SL 91
2621 Ridgepoint Drive, Suite 235 Austin, TX 78754
800.866.6506
www.ikey.com
SL-91
Small Footprint with Epoxy Keycaps
iKey’s innovative SL-91 mobile keyboard was designed to accommodate rugged app
lications in manufacturing, material handling and remote data entry. Its unique
epoxy-coated keys are arranged for convenient gloved-hand use. It features a
small-footprint design, mounting holes in its case and a 10-key numeric pad. Like
other keyboards in the iKey line, the SL-91 is constructed using a robust p
olycarbonate case and industrial silicone keypad, sealing it from dust, liquids and
corrosives.
Technical Specifications
Certifications
NEMA 4X UL60950, FCC Part 15 Class B
Shock
3x11 ms pulses of 50g on each of 3 axes
Cable
LENGTH: 4 ft coiled (1.2m) DESIGN: PS/2 or USB Cable
Key Switch
MATERIAL: Epoxy-Coated Industrial Silicone Rubber LIFE: Greater Than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm)
ACTUATION FORCE: 7.03 oz +/- 0.70 oz (200g +/- 20g) FEEDBACK: Tactile with mechanical snap
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3
hours
Power
PS2: KEYBOARD: [email protected] (Keyboard port) USB: [email protected] (from CPU port)
Compatability
PS/2 KEYBOARD: All Windows Operating Systems USB KEYBOARD: All Windows and Macintosh OS
Temperature Range
STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
Weight
2.25 lbs +/- 0.10 lbs (1.02 kg +/- 0.05 kg)
Warranty
1 year limited warranty
Humidity
100%
Dimensions
11.40" x 6.30" x 1.90" (w-h-d) 289.6mm x 160.0mm x 48.3mm
Model Numbers
Features and Benefits
24 Function Keys
Built-In Mounting Holes
Integrated 10-Key Numeric Pad
Integrated Backlighting
Lightweight ABS Polycarbonate Case
USB and PS/2 configurations available
©2011 iKey, Ltd. All rights reserved. 2621 Ridgepoint Drive Suite 235 Austin, TX 78754 1-800- 866-6506
