WorkPad 2MB Upgrade Features
Activating WorkPad Mail
Contacts
• Store more data: up to 6000 addresses, 5 years of appointments, 1500 to do items,
1500 memos, and 200 e-mails on your WorkPad.
Read and manage your e-mail
Technical Support
Read, reply, compose and delete e-mail messages on your connected WorkPad. Use HotSync®
technlogy to synchronize with the e-mail application on your computer.
To register your WorkPad and to receive your personalized registration number prior
to receiving technical support, refer to the Registration Number listing. If you need
assistance installing the WorkPad 2MB Upgrade or using your WorkPad, refer to the
Support Number listing.
WorkPad Mail is compatible with
many popular e-mail applications*
Country/Language
Registration Number
Support Number
Austria/German
01-54658-5075
01-54658-5060
• Eudora 3.0.3 or higher
Belgium/Flemish
02-717-2504
02-714-3570
Belgium/French
02-717-2503
02-714-3515
Canada
1-800-565-3344
1-800-565-3344
Denmark/Danish
03-525-6905
03-525-0291
Finland/Finnish
9-22-931805
9-22-931840
France/French
01-6932-4003
01-6932-4040
Germany/German
069-6654-9003
069-6654-9040
Ireland/English
01-815-9207
01-667-1845
Italy/Italian
02-482-75003
02-482-75040
Netherlands/Dutch
020-504-0531
020-504-0501
Norway/Norwegian
02-305-3203
02-305-3240
Portugal/Lisboa
0034-1-662-4270
01-791-5147
Portugal/Porto
0034-1-662-4270
02-207-1147
Puerto Rico
1-800-772-2227
1-800-772-2227
Spain/Spanish
91-662-4270
91-662-4916
Sweden/Swedish
08-632-0063
08-751-5227
Switzerland/German
01-212-1810
0848-805252
Switzerland/French
022-310-0418
0848-805252
Switzerland/Italian
091-971-0523
0800-806030
WorkPad 2MB Upgrade Installation Guide
United Kingdom/Enlish
01475-555555
01475-555055
For the Wo r k P a d - 1 0 U
United States/English
1-800-772-2227
1-800-772-2227
• Take advantage of the latest application improvements using the Palm OS™ 3.0
(preinstalled on the memory card).
• Upgrade to future releases of the Palm OS using Flash Memory without replacing
the memory card.
• Lotus cc:Mail versions 7.0, 6.0 and 2.5
• Microsoft Exchange 4.0 or higher
• Microsoft Outlook 97
“Beam” addresses, events, categories
and applications using the infrared port.
• Microsoft Outlook Express
• Microsoft Windows Messaging 4.0
Enter expense data while on
the road, then with one touch,
transfer your expenses to a
Microsoft Excel spreadsheet.
Choose larger fonts in the
Options menu to make the
screen easier to read.
See the WorkPad manuals for step-by-step instructions.
Read and compose
e-mail while away from
your desk and set Mail’s
HotSync® option to download only unread messages.
Install WorkPad Mail at your convenience
To set up your WorkPad Mail application, just click the Windows Start menu, select Programs
and WorkPad Desktop, and then select WorkPad Mail Setup. The instructions will guide you
through the setup process. To learn more about the WorkPad Mail application, see the “Mail”
chapter in the Applications Handbook for the WorkPad.
Specify alarm sounds
and time intervals using
new alarm options.
See the Accessory Catalog for information on the optional modem.
Note: In other countries, contact you IBM reseller or IBM marketing representative.
Copyright ©1998 3Com Corporation or its subsidiaries. All rights reserved. 3Com, Palm Computing, Graffiti, and HotSync
are registered trademarks, and Palm Computing platform logo is a trademark of Palm Computing, Inc., 3Com Corporation
or its subsidiaries. The following are registered trademarks of International Business Machines Corporation in the United
States and/or other countries: IBM and WorkPad. Other company, product and service brand names may be trademarks,
® service marks or registered trademarks of their respective owners. Printed in USA. P/N: 423-0224-16
®
Your PC Companion
Contents
• WorkPad 2MB Upgrade memory card
• New memory door with infrared support
• WorkPad Desktop organizer software CD-ROM (for PC only)
• Basic Handbook for the WorkPad
• Applications Handbook for the WorkPad
• Installation Guide
WorkPad2MBBack
4/28/98 11:15 AM
Page 1
I. Install the WorkPad Desktop Software
The WorkPad 2MB Upgrade includes a new memory card, a new memory door with
an infrared window for your WorkPad and new WorkPad Desktop software for your
PC*. Just follow these simple instructions to install the software on your PC first and
then install the memory card in your organizer. In just minutes you'll be ready to
enjoy all the new WorkPad 2MB Upgrade features.
Protect your data! Complete all steps in the order listed or you may lose your
user data.
1.
Removing the current memory card from your WorkPad deletes your add-on software
applications. You will need to reinstall your add-on software applications after you
install the new memory card.
III. Install the WorkPad 2MB Upgrade Memory Card
1.
Remove the WorkPad 2MB Upgrade memory card
from its bag.
2.
Firmly insert the card into the socket making
sure the notch is in the lower left corner.
IV. Transfer Your Data to Your WorkPad
1.
Perform a Soft Reset by pressing the reset button
on the back of your WorkPad with a paper clip.
1.
Turn off your WorkPad and remove the battery door and batteries from the back of
your WorkPad.
2.
Remove any static electricity from your body by touching a grounded metal object,
such as the bare metal case on the back of your computer.
2.
Calibrate the screen by tapping the targets with
the stylus and set the time and date.
3.
Remove the memory door by pushing on
the foot in the upper-right corner. If it is
difficult to remove, gently insert a paper
clip into the memory door release hole
while pushing on the foot.
3.
Perform a HotSync® operation to transfer your user data from the WorkPad Desktop
software to your WorkPad. Select your user name when prompted.
4.
After the HotSync operation, tap the reset button on your WorkPad screen.
5.
Reinstall any add-on software applications.
Insert your WorkPad in the cradle and press the HotSync® button to back up your data.
2.
Remove your WorkPad from the cradle.
3.
Insert the WorkPad Desktop software CD into your CD-ROM drive and click the
Install button. When the WorkPad Desktop Installer menu appears, follow the
instructions on the screen to install the software.
4.
II. Remove Your Existing Memory Card
3.
Press the top corners of the card until
the clips snap in place.
Perform a HotSync operation to complete the WorkPad Desktop software
installation process.
4.
Note: Windows NT users need write privileges to install the software and
must install it in their user account, not in the administrator account.
Release the memory card by sliding one
of the metal or white plastic clips towards
the side of your WorkPad while gently
lifting the card until it clears the clip.
Repeat this step with the other clip.
4.
5.
* Macintosh systems are not supported.
Remove the memory card from its socket by
gently rocking it from side to side as you pull
the card away from the socket.
5.
Slide the new memory door over the memory
compartment. Do not use the old memory
door; it will damage the new memory
card.
Congratulations!
You’ve completed the WorkPad Desktop software and 2MB Upgrade installation.
Read on for a quick overview of the new features. For additional information,
consult the Basic Handbook and the Applications Handbook.
Replace the batteries making sure the positive (+)
and negative (-) ends are in the correct position,
and then replace the battery door.
Note: Your WorkPad will not work until you reset it as described on panel IV.
See back to learn more
