Stockham Iron Valves

Setting The Standard In Service

®

Setting the Standard in Service

The Stockham Pledge

Stockham is committed to setting the standard in quality service to the Commercial Construction industry.

Our pledge to our customers is:

• A friendly voice every time you call

• Quick response to your quotes and questions

• On-time delivery

• Accurate shipments

3

Iron Valves

4

General Information

.................................................................................................................................5-8

Globe and Angle Valves

Class 125 ................................................................................................................................9-10, 34

Class 250 ....................................................................................................................................11-13

Class 300 ......................................................................................................................................... 14

Gate Valves

Class 125 ...................................................................................................................15-20, 23, 35-36

Class 150 ......................................................................................................................................... 21

Class 250 ....................................................................................................................................24-25

Swing Check Valves

Class 125 ..............................................................................................................................26-29, 37

Class 250 ......................................................................................................................................... 30

Class 300 ......................................................................................................................................... 31

Wafer Check Valves

200 CWP ......................................................................................................................................... 32

Class 125 ......................................................................................................................................... 33

International Iron Valves

Class 125 ....................................................................................................................................34-37

Malleable Valves

Globe ............................................................................................................................................... 14

Gate ............................................................................................................................................21-23

Check ............................................................................................................................................... 31

Stop Check Valves

Y-Pattern .......................................................................................................................................... 12

Angle Pattern ................................................................................................................................... 13

Technical Data

.......................................................................................................................................38-40

Figure Number Index

IRON VALVES

FIG. NO. PAGE

F-532 .................................. 11

F-540 .................................. 12

F-541 .................................. 13

F-661 .................................. 24

F-667 .................................. 25

F-947 .................................. 30

G-512 .................................... 9

G-512-I ............................... 34

G-515 .................................. 10

G-574 .................................. 14

G-608 .................................. 15

G-612 .................................. 16

G-612-I ............................... 35

G-613 .................................. 17

G-620 .................................. 18

IRON VALVES

FIG. NO. ........................ PAGE

G-623 .................................. 19

G-623-I ............................... 36

G-624 .................................. 20

G-675 .................................. 21

G-676 .................................. 23

G-679 .................................. 22

G-927 .................................. 26

G-931 .................................. 27

G-931-I ............................... 37

G-931 L & W ....................... 28

G-933 .................................. 29

G-975 .................................. 31

WG-961 .............................. 32

WG-970 .............................. 33

Iron Valves Cross Reference

BRONZE

GLOBE

Class 125

Class 300 SS Trim

GATE

Class 125 RS-Thread

Class 125 NRS-Thread

Class 125 RS-Solder

Class 125 NRS-Solder

Class 150 Union Bonnet

Class 300 SS Trim

CHECK

Class 125 Thread

Class 125 Solder

Class 300 Swing Check

For Commonly Used Valves

Stockham

B-16

B-74

B-66

B-100

B-103

B-108

B-104

B-120

B-145

B-319Y

B-309Y

B-375

B-321

NIBCO

T-211-B

T-276AP

T-275-B

T-111

T-113

S-111

S-113

T-134

T-174-SS

T-413-BY

S-413-B

T-473-B

T-433-B

Milwaukee

502

593A

572

148

105

149

115

1151

1184

509

1509

507

515

IRON

GATE

Class 125 NRS

Class 125 OS&Y

Class 250 OS&Y

GLOBE

Class 125

SWING CHECK

Class 125 Flanged

STOP CHECK

Class 250 Straight-way Y-Pattern

Class 250 Angle Y-Pattern

Stockham NIBCO

G-612

G-623

F-667

F-619

F-617-0

F-667-0

G-512

G-931

F-540

F-541

F-718-B

F-918-B

----

F-869-B

Milwaukee

F2882 A

F2885 A

F2894 A

F2981 A

F2974 A

-----

-----

Powell

1787

1793

1797

241

559

-----

-----

Walworth

W719F

W726F

W786F

W906F

W928F

----

----

5

Iron Valves

Stockham iron body valves are proven performers in mechanical systems of commercial buildings throughout

America. Chemical plants, steel mills, shipyards, refineries, pulp and paper mills, and utilities have also found that

Stockham iron body valves do the job better and longer for their many general services.

QUALITY MANAGEMENT

Stockham is committed to a philosophy of total quality management.

It begins with design, to comply with pertinent MSS and ASME

Standards. Continuous improvement are applied in a process to improve materials and services to meet or exceed customer needs.

DESIGN:

GATE VALVES-CLASSES 125 and 250

Stem—

All stems are designed for ample strength and are machined to function easily. Backseats are provided on OS&Y valves.

MATERIALS

The iron used as the basic valve material conforms to the chemical and physical requirements of the American Society of Testing and

Materials A-126 Class B for Cast Iron Valves.

Packing Gland Assembly—

Glands and gland flanges have a ball and socket joint which assures alignment. It provides for proper packing compression without binding against the stem.

Packing—

Non-Asbestos.

RATED WORKING PRESSURES

The pressure-temperature ratings of Stockham iron body valves in this catalog section are as follows:

Disc—

Strong, solid wedge discs have disc guides for precision seating with minimum friction against body seats.

Yoke and Bonnet—

One-piece yoke bonnets are utilized on 12" and smaller size OS&Y valves. Larger sizes have separate yokes and bonnets.

TEMPERATURE

°F

-20 to 100

150

200

225

250

275

300

325

350

375

400

425

450

500

600

650

PRESSURE (PSIG)

CLASS 125

CAST IRON

CLASS 250

CAST IRON

SIZES SIZES SIZES SIZES SIZES

2-12 14-24 30-36 2-12 14-24

200

200

190

180

175

170

165

155

150

145

140

130

125

150

150

135

130

125

120

110

105

100

150

150

115

100

85

65

50

500

500

460

440

415

395

375

355

335

315

290

270

250

300

300

280

270

260

250

240

230

220

210

200

Stuffing Box—

NRS valves have stuffing boxes assembled to bonnets to accommodate the packing gland assembly.

Seat Ring—

Buttress-type seat rings are bottom-seated with accurately machined faces to match disc faces.

Handwheel or Operating Nut—

Handwheels have large diameters for good leverage. Operating nuts, 2" square may be furnished on any NRS valve if specified.

The temperature shown for a corresponding pressure rating is the temperature of the pressure containing shell of the component. In general, this temperature is the same as that of the contained fluid. Composition disc valves are excluded from these ratings.

6

Iron Valves

Yoke Bushing—

Yoke bushings on OS&Y valves have Acme threads for stem engagement, and handwheels fit snugly over bushings.

Handwheels are securely locked to yoke bushings with locknuts.

Bolted yoke cap secures the yoke bushing to yoke.

Handwheel—

leverage.

Handwheels have large diameters for ample

Yoke Bushing—

Accurate Acme threads engage stem threads. Set screws fasten yoke bushings to yoke.

Body—

Body sections are evenly distributed for maximum strength.

Dimensions and drilling of end flanges of cast iron valves conform to the ASME Standard B16.1 for Classes 125 and 250 Cast Iron Flanges.

Face-to-face dimensions comply with ASME Standard B16.10.

Body—

Bodies are designed with uniform sections evenly distributed for maximum strength. Dimensions and drilling of end flanges on flanged valves conform to the ASME Standard B16.1 for Classes 125 and 250 Cast Iron Flanges. Face-to-face dimensions comply with the

ASME Standard B16.10.

DESIGN:

GLOBE AND ANGLE VALVES-OUTSIDE SCREW AND

YOKE-CLASSES 125 and 250 DESIGN:

SWING CHECK VALVES-CLASSES 125 and 250

Stem—

Stems are machined with Acme threads which fully engage the yoke bushing threads at all times.

Cap

—Caps are bolted to bodies.

Packing Gland Assembly—

Glands and gland flanges have a ball and socket joint which assures alignment and proper packing compression.

Hinge—

Hinges are precisely drilled for assembly with discs.

Hinge Pin—

Pins are located by side plugs screwed into bodies.

Packing—

Non-Asbestos.

Backseat Bushing—

Bushings are threaded into bonnets, providing beveled seats for backseating on stem shoulders.

Disc—

Disc faces are accurately machined for tight seal with seat rings.

Seat Ring—

Buttress design of renewable seat rings provides bottom seating and good strength.

Disc—

Bronze discs are furnished in Class 125 and 250 globe and angle valves, which are regrindable. Disc nuts thread into disc. The

Class 250 nonreturn stop-check valve conforms to ASME boiler codes and utilizes a dashpot and piston design to cushion the disc action.

Body—

Dimensions and drilling of end flanges on flanged valves conform to ASME Standard B16.1 for Classes 125 and 250 Cast Iron

Flanges. Face-to-face dimensions comply with ASME B16.10.

Yoke Bonnet—

One-piece yoke bonnets are fastened to bodies with capscrews.

Seat Rings—

Seat rings are bottom seated and are readily renewable.

Figure G-931 L&W:

2"-12" come standard with an adjustable lever arm which can be orientated in any position in 15° increments. These valves can be installed in horizontal lines or in vertical lines with upward flow. 14"-

24" valves must be specified at the time of inquiry and order with the installation orientation for horizontal or vertical-upward flow.

7

Iron Valves

ACCESSORIES—

Stockham iron body valves may be furnished with motor operators, gearings, bypasses, floorstands, extension stems, lever and weight attachment or other accessories.

FINISH—

finish.

External cast iron parts are coated with a durable black

MARKING—

Numerals indicate the size and pressure class. Cast arrows indicate direction of flow on check, globe and angle valves.

TESTING AND INSPECTION—

Before shipment, each valve is individually tested under pressure for soundness of castings and tight closure to MSS Standards.

WEIGHTS AND DIMENSIONS—

Dimensions and weights shown in this catalog section are furnished for estimating purposes only and are subject to change without notice. It is our intent to maintain basic dimensional requirements of accepted standards.

Size

2

2

1

/

2

8

10

12

14

5

6

3

4

16

18

20

24

30

36

C

V

COEFFICIENTS*

(For estimating purposes only)

Gate

13351

16277

21562

28715

35760

52165

82563

119910

327

480

742

1314

2129

3175

5691

8970

Globe Swing Check

50

74

114

202

327

487

873

1376

5340

6511

8625

11486

14304

20866

131

192

297

526

852

1270

2276

3588

*Fully open. C

V

=GPM @ 1 PSI ∆P, 60°F Water

The above values for Swing Check Valves are correct only when the valve is fully open. This corresponds to a velocity of 6 ft./sec. for water flow.

8

Iron Globe Valves

Figure G-512

Class 125 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

14

13

12

20

24

17

6

29

15

2

28

27

30

25

26

21

4

1

Materials of Construction

No. Description Material

1 Body Hi-Str. Cast Iron

2 Bonnet

4 Disc

6 Body Seat Ring

*7 Disc Seat Ring

8 Stem

9 Yoke Bushing

12 Packing

Hi-Str. Cast Iron

2" - 6" Bronze

8" - 10" Cast Iron

Bronze

8" & 10" Bronze

Manganese Bronze

Manganese Bronze

Non-Asbestos Rings

13 Gland

14 Gland Flange

15 Handwheel

(2" - 4") Brass

(5" - 10") Bronze

Ductile

Ductile

17 Disc Stem Ring

20 Stem Hole Bushing

21 Locking Device

*22 Disc Guide Stem

Bronze

Brass

2" - 6" 18-8 SST Sheet

8" & 10" Brass

*23 Disc Guide Stem Pin

24 Bonnet Gasket

25 Bonnet Studs

26 Bonnet Stud Nuts

27 Gland Studs

28 Gland Stud Nuts

29 Handwheel Nut

30 Identification Plate

8" & 10" Brass

Non-Asbestos Sheet

Steel

Steel

Naval Brass

Brass

Steel - Phos. Coated

Aluminum

* Not shown

Industry Standards

Complies with MSS SP-85 Type 1

See page 6 for Pressure Temperature Ratings

C

M

B

Open

Valve

Size

10

8

6

5

4

3

2

2

1

2

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

B

Dimensions

C M WT

11.12 8.00 8.00 35

(282) (203) (203) (15)

11.50 8.00 8.50 40

(292) (203) (216) (18)

13.25 9.00 9.50 57

(337) (229) (241) (26)

15.50 10.00 11.50 95

(394) (254) (292) (43)

17.50 10.00 13.00 126

(445) (254) (330) (57)

19.50 12.00 14.00 176

(495) (305) (356) (80)

25.00 16.00 19.50 344

(635) (406) (495) (156)

30.50 18.00 24.50 570

(775) (457) (622) (259)

9

Iron Angle Valves

Figure G-515

Class 125 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged End

15

9

2

14

13

12

20

17

6

1

29

8

28

30

27

25

26

24

21

4

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc

6 Seat Ring

8 Stem

9 Yoke Bushing

12 Packing

13 Gland

14 Gland Flange

15 Handwheel

17 Disc Stem Ring

20 Stem Hole Bushing

21 Locking Device

24 Bonnet Gasket

25 Bonnet Studs

26 Bonnet Stud Nuts

27 Gland Studs

28 Gland Stud Nuts

29 Handwheel Nut

30 Identification Plate

Cast Iron

Bronze

Bronze

Manganese Bronze

Manganese Bronze

Non-Asbestos Rings

(2" - 4") Brass

(6") Bronze

Ductile

Ductile

Bronze

Brass

18-8 Stainless Steel

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Naval Brass

Brass

Carbon Steel

Aluminum

Industry Standards

Complies with MSS SP-85 Type 2

See page 6 for Pressure Temperature Ratings

P

K

AA Open

BB Closed

H

A

A

Size

4

3

6

2

2

1

2

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

A H K P AA BB WT

4.00 2.00

(102) (51)

4.25 2.50

(108) (64)

0.88 8.00 11.00 10.25 32

(22) (203) (279) (260) (15)

0.88 8.00 11.50 10.50 38

(22) (203) (292) (267) (17)

4.75 3.00

(121) (76)

1.00 9.00 12.75 11.75 54

(25) (229) (324) (299) (25)

5.75 4.00 1.12 10.00 15.00 13.75 88

(146) (102) (29) (254) (381) (349) (40)

7.00 6.00 1.25 12.00 19.50 17.75 158

(178) (152) (32) (305) (495) (451) (72)

10

Iron Globe Valves

Figure F-532

Class 250 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

8

14

13

12

29

15

9

2

28

30

27

25

26

24

17

21

4

7

23

6

22

1

Materials of Construction

No. Description Material

1 Body Hi-Str. Cast Iron

2 Bonnet

4 Disc

6 Body Seat Ring

7 Disc Seat Ring

8 Stem

9 Yoke Bushing

12 Packing

13 Gland

14 Gland Flange

15 Handwheel

17 Disc Stem Ring

21 Locking Device

22 Disc Guide Stem

23 Disc Guide Stem Pin

Hi-Str. Cast Iron

2" - 3" Bronze

4" - 8" Cast Iron

Bronze

Bronze

Manganese Bronze

Manganese Bronze

Non-Asbestos Rings

Bronze

2", 3" & 6" Steel

2½", 4", 5" & 8" Mall. Iron

Malleable Iron

Bronze

2" - 5" 18-8 SST Sheet

Steel

Steel

24 Gasket

25 Bonnet Studs

26 Bonnet Stud Nuts

27 Gland Studs

Non-Asbestos Sheet

Steel

Steel

Steel - Phos. Coated

28 Gland Stud Nuts

29 Handwheel Nut

Steel - Phos. Coated

Steel - Phos. Coated

30 Identification Plate Aluminum

*31 Disc - Disc Stem Ring Pin Steel

* Not Shown

C

M

B

Open

Industry Standards

Complies with MSS SP-85 Type 1

See page 6 for Pressure Temperature Ratings

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

6

4

8

2

2

1

2

3

B C M WT

13.75 9.00 10.50 62

(349) (229) (267) (28)

14.75 10.00 11.50 82

(375) (254) (292) (37)

16.50 10.00 12.50 118

(419) (254) (318) (54)

18.50 12.00 14.00 167

(470) (305) (356) (76)

23.25 16.00 17.50 320

(591) (406) (445) (145)

28.50 20.00 21.00 570

(724) (508) (533) (259)

11

Iron Stop Check Valves

Figure F-540

Class 250 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

6

15

10

9

8

11

12

21

17

7

16

19

5

4

3

2

J

1

15

11

L

Open

E

K

Features

A

• Valve designed for steam applications that operate between 100 and

250 psig.

• The Stop-Check feature of this valve requires a minimum of 50 psi pressure differential between piping system and boiler to operate properly.

• For installation between boilers suppling the same steam header, and positioned with pressure under the disc. Straightway is for horizontal or vertical line with upward flow. Angle valves are for "horizontaldownward" or "upward-horizontal" flow.

• These valves will perform the four following important functions:

1. Act as an automatic-non return valve applied as a containment device to prevent gross backflow of steam from main header to boiler in case the boiler fails.

2. Assist in cutting out boiler, when ceasing to fire. In this case, valve disc automatically closes to restrict backflow of steam to the boiler.

3. Assist in returning boiler after a shutdown.

4. Restricts backflow of steam from header into boiler which has been shut down and accidently opened. The check valve feature should not be relied upon for primary shut-off.

• Cylindrical shaped disc is the only pressure-actuated part, light in weight with ample guiding surface. It is specially designed to produce a maximum lift at minimum velocities. There are no wing guides to cause "spinning" with resultant rapid wear.

• Long throttling lip on disc retards flow when seating position is approached. Disc chattering is prevented and wiredrawing of seating surfaces is reduced.

• Flat Seats, accurately machined, facilitate true seating.

• Removable cast iron liner guides the disc throughout its full travel.

Being entirely independent of the body, it is not subject to distortion by expansion strains.

• Piston Ring 6" and larger adds to dashpot's ability to avoid rapid disc movements. Where pulsations are extremely severe, two rings can be installed.

• Dashpot is self-contained in the liner. It provides an effective cushion for the disc to prevent pipe line vibrations or hammering on the seat at low velocities or on pulsating loads.

• Flanges conform to ASME B16.1. Flanges have 1/16" raised face with concentric grooves.

• The body has integral bosses for drain connections. The bosses are tapped and plugged.

• Determining the proper valve size needed is important. The size of a stop check valve should be based on the boiler capacity and steam flow through the valve, rather than on the size of the boiler outlet or existing piping.

12

Materials of Construction

No. Description Material

1 Body Gray Cast Iron

2 Bonnet

3 Disc

4 Liner

2

1

/

2

Gray Cast Iron

", 3", 4", 5" Steam Bronze

6", 8", 10" Gray Cast Iron

2

1

/

2

", 3", 4", 5" Gray Cast Iron

6", 8", 10"

5 Body Seat Ring

Gray Cast Iron- Nickel Plated

Steam Bronze

6 Stem

7 Packing

Carbon Steel - Nickel Plated

Non-Asbestos Rings

8 Gland 2

1

/

2

", 3", 4", 5", 6" Brass

9 Gland Flange

8", 10" Brass

Ductile Iron

10 Yoke Bushing Manganese Bronze

11 Handwheel 2

1

/

2

", 3", 4", 5", 6" Ductile Iron

12 Handwheel Nut

8", 10"

**13 Piston Ring 6", 8", 10"

*14 Throttling Lip 6", 8", 10"

15 Drain Plug

16 Bonnet Studs

Bonnet Stud Nuts

17 Gland Studs

Brass

Carbon Steel

Chrome Vanadium Steel

Steam Bronze

Carbon Steel - Zinc Plated

Carbon Steel

Carbon Steel

Carbon Steel - Zinc Plated

Gland Stud Nuts

*18 Bonnet Gasket

19 Seat Ring Gasket

*20 Locking Pin 6", 8", 10"

Carbon Steel - Zinc Plated

Non-Asbestos Sheet

Non-Asbestos Sheet

Carbon Steel - Zinc Plated

21 ID Plate Aluminum

* Not Shown

** Sizes 5" and smaller made without Piston Ring

See pages 38 - 40 for sizing and other Technical Data

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

2

3

1

2

4

5

6

8

10

A E J K L WT

13.00 7.50 15.75 9.00 5.00 103

(330) (191) (400) (229) (127) (47)

14.75 8.25 19.75 10.00 7.25 140

(375) (210) (502) (254) (184) (64)

17.00 10.00 21.75 10.00 7.75 226

(432) (254) (552) (254) (197) (103)

19.00 11.00 25.75 14.00 10.50 307

(483) (279) (654) (356) (267) (139)

21.50 12.50 29.25 16.00 11.75 420

(546) (318) (743) (406) (298) (191)

26.00 15.00 36.75 20.00 16.25 737

(660) (381) (933) (508) (413) (335)

30.00 17.50 41.75 20.00 17.75 1250

(762) (445) (1,060) (508) (451) (568)

Iron Angle Stop Check Valves

Figure F-541

Class 250 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

15

10

9

8

11

12

1

21

17

7

19

5

16

3

4

2 J

Open

A

11

A

K

Features

E

• Valve designed for steam applications that operate between 100 and

250 psig.

• The Stop-Check feature of this valve requires a minimum of 50 psi pressure differential between piping system and boiler to operate properly.

• For installation between boilers suppling the same steam header, and positioned with pressure under the disc. Straightway is for horizontal or vertical line with upward flow. Angle valves are for "horizontaldownward" or "upward-horizontal" flow.

• These valves will perform the four following important functions:

1. Act as an automatic-non return valve applied as a containment device to prevent gross backflow of steam from main header to boiler in case the boiler fails.

2. Assist in cutting out boiler, when ceasing to fire. In this case, valve disc automatically closes to restrict backflow of steam to the boiler.

3. Assist in returning boiler after a shutdown.

4. Restricts backflow of steam from header into boiler which has been shut down and accidently opened. The check valve feature should not be relied upon for primary shut-off.

• Cylindrical shaped disc is the only pressure-actuated part, light in weight with ample guiding surface. It is specially designed to produce a maximum lift at minimum velocities. There are no wing guides to cause "spinning" with resultant rapid wear.

• Long throttling lip on disc retards flow when seating position is approached. Disc chattering is prevented and wiredrawing of seating surfaces is reduced.

• Flat Seats, accurately machined, facilitate true seating.

• Removable cast iron liner guides the disc throughout its full travel.

Being entirely independent of the body, it is not subject to distortion by expansion strains.

• Piston Ring 6" and larger adds to dashpot's ability to avoid rapid disc movements. Where pulsations are extremely severe, two rings can be installed.

• Dashpot is self-contained in the liner. It provides an effective cushion for the disc to prevent pipe line vibrations or hammering on the seat at low velocities or on pulsating loads.

• Flanges conform to ASME B16.1. Flanges have 1/16" raised face with concentric grooves.

• The body has integral bosses for drain connections. The bosses are tapped and plugged.

• Determining the proper valve size needed is important. The size of a stop check valve should be based on the boiler capacity and steam flow through the valve, rather than on the size of the boiler outlet or existing piping.

Materials of Construction

No. Description Material

1 Body Gray Cast Iron

2 Bonnet

3 Disc

4 Liner

2

1

/

Gray Cast Iron

2

", 3", 4", 5" Steam Bronze

6", 8", 10" Gray Cast Iron

2

1

/

2

", 3", 4", 5" Gray Cast Iron

5 Body Seat Ring

6", 8", 10" Gray Cast Iron - Nickel Plated

Steam Bronze

6 Stem

7 Packing

Carbon Steel - Nickel Plated

Non-Asbestos Rings

8 Gland 2

1

/

2

", 3", 4", 5", 6" Brass

9 Gland Flange

8", 10" Brass

Ductile Iron

10 Yoke Bushing Manganese Bronze

11 Handwheel 2

1

/

2

", 3", 4", 5", 6" Ductile Iron

12 Handwheel Nut

8", 10"

**13 Piston Ring 6", 8", 10"

*14 Throttling Lip 6", 8", 10"

15 Drain Plug

16 Bonnet Studs

Bonnet Stud Nuts

17 Gland Studs

Brass

Carbon Steel

Chrome Vanadium Steel

Steam Bronze

Carbon Steel - Zinc Plated

Carbon Steel

Carbon Steel

Carbon Steel - Zinc Plated

Gland Stud Nuts

*18 Bonnet Gasket

19 Seat Ring Gasket

*20 Locking Pin 6", 8", 10"

Carbon Steel - Zinc Plated

Non-Asbestos Sheet

Non-Asbestos Sheet

Carbon Steel - Zinc Plated

21 ID Plate Aluminum

* Not Shown

** Sizes 5" and smaller made without Piston Ring

See pages 38 - 40 for sizing and other Technical Data

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

2

1

2

8

10

5

6

3

4

A E J K WT

5.75 7.50 13.25 9.00 86

(146) (191) (337) (229) (39)

6.25 8.25 14.75 10.00 123

(159) (210) (375) (254) (55)

7.00 10.00 16.25 10.00 186

(178) (254) (413) (254) (84)

7.88 11.00 19.50 14.00 250

(200) (279) (495) (356) (113)

8.75 12.50 22.50 16.00 340

(222) (318) (572) (406) (154)

10.50 15.00 28.75 20.00 640

(267) (381) (730) (508) (291)

12.25 17.50 32.50 20.00 1025

(311) (445) (826) (508) (465)

13

Malleable Iron Globe Valves

Figure G-574

Class 300 • Union Bonnet • Rising Stem • Nickel Plug • Threaded Ends

12

14

7

2

10

4

13

5

11

9

1

3

8

6

Materials of Construction

No. Description Material

1 Body Malleable Iron

2 Bonnet

3 Stem

4 Plug

5 Union Ring

6 Packing

7 Gland

8 Packing Nut

9 Body Seat Ring

10 Disc Stem Ring

11 Lock Washer

12 Handwheel

13 Handwheel Nut

14 Identification Plate

Malleable Iron

Malleable Iron

Nickel Alloy

Malleable Iron

Asbestos Free

Mild Steel

Malleable Iron

13% Chrome Steel

13% Chrome Steel

18-8 Stainless Steel

Malleable Iron

Steel (Phosphated)

Temperature

Valve

°F

Ratings

-20 to 150 -30 to 65

200

250

300

350

400

450

500

550

°C

93

121

149

177

205

232

260

288

Working Pressures,

Non-shock, PSI

PSI

1000

960

925

890

850

810

775

740

700 kPa

6894

6618

6377

6136

5860

5584

5343

5102

4826

C

M

B

Open

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

1

1

2

2

1

2

1

3

4

8

3

1

4

1

1

4

B C M WT

5.38 2.56

(137) (65)

5.38 2.56

(137) (65)

5.24 2.56

(133) (65)

5.31 2.75

(135) (70)

3.62

(92)

3.62

(92)

1.8

(.82)

1.8

(.82)

2.80

(71)

1.54

(.74)

3.31 2.53

(84) (1.14)

6.73 3.06

(171) (78)

3.90 3.8

(99) (1.71)

7.68 3.62 4.41 5.93

(195) (92) (112) (2.67)

8.62 4.06 4.92 8.07

(219) (103) (125) (3.63)

9.80 4.75 5.98 12.76

(249) (121) (152) (5.74)

14

Iron Gate Valves

Figure G-608

Class 125 • Bolted Bonnet • Non-Rising Stem • Bronze Trim • Threaded Ends

21

24

23

25

8

13

12

11

4

1

15

27

26

28

2

7

6

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc

6 Seat Ring

7 Disc Ring

8 Stem

11 Stuffing Box

12 Packing

13 Gland Flange

15 Handwheel

21 Handwheel Nut

23 Bonnet Gasket

24 Bonnet Bolt

25 Bonnet Bolt Nut

26 Gland Bolt

27 Gland Bolt Nut

28 Stuffing Box Gasket

*34 Stuffing Box Bolt

*35 Stuffing Box Bolt Nut

4"

Cast Iron

2" - 3" Bronze

4" Cast Iron

Bronze

Bronze

Manganese Bronze

Ductile

Non-Asbestos Rings

Ductile

Ductile

Carbon Steel

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Carbon Steel

Carbon Steel EZP

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

* Not shown

Industry Standards

Complies with MSS SP-70 Type 1 and WW-V-58 Type 1, Class 1

See page 6 for Pressure Temperature Ratings

C

A

B

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

2

2

1

2

3

4

A B C WT

5.38 11.31 8.00 25

(137) (287) (203) (11)

6.62 12.40 8.00 31

(168) (315) (203) (14)

7.00 13.25 8.00 44

(178) (337) (203) (20)

8.00 16.31 10.00 71

(203) (414) (254) (32)

15

Iron Gate Valves

Figure G-612

Class 125 • Bolted Bonnet • Non-Rising Stem • Bronze Trim • Flanged Ends

16

13

12

2

C

M

B

21

15

23

8

7

4

27

26

11

28

6

1

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc

6 Seat Ring

7 Disc Ring

8 Stem

11 Stuffing Box

12 Packing

13 Gland Flange

*14 Gland

15 Handwheel

2" - 3"

2" - 8"

Cast Iron

Bronze

4" - 30" Cast Iron

2" - 12" Bronze

14" - 30" Bronze

4" - 12" Bronze

14" - 30" Bronze

2" - 12" Manganese Bronze

14" - 30" Copper-Silicon Bronze

Ductile

10" - 30" Cast Iron

Non-Asbestos Rings

2" - 8" Ductile

14" - 30" Ductile

10" - 12" Bronze

Ductile

21 Handwheel Nut

23 Bonnet Gasket

24 Bonnet Bolt

25 Bonnet Bolt Nut

26 Gland Bolt

27 Gland Bolt Nut

28 Stuffing Box Gasket

*34 Stuffing Box Bolt

Carbon Steel

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Carbon Steel

Carbon Steel EZP

Non-Asbestos Sheet

Carbon Steel

*35 Stuffing Box Bolt Nut Carbon Steel

*55 Gland Follower 10" - 12" Ductile

* Not shown

Industry Standards

Complies with MSS SP-70 Type 1

See page 6 for Pressure Temperature Ratings

Valve

Size

10

8

6

5

4

3

2

2

1

2

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

B

Dimensions

C M WT

11.31 8.00 7.00 30

(287) (203) (178) (14)

12.40 8.00 7.50 40

(315) (203) (191) (18)

13.25 8.00 8.00 56

(337) (203) (203) (25)

16.31 10.00 9.00 90

(414) (254) (229) (41)

18.00 10.00 10.00 126

(457) (254) (254) (57)

20.69 12.00 10.50 152

(526) (305) (267) (68)

24.12 14.00 11.50 260

(613) (356) (292) (117)

33.00 20.00 13.00 490

(838) (508) (330) (222)

Valve

Size

12

14

16

18

30

20

24

B

Dimensions

C M WT

36.50 20.00 14.00 672

(927) (508) (356) (304)

40.50 20.00 15.00 968

(1029) (508) (381) (440)

48.00 22.00 16.00 1180

(1219) (559) (406) (535)

50.75 22.00 17.00 1701

(1289) (559) (432) (772)

56.12 24.00 18.00 2188

(1426) (610) (457) (993)

64.00 30.00 20.00 3150

(1626) (762) (508) (1432)

86.63 30.00 24.00 1701

(2200) (762) (610) (772)

Iron Gate Valves

Figure G-613

Class 125 • Bolted Bonnet • Non-Rising Stem • All Iron • Flanged Ends

13

12

28

24

23

25

21

15

27

26

11

9

4

2

8

1

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc

8 Stem

9 Disc Nut

11 Stuffing Box

12 Packing

13 Gland Flange

15 Handwheel

4" - 8"

21 Handwheel Nut

23 Bonnet Gasket

24 Bonnet Bolt

25 Bonnet Bolt Nut

26 Gland Bolt

27 Gland Bolt Nut

28 Stuffing Box Gasket

*34 Stuffing Box Bolt

*35 Stuffing Box Bolt Nut

* Not shown

Cast Iron

Cast Iron

Steel - Nickel Plated

13 CR Stainless Steel

Ductile

Non-Asbestos Rings

Ductile

Ductile

Carbon Steel

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Carbon Steel

Carbon Steel EZP

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Industry Standards

Complies with MSS SP-70 Type 1

See page 6 for Pressure Temperature Ratings

C

M

B

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

6

5

8

4

3

2

2

1

2

B C M WT

11.31 8.00 7.00 30

(287) (203) (178) (14)

12.40 8.00 7.50 44

(315) (203) (191) (20)

13.25 8.00 8.00 56

(337) (203) (203) (25)

16.31 10.00 9.00 91

(414) (254) (229) (41)

18.00 10.00 10.00 126

(457) (254) (254) (57)

20.69 12.00 10.50 152

(526) (305) (267) (69)

24.12 14.00 11.50 260

(613) (356) (292) (118)

17

Iron Gate Valves

Figure G-620

Class 125 • Bolted Bonnet • OS&Y • Bronze Trim • Threaded Ends

21

47

27

26

24

8

4

1

13

12

2

23

25

15

9

48

7

6

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Yoke Bonnet

4 Disc 2"

Cast Iron

Bronze

2

1

/

2

" - 3" Bronze

6 Seat Ring

7 Disc Ring

8 Stem

9 Yoke Sleeve

12 Packing

13 Gland

4"

4"

Cast Iron

Bronze

Bronze

Manganese Bronze

Manganese Bronze

Non-Asbestos Rings

Ductile

Ductile 15 Handwheel

21 Handwheel Nut

23 Bonnet Gasket

24 Bonnet Bolt

Sintered Nickel Steel

Non-Asbestos Sheet

Carbon Steel

Carbon Steel 25 Bonnet Bolt Nut

26 Gland Bolt

27 Gland Bolt Nut

*46 Yoke Cap

47 Yoke Cap Bolt

48 Yoke Cap Bolt Nut

Carbon Steel

Carbon Steel EZP

Ductile

Carbon Steel

Carbon Steel

* Not shown

B Open

D Closed

C

A

Industry Standards

Complies with MSS SP-70 Type 1 and WW-V-58 Type 1, Class 1

See page 6 for Pressure Temperature Ratings

Valve

Size

2

2

1

2

3

4

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

A

Dimensions

B C D WT

5.38 14.75 8.00 12.50 25

(137) (375) (203) (318) (11)

6.62 16.06 8.00 13.31 38

(168) (408) (203) (338) (17)

7.00 17.38 8.00 13.88 46

(178) (441) (203) (353) (21)

8.00 21.44 10.00 17.06 77

(203) (545) (254) (433) (35)

18

Iron Gate Valves

Figure G-623

Class 125 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

C

M

13

12

24

23

8

7

15

9

48

6

21

47

46

27

26

2

25

4

1

B

Open

10

12

14

16

18

20

24

30

36

Valve

Size

6

5

8

4

3

2

2

1

2

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

B

Dimensions

C M WT

14.75 8.00 7.00 33

(375) (203) (178) (15)

16.06 8.00 7.50 47

(408) (203) (191) (21)

17.38 8.00 8.00 58

(441) (203) (203) (26)

21.44 10.00 9.00 97

(545) (254) (229) (44)

25.81 10.00 10.00 135

(656) (254) (254) (61)

30.31 12.00 10.50 162

(770) (305) (267) (73)

37.75 14.00 11.50 280

(959) (356) (292) (126)

49.41 18.00 13.00 502

(1255) (457) (330) (228)

56.81 18.00 14.00 670

(1442) (457) (356) (304)

64.88 20.00 15.00 1093

(1648) (508) (381) (496)

75.25 22.00 16.00 1425

(1911) (559) (406) (647)

82.00 22.00 17.00 1738

(2083) (559) (432) (789)

90.62 24.00 18.00 2085

(2302) (610) (457) (946)

105.38 30.00 20.00 3183

(2677) (762) (508) (1445)

160.25 30.00 24.00 5795

(4070) (762) (610) (2629)

192.69 30.00 28.00 7622

(4894) (762) (711) (3457)

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc 2"

Cast Iron

Bronze

2

1

/

2

& 3" Bronze

4" - 36" Cast Iron

6 Body Seat Ring 2" - 12" Bronze

14" - 36" Bronze

7 Disc Seat Ring 4" - 12" Bronze

8 Stem

14" - 36" Bronze

2" - 12" Manganese Bronze

14" - 36" Brass

9 Yoke Sleeve 2" - 12" Manganese Bronze

12 Packing

13 Gland

(1 Piece)

14" - 36" Ductile Iron

Non-Asbestos Rings

2" - 8" Ductile Iron

14" - 36" Ductile Iron

*13 Gland 10" & 12" Bronze

*13 Gland Flange 10" & 12" Ductile Iron

15 Handwheel Ductile Iron

21 Handwheel Nut 2" - 8" Sintered Nickel Steel

23 Bonnet Gasket

10" - 36" Ductile Iron

Non-Asbestos Sheet

24 Bonnet Bolt

25 Bonnet Bolt Nut

Carbon Steel

Carbon Steel

26 Gland Bolt 2" - 12" Carbon Steel

*26 Gland Eyebolt 14" - 36" Carbon Steel

27 Gland Bolt Nut

46 Yoke Cap

Carbon Steel

2" - 8" Ductile Iron

10" - 12" Cast Iron

47 Yoke Cap Bolt 2" - 12" Carbon Steel

48 Yoke Cap Bolt Nut 2" - 12" Carbon Steel

*49 Stem Collar Seat 14" - 36" Brass

*50 Disc Pin

*51 Yoke Bolt

14" - 36" Brass

14" - 36" Carbon Steel

*52 Yoke Bolt Nut 14" - 36" Carbon Steel

*53 Yoke to Bonnet Bolt 14" - 36" Carbon Steel

*54 Backseat Bushing 14" - 36" Brass

*55 Eyebolt Pin 14" - 36" Carbon Steel

*56 Yoke 14" - 36" Cast Iron

* Not shown

Industry Standards

Complies with MSS SP-70 Type 1

See page 6 for Pressure Temperature Ratings

19

Iron Gate Valves

Figure G-624

Class 125 • Bolted Bonnet • OS&Y • All Iron • Flanged Ends

15

9

26

23

25

8

27

13

12

24

2

21

47

46

48

4

1

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc

6 Seat Ring

8 Stem

Cast Iron

Cast Iron

12" - 36" Cast Iron

Carbon Steel, NI-PLA

9 Yoke Sleeve

12 Packing

13 Gland

Manganese Bronze

Non-Asbestos Rings

2" - 8" Ductile

10" - 36" Carbon Steel ZN-PLA

15 Handwheel Ductile

21 Handwheel Nut 2" - 10" Sintered Nickel Steel

23 Bonnet Gasket

12" - 36" Ductile

Non-Asbestos Sheet

24 Bonnet Bolt

25 Bonnet Bolt Nut

26 Gland Bolt

27 Gland Bolt Nut

Carbon Steel

Carbon Steel

Carbon Steel

Carbon Steel, ZN-PLA

46 Yoke Cap

47 Yoke Cap Bolt

Ductile

Carbon Steel

48 Yoke Cap Bolt Nut Carbon Steel

*55 GLD Follower 10" - 36" Ductile

* Not shown

Industry Standards

Complies with MSS SP-70 Type 1

See page 6 for Pressure Temperature Ratings

C

M

B

Open

Valve

Size

6

5

8

4

3

2

2

1

2

10

12

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

B

Dimensions

C M WT

14.75 8.00 7.00 33

(375) (203) (178) (15)

16.06 8.00 7.50 47

(408) (203) (191) (21)

17.38 8.00 8.00 58

(441) (203) (203) (26)

21.44 10.00 9.00 97

(545) (254) (229) (44)

25.81 10.00 10.00 135

(656) (254) (254) (61)

30.31 12.00 10.50 162

(770) (305) (267) (73)

37.75 14.00 11.50 280

(959) (356) (292) (126)

49.41 18.00 13.00 502

(1255) (475) (330) (228)

56.81 18.00 14.00 670

(1442) (457) (356) (304)

Valve

Size

14

16

18

20

36

24

30

B

Dimensions

C M WT

64.38 20.00 15.00 1093

(1635) (508) (381) (497)

75.25 22.00 16.00 1425

(1911) (559) (406) (647)

82.00 22.00 17.00 1738

(2083) (559) (432) (790)

90.62 24.00 18.00 2085

(2302) (610) (457) (911)

105.28 30.00 20.00 3183

(2674) (762) (508) (1446)

129.62 36.00 24.00 5795

(3292) (914) (610) (2360)

155.62 42.00 28.00 7522

(3953) (1067) (711) (3417)

20

Malleable Iron Gate Valves

Figure G-675

Class 150 • U-Bolt Bonnet • Rising Stem • All Iron • Threaded Ends

13

11

7

5

8

9

C

M

B

Open

12

4

6

2

1

3

Materials of Construction

No. Description Material

1 Body Malleable Iron

2 Bonnet

3 Disc

4 Stem

5 Packing

6 Gland

7 Packing Nut

8 Gasket

9 “U” Bolt

Malleable Iron

Malleable Iron

Nickel Plated Steel

Asbestos Free

N/Plated Steel

Malleable Iron

Asbestos Free

Mild Steel

*10 “U” Bolt Nuts Mild Steel

11 Identification Plate Aluminum

12 Handwheel Nut

13 Handwheel

Mild Steel

Malleable Iron

* Not shown

Temperature

Valve

Ratings

°F

-20 to 150 -30 to 65

200

225

250

275

300

325

350

375

°C

93

107

121

135

149

163

177

191

1

/

4

" - 2"

(6mm - 50mm)

150 psi, Sat. Steam

PSI

225

210

200

190

185

175

165

160

150 kPa

1550

1450

1380

1310

1280

1210

1140

1100

1030

Working Pressures, Non-shock

2

1

/

2

" - 4"

(65mm - 100mm)

125 psi, Sat. Steam

PSI

175

165

160

150

145

140

135

125

120 kPa

1210

1140

1100

1030

1000

970

930

860

830

Valve

Size

1

1

1

4

1

1

2

2

3

4

2

3

1

2

1

2

1

3

4

8

4

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

B

Dimensions

C M WT

5.08 2.06

(129) (52)

5.08 2.06

(129) (52)

5.08 2.06

(129) (52)

6.18 2.56

(157) (65)

3.00 1.40

(76) (0.64)

3.00 1.40

(76) (0.64)

2.06 1.86

(52) (0.84)

2.32 2.44

(59) (1.10)

7.40 2.76

(188) (70)

8.90 3.07

(226) (78)

2.56 3.53

(65) (1.60)

2.87 5.80

(73) (2.63)

9.96 3.62

(253) (92)

3.15 7.00

(80) (3.17)

11.61 4.06 3.62 11.20

(295) (103) (92) (5.08)

12.91 4.76 4.13 19.20

(328) (121) (105) (8.71)

15.35 5.98 4.57 23.10

(390) (152) (116) (10.47)

19.76 9.02 5.55 52.67

(502) (229) (141) (23.61)

21

Malleable Iron Gate Valves

Figure G-679

Class 150 • U-Bolt Bonnet • Rising Stem • Bronze Trim • Threaded Ends

22

13

11

7

5

8

14

9

C

M

B

Open

12

4

6

2

1

3

Materials of Construction

No. Description Material

1 Body Malleable Iron

2 Bonnet

3 Disc

4 Stem

5 Packing

6 Gland ½"-3"

4"

7 Packing Nut

8 Gasket

Malleable Iron

Bronze

Brass

Asbestos Free

Rod Brass

Bronze

Malleable Iron

Asbestos Free

9 “U” Bolt

*10 “U” Bolt Nuts

Mild Steel

Mild Steel

11 Identification Plate Aluminum

12 Handwheel Nut Mild Steel

13 Handwheel

14 Body Seat Rings

Malleable Iron

Bronze

Valve

Size

3

1

2

4

1

3

1

4

8

4

2

2

1

1

1

1

2

4

2

1

3

* Not shown

Temperature

Valve

Ratings

Working Pressures, Non-shock

1

/

4

" - 2"

(6mm - 50mm)

2

1

/

2

" - 4"

(65mm - 100mm)

°F

-20 to 150 -30 to 65

200

225

250

275

300

325

350

375

°C

93

107

121

135

149

163

177

191

150 psi, Sat. Steam 225 psi, CWP 125 psi, Sat. Steam 175 psi, CWP

PSI

225

210

200

190

185

175

165

160

150 kPa

1550

1450

1380

1310

1280

1210

1140

1100

1030

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

PSI

175

165

160

150

145

140

135

125

120 kPa

1210

1140

1100

1030

1000

970

930

860

830

B

Dimensions

C M WT

5.08 2.06

(129) (52)

5.08 2.06

(129) (52)

5.08 2.06

(129) (52)

6.18 2.56

(157) (65)

3.00 1.40

(76) (0.64)

3.00 1.40

(76) (0.64)

2.06 1.76

(52) (0.80)

2.32 2.44

(59) (1.10)

7.40 2.76

(188) (70)

8.90 3.07

(226) (78)

2.56 3.53

(65) (1.60)

2.87 5.80

(73) (2.63)

9.96 3.62

(253) (92)

3.15 7.00

(80) (3.17)

11.61 4.06 3.62 11.20

(295) (103) (92) (5.08)

12.91 4.76 4.13 19.20

(328) (121) (105) (8.71)

15.35 5.98 4.57 23.10

(390) (152) (116) (10.47)

19.76 9.02 5.55 52.10

(502) (229) (141) (23.61)

Malleable Iron Gate Valves

Figure G-676

Class 125 • U-Bolt Bonnet • Rising Stem • All Iron • Flanged Ends

13

11

7

5

8

1

3

12

4

6

2

Materials of Construction

No. Description Material

1 Body Malleable Iron

2 Bonnet

3 Disc

4 Stem

5 Packing

6 Gland

7 Packing Nut

8 Gasket

9 “U” Bolt

Malleable Iron

Malleable Iron

N/plated Steel

Asbestos Free

Ni Plated Steel

Malleable Iron

Asbestos Free

Mild Steel

*10 “U” Bolt Nuts Steel

11 Identification Plate Aluminum

12 Handwheel Nut

13 Handwheel

Mild Steel

Malleable Iron

* Not shown

9

Temperature

Valve

Ratings

°F

-20 to 150 -30 to 65

200

225

250

275

300

325

350

375

°C

93

107

121

135

149

163

177

191

Working Pressures, Non-shock

PSI

200

185

175

165

155

145

135

130

120

1" - 2"

(25mm - 50mm)

200 psi, CWP

kPa

1380

1280

1210

1140

1070

1000

930

900

830

PSI

175

165

160

150

145

140

135

125

120

2

1

/

2

" - 4"

(65mm - 100mm)

175 psi, CWP

kPa

1210

1140

1100

1030

1000

970

930

860

830

C

M

B

Open

Valve

Size

4

2

1

3

2

1

1

1

2

2

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

B

Dimensions

C M WT

7.40 2.76

(188) (70)

9.96 3.62

(253) (92)

3.19 5.50

(81) (2.49)

3.74 10.40

(95) (4.71)

11.61 4.06 4.25 14.30

(295) (103) (108) (6.48)

12.91 4.76 4.92 22.00

(328) (121) (125) (9.97)

15.35 5.98 5.08 32.00

(390) (152) (129) (14.50)

19.76 9.02 6.77 60.00

(502) (229) (172) (27.19)

23

Iron Gate Valves

Figure F-661

Class 250 • Bolted Bonnet • Non-Rising Stem • Bronze Trim • Flanged Ends

24

2

12

9

14

17

23

5

C

M

B

3

4

1

18

10

15

8

20

11

19

6

22

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

3 Disc

4 Seat Ring

5 Disc Ring

6 Stem

7 Stuffing Box

8 Gland

9 Gland Flange

10 Handwheel

11 Bonnet Bolts

12 Bonnet Bolt Nuts

*13 Stuffing Box Bolts

14 Gland Studs 2

1

/

2

", 3", 4", 6"

Gland Bolts 2", 8", 10", 12"

15 Gland Stud or Bolt Nuts

*16 Stuffing Box Studs

17 Stuff Box Stud - Bolt Nuts

18 Handwheel Nut

19 Bonnet Gasket

20 Packing

21 Stuffing Box Gasket

22 Disc Bushing

23 Identification Plate

*Not shown

2" - 4"

Cast Iron

Bronze

6" - 12" Cast Iron

Bronze

6" - 12" Bronze

2" - 8" Manganese Bronze

10"

12"

Naval Brass

Manganese Bronze

2" - 4" Ductile

6" - 12" Cast Iron

2" - 4" Ductile

6" - 12" Bronze

6" - 12" Ductile

Ductile

Carbon Steel

Carbon Steel

Carbon Steel

Carbon Steel

Carbon Steel

Steel EZP

Carbon Steel

Carbon Steel

Carbon Steel

Non-Asbestos Sheet

Non-Asbestos Rings

Non-Asbestos Sheet

Bronze

Aluminum

Industry Standards

Complies with MSS SP-70 Type 1 and WW-V-58, Type 1, Class 1

See page 6 for Pressure Temperature Ratings

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

4

3

2

2

1

2

8

6

10

12

B C M WT

11.94 8.00 8.50 47

(303) (203) (216) (21)

12.94 8.00 9.50 84

(328) (203) (241) (38)

14.50 10.00 11.12 113

(368) (254) (282) (51)

17.38 12.00 12.00 175

(441) (305) (305) (79)

23.00 16.00 15.88 335

(584) (406) (403) (151)

30.75 20.00 16.50 545

(781) (508) (419) (246)

36.00 22.00 18.00 854

(914) (559) (457) (385)

39.75 24.00 19.75 1250

(1010) (610) (502) (563)

Iron Gate Valves

Figure F-667

Class 250 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

15

9

46

13

24

23

8

4

Industry Standards

Complies with MSS SP-70 Type 1 and WW-V-58, Type 1, Class 1

See page 6 for Pressure Temperature Ratings

C

M

B

Open

21

47

48

27

26

12

2

25

7

6

1

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc

6 Seat Ring

7 Disc Ring

8 Stem

9 Yoke Sleeve

Cast Iron

2" - 3" Bronze

4" - 12" Cast Iron

Bronze

4" - 12" Bronze

2", 2

1

/

2

", 3", 4", 6", 8" Manganese Bronze

5", 10", 12" Naval Brass

Manganese Bronze

12 Packing

13 Gland

*14 Gland Flange

2", 2

1

/

2

", 3", 4", 6"

8" - 12"

5"

15 Handwheel

Non-Asbestos Rings

Ductile

Bronze

Carbon Steel

8", 10", 12" Ductile

Ductile

21 Handwheel Nut

23 Bonnet Gasket

24 Bonnet Bolt

2" - 6"

8" - 12"

Sintered Nickel Steel

Ductile

Non-Asbestos Sheet

Carbon Steel

25 Bonnet Bolt Nut Carbon Steel

26 Gland Bolt 2", 2

1

/

2

", 3", 4", 6", 8" Carbon Steel

Gland Stud 5", 10", 12"

27 Gland Bolt Nut

Carbon Steel

Carbon Steel EZP

46 Yoke Cap 2", 2

1

/

2

", 3", 4", 6"

8"

47 Yoke Cap Bolt

48 Yoke Cap Bolt Nut

Ductile

Cast Iron

Carbon Steel

Carbon Steel

*51 Yoke Hub Bolt 5", 10", 12" Carbon Steel

*52 Yoke Hub Bolt Nut 5", 10", 12" Carbon Steel

*53 Yoke Pad Bolt

*Not shown

5", 10", 12" Carbon Steel

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

6

5

8

4

3

2

2

1

2

10

12

B C M WT

15.06 8.00 8.50 54

(382) (203) (216) (24)

16.69 8.00 9.50 80

(424) (203) (241) (36)

18.75 10.00 11.12 114

(476) (254) (282) (52)

23.44 12.00 12.00 174

(595) (305) (305) (79)

24.00 14.00 15.00 280

609 356 381 127

31.75 16.00 15.88 332

(806) (406) (403) (151)

39.88 18.00 16.50 600

(1,012) (457) (419) (270)

41.75 22.00 18.00 920

(1060) (559) (457) (417)

47.00 24.00 19.75 1400

(1193) (610) (502) (635)

25

Figure G-927

Class 125 • Bolted Cap • Bronze Trim • Threaded Ends

Iron Check Valves

33

32

34

8

6

2

1

19

25

23

4

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Cap

4 Disc

6 Seat Ring

8 Hinge Pin

19 Hinge

23 Disc Nut

*24 Side Plug

25 Disc Washer

*28 Hinge Pin Bushing

32 Bonnet Gasket

33 Cap Bolt

34 Cap Bolt Nut

36 Identification Plate

Cast Iron

Bronze

Bronze

Alum Silicon Bronze

Bronze

Brass

Brass

Brass

Brass

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Aluminum

* Not shown

Industry Standards

Complies with MSS SP-71, Type 1

See page 6 for Pressure Temperature Ratings

A

B

Valve

Size

2

2

1

2

3

4

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Dimensions

A B WT

6.12 4.50

(155) (114)

18

(8)

7.25 5.38 22

(184) (137) (10)

8.00 5.88 29

(203) (149) (13)

9.25 6.62 54

(235) (168) (25)

26

33

1

34

8

Iron Check Valves

Figure G-931

Class 125 • Bolted Cap • Bronze Trim • Flanged Ends

6

Valve

Size

6

5

8

4

3

2

2

1

2

18

20

14

16

10

12

24

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Dimensions

B M WT

4.50 8.00 25

(114) (203) (11)

5.38 8.50 30

(137) (216) (14)

5.88 9.50 42

(149) (241) (19)

6.62 11.50 74

(168) (292) (33)

7.75 13.00 100

(197) (330) (45)

8.25 14.00 125

(210) (356) (56)

10.25 19.50 230

(260) (495) (104)

12.00 24.50 490

(305) (622) (219)

13.75 27.50 660

(349) (699) (317)

15.50 31.00 794

(393) (787) (360)

17.63 36.00 1020

(447) (914) (462)

19.25 36.00 1304

(610) (914) (591)

27.62 40.00 2590

(702) (1016) (1117)

31 46.00 3840

(787) (1168) (1745)

19

25

23

4

33

36

2

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Cap

4 Disc

6 Seat Ring

7 Disc Ring

8 Hinge Pin

19 Hinge

20 Disc Stud

21 Disc Stud Pin

23 Disc Nut

24 Side Plug

25 Disc Washer

*26 Lockwasher

*27 Plain Washer

*28 Hinge Pin Bushing

32 Bonnet Gasket

33 Cap Bolt

34 Cap Bolt Nut

36 Identification Plate

2" - 6"

Cast Iron

Bronze

8" - 24" Cast Iron

2" - 12" Bronze

14" - 24" Bronze

8" - 12" Bronze

14" - 24" Bronze

2" - 8" Alum Silicon Bronze

10" - 12" Naval Brass

14" - 16" Stainless Steel

18" - 24" Stainless Steel

2" - 6" Bronze

8" - 12" Ductile

18" - 24" Ductile

14" - 16" Carbon Steel

8" - 16" Steel

18" - 24" Steel

8" - 16" 18-8 Stainless Steel

18" - 24" Steel

2" - 6" Brass

8" - 24" Steel

2" - 16" Brass

18" - 24" Ductile

2" - 6" Brass

8" - 16" Steel

18" - 24" Steel

18" - 24" Steel

2" - 12" Brass

14" - 16" Bronze

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Aluminum

* Not shown

M

Industry Standards

Complies with Military Spec. MIL-V-18436 and MSS SP-71, Type 1

See page 6 for Pressure Temperature Ratings

B

27

Iron Check Valves

Figure G-931 L&W

Class 125 • Bolted Cap • Bronze Trim • Flanged End • Lever & Weight

33

32

34

6

1

19

23

25

4

2

26

15

Materials of Construction

No. Description Material

1 Body Ferrosteel

2 Cap

4 Disc

6 Body Seat Ring

*7 Disc Seat Ring

*8 Hinge Pin

*11 Stuffing Box

*12 Packing

*14 Packing Nut

15 Lever

19 Hinge

*20 Disc Stud

*21 Disc Stud Pin

*22 Hinge Pin Key

23 Nut for Disc

*24 Hinge Pin Plug

25 Disc Washer

26 Weight

*27 Hinge Pin Bushing

*28 Lever Washer

*29 Coupling

*30 Gib-Key

*31 Lever Nut

32 Gasket

33 Cap Bolts

34 Cap Bolt Nuts

*36 ID Plate

Ferrosteel

2" - 6" Bronze

8" Ferros Steel

Bronze

8" Bronze

Exelloy

Brass

Non-Asbestos

Bronze

Malleable Iron

2" - 6" Bronze

8" Malleable Iron

8" Steel

8" 18-8 Stainless Steel

Steel

2" - 6" Brass

8" Steel

Brass

2" - 6" Brass

8" Steel

Cast Iron

Bronze

Steel

Malleable Iron

Steel

Steel Di-Chromate

Non-Asbestos Sheet

Steel

Steel

Aluminum

* Not shown

† Parts indicated are necessary for changing regular valve to outside lever and weight

See page 7 for Lever and Weight Technical Orientation Data

28

M

B

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

B M WT

Valve

Size

Size

4

3

2

2

1

2

8

6

10

4.50 8.00 30

(114) (203) (14)

5.38 8.50 40

(137) (216) (18)

5.88 9.50 54

(149) (241) (24)

6.62 11.50 85

(168) (292) (38)

8.25 14.00 137

(210) (356) (62)

10.25 19.50 240

(260) (495) (108)

12.00 24.50 460

(305) (622) (208)

12

14

16

18

20

24

Dimensions

B M WT

13.75 27.50 700

(349) (699) (317)

16.88 31.00 1060

(429) (787) (481)

19.12 36.00 1500

(486) (914) (682)

24.00 38.00 1970

(610) (965) (895)

27.62 42.00 2590

(702) (1067) (1117)

31.00 46.00 3840

(787) (1168) (1745)

33

2

34

8

Iron Check Valves

Figure G-933

Class 125 • Bolted Cap • All Iron • Flanged Ends

36

32

19

25

23

4

1

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Cap

4 Disc

*6 Seat Ring

8 Hinge Pin

19 Hinge

20 Disc Stud

21 Disc Stud Pin

23 Disc Nut

*24 Side Plug

25 Disc Washer

*26 Lockwasher

2" - 4"

6" - 24"

8" - 16"

Cast Iron

Ductile

Cast Iron

5", 10" - 24" Cast Iron

2" - 4", 6" - 8" Cast Iron (Integral)

Stainless Steel

Ductile

Steel

18" - 24" Steel

8" - 16" 18-8 Stainless Steel

18" - 24" Steel

8" - 24" Steel

2" - 12" Carbon Steel

14" - 24" Ductile

2" - 12" Carbon Steel

14" - 24" Steel

*27 Plain Washer 14" - 24" Steel

*28 Hinge Pin Bushing 2" - 12" Carbon Steel

32 Cap Gasket

33 Cap Bolt

Non-Asbestos Sheet

Carbon Steel

34 Cap Bolt Nut

36 Identification Plate

Carbon Steel

Aluminum

* Not shown

Industry Standards

Complies with Military Spec. MIL-V-18436 and MSS SP-71, Type 1

See page 6 for Pressure Temperature Ratings

M

B

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions Valve

Size

5

4

2

2

1

2

3

8

6

B M WT

4.50 8.00 25

(114) (203) (11)

5.38 8.50 30

(137) (216) (13)

5.88 9.50 42

(149) (241) (19)

6.62 11.50 74

(168) (292) (33)

7.75 13.00 100

(197) (330) (45)

8.25 14.00 125

(210) (356) (56)

10.25 19.50 230

(260) (495) (104)

Size

10

12

18

20

14

16

24

Dimensions

B M WT

12.00 24.50 440

(305) (622) (200)

13.75 27.50 660

(349) (699) (299)

16.88 31.00 1060

(429) (787) (481)

19.12 36.00 1500

(486) (914) (682)

24.00 38.00 1970

(610) (965) (895)

27.62 42.00 2590

(702) (1067) (1117)

31.00 46.00 3840

(787) (1168) (1745)

29

16

15

5

7

3

9

8

Figure F-947

Class 250 • Bolted Cap • Bronze Trim • Flanged Ends

Iron Check Valves

13

14

2

4

10

12

1

Materials of Construction

No. Description Material

1 Body Ferrosteel

2 Cap

3 Disc

4 Hinge

5 Hinge Pin

*6 Hinge Pin Plug

7 Body Seat Ring

8 Disc Seat Ring

9 Disc Bolt

10 Disc Nut Washer

12 Disc Bolt Nut

13 Cap Studs

14 Cap Stud Nuts

15 Gasket

16 Identification Plate

Ferrosteel

2" - 3" Bronze

4" - 8" Cast Iron

Malleable Iron

2" - 3" 13 Cr. Stainless Steel

4" - 8" Bronze

Bronze

Bronze

4" - 8" Bronze

4" - 8" Steel

Steel

Steel - Dichromate Fin.

Steel

Steel

Non-Asbestos Sheet

Aluminum

*Not shown

M

B

Industry Standards

Complies with MSS SP-71 Type 1 and

Military Specifications MIL-V-18436 Group B, Type 3, Trim 5

See page 6 for Pressure Temperature Ratings

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

4

3

2

2

1

2

8

6

B M WT

5.25 10.50 46

(133) (267) (21)

6.00 11.50 64

(152) (292) (29)

6.25 12.50 90

(159) (318) (41)

7.25 14.00 133

(184) (356) (60)

9.00 17.50 250

(229) (445) (113)

11.00 21.00 410

(279) (533) (185)

30

Malleable Iron Check Valves

Figure G-975

Class 300 • Threaded Cap • Y-Pattern • All Iron • Threaded Ends

6

7

2

9

8

5

4

3

1

Materials of Construction

No. Description Material

1 Body Malleable Iron

2 Cap

3 Disc ½" & ¾"

1" - 2"

4 Disc Hinge Nut

5 Hinge Pin

6 Hinge

7 Hinge Pin Plug

8 Identification Plate

9 Drive Screw

Malleable Iron

Mild Steel

Malleable Iron

Steel

13% Chrome Steel

Malleable Iron

13% Chrome Steel

Aluminum

Steel

M

B

Temperature

Valve

°F

Ratings

-20 to 150 -30 to 65

200

250

300

350

400

450

500

550

°C

93

121

149

177

205

232

260

288

Working Pressures,

Non-shock, PSI

PSI

1000

960

925

890

850

810

775

740

700 kPa

6894

6618

6377

6136

5860

5584

5343

5102

4826

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve

Size

2

1

1

1

1

2

4

1

3

2

4

1

Dimensions

M B WT

2.75

(70)

3.27

(83)

1.69

(43)

2.00

(51)

1.0

(.43)

1.50

(.65)

4.06 2.45 2.50

(103) (62) (1.11)

4.75 2.85 2.90

(120) (73) (1.30)

5.40 3.29 5.80

(137) (84) (2.61)

6.62 4.28 10.0

(168) (109) (4.51)

31

Iron Wafer Check Valves

Figure WG-961

200 CWP • Iron Body • EPDM Seat

4

8

6

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Disc*

3 Seal

4 Pin Retainer

5 Stop Pin

6 Spring

7 Hinge Pin

8 Plate Bearing

Stainless Steel

EPDM

Cast Iron

Stainless Steel

Stainless Steel

Stainless Steel

PTFE

*2", 2½", 5", 10", & 12" Material: Aluminum Bronze

1

7

2

A Dia.

C

Minimum

Flange

Bore

B

5

3

Valve

Size

6

5

8

4

3

2

2

1

2

10

12

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

A

Dimensions

B C WT

4.12 2.12

(105) (54)

4.88 2.12

(124) (54)

2.06 5.00

(52) (2.27)

2.47 7.00

(63) (3.17)

5.38 2.25

(137) (57)

3.06 9.00

(78) (4.08)

6.88 2.50 4.00 13.00

(175) (64) (102) (5.90)

7.75 2.75 5.00 22.00

(197) (70) (127) (9.98)

8.75 3.00 6.06 31.00

(222) (76) (154) (14.06)

11.00 3.75 7.97 69.00

(279) (95) (202) (31.29)

13.38 4.25 10.00 95.00

(340) (108) (254) (43.08)

16.12 5.62 11.94 156.00

(409) (143) (303) (70.20)

32

Iron Wafer Check Valves

Figure WG-970

Class 125 • Iron Body • Buna-N Seat

8

2

11

7

5

12

4

6

10

9

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Plate

3 Seal

4 Stop Pin

5 Hinge Pin

6 Spring

7 Stop Pin Retainer

8 Hinge Pin Retainer

9 Body Bearing

10 Plate Bearing

11 Spring Bearing

Aluminum Bronze

Buna-N

316 Stainless Steel

316 Stainless Steel

316 Stainless Steel

316 Stainless Steel

316 Stainless Steel

PTFE

PTFE

PTFE

1

A Dia.

C

Minimum

Flange

Bore

B

3

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

8

6

10

5

4

2

2 ½

3

30

36

20

24

16

18

12

14

A B C WT

4.12 2.12

(105) (54)

4.88 2.12

(124) (54)

2.06 5.00

(52) (2.27)

2.47 7.00

(63) (3.17)

5.38 2.25

(137) (57)

3.06 9.00

(78) (4.08)

6.88 2.50 4.00 13.00

(175) (64) (102) (5.90)

7.75 2.75 5.00 22.00

(197) (70) (127) (9.98)

8.75 3.00 6.06 31.00

(222) (76) (154) (14.06)

11.00 3.75 7.97 69.00

(279) (95) (202) (31.28)

13.38 4.25 10.00 95.00

(340) (108) (254) (43.08)

16.12 5.62 11.94 156.00

(409) (143) (303) (70.75)

17.75 7.25 12.50 203

(451) (184) (316) (92.06)

20.25 7.50 15.00 247.00

(514) (191) (381) (112.02)

21.62 8.00 16.88 303.00

(549) (203) (429) (137.01)

23.88 8.38 18.81 390.00

(607) (213) (478) (176.87)

28.25 8.75 22.62 566.00

(724) (222) (575) (256.69)

34.75 12.00 29.25 1083.00

(883) (305) (743) (491.15)

41.25 14.50 35.00 1505.00

(1048) (368) (889) (682.54)

33

14

13

12

20

24

17

International Iron Globe Valves

Figure G-512-I*

Class 125 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

6

29

15

2

28

27

30

25

26

21

4

1

Materials of Construction

No. Description Material

1 Body Hi-Str. Cast Iron

2 Bonnet

4 Disc

6 Body Seat Ring

*7 Disc Seat Ring

8 Stem

9 Yoke Bushing

12 Packing

Hi-Str. Cast Iron

2" - 6" Bronze

8" - 10" Cast Iron

Bronze

8" & 10" Bronze

Manganese Bronze

Manganese Bronze

Non-Asbestos Rings

13 Gland

14 Gland Flange

15 Handwheel

(2" - 4") Brass

(5" - 10") Bronze

Ductile

Ductile

17 Disc Stem Ring

20 Stem Hole Bushing

21 Locking Device

*22 Disc Guide Stem

Bronze

Brass

2" - 6" 18-8 SST Sheet

8" & 10" Brass

*23 Disc Guide Stem Pin

24 Bonnet Gasket

25 Bonnet Studs

26 Bonnet Stud Nuts

27 Gland Studs

28 Gland Stud Nuts

29 Handwheel Nut

30 Identification Plate

8" & 10" Brass

Non-Asbestos Sheet

Steel

Steel

Naval Brass

Brass

Steel - Phos. Coated

Aluminum

* Not shown

Industry Standards

Complies with MSS SP-85 Type 1

See page 6 for Pressure Temperature Ratings

C

M

* NOTE: All International Iron valves are painted gray.

34

B

Open

Valve

Size

10

8

6

5

4

3

2

2

1

2

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

B

Dimensions

C M WT

11.12 8.00 8.00 35

(282) (203) (203) (15)

11.50 8.00 8.50 40

(292) (203) (216) (18)

13.25 9.00 9.50 57

(337) (229) (241) (26)

15.50 10.00 11.50 95

(394) (254) (292) (43)

17.50 10.00 13.00 126

(445) (254) (330) (57)

19.50 12.00 14.00 176

(495) (305) (356) (80)

25.00 16.00 19.50 344

(635) (406) (495) (156)

30.50 18.00 24.50 570

(775) (457) (622) (259)

International Iron Gate Valves

Figure G-612-I*

Class 125 • Bolted Bonnet • Non-Rising Stem • Bronze Trim • Flanged Ends

13

12

2

C

M

B

* NOTE: All International Iron valves are painted gray.

21

15

27

26

11

28

7

4

6

23

8

1

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc

6 Seat Ring

7 Disc Ring

8 Stem

11 Stuffing Box

Cast Iron

2" - 3" Bronze

4" - 12" Cast Iron

Bronze

4" - 12" Bronze

Manganese Bronze

2" - 8" Ductile

10" - 12" Cast Iron

12 Packing

13 Gland Flange

*14 Gland

15 Handwheel

21 Handwheel Nut

23 Bonnet Gasket

24 Bonnet Bolt

25 Bonnet Bolt Nut

Non-Asbestos Rings

2" - 8" Ductile

10" - 12" Bronze

Ductile

Carbon Steel

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

26 Gland Bolt

27 Gland Bolt Nut

28 Stuffing Box Gasket

*34 Stuffing Box Bolt

Carbon Steel

Carbon Steel EZP

Non-Asbestos Sheet

Carbon Steel

*35 Stuffing Box Bolt Nut Carbon Steel

*55 Gland Follower 10" - 12" Ductile

* Not shown

Industry Standards

Complies with MSS SP-70 Type 1

See page 6 for Pressure Temperature Ratings

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Valve Dimensions

Size

6

5

8

4

3

2

2

1

2

10

12

B C M WT

11.31 8.00 7.00 30

(287) (203) (178) (14)

12.40 8.00 7.50 40

(315) (203) (191) (18)

13.25 8.00 8.00 56

(337) (203) (203) (25)

16.31 10.00 9.00 90

(414) (254) (229) (41)

18.00 10.00 10.00 126

(457) (254) (254) (57)

20.69 12.00 10.50 152

(526) (305) (267) (68)

24.12 14.00 11.50 260

(613) (356) (292) (117)

32.25 16.00 13.00 484

(819) (406) (330) (220)

36.00 18.00 14.00 685

(914) (457) (356) (311)

35

International Iron Gate Valves

Figure G-623-I*

Class 125 • Bolted Bonnet • OS&Y • Bronze Trim • Flanged Ends

13

12

24

23

8

7

15

9

48

6

C

M

B

Open

* NOTE: All International Iron valves are painted gray.

36

21

47

46

27

26

2

25

4

1

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Bonnet

4 Disc 2"

Cast Iron

Bronze

2

1

/

2

& 3" Bronze

6 Body Seat Ring

4" - 12" Cast Iron

Bronze

7 Disc Seat Ring 4" - 12" Bronze

8 Stem Manganese Bronze

9 Yoke Sleeve

12 Packing

Manganese Bronze

Non-Asbestos Rings

13 Gland (1 Piece) 2" - 8" Ductile Iron

*13 Gland 10" & 12" Bronze

*13 Gland Flange 10" & 12" Ductile Iron

15 Handwheel Ductile Iron

21 Handwheel Nut 2" - 8" Sintered Nickel Steel

10" - 12" Ductile Iron

23 Bonnet Gasket

24 Bonnet Bolt

25 Bonnet Bolt Nut

26 Gland Bolt

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Carbon Steel

*26 Gland Eyebolt

27 Gland Bolt Nut

46 Yoke Cap

47 Yoke Cap Bolt

Carbon Steel

Carbon Steel

2" - 8" Ductile Iron

10" - 12" Cast Iron

Carbon Steel

Carbon Steel 48 Yoke Cap Bolt Nut

* Not shown

Industry Standards

Complies with MSS SP-70 Type 1

See page 6 for Pressure Temperature Ratings

Valve

Size

6

5

8

4

3

2

2

1

10

2

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

12

B

Dimensions

C M WT

14.75 8.00 7.00 33

(375) (203) (178) (15)

16.06 8.00 7.50 47

(408) (203) (191) (21)

17.38 8.00 8.00 58

(441) (203) (203) (26)

21.44 10.00 9.00 97

(545) (254) (229) (44)

25.81 10.00 10.00 135

(656) (254) (254) (61)

30.31 12.00 10.50 162

(770) (305) (267) (73)

37.75 14.00 11.50 280

(959) (356) (292) (126)

44.94 16.00 13.00 502

(1141) (406) (330) (228)

53.69 18.00 14.00 670

(1364) (457) (356) (304)

33

1

34

8

International Iron Check Valves

Figure G-931-I*

Class 125 • Bolted Cap • Bronze Trim • Flanged Ends

6

M

B

19

25

23

4

36

2

33

Materials of Construction

No. Description Material

1 Body Cast Iron

2 Cap

4 Disc

6 Seat Ring

7 Disc Ring

8 Hinge Pin

19 Hinge

20 Disc Stud

21 Disc Stud Pin

23 Disc Nut

24 Side Plug

25 Disc Washer

*28 Hinge Pin Bushing

32 Bonnet Gasket

33 Cap Bolt

34 Cap Bolt Nut

36 Identification Plate

* Not shown

2" - 6"

Cast Iron

Bronze

8" - 12" Cast Iron

Bronze

8" - 12" Bronze

2" - 8" Alum Silicon Bronze

10" - 12" Naval Brass

2" - 6" Bronze

8" - 12" Ductile

8" - 12" Steel

8" - 12" 18-8 Stainless Steel

2" - 6" Brass

8" - 12" Steel

Brass

2" - 6" Brass

8" - 12" Steel

Brass

Non-Asbestos Sheet

Carbon Steel

Carbon Steel

Aluminum

Industry Standards

Complies with Military Spec. MIL-V-18436 and MSS SP-71, Type 1

See page 6 for Pressure Temperature Ratings

Valve

Size

6

5

8

4

3

2

2

1

2

10

12

Dimensions and Weights

Inches (millimeters) - Pounds (kilograms)

Dimensions

B M WT

4.50 8.00 25

(114) (203) (11)

5.38 8.50 30

(137) (216) (14)

5.88 9.50 42

(149) (241) (19)

6.62 11.50 74

(168) (292) (33)

7.75 13.00 100

(197) (330) (45)

8.25 14.00 125

(210) (356) (56)

10.25 19.50 230

(260) (495) (104)

12.00 24.50 490

(305) (622) (219)

13.75 27.50 660

(349) (699) (317)

* NOTE: All International Iron valves are painted gray.

37

Iron Valves

Technical Data

Y-Pattern Stop Check Valve

Selecting the Proper Size –

Determining Pressure Drop

Since stop-check valves have a floating disc member, it is important the valve be sized to provide full disc lift under flow conditions prevailing during the major portion of the service life. If the valve is too large, the disc will float in a partially open position and may cause fluttering of the disc and rapid wear.

Conversely, if the valve is too small, pressure drop will be excessive.

The chart on the following page is a graphic presentation of flow data determined by test. Its use offers a simple method of determining the best size stop-check valve, as well as the pressure drop under varying conditions of flow, without any computation.

How to Use the Chart

Shown on the Following Page

Given

: Steam Pressure-Temperature...250 psig 450°F

Flow Rate...Typical Daily Demand Curve

2. From that point, draw another line through the valve size, for example the 8-inch size, and establish a point on Index 2. Now move horizontally to the diagonal pressure drop line on the right side. Where these lines intersect, the pressure drop is 7.5 psi for the 8-inch, Class 250 globe valve and 8.5 psi for the 8-inch Class 250 angle valve.

Chart solutions resulting in a point on Index 2 that falls below the Line A-A for Class 250 valves indicate the disc will not be fully lifted under the flow conditions used. Operation under such conditions is not recommended but, at times, must be tolerated for short periods during the low loads.

3. Enter the chart where Line A-A intersects Index 2 for Class 250 valves.

Move diagonally upward through the size being investigated (8-inch) and establish a second point on Index 1. From this point, extend a line to the specific volume established in Step 1 and at its intersection with the flow rate line, read 48,000 Lb/H as the minimum flow rate at which the disc will be in the fully lifted position. The pressure drop at this flow rate is

1.9 psi for globe and 2.1 psi for angle valves.

4. Repeat Steps 2 and 3 for other possible valve sizes, tabulate results, and make size selection on basis of pressure drop and duration of partial disc lift considerations.

Typical Daily Load-Demand Curve

100,000

90,000

80,000

70,000

10-Inch Valve

60,000

50,000

8-Inch Valve

40,000

30,000

20,000

10,000

0

12

Midnight

6

AM

12

Noon

TIME OF DAY

6

PM

12

Midnight

Valve

Size

(Inches)

6

8

10

Press drop @ Max.Min.

Flow rate (100,000 #/Hr.), psi

Globe

20.5

7.5

3.3

Angle

22.5

8.5

3.6

Flow Rate for

Wide open valve

#/Hr.

26,500

48,000

68,000

Dotted lines on Demand Curve indicate minimum flow rates for wide open

8" and 10" valves.

5. The best choice for this example would be the 10" size because pressure drop is much lower and duration of partially lifted disc is only slightly greater than for the 8" size.

6. Pressure drop for any intermediate flow condition can be determined as outlined in Steps 1 and 2.

Find

: Valve Catalog No. and the best size for above installation.

Solution

:

1. Enter the Temperature chart at 450°F. Move vertically upward to the curved line for 250 psi, then horizontally to the right to establish a point on the specific volume scale. From this point, draw a line through the flow rate being investigated (100,000 Lb/H) and establish a point on Index 1.

7. Valves require a minimum of 50psi differential pressure to seat the valve.

38

Iron Valves

Technical Data

Y-Pattern Stop Check Valve

39

Iron Valves

Installation Recommendations

Y-Pattern Stop-Check and Isolation Gate Valves

DRAIN

Straight-Way

Y-Pattern

Installed in a horizontal line

BOILER

HEADER

HEADER

DRAIN

BOILER

Straight-Way

Y-Pattern

Installed in a vertical line for upward flow

DRAIN

BOILER

Angle Y-Pattern

Installed for horizontal-todownward flow

DRAIN

DRAIN

40

BOILER

DRAIN

Angle Y-Pattern

Installed for upwardto-horizontal flow

HEADER

HEADER

As shown in these diagrams, Stockham Y-Pattern stop-check valves used in a boiler installation can be positioned for horizontal or upward flow. The proper method for draining both Y-pattern stop-check valves and isolation gate valves is shown for typical mounting positions. Tapped and plugged drain holes are furnished. For top efficiency, be sure the proper size valve is used.

®

CRANE Energy Global Headquarters

19241 David Memorial Drive, Suite 150

Shenandoah, Texas 77385

Tel: +1-936-271-6500

Fax: +1-936-271-6510

Stockham Customer Service

2129 3 rd

Avenue, S.E.

Cullman, Alabama 35055

Tel: +1-800-STOCKHAM

Fax: +1-256-775-3860

www.craneenergy.com

CRANE Energy Flow Solutions

®

brands you know...technology you want...solutions you need

Ball, Check, Corrosion Resistant Gate and Globe Valves Valve System Solutions, Highly Engineered Specialty Valves

Lined Check and Resilient Seated Butterfly Valves

Ball, Bronze, Butterfly, Cast Steel, and Iron Valves

High Performance Wafer Check Valves

Nozzle-Type, Severe Service Check Valves

PACIFIC VALVES

High Pressure and Severe Service Valves

®

Ball, Bronze, Butterfly, Cast Steel, and Iron Valves

High Performance Butterfly and Metal Seated Valves

Cast Steel Valves

Ball, Bronze, Butterfly, Cast Steel, and Iron Valves

Certified Valve Repair Services

Aloyco, Center Line, Compac-Noz, Crane, Duo-Chek, Flowseal, Jenkins, Krombach, Noz-Chek, Pacific,

Stockham, Triangle, and Uni-Chek are all trademarks of Crane Co. ©2009

EG-SC-CT-EN-L11-01-0912 (CV-801)

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
