ERserver
IBM xSeries 345
Type 8670
Option Installation Guide
SC88-P919-00
ERserver
IBM xSeries 345
Type 8670
Option Installation Guide
SC88-P919-00
Note:
Before using this information and the product it supports, be sure to read the general information in
“Notices”, on page 45.
Second Edition (May 2003)
© Copyright International Business Machines Corporation 2003. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.
Contents
Safety
. . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Chapter 1. Introduction . . . . . . . . . . . . .
Related publications . . . . . . . . . . . . . .
Notices and statements used in this book . . . . . .
Major components of the xSeries 345 Type 8670 server .
System-board option connectors . . . . . . . . . .
PCI riser-card option connectors . . . . . . . . . .
System-board internal cable connectors . . . . . . .
System-board external port connectors . . . . . . .
System-board switches and jumpers . . . . . . . .
System-board LED . . . . . . . . . . . . . . .
Light Path Diagnostics panel . . . . . . . . . . .
. 1
. 1
. 2
. 3
. 4
. 4
. 5
. 6
. 7
. 9
. . . . . . . . . 10
Chapter 2. Installing options . . . . .
Installation guidelines . . . . . . . .
System reliability considerations . . .
Working inside the server with the power
Handling static-sensitive devices . . .
Server power features . . . . . . . .
Turning on the server . . . . . . .
Turning off the server . . . . . . .
Removing the cover and bezel . . . . .
Working with adapters . . . . . . . .
Installing a ServeRAID-5i controller . .
Installing a hot-swap drive . . . . . . .
Installing memory modules . . . . . .
Installing a microprocessor . . . . . .
Installing a hot-swap power-supply option .
Replacing a hot-swap fan . . . . . . .
Replacing the battery . . . . . . . .
Completing the installation. . . . . . .
Installing the server cover and bezel . .
Installing the server in a rack. . . . .
Updating your server configuration. . .
Connecting external options . . . . .
Cabling the server. . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
on
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Chapter 3. Input/output connectors . . . . . . . . .
Auxiliary-device (pointing device) connector . . . . . . .
Ethernet connectors . . . . . . . . . . . . . . . .
Integrated system management processor (ISMP) interconnect
Keyboard connector . . . . . . . . . . . . . . . .
Serial connector . . . . . . . . . . . . . . . . .
Ultra320 SCSI controller system-board connectors . . . . .
SCSI cabling requirements . . . . . . . . . . . .
SCSI IDs . . . . . . . . . . . . . . . . . . .
SCSI connector . . . . . . . . . . . . . . . .
Universal Serial Bus version 1.1 connectors . . . . . . .
Video connector . . . . . . . . . . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. .
. .
. .
ports
. .
. .
. .
. .
. .
. .
. .
. .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
11
11
11
11
11
13
13
13
15
16
21
22
23
26
31
33
34
36
36
36
36
37
37
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
39
40
40
40
40
41
41
41
41
42
42
42
Appendix. Notices . . . . . . . . . . . . . . . . . . . . . . . 45
Edition notice . . . . . . . . . . . . . . . . . . . . . . . . . 45
© Copyright IBM Corp. 2003
iii
Trademarks . . . . . . . . . . . . . . . . . . .
Important notes. . . . . . . . . . . . . . . . . .
Product recycling and disposal . . . . . . . . . . . .
Electronic emission notices . . . . . . . . . . . . .
Federal Communications Commission (FCC) statement . .
Industry Canada Class A emission compliance statement .
Australia and New Zealand Class A statement . . . . .
United Kingdom telecommunications safety requirement. .
European Union EMC Directive conformance statement . .
Taiwanese Class A warning statement . . . . . . . .
Chinese Class A warning statement . . . . . . . . .
Japanese Voluntary Control Council for Interference (VCCI)
Power cords . . . . . . . . . . . . . . . . . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
statement
. . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
46
46
47
47
47
48
48
48
48
49
49
49
49
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
iv
IBM xSeries 345 Type 8670: Option Installation Guide
Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto, lea la información de seguridad.
© Copyright IBM Corp. 2003
v
Läs säkerhetsinformationen innan du installerar den här produkten.
Statement 1
Danger
Electrical current from power, telephone, and communication cables is hazardous.
To avoid a shock hazard:
v Do not connect or disconnect any cables or perform installation, maintenance, or
reconfiguration of this product during an electrical storm.
v Connect all power cords to a properly wired and grounded electrical outlet.
v Connect to properly wired outlets any equipment that will be attached to this
product.
v When possible, use one hand only to connect or disconnect signal cables.
v Never turn on any equipment when there is evidence of fire, water, or structural
damage.
v Disconnect the attached power cords, telecommunications systems, networks, and
modems before you open the device covers, unless instructed otherwise in the
installation and configuration procedures.
v Connect and disconnect cables as described in the following table when installing,
moving, or opening covers on this product or attached devices.
To connect:
To disconnect:
1. Turn everything OFF.
1. Turn everything OFF.
2. First, attach all cables to devices.
2. First, remove power cords from outlet.
3. Attach signal cables to connectors.
3. Remove signal cables from connectors.
4. Attach power cords to outlet.
4. Remove all cables from devices.
5. Turn device ON.
Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has a
module containing a lithium battery, replace it only with the same module type made
by the same manufacturer. The battery contains lithium and can explode if not
properly used, handled, or disposed of.
Do not:
v Throw or immerse into water.
v Heat to more than 100° C (212° F)
v Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
vi
IBM xSeries 345 Type 8670: Option Installation Guide
Statement 3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
v Do not remove the covers. Removing the covers of the laser product could result in
exposure to hazardous laser radiation. There are no serviceable parts inside the
device.
v Use of controls or adjustments or performance of procedures other than those
specified herein might result in hazardous radiation exposure.
Danger
Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the
following. Laser radiation when open. Do not stare into the beam, do not view directly with
optical instruments, and avoid direct exposure to the beam.
Statement 4
≥18 kg (39.7 lb)
≥32 kg (70.5 lb)
CAUTION:
Use safe practices when lifting.
≥55 kg (121.2 lb)
Safety
vii
Statement 5
CAUTION:
The power-control button on the device and the power switch on the power supply do
not turn off the electrical current supplied to the device. The device also might have
more than one power cord. To remove all electrical current from the device, ensure
that all power cords are disconnected from the power source.
2
1
Statement 8
CAUTION:
Never remove the cover on a power supply or any part that has the following label
attached.
Hazardous voltage, current, and energy levels are present inside any component that
has this label attached. There are no serviceable parts inside these components. If you
suspect a problem with one of these parts, contact a service technician.
Statement 12
CAUTION:
The following label indicates a hot surface nearby.
viii
IBM xSeries 345 Type 8670: Option Installation Guide
Statement 13
DANGER:
Overloading a branch circuit is potentially a fire hazard and a shock hazard under
certain conditions. To avoid these hazards, ensure that your system electrical
requirements do not exceed the branch circuit protection requirements. Refer to the
information that is provided with your IBM device for electrical specifications.
Statement 14
CAUTION:
Hazardous voltage, current, and energy levels might be present. Only a qualified
service technician is authorized to remove the covers where the following label is
attached.
Statement 15
CAUTION:
Make sure that the rack is secured properly to avoid tipping when the server unit is
extended.
Statement 16
CAUTION:
Some accessory or option board outputs exceed Class 2 or limited power source
limits and must be installed with appropriate interconnecting cabling in accordance
with the national electric code.
Safety
ix
Statement 17
CAUTION:
The following label indicates moving parts nearby.
WARNING: Handling the cord on this product or cords associated with accessories
sold with this product, will expose you to lead, a chemical known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash
hands after handling.
ADVERTENCIA: El contacto con el cable de este producto o con cables de
accesorios que se venden junto con este producto, pueden exponerle al plomo, un
elemento químico que en el estado de California de los Estados Unidos está
considerado como un causante de cancer y de defectos congénitos, además de
otros riesgos reproductivos. Lávese las manos después de usar el producto.
x
IBM xSeries 345 Type 8670: Option Installation Guide
Chapter 1. Introduction
This Option Installation Guide contains instructions for installing, removing, and
connecting optional devices that your server supports.
Related publications
In addition to this Option Installation Guide, the following documentation comes with
your server:
v User’s Guide
This publication is in Portable Document Format (PDF) on the IBM® xSeries
Documentation CD. It contains general information about your server.
v Installation Guide
This printed publication contains instructions for setting up your server and basic
instructions for installing some options.
v Safety Information
This publication is in PDF on the IBM xSeries Documentation CD. It contains
translated caution and danger statements. Each caution and danger statement
that appears in the documentation has a number that you can use to locate the
corresponding statement in your language in the Safety Information book.
v Rack Installation Instructions
This printed publication contains instructions for installing your server in a rack.
v Hardware Maintenance Manual and Troubleshooting Guide
This publication is in PDF on the IBM xSeries Documentation CD. It contains
information to help you solve problems yourself, and it contains information for
service technicians.
Depending on your server model, additional publications might be included on the
IBM xSeries Documentation CD.
Your server might have features that are not described in the documentation that
you received with the server. The documentation might be updated occasionally to
include information about those features, or technical updates might be available to
provide additional information that is not included in your server documentation.
These updates are available from the IBM Web site. Complete the following steps
to check for updated documentation and technical updates:
1. Go to http://www.ibm.com/pc/support/.
2. In the Quick path to a product field, type 8670 and click Go.
3. On the left side of the “xSeries 345 8670 support” page, click Online
publications.
4. From the Online publications by category menu, select the category of
publications you want to display.
© Copyright IBM Corp. 2003
1
Notices and statements used in this book
The caution and danger statements that appear in this book are also in the
multilingual Safety Information book, which is on the IBM xSeries Documentation
CD. Each statement is numbered for reference to the corresponding statement in
the Safety Information book.
The following notices and statements are used in the documentation:
v Notes: These notices provide important tips, guidance, or advice.
v Important: These notices provide information or advice that might help you avoid
inconvenient or problem situations.
v Attention: These notices indicate potential damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in which
damage could occur.
v Caution: These statements indicate situations that can be potentially hazardous
to you. A caution statement is placed just before the description of a potentially
hazardous procedure step or situation.
v Danger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
2
IBM xSeries 345 Type 8670: Option Installation Guide
Major components of the xSeries 345 Type 8670 server
The orange color on components and labels in the server indicates hot-swap or
hot-plug components. You can install or remove these components while the server
is running, provided that the server is configured to support hot-swap and hot-plug
features.
The blue color on components and labels indicates touch points, where a
component can be gripped, a latch moved, and so on.
The following illustration shows the major components in the server.
Microprocessor
air baffle
Heat sink
PCI riser card
assembly
Microprocessor
Memory module
Air baffle
System board
VRM
Power supply
blank (some models)
Hot-swap
power supply
Shuttle
Hot-swap fan
Filler panel for
drive bay
Chapter 1. Introduction
3
System-board option connectors
The following illustration shows the connectors on the system board for
user-installable options.
DIMM 1
(J1)
DIMM 2
(J2)
DIMM 4
(J4)
DIMM 3
(J3)
VRM 2
(J5)
Microprocessor 2
(J6)
PCI-X slot 1
64-bit 3.3V
100 MHz
(J14)
Microprocessor 1
(J7)
PCI-X slot 2
64-bit 3.3V
100 MHz
(J13)
VRM 1
(J8)
Battery
(BH1)
PCI riser
card
(J16)
PCI riser-card option connectors
The following illustration shows the connectors on the PCI-riser card for
user-installable options.
PCI-X slot 3 64-bit
3.3V 133 MHz (PCI 3)
PCI-X slot 4 64-bit
3.3V 133 MHz (PCI 4)
PCI slot 5 32-bit
5V 33 MHz (PCI 5)
System management connector
4
IBM xSeries 345 Type 8670: Option Installation Guide
System-board internal cable connectors
The following illustration shows the internal connectors on the system board.
Fans 4 and 8
(J28)
Fans 3 and 7
(J27)
USB 3
operator panel
Power signal
(J25)
Fans 2 and 6
(J29)
Fans 1 and 5
(J26)
Power
(J24)
Internal SCSI
(J23)
IDE (J21)
Operator panel
(J22)
Chapter 1. Introduction
5
System-board external port connectors
The following illustration shows the external input/output connectors on the system
board.
Serial/video
(J9)
Mouse/keyboard
(J10)
Ethernet 1
(J11)
Ethernet 2
(J12)
RS485-A and B
(J15)
USB 1
(J17)
USB 2
(J18)
External
SCSI
(J19)
6
IBM xSeries 345 Type 8670: Option Installation Guide
System-board switches and jumpers
The following illustration shows the switches and jumpers on the system board.
SW2
ON
8 7 6 5 4 3 2 1
System board
switch block
(SW2)
Flash boot block
recovery jumper
(J34)
Chapter 1. Introduction
7
Table 1 describes the function of each switch on the switch block.
Table 1. Switches 1-8
Switch
number
Default value
Switch
description
8
Off
Reserved.
7
Off
Reserved.
6
Off
Reserved.
5
Off
Reserved.
4
Off
Reserved.
3
Off
Power-on override. When toggled to On, this switch forces the power on, overriding
the power-on button.
2
Off
Power-on password override. Changing the position of this switch bypasses the
power-on password check the next time the server is turned on and starts the
Configuration/Setup Utility program so that you can change or delete the power-on
password. You do not need to move the switch back to the default position after the
password is overridden.
Changing the position of this switch does not affect the administrator password check
if an administrator password is set.
See the User’s Guide on the IBM xSeries Documentation CD for additional
information about the power-on password.
1
Off
H8 out serial port. This switch is reserved for service use only.
Notes:
1. Before changing any switch settings or moving any jumpers, turn off the server;
then, disconnect all power cords and external cables. (Review the information in
“Safety” on page v, “Installation guidelines” on page 11, “Handling static-sensitive
devices” on page 11, and “Turning off the server” on page 13.)
2. Any system-board switch or jumper blocks that are not shown in the illustrations
in this book are reserved.
8
IBM xSeries 345 Type 8670: Option Installation Guide
System-board LED
The following illustration shows the light-emitting diodes (LEDs) on the system
board.
DIMM 1 error LED
(CR12)
DIMM 2 error LED
(CR15)
DIMM 3 error LED
(CR14)
DIMM 4 error LED
(CR13)
VRM 2 error LED
(CR16)
Microprocessor 2
error LED (CR17)
Microprocessor 1
error LED (CR18)
VRM 1 error LED
(CR19)
Integrated System Management
Processor (ISMP) activity
LED (CR41)
Chapter 1. Introduction
9
Light Path Diagnostics panel
The following illustration shows the error LEDs on the Light Path Diagnostics™
panel.
1
2
POWER
SUPPLIES
Light Path
Diagnostics™
VRM
CPU
NON
REDUNDANT
MEMORY
OVER SPEC
DASD
NMI
A
ISMP
B
CPU/VRM
MISMATCH
C
PCI
BUS
REMIND
FAN
TEMP
To access the Light Path Diagnostics panel, remove the top cover.
For more information about the Light Path Diagnostics feature, see the Hardware
Maintenance Manual and Troubleshooting Guide on the IBM xSeries Documentation
CD.
To acknowledge a system error but not take immediate action, press the Remind
button and place the Light Path Diagnostics feature in Remind mode. The
system-error LED on the front of the server flashes in Remind mode. If a new
failure occurs, the system-error LED is lit again.
The following table describes the LEDs on the Light Path Diagnostics panel.
Table 2. Diagnostics panel LEDs
Diagnostic panel LED
Description
POWER SUPPLY 1
The power supply in bay 1 failed.
POWER SUPPLY 2
The power supply in bay 2 failed.
VRM
An error occurred on one or both microprocessor voltage regulator modules (VRMs).
CPU
One or both microprocessors failed, or one is seated in the wrong socket.
NON REDUNDANT
The server power supplies are no longer redundant (applicable only with redundant
power).
MEMORY
One or more dual inline memory modules (DIMMs) failed.
OVER SPEC
The system has shut down due to a system over load condition.
DASD
The SCSI backplane or a device connected to a SCSI bus failed.
NMI
A nonmaskable interrupt occurred.
PCI BUS A
An error occurred on an adapter in PCI-X slots 1 or 2 or on one of the integrated PCI
devices.
ISMP
The integrated system management processor detected an internal error.
PCI BUS B
An error occurred on an adapter in PCI-X slots 3 or 4.
FAN
A fan (1, 2, 3, 4, 5, 6, 7, or 8) failed or is operating slowly.
CPU/VRM MISMATCH
The service processor detected a CPU or VRM mismatch.
PCI BUS C
An error occurred on an adapter in PCI slot 5.
TEMP
The system temperature exceeded the maximum rating.
10
IBM xSeries 345 Type 8670: Option Installation Guide
Chapter 2. Installing options
This chapter provides detailed instructions for installing hardware options in your
server.
Installation guidelines
Before you begin installing options in your server, read the following information:
v Read the safety information beginning on page v and the guidelines in “Handling
static-sensitive devices”. This information will help you work safely with your
server and options.
v Make sure that you have an adequate number of properly grounded electrical
outlets for your server, monitor, and other devices that you will connect to the
server.
v Back up all important data before you make changes to disk drives.
v Have a small flat-blade screwdriver available.
v For a list of supported options for your server, go to
http://www.ibm.com/pc/compat/ on the World Wide Web.
System reliability considerations
To help ensure proper system cooling and system reliability, make sure that:
v Each of the drive bays has a drive or a filler panel and electromagnetic
compatibility (EMC) shield installed in it.
v There is adequate space around the server to allow the server cooling system to
work properly. Leave approximately 50 mm (2 in.) of open space around the front
and rear of the server. Do not place objects in front of the fans.
v You have followed the cabling instructions that come with optional adapters.
v You have replaced a failed fan as soon as possible.
Working inside the server with the power on
Your server supports hot-plug, hot-add, and hot-swap devices and is designed to
operate safely while turned on with the cover removed. Follow these guidelines
when you work inside a server that is turned on:
v Avoid loose-fitting clothing on your forearms. Button long-sleeved shirts before
working inside the server; do not wear cuff links while you are working inside the
server.
v Do not allow your necktie or scarf to hang inside the server.
v Remove jewelry, such as bracelets, necklaces, rings, and loose-fitting wrist
watches.
v Remove items from your shirt pocket (such as pens or pencils) that could fall into
the server as you lean over it.
v Avoid dropping any metallic objects, such as paper clips, hair pins, or screws,
into the server.
Handling static-sensitive devices
Attention: Static electricity can damage electronic devices and your system. To
avoid damage, keep static-sensitive devices in their static-protective packages until
you are ready to install them.
© Copyright IBM Corp. 2003
11
To reduce the possibility of electrostatic discharge, observe the following
precautions:
v Limit your movement. Movement can cause static electricity to build up around
you.
v Handle the device carefully, holding it by its edges or its frame.
v Do not touch solder joints, pins, or exposed printed circuitry.
v Do not leave the device where others can handle and possibly damage the
device.
v While the device is still in its static-protective package, touch it to an unpainted
metal part of the system unit for at least 2 seconds. (This drains static electricity
from the package and from your body.)
v Remove the device from its package and install it directly into your system unit
without setting it down. If it is necessary to set the device down, place it in its
static-protective package. Do not place the device on your system unit cover or
on a metal table.
v Take additional care when handling devices during cold weather because heating
reduces indoor humidity and increases static electricity.
12
IBM xSeries 345 Type 8670: Option Installation Guide
Server power features
When the server is connected to an ac power source but is not turned on, the
operating system does not run, and all core logic except for the service processor is
shut down; however, the server can respond to requests from the service processor,
such as a remote request to turn on the server. The power-on LED flashes to
indicate that the server is connected to ac power but not turned on.
Turning on the server
Approximately 20 seconds after the server is connected to ac power, the
power-control button becomes active, and you can turn on the server and start the
operating system by pressing the power-control button. The server can also be
turned on in any of the following ways:
v If a power failure occurs while the server is turned on, the server will restart
automatically when power is restored.
v If the server is connected to an Advanced System Management interconnect
network that contains at least one server with an optional Remote Supervisor
Adapter installed, the server can be turned on from the Remote Supervisor
Adapter user interface.
v If your operating system supports the system-management software for an
optional Remote Supervisor Adapter, the system-management software can turn
on the server.
v If your operating system supports the Wake on LAN® feature, the Wake on LAN
feature can turn on the server.
Note: When 4 GB or more of memory (physical or logical) is installed, some
memory is reserved for various system resources and is unavailable to the
operating system. The amount of memory that is reserved for system
resources depends on the operating system, the configuration of the server,
and the configured PCI options.
Turning off the server
When you turn off the server and leave it connected to ac power, the server can
respond to requests from the service processor, such as a remote request to turn
on the server. To remove all power from the server, you must disconnect it from the
power source.
Some operating systems require an orderly shutdown before you turn off the server.
See your operating-system documentation for information about shutting down the
operating system.
Chapter 2. Installing options
13
Statement 5:
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current
from the device, ensure that all power cords are disconnected from the power
source.
2
1
The server can be turned off in any of the following ways:
v You can turn off the server from the operating system, if your operating system
supports this feature. After an orderly shutdown of the operating system, the
server will be turned off automatically.
v You can press the power-control button to start an orderly shutdown of the
operating system and turn off the server, if your operating system supports this
feature.
v If the operating system stops functioning, you can press and hold the
power-control button for more than 4 seconds to turn off the server.
v If the server is connected to an Advanced System Management interconnect
network that contains at least one server with an optional Remote Supervisor
Adapter installed, the server can be turned off from the Remote Supervisor
Adapter user interface.
v If an optional Remote Supervisor Adapter is installed in the server, the server can
be turned off from the Remote Supervisor Adapter user interface.
v If the Wake on LAN feature turned on the server, the Wake on LAN feature can
turn off the server.
v The integrated system management processor can turn off the server as an
automatic response to a critical system failure.
v You can turn off the server through a request from the service processor.
14
IBM xSeries 345 Type 8670: Option Installation Guide
Removing the cover and bezel
The following illustration shows how to remove the cover and bezel.
Cover-release latch
Bezel
Complete the following steps to remove the server top cover:
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11.
2. If you are planning to install or remove a microprocessor, memory-module, PCI
adapter, or battery, turn off the server and all attached devices and disconnect
all external cables and power cords (see “Turning off the server” on page 13).
3. Press down on the left and right side latches and pull the server out of the rack
enclosure until both slide rails lock.
Note: You can reach the cables on the back of the server when the server is in
the locked position.
4. Lift the cover-release latch. Lift the cover off the server and set the cover aside.
Attention: For proper cooling and airflow, replace the cover before turning on
the server. Operating the server for extended periods of time (over 30 minutes)
with the cover removed might damage server components.
Complete the following steps to remove the bezel:
1. Press in on the tabs on the top of the bezel, and rotate the bezel away from the
server front.
2. Store the bezel in a safe place
Chapter 2. Installing options
15
Working with adapters
The following notes describe the types of adapters that your server supports and
other information that you must consider when installing adapters:
Before you install an adapter, review the following information:
v Read the documentation that comes with your operating system.
v Locate the documentation that comes with the adapter and follow those
instructions in addition to the instructions in this chapter. If you need to change
the switch or jumper settings on your adapter, follow the instructions that come
with the adapter.
v You can install only low-profile adapters in slots 1 and 2.
v You can install standard full-length adapters, with the adapter guides removed
from the adapters, in slots 3 and 4.
v You can install only a half-length adapter in slot 5.
v The ServeRAID-5i controller can be installed only in PCI slot 2. The low-profile
2-U bracket that comes with the controller is required to install the controller.
v The optional IBM Remote Supervisor Adapter can be installed only in PCI slot 5.
Use the ribbon cable that comes with the adapter to connect the adapter to the
system management connector on the PCI riser-card.
v Your server supports 5.0 V and universal PCI adapters on the 32-bit PCI slot 5;
your server supports only 3.3 V and universal PCI adapters in the 64-bit
PCI/PCI-X slot 3 and 4.
v The PCI bus configuration is:
– Non-hot-plug, 64-bit PCI-X slots 1 through 2 (PCI bus A, 100 MHz)
– Non-hot-plug, 64-bit PCI-X slots 3 through 4 (PCI bus B, 133 MHz)
– Non-hot-plug, 32-bit PCI slot 5 (PCI bus C, 33 MHz)
v The system scans PCI and PCI-X slots 1 through 5 to assign system resources;
then the system starts (boots) the system devices in the following order, if you
have not changed the default boot precedence: integrated Ethernet controller,
integrated SCSI controller, and then PCI and PCI-X slots 5, 3, 4, 1, and 2.
Notes:
1. If the ServeRAID-5i controller is installed, it takes control of the integrated
SCSI controller with RAID capabilities and operates at 66 MHz. The
ServeRAID-5i controller can be installed only in slot 2.
2. To have SCSI capabilities if you remove the ServeRAID-5i controller or other
RAID controller, start the Configuration/Setup Utility program and select
Devices and I/O Ports from the main menu to enable the SCSI controller
with RAID capabilities. See the User’s Guide on the IBM xSeries
Documentation CD for details about using the Configuration/Setup Utility
program.
3. To change the boot precedence for PCI and PCI-X devices, start the
Configuration/Setup Utility program and select Start Options from the main
menu. See the User’s Guide on the IBM xSeries Documentation CD for
details about using the Configuration/Setup Utility program.
16
IBM xSeries 345 Type 8670: Option Installation Guide
The following illustrations show the location of the PCI and PCI-X adapter
expansion slots on the system board and PCI riser card.
System board
DIMM 1
(J1)
DIMM 2
(J2)
DIMM 4
(J4)
DIMM 3
(J3)
VRM 2
(J5)
Microprocessor 2
(J6)
PCI-X slot 1
64-bit 3.3V
100 MHz
(J14)
Microprocessor 1
(J7)
PCI-X slot 2
64-bit 3.3V
100 MHz
(J13)
VRM 1
(J8)
Battery
(BH1)
PCI riser
card
(J16)
PCI riser card
PCI-X slot 3 64-bit
3.3V 133 MHz (PCI 3)
PCI-X slot 4 64-bit
3.3V 133 MHz (PCI 4)
PCI slot 5 32-bit
5V 33 MHz (PCI 5)
System management connector
Chapter 2. Installing options
17
The following illustration shows how to install a PCI or PCI-X adapter.
Low-profile
PCI adapter
Adapter
retainer
P
P
C
S
T
N
M
A
R
D
C
N N
E
O U
P
N ED
S
R
R
E
V
O
I
M
N
s™
ath c
P ti
t s
h o
ig n
L iag
D
R S
E IE
W PL
1 PO P
U
S
2
V
U
M
M
R CH
/V T
U A
P M
C IS
M
E
M
S
Y
R
A
D
O
D
A
B
R
E
C
I
C
P US
B
M
IN
D
FA
N
T
E
M
P
Complete the following steps to install a PCI or PCI-X adapter:
1. Read the safety information beginning on page v, and “Installation guidelines”
on page 11.
2. Turn off the server and peripheral devices and disconnect all power cords and
external cables (see “Turning off the server” on page 13); then, remove the
cover (see “Removing the cover and bezel” on page 15).
3. Determine which expansion slot you will use for the adapter.
18
IBM xSeries 345 Type 8670: Option Installation Guide
4. If you are installing an adapter in PCI slot 3, 4, or 5, remove the PCI riser-card
assembly.
PCI riser-card
assembly
Retention
latch
Guide tab
a. Lift the retention latch to release the PCI riser-card assembly.
b. Lift the assembly from the server.
c. Place the assembly on a flat, level surface.
5. Open the adapter retainer and slide the expansion-slot cover out of the server
or PCI riser-card assembly. Store it in a safe place for future use.
Attention: Expansion-slot covers must be installed on all empty slots. This
maintains the electronic emissions characteristics of the system and ensures
proper cooling of system components.
6. See the documentation that comes with your adapter for any cabling
instructions. It might be easier for you to route cables before you install the
adapter.
7. Remove the adapter from the static-protective package.
Attention: Avoid touching the components and gold-edge connectors on the
adapter.
Chapter 2. Installing options
19
8. Install the adapter:
a. If you are installing a full-length adapter, remove the blue adapter guide (if
any) from the end of the adapter.
Adapter guide
b. Carefully grasp the adapter by its top edge or upper corners, and align it
with the expansion slot.
c. Press the adapter firmly into the expansion slot and close the adapter
retainer.
Attention: When you install an adapter in the server, be sure that it is
completely and correctly seated in the connector. Incomplete insertion
might cause damage to the system board or the adapter.
PCI adapter
Adapter retainers
20
IBM xSeries 345 Type 8670: Option Installation Guide
9. If you removed the PCI riser-card assembly to install the adapter, press the
PCI riser-card assembly firmly into the connector and close the retention latch.
Note: Make sure that the PCI riser-card assembly is properly seated on the
system-board connector and that the cables under the PCI riser-card
assembly are not pinched.
PCI riser-card
assembly
Retention
latch
10. Connect any needed cables to the adapter. See the documentation that comes
with your adapter for cabling instructions.
Attention:
v When you route the cables, do not block the ventilated space around any of
the fans. In addition, route any cables that are plugged into the PCI adapter
under adjacent adapters so they are not pinched between the top edge of
the adapter and the shuttle side wall.
v To ensure system reliability, an optional SCSI adapter cannot control internal
hard disk drives.
If you have other options to install or remove, do so now. Otherwise, go to
“Installing the server cover and bezel” on page 36.
Installing a ServeRAID-5i controller
The following notes describe the ServeRAID-5i controller and other information that
you must consider when installing the ServeRAID-5i controller:
v You can install an optional RAID controller in your server to control the internal
hot-swap hard disk drives, for example, to enable you to configure the internal
hot-swap hard disk drives into disk arrays. You can also cable a RAID adapter to
external hard disk drives. See your RAID controller option documentation for
complete instructions on installing a RAID controller in your server and for
additional information on RAID controllers.
v No rerouting of the internal SCSI cable is required if you are installing the
ServeRAID-5i controller. The ServeRAID-5i controller uses the SCSI connector
on the system board for output.
Chapter 2. Installing options
21
v The ServeRAID-5i controller can be installed only in PCI-X slot 2. Slot 2 is the
only PCI-X slot that supports the ServeRAID-5i controller requirements.
v Connections made to external SCSI devices will be asynchronous.
v To have SCSI capabilities if you remove the ServeRAID-5i controller or other
RAID controller, start the Configuration/Setup Utility program and select Devices
and I/O Ports from the main menu to enable the SCSI controller with RAID
capabilities. See the User’s Guide on the IBM xSeries Documentation CD for
details about using the Configuration/Setup Utility program.
Complete the following steps to install a ServeRAID-5i controller:
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11.
2. Turn off the server and peripheral devices and disconnect all power cords and
external cables (see “Turning off the server” on page 13); then, remove the
cover (see “Removing the cover and bezel” on page 15).
3. Open the adapter retainer and slide the slot 2 expansion-slot cover out of the
server. Store it in a safe place for future use.
Attention: Expansion-slot covers must be installed on all empty slots. This
maintains the electronic emissions characteristics of the system and ensures
proper cooling of system components.
4. Install the low profile 2-U bracket on the adapter:
a. Remove the adapter from the static-protective package. Set the adapter
down on a nonconductive, static-protected surface (place it component side
up).
Attention: Avoid touching the components and gold-edge connectors on
the adapter.
b. Remove the 3-U bracket from the adapter and replace it with the 2-U low
profile bracket that comes with the RAID controller option. See the
documentation that comes with your RAID controller option for instructions.
5. Install the adapter:
a. Carefully grasp the adapter by its top edge or upper corners, and align it
with the expansion slot on the system board.
b. Press the adapter firmly into the expansion slot and close the adapter
retainer.
Attention: When you install an adapter in the server, be sure that it is
completely and correctly seated in the connector. Incomplete insertion might
cause damage to the system board or the adapter.
If you have other options to install or remove, do so now. Otherwise, go to
“Installing the server cover and bezel” on page 36.
Installing a hot-swap drive
The following notes describe the type of hard disk drive that your server supports
and other information that you must consider when installing a hard disk drive:
v Your server supports six 1-inch (26 mm) slim 3.5-inch low-voltage differential
(LVD) hard disk drives.
v All hot-swap drives installed in the server should have the same throughput
speed rating. Mixing hard disk drives with different speed ratings will cause all
drives to operate at the lower throughput speed.
v The SCSI ID assigned to each bay is printed on the bezel.
22
IBM xSeries 345 Type 8670: Option Installation Guide
The following illustration shows how to install a hot-swap hard disk drive.
Drive-tray assembly
Drive handle
Filler panel
Complete the following steps to install a drive in a hot-swap bay.
Attention: To maintain proper system cooling, do not operate the server for more
than 10 minutes without either a drive or a filler panel installed in each bay.
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11.
2. Remove the filler panel from one of the empty hot-swap bays by inserting your
finger into the depression at the left side of the filler panel and pulling it away
from the server.
3. Install the hard disk drive in the hot-swap bay:
a.
b.
c.
d.
e.
Ensure that the tray handle is open (that is, perpendicular to the drive).
Align the drive assembly with the guide rails in the bay.
Gently push the drive assembly into the bay until the drive stops.
Push the tray handle to the closed (locked) position.
Check the hard disk drive status LED to verify that the hard disk drive is
operating properly.
If the amber hard disk drive status LED for a drive is lit continuously, that
individual drive is faulty and needs to be replaced. If the green hard disk
drive activity LED is flashing, the drive is being accessed.
Note: If you have a RAID configuration on your server using the integrated
SCSI controller with RAID capabilities, or if your server has a RAID
adapter installed, you might need to reconfigure your disk arrays after
installing hard disk drives. See the RAID documentation on the IBM
xSeries Documentation CD for information about RAID adapters.
Installing memory modules
The following notes describe the types of dual inline memory modules (DIMMs) that
your server supports and other information that you must consider when installing
DIMMs:
v The system board contains four DIMM connectors and supports two-way memory
interleaving.
v The DIMM options available for your server are 256 MB, 512 MB, 1 GB, and 2
GB.
Chapter 2. Installing options
23
v The amount of usable memory will be reduced depending on the system
configuration. The BIOS will display the total amount of installed memory and the
amount of configured memory.
v Your server supports a minimum of two 256 MB DIMMs (for a total of 512 MB)
installed in the DIMM 1 and DIMM 2 memory connectors (J1 and J2,
respectively). When you install additional DIMMs, install them in pairs, with the
next pair in DIMM connectors 3 and 4 (J3 and J4).
v Both DIMMs in a pair must be the same size, speed, type, and technology. You
can mix compatible DIMMs from various manufacturers.
v The second pair of DIMMs do not have to be the same size, speed, type, and
technology as the first pair.
v Install only 2.5 V, 184-pin, double-data-rate (DDR), PC2100, registered
synchronous dynamic random-access memory (SDRAM) with error correcting
code (ECC) DIMMs. These DIMMs must be compatible with the latest PC2100
(and downward compatible with PC1600) SDRAM Registered DIMM
specification, which is available from http://www.jedec.org/ on the World Wide
Web. For a list of supported options for your server, go to
http://www.ibm.com/us/compat/ on the World Wide Web.
v Your server supports Chipkill™ technology, if the DIMMs are all of the type 4x.
v Save new configuration information only if you replace a faulty DIMM that was
marked as Disabled in the Configuration/Setup Utility program Memory Settings
menu. In this case, re-enable the memory row in the Configuration/Setup Utility
program or reload the default memory settings. See the User’s Guide on the IBM
xSeries Documentation CD for more information.
v Before you begin, read the documentation that comes with your option.
v Install the DIMMs in the order shown in the following table:
Table 3. DIMM order of installation
Pair
DIMM connectors
First
1 and 2 (J1, J2)
Second
3 and 4 (J3, J4)
The following illustration shows how to install DIMMs on the system board.
DIMM 3 (J3)
DIMM 4 (J4)
DIMM 1 (J1)
DIMM 2 (J2)
24
IBM xSeries 345 Type 8670: Option Installation Guide
Complete the following steps to install a DIMM:
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11.
2. Turn off the server and disconnect all power cords and external cables (see
“Turning off the server” on page 13); then, remove the server cover (see
“Removing the cover and bezel” on page 15).
3. Locate the DIMM connectors on the system board and determine the
connectors into which you will install the DIMMs.
4. Touch the static-protective package that contains the DIMM option to any
unpainted metal surface on the server. Then, remove the DIMM from the
package.
5. To install the DIMM, repeat the following steps for each DIMM that you install:
a. Turn the DIMM so that the DIMM keys align correctly with the connector on
the system board.
Attention: To avoid breaking the retaining clips or damaging the DIMM
connectors, handle the clips gently.
b. If closed, open the retaining clips; then, insert the DIMM by pressing the
DIMM straight into the connector. Be sure that the retaining clips snap into
the closed position.
Note: If a gap exists between the DIMM and the retaining clips, the DIMM
has not been properly installed. In this case, open the retaining clips
and remove the DIMM; then, reinsert the DIMM.
If you have other options to install or remove, do so now. Otherwise, go to
“Installing the server cover and bezel” on page 36.
Chapter 2. Installing options
25
Installing a microprocessor
The following notes describe the type of microprocessor that your server supports
and other information that you must consider when installing a microprocessor:
v Your server supports up to two microprocessors. With two microprocessors, your
server can operate as a symmetric multiprocessing (SMP) server. With SMP,
certain operating systems and application programs can distribute the processing
load between the microprocessors. If your server comes with one
microprocessor, you can install a second microprocessor.
v You might need to update the server BIOS code. Be sure to read the
documentation that comes with the microprocessor so that you can determine
whether you need to update the server BIOS code. You can download the latest
level of BIOS code and many other code updates for your server at
http://www.ibm.com/pc/support/ on the World Wide Web.
v (Optional) Obtain an SMP-capable operating system. For a list of supported
operating systems and other options, go to http://www.ibm.com/pc/us/compat/ on
the World Wide Web.
v To order additional microprocessor options, contact your IBM reseller or IBM
marketing representative.
v When you install the microprocessor in socket J6, you must also install the
voltage regulator module (VRM) that comes with the microprocessor in VRM
connector J5.
v The microprocessor speeds are automatically set for this server; therefore, you
do not need to set any microprocessor frequency-selection jumpers or switches.
v If you need to replace a microprocessor, call for service.
v If your server supports a 400 MHz front-side bus, install only a microprocessor
with one pin missing from one corner and two pins missing from an adjacent
corner. If your server supports a 400 MHz front-side bus, the heat-sink retention
mechanism surrounding the microprocessor connector is metallic gray.
400 MHz front-side bus
microprocessor
533 MHz front-side bus
microprocessor
If your server supports a 533 MHz front-side bus, install only a microprocessor
with one pin missing from each of two adjacent corners. If your server supports a
533 MHz front-side bus, the heat-sink retention mechanism surrounding the
microprocessor connector is black.
v If the thermal-grease protective cover (for example, a plastic cap or tape liner) is
removed from the heat sink or fan sink, do not touch the thermal grease on the
bottom of the heat sink or fan sink or set down the heat sink or fan sink.
Note: Removing the heat sink or fan sink from the microprocessor destroys the
even distribution of the thermal grease and requires replacing the thermal
grease. Setting down the heat sink or fan sink onto any surface when the
26
IBM xSeries 345 Type 8670: Option Installation Guide
thermal-grease protective cover is removed will contaminate the thermal
grease. If the thermal grease becomes contaminated with particles, it must
be replaced.
For information about replacing contaminated thermal grease on the heat sink or
fan sink, contact IBM Integrated Technology Services. For the most up-to-date
phone numbers, go to http://www.ibm.com/planetwide/, or in the U.S. and
Canada, call 1-800-IBM-SERV (1-800-426-7378).
Have the following information ready when you call:
– Machine type and model
– Serial number of your server or computer
v Do not remove the first microprocessor from the system board to install the
second microprocessor.
The following illustration is a simplified layout of the microprocessor connector
locations and other microprocessor-related components on the system board.
VRM 2 connector
(J5)
Microprocessor 2
(J6)
Microprocessor 1
(J7)
VRM 1 connector
(J8)
Note: For additional illustrations of the system-board components, see
“System-board option connectors” on page 4.
Chapter 2. Installing options
27
The following illustration shows how to install the second microprocessor on the
system board.
Captive screws
Heat sink
Microprocessor
VRM
Microprocessor
release lever
Attention:
v A startup (boot) processor must always be installed in socket J7 on the system
board.
v To ensure proper server operation when you install an additional microprocessor,
use microprocessors that have the same cache size and type, and the same
clock speed. Microprocessor internal and external clock frequencies must be
identical.
Complete the following steps to install an additional microprocessor:
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11.
2. Turn off the server and disconnect all power cords and external cables (see
“Turning off the server” on page 13); then, remove the server cover (see
“Removing the cover and bezel” on page 15).
3. Remove the air baffle covering the microprocessor section of the system board
and set the air baffle aside.
28
IBM xSeries 345 Type 8670: Option Installation Guide
4. Remove the air baffle from the empty microprocessor socket. Store it in a safe
place for future use. An empty microprocessor socket must contain an air baffle.
s™
ath c
P ti
t s
h o
ig n
L iag
D
R S
E IE
W PL
1 PO P
U
S
2
U
P
C
P
S
T
N
M
A
R
D
V
C
N N
E
O U
P
N ED
S
R
R
E
V
O
I
M
N
Y
R
O
M
E
M
D
S
A
D
M
R CH
/V T
U A
P M
C IS
M
A
B
D
IN
M
E
R
C
I
C
P US
B
N
FA
P
M
E
T
5. Install a VRM in the VRM connector (J5). See the illustration at the beginning of
these instructions for the location of the connectors:
a. Center the VRM over the connector. Make sure that the VRM is oriented
and aligned correctly.
b. Carefully but firmly push down the VRM to seat the VRM in the connector.
c. Insert one end of the retainer clip on the side of the connector and fit the
retainer clip over the VRM. Insert the free end of the retainer clip on the
other side of the connector.
6. Locate the second microprocessor socket (connector J6) on the system board.
Chapter 2. Installing options
29
7. Install the microprocessor:
a. Touch the static-protective package containing the microprocessor to any
unpainted metal surface on the server. Then, remove the microprocessor
from the package.
b. Remove the protective cover, tape, or label from the surface of the
microprocessor socket, if present.
Attention: You must ensure that the locking lever on the microprocessor
socket is in the fully open position before you insert the microprocessor in
the socket. Failure to do so might result in permanent damage to the
microprocessor, microprocessor socket, and system board.
c. Rotate the locking lever on the microprocessor socket from its closed and
locked position until it stops or clicks in the fully open position
(approximately 135° angle).
Lever fully
open
Lever closed
Attention:
v Do not use excessive force when pressing the microprocessor into the
socket.
v Make sure that the microprocessor is oriented and aligned correctly with
pin number 1 in the socket before you try to close the lever.
d. Center the microprocessor over the microprocessor socket. Align the triangle
on the corner of the microprocessor with the triangle on the corner of the
socket and carefully press the microprocessor into the socket.
Microprocessor 2
Alignment marks
Microprocessor
socket 2
e. Carefully close the microprocessor-release lever to secure the
microprocessor in the socket.
8. Install a heat sink on the microprocessor:
Attention:
v Do not set the heat sink down after you remove the plastic cover.
Thermal grease
Heat sink
30
IBM xSeries 345 Type 8670: Option Installation Guide
v Do not touch the thermal grease on the bottom of the heat sink or set down
the heat sink. Any contact with the thermal grease will contaminate it. For
details, see the thermal grease information on page 26.
a. Remove the plastic protective cover from the bottom of the heat sink.
b. Align and place the heat sink on top of the microprocessor with the thermal
grease side down. Press firmly on the heat sink.
Attention: If you do not alternate the tightening of the two captive screws,
you might damage the microprocessor. Ensure that the screws are
completely tightened; otherwise, the server will not function properly.
c. Alternate the tightening of the captive screws to secure the heat sink to the
microprocessor. Turn one screw a few turns and then turn the other screw a
few turns, alternating between the screws until the heat sink is secure.
9. Install the air baffle over the microprocessor section of the system board.
If you have other options to install or remove, do so now. Otherwise, go to
“Installing the server cover and bezel” on page 36.
Installing a hot-swap power-supply option
Your server supports a maximum of two hot-swap power supplies.
Statement 8
CAUTION:
Never remove the cover on a power supply or any part that has the following label
attached.
Hazardous voltage, current, and energy levels are present inside any component that
has this label attached. There are no serviceable parts inside these components. If you
suspect a problem with one of these parts, contact a service technician.
Chapter 2. Installing options
31
The following illustration shows how to install a power supply.
Power supply
Handle
(open position)
AC power
LED (green)
DC power
LED (green)
Power supply blank
(some models)
Complete the following steps to install a power supply:
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11.
2. (Some models) Remove the power-supply blank from the empty power-supply
bay by pinching the side clip and pulling the power-supply blank from the bay.
Save the power-supply blank in case you remove the power supply at a later
time.
Attention: During normal operation, each power-supply bay must have either
a power supply or power-supply blank installed for proper cooling.
3. Install the power supply in the bay:
a. Move the handle on the power supply into the open position, pinch the
side-clip, and slide the power supply into the chassis.
b. Gently close the handle to seat the power supply in the bay.
4. Plug the power cord for the new power supply into the power-cord connector on
the power supply.
The following illustration shows the power-supply connectors on the back of the
server.
Power supply 1
power cord connector
Power supply 2
power cord connector
5. Route the power cord through the cable-management arm. (See “Installing the
server in a rack” on page 36).
6. Plug the power cord into a properly grounded electrical outlet.
7. Verify that the dc power LED and ac power LED on the power supply are lit,
indicating that the power supply is operating correctly.
32
IBM xSeries 345 Type 8670: Option Installation Guide
Replacing a hot-swap fan
The following notes describe information that you must consider when installing a
hot-swap fan.
Attention: To ensure proper server operation, if a fan fails, replace it as soon as
possible.
v Your server supports a maximum of eight hot-swap fans.
v The following illustration shows the location of the hot-swap fans.
Fan 6
Fan 7
Fan 8
Fan 1
Fan 2
Fan 5
Fan 3
Fan 4
Fan LED
s™
ath c
P ti
t s
h o
ig n
L iag
D
R S
E IE
W PL
1 PO P
U
S
2
C
U
P
P
S
T
N
M
A
D
C
N N
E
O U
P
N ED
S
R
R
E
V
O
I
M
N
R
V
D
S
A
D
M
R CH
/V T
U A
P M
C IS
M
ME
MO
RY
A
B
D
IN
M
E
R
C
I
C
P US
B
N
FA
P
M
E
T
Complete the following steps to replace a hot-swap-fan:
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11.
2. Remove the cover. See “Removing the cover and bezel” on page 15. The LED
on the failing fan assembly will be lit.
Attention: To ensure proper system cooling, do not remove the top cover for
more than 30 minutes during this procedure.
3. Place your fingers into the two handles on the top of the failing fan.
4. Press the handles and lift the fan out of the server.
5. Orient the new fan so the LED on top of the fan is to the right of the server.
6. Push the replacement fan assembly into the server until it clicks into place.
7. Replace the cover. See “Installing the server cover and bezel” on page 36.
Chapter 2. Installing options
33
Replacing the battery
The following notes describe information that you must consider when replacing the
battery:
v IBM has designed this product with your safety in mind. The lithium battery must
be handled correctly to avoid possible danger. If you replace the battery, you
must adhere to the following instructions.
Note: In the U. S., call 1-800-IBM-4333 for information about battery disposal.
v If you replace the original lithium battery with a heavy-metal battery or a battery
with heavy-metal components, be aware of the following environmental
consideration. Batteries and accumulators that contain heavy metals must not be
disposed of with normal domestic waste. They will be taken back free of charge
by the manufacturer, distributor, or representative, to be recycled or disposed of
in a proper manner.
v To order replacement batteries, call 1-800-772-2227 within the United States, and
1-800-465-7999 or 1-800-465-6666 within Canada. Outside the U.S. and
Canada, call your IBM reseller or IBM marketing representative.
Note: After you replace the battery, you must reconfigure your server and reset
the system date and time.
Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has a
module containing a lithium battery, replace it only with the same module type made
by the same manufacturer. The battery contains lithium and can explode if not
properly used, handled, or disposed of.
Do not:
– Throw or immerse into water.
– Heat to more than 100° C (212° F)
– Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Complete the following steps to replace the battery:
1. Read the safety information beginning on page v, and “Installation guidelines”
on page 11.
2. Follow any special handling and installation instructions supplied with the
battery.
3. Turn off the server and all attached devices and disconnect all power cords
and external cables (see “Turning off the server” on page 13); then, remove the
server cover (see “Removing the cover and bezel” on page 15).
4. Remove the adapters from PCI slots 1 and 2 (see “Working with adapters” on
page 16).
5. Disconnect any internal cables, as necessary.
34
IBM xSeries 345 Type 8670: Option Installation Guide
6. Locate the battery (connector BH1) on the system board.
Battery
(BH1)
7. Remove the battery:
a. Use one finger to press the top of the battery clip away from the battery.
b. Lift and remove the battery from the socket.
8. Insert the new battery:
a. Use one finger to press the top of the battery clip away from the battery.
b. Press the battery into the socket until it clicks into place. Make sure the
battery clip holds the battery securely.
9. Reinstall the adapters that you removed, and reconnect the internal cables that
you disconnected.
10. Connect all external cables and all power cords.
11. Reinstall the server cover (see “Installing the server cover and bezel” on
page 36).
Chapter 2. Installing options
35
12. Start the Configuration/Setup Utility program and set configuration parameters
as needed. See the User’s Guide on the IBM xSeries Documentation CD for
additional information about using the Configuration/Setup Utility program.
Completing the installation
To complete your installation, reinstall the bezel, reinstall the server cover,
reconnect all cables that you disconnected earlier, and for certain options, run the
Configuration/Setup Utility program. Follow the instructions in this section.
Attention:
v For proper cooling and airflow, replace the server cover before or shortly after
turning on the server. Operating the server for extended periods of time (over 30
minutes) with the server cover removed might damage server components.
v To ensure proper server operation, do not remove the air-baffle assembly from
the server except when installing or removing the components that are located
under the air baffle.
Installing the server cover and bezel
The following illustration shows how to install the server cover and bezel.
Cover-release latch
Bezel
Complete the following steps to install the server cover:
1. Place the cover-release latch in the open (up) position.
2. Insert the bottom tabs of the top cover into the matching slots in the server
chassis.
3. Press down on the cover-release latch to lock the cover in place.
Complete the following steps to install the bezel:
1. Align the hooks on the bottom of the bezel with the server.
2. Press the bezel toward the server until it clicks into place.
Installing the server in a rack
Detailed cabling instructions for a typical rack server configuration are in the Rack
Installation Instructions that come with your server.
Updating your server configuration
When you start your server for the first time after you add or remove an internal
option or an external SCSI device, you might see a message telling you that the
36
IBM xSeries 345 Type 8670: Option Installation Guide
configuration has changed. The Configuration/Setup Utility program automatically
starts so that you can save the new configuration information. See the User’s Guide
on the IBM xSeries Documentation CD for more information about the
Configuration/Setup Utility program.
Some options have device drivers that you need to install. See the documentation
that comes with your option for information about installing any required device
drivers.
Your server comes with one or two microprocessors installed on the system board.
If your server comes with two microprocessors or if your server comes with one
microprocessor and you have installed an additional microprocessor, your server
can now operate as an SMP server. Therefore, you might need to upgrade your
operating system to support SMP. See the User’s Guide on the IBM xSeries
Documentation CD and your operating-system documentation for additional
information.
If you have a RAID configuration on your server using the integrated SCSI
controller or if your server has a RAID controller installed, and you have installed or
removed a hard disk drive, you might need to reconfigure your disk arrays. See the
RAID documentation on the IBM xSeries Documentation CD for information about
reconfiguring your disk arrays.
To have SCSI capabilities if you remove the ServeRAID-5i controller or other RAID
controller, start the Configuration/Setup Utility program and select Devices and I/O
Ports from the main menu to enable the SCSI controller with RAID capabilities. See
the User’s Guide on the IBM xSeries Documentation CD for details about using the
Configuration/Setup Utility program.
Connecting external options
If you install a SCSI adapter or use the external SCSI connector, you can attach
external SCSI devices, such as a SCSI storage expansion enclosure, to your
server. You can attach additional external options to the other input/output (I/O)
connectors on the front and rear of your server. (See Chapter 3, “Input/output
connectors”, on page 39 for more information.)
Complete the following steps to attach an external device:
1. Read the safety information beginning on page v, and “Installation guidelines” on
page 11. Also, read the documentation that comes with your options.
2. Turn off the server and all attached devices (see “Turning off the server” on
page 13).
3. Follow the instructions that come with the option to prepare it for installation and
to connect it to the server.
Note: If you are attaching an external SCSI device, see “Ultra320 SCSI controller
system-board connectors” on page 41 for information about SCSI cabling
and SCSI IDs.
Cabling the server
Notes:
1. You must turn off the server (see “Turning off the server” on page 13) before
connecting any cables to or disconnecting any cables from the server.
Chapter 2. Installing options
37
2. See the documentation that comes with your options for additional cabling
instructions. It might be easier for you to route cables before you install certain
options.
3. Cable identifiers are printed on the cables that come with your server and
options. Use these identifiers to connect the cables to the correct connectors.
The following illustrations show the locations of the input and output connectors on
your server.
Rear view
Mouse
Universal Serial Bus (USB)
1 and 2
Serial
Video
Keyboard
RS 485-A
(ISMP)
RS 485-B
Ethernet 2
(ISMP)
Ethernet 1
Front view
USB 3
38
IBM xSeries 345 Type 8670: Option Installation Guide
SCSI
Chapter 3. Input/output connectors
Your server has the following input/output (I/O) connectors:
v One auxiliary-device (pointing device)
v Two Ethernet
v Two integrated system management (RS-485)
v One keyboard
v One serial
v One Ultra320 SCSI controller (LVD) SCSI
v Three Universal Serial Bus (USB) version 1.1 (USB 1 and USB 2 on the rear,
USB 3 on the front)
v One video
The following illustrations show the locations of these connectors.
Rear view
Mouse
Universal Serial Bus (USB)
1 and 2
Serial
Video
Keyboard
RS 485-A
(ISMP)
RS 485-B
Ethernet 2
(ISMP)
Ethernet 1
SCSI
Front view
USB 3
The following sections describe these connectors.
If you have an optional Remote Supervisor Adapter (system-management adapter)
installed in PCI slot 5, your server also has an additional Ethernet connector, an
additional serial connector, and an Advanced System Management (ASM)
Interconnect connector. See the documentation that comes with the Remote
Supervisor Adapter for more information about the ASM Interconnect network.
© Copyright IBM Corp. 2003
39
Auxiliary-device (pointing device) connector
Use this connector to connect a mouse or other pointing device. The following
illustration shows an auxiliary-device connector.
6
5
4
3
2
1
Ethernet connectors
The following illustration shows an Ethernet connector.
8
1
Connect a Category 3, 4, or 5 unshielded twisted-pair cable to this connector.
100BASE-TX and 1000BASE-T Fast Ethernet standards require Category 5 or
higher cabling.
See the User’s Guide on the IBM xSeries Documentation CD for more information
about the Ethernet controller.
Integrated system management processor (ISMP) interconnect ports
The integrated system management processor (ISMP) ports (RS-485 A and B) use
a dual RJ-45 connector to interconnect ISMPs of several servers through an
optional Remote Supervisor Adapter.
Note: ISMP ports (RS-485 A and B) are used for the RS-485 interconnect network
communications. These ports become inactive if you install an optional IBM
Remote Supervisor Adapter in this server. If you install an optional IBM
Remote Supervisor Adapter, you must use the RJ-45 connector on the
adapter for interconnect network communications.
Keyboard connector
Use this connector to connect a PS/2 (non-USB) keyboard to the server. The
following illustration shows a keyboard connector.
6
5
4
3
2
1
If you attach a keyboard to this connector, USB ports and devices are disabled
during POST.
40
IBM xSeries 345 Type 8670: Option Installation Guide
Serial connector
Use a serial connector to connect a serial device. The following illustration shows a
serial connector.
5
1
6
9
Ultra320 SCSI controller system-board connectors
The integrated dual channel small computer system interface (SCSI) controller with
RAID capabilities supports two independent Ultra320 SCSI channels: one external
and one internal. Each channel supports up to 15 SCSI devices. You can use the
external LVD SCSI channel connector on the rear of your server to connect different
types of SCSI devices, such as drives or printers. This controller uses:
v Double-transition clocking to achieve up to 320 MB-per-second data-transfer
rates
v Domain name validation to negotiate compatible data-transfer speeds with each
device
v Cyclic redundancy checking (CRC), instead of the usual parity checking, to
improve data reliability
v An active terminator for SCSI bus termination
The server comes with one SCSI cable, which connects the internal connector on
the system board to the standard hot-swap-drive backplane. If you plan to attach
external SCSI devices, you must order additional cables. To select and order the
correct cables for use with external devices, contact your IBM reseller or IBM
marketing representative.
SCSI cabling requirements
For information about the maximum length of SCSI cable, go to the American
National Standards Institute (ANSI) SCSI standards on the ANSI Web site at
http://www.ansi.org/ on the World Wide Web. Adhering to these standards will help
to ensure that your server operates properly.
SCSI IDs
Each SCSI device that is connected to a SCSI controller must have a unique SCSI
ID. This ID enables the SCSI controller to identify the device and ensure that
different devices on the same SCSI channel do not attempt to transfer data
simultaneously. SCSI devices that are connected to different SCSI channels can
have duplicate SCSI IDs. Table 4 lists the SCSI IDs for the hard disk drives and
backplanes that are connected to one channel.
Table 4. SCSI IDs for standard hot-swap hard disk drives, controller, and backplane
Device
SCSI ID
Drive bay 1
0
Drive bay 2
1
Drive bay 3
2
Drive bay 4
3
Drive bay 5
4
Drive bay 6
5
Chapter 3. Input/output connectors
41
Table 4. SCSI IDs for standard hot-swap hard disk drives, controller, and
backplane (continued)
Device
SCSI ID
Controller
7
Backplane
8
The hot-swap-drive backplane controls the SCSI IDs for the internal hot-swap drive
bays. However, when you attach an external SCSI device to an optional SCSI
adapter, you must set a unique ID for the device. See the information that comes
with the device for instructions to set its SCSI ID.
SCSI connector
The following illustration shows a SCSI connector.
34
1
68
35
Universal Serial Bus version 1.1 connectors
Use a Universal Serial Bus (USB) connector to connect a USB device. USB
technology transfers data at up to 12 Mb per second (Mbps) with a maximum of
127 devices and a maximum signal distance of 5 meters (16 ft) per segment. Using
Plug and Play technology, USB devices are configured automatically. The following
illustration shows a USB connector.
1
4
Use a 4-pin cable to connect a device to a USB connector. If you need to connect
more USB devices than the server has USB connectors for, use a USB hub to
connect additional devices.
If you connect a PS/2 (non-USB) keyboard to the keyboard connector, USB ports
and devices are disabled during POST.
If you connect a USB keyboard that has a mouse port, the keyboard emulates a
mouse, and you cannot disable the mouse settings in the Configuration/Setup Utility
program.
Video connector
The integrated super video graphics array (SVGA) video controller is not removable,
but you can disable it through the Configuration/Setup Utility program or by
installing a PCI video adapter.
Note: If you install a PCI video adapter, the server BIOS will automatically disable
the integrated video controller.
42
IBM xSeries 345 Type 8670: Option Installation Guide
The following illustration shows a video connector.
5
1
15
11
Chapter 3. Input/output connectors
43
44
IBM xSeries 345 Type 8670: Option Installation Guide
Appendix. Notices
This information was developed for products and services offered in the U.S.A.
IBM may not offer the products, services, or features discussed in this document in
other countries. Consult your local IBM representative for information on the
products and services currently available in your area. Any reference to an IBM
product, program, or service is not intended to state or imply that only that IBM
product, program, or service may be used. Any functionally equivalent product,
program, or service that does not infringe any IBM intellectual property right may be
used instead. However, it is the user’s responsibility to evaluate and verify the
operation of any non-IBM product, program, or service.
IBM may have patents or pending patent applications covering subject matter
described in this document. The furnishing of this document does not give you any
license to these patents. You can send license inquiries, in writing, to:
IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. Some states do not allow disclaimer of express or
implied warranties in certain transactions, therefore, this statement may not apply to
you.
This information could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the publication. IBM may make improvements and/or
changes in the product(s) and/or the program(s) described in this publication at any
time without notice.
Any references in this information to non-IBM Web sites are provided for
convenience only and do not in any manner serve as an endorsement of those
Web sites. The materials at those Web sites are not part of the materials for this
IBM product, and use of those Web sites is at your own risk.
IBM may use or distribute any of the information you supply in any way it believes
appropriate without incurring any obligation to you.
Edition notice
© COPYRIGHT INTERNATIONAL BUSINESS MACHINES CORPORATION, 2003.
All rights reserved.
Note to U.S. Government Users Restricted Rights — Use, duplication or disclosure
restricted by GSA ADP Schedule Contract with IBM Corp.
© Copyright IBM Corp. 2003
45
Trademarks
The following terms are trademarks of International Business Machines Corporation
in the United States, other countries, or both:
Active Memory
Active PCI
Active PCI-X
Alert on LAN
C2T Interconnect
Chipkill
EtherJet
e-business logo
Eserver
FlashCopy
IBM
IntelliStation
Light Path Diagnostics
NetBAY
Netfinity
NetView
OS/2 WARP
Predictive Failure
Analysis
PS/2
ServeRAID
ServerGuide
ServerProven
TechConnect
Tivoli
Tivoli Enterprise
Update Connector
Wake on LAN
XA-32
XA-64
X-Architecture
XceL4
XpandOnDemand
xSeries
Lotus, Lotus Notes, SmartSuite, and Domino are trademarks of Lotus Development
Corporation and/or IBM Corporation in the United States, other countries, or both.
ActionMedia, LANDesk, MMX, Pentium, ProShare, and Xeon are trademarks of
Intel Corporation in the United States, other countries, or both.
Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in
the United States, other countries, or both.
UNIX is a registered trademark of The Open Group in the United States and other
countries.
Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States, other countries, or both.
Linux is a registered trademark of Linus Torvalds.
Other company, product, or service names may be trademarks or service marks of
others.
Important notes
Processor speeds indicate the internal clock speed of the microprocessor; other
factors also affect application performance.
CD-ROM drive speeds list the variable read rate. Actual speeds vary and are often
less than the maximum possible.
46
IBM xSeries 345 Type 8670: Option Installation Guide
When referring to processor storage, real and virtual storage, or channel volume,
KB stands for approximately 1000 bytes, MB stands for approximately 1 000 000
bytes, and GB stands for approximately 1 000 000 000 bytes.
When referring to hard disk drive capacity or communications volume, MB stands
for 1 000 000 bytes, and GB stands for 1 000 000 000 bytes. Total user-accessible
capacity may vary depending on operating environments.
Maximum internal hard disk drive capacities assume the replacement of any
standard hard disk drives and population of all hard disk drive bays with the largest
currently supported drives available from IBM.
Maximum memory may require replacement of the standard memory with an
optional memory module.
IBM makes no representation or warranties regarding non-IBM products and
services that are ServerProven®, including but not limited to the implied warranties
of merchantability and fitness for a particular purpose. These products are offered
and warranted solely by third parties.
IBM makes no representations or warranties with respect to non-IBM products.
Support (if any) for the non-IBM products is provided by the third party, not IBM.
Some software may differ from its retail version (if available), and may not include
user manuals or all program functionality.
Product recycling and disposal
This unit contains materials such as circuit boards, cables, electromagnetic
compatibility gaskets, and connectors which may contain lead and copper/beryllium
alloys that require special handling and disposal at end of life. Before this unit is
disposed of, these materials must be removed and recycled or discarded according
to applicable regulations. IBM offers product-return programs in several countries.
For country-specific instructions, refer to the following Web site:
http://www.ibm.com/ibm/environment/products/prp.shtml.
This product may contain a sealed lead acid, nickel cadmium, nickel metal
hydride, lithium, or lithium ion battery. Consult your user manual or service
manual for specific battery information. The battery must be recycled or
disposed of properly. Recycling facilities may not be available in your area.
For information on disposal of batteries, contact your local waste disposal
facility.
In the United States, IBM has established a collection process for reuse, recycling,
or proper disposal of used IBM sealed lead acid, nickel cadmium, nickel metal
hydride, and battery packs from IBM equipment. For information on proper disposal
of these batteries, contact IBM at 1-800-426-4333. Have the IBM part number listed
on the battery available prior to your call.
Electronic emission notices
Federal Communications Commission (FCC) statement
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
Appendix. Notices
47
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be required to correct the
interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to
meet FCC emission limits. Properly shielded and grounded cables and connectors
must be used in order to meet FCC emission limits.IBM is not responsible for any
radio or television interference causedby using other than recommended cables and
connectors or by using other than recommended cables and connectors or by
unauthorized changes or modifications to this equipment. Unauthorized changes or
modifications could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Industry Canada Class A emission compliance statement
This Class A digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d’Industrie Canada
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
Australia and New Zealand Class A statement
Attention: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
United Kingdom telecommunications safety requirement
Notice to Customers
This apparatus is approved under approval number NS/G/1234/J/100003 for indirect
connection to public telecommunication systems in the United Kingdom.
European Union EMC Directive conformance statement
This product is in conformity with the protection requirements of EU Council
Directive 89/336/EEC on the approximation of the laws of the Member States
relating to electromagnetic compatibility. IBM cannot accept responsibility for any
failure to satisfy the protection requirements resulting from a nonrecommended
modification of the product, including the fitting of non-IBM option cards.
This product has been tested and found to comply with the limits for Class A
Information Technology Equipment according to CISPR 22/European Standard EN
55022. The limits for Class A equipment were derived for commercial and industrial
environments to provide reasonable protection against interference with licensed
communication equipment.
48
IBM xSeries 345 Type 8670: Option Installation Guide
Attention: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
Taiwanese Class A warning statement
Chinese Class A warning statement
Japanese Voluntary Control Council for Interference (VCCI) statement
Power cords
For your safety, IBM provides a power cord with a grounded attachment plug to use
with this IBM product. To avoid electrical shock, always use the power cord and
plug with a properly grounded outlet.
IBM power cords used in the United States and Canada are listed by Underwriter’s
Laboratories (UL) and certified by the Canadian Standards Association (CSA).
For units intended to be operated at 115 volts: Use a UL-listed and CSA-certified
cord set consisting of a minimum 18 AWG, Type SVT or SJT, three-conductor cord,
a maximum of 15 feet in length and a parallel blade, grounding-type attachment
plug rated 15 amperes, 125 volts.
For units intended to be operated at 230 volts (U.S. use): Use a UL-listed and
CSA-certified cord set consisting of a minimum 18 AWG, Type SVT or SJT,
Appendix. Notices
49
three-conductor cord, a maximum of 15 feet in length and a tandem blade,
grounding-type attachment plug rated 15 amperes, 250 volts.
For units intended to be operated at 230 volts (outside the U.S.): Use a cord set
with a grounding-type attachment plug. The cord set should have the appropriate
safety approvals for the country in which the equipment will be installed.
IBM power cords for a specific country or region are usually available only in that
country or region.
50
IBM power cord part
number
Used in these countries and regions
02K0546
China
13F9940
Australia, Fiji, Kiribati, Nauru, New Zealand, Papua New Guinea
13F9979
Afghanistan, Albania, Algeria, Andorra, Angola, Armenia, Austria,
Azerbaijan, Belarus, Belgium, Benin, Bosnia and Herzegovina,
Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon, Cape
Verde, Central African Republic, Chad, Comoros, Congo
(Democratic Republic of), Congo (Republic of), Cote D’Ivoire
(Ivory Coast), Croatia (Republic of), Czech Republic, Dahomey,
Djibouti, Egypt, Equatorial Guinea, Eritrea, Estonia, Ethiopia,
Finland, France, French Guyana, French Polynesia, Germany,
Greece, Guadeloupe, Guinea, Guinea Bissau, Hungary, Iceland,
Indonesia, Iran, Kazakhstan, Kyrgyzstan, Laos (People’s
Democratic Republic of), Latvia, Lebanon, Lithuania, Luxembourg,
Macedonia (former Yugoslav Republic of), Madagascar, Mali,
Martinique, Mauritania, Mauritius, Mayotte, Moldova (Republic of),
Monaco, Mongolia, Morocco, Mozambique, Netherlands, New
Caledonia, Niger, Norway, Poland, Portugal, Reunion, Romania,
Russian Federation, Rwanda, Sao Tome and Principe, Saudi
Arabia, Senegal, Serbia, Slovakia, Slovenia (Republic of),
Somalia, Spain, Suriname, Sweden, Syrian Arab Republic,
Tajikistan, Tahiti, Togo, Tunisia, Turkey, Turkmenistan, Ukraine,
Upper Volta, Uzbekistan, Vanuatu, Vietnam, Wallis and Futuna,
Yugoslavia (Federal Republic of), Zaire
13F9997
Denmark
14F0015
Bangladesh, Lesotho, Maceo, Maldives, Namibia, Nepal,
Pakistan, Samoa, South Africa, Sri Lanka, Swaziland, Uganda
14F0033
Abu Dhabi, Bahrain, Botswana, Brunei Darussalam, Channel
Islands, China (Hong Kong S.A.R.), Cyprus, Dominica, Gambia,
Ghana, Grenada, Iraq, Ireland, Jordan, Kenya, Kuwait, Liberia,
Malawi, Malaysia, Malta, Myanmar (Burma), Nigeria, Oman,
Polynesia, Qatar, Saint Kitts and Nevis, Saint Lucia, Saint Vincent
and the Grenadines, Seychelles, Sierra Leone, Singapore, Sudan,
Tanzania (United Republic of), Trinidad and Tobago, United Arab
Emirates (Dubai), United Kingdom, Yemen, Zambia, Zimbabwe
14F0051
Liechtenstein, Switzerland
14F0069
Chile, Italy, Libyan Arab Jamahiriya
14F0087
Israel
IBM xSeries 345 Type 8670: Option Installation Guide
IBM power cord part
number
Used in these countries and regions
1838574
Antigua and Barbuda, Aruba, Bahamas, Barbados, Belize,
Bermuda, Bolivia, Brazil, Caicos Islands, Canada, Cayman
Islands, Costa Rica, Colombia, Cuba, Dominican Republic,
Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras,
Jamaica, Japan, Mexico, Micronesia (Federal States of),
Netherlands Antilles, Nicaragua, Panama, Peru, Philippines,
Taiwan, United States of America, Venezuela
24P6858
Korea (Democratic People’s Republic of), Korea (Republic of)
34G0232
Japan
36L8880
Argentina, Paraguay, Uruguay
49P2078
India
49P2110
Brazil
6952300
Antigua and Barbuda, Aruba, Bahamas, Barbados, Belize,
Bermuda, Bolivia, Caicos Islands, Canada, Cayman Islands,
Colombia, Costa Rica, Cuba, Dominican Republic, Ecuador, El
Salvador, Guam, Guatemala, Haiti, Honduras, Jamaica, Mexico,
Micronesia (Federal States of), Netherlands Antilles, Nicaragua,
Panama, Peru, Philippines, Saudi Arabia, Thailand, Taiwan,
United States of America, Venezuela
Appendix. Notices
51
52
IBM xSeries 345 Type 8670: Option Installation Guide
Index
A
D
adapter
boot option 16
considerations 16
installing
non-hot-plug 18
RAID 21
PCI bus, identification 16
retention bracket 3
support bracket 3
Advanced System Management ports
air-baffle assembly
illustration 3
auxiliary-device port 40
DIMM.
See memory module
drive
hot-swap
installing 23
internal 22
E
40
B
battery
connector 4
replacing 34
bezel
installing 36
C
cable
connectors 5, 6
routing 38
SCSI 41
cabling
external 38, 41
system-board external connectors 6
system-board internal connectors 5
the server 38
Class A electronic emission notice 47
components
major 3
system board 4
configuration
hardware, cabling for 36
updating 36
connectors
adapter 4
battery 4
cable 5
Ethernet 40
external port 6
internal cable 5
memory 4
microprocessor 4
port 6
SCSI 41
system board 4
system-board switch block 7
Universal Serial Bus 42
VRM 4
© Copyright IBM Corp. 2003
electrical safety information viii
electronic emission Class A notice
Ethernet connector 40
external
cabling 38
devices, connecting 37
47
F
fan, replacing 33
FCC Class A notice 47
filler panel
hard disk drive bay 23
H
handling
static-sensitive devices 11
hot-swap and hot-plug devices
drives 3, 23
fans 3, 33
power supplies 31
hot-swap drive
installing 23
hot-swap fan, replacing 33
hot-swap power supply
installing 31
hub 42
I
installation order
memory modules 24
installing
bezel 36
hot-swap drive 23
hot-swap fan 33
hot-swap power supply 31
memory module 23
microprocessor 26
non-hot-plug adapter 18
options 11
RAID adapter 21
VRM 29
53
K
keyboard port
port
Advanced System Management 40
auxiliary-device 40
connectors 6
input/output 39
keyboard 40
parallel 42
pointing device 40
serial 41
Universal Serial Bus 42
power cords 49
power supply
installing 31
operating requirements 31
power-on password override switch 8
40
L
LEDs
CPU 10
DASD 10
FAN 10
MEMORY 10
NMI 10
NONREDUNDANT 10
PCI BUS 10
POWER SUPPLY 1 10
POWER SUPPLY 2 10
SERVICE PROCESSOR BUS
system board 9
TEMPERATURE 10
VRM 10
10
M
memory module
installing 23
order of installation
supported 23
microprocessor
heat sink 30
installing 26
VRM 29
47
O
options
external
cabling requirements
connecting 37
installing 11
order of installation
memory modules 24
41
P
PCI
bus A 16
bus B 16
bus C 16
pointing device port
54
rack, installing server in
related publications 1
replacing
battery 34
hot-swap fan 33
36
S
24
N
notes, important 46
notices
attention 2
book 2
caution 2
danger 2
electronic emission
FCC, Class A 47
important 2
R
40
IBM xSeries 345 Type 8670: Option Installation Guide
safety information
electrical vi, viii
laser vii
lifting vii
SCSI
adapter boot option 16
cable
external devices 41
maximum length 41
IDs 41
SCSI connector
description 41
location 5
SCSI controller 41
serial port 41
Standby mode 13
statements
attention 2
caution 2
danger 2
important 2
static electricity 11
static-sensitive devices
handling 11
switch
power-on password override 8
switch block 7
system board
connectors
user-installable options 4
LEDs 9
switch block 7
system reliability 11
system-board
connectors
external port 6
internal cable 5
SCSI 5, 41
T
thermal material
heat sink 31
trademarks 46
turning off the server 13
turning on the server 13
U
United States electronic emission Class A notice
United States FCC Class A notice 47
Universal Serial Bus connector 42
Universal Serial Bus port 42
47
V
video port 42
voltage regulator module
installing 29
VRM
See voltage regulator module
W
Web site
SCSI standards 41
working inside server with power on
11
