Samsung SVR Install Guide
nt ige ell Int y& rit Se cu Fir e d Lt Install Manual 0 Install Manual Introduction Thank you for purchasing a Samsung SVR series digital video recorder. Lt d ` Fir e This manual is for SVR-3200, SVR-1680C, SVR-1660C, SVR-1645, SVR-960C, SVR-945, SVR-480. Before product installation and operation, please become thoroughly familiar with this user manual and other manuals referenced by this manual. This user manual and the software and hardware described here are protected by copyright law. With the exception of copying for general use within fair use, copying and reprinting the user manual, either partially or in entirety, or translating it into another language without the consent y& of Samsung Techwin, Inc. is strictly prohibited. This specification may change without prior notice for improvement of product performance. Product Warranty and Limits of Responsibility rit The manufacturer does not assume any responsibility concerning the sale of this product and does not delegate any right to any third party to take any responsibility on its behalf. The Se cu product warranty does not cover cases of accidents, negligence, alteration, misuse or abuse. No warranty is offered for any attachments or parts not supplied by the manufacturer. The warranty period for this product is for 3 years from the date of purchase. The following cases are not covered by the warranty and payment is required for repairs. Malfunctions due to negligence by the user Deliberate disassembly and replacement by the user Connection of a power source other than a properly rated power source Malfunctions caused by natural disasters (fire, flood, tidal wave, etc.) Replacement of expendable parts (HDD, FAN, etc.) ell ige nt ※ The warranty period for the HDD and Fan is one year after purchase. Int Warranty only refers to the warranty covering products that have been paid for. 1 Install Manual d After the expiration of the warranty period (3 years), examination and repair will be provided for scope will require payment. Lt a fee. Even during the warranty period, repair and examination of items outside the warranty This product is not for exclusive use of crime prevention but for assistance in cases as Fir e fire or theft. We take no responsibility for damage from any incident. Experience and technical skills are needed for the installation of this product as an improper installation may cause fire, electric shocks, or defects. Any installation job should be performed by the vendor you purchased this product from. This manual is authored SVR-3200, SVR-1680C, SVR-1660C, SVR-1645, SVR-960C, SVR-945, y& SVR-480 according to firmware version 1.8.0 The content of this manual may differ according to Firmware or Software upgrades, and the Int ell ige nt Se cu rit standard and appearance of the product is changeable without prior notice to users. 2 Install Manual Lt d Contents Introduction ..................................................................................... 1 Fir e Product Warranty and Limits of Responsibility ............................................................ 1 Chapter 1. Safety Precautions ....................................................... 4 1.1 Explaining the Symbols ................................................................................. 4 Chapter 2. Summary ....................................................................... 8 Features .................................................................................................... 8 2.1 Components ............................................................................................. 12 2.2 Description of product ................................................................................. 13 y& 2.1 Front view.......................................................................................... 13 2.2.2 Rear Part........................................................................................... 23 2.2.3 Remote control ................................................................................... 29 rit 2.2.1 Chapter 3. Installation .................................................................. 31 Installation & Connection ............................................................................. 31 3.1.1 3.2 Se cu 3.1 Basic connection and operation .............................................................. 31 OSD Menu structure & Operation .................................................................. 33 3.2.2 Remote control setup & basic operation ................................................... 34 3.2.3 Example of installation structure ............................................................. 36 3.2.4 Basic setup ........................................................................................ 37 Using input/output terminals ......................................................................... 41 nt 3.3 External Storage connections................................................................. 56 3.3.5 Remote monitoring & control .................................................................. 63 ige 3.3.4 Trouble Shooting .......................................................................... 65 ell Compatible HDD List .................................................................... 67 Compatible Media List .................................................................. 67 Int Specification ................................................................................. 67 Dimensions ................................................................................... 71 3 Fir e 1.1 Explaining the Symbols Lt Chapter 1. Safety Precautions d Install Manual Warning Refers to information users need to know in order to prevent serious injury or death. Before installation y& 9 Verify the supplied voltage (AC100V~AC240V) before connecting to the power supply. 9 Make sure the power supply is off before installation. 9 Do not install in a very humid environment. Doing so may cause an electric shock or fire. rit 9 Make sure ground line is connected to reduce electric shock risk. During operation Se cu 9 Do not open the product cover except by qualified personnel or system installer. Opening the product cover may cause an electric shock. 9 Do not plug multiple appliances into a single power outlet. Doing so may cause fire. 9 Do not place dishes holding water or heavy objects on the product. Doing so may cause a malfunction. 9 Do not use in areas where inflammable substances such as propane gas or gasoline nt or high amount of dust is present. Doing so may cause an explosion or fire. 9 Do not touch the power line with a wet hand. Doing so may cause an electric shock. 9 Do not insert a hand into the opening of the DVD. Doing so may cause an injury. ige 9 Make sure conductive materials do not enter the cooling ventilator opening. 9 Do not apply excessive force when pulling on the power cord. Damaging the cord may cause an electric shock or fire. ell 9 Improper replacement of the built-in battery by other types of batteries may cause explosion. The batter must be replaced by the same battery type. Also, expired batteries may cause pollution and must be disposed of with care. Int 9 Do not place the battery in fire or in extreme heat. Also, do not dissect or disassemble the battery. 9 Recharge the batteries for the remote controller. 4 Dismantling and cleaning Lt d Install Manual 9 Do not dismantle, repair or modify the product deliberately. Doing so may cause a damage, an electric shock or an injury. Fir e 9 Do not use water, paint thinner or organic solvent for cleaning the product exterior. Doing so may cause a malfunction or an electric shock. Use a dry cloth to clean the exterior. Caution Provides information users need to know in order to prevent minor y& injury or product damage. During installation 9 To get adequate ventilation, install the product with at least 15cm of space between rit the cooling ventilation opening and a wall. 9 To prevent falling, install the product in a flat area . Dropping the product may Se cu cause an injury or a malfunction. 9 Avoid areas exposed to sun light or heat since they may cause deformation or a malfunction. 9 If a camera is installed while the DVR is recording, image in another channel may be disrupted. Start the storage after installing the camera is recommended. During use nt 9 Make sure the product is not exposed to shocks or shaking when using the product or during moving. ige 9 Do not move the product while it is in operation, and apply strong shocks to the product or throw the product. 9 If hard disk drives other than those recommended are used additionally, abnormal operation may occur. Inquire at the point of purchase of the product before ell installing such a hard disk drive. 9 Product warranty will not cover deliberate additional use of such hard disk drives. Int 9 This product is a supplementary rather than primary means for preventing fire and theft. Our company is not responsible for incidence of incident or damage that may occur. 5 Install Manual d Samsung Techwin cares for the environment at all product manufacturing stages, and is taking a number of steps to provide Lt customers with more environmentally friendly products. The Eco mark represents Samsung Techwin’s will to create environmentally friendly products, and indicates that the product satisfies the EU Fir e RoHS Directive. FCC Compliance Statement NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable y& protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful rit interference in which cause the user will be required to correct the interference at his own expense. Correct Disposal of This Product (Waste Electrical & Electronic Equipment) Se cu (Applicable in the European Union and other European countries with separate collection systems.) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where nt they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with ige other commercial wastes for disposal. ell Correct Disposal of Batteries in this Product (Applicable in the European Union and other European countries with separate battery return systems.) This marking on the battery, manual or packaging indicates that the batteries in this Int product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC 6 Install Manual d Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment. To protect natural resources and to promote material reuse, Lt please separate batteries from other types of waste and recycle them through your local, free battery return system. The rechargeable battery incorporated in this product is not user replaceable. Int ell ige nt Se cu rit y& Fir e For information on its replacement, please contact your service provider. 7 Install Manual Lt d Chapter 2. Summary This unit is a digital video recording and playback device to record image and video input as the mouse and GUI allow easy setup and operation. Fir e from 32/16/9 channels to its built-in hard disk. The buttons on the front of the unit as well The Samsung SVR series of digital video recorders (DVRs) provide additional safety and security to banks, apartment buildings and complexes, government offices as well as other public, private and commercial facilities. Recorded high-quality video and images are stored on hard disk for later retrieval or playback. Real time functionality delivers y& users with the ability to simultaneously record multiple channels, playback video, and copy video. A few of the more advanced user-conveniences include motion detection, Pan/Tilt/Zoom controls (PTZ), password protection, real time audio recording, event lists, 2.1 rit and log files. Features Monitoring Screen provides multiple screens. Se cu The monitoring screen supports vivid, high-definition live visual feed from each channel and Real time MPEG-4 visual output (480 frames) Multiple split-screen monitoring modes SVR-3200/1680C/1660C/1645: Single, 4, 9, 10, 16 SVR-960C/945: Single, 4, 9 nt SVR-480 : Single, 4 Automatic Screen Switching (AUTO) Supports various monitor output modes ige SVR-3200: 4 Composite, 2 VGA ell SVR-1680C: 4 Composite, 1 VGA SVR-1660C/1645/960C/945/480: 2 Composite, 1 VGA Pan/Tilt, Digital Zoom, PIP (Picture-In-Picture), The PIP function will be available with Int a firmware upgrade in the future. 8 Install Manual d Audio Recording Simultaneous recording of 16/9/4 channels of audio in real time Lt SVR series DVRs provide real time audio recording. SVR-3200/1680C/1600/1645 : Input - 16 channels (4 RCA in rear, 12 D-SUB), Output - 1 in rear, SVR-960C/945 : 9 channels (4 RCA in rear, 5 D-SUB), Supports simultaneous recording and playback Video Recording Fir e Output - 1 in rear, SVR-480 : 4 channels (4RCA), Output – 1 in rear The product is capable of storing visual image data as high resolution MPEG-4 video at up y& to 480 frames per second, as well as pre-emptively initiating recording sequences up to five seconds prior to an event. The COVERT feature (concealment of private visual data) helps to protect privacy. High quality real time MPEG-4 recording Three screen-resolution levels for improved control over data sizes Multi-recording for manual and scheduled events Simultaneous recording/playback/backup/networking Easily accessible options for channel-specific resolution and motion detection ranges Per-second frame rates (up to 30 frames per channel) are user customizable Se cu rit nt SVR-3200 Half D1 : NTSC (704x240) 960fps, PAL (704x288) 800fps SVR-1680C D1 : NTSC (704x480) 480fps, PAL (704x576) 400fps ige SVR-1660C/1645 CIF : NTSC (352x240) 480fps, PAL (352x288) 400fps SVR-960C/945 CIF : NTSC (352x240) 270fps, PAL (352x288) 225fps SVR-480 D1 : NTSC (704x480) 120fps, PAL (704x576) 100fps Manual and scheduled recording Video signal loss detection Int ell Event logs (sensors, D-I/O, video loss, motion detection, text) 9 Each channel supports pre-emptive recording sequences up to 5 seconds prior to an Search/Playback Various search and playback options are offered for the user’s convenience. Playback by time, date and channel Mouse interface increases data searchability Forward/backward search while playback is paused Playback by event log entry (sensor, video loss, motion detection and text) Remote controller and Jog/Shuttle further improve searching (The SVR- 960C/945/480 models do not support Jog/Shuttle.) Full-frame playback (Available in SVR-3200/1680C/1660C only) Se cu rit y& Fir e Lt actual event d Install Manual Data Storage The hard disk included with the product is for data storage. If desired, recorded data can be backed up or stored to DVD-R, CD-R or a USB storage device. The built-in hard disk is provided as primary storage Multiple portable data storage media are supported: DVD-R, CD-R and USB ※ Refer to the appendix on the back of the manual regarding compatible media types. Hard disk expansion device (external recording device): SVS-5E (optional) External ige nt Int ell hard disk expansion is supported with the SVS-5E (Available for purchase separately) 10 Install Manual d Networking interface client, the core features of the device can be easily remotely controlled. E-mails can be sent via TCP/IP or DHCP upon an event trigger Remote live visual feed (single or 4 section split-screen) PC playback, storage, search and DVR control functions via Network Viewer Remote recording, search and playback scheduling Supports 10/100Mbps Ethernet/xDSL Multiple DVR connections y& Fir e rit Miscellaneous User-friendly GUI and mouse interface Simplified firmware upgrades through USB Visual data recording and backup to USB Supports PTZ control (SPEED DOME), Coax, PRESET Multilingual support: Korean, English, Italian, Spanish, Japanese Single remote controller to control 16 DVRs Int ell ige nt Se cu 11 Lt The product supports LAN, xDSL and other networking capabilities. Combined with the PC d Install Manual 2.1 Components HDD Mount Screw Fir e SATA Cable Program CD y& Remote Controller Install Manual Se cu rit AC CORD Lt Please check the included accessories as follows. DVR Quickguide Rackmount & Screw ige nt SNM-128S Quickguide For the SVR-945, a switched-mode power supply (SMPS) power cord is included, while a stand is included instead of the standard rack mount. SVR-480 does not include rack mount & Screw. STAND Int ell AC CORD & SMPS 12 Install Manual d Description of product Lt 2.2 2.2.1 Front view SVR-3200 Classification DVD-Multi for 1 copying 2 Channel LED Function For copying recorded video and images to DVD/CD Se cu No. rit y& Fir e 2.2.1.1 optical media. Shows the data input and event operation status Jog can adjust setting values, control the STEP function, 3 JOG/SHUTTLE navigate through the menu, and adjust the playback speed and direction. Shuttle controls PTZ. Channel button 5 AUTO 6 MULTI 8 Int 10 Starts or stops user defined sequences. Changes split-screen sections for live video feeds or playback. MENU Navigates into the Menu. SEARCH Starts Search mode. REC button Starts or stops manual recording ell 9 ige 7 Selects channel in live feed or playback nt 4 REC lamp Lit when recording. HDD lamp Lit when HDD is working. NETWORK lamp Lit when network is connected. EVENT lamp Lit when an event is detected. COPY lamp Indicates copying operation. 13 Install Manual Lit when copying. 11 Power button Turns on or off the device. 12 ESC button The Escape button navigates up the menu tree and Lt d PLAY lamp closes dialog windows. COPY Starts Copy mode. 14 FUNC Starts Function mode. 15 MONITOR Cycles through from Monitor 1 to 4. 16 PTZ Starts or ends PTZ function. 17 Fir e 13 USB ports for external devices (mouse, USB memory USB1, USB2 stick). PLAY/ENTER Start playback or select an item on the menu. 19 ◀/REW Navigates or selects in the menu, or for playback, y& 18 changes the reverse playback speed. 20 Navigates or selects in the menu, or for playback, ▶/FWD changes the forward playback speed. ▲/PAUSE Navigates or selects in the menu, or for playback, rit 31 pauses live or recorded video. ▼/STOP 22 Navigates or selects in the menu, or for playback, stops Int ell ige nt Se cu playback. 14 SVR-1680C, SVR-1660C, SVR-1645 Classification 1 2 Function DVD-Multi for For copying recorded video and images to DVD/CD copying optical media. Channel LED Shows the data input and event operation status rit No. y& Fir e Lt 2.2.1.2 d Install Manual 3 JOG/SHUTTLE Se cu Jog can adjust setting values, control the STEP function, navigate through the menu, and adjust the playback speed and direction. Shuttle controls PTZ. 4 Channel button 5 AUTO 6 MULTI Selects channel in live feed or playback Starts or stops user defined sequences. Changes split-screen sections for live video feeds or playback. MENU Navigates into the Menu. 8 SEARCH Starts Search mode. 9 REC button Starts or stops manual recording REC lamp Lit when recording. HDD lamp Lit when HDD is working. NETWORK lamp Lit when network is connected. ige ell 10 nt 7 Lit when an event is detected. COPY lamp Indicates copying operation. PLAY lamp Lit when copying. 11 Power button Turns on or off the device. 12 ESC button The Escape button navigates up the menu tree and Int EVENT lamp 15 Install Manual d closes dialog windows. COPY Starts Copy mode. 14 FUNC Starts Function mode. 15 MONITOR Cycles through from Monitor 1 to 4 : SVR-1680C, Lt 13 SVR-1645 16 PTZ 17 Starts or ends PTZ function. Fir e Switches from main and sub monitor : SVR-1660C, USB ports for external devices (mouse, USB memory USB1, USB2 stick). PLAY/ENTER Start playback or select an item on the menu. 19 ◀/REW Navigates or selects in the menu, or for playback, y& 18 changes the reverse playback speed. 20 Navigates or selects in the menu, or for playback, ▶/FWD changes the forward playback speed. 31 ▲/PAUSE Navigates or selects in the menu, or for playback, ▼/STOP 22 rit pauses live or recorded video. Navigates or selects in the menu, or for playback, stops Int ell ige nt Se cu playback. 16 SVR-960C No. y& Fir e Lt 2.2.1.3 d Install Manual Classification for For copying recorded video and images to DVD/CD rit DVD-Multi 1 Function optical media. 2 Channel LED Shows the data input and event operation status 3 Channel button Selects channel in live feed or playback 4 AUTO 5 MULTI Se cu copying Starts or stops user defined sequences. Changes split-screen sections for live video feeds or playback. MENU 7 SEARCH 8 REC button Navigates into the Menu. Starts Search mode. Starts or stops manual recording nt 6 HDD lamp Lit when HDD is working. NETWORK lamp Lit when network is connected. EVENT lamp Lit when an event is detected. COPY lamp Indicates copying operation. PLAY lamp Lit when copying. ige Lit when recording. ell 9 REC lamp Power button Turns on or off the device. 11 ESC button The Escape button navigates up the menu tree and Int 10 closes dialog windows. 12 COPY Starts Copy mode. 13 FUNC Starts Function mode. 17 MONITOR Switches from main and sub monitor 15 PTZ Starts or ends PTZ function. 16 Lt 14 d Install Manual USB ports for external devices (mouse, USB memory USB1, USB2 stick). PLAY/ENTER Start playback or select an item on the menu. 18 ◀/REW Navigates or selects in the menu, or for playback, Fir e 17 changes the reverse playback speed. 19 Navigates or selects in the menu, or for playback, ▶/FWD changes the forward playback speed. 20 ▲/PAUSE Navigates or selects in the menu, or for playback, ▼/STOP 21 y& pauses live or recorded video. Navigates or selects in the menu, or for playback, stops Int ell ige nt Se cu rit playback. 18 SVR-945 Classification Function rit No. y& Fir e Lt 2.2.1.4 d Install Manual Channel LED Shows the data input and event operation status 2 Channel button Selects channel in live feed or playback 3 AUTO Starts or stops user defined sequences. 4 MULTI Se cu 1 Changes split-screen sections for live video feeds or playback. 5 MENU 6 SEARCH 7 REC button Starts Search mode. Starts or stops manual recording Lit when recording. nt REC lamp Navigates into the Menu. NETWORK lamp Lit when network is connected. EVENT lamp Lit when an event is detected. COPY lamp Indicates copying operation. PLAY lamp Lit when copying. Power button Turns on or off the device. ell 9 Lit when HDD is working. ige 8 HDD lamp 10 The Escape button navigates up the menu tree and closes dialog windows. COPY Starts Copy mode. 12 FUNC Starts Function mode. 13 MONITOR Switches from main and sub monitor Int 11 ESC button 19 PTZ 15 Starts or ends PTZ function. USB ports for external devices (mouse, USB memory USB1, USB2 stick). Lt 14 16 PLAY/ENTER Start playback or select an item on the menu. 17 ◀/REW Navigates or selects in the menu, or for playback, Fir e changes the reverse playback speed. 18 Navigates or selects in the menu, or for playback, ▶/FWD changes the forward playback speed. 19 ▲/PAUSE Navigates or selects in the menu, or for playback, pauses live or recorded video. Navigates or selects in the menu, or for playback, stops y& ▼/STOP 20 Int ell ige nt Se cu rit playback. 20 d Install Manual SVR-480 Classification DVD-Multi 1 Function rit No y& Fir e Lt 2.2.1.5 d Install Manual for For copying recorded video and images to DVD/CD optical media. 2 Channel button Selects channel in live feed or playback 3 Channel LED 4 AUTO 5 MULTI Se cu copying Shows the data input and event operation status Starts or stops user defined sequences. Changes split-screen sections for live video feeds or playback. 6 MENU 7 SEARCH 8 REC button Starts or stops manual recording REC lamp Lit when recording. HDD lamp Lit when HDD is working. NETWORK Lit when network is connected. Starts Search mode. nt ige 9 Navigates into the Menu. lamp ell EVENT lamp Lit when an event is detected. COPY lamp Indicates copying operation. PLAY lamp Lit when copying. Power button Turns on or off the device. 11 USB1, USB2 USB ports for external devices (mouse, USB memory stick). 12 ESC button The Escape button navigates up the menu tree and closes Int 10 21 Install Manual d dialog windows. COPY Starts Copy mode. 14 FUNC Starts Function mode. 15 MONITOR Switches from main and sub monitor 16 PTZ Starts or ends PTZ function. 17 PLAY/ENTER Start playback or select an item on the menu. 18 ◀/REW Navigates or selects in the menu, or for playback, changes 19 Navigates or selects in the menu, or for playback, changes ▶/FWD the forward playback speed. ▲/PAUSE Navigates or selects in the menu, or for playback, pauses y& 20 Fir e the reverse playback speed. Lt 13 live or recorded video. ▼/STOP 21 Navigates or selects in the menu, or for playback, stops Int ell ige nt Se cu rit playback. 22 d Install Manual SVR-3200 Input/Output terminal name Function Se cu No. rit y& Fir e 2.2.2.1 Lt 2.2.2 Rear Part 1 POWER IN 2 CH1 ~ 32 3 MONITOR 1 ~ 4 4 AUDIO IN(RCA) 5 AUDIO OUT 6 GROUND 7 ETHERNET Ethernet port for network connections (RJ-45). 8 STORAGE External storage connection port (Function not supported in the 10 12 Connection terminal for monitor BNC output. RCA audio jack for RCA input. Audio jack for speaker output. nt Ground terminal between DVR and external device. current version) eSATA Connection terminal for external eSATA HDD or HDD for backups. VGA OUTPUT 2 Output port for PC monitor. VGA OUTPUT 1 Output port for PC monitor. ell 11 Connection terminal for camera BNC input. ige 9 Socket for AC 100V ~ AC 240V power cord. Serial Port (Terminal Connection terminal for expanded controller, speed dome camera, Block) etc. Int RS-232C/485/422 13 Serial Port (D-Sub) RS-232C D-SUB connector. 14 RELAY OUT Connection terminal for relay output. 23 Connection terminal for sensor input. 16 AUDIO IN(D-SUB) Connection terminal for audio output D-SUB. 17 D-I/O Connection terminal for DIGITAL IN/OUT. Lt SENSOR IN Int ell ige nt Se cu rit y& Fir e 15 d Install Manual 24 Install Manual d SVR-1680C, SVR-1660C, SVR-1645 No. y& Fir e Lt 2.2.2.2 Input/Output Function rit terminal name POWER IN Socket for AC 100V ~ AC 240V power cord. 2 CH1~16 Connection terminal for camera BNC input. 3 LOOP OUT Connection terminal for camera BNC output (loop). 4 MONITOR 1 ~ 2 5 AUDIO IN(RCA) 6 AUDIO OUT 7 GROUND 8 ETHERNET 9 STORAGE Se cu 1 Connection terminal for monitor BNC output. RCA audio jack for RCA input. Audio jack for speaker output. Ground terminal between DVR and external device. Ethernet port for network connections (RJ-45). nt External storage connection port (Function not supported in the current version) 11 Connection terminal for external eSATA HDD or HDD for backups. VGA OUTPUT Output port for PC monitor. Serial Port (Terminal Connection terminal for expanded controller, speed dome Block) RS-232C/485/422 camera, etc. ell 12 eSATA ige 10 Serial Port (D-Sub) RS-232C D-SUB connector. 14 RELAY OUT Connection terminal for relay output. 15 SENSOR IN Connection terminal for sensor input. Int 13 16 AUDIO IN(D-SUB) Connection terminal for audio output D-SUB. 17 D-I/O Connection terminal for DIGITAL IN/OUT. 25 SVR-960C Input/Output Function rit No. y& Fir e Lt 2.2.2.3 d Install Manual terminal name POWER IN Socket for AC 100V ~ AC 240V power cord. 2 GROUND Ground terminal between DVR and external device. 3 CH1~9 4 LOOP OUT 5 MONITOR 1 ~ 2 6 AUDIO IN(RCA) 7 AUDIO OUT 8 ETHERNET 9 eSATA 10 VGA OUTPUT Output port for PC monitor. 11 Serial Port (D-Sub) RS-232C D-SUB connector. Serial Port (Terminal Connection terminal for expanded controller, speed dome camera, Block) etc. Connection terminal for camera BNC input. Connection terminal for camera BNC output (loop). Connection terminal for monitor BNC output. RCA audio jack for RCA input. Audio jack for speaker output. Ethernet port for network connections (RJ-45). nt ige 12 Se cu 1 Connection terminal for external eSATA HDD or HDD for backups. ell RS-232C/485/422 RELAY OUT Connection terminal for relay output. 14 SENSOR IN Connection terminal for sensor input. 15 AUDIO IN(D-SUB) Connection terminal for audio output D-SUB. Int 13 16 D-I/O Connection terminal for DIGITAL IN/OUT. 26 SVR-945 Input/Output Function rit No. y& Fir e Lt 2.2.2.4 d Install Manual terminal name CH1~9 Connection terminal for camera BNC input. 2 LOOP OUT Connection terminal for camera BNC output (loop). 3 MONITOR 1 ~ 2 4 AUDIO IN(RCA) 5 AUDIO OUT 6 ETHERNET 7 eSATA Se cu 1 Connection terminal for monitor BNC output. RCA audio jack for RCA input. Audio jack for speaker output. Ethernet port for network connections (RJ-45). Connection terminal for external eSATA HDD or HDD for nt backups. VGA OUTPUT Output port for PC monitor. 9 Serial Port (D-Sub) RS-232C D-SUB connector. 10 Serial Port (Terminal Connection terminal for expanded controller, speed dome Block) RS-232C/485/422 camera, etc. RELAY OUT Connection terminal for relay output. AUDIO IN(D-SUB) Connection terminal for audio output D-SUB. 11 ell 12 ige 8 SENSOR IN Connection terminal for sensor input. 14 D-I/O Connection terminal for DIGITAL IN/OUT. 15 GROUND Ground terminal between DVR and external device. Int 13 16 POWER IN Socket for AC 100V ~ AC 240V power cord. 27 Install Manual d SVR-480 No. y& Fir e Lt 2.2.2.5 Input/Output Function rit terminal name GROUND Ground terminal between DVR and external device. 2 CH1~4 Connection terminal for camera BNC input. 3 LOOP OUT Connection terminal for camera BNC output (loop). 4 MONITOR 1 ~ 2 5 AUDIO IN(RCA) 6 AUDIO OUT 7 ETHERNET 8 eSATA Se cu 1 Connection terminal for monitor BNC output. RCA audio jack for RCA input. Audio jack for speaker output. Ethernet port for network connections (RJ-45). Connection terminal for external eSATA HDD or HDD fo nt backups. Serial Port (D-Sub) RS-232C D-SUB connector. 10 VGA OUTPUT Output port for PC monitor. 11 Serial Port (Terminal Block) Connection terminal for expanded controller, speed RS-485/422 dome camera, etc. RELAY OUT Connection terminal for relay output. SENSOR IN Connection terminal for sensor input. 12 ell 13 ige 9 14 POWER IN Socket for AC 100V ~ AC 240V power cord. Int Please refer to the detailed description for installation & use in the “Install Manual”. 28 Install Manual d 2.2.3 Remote control All DVR unit features can be controlled with the remote controller; 16 units can be controlled Lt with a single remote controller. Unit IDs should be set in the DVR Menu > Communication > Remote > Remocon ID. Classification 1 ID 2 FUNC 3 MULTI Function Fir e No. Selects ID. Starts function mode. Changes split-screen sections for live video or playback. STATUS Displays system setup y& 4 information. 5 MON Changes screen to spot monitor. AUTO Int Selects split-screen and channel options. Switches to automatic display. 8 ZOOM Executes digital zoom. 9 PIP Displays picture-in-picture. 10 PTZ Switches to PTZ mode. 11 Channel buttons Changes channels. 12 RECORD ( ) Starts and stops manual 13 +10 recording. Uses for channels over 9 (e.g. "+10” + “1”) 14 FN1 Spare button 1. 15 FN2 Spare button 2. 16 MENU Switches to menu screen. 17 COPY Displays copy menu and ell ige nt Se cu 7 DISP rit 6 saves recorded video to external storage device (USB). 29 18 Classification Function Moves cursor left in setup (◀) menu. 19 Lt No. d Install Manual Moves cursor right in (▶) 20 (▲) Fir e setup menu. Moves cursor up in setup menu. 21 (▼) Moves cursor down in setup menu. ENTER 23 ESC Saves settings and execute. Cancels settings or y& 22 navigates up in menu. 24 SEARCH( ) Displays the search menu. 25 FAST Fast reverses playback. 26 rit REWIND(◀◀) REWIND Reverses playback. PLAY(◀) FORWARD Se cu 27 Forwards playback. PLAY(▶) 28 FAST Fast forwards playback. 29 STOP( ) Stops playback. 30 STEP Reverses playback frame by REVERSE(◀l) frame. STEP Forwards playback frame by FORWARD(l▶) frame. 32 PAUSE(ll) Pauses playback. 33 P/T Controls PAN/TILT. 34 LOAD PRESET Loads presets. 35 AUX ON Turns auxiliary on. 31 Int ell ige nt FORWARD(▶▶) 30 Install Manual Lt d Chapter 3. Installation 3.1 Installation & Connection Fir e 3.1.1 Basic connection and operation 3.1.1.1 Camera connection rit y& Connect the DVR and CCTV cameras using coaxial cable as in the following figure. - The cameras’ video input type must be one and only of NTSC or PAL. Both types should not be used together. Se cu - Automatic settings for 75Ω terminal resistance While terminal resistance is generally 75Ω with only one video input port in use, when the lower video input port is also connected, the settings automatically separate into 75Ω terminal resistance while the status is Hi-Z (high impedance). - The video input type (NTSC/PAL) is automatically recognized when the device is operation. When multiple cameras are used, the video input type is taken from the first camera detected nt starting from channel 1 and progressing sequentially to channel 16. 3.1.1.2 Monitor connection Int ell ige Monitors connect to the DVR unit using a video cable as shown in the following figure. 31 Install Manual d 3.1.1.3 Audio connection Audio equipment connects to the DVR unit using RCA audio cables or D-SUB as shown in the y& Fir e Lt following figure. SVR-480 does not support D-SUB audio. Se cu rit Refer to the following figure when connecting D-SUB. The audio inputs are pin numbers 5 ~ 16. 3.1.1.4 Power connection & operation ige nt Connect the power cable as shown in the following figure. - The DVR unit will boot automatically when the power is connected. - To turn the DVR unit off, press the power button for 5 seconds, then choose “Yes” when the ell power-off dialog appears. Int - To turn the power on again, press the power button. 32 3.2 Fir e Lt d Install Manual OSD Menu structure & Operation 3.2.1 Menu structure Press the [MENU] button on the front panel to change to setup mode and display the following y& dialog. Sub menu rit Main menu Setup dialog Se cu box (1) Main menu: The currently selected tab is highlighted in blue with submenus and options displayed below. Use the cursor [◀/▶] keys to navigate between submenu items then press nt [Enter] to activate it. ige (2) Sub menu: The currently selected submenu name is displayed in the title bar. Use the cursor [◀/▶] keys to navigate across submenus and press [Enter] to display it in the dialog box. Press [ESC] to navigate up to the main menu tabs. ell (3) Setup dialog box: The currently selected setting is highlighted in blue. Use the cursor [◀/▶] keys to move between settings and press [Enter] or [▼] to enter edit mode and change a setting. All setting values are either numeric or text based. Use the cursor [◀/▶] or [▲/▼] keys Int to edit numeric values. Text based values are edited with the character input dialog. To save a value and resume navigation, press [ESC]. Press [ESC] again to navigate up to the main menu. 33 Install Manual Character input dialog box d 3.2.1.1 Fir e Lt The characters input dialog lets you input text. Character input Use the cursor [▲/▼] and [◀/▶] keys to choose characters then press [Enter] to input it. Use y& [Å] to backspace, and [Æ] to insert a space. When finished, press [Enter] to exit the character input dialog with the newly inputted value. 3.2.2.1 rit 3.2.2 Remote control setup & basic operation ID setup When operating multiple units, a single remote controller can be used to control all of them by ige nt Se cu assigning each unit a unique ID. Setup each unit's unique ID as follows. (1) Press [MENU]. ell (2) Press [▶] to select “Network” then press [Enter] or [▼]. (3) Press [▼] to select “Remote” then press [Enter]. (4) Press [▶] to select “Remote Control ID” then press [Enter]. Int (5) Adjust the ID value using [◀/▶] then press [ESC]. (6) Press [ESC] several times until you are back in monitor mode. 34 Install Manual d Remote Control ID supports a maximum of 16 IDs. 3.2.2.2 Lt For unused remote controllers, set Remote Control ID to Off. Selecting IDs All DVR unit features can be controlled with the remote controller; 16 units can be controlled Fir e with a single remote controller. Unit IDs should be set. 1) Check the remote controller ID in DVR Menu. 2) Press the ID button on the remote controller. 3) Press the number button on the remote controller. If the remote controller ID and the DVR ID are the same, the DVR buzzer beeps Usable range of Remote Controller 3.2.2.4 Inserting and changing batteries in the Remote Controller Se cu rit y& 3.2.2.3 ige nt The remote controller takes AAA sized batteries. 1. Open the battery cover on Int ell the back. 2. Check the positive(+) and negative(-) battery poles 3. Close the battery cover. and insert or replace the batteries. 35 Install Manual Lt Basic connection diagram Fir e 3.2.3.1 Se cu rit Extended connection diagram y& Connect the cameras, monitors and audio. 3.2.3.2 d 3.2.3 Example of installation structure Connect the cameras, monitors, audio, sensors, relays and other peripherals. External storage and backup connection diagram ell ige nt 3.2.3.3 Int Connect a USB memory device or a “Samsung SVS-5E external HDD (eSATA)” unit. 36 Install Manual d Internet/Intranet connection diagram Fir e Lt 3.2.3.4 3.2.4.1 y& 3.2.4 Basic setup Video check The product automatically powers on when the power cord is plugged in. Once it finishes rit booting up, the default 16 channel split-screen is displayed. If a password for the unit has been set, the password input dialog is displayed. Se cu Only the numeric buttons work here and all others are temporarily disabled until ige nt the correct password is entered. (The factory default has no password protection.) Date & time setup ell 3.2.4.2 - Press [MENU] and select “Quick Setup” when the OSD menu appears. Int - After selecting “System Time”, press [Enter]. 37 Fir e Lt d Install Manual y& Time Zone (1) Press [◀/▶] or [▲/▼] to select “Time Zone”, and then press [Enter]. (2) Press [◀/▶] to set the correct Time Zone, and then press [ESC]. rit Daylight Saving (1) When selecting a Daylight Saving Time zone, Daylight Saving automatically changes to On, and is Off for other time zones. ige nt Saving to Custom. Se cu (2) To customize the start and end time of DST, use the [◀/▶] buttons and change Daylight (3) Changing Daylight Saving to Custom displays the Custom DST Setup options. ell Upon clicking on Custom DST Setup, two setup methods display. Int The first is for selecting a month and date to define the start and end times of DST. 38 Fir e Lt d Install Manual Se cu rit y& The second is for selecting a month, week, and day to define the start and end times of DST. Date Format (1) Press [◀/▶] or [▲/▼] to select “Date Format”, and then press [Enter]. Press [◀/▶] to select a date format: YYYY/MM/DD, MM/DD/YYYY, or DD/MM/YYYY. nt (2) Press [ESC] to exit edit mode. Time ige (1) Press [◀/▶] or [▲/▼] to select “Time”, and then press [Enter]. (2) Press [◀/▶] to individually select “Date” and “Time”. Press [▲/▼] to set the proper values for each. ell (3) Press [ESC] to exit edit mode. Apply Date/Time Setting a new date and/or time has a serious impact on the HDD recording file system. As such, Int unlike other settings that are automatically saved, the date and time settings must be manually saved to avoid the possibility of an inadvertent change. Click the [Apply Date / Time] button to confirm and save the settings. 39 d Install Manual (1) Press [◀/▶] or [▲/▼] to select “Apply Date / Time” and then press [Enter]. A confirmation Lt dialog is displayed as shown below. (2) Press [◀/▶] or [▲/▼] to select “YES” and then press [Enter]. Press [ESC] to cancel the Fir e new date/time and return to the original value from before. Record setup y& 3.2.4.3 Se cu rit Press [Menu] and select “Quick Setup” when the OSD menu appears. Program setup nt This menu allows user to set resolution, frame rates, and quality for each channel individually. Int ell ige Please refer to the “Record setup” sections for more information. 40 Fir e Lt d Install Manual y& Schedule Setup Se cu rit Select the “Schedule & Event” option, and set the Day & Time options. nt How to check the record status If the record setup is configured correctly, [REC LED] on the front panel will ige light up RED. Also, record status [S] will be displayed on the video screen. [S] indicates scheduled recording. Using input/output terminals ell 3.3 3.3.1 Handling cable ends The following details how to handle cables for the terminal block. Please note that different Int gauges of wire are needed for stranded wire and solid wire. 41 Fir e Lt d Install Manual - Stranded wire: Strip 8 ~ 10㎜ of insulation off the end of the wire and solder it together. Use AWG 22 ~ 26 wire. - Solid wire: Strip 8 ~ 10㎜ of insulation off the end of the wire. Use AWG 20 ~ 26. y& 3.3.2 Wire insertion/removal When inserting/removing wires to/from the terminal block, push the driver as shown below and Se cu rit insert or remove the wire. 3.3.3 Sensor connections & settings Specification nt 3.3.3.1 ige The sensor specifications are as follows. 16 transistor input Input types N.C, N.O support Support Sensor Dry contact sensor Connection method Insert stripped wire end into terminal block ell Specification No. of inputs Electric Int capacity Pulse width of usable Minimum 500ms input Output power Typical DC 12mA 42 Install Manual d Sensor input terminal connection Connect sensors to S1 ~ S16 as illustrated in the figure below. Please note that the figure Lt shows connecting sensors with dry contacts. Refer to the section on handling wiring for more rit y& Fir e information about connecting or disconnecting sensor wires. Sensor Settings (1) Press [Menu] and select “Event” when the OSD menu appears. ell ige nt Se cu (2) Press [Enter] or [▼] to enter the submenu, select “Sensor” and press [Enter]. All This allows setting all 16 sensors simultaneously to off or Normal Open (N.O.) / Normal Close Int (N.C.). (1) Set the input type after setting "All". 43 Install Manual d Individual sensor This option allows setting each of the 16 sensor input types individually. Lt (1) Select a sensor then press [Enter]. (2) Set the input type for the selected sensor. Fir e (3) Press [ESC] to exit to the OSD menu when you are finished. Sensor setup lets you choose whether or not to use sensors and their type, and Record & Relay setup, while set separately, should be set according to the sensor type. Please refer to the “Record setup”, the “Event Action” heading in 3.3.3.2 Relay connections & settings Specification The alarm specifications are as follows. Specification Output type 4 relay outputs rit No. of outputs y& the “Event setup”, and “Relay out” sections for more information. Dry contact Insert stripped wire end into terminal block Rated DC 30V 1A current AC Se cu Connection method Int ell ige nt 125V 0.5A 44 Install Manual d Relay out connection Connect relays to R1 ~ R16 as illustrated in the figure below. The example shows how to Lt connect a warning light. Refer to the section on handling wiring for more information about y& Fir e connecting or disconnecting relay wires. rit Relay Out Settings Relays can be triggered by following events; alarm sensor, motion detection, video loss, hard disk fail, hard disk full, fan fail, password fail, and DDNS registration failure. Relays can also Se cu be triggered remotely over the network using the Samsung Network Video Management ige nt software. ell For more information, refer to the user manual. The user manual can be downloaded from www.samsungcctv.com or on the CD Int provided with the product. 3.3.3.3 D-I/O (Digital Input/Output) connection & settings The D-I/O has 12 D-I/O ports and can accommodate 12 inputs/outputs. If sensors are working 45 Install Manual d as Relay out, the Output can be operated with digital I/O. Also, if Input is operated, the emergency recording is started. Then the emergency recording starts to record with the Event Lt Record value. The D-I/O specifications are as follows. Rated current No. of inputs/outputs 12 Output type DC 3V output Connection method Connect stripped wire end with 15 pin D_SUB. DC 3.3 ~ 5V y& Specification Fir e Specification D-I/O Connection D-I/O inputs/outputs are connected shown in the following figure. Please refer to the section on D-I/O Settings nt Se cu rit handling wiring for information about connecting and disconnecting. ige The 12 D-I/O ports are split with 6 for input and 6 for output. They can be configured under the Int ell Event Setup menu tab. 46 Fir e Lt d Install Manual y& For more information, refer to the user manual. The user manual can be downloaded from www.samsungcctv.com or on the 3.3.3.4 rit CD provided with the product. Serial communication terminal connections & settings Se cu Serial communication terminal connection for Pan/Tilt/Zoom PTZ cameras for the DVR unit can be connected through the COM port, and supported models configured through the OSD menu. The following figures illustrate how to connect PTZ cameras through the RS-422/485 port (COM2/COM4) and how to connect other devices through the serial port connection terminals.c Refer to the section on handling wiring for more information about connecting or disconnecting Int ell ige nt wires. [SVR-3200, 1680C, 1660C] 47 [SVR-1645, 960C, 945] Install Manual d Serial Comm. Terminal Connection Diagram y& Fir e Lt COM1 connection diagram(RS-232) rit COM2 connection diagram (RS-422/485) RS-485(All SVR series ) Int ell ige nt Se cu RS-422(SVR-3200, 1680C, 1660C) 48 d Install Manual Fir e Lt COM3 connection diagram (RS-232) PTZ, Keyboard Compatible List Manufacturer y& Model SDZ160/330, Samsung SPD SAMSUNG TECHWIN Keyboard SCC3000, Samsung SRX-100B BOSCH AutoDome, TC8560X-4 BOSCH PELCO rit PELCO(P), PELCO(D) HONEYWELL Sony EVI-D3x SONY VT VPT-4x AD SpeedDome SungJin SJ372R1’ Samsung SCC641 Panasonic WV-CS850 LG GAC-PT2 Se cu Honeywell 755/655, HRX-2000, ScanDome2 VT AD SUNGJIN SAMSUNG ELECTRONICS PANASONIC LG WEBGATE Inc. Merit-Lilin FastDome MERIT Elmo PTC200C ELMO CANON ige Canon VC-C4 nt Keyboard KBD300A, WGI SPD1800/2600 HTC-230S D-MAX RVision RVISION Elbex ELBEX VIDO ell VIDO VICON Hunt HUNT ORX-1000 SYSMANIA Fine CRR-1600 LIVEI Int VICON 49 TOKINA Kodicom KRE KODICOM Nuvico NUVICO Serial Settings Lt Tokina d Install Manual other two are RS-422/485(Com2, Com4). Fir e A total of four serial ports are available for the DVR. Two are RS-232C(Com1, Com3) and the The Serial Port settings are available under Communication > Remote. Se cu rit y& The following options are provided for the Serial Port settings. PTZ(Serial) Select PTZ. To control the PTZ operation via serial port, select PTZ in the Device options, and then set up a Int ell ige nt serial port. To control the PTZ operation via coax protocol, you do not need to set up this option. 50 Fir e Lt d Install Manual Type y& Select a serial port. Protocol Select a connected PTZ device. rit Camera ID Enter the ID of the selected camera. Se cu Interface Select one from among Com2 to 4. To use RS-232, select Com3. For RS-422 or 485, select Com2 or 4. Baud rate/Parity/Stop Bit/Data Bit Enter the same settings as the ones for the PTZ device. nt Idle Time Activate or disable PTZ Home, and set up a standby duration for the device before ige moving to PTZ home. PTZ(Coax) ell The Coax Protocol option does not support normal PTZ protocols, but rather supports the Pelco Standard and Extended Protocols. The standard protocol supports basic PTZ functions such as PTZ and presets. The extended Int protocol supports more expansive features such as menu control and video playback in addition to the basic PTZ functions. To use this option, a PTZ device must be embedded with a coax standard or extended protocol. 51 Fir e Lt d Install Manual Type y& Select Coax. Protocol rit Select Pelco or Pelco Extended according to the coax protocol type of Pelco camera. AD Dome does not support menu control, Presets or AUX when setup with a Se cu coax protocol. Idle Time Activate or disable PTZ Home, and setup a standby duration of the device before moving to PTZ home. 3.3.3.5 External device connection using Serial port nt Text Input Device Connection (ATM / POS / Access Control) Text and video data from POS/ATM terminals can be synchronously recorded through Int ell ige COM1/RS-232. As shown in the above figure, COM1/RS-232 (9-pin D-SUB) are used to receive text data that is configured under the OSD Communication > Event menu. 52 d Install Manual y& Fir e Lt Serial Settings (COM1) (1) In the OSD menu, navigate to Communication > Serial. (2) Set the “Serial Number” option to COM1 for text. rit (3) Set the Baud Rate/Parity/Stop bit/Data bit options identical to the Input device. ige nt Se cu Text Settings (1) On the OSD menu, select Event Setup > Text. (2) Set text and relations options. ell Some external devices may not be recognized. Please consult your product distributor prior to installation. Int 3.3.3.6 USB device connections The USB ports are mainly used to copy video data to supported external USB storage devices like USB memory sticks (copies data within an hour). 53 Install Manual d Supported USB devices conform to the following specifications. Fir e Lt USB Spec. Ver. 2.0 Supported device USB memory stick types Output Max. 200mA per DC 5V / Port voltage/current y& The storage device should be formatted with the FAT32 file system. Supported storage devices are automatically recognized when copying. To copy video, set Se cu rit copying options in the Copy dialog, select the storage device, then copy the data. [RE4 Copy] nt [CD/DVD Copy] Int ell ige Select the channel to copy. [SVR-960C/945] [SVR-1680C/1660C/1645] 54 [SVR-3200] y& [AVI Copy] Fir e Lt d Install Manual Some USB storage devices may require additional software and drivers. Care should be taken in these cases as the DVR may not recognize some USB products like this. If copied files do not playback on another computer, double 3.3.3.7 rit check that proper playback software and codecs are installed. Video in/out connections set terminal resistance. Se cu The DVR video input/output are “Loop through" and detect connection status automatically to For example, when only video input is connected, terminal resistance is internally set to 75Ω. However, when video input and output are connected, terminal resistance is set to Hi-Z. As such, when input and output are connected, the external output device should have its resistance set Int ell ige nt to 75Ω. 55 Install Manual Audio in/out connections d 3.3.3.8 There are 4 RCA audio in and 12 D-SUB audio in. Lt All 16 audio sources can be monitored through a single output. The 12 D-SUB audio inputs use terminals 5 ~ 16 and are connected as shown in the following 3.3.4 External Storage connections eSATA Port rit 3.3.4.1 y& Fir e figure. One eSATA external storage device can be connected through the eSATA port in the back of the Se cu DVR unit for a maximum of 8TB of storage space. The eSATA port only supports the “SVS-5E” eSATA external HDD from Samsung Techwin. 3.3.4.2 eSATA device connection Use the eSATA port in the back of the DVR unit to connect your SVS-5E external HDD. External Int ell ige nt storage requires its own power source as the DVR unit does not supply power to it. Since some external devices may not be recognized if connected with the DVR unit on, the following procedure should be followed. 56 Install Manual d 1. Turn DVR power OFF. 2. Connect external device and eSATA interface cable. Lt 3. Turn external device power ON. 3.3.4.3 Supported HDD Fir e 4. Turn DVR Power ON. Refer to the appendix in the back of the manual for information on supported HDDs. 3.3.4.4 Registering & formatting HDDs When the DVR is first booted after a new HDD is physically installed, the "Disk Manager" automatically runs as shown in the following figure. Se cu rit y& If the “Disk Manager” does not run, check that the HDD is properly installed. (1) Press [Enter] with “Disk Manager” selected. (2) Press [▲/▼] to select the new HDD (“No” under the “Enabled” column heading), and then press [Enter]. (3) If prompted to format the disk, select “YES”. ige nt (4) Close “Disk Manager” by pressing [ESC]. 3.3.4.5 Attaching & Detaching HDD Please follow the instructions below to add or replace an HDD. ell Attaching an HDD Attach the enclosed HDD fixture screws to both sides of the HDD. With 2 fixture screws to a side, attach 4 screws to the HDD. Int The following picture shows an HDD attached with 4 fixture screws. 57 Fir e Lt d Install Manual Once the HDD is attached with the screws, insert it into an HDD bracket. For the location of HDDs, IntA is the bottom right, IntB is the upper right, IntC is the bottom left, y& and IntD is the upper left. The following picture shows an HDD being inserted to IntA. When attaching an HDD, first insert the front part of the HDD to the bracket, and then press ige nt Se cu rit down on the other side with the SATA port. Once the HDD is inserted, connect the SATA and power cables. As shown in the picture below, connect the enclosed SATA cable, and then an SMPS power cable. Int ell The following picture shows the product attached with the maximum 4 HDDs. 58 ige nt Se cu rit y& Fir e Lt d Install Manual After inserting the HDD, fasten the HDD fixture bracket as shown in the picture below. Int ell Now the HDD is fully attached to the product. 59 rit y& Fir e Lt d Install Manual the DVR Disk menu. Se cu To enable the newly attached HDD, you must change the availability of the HDD to "Yes" under To access the menu, go to Menu > System Settings > Disk > Disk Manager. ell ige nt The newly attached HDD will display in the HDD list with No in the Availability pane. Int To change the availability, place the cursor on No and then press Enter. When a dialog window appears, select "Yes." Now the HDD is ready to use. 60 y& Fir e Lt d Install Manual Detaching HDD Detaching an HDD is the same as attaching it, but in reverse order. ell ige nt Se cu rit Loosen the HDD fixture bracket. Unplug the SATA and power cables. Detach the HDD. When detaching an HDD, first lift up the back part of the HDD with the SATA port, and then the Int front part. Remove or keep the HDD fixture screws in case you want to attach an HDD later. 61 y& Fir e Lt d Install Manual rit Go to Menu > System Settings > Disk > Disk Manager. Select the detached HDD, and the press Enter. Select "Yes" in the dialog window and remove Int ell ige nt Se cu the HDD from the HDD list. 62 d Install Manual 3.3.5 Remote monitoring & control connection can be used to control DVRs and monitor areas same as local spot. Fir e Ethernet connection (1) Shut the DVR power off. rit y& 3.3.5.1 Lt Connections can be made through Internet/Intranet by using the remote computer. This Se cu (2) Connect the Ethernet cable to the DVR and hub or router. (3) Turn the DVR power on. To prevent damage to the DVR, turn the power on after connecting the Ethernet cable. The Ethernet cable should be securely connected. After powering on the DVR, check the connection. Network settings nt 3.3.5.2 ige The following describes settings for Ethernet. Refer to “User Manual” when using xDSL for detailed setup instructions. The user manual can be downloaded from www.samsungcctv.com or found on Int ell the CD provided with the product. 63 y& Fir e Lt d Install Manual When using Ethernet Set the type to Ethernet and fill in the IP address, Netmask, Gateway, and DNS information rit provided by your network administrator. Use Up/Down direction keys or the mouse wheel to When using PPPoE Se cu select the items, and then setup with the appropriate values. Change the network configuration type to xDSL then navigate to the xDSL menu. Change the port from Ethernet. (IMPORTANT: You must remember the port.) In the xDSL screen, input the login ID and password that you received when you registered for PPPoE. When using DDNS nt Change the DDNS polling interval to more than 1 minute and enter the login ID and password Int ell ige for your DDNS server. 64 Install Manual d Trouble Shooting Check power z Check power cord 2. Monitor does not display camera video Check monitor power z Check cable between the monitor and DVR z Check monitor cable port z Check that DVR power is on y& z Fir e z Lt 1. DVR does not boot 3. Some channels do not display images Check camera power z Check camera video input z Check DVR video input port z Check whether the Screen > Activity option is on/off z Check the Monitor > Covert option for privacy settings Se cu rit z 4. DVR does not record z Check Disk Manager to see that the HDD is installed z Check the Record settings 5. DVR does not playback Check the Record settings z Check for button activation nt z ige 6. Video is overly bright / dark Check the camera settings z Check that video and power cables are properly plugged in z Check brightness and contrast settings under the “Screen” menu ell z 7. Remote controller does not work Check the Remote controller battery z Check the Remote controller ID z Check Remote controller usage specifications Int z 65 Install Manual Check DVR power z Check screen lock status Lt z d 8. Front buttons do not work z Check that network cable is properly connected z Check DVR IP address z Check PC IP address z Run a ping test 10. When to contact your reseller Fir e 9. Cannot connect to network y& If any of the following happen, immediately turn of the DVR and contact the reseller that you purchased it from. z The product exhibits extremely abnormal behavior, e.g. strange noises, odors, or smoke The power jack is damaged z Rain, water, or other liquids get into the product z The product does not work as described in the user manual z The product has fallen and become damaged z Product performance changes significantly Int ell ige nt Se cu rit z 66 Install Manual d Compatible HDD List Model 1000GB WD10EVCS 750GB WD7500AVCS 500GB WD5000AVVS 320GB WD3200AVVS Compatible Media List Fir e Capacity Lt Western Digital CD-R manufacture Mitsubishi (16X) Mitsubishi (16X) TDK (16X) TDK (16X) Imation (16X) Imation (16X) Sony (16X) Sony (16X) y& DVD-R manufacture rit Specification Item Display Description Se cu SVR-3200 : 32 composite video 0.5–2 Vpp, 75 ohm automatic termination SVR-1680C/1660C/1645 : 16 composite video 0.5–2 Inputs Video Vpp, 75 ohm automatic termination SVR-960C/945 : 9 composite video 0.5–2 Vpp, 75 ohm automatic termination nt SVR-480 : 4 composite video 0.5–2 Vpp, 75 ohm Int ell Live ige Resolution Frame rate automatic termination 704x480 NTSC SVR-3200 : NTSC(960Cfps), PAL(800fps) SVR-1680C/1660C/1645 : NTSC(480fps), PAL(400fps) SVR-960C/945 : NTSC(270fps), PAL(225fps) SVR-480 : NTSC(120fps), PAL(100fps) Resolution 704x480 NTSC, 704x576 PAL SVR-3200/1680C/1660C/1645 : 1/4/9/10/16 Multi Screen SVR-960C/945 : 1/4/9 SVR-480 : 1/4 67 Install Manual Record Rate/NTSC MPEG-4 Lt Compression Recording d Performance SVR-3200 : 480fps@704x480, 960Cfps@704x240, 960Cfps@352x240 480fps@352 x 240 Fir e SVR-1680C : 480fps@704x480, 480fps@704x240, SVR-1660C/1645 : 120fps@704x480, 240fps@704x240, 480fps@352x240 SVR-960C/945 : 120fps@704x480, 240fps@704x240, 270fps@352x240 SVR-480 : 120fps@704x480, 120fps@704x240, y& 120fps@352x240 SVR-3200 : 400fps@704x576, 800fps@704x288, 800fps@352x288 SVR-1680C : 400fps@704x576, 400fps@704x288, 400fps@352x288 rit Record Rate/PAL SVR-1660C/1645 : 100fps@704x576, 200fps@704x288, 400fps@352x288 Se cu SVR-960C/945 : 100fps@704x576, 200fps@704x288, 225fps@352x288 SVR-480: 100fps@704x576, 100fps@704x288, 100fps@352x288 Mode Continuous Pre-Event Up to 5 sec. Post-Event Up to 60 sec. Search mode ige Playback Overwrite modes nt Search & Frame rate ell Playback function Int Network Manual, Schedule, Event, Emergency Transmission speed Date/time, Event, Calendar, Thumbnail, Bookmark Text(Exclusive viewer) 480 fps D1 NTSC, 400 fps D1 PAL REW, FWD, Frame advance (control keys and jog shuttle) SVR-3200/1680C : 16 Mbps SVR-1660C/1645/960C/945/480 : 9 Mbps Bandwidth control Automatic Multi Stream MPEG-4(Dual Streams)/JPEG Remote Users Up to 10 simultaneous users 68 Install Manual Maximum Capacity Internal HDD External HDD SVR-1645/960C/945/480 : 8 TB SVR-3200/1680C/1660C : 4 HDD SVR-1645/960C/945/480 : 2 HDD SVR-3200/1680C/1660C : External eSATA 2 port SVR-1645/960C/945/480 : External eSATA 1 port DVD-R / CD-R USB (Back-up) 2 External USB Ports(USB 2.0) BMP, AVI, Proprietary format / JPG(Exclusive viewer) Password Protection 10 User Level Data Authentication Watermark rit Interface Analog RGB 800x600, 1024x768, 1280x1024 VGA Monitors d SVR-3200/1680C/1660C : 16 TB DVD Writer (Back-up) File Format (Back-up) Security CMS Software(SNM-128S/P), Built-in web server y& Storage and NTP Lt Monitoring TCP/IP, DHCP, DNS, DDNS, HTTP, ARP, ICMP Fir e Protocol support resolution BNC, 1 Vp-p, 75 ohm, Multi-screen, Menu, Playback Se cu Main Composite Monitor2~4 : SVR-3200/1680C(Menu, Event Pop- Sub Composite up, Covert, Display Switching) Sport : SVR-1660C/1645/960C/945/480(event Popup, Display switching), 1 Vp-p, 75 ohm SVR-3200 : None nt SVR-1680C/1660C/1645 : 16 Output, 1 Vpp, 75 ige Loop Outputs Int ell Audio Alarm Inputs ohm SVR-960C/945 : 9 Output, 1 Vpp, 75 ohm SVR-480 : 4 Output, 1 Vpp, 75 ohm SVR-3200/1680C/1660C/1645 : 16 input, 30k ohm SVR-960C/945 : 9 input Output 1 line, 100k ohm Compression ADPCM Sampling rate 16 kHz SVR-3200/1680C/1660C/1645 : 16 Input, NO/NC Inputs SVR-960C/945 : 9 Input SVR-480 : 4 Input 69 Screw terminal 4 relay outputs, NO/NC Outputs (SVR-480 : Screw terminal 2 relay outputs, NO/NC) Remote notification Notification via e-mail Ethernet RJ45 10/100 Base-T Serial interface RS232 Lt Connections d Install Manual PTZ control interface Fir e SVR-3200/1680C/1660C : RS485/RS422 SVR-1645/960C/945/480 : RS485 Via coax cable (SVR-1680C/1660C/960C) PTZ Keyboard RS485, max. signal voltage ±12 V USB 2 USB 2.0 ports SVR-3200/1680C/1660C : External eSATA 2 port eSATA Application Support Dome ATM/POS, Mouse, Remote Controller Supported PTZ cameras Protocols y& SVR-1645/960C/945/480 : External eSATA 1 port Samsung Techwin, Pelco D, Pelco P, Pelco Coaxitron, Panasonic, Bosch, SEC Input Voltage Electrical 100 to 240 VAC ±10%; 50/60 Hz, Auto-ranging Max. 65 W (with 1x HDD) Max. 88 W (with 2x HDD) Se cu Power consumption rit General Max. 90 W (with 4x HDD) Environmental Operating Temperature Operating Humidity +5°C to +40°C (+32°F to +104°F) 0% RH to 60% RH 445 x 88 x 388 mm (17.5 x 3.5 x 15.3 in) SVR-945 : 300 x 88 x 302 mm(118.11 x 34.65 x Dimensions (W x H x D) ige nt Mechanical Weight (1x hard disks) ell Rack mount kit Int Language 130.7 in) SVR-480 : 350 x 88 x 401.3 mm(13.77 x 3.46 x 15.79 in) Approx. 10 kg (22.1 lb), SVR-945 : 5 kg (11 Ib) SVR-480 : 5.6kg For mounting one unit in an EIA 19-inch rack (SVR-945 Stand type) English, Spanish, French, German, Italian, Polish, Portuguese, Russian, Turkish, Japanese, Czech, Serbian, Swedish, Rumanian, Danish, Chinese, Korean, Taiwanese 70 d Install Manual Lt Dimensions Int ell ige nt Se cu rit y& Fir e SVR-3200, SVR-1680C, SVR-1660C, SVR-1645 71 nt ige ell Int y& rit Se cu Fir e SVR-960C d Lt Install Manual 72 nt ige ell Int y& rit Se cu Fir e SVR-945 d Lt Install Manual 73 nt ige ell Int y& rit Se cu Fir e SVR-480 d Lt Install Manual 74 Install Manual d This product uses some Software programs which are distributed under the GNU GPL(General Public License)/LGPL license, and the program is licensed as is without warranty of any kind. , Lt The program can be obtained from us for a period of three years after our last distribution of this product by sending email to [email protected]. If you want to obtain the complete Corresponding Source Code in the physical medium such as CD-ROM by airmail, the cost of Fir e physically performing source distribution might be charged. This offer is valid to anyone in receipt of this information. For more additional information visit http://samsungcctv.com/gpl GPL Software : linux kernel, busybox, boa, dhcpcd, iproute2, rp-pppoe, smartsuite. GNU GENERAL PUBLIC LICENSE y& Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA rit Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble Se cu The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change free software--to make sure the software is free for all its users. This General Public License applies to most of the Free Software Foundation's software and to any other program whose authors commit to using it. (Some other Free Software Foundation software is covered by the GNU Lesser General Public License instead.) You can apply it to your programs, too. When we speak of free software, we are referring to freedom, not price. Our General Public nt Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if ige you want it, that you can change the software or use pieces of it in new free programs; and that you know you can do these things. To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to surrender the rights. These restrictions translate to certain responsibilities for ell you if you distribute copies of the software, or if you modify it. For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all the rights that you have. You must make sure that they, too, receive or can Int get the source code. And you must show them these terms so they know their rights. We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission to copy, distribute and/or modify the software. 75 Install Manual d Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this free software. If the software is modified by someone else and problems introduced by others will not reflect on the original authors' reputations. Lt passed on, we want its recipients to know that what they have is not the original, so that any Finally, any free program is threatened constantly by software patents. We wish to avoid the Fir e danger that redistributors of a free program will individually obtain patent licenses, in effect making the program proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all. The precise terms and conditions for copying, distribution and modification follow. TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION y& 0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The "Program", below, refers to any such program or work, and a "work based on the Program" means either the Program or any derivative work under copyright law: that is to say, rit a work containing the Program or a portion of it, either verbatim or with modifications and/or translated into another language. (Hereinafter, translation is included without limitation in the term "modification".) Each licensee is addressed as "you". Se cu Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made by running the Program). Whether that is true depends on what the Program does. 1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an nt appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the ige Program a copy of this License along with the Program. You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee. 2. You may modify your copy or copies of the Program or any portion of it, thus forming a work ell based on the Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided that you also meet all of these conditions: a) You must cause the modified files to carry prominent notices stating that you changed Int the files and the date of any change. b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be licensed as a whole at no 76 Install Manual d charge to all third parties under the terms of this License. c) If the modified program normally reads commands interactively when run, you must Lt cause it, when started running for such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty) and that users may Fir e redistribute the program under these conditions, and telling the user how to view a copy of this License. (Exception: if the Program itself is interactive but does not normally print such an announcement, your work based on the Program is not required to print an announcement.) These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Program, and can be reasonably considered independent y& and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a work based on the Program, the distribution of the whole must be on the terms of this License, whose permissions for other rit licensees extend to the entire whole, and thus to each and every part regardless of who wrote it. Thus, it is not the intent of this section to claim rights or contest your rights to work Se cu written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program. In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License. 3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also nt do one of the following: a) Accompany it with the complete corresponding machine-readable source code, which ige must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing source distribution, a ell complete machine-readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, Int c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with 77 Install Manual d such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making Lt modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the executable. However, as a Fir e special exception, the source code distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable. If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the y& same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code. 4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute rit the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance. Se cu 5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it. 6. Each time you redistribute the Program (or any work based on the Program), the recipient nt automatically receives a license from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions ige on the recipients' exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License. 7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, ell agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then Int as a consequence you may not distribute the Program at all. For example, if a patent license would not permit royalty-free redistribution of the Program by all those who receive copies directly or indirectly through you, then the only way you 78 Install Manual d could satisfy both it and this License would be to refrain entirely from distribution of the Program. Lt If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances. Fir e It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system, which is implemented by public license practices. Many people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software y& through any other system and a licensee cannot impose that choice. This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License. 8. If the distribution and/or use of the Program is restricted in certain countries either by rit patents or by copyrighted interfaces, the original copyright holder who places the Program under this License may add an explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded. In Se cu such case, this License incorporates the limitation as if written in the body of this License. 9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version number. If the Program specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by nt the Free Software Foundation. If the Program does not specify a version number of this License, you may choose any version ever published by the Free Software Foundation. ige 10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of ell preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally. NO WARRANTY Int 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS 79 Install Manual d AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE Lt IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU Fir e ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION. 12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL y& DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH rit HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Se cu GNU LESSER GENERAL PUBLIC LICENSE Version 3, 29 June 2007 Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/> Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. This version of the GNU Lesser General Public License incorporates the terms and nt conditions of version 3 of the GNU General Public License, supplemented by the additional ige permissions listed below. 0. Additional Definitions. As used herein, "this License" refers to version 3 of the GNU Lesser General Public ell License, and the "GNU GPL" refers to version 3 of the GNU General Public License. "The Library" refers to a covered work governed by this License, other than an Application Int or a Combined Work as defined below. 80 An "Application" is any work that makes use of an interface provided by the Library, but Library is deemed a mode of using an interface provided by the Library. Lt which is not otherwise based on the Library. Defining a subclass of a class defined by the d Install Manual A "Combined Work" is a work produced by combining or linking an Application with the Fir e Library. The particular version of the Library with which the Combined Work was made is also called the "Linked Version". The "Minimal Corresponding Source" for a Combined Work means the Corresponding Source for the Combined Work, excluding any source code for portions of the Combined Work that, considered in isolation, are based on the Application, and not on the Linked y& Version. The "Corresponding Application Code" for a Combined Work means the object code and/or source code for the Application, including any data and utility programs needed for the Combined Work. Se cu 1. Exception to Section 3 of the GNU GPL. rit reproducing the Combined Work from the Application, but excluding the System Libraries of You may convey a covered work under sections 3 and 4 of this License without being bound by section 3 of the GNU GPL. 2. Conveying Modified Versions. nt If you modify a copy of the Library, and, in your modifications, a facility refers to a function or data to be supplied by an Application that uses the facility (other than as an argument ige passed when the facility is invoked), then you may convey a copy of the modified version: a) under this License, provided that you make a good faith effort to ensure that, in the event an Application does not supply the function or data, the facility still operates, and performs ell whatever part of its purpose remains meaningful, or b) under the GNU GPL, with none of the additional permissions of this License applicable to that copy. Int 3. Object Code Incorporating Material from Library Header Files. 81 Install Manual d The object code form of an Application may incorporate material from a header file that is part of the Library. You may convey such object code under terms of your choice, provided Lt that, if the incorporated material is not limited to numerical parameters, data structure layouts and accessors, or small macros, inline functions and templates (ten or fewer lines in Fir e length), you do both of the following: a) Give prominent notice with each copy of the object code that the Library is used in it and that the Library and its use are covered by this License. b) Accompany the object code with a copy of the GNU GPL and this license document. y& 4. Combined Works. You may convey a Combined Work under terms of your choice that, taken together, effectively do not restrict modification of the portions of the Library contained in the rit Combined Work and reverse engineering for debugging such modifications, if you also do each of the following: Se cu a) Give prominent notice with each copy of the Combined Work that the Library is used in and that the Library and its use are covered by this License. b) Accompany the Combined Work with a copy of the GNU GPL and this license document. c) For a Combined Work that displays copyright notices during execution, include the user nt copyright notice for the Library among these notices, as well as a reference directing the ige to the copies of the GNU GPL and this license document. d) Do one of the following: ell 0) Convey the Minimal Corresponding Source under the terms of this License, and the Corresponding Application Code in a form suitable for, and under terms that permit, Int the user to recombine or relink the Application with a modified version of the Linked Version to produce a modified Combined Work, in the manner specified by section 6 of the GNU GPL for conveying Corresponding Source. 82 1) Use a suitable shared library mechanism for linking with the Library. A suitable d Install Manual mechanism is one that (a) uses at run time a copy of the Library already present on of the Library that is interface-compatible with the Linked Version. Lt the user's computer system, and (b) will operate properly with a modified version Fir e e) Provide Installation Information, but only if you would otherwise be required to provide such information under section 6 of the GNU GPL, and only to the extent that such information is necessary to install and execute a modified version of the Combined Work produced by recombining or relinking the Application with a modified version of the Linked y& Version. (If you use option 4d0, the Installation Information must accompany the Minimal Corresponding Source and Corresponding Application Code. If you use option 4d1, you must provide the Installation Information in the manner specified by section 6 of the GNU rit GPL for conveying Corresponding Source.) Se cu 5. Combined Libraries. You may place library facilities that are a work based on the Library side by side in a single library together with other library facilities that are not Applications and are not covered by this License, and convey such a combined library under terms of your choice, if you do both of the following: a) Accompany the combined library with a copy of the same work based on the Library, nt uncombined with any other library facilities, conveyed under the terms of this License. ige b) Give prominent notice with the combined library that part of it is a work based on the Library, and explaining where to find the accompanying uncombined form of the same work. ell 6. Revised Versions of the GNU Lesser General Public License. The Free Software Foundation may publish revised and/or new versions of the GNU Lesser General Public License from time to time. Such new versions will be similar in spirit Int to the present version, but may differ in detail to address new problems or concerns. 83 Each version is given a distinguishing version number. If the Library as you received it d Install Manual specifies that a certain numbered version of the GNU Lesser General Public License "or any Lt later version" applies to it, you have the option of following the terms and conditions either of that published version or of any later version published by the Free Software Foundation. If the Fir e Library as you received it does not specify a version number of the GNU Lesser General Public License, you may choose any version of the GNU Lesser General Public License ever published by the Free Software Foundation. If the Library as you received it specifies that a proxy can decide whether future versions y& of the GNU Lesser General Public License shall apply, that proxy's public statement of acceptance of any version is permanent authorization for you to choose that version for the Int ell ige nt Se cu rit Library. 84 nt ige ell Int y& rit Se cu Fir e d Lt Install Manual 85 nt ige ell Int y& rit Se cu Fir e d Lt Install Manual 86
