EUROCOIN 2015

BILL ACCEPTORS

www.eurocoin.co.uk

J C M   BILL  AC C EPTO RS

NOTE RECYCLING

VEGA RC

VEGA RC TWIN iPRO RC

HEAD ONLY

TAIKO

WITH STACKER

UBA

TBV

iVIZION

DBV 40x Series

iPRO

EBA 4x Series

IN ThIS SECTION...

SYSTEMS

Intelligent Cash Box

www.eurocoin.co.uk                                               +44 (0)1707 280 028

J C M   B I L L   A C C E P T O R S

VIZION

BETTER. S MARTER. FAS TER.

CIS TECHNOLOGY OPTICAL NOTE

ALIGNMENT

FULL IMAGE

CAPTURE

ANTI-STRINGING

FASTES T NOTE

STACKING

99%+

ACCEPTANCE

3

85 MM WIDE

SEALED BILL PATH

DUST/LIQUID

RESIS TANT

DUAL

PROCESS ORS

SENTRY 2.0 BEZEL

EUROCOIN

.

CO

.

UK

www.eurocoin.co.uk

ICB 2.0 WITH RFID

J C M   B I L L   A C C E P T O R S

JCM iVIZION

The iVizion is an incredible landmark in the evolution of gaming technology.

iVizion utilises Contact Image Sensor (CIS) Technology, causing it to scan 75 times more data points than any competitor product and captures a full image of each banknote or ticket.

The inclusion of 2 high-speed processors ensures the fastest note-to-note processing speed in the industry, while the feature of optically centering banknotes eliminates the need for mechanical centering thus dramatically improving processing speed again.

iVizion combines both an optical and mechanical jCm patented anti-stringing device, giving the maximum in security and fraud detection.

iVizion is self-calibrating and 100% gaming protocol compatible, while a sealed banknote path promotes dirt and liquid resistance, contributing to the incredible 99% minimum acceptance rate.

The Intelligent Cashbox (ICB) stores each note and ticket transaction, providing a wealth of accurate data, plus allowing the iVizion to be customised to the exclusive needs of each individual operator.

WHY SHOULD MY COMPANY BUY THIS?

The validation process used by iVIZION™ is powered by

Contact Image Sensor (CIS) technology that scans 75 times more data points than any competitive product and captures the full image of a banknote or a ticket.

Quite simply, iVIZION™ is the most powerful bill validator available, and your best defense against counterfeiting.

• Superior CIS Technology

• Scans 75 more data points than any competitor

• Self-calibrating

• Protective sealed bill path

• 100% compatible with all gaming protocols

Description jCm IVIZION jCm CAShBOx

Part #

47200xxx

47200328

• Intelligent Cashbox (ICB) with RFID memory, customizable ICB reporting and web enabled ICB reports

• 64mb Flash memory expandable to 192mb

• Optical and mechanical anti-stringing security

• Optical banknote centering

• Fastest note-to-note processing in the industry

+44 (0)1707 280 028       [email protected]

4

J C M   B I L L   A C C E P T O R S

5

JCM UBA

The UBA Series by jCm has been specifically designed to accept all the world’s currencies, with specially engineered transport Unit, Frame and Cashbox widened to accommodate all bills up to 85mm in width.

The UBA boasts a 4-way acceptance ability, giving it the highest acceptance rate in the industry, and is Intelligent

Cashbox (ICB) compatible.

Utmost security is provided by multi-frequency validation technology including Red, Green, IR and UV

LED’s alongside a magnetic sensor, phototransistors, reflective, transparency and barcode sensors.

Validation speed is still exceptional at 4 seconds; while jCm’s established and unrivaled anti-stringing mechanism prevents retraction of bills.

The lightweight, durable, damage resistant plastic construction features a cashbox ‘viewing window’, allowing visual evidence of the last note inserted.

The UBA is fully TITO compatible and validates and stores all slot tickets.

WHY SHOULD MY COMPANY BUY THIS?

The UBA accepts all world currencies and offers the highest levels of security against note fraud. It is widely recognized as the industry market leader for secure banknote validation.

The UBA family of products now also includes the UBA

Recycler, complete with note payout system.

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS

114mm W x 234mm D x 298mm h

WEIGHT

4.0 Kg

INTERfACE OPTIONS

Serial & RS-232C

(USB & ccTalk optional)

12vdc 4A

POWER REqUIREMENTS

NOTE WIDTHS

62mm to 85mm

CASHBOx CAPACITY

Standard 500, optional 900

ACCEPTANCE RATE

VALIDATION SPEED

98% or higher

2 seconds per note

Description jCm UBA

Part #

47200xxx

• Cashbox compatible with WBA series cashbox

• Cashbox capacity approximately 500 notes

(900 optional)

• ESCROW – 1 banknote

• Superior optical sensing technology

• Visual audit window in cashbox

• Configured via either Flash Programme or

EPROm

• Easy maintenance – All major areas including the bill path are accessible without use of tools

• Self-centering mechanism increases first time acceptance rate and eliminates need for additional bill guides in bezel and cashbox.

• Quick and easy programme downloads via USB without removal of unit

• Same size as WBA and mounted in the same fashion

www.eurocoin.co.uk

J C M   B I L L   A C C E P T O R S

CLEAR BLUE BEZEL

• Clear blue bezel

• Available in 2 or 5

LED format

G PATTERN BEZEL

• Black bezel with blue LED

• Available in 82mm and

77mm note widths

• Sutiable for UBA and

WBA

Description

113944 UBA 85mm 5 LED

113946 UBA 85mm 2 LED

BLACK BEZEL GREEN LED

• Black bezel with green LED

• Available in 85mm and

82mm note widths

Part #

47200321

472xxxxx

Description

G00100 UBA/WBA 82mm

G00101 UBA/WBA 77mm

• Calibration cards and test kits for UBA

CALIBRATION CARDS

Part #

47200322

47200393

Description

113945 UBA 85mm 2 LED

131649 UBA 82mm 2 LED

124152 UBA 82mm NO LED

123185 UBA 82mm RIDGED 2 LED

900 CAPACITY CASHBOx

• 900 note capacity cashbox

• To suit UBA

• Supplied with handle

Part #

47200320

47200323

47200395

47200396

Description

WhITE CALIBRATION CARD UBA10

UBA CALIBRATION AND TEST KIT

BLACK CALIBRATION CARD UBA10

UV CALIBRATION CARD UBA10

Part #

47200163

47200207

47200164

47200165

JCM AUTHORISED  SERVICE CENTRE

Eurocoin has been appointed as an Authorised

Service Centre for jCm across Europe and

Africa.

Description

127891 UBA 900 CAPACITY

500 CAPACITY CASHBOx

• 500 note capacity

• To suit UBA

• Supplied with handle

Description

128680 UBA 500 CAPACITY

Part #

47200324

JCM is delighted to be working with Eurocoin across Europe. The Eurocoin team has great experience and an excellent reputation.

Our combined efforts will be good news for all customers

UBA Taiko EBA TBV iVizion DBV VEGA RC UBA RC

+44 (0)1707 280 028 | [email protected]

Part #

47200283

+44 (0)1707 280 028       [email protected]

6

J C M   B I L L   A C C E P T O R S

JCM UBA 1x SPARES LIST

• Spares List for jCm UBA 1x

• Need further information?

[email protected]

7 102786 8 102791

9 102755 10   116215

7

Description

1

102756 LEVER

2

102769 BACK COVER

3

128528 BELT

4

103923 CENTERING mOTOR

5

102767 COVER FRONT

6

130799 CPU BOARD

7

102786 GEAR

8

102791 GEAR

9

102755 LINK LEVER

10

116215 LOWER SENSOR BOARD

11

104071 SOLENOID ASSY

12

102760 SOLENOID BASE

13

102989 SPACER

14

106443 STACKER mOTOR

15

102777 TRANSPORT COVER RIGhT

16

102778 TRANSPORT COVER LEFT

17

102753 TRANSPORT GUIDE A

18

102754 TRANSPORT GUIDE B

19

106441 TRANSPORT mOTOR

20

102758 UP SLIDER

21

116213 UPPER SENSOR BOARD

1 102756

3 128528

2 102769

4 103923

Part #

47200143

47200202

47200335

47200196

47200173

47200171

47200181

47200182

47200148

47200172

47200187

47200337

47200334

47200184

47200204

47200205

47200179

47200180

47200183

47200149

47200170

11   104071

13   102989

15   102777

17   102753

19   106441

21   116213

12   102760

14   106443

16   102778

18   102754

20   102758

WHY SHOULD MY COMPANY BUY THIS?

Advanced jCm validation techniques result in exceptionally high first-time banknote acceptance rates, regardless of how the note is inserted.

5 102767 6 130799 www.eurocoin.co.uk

J C M   B I L L   A C C E P T O R S

JCM iPRO NOTE 

ACCEPTOR + iPRO RC

The latest generation of bill acceptor has been launched by market leaders jCm - the new jCm iPRO. The iPRO has one of the most sophisticated sensing and antistringing defenses to bank note fraud that has ever been developed by jCm.

The iPRO's modular design means that the iPRO validator head can easily replace an existing UBA head, providing an instant improved performance.. The iPRO accepts bank notes up to 85mm in width and 170mm in length, plus barcode coupons two-way, face up.

Building upon the successful UBA platform, the iPRO

Recycler offers 2 different note denomination payout, plus both ID003 and ccTalk interfaces as standard. Its new roller friction recycling technology allows up to 100 notes in each of 2 denominations to be stored, recycled and paid out to users quickly and efficiently.

• 100% compatible as UBA “plug-and-play” upgrade

• Sealed bill path for dust, liquid & light protection

• 7 wavelength optical and magnetic sensors

• Dual exit sensors with anti-stringing drum device

• ICB® optional add-on

T E C H N I C A L   S P E C I f I C AT I O N S

ACCEPTANCE RATE

98% or greater

BANKNOTE SIZE Width: 62 – 85mm (2.44 – 3.35")

Length: 120 – 170mm (4.73 – 6.69")

INSERTION DIRECTION

Banknote: four-way

Barcode coupon: two-way faceup

CASHBOx CAPACITY

600 notes (standard)

1000 notes (optional)

DIMENSIONS

298(h)x114(W)x234mm(D) (11.73×4.49×9.21")

INTERfACE

USB, Photo-coupler isolation, RS232C, CCTalk

PROTOCOL

ID-003 and OEm Serial, ccTalk

WEIGHT UNIT & CB

Approximately 4kg (8.81 lbs)

INSTALLATION

Down stack

Up stack

MEMORY

64 mbit flash memory standard

Description Part # jCm IPRO NOTE ACCEPTOR 4720IPRO, 472PRORC

• Faster note-to-note speed

• highest first time acceptance rate

• Down & up stacker

• 2 bank note denomination payout, 100 notes per denomination capacity

• ID003 and ccTalk interface

• Recycles bank notes up to 82mm wide and 158mm long

+44 (0)1707 280 028       [email protected]

8

J C M   B I L L   A C C E P T O R S

JCM TAIKO

Taiko, meaning ‘drum’ in japanese, is the new bill acceptor from jCm featuring their unique high security drum winding technology.

Drum technology transports banknotes and acts as a powerful anti-fishing mechanism by rotating and tangling any foreign object attached to the note.

In addition to this elite feature, Taiko has the renowned security associated with all jCm products, featuring an anti-pullback system and high quality counterfeit protection.

The latest in sensor technology delivers validation security including blue, red, IR and NIR sensors.

Taiko is small, light and door-mountable with a clip-on style, making it easy to transport, install, remove and integrate into a wide range of applications.

As well as being secure and practical, Taiko features an attractive “rainbow” faceplate with 7 different LED colours.

9

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS

100mm W x 98mm D x 88mm h

WEIGHT

0.6 Kg

INTERfACE OPTIONS

mDB, Serial, Pulse, Parallel and ccTalk protocols

POWER REqUIREMENTS

12vdc 1.4 A maximum

NOTE WIDTHS

62 to 82mm

ACCEPTANCE RATE

VALIDATION SPEED

No less than 90%

2.8 seconds per note

Description jCm TAIKO

Part #

47200xxx

• Innovative drum winding technology

• Automatic re-validation

• Combined anti-fishing mechanisms – drum, lever & optical sensor

• Validation methods – transparency, reflection

(red, blue, IR & NIR sensors) & optical (4 wavelengths)

• Dip switch selectable Interface

• CE approval

• “Rainbow” Full Colour LED faceplate – pattern changeable via dip switch

• mDB, serial, pulse, parallel and ccTalk protocols

• Available in European configuration [Pub 7] or USA configuration with magnetic head [Pub 11]

www.eurocoin.co.uk

EURO BEZEL

• Taiko EUR bezel

• Faceplate Type-1

• Available in 67mm and

82mm note widths

Description

121872 TAIKO EUR BEZEL

GBP BEZEL

• Taiko GBP vending bezel

• Faceplate Type-2

• Available in 75mm and

82mm note widths

Description

121873 TAIKO GBP BEZEL

VENDING BEZEL

• Taiko vending bezel

• Available in 67mm and

82mm note widths

J C M   B I L L   A C C E P T O R S

JCM TAIKO SPARES LIST

• Spares List for jCm Taiko

• Need further information?

[email protected]

Part #

47200220

Part #

47200314

Description

1

115508 LEVER SPRING

2

090776 PARALLEL PIN CONNECTOR

3

127664 ROLLER ASSY

4

115545 TRANSPORT mOTOR ASSY

5

110867 CENTRE GUIDE A

6

137778 CPU BOARD

7

137777 SENSOR BOARD

8

110875 GUIDE LEVER

9

110871 UPPER GUIDE

Part #

47200339

47200340

47200341

47200342

47200343

47200344

47200345

47200346

47200347

1 115508

Description

143687 TAIKO VENDING BEZEL

Part #

47200315

EBA COMPATIBLE BEZEL fOR TAIKO

• Bezel is highly recommended for replacing EBA 2x or 1x with

Taiko bill acceptor

• Available in 68mm, 71mm and 76mm note widths

3 127664

Description

189452 TAIKO BEZEL 68mm NOTE WIDTh

189453 TAIKO BEZEL 71mm NOTE WIDTh

187826 TAIKO BEZEL 76mm NOTE WIDTh

Part #

47200632

47200631

47200633

5 110867

WHY SHOULD MY COMPANY BUY THIS?

Taiko is a powerful, compact, and highly secure note validator designed for public sites everywhere. Its unique

‘drum’ technology makes

‘note fishing’ fraud virtually impossible.

7 137777

9 110871

+44 (0)1707 280 028       [email protected]

2 090776

4 115545

6 137778

8 110875

10

J C M   B I L L   A C C E P T O R S

11

WHY SHOULD MY COMPANY BUY THIS?

The addition of a note recycler means that the Vega can both accept and pay back notes, a time saving feature which is convenient to both operators and users alike.

• multiple protocols in one software

• Compact with lockable, removable cashbox

• Sensor path sealed against dust and liquids

• high precision sensor technology

• ESCROW – one bank note

• CE & UL approval

• multiple interface protocols in one package

www.eurocoin.co.uk

JCM VEGA & VEGA RC

Vega is the next generation of bill acceptors. Vega features an optional Bill Recycler which will payout up to

30 notes to customers using banknotes as opposed to the traditional coin payout method.

The Vega recycler can be conveniently mounted on top of the acceptor, and benefits both operators and users alike in terms of cost and convenience.

Vega is equipped with a lockable, removable cash box and can use either an up or down stacker.

Software downloads can be made via USB in less than 1 minute, and multiple interface protocols are supported.

Advanced and precise sensor technology ensures secure validation, combined with a gate mechanism preventing

‘stringing’ and fraud.

The Vega is able to be installed in almost every kind of terminal, and the recycler reduces the necessity for on-site cashiers and eliminates the issue of coin jams and empty hoppers.

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS 

Vega

Vega-RC

WEIGHT

Unit

Unit & Cashbox

104mm W x 168mm D x 233.5mm h

104mm W x 285mm D x 233.5mm h

2.0 kg

2.8 kg

Unit, Cashbox & Recycler 3.1 kg

INTERfACE OPTIONS          Photo-coupler Isolation,

RS232C, ccTalk, Serial, mDB

POWER REqUIREMENTS

Vega 12vdc 2 A

Vega-RC

NOTE WIDTHS

12vdc 5 A

60 to 82mm

CASHBOx CAPACITY 300 notes std, 1000 optional

ACCEPTANCE RATE

98% or higher

VALIDATION SPEED

3 seconds per note

Description jCm VEGA jCm CAShBOx VEGA jCm VEGA R/C

• All major areas, including bill path, accessible without tools

Part #

47200xxx

47200xxx

• Optional programmable bill recycler

• highly secure anti-stringing technology

• Recycler cacapity - 30 notes; note recycle feature is operator manageable by dip-switch

• Available with DES encryption

J C M   B I L L   A C C E P T O R S

JCM VEGA TWIN

The latest addition to the Vega family of products. Vega

Twin enables the recycling of two banknote denominations. The Vega Twin has an instant attraction to existing Vega RC users, as the Twin Note Recycler Unit will retrofit to the jCm Vega head, requiring only a simple firmware upgrade.

It has the ability to hold and recycle two banknotes, with a capacity of 30 bills in each denomination.

The Vega Twin RC model is 20mm taller than the original

Vega RC, so that upgrading machine cabinets to the dual note functionality should not present any problems to existing Vega users.

The Twin RC unit offers a number of technical and security enhancements that make the note validation and repayment process fast and efficient.

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS 

Vega RC Twin 104mm W x 285mm D x 253.5mm h

WEIGHT

Unit

Unit & Cashbox

2.0 kg

2.8 kg

Unit, Cashbox & Recycler 3.1 kg

INTERfACE OPTIONS          Photo-coupler Isolation,

RS232C, ccTalk, Serial, mDB

POWER REqUIREMENTS

Vega RC Twin

NOTE WIDTHS

12vdc 5 A

60 to 82mm

CASHBOx CAPACITY 300 notes std, 1000 optional

ACCEPTANCE RATE

VALIDATION SPEED

98% or higher

3 seconds per note

Description jCm VEGA RC TWIN

Part #

472011xx

• VEGA RC Twin is a compact note recycler for two denominations (30 notes each).

• Only 20mm more in height than VEGA RC single denomination recycler.

• Width & Depth remain the same as VEGA-RC single drum.

• Field upgradeable from VEGA RC single drum to

VEGA RC Twin.

• Security : Banknotes cannot be accessed when the rear cover is open.

+44 (0)1707 280 028       [email protected]

12

J C M   B I L L   A C C E P T O R S

JCM EBA-40

The EBA-40 Note acceptor is the newest in the European

Bill Acceptor series, boasting faster processing speeds, better acceptance rates and full compatibility with its predecessor.

The EBA-40 allows plug & play upgrade from the EBA-3x series, one of the most widely used bill validators in its class in Europe. Eurocoin are proud to provide this acceptor as the replacement for the EBA 3x series.

T E C H N I C A L   S P E C I f I C AT I O N S

ACCEPTANCE RATE

BANKNOTE RISE

98%+

62-85mm

PROCESSING SPEED

CASH BOx CAPACITY

INTERfACES

TTL Serial Interface, mDB Interface, CCTalk,

Photo-Coupler Interface, RS232C

USB (USB Spec. Rev. 2.0 Compliance)

PROTOCOLS

ID-003 Serial, ID-008 USB

ID-0D3, ID-002 Pulsed

POWER REq (WITH STACKER)

OPERATING TEMP

1.8 Seconds

400 Notes (New)

+12V ± 5% DC

+24V ± 5% DC

25°C ± 5°C

13

• Proven Anti-Pullback Technology

• Automatic Centering

• Automatic Re-Validation (Selectable)

• Able to Accept up to 85mm Wide Banknotes

Description jCm EBA 40 NOTE ACCEPTOR

Part #

47201515

• Semi-Security Removable Cash Box mDB Ready

• Integrated mechanical PB (Anti Stringing / Fishing)

Unit

www.eurocoin.co.uk

J C M   B I L L   A C C E P T O R S

JCM DBV-400/500 BILL

VALIDATORS

jCm Global’s all new DBV-400 series has been meticulously developed based on our 25 years of experience in bill validation technology. The robust design, increased processing speed, and state-of-the-art sensor technology combine to make the DBV-400 the best choice for a wide range of automated payment applications.

In addition, the universal design of the DBV-500 supports most major currencies without any hardware modification.

T E C H N I C A L   S P E C I f I C AT I O N S

ACCEPTANCE RATE

98% + (DBV-400)

90% + (DBV-500)

BANKNOTE SIZE

60-72mm, 110-160mm (Width,Length)

CAPACITIES

S: 300/500 notes m: 500/1000 notes

L: 1000/1500 notes

INTERfACES

RS232C, TTL, Photo-coupler, USB

PROTOCOLS

ID-003 Serial, ID-008 USB, ID-044 Vend Serial,

ID-0D3 mDB, ID-002 Pulsed

POWER REq.

12-24VDC (12V, max 1.9A - 24V, max 0.96A)

OPERATING TEMP

OPTIONS

-15˚C to +60˚C

Bezel with Lighted Logo (DBV 400 Only)

• Robust design with thick plastic frame

• Cash box capacity options

300/500/1000 notes (DBV-400)

500/1000/1500 notes (DBV-500)

• Under 2 seconds for note-to-note acceptance

• 6-8 wavelengths of high-precision optical sensors

• Designed to work at -15°C and up to +60°C

Description jCm DBV-400/500 BILL VALIDATORS

Part #

TBA

• Sleep mode supported as standard

• Full color illuminated insertion slot (DBV-400 Only)

• Optical and mechanical anti-stringing and antifishing sensors

• Less risk of damage by mishandling, lower cost of ownership

• multiple capacity options, fewer cash box pick-up equal reduced operational cost

• Increases operational efficiency and improves user satisfaction

+44 (0)1707 280 028       [email protected]

14

15

J C M   B I L L   A C C E P T O R S

JCM DBV 30x SERIES

The DBV provides the high quality and excellent security expected of any jCm bill acceptor, with the additional benefits of supporting handhelds and the RC-10 note recycling unit.

DBV enables technical support and data downloads via hand-held PDAs, allowing software updates, accounting overviews, statistic downloads and function testing to be done on site.

maximum security is provided against counterfeits through use of both reflection and transmission sensors, all of which are integrated and protected from environmental damage.

With a compact and modern design, and the ability to stack up or down, the DBV is suitable for a wide range of applications, and when combined with the RC-10 enables terminals to both accept and dispense notes.

An optional 1,000 capacity cashbox is available, and with a processing speed of approximately 2 notes per second, the DBV is efficient as well as secure.

• Optical and magnetic validation to ensure security against counterfeits

• Optional Security Bezel

• Optional cashbox with 1,000 note capacity

• Can be combined with RC-10 to provide note accepting and dispensing unit

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS 

300 106.6mm W x 168.5mm D x 249.6mm h

500

1000

106.6mm W x 192.5mm D x 249.6mm h

106.6mm W x 291.5mm D x 249.6mm h

RC-10 104.5mm W x 155.0mm D x 426.0mm h

WEIGHT 

jCm DBV 30x 1.2 kg

RC-10 2.1 kg

INTERfACE OPTIONS         mDB, TTL, RS-232, Photo

Coupler, Pulse, Serial

NOTE WIDTHS

CASHBOx CAPACITY

62 to 72mm

300, 500 and 1000

ACCEPTANCE RATE

95% or higher

VALIDATION SPEED 2 secs - approx 4 secs (RC-10)

RECYCLING CAPACITY                           max 11 notes

Description jCm DBV 30x SERIES

Part #

47200xxx

• Technical support and data downloads via handheld PDAs

• Easy maintenance access

• Built-in auditing function

• Diagnostics LED

• Optional cashbox with 500 and 1,000 note capacity

www.eurocoin.co.uk

J C M   B I L L   A C C E P T O R S

JCM TBV

The new TBV™ is the most efficient and advanced

Transactional Bill Validator to emerge yet.

Designed exclusively for commercial use, the TBV™ can be used for single or bulk note transactions. It can accept up to 50 mixed denomination notes at a time while still maintaining the fastest current processing speed of 2 seconds or less.

Notes are processed from the bottom, allowing additional notes to be added, while rejected notes are returned in a separate slot without slowing the process.

The double locking cashbox has the largest current capacity at 2,000 notes, while being impact resistant and easily accessible.

Self-centering technology allows acceptance of all currencies up to 85mm wide, and multiple currencies can be inserted at once.

Advanced sensor technology gives counterfeit detection on 6 wavelengths, ensuring optimum security.

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS 114mm W x 468.9mm D x 475.8mm h

WEIGHT

12 Kg

INTERfACE OPTIONS

Photo-coupler, RS-232, ccTalk

POWER REqUIREMENTS

24vdc 5.3A maximum

NOTE WIDTH

60 - 85mm

CASHBOx CAPACITY

ACCEPTANCE RATE

VALIDATION SPEED

2000

98% or higher

2 seconds (variable width)

WHY SHOULD MY COMPANY BUY THIS?

The TBV can accept up to 50 mixed denomination notes in one transaction, yet still maintains a processing speed of 2 seconds or less. It is ideal for the fast, secure banknote counting and storage applications.

• Options – Bezel for single feed, metal bezel, stacker-less frame, bulk note feed assembly

• Superior sensing technology with 6 wavelengths of optical sensors (IR, red, green, blue, orange, UV) plus magnetic head

• Bulk note feeder capable of accepting 50 notes in one process

• Self-centering mechanism allows notes of different widths to be inserted simultaneously

Description jCm TBV jCm CAShBOx TBV

Part #

47200xxx

47200xxx

• Barcode scanner accepts in 2 ways

• Accepts different currencies (RUS, USD or EUR) only one at a time.

• Durable and high impact resistant cashbox is removable and double lockable with easy access side door

• ICB compatible in order to reduce accounting variances, reduce drop process time consumption and eliminate manual intervention through a reliable and automated process

+44 (0)1707 280 028       [email protected]

16

J C M   B I L L   A C C E P T O R S

JCM BILL ACCEPTORS  

END-Of-LIfE NOTIfICATION fOR WBA, EBA 2x AND 3x

jCm have given notice that the WBA, EBA 2x and EBA 3x series are now all in end-of-life status, meaning that device production and on-going software support have now been withdrawn.

Eurocoin are able to continue to provide some essential spare parts for these units at this time, but stocks are in decline. WBA, EBA 2x and EBA 3x device users, therefore, should now work with the Eurocoin Customer Service team to migrate their machines and kiosks over to the designated replacement jCm devices, as summarised below:

JCM  WBA - Clients should upgrade to UBA, iPRO or iVIZION

JCM 2x - Clients should upgrade to EBA 4x series

JCM  3x - Will go end-of-life on 31.12.16. Customers should start to migrate to EBA 4x series

17

Full details of all these models are contained in this catalogue, and direct support & assistance can be provided from any of our European E-Service offices.

EUROPE-WIDE SERVICE AND SUPPORT fROM OUR REGIONAL OffICES

UK & Eire

Tel: + 44 1707 280028 [email protected]

www.e-service.co.uk

Italy

Tel: + 39 328 1259421 [email protected]

www.e-service-italia.it

Spain

Tel: + 34 608 58 22 28 [email protected]

www.e-service-espana.es

Poland

Tel: + 48 501 533 041 [email protected]

www.e-service-central.pl

Romania

Tel: + 40 213 210 779 [email protected]

www.e-service-romania.ro

Serbia

Tel : +38 112 540920 [email protected]

www.eurocoin.rs

Hungary

Tel: +36 20553 3228 [email protected]

www.kiosk.novoparts.hu

www.eurocoin.co.uk

J C M   B I L L   A C C E P T O R S

JCM EBA 3x CASHBOx

• 120823 EBA 3x-SD30 cashbox only

• Locks supplied separately

• Capacity: 400 Notes

1 119334 2 117650

Description jCm CAShBOx EBA 3x

Part #

47200240

JCM EBA 3x fACEPLATE

• 094263 EBA 3x black faceplate

• Green LED

• Note Width: 85mm

Description jCm EBA FACEPLATE

Part #

47200325

3 118863

5 119287

JCM EBA 3x SPARES LIST

• Spares List for jCm EBA 3x

• Need further information?

[email protected]

7 094774

9 119329

Description

1

119334 GEAR ROLLER FINAL

2

117650 CPU BOARD EBA 34

3

118863 CPU BOARD EBA 32/33

4

118868 SENSOR BOARD EBA 3x

5

119287 SENSOR COVER

6

091079 SQUARE PRISm

7

094774 LED BOARD

8

119288 SENSOR COVERS

9

119329 GEARBOx ROLL COVER

10

119282 mOVE GUIDE A

11

119283 mOVE GUIDE B

12

089443 STEPPING mOTOR

13

119277 GUIDE 30 A EBA 3x

14

119278 GUIDE 30 B EBA 3x

15

119279 GUIDE 30 CR

16

118865 STACKER BOARD

17

119307 BEARING ROLLER

18

119387 PRISm BOx EBA 3x

Part #

47200162

47200236

47200331

47200218

47200358

47200359

47200360

47200361

47200362

47200364

47200365

47200366

47200367

47200353

47200368

47200369

47200370

47200371

11   119283

13   119277

15   119279

17   119307

+44 (0)1707 280 028       [email protected]

4 118868

6 091079

8 119288

10   119282

12   089443

14   119278

16   118865

18   119387

18

19

J C M   B I L L   A C C E P T O R S

JCM ICB

The Intelligent Cashbox system (ICB) is a superb accounting tool from jCm, allowing clients to read and record every bank note denomination in the note acceptor stacker without opening the device. It is high speed, low cost, and provides excellent security and efficiency for venues large or small.

The jCm ICB system consists of a read/write tool, a software programme and an optional receipt printer.

Any jCm stacker with the correct memory module fitted may be inserted into the read/write tool, and have each banknote and ticket read in seconds. The detailed result is then recorded in the software and an optional receipt can be printed for use in banking or accounting procedures. All data is automatically recorded against the correct machine serial number, and is easily extracted to an Excel spreadsheet.

ICB eliminates the possibility of human error during the cash collection and count processes, as all necessary information is stored in the cashbox memory rather than manually recorded.

Independent data is supplied directly from the bill validator, and the ICB is password protected, ensuring complete security of records.

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS

Read Write Tool 140mm W x 267mm D x 830mm h

Printer

COMPATIBILITY

140mm W x 305mm D x 140mm h

ICB functions with all jCm WBA and UBA stackers with upgraded memory modules. jCm iVizion is supplied ICB-ready

OUTPUTS 

2 x Serial outputs for printer & PC connections

Description jCm ICB

Part #

47200xxx i

• Increases accountancy accuracy

• Eliminates human error in accounting process

• Compatible with iVizion, WBA and UBA Series

• Internal memory stores all necessary information for every transaction accepted

• Automates cashboxes across the gaming floor

• Cashbox automatically linked to host machine

• Available in metal or lightweight, durable plastic

• ICB Software Reports can be customised to provide complete breakdown of banknote and ticket denominations

www.eurocoin.co.uk

J C M   B I L L   A C C E P T O R S

BLUEWAVE DELUxE

TM

The jCm DT300 Bluewave Deluxe is the latest generation of jCm's handheld programming tools, designed to upgrade jCm bill acceptors quickly and easily, right at your machine or kiosk terminal.

Up to 20 different software files can be stored on the SD card, and details are displayed on the Bluewave Deluxe

LCD screen.

machine and Kiosk operators now require just one jCm tool to upgrade all jCm bill acceptor models - see our

'Specification' tab for a full list of models.

The DT300 will make all your banknote validator upgrades, quick, simple and cost-effective.

TAIKO PUB 7 SERIAL HARNESS

• Connecting Serial harness for Taiko Pub 7 validator

• Connects Taiko to Serial

Adaptor Box for BlueWave

2.0

Description

400-000087R TAIKO PUB 7 SERIAL hARNESS

Part #

47200705

T E C H N I C A L   S P E C I f I C AT I O N S

USER INTERfACE

menu driven

COMPATIBILITY

UBA, iVIZION, VEGA, iPRO, TBV...

STORAGE

Supports multiple Firmware

VOLTAGE

4 AAA Alkaline Batteries (6.0VDC max)

MEMORY

2GB SD Card

Description Part #

BLUEWAVE DELUxE hANDhELD INC. USB CABLE + 2GB SD 47200950

WBA SERIAL HARNESS

• Connecting Serial harness for WBA validator

• Connects WBA to

Serial Adaptor Box for

BlueWave 2.0

EBA 3x SERIAL HARNESS

• Connecting Serial harness for EBA 3x validator

• Connects EBA 3x to

Serial Adaptor Box for

BlueWave 2.0

Description

400-000086R WBA SERIAL hARNESS

Part #

47200702

Description

400-000088R EBA SERIAL hARNESS

+44 (0)1707 280 028       [email protected]

Part #

47200706

20

21

J C M   B I L L   A C C E P T O R S

MERKUR DISPENSER

The merkur Dispenser 100 is a highly reliable and secure note validator and payout device, capable of accepting all European currencies.

It features a unique and patented vault area, where 3 separate storage drums hold banknotes waiting to be paid out. Priority banknote values or combinations for payouts can be assigned. The dispenser can return up to

100 notes of 3 denominations.

If a storage drum reaches maximum capacity, the dispenser cleverly routes additional inserted bank notes to the stacker. All banknote denominations which have not been selected for repayment are likewise deposited in the stacker. The unit has a cashier function that will automatically transfer all notes from the dispenser to the cashbox for easy reconciliation.

Patented encrypted communications between the device components ensures maximum security. The jCm bill validator head, stacker, and vault all have their own independent locking mechanisms, and banknotes are validated on both insertion and payout.

The dispenser records its own statistics on the content of the three banknote drums; this data is fully protected when the unit is disconnected from the mains power and can be transferred automatically to the host machine or device.

• Lockable cashbox, capacity approx 400 notes

• Ability to accept and dispense 3 different types of banknote

• Capable of accepting all European currencies

• Intelligent ‘self-test’ function at each start up

(light sensors, belt tension, cashboxes and currency transport areas)

• high protection against electrostatic discharge

T E C H N I C A L   S P E C I f I C AT I O N S

DIMENSIONS

115mm W x 255mm D x 455mm h

POWER REqUIREMENT 

+ 24vdc

BANK NOTES ACCEPTED

INTERfACE OPTIONS

Customer Specified

- all European Currencies ccTalk

BANK NOTES ISSUED

Up to 3 denominations

DISPENSER CAPACITY

Up to 3 denominations, maximum 34 of each denomination

STACKER CAPACITY

Approx 400 notes

Description mERKUR DISPENSER 100

600 NOTE CASSETTE

REAR mOUNT BRACKET FOR mERKUR

CCTALK BOARD

Part #

477xxxxx

47701001 xxxxxxxx xxxxxxxx

• 5 light sensors monitor the bank note transport while 9 sensors monitor activity of the 3 storage drums

• modular design enables easy replacement of individual parts

• Removal of dispenser achieved via simple locking mechanism

• Ideally suited to busy retail kiosks, gaming and vending machines and change givers, where a high level of transactions take place daily

www.eurocoin.co.uk

J C M   B I L L   A C C E P T O R S

Europe’s finest TITO Products  

World Class Brands. Proven Performance. Superb Support.

To find out how Eurocoin can help your business convert to TITO, please contact us at

[email protected]

or call

+44 (0) 208 275 3000

+44 (0)1707 280 028       [email protected]

22

[email protected]    www.eurocoin.co.uk  

+44 (0)1707 280 028

BILL ACCEPTORS

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
