Dear Reader,

Thanks for taking an interest in Focusrite!

Since 1985 Focusrite remains the go-to brand for the best in analogue signal processing. But time moves on and we have kept up with the changes in the recording industry with the move to Digital Audio

Workstations (DAWs). Our product range now not only includes our “heritage” ISA series, which has its roots in the 1980’s with transformer-coupled microphone preamps and the legendary Focusrite EQ, but also hybrid analogue / digital signal processing found in the Liquid family.

Digital conversion is today as much our expertise as is microphone pre-amplifier design. The ISA One Digital features A/D conversion that out-performs any other product anywhere near its price bracket in terms of dynamic range, noise and jitter.

Indeed, all our ISA A/D converter cards are the equal of, and in some cases out-perform, the best converter brands available, and often at a fraction of the price.

Which brings me to our fastest-growing business segment today: Audio Interfaces.

Our new Scarlett USB 2.0 and secondgeneration Saffire Audio Interfaces are truly

State-of-the-Art delivering on one simple promise – the best sound in their class.

The growing range includes products for all pockets and requirement levels, from the Saffire 6 USB - our entry-level interface

- to the Liquid Saffire 56, which combines two channels of Liquid mic-pre emulation with six Focusrite Saffire mic pres, specially designed for the Saffire Range. RedNet goes one step further, using innovative networking technology and standard ethernet protocols to completely redefine how we see the modern recording studio.

So we are both Focusrite - the Heritage

Analogue Audio Company, and Focusrite -

The Interface Company. Old School and

New School. We aim to continue to be the best of both. I hope you will join our family of satisfied customers.

Phil Dudderidge

Owner & Managing Director

REDNET ............................................................................. 4

Liquid Saffire 56 ............................................................... 6

Saffire PRO 40 .................................................................. 8

Saffire PRO 24 .................................................................. 9

Saffire PRO 24 DSP ..........................................................10

VRM Box ..........................................................................11

What is VRM ....................................................................12

Saffire PRO 14 .................................................................13

Saffire 6 USB ...................................................................14

Scarlett 8i6 ......................................................................15

Interface Comparison Chart ...........................................15

Scarlett 18i6 ....................................................................16

Saffire /Scarlett MixControl ...........................................17

Pro Tools 9 Now Focusrite Ready ....................................18

Midnight ...........................................................................19

OctoPre MkII ................................................................... 20

OctoPre MkII Dynamic .................................................... 21

Focusrite Artists ............................................................ 22

The Liquid Channel ........................................................ 24

Liquid Mix HD ................................................................. 26

ISA430 MkII .................................................................... 27

ISA828 ............................................................................ 28

ISA428 MkII .................................................................... 29

Digital Card Options ....................................................... 29

ISA One ........................................................................... 30

Focusrite would like to thank the Academy of Contemporary Music, Guildford and Simon Changer at The Church Studios for allowing us to photograph their facilities.

the comPonents

RedNet 1 and 2: 8 and 16 channel AD-DA Interfaces

RedNet 1 and 2 feature Focusrite’s precision 24-bit AD and DA conversion for superb audio performance, with 120dB dynamic range at sample rates up to 192kHz. RedNet 1 provides eight channels; RedNet 2, 16 channels.

RedNet 3: Digital I/O

RedNet 3 interfaces existing digital audio systems and components up to a maximum of 32 inputs and outputs. Sixteen ADAT optical ports provide a full 32 digital channels in and out at up to

96kHz (S-MUX2). Support for AES, S/PDIF and ADAT digital audio formats and word clock.

RedNet is Focusrite’s powerful new scalable professional digital audio networking system, delivering everything you need in a studio environment. Using standard, robust and reliable Internet Protocol (IP) networking technology to carry high resolution audio over a standard Ethernet network, RedNet makes studio design, installation and configuration easier than ever before.

RedNet 4: Eight Microphone preamps/line inputs

RedNet 4 provides eight specially-designed Focusrite mic preamps and line inputs with two selectable DIs – plus Focusrite world-class precision AD conversion and specially-crafted mic preamps. Front panel or remote control.

4

At its heart is the robust, tried-and-tested Dante™ digital audio networking technology, from Audinate. Dante uses standard Gigabit Ethernet networking components to carry up to 128 inputs and 128 outputs over standard Ethernet.

Dante has become a standard in live sound, frequently relied on for major events.

Focusrite brings Dante into the heart of the studio with versatile, superb-quality audio interfaces that will revolutionise everything in your studio – from wiring to workflow. And unlike other digital audio systems, RedNet is non-proprietary, working with any ASIO or Core Audio compliant DAW software including Pro Tools 9, Logic and Nuendo.

THE RANgE

RedNet initially comprises five products. Four high-quality, versatile interfaces deliver traditional Focusrite ethos and performance, where sound is everything, with exceptional value for money. Accompanying these is the optional RedNet

PCIe card, delivering under 3mS latency at any sample rate*.

*Latency under 3mS requires the RedNet PCIe card and a DAW buffer setting of 32 samples or less

Every analogue interface features 120dB dynamic range, 24-bit resolution and sample rates up to 192kHz. Each embodies the most advanced conversion designs and components on the market. Each includes JetPLL™ for ultra-low-jitter clock recovery. The result: quality that is, quite literally, second to none.

SIgN UP TO THE REDNET NEWSLETTER

Get access all the latest updates and news www.focusrite.com/rednetnewsletter

RedNet Low-Latency PCIe Card

Where low latency is critical, such as tracking, the RedNet PCIe card for Mac or Windows delivers sub-3mS latency, 128 inputs and outputs, and sample rates from 44.1 to 192kHz. A standard Ethernet RJ45 connects to your network. Alternatively, use the Dante Virtual Soundcard (DVS) and your machine’s built-in Ethernet port, for latency comparable to Focusrite FireWire interfaces.

5

Liquid Saffire 56

Professional firewire

®

audio interface featuring liquid mic PreamPs

Liquid Saffire 56 is Focusrite’s flagship 2U multi-channel

FireWire audio interface. Liquid technology combines with

Saffire PRO FireWire interfacing to deliver a host of authentic preamp flavours, seamless software integration, excellent routing flexibility and future-proof, rock-solid driver stability.

• Two Liquid mic preamps

The marriage of a flexible analogue front end with

cutting-edge Dynamic Convolution™ DSP. Each Liquid preamp

lets you choose from ten different classic preamp emulations.

• Six high quality award-winning Focusrite mic preamps

Six Saffire mic preamps complement two Liquid preamps.

All eight preamps demonstrate the same wide bandwidth

philosophy behind the early vintage Focusrite units.

High quality 24-bit/192kHz FireWire Interface

Professional digital conversion and JetPLL™ jitter

reduction technology; pristine audio quality and

reliable synchronisation are guaranteed.

• Total I/O count of 28 inputs and 28 outputs

A host of I/O options are provided, including a unique

loop-back facility for routing audio between software

applications via Saffire MixControl.

• Saffire MixControl ultra-low-latency DSP mixer/router

Provides an 18 x 16 DSP mixer with excellent routing

flexibility, intuitive one-click mixing configurations, and

lower than 1.4ms latency (less than the time it takes

sound to travel two feet through air!).

Saffire MixControl

Liquid preamp remote control

6

FireWire and the FireWire symbol are trademarks of Apple Inc., registered in the U.S. and other countries.

The FireWire logo is a trademark od Apple Inc.

Focusrite VST/AU plug-in suite

FEATURED EMULATIONS:

RED 1 H - BASED ON THE FOCUSRITE RED 1 QUAD CLASS A MIC-PRE

CLASS A 2A - BASED ON THE NEVE 1073 MONO MIC-PRE

TRANY H - BASED ON THE API 3124+ DISCRETE QUAD MIC-PRE

SILVER 2 - BASED ON THE AVALON VT-737SP VALVE CHANNEL STRIP

SAVILLEROW - BASED ON THE HELIOS CONSOLE MIC-PRE / EQ MODULE

DUNK - BASED ON THE MANLEy SLAM! TRANSFORMER / VALVE MIC-PRE

NEW AGE 1 - BASED ON THE MILLENIA HV-3D 8 CHANNEL MIC-PRE

OLD TUBE - BASED ON THE PULTEC MB-1 FIXED GAIN VALVE MIC-PRE

DEUTSCH 72 - BASED ON THE TELEFUNKEN V72 VALVE MIC-PRE

STELLAR 1B - BASED ON THE UNIVERSAL AUDIO M610 MONO TUBE MIC-PRE

IMPORTANT INFORMATION: FOCUSRITE, the FF logo, LIQUID TECHNOLOGY and the LIQUID logo, and SAFFIRE are trademarks of Focusrite Audio Engineering Limited. DYNAMIC CONVOLUTION is a trade mark of Sintefex Ltd. All other product names, trade marks, or trade names are the names of their respective owners, which are in no way associated, connected nor affiliated with Focusrite or its LIQUID SAFFIRE 56 product and which have not endorsed Focusrite’s

LIQUID SAFFIRE 56 product. These other product names, trade marks, and trade names are used solely to identify and describe the third party products the sonic behaviour of which was studied for the LIQUID SAFFIRE 56 product, and to accurately describe the functionality of the LIQUID SAFFIRE 56 product. The LIQUID SAFFIRE 56 product is an independently engineered technology which utilises the patented process of Dynamic Convolution to actually measure examples of the sonic impact of original analogue products upon an audio stream, so as to electronically emulate the performance of the original product studied. The result of this process is subjective and may not be perceived by a user as producing the same effects as the original products studied.

7

8

Saffire PRO 40

firewire audio interface featuring eight focusrite mic PreamPs

The Focusrite Saffire PRO 40 represents the latest generation of Focusrite multi-channel FireWire audio interfaces. An unparalleled preamp legacy forms the foundation, with eight award-winning Focusrite preamps. Legendary sonic performance is combined with the very latest in FireWire interfacing technology to deliver seamless integration, excellent routing flexibility and, rock-solid driver stability.

• Eight high quality award-winning Focusrite preamps

Upholding Focusrite’s high bandwidth (20Hz to 200kHz!)

philosophy, ensuring low noise and distortion whilst

delivering clarity without unwanted artefacts.

• High quality 24-bit/96kHz FireWire interface

Features high quality A-D / D-A conversion and JetPLL™

jitter reduction technology; pristine audio quality

and reliable synchronisation are guaranteed.

• Total I/O count of 20 inputs and 20 outputs

A host of I/O options are provided, including a unique

loop-back facility for routing audio between software

applications via Saffire MixControl.

• Suite of Focusrite VST/AU plug-ins

Upgrade your standard sequencer effects with

all-new Focusrite Compression, Reverb, Gating and EQ

VST/AU plug-ins.

• Two separate headphone buses

Two artists can receive independent and fully customised

monitor mixes. Each output has an independent level

control available on the front panel.

• Two Hi-Z instrument inputs

No need for a separate DI. The first two channels feature

instrument inputs with switchable Hi-Z.

• Saffire MixControl ultra-low-latency DSP mixer/router

Provides an 18 x 16 DSP mixer with excellent routing

flexibility, intuitive one-click mixing configurations, and

lower than 1.4ms latency (less than the time it takes sound

to travel two feet through air!).

Saffire PRO 24

16 in / 8 out firewire audio interface featuring two focusrite mic PreamPs

The Focusrite Saffire PRO 24 is a 16 in /

8 out FireWire audio interface designed for the modern home studio environment.

An unparalleled preamp legacy forms the foundation, with two award-winning

Focusrite preamps. Legendary sonic performance and a host of I/O options combine with the very latest in MixControl software to deliver seamless integration, excellent routing flexibility and rock-solid driver stability.

• Two high quality award-winning

Focusrite mic pres

• High Quality 24-bit/96kHz

FireWire interface

• Total I/O count of 16 inputs and 8 outputs

• Saffire MixControl ultra-low-latency

DSP mixer/router

• Class-leading LED metering

• Focusrite VST/AU plug-in suite, for use

in the mix

• Unmatched routing flexibility

ADDITIONAL FEATURES:

Dedicated front-panel headphone bus, Bus-powering, Two Hi-Z instrument inputs, Tactile main monitor dial, Switchable phantom power, Software PFL

9

10

Saffire PRO 24 DSP

firewire audio interface with real-time dsP-Powered tracKing and miXing solutions

The Focusrite Saffire PRO 24 DSP is a 16 in

/ 8 out FireWire audio interface, featuring real-time DSP-powered tracking and mixing solutions tailor-made for the modern home studio environment. Alongside DSP-powered

Compression and EQ for ultra-low-latency tracking and ‘comfort’ reverb, is VRM; a Virtual Reference Monitoring technology that lets you hear your mix in different environments, through different speakers and from different positions, all just using headphones.

• Virtual Reference Monitoring (VRM)

• Two high quality award-winning

Focusrite preamps

• Onboard DSP-powered, tracking

and mixing tools

• High Quality 24-bit/96kHz

FireWire interface

• Total I/O count of 16 inputs and 8 outputs

• Saffire MixControl ultra-low-latency

DSP mixer/router

• Focusrite VST/AU plug-in suite, for use

in the mix

• Two dedicated front-panel

headphone busses

• Bus-powered for mobile recording

VRM Box

comPact headPhones monitoring sYstem with Virtual reference monitoring

Pocket sized and built to last, VRM Box places Focusrite’s Virtual Reference

Monitoring (VRM) technology in a robust, palm-sized audio interface. VRM Box functions as a high-quality 24-bit/48kHz USB audio playback interface, compatible with

Pro Tools 9 or any other open DAW software.

VRM Box also features a digital (S/PDIF) input, which supports sample rates up to

192kHz, allowing you to run it in conjunction with Pro Tools HD or any other interface with an S/PDIF output.

• 24 Different Mix References

Virtual Reference Monitoring (VRM) from

Focusrite lets you audition your mix in different environments, through different speakers, just using headphones.

• Hear Everything

Boasting a dynamic range of 108dB, VRM

Box delivers a high-quality reproduction of your sound, ensuring you hear everything.

• Ultimate Playback Interface

Whether you’re mixing, creating music or simply listening to tracks, VRM Box is the perfect playback interface for your digital audio software.

• Pro Tools Friendly

VRM Box features a digital input, allowing you to run it alongside your

Pro Tools interface or any interface with an S/PDIF output.

Listen to VRM in action here:

www.focusrite.com/vrm_sampler

11

12

What is VRM?

Convenient though headphones may be, they’re simply not the same as listening on a pair of monitor loudspeakers. And yet… listening on one pair of monitor speakers isn’t enough either. To tell how your music will sound in the real world, you need to listen in different environments, with different speakers. Until now, you had to burn a CD or transfer a file and play it back on real systems in actual environments to A/B your mixes in different places. But now, there’s a better way.

VIRTUAL REFERENCE MONITORINg

The answer is Focusrite’s unique and well-established VRM™ (Virtual Reference Monitoring) technology – a room and loudspeaker simulation system for headphone monitoring. While listening on conventional monitoring headphones, VRM lets you select your listening environment – pro studio, bedroom studio or living room – and choose from an extensive list of industry-standard studio monitors and loudspeaker systems to listen on.

VRM’s extensive selection of built-in loudspeakers and listening environments is based on precise mathematical models derived from convolutions of actual impulse responses measured using the original loudspeakers. The use of mathematical modelling provides maximum flexibility of combinations of loudspeakers and listening environments for the highest possible accuracy of the virtual monitoring simulation.

VRM allows you to choose between 10 pairs of industry-standard nearfield monitors in an acoustically-treated control room. In addition, two extra rooms are provided – a large living room and a smaller bedroom – where you can choose between speakers such as quality hi-fi, computer, cheap stereo and TV speakers.

VRM GUI featured on the Saffire 24 DSP (part of Saffire MixControl)

VRM gUI featured on the VRM Box

CHOOSE FROM 15 INDUSTRy-STANDARD STUDIO MONITORS AND SPEAKERS

Saffire PRO 14

8 in / 6 out firewire audio interface featuring two focusrite mic PreamPs

The Saffire PRO 14 is an 8 in / 6 out audio interface with legendary sonic performance and unmatched flexibility at a truly affordable price. The latest in Focusrite’s new generation of FireWire audio interfaces, the Saffire PRO 14 is designed to make home studio recording and mixing easy without sacrificing audio quality. Twenty-five years of mic pre excellence form the foundation of this new interface, with two award-winning

Focusrite preamps. Combined with a host of additional I/O options, the Saffire PRO 14 helps you get the tracks you want without having to constantly re-patch your studio.

• Two award-winning Focusrite preamps

• High quality 24-bit/96kHz

FireWire interface

• Total I/O count of 8 inputs and 6 outputs

• Two Hi-Z instrument inputs

• Saffire MixControl ultra-low-latency

DSP mixer/router

• Focusrite VST/AU plug-in suite, for use

in the mix

• Xcite+ software bundle

• Bus-powered for a tidy mobile

recording rig

13

14

Saffire 6 USB

2 in / 4 out usB audio interface featuring two focusrite mic PreamPs

The Focusrite Saffire 6 USB focuses on just one thing – quality of sound. Whether you’re a singer song-writer who wants to record, or a laptop DJ, Saffire 6 USB will make the most of your sound. Two Focusrite mic preamps, professional digital conversion and custom drivers with super-low latency, make

Saffire 6 USB the best sounding interface in its class. Flexible monitoring, four phono outputs and a professional high-level headphone output make it ideal for DJs too.

• Two high quality award-winning

Focusrite preamps

• High-quality 24-bit/48kHz USB interface

with super-low driver latency

• 4 RCA outputs make Saffire 6 USB

the ideal interface for the laptop DJs

performing live

• Xcite+ pack, including Ableton Live Lite,

Novation’s Bass Station and 1 gig of loops

• Focusrite Compression, Reverb, Gating

and EQ plug-in suite

• Monitor either the main mix or cue mix

via headphones, all switchable from the

front panel

• Dedicated Mixer dial lets you blend

your monitor mix between what you’re

recording and the DAW audio, for true

zero-latency monitoring

Scarlett 8i6

8 in / 6 out usB 2.0 audio interface featuring two focusrite mic PreamPs

The Scarlett 8i6 is an 8 in / 6 out audio interface with outstanding sonic performance and flexibility at a truly affordable price. Part of Focusrite’s new range of USB audio interfaces, the Scarlett

8i6 is designed to make home studio recording and mixing easy without sacrificing audio quality. Twenty-five years of mic pre excellence form the foundation of this new interface, with two award-winning Focusrite preamps. Combined with a host of additional

I/O options, the Scarlett 8i6 helps you get the tracks you want without having to constantly re-patch your studio.

• Two high-quality award-winning

Focusrite preamps

• High-quality 24-bit/96kHz USB interface

• Total I/O count of 8 inputs and 6 outputs

• Scarlett MixControl ultra-low-latency

DSP mixer/router

• Scarlett VST/AU/RTAS Plug-in Suite, for use in the mix

• Xcite+ Software Bundle

• Two Hi-Z instrument inputs

• Dedicated front-panel headphone bus

Liq uid S affi re 5

6

Sa ffi re P

Sa ffi re P

RO 4

0

RO 2

4 D

Sa ffi re P

SP

Sa ffi re P

RO 2

4

RO 1

4

Sa ffi re 6 U

SB

Sc ar le tt 8 i6

Sc ar le tt 1

8i6

CONNECTION / PROTOCOL

NUMBER OF ANALOgUE INS

NUMBER OF DIgITAL INS

NUMBER OF ANALOgUE OUTS

NUMBER OF DIgITAL OUTS

VIRTUAL LOOPBACK INS

ADAT OPTICAL INPUT

ADAT OPTICAL OUTPUT

STEREO S/PDIF I/O

HEADPHONE OUTPUT

ANALOgUE INPUT PADS

NUMBER OF MIC PRES

LIQUID PREAMPS

BNC WORDCLOCK I/O

VRM

DSP INPUTS PROCESSINg

MAXIMUM SAMPLE RATE

STANDALONE OPERATION

MIXING / ROUTING SOFTWARE

XCITE+ PACk

BUS-POWERED

RACKMOUNTABLE

NO

192kHz

YES

YES

NO

NO

YES

YES

2

2

8

2

YES

NO

NO

96kHz

YES

YES

YES

NO

YES

0

NO

NO

YES

2

2

8

FW400

8

FW400 FW400

8 4

FW400

4

FW400

4

2

YES

YES

18

10

18

10

10

10

2

YES

YES

10

6

2

2

YES

NO

10

6

2

2

YES

NO

2

NO

NO

2

4

2

NO

96KHZ

YES

YES

YES

YES

NO

NO

NO

2

0

YES

1

2

NO

96kHz

YES

YES

YES

YES

NO

0

NO

NO

YES

1

2

2

YES

96kHz

YES

YES

YES

YES

NO

2

2

YES

2

0

NO

YES

NO

YES

YES

NO

0

NO

NO

NO

48kHz

NO

2

2

NO

1

0

NO

NO

USB

2

0

4

0

YES

1

2

2

2

NO

NO

USB 2.0

USB 2.0

4 8

2

4

2

10

4

2

0

YES

NO

0

2

YES

1

0

NO

NO

NO

96 kHz

NO

YES

YES

NO

NO

YES

YES

NO

NO

0

NO

NO

NO

96kHz

NO

15

16

Scarlett 18i6

18 in / 6 out usB 2.0 audio interface featuring eight focusrite analogue inPuts

The Focusrite Scarlett 18i6 is an 18 in / 6 out USB 2.0 audio interface designed to make home multitrack recording a breeze.

Alongside two award-winning Focusrite preamps, six high-quality analogue inputs allow you to simultaneously record guitar, bass, vocals and keys. You don’t need to stop there either – pop in the ADAT optical cable from an outboard eight-channel mic pre unit such as the Focusrite OctoPre MkII and you can track drums at the same time. Eighteen high-quality inputs feed cutting-edge digital conversion combined with the very latest in USB 2.0 interfacing technology, making

Scarlett 18i6 the perfect tracking interface.

• Total I/O count of 18 inputs and 6 outputs

• Two high-quality award-winning

Focusrite preamps

• High-quality 24-bit/96kHz

USB 2.0 interface

• Scarlett MixControl ultra-low-latency

DSP mixer/router

• Scarlett VST/AU/RTAS Plug-in Suite, for use in the mix

• Xcite+ Software Bundle

• Two Hi-Z instrument inputs

• Dedicated front-panel headphone bus

Scarlett Plugin Suite

Professional rtas/Vst/au Plug-in suite BY focusrite

Scarlett Plug-in Suite from Focusrite is a professional set of tools for tracking and mixing, including Compression, Gating , EQ, and Reverb. Each powerful plug-in has a host of fast and easy-to-use presets, providing a great starting point for a huge number of popular sound sources, from vocals and guitars to synth bass and percussion.

In addition, every plug-in parameter can be finely tuned to bring out the optimum sound you want, exactly the way you want it. So whether you want a fast set-up or an advanced set-up, Scarlett is destined to become your new 'go-to' plug-in. Scarlet includes the most popular formats including

VST/AU and RTAS (Pro Tools).

SHIPS FREE WITH

EVERY SCARLETT

INTERFACE

• Unmatched sonic quality at an incredible price

• A faithful recreation of classic Focusrite compressors and gates

• Stunning GUI with life-like classic port-hole VU meters

• Multi-modes enable creative gating techniques

• Classic Focusrite EQ curves and controls

• Professional reverb based on classic studio designs

Saffire /Scarlett MixControl

MixControl software is a powerful ultra-low-latency monitoring package that enables you to create several independent mixes and send each of them out to any interface output. Each mix can be built up using a combination of input signals and DAW outputs. Intuitive one-click configurations help you track, monitor and mix as quickly as possible.

3

2 1

4

5

6

The software window comprises of four main sections: a mixer, a router, a monitor section and a device status section:

• The mixer section allows you to create independent mixes - each of which can be routed out to physical outputs for monitoring, headphone cues or external processing.

• The router section is used to send any combination of physical inputs, DAW outputs or usercreated mixes of these streams to any outputs.

• The monitor section provides control of Volume, Dim, Mute and independent left or right cut.

• The device set-up section shows the status of synchronisation and connection, as well as allowing the user to change the sample rate and the synchronisation source for clocking.

The image above is for representation purposes. The configuration of MixControl changes depending on the interface in use.

7

MixControl gUI

Saffire MixControl utilises a unique tab system for mixes, allowing you to send whatever you want, wherever you want!

3

4

5

6

7

1

2

Fully-featured mix window with clear input and output metering

Multiple independent mixes can be created, each accessible via their own tab

Solos, mutes, pans and PFL’s available on every channel

Mixer output channels can be routed to any number of outputs

Routing section provides a clear indication of all audio routing

Monitor section lets you switch between different monitoring set-ups quickly

Clear device status section shows sample rate, sync source and more

17

18

Pro Tools 9

Now Focusrite Ready

In 2000, Digidesign chose Focusrite as their hardware partner to deliver what was to become the most successful Pro Tools interface ever - the original Mbox.

Now, with the introduction of Pro Tools 9, Focusrite interfaces are once again the best choice for Pro Tools users.

All Focusrite audio interfaces are Pro Tools 9 compatible.

MIDNIgHT

the classic Plug-in suite BY focusrite

Focusrite’s new Midnight plug-in suite takes two of the most iconic Focusrite modules of all time – the ISA110 equaliser and ISA130 compressor; models their sound exactly with powerful

DSP technology; and gives them elegant, functional on-screen front panels that make them simplicity itself to use.

The Midnight modules deliver incredible power and flexibility into your digital studio in VST,

AU and RTAS formats. Now you can take a massive step up and incorporate the pure, warm, delicious sound and straightforward controllability of these classic analogue processors in your own tracks - at a price you can actually afford.

19

OctoPre MkII

eight focusrite mic PreamPs with Built-in 24-Bit / 96KhZ adat outPut

OctoPre MkII Dynamic

eight focusrite mic Pres with comPression and Built-in 24-Bit / 96KhZ adat i/o

With eight channels of Focusrite pre-amplification and a built-in 24-bit / 96kHz ADAT output, OctoPre MkII is

Focusrite’s powerful input upgrade for your Pro Tools system, or any digital audio workstation. It’s also a great expansion for any analogue or digital console, or hard disk recorder.

The digital output allows users to make the most of often neglected ADAT inputs; ideal for expanding the number of mic preamp inputs on your interface. Connect OctoPre MkII to your audio interface’s ADAT input to create a high quality, multi-channel recording solution, ideal for tracking drums, vocals, guitars and more.

• Eight high quality award-winning Focusrite preamps

The best sounding multi-channel mic pre in its class.

• Built-in eight channel 24-bit / 96 kHz digital output

Make the most of your interface’s ADAT input. OctoPre

MkII connects via its built-in ADAT Optical output, with

a ‘real world’ dynamic range performance of 110dB.

• Mic pres optimised for tracking drums

OctoPre MkII is designed not to clip, with 10dB pads and

preamps optimised to handle extreme levels from sound

sources like kick drum and snare.

• Two quality Hi-Z instrument inputs

OctoPre MkII’s first two channels feature DI’s, ready for

you to plug in your guitars and bass, instantly accessible

on the front fascia.

• 5 LED input metering on every channel

OctoPre MkII’s fast-acting 5-LED input meters provide

clear reference of input levels, helping you to avoid

analogue or digital clipping.

• Direct outputs on every channel

For routing and flexibility, especially in the live

environment. Each mic pre can be routed to the mixer’s

analogue channels, with two mirrored ADAT outputs

(44.1 kHz) left free to send to digital recorders.

• 48V phantom power available on every channel

Switched in two groups (1-4 and 5-8) every channel is

capable of supplying phantom power, for use with most

condenser microphones.

• State-of-the-art clocking

OctoPre MkII’s internal clock delivers a jitter performance

of less than 10 PPM. For external clocks, a BNC

connector is provided and industry-standard JetPLL™

jitter reduction technology is employed.

20

Working together -

OctoPre MkII & Saffire PRO 40

With eight channels of Focusrite microphone preamplification, eight VCA-based Red 3-derived compressors and built-in 24-bit / 96 kHz digital inputs and outputs, OctoPre

MkII Dynamic is Focusrite’s feature-rich expansion upgrade for any digital audio workstation. It’s equally an ideal expansion for any analogue or digital console, or hard disk recorder.

• Eight award-winning Focusrite preamps

Focusrite’s unparalleled preamp legacy forms the

foundation of this device, with mic pres optimised to handle

extreme levels from sound sources like acoustic drums.

• Eight ‘single-dial’ Focusrite compressors

A single dial gets you to the right amount of compression,

fast. These new VCA-based, feed-forward compressors

model the character of the celebrated Focusrite Red 3.

• Compress transparently or with effect

The classic soft-knee design achieves beautifully

transparent compression that caresses your sound.

Focusrite’s unique “More” switch doubles the ratio to

deliver ‘compression with effect’.

• Built-in eight channel 24-bit / 96 kHz digital outputs

Make the most of your interface’s ADAT input for tracking,

with eight channels of analogue to digital conversion via

ADAT, boasting a ‘real world’ dynamic range performance

of 110dB.

• Built-in eight channel 24-bit / 96 kHz digital inputs

Switchable from the front panel, digital to analogue

conversion via ADAT provides analogue monitoring of

any digital ADAT feed, as well as the ability to clock from

any ADAT device.

• State-of-the-art clocking

OctoPre MkII Dynamic’s internal clock delivers a jitter

performance of +/- 20 PPM. For external clocks, industry-

standard JetPLL™ jitter reduction technology is employed.

• Two high-quality instrument inputs

OctoPre MkII Dynamic’s first two channels feature DI’s,

ready for you to plug in your guitars and bass.

No expensive external DI required.

OctoPre MkII Dynamic ‘More’ Function

Each compressor on the OctoPre

MkII Dynamic features a ‘More’ button for an enhanced compression effect. The More button doubles the ratio from 2:1 to 4:1 and shifts the threshold range, so you have more sensitivity on control.

21

FOCUSRITE ARTISTS

La Roux

La roux are singer-synth player Elly Jackson and co-writer/producer Ben Langmaid. There self titled debut album has delivered some of the years biggest tracks in No.1 selling single

Bulletproof and In for the Kill charting at No.2. The album has been nominated for the 2009

Mercury Prize.

We caught up with Ben during a busy live touring schedule to chat about how La Roux have utilised Focusrite products on the current and forthcoming albums.

Your sound is very electro based… Did your routes begin in dance music?

I started as a DJ and moved into production after helping a friend of mine (Rollo) set up the band Faithless. I went on to produce my own records under the guises of Huff & Puff and Huff

& Herb to name a few.

How are you using the liquid channel in the studio?

I’m using the liquid channel Mainly for vocals and currently testing out all the combinations of vintage compressors, eq’s and pre-amps to see how it performs!

What are your main reasons for going with Focusrite Hardware?

They’re a solid company with a very strong reputation. I used the Saffire Pro 26 and the

ISA430MKII to record all of Elly’s vocals on the first La Roux album and they produced some quality results.

And the key features you love on the Liquid Channel?

I’m into the different combinations of compression and pre-amps. The precise emulations offer me a lot of variety and access to a vast array of classic units in the studio, which I’d otherwise spend a small fortune on! Being able to save my presets is a handy feature as well…

What benefits have the liquid channel brought to your studio work?

Quite simply its quick to setup and easy to use. You can tailor the kit to your vocalist’s sound and tone whilst tapping into the vast bank of presets. I’m only just scratching the sides of its full potential.

How have you found the linkup with the liquid channel to your DAW?

The seamless linkup with my mac made it quick and easy to setup. We had it plugged in straight out the box and running in a few minutes. I’m also able to back up my presets. www.laroux.co.uk

FOCUSRITE ARTISTS

Andreya Triana

From a young age, Andreya wanted to sing. She taught herself how to play guitar and was soon taking every opportunity she could to play. Her determination has brought her to the forefront of the electronic music fraternity, and is now signed to Ninja Tune, one of the most well-respected record labels in the field.

Recent collaborations include Flying Lotus, Mr Scruff and Bonobo, with whom she toured the

US and Canada in 2010.

Andreya uses the Focusrite Saffire 6 USB audio interface to record guitar and vocal demos.

Its portability makes it perfect for use on the road, while its quality preamps and A-D conversion let Andreya get professional results.

www.andreyatriana.com

Simon Changer

The ISA428 lets me get good, clean gain, to complement my vintage gear.

Engineer - Credits include:

David Gray, Bjork

ISA 428 MkII

Matt Robertson

I trust the sound, and I know it’s not going to let me down.

Recording engineer

kWIZ

I can emulate any monitors so I can have a familiar sound just with my headphones.

Beyoncé’s programmer

Octopre MkII Dynamic Saffire 24 DSP

23

The Liquid Channel

anY mic Pre and comPressor in historY

24

The Liquid Channel

is a revolutionary channel strip that can emulate any classic mic pre and compressor. Combining radical new analogue mic preamp technology with Dynamic

Convolution™ techniques, and augmented by fully digital controls and remote software, it provides the ultimate fluid vintage collection.

• Loaded with 40 classic mic preamp and 40

compressor emulations

• 100 programme memories provide full recall of

every setting

• LiquidControl software allows comprehensive remote

operation via USB

• 192kHz internal processing and ADC/DAC as standard

• Focusrite digital EQ based on the Forte Suite software

• Adjustable harmonic distortion accounts for variance

in vintage originals

WHAT IS DyNAMIC CONVOLUTION?

Dynamic Convolution is a unique, patented technology that emulates the sonic properties of original compressors, EQs and the amplification element of mic preamps. Essentially, it samples (as opposed to models), the effect a processor has on the audio signal through the application of a unique, leveldependant set of responses to that signal. These measured responses, sampled at numerous levels and with a multitude of setting combinations, are applied to the input stream on a sample-by-sample basis for extremely convincing results.

Liquid Channel Remote Control Software (via USB)

MIX

FOCUSRITE ARTISTS

Liquid Channel Perfects

Carl Cox’s Live Mix

“My Liquid Channels are transparent but warm and big in their sound and, as testament to their quality, our FOH engineer said it was the first time in his career that he didn’t need to add any EQ or processing!” remarks Carl Cox, one of the world’s premier DJs.

A pair of the hardware processors acts as the last stage in his chain, before the signal from the stage hits the enormous PA system, whether he’s playing a beach party in Miami, a superclub in Berlin, or a global music festival. “They fit the bill perfectly. They are the solid final link in my audio chain for my live show, something that gives me a sonic edge. EQ, compression, limiting: you just set it and forget it.”

Liquid Channels will be rocking the Carl Cox Live Show for some time to come!

Cox is no stranger to the DJ booth, and has picked up numerous accolades in his tremendous career. He was the first ever winner of DJ Magazine’s Top 100 poll in 1997, and he still packs venues worldwide. But he also has serious studio chops, with three albums, countless singles and a glut of remixes to his name. www.carlcox.com

25

Liquid Mix HD

anY classic comPressor and eq in historY for the Price of a single Plug-in

Why pay for one plug-in, when you can have 60?

Only Liquid technology gives you genuine emulations of the most revered signal processors used on countless hits throughout recording history.

Each Liquid Mix channel provides compressor and EQ emulations selected from a huge pool of high-quality vintage and modern day classics. 40 compressors and 20 EQs are available straight out of the box, with an expanding library online. Furthermore, a totally unique hybrid 7-band ‘super

EQ’ can be built out of separate classic EQ sections in every channel.

• Unrivalled variety of classic emulations

40 compressors and 20 EQs, sampled from vintage

originals with a free expanding library online.

• Dynamic Convolution technology

The unique patented Dynamic Convolution process

delivers unparalleled EQ and compression emulations.

• Unique Hybrid super EQ

Create your own totally unique 7-band super EQ, built

out of separate classic EQ bands.

Each channel appears as a separate effect within the sequencer. Liquid Mix HD seamlessly integrates Liquid technology with the Pro Tools HD environment, potentially providing over 60 simultaneous channels (dependent on the HD system).

• Optimised for Pro Tools HD

Over one hundred simultaneous mono instances can be run

at 44.1/48kHz on an HD3 system.

• Ultra-low latency for recording

With the ultra-low latency of Liquid Mix HD (just 12

samples), it can now be used for recording and live

sound applications.

• Full control surface mapping

Pro Tools TDM format ensures full control mapping on all

major Pro Tools control surfaces, including ICON and VENUE.

Multiple instances of

Liquid Mix running simultaneously

ISA430 MkII – Producer Pack

the Pinnacle of focusrite’s analogue channel striP technologY

The ISA 430 MKII represents the pinnacle of Focusrite’s analogue channel strip technology, bringing together all the classic designs in one comprehensive production tool.

Augmented with additional features and flavours, alongside unmatched internal routing and connectivity, the ISA 430

MKII confirms Focusrite’s iconic status as the leading manufacturer of channel strips.

• Classic Focusrite transformer-based mic

preamp with variable impedance and ‘Air’ feature

• Multi-format compressor; transparent VCA

circuit and two vintage optical solutions

• Classic Focusrite EQ design; an expanded

version of the original ISA 110

• Post mic pre output for the shortest possible

signal path

• Proprietary Focusrite discrete Class A VCA gate

and expander designs

• Optical de-esser featuring ‘De-esser Listen’ for

precise control over sibilance

• Soft Limiter to avoid critical digital overload

(requires optional A-D converter)

• Optional stereo A-D converter with 120dB dynamic range

26

Pro Tools HD is a trademark of Avid Technology Inc. All other product names, trademarks, or trade names are the names of their respective owners, which are in no way associated, connected nor affiliated with Focusrite or its LIQUID MIX products and which have not endorsed Focusrite’s LIQUID MIX products.

27

28

ISA828

eight classic mic PreamPs alongside a Premium eight-channel a-d conVerter oPtion

Combining the best of yesterday with the best of tomorrow, Focusrite’s ISA828 eight channel mic preamp features exactly the same classic microphone preamplifier design as Focusrite’s critically acclaimed Forté console. To partner seamlessly with Pro Tools HD and other professional

DAW platforms, the ISA828 integrates with our finest eight-channel A/D converter option.

• The classic Focusrite mic pre at its lowest

cost-per-channel to date

• The best A-D performance on the market,

bar none (requires optional ADC)

• Integrates quickly and seamlessly with

ProTools HD

• Switchable impedance to suit any microphone

• Multiple front panel instrument - No separate

DI box required

• High pass filter, phase reverse and phantom

power on every channel

ISA428 MkII

four classic mic PreamPs with di inPuts and a Premium eight-channel conVerter oPtion

The ISA428 MkII provides four of Focusrite’s prestigious transformer based microphone preamps.

It features the same classic circuitry and renowned audio quality found in the original at a new level of affordability. With switchable input impedance, direct instrument inputs and an optional eight channels of high quality analogue to digital conversion, the

ISA428 MkII creates the perfect front end for the discerning recording professional.

• Four classic Focusrite transformer-

based preamps

• 8 channels of cutting-edge A-D conversion,

running at up to 192kHz (requires optional ADC)

• Switchable impedance setting, ideal for mic

matching or extended microphone creativity

• Four front panel instrument inputs - no separate

DI box required

• Dedicated analogue insert points on

every channel

• Classic high pass filters on every channel

Why go digital with Focusrite?

For 15 years now, we’ve been tirelessly perfecting our digital conversion technology. By simply slotting into the back of the analogue unit, audio signals travel the shortest possible distance and remain free from extraneous clocks or other sources of digital noise. Fine tuning the marriage between analogue and digital audio circuitry enables our A-D converters to achieve superb dynamic range with extremely low noise and jitter.

ISA 8-channel ADC

Eight channels of precision

Focusrite A-D conversion for

ISA428, ISA428 MkII and ISA828, with 121.5dB dynamic range and jitter below 250 picoseconds.

Digital connections include AES/

EBU, ADAT Optical and S/PDIF

(coaxial and optical).

ISA Stereo ADC

Two channels of cutting-edge

A-D conversion for ISA430 MkII and ISA One, with 120dB dynamic range and jitter below 300 picoseconds. Digital connections include AES/EBU, ADAT Optical, and S/PDIF (coaxial and optical).

29

30

ISA One

classic microPhone PreamP with indePendent di and Professional digital outPut oPtion

The ISA One microphone preamplifier delivers Focusrite’s prestigious ISA transformer-based preamp in a rugged and portable chassis, at a groundbreaking price. ISA One shares the same preamplifier topology as Focusrite’s classic ISA110, featuring the original Lundhal LL1538 transformer and bespoke Zobel network.

This preamp topology formed the cornerstone of Focusrite’s legendary Forté console and ISA Series preamplifiers have been used on countless hit records over the last two decades.

With its robust construction, the ISA One has made the classic Focusrite signature sound more portable and more affordable than ever before.

• ISA Series transformer-based preamp

Encased in a rugged and portable chassis, offering the

classic Focusrite microphone preamp at its lowest

cost to date.

• Flexible independent DI channel

ISA One is ideal both for engineers and demanding

performers alike, featuring independent gain control,

an output for routing to an amp and an independent

XLR output on the rear.

• Switchable impedance

Choose one of four carefully selected input impedances,

including the original ISA 110 setting, to suit

any microphone.

• Class-leading stereo A-D conversion

Easily installed in any ISA One, this card embodies

cutting-edge conversion technology, incorporating

Focusrite analogue circuitry to deliver the best A-D

performance in its class.

• Dedicated insert point

Allowing you to place extra processing between the pre

amp or DI and the optional converter, such as an EQ

or compressor.

• Phantom power, phase reverse and high-pass filter

All available from the angled front fascia. The

high-pass filter operates at 75Hz, 18 dB/octave.

More than a mic preamp

The ISA One features an independent D.I. channel with its own gain control, an output for routing to an amp, and an independent XLR output on the rear. Stereo cue mix inputs and a dedicated insert point are also available.

Model pictured has the optional ISA Stereo A-D Converter installed

FOCUSRITE ARTISTS

Focusrite Preamps From

The Very Beginning

Focusrite have been behind Amy Macdonald’s sound from the very first sessions in producer

Pete Wilkinson’s home studio, “we worked in a very lo-fi way where Amy came to my little studio at home and put down her vocals. All of Amy’s original vocals were recorded through my

Voicemaster Pro; it was the vocal that the mix engineer and mastering house ended up with.”

The ISA One Digital gives the Focusrite sound that I have on my ISA rackmount gear in a preamp I can take on the road to extend my system. As a clock source it’s rock solid, and it’s great value for money. It’s an outstanding little preamp.

James Stone

But it’s not just Amy’s vocal that gets the Focusrite treatment. Joe Fields, Pete’s engineer of choice, continues: “When Pete brings the template in, we replace the instruments to try to get it sounding how he had it in his studio. We start with drums then bass and guitars, then live strings. We tracked the strings and most of the drums through Focusrite ISA428s.”

These days, Amy and her team use the ISA One Digital preamp on her vocals. To hear the quality of the Focusrite mic pre, check out Amy’s second album, A Curious Thing, which is available now.

www.amymacdonald.co.uk

31

www.focusrite.com

FA0135-06

It’s always nice to have something that you know gives good results. I was a tape op when Focusrite came along, and whenever I got the chance to try Focusrite equipment, it always sounded amazing. It’s something that I’ll always go for if it’s in a room, because I trust it and I know it always comes through.

The Focusrite sound is always nice on anything you want a lot of high fidelity to.

Drum overheads always sound great, and it’s the same with strings recordings.

It works really well on vocals; It helps me make the mix.

Adrian Bushby

Double GRAMMY Award-winning Recording Engineer

Muse, Foo Fighters, Band Of Skulls, Two Door Cinema Club

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
