Por t a b l e & Tr a n s por table
Monitors
CROSSFIRE
Attachment Lock
Safe-Tak 1250 Portable Base with Safe Tak Valve
•S
afe-Tak “flow safety valve” automatically reduces flow to monitor
if it becomes unstable.
Locking button is interlocked
under pressure and can not be
depressed once the water is flowing,
assuring the top portion can not be
accidentally released.
Portable Deck/Gun Monitor
TFT’s Safest, Most Versatile
Master Stream Appliance Ever!
XFH
•C
omes with either two clappered
swivel inlets or one single
full-time swivel inlet.
Portable Stow-A-Way 800 Portable Base Without Safe-Tak Valve
With a flow rating of 1250 gpm (4500 l/min) in portable operation, the
Crossfire monitor integrates TFT’s exclusive Safe-Tak safety shutoff system
to prevent unintentional movement. The monitor’s compact and lightweight
design includes stainless steel spring legs with carbide tips for maximum
stability, and a visual attachment indicator for additional security.
Safe-Tak Valve
• Comes with either two clappered swivel
inlets or one single full-time
swivel inlet.
Safe-Tak “Flow Safety Valve”
automatically reduces flow should
the monitor lose contact with the
ground surface.
• Includes safety tie-down strap with
attached storage cap.
XFL
Attachment lock
Rotational Lock Lever
Rotational Lock Lever
1250 Stow-A-Way Portable Base Without Safe-Tak Valve
• Comes with single full-time swivel inlet.
Lever-action lock is faster and more
positive than knobs which depend on
metal-on-metal friction. Locked position
is easily identified.
Patented Safe-Tak Valve
•H
igh volume/low loss valve meets NFPA
slow close requirements.
XFAN
Automatic Drain
(All portable bases fold easily and store in an optional stainless mounting bracket.)
When monitor pressure drops below
5 psi, the automatic drain opens,
allowing trapped water or hose lines
to empty. Problems with freezing or
residual pressure after the monitor
is shut off are solved.
Automatic Drain
Stainless Steel Legs
& Carbide Tips
Stainless legs and carbide tips
Replaceable tungsten carbide spike tips
and stainless steel legs provide
long-lasting stability and support.
2
www.tft.com
800-348-2686
219-548-4000
3
BLITZFIRE HE
Blitzfire Portable Monitor Offers
Safe Initial Attack With Limited Staff
Portable High Elevation Monitor
With a flow rating up to 500 gpm (2000 l/min), the TFT Blitzfire Portable
Monitor integrates an exclusive safety shutoff system that prevents
unintentional movement during critical fire-ground operations.
The monitor’s compact and lightweight design offers a low attack angle and
exclusive slide valve for complete nozzle-man flow control.
Blitzfire HE is the Same as TFT’s
Blitzfire, but With More ALTITUDE
While both the traditional Blitzfire and the Blitzfire HE (High Elevation) include
the low 10 degree down angle that’s perfect for directing a fire stream into any
door or window opening during an initial attack, the standard Blitzfire series
offers a 46 degree elevation capability, while the HE version provides an even
higher 86 degree up elevation angle.
The Blitzfire portable monitor fills the need of safely providing maximum flow with
the limited manpower resources that face many departments today. If the monitor’s
Safe-Tak mechanism is tripped by instability, firefighters can quickly and easily reset
the flow by opening the valve to any of its six detent flow positions.
Swiveling inlet for stability above
and below grade.
The much higher elevation can offer tactical advantages, such as the ability to
place a high-volume stream directly into an overhead, or reaching that pipe rack
system that’s directly in front of you that is somehow just out of your
reach. Whatever your needs, TFT has you covered.
BLITZFIRE
Portable Monitor
Unique Double Ball Pivot Design
Slide Valve Design for maximum
stream quality when gated.
TFT exclusive
Integrated Safety
Shut-Off Valve.
Low attack angle
improves operational
performance.
Wide stance with carbide tipped
spikes provides maximum stability.
4
www.tft.com
800-348-2686
219-548-4000
5
BLITZFIRE OSC
BLITZFIRE HE OSC
Portable Oscillating Monitor
Portable High Elevation Oscillating Monitor
The Blitzfire OSC is a highly maneuverable initial attack monitor with TFT’s exclusive nozzle
oscillation feature. The Blitzfire OSC’s low elevation angle makes it suitable for aggressive
interior attack or exterior defensive operations when cooling or exposure protection is necessary.
It can go anywhere a handline goes, while delivering far more water with limited staff.
Oscillating Head
and Controls
If the Blitzfire OSC starts to slide or lift, the SAFETY SHUT OFF VALVE automatically shuts off the
flow of water. This safety feature reduces the risk of injury from an out-of-control appliance.
The shut-off slows near stroke end to eliminate potential water hammer.
The Blitzfire OSC’s unique
water turbine design
drives the oscillating
unit in a selectable
20, 30, or 40-degree
sweeping motion.
With a flow range up to 500 gpm (2000 lpm), the Blitzfire HE OSC portable
monitor features low loss pivoting inlets and outlets, as well as a manually
adjustable elevation from 10 degrees up to 86 degrees. The integrated water
driven oscillation mechanism sweeps in a selectable 20, 30, or 40-degree pattern
for maximum exposure coverage. The standard safety shut-off valve will shut off
if the monitor becomes unstable. Slow valve closure design diminishes potential
water hammer. With its turbulence free slide
valve and six detent valve positions, the Blitzfire
offers total nozzle operator flow control.
Available with either Standard,
Low-Pressure, or Dual-Pressure
Automatic Nozzle, Fixed
Gallonage Nozzle, or Stacked Tips.
Nozzles
Choose the nozzle that fits your needs. TFT’s
Max-Force and Max-Matic Automatics and MaxFlow Fixed Gallonage nozzles offer flow ranges
from 100 gpm up to 500 gpm (400/2000 lpm),
and can be ordered with operating pressures of
100/55 (7 bar/4 bar), 100, 80, or 50 psi
(7 bar, 6 bar, or 3 bar).
An anchor strap is included
for safe operation.
6
A unique rear inlet provides
additional stability.
www.tft.com
TFT’s lightweight tips are hardcoat anodized, and have
pressure/flow charts laser engraved on each tip, with tip
sizes of 1.5”, 1.25”, or 1.0” (38, 32, and 25mm).
800-348-2686
219-548-4000
7
BLITZFORCE
Oscillating
Option
Portable Monitor
High Flow, Low Loss Waterway
Maximum Stability in Harsh Conditions
Full flow 2” (51mm) waterway provides
500 gpm (2000 l/min) initial attack
flows with only 9 psi loss. Features
an integral stream shaper for
superior reach and penetration
performance.
High strength folding aluminum alloy legs include
replaceable carbide tip spikes and integrated nylon
kneepads for maximum stability during operation.
Permanent laser engraved operational
instructions, reflective labeling, unique
product serialization, choice of fixed
gallonage nozzle or stacked tips, and a
stainless apparatus mounting bracket.
BlitzForce Lightweight Portable
Attack Monitor
Small, Lightweight and Compact Design
Weighs just 14.5 lbs (6.6 kg) and stores securely
for a rapid deployment in a space of only
19” by 9” x 12” (48 x 23 by 30 cm).
The BlitzForce is one of TFT’s innovative, lightweight, and highly
versatile portable attack monitors. Rated up to 500 gpm, (2,000 l/min),
BlitzForce integrates a low-loss waterway with positive locking valve
control, and a corrosion resistant anodized and powder coated finish.
An exclusive high strength tie-down strap and carbide tipped folding
legs offer stability during operations.
With an integral stream shaper for superior stream performance,
the BlitzForce delivers a 20-degree side-to-side (40 degree total)
and a 20 to 60 degree up and down range of stream motion. A fiveyear warranty, stainless steel apparatus mounting bracket, and
your choice of combination nozzle or stacked tips are standard.
8
BlitzForce Package Includes:
The BlitzForce’s quickly deployed,
high strength tie-down strap prevents
unintentional monitor movement.
www.tft.com
800-348-2686
219-548-4000
Oscillating Option
Offers Extended
Coverage
The optional BlitzForce oscillating
mechanism can be used for exposure
protection, cooling, or in any other
situation where it is desirable to have
a monitor sweep back and forth.
The horizontal sweep can be set for
a 20, 30 or 40 degree sweep. The
integrated oscillating mechanism can be
uncoupled, and the water stream
can be aimed manually.
9
HEMISPHERE
Transportable Monitor
Hemisphere Mounting Clamps
Within minutes, one person can securely attach Hemisphere clamps to I-Beams, Railings, Tank Lips,
Trees/Poles/Bollards or even 2 inch hitches and establish 500 gpm (2000 l/min) water flow
coverage on the fireground or preplanned locations that ground monitors could never cover.
500 GPM Anywhere, Anytime
TFT’s revolutionary Hemisphere transportable initial attack monitor is not limited
to ground or flat surface use, but instead securely and easily attaches to nearly
any stationary component, allowing 500 gpm (2000 l/min) flow in virtually ANY
direction within a 360 degree range. Patent pending safety features prevent
removing the monitor from its base during use, while its easy to use monitor base
can be safely and quickly attached to a beam, a railing, a tank lip, a pole,
a concrete barrier, or even a common trailer hitch.
I-BEAM CLAMP
MODEL HPM-A
I-BEAM CLAMP DOUBLES AS 2 INCH HITCH MOUNT
Built-in stream
straightener.
Monitor and valve bodies are
hardcoat anodized aluminum
inside and out with a blue
TFT powder-coat finish.
SCAFFOLDING CLAMP
MODEL HPM-G
Adjustable double ball
swivel enables water or
foam discharge anywhere
in a hemispherical range.
Integrated ¼ turn
ball valve features
bail handle that locks
into closed position
to prevent accidental
discharge.
FITS INDUSTRIAL RAILINGS AND OSHA SCAFFOLDING
TANK-LIP CLAMP
MODEL HPM-F
Hand crank for 360° rotation
of main waterway.
10
Rotation release lever (separate
from the release pin) allows monitor
to be rotated around base without
releasing monitor,
www.tft.com
CLAMPS SECURELY TO PETROCHEMICAL TANK LIPS
800-348-2686
219-548-4000
FLEX CLAMP
MODEL HPM-H
CLAMPS QUICKLY TO TREE, POLE, BOLLARD
11
CROSSFIRE
SERIES
NOZZLES
CROSSFIRE ACCEPTS THE WIDEST RANGE OF FIREFIGHTING NOZZLES
Master Stream nozzles for the Crossfire portable
and apparatus mounted monitor series are
designed to provide maximum stream performance
under demanding firefighting conditions. All TFT
Master Stream nozzles deliver outstanding reach
and penetration, as well as offering
a wide protective fog pattern.
BLITZFIRE &
HEMISPHERE
SERIES
NOZZLES
MAX SERIES NOZZLES PROVIDE MAXIMUM
PERFORMANCE WITH TRANSPORTABLE MONITORS
For rapid advancement and attack during firefighting operations, lightweight portable
monitors require the performance of the Max series of nozzles to maximize fire stream
performance under the harshest fire ground conditions.
• With a choice of fixed, selectable gallonage, or
user selected dual-pressure automatic nozzle
designs, models are available with flow ranges
up to 500 gpm (2000 l/min).
• With a choice of fixed, selectable gallonage, or user selected
pressure automatic nozzle designs, models are available
with flow ranges up to 1250 gpm (4800 l/min) with many
offering flush without shutting down.
M-FA1250-NJ
Automatic with Flush
300-1250 gpm (1100-4800 l/min)
MD12A 2.5”NH (65MM)
Max-Force Dual Pressure Automatic Tip
100-500 gpm (400-2000 l/min)
Twist of front knob switches from Standard 100 PSI
(7 bar) to low pressure mode of 55 psi (4 bar)
BLITZFORCE NOZZLES DESIGNED FOR MAXIMUM SIMPLICITY
When the lightest and most compact portable monitor is required, the BlitzForce and a
choice of 500 gpm (2000 l/min) combination
nozzle or compact stack smooth bore tips
is a perfect lightweight high performance
LOW AND MULTI-EXPANSION
LOWATTACHMENTS
AND MULTI-EXPANSION
FOAM
FOAM ATTACHMENTS
• Providing superior stream quality in a lightweight,
low cost Master Stream nozzle, the ZN series and
its all metal design delivers superior quality
and rugged durability.
BLITZFORCE
SERIES
NOZZLES
12
MST-3NJ
3 Stacked Tips
1.5, 1.25, and 1 in
(38, 32, and 25 mm)
• Fixed fog tooth design delivers a wide protective
fog pattern, or hard hitting straight stream and
easily accepts a foam aspiration attachment.
• Specialty nozzles, such as self educting foam nozzles and
stacked smooth bore tips, are available in a range of sizes
to meet any application.
• Optional stacked smooth bore tips offer three sizes
with laser engraved flow pressure charts to assure
target firefighting flows.
Lightweight, compact and easily attached, TFT’s low and multiexpansion foam attachments are the perfect addition to any Master
Stream nozzle choice. Maximizing finished foam production
while maintaining critical reach, these attachments enhance
any portable monitor’s capabilities.
• Developed for low to medium expansion of AFFF,
AFFF-AR, and Class A foam concentrates, with
the foam attachment in place, the pattern can be
quickly adjusted for maximum reach
or maximum foam aspiration.
ZN12
Fixed Gallonage Nozzle
500 [email protected] psi
(2000 l/min @ 7 bar)
www.tft.com
LOW AND MULTI EXPANSION FOAM ATTACHMENTS
800-348-2686
219-548-4000
FJ-MX-MD
FoamJet-MX multiexpansion foam
attachment
13
Task Force Tips’ Sales, Service
and Technical Support Teams
Stand Ready to Assist You.
TFT professionals are available every hour of every day to assist and support
your product specification and operational needs. Providing product demonstration
and operational awareness of the entire fire suppression and water supply product line,
our global team can help you solve any operational challenge.
USA & Canada Sales
Support and Resources
[email protected] • 800-348-2686
• www.tft.com and newforce.tft.com
• 24 hour live technical service and support
International Sales
• Plant tours, water flow training and education
[email protected] • 219-548-4000
• Minimum five year warranty on all products
• 24 hour turn-around service program (Domestic U.S. only.)
Service & Technical
• On-line catalog and product search
[email protected] • 800-348-2686
• O
n-line technical library, including operational
and service manuals
• Product serialization with on-line history look-up
• On-line product and service videos
Worldwide Approval and Certifications
As well as being a Registered Firm to ISO 9001:2008 by Underwriter’s
Laboratory, Task Force Tips maintains product certifications and
approvals from agencies around the world. All certifications are available
for review on the TFT website at www.tft.com/literature, and include
approvals of manual and electronic models used in hazardous locations
as well as country specific requirements. All products are designed,
developed and manufactured in the United States of America
at our Valparaiso, Indiana world headquarters.
Made In The USA
ISO
TASK FORCE TIPS, INC
14
www.tft.com
800-348-2686
FM
APPROVED
219-548-4000
15
3701 Innovation Way • Valparaiso, IN 46383-9327, USA
USA & Canada 800.348.2686 • 219.462.6161 • Fax 219.464.7155
International +1.219.548.4000 • Fax +1.219.548.7155
www.tft.com • newforce.tft.com
facebook.com/taskforcetips
©Copyright Task Force Tips, Inc. 2016
youtube.com/taskforcetips
search task force tips on iTunes
twitter.com/taskforcetips
LOT-049 MARCH 11, 2016 Rev00
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
