Presentation of ELKO EP Company
ELKO EP, which is based in Holešov, has been with you on the electrical market for the past 20
years, covering a wide range of domestic equipments in the field of electrical installations. In the
last few years there has been dynamic development of smart wiring, in which our company has
been seven years developing and launching iNELS smart home system solutions. In modular
devices, as well as in smart wiring, we have become market leaders. We‘re developing products
that bring comfort to customers and safety for the environment.
The Parent ELKO EP company has gradually grown in 7 branches - Slovakia, Hungary, Poland,
Russia, Ukraine, Romania and most recently Germany. At the same time we export to 60
countries around the world, and our products can be found under the world famous brand
names (Schneider Electric, Eaton, HAGER, Siemens, MORS SMITT).
Our work is based on the development and modern technology. In practice, we appreciate you
as our customer, because you‘re receiving good products and smart solutions, which meet your
requirements. Own development facilities, precise production and distribution, all this gives you
the opportunity to use solutions which are both innovative and practical. There are our modern
manufacturing facilities to produce all our products. It was extended over the newest and fastest
SMD line, which means for you guaranteed quality and flexibility of supply.
We have and supervise 80% share of the Czech market and the fourth position in Europe.
Current-year sales growth: 20%
Number of employees in Holešov: 170
Number of employees of ELKO EP Holding: 236
Awards and Recognition:
In 2011, the experts awarded the top products developed in ELKO EP: RF Touch - wireless touch control unit won a Golden Amper, Moravian Electrical and Electronic
Association Award, Innovation Award of the year and PwC Special Award for Innovation. Also iNELS Multimedia - Multimedia control through television, won an award
- honorable mention Grand Prix.
ELKO EP Company provides the possibility for students in technical fields to do their thesis.
In 2012, the company ELKO EP became the number one company in Zlín Region and in the national finals, we won second place.
Our range of products is divided into three product lines - relay (classical modular devices), RF Control (wireless), iNELS BUS system (Bus System). Each product line
has its own technical catalogue, where you can find complete information on individual products.
Product Lines
www.elkoep.com
RELAYS - Modular electronic devices
A wide range of electronic modular devices, which brings new possibilities to home and office control, monitoring and
security, as well as to industrial process control: time relays, installation contactors, staircase automatic switches, time
switches clocks, dimmers, thermostats, power supplies units, control and signalling devices, GSM gates, etc.
www.inels.com
iNELS BUS - Intelligent electro-installation System
iNELS will transform your house into a timeless intelligent household. It will take charge of heating and air-conditioning
regulation, lighting control and switching home appliances, while also providing perfect security for your home. Enjoy
controlling your entire house via a TV screen thanks to iNELS Multimedia (iMM) or use the elegant iNELS Touch Panel (iTP).
www.elkoep.com
iNELS RF Control - Wireless control
A unique wireless control system, which is providing you perfect control over your home! The RF Control system enables
you to control functions such as heating, lighting, electrical appliances and window shutters, all with a single touch. No
wall cutting, fast and easy installation, exclusive design of wireless wall switch buttons and other components.
www.logus90.com
LOGUS90 – Home switches and sockets
We are offering you an exclusive switches, sockets and accessories in a standard plastic or metallic design. However,
there are also charming luxury frames from purely natural materials such as genuine wood, metal, granite or hardened
glass. Be especial!
2
iNELS system advantages
Advantages to classical electrical installation:
Comfort
- dimming function (gradual dim-up/dim-down, soft start, light scenes)
- control via touch-screen (built-in a wall) = complete information
- control via any remote controller (e.g. of your TV or stereo)
- voice control (Sophy unit, responds to your voice commands)
- temperature regulation according to pre-set programs – in each
room individually
- possibility to control by mobile phone, computer and Internet
Automatization
- function is done automatically on the basis of set value (time, temperature,
light intensity, movement of people, wind strength...)
- it is possible to execute several functions on the basis of one command or
event (e.g. when it is dark - INELS rolls shutters down, switches lights on,
increases room temperature and switches TV on, and many others ...)
- arrival/departure functions: after a code is entered (or a card reading) to a
keyboard, system automatically sets electrical appliances according to the
identified user.
Supervision
- system informs you about selected event/events by SMS text message
- anywhere you are and where you can get internet access, you can connect
to your house and supervise or change its state
- integrated security system can be connected to a security agency
Security
- alarm with extended functions is a part of the system
- system is equipped by a keyboard which can be controlled by a code
or by an access card
- all settings and accesses are subjects of passwords in several levels
- protection of a house in case of bad weather (shutters in strong winds or
storm), unexpected events (irregularities in power supply, overload),
natural disasters (sensor for flooding, smoke sensor)
- bio-installation: disconnection of unused electric circuit (e.g. socket
outlets in bedroom while sleeping)
- setting ideal conditions for your children’s sleep (gradual dimming off ,
pleasant temperature, motion monitoring = baby-sitting)
- touchable parts of sensors are supplied by a safe voltage 24V DC
Savings
- regulation of heating / cooling
- time or time-limited switching
- light regulation (possible energy savings up to 10% )
- dependant switching (e.g. when it is dark, for desired temperature etc.)
- blocking of selected appliances in case of high meter tariff
- elimination of unwillingly switched appliances (e.g. when there is no
motion – light switches off)
Design
- modern design of the switches and sockets, thermostat, voice activity
detectors – optional designes of Elegant or LOGUS90
- variety to combine different colours also in multiframe versions
- touch panel screen – unique solution of elegant wireless home
automation
Time for installation
- considerably lower thanks to bus installation (only 2 control wires)
- units are installed and later programmed
Flexibility of changes and extensions
- in future it is possible to add or change units easily
- functions can be changed by PC, also remotely through Internet
Available features for disabled people
- voice and remote control
- sound messages for blind (unit Sophy speaks pre-recorded messages)
- several actions can be done by one command
- control by computer from one spot
10 reasons to choose the iNELS BUS System
1) Ideal solution for new buildings
2) Reduction in energy use up to 30 %
3) Two-wire bus
4) Electro-installation can be extended
5) There is a possibility to change the way of controlling
6) Remote control through Smart phone, tablets or laptop
7) Effective solution - can be combined with a security system
8) Regulation depending on the weather
9) Logical and central functions (e.g. exit button)
10) Media under control (can be also controlled via TV)
