 2 A per output

(...0002) (from U

L

)

Power Distribution

• Outputs: U

L power supply

Mechanical

• Operating Temperature: 0 to +55 °C (-13 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• U

B and U

L power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• LEDs to indicate status of PROFIBUS communication and power supplies

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

H17

PROFIBUS

eurofast ®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Part Number

FLDP-OM 8-0001

FLDP-OM 8-0002

FLDP-OM 16-0001

G

Outputs

8

16

OutputCount

8 0-7

Connectors

0-7

0-7

G

Pinout

H

2G

per

1

2

Outputs Connector

1

Current

0.5 A

2 A

0.5 A

Input/Output Connectors

2G

Mating cordset:

RK 4.4T-*-RS 4.4T

H

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Mating cordset:

RK 4.5T-*-RS 4.5T

1

2

1

I/O

Map

Data

I/O Data Map 1

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

-

I/O Data Map 2

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0

1

O-7 O-6 O-5 O-4 O-3 O-2

O-15 O-14 O-13 O-12 O-11 O-10

O-1

O-9

O-0

O-8

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

-

H18

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

Deluxe Output Stations

FXDP-OM 8-0001

FXDP-OM 16-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <70 mA (from U

B

)

• Output Current: <1.4 A per output (from U

L

)

Power Distribution

• Outputs: U

L power supply

Mechanical

• Operating Temperature: -25 to +55°C (-13 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Output short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating a fault for each output point

Diagnostics (Physical)

• One LED indicates short-circuit for each output point

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

H19

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Part Number

FXDP-OM 8-0001

FXDP-OM 16-0001

Output Count

8

16

0-7

Connectors

0-7

Pinout

H

2H

per

Outputs Connector

1

2

Current

1.4 A

1.4 A

X

X

X

X

Input/Output Connectors

H 2H

I/O Map

1

2

Mating cordset:

RK 4.4T-*-RS 4.4T

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

I/O Data Map 1

Out

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

SC

1

2

3

SC-7 SC-6 SC-5 SC-4 SC-3 SC-2 SC-1 SC-0

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

I/O Data Map 2

Out

Diag

2

3

0

1

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

1 O-15 O-14 O-13 O-12 O-11 O-10 O-9 O-8

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

V

I

V

O

SC

SC-7 SC-6 SC-5 SC-4 SC-3 SC-2 SC-1 SC-0

SC-15 SC-14 SC-13 SC-12 SC-11 SC-10 SC-9 SC-8

-

H20

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

Standard Input/Output

Stations

FLDP-IOM 84-0001

FLDP-IOM 88-0001

FLDP-IOM 88-0002

FLDP-IOM 88-0004

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <150 mA plus sum of input currents (from U

B

)

• Sensor Current: <500 mA per group inputs (from U

B group is all inputs for IOM 84 and IOM 88-0002, two groups of four inputs for IOM 88-0001))

• Output Current: See table on facing page (from U

L

)

Power Distribution

• Inputs: U

B power supply

• Outputs: U

L power supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• One LED indicates short-circuit for all inputs

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

H21

PROFIBUS

eurofast ®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Count per

Part Number

FLDP-IOM 84-0001

FLDP-IOM 88-0001

FLDP-IOM 88-0002

FLDP-IOM 88-0004*

* High speed (0.2 ms) inputs

Input Connectors Pinout

8 0-3 2S

Inputs

2

Connector Sensor

PNP

8 0-7 C 1 PNP

8 0-3 2S

8 0-3 2S

2

2

PNP

PNP

Style

X

X

X

X

Inputs Outputs per

Diagnostics Wire-Break Outputs Connector Current

4 4-7 H 1 2 A

8 0-7 C 1 0.5 A

8 4-7 2G

8 4-7 2G

2

2

0.5 A

0.5 A

2S

Input/Output Connectors

C

Data

1

2

2

2

I/O

Map

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

2G

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VB2-RS 4.4T-1/2RK 4.4T-*/*/S651

H

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Mating cordset:

RK 4.4T-*-RS 4.4T

I/O Data Map 1

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

0 O-6 O-4 O-2 O-0

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

SC

I/O Data Map 2

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

0 O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

SC

H22

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

Standard Input/Output

Station

FLDP-IOM 88-0002-ST

Rugged, Fully Potted Stations

IP 67 Protection

Screw Terminal Connections

Automatic Baud Rate Sensing

Electrical

• Operating Current: <150 mA plus sum of input currents (from U

B

)

• Sensor Current: <500 mA sum of all inputs (from U

B

)

• Output Current: <500 mA per output (from U

L

)

Power Distribution

• Inputs: U

B power supply

• Outputs: U

L power supply

Mechanical

• Operating Temperature: 0 to +55 °C (+32 to +131 °F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• One LED indicates short-circuit for all inputs

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

H23

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Inputs Outputs

Part Number

FLDP-IOM 88-0002-ST

Count per

Input

8 0-3

Connectors Pinout Inputs Connector Sensor

ST,

2S

2 PNP

Style

X

ST per

Diagnostics Wire-Break Outputs Connector Current

8 4-7

ST,

2G

2 0.5 A

Input/Output Connectors

2S 2G

Data

1

Map

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

I/O Data Map 1

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

0 O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

SC

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H24

TURCK

Process Automation – Networks

Standard Input/Output

Stations

FLDP-IOM 1616-0001

FLDP-IOM 248-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <110 mA plus sum of input currents (from U

B

)

• Sensor Current: <500 mA per eight inputs (from U

B

)

• Output Current: <500 mA per output (from U

L

)

Power Distribution

• Inputs: U

B power supply

• Outputs: U

L power supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• One LED indicates short-circuit for each group of eight inputs

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

H25

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Inputs

Count per

Part Number

Input Connectors Pinout

FLDP-IOM 1616-0001 16

0-7 2S

Inputs

2

Connector Sensor

PNP

FLDP-IOM 248-0001

24 0-11 2S 2 PNP

Style

X

X

Outputs Data per

Diagnostics Wire-Break Outputs Connector Current Individual Detection

16 8-15 2G 2 0.5 A 1

I/O

Map

8 12-15 2G 2 0.5 A 2

Input/Output Connectors

2S 2G

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

I/O Data Map 1

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

1 I-15 I-14 I-13 I-12 I-11 I-10 I-9 I-8

0

2

O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

O-15 O-14 O-13 O-12 O-11 O-10 O-9 O-8

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

SC

I/O Data Map 2

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

1 I-15 I-14 I-13 I-12 I-11 I-10 I-9 I-8

2

0

I-23 I-22 I-21 I-20 I-19 I-18 I-17 I-16

O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 V

I

V

O

SC

H26

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

Input/Output Station for

Robot Control

FLDP-IOM 2012-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <110 mA plus sum of input currents (from U

B

)

• Sensor Current: <500 mA per group of eight or twelve inputs (from U

B

)

• Output Current: <500 mA per output (from U

L

)

Power Distribution

• Inputs: U

B power supply

• Outputs: U

L power supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• One LED indicates short-circuit for each group of inputs

• LEDs to indicate status of PROFIBUS communication and power supply

PROFIBUS

eurofast

®

Pinouts

Male Female

H27

5-Pin 5-Pin

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

minifast

®

Power Pinouts

Male Female

1 = Gnd2

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Inputs

Count per

Part Number

Input Connectors Pinout Inputs Connector Sensor

FLDP-IOM 2012-0001

20 X1,X2 B2 8, 12 PNP

Style

X

Outputs Data per

Diagnostics Wire-Break Connectors Pinout Outputs Connector Current Individual Detection I/O

12 X1,X2 B2 8,4 0.5 A 1

Map

Input/Output Connectors

B2

I/O Data Map 1

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

2

0

0

1

1

X1I7 X1I6 X1I5 X1I4 X1I3 X1I2 X1I1 X1I0

X2I7 X2I6 X2I5 X2I4 X2I3 X2I2 X2I1 X2I0

-

-

-

X1O7 X1O6 X1O5 X1O4 X1O3 X1O2 X1O1 X1O0

-

-

-

-

-

X2I11 X2I10 X2I9 X2I8

X2O3 X2O2 X2O1 X2O0

Diagnosis

Status

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 U

I

U

O

SC

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H28

TURCK

Process Automation – Networks

Standard Input/Output

Stations

FLDP-IOM124-0001

FLDP-IOM124-0002

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <150 mA plus sum of input currents (from U

B

)

• Sensor Current: <500 mA per group inputs (from U

B group is all inputs for IOM 84 and IOM 88-0002, two groups of four inputs for IOM 88-0001))

• Output Current: See table on facing page (from U

L

)

Power Distribution

• Inputs: U

B power supply

• Outputs: U

L power supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• Input short-circuit and power supply status mapped to PROFIBUS diagnostic table, one bit indicating each fault for the entire station

Diagnostics (Physical)

• One LED indicates short-circuit for all inputs

• LEDs to indicate status of PROFIBUS communication and power supply

H29

C0

C1

C4

DeviceNet

Male

multifast Pinout

Female

C5

C2

C6

C3

C7

17-Pin 17-Pin

1 = 0 V, us1

2 = 0 V, US2

3 = +24, US2

4 = +24, US1

5 = PE

6 = *

7 = Us COM

8 = *

9 = KSR2

10 =KSR1

11 =*

12 =Us CAN high

13 =Devnet high

14 =Devnet low

15 =RBST

16 =UL

17 =Us CAN low

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Inputs

Part Number

FLDP-IOM124-0001

FLDP-IOM124-0002

Count per

12

Input

12

6

Connectors Pinout Inputs Connector Sensor

2S 2 PNP

6 2S 2 PNP

Style

X

X

Outputs per

Diagnostics Wire-Break Outputs Connector Current

4 2 2G 2 2 A

4 2 2G 2 2 A

2S

Input/Output Connectors

2G

Data

1

1

I/O

Map

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

I/O Data Map 1

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 C4P2 C4P4 C2P2 C2P4 C1P2 C1P4 C0P2 C0P4

1 C6P2 C6P4 C5P2 C5P4

0 C7P2 C7P4 C3P2 C3P4

Diagnosis

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 U

B

U

L

SC

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H30

TURCK

Process Automation – Networks

Deluxe Input/Output

Stations

FXDP-IOM 88-0001

FXDP-CSG 88-0001

FXDP-XSG 16-0001

Rugged, Fully Potted Stations

IP 67 Protection

Rotary Address Switches

Automatic Baud Rate Sensing

Electrical

• Operating Current: <70 mA plus sum of input currents (from U

B

)

• Sensor Current: <120 mA per connector (input or pair of inputs) (from U

B

)

• Output Current: 1.4 A per output (from U

L

)

Power Distribution

• Inputs: U

B power supply

• Outputs: U

L power supply

Mechanical

• Operating Temperature: -25 to +55°C (-13 to +131°F)

• Protection: NEMA 1,3,4,12,13 / IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Logical)

• I/O and power supply faults mapped to PROFIBUS diagnostic table, one bit per output and one bit per input connector

Diagnostics (Physical)

• One LED indicates short-circuit for each I/O point

• LEDs to indicate status of PROFIBUS communication and power supply

minifast

®

Power Pinouts

Male Female

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = U

L

5-Pin 5-Pin

H31

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Count per

Part Number

Input Connectors Pinout

FXDP-IOM 88-0001

8 0-3 2S

Inputs

2

Connector Sensor

PNP

FXDP-CSG 88-0001

8 0-7 C

FXDP-XSG 16-0001

16 0-7 2X

1

1

PNP

PNP

Style

Inputs Outputs Data per

X

X

X

Diagnostics Wire-Break Connectors Pinout Outputs Connector Current

8 4-7 2G 2 1.4 A

8

16

0-7

0-7

C

2X

1

1

1.4 A

1.4 A

X

X

X

Diagnostics Wire-Break I/O

1

Map

2

3

2S C

Input/Output Connectors

2X 2G

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VB2-RS 4.4T-1/2RK 4.4T-*/*/S651

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

Mating cordset:

RK 4.4T-*-RS 4.4T

Splitter:

VBRS 4.4-2RK 4T-*/*

I/O Data Map 1

In

Diag

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0

1

2

-

-

-

-

-

-

-

-

UB

SC-15 SC-14 SC-13 SC-12 SC-11 SC-10

UL

SC-9

SC

SC-8

SC-7,6 SC-5,4 SC-3,2 SC-1,0

0 O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

I/O Data Map 2

In

Diag

Out

2

3

0

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 UB UL SC

1 SC-7 SC-5 SC-3 SC-1 -

SC-15

O-7

-

SC-I7 SC-I6 SC-I5 SC-I4 SC-I3 SC-I2 SC-I1 SC-I0

O-6

SC-13

O-5

-

O-4

SC-11

O-3

-

O-2

SC-9

O-1

-

O-0

I/O Data Map 3

In

Diag

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

1 I-15 I-14 I-13 I-12 I-11 I-10 I-9 I-8

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0

1

2

UB UL SC

SC-7 SC-6 SC-5 SC-4 SC-3 SC-2 SC-1 SC-1

SC-15 SC-14 SC-13 SC-12 SC-11 SC-10 SC-9 SC-8

3

Out

0

1

O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0

O-15 O-14 O-13 O-12 O-11 O-10 O-9 O-8

H32

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

PROFIBUS-DP FDP20 Stations

TURCK’s FDP20 PROFIBUS stations are low-cost screw-terminal connection stations designed for mounting in an enclosure.

These stations provide easy connection of standard I/O devices such as push buttons, pilot lights, motor starters and drives to a PROFIBUS network. FDP20 stations are designed to easily upgrade existing equipment to a PROFIBUS network.

Mechanical Specifications

TURCK FDP20 stations are designed to be mounted in standard equipment enclosures (operator stations, motor control centers, etc.). These stations use screw terminal connections for all I/O and network wiring. Detailed environmental specifications include:

• Housing material: Nylon 6

• Protection level: IP 20

• Operating temperature: 0 to +55°C (32 to +131°F)

The station’s components are identified in the figure below.

Address Switches

PROFIBUS-DP Connector

Connectors

Bus connectors

I/O and Power Connectors

PROFIBUS-DP D9 Connector

Label

I/O connectors

Each FDP20 version uses a different screw terminal connector. Detailed pinout information is given in the product information on the following pages.

H33

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Power

FDP20 stations provide an auxiliary power connection for I/O devices and station electronics. Power can be applied separately to different I/O groups as shown in the following diagram.

Power ratings for FDP20 stations:

• Operating Voltage: 18-30 VDC (24 VDC nominal)

• Internal Current Consumption: <75 mA (@ nominal 24 VDC) plus sum of I/O currents

• Input Signal Current (each input): OFF < 0.5 mA; ON 1-3.4 mA

• Input Delay: 2.5 ms

• Output Current: 1.8 A max per output (XSG version only)

Addressing

PROFIBUS

® stations must have a network address for communication. The address for FDP20 stations may be set via the visible rotary switches on the front of the station.

The pair of switches represents the address as a decimal number; the left switch being the 10’s multiplier and the right switch the 1’s multiplier. To program the stations, rotate the switches with a small slotted screwdriver until the arrows are pointing at the appropriate numbers for the chosen address.

Diagnostics

FDP20 stations provide LEDs for diagnosing communication problems.

Bus

• Green: Normal operation

• Red: No communication

Voltage Supply

• Green: Power present

• Red: No power

Input/Output Status

• Off: Point is off

• Green: Point is on

Common short-circuit Indication (Two LEDs for entire station)

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

H34

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

Enclosure Mounted

Input/Output Station

FDP20-16XSG

FDP20-16S

In-Cabinet I/O

IP 20 Protection

Ideal for Retrofits

Automatic Baud Rate Detection

Electrical

• Operating Current: <75 mA plus sensor currents (from Auxiliary power)

• Input Current: <700 mA sum of all inputs (from Auxiliary power)

• Output Current: <1.8 A per output (from Auxiliary power)

Power Distribution

• Inputs: Auxiliary power

• Outputs: Auxiliary power supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: IEC IP 20

Material

• Housing: Nylon

Diagnostics (Physical)

• LEDs to indicate status of PROFIBUS-DP communication

PROFIBUS-DP D9 Connector

3 = BUS_B

5 = DGnd

6 = +5VDC

8 = BUS_A

H35

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Part Number

FDP20-16XSG

FDP20-16S

Count

16

Input

16

Pinout

FLX-DP

FL-DP

PNP

Sensor

PNP

Style

Inputs Outputs

Diagnostics Wire-Break Output Count

16

Pinout

FLX-DP

0

Current

0.5 A

Input/Output Connectors

FL-DP FLX-DP

Data

1

Data

2

Map

Indicates I/O groups which can be powered from separate Aux. power supplies if desired

I/O Data Map 1

In

Out

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0

1

0

I-15

O-7

I-14

O-6

I-13

O-5

I-12

O-4

I-11

O-3

I-10

O-2

I-9

O-1

I-8

O-0

1 O-15 O-14 O-13 O-12 O-11 O-10 O-9 O-8

I/O Data Map 2

In

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0

1

I-7

I-15

I-6

I-14

I-5

I-13

I-4

I-12

I-3

I-11

I-2

I-10

I-1

I-9

I-0

I-8

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H36

TURCK

Process Automation – Networks

PROFIBUS -DP Repeater

The REP-DP repeater serves to assemble two galvanically isolated PROFIBUS-DP segments in RS-485 technology with 32 participants each, and provides IP 67 protection. Up to four repeaters can be connected in series, so that up to 127 nodes can be operated via a single master; thus PROFIBUS networks can be extended significantly by using repeaters (depending on the baud rate).

The transmission rate is detected automatically (up to 12 Mbaud), and the signals are regenerated in amplitude. If there are faulty protocols in one of the segments (a wire-break, short-circuit in the bus line or by a defective node), that segment is decoupled and an error indication is provided by the LED.

Connection:

Individual PROFIBUS segments are connected via M12 connectors (see technical guidelines for PROFIBUS connection technology). The repeater is equipped with three female and one male connector; unused connections must be terminated with a terminating resistor (type: RSSW 45-TR). The shield of the PROFIBUS cable can be grounded directly via a grounding screw (internally the shield is coupled capacitively with the ground). Power (24 VDC) is supplied via standard

7/8 inch connectors.

Terminating Resistors

From Previous Segment

To Next Ssegment

H37

To Power Supplies

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Profibus-DP Repeater

REP-DP-0002

Extend Network Length

Extend Drop Lengths

Allows More Than 32 Stations on Network

Isolate Communication Segments

Electrical

• Operating Current: <60 mA

Power Distribution

• Station: Auxiliary power supply (U

B

)

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: NEMA 1,3,4,12,13 and IEC IP 67

• Vibration: 50 g @ 10-500 Hz

Material

• Connectors: Nickel-plated brass

• Housing: Nylon 6

Diagnostics (Physical)

• LEDs indicate communication status for each segment and power supply

PROFIBUS

eurofast

®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

1 = Gnd

2 = Gnd

3 = PE

4 = U

B

5 = NC

minifast

®

Power

Pinouts

Male

5-Pin

H38

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

PROFIBUS-DP to AS-interface Gateways

AS-I systems can be easily connected to a higher-level network, like PROFIBUS, through a gateway master. The gateway acts as a master to the AS-I system(s) and a slave to the PROFIBUS system, mapping all of the AS-I data for PROFIBUS in a single block.

For AS-I specifications and rating details see section G of this catalog.

PROFIBUS-DP System

(Gateway is the Slave)

AS-I System

(Gateway is the Master)

H39

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Addressing

PROFIBUS

® stations must have a network address for communication. The address for AS-I/ PROFIBUS gateways may be set via the on-unit display and push buttons. Please consult the manual for a particular gateway for instruction on the procedure.

Diagnostics

AS-I/ PROFIBUS gateways contain LEDs for diagnosing I/O and communication problems for AS-I and PROFIBUS. For a detailed description of the LED states please see the Bihl+Wiedemann AS-I/ PROFIBUS Gateway User Manual available for download from www.bihl-wiedemann.com.

Power

Most AS-I/ PROFIBUS gateways draw power from the AS-I power supply. The option to use a separate, non-AS-I power supply is also available. Consult the gateway documentation to ensure that the gateway being selected meets the requirements of your system.

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H40

TURCK

Process Automation – Networks

AS-I Profibus-DP Gateways in

Stainless Steel

ASI-DPG-SS BW1567*

ASI-DPG-SS BW1568*

ASI-DPG-SS BW1569*

ASI-DPG-SS-SE BW1773*

ASI-DPG-SS-SE BW1774*

ASI-DPG-SS-C1D2 BW1653

ASI-DPG-SS-C1D2 BW1654

ASI-DPG-SS-C1D2 BW1655

* Not ETL Listed

AS-I v3.0 Supported

Graphical Display

Integrated Ground-Fault Detection

Integrated AS-I Diagnostics

Electrical

• Operating Current: 200 mA from V

AS-I

200 mA from V

AS-i1

250 mA from V

AUX

(Power Supply A)

, 70mA from V

AS-i2

(Power Supply E)

(Power Supply A2)

Power Distribution

• From AS-I supply for each network (Power Supply A, A2)

• From external supply (Power Supply E)

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: IP 20

Material

• Housing: Stainless Steel

Diagnostics (Logical)

• Health of AS-I network is available via Proximus-DP interface

Diagnostics (Physical)

• LED to indicate status of network and AS-I communication and power supply

PROFIBUS-DP Connector

1 = Shield

3 = BUS_B

5 = DGnd

6 = +5 VDC

8 = BUS_A

H41

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Part Number

ASI-DPG-SS BW1567

ASI-DPG-SS BW1568

ASI-DPG-SS BW1569

ASI-DPG-SS-SE BW1773

ASI-DPG-SS-SE BW1774

ASI-DPG-SS-C1D2 BW1653

ASI-DPG-SS-C1D2 BW1654

ASI-DPG-SS-C1D2 BW1655

Level

Higher

Network

PROFIBUS-DP

PROFIBUS-DP

PROFIBUS-DP

PROFIBUS-DP

PROFIBUS-DP

PROFIBUS-DP

PROFIBUS-DP

PROFIBUS-DP

A

A2

E

A

Power

A2

E

A

A2

Style

3.0

3.0

3.0

2.1

2.1

2.1

2.1

AS-I

2.1

Version

1

2

2

2

1

2

# of

A

S-

I

Masters

1

2

DuplicateAddressDetection

X

X

X

X

X

X

A

A2 E

A - Single AS-I network is powered by and AS-I power supply

A2 - Dual AS-I networks are each powered by their own AS-I power supply

E - Dual AS-I networks are both powered by a single 30 VDC supply, decoupled through the gateway

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H42

TURCK

Process Automation – Networks

AS-I PROFIBUS-D Economy

Gateways

AS-I v3.0 Supported

LED Display

PROFIBUS-DP Support

Integrated AS-I Diagnostics

Electrical

• Operating Current: <300 mA from AS-I

Power Distribution

• From AS-I supply

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: IP 20

Material

• Housing: Stainless Steel

Diagnostics (Logical)

• AS-I diagnostic data is available via Network interface

Diagnostics (Physical)

• LEDs to indicate status of network and AS-I communication and power supply

ASI-DPG-SS-B BW1746

PROFIBUS-DP Connector

1 = Shield

3 = BUS_B

5 = DGnd

6 = +5 VDC

8 = BUS_A

H43

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Part Number

ASI-DPB-SS BW1746

Level

Higher

Network

PROFIBUS-DP A

Power

Style

2.1

AS-I

Version

A

# of

A

S-

I

Masters

1

A

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H44

TURCK

Process Automation – Networks

AS-I PROFIBUS

®

-DP Gateways

ASI-DPG BW1253

ASI-DPG BW1371

AS-I v2.1 Supported

2-Digit Display

IP 65 Protection

Integrated AS-I Diagnostics

Electrical

• Operating Current: 200 mA from V

AS-I

Power Distribution

• From AS-I supply for each network

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: IP 65

Material

• Housing: Plastic

Diagnostics (Logical)

• Health of AS-I network is available via Network interface

Diagnostics (Physical)

• LEDs to indicate status of network and AS-I communication and power supply

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

PROFIBUS

eurofast

Pinouts

®

Female

5-Pin

BW1371 only

H45

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Level

Part Number

ASI-DPG BW1253

ASI-DPG BW1371

Higher

Network

PROFIBUS-DP

PROFIBUS-DP

A

A

Power

A - Single AS-I network is powered by and AS-I power supply

Style

2.1

AS-I

2.1

Version

1

1

# of

A

S-

I

Masters

1

1

DuplicateAddressDetection

1

9

10

7

8

5

6

1

2

3

4

BUS_A

BUS_B

BUS_A

BUS_B

0V

Shield

FG (Function Gnd)

FG (Function Gnd)

Shield

+5V

Note: AS-I connections are made via standard AS-I base modules ASI-BM BW1180 or ASI-BM BW1182 (see p. E103-104)

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H46

TURCK

Process Automation – Networks

PROFIBUS

®

-DP BL67 Stations

TURCK's BL67 is a modular, user configurable network I/O system designed to allow installation of nodes containing different types and sizes of I/O depending on the users needs for a particular area. Featuring IP 67 protection and metal threaded connectors, the BL67 can often be mounted in the physical process environment or directly on a machine without a separate enclosure for the I/O. This saves planning and installation time, as well as the cost of the enclosure itself.

The BL67 system supports several different network protocols, including PROFIBUS-DP. A BL67 station consists of a gateway module that interfaces to the PROFIBUS system, and several I/O modules that interface with the physical I/O in the field. Different connector options are available to allow a greater level of customization to the user.

For more details on the BL67 system, please see section G of this catalog.

TURCK's I/O Assistant software package is used to configure the BL67 system.

H47

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

BL67 Gateway

BL67-GW-DP

Modular I/O

Fieldbus Independent Configuration

IP 67 Protection

Various I/O Styles

Electrical

• Operating Current: <50 mA from V

I

• Supply Current: <10 A to I/O (from V

I

• Backplane Current: <1.5 A (from V

I

) and V

O

)

Mechanical

• Operating Temperature: -25 to +55°C (+32 to +131°F)

• Protection: IP 67

• Vibration: 5 g @ 10-500 Hz

Material

• Housing: PC-V0 (Lexan)

Diagnostics (Logical)

• Diagnostic information available through the PROFIBUS-DP interface

Diagnostics (Physical)

• LEDs to indicate status of PROFIBUS-DP and Module Bus communication

PROFIBUS

eurofast ®

Pinouts

Male Female

1 = 5 VDC*

2 = BUS _A

3 = Gnd

4 = BUS_B

5 = Shield

* Female connector only

5-Pin 5-Pin

minifast

®

Power

Pinouts

Male

1 = Gnd

2 = Gnd

3 = PE

4 = V

I

5 = V

O

Note: Power feeding modules may be used for I/O current supply to prevent overloading the gateway power supply.

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

5-Pin

H48

TURCK

Process Automation – Networks

PROFIBUS

®

-DP BL20 Stations

TURCK's BL20 is a modular, user configurable network I/O system designed to allow installation of nodes containing different types and sizes of I/O depending on the users needs for a particular area. Featuring IP 20 protection and terminal point connections, the BL20 is intended to be mounted in the control cabinet or in a field enclosure.

The BL20 system supports several different network protocols, including PROFIBUS-DP. A BL20 station consists of a gateway module that interfaces to the PROFIBUS system, and several I/O modules that interface with the physical I/O in the field. The terminal bases are available with tension clamp or screw terminal connector types.

For more details on the BL20 system, please see section H of this catalog.

TURCK's I/O Assistant software package is used to configure the BL20 system.

H49

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

BL20 Gateway

BL20-GWBR-PBDP

Modular I/O

Fieldbus Independent Configuration

IP 20 Protection

Various I/O Styles

Electrical

• Operating Current: <430 mA from BR power supply (U

SYS

)

• Supply Current: <10 A to I/O (from U

L

)

<1.5 A to backplane (from U

SYS

)

Mechanical

• Operating Temperature: 0 to +55°C (+32 to +131°F)

• Protection: IP 20

• Vibration: 1 g @ 5...100 Hz

Material

• Housing: PC-V0 (Lexan)

Diagnostics (Logical)

• Diagnostic information available through the PROFIBUS-DP interface

Diagnostics (Physical)

• LEDs to indicate status of PROFIBUS-DP and Module Bus communication

Power Connectors

PROFIBUS-DP Connector

1 = Shield

3 = BUS_B

5 = Gnd

6 = +VDC

8 = BUS_A

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H50

TURCK

Process Automation – Networks

Notes:

H51

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-DP, Cable Specifications

Cable that Meets the Requirements of

EN50170-2-2:1996 for Communications

Up to 12 Mbaud

Figure A

Jacket

Baud Rate (k baud)

Maximum Trunk Length

Drain Wire

Red

Green

Foil Shield

Braided Shield

9.6

1200 meters

19.2

1200 meters

93.75

1200 meters

Figure B

Figure C

187.5

1000 meters

Jacket

Jacket

500

400 meters

Braided Shield

Drain Wire

White

Blue

Green

Red

Mylar Tape

Aluminum Mylar Foil Shielded

Inner Jacket

Drain Wire

Red

Green

Foil Shield

Aluminum Armor

1500

200 meters

1200

100 meters

Type Approvals

Data Pair 2nd Data Pair

AWG

Color Code

DCR (/1000 feet)

Insulation

AWG

Color Code

DCR (/1000 feet)

Insulation

Outer Jacket

Material Color

Nominal O.D.

Shields

Type

Drain Wire

Bulk Cable

Part Number /

Weight/300 M

Figure

455

AWM 2464

75°C 300 Volts

456

AWM 20233

80°C 300 Volts

457

75°C 300 Volts

458

AWM 20233

80°C 300 Volts

4511

AWM 2464

75°C 300 Volts

4510A

75°C 300 Volts

4515

80°C 300 Volts

NEC PLTC

CEC AWM-I/II A/B FT4

2/22 AWG

RD/GN

NEC AWM

CEC AWM-I/II A/B FT4

2/22 AWG

RD/GN

NEC CMX

NEC AWM

CEC AWM-I/II A/B FT4

2/22 AWG

RD/GN

NEC PLTC

CEC AWM-I/II A/B FT4

2/22 AWG

RD/GN

NEC PLTC

CEC CM-CMG

HL ABCD

2/22 AWG

RD/GN

2/22 AWG

RD/GN

2/22 AWG

RD/GN

16.5 Ohms

PE

16.5 Ohms

PE

16.5 Ohms

PE

16.5 Ohms

PE

16.5 Ohms

PE

16.5 Ohms

PE

16.5 Ohms

PE

None

None

None

None

None

None

None

N/A

N/A

N/A

N/A

N/A

N/A

N/A

PVC Purple

8.5 mm (.335 in)

PUR Purple

7.9 mm (.310 in)

Foil/Braid

22 AWG

Foil/Braid

22 AWG

RB50672-*M

62 lbs.

RB50683-*M

48 lbs.

PUR Purple

8.0 mm (0.315 in)

TPU Plum

8.5 mm (0.335 in)

PVC Purple

8.5 mm (.319 in)

Aluminum

Armor/PVC

15.4 mm (.605 in)

PUR Purple

7.5 mm (0.295 in)

Foil/Braid

No Drain

Foil/Braid

22 AWG

Foil/Braid

22 AWG

Foil/Braid

22 AWG

Foil/Braid

22 AWG

RB50708-*M

51 lbs.

RB50692-*M

58 lbs.

flexlife-10

®

RB50881-*M

64 lbs.

flexlife-10

RB50875-*M

112 lbs.

armorfast

®

RB51225-*M

42 lbs.

Halogen-Free

††

4516

105° 300 Volt

NEC PLTC/ISO

Open Wiring

CEC CMG

2/22 AWG

RD/GN

16.5 Ohms

PE

None N/A

PVC Purple

11.1 mm (.435 in)

590

AWM 2464

75°C 300 Volts

NEC PLTC

CEC AWM-I/II A/B FT4

2/22 AWG

RD/GN

16.5 Ohms

PE

2/22 AWG

BU/WH

16.5 Ohms

PE

* Indicates length in meters.

Standard cable lengths are 30, 75, 150, 225 and 300 meters. Consult factory for other lengths.

††

Zero Halogen: to DIN VDE 0472 part 815 + IEC 60754-1

PVC Purple

9.6 mm (.380 in)

Foil/Braid

22 AWG

Foil/Braid

22 AWG

RB51259-*M

93 lbs.

RB51057-*M

75 lbs.

A

A

A

A

A

C

A

A

B

H52

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

PROFIBUS

®

-DP, (M12x1)

eurofast

®

Cable and Cordset Selection Matrix

1

RSSW

Pin (Male)

3

WSSW

eurofast

2

RKSW

Socket (Female)

4

WKSW

RSSW 45x-*M WSSW 45x-*M RKSW 45x-*M WKSW 45x-*M

Bare

1

RSSW RSSW 45x-*M RSSW WSSW 45x-*M RSSW RKSW 45x-*M RSSW WKSW 45x-*M

RSSW

3

WSSW WSSW 45x-*M WSSW RKSW 45x-*M WSSW WKSW 45x-*M

WSSW

2

RKSW RKSW 45x-*M RKSW WKSW 45x-*M

RKSW

4

WKSW WKSW 45x-*M

WKSW

See page H54 for dimensional drawings.

* Indicates length in meters.

x Indicates cable type.

Refer to the Cordset Builder at www.turck.com for assistance with cordset/cable combinations.

Standard cable lengths are 0.3, 0.5, 1.0, 2.0, 2.5, 3.0, 3.5, 4.0, 5.0, 6.0, 8.0, 10, 15....50 Meters. Consult factory for other lengths.

For stainless steel coupling nuts change part number RSSW...RSSWV.

Change 45 to 59 for 59x series cordsets.

H53

eurofast

Male

Pinouts

45 series pinout

1. N/C

2. Green (TxD)

3. N/C

4. Red (RxD)

5. Bare (Shield Drain Wire)

59 series pinout

1. Blue (TxD_1)

2. Green (TxD)

3. White (RxD_1)

4. Red (RxD)

5. Bare (Shield Drain Wire)

eurofast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-DP, (M12x1)

eurofast

®

Cable and Cordsets

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

PUR (Polyurethane)

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane) or POM (Nylon)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 68

250 V

Rated Current:

4 A

Ambient Temperature:

-40° to +75°C (-22° to +167°F)

1 2

RSSW ..

3

Pages H53 - H56 RKSW ..

4

Pages H53 - H56

WSSW ..

Pages H53 - H56 WKSW ..

Pages H53 - H56

RSAW ..

(

armorfast only)

RKAW ..

(

armorfast only)

H54

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

PROFIBUS

®

-DP, (M12x1)

eurofast

®

Cable and Cordset Selection Matrix

Bare

1

RSSW

Pin (Male)

3

WSSW

2

eurofast

Socket (Female)

4

RKSW WKSW

10

Pin (Male)

FSSDWE

Socket (Female)

11

FKSDWE

7

D9S/T 45x-*M

RSSW D9S/T

45x-*M

WSSW D9S/T

45x-*M

RKSW D9S/T

45x-*M

WKSW D9S/T

45x-*M

FSSDWE D9S/T

45x-*M

FKSDWE D9S/T

45x-*M

D9S/T

8

D9SM/T 45x-*M

RSSW D9SM/T

45x-*M

WSSW D9SM/T

45x-*M

RKSW D9SM/T

45x-*M

WKSW D9SM/T

45x-*M

FSSDWE D9SM/T

45x-*M

D9SM/T

See page H54 & H58 for dimensional drawings.

* Indicates length in meters.

x Indicates cable type.

Refer to the Cordset Builder at www.turck.com for assistance with cordset/cable combinations.

Standard cable lengths are 0.3, 0.5, 1.0, 2.0, 2.5, 3.0, 3.5, 4.0, 5.0, 6.0, 8.0, 10, 15....50 meters. Consult factory for other lengths.

For stainless steel coupling nuts change part number RSSW...RSSW.

FKSDWE D9SM/T

45x-*M

Extension example:

H55

eurofast

Male

Pinouts

45 series pinout

1. N/C

2. Green (TxD)

3. N/C

4. Red (RxD)

5. Bare (Shield Drain Wire)

eurofast

Female

D9

Male

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-DP, (M12x1)

eurofast

®

Cable and Cordset Selection Matrix

7

D9S

9

SD9S

Bare

1

RSSW

Pin (Male)

3

WSSW

2

eurofast

Socket (Female)

4

RKSW WKSW

10

Pin (Male)

FSSDWE

Socket (Female)

11

FKSDWE

WSSW D9S WSSW

45x-*M-*M

RKSW D9S RKSW

45x-*M-*M

WKSW D9S WKSW

45x-*M-*M

FSSDWE D9S FSSDWE

45x-*M-*M

FKSDWE D9S FKSDWE

45x-*M-*M

WSSW SD9S WSSW

45x-*M-*M

RKSW SD9S RKSW

45x-*M-*M

WKSW SD9S WKSW

45x-*M-*M

FSSDWE SD9S FSSDWE

45x-*M-*M

FKSDWE SD9S FKSDWE

45x-*M-*M

Bare

1

2

RSSW/RKSW

eurofast

Pin (Male)

3

4

WSSW/WKSW

Socket (Female)

10

11

RSSW/RKSW

7

D9S 45x-*M

RSSW D9S RKSW

45x-*M-*M

WSSW D9S WKSW

45x-*M-*M

FSSDWE D9S FKSDWE

45x-*M-*M

D9S

9

SD9S 45x-*M

RSSW SD9S RKSW

45x-*M-*M

WSSW SD9S WKSW

45x-*M-*M

FSSDWE SD9S FKSDWE

45x-*M-*M

SD9S

See page H54 & H58 Tfor dimensional drawings.

* Indicates length in meters.

x Indicates cable type.

Refer to the Cordset Builder at www.turck.com for assistance with cordset/cable combinations.

Standard cable lengths are 0.3, 0.5, 1.0, 2.0, 2.5, 3.0, 3.5, 4.0, 5.0, 6.0, 8.0, 10, 15....50 meters. Consult factory for other lengths.

For stainless steel coupling nuts change part number RSSW...RSSW.

eurofast

Male

Pinouts

45 series pinout

1. N/C

2. Green (TxD)

3. N/C

4. Red (RxD)

5. Bare (Shield Drain Wire)

eurofast

Female

D9

Male

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H56

TURCK

Process Automation – Networks

PROFIBUS

®

-DP (M12x1),

eurofast

®

Retractile Cordsets

Single or Double Ended

Available in 1, 2, 5 Meter Extended Lengths

Part Number

RSSW 456SP-1M

Specs Application

(M12x1) eurofast male connector

1 M extended length

.25 M retracted length

RSSW 456SP-2M

PUR (Polyurethane)

250 V, 4 A

-40° to +80°C

(M12x1) eurofast male connector

2 M extended length

.5 M retracted length

1. NC

2. GN

3. NC

4. RD

5. Drain

Pinouts

RSSW 456SP-5M

(M12x1) eurofast male connector

5 M extended length

1.12 M retracted length

Single ended cordset part numbers shown. Also available in double ended (M12x1) eurofast connectors.

H57

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-DP, Field Wireable D9 Connectors

Specifications - (D9)

Housing:

Terminating Switch:

Protection:

Rated Voltage:

Rated Current:

Temperature Rating:

TPU (Polyurethane)

Yes

IEC IP 20

250 V

5 A

40° to +60°C

*Max. Cable diameter: 8.5 mm

7

Specifications (FKSDWE .. FSFDWE)

Housing:

Coupling Nut:

Rated Voltage:

PUR (Polyurethane)

Nickel Plated CuZn or Stainless Steel

Contact Carrier:

TPU (Polyurethane) or POM (Nylon)

Contacts:

Gold Plated CuZn

Protection:

NEMA 1, 3, 4, 6P and IEC IP 67

250 V

Rated Current:

4 A

Temperature

Rating:

-40° to +75°C

8

Connector, PDP, D9S

9

Pages H55 - H56

Connector, PDP, D9SM Pages H55 - H56

Note: Part numbers are for ordering connector only.

Cable must be ordered separately.

Connector, PDP, SD9S

10

Pages H55 - H56

11

FSSDWE ..

Pages H55 - H56 FKSDWE ..

Pages H55 - H56

H58

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

PROFIBUS

®

-DP, Field Wireable D9 Connectors

Provides Connection to Master or Node in the field

Maximum Cable O.D. is 8.5 mm

Housing Part Number Specs Application Pinouts

Connector,PDP,D9S

Right Angle,

Terminating Switch

Connector,PDP,SD9S

250 V, 5 A

-25° to +80°C

Straight, Terminating

Switch

1. N/C

2. N/C

3. RD (Bus_B)

4. N/C

5. N/C

6. N/C

7. N/C

8. Green (Bus_A)

9. N/C

Male

Connector,PDP,D9SM

250 V, 4 A

-25° to +80°C

Right Angle, Master,

Terminating Switch

H59

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-DP, Terminating Resistors

Terminating Resistors Stabilize and

Minimize Reflections on the Bus Line

A Terminating Resistor is Required at the

Beginning and End of the Main Bus Line

Housing Part Number

RSSW 45-TR

Specs Application

eurofast ®

Resistor

Terminating

Internal resistor

Male eurofast connector

Reverse keyed

1. N/C

2. GN

3. N/C

4. RD

5. BARE

Pinouts

See Below

RKSW 45-TR

Nickel Plated

Brass or

Stainless Steel

250 V, 4 A

-40° to +75°C

eurofast Terminating

Resistor

Internal resistor

Female eurofast connector

Reverse keyed

PDP-TRA

1. N/C

2. GN

3. N/C

4. RD

5. BARE

Active Terminating

Resistor

External power supply minifast and eurofast connector

®

LED signal for power status

1. N/C

2. BUS_A

3. N/C

4. BUS_B

5. N/C

1. N/C

2. GND

3. N/C

4. U

I

=24 VDC

5. N/C

See Below

See Below

Male

Pinout Diagram, RSSW 45-TR Pinout Diagram, RKSW 45-TR

Ω

Ω

Ω

Pinout Diagram, PDP-TRA

Ω

Ω

eurofast Male Connector eurofast Female Connector eurofast Male Connector

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H60

TURCK

Process Automation – Networks

PROFIBUS

®

-DP,

eurofast ®

Feed Through Receptacle

Provides Bulkhead Panel Mount

Connection

Housing Part Number Specs Application Pinouts

Male

FKW FSW 45/M12

Nickel Plated Brass or

Stainless Steel

250 V, 4 A

-40° to +75°C

eurofast Feed Through

Connection

Straight male/female connector

For pre-molded reverse keyed eurofast cables

Female

H61

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-DP,

eurofast

®

Bus Tees

Creates a Branch from the Main Bus Line

Housing Part Number

RKSW 2RSSW 45

Specs Application

eurofast Bus Tee

Male eurofast drop connector

Fully shielded

eurofast tee

Wiring Diagrams

* RKSW 2RSSW 45-0001

PUR

(Polyurethane)

Nickel Plated

Brass

250 V, 4 A

-40° to +75°C

eurofast Terminating

Resistor

Male eurofast connector

Fully shielded

eurofast tee

VB2/FSW/FKW/FSW 45

Y Junction

Fully shielded

eurofast

connectors

* This part must be used when joining two tees together directly. A female terminating resistor will not work with this tee since there is no ground and power connection on the male side.

Male

Pinouts

eurofast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H62

TURCK

Process Automation – Networks

PROFIBUS

®

-DP,

eurofast

®

Field Wireable Connectors

Allows Transition from Hard Wiring to

Quick Connection to Network

Housing Part Number

BMSWS 8151-8.5

Specs

Nickel Plated Brass

PG 9 cable gland, accepts 4-9 mm cable diameter

Screw terminal accepts up to 18 AWG conductors

85°C

125 V, 4 A

Application

BMSWS 8251-8.5

Nickel Plated Brass

PG 9 cable gland, accepts 4-9 mm cable diameter

Screw terminal accepts up to 18 AWG conductors

85°C

125 V, 4 A

BMWS 8151-8.5

Nickel Plated Brass

PG 9 cable gland, accepts 4-9 mm cable diameter

Screw terminal accepts up to 18 AWG conductors

85°C

125 V, 4 A

Metal, fully shielded

Mates with reverse key 5-pin cordsets and receptacles

BMWS 8251-8.5

Nickel Plated Brass

PG 9 cable gland, accepts 4-9 mm cable diameter

Screw terminal accepts up to 18 AWG conductors

85°C

125 V, 4 A

Pinouts

Male

Female

H63

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-DP, Circuit Board Connectors and OEM Receptacles

Provides (M12x1)

eurofast

® to Field Devices

Connection

Housing

13

Part Number

FSFDW 45 PCB

Specs Application

Male eurofast PCB pins

Pinouts

12

Male

FSFDLW 45

Male eurofast solder cups

14

WFSW 45 PCB

Nickel Plated CuZn or Stainless Steel

250 V, 4 A

-40° to +75°C

Male eurofast right angle PCB pins

1. N/C

2. GN

3. N/C

4. RD

5. BARE

16

FKFDW 45 PCB

Female eurofast PCB pins

Female

15

FKFDLW 45

Male eurofast solder cups

See pages H65 for dimensional drawings.

Standard housing material is nickel plated brass "FKFD .."; "FKFDV .." indicates 316 stainless steel.

Panel Cutout

FKFD ... FSFD

Board Layout

(reference only)

FKFD ... FSFD

Panel Cutout

WFS

Board Layout

(reference only)

WFS

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H64

TURCK

Process Automation – Networks

eurofast

®

PCB Mount Male and Female Receptacles

12 15

FSFDLW ..

13

Page H64 FKFDLW ..

16

Page H64

FSFDW ..PCB

14

Page H64 FKFDW ..PCB

Page H64

WFSW ..PCB

Page H64

H65

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Gasket and Mounting Screws Provided

For Use with a Single Gang Electrical Box

Part Number Specs

PROFIBUS

®

-DP,

eurofast

®

Wall Plate Adapters

Application Pinouts

BPA-45-E113

Stainless Steel

250 V, 4.0 A

-40 to +70°C

(-40 to +158°F)

Attaches to standard single gang electrical box for transition to

5-wire (M12x1) eurofast connector

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H66

TURCK

Process Automation – Networks

PROFIBUS

®

-PA Media Overview

PROFIBUS-PA (Process Automation) uses synchronous transfer mode technology, as defined in IEC 61158-2, to communicate between field devices and the RS 485 backbone of PROFIBUS

®

-DP. A segment coupler, or gateway is installed to bridge PROFIBUS-DP with PROFIBUS-PA. Otherwise, the protocols are identical, allowing transparent communication between general purpose automation systems and decentralized field devices.

PROFIBUS-PA is a master-slave bus. Transmitters used in the process industry are typically slave devices or passive stations which only communicate at the request of the master.

General Layout Topologies

The topology for PROFIBUS-DP is a linear bus. Branching can be accomplished with repeaters or, in the case of

PROFIBUS-PA, this can be accomplished with the segment couplers. The PROFIBUS-PA topology follows the physical layer as defined in ISA SP50.02. Daisy chain or star topologies are allowed.

Process Control System

PROFIBUS-DP RS-485 Transmissions

FLDP-IOM 88-0001

Segment coupler/link

Transmitters

PROFIBUS-PA IEC

61158-2 transmissions

RKV 40-1M

RSV RKV 48-1M

JBBS-48SC-M633

Trunk Line

RSV RKV 48-1M

RSV RKV 48-1M

RSV 48TR

RSFK BC

Transmitters

H67

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA, Cable Specifications

Cable that Meets the Requirements of ISA/SP50 and PROFIBUS-PA Requirements for Type A Cable

All Cables are Rated -40° to +105°C and are

Sunlight Resistant

Available in 3-wire Versions with a Device Ground or 2-wire Versions

Type A Cable Specifications

Figure A

Designed for harsh environments

Temperature range: -40° to +105°C

Governed by: ISA SP50.02 specification

Sunlight resistant per test

PLTC and ITC rated (CSA FT4)

Impedence [Z

0 at f r

(31.25 kHz)] = 100 Ohms + 20 %

Maximum attenuation at 1.25 f r

(39 kHz) = 3.0 dB/km

Maximum capacitive unbalance to shield = 2 nF/km

Maximum DC resistance (per conductor) = 24 Ohms /km

Figure B

Maximum propagation delay variance 0.25 f r to 1.25 f r

= 1.7

μs/km

Conductor cross-sectional area (wire size) = nominal 0.8 mm

2

(#18 AWG)

Minimum shield coverage shall be 90%.

Jacket

Jacket

Braid Shield

Foil Shield

Drain Wire

Brown

Blue

Data

Inner Jacket

Aluminum Armor

Foil Shield

Drain Wire

Blue

Brown

Green/Yellow

Data

Type Approvals

Data Pair

AWG

Color Code

DCR (/1000 feet)

Insulation

483

105°C 300 Volts

483B

105°C 300 Volts

NEC ITC PLTC

Open Wiring

CEC [CMG]

NEC ITC PLTC

Open Wiring

CEC [CMG]

NEC ITC PLTC/CM

CEC [CMG HLBCD]

2/18 AWG

BU/BN

2/18 AWG

BU/BN

6.5 Ohms

XLPE

6.5 Ohms

XLPE

482A

105°C 300 Volts

482BA

105°C 300 Volts

483BK

105°C 300 Volts

NEC ITC PLTC

CEC [CMG]

NEC ITC PLTC

Open Wiring

CEC [CMG]

2/18 AWG

BU/BN

2/18 AWG

BU/BN

2/18 AWG

BU/BN

6.5 Ohms

PVC

6.5 Ohms

PE

6.5 Ohms

PE

* Indicates length in meters.

Standard cable lengths are 30, 75, 150, 225 and 300 meters.

Device Ground

AWG

Color Code

None

None

18 AWG

GN/YE

18 AWG

GN/YE

None

Outer Jacket

Material Color

Nominal O.D.

PVC Orange

7.9 mm (.310 in)

PVC Blue

7.9 mm (.310 in)

Armor/PVC Orange

13.5 mm (0.53 in)

Armor/PVC Blue

13.5 mm (0.53 in)

PVC Black

7.9 mm (.310 in)

Shields

Type

Drain Wire

Foil/Braid

20 AWG

Bulk Cable

Part Number /

Weight/300 M

Figure

RB50785-*M

59 lbs.

A

Foil/Braid

20 AWG

Foil

20 AWG

Foil

20 AWG

Foil/Braid

20 AWG

RB50786-*M

59 lbs.

RB50929-*M

96 lbs.

RB50952-*M

96 lbs.

RB50860-*M

59 lbs.

A

B

B

A

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H68

TURCK

Process Automation – Networks

PROFIBUS

®

-PA, Cable and Cordset Selection Matrix

1

RSV

Pin (Male)

2

WSV

minifast

®

3

RKV

Socket (Female)

4

WKV

5

eurofast

®

Pin (Male)

RSCV

RSV 48x-*M WSV 48x-*M RKV 48x-*M WKV 48x-*M RSCV 48x-*M

Bare

1

RSV RSV 48x-*M RSV WSV 48x-*M RSV RKV 48x-*M RSV WKV 48x-*M RSV RSCV 48x-*M

RSV

2

WSV WSV 48x-*M WSV RKV 48x-*M WSV WKV 48x-*M WSV RSCV 48x-*M

WSV

3

RKV RKV 48x-*M RKV WKV 48x-*M RKV RSCV 48x-*M

RKV

4

WKV WKV 48x-*M WKV RSCV 48x-*M

WKV

5

RSCV RSCV 48x-*M

RSCV

6

WSCV

7

RKCV

8

WKCV

See pages H71 - H72 for dimensional drawings.

* Indicates length in meters.

x Indicates cable type.

Refer to the Cordset Builder at www.turck.com for assistance with cordset/cable combinations.

Standard cable lengths are 0.3, 0.5, 1.0, 2.0, 2.5, 3.0, 3.5, 4.0, 5.0, 6.0, 8.0, 10, 15....50 Meters. Consult factory for other lengths.

minifast

Pinouts

eurofast

Male Female Male Female

1. Brown (+ Voltage)

2. N/C

3. Blue (- Voltage)

4. Bare (Shield Drain Wire)

H69

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA, Cable and Cordset Selection Matrix

6

Pin (Male)

WSCV

WSCV 48x-*M

7

eurofast

®

Socket (Female)

8

RKCV WKCV

RKCV 48x-*M WKCV 48x-*M

9

minifast

®

Bulkhead

Pin (Male) Socket (Female)

10 11

eurofast Bulkhead

Pin (Male) Socket (Female)

12

RSFPV RKFPV FSFDV FKFDV

RSFPV 48x-*M RKFPV 48x-*M FSFDV 48x-*M FKFDV 48x-*M

RSV WSCV 48x-*M RSV RKCV 48x-*M RSV WKCV 48x-*M RSV RSFPV 48x-*M RSV RKFPV 48x-*M RSV FSFDV 48x-*M RSV FKFDV 48x-*M

WSV WSCV 48x-*M WSV RKCV 48x-*M WSV WKCV 48x-*M WSV RSFPV 48x-*M WSV RKFPV 48x-*M WSV FSFDV 48x-*M WSV FKFDV 48x-*M

RKV WSCV 48x-*M RKV RKCV 48x-*M RKV WKCV 48x-*M RKV RSFPV 48x-*M RKV RKFPV 48x-*M RKV FSFDV 48x-*M RKV FKFDV 48x-*M

WKV WSCV 48x-*M WKV RKCV 48x-*M WKV WKCV 48x-*M WKV RSFPV 48x-*M WKV RKFPV 48x-*M WKV FSFDV 48x-*M WKV FKFDV 48x-*M

RSCV WSCV 48x-*M RSCV RKCV 48x-*M RSCV WKCV 48x-*M RSCV RSFPV 48x-*M RSCV RKFPV 48x-*M RSCV FSFDV 48x-*M RSCV FKFDV 48x-*M

WSCV WSCV 48x-*M WSCV RKCV 48x-*M WSCV WKCV 48x-*M WSCV RSFPV 48x-*M WSCV RKFPV 48x-*M WSCV FSFDV 48x-*M WSCV FKFDV 48x-*M

RKCV RKCV 48x-*M RKCV WKCV 48x-*M RKCV RSFPV 48x-*M RKCV RKFPV 48x-*M RKCV FSFDV 48x-*M RKCV FKFDV 48x-*M

WKCV WKCV 48x-*M WKCV RSFPV 48x-*M WKCV RKFPV 48x-*M WKCV FSFDV 48x-*M WKCV FKFDV 48x-*M

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H70

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

minifast

®

Cordset and Receptacle Connector Dimensions

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

PUR (Polyurethane)

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 68

300 V

Rated Current:

9 A

Ambient Temperature:

-40°C to +105°C (-40° to +221°F)

1 3

RSV ..

2

Pages H69 - H70 RKV ..

4

Pages H69 - H70

WSV ..

9

Pages H69 - H70 WKV ..

10

Pages H69 - H70

RSFPV ..

H71

Pages H69 - H70 RKFPV ..

Pages H69 - H70

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA,

eurofast

®

Cordset and Receptacle Connector Dimensions

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

PUR (Polyurethane)

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane) or POM (Nylon)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 68

250 V

Rated Current:

4 A

Ambient Temperature:

-40° to +105°C (-40° to +221°F)

5 7

RSCV ..

6

Pages H69 - H70 RKCV ..

8

Pages H69 - H70

WSCV ..

11

Pages H69 - H70 WKCV ..

12

Pages H69 - H70

FSFDV ..

Pages H69 - H70 FKFDV ..

Pages H69 - H70

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

H72

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TURCK

Process Automation – Networks

PROFIBUS

®

-PA, Terminating Resistors

Terminating Resistors Stabilize and

Minimize Reflections on the Bus Line

A Terminating Resistor is Required at the

Beginning and End of the Main Bus Line

Housing Part Number Specs Application

RSV 48-TR

Nickel Plated Brass or

Stainless Steel

300 V, 9 A

-40° to +75°C

minifast

®

Terminating Resistor

Male minifast connector

Pinouts

Male

RSEV 48-TR

Nickel Plated Brass or

Stainless Steel

250 V, 4 A

-40° to +75°C

eurofast

®

Terminating Resistor

Male eurofast connector

Male

H73

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA, Feed Through Connectors

Receptacles Provide Transition from

Male to Female Connectors

Available for Bulkhead and Feed Through

Applications

Housing Part Number Specs Application

RSFV RKFV 48/22

Nickel Plated CuZn or Stainless Steel

300 V, 9 A

-40° to +75°C

minifast ®

Receptacle

Bulkhead

Straight male/female feed through

For use with

DeviceNet minifast cordsets

FKV FSV 48/M12

Nickel Plated CuZn or Stainless Steel

250 V, 4 A

-40° to +75°C

eurofast ®

Feed Through

Connection

• straight male/female connector

• for pre-molded

eurofast cables

Standard housing material is nickel plated brass. "RSF RKF.."; "RSFV RKFV.." indicates stainless steel housing.

Male

Pinouts

Female

Male Female

Panel Cutout

RSFV RKFV 48/22

Panel Cutout

FKV FSV 48/M12

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H74

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

minifast ®

Passive Multiport Junctions (Bricks)

Rugged, Fully Encapsulated Enclosure

For Connecting I/O in Concentrated

Areas

Suitable for Outdoor Applications

Part Number

JBBS-48-M413

JBBS-48SC-M413

JBBS-48-M613

Specs

No short-circuit protection

Electrical

Short-circuit protection: 55 mA (Isc)

Open circuit voltage: 35 VDC

Current consumption: 5 mA

Diagnostic

LED indicators

Power: Green = On

Short-circuit: Red = Shorted

No short-circuit protection

JBBS-48SC-M613

Electrical

Short-circuit protection: 55 mA (Isc)

Open circuit voltage: 35 VDC

Current consumption: 5 mA

Diagnostic

LED indicators

Power: Green = On

Short-circuit: Red = Shorted

JBBS-48-M813

No short-circuit protection

Application

4-port Junction

Bus in/bus out connections

(7/8-16UN) minifast

Four (7/8-16UN) minifast connectors for field devices

CL I, Div 2; Groups A-D see

TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

6-port Junction

Bus in/bus out connections

(7/8-16UN) minifast

Six (7/8-16UN) minifast connectors for field devices

CL I, Div 2; Groups A-D see

TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

JBBS-48SC-M813

Electrical

Short-circuit protection: 55 mA (Isc)

Open circuit voltage: 35 VDC

Current consumption: 5 mA

Diagnostic

LED indicators

Power: Green = On

Short-circuit: Red = Shorted

8-port Junction

Bus in/bus out connections

(7/8-16UN) minifast

Eight (7/8-16UN) minifast connectors for field devices

CL I, Div 2; Groups A-D see

TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

Wiring Diagrams

H75

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

Anodized Aluminum

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 67, IP 68, IP 69K

300 V

Rated Current:

9 A

Ambient Temperature:

-40° to +75°C (-40° to +167°F)

Dimensions

8-Port 6-Port

4-Port

Male

Pinouts

minifast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H76

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

minifast ®

Passive Multiport Junctions (Bricks)

Rugged, Fully Encapsulated Enclosure

For Connecting I/O in Concentrated

Areas

Suitable for Outdoor Applications

Part Number Specs

JBBS-48-M423

No short-circuit protection

Fiberglass housing

Application

4-port Junction

Bus in/bus out connections

(7/8-16UN) minifast

Four (7/8-16UN) minifast connectors for field devices

CL I, Div 2; Groups A-D see TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

Wiring Diagrams

JBBS-48-M623

No short-circuit protection

Fiberglass housing

6-port Junction

Bus in/bus out connections

(7/8-16UN) minifast

Six (7/8-16UN) minifast connectors for field devices

CL I, Div 2; Groups A-D see TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

H77

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

Fiberglass

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 67, IP 68, IP 69K

300 V

Rated Current:

9 A

Ambient Temperature:

-40° to +75°C (-40° to +167°F)

Dimensions

4-Port 6-Port

Male

Pinouts

minifast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H78

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

eurofast

®

Passive Multiport Junctions (Bricks)

Rugged, Fully Encapsulated Enclosure

For Connecting I/O in Concentrated

Areas

Suitable for Outdoor Applications

Part Number

JBBS-48-E413

JBBS-48SC-E413

JBBS-48-E613

Specs

No short-circuit protection

Electrical

Short-circuit protection: 55 mA (Isc)

Open circuit voltage: 35 VDC

Current consumption: 5 mA

Diagnostic

LED indicators

Power: Green = On

Short-circuit: Red = Shorted

No short-circuit protection

JBBS-48SC-E613

Electrical

Short-circuit protection: 55 mA (Isc)

Open circuit voltage: 35 VDC

Current consumption: 5 mA

Diagnostic

LED indicators

Power: Green = On

Short-circuit: Red = Shorted

Application

4-port Junction

Bus in/bus out connections

(M12x1) eurofast

Four (M12x1) eurofast connectors for field devices

CL I, DIv 2; Groups A-D see

TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

6-port Junction

Bus in/bus out connections

(M12x1) eurofast

Six (M12x1) eurofast connectors for field devices

CL I, Div 2; Groups A-D see

TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

Wiring Diagrams

H79

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

Anodized Aluminum

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 67, IP 68, IP 69K

250 V

Rated Current:

4 A

Ambient Temperature:

-40° to +75°C (-40° to +167°F)

Dimensions

4-Port 6-Port

Male

Pinouts

eurofast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H80

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

eurofast

®

Passive Multiport Junctions (Bricks)

Rugged, Fully Encapsulated Enclosure

For Connecting I/O in Concentrated

Areas

Suitable for Outdoor Applications

Part Number

JBBS-48-E813

No short-circuit protection

Specs Application

JBBS-48SC-E813

Electrical

Short-circuit protection: 55 mA (Isc)

Open circuit voltage: 35 VDC

Current consumption: 5 mA

Diagnostic

LED indicators

Power: Green = On

Short-circuit: Red = Shorted

8-port Junction

Bus in/bus out connections

(M12x1) eurofast

Eight (M12x1) eurofast connectors for field devices

CL I, Div 2; Groups A-D see

TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

Wiring Diagrams

H81

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

Anodized Aluminum

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 67, IP 68, IP 69K

250 V

Rated Current:

4 A

Ambient Temperature:

-40° to +75°C (-40° to +167°F)

Dimensions

8-Port

Male

Pinouts

eurofast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H82

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

eurofast

®

Passive Multiport Junctions (Bricks), Short-Circuit Protected

Rugged, Fully Encapsulated Enclosure

For Connecting I/O in Concentrated

Areas

Suitable for Outdoor Applications

Part Number Specs Application Wiring Diagrams

JBBS-48SC-E613/EX

Diagnostic

LED indicators

Power: Green = On

Short-circuit: Red = Shorted

Short-Circuit Protection

≤35 mA

Current consumption

≤7 mA

Voltage drop

≤0.3 V

6-port Junction

Bus in/bus out connections

(M12x1) eurofast

Six (M12x1) eurofast connectors for field devices

CL I, Div 2; Groups A-D see TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

FISCO/ENTITY Field Device

H83

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

Anodized Aluminum

Nickel Plated CuZn

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 67, IP 68, IP 69K

250 V

Rated Current:

4 A

Ambient Temperature:

-40° to +75°C (-40° to +167°F)

Dimensions

6-Port

Male

Pinouts

eurofast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H84

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

eurofast

®

Passive Multiport Junctions (Bricks)

Rugged, Fully Encapsulated Enclosure

For Connecting I/O in Concentrated

Areas

Suitable for Outdoor Applications

Part Number Specs

JBBS-48-E414

No short-circuit protection

Application

4-port Junction

Bus in/bus out connections

(M12x1) eurofast

Four (M12x1) eurofast connectors for field devices

CL I, DIv 2; Groups A-D see TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

Wiring Diagrams

JBBS-48-E614

No short-circuit protection

6-port Junction

Bus in/bus out connections

(M12x1) eurofast

Six (M12x1) eurofast connectors for field devices

CL I, Div 2; Groups A-D see TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

H85

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

Anodized Aluminum

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 67, IP 68, IP 69K

250 V

Rated Current:

4 A

Ambient Temperature:

-40° to +75°C (-40° to +167°F)

Dimensions

4-Port 6-Port

Male

Pinouts

eurofast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H86

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

eurofast

®

Passive Multiport Junctions (Bricks)

Rugged, Fully Encapsulated Enclosure

For Connecting I/O in Concentrated

Areas

Suitable for Outdoor Applications

Part Number Specs Application

JBBS-48-E814

No short-circuit protection

8-port Junction

Bus in/bus out connections

(M12x1) eurofast

Eight (M12x1) eurofast connectors for field devices

CL I, Div 2; Groups A-D see TURCK drawing N1-2.400

T6, Ta = 70°C (SC Only)

Wiring Diagrams

H87

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Specifications

Housing:

Coupling Nut:

Contact Carrier:

Contacts:

Anodized Aluminum

Nickel Plated CuZn or Stainless Steel

TPU (Polyurethane)

Gold Plated CuZn

Protection:

Rated Voltage:

NEMA 1, 3, 4, 6P and IEC IP 67, IP 68, IP 69K

250 V

Rated Current:

4 A

Ambient Temperature:

-40° to +75°C (-40° to +167°F)

Dimensions

8-Port

Male

Pinouts

eurofast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H88

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

minifast

®

Conduit Adapters

Gasket and Mounting Screws Provided

Same Housing Style for Single or Double

Port

Housing Part Number Specs Application Pinout

BCA 48-M123

Nylon Housing

300 V, 9 A

-40° to +75°C

Attaches to standard conduit body* for transition to 4-wire (7/8-16UN)

minifast connector

*Crouse-Hinds 3/4" Form 8, or Mark

9 or equivalent.

Male

BCA 48-M223

Attaches to standard conduit body* for transition to 4-wire (7/8-16UN)

minifast connector

*Crouse-Hinds 3/4" Form 8, or Mark

9 or equivalent.

1-port Wiring Diagram 2-port Wiring Diagram

H89

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA,

eurofast

®

Conduit Adapters

Gasket and Mounting Screws Provided

Same Housing Style for Single or Double

Port

Housing Part Number Specs Application Pinout

BCA 48-E123

Nylon Housing

250 V, 4 A

-40° to +75°C

Attaches to standard conduit body* for transition to 4-wire (M12x1)

eurofast connector

*Crouse-Hinds 3/4" Form 8, or

Mark 9 or equivalent.

Female

BCA 48-E223

Attaches to standard conduit body* for transition to 4-wire (M12x1)

eurofast connector

*Crouse-Hinds 3/4" Form 8, or

Mark 9 or equivalent.

1-port Wiring Diagram 2-port Wiring Diagram

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H90

TURCK

Process Automation – Networks

PROFIBUS

®

-PA, Tees

Creates a Drop or Branch from the Main

Bus Line

minifast

Lines

®

Connectors on Bus or Drop

Housing Part Number Specs

RSV 2RKV 48

Application Wiring Diagrams

minifast Tee

Data, ground, shield

Stainless steel coupling nuts

RSV FKV RKV 48

PUR (Polyurethane)

250 V, 4 A

-40° to +75°C

minifast to eurofast

®

Drop

Data, ground, shield

Stainless steel coupling nuts

RSCS 2RKCS 48

eurofast Tee

Stainless steel coupling nuts

Male

minifast

Female

Pinouts

Male

eurofast

Female

H91

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA, Gender Changers and Elbow Connectors

Allows Quick and Easy Changes from

Male to Female

minifast

®

Connectors

Housing Part Number Specs

RSV RSV 48

Application

Male minifast Gender Changer

Changes female cordset to male receptacle

RKV RKV 48

TPU (Polyurethane)

250 V, 4 A

-40° to +75°C

Female minifast Gender Changer

Changes female cordset to male receptacle

WSV RKV 48

minifast Elbow

Right angle male to female connector

Male

Pinouts

minifast

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H92

TURCK

Process Automation – Networks

PROFIBUS

®

-PA, Surge Suppressor

Protects Data Communication Lines (V+ and V-)

Absorbs the Front End of the Transient,

Responding in Less Than a Nanosecond

Diverts the Surge Energy to Ground

Automatically Resets and waits for Next Surge

Housing

See Drawing 1

Part Number

RSV RKV 48 SS

Specs

Electrical

Maximum operating voltage: 27 Volts

Maximum operating current: 200 mA

Clamping Action Turn-on: 28.5 Volts

Maximum clamping at 2 kA: (8 x 20 Sec): 44 Volts

Maximum surge voltage: 20 kV

Maximum surge current: 2.5 kA

Current leakage/line at operating voltage: 5 A

Capacitance /line at operating voltage: 500 pF

Response time: Less than 1 nanosecond

Mechanical

Ground Stud: 10-32 stainless steel

Operating temperature: -40° to +85°C

Application

Male and female

minifast

®

, 4-pin

1

Pinouts

Male

Female

H93

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA

, Field Wireable Tee

A Hybrid Connection System Offering

Reliable Connections on the Short Drops and

Ease of Installation on the Long Trunk Runs

Features Standard

minifast ®

Connector for the Drop Connection and Terminal

Connectors on the Trunk Connections

Housing Style Part Number Specs

See Drawing 1

See Drawing 2

Application

SPTT1-A48

SPTTM13-A48

Anodized Aluminum

250 V, 4 A

-40° to +75°C

NEMA 1, 3, 4, 6P and IEC IP 68

(7/8-16UN) minifast connector for drop connection, and field wireable terminals on the trunk connections.

Pinout

Female

1 2

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H94

TURCK

Process Automation – Networks

PROFIBUS

®

-PA, (7/8-16UN)

minifast

®

Male Receptacles

Provides Quick Connection to Field

Devices

Available for 1/2-14NPT, 1/2-14NPSM,

3/4-14NPT and M20 Threads

Housing

13

Part Number

RSFV 48-*M/14.5

Specs Application

1/2-14NPT full length threads

Pinouts

15

RSFV 48-*M/14.75

3/4-14NPT full length threads

14

Male

RSFV 48-*M/M20

Nickel Plated CuZn or Stainless Steel

600 V, 9 A

-40° to +105°C

M20x1.5 threads

1. BN

2. N/C

3. BU

4. N/C

16

RSFV 48-*M

1/2-14NPSM threads

17

RSFV 48-*M/NPT

See page H99 for dimensional drawings.

Standard cable length is 0.3 Meters. Consult factory for other lengths.

Receptacles require a 13/16" (21 mm) clearance hole for panel mounting.

Standard housing material is nickel plated brass. "RKF .."; indicates 316 stainless steel housing.

For locknuts to be included, add "W/LN" to the end of the part number.

1/2-14NPT modified length threads

H95

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA, (7/8-16UN)

minifast

®

Female Receptacles

Provides Quick Connection to Field Devices

Available for 1/2-14NPT, 1/2-14NPSM,

3/4-14NPT and M20 Threads

Housing

18

Part Number

RKFV 48-*M/14.5

Specs Application

1/2-14NPT full length threads

Pinouts

20

RKFV 48-*M/14.75

3/4-14NPT full length threads

19

Female

RKFV 48-*M/M20

Nickel Plated CuZn or Stainless Steel

600 V, 9 A

-40° to +105°C

M20x1.5 threads

1. BN

2. N/C

3. BU

4. GY

21

RKFV 48-*M

1/2-14NPSM threads

22

RKFV 48-*M/NPT

1/2-14NPT modified length threads

See page H100 for dimensional drawings.

Standard cable length is 0.3 Meters. Consult factory for other lengths.

Receptacles require a 13/16" (21 mm) clearance hole for panel mounting.

Standard housing material is nickel plated brass. "RKF .."; indicates 316 stainless steel housing.

For locknuts to be included, add "W/LN" to the end of the part number.

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H96

TURCK

Process Automation – Networks

PROFIBUS

®

-PA, (M12x1)

eurofast

®

Male Receptacles

Mounted for Quick Connection to

Enclosures

Available for 1/2-14NPT, 1/2-14NPSM,

3/4-14NPT and M20 Threads

Housing

23

Part Number

FSV 48-*M/14.5

Specs Application

1/2-14NPT full length threads

25

FSV 48-*M/14.75

3/4-14NPT full length threads

24

FSV 48-*M/M20

Nickel Plated CuZn or Stainless Steel

250 V, 4 A

-40° to +105°C

M20x1.5 threads

1. BN

2. N/C

3. BU

4. N/C

26

FSV 48-*M

PG 9 threads

27

FSV 48-*M/NPT

1/2-14NPT modified length threads

See page H101 for dimensional drawings.

Standard cable length is 0.3 Meters. Consult factory for other lengths.

Receptacles require a 13/16" (21 mm) clearance hole for panel mounting.

Standard housing material is nickel plated brass. "RKF .."; indicates 316 stainless steel housing.

Pinout

Male

H97

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA, (M12x1)

eurofast

®

Female Receptacles

Mounted for Quick Connection to

Enclosures

Available for 1/2-14 NPT, 1/2-14 NPSM,

3/4-14 NPT and M20 Threads

Housing

28

Part Number

FKV 48-*M/14.5

Specs Application

1/2-14NPT full length threads

30

FKV 48-*M/14.75

3/4-14NPT full length threads

29

FKV 48-*M/M20

Nickel Plated CuZn or Stainless Steel

250 V, 4 A

-40° to +105°C

M20x1.5 threads

1. BN

2. N/C

3. BU

4. GY

31

FKV 48-*M

PG 9 threads

32

FKV 48-*M/NPT

1/2-14NPT modified length threads

See page H102 for dimensional drawings.

Standard cable length is 0.3 Meters. Consult factory for other lengths.

Receptacles require a 13/16" (21 mm) clearance hole for panel mounting.

Standard housing material is nickel plated brass. "RKF .."; indicates 316 stainless steel housing.

Pinouts

Female

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H98

TURCK

Process Automation – Networks

minifast

®

Male Receptacles

13 15

RSFV .. 14.5

14

Page H95 RSFV .. 14.75

16

Page H95

Page H95 RSFV .. M20

17

Page H95 RSFV ..

RSFV .. NPT Page H95

H99

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

18

minifast

®

Female Receptacles

20

RKFV .. 14.5

19

Page H96 RKFV .. 14.75

21

Page H96

Page H96 RKFV .. M20

22

Page H96 RKFV ..

RKFV .. NPT Page H96

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H100

TURCK

Process Automation – Networks

eurofast

®

Male Receptacles

23 25

FSV .. 14.5

24

Page H97 FSV .. 14.75

26

Page H97

Page H97 FSV .. M20

27

Page H97 FSV ..

FSV .. NPT Page H97

H101

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

28 30

FKV .. 14.5

29

Page H98 FKV .. 14.75

31

Page H98

Page H98 FKV .. M20

32

Page H98 FKV ..

FKV .. NPT Page H98

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H102

TURCK

Process Automation – Networks

PROFIBUS

®

-PA,

minifast

®

Field Wireable Connectors

Screw Terminals Accept up to 16 AWG

Conductors

Housing Part Number

BS 4148-0/9

BS 4148-0/13.5

B 4148-0/9

B 4148-0/13.5

Specs

Glass filled nylon

PG 9 cable gland, accepts 6-8 mm cable diameter

85°C

250 V, 9 A

Glass filled nylon

PG 13.5 cable gland accepts 10-12 mm cable diameter

85°C

250 V, 9 A

Glass filled nylon

PG 9 cable gland, accepts 6-8 mm cable diameter

85°C

250 V, 9 A

Glass filled nylon

PG 13.5 cable gland accepts 10-12 mm cable diameter

85°C

250 V, 9 A

For stainless steel coupling nuts change part number BS ... to BSV ...

Application

Mates with all 4-pin

minifast cordsets and receptacles

Pinout

Female

Male

H103

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

PROFIBUS

®

-PA,

eurofast

®

Field Wireable Connectors

Screw Terminals Accept up to 18 AWG

Conductors

Housing Part Number Specs

BS 8141-0/PG9

PBT, Black

PG 7 cable gland, accepts 4-8 mm cable diameter

85°C

125 V, 4 A

Application Pinouts

Male

BS 8241-0/PG9

PBT, Black

PG 7 cable gland, accepts 4-8 mm cable diameter

85°C

125 V, 4 A

B 8141-0/PG9

PBT, Black

PG 7 cable gland, accepts 4-6 mm cable diameter

85°C

250 V, 4 A

Mates with standard key

4-pin eurofast cordsets and receptacles

Female

B 8241-0/PG9

PBT, Black

PG 7 cable gland, accepts 4-6 mm cable diameter

85°C

250 V, 4 A

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H104

TURCK

Process Automation – Networks

PROFIBUS

®

-PA, Gender Changers and Elbow Connectors

Allows Quick and Easy Changes from

Male to Female and

minifast

to

eurofast

®

Connectors

®

Housing Part Number Specs Application

RSM 48-FK 4.5

Nickel plated brass CuZn or

Stainless Steel

250 V, 4 A

-40° to +80°C

Female eurofast, male

minifast, 4-pin

Wiring Diagram

minifast

Male

Pinouts

eurofast

Female

H105

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Process

Automation

Notes:

TURCK Inc. 3000 Campus Drive Minneapolis, MN 55441 Application Support: 1-800-553-0016 Fax: (763) 553-0708 www.turck.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

H106

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
