Control Circuit Transformers
Transition Guide
Primary Voltage 480 V and below
Introduction
New, New,
New!
A new generation of control circuit transformers
The T4.. Series (primary voltage 480V and below) of control
circuit transformers from ABB is transitioning to a new
generation design. The new line of transformers has an
improved insulation class rating (130ºC with average
winding temperature rise of 80ºC). The new product line will
be the X4.. series.
Beginning July 1, 2008, the new generation X4 will replace
the T4 Series of transformers. This transition guide will help
you substitute the old generation transformers with the new
family of product.
1
Control Circuit Transformers – Transition Guide
New Part Numbers
Primary voltage: 460/230/208V, 480/240V, 440/220/200V
Secondary voltage: 115/24V, 120/25V, 110/23V
NEW P/N
OLD P/N
VA Rating
Output Amps
List Price
X4045SF1
T4045SF1
45
1.90 / 0.39
$ 72.70
X4050PSF1
T4050PSF1
50
2.08 / 0.44
$ 83.88
X4075PSF1
T4075PSF1
75
3.13 / 0.65
$ 93.20
X4100PSF1
T4100PSF1
100
4.17 / 0.87
$ 102.52
X4150PSF1
T4150PSF1
150
6.25 / 1.30
$ 109.98
X4200PSF1
T4200PSF1
200
8.33 / 1.74
$ 130.48
X4250PSF1
T4250PSF1
250
10.42 / 2.17
$ 145.39
X4300PSF1
T4300PSF1
300
12.50 / 2.61
$ 158.44
X4350PSF1
T4350PSF1
350
14.58 / 3.04
$ 171.49
X4500PSF1
T4500PSF1
500
20.84 / 4.35
$ 229.27
X4750PSF1
T4750PSF1
750
6.52
$ 270.28
Discount schedule AT
2
Control Circuit Transformers – Transition Guide
New Dimensions
B
E
C
A
D
Top View
A
Side View
B
D
C
New P/N
in
mm
in
mm
in
E
Mounting slots
mm
in
mm
in
mm
X4045SF1
4 1/2
115
3
76
3 1/8
80
2 7/8
72
2 1/2
64
X4050PSF1
4 1/2
115
3
76
4
102
2 7/8
72
2 1/2
64
X4075PSF1
4 1/2
114
3 3/8
86
4 3/8
110
2 3/4
71
2 3/4
71
X4100PSF1
4 1/2
115
3 3/4
95
4 5/8
118
3
76
3 1/8
80
X4150PSF1
5
128
3 3/4
95
4 5/8
118
3 1/8
81
3 1/8
80
X4200PSF1
4 3/8
111
4 1/2
114
5 1/4
134
3
76
3 3/4
95
X4250PSF1
4 3/4
120
4 1/2
114
5 1/4
134
3
76
3 3/4
95
X4300PSF1
6 1/8
155
5 1/4
133
6
151
3 7/8
98
4 3/8
111
X4350PSF1
6 1/8
155
5 1/4
133
6
151
3 7/8
98
4 3/8
111
X4500PSF1
7 1/8
181
5 1/4
133
5 1/8
131
5.37
136
4 3/8
111
3
in
mm
3/16 x 7/16
5 x 12
5/16 x 1 1/16
8 x 27
Control Circuit Transformers – Transition Guide
New vs. Old Comparison Drawings
Wide range
of standard
product:
45VA - 750VA
4
Control Circuit Transformers – Transition Guide
New vs. Old Comparison Drawings
Improved
insullation
rating (130ºC)
to meet a
wider range
of industrial
applications
5
Control Circuit Transformers – Transition Guide
New vs. Old Comparison Drawings
No change
in VA
ratings
and output
amps
6
Control Circuit Transformers – Transition Guide
New vs. Old Comparison Drawings
Copper
magnet wire
provides
the highest
quality and
efficency in
operation
7
Control Circuit Transformers – Transition Guide
New Links & Resources
More
information
available
online
CAD Drawings: Outline drawings of the new
transformer products are available for download from
the ABB website. Please visit www.abb-control.com,
then select “CAD Library” under the Product Information
heading, or you may click here to download. Print Catalog: A revised LV023 including the new
Transformers section will be available 3rd Quarter 2008.
Publication LV120
No. 1SXU 1SXU114120L0201
Printed in USA, April, 2008
Electronic Catalog: A downloadable version of the
revised catalog will be made available after July 1,
2008. Please visit www.abb-control.com and select
“Catalog Index” under the Literature Resources heading.
ABB Inc.
1206 Hatton Road
ichita Falls, TX 76302
Telephone 888-385-1221; 940-397-7000
Fax 940-397-7085
http://www.abb-control.com
