Meeting Worldwide Regulatory Requirements for the Analysis of Trace Metals in Drinking

Water Using the Agilent 7500c ICP-MS

Application

Environmental

Authors

Steven Wilbur, Emmett Soffey

Agilent Technologies, Inc.

2850 Centerville Road

Wilmington, DE 19808-1610

USA these guidelines, as they pertain to trace metals, vary somewhat in their lists of regulated metals and concentrations, they are fundamentally similar. They all require accurate, precise measurement of multiple toxic metals in drinking waters at the lowest practical limits of quantification. This application note will demonstrate that the sensitivity, accuracy, and precision requirements for the analysis of trace metals in drinking water worldwide can be met by a single, robust technique using the Agilent 7500c ICP-MS system with

Octopole Reaction System (ORS) technology.

Abstract

The Agilent 7500c ICP-MS can be used to meet the regulatory requirements for trace metals in drinking water around the world. Elements previously relegated to other techniques, such as GFAA or ICP-OES due to very high or low concentrations or the presence of interferences, can now be measured in a single analysis.

Introduction

Virtually all developed countries have adopted programs and regulations to monitor and maintain the quality of public water systems. In the US, water quality is regulated by the United States

Environmental Protection Agency (USEPA) as mandated by the Safe Drinking Water Act of 1974.

In the European Union, drinking water is regulated by the Council Directive 98/83/EC of 3, November,

1998 on the Quality of Water Intended for Human

Consumption. In Japan, quality of drinking water is regulated by the Japan Water Supply Act, dating from 1957, and most recently updated in 2001.

Most of the rest of the world’s developed countries have adopted drinking water quality standards based on World Health Organization (WHO)

Standards, Guidelines for Drinking Water Quality,

1996, 1998, or on the USEPA standards. While

US Regulations

In the US, the quality of public drinking water is safeguarded by the provisions of the Safe Drinking

Water Act of 1974.

The Safe Drinking Water Act (SDWA) was originally passed by Congress to protect public health by regulating the nation’s public drinking water supply. The law, amended in 1986 and 1996, requires many actions to protect drinking water and its sources in rivers, lakes, reservoirs, springs, and ground water wells (SDWA does not regulate private wells, which serve fewer than

25 individuals). SDWA authorizes the USEPA to set primary national health-based standards for drinking water to protect against both naturallyoccurring and man-made contaminants that may be found in drinking water. These primary national drinking water standards include maximum contaminant level goals (MCLGs), levels below which there is no known or expected health risk. From these MCLG values, EPA determines maximum contaminant levels (MCLs), which are

2 enforceable levels that may not be exceeded. The

MCLs are set as closely as possible to the MCLGs and are based on best available current technology and economic feasibility. These limits are reviewed and updated periodically as new information becomes available and technology improves.

consuming preconcentration, which was required to meet the required detection limits using

ICP-OES.

Japanese Regulations

Drinking water quality in Japan is regulated by the

Japan Water Supply Act, which was first promulgated in 1957 with the Quality Standard for Drinking Water set the following year. This standard currently regulates the drinking water quality of more than 97% of the population. The Quality Standard sets maximum allowable concentrations

(MAC) for 17 metals. It also requires that quantification limits be set at 1/10 of the MAC to assure accurate measurements at trace levels. Because of this, in 2001 the Drinking Water Test Method was revised and expanded to include the use of ICP-MS for 14 of the 17 metals. The approval of the use of

ICP-MS has eliminated the need for costly and time

European Union Regulations

Currently, water quality in the European Union (EU) is regulated by Council Directive 80/778/EEC. This directive applies to all waters intended for human consumption, except natural mineral waters or waters which are medicinal products. As of

December 2003, Directive 80/778/EEC will be repealed and replaced by Council Directive

98/83/EC Directive on the Quality of Water

Intended for Human Consumption, which came into force on December 25, 1998. The standards are based largely on recommendations by the

WHO 1 . Member states of the European Community, while they must comply fully, are permitted to implement regulation and enforcement locally. As a result, no single regulation exists for the analysis of trace metals in water throughout Europe.

1 World Health Organization Guidelines and International Standards for

Drinking-Water Quality, 1998

Table 1.

Drinking Water Standards for Trace Metal Content from WHO Recommendations, EU Regulations, Japan Drinking Water

Regulations and USEPA.

Analyte

WHO

Standard

(mg/L)

EC Directive

98/83/EC

(mg/L)

Japan

Drinking USEPA

Water Primary

Standard

(mg/L)

MCL

(mg/L)

Agilent

7500c

MDLs***

(mg/L)

Aluminum (Al)

Antimony (Sb)

Arsenic (As)

Barium (Ba)

Nickel (Ni)

Selenium (Se)

Silver (Ag)

Sodium (Na)

0.005**

0.01**

0.7

Beryllium (Be)

Boron (B)

Cadmium (Cd)

Chromium (Cr)

0.5**

0.003

0.05**

2** Copper (Cu)

Iron (Fe)

Lead (Pb)

Manganese (Mn)

0.01

0.5**

Mercury (Hg) 0.001

Molybdenum(Mo) 0.07

0.02**

0.01

Thallium (Tl)

Uranium (U)

Zinc (Zn)

0.002**

0.2

.005

.01

1

0.005

0.05

2

0.2

.01

.05

0.001

0.02

0.01

200

0.2

0.002

0.01

1.0

0.01

1.0

0.3

0.05

0.05

0.0005

0.01

0.01

200

0.002

0.02-0.2*

0.006

0.01

2

0.004

0.005

0.1

1.3

0.3*

0.015

0.05*

0.002

0.05

0.01*

0.002

0.030

5.0*

0.000054

0.000035

0.000052

0.000027

0.000028

*Secondary Standard, **Provisional Guideline Value, ***MDLs Calculated as Three Sigma of 10 Replicates of Low Standard, as Described in this Work. MDLs Reported in mg/L to Match Regulatory Requirements.

0.000025

0.000019

0.000023

0.00125

0.000017

0.000020

0.000005

0.000030

0.000024

0.000047

0.000027

0.0276

0.000021

0.000015

0.000101

Table 1 includes the trace metals that are regulated by various worldwide regulatory and advisory agencies. ICP-MS is the only analytical technique capable of meeting all the required detection limits for all the regulated trace metals.

Therefore, while not mandated as the only acceptable technique for most regulations, ICP-MS is becoming the instrument of choice for trace metals analysis in water worldwide.

While the details of QA/QC criteria and reporting requirements vary significantly from jurisdiction to jurisdiction, Table 1 shows that the actual detection limit requirements are very similar. In addition, the fundamental goals of the QA/QC requirements in all jurisdictions are the same.

This is to insure that the reported values for all samples meet commonly accepted guidelines for accuracy and precision. Typically, these guidelines are met through the analysis of periodic QC samples inserted into the sample queue. Such QC samples should include: a check on the accuracy of the initial instrument calibration; a control sample of known concentration similar to that of the analytes in a similar matrix; a sample designed to test the ability of the system to eliminate interferences as false positives; a sample designed to detect sample carryover or memory problems; and periodic calibration check samples to check for instrument drift. If samples are to be analyzed outside the calibration range of the analytical method, then a linear range check sample must also be analyzed. It is outside the scope of this application note to detail the specific QA/QC requirements for each regulation where they exist at all. Instead, a general QA/QC protocol will be outlined which will demonstrate the ability of the Agilent 7500c to meet generally accepted guidelines while easily meeting the required reporting limits for drinking water monitoring worldwide. Simple modifications to this procedure can be implemented to insure strict compliance with detailed local requirements.

Advantages to the Use of the ORS for Drinking Water

Analysis

Generally, drinking water is not considered a particularly difficult matrix for analysis by ICP-MS.

There are, however, a few significant challenges.

These challenges are due to the very low desired reporting limits for several elements (Table 1), as well as the possibly high concentrations for others, such as Ca and Na. This combination of very low and very high analyte concentrations presents a challenge that no other analytical technique can overcome. In order to measure all elements simultaneously, the ICP-MS must be able to accurately measure mercury at 0.05 ppb or less and Na or Ca as high as 1000s of ppm. In addition, the ICP-MS must be able to eliminate common interferences on

Fe, As, Se, Cu, V, and other elements which originate in the plasma and interface region. If unmanaged, these interferences make trace level analysis of the above elements difficult or impossible in many water samples.

The ORS serves two purposes. First, it uses collision/reaction cell technology to virtually eliminate polyatomic interferences on most elements. This allows the analyst to select the most abundant isotope of each analyte for analysis and avoid the use of mathematical correction factors. The result is sub-ppb detection limits for virtually all elements of interest. Second, it allows the analyst to use passive collisions in the ORS to reduce the ion current for high concentration, low-mass elements such as
