Straight Blade Receptacles
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
Receptacle Types
Hospital Grade
HOSPITAL SPEC
● 15–20 Amp Duplex &
Single Configurations
● Interlocking
Thermoplastic Nylon
Cover & Body
● Permanent "Green Dot"
Marked on Face
● Nickel-Plated Brass
Strap with Integral
Ground Contacts
● Surge, GFCI, and IG
Versions
8300-R
TAMPER-RESISTANT
POWER INDICATION
● 15–20 Amp Configurations
● 100,000 Hr. Green LED
Power Status Indicator
● Permanent “Green
Dot” Lens
● Suitable for Critical
Care Areas and
Emergency Circuits
● Nickel-Plated Brass
Strap with Integral
Ground Contacts
● Back & Side Wired
Ground Termination
● 15–20 Amp Duplex
Configurations
● Mechanical Safety
Shutter System
● Interlocking
Thermoplastic Cover
& Body
● Approved for Emergency
Circuits and Pediatric/
Psychiatric Care Areas
● Meets NEC Article
517-18C Requirements
8200-SGG
PAGES B3, H3-H10
8300-PLW
PAGES B3, H3
PAGES B3, H3
Straight Blade Receptacle Types
Industrial Grade
INDUSTRIAL SPEC
● 15–20 Amp Duplex &
Single Configurations
● Interlocking
Thermoplastic Nylon
Cover and Body
● Brass Strap with
Integral Ground
● Back and Side Wired
ISOLATED GROUND
SURGE PROTECTION
● 15–20 Amp Duplex &
Single Configurations
● Thermoplastic Nylon
Cover and Body
● Isolated Grounding
Contact
● Permanent "IG" Mark
● 15–20 Amp Duplex,
Single and 4-in-1
Configurations
● UL Listed to 1449 and
498 Standards
● Protection Indicator
Light and Audible
Damage Alarm
● Decora-Style Nylon
Face
● Surge with IG Versions
8310-IG
5262-E
8380-I
PAGES B4, B5, H4-H8, L20
PAGE B5
FOUR-IN-ONE
PAGES B8, G4, H6, L14
FLANGED OUTLETS
POWER INLETS & OUTLETS
● 15–20 Amp
Configurations
● Single Unit with
Weather Resistant
Cover
● Indoor/Outdoor Rated
to NEMA 3R and IP64
Standards
5279-C
21254-IGI
●
●
●
●
15–20 Amp Configurations
Hospital, Surge and IG Versions
Thermoplastic Nylon Face and Body
Universal Mounting
PAGES B4, B7, H5, L15 & L16
● 15–20 Amp Configurations
● Nylon Dead-Front Construction
● Thermoplastic Transparent Wiring
Module
● Captive, Color Coded Brass Terminal
Screws
PAGES C5 & C6, C12 & C13
5279-FWP
PAGES B23 & E40
Commercial Grade
COMMERCIAL SPEC
● 15–20 Amp
Configurations
● Back and Side Wired
and Side Wired Only
Versions
● Tamper-Resistant
Version
● Indented and Smooth
Face Versions
B
1
DECORA®-STYLE
BRASS FLOOR BOX
● 15–20 Amp Duplex and
Single Configurations
● Back and Side Wired
● Hospital Grade,Tamper
Resistant, Surge,
GFCI, IG & Power
Indication Versions
● Decora-Style Face
● 15 Amp Single
● Solid Brass Plate and
Integrated Single
Receptacle
● Brass Screw-In Plug
with Rubber O-ring
16362-A
PAGE B17–B21
PAGES B8, B15, B16, G5, G6, H7,
H8 & L19
PAGE B21
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
Receptacle Features
10 YEAR LIMITED
INDICATION
TM
Exclusive nickel-plated brass,
staked on, self-grounding clip,
will never fall off
Nickel-plated brass, one piece
mounting strap with integral
ground contact, for superior
ground path
Green LED meets UL498 Hospital
Grade identification requirements
and offers visual confirmation that
the device is energized
Back and side-wire
grounding terminal for
quick ground installation
Thick-walled impact-resistant
thermoplastic nylon cover and
body withstands abuse
Large, triple-wipe, nickel plated brass “T” contacts for superior contact and conductivity
Nickel-plated brass
bushing for additional
assembly security
Face and body locked together
with exclusive four-corner latch
construction, remains securely
fastened
Back and side
wiring options
Smooth face, easy
to clean and soil
resistant
One-piece mounting
strap for superior
ground path.
Green LED lens meets UL498
Hospital Grade requirement for
identification of HG devices.
COMPONENT
Apron barrier to prevent
accidental contact of terminal
screw heads with metal box
Circuit board integrates 100,000 hr.
LED and components in a
compact fail-safe assembly.
Nylon
Back
Nylon
Nickel-Plated Brass
Terminal Screws
Nickel-Plated Brass #10-32
Grounding Screw
Nickel-Plated Brass #8-32
Yoke
Nickel-Plated Brass
Clamp Nuts
Grounding Clip
Zinc-Plated Steel
Nickel-Plated Brass
WD-6
C-73
STANDARDS & CERTIFICATIONS
UL
UL Fed Spec
498HG
Exclusive V-shaped, serrated backwiring clamps for superior contact
and conductivity.
Power Indicaton
Available Colors
Line Contacts
ANSI
Back or side wired grounding
terminal offers wiring flexibility.
DESCRIPTION
Face
NEMA
Decora Plus™ Hospital Grade
Power Indication Receptacles
Also Available
8300-PLR
Hospital Grade Receptacle Features
Exclusive triple combination
#10-32 nickel-plated brass
terminal screws, straight slot,
Phillips #2, Robertson #1, for
quick, sure terminations
WC-596
CSA
C22.2 No. 42
NOM
#E13393
#LR-406
#057
8300-PLI
Ivory
8300-PLW
White
8300-PLR
Red
FOR HORSEPOWER RATING INFORMATION, SEE PAGE R11
B
2
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V& 250V; 20A 125V & 250V
Hospital Grade
10 YEAR LIMITED
NEMA 5-15R
ELECTRICAL
NEMA 5-20R
NEMA 6-15R
MECHANICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
TEMP.
RISE
Withstands
2000V
per
UL 498
Full
rated
current
Max 30C
after 250
cycles of
overload at
200% of
rated current
TERMINAL
I.D.
Brass, hot
Grounding
NEMA 6-20R
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #10 AWG
White,neutral
NEMA ANSI UL UL Fed Spec
WD-6 C-73 498HG WC-596
#E13399
CSA
NOM
C22.2 No. 42
#E13399
#152105 #057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
8200-HI
HOSP. GRADE
DUPLEX
8200-HLI
8300-PLW
HOSP. GRADE
DUPLEX
ILLUMINATED
8300-L
8210-R
HOSP. GRADE
DUPLEX
HOSP. GRADE
DUPLEX
w/Green LED Power
Status Indication
w/6" Wire Leads
HOSP. GRADE
SINGLE
8200
8200-I
8200-W
8200-G
8200-R
8200-H
8200-HI
8200-HW
8200-HGY
8200-HR
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
8200-SG
–
–
8200-SGI
8200-HLI
8200-PLI
8200-SGW
8200-HLW
8200-PLW
8200-SGG
–
–
8200-SGR
8200-HLR
8200-PLR
8200-L
8200-LI
8200-LW
8200-LGY
8200-LR
8210
8210-I
8210-W
–
8210-R
Brown
Ivory
White
Gray
Red
Black
Almond
8300
8300-I
8300-W
8300-G
8300-R
8300-E
–
8300-H
8300-HI
8300-HW
8300-HGY
8300-HR
–
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
8300-SG
–
–
8300-SGI
8300-HLI
8300-PLI
8300-SGW
8300-HLW
8300-PLW
8300-SGG
–
–
8300-SGR
8300-HLR
8300-PLR
–
–
–
–
–
–
8300-L
8300-LI
8300-LW
8300-LGY
8300-LR
8300-LE
8300-LA
8310
8310-I
8310-W
8310-G
8310-R
–
–
0.85
(21.6 mm)
0.97
(24.6 mm)
1.12
(28.4 mm)
3.28 (83.3 mm)
TAMPER
RESISTANT
1.23
(31.3 mm)
8200-SG
1.51
(38.5 mm)
1.31
(33.3 mm)
2.77 (70.4 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
2.77 (70.4 mm)
3.28 (83.3 mm)
8200, 8300, 8200-PL,
8300-PL, 8400, 8600
1.31
(33.3 mm)
Note:
• There are dimensional differences
between the 8200SG and 8300-SG
Series.
• 8200-SG Series
contains a nickelplated steel yoke
with riveted ground
contacts.
• 8300-SG Series
contains a onepiece, nickel-plated
brass yoke.
1.51
(38.5 mm)
8300-SG
1.38
(33.7 mm)
0.82
(20.8 mm)
1.33
(33.7 mm)
1.06
(30 mm)
1.31
(33.3 mm)
1.18
(29.9 mm)
1.31
(33.3 mm)
8200-H, 8300-H
1.31
(33.3 mm)
8200-HL, 8300-HL
4.06 (103.2 mm)
2.38 (60.3 mm)
3.28 (83.3 mm)
0.87
(22.1 mm)
3.28 (83.3 mm)
LEVITON
4.06 (103.2 mm)
8400
8400-I
–
–
–
–
0.87
(22.1 mm)
2.77 (103.2 mm)
Brown
Ivory
White
Gray
Red
Black
1.31
(33.3 mm)
3.28 (83.3 mm)
20A 250V, NEMA 6-20R
0.88
(22.3 mm)
4.06 (103.2 mm)
15A 250V, NEMA 6-15R
Brown
8600
Ivory
8600-I
White
–
Gray
–
Red
–
15A
125V
1.55
(39.5 mm)
1.21
(38.4 mm)
2.76 (70.0 mm)
HOSP. GRD.
DUPLEX
1.53
(38.9 mm)
4.06 (103.2 mm)
2.78 (70.6 mm)
1.11
(28.1 mm)
FACE
COLOR
3
8300-SGI
HOSP. GRADE
DUPLEX TAMPER
RESISTANT
Brown
Ivory
White
Gray
Red
8400-I
B
8200-SGG
HOSP. GRD.
SLIM
DUPLEX
4.06 (103.2 mm)
8300-E
FACE
COLOR
TAMPER
RESISTANT
Hospital Grade Straight Blade Receptacles
Back & Side Wired, Self-Grounding
8210, 8310
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V; 20A 125V
Hospital Grade
10 YEAR LIMITED
NEMA 5-15R
NEMA 5-20R
MECHANICAL
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
TEMP.
RISE
TERMINAL
ACCOMM.
Brass, hot
#14 – #10 AWG
Grounding
4-in-1
White,neutral
#14 – #12 AWG
STANDARDS & CERTIFICATIONS
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#E13399
#E13399
CSA
NOM
C22.2 No. 42
#152105 #057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
Back & Side Wired
NEMA ANSI UL UL Fed Spec
WD-6 C-73 498HG WC-596
.5
1.5
1.0
2.0
4-in-1 Side Wired
Split Circuit Not Available
21254-IGI
8300-IGI
FACE
COLOR
HOSPITAL GRADE
IG DUPLEX
HOSPITAL GRADE
IG 4-IN-1
8480-IGI
HOSPITAL GRADE
IG 4-IN-1 SURGE
Refer to page B7 for Device Drawings
Brown
Ivory
White
Gray
Red
Orange
Blue
8200-IGB
8200-IGI
8200-IGW
8200-IGG
8200-IGR
8200-IG
–
Brown
Ivory
White
Gray
Red
Orange
Blue
8300-IGB
8300-IGI
8300-IGW
8300-IGG
8300-IGR
8300-IG
–
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
–
–
1254-IGI
8480-IGI
1254-IGW
8480-IGW
–
–
–
–
1254-IG
–
–
8480-IGB
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
–
–
21254-IGI
8490-IGI
21254-IGW
–
–
–
–
–
21254-IG
–
–
8490-IGB
NYLON WALLPLATES
HOSPITAL GRADE
IG DUPLEX
HOSPITAL GRADE
IG SINGLE
w/ 6" Lead
w/ 6" Lead
–
–
–
–
–
8200-LIG
–
–
–
–
–
–
8210-IG
–
–
–
–
–
–
8300-LIG
–
–
–
–
–
–
8310-IG
–
302 STAINLESS STEEL WALLPLATES
ISOLATED GROUND
1.55
(39.5 mm)
1.12
(28.4 mm)
8200-IG, 8300-IG
1.38
(33.7 mm)
3.28 (83.3 mm)
2.77 (103.2 mm)
3.28 (83.3 mm)
1.31
(33.3 mm)
4.06 (103.2 mm)
2.77 (70.4 mm)
0.87
(22.1 mm)
0.87
(22.1 mm)
1.31
(33.3 mm)
8200-LIG, 8300-LIG
84016-40
0.82
(20.8 mm)
1.33
(33.7 mm)
1.06
(30 mm)
1.31
(33.3 mm)
8210-IG, 8310-IG
4.06 (103.2 mm)
80716-I
84004-40
84003-40
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
2.38 (60.3 mm)
80704-IG
3.28 (83.3 mm)
80703-IG
4.06 (103.2 mm)
ISOLATED GROUND
1.12
(28.4 mm)
8310-IG
8300-LIG
Hospital Grade Straight Blade Isolated Ground Receptacles
Max 30C
after 250
cycles of
overload at
200% of
rated current
TERMINAL
I.D.
B
4
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V& 250V; 20A 125V & 250V
Industrial Grade
10 YEAR LIMITED
NEMA 5-15R
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
NEMA 5-20R
NEMA 6-15R
MECHANICAL
ELECTRICAL
TERMINAL
I.D.
TEMP.
RISE
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
Brass, hot
Max 30C
after 250
cycles of
overload at
200% of
rated current
#14 – #10 AWG
Grounding
NEMA 6-20R
STANDARDS & CERTIFICATIONS
White,neutral
NEMA ANSI
WD-6 C-73
498
UL
UL Fed Spec CSA NOM
WC-596 C22.2 No. 42
#E13399
#E13399
#152105 #057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Industrial Grade Straight Blade Receptacles
Back & Side Wired, Self-Grounding
5262-E
FACE
COLOR
5362-I
5661-I
General Duty, 5262-GYS
5352-W
IG DUPLEX
RECEPTACLE
SINGLE
RECEPTACLE
DUPLEX RECEPTACLE
NARROW BODY
Single-Piece Brass Strap
Combo-Head Brass
Terminal Screws
Back Wired Ground Screw
8-Hole Feed-Thru
Multi-Piece Steel Strap
Combo-Head Steel
Terminal Screws
Multi-Piece Steel Strap
Combo-Head Steel
Terminal Screws
Multi-Piece Steel Strap
Combo-Head Steel
Terminal Screws
8-Hole Feed-Thru
8-Hole Feed-Thru
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
5262
5262-IGB
5261
5262-I
5262-IGI
5261-I
5262-W
5262-IGW
5261-W
5262-GY
5262-IGG
5261-GY
–
–
–
5262-R
5262-IGR
–
–
5262-IG
–
5262-E
–
–
–
–
–
Brown
Ivory
White
Gray
Almond
Red
Orange
Black
Blue
Brown
Ivory
White
Gray
Almond
Red
Orange
Black
Blue
Brown
Ivory
Orange
Gray
Almond
1.53
(38.9 mm)
(22.3 mm)
Combo-Head Steel
Terminal Screws
Contractor Pack
2-Year Warranty
5262-S
5262-SI
5262-SW
5262-GYS
5262-SA
5262-SR
–
–
5262-SBU
5262-L
5262-LI
5262-LW
5262-LGY
5262-LA
5262-LR
–
5262-LE
–
–
–
–
5662
5662-I
–
–
–
–
5362-S
5362-SI
5362-SW
5362-GYS
5362-SA
5362-SR
–
–
5362-SBU
–
5352-I
5352-W
–
–
–
–
–
–
5362-L
5362-LI
5362-LW
5362-LGY
5362-LA
5362-LR
–
5362-LE
–
–
–
–
–
–
5462
5462-I
–
5462-GY
–
–
–
–
–
–
1.55
(39.5 mm)
1.31
0.88
5262-L
DUPLEX RECEPTACLE DUPLEX RECEPTACLE
General Duty
w/6" Leads
Multi-Piece Steel Strap
General Duty
–
5252-I
5252-W
–
–
–
–
–
–
15A 250V, NEMA 6-15R, 2-P 3-W, Grounding
–
–
5661
–
–
5661-I
–
5662-IG
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
5362
5362-IGB
5361
5362-I
5362-IGI
5361-I
5362-W
5362-IGW
5361-W
5362-GY
5362-IGG
5361-GY
–
5362-IGA
5361-A
5362-R
5362-IGR
–
–
5362-IG
–
5362-E
–
5361-E
–
5362-BIG
–
20A 250V, NEMA 6-20R, 2-P 3-W, Grounding
–
–
5461
–
–
5461-I
–
5462-IG
–
–
–
5461-GY
–
–
5461-A
Brown
Ivory
Orange
1.11
(28.1 mm)
5361-I
5362-IG
DUPLEX RECEPTACLE
Heavy Duty
0.84
(21.4 mm)
(33.2 mm)
1.31
(33.3 mm)
5
0.88
(22.3 mm)
1.31
(33.3 mm)
1.12
(28.4 mm)
5262, 5362
5262-IG, 5662-IG,
5362-IG, 5462-IG
1.31
(33.3 mm)
5261, 5661,
5361, 5461
1.31
(33.2 mm)
5252, 5352,
5462, 5662
3.28 (83.3 mm)
1.09
(27.7 mm)
4.06 (103.2 mm)
2.78 (70.6 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
4.06 (103.2 mm)
2.38 (60.3 mm)
1.06
(27.0 mm)
3.28 (83.3 mm)
3.28 (83.3 mm)
1.33
(33.7 mm)
4.06 (103.2 mm)
2.77 (70.4 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
F UL S
B
15A
125V
20A-125V
2.78 (70.6 mm)
LEVITON
1.33
(33.7 mm)
5262-S, 5362-S
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 250V;20A 125V
Industrial Grade
10 YEAR LIMITED
NEMA 5-15R
NEMA 5-20R
NEMA 6-15R
MECHANICAL
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
TERMINAL
I.D.
TEMP.
RISE
Brass, hot
Max 30C
after 250
cycles of
overload at
200% of
rated current
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #10 AWG
Grounding
White,neutral
NEMA ANSI
WD-6 C-73
498
UL UL Fed Spec CSA NOM
WC-596 C22.2 No. 42
#E13399
#E13399
#152105 #057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Side Wired, Self-Grounding
4792
FACE
COLOR
COMBINATION LOCKING &
STRAIGHT BLADE DUPLEX
RECEPTACLE; COMMON FEED
5292-I
5242-W
5351-I
5251
DUPLEX RECEPTACLE
NARROW BODY
5261-CH
SINGLE
RECEPTACLE
FACE
COLOR
Steel Strap; Stainless
Steel Plate
Back & Side Wired
Back & Side Wired
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
Brown
Ivory
White
Gray
Red
Black
–
5242
5251
–
5242-I
5251-I
–
5242-W
–
–
5242-GY
–
–
5242-R
–
4792
15A 250V, NEMA 6-15R, 2-P 3-W, Grounding
Brown
–
–
5651
Ivory
–
–
5651-I
White
–
–
5651-W
DUAL VOLTAGE 15A 125V, NEMA 5-15R, 15A 250V, NEMA 6-15R, 2-P 3-W, Grounding - Back & Side Wired
Brown
–
5292
–
Ivory
–
5292-I
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
Brown
Ivory
White
Gray
–
–
–
–
5342
5342-I
5342-W
5342-GY
80704-GY
80716-I
15A 125V, NEMA 5-15R,
2-P 3-W, Grounding
Brown
5261-CH
20A 125V, NEMA 5-20R,
2-P 3-W, Grounding
Brown
5361-CH
5351
5351-I
–
–
NYLON WALLPLATES
80703-I
SINGLE
RECEPTACLE
CLOCK HANGER
302 STAINLESS STEEL WALLPLATES
80730
84003-40
84004-40
84016-40
Industrial Grade Straight Blade Receptacles
For Combination Duplex
Receptacle feed options,
see page E39.
84030-40
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
2.38 (60.3 mm)
4.5 (114.8 mm)
1.31
(33.3 mm)
4.06 (103.2 mm)
1.06
(30 mm)
0.25 (6.4 mm)
2.38 (60.3 mm)
1.33
(33.7 mm)
3.28 (83.3 mm)
3.28 (83.3 mm)
0.82
(20.8 mm)
4.06 (103.2 mm)
1.09
(27.7 mm)
2.78 (70.6 mm)
3.28 (83.3 mm)
1.44 (36.4 mm)
4.06 (103.2 mm)
2.77 (70.4 mm)
.097
(24.7 mm)
1.63
(41.5 mm)
1.56
(39.6 mm)
0.21 (5.4 mm)
4792
0.84
(21.4 mm)
5242, 5342, 5292
5251, 5351, 5651
2.75 (69.9 mm)
5261-CH, 5361-CH
B
6
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V; 20A 125V
Hospital & Industrial Grade
10 YEAR LIMITED
NEMA 5-15R
MECHANICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
TERMINAL
I.D.
TEMP.
RISE
Grounding
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #12 AWG
White,neutral
NEMA ANSI
WD-6 C-73
UL
498HG
UL
498
CSA
NOM
C22.2 No. 42
#E13399 #E13399 #152105
#057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Side Wired
™
For clamping and
performance data refer
to page B8.
21254-HI
FACE
COLOR
INDUSTRIAL
GRADE
HOSPITAL
GRADE
HOSPITAL GRADE
IG
Brown
Ivory
White
Gray
Red
Black
Orange
Blue
1254
1254-I
1254-W
–
1254-R
1254-E
–
–
1254-H
1254-HI
1254-HW
–
1254-HR
–
–
–
Brown
Ivory
White
Gray
Red
Black
Orange
Blue
Yellow
21254
21254-I
21254-W
21254-GY
21254-R
21254-E
–
–
21254-Y
21254-H
21254-HI
21254-HW
21254-HGY
21254-HR
–
Split Circuit Not Available
Split Circuit Not Available
5490-BU
8480-IGI
INDUSTRIAL GRADE INDUSTRIAL GRADE
SURGE
IG, SURGE
Indicator Light
Indicator Light
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
–
–
–
1254-IGI
5480-I
–
1254-IGW
5480-W
–
–
5480-GY
–
–
–
–
–
–
–
1254-IG
–
5480-IG
–
5480-BU
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
–
–
–
21254-IGI
5490-I
–
21254-IGW
5490-W
–
–
5490-GY
–
–
–
–
–
–
–
21254-IG
–
–
–
5490-BU
–
–
–
ADAPTER
PLATE
–
8480-I
8480-W
–
8480-R
–
–
–
–
8490-IGI
–
–
–
–
8490-I
8490-W
–
8490-R
–
–
–
8490-IG
8490-IGB
–
–
–
–
BOX
COLOR
3254
3254-I
3254-W
3254-GY
3254-R
3254-E
3254-OR
3254-BLU
PORTABLE
BOX
Ivory
Gray
Black
Orange
Blue
Yellow
4254-I
4254-GY
4254-E
4254-OR
4254-BLU
4254-Y
Portable boxes are not UL Listed.
4.80 (121.9 mm) square
0.31
(7.9 mm)
4 knockouts
0.66
ø (16.8)
Feed Thru Wire Hole
0.25 (6.4 mm)
0.42 (10.7 mm)
0.12 (3.2 mm)
2.75 (69.8 mm)
.90
(22.9 mm)
2.73 (69.3 mm)
4.50 (114.3 mm) square
0.68 (17.1 mm)
3.38 (85.9 mm)
4.50 (114.3 mm) square
3.28 (83.3 mm) square
B
–
8480-IGI
8480-IGW
–
–
–
8480-IG
8480-IGB
Accepts #16/3 AWG Type SJ to #12/3 AWG
Type SO COPPER Only.
3.38 (85.9 mm) square
Single-Gang
HOSPITAL GRADE
SURGE
Indicator Light
3.28 (83.4 mm)
Brown
Ivory
White
Gray
Red
Black
Orange
Blue
3.38 (85.9 mm)
8490-R
HOSPITAL GRADE
IG, SURGE
Indicator Light
5490-IG
–
–
4.25 (107.9 mm)
PLATE
COLOR
Mounts
Directly
Split Circuit Not Available
Four-In-One Portable Boxes
Four-In-One Adapter Plates
4” Octagon
Mounts
with
Adapter
Plate
2-Gang
1.75
(44.4 mm)
3.38 (85.9 mm
1.15 (29.2mm)
4” Square
7
NEMA 5-20R
STANDARDS & CERTIFICATIONS
Brass, hot
Max 30C
at full rated
current after 50
cycles overload
at 150% rated
current for both
AC and DC per
UL 498
3.38 (85.9 mm)
Hospital & Industrial Grade Four-In-One Straight Blade Receptacles
ELECTRICAL
DIMENSIONS APPLY TO ALL
FOUR-IN-ONE RECEPTACLES
1.73
(43.9 mm)
4254
411/16”Square
3254
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V; 20A 125V
Hospital & Industrial Grade
10 YEAR LIMITED
NEMA 5-15R
NEMA 5-20R
MECHANICAL
ELECTRICAL
TERMINAL
I.D.
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
TEMP.
RISE
Withstands
2000V
per
UL 498
Full
rated
current
Max 30C
after 250
cycles of
overload at
200% of
rated current
Brass, hot
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #10 AWG
Grounding
White,neutral
NEMA ANSI UL UL Fed Spec CSA NOM
WD-6 C-73 498HG WC-596 C22.2 No. 42
#E13399
–
#152105 #057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
OPERATING TEMP.
-40C to 60C
.5
1.5
1.0
2.0
Back & Side Wired
UL 498HG does not
apply to Industrial Grade
receptacles.
8380-IGO
8380-I
FACE
COLOR
HOSPITAL GRADE
SURGE, DUPLEX
Indicator Light,
Audible Alarm
8381-IGI
7280-I
Back View
5280
5380-IGB
HOSPITAL GRADE HOSPITAL GRADE HOSPITAL GRADE INDUSTRIAL GRADE INDUSTRIAL GRADE INDUSTRIAL GRADE
SURGE, SINGLE IG, SURGE, DUPLEX IG, SURGE, SINGLE
SURGE, DUPLEX
SURGE, DUPLEX
IG, SURGE, DUPLEX
Indicator Light,
Audible Alarm
Indicator Light,
Audible Alarm
Indicator Light,
Audible Alarm
Indicator Light,
Audible Alarm
Indicator Light
Indicator Light
Brown
Ivory
White
Gray
Red
Blue
Orange
Almond
Lt. Almond
8280
8280-I
8280-W
–
8280-R
8280-B
–
8280-A
8280-T
–
–
–
–
–
–
–
–
–
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
–
–
7280
8280-IGI
8281-IGI
7280-I
8280-IGW
–
7280-W
8280-IGG
–
7280-GY
–
–
–
8280-IGB
–
7280-B
8280-IGO
8281-IGO
–
–
–
7280-A
–
–
–
5280
5280-I
5280-W
5280-GY
–
5280-B
–
5280-A
5280-T
–
5280-IGI
5280-IGW
5280-IGG
–
5280-IGB
5280-IGO
5280-IGA
–
Brown
Ivory
White
Gray
Red
Blue
Orange
8380
8380-I
8380-W
8380-GY
8380-R
8380-B
–
8381
8381-I
8381-W
8381-GY
8381-R
–
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
–
–
7380
8380-IGI
8381-IGI
7380-I
8380-IGW
8381-IGW
7380-W
8380-IGG
–
7380-GY
–
–
–
–
8381-IGB
7380-B
8380-IGO
–
–
5380
5380-I
5380-W
5380-GY
–
5380-B
–
–
5380-IGI
5380-IGW
5380-IGG
–
5380-IGB
5380-IGO
CLAMPING PERFORMANCE
PERFORMANCE DATA
OPERATING
FREQUENCY
MAXIMUM
CONTINUOUS
OPERATING
VOLTAGE (MCOV)
MAXIMUM
SINGLE-PULSE
(10x1000µs)
Joules
MAXIMUM
SINGLE-PULSE
(8x20µs)
L-N/L-G/N-G
EMI-RFI NOISE
REJECTION
@ 50 Ohms
500K - 30MHz
UL 1449 SUPPRESSED
VOLTAGE RATINGS (SVR)
Assigned at 6" lead length with 6kV/500A
impulse in accordance w/ UL 1449 (2nd Ed.)
50, 60Hz
150V rms
720
24kA/12kA/12kA
-30dB
400/400/400Vpk
Hospital & Industrial Grade AC Decora Surge Receptacles
FLAMMABILITY
Rated V-2 per UL 94
3.81 (96.8 mm)
3.28 (83.3 mm)
2.70 (68.6 mm)
1.70
(43.2 mm)
B
1.47
(37.3 mm)
APPLIES TO ALL RECEPTACLES ON THIS PAGE
8
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
20A 120/208V 3ØY; 30A 125V
10 YEAR LIMITED
Industrial Grade
MECHANICAL
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
TERMINAL
I.D.
TEMP.
RISE
White,neutral
498
UL
UL Fed Spec
WC-596
#E13399
–
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
NOM
#152105 #057
AC HORSEPOWER RATINGS
20A 120/208V 3Ø
ENVIRONMENTAL
FLAMMABILITY
CSA
C22.2 No. 42
30A 125V
2.0
2.0
7250-FR
FACE
COLOR
5371-IG
5371
FLUSH MOUNT
RECEPTACLE
NEMA
18-20R
MATCHING
ANGLE PLUG
20A 120/208V 3øY, 4-P 4-W, Non-Grounding
9530-P
7313
FACE
COLOR
NEMA
18-20P
FLUSH MOUNT
RECEPTACLE
TT
TT-30R
MATCHING
ANGLE PLUG
TT
TT-30P
30A 125V, 2-P 3-W, Grounding (For Recreational Vehicles)
G
Black
7250-FR
FACE
COLOR
Black
7251-C
FLUSH MOUNT
RECEPTACLE
NEMA
5-30R
7313
FLUSH MOUNT
ISOLATED GRD. RECEPTACLE
G
830-T
W
NEMA
5-30R
MATCHING
ANGLE PLUG
W
NEMA
5-30P
30A 125V, 2-P 3-W, Grounding
Black
Orange
5371
–
STAINLESS
STEEL
–
5371-IG
NYLON
WALLPLATES
430
STAINLESS STEEL
WALLPLATES
Use with 7250
1.41" Dia.
9530-P
–
2.15" Dia. Openings
ALUMINUM
WALLPLATES
GRAY LEXAN
FLIP LID
COVER
2.15" Dia. Openings
IP64 Rated
Includes Gasket
and Screws
84004
80728-E
80728-I
80726-I
84028
84026
83028
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
WP2
2.76 (70.2 mm)
2.25 (57.1 mm)
0.91
(23.0 mm)
2.52 (64.0 mm) FACE
4.37 (111.1 mm)
3.70 (94.1 mm)
2.50 (63.5 mm)
2.37 (60.3 mm)
2.11 (53.6 mm) dia.
75fl C RATING
STRIP GAGE
AL CU
1.70 (45.5 mm)
3.28 (83.3 mm)
WIRE RANGE
A.W.G. # 10 - # 4
1.75
(44.4 mm)
2.52 (64.0 mm) FACE
WITH AL-CU.
REPLACE ONLY
75fl C RECEPTACLE
9
Up to #4 AWG
Grounding
NEMA ANSI
WD6 C-73
For specifications on Matching Angle Plugs, see Section C.
1.32
(33.5 mm)
B
PRODUCT
I.D.
Ratings are
permanently
marked
on device
TIGHTEN TERM. SCREW
TO 25 IN. -LBS.
Industrial Grade Straight Blade Power Receptacles and Plugs
Brass, hot
30C max at full
rated current
after 50 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
1.81
(46.0 mm)
DIMENSIONS APPLY TO 7313, 5371 & 5371-IG
1.89 (47.9 mm)
DIMENSIONS APPLY TO 9530-P
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
30A 250V & 277V; 30A 125/250V
Industrial Grade
10 YEAR LIMITED
MECHANICAL
ELECTRICAL
TERMINAL
I.D.
CURRENT
INTERR.
TEMP.
RISE
Withstands
2000V
per
UL 498
Full
rated
current
30C max at full
rated current
after 50 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
TERMINAL
ACCOMM.
Brass, hot
Up to #4 AWG
Grounding
STANDARDS & CERTIFICATIONS
PRODUCT
I.D.
Ratings are
permanently
marked
on device
White,neutral
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
498
UL
UL Fed Spec
WC-596
#E13399
–
CSA
NOM
C22.2 No. 42
#152105 #057
AC HORSEPOWER RATINGS
ENVIRONMENTAL
FLAMMABILITY
NEMA ANSI
WD6 C-73
30A 250V
30A 277V
30A
125/250V
2.0
3.0
2.0
For specifications on Matching Angle Plugs, see Section C.
5372
FLUSH MOUNT
RECEPTACLE
Black
Orange
5372
–
FACE
COLOR
9730-A
5376
FACE
COLOR
NEMA
6-30R
FLUSH MOUNT
ISOLATED GRD.
NEMA
6-30R
5054
5207
SURFACE MNT.
RECEPTACLE
NEMA
6-30R
MATCHING
ANGLE PLUG
30A 250V, 2-P 3-W, Grounding
–
5376
5372-IG
–
FLUSH MOUNT
RECEPTACLE
NEMA
7-30R
NEMA
6-30P
9630-P
–
MATCHING
ANGLE PLUG
NEMA
7-30P
30A 277V, 2-P 3-W, Grounding
Black
9730-A
FACE
COLOR
9730-P
FLUSH MOUNT
RECEPTACLE
NEMA
10-30R
SURFACE MNT.
RECEPTACLE
NEMA
10-30R
MATCHING
ANGLE PLUG
NEMA
10-30P
30A 125/250V, 3-P 3-W, Non-Grounding
Black
5207
5054
NYLON
WALLPLATES
9332-P
430
STAINLESS STEEL
WALLPLATES
2.15" Dia. Openings
ALUMINUM
WALLPLATES
GRAY LEXAN
FLIP LID
COVER
2.15" Dia. Openings
IP64 Rated
Includes Gasket
and Screws
80728-E
80728-I
80726-I
84028
84026
83028
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
2.25 (57.1 mm)
0.91
(23.0 mm)
2.22 (56.3 mm)
WP2
2.68 (68.1 mm)
2.04 (51.9 mm)
WITH AL-CU.
REPLACE ONLY
75fl C RECEPTACLE
3.70 (94.1 mm)
4.82 (122.5 mm)
25
2.50 (63.5 mm)
50
A
3.28 (83.3 mm)
10 30
V
A
_2
1.50 (38.0 mm)
0
3
Ø 2.11 (53.6 mm)
WIRE RANGE
A.W.G. # 10 - # 4
EM
2.37 (60.3 mm)
TIGHTEN TERM. SCREW
TO 25 IN. -LBS.
N
3
3
Industrial Grade Straight Blade Power Receptacles and Plugs
DIELECTRIC
VOLTAGE
75fl C RATING
STRIP GAGE
AL CU
1.77 (45.0 mm)
1.81
(46.0 mm)
DIMENSIONS APPLY TO ALL
FLUSH RECEPTACLES ON THIS PAGE
DIMENSIONS APPLY TO ALL
SURFACE MNT. RECEPTACLES ON THIS PAGE
B
10
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
30A 125/250V; 30A 250V 3Ø
30A 120/208V 3Ø
MECHANICAL
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
TERMINAL
I.D.
TEMP.
RISE
30C max at full
rated current
after 50 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
Brass, hot
PRODUCT
I.D.
Ratings are
permanently
marked
on device
Up to #4 AWG
Grounding
White,neutral
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec
WC-596
#E13399
–
CSA
NOM
C22.2 No. 42
#152105
#057
AC HORSEPOWER RATINGS
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
30A
125/250V
Rated V-2 per UL 94
-40C to 60C
2.0
30A
250V 3ø
30A
120/208V 3ø
3.0
3.0
For specifications on Matching Angle Plugs, see Section C.
55054
8430
278-PM
FACE
COLOR
FLUSH MOUNT
RECEPTACLE
Black
Orange
278†
–
NEMA
14-30R
FLUSH MOUNT NEMA
ISOLATED GRD. 14-30R
278-IG
8330
PANEL MOUNT
RECEPTACLE
NEMA
14-30R
SURFACE MNT.
RECEPTACLE
NEMA
14-30R
MATCHING
ANGLE PLUG
NEMA
14-30P
30A 125/250V, 3-P 4-W, Grounding
–
278-IG†
278-PM
–
55054
–
9432-P
–
†Fits 2.15" Dia. Openings — See page B16
FACE
COLOR
FLUSH MOUNT
RECEPTACLE
NEMA
15-30R
MATCHING
ANGLE PLUG
FACE
COLOR
NEMA
15-30P
8430
Black
8432-P
NYLON
WALLPLATES
NEMA
18-30R
MATCHING
ANGLE PLUG
NEMA
18-30P
30A 120/208V 3ØY, 4-P 4-W, Non-Grounding
30A 250V 3ØY, 3-P 4-W, Grounding
Black
FLUSH MOUNT
RECEPTACLE
302 STAINLESS STEEL
WALLPLATES
8330
8332-P
430 STAINLESS STEEL
WALLPLATES
STEEL
ALUMINUM FINISH
2.465" Dia. Openings
80532-I
2.68 (68.1 mm)
80532-E
S701-40
S701
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
1.81 (46 mm)
1.81
0.04 (1.1 mm)
S701-GY
0.04 (1.1 mm)
(46.0 mm)
G
RD
G
2.23 (56.7 mm)
2.38 (60.3 mm)
3.28 (83.3 mm)
2.08 (52.8 mm)
3.75 (95.3 mm)
2.10 (53.3 mm)
Ø 2.44 (61.9 mm)
v
A- 1
2 5 2 50
.
30
.
2.38 (60.3 mm)
0.34
(8.6 mm)
0.18
(4.6 mm)
M A 14 - 3
0
.
3.28 (83.3 mm)
NE
1.41 (35.7 mm)
4.82 (122.5 mm)
3.75 (95.3 mm)
1.41 (35.7 mm)
2.08 (52.8 mm)
2.04 (51.9 mm)
80532-W
2.410 (53.3 mm)
Industrial Grade Straight Blade Power Receptacles and Plugs
10 YEAR LIMITED
0.42 (10.7 mm)
B
2.50 (63.5 mm)
278, 278-IG
2.22 (56.5 mm)
0.42
(10.7 mm)
2.10
2.75 (69.8 mm)
(56.5 mm)
55054
11
0.42
(10.7 mm)
2.22
(53.3 mm)
8330
278-PM
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
50A 125V & 250V; 50A 277V
Industrial Grade
10 YEAR LIMITED
ELECTRICAL
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
MECHANICAL
TEMP.
RISE
TERMINAL
I.D.
Brass, hot
30C max at full
rated current
after 50 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
Up to #4 AWG
Grounding
White,neutral
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
498
UL
UL Fed Spec
WC-596
#E13399
–
CSA
NOM
C22.2 No. 42
#152105 #057
AC HORSEPOWER RATINGS
ENVIRONMENTAL
FLAMMABILITY
NEMA ANSI
WD-6 C-73
50A 125V
50A 250V
50A 277V
2.0
3.0
5.0
For specifications on Matching Angle Plugs, see Section C.
5373
9750
5374
FACE
COLOR
FLUSH MOUNT
RECEPTACLE
5374-IG
5374
NEMA
5-50R
5378
MATCHING
ANGLE PLUG
NEMA
5-50P
50A 125V, 2-P 3-W, Grounding
G
Black
5373
FACE
COLOR
FLUSH MOUNT
RECEPTACLE
Black
Orange
5374
–
FACE
COLOR
G
9550-P
W
NEMA
6-50R
FLUSH MOUNT
ISOLATED GRD.
NEMA
6-50R
SURFACE MNT.
RECEPTACLE
W
NEMA
6-50R
MATCHING
ANGLE PLUG
50A 250V, 2-P 3-W, Grounding
–
5378
5374-IG
–
FLUSH MOUNT
RECEPTACLE
NEMA
7-50R
NEMA
6-50P
9650-P
–
MATCHING
ANGLE PLUG
NEMA
7-50P
50A 277V, 2-P 3-W, Grounding
Black
9750-A
9750-P
NYLON
WALLPLATES
430
STAINLESS STEEL
WALLPLATES
ALUMINUM
WALLPLATES
GRAY LEXAN
FLIP LID
COVER
2.15" Dia. Openings
IP64 Rated
Includes Gasket
and Screws
80726-I
84028
84026
83028
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
1.77 (45.0 mm)
2.68 (68.1 mm)
3.70 (94.1 mm)
2.04 (51.9 mm)
3.28 (83.3 mm)
2.50 (63.5 mm)
1.81 (46.0 mm)
Ø 2.11 (53.6 mm)
(38.0 mm)
1.50
2.22 (56.3 mm)
WP2
4.82 (122.5 mm)
80728-I
2.37 (60.3 mm)
80528-BLK
B
2.25 (57.1 mm)
5373,5374, 5373-IG, 9750
Industrial Grade Straight Blade Power Receptacles and Plugs
DIELECTRIC
VOLTAGE
5378
12
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
50A 125/250V; 50A 250V
50A 250V 3Ø
MECHANICAL
ELECTRICAL
TERMINAL
I.D.
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
TEMP.
RISE
Withstands
2000V
per
UL 498
Full
rated
current
30C max at full
rated current
after 50 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
Up to #4 AWG
Grounding
White,neutral
498
#E13399
UL
UL Fed Spec CSA NOM
WC-596 C22.2 No. 42
–
#152105
#057
AC HORSEPOWER RATINGS
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
50A
125/250V
Rated V-2 per UL 94
-40C to 60C
3.0
50A
125/250V
50A
250V 3ø
3.0
7.5
For specifications on Matching Angle Plugs, see Section C.
5206
279
5050
FACE
COLOR
FLUSH MOUNT
RECEPTACLE
NEMA
10-50R
8450
279-PM
SURFACE MNT.
RECEPTACLE
NEMA
10-50R
55050
MATCHING
ANGLE PLUG
NEMA
10-50P
50A 125/250V, 3-P 3-W, Non-Grounding
Black
5206
FACE
COLOR
5050
FLUSH MOUNT
RECEPTACLE
NEMA
14-50R
PANEL MOUNT
RECEPTACLE
9450-P
NEMA
14-50R
SURFACE MNT.
RECEPTACLE
NEMA
14-50R
MATCHING
ANGLE PLUG
NEMA
14-50P
50A 125/250V, 3-P 4-W, Grounding
Black
Orange
279
–
FACE
COLOR
279-PM
–
FLUSH MOUNT
RECEPTACLE
55050
–
NEMA
15-50R
9452-P
–
MATCHING
ANGLE PLUG
NEMA
15-50P
50A 250V 3ø, 3-P 4-W, Grounding
Black
Orange
8450
8450-IG
8452-P
–
(Isolated Ground)
420
STAINLESS STEEL WALLPLATES
Use with 5206 and 279
WEATHER RESISTANT COVERS
GLASS FILLED THERMOPLASTIC
Use with 5206
302
STAINLESS STEEL
Use with 8450-A
2.15" Dia. Openings
2.465" Dia. Openings
IP64 Rated
Includes Gasket
and Screws
WP2
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
S701-40
2.68 (68.1 mm)
2.10 (53.3 mm)
2.75 (69.8 mm)
50
v
A- 1
2 5 2 50
1.80
(45.7 mm)
0.42
(10.7 mm)
2.22
2.50 (63.5 mm)
A
STRIP
GAGE
5-5
GR
DG
G
G
RD
2.08 (52.8 mm)
G
RD
2.10 (53.3 mm)
2.38 (60.3 mm)
G
.
3.28 (83.3 mm)
.
3.75 (95.3 mm)
NE
75fl C RATING
v
A- 1
2 5 2 50
1.64 (41.6 mm)
AL. CU.
M A 14 - 5
0
.
50
NE
.
.
4.82 (122.5 mm)
M A 14 - 5
0
0.42 (10.7 mm)
1.81 (46.0 mm)
REPLACE ONLY WITH AL-CU
75fl C RECEPTACLE
.
NE
2.22
(56.5 mm)
50
3.28 (83.3 mm)
0.42
(10.7 mm)
3.75 (95.3 mm)
2.44 (61.9 mm)
0.04 (1.1 mm)
2.38 (60.3 mm)
1.81 (46 mm)
2.08 (52.8 mm)
2.04 (51.9 mm)
84026
2.23 (56.7 mm)
84028
1.41
(35.7 mm)
13
NEMA ANSI
WD6 C-73
1.41 (35.7 mm)
2.10 (53.3 mm)
Industrial Grade Straight Blade Power Receptacles and Plugs
Brass, hot
B
10 YEAR LIMITED
3
A.- 2
5 0 V.
WIRE SIZE RANGE AWG #10-#4
TIGHTEN TERMINAL SCREWS
TO 25 IN. LB.
(56.5 mm)
5050,55050
279
279-PM
8450, 8450-IG
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
50A 120/208V 3ØY; 60A 125/250V
60A 250V 3Ø; 60A 120/208V
10 YEAR LIMITED
ELECTRICAL
MECHANICAL
CURRENT
INTERR.
TEMP.
RISE
TERMINAL
I.D.
Withstands
2000V
per
UL 498
Full
rated
current
30C max at full
rated current
after 50 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
Brass, hot
PRODUCT
I.D.
Ratings are
permanently
marked
on device
Up to #4 AWG
Grounding
White,neutral
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec
WC-596
#E13399
–
CSA
NOM
C22.2 No. 42
#152105
#057
AC HORSEPOWER RATINGS
50A
60A
120/208V 1125/250V
3øY
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
7.5
60A
250V 3ø
60A
120/280V
3øY
10
7.5
3.2
For specifications on Matching Angle Plugs, see Section C.
8350
FACE
COLOR
9460
8360
FLUSH MOUNT
RECEPTACLE
NEMA
18-50R
MATCHING
ANGLE PLUG
NEMA
18-50P
FACE
COLOR
FLUSH MOUNT
RECEPTACLE
Black
Orange
9460
9460-IG
FACE
COLOR
FLUSH MOUNT
RECEPTACLE
50A 120/208V 3øY, 4-P 4-W, Non-Grounding
Black
8350
FACE
COLOR
NEMA
15-60R
MATCHING
ANGLE PLUG
NEMA
15-60P
8460
8460-IG
NEMA
14-60P
9462-P
–
NEMA
18-60R
MATCHING
ANGLE PLUG
NEMA
18-60P
60A 120/208V 3ØY, 4-P 4-W, Non-Grounding
60A 250V 3Ø, 3-P 4-W, Grounding
Black
Orange
MATCHING
ANGLE PLUG
60A 125/250V, 3-P 4-W, Grounding
8352-P
FLUSH MOUNT
RECEPTACLE
9462-P
NEMA
14-60R
8462-P
–
Black
8360
8362-P
(Isolated Ground)
PLASTIC
WALLPLATES
NYLON
WALLPLATES
80530-BLK
302
STAINLESS STEEL
WALLPLATES
2.465" Dia. Holes
430
STAINLESS STEEL
WALLPLATES
STEEL
ALUMINUM FINISH
80530-I
S701-40
S701
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
S701-GY
2.76 (70.2 mm)
1.81 (46 mm)
0.04 (1.1 mm)
2.75 (69.8 mm)
2.52 (64.0 mm) FACE
4.37 (111.1 mm)
2.23
(56.7 mm)
Ø 2.44 (61.9 mm)
2.38 (60.3 mm)
3.28 (83.3 mm)
3.75 (95.3 mm)
2.52 (64.0 mm) FACE
Industrial Grade Straight Blade Power Receptacles and Plugs
DIELECTRIC
VOLTAGE
0.42 (10.7 mm)
B
2.10
(53.3 mm)
8350, 8360, 8460, 8460-IG, 9460
1.89 (47.9 mm)
8462-P
14
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 250V
Hospital & Commercial Grade
10 YEAR LIMITED
NEMA 5-15R
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
MECHANICAL
TEMP.
RISE
TERMINAL
I.D.
Hospital & Commercial Grade AC Decora Plus™ Receptacles
Brass, hot
Max 30C
after 250
cycles of
overload at
200% of
rated current
TERMINAL
ACCOMM.
PRODUCT
I.D.
NEMA ANSI
WD6 C-73
498
UL Fed Spec
WC-596
Ratings are
permanently
marked
on device
#E13399
–
#14 – #10 AWG
Grounding
NEMA 6-15R
STANDARDS & CERTIFICATIONS
White,neutral
UL
CSA
NOM
C22.2 No. 42
#152105
#057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Back & Side Wired, Self-Grounding
Note:
This device
meets UL Fed
Spec WC-596
Requirements
16262-HGR
FACE
COLOR
16262-SGW
HOSP. GRADE
DUPLEX
16262-IG
HOSP. GRADE
DUPLEX
TAMPER-RESISTANT
16262-PLI
7599-HGI
HOSP. GRADE
IG DUPLEX
HOSP. GRADE
DUPLEX
Self-Grounding
Does Not Apply
w/Green LED
Power Indicator
DR15S-GI
HOSP. GRADE
SMARTLOCKPRO ®
w/LED – GFCI DUPLEX
w/ LOCKOUT
16262-E
COMM. GRADE COMM. GRADE
DUPLEX
DUPLEX
TAMPERRESISTANT
Brown
Ivory
White
Gray
Red
Black
Orange
Almond
Lt. Almond
–
16262-HGI
16262-HGW
16262-HGG
16262-HGR
–
–
–
–
16262-SG
16262-SGI
16262-SGW
–
16262-SGR
–
–
–
–
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
16262-IGB
–
16262-IGI
16262-PLI
16262-IGW
16262-PLW
–
–
16262-IGR
16262-PLR
–
–
16262-IG
–
–
–
–
–
7599-HG
7599-HGI
7599-HGW
7599-HGG
7599-HGR
–
–
7599-HGA
7599-HGT
–
DR15S-GI
DR15S-GW
–
–
–
–
DR15S-GA
–
16262
16262-I
16262-W
16262-GY
–
16262-E
–
–
–
Ivory
White
16662-HGI
16662-HGW
–
–
15A 250V, NEMA 6-15R, 2-P 3-W, Grounding
–
–
–
–
–
–
–
–
16662-I
16662-W
SEE SECTION F FOR ADDITIONAL GFCI’s
• Meets or Exceeds UL, 2006 Requirements
• SmartLockPRO ® GFCI Prevents Reset in
Case of Line-Load Reverse Wiring
• Greater Protection Against Loss of Ground
Fault Protection Due to Surges, Abuse and
Overvoltages
• Device Prevents Reset If Its Protective
Function Has Been Compromised
1.31
(33.3 mm)
0.88 (22.4 mm)
0.94
1.31
(33.3 mm)
0.88 (22.4 mm)
(23.88
mm)
1.7 (43.2
mm)
1.53 (38.9 mm)
1.12 (28 mm)
3.81 (96.8 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
2.78 (70.6 mm)
4.21 (106.93 mm)
3.28 (83.81
mm)
CLASS
TEST MONTHLY
TEST MENSUEL
(96.77
2.73.81
(68.6
mm)mm)
GFCI
3.81 (96.8 mm)
3.28 (83.3 mm)
2.62 (66.55 mm)
0.29 (7.37 mm)
LEVITON
CLASS A
2.78 (70.6 mm)
TEST
RESET
4.06 (103.2 mm)
15A 125V
RECEPTACLE
3.70 (93.98 mm)
4.21 (106.93 mm)
15 AMP
APPLIES TO 16262 SERIES RECEPTACLES
FOLLOW DIRECTIONS
SUIVEZ INSTRUCTION
1.52
(38.7 mm)
125V
15
1.14
(29.0 mm)
2.74 (69.60 mm)
B
TEST
RESET
1.19
(30.23 mm)
1.31
(33.27 mm)
7599-HG SERIES
1.14
(29.0 mm)
1.52
(38.7 mm)
DR15S SERIES
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
20A 125V & 250V
Hospital & Commercial Grade
10 YEAR LIMITED
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
MECHANICAL
TEMP.
RISE
TERMINAL
I.D.
TERMINAL
ACCOMM.
Brass, hot
#14 – #10 AWG
Grounding
White,neutral
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec
WC-596
#E13399
–
CSA
NOM
C22.2 No. 42
#152105 #057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Back & Side Wired, Self-Grounding
FACE
COLOR
16362-A
16362-IG
16362-PLR
HOSP. GRADE
IG DUPLEX
HOSP. GRADE
DUPLEX
HOSP. GRD. SMARTLOCK® PRO
w/ LED - GFCI DUPLEX w/ LOCKOUT
Self-Grounding Does Not Apply
w/Green LED
Power Indicator
Meets 2003 UL Requirements
16362-HGI
HOSP. GRADE
DUPLEX
7899-HGA
COMM. GRADE
DUPLEX
20A 125V, NEMA 5-20R, 2-P 3-W, GROUNDING
Brown
Ivory
White
Gray
Red
Orange
Almond
Lt. Almond
–
16362-HGI
16362-HGW
16362-HGG
16362-HGR
–
–
–
Ivory
White
Black
16462-HGI
16462-HGW
–
16362-IGB
–
7899-HG
16362-IGI
16362-PLI
7899-HGI
16362-IGW
16362-PLW
7899-HGW
16362-IGG
–
7899-HGG
16362-IGR
16362-PLR
7899-HGR
16362-IG
–
–
–
–
7899-HGA
–
–
7899-HGT
20A 250V, NEMA 6-20R, 2-P 3-W, GROUNDING
–
–
–
–
–
–
–
–
–
16362
16362-I
16362-W
16362-GY
16362-R
–
16362-A
–
16462-I
16462-W
16462-E
SEE SECTION F FOR ADDITIONAL GFCI’s
• Meets or Exceeds UL, 2006 Requirements
• SmartLockPRO ® GFCI Prevents Reset in
Case of Line-Load Reverse Wiring
• Greater Protection Against Loss of Ground
Fault Protection Due to Surges, Abuse and
Overvoltages
• Device Prevents Reset If Its Protective
Function Has Been Compromised
0.94
(23.88 mm)
1.31
(33.3 mm)
0.88 (22.4 mm)
1.53 (38.9 mm)
1.7 (43.2 mm)
Hospital & Commercial Grade AC Decora Plus™ Receptacles
Max 30C
after 250
cycles of
overload at
200% of
rated current
STANDARDS & CERTIFICATIONS
PRODUCT
I.D.
Ratings are
permanently
marked
on device
1.12 (28 mm)
4.21 (106.93 mm)
CLASS
3.28 (83.81
mm)
TEST MONTHLY
TEST MENSUEL
2.7 (68.6
mm) mm)
3.81 (96.77
GFCI
3.81 (96.8 mm)
3.28 (83.3 mm)
2.62 (66.55 mm)
0.29 (7.37 mm)
20 AMP
B
LEVITON
CLASS A
2.78 (70.6 mm)
TEST
RESET
4.06 (103.2 mm)
15A 125V
RECEPTACLE
4.21 (106.93 mm)
3.70 (93.98 mm)
FOLLOW DIRECTIONS
SUIVEZ INSTRUCTION
APPLIES TO 16362 SERIES RECEPTACLES
125V
1.52
(38.7 mm)
2.74 (69.60 mm)
1.14
(29.0 mm)
TEST
RESET
1.19
(30.23 mm)
1.31
(33.27 mm)
7899-HG SERIES
16
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 250V;20A 125V & 250V
Commercial Grade
NEMA 5-15R
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
NEMA 5-20R
NEMA 6-15R
MECHANICAL
ELECTRICAL
TERMINAL
I.D.
TEMP.
RISE
Brass, hot
30C max at full
rated current
after 100 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
Grounding
NEMA 6-20R
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #10 AWG
White,neutral
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec CSA NOM
WC-596 C22.2 No. 42
#E13399
–
#152105 #057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
BR15-I
5088-A
DUPLEX
RECEPTACLE
SINGLE
RECEPTACLE
5098
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
Brown
Ivory
White
Gray
Almond
Black
BR15
BR15-I
BR15-W
BR15-GY
BR15-A
BR15-E
BR20
BR20-I
BR20-W
BR20-GY
BR20-A
BR20-E
5098
5098-I
–
–
–
–
80704-GY
5891
–
5891-W
–
–
–
5824
5824-I
–
–
–
–
5823
5823-I
–
–
–
–
302 STAINLESS STEEL WALLPLATES
80716-I
80730
84003-40
84004-40
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
1.06
(26.9 mm)
1.56 (39.5 mm)
5089
5089-I
–
–
–
–
20A 250V, NEMA 6-20R, 2-P 3-W, Grounding
NYLON WALLPLATES
80703-I
SINGLE
RECEPTACLE
15A 250V, NEMA 6-15R, 2-P 3-W, Grounding
5088
5088-I
–
–
5088-A
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
Brown
Ivory
White
Gray
Almond
Black
5089-I
DUPLEX
RECEPTACLE
1.38
(35.0 mm)
0.84
(21.4 mm)
84016-40
1.31
(33.2 mm)
84030-40
1.38
(35.0 mm)
1.06
(26.9 mm)
1.37 (3.49 mm)
2.36 (60.0 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
2.78 (70.6 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
1.37 (34.9 mm)
2.36 (60.0 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
15A
250V
ON
VIT
LE
ON
VIT
LE
2.77 (70.2 mm)
15A
125V
3.28 (83.3 mm)
FACE
COLOR
4.06 (103.2 mm)
Commercial Grade Straight Blade Receptacles
Back & Side Wired, Self-Grounding
LEVITON
B
0.82
(2.08 mm)
1.09
(27.6 mm)
BR15, BR20
17
1.33
(33.7 mm)
5088, 5891
1.09
(27.7 mm)
1.55
(39.5 mm)
5098, 5824
0.82
(20.8 mm)
1.33
(33.7 mm)
5089, 5823
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 250V; 20A 125V & 250V
Commercial Grade
NEMA 5-15R
NEMA 5-20R
NEMA 6-15R
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
NEMA 6-20R
MECHANICAL
ELECTRICAL
TERMINAL
I.D.
TEMP.
RISE
Brass, hot
30C max at full
rated current
after 100 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
TERMINAL
ACCOMM.
#14 – #10 AWG
Grounding
STANDARDS & CERTIFICATIONS
PRODUCT
I.D.
Ratings are
permanently
marked
on device
White,neutral
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec
WC-596
#E13399
–
CSA
NOM
C22.2 No. 42
#152105
#057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Back & Side Wired, Self-Grounding
5842-I
Commercial Grade Straight Blade Receptacles
5031-I
FACE
COLOR
5844
DUPLEX RECEPTACLE, NARROW BODY, SIDE WIRED
DUAL VOLTAGE
NEMA
5-15R
NEMA
6-15R
NEMA
5-20R
NEMA
6-20R
NEMA
5-20R
NEMA
6-20R
15A 125V/15A 250V, 2-P 3-W, Grounding
Brown
Ivory
White
5031
5031-I
5031-W
FACE
COLOR
DUPLEX RECEPTACLE, NARROW BODY, SIDE WIRED
DUAL VOLTAGE
20A 125V/20A 250V, 2-P 3-W, Grounding
Brown
Ivory
5842
5842-I
FACE
COLOR
DUPLEX RECEPTACLE, WIDE BODY, BACK & SIDE WIRED, 8-Hole Feed-Thru
DUAL VOLTAGE
20A 125V/20A 250V, 2-P 3-W, Grounding
5844
5844-I
20A-125V
2.78 (70.6 mm)
20A-250V
0.84
(21.4 mm)
3.28 (83.3 mm)
2.78 (70.6 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
84030-40
1.31
(33.2 mm)
0.84
(21.4 mm)
1.53
(39.0 mm)
2.80 (71.0 mm)
80730
84003-40
84016-40
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
4.06 (103.2 mm)
80716-I
20A-250V
LEVITON
1.07
(27.2 mm)
1.31
(33.3 mm)
5031
1.09
(27.7 mm)
1.55
(39.5 mm)
1.31 (33.3 mm)
20A-125V
LEVITON
80703-I
302 STAINLESS STEEL WALLPLATES
3.28 (83.3 mm)
NYLON WALLPLATES
4.06 (103.2 mm)
Brown
Ivory
1.09
(27.7 mm)
5842
1.55
(39.5 mm)
5844
B
18
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 250V; 20A 125V & 250V
Commercial Grade
NEMA 5-15R
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
NEMA 5-20R
NEMA 6-15R
MECHANICAL
TEMP.
RISE
TERMINAL
I.D.
TERMINAL
ACCOMM.
Brass, hot
30C max at full
rated current
after 100 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #10 AWG
Grounding
White,neutral
NEMA 6-20R
STANDARDS & CERTIFICATIONS
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec
WC-596
#E13399
–
CSA
NOM
C22.2 No. 42
#152105
#057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Commercial Grade AC Combination Devices
Side Wired
CR20-GY
FACE
COLOR
CR015-GY
DUPLEX
RECEPTACLE
TAMPER RESISTANT
DUPLEX
RECEPTACLE
SMOOTH FACE
CR15
CR15-I
CR15-W
CR15-GY
CR15-A
CR15-E
CR15-C
–
CR15-CI
CR15S-GI
–
CR15S-GW
–
–
–
–
–
–
15A 250V, NEMA 6-15R, 2-P 3-W, Grounding
Brown
Ivory
5028
5028-I
–
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
–
–
Brown
Ivory
White
Gray
Almond
Black
CR20
CR20-I
CR20-W
CR20-GY
CR20-A
CR20-E
–
–
–
–
–
–
20A250V, NEMA 6-20R, 2-P 3-W, Grounding
–
–
–
–
–
–
Brown
Ivory
White
5822
5822-I
5822-W
CR15, CR20,
5822, CR15C, 5028
CR020
CR020-I
CR020-W
CR020-GY
–
–
1.07
(27.1 mm)
–
–
–
1.53 (39.0 mm)
4.06 (103.2 mm)
2.79 (70.9 mm)
3.28 (83.3 mm)
1.31
(33.3 mm)
1.54 (39.0 mm)
1.06 (26.8 mm)
4.06 (103.2 mm)
2.64 (67.1 mm)
2.80 (71.0 mm)
3.28 (83.3 mm)
1.31
(33.3 mm)
4.06 (103.2 mm)
2.64 (67.1 mm)
1.07
(27.1 mm)
–
–
–
–
–
–
–
–
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
0.84 (21.4 mm)
1.53 (39.0 mm)
CR015
CR015-I
CR015-W
CR015-GY
–
–
0.81
(20.7 mm)
CR015, CR020
3.28 (83.3 mm)
Brown
Ivory
White
Gray
Almond
Black
2.80 (71.0 mm)
19
CR15S-GI
DUPLEX
RECEPTACLE
CANADIAN
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
.084 (21.4 mm)
B
5028
DUPLEX
RECEPTACLE
1.31
(33.3 mm)
CR15S
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 250V; 20A 125 & 250V
Commercial Grade
NEMA 5-15R
NEMA 5-20R
NEMA 6-15R
NEMA 6-20R
MECHANICAL
ELECTRICAL
TERMINAL
I.D.
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
TEMP.
RISE
Withstands
2000V
per
UL 498
Full
rated
current
30C max at full
rated current
after 100 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
Brass, hot
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #10 AWG
Grounding
White,neutral
NEMA ANSI
WD-6 C-73
498
UL
UL Fed Spec CSA NOM
WC-596 C22.2No.42
#E13399
–
#152105
#057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Side Wired
SINGLE
RECEPTACLE
5340-I
5059
DUPLEX RECEPTACLE
ON 4" COVER
ZINC PLATED
Commercial Grade Straight Blade Receptacles
5042
5015
FACE
COLOR
SINGLE RECEPTACLE
ON 4" COVER
ZINC PLATED
DUPLEX RECEPTACLE
w/ 6" Leads
Contractor Pack
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
Brown
Ivory
White
5015
5015-I
5015-W
5042
5059
–
–
–
–
15A 250V, NEMA 6-15R, 2-P 3-W, Grounding
Brown
Ivory
White
5029
5029-I
5029-W
–
–
–
–
–
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
Brown
Ivory
White
Gray
Almond
5801
5801-I
5801-W
–
–
–
–
–
–
–
–
–
–
–
–
20A 250V, NEMA 6-20R, 2-P 3-W, Grounding
Brown
Ivory
White
Almond
5821
5821-I
5821-W
5821-A
–
–
–
–
1.06 (26.9 mm)
80716-I
1.38 (35.0 mm)
0.87
(22.2 mm)
0.78
(19.8 mm)
–
–
–
5340
5340-I
5340-W
5340-GY
5340-A
–
–
–
–
NYLON WALLPLATES
80703-I
–
5040-I
5040-W
–
–
–
–
302 STAINLESS STEEL WALLPLATES
80730
84003-40
84016-40
FOR ADDITIONAL WALLPLATE OPTIONS SEE SECTION Q
1.06
(26.9 mm)
0.87
(22.2 mm)
4.12 (104.8 mm)
2.47 (62.8 mm)
0.06
(1.7 mm)
0.19
(4.7 mm)
84030-40
6.00
(152.4 mm)
3 LEADS
4.13 (104.8 mm)
2.47 (62.9 mm)
1.31
(33.3 mm)
0.86
(21.9 mm)
3.28
(83.3 mm)
4.06
(103.2 mm)
2.79
(70.9 mm)
2.36 (60.0 mm)
LEVITON
15A-125V
2.47 (62.8 mm)
2.80 (71.0 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
2.39 (60.0 mm)
ON
2.47 (62.9 mm)
VIT
1.37 (3.49 mm)
LE
1.37 (3.49 mm)
15A
125V
0.38
(9.5 mm)
0.82
(20.8 mm)
1.33
(33.7 mm)
5015, 5029, 5801, 5821
0.82
(20.8 mm)
1.06
(27.0 mm)
5042
1.09
(27.7 mm)
0.19
(4.8 mm)
1.33
(33.7 mm)
5040
5059
B
20
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 20A 125 & 250V
Commercial Grade
NEMA 5-15R
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
Withstands
2000V
per
UL 498
Full
rated
current
NEMA 5-20R
NEMA 6-15R
MECHANICAL
TEMP.
RISE
TERMINAL
I.D.
Brass, hot
30 C max at full
rated current
after 100 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
Grounding
NEMA 6-20R
STANDARDS & CERTIFICATIONS
TERMINAL
ACCOMM.
PRODUCT
I.D.
Ratings are
permanently
marked
on device
#14 – #10 AWG
White,neutral
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec CSA NOM
WC-596 C22.2 No. 42
#E13399
–
#152105
#057
AC HORSEPOWER RATINGS
15A 125V 15A 250V 20A 125V 20A 250V
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
.5
1.5
1.0
2.0
Commercial Grade Straight Blade Receptacles
Side Wired
5250
5249-CAP
FACE
COLOR
FLOORBOX
CAP & GASKET
REPLACEMENT
Brass
Brown
Ivory
5249-CAP
–
–
Brown
–
DISPLAY RECEPTACLE
w/ SOLID BRASS PLATE
SINGLE FLOOR
BOX ASSEMBLY
DUPLEX FLOOR
BOX ASSEMBLY
SHORT STRAP 8-32
Tapped Mounting Holes
on 1 15/16" Center
–
5258-SS
–
–
5284-SS
–
5658-SS
–
–
–
–
–
5458-SS
–
20A 125V, NEMA 5-20R, 2-P 3-W, Grounding
Brass
Ivory
25249-CAP
–
–
–
Brown
–
–
–
5349-FBA†
–
25349-FBA††
20A 250V, NEMA 6-20R, 2-P 3-W, Grounding
–
–
† Use 5249-CAP Replacement
†† Use 25249-CAP Replacement
UL Listed Box
w/ #6 x 1” Screws
Mounting Brackets
BR15/BR20
Duplex
Recepatcle
0
2.0 m)
m
.80
(50
Plastic
Shell
Gasket
3
(93 .70
.98
mm
)
Rubber
O-Rings
Brass Plate
w/ #6/32 Brass Screws
w/ O-Seal Washers
0
)
2.0 mm
.80
(50
2.38 (60.3 mm)
0.27
ø(6.8
mm)
4
(11 .50
4.3
mm
)
3.00
(76.20 mm)
4.50 (114.3mm)
1.74
ø(44.1
mm)
5249-CAP
Brass Screw
Caps
4.50
(114.30 mm)
4.50
(114.30 mm)
3.00
(76.20 mm)
2.75 (89.9 mm)
21
SHORT STRAP 8-32
Tapped Mounting Holes
on 1 3/4" Center
15A 125V, NEMA 5-15R, 2-P 3-W, Grounding
–
–
–
–
–
–
5250
5249-FBA†
25249-FBA††
15A 250V, NEMA 6-15R, 2-P 3-W, Grounding
–
–
–
Cat. no. 25249-FBA
(includes all of the above components)
B
5284-SS
5458-SS
5349-FBA
0.20
ø(5.0
mm)
5249/5349-FBA
SERIES
.74 )
Ø 1 0 mm
.2
(44
5
)
2.7 mm
.85
(69
5250-FBA
25249/25349-FBA
SERIES
.46 )
Ø 1 mm
.1
(37 3.75 m)
m
.3
9
( 5
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 277V; 20A 125/250V
Commercial Grade
NEMA 7-15R
NEMA 10-20R
ELECTRICAL
MECHANICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
TEMP.
RISE
TERMINAL
I.D.
Withstands
2000V
per
UL 498
Full
rated
current
30C max at full
rated current
after 50 cycles
overload at
150% rated
current for both
AC and DC per
UL 498
Brass, hot
TERMINAL
ACCOMM.
#14 – #10 AWG
Grounding
STANDARDS & CERTIFICATIONS
PRODUCT
I.D.
Ratings are
permanently
marked
on device
White,neutral
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
NEMA ANSI
WD6 C-73
498
UL
UL Fed Spec CSA NOM
WC-596 C22.2 No. 42
#E13399
–
#152105 #057
AC HORSEPOWER RATINGS
15A 277V
20A 125/250V
2
2L-L*/1 L-N
L-L Denotes phase-to-phase HP rating
L-N Denotes phase-to-neutral HP rating
*Suitable for 208V motor applications at HP rating
Side Wired
DUPLEX RECEPTACLE
GROUNDING
SINGLE RECEPTACLE
NON-GROUNDING
15A 277V, NEMA 7-15R, Back & Side Wired, 2-P 3-W, GROUNDING
Brown
Ivory
5585
5585-I
–
–
20A 125/250V, NEMA 10-20R, Side Wired, 3-P 3-W, GROUNDING
–
–
Brown
Ivory
41650-F
41650-6
41652-6
5032
5032-I
41652-000
41652-6F
Quick Port Snap-In-Jacks and Modules with Brass Floorplate
HOUSING
COLOR
SINGLE
FLOOR JACK
6 CONDUCTOR JACK
Brass
41650-6
SINGLE
FLOOR JACK
WITH COAXIAL
F-CONNECTOR
41650-F
DUPLEX
FLOOR JACK
WITH TWO 6
CONDUCTOR JACKS
41652-6
DUPLEX FLOOR JACK
6 CONDUCTOR JACK
AND COAXIAL
F-CONNECTOR
DUPLEX
FLOOR JACK
HOUSING ONLY WITH
1 BLANK FILTER
41652-6F
41652-000
Commercial Grade Straight Blade Receptacles
5032-I
5585
FACE
COLOR
1.66
41652-6F
1.20 (30.5 mm)
3.28 (83.3 mm)
4.06 (103.2 mm)
2.76 (70.2 mm)
2.38 (60.5 mm)
2.75 (69.9 mm)
1.44 (36.5 mm)
0.97 (24.7 mm)
1.74 (44.2 mm)
4.50 (114.3 mm)
0.65
0.19 (4.8 mm)
(16.5 mm)
1.93 (49.0 mm)
3.28 (83.3 mm)
3.84 (97.5 mm)
(42.2 mm)
B
1.31 (33.3 mm)
5585
22
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V & 250V; 20A 125V & 250V
Industrial Grade
B
23
STANDARDS & CERTIFICATIONS
MECHANICAL
CURRENT
INTERR.
TEMP.
RISE
Withstands
1500V
per
UL 498
Full
rated
current
Max 30C
after 250
cycles of
overload at
200% of
rated current
TERMINAL TERMINAL PRODUCT
I.D.
ACCOMM.
I.D.
CORD GRIP
RANGE
Ratings & NEMA
#18 – #10 I.D. permanently
AWG
marked on device
Brass, hot
Grounding
–
NEMA ANSI UL UL Fed Spec CSA NOM
WD-6 C-73 498 Listed WC-596 C22.2 No.42
White,neutral
#E13393
Plugs, Connectors
& Flanged Inlets
#LR-16347 #057
#E13399
ENVIRONMENTAL
FLAMMABILITY
OPERATING TEMP.
Rated V-2 per UL 94
-40C to 60C
Receptacles
& Flanged Outlets
Engineered to IP64
Splashproof &
Dust-Tight
FLANGED INLET
STANDARD
WIRE WELLS
NEMA
FLANGED OUTLET
STANDARD
WIRE WELLS
4715-FWP
4716-FWP
5279-FWP
5278-FWP
TYPE
NEMA
FLANGED INLET
SLOTS FOR
FORK TERMINALS
NEMA
FLANGED OUTLET
SLOTS FOR
FORK TERMINALS
NEMA
15A 125V, 2-P 3-W Straight Blade, Grounding
Gray Glass-Filled
Thermoplastic Cover
Device White Nylon
5278-CWP
5279-CWP
5278-FWP
5-15P
5-15R
5279-FWP
5-15P
5-15R
15A 250V, 2-P 3-W Straight Blade, Grounding
Gray Glass-Filled
Thermoplastic Cover
Device White Nylon
15678-CWP
15679-CWP
6-15P
–
–
–
–
6-15R
15A 125V, 2-P 3-W Locking, Grounding
Gray Glass-Filled
Thermoplastic Cover
Device White Nylon
4716-CWP
4715-CWP
4716-FWP
L5-15P
L5-15R
4715-FWP
L5-15P
L5-15R
15A 250V, 2-P 3-W Locking, Grounding
Gray Glass-Filled
Thermoplastic Cover
Device White Nylon
4586-CWP
4585-CWP
–
L6-15P
–
–
–
–
–
–
–
–
–
L6-15R
20A 125V, 2-P 3-W Straight Blade, Grounding
Gray Glass-Filled
Thermoplastic Cover
Device White Nylon
15378-CWP
15379-CWP
5-20P
–
5-20R
20A 250V, 2-P 3-W Straight Blade, Grounding
5478-CWP
5479-CWP
–
6-20P
6-20R
1.49
3.25 (82.6 mm)
4.56 (115.9 mm)
1.88 (46.6 mm)
0.13 (3.32 mm)
2.09 (53.0 mm)
Gray Glass-Filled
Thermoplastic Cover
Device White Nylon
1.69 (42.8 mm)
Integrated Power Inlets and Outlets with Weather-Resistant Covers
ELECTRICAL
DIELECTRIC
VOLTAGE
1.33
(37.8mm) (33.8mm)
2.84 (72.2 mm)
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
15A 125V
Industrial Grade
10 YEAR LIMITED
NEMA 5-15R
6252-DIN & 16252-DPL
STANDARDS & CERTIFICATIONS
SPECIFICATIONS & FEATURES
• Ideal for mounting in equipment cabinets where
convenient plug-in surge protection is desired.
• Provides MOV-Based Normal Mode and
Common Mode L-N, L-G, N-G protection.
• Hospital Grade Receptacles ensure the best
electrical connection of equipment.
• Green LED goes off when surge protection is lost.
• Power continues to be provided to connected
loads in the event of protection loss.
OPERATING
FREQUENCY
RATED
LINE VOLTAGE
50, 60Hz
120V
UL Fed Spec CSA NOM
WC-596 C22.2 No. 42
#E13399
–
#152105
Recognized Component
#057
MECHANICAL
NEMA ANSI UL
UL 943
CSA NOM
WD1&
C22.2 No. 42
WD-6 C-73 Listed Class A & 498
#E48380
Terminal Block accepts
#22-#12 AWG conductors.
#LR-57811 #057
ENVIRONMENTAL
3880-DIN & 3801-DIN
ANSI/IEEE STANDARDS & CERTIFICATIONS
ANSI/IEEE
UL
CSA
Categories A & B
1449
C22.2 No. 42
NOM
#E146315
#LR-94773
STORAGE TEMP.
OPERATING TEMP.
-20C to 85C
-10C to 60C
FLAMMABILITY
Rated V-2 per UL 94
#057
PERFORMANCE DATA FOR 3880-DIN & 3801-DIN
MAXIMUM
MAXIMUM
RATED
CONTINUOUS
SINGLE-PULSE
SINGLE-PULSE
OPERATING
TRANSIENT CURRENT TRANSIENT ENERGY
VOLTAGE (MCOV)
(8x20µs, Amps peak)
(10x1000µs, Joules)
150V rms
24kA (L-N),
12kA (L-G),12kA (N-G)
EMI-RFI NOISE
REJECTION
@ 50 Ohms
500k- 30MHz
720 Joules
-30dB
CLAMPING PERFORMANCE FOR 3880-DIN & 3801-DIN
ELECTRICAL
DIELECTRIC
VOLTAGE
CURRENT
INTERR.
TEMP.
RISE
Withstands
2000V
per UL 498
Full rated
current
Max 30C after 250
cycles of overload at
200% of rated current
UL 1449 SUPPRESSED VOLTAGE RATINGS (SVR)
Assigned at 6" lead length with 6kV/500A impulse in accordance with
UL 1449 (Ed.)
400/400/400Vpk
TOP VIEW
BACK VIEW
3880-DIN
3801-DIN
8598-DIN
FACE
COLOR
RATED
LINE VOLTAGE
DUPLEX RECEPTACLE
HOSPITAL GRADE
SURGE PROTECTED
DUPLEX OUTLET
Indicator Light,
Audible Alarm
SURGE PROTECTED
SINGLE CONVENIENCE
RECEPTACLE
Blue
Black
Gray
120V
120V
120V
16252-DIN
GFCI PROTECTED
SMARTLOCK®
DUPLEX
Indicator Light
15A 125V NEMA 5-15R, 2-P 3-W, Grounding
3880-DIN
–
–
3801-DIN
–
–
DUPLEX
RECEPTACLE
–
8598-DIN
–
–
–
16252-DIN
Industrial Grade DIN-Rail Mountable Receptacles
• Audible alarm on 3880-DIN has an integral
disable (quiet) switch.
• Easy installation with pressure terminals.
UL
498
8598-DIN
STANDARDS & CERTIFICATIONS
• Designed for use on 120V single-phase AC
power sources.
• Module housing comes in black only.
NEMA ANSI
WD-6 C-73
3880-DIN, 3801-DIN,
8598-DIN, 16252-DIN & 16252-DPL
2.73 (69.3 mm)
2.60 (66 mm)
2.73 (69.3 mm)
2.73 (69.3 mm)
2.60 (66 mm)
2.60 (66 mm)
1.99
(50.5 mm)
5.63 (143 mm)
5.05 (128.2 mm)
5.63 (143 mm)
5.05 (128.2 mm)
m)
6.6 m
6.22 (158 mm)
2.23 (5
5.05 (128.2 mm)
2.54 (64.5 mm)
COMMON
)
1
7. .09
7
m
m
)
(2
8598-DIN
3880-DIN
16252-DIN
2.8
(71.1
mm
3801-DIN
B
24
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
Technical Information
Types of Receptacles
Receptacles generally are made to accommodate either of two types of
plugs. Straight-Blade plugs are pushed in and pulled straight out.
Locking plugs are pushed in and rotated slightly in a clockwise direction
to a position were they cannot be pulled straight out. They must be
rotated counterclockwise back to the insertion position in order to be
withdrawn. This locking action is intended to prevent accidental disconnection of the circuit by pulling the plug straight out unintentionally.
Technical Information for Straight Blade Receptacles
Grounding
Originally, residential electrical circuitry was “2-pole, 2-wire” and did not
have an equipment grounding means at the receptacle. The only
grounding point was at the service entrance, where the neutral (white)
conductor was grounded. The receptacle slot for the neutral wire,
according to NEMA configuration 1-15R, must be longer than the slot
for the phase or hot wire (typically black or red). This enables certain
items of equipment, like TV sets and home appliances, to have their
external metal parts or casing grounded through the white neutral connection. Such equipment uses a polarized plug where the neutral plug
blade is wider than the hot plug blade, ensuring that it mates properly
with the NEMA 1-15R configuration receptacle. Receptacles designed
for 2-pole, 2-wire circuits do not have mounting straps that are connected to a grounding terminal. Leviton still offers 2-pole, 2-wire receptacles
for replacement use only in existing non-grounding systems.
Experience proved that a single grounding point through the neutral
conductor was not sufficiently safe. Conditions could occur where fault
currents and differences in potential lead to shocks, overheating, equipment burnout and fire. Therefore, the 2-pole, 3-wire circuit was developed. A third conductor, called the grounding conductor, does not carry
current during normal circuit operation. It is connected to the neutral
bus bar at the service entrance and runs along with the current-carrying neutral and hot conductors .The grounding conductor is connected
only to outlet boxes, chassis and other non-current carrying components that may carry current in case of damage or defects in the wiring
system. It is sometimes referred to as the “equipment grounding conductor.”
The grounding contacts on the 2-pole, 3-wire receptacles are most
commonly shaped like a “U”, which is how the term “U-ground”
evolved. The grounding contacts on these receptacles are securely fastened to the mounting strap. In Leviton receptacles, the grounding contacts are permanently riveted to the mounting strap, and in most
Leviton Hospital Grade and Industrial Grade receptacles they are an
integral part of the strap. Many Leviton receptacles offer dual ground
connection options to help ensure that the receptacle is properly connected to the grounding system: An integral green grounding screw for
direct connection to the green or bare grounding wire, and a patented
Groundamatic ® self-grounding clip riveted to the strap to provide automatic ground connection when the receptacle is mounted in a properly
grounded metal wallbox.
Isolated-Ground Receptacles
Although the conventional grounding system provides safety for personnel and equipment, it may be a source of electrical interference that
can cause problems in modern electronic equipment. Because the conventional grounding network runs through an entire facility, it can unintentionally function as a pick-up of transient electrical signals or “noise.”
25
MOUNTING STRAP
GROUNDED TO BOX
OUTLET BOX
LINE TERMINAL
BLACK
WHITE
ISOLATED GROUNDING
TERMINAL (ISOLATED
FROM STRAP)
GREEN
CONVENTIONAL
GROUND
ISOLATED
GROUND
ISOLATED-GROUNDING RECEPTACLES
Mounting Straps
There are basically two kinds of mounting straps for receptacles. The
“through” type passes between the receptacle body and cover. The
“wrap-around” type acts as a cradle for the receptacle, surrounding its
side, ends and bottom surfaces.
Power Contact Design
The “contact” does more than make contact with the plug blade — It
must grip the plug blade for maximum electrical conductivity and
mechanical strength. Leviton receptacles feature double-wipe contacts
that grip both sides of each blade, including the U-ground contacts that
are often single-wipe in receptacles made by other manufacturers.
Leviton Hospital Grade and Industrial Grade receptacles feature triplewipe contacts for added strength and durability in high-abuse applications. Leviton contacts are made of the copper alloys that offer maximum strength and electrical conductivity.
Types of Wiring for Receptacles
Side Wiring
Loop wire around
terminal screw. Screw head
locks wire against terminal.
For copper or copper/clad
aluminum conductors.
B
These transient signals will then be introduced to equipment through
the ground connection. Microprocessor-based equipment, including
computers, cash registers, medical equipment and audio/video equipment, may malfunction as a result of this noise.
Isolated-Grounding Receptacles can help eliminate problems caused
by electrical interference in a conventional ground system. The ground
contacts on Isolated-Ground Receptacles are electrically isolated from
the mounting strap and therefore they are isolated from the conventional ground system. The green ground screw is connected to a pure
ground path that is separate from a facility’s grounding network. The
isolated ground network is relatively free of electrical noise because it is
not a facility-wide grounding path and it’s connected to ground at a
single point.
Quickwire™ Connection
Insert wire into wire well.
Wire is automatically
clamped by spring action,
insuring good electrical connection. For copper conductors only.
Quickwire™ and Screw
Option of
(1) side wiring or
(2) Quickwire connection.
NOTE: For continuous wiring,
both sets of terminals (screw
and Quickwire) can be used
together.
Back & Side Wiring
Option of (1) side wiring or
(2) back wiring: Insert wire
into well. Tighten screw, thus
clamping wire against
terminal. Back wiring for
copper or copper/clad
aluminum conductors.
Two-Circuit Conversion
To power each outlet of
a duplex receptacle
separately, simply break off
the tab between the two terminals.
www.leviton.com
To learn more about Leviton devices or for answers to technical questions call our Techline at
1-800-824-3005 or visit us at:
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
