P

REFACE

Thank you for purchasing the TV-IP110/TV-IP110W Wire/Wireless

Internet Camera Server, a powerful and high-quality image network camera.

The camera can be installed as a standalone system within your application environment easily and quickly, and supports remote management function so that you can access and control it using a Web browser on your PC.

This guide will provide you more information of instruction and illustrations on how to use your camera, which includes:

Chapter 1 Introduction to Your Camera describes the features of the camera. You will also know the components and functions of the camera.

Chapter 2 Hardware Installation helps you install the camera according to your application environment. You can use this camera at home, at work, at any where you want.

Chapter 3 Accessing the Camera lets you start using your camera without problem. The camera can be set up easily and work within your network environment instantly.

Chapter 4 Configuring the Camera guides you through the configuration of the camera using the web browser on your PC.

Chapter 5 Using SecurView™ shows you the detail instructions on operating SecurView™ software.

Chapter 6 Appendix provides the specification of the camera and some useful information for using your camera.

NOTE

The illustrations and configuration values in this guide are for reference only. The actual settings depend on your practical application of the camera.

- 1 -

Contents

PREFACE ......................................................................... 1



CHAPTER 1 ..................................................................... 4



INTRODUCTION TO YOUR CAMERA ............... 4



1.1



C

HECKING THE

P

ACKAGE

C

ONTENTS

................................... 4



TV-IP110 (F

RONT

/B

ACK

V

IEW

) .................................................... 5



TV-IP110W (F

RONT

/B

ACK

V

IEW

) ................................................. 6



1.3



F

EATURES AND

B

ENEFITS

..................................................... 8



1.4



S

YSTEM

R

EQUIREMENT

......................................................... 9



CHAPTER 2 ................................................................... 10



HARDWARE INSTALLATION .............................. 10



2.1



I

NSTALLING THE

C

AMERA

S

TAND

....................................... 10



2.2



C

ONNECTING THE

C

AMERA TO

LAN ................................... 11



2.3



A

PPLICATIONS OF THE

C

AMERA

.......................................... 12



CHAPTER 3 ................................................................... 13



ACCESSING THE CAMERA .................................. 13



3.1



U

SING

IP S

ETUP

.................................................................. 13



3.2



A

CCESSING TO THE

C

AMERA

............................................... 18



3.3



C

ONFIGURING THE

IP A

DDRESS OF THE

PC ........................ 21



CHAPTER 4 ................................................................... 22



CONFIGURING THE CAMERA ........................... 22



4.1



U

SING THE

W

EB

C

ONFIGURATION

...................................... 22



4.2



U

SING

S

MART

W

IZARD

....................................................... 23



4.3



B

ASIC

S

ETUP

....................................................................... 27



4.4



N

ETWORK

S

ETTINGS

........................................................... 31



4.5



S

ETTING UP

V

IDEO

.............................................................. 38



4.6



E

VENT

S

ERVER

C

ONFIGURATION

........................................ 41



4.7



M

OTION

D

ETECT

................................................................. 44



4.8



E

VENT

C

ONFIG

.................................................................... 46



4.9



T

OOLS

................................................................................. 51



4.10



I

NFORMATION

..................................................................... 53



CHAPTER 5 ................................................................... 54



- 2 -

SECURVIEW™ SOFTWARE .................................. 54



5.1



INSTALLATION ............................................................... 54



5.2



USING INSTALLATION .................................................. 59



I

TEM FEATURES

............................................................................ 59



T

O REMOVE A CAMERA

................................................................ 69



T

O LINK TO THE

W

EB PAGE OF THE CAMERA

............................... 70



T

O RECORD VIDEO

........................................................................ 71



T

O CONFIGURE THE RECORDING SETTINGS

................................... 76



T

O PLAYBACK THE RECORDED VIDEO

.......................................... 78



T

O SET UP MOTION DETECTION OPTIONS

...................................... 78



A

CCOUNT

..................................................................................... 81



O

THER

.......................................................................................... 81



I

NFORMATION

............................................................................... 82



CHAPTER 6 ................................................................... 83



APPENDIX ..................................................................... 83



A.1



S

PECIFICATION

.................................................................... 83



- 3 -

C

HAPTER

1

I

NTRODUCTION

T

O

Y

OUR

C

AMERA

1.1 Checking the Package Contents

Check the items contained in the package carefully. You should have the following:

5

TV-IP110/TV-IP110W Network Camera.

5

Multi-Language Quick Installation Guide

5

Utility CD-ROM

5

Detachable External Antenna (for TV-IP110W only)

5

Camera Stand

5

RJ-45 Ethernet Cable

5

AC Power Adapter (5VDC, 2.5A)

NOTE:

If there is any item damage or missing, please contact your local authorized deal for replacement.

- 4 -

1.2 Getting to Know Your Camera

TV-IP110 (Front/Back View)

- 5 -

TV-IP110W (Front/Back View)

- 6 -

- Power LED: A steady orange light indicates the camera is powered on.

-

Link LED: A flash green light indicates the camera’s network connection correctly.

-

Detachable Antenna (TV-IP110W only):

The detachable external antenna allows you to adjust its position to obtain the maximum signal.

-

Camera Stand Connection: Connects the camera with the camera stand.

-

Power Connector: Connects the AC power adapter to supply power to the camera.

-

LAN Port: It is used to connect the network RJ-45 cable, which supports the NWay protocol so that the camera can detect the network speed automatically.

-

Reset Button: Reset will be initiated when the reset button is pressed once. The power LED begins to flash.

Factory Reset will be initiated when the reset button is pressed continuously for three seconds or when Power LED begins to light up. Release the reset button and the Power LED will begin to flash.

- 7 -

1.3 Features and Benefits

„ Surveillance Supported

Enable motion detection and setup automated email alerts and upload

FTP for security.

„ Remote Control Supported

By using a standard Web browser or the bundled SecurView software application, the administrator can easily change the configuration of the camera via Intranet or Internet. In addition, the camera can be upgraded remotely when a new firmware is available. The users are also allowed to monitor the image and take snapshots via the network.

„ Multiple Platforms Supported

The camera supports multiple network protocols, including TCP/IP,

SMTP e-mail, HTTP, and other Internet related protocols. Therefore, you can use the camera in a mixed operating system environment, such as Windows 2000, XP, and Vista.

„ Multiple Applications Supported

Through the remote access technology, you can use the cameras to monitor various objects and places for your own purposes.

For example, babies at home, patients in the hospital, offices and banks, and more. The camera can capture both still images and video clips, so that you can keep the archives and restore them at any time.

- 8 -

1.4 System Requirement

„ Networking

LAN: 10Base-T Ethernet or 100Base-TX Fast Ethernet.

WLAN: IEEE 802.11b/g. (For TV-IP110W)

„ Accessing the Camera using Web Browser

Platform: Microsoft® Windows® 2000/XP/Vista

Macintosh OSX

CPU: Intel Pentium III 350MHz or above

RAM: 128MB

User Interface: Microsoft® Internet Explorer 6.0 or above

„ Accessing the Camera using SecurView

Platform: Microsoft® Windows® 2000/XP/Vista.

Hardware Requirement:

1 camera connected: Intel Pentium III 800MHz; 512MB RAM

2 ~ 4 cameras connected: Intel Pentium 4 1.3GHz; 512MB RAM

5 ~ 8 cameras connected: Intel Pentium 4 2.4GHz; 1GB RAM

9 ~ 16 cameras connected: Intel Pentium 4 3.4GHz; 2GB RAM

Resolution: 1024x768 or above

NOTE

If you connect multiple cameras to monitor various places simultaneously, you are recommended to use a computer with higher performance.

- 9 -

C

HAPTER

2

H

ARDWARE

I

NSTALLATION

2.1 Installing the Camera Stand

The camera comes with a camera stand, which uses a swivel ball screw head to lock to the camera’s screw hole. When the camera stand is attached, you can place the camera anywhere by mounting the camera through the three screw holes located in the base of the camera stand.

The Camera Stand

- 10 -

2.2 Connecting the Camera to LAN

Connects an Ethernet cable to the

LAN port located on the Camera’s real panel, and then attaches it to the network.

Connects an antenna to the antenna connector. (TV-IP110W)

Attach the external power supply to the DC power input connector located on Camera’s real Panel, and then connect it to your local power supply.

NOTE

Please configure the wireless setting via the wire connection.

- 11 -

2.3 Applications of the Camera

The camera can be applied in multiple applications, including:

„ Monitor local and remote places and objects via Internet or Intranet.

„ Capture still images and video clips remotely.

„ Upload images or send email messages with the still images attached.

The following diagram explains one of the typical applications for your camera and provides a basic example for installing the camera.

*

- 12 -

C

HAPTER

3

A

CCESSING THE

C

AMERA

3.1 Using IP Setup

The camera comes with a conveniently utility, IP Setup, which is included in the Installation CD-ROM, allowing you to search the camera on your network easily.

1. Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program.

2. Click the IP Setup from the Auto-Run menu screen. Then IP Setup

Wizard will appear. Click “Next” when the Welcome to the IPSetup

Setup Wizard appears.

- 13 -

3. Click “Browse” to choose the desired destination location. By default, the destination location is C:\Program Files\TRENDnet\IPSetup. Then

Click “Next”.

4. Click “Next” to confirm the IPSetup software to be installed to the computer.

5. When the Installation Complete window appears, click “Finish”.

- 14 -

6. After installing the IPSetup utility, the application is automatically installed to your computer, and creates a folder in “ Start

\Program\TRENDnet\IPSetup”.

7. Click Start > Programs > TRENDnet > IPSetup, and then click

IPSetup

8. The IPSetup window will appear. It will search the Camera within the same network.

- 15 -

Camera Display Area

-

Camera Display Area: It shows the connected camera(s) within the same network.

Double click the IP address; it will link to Camera’s Web Configuration page.

-

Change IP: Click this button to bring up the following window. It allows you to change the IP Address. You can select either Static IP or click DHCP. Then, enter the Administrator ID & password. By default ID/password is: admin. When complete, click “Change”.

- 16 -

-

Search

: Click this button to search the connected camera in the

same network.”

-

Exit

: Click this button to exit the program.

- 17 -

3.2 Accessing to the Camera

1. Open the Web browser on your computer (example showed in the

User’s Guide is based on the Internet Explorer)

2. Type the Camera IP address that DHCP server assigned in the web browser URL (e.g. 192.168.10.30) and then press [Enter].

3. When the login window appears, enter the default User name ( admin ) and password ( admin ) and press OK to access to the main screen of the camera’s Web Configuration.

- 18 -

NOTE

If you are initially access to the camera, you will be ask to install a new plug-in for the camera. Permission request depends on the

Internet security settings of your computer. Click Yes to proceed.

After you login into the Web Configuration of the camera, the main page will appear as below:

Camera Information

Zoom In

Live View/ Setup

Function

Live View Image

- 19 -

The main page of the Web Configuration provides you with many useful information and functions, including:

„ Camera Information

Display the camera’s location and the current date & time. The information can be modified in the Web

Configuration.

„ Live View Image

Displays the real-time image of the connected camera.

„ Zoom In

Click the buttons to zoom in the live view image by 1x, 2x, and 3x.

„ Live View/Setup Switch

Click Setup to configure the camera. For details, see Chapter 4.

„ Function

Use these buttons to control the video functions. z Manual Record allows you to record and save a video clip. z Snapshot allows you to capture and save a still image. z Browse allows assign the destination folder to store the video clips and still images.

- 20 -

3.3 Configuring the IP Address of the PC

If you are failed to access to the camera, please check the IP address of your computer. When you connect the camera to your computer directly to proceed with configuration of the camera, you need to set up the IP addresses to be in the same segment for the two devices to communicate.

1. On your computer, click Start > Control Panel to open the Control

Panel window.

2. Double-click Network Connection to open the Network Connection window.

3. Right-click Local Area Connection and then click Properties from the shortcut menu.

4. When the Local Area Connection Properties window appears, select the

General tab.

5. Select Internet Protocol [TCP/IP] and then click Properties to bring up the Internet Protocol [TCP/IP] Properties window.

6. To configure a fixed IP address that is within the segment of the camera, select the Use the following IP address option. Then, enter an IP address into the empty field.

7. When you are finished, click OK.

- 21 -

C

HAPTER

4

C

ONFIGURING THE

C

AMERA

4.1 Using the Web Configuration

You can access and manage the camera through the Web browser or from the SecurView™ software (see chapter 5 in more detail). This chapter describes the Web Configuration, and guides you through the configuration of the camera by using the web browser.

To configure the camera, click Setup on the main page of Web

Configuration. The Web Configuration will start from the Basic page.

- 22 -

The Web Configuration contains the settings that are required for the camera in the left menu bar, including Smart Wizard, Basic, Network,

Video, Event Server, Motion detect, Event Config, Tools, and

Information.

4.2 Using Smart Wizard

The camera’s Smart Wizard lets you configure your camera easily and quickly. The wizard will guide you through the necessary settings with detailed instructions on each step.

To start the wizard, click Smart Wizard in the left menu bar.

Step 1. Camera Settings

- 23 -

Step 2. IP Settings

Enter Camera

name, Location,

New Admin

password and enter again to

confirm Admin

password

Select the IP setting according to your network: DHCP,

Static IP, or PPPoE.

Step 3. Email Settings

- 24 -

Enter the required information to be able to send email with image.

Step 4. Wireless Networking (for TV-110W only)

Select Enable to enable the wireless function of the camera, and then complete the required settings.

- 25 -

Step 5. Confirm Settings

This step shows all the setting information.

This step shows the configuration of your camera. When you confirm the settings, click Apply to finish the wizard and reboot the camera. Otherwise, click Prev to go back to the previous step(s) and change the settings; or click Cancel to end the wizard and discard the changes.

- 26 -

4.3 Basic Setup

The Basic menu contains three sub-menus that provide the system settings for the camera, such as the Camera Name, Location, Date & Time, and User management.

Basic >> System

- 27 -

„ Basic

- Camera Name: Enter a descriptive name for the camera.

- Location: Enter a descriptive name for the location used by the camera.

„ Indication LED

This item allows you to set the LED illumination as desired. There are two options: Normal and OFF.

Basic >> Date & Time

„ Date & Time

- 28 -

v

- TimeZone: Select the proper time zone for the region from the pulldown menu.

- Synchronize with PC: Select this option and the date & time settings of the camera will be synchronized with the connected computer.

- Synchronize with NTP Server: Select this option and the time will be synchronized with the NTP Server. You need to enter the IP address of the server and select the update interval in the following two boxes.

- Manual: Select this option to set the date and time manually.

Basic >> User

„ Administrator

To prevent unauthorized access to the camera’s Web Configuration, you are strongly recommend to change the default administrator password. Type the administrator password twice to set and confirm the password.

- 29 -

„ General User

- User Name: Enter the user’s name you want to add to use the camera.

- Password: Enter the password for the new user.

When you are finished, click Add/Modify to add the new user to the camera. To modify the user’s information, select the one you want to modify from User List and click Add/Modify.

- User List: Display the existing users of the camera. To delete a user, select the one you want to delete and click Delete.

„ Guest

- User Name: Enter the guest’s name you want to add to use the camera.

- Password: Enter the password for the new guest.

- User List: Display the existing guests of the camera. To delete a user, select the one you want to delete and click Delete.

NOTE

The “General User” can access the camera and control the Function buttons of the camera’s Web Configuration; the “Guest’ can only view the live view image from the main page of the Web

Configuration while accessing the camera. Only the “Administrator” is allowed to configure the camera through the Web Configuration.

- 30 -

4.4 Network Settings

The Network menu contains three sub-menus that provide the network settings for the camera, such as the IP Setting, DDNS Setting, IP Filter, and wireless network.

- 31 -

Network >> Network

„ IP Setting

This item allows you to select the IP address mode and set up the related configuration.

- DHCP: Select this option when your network uses the DHCP server.

When the camera starts up, it will be assigned an IP address from the

DHCP server automatically.

- Static IP: Select this option to assign the IP address for the camera directly. You can use IPSetup to obtain the related setting values.

- 32 -

IP

By the default setting, your camera IP address is assigned from your DHCP server. If you do not have a DHCP server in your network, the IP address will be assigned to 192.168.10.30.

Subnet Mask

Enter the Subnet Mask of the camera. The default setting is 255.255.255.0

.

Default Gateway

Enter the Default Gateway of the camera.

Primary/

Secondary DNS

DNS (Domain Name System) translates domain names into IP addresses. Enter the Primary DNS and Secondary DNS that are provided by ISP.

- PPPoE: Select this option when you use a direct connection via the

ADSL modem. You should have a PPPoE account from your Internet service provider. Enter the User Name and Password. The camera will get an IP address from the ISP as starting up.

NOTE

Once the camera get an IP address from the ISP as starting up, it automatically sends a notification email to you. Therefore, when you select PPPoE as your connecting type, you have to set up the email or DDNS configuration in advance.

„ DDNS Setting

With the Dynamic DNS feature, you can assign a fixed host and domain name to a dynamic Internet IP address. Select the Enable option to enable this feature. Then, select the Provider from the pulldown list and enter the required information in the Host Name, User

Name, and Password boxes. Please note that you have to sign up for

DDNS service with the service provider first.

„ UPnP

The camera supports UPnP (Universal Plug and Play), which is a set of computer network protocols that enable the device-to-device interoperability. In addition, it supports port auto mapping function so that you can access the camera if it is behind an NAT router or firewall.

Select the Enable option to enable this feature.

- 33 -

„ Ports Number

- HTTP Port: The default HTTP port is 80.

NOTE

If the camera is behind an NAT router of firewall, the suggested to be used is from 1024 to 65535.

Network >> IP Filter

The IP Filter setting allows the administrator of the camera to limit the users within a certain range of IP addresses to access the camera.

„ Start/End IP Address

Assign a range of IP addresses that are not allowed to access the camera by entering the Start IP address and End IP address. When you are finished, click Add to save the range setting. You can repeat the action to assign multiple ranges for the camera.

For example, when you enter 192.168.10.50 in Start IP Address and

192.168.10.80 in End IP Address, the user whose IP address located within 192.168.10.50 ~ 192.168.10.80 will not be allowed to access the camera.

„ Deny IP List

The list displays the range setting(s) of IP addresses that are not allowed to access the camera. To clear the setting, select a range of IP addresses from the list and click Delete.

Network >> Wireless Setting (for TV-IP110W only)

- 34 -

„ Wireless

The camera supports WLAN while you use the wireless network.

Select the Enable option to enable this feature.

- Network ID (SSID}: The default SSID setting is “TRENDnet”. To connect the camera to a specified access point, set a SSID for the camera to correspond with the access point’s ESS-ID. To connect the camera to an

Ad-Hoc wireless workgroup, set the same wireless channel and SSID to match with the computer’s configuration.

Click Site Survey to display the available wireless networks, so that you can easily connect to one of the listed wireless networks.

- 35 -

List of searching results

- Wireless Mode: Select the type of wireless communication for the camera: Infrastructure or Ad-Hoc.

- Channel: Select the appropriate channel from the list.

- Authentication: Select the authentication method to secure the camera from being used by unauthorized user: Open, Shared-key,

WPA-PSK, and WPA2-PSK. The following table explains the four options:

Open

The default setting of Authentication mode, which communicates the key across the network.

Shared-key

Allow communication only with other devices with identical WEP settings.

WPA-PSK/

WPA2-PSK

WPA-PSK/WPA2-PSK is specially designed for the users who do not have access to network authentication servers. The user has to manually enter the starting password in their access point or gateway, as well as in each PC on the wireless network.

If you select Open or Shared-key as the Authentication mode, you need to complete the following settings:

Encryption: Select the WEP option to enable the data encryption feature to secure the camera within the wireless network.

Format: Once you enable the Encryption feature, you need to determine the encryption format by selecting ASCII or HEX.

ASCII format causes each character you type to be interpreted as

- 36 -

an eight-bit value. Hex format causes each pair of characters you type to be interpreted as an eight-bit value in hexadecimal (base 16) notation.

Key Length: Select the WEP key length you use: 64 bits or 128

bits.

WEP Key 1/2/3/4: Enter the WEP key(s) in the following boxes.

If you select WPA-PSK or WPA2-PSK as the Authentication mode, you need to complete the following settings:

Encryption: Select TKIP or AES. TKIP (Temporal Key Integrity

Protocol) changes the temporal key every 10,000 packets to insure much greater security than the standard WEP security. AES

(Advanced Encryption Standard) is used to ensure the highest degree of security and authenticity for digital information.

Pre-Shared Key: This is used to identify each other in the network. Enter the name in the box, and this name must match the

Pre-shared key value in the remote device.

- 37 -

4.5 Setting up Video

The Video contains three sub-menus that provide the video and settings for the camera.

- 38 -

Video >> Camera

„ Image Setting

- Brightness: Adjust the brightness level from 0 ~ 100.

- Contrast: Adjust the contrast level from 0 ~ 100.

- Saturation: Adjust the colors level from 0 ~ 100

.

Click Default to restore the default settings of the three options above.

- Mirror: Select the Horizontal option to mirror the image horizontally. Select the Vertical option to mirror the image vertically.

- Light Frequency: Select the proper frequency according to the camera’s location: 50Hz, 60Hz, or Outdoor.

„ Overlay Setting

- Includes Date & Time: Select this option to display the date & time stamp on the live view image.

- Enable Opaque: Select this option to set a black background to the displayed date & time stamp.

- 39 -

„ MJPEG

- Video Resolution: Select the desired video resolution from the three formats: VGA, QVGA and QQVGA. The higher setting (VGA) obtains better video quality while it uses more resource within your network.

- Video Quality: Select the desired image quality from five levels:

Lowest, Low, Medium, High, and Highest.

- Frame Rate: Select a proper setting depending on your network status.

NOTE

The camera supports MJPEG compression. MJPEG capture the images in JPEG format, which require higher bandwidth to view smooth video. The administrator can control the bandwidth of each connection well through the setting options above.

- 40 -

4.6 Event Server Configuration

The Event Server menu contains three sub-menus that allow you to upload images to FTP, send emails that include still images, and store the images to a NAS system.

When you complete the required settings for FTP or Email, click Test to test the related configuration is correct or not. Once the camera connects to the server successfully, click Apply.

- 41 -

Event Server Setting>> FTP

„ FTP

- Host Address: Enter the IP address of the target FTP server.

- Port Number: Enter the port number used for the FTP server.

- User Name: Enter the user name to login into the FTP server.

- Password: Enter the password to login into the FTP server.

- Directory Path: Enter the destination folder for uploading the images. For example, /Test/ .

- Passive Mode: Select the Enable option to enable passive mode.

- 42 -

Event Server Setting >> Email

„ Email

- SMTP Server Address: Enter the mail server address. For example, mymail.com

.

- Sender Email Address: Enter the email address of the user who will send the email. For example, [email protected]

.

- Sender User Name: Enter the user name to login the mail server.

- Sender Password: Enter the password to login the mail server.

- Receiver #1 Email Address: Enter the first email address of the user who will receive the email.

- Receiver #2 Email Address: Enter the second email address of the user who will receive the email.

- 43 -

4.7 Motion Detect

The Motion Detect menu contains the command and option that allow you to enable and set up the motion detection feature of the camera. The camera provides two detecting areas.

To enable the detecting area, select Window 1 or 2 from the pull-down list, and then select Enable. When the detecting area is enabled, you can use the mouse to move the detecting area and change the area coverage.

- 44 -

- Name: Assign a name to the detecting area.

- Threshold: Move the slide bar to adjust the level for detecting motion to record video.

- 45 -

4.8 Event Config

The Event Config menu contains four sub-menus that provide the commands to configure event profiles.

- 46 -

Event Configuration >> General Setting

- Snapshot/Recording Filename Prefix: You can assign a given prefix to each new captured file. Otherwise, leave this option blank to use the default setting.

Event Configuration >> Arrange Schedule Profile

This sub-menu displays the scheduled profile(s). To customize the profile, click Add and then enter a descriptive name for the profile in the prompt dialog window.

After entering the profile name, click OK and the profile is added to the

Schedule Profiles list. To delete the profile, select the profile in the list and click Delete.

- 47 -

- Profile Name: Display the profile name that you select in the

Schedule Profiles list.

- Weekdays: Select the weekday(s) that you want to separately assign in the schedule profile. The weekday that has been assigned will be displayed with green color.

- Time List: Display the time period that you have assigned within the selected weekday. To assign the same time period to every weekday, click Add this to all weekdays; click Delete this from all weekdays to remove the selected time period from every weekday. Click Delete to remove the selected time period.

- Start/End Time: Enter the start and end time and then click Add to assign a time period within in the selected weekday.

- 48 -

Event Configuration >> Motion Detect Trigger

Select the Enable option to enable the trigger function of the camera, so that you can send captured images within the detecting area to the FTP server and email receiver. You have to configure corresponding settings, such as FTP server and email server, to enable this feature.

- Schedule Profile: Select a schedule profile from the pull-down list.

- Action: Select the destination that the captured images will be sent to:

Send Email, or FTP Upload.

Event Configuration >> Schedule Trigger

- 49 -

You can separately configure the schedule for trigger function of the camera by Email or FTP. Select the Enable option on each item, and then select a

Schedule Profile from the pull-down list and set the Interval time.

- 50 -

4.9 Tools

The Tools menu provides the commands that allow you to restart or reset the camera. You can also backup and restore your configuration, and upgrade the firmware for the camera.

- 51 -

„ Factory Reset

Click Reset to restore all factory default settings for the camera.

„ System Reboot

Click Reboot to restart the camera just like turning the device off and on. The camera configuration will be retained after rebooting.

„ Configuration

You can save your camera configuration as a backup file on your computer. Whenever you want to resume the original settings, you can restore them by retrieving the backup file.

- Backup: Click Get the backup file to save the current configuration of the camera.

- Restore: Click Browse to locate the backup file and then click

Restore.

„ Update Firmware

This item displays the current firmware version. You can upgrade the firmware for your camera once you obtained a latest version of firmware.

- Select the firmware: Click Browse to locate the backup file

(xxx.pck) and then click Update. Factory reset and IP Setup are required after firmware update.

NOTE

Make sure to keep the camera connected to the power source during the process of upgrading firmware. Otherwise, the camera might be damaged because of failure of upgrading firmware.

- 52 -

4.10 Information

The Information menu displays the current configuration and events log of the camera.

„ Device Info

Display the Basic, Video, Network, and Wireless settings of the camera.

„ System Log

The Logs table displays the events log recorded by the system.

- 53 -

C

HAPTER

5

S

ECUR

V

IEW

™ S

OFTWARE

This Chapter describes detail instructions on operating SecurView™ software, a useful friendly application for ease of control and navigation requirement.

5.1 INSTALLATION

1. Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program.

2. Click the SecurView from the Auto-Run menu screen.

- 54 -

NOTE

To use SecurView™, you must have Microsoft .NET Framework

2.0 installed in the computer. The setup wizard will detect it and, if the program is not installed yet, ask you to install it during the process of installing SecurView™.

- 55 -

3. Then SecurView Setup Wizard will appear. Click “Next” when the

Welcome to the SecurView Setup Wizard appears.

4. Click “Browse” to choose the desired destination location. By default, the destination location is C:\Program Files\TRENDnet\SecurView.

Then Click “Next”.

- 56 -

5. Click “Next” to confirm the SecurView software to be installed to the computer.

- 57 -

6. When the Installation Complete window appears, click “Close”.

7. After installing the IPSetup utility, the application is automatically installed to your computer, and creates a folder in “ Start

\Program\TRENDnet\SecurView”.

- 58 -

1. To launch the program, click Start > Program > TRENDnet >

SecurView, and then click SecruView™. The main screen will appear as below.

NOTE

Please set the resolution to 1024x768 or above on your computer while using SecurView™; otherwise, the displayed main screen may be distorted.

Item features

The following describes the function of each item on the main screen:

„ CONTROLS Panel

- 59 -

- SETTING: Click to enter the Setting screen of SecurView™. Click again to return to the main screen of SecurView™.

- PLAY: Click to play the recorded video file using the media player on the computer (for example, Windows Media Player by default).

- LOCK: Click to lock the camera controls. Click again to resume controls for the camera. If you have set ID and Password in

SETTING > Account, you will be asked to enter the required information to unlock.

- ALL RECORD: Click to start recording video clips using ALL connected cameras. To stop recording, please click Record button

to stop the individual camera. Please note: stop recording only

- 60 -

stop the manual recording camera. For schedule recording, please change the setting on configuration.

TIP

By default, the ID and Password boxes are “blank.” Click

SETTING > Account to change the ID and password of lock/unlock function.

„ VIEW SELECTION Panel

- View mode buttons: SecurView™ provides multiple view modes, including 1/4/9/16 windows and Full screen mode.

- SCAN: When multiple cameras connected, click this button to display the video views between cameras. Click the Scan button again to stop scanning.

- PREV: When multiple cameras connected, click this button to switch the video view to the previous camera.

- NEXT: When multiple cameras connected, click this button to switch the video view to the next camera.

TIP

To set the time interval of scanning, click SETTING > Other and then adjust the time from 1 to 10 seconds in the Time interval of

scan option.

- 61 -

„ CAMERA Panel

-

TRIGGER OUT: Click to turn on the trigger out connector of the camera. This button is available only when the connected camera supports the trigger out connector, which is used to control the external device connected to the camera, such as a light. (Not support on these models)

- SNAPSHOT: Click to capture a still image using the selected camera and save the file in the computer.

- RECORD: Click to start recording a video clip using the selected camera. Click again to stop recording and save the file in the computer.

- TALK: Click to speak out through the camera. Please note only one user is allowed to use this function at the same time. (Not support on these models)

-

LISTEN: Click to receive the on-site sound and voice from the camera. (Not support on these models)

-

- 62 -

„ SYSTEM Panel

This panel displays the current date and time.

„ PAN-TILT CONTROL Panel

(Not support on these models)

When you connect a pan/tilt camera, the system will detect the camera’s function automatically and the PAN-TILT CONTROL buttons will become functional. Otherwise, these buttons are displayed as gray out buttons.

- Direction/Home buttons: Click these buttons to adjust the camera’s viewing angle to Up (

) / Down (

) / Left ( ) / Right

(

) / Left-Up (

) / Left-Down ( ) / Right-Up ( ) /

Right-Down ( ).

Click the Home button ( ) to return the camera to the default position.

- SWING: If you have saved two or more positions for the selected camera, click this button to control the camera swinging from one position to another position.

- 63 -

„ Video View Window and Camera List

Video Viewing

Window

Camera List

- Video Viewing Window: This window displays the video view of the selected camera, which can be divided into 4/9/16 windows according to your selection in VIEW SELECTION panel.

- Camera List: This list displays the information of the connected camera(s).

- 64 -

„ To add a camera

1. Click SETTING in the CONTROLS panel to display the Setting screen.

2. Click Add New Camera.

- 65 -

3. In the pop-up Add New Camera dialog window, you can: z Select the Search tab if you are not sure of the camera’s IP address.

Click Search camera to search the available camera within the network. Once the camera is found and is shown in the list, select it and click Add Camera. z Select the Input tab to add a camera by entering its IP address directly. Enter the camera’s IP address (e.g. 192.168.10.30) and

Port (default: 80 ), and then click Add Camera.

- 66 -

4. Enter the User name and Password for the camera, and then click OK.

The connected camera will be displayed in the Camera List.

- 67 -

5. Click SETTING to return to the Video View Window. The video view of the selected camera will be displayed now.

- 68 -

To remove a camera

1. Click SETTING in the CONTROLS panel to display the Setting screen.

2. Select a camera from the list and click Delete Camera.

Select a camera

Delete the camera

- 69 -

To link to the Web page of the camera

Click SETTING > Camera List > Camera Configuration and then Link

web page to launch the Web browser that displays live view image and

Web Configuration of the selected camera.

- 70 -

To record video

SecurView™ provides three methods to record video clips: one is to click the RECORD/All Record button to record manually; the second is to record by motion detection; the third is to set the recording schedule in

Setting > Recording Configuration > Schedule Recording

Configuration. z Manually recording

Click RECORD/All Record and it starts recording. Click the button again to stop.

- 71 -

z Trigger recording by motion detection

When the motion detection function of the selected camera is enabled, you can configure the camera to start recording triggered by the motion detected. Click SETTING > Motion Configuration, and then select the Recording option to enable the selected camera to record by motion detection. z Schedule recording Configuration

This recording method will work after you have completed the required settings in Schedule Recording Configuration. The recording schedule can be defined by Dates or Days.

- 72 -

- Dates: Select the camera from the pull-down list..

Select a camera

Add Schedule

- Then, click Add to set the Start/Stop date and time and then click

OK to add the recording schedule to the list.

- Click Apply to save the settings

- 73 -

- 74 -

Days: First, select the camera from the pull-down list and select

Days tab. Then, select the weekday from the day buttons and then set the time period. Click Apply to save the settings.

- 75 -

To configure the recording settings

To configure the recording settings, including the storage folder and storage options, click SETTING > Recording Configuration. z Recording File Path: To change the destination folder to save the recorded video file, click Browse under the Recording File Path box to assign a new folder. z Each Recording File Size: This option allows you to select from 20 to 100 MB so that the video will be recorded as another file automatically when the recording file reaches the specified size limit. z Reserved HDD space for each camera: This option allows you to set to reserve the storage space on the hard disk drive for the manual/scheduled recording and motion-detected recording half-and-

- 76 -

half of each camera. Before setting the reserve space on the hard disk drive, you can check the available storage space that is displayed in the HDD Free space field. z Enable Recycle Recording: Click on the camera number to clear the files when the unreserved space of the hard disk drive is full.

NOTE

The system will not delete the recorded file of motion detection, please back up and then remove the files nonscheduled. Otherwise, the system might stop the motion-detected recording because of the shortage of storage space.

- 77 -

To playback the recorded video

The recorded video clips are saved in your computer, and can be played using the media player on the computer, such as Windows Media Player.

To start playback, simply click the PLAY button on the CONTROLS panel, and the following dialog screen will appear, allowing you to select the file to playback.

Select the recorded video file under the [camera] path and then click Open to launch the media player to playback.

NOTE

If your player on the computer don’t have video codec to playback the recorded video. You can download video codec from http://www.xvid.org/downloads.15.0.html

to support.

To set up motion detection options

When the motion detection function of the selected camera is enabled, you can set the Motion Options by selecting Alarm, Recording, Send e-Mail, and Trigger Out under SETTING > Motion Configuration.

- 78 -

z Alarm: Select Beep or Music to alert you for the motion detected.

When you select Music, you can customize the sound by clicking

Browse and then selecting your favorite music (*.wav or *.mp3 file) in the computer. z Recording: Select this option to enable the camera to record by motion detected. z Send Email: Select this option so that the system will be able to send an email to the specified receiver. Once the option is selected, you have to complete the required information in SETTING > Motion

Configuration > Email Configuration.

- 79 -

- Mail Server: Enter the mail server address. For example, mymail.com

.

- Mail From: Enter the email address of the user who will send the email. For example, [email protected]

.

- Mail To: Enter the email address of the user who will receive the email.

- User Name: Enter the user name to login the mail server.

- Password: Enter the password to login the mail server.

- Subject: Enter a subject for the notification email. z Trigger Out: If the selected camera supports Trigger Out connector, select this option to enable the Trigger Out function.

- 80 -

Account

Click SETTING > Account to setup the username & password to lock & unlock the main screen of the SecurView.

Other

Click SETTING > Other to setup the scanning time between cameras. The default setting is 2 seconds. You can set the interval time between 2 ~ 20 seconds.

- 81 -

Information

Click SETTING > About to display the information of the software application.

- 82 -

C

HAPTER

6

A

PPENDIX

A.1 Specification

„ Image Sensor

Sensor

Resolution

1/4” color CMOS

640x480

„ Video

Compression MJPEG

„ System Hardware

Processor

RAM

ROM

Power

ARM9 base

16MB SDRAM

4MB NOR Flash

DC 5V, 2.5AV

„ Communication

LAN

10/100Mbps Fast Ethernet, auto-sensed,

Auto-MDIX

WLAN

IEEE 802.11b/g

SMTP, FTP, PPPoE, UPnP

„ User Interface

LAN One RJ-45 port

Antenna

One detachable antenna

Reset One reset button

- 83 -

LEDs Power LED (orange); Link LED (green)

„ SecurView™ Software

OS Support

Windows 2000/XP/Vista

Feature

playback/recording/configuration features

„ Web Configuration

OS Support

Browser

Windows 2000/XP/Vista

Internet Explorer 6.0 or above

„ Operating Environment

Temperature

- Operation: 5

°C ~ 45°C

- Storage: -15

°C ~ 60°C

Humidity - Operation: 20% ~ 85% non-condensing

- Storage: 0% ~ 90% non-condensing

„ EMI

FCC Class B, CE Class B

- 84 -

C

A.2 Glossary of Terms

NUMBERS

10BASE-T

100BASE-TX

A

ADPCM

AMR

Applet

ASCII

ARP

AVI

B

BOOTP

10BASE-T is Ethernet over UTP Category III, IV, or V unshielded twisted-pair media.

The two-pair twisted-media implementation of 100BASE-T is called 100BASE-TX.

Adaptive Differential Pulse Code Modulation, a new technology improved from PCM, which encodes analog sounds to digital form.

AMR (Adaptive Multi-Rate) is an data compression scheme optimized for speech coding, which is adopted as the standard speech codec by 3GPP.

Applets are small Java programs that can be embedded in an

HTML page. The rule at the moment is that an applet can only make an Internet connection to the computer form that the applet was sent.

American Standard Code For Information Interchange, it is the standard method for encoding characters as 8-bit sequences of binary numbers, allowing a maximum of 256 characters.

Address Resolution Protocol. ARP is a protocol that resides at the TCP/IP Internet layer that delivers data on the same network by translating an IP address to a physical address.

Video Interleave, it is a Windows platform and video file type, a common format for small movies and videos.

Bootstrap Protocol is an Internet protocol that can automatically configure a network device in a diskless workstation to give its own IP address.

- 85 -

Communication

Communication has four components: sender, receiver, message, and medium. In networks, devices and application tasks and processes communicate messages to each other over media. They represent the sender and receivers. The data they send is the message. The cabling or transmission method they use is the medium.

Connection

In networking, two devices establish a connection to communicate with each other.

D

DHCP

Developed by Microsoft, DHCP (Dynamic Host Configuration

Protocol) is a protocol for assigning dynamic IP addresses to devices on a network. With dynamic addressing, a device can have a different IP address every time it connects to the network. In some systems, the device's IP address can even change while it is still connected. It also supports a mix of static and dynamic IP addresses. This simplifies the task for network administrators because the software keeps track of IP addresses rather than requiring an administrator to manage the task. A new computer can be added to a network without the hassle of manually assigning it a unique IP address. DHCP allows the specification for the service provided by a router, gateway, or other network device that automatically assigns an

IP address to any device that requests one.

DNS

Domain Name System is an Internet service that translates domain names into IP addresses. Since domain names are alphabetic, they're easier to remember. The Internet however, is really based on IP addresses every time you use a domain name the DNS will translate the name into the corresponding

IP address. For example, the domain name

www.network_camera.com might translate to 192.167.222.8.

E

Enterprise network

An enterprise network consists of collections of networks connected to each other over a geographically dispersed area.

The enterprise network serves the needs of a widely distributed company and operates the company’s mission-critical applications.

- 86 -

Intranet

Internet

This is a private network, inside an organization or company that uses the same software you will find on the public

Internet. The only difference is that an Intranet is used for internal usage only.

The Internet is a globally linked system of computers that are logically connected based on the Internet Protocol (IP). The

Internet provides different ways to access private and public information worldwide.

Internet address

To participate in Internet communications and on Internet

Protocol-based networks, a node must have an Internet address that identifies it to the other nodes. All Internet addresses are

IP addresses

IP

Internet Protocol is the standard that describes the layout of the basic unit of information on the Internet (the packet) and also details the numerical addressing format used to route the information. Your Internet service provider controls the IP address of any device it connects to the Internet. The IP addresses in your network must conform to IP addressing rules. In smaller LANs, most people will allow the DHCP function of a router or gateway to assign the IP addresses on internal networks.

IP address

ISP

J

JAVA

IP address is a 32-binary digit number that identifies each sender or receiver of information that is sent in packets across the Internet. For example 80.80.80.69 is an IP address. When you “call” that number, using any connection methods, you get connected to the computer that “owns” that IP address.

ISP (Internet Service Provider) is a company that maintains a network that is linked to the Internet by way of a dedicated communication line. An ISP offers the use of its dedicated communication lines to companies or individuals who can’t afford the high monthly cost for a direct connection.

Java is a programming language that is specially designed for writing programs that can be safely downloaded to your computer through the Internet without the fear of viruses. It is an object-oriented multi-thread programming best for creating applets and applications for the Internet, Intranet and other complex, distributed network.

- 88 -

L

LAN

M

MJPEG

Local Area Network a computer network that spans a relatively small area sharing common resources. Most LANs are confined to a single building or group of buildings.

N

MJPEG (Motion JPEG) composes a moving image by storing each frame of a moving picture sequence in JPEG compression, and then decompressing and displaying each frame at rapid speed to show the moving picture.

NAT

Network

A network consists of a collection of two or more devices, people, or components that communicate with each other over physical or virtual media. The most common types of network are:

LAN – (local area network): Computers are in close distance to one another. They are usually in the same office space, room, or building.

WAN – (wide area network): The computers are in different geographic locations and are connected by telephone lines or radio waves.

NWay Protocol

A network protocol that can automatically negotiate the highest possible transmission speed between two devices.

Network Address Translator generally applied by a router that makes many different IP addresses on an internal network appear to the Internet as a single address. For routing messages properly within your network, each device requires a unique IP address. But the addresses may not be valid outside your network. NAT solves the problem. When devices within your network request information from the Internet, the requests are forwarded to the Internet under the router's IP address. NAT distributes the responses to the proper IP addresses within your network.

- 89 -

P

PCM

PING

PPPoE

Protocol

R

RJ-45

Router

PCM (Pulse Code Modulation) is a technique for converting analog signals into digital form for transmission.

Packet Internet Groper, a utility used to determine whether a specific IP address is accessible. It functions by sending a packet to the specified address and waits for a reply. It is primarily used to troubleshoot Internet connections.

Point-to-Point Protocol over Ethernet. PPPoE is a specification for connecting the users on an Ethernet to the Internet through a common broadband medium, such as DSL or cable modem.

All the users over the Ethernet share a common connection.

Communication on the network is governed by sets of rules called protocols. Protocols provide the guidelines devices use to communicate with each other, and thus they have different functions. Some protocols are responsible for formatting and presenting and presenting data that will be transferred from file server memory to the file server’s net work adapter Others are responsible for filtering information between networks and forwarding data to its destination. Still other protocols dictate how data is transferred across the medium, and how servers respond to workstation requests and vice versa. Common network protocols responsible for the presentation and formatting of data for a network operating system are the

Internetwork Packet Exchange (IPX) protocol or the Internet

Protocol (IP). Protocols that dictate the format of data for transferors the medium include token-passing and Carrier

Sense Multiple Access with Collision Detection (CSMA/CD), implemented as token-ring, ARCNET, FDDI, or Ethernet. The

Router Information Protocol (RIP), a part of the Transmission

Control Protocol/Internet Protocol (TCP/IP) suite, forwards packets from one network to another using the same network protocol.

RJ-45 connector is used for Ethernet cable connections.

A router is the network software or hardware entity charged with routing packets between networks.

- 90 -

U

S

Server

SIP

SMTP

SNMP

Station

Subnet mask

T

(TCP/IP)

Transceiver

It is a simple computer that provides resources, such as files or other information.

SIP (Session Initiated Protocol) is a standard protocol that delivers the real-time communication for Voice over IP

(VoIP), which establishes sessions for features such as and video conferencing.

The Simple Mail Transfer Protocol is used for Internet mail.

Simple Network Management Protocol. SNMP was designed to provide a common foundation for managing network devices.

In LANs, a station consists of a device that can communicate data on the network. In FDDI, a station includes both physical nodes and addressable logical devices. Workstations, singleattach stations, dual-attach stations, and concentrators are

FDDI stations.

In TCP/IP, the bits used to create the subnet are called the subnet mask.

Transmission Control Protocol/Internet Protocol is a widely used transport protocol that connects diverse computers of various transmission methods. It was developed y the

Department of Defense to connect different computer types and led to the development of the Internet.

A transceiver joins two network segments together.

Transceivers can also be used to join a segment that uses one medium to a segment that uses a different medium. On a

10BASE-5 network, the transceiver connects the network adapter or other network device to the medium. Transceivers also can be used on 10BASE-2 or 10BASE-T networks to attach devices with AUI ports.

- 91 -

UDP

User Name

Utility

UTP

W

WAN

WEP

Windows

WPA

WPA2

The User Datagram Protocol is a connectionless protocol that resides above IP in the TCP/IP suite

The USERNAME is the unique name assigned to each person who has access to the LAN.

It is a program that performs a specific task.

Unshielded twisted-pair. UTP is a form of cable used by all access methods. It consists of several pairs of wires enclosed in an unshielded sheath.

Wide-Area Network. A wide-area network consists of groups of interconnected computers that are separated by a wide distance and communicate with each other via common carrier telecommunication techniques.

WEP is widely used as the basic security protocol in Wi-Fi networks, which secures data transmissions using 64-bit or

128-bit encryption.

Windows is a graphical user interface for workstations that use

DOS.

WPA (Wi-Fi Protected Access) is used to improve the security of Wi-Fi networks, replacing the current WEP standard. It uses its own encryption, Temporal Key Integrity Protocol (TKIP), to secure data during transmission.

Wi-Fi Protected Access 2, the latest security specification that provides greater data protection and network access control for

Wi-Fi networks. WPA2 uses the government-grade AES encryption algorithm and IEEE 802.1X-based authentication, which are required to secure large corporate networks.

- 92 -

Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase.

TV-IP110/TV-IP110W – 3 Years Warranty

If a product does not operate as warranted above during the applicable warranty period,

TRENDnet shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product. All products that are replaced will become the property of TRENDnet. Replacement products may be new or reconditioned.

TRENDnet shall not be responsible for any software, firmware, information, or memory data of customer contained in, stored on, or integrated with any products returned to TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to service the product by any unauthorized service center. This warranty is voided if (i) the product has been modified or repaired by any unauthorized service center, (ii) the product was subject to accident, abuse, or improper use (iii) the product was subject to conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within the applicable warranty period for a Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-authorized by

TRENDnet with RMA number marked on the outside of the package, and sent prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE

AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT

TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING

WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF

LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET

NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT

ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION

MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING

AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT

DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S

MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED

ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE

- 93 -

OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER

HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW

TRENDNET ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY,

WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR

INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF

ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN

CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,

PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH

DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND

OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF

LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED

HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of the state of

California.

AC/DC Power Adapter, Cable, Cooling Fan, and Power Supply carry 1 year warranty.

- 94 -

- 95 -

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
