AGRI-VAC
HIGH PERFORMANCE PNEUMATIC
GRAIN MOVING UNITS
The only system you’ll ever need. Gives one
person total grain-handling capability! Do it
all with the Walinga Agri-Vac. Fill or empty any
storage facility being used.
The Walinga Agri-Vac puts an end to legs,
augers, sweeps and shovels. Grain handling
has never been simpler, safer or healthier. Just
couple the Agri-Vac to your tractor and drive
into position. Lightweight vacuum/pressure
hoses attach in seconds and flex easily.
Suddenly even tight spots and awkward angles
are no problem!
TRANSPORTATION
PNEUMATIC CONVEYING SYSTEMS
MACHINING
Beyond the
PRODUCT
­­­Walinga builds solutions for most of your
grain-handling needs. Visit our website to see
more on our truck and vac systems!
2
FE AT U R ES & B E N E F ITS
Easier, Healthier, Safer
The Only System You’ll Ever Need.
Gives One Person Total GrainHandling Capability!
Do it all with the Walinga Agri-Vac. Fill or empty
your storage facilities. The Walinga Agri-Vac
puts an end to legs, augers, sweeps and shovels.
Grain handling has never been simpler, safer and
healthier. Just couple the Agri-Vac to your tractor
and drive into position. Lightweight vacuum/
pressure hoses attach in seconds and flex easily,
making tight spots easy to clean.
• No shoveling
• Removes dust with grain
• Easy-handling
• Hose reaches into corners
• Vacuum action sucks up grain
• Saves your lungs!
The Agri-Vac Maintains Excellent Grain
Quality Thanks To The Large Drop Thru/
Blow Thru Airlock.
Inlet and outlet ports have special flow contours
that maximize capacity. A rotor wiper levels pockets
to prevent grain damage. The 10-vane fabricated
steel rotor has adjustable hardox steel tips to
increase airlock life. Pressure protected airlock
motor is reversible so you can easily remove
foreign objects.
Top Versatility! Walinga Agri-Vac
Puts You Cleanly In Control.
Check these performance highlights: Truck
loading boom rotates manually or hydraulically,
and raises or lowers to suit truck height. Grain
bin ‘hot spots‘ are easy to remove. Light-weight
cleanup hose makes for easy vacuum clean out,
including seed drills, grain bins, flat storage piles
and/or buildings.
3
Cyclonic Action Helps Pre-Clean The
Air & Assures Optimum Air Flow.
The Agri-Vac‘s cone shaped receiver is designed for
minimal resistance to material and airflow. Grain
and air are separated in the receiver. Material flows
into the rotary airlock and the air moves on to the
blower, which then pushes material out of the
airlock into the bin or truck. No filters or screens
to cause plug-ups or freeze-ups.
Lots Of Loading Options.
Loading/Unloading tubes can be permanently
installed in your grain bins and connected
with your piping system. You just move the
Agri-Vac from site to site. Push grain hundreds
of feet. Pull out every last bit of grain with the
flexible hose and clean-up nozzle.
FE AT U R ES & B E N E F ITS
Mobile Transfer Units
How It Works
1
Heavy duty
discharge cyclone
Walinga PD Blower
With more than 60 years experience in manufacturing
feed and grain handling equipment the Walinga
Agri-Vac is first for quality. The blowers are made
of special alloy casting to facilitate hardening. These
hardened surface blowers can triple the life of
non-hardened blowers.
5
6
Heavy duty steel elbow at airlock
discharge connects to flexible piping
for adjustable height truck loading kit
The Walinga Agri-Vac is designed for maximum
performance due to its engineered efficiency.
A minimum of resistance to material and airflow
is achieved as a result of this design. The material
(grain) is drawn to the conical receiver which
creates cyclonic action, thus acting as a PreCleaner. The grain and the air are separated in
the receiver, the material flows into the rotary
airlock and the air moves on to the blower which
in turn pushes the material back out of the rotary
airlock into the truck or bin pipe. In addition,
Walinga’s Secondary Pre-Cleaner (standard on most
models) filters the air for a second time, resulting
in an extended life of the unit.
2
Easy to reach truck
loading kit has hydraulic
lift for easy positioning
3
4
Secondary Pre-Cleaner extends life of unit
Walinga’s dust separator (Pre-Cleaner) device greatly
reduces premature wear of the blower because most
grains create dust-laden air. Our Pre-Cleaner does not
use filters which plug or freeze. Minimal maintenance
is easy and fast. The dust simply needs to be dumped
out of the Pre-Cleaner. Product quality is maintained, in
fact may be improved as the result of a natural cleaning
action during transfer.
The Unique Drop Thru/
Blow Thru Airlock
Walinga’s airlock is designed for maximum
performance and minimal grain damage. The
housing is precision machined from a cast shell
for unequalled performance. The 10-vane fabricated
steel rotor has adjustable hardox tips for longer life
and the inlet and outlet ports have a special flow
contour for maximum capacity. To prevent grain
damage, a special rotor wiper levels the pockets.
The airlock is driven by a pressure protected,
variable speed, hydraulic motor that is reversible
so you can easily remove foreign objects which
might be in your grain.
Fast and easy hose connections
with convenient inlet positions
5
* Unit may not be exactly as shown.
Heavy duty frame and fenders
6
LEADERS IN P NE UM AT I C
C ONVEYING SYSTEMS
Walinga products are ripe with innovative solutions.
When you engage with Walinga, your relationship
extends beyond the simple purchase of a Walinga
product. Walinga not only listens to their customers,
they engage in conversation.
Did you know that many standard features start out
as customer initiated design projects? Throughout the
year Walinga engineers review and collect customer
feedback. Sometimes customers only suggest an
SUCTION NOZZLE
FLOOR SWEEP NOZZLE
opportunity for improvement, some might offer the
bones of a solution and occasionally one will go as
far as sharing something specific they’ve fabricated
for themselves. Each year Walinga engineers build a
full size working prototype incorporating the best
of these ideas and annually invite customers to come
play with it. Changes might be made, some features
may not prove worthy, but ideas that work will become
standard production items.
EMPTYING A
PRE-CLEANER
Manufacturing at Walinga’s Fergus, Ontario plant utilizes an
overhead rail assembly line. Shown here, Agri-Vac parts have
completed finishing and are en route to final assembly.
8
High P erform ance
PNEUMATIC GRAIN MOVING UNITS
Walinga Agri-Vac, A Model for Every Need
AGRI-VAC
LOW-MID RANGE
PORTABLE CLEAN-UP
3510G
3510E
3510 3PH
*CAPACITIES:
3510E (20hp) 650 Bu/Hr (17 Tonnes/Hr)
3510G (30hp) 700 Bu/Hr (18 Tonnes/Hr)
3510 3PH 700 Bu/Hr (18 Tonnes/Hr)
*Capacities based on Corn & using
a 12' (3.65 m) long suction line and
12' (3.65m) long discharge line.
Barometric pressure, humidity,
and condition of product will
affect capacity.
Some items shown may be optional.
Electric
AGRI-VAC
MID-HIGH CAPACITY
PTO POWERED
Gas Powered
5614 DLX
6614 DLX
7614 DLX HD
*CAPACITIES:
5614 PC& 5614 DLX 2500 Bu/Hr (64 Tonnes/Hr)
6614 PC & 6614 DLX 3600 Bu/Hr (92 Tonnes/Hr)
7614 PC HD & 7614 DLX HD
5000 Bu/Hr (127 Tonnes/Hr)
*Capacities based on Corn & using
a 12’ (3.65 m) suction line and truck
loading kit.
Barometric pressure, humidity,
and condition of product will
affect capacity.
Some items shown may be optional.
AGRI-VAC
HIGH CAPACITY
PTO POWERED
*CAPACITIES:
7816 DLX
5500 Bu/Hr (140 Tonnes/Hr)
8614 DLX
7000 Bu/Hr (178 Tonnes/Hr)
*Capacities based on Corn & using
a 12’ (3.65 m) suction line and truck
loading kit.
Barometric pressure, humidity,
and condition of product will
affect capacity.
Some items shown may be optional.
7816 DLX
8614 DLX
MAXIMUM LOADING CAPABILITIES
ONE PIECE UNIT
AIRLOCK PACKAGE
ULTRA-VEYOR
BLOWER PACKAGE
MID-HIGH CAPACITY
STATIONARY UNIT
*CAPACITIES:
4510UV10
500 Bu/Hr (13.3 Tonnes/Hr)
4510UV20
800 Bu/Hr (21.0 Tonnes/Hr)
5510UV30
1100 Bu/Hr (29.3 Tonnes/Hr)
5614UV40
1300 Bu/Hr (34.7 Tonnes/Hr)
5614UV50
1500 Bu/Hr (40.0 Tonnes/Hr)
6614UV60
1800 Bu/Hr (48.0 Tonnes/Hr)
*CAPACITIES:
4510UV10 500 Bu/Hr (13.3 Tonnes/Hr)
4510UV15 650 Bu/Hr (17.5 Tonnes/Hr)
4510UV20 800 Bu/Hr (21.0­­­ Tonnes/Hr)
6614 UV75
2100 Bu/Hr (56.0 Tonnes/Hr)
*Capacities based on moving dry corn
approximately 100’ (30.4m). Barometric
pressure, humidity, and condition of product
will affect capacity. Some items shown may
be optional.
*Capacities based on moving dry corn approximately 100’ (30.4m).
Barometric pressure, humidity, and condition of product will
affect capacity. Some items shown may be optional.
7614F
6614D
*CAPACITY:
7614F 8' Hose Length 4500 Bu/Hr (114 Tonnes/Hr)
42' Hose Length 3700 Bu/Hr (94 Tonnes/Hr)
*Barometric pressure, humidity, and condition of product will
affect capacity. Some items shown may be optional.
*CAPACITY:
6614D
3600 Bu/Hr (92 Tonnes/Hr)
*CAPACITY:
7614D HD
*Capacities based on Corn & using a 12’ (3.65m) suction line and truck loading kit.
Barometric pressure, humidity, and condition of product will affect capacity.
Some items shown may be optional.
*Capacities based on Corn & using a 12’ (3.65m) suction line and truck loading kit.
Barometric pressure, humidity, and condition of product will affect capacity. Some
items shown may be optional.
7816D
*CAPACITY:
7816D
ULTRA-VAC
SELF-CONTAINED HIGH
CAPACITY DIESEL
POWERED
7614D HD
5500 Bu/Hr (140 Tonnes/Hr)
*Capacities based on Corn & using a 12’ (3.65m) suction line and truck loading kit.
Barometric pressure, humidity, and condition of product will affect capacity.
Some items shown may be optional.
5000 Bu/Hr (127 Tonnes/Hr)
8614D
*CAPACITY:
8614D
7000 Bu/Hr (178 Tonnes/Hr)
*Capacities based on Corn & using a 12’ (3.65m) suction
line and truck loading kit. Barometric pressure, humidity, and condition of
product will affect capacity. Some items shown may be optional.
10
Walinga products represent the best in manufacturing
excellence. Our in-house engineering and design
teams utilize the most current computer technology
available. State-of-the-art manufacturing equipment,
combined with over 60 years of experience, ensures
that our customers receive unsurpassed quality.
Walinga adheres to one
clear and simple mandate:
the customer must be completely satisfied.
From initial contact, to delivery, to future service we guarantee accessibility, professional expertise
and meticulous attention to detail. There are
no “small” projects at Walinga. Each customer is
given the full attention of our seasoned team.
A comprehensive network of distributors, dealers
and agents ensures that a company representative
is available at any time and virtually anywhere
throughout Canada, the United States, South
America, Europe, Australia, and Asia.
Head Office
Michigan
Manitoba
Ontario
R.R. #5, Guelph, ON.
Canada N1H 6J2
Tel: 519.824.8520
Tel: 888.925.4642
Fax: 519.824.5651
1190 Electric Ave.
Wayland, MI.
USA 49348
Tel: 616.877.3470
Tel: 800.466.1197
Fax: 616.877.3474
70 3rd Ave. N.E.
Box 1790
Carman, Manitoba
Canada R0G 0J0
Tel: 204.745.2951
Fax: 204.745.6309
938 Glengarry Cres.
Fergus, Ontario
Canada N1M 2W6
Tel: 519.787.VACS (8227)
Fax: 519.787.8210
34-18989-6 07/15
Custom-built aluminum feed bodies and trailers,
pneumatic conveying systems, central vac systems,
aluminum and steel dump bodies, rendering and
recycling units each built according to exacting
standards. Every stage of the manufacturing process
from design to completion is performed by Walinga.
The result—a cost effective, durable product line that
responds to any challenge with premium performance.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
