Canon 1730 User`s guide

Canon 1730 User`s guide
Remote UI Guide
Please read this guide before operating this product.
After you finish reading this guide, store it in a safe place for future reference.
ENG
imageRUNNER
1750i/1740i
1730i/1730
Remote UI Guide
Manuals for the Machine
The manuals for this machine are organized as shown below. Please refer to them for detailed
information. Some manuals may not be needed for certain system configurations and products
purchased.
Guides with this symbol are printed manuals.
• Installation of the Machine
• Legal Notices
• Setup Instructions
• Quick Reference for Basic Operations
• Basic Operations
• Troubleshooting
• Copying Instructions
• Sending and Fax Instructions
• Remote User Interface Instructions
• Network Connectivity
• Security Management
• Color Network ScanGear Instructions
• USB Memory Media Printing Instructions
• PS/PCL/UFRII LT Printer Instructions
• Windows Printer Driver Instructions
• Windows Fax Driver Instructions
• Macintosh Printer Driver Instructions
CD-ROM
Guides with this symbol are PDF manuals included on the
accompanying CD-ROM.
Starter Guide
User’s Guide
Easy Operation Guide
Reference Guide
CD-ROM
Copying Guide
CD-ROM
Sending and Facsimile Guide
CD-ROM
Remote UI Guide
(This Document)
CD-ROM
System Settings Guide
CD-ROM
Network ScanGear Guide
CD-ROM
Printer Guide
CD-ROM
Windows Printer Driver Guide
CD-ROM
Windows Fax Driver Guide
CD-ROM
Mac Printer Driver Guide
CD-ROM
To view the manual in PDF format, Adobe Reader/Adobe Acrobat Reader is required. If Adobe Reader/Adobe Acrobat Reader is not installed on your
system, please download it from the Adobe Systems Incorporated website.
How This Manual Is Organized
Chapter 1
Introduction to the Remote UI
Chapter 2
Managing Jobs and Machine Data
Chapter 3
Specifying Department ID and User Management
Chapter 4
Customizing Settings
Chapter 5
Appendix
Includes the glossary and index.
Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions. However, as we are constantly improving our
products, if you need an exact specification, please contact Canon.
Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
How to Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Symbols Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Keys and Buttons Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Displays Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Abbreviations Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Availability of the Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Disclaimers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Chapter 1
Introduction to the Remote UI
Overview of the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Functions of the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
The Top Page of the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Logon Modes of the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Buttons on the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
Before Using the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
Starting the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
Viewing the Machine Status and Information . . . . . . . . . . . . . . . . . . . . . . . . .1-14
Chapter 2
Managing Jobs and Machine Data
Managing Jobs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Managing the Print Jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Viewing the Job Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Managing the Address Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Editing the Destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
Importing and Exporting Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Exporting Address Book Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Importing Address Book Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13
Exporting User Management Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
Importing User Management Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15
Resetting Imported User Management Data . . . . . . . . . . . . . . . . . . . . . . . . .2-17
Exporting Additional Functions Setting Data . . . . . . . . . . . . . . . . . . . . . . . . .2-21
Importing Additional Functions Setting Data . . . . . . . . . . . . . . . . . . . . . . . . .2-23
iv
Managing Key Pairs and Digital Certificates
from a Web Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Installing and Registering a Key and Certificate . . . . . . . . . . . . . . . . . . . . . . 2-26
Deleting a Key and Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
Installing and Registering a CA Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Deleting a CA Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
Chapter 3
Specifying Department ID and User Management
Managing the Department IDs and User IDs. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Enabling Department ID Management and User Management . . . . . . . . . . . . 3-2
Managing the Department IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Managing the User IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Chapter 4
Customizing Settings
Customizing the System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Editing the LDAP Server Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Editing the Forwarding Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
Specifying the Authorized Send Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Customizing the Machine Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Specifying the SNMPv3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Enabling SNMPv3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
Specifying the User Information for SNMPv3 . . . . . . . . . . . . . . . . . . . . . . . . 4-31
Specifying the Context Settings for SNMPv3. . . . . . . . . . . . . . . . . . . . . . . . . 4-34
Verifying SSL Server Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
Chapter 5
Appendix
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
v
Preface
Thank you for purchasing the Canon imageRUNNER 1750i/1740i/1730i/1730. Please read
this manual thoroughly before operating the machine to familiarize yourself with its
capabilities, and to make the most of its many functions. After reading this manual, store it in
a safe place for future reference.
How to Use This Manual
Symbols Used in This Manual
The following symbols are used in this manual to explain procedures, restrictions,
handling precautions, and instructions that should be observed for safety.
IMPORTANT Indicates operational requirements and restrictions. Be sure to read
these items carefully to operate the machine correctly, and avoid
damage to the machine or property.
NOTE
Indicates a clarification of an operation, or contains additional
explanations for a procedure. Reading these notes is highly
recommended.
Keys and Buttons Used in This Manual
The following tables provide a few examples of how keys, buttons, and other user
interfaces such as icons displayed on the screen are expressed in this manual:
• Keys on the machine’s control panel and touch panel display:
Control Panel
Touch Panel Display
Keys
Example
Key icon + (Key Name)
(Additional Functions)
[Key Name]
[OK], [Cancel], etc.
[Key Icon]
[
], [
], etc.
• Buttons, icons and other user interfaces on computer operation screens:
Buttons and Other Objects
vi
Example
[Button Name]
[OK]
[Name] + icon, menu, etc.
[CD-ROM] icon, [Start] menu, etc.
[Icon] + (Icon Name).
[
] (New)
Displays Used in This Manual
Unless otherwise noted, the screen shots used in this manual are taken from the
imageRUNNER 1740i with the following optional equipment: Staple Finisher-H1,
Cassette Module-Y1 (triple-tiered), Super G3 Fax Board-AJ1, PCL Printer Kit-AL1,
and PS Printer Kit-AL1.
Functions that are unavailable due to a particular combination of accessories and
optional equipment are not displayed in the web browser. Therefore, the screen
shots of the Remote UI used in this manual may differ from the ones you actually
see on your web browser, depending on the model or options you have installed or
activated.
The IP addresses shown in the screen shots and text in this manual are for
illustrative purposes only.
The buttons and other objects that are related to operations during the procedure
are marked with a
, as shown in the example below.
vii
Abbreviations Used in This Manual
In this manual, product names are abbreviated as follows:
Microsoft Windows 2000 operating system:
Windows 2000
Microsoft Windows XP operating system:
Windows XP
Microsoft Windows Vista operating system:
Windows Vista
Microsoft Windows 7 operating system:
Windows 7
Microsoft Windows operating system:
Windows
Trademarks
Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S. and
other countries.
Microsoft, Windows, Windows Vista, and Internet Explorer are either registered
trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries.
Other product and company names herein may be the trademarks of their
respective owners.
Availability of the Optional Equipment
Of the optional equipment described in the manuals, the Copy Card Reader-F1
may not be available depending on the country or region of purchase. For more
information on the optional equipment, see Chapter 4, “Optional Equipment,” in the
Reference Guide.
viii
Legal Notices
Copyright
Copyright 2012 by Canon Inc. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording, or by any
information storage or retrieval system without the prior written permission of
Canon Inc.
Disclaimers
The information in this document is subject to change without notice.
CANON INC. MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL, EITHER EXPRESS OR IMPLIED, EXCEPT AS PROVIDED HEREIN,
INCLUDING WITHOUT LIMITATION, THEREOF, WARRANTIES AS TO
MARKETABILITY, MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OR USE OR NON-INFRINGEMENT. CANON INC. SHALL NOT BE
LIABLE FOR ANY DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF
ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM THE USE OF
THIS MATERIAL.
ix
x
Introduction to the Remote UI
1
CHAPTER
This chapter describes the functionality of the Remote UI and how to start it.
Overview of the Remote UI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Functions of the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
The Top Page of the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Logon Modes of the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Buttons on the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Before Using the Remote UI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Starting the Remote UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Viewing the Machine Status and Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
1-1
Overview of the Remote UI
The Remote UI (Remote User Interface) software comes preinstalled in the
machine and enables you to access the machine’s functions by using a web
browser. For example, the Remote UI enables you to check the job status, delete
jobs, and edit various settings. To use the Remote UI, all you need is a web browser
and a network connection between your computer and the machine.
Introduction to the Remote UI
1
First set the IP (Internet Protocol) address for the machine from the machine’s
control panel and set up the necessary network connection. Then start your web
browser and enter the IP address of the machine. The Remote UI top page is
displayed on your computer screen and is ready for you to log in.
Touch Panel Display
Machine’s Control Panel
Computer
You can operate the machine both with the control panel and from the Remote UI.
1-2
Overview of the Remote UI
Functions of the Remote UI
The major functions available on the Remote UI are as follows:
■ Viewing the machine status
(See “Viewing the Machine Status and Information,” on p. 1-14.)
■ Managing jobs and job logs
You can view the current status of the jobs and the job logs processed by the
machine on your computer screen. You can also delete the jobs when you log in
to the Remote UI as the System Manager or can delete your own jobs when you
log in as an End User.
(See “Managing Jobs,” on p. 2-2.)
NOTE
For the End Users to delete their own jobs, the Permit End-user’s Job Operation
setting must be enabled. (See “To specify the System Manager ID and System
Password:,” on p. 4-9.)
■ Importing and exporting the machine data
You can save and load the machine data such as Address Book data or the
Additional Functions setting data.
(See “Importing and Exporting Data,” on p. 2-11.)
■ Managing key pairs and digital certificates
You can install and register key pairs and digital certificates.
(See “Managing Key Pairs and Digital Certificates from a Web Browser,” on
p. 2-25.)
■ Specifying the Department ID Management and User Management
You can manage the Department IDs and User IDs. User IDs can be registered,
edited, or deleted only on the Remote UI, while the Department IDs can be
managed both on the machine’s control panel and on the Remote UI.
(See “Managing the Department IDs and User IDs,” on p. 3-2.)
■ Specifying the Authorized Send settings
You can specify the Authorized Send settings only on the Remote UI.
(See “Specifying the Authorized Send Settings,” on p. 4-17.)
Overview of the Remote UI
1-3
1
Introduction to the Remote UI
You can view the current status of the machine, such as the remaining paper or
toner amount, on your computer screen.
■ Customizing the Additional Functions settings
You can edit the Additional Functions settings on the Remote UI as you can by
(Additional Functions) on the machine’s control panel.
pressing
(See “Customizing Settings,” on p. 4-1.)
The Top Page of the Remote UI
1
Introduction to the Remote UI
When you enter the IP address of the machine on your web browser and press the
[ENTER] key on your computer keyboard, the Remote UI top page is displayed.
NOTE
• The appearance of the Remote UI top page depends on the management mode
applied to the machine. For more information, see “Enabling Department ID
Management and User Management,” on p. 3-2.
• For instructions on how to log in to the Remote UI, see “Starting the Remote UI,” on
p. 1-9.
1-4
Overview of the Remote UI
Logon Modes of the Remote UI
When you log in to the Remote UI by entering the System Manager ID and System
Password or the User ID registered as the System Manager and its password, the
authority of the System Manager is applied to the Remote UI, and other users (End
Users) cannot edit the System Settings and other settings restricted to the System
Manager.
Introduction to the Remote UI
■ System Manager Mode
You can access the Remote UI functions with no restrictions.
■ End-User Mode
You can access all Remote UI functions except those restricted to the System
Manager. Major functions open to End Users and the System Manager are:
• Checking the machine status such as paper or toner amount
• Checking the job status and deleting their own jobs
NOTE
For the End Users to delete their own jobs, the Permit End-user’s Job Operation
setting must be enabled. (See “To specify the System Manager ID and System
Password:,” on p. 4-9.)
• Registering or editing the addresses for the Send/Fax functions
NOTE
The Address Book can be protected by setting a password in the Restrict Send
Function page. (See “To specify the Restrict the Send Function settings:,” on p. 4-8.)
• Customizing the Additional Functions settings except those restricted to the
System Manager, such as the System Settings.
Overview of the Remote UI
1
1-5
Buttons on the Remote UI
After you have logged in to the Remote UI, the Device Status page is displayed.
The left frame of the page displays the buttons listed below, which allow you to
access and perform operations on other Remote UI pages.
Introduction to the Remote UI
1
Click to return to the Remote UI top page.
Click to display the machine status and various setting information.
Click to display the status of the jobs and the logs of the jobs
processed by the machine.
Click to manage the Address Book of the machine.
Click to specify or change various settings on the machine. This
button works similarly as the
(Additional Functions) key on the
machine’s control panel.
Click to update or refresh the current page with the latest information.
Click to display the online help for the Remote UI.
Click to return to the top of the page.
Click to return to the previous page.
1-6
Overview of the Remote UI
System Requirements
The Remote UI has been confirmed to work in the following system environments.
Introduction to the Remote UI
■ Windows
1
• OS (Operating Systems)
- Windows 2000
- Windows XP
- Windows Vista
- Windows 7
• Web Browser
- Microsoft Internet Explorer 6.0 or later
■ Macintosh
• OS (Operating System)
- Mac OS X 10.3 or later, except Classic Environment
• Web Browser
- Safari 2.0.3 or later
- Safari 1.3.2 on Mac OS X 10.3.x is also supported.
NOTE
Other than the software listed above, no other software, such as a web server, is
necessary. (There is already a web server inside the machine.)
System Requirements
1-7
Before Using the Remote UI
Before you start using the Remote UI, specify or check the following settings.
1
Introduction to the Remote UI
■ Specifying the Network Settings on the machine
• Specify or check the Network Settings to obtain or find out the IP address of the
machine.
• Confirm that the Use HTTP setting is set to ‘On’.
NOTE
• You can find the Network Settings including the Use HTTP setting by pressing
(Additional Functions) ➞ [System Settings].
• If you cannot find out the IP address of the machine, consult your network
administrator or see the System Settings Guide.
■ Enabling the Remote UI and specifying the device name
• Confirm that the Remote UI On/Off setting is set to ‘On’. If you want to establish
a more secure communication by using SSL, set the Use SSL setting to ‘On’.
Make sure to generate and specify the default SSL key pair. (See Chapter 3,
“Setting up the Machine for Your Network Environment,” in the System Settings
Guide.)
• Specify the name of the device in the Device Info Settings to identify the
machine you operate from the Remote UI by the specified name.
IMPORTANT
• Connection via a proxy server is not possible. If your system environment has a proxy
server, specify the IP address of the machine as an proxy exception on your web
browser. (Set your web browser not to access the IP address of the machine through a
proxy server.) Setting procedures vary depending on the system environment. Consult
your network administrator.
• Enable all cookies and use Java Script on your web browser. Otherwise, you will not
be able to change the machine’s settings using the Remote UI.
• If multiple Remote UIs are running simultaneously, the latest setting is enabled.
NOTE
You can find the Remote UI On/Off setting and Device Info Settings by pressing
(Additional Functions) ➞ [System Settings]. For more information on the Remote UI
On/Off setting, see Chapter 6, “Protecting the Machine from Unauthorized Access,” in
the System Settings Guide. For more information on the Device Info Settings, see
Chapter 7, “Other System Settings,” in the System Settings Guide.
1-8
Before Using the Remote UI
Starting the Remote UI
To start the Remote UI, follow the procedure below.
IMPORTANT
• The IP addresses shown in the screen shots and text in this manual are for illustrative
purposes only.
• If the Language Switch setting is set to ‘On’, some characters are restricted and
cannot be entered. To enter all characters, set the Language Switch setting to ‘Off’.
(See Chapter 3, “Configuring the Machine’s Basic Settings,” in the Reference Guide.)
• If you change the language on the Remote UI, the characters of the displayed
language can be entered. However, if the displayed language is different from the
language used on the touch panel display of the machine, the language may not be
displayed correctly.
• To enter characters from a web browser, use the characters that you can enter from
the machine’s control panel. If you use other characters, they may not be displayed or
recognized properly on the machine.
1
2
Start your web browser.
Enter the appropriate URL into [Address] or [Location] bar in the
web browser ➞ press the [ENTER] key on your computer
keyboard.
http://<the IP address of the machine>/
If you do not know the appropriate URL, consult your network administrator.
The Remote UI top page is displayed.
IMPORTANT
If the machine’s SSL communication is enabled, a security alert may be displayed
regarding the security certificate. In this case, check that the correct URL is entered,
and then proceed to display the Remote UI top page. For more information on the SSL
communication, see Chapter 3, “Setting up the Machine for Your Network
Environment,” in the System Settings Guide.
NOTE
You can change the language displayed on the Remote UI top page by clicking the
[Language] drop-down list box and selecting the desired language, regardless of the
language used on the touch panel display of the machine.
Starting the Remote UI
1-9
Introduction to the Remote UI
1
3
Enter your ID and password depending on the management mode
applied to the machine.
The required ID and password vary depending on the management mode
(Department ID/User Management) applied to the machine. For more information, see
“Enabling Department ID Management and User Management,” on p. 3-2.
● When Department ID Management and User Management are disabled:
1
Introduction to the Remote UI
❑ Select the logon mode and enter the System Manager ID and System Password, or
user name.
• To log in to the Remote UI in the System Manager Mode, select the option button
for [System Manager Mode] ➞ enter the System Manager ID and System
Password.
IMPORTANT
The System Manager ID and System Password are both set to ‘7654321’ at
purchase. Change them before using the machine. (See “To specify the System
Manager ID and System Password:,” on p. 4-9.)
• To log in to the Remote UI in the End-User Mode, select the option button for
[End-User Mode] ➞ enter the user name or leave the [User Name] text box blank.
(See the note below.)
NOTE
If you are logging in to the Remote UI in the End-User Mode and want to delete
your own print job, enter your user name with which you sent the print job (it is
usually the user name for your computer). Otherwise, click [OK] to log in to the
Remote UI with the [User Name] text box left blank. (See the note on p. 1-5.)
1-10
Starting the Remote UI
Introduction to the Remote UI
1
NOTE
• If the page is not shown correctly, check the following settings:
- Cache settings on your web browser
- HTTP port number (default is ‘80’)
• For information on other network connection problems and remedies, see
Chapter 8, “Troubleshooting,” in the System Settings Guide or consult your
network administrator.
Starting the Remote UI
1-11
● When Department ID Management is enabled:
❑ Enter the Department ID and password.
You can log in as the System Manager by entering the System Manager ID in the
[Department ID] text box and the System Password in the [Password] text box.
Introduction to the Remote UI
1
1-12
Starting the Remote UI
● When User Management is enabled:
❑ Enter the User ID and password.
You can log in as the System Manager by entering the User ID registered as the
System Manager in the [User ID] text box and its password in the [Password] text
box.
Introduction to the Remote UI
1
● When both Department ID Management and User Management are
enabled:
NOTE
The same Remote UI top page as shown in “When User Management is
enabled:,” on p. 1-13 appears.
❑ Enter the User ID and password.
You can log in as the System Manager by entering the User ID registered as the
System Manager in the [User ID] text box and its password in the [Password] text
box.
4
Click [OK].
The Device Status page appears. (See “Viewing the Machine Status and Information,” on
p. 1-14.)
Starting the Remote UI
1-13
Viewing the Machine Status and Information
When you successfully log in to the Remote UI, the Device Status page in the
[Device] menu is displayed. From the [Device] menu, you can view the current
status of the machine, information about the consumables such as paper, and other
information about the machine.
Introduction to the Remote UI
1
1
Click [Device] ➞ click the hyperlink to the page you want to
display in the [Device] menu.
The information page you selected is displayed.
1-14
Viewing the Machine Status and Information
The pages in the [Device] menu are as follows:
Displays the machine status such as available memory,
availability of consumables, and error information if any. To check
the details of the error, click [Error Information].
Device Information
page:
Displays the information about the machine, such as the system
manager’s information and the location where the machine is
installed.
Device Features
page:
Displays the information about the machine, such as the
maximum print speed, the total RAM size, and the number of the
drawers attached to the machine.
Network Settings
page:
Displays the information about the machine’s network settings.
Counter Check
page:
Displays page counts such as the total counts and copy counts.
The number and types of counters displayed may vary
depending on the machine configuration.
Viewing the Machine Status and Information
1-15
1
Introduction to the Remote UI
Device Status
page:
Introduction to the Remote UI
1
1-16
Viewing the Machine Status and Information
Managing Jobs and
Machine Data
2
CHAPTER
This chapter describes how to manage jobs, import/export data, and install key pairs and
digital certificates by using the Remote UI.
Managing Jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Managing the Print Jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Viewing the Job Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Managing the Address Book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Editing the Destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
Importing and Exporting Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Exporting Address Book Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Importing Address Book Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13
Exporting User Management Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
Importing User Management Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15
Resetting Imported User Management Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
Exporting Additional Functions Setting Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21
Importing Additional Functions Setting Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-23
Managing Key Pairs and Digital Certificates from a Web Browser . . . . . . . . . . . . . . . . . 2-25
Installing and Registering a Key and Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
Deleting a Key and Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-30
Installing and Registering a CA Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-32
Deleting a CA Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-35
2-1
Managing Jobs
You can manage the print jobs and view the logs of the jobs processed by the
machine. The [Job Status] menu has the following sections:
• Print Job
Managing Jobs and Machine Data
2
- Status
- Log
• Send/Receive Fax Job
- Log
• Send/Store/Receive Job
- Log
Managing the Print Jobs
You can manage the print jobs that are being processed or waiting to be processed
by the machine.
NOTE
End Users can delete their own print jobs, when the Permit End-user’s Job Operation
setting is enabled. (See “To specify the System Manager ID and System Password:,”
on p. 4-9.)
2-2
Managing Jobs
1
Click [Job Status] ➞ [Status] in the [Job Status] menu.
The list of print jobs being processed or waiting to be processed by the machine is
displayed.
2
To delete a print job, click [
delete ➞ [
] (Delete).
] (Select) next to the job you want to
The selected job is deleted.
Managing Jobs
2-3
Managing Jobs and Machine Data
2
Viewing the Job Logs
You can view the logs of the jobs processed by the machine. The maximum
numbers of the logs displayed are as follows:
• Print Job Log: the last 128 jobs
• Send/Receive Fax Job Log: the last 45 jobs
• Send/Store/Receive Job Log: the last 128 jobs
IMPORTANT
The Job Logs are displayed only when the Job Log Display setting in the Edit System
Settings page is enabled. (See “Customizing the System Settings,” on p. 4-2.)
Managing Jobs and Machine Data
2
1
Click [Job Status] ➞ [Log] you want to view in the [Job Status]
menu.
The screen shot above shows the screen displayed when you select the [Log] of the
<Print Job>.
The Print Job page shows a list of the jobs that have already been processed by the
machine.
2-4
Managing Jobs
Managing the Address Book
You can manage the Address Book data on the Remote UI as well as on the
machine’s control panel. The types of addresses are as follows:
■ E-mail Address
■ I-fax Address
You can manage I-fax addresses.
■ File Server Address
You can manage file server addresses with the information to save scanned
documents in a file server, such as the protocol and path name of the destination
folder.
■ Fax Number
You can manage fax numbers.
■ Group Address
You can manage group addresses, which enable you to include multiple
addresses in a single group.
NOTE
For instructions on how to manage the Address Book on the machine’s control panel,
see Chapter 4, “Specifying Destinations Easily and Quickly,” in the Sending and
Facsimile Guide.
Managing the Address Book
2-5
Managing Jobs and Machine Data
2
You can manage e-mail addresses.
Editing the Destinations
You can register, edit, or delete the destinations in the Address Book.
NOTE
The screen shots and procedures in this section are for the Address Book. The
Address Book and One-touch Speed Dial use a similar procedure for editing
destinations.
2
Managing Jobs and Machine Data
1
Click [Address] ➞ [One-touch Speed Dial] or [Address Book] from
the menu displayed under [Address].
If the address book is protected by a password, the Enter password page appears.
Enter the password ➞ click [OK].
The Address Book page is displayed.
NOTE
You can select the address numbers to display from the [Select Range] drop-down list
box.
2-6
Managing the Address Book
Edit the destinations.
● To register a new destination:
❑ Click [None] or any number for which [None] is displayed.
2
Managing Jobs and Machine Data
2
The Register New Address page is displayed.
❑ Select the type of the address from the [Type] drop-down list box ➞ specify the
necessary settings depending on the type of address you selected ➞ click [OK].
The new address is registered in the machine, and the page returns to the Address
Book page.
NOTE
For more information on the address types, see Chapter 4, “Specifying
Destinations Easily and Quickly,” in the Sending and Facsimile Guide.
Managing the Address Book
2-7
● To register a new group address:
❑ Click [None] or any number for which [None] is displayed on the page shown in step 1.
The Register New Address page is displayed.
❑ Select <Group> from the [Type] drop-down list box.
❑ Enter the name for the group in the [Group Name] text box.
❑ Click [Address Book].
The list of addresses registered in the machine is displayed in the new window.
❑ Specify the type of address from the drop-down list box.
❑ Select the check boxes next to the addresses you want to include to the group ➞
2
Managing Jobs and Machine Data
click [OK].
The selected addresses are displayed in the [Members List].
❑ Make sure that the addresses you want to add to the group are displayed in the
Members List field ➞ click [OK].
The new group address is registered and the page returns to the Address Book page.
2-8
Managing the Address Book
● To edit the details of the destination:
❑ Click the name or any number next to the name on the Address Book page shown in
step 1.
The Destination Details page appears.
❑ Click [Edit].
Managing Jobs and Machine Data
2
The Edit Destination page is displayed.
Managing the Address Book
2-9
❑ Edit the settings as necessary ➞ click [OK].
Managing Jobs and Machine Data
2
The page returns to the Address Book page.
● To delete the destination:
❑ On the Address Book page shown in step 1, click [
you want to delete ➞ [
] (Delete).
The selected destination is deleted.
2-10
Managing the Address Book
] (Select) next to the address
Importing and Exporting Data
You can save (export) setting information such as the Address Book and Additional
Functions setting data as a file. You can store the exported file as a backup and
load (import) the data into the machine when necessary.
Importing and Exporting Data
2-11
2
Managing Jobs and Machine Data
IMPORTANT
• The importing/exporting operation may take a few minutes to complete. Do not turn
the machine’s main power OFF until the operation is complete. Otherwise, the
machine may malfunction.
• During an exporting operation, the page does not change until the operation is
complete. Do not click [Start Export] while the computer indicates that the operation is
still being processed.
• The Import/Export function is available only when the Remote UI is in the System
Manager Mode.
• The importing/exporting operation is performed based on the language displayed on
the touch panel display of the machine. For example, if the language displayed on the
touch panel display and the language of the Address Book data to import do not
match, the importing operation cannot be properly performed.
Exporting Address Book Data
You can save (export) the Address Book data stored in the machine as a file.
1
Click [Add.Func.] ➞ [Import/Export] in the [Add.Func.] menu.
Managing Jobs and Machine Data
2
The Import/Export page is displayed.
2
Click [Address Book] on the page shown in step 1.
The Import/Export Address Book page is displayed.
2-12
Importing and Exporting Data
3
Click [Start Export].
4
Managing Jobs and Machine Data
2
Follow the instructions on the computer screen to specify the
location to save the file.
The file is saved in the specified location.
Importing Address Book Data
You can load (import) the Address Book data into the machine from a saved
(exported) file.
IMPORTANT
• When you load (import) the Address Book data, the addresses registered in the
machine are overwritten by the new data.
• The machine imports/exports the Address Book data based on the index numbers
displayed on the address list on the Address Book page on the Remote UI. An
address entry is overwritten if the imported Address Book data contains an address
entry with the same index number.
• Do not load the Address Book when the machine has Delayed Send jobs.
• If the machine is in the Sleep mode, press the machine’s control panel power switch to
clear the Sleep mode before performing an Import operation.
1
Click [Add.Func.] ➞ [Import/Export] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export page is displayed.
Importing and Exporting Data
2-13
2
Click [Address Book].
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export Address Book page is displayed.
3
Click [Import].
For help, see the screen shot in step 3 in “Exporting Address Book Data,” on p. 2-12.
The Import Address Book page is displayed.
Managing Jobs and Machine Data
2
4
Click [Browse] ➞ select the file to import ➞ click [OK].
The Remote UI starts importing the data and when it is complete, the page returns to
the Import/Export Address Book page.
IMPORTANT
Do not import any files while the machine is processing other jobs.
Exporting User Management Data
You can save (export) the User Management data stored in the machine as a file.
IMPORTANT
All the User IDs are exported as ‘User’ (End User).
1
Click [Add.Func.] ➞ [Import/Export] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export page is displayed.
2-14
Importing and Exporting Data
2
Click [User Management Data].
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export User Management Data page is displayed.
3
Click [Start Export].
4
Managing Jobs and Machine Data
2
Follow the instructions on the computer screen to specify the
location to save the file.
The file is saved in the specified location.
Importing User Management Data
You can load (import) the User Management data into the machine from a saved
(exported) file.
IMPORTANT
• Be sure to disable the Department ID Management and User Management before
importing the User Management data. (See “Enabling Department ID Management
and User Management,” on p. 3-2.)
• All the User IDs are registered or overwritten as ‘User’ (End User) when the machine
imports the User ID data and their passwords are cleared. You must reset the
passwords for the User IDs and for Department IDs each User ID belongs to after
importing. (See “Resetting Imported User Management Data,” on p. 2-17.)
• If the machine is in the Sleep mode, press the machine’s control panel power switch to
clear the Sleep mode before importing the data.
Importing and Exporting Data
2-15
1
Click [Add.Func.] ➞ [Import/Export] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export page is displayed.
2
Click [User Management Data].
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
2
Managing Jobs and Machine Data
The Import/Export User Management Data page is displayed.
3
Click [Import].
For help, see the screen shot in step 3 in “Exporting User Management Data,” on
p. 2-14.
The Import User Management Data page is displayed.
4
Click [Browse] ➞ select the file to import ➞ click [OK].
The Remote UI starts importing the data and when it is complete, the page returns to
the Import/Export User Management Data page.
IMPORTANT
Do not import any files while the machine is processing jobs.
2-16
Importing and Exporting Data
Resetting Imported User Management Data
For security reasons, the loaded (imported) User Management data does not
contain the passwords for User IDs and for Department IDs each User ID belongs
to. You must follow the procedure below to reset the passwords after loading
(importing) the User Management data.
1
Click [Add.Func.] ➞ [Department ID/User Management] in the
[Add.Func.] menu.
The [Department ID/User Management] page is displayed.
Importing and Exporting Data
2-17
2
Managing Jobs and Machine Data
IMPORTANT
• Before you enable Department ID Management and User Management, be sure to
reset the passwords for User IDs as directed in the procedure below.
• To reset the passwords, log in to the Remote UI in the System Manger mode. (See
“When Department ID Management and User Management are disabled:,” on
p. 1-10.)
2
Click [Settings].
Managing Jobs and Machine Data
2
The [Department ID/User Management Settings] page is displayed.
3
Click [User Management Settings].
The [Register New User] page is displayed.
2-18
Importing and Exporting Data
4
Click [Cancel] on the [Register New User] page.
Managing Jobs and Machine Data
2
Specifying the new user information is not required in this step.
The User IDs registered in the machine are displayed.
5
Click the User ID to reset the passwords.
The [Edit User] page is displayed.
Importing and Exporting Data
2-19
6
Reset the passwords ➞ click [OK].
Managing Jobs and Machine Data
2
Change Password: Select this check box and enter the password for the User ID in
(for the User ID)
the [Password] and [Confirm] text box.
NOTE
You can enter the new password for the User ID instead of entering the old
(before importing) password.
Change Password: Select this check box and enter the password for the
(for the Department Department ID the User ID belongs to in the [Password] and
ID)
[Confirm] text box.
User Type:
Specify the User Type by selecting the [User] (End User) or
[System Manager] option button.
IMPORTANT
All the User IDs are registered or overwritten as ‘User’ (End User) when the
machine imports User Management data, so you may need to reset the User
Types. If the User Types of all the User IDs are set to ‘User’ (End User), every
user is regarded as the System Manager and will be able to log in to the machine
and the Remote UI in the System Manager Mode.
2-20
Importing and Exporting Data
7
8
Repeat steps 5 and 6 to reset the passwords of the other User IDs.
Enable Department ID Management and/or User Management as
necessary after resetting the passwords for all the User IDs.
For more information, see “Enabling Department ID Management and User
Management,” on p. 3-2.
Exporting Additional Functions Setting Data
You can save (export) the Additional Functions setting data stored in the machine
as a file.
NOTE
The Additional Functions settings you can export are displayed on the page shown in
step 3.
1
Click [Add.Func.] ➞ [Import/Export] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export page is displayed.
2
Click [Additional Functions].
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export Additional Functions page including the list of the Additional
Functions settings to be exported is displayed.
Importing and Exporting Data
2-21
2
Managing Jobs and Machine Data
NOTE
To switch from the User ID list to the Department ID list, click [Department ID
Management Settings] on the [Department ID/User Management Settings] page
shown in step 3, and click [Cancel] on the [Register New Department] page. To display
the list of the User IDs again, follow steps 1 to 4.
3
Click [Start Export].
Managing Jobs and Machine Data
2
4
Follow the instructions on the computer screen to specify the
location to save the file.
The file is saved in the specified location.
2-22
Importing and Exporting Data
Importing Additional Functions Setting Data
You can load (import) the Additional Functions setting data into the machine from a
saved (exported) file.
IMPORTANT
If the machine is in the Sleep mode, press the machine’s control panel power switch to
clear the Sleep mode before performing an Import operation.
1
Click [Add.Func.] ➞ [Import/Export] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export page is displayed.
2
Click [Additional Functions].
For help, see the screen shot in step 1 in “Exporting Address Book Data,” on p. 2-12.
The Import/Export Additional Functions page including the list of the Additional
Functions settings to be imported is displayed.
3
Click [Import].
For help, see the screen shot in step 3 in “Exporting Additional Functions Setting Data,”
on p. 2-21.
The Import Additional Functions page is displayed.
Importing and Exporting Data
2-23
2
Managing Jobs and Machine Data
NOTE
The Additional Functions settings you can import are displayed on the page shown in
step 3 in “Exporting Additional Functions Setting Data,” on p. 2-21.
4
Click [Browse] ➞ select the file to import ➞ click [OK].
Managing Jobs and Machine Data
2
The Remote UI starts importing the data and when it is complete, the page returns to
the Import/Export Additional Functions page.
IMPORTANT
Do not import any files while the machine is processing other jobs.
5
Restart the machine to enable the imported settings.
Turn OFF the machine, wait at least 10 seconds, and then turn it ON.
IMPORTANT
• When Additional Functions settings data is imported, the System Manager ID,
Department IDs, Address Book password, and network settings are automatically
overwritten.
• The Remote UI cannot be used to perform other operations until the machine is
restarted.
• Do not import any files while the machine is processing other jobs.
2-24
Importing and Exporting Data
Managing Key Pairs and Digital Certificates
from a Web Browser
Key pairs and digital certificates can be used for security purposes, such as
IEEE802.1X port-based authentication and SSL communication.
■ Key and Certificate
In IEEE802.1X port-based authentication, a key pair (or a private key and
certificate) in PKCS#12 format is required for enabling the EAP-TLS method on
the client device. If you want to access the machine securely from a web browser
(Remote UI), generate a key pair and set it for SSL communications. Up to three
key pairs can be registered.
■ CA Certificate
CA certificates are used for verifying the digital certificates sent from other
devices, such as servers, client computers, etc. Up to 10 CA certificates
(including the pre-installed CA certificates) can be registered.
This section focuses on how to install and register key pairs and digital certificates
from a computer on the network. For instructions on how to generate a key pair for
SSL communications, see Chapter 3, “Setting up the Machine for Your Network
Environment,” in the System Settings Guide.
IMPORTANT
• Certificates must meet the following requirements:
- Format: X.509 version 1 or version 3 (DER encoded binary)
- Signature algorithm: SHA1-RSA, SHA256-RSA, SHA384-RSA*, SHA512-RSA*,
MD5-RSA, or MD2-RSA (For CA certificates, SHA1-DSA is also allowed.)
- Key length: 512, 1024, 2048, or 4096 bits (RSA)/2048 or 3072 bits (DSA)
- File extension: ‘.p12’ or ‘.pfx’ (for key pair files)/‘.cer’ or ‘.der’ (for CA certificate files)
* SHA384-RSA and SHA512-RSA are supported only when the key length is 1024 bits or more.
• The machine does not use certificate revocation list (CRL) for verifying digital
certificates.
• The Certificate Settings are available only when the Remote UI is in the System
Manager Mode.
Managing Key Pairs and Digital Certificates from a Web Browser
2-25
2
Managing Jobs and Machine Data
You can manage key pairs and digital certificates from the Remote UI by dividing
them into the following types:
Installing and Registering a Key and Certificate
Install a key pair (or a private key and certificate) in the machine as described
below. You can also register the key pair or delete unnecessary key pair files.
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
Managing Jobs and Machine Data
2
The Settings page is displayed.
2
Click [TCP/IP Settings] on the page shown in step 1.
The TCP/IP Settings page is displayed.
2-26
Managing Key Pairs and Digital Certificates from a Web Browser
3
Scroll the page until [Certificate Settings] appears ➞ click [Key
and Certificate Settings].
Managing Jobs and Machine Data
2
The Key and Certificate Settings page is displayed.
4
Click [Register Key and Certificate].
The Register Key and Certificate page is displayed.
Managing Key Pairs and Digital Certificates from a Web Browser
2-27
NOTE
If you want to generate an SSL key pair with the machine, click [Generate Key] ➞
enter the required information on the page that appears ➞ click [OK]. For more
information, see Chapter 3, “Setting up the Machine for Your Network Environment,” in
the System Settings Guide.
5
Select the function.
● To install a new key and certificate:
2
Managing Jobs and Machine Data
❑ Click [Install].
The Install Key and Certificate page is displayed.
❑ Click [Browse] ➞ select the key pair file to install ➞ click [Start Installation].
The Remote UI starts installing the key and certificate and when it is complete, the
page returns to the Register Key and Certificate page.
IMPORTANT
The maximum number of characters that you can enter for the file name is 24
(including the file extension ‘.p12’ or ‘.pfx’).
2-28
Managing Key Pairs and Digital Certificates from a Web Browser
● To register the key and certificate:
❑ Click [
] (Select) next to the key pair file you want to register ➞ [Register].
❑ Enter the key name and password (up to 24 characters respectively) ➞ click [OK].
The Remote UI starts registering the key and certificate and when it is complete, the
page returns to the Register Key and Certificate page.
Managing Key Pairs and Digital Certificates from a Web Browser
2-29
Managing Jobs and Machine Data
2
● To delete the installed (but not registered) key and certificate:
❑ Click [
] (Select) next to the file you want to delete ➞ [Delete].
Managing Jobs and Machine Data
2
The selected file is deleted.
6
Restart the machine.
Turn OFF the machine, wait at least 10 seconds, and then turn it ON.
Deleting a Key and Certificate
Key pairs become invalid when the certificate expires or when the file becomes
corrupted. If this happens, delete unnecessary key pair files as described below.
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
The Settings page is displayed.
2
Click [TCP/IP Settings] on the page shown in step 1.
For help, see the screen shot in step 1 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
The TCP/IP Settings page is displayed.
2-30
Managing Key Pairs and Digital Certificates from a Web Browser
3
Scroll the page until [Certificate Settings] appears ➞ click [Key
and Certificate Settings].
For help, see the screen shot in step 3 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
The Key and Certificate Settings page is displayed.
Click [ ] (Select) next to the key pair you want to delete ➞
[Delete].
2
Managing Jobs and Machine Data
4
The selected key pair is deleted.
NOTE
• If you want to display the details of a certificate, click [
] (Certificate).
• You may not be able to delete a key pair. In this case, check what the key pair is being
used for (indicated under <Key Usage>) and perform the following:
- If the key pair is used for SSL, disable the SSL settings for e-mails/I-faxes and the
Remote UI. (See Chapter 3, “Setting up the Machine for Your Network Environment,”
and Chapter 6, “Protecting the Machine from Unauthorized Access,” in the System
Settings Guide.)
- If the key pair is used for IEEE802.1X authentication, register a new key pair and set
it as the default key. (See Chapter 2, “Connecting the Machine to a TCP/IP Network,”
in the System Settings Guide.) The key pair reset to ‘Off’ can be deleted.
5
Restart the machine.
Turn OFF the machine, wait at least 10 seconds, and then turn it ON.
Managing Key Pairs and Digital Certificates from a Web Browser
2-31
Installing and Registering a CA Certificate
Install a CA certificate in the machine as described below. You can also register the
CA certificate or delete unnecessary certificate files.
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
2
Managing Jobs and Machine Data
The Settings page is displayed.
2
Click [TCP/IP Settings] on the page shown in step 1.
For help, see the screen shot in step 1 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
The TCP/IP Settings page is displayed.
3
Scroll the page until [Certificate Settings] appears ➞ click [CA
Certificate Settings].
For help, see the screen shot in step 3 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
The CA Certificate Settings page is displayed.
4
Click [Register CA Certificate].
The Register CA Certificate page is displayed.
2-32
Managing Key Pairs and Digital Certificates from a Web Browser
Select the function.
● To install a new CA certificate:
❑ Click [Install].
2
The Install CA Certificate page is displayed.
❑ Click [Browse] ➞ select the CA certificate file to install ➞ click [Start Installation].
The Remote UI starts installing the CA certificate and when it is complete, the page
returns to the Register CA Certificate page.
IMPORTANT
The maximum number of characters that you can enter for the file name is 24
(including the file extension ‘.cer’ or ‘.der’).
Managing Key Pairs and Digital Certificates from a Web Browser
2-33
Managing Jobs and Machine Data
5
● To register the CA certificate:
❑ Click [
] (Select) next to the CA certificate file you want to register ➞ [Register].
Managing Jobs and Machine Data
2
The Remote UI starts registering the CA certificate and when it is complete, the
page returns to the CA Certificate Settings page.
● To delete the installed (but not registered) CA certificate:
❑ Click [
] (Select) next to the file you want to delete ➞ [Delete].
The selected file is deleted.
6
Restart the machine.
Turn OFF the machine, wait at least 10 seconds, and then turn it ON.
2-34
Managing Key Pairs and Digital Certificates from a Web Browser
Deleting a CA Certificate
CA certificates become invalid when the certificate expires or when the file
becomes corrupted. If this happens, delete unnecessary files as described below.
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
2
2
Managing Jobs and Machine Data
The Settings page is displayed.
Click [TCP/IP Settings] on the page shown in step 1.
For help, see the screen shot in step 1 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
The TCP/IP Settings page is displayed.
3
Scroll the page until [Certificate Settings] appears ➞ click [CA
Certificate Settings].
For help, see the screen shot in step 3 in “Installing and Registering a Key and
Certificate,” on p. 2-26.
The CA Certificate Settings page is displayed.
Managing Key Pairs and Digital Certificates from a Web Browser
2-35
4
Click [ ] (Select) next to the CA certificate you want to delete ➞
[Delete].
Managing Jobs and Machine Data
2
The selected CA certificate is deleted.
NOTE
If you want to display the details of a certificate, click [
5
] (Certificate).
Restart the machine.
Turn OFF the machine, wait at least 10 seconds, and then turn it ON.
2-36
Managing Key Pairs and Digital Certificates from a Web Browser
Specifying Department ID and
User Management
3
CHAPTER
This chapter describes how to specify the Department ID Management and User Management
settings by using the Remote UI.
Managing the Department IDs and User IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Enabling Department ID Management and User Management. . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Managing the Department IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Managing the User IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10
3-1
Managing the Department IDs and User IDs
You can specify the Department ID Management and User Management settings
on the Remote UI.
IMPORTANT
• Be sure to disable User Management when the optional Copy Card Reader-F1 is
attached to the machine.
• Specifying the Department ID Management and User Management settings are
available only when the Remote UI is in the System Manager Mode.
Specifying Department ID and User Management
3
Enabling Department ID Management and User
Management
You can enable either or both the Department ID management and User
Management, depending on your needs.
IMPORTANT
• Be sure to confirm the System Manager ID and System Password are properly set to
log in to the Remote UI in the System Manager Mode before enabling Department ID
Management. (See “To specify the System Manager ID and System Password:,” on
p. 4-9.)
• Before enabling Department ID/User Management, register at least one Department
ID/User ID beforehand. (See “Managing the Department IDs,” on p. 3-6 and
“Managing the User IDs,” on p. 3-10.)
• First register a User ID as the System Manager, and then register other User IDs as
the End Users before enabling User Management. (See “To register a new User ID:,”
on p. 3-10.)
1
Click [Add.Func.] ➞ [Department ID/User Management] in the
[Add.Func.] menu.
NOTE
The list of the Department IDs switches to the list of the User IDs by clicking [Change
List View]. The [Change List View] button appears when both Department ID
Management and User Management are enabled and at least one ID is registered for
each mode.
3-2
Managing the Department IDs and User IDs
Specifying Department ID and User Management
3
The page above displays the list of the Department IDs.
The page above displays the list of the User IDs.
2
Click [Settings] on the page shown in step 1.
The Department ID/User Management Settings page appears.
Managing the Department IDs and User IDs
3-3
3
Select the [Enable Department ID Management] and/or [Enable
User Management] check box, and specify the necessary settings
➞ click [OK].
Specifying Department ID and User Management
3
The settings are as follows:
Enable Department Select this check box to enable Department ID Management.
ID Management:
When it is enabled, the users must enter their Department ID and
password (when it is set) to log in to the machine and the
Remote UI.
IMPORTANT
Before selecting this check box, make sure that at least one Department ID is
registered.
Department ID
Management
Settings:
Click this button to register a Department ID. (See “Managing the
Department IDs,” on p. 3-6.)
Enable User
Management:
Select this check box to enable User Management. When it is
enabled, the users must enter their User ID and password (when
it is set) to log in to the machine and the Remote UI.
IMPORTANT
Before selecting this check box, make sure that at least one User ID is
registered.
3-4
Managing the Department IDs and User IDs
User Management
Settings:
Click this button to register a User ID. (See “Managing the User
IDs,” on p. 3-10.)
Allow Printer Jobs
with Unknown IDs:
Select this check box to allow the machine to accept print jobs
from unknown IDs.
Allow Remote Scan Select this check box to allow the machine to accept remote
Jobs with Unknown scan jobs from unknown IDs.
IDs:
Select this check box to add the User ID to the name of the sent
document.
Clear All Counts:
Click this button to reset the counters to zero for all Department
IDs.
NOTE
For instructions on how to specify the settings above on the machine’s control panel,
see Chapter 6, “Protecting the Machine from Unauthorized Access,” in the System
Settings Guide.
Managing the Department IDs and User IDs
3-5
3
Specifying Department ID and User Management
Add Username to
Document Name:
Managing the Department IDs
You can register, edit, or delete the Department IDs.
1
Click [Add.Func.] ➞ [Department ID/User Management] in the
[Add.Func.] menu.
NOTE
The list of the Department IDs switches to the list of the User IDs by clicking [Change
List View]. The [Change List View] button appears when both the Department ID
Management and the User Management are enabled and at least one ID is registered
for each mode.
Specifying Department ID and User Management
3
The page above displays the list of the Department IDs.
3-6
Managing the Department IDs and User IDs
Specifying Department ID and User Management
3
The page above displays the list of the User IDs.
2
Edit the Department IDs.
● To register a new Department ID:
NOTE
You can register up to 1,000 Department IDs.
❑ Click [Settings] on the page shown in step 1.
The Department ID/User Management Settings page is displayed.
❑ Click [Department ID Management Settings].
The Register New Department page is displayed.
You can also display the Register New Department page by clicking [
the list of the Department IDs shown in step 1.
] (New) on
Managing the Department IDs and User IDs
3-7
❑ Specify the necessary settings on the Register New Department page ➞ click [OK].
Specifying Department ID and User Management
3
The settings are as follows:
Department ID:
Set Password:
Password:
Confirm:
Page Limits:
Enter a numeric ID (seven digits maximum).
Select this check box to set the password.
Enter a numeric password (seven digits maximum).
Enter the password again to confirm it.
Select each check box to enter the maximum number of
prints, copies, or scans that the department is allowed to
make (0 - 999999).
IMPORTANT
When the optional Copy Card Reader-F1 is attached to the machine, do not
register a new Department ID.
NOTE
• For instructions on how to specify the settings above on the machine’s control
panel, see Chapter 6, “Protecting the Machine from Unauthorized Access,” in the
System Settings Guide.
• The maximum number of digits you can register for the Department ID is seven.
If you enter fewer than seven digits, the machine automatically adds zeros to the
beginning.
Example: If <321> is entered, the Department ID will be displayed as
<0000321>.
• <Print Total> is the sum of <Copy> and <Print>.
3-8
Managing the Department IDs and User IDs
● To edit the Department ID:
❑ On the Department ID list shown in step 1, click [
] (Edit) next to the Department
ID you want to edit.
The Edit Department ID page is displayed.
❑ Edit the settings as necessary ➞ click [OK].
● To delete the Department ID:
❑ On the Department ID list shown in step 1, click [
ID you want to delete ➞ [
] (Select) next to the Department
] (Delete).
The selected Department ID is deleted.
IMPORTANT
When the optional Copy Card Reader-F1 is attached to the machine, do not
delete a Department ID.
Managing the Department IDs and User IDs
3-9
Specifying Department ID and User Management
3
Managing the User IDs
You can register, edit, or delete the User IDs.
IMPORTANT
• First register a User ID as the System Manager, and then register other User IDs as
the End Users before enabling User Management.
• If the User Types of all the User IDs are set to ‘User’ (End User), every user is
regarded as the System Manager and will be able to log in to the machine and the
Remote UI in the System Manager Mode.
• If you enable both Department ID Management and User Management, be sure to
assign a Department ID (and the password for the Department ID) to each User ID.
Users can log in to the machine and the Remote UI by entering the User ID that
belongs to a Department ID.
• User IDs can be registered, edited, or deleted only on the Remote UI, while User
Management can be enabled and disabled both on the machine’s control panel and on
the Remote UI.
Specifying Department ID and User Management
3
1
Click [Add.Func.] ➞ [Department ID/User Management] in the
[Add.Func.] menu.
For help, see the screen shot in step 1 in “Managing the Department IDs,” on p. 3-6.
2
Edit the User IDs.
● To register a new User ID:
NOTE
You can register up to 1,000 User IDs.
❑ Click [Settings] on the page shown in step 1 in “Managing the Department IDs,” on
p. 3-6.
The Department ID/User Management Settings page is displayed.
❑ Click [User Management Settings].
3-10
Managing the Department IDs and User IDs
❑ Specify the necessary settings on the Register New User page ➞ click [OK].
Managing the Department IDs and User IDs
3-11
3
Specifying Department ID and User Management
The Register New User page is displayed.
You can also display the Register New User page by clicking [
] (New) on the list
of the User IDs shown in step 1 in “Managing the Department IDs,” on p. 3-6.
The settings are as follows:
User ID:
Set Password:
Password:
Confirm:
Department ID:
Set Password:
Password:
Confirm:
3
Enter a User ID (a log-in name) (32 characters maximum).
Select this check box to set a password for the User ID.
Enter the password (32 characters maximum).
Enter the password again to confirm it.
Enter the Department ID the User ID belongs to (seven digits
maximum).
Select this check box to set a password for the Department
ID.
Enter the password (seven digits maximum).
Enter the password again to confirm it.
Specifying Department ID and User Management
IMPORTANT
If you enable both Department ID Management and User Management, be sure
to assign a Department ID (and the password for the Department ID) to each
User ID. Users can log in to the machine and the Remote UI by entering their
User ID that belongs to a Department ID.
User Type:
Display Name:
E-mail Address:
Specify the User Type by selecting the [User] (End User) or
[System Manager] option button.
Enter the user name to display (32 characters maximum).
Enter the e-mail address of the user (120 characters
maximum).
IMPORTANT
• When the optional Copy Card Reader-F1 is attached to the machine, do not
register a new User ID.
• The settings above can be specified only on the Remote UI.
3-12
Managing the Department IDs and User IDs
● To edit the User ID:
❑ Click the User ID you want to edit on the list of the User IDs shown in step 1 in
“Managing the Department IDs,” on p. 3-6.
The Edit User page is displayed.
❑ Edit the settings as necessary ➞ click [OK].
Specifying Department ID and User Management
3
Managing the Department IDs and User IDs
3-13
● To delete the User ID:
❑ Click [
] (Select) next to the User ID you want to delete ➞ [
] (Delete).
For help, see the screen shot in step 1 in “Managing the Department IDs,” on
p. 3-6.
Specifying Department ID and User Management
3
The selected User ID is deleted.
IMPORTANT
When the optional Copy Card Reader-F1 is attached to the machine, do not
delete a User ID.
3-14
Managing the Department IDs and User IDs
Customizing Settings
4
CHAPTER
This chapter describes how to customize the machine settings by using the Remote UI.
Customizing the System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Editing the LDAP Server Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Editing the Forwarding Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
Specifying the Authorized Send Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Customizing the Machine Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Specifying the SNMPv3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Enabling SNMPv3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-30
Specifying the User Information for SNMPv3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-31
Specifying the Context Settings for SNMPv3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-34
Verifying SSL Server Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
4-1
Customizing the System Settings
In the System Settings page in the [Add.Func.] (Additional Functions) menu, you
can specify the System Settings of the machine. Although many of the settings can
be specified both on the Remote UI and on the machine’s control panel, some
settings can be specified only on the machine.
You can find the System Settings on the machine’s control panel by pressing
(Additional Functions). For more information, see the System Settings Guide.
IMPORTANT
You can edit the System Settings on the Remote UI only when it is in the System
Manager Mode.
Customizing Settings
4
System Settings on the
Machine
4-2
Menus or Buttons on the Remote UI to access the
settings listed left
System Manager Settings
(System Manager’s name and
other information)
[Add.Func.] ➞ [System Settings] ➞ [Edit]
(See p. 4-5)
System Manager Settings
(System Manager ID and System
Password)
[Add.Func.] ➞ [System Settings] ➞ [Edit]
➞ [Register ID and Password]
(See p. 4-9)
Device Info Settings
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Department ID Management
[Add.Func.]
➞ [Department ID/User Management]
(See p. 3-6)
User ID Management
[Add.Func.]
➞ [Department ID/User Management]
(See p. 3-10)
Network Settings
[Add.Func.] ➞ [Settings] ➞ [Network Settings]
Communications Settings
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Forwarding Settings
[Add.Func.] ➞ [Forwarding Settings]
(See p. 4-14)
Store/Print When Forwarding
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Use SSL
(under the Remote UI On/Off
setting)
[Add.Func.] ➞ [System Settings] ➞ [Edit]
(The Remote UI On/Off setting is available only on the
machine’s control panel.)
Restrict the Send Function
[Add.Func.] ➞ [System Settings] ➞ [Edit]
➞ [Restrict the Send Function]
(See p. 4-8)
Customizing the System Settings
System Settings on the
Machine
Menus or Buttons on the Remote UI to access the
settings listed left
Register LDAP Server
[Add.Func.] ➞ [Register LDAP Server]
(See p. 4-10)
Job Log Display
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Memory Media Send Log*
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Use USB Device
[Add.Func.] ➞ [System Settings] ➞ [Edit]
PDL Selection (Plug-n-Play)
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Memory Media Settings
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Secure Print Settings
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Mem. Used When Warning
Displayed
[Add.Func.] ➞ [System Settings] ➞ [Edit]
Other Settings
Available only on the machine’s control panel.
1
Click [Add.Func.] ➞ [System Settings] in the [Add.Func.] menu.
The System Manager Settings page is displayed.
Customizing the System Settings
4
Customizing Settings
* [Memory Media Send Log] is displayed only when the Use Scan to Memory Media setting in Memory Media Settings
is set to ‘On’.
4-3
2
Click [Edit].
Customizing Settings
4
The Edit System Settings page is displayed.
4-4
Customizing the System Settings
● To specify the System Settings:
❑ Specify the necessary settings ➞ click [OK].
Customizing Settings
4
Customizing the System Settings
4-5
The settings are as follows:
<System Manager Information Settings>
System Manager:
Phone:
E-mail Address:
System Manager
Comment:
Enter the name of the System Manager (32 characters
maximum).
Enter the contact information of the System Manager (64
characters maximum).
Enter the e-mail address of the System Manager (64
characters maximum).
Enter the comments from the System Manager (64 characters
maximum).
IMPORTANT
<Phone>, <E-mail Address>, and <System Manager Comment> can be
specified only on the Remote UI.
NOTE
For instructions on how to specify the System Manager ID and System
Password, see “To specify the System Manager ID and System Password:,” on
p. 4-9.
Customizing Settings
4
<Support>
URL:
Enter the URL for supporting the users as necessary.
IMPORTANT
<Support> can be specified only on the Remote UI.
4-6
Customizing the System Settings
NOTE
For information on the settings except described above, see the following
chapters in the System Settings Guide:
Device Information
Settings:
Chapter 7, “Other System Settings”
Job Log Display:
Chapter 6, “Protecting the Machine from Unauthorized
Access”
Memory Media
Send Log:
Chapter 7, “Other System Settings”
System Manager
Chapter 1, “Before You Start”
Information Settings:
Chapter 7, “Other System Settings”
Communications
Settings:
Chapter 4, “Setting the Send Function”
E-Mail/I-Fax
Settings:
Chapter 4, “Setting the Send Function”
Fax Settings:
Chapter 4, “Setting the Send Function”
Store/Print When
Forwarding:
Chapter 4, “Setting the Send Function”
4
Customizing Settings
USB Settings:
Remote UI Settings: Chapter 6, “Protecting the Machine from Unauthorized
Access”
PDL Selection (PnP): Chapter 7, “Other System Settings”
Memory Media
Settings:
Chapter 4, “Setting the Send Function” and
Chapter 7, “Other System Settings”
Secured Print
Settings:
Chapter 7, “Other System Settings”
Memory Used When Chapter 7, “Other System Settings”
Warning Message is
Displayed:
Customizing the System Settings
4-7
● To specify the Restrict the Send Function settings:
❑ Click [Restrict the Send Function] displayed on the Edit System Settings page.
For help, see the screen shot in “To specify the System Settings:,” on p. 4-5.
The Restrict Send Function page is displayed.
❑ Specify the necessary settings ➞ click [OK].
Customizing Settings
4
NOTE
For information on the settings, see Chapter 4, “Setting the Send Function,” in
the System Settings Guide.
4-8
Customizing the System Settings
● To specify the System Manager ID and System Password:
❑ Click [Register ID and Password] on the Edit System Settings page.
For help, see the screen shot in “To specify the System Settings:,” on p. 4-5.
The Register ID and Password page is displayed.
❑ Specify the necessary settings ➞ click [OK].
The settings are as follows:
Set ID and
Password:
System Manager ID:
Set/Change
Password:
System Manager
Password:
Confirm:
Select this check box to set the System Manager ID and
System Password.
Enter the System Manager ID (seven digits maximum).
Select this check box to set or change the System Password.
Enter the System Password (seven digits maximum).
Enter again the password to confirm it.
IMPORTANT
The System Manager ID and System Password are both set to ‘7654321’ at
purchase. Change them before using the machine.
Permit End-user’s
Job Operation:
When this check box is selected, print jobs can be deleted in
the End-User Mode under the user name entered when
logging in.
IMPORTANT
<Permit End-user’s Job Operation> can be specified only on the Remote UI.
Customizing the System Settings
4-9
Customizing Settings
4
Editing the LDAP Server Settings
You can manage the LDAP server settings.
IMPORTANT
Specifying the LDAP server settings is available only when the Remote UI is in the
System Manager Mode.
NOTE
For instructions on how to edit the LDAP server settings on the machine’s control
panel, see Chapter 3, “Setting up the Machine for Your Network Environment,” in the
System Settings Guide.
Customizing Settings
4
1
Click [Add.Func.] ➞ [Register LDAP Server] in the [Add.Func.]
menu.
The Register LDAP Server page is displayed.
4-10
Editing the LDAP Server Settings
Edit the LDAP server settings.
● To register a new LDAP server:
❑ Click [
] (Register) on the page shown in step 1.
The Register LDAP Server (or Register LDAP Search Server) page is displayed.
❑ Specify the necessary settings ➞ click [OK].
4
Customizing Settings
2
NOTE
• For information on the settings, see Chapter 3, “Setting up the Machine for Your
Network Environment,” in the System Settings Guide.
• If Authorized Send is activated, <Authentication Method> appears on this page.
Specify whether to carry over the login information (user name and password) from
Authorized Send to the authentication information used when users search for e-mail
addresses and fax numbers via the LDAP server. To use the same user name and
password for LDAP search authentication, select [Assume the same authentication
information as when operation to send was started]. If not, select [Use device-specific
authentication information].
Editing the LDAP Server Settings
4-11
● To edit the LDAP server:
❑ Click the LDAP server name you want to edit on the page shown in step 1.
The Edit LDAP Server (or Edit LDAP Search Server) page is displayed.
❑ Edit the settings as necessary ➞ click [OK].
Customizing Settings
4
● To delete the LDAP server:
❑ On the page shown in step 1, click [
delete ➞ [
] (Delete).
The selected LDAP server is deleted.
4-12
Editing the LDAP Server Settings
] (Select) next to the LDAP server you want to
● To register or edit the LDAP search attributes:
❑ Click [Register/Edit LDAP Search Attributes] on the page shown in step 1.
The Register/Edit LDAP Search Attributes page is displayed.
❑ Specify or edit the necessary settings ➞ click [OK].
NOTE
For information on the settings, see Chapter 3, “Setting up the Machine for Your
Network Environment,” in the System Settings Guide.
Editing the LDAP Server Settings
4-13
Customizing Settings
4
Editing the Forwarding Settings
You can register, edit, or delete the conditions for forwarding received documents.
IMPORTANT
Specifying the Forwarding Settings is available only when the Remote UI is in the
System Manager Mode.
NOTE
For instructions on how to edit the forwarding settings on the machine’s control panel,
see Chapter 4, “Setting the Send Function,” in the System Settings Guide.
Customizing Settings
4
1
Click [Add.Func.] ➞ [Forwarding Settings] in the [Add.Func.]
menu.
The Forwarding Settings page is displayed.
2
Edit the forwarding settings.
● To register a new forwarding condition:
❑ Click [
] (Add New Conditions) on the page shown in step 1.
The Add New Conditions page is displayed.
❑ Specify the necessary settings ➞ click [OK].
4-14
Editing the Forwarding Settings
● To forward all received documents without specific conditions:
❑ Click [Forwarding without Conditions] on the page shown in step 1.
The Add New Conditions page is displayed.
❑ Specify the necessary settings ➞ click [OK].
NOTE
For information on the settings, see Chapter 4, “Setting the Send Function,” in
the System Settings Guide.
Editing the Forwarding Settings
4-15
Customizing Settings
4
NOTE
For information on the settings, see Chapter 4, “Setting the Send Function,” in
the System Settings Guide.
● To edit the forwarding condition:
❑ Click the name of the forwarding condition that you want to edit on the page shown in
step 1.
If you select [All] in the [Receive Type] drop-down list box, all the forwarding
settings registered in the machine are displayed.
The Edit Conditions page is displayed.
❑ Edit the settings as necessary ➞ click [OK].
Customizing Settings
4
● To delete the forwarding condition:
❑ On the Forwarding Settings page shown in step 1, click [
forwarding condition that you want to delete ➞ [
Conditions).
The selected forwarding condition is deleted.
4-16
Editing the Forwarding Settings
] (Select) next to the
] (Delete the Selected
Specifying the Authorized Send Settings
You can specify the Authorized Send settings on the Remote UI only.
IMPORTANT
Specifying the Authorized Send settings is available only when the Remote UI is in the
System Manager Mode.
Click [Add.Func.] ➞ [Send Function Authentication Settings] in
the [Add.Func.] menu.
4
Customizing Settings
1
The Send Function Authentication Settings page is displayed.
Specifying the Authorized Send Settings
4-17
2
Specify the necessary settings ➞ click [OK].
Customizing Settings
4
4-18
Specifying the Authorized Send Settings
The setting descriptions are as follows:
Select this check box to activate Authorized Send and
authenticate users who send documents from the machine. To
enable the settings in the Send Function Authentication Settings
page, this check box must be selected.
Display confirm
screen when
logged out:
Select this check box to display the confirmation screen when a
user logs out of Authorized Send. The log out options are [Send]
and [Device]. (See Chapter 2, “Sending Documents,” in the
Sending and Facsimile Guide.)
• [Send]: Logs out of Authorized Send only.
• [Device]: Simultaneously logs out of other security features
such as Department ID Management.
IMPORTANT
The confirmation screen appears only if the machine is locked with security
features such as Department ID Management. If the machine is locked with
security features and [Display confirm screen when logged out] is not selected, the
machine works as if [Device] is pressed when the user logs out of Authorized Send.
<LDAP Authentication Server Settings>
Press [Register] and specify the authentication server settings in the machine,
according to the server used. Up to five authentication servers can be registered.
To change or delete the registered server settings, select the desired server name and
press [Edit] or [Delete].
Specifying the Authorized Send Settings
4-19
4
Customizing Settings
Display
authentication
screen when
operation to
send is started:
Server Name:
Enter the name of the authentication server.
Server Address:
Specify the IP address or DNS name of the authentication server.
If log in to an authentication server uses the Kerberos
authentication method, the DNS name needs to be in a Fully
Qualified Domain Name (FQDN) format.
Location to Start
Search:
Specify the location of the directory tree to start searching for
user entries.
Port Number:
Specify the port number for accessing the authentication server.
The default port number is ‘389’ (non-SSL) or ‘636’ (SSL).
Attribute of User
Name:
Specify the user attribute name such as ‘sAMAccountName’ and
‘uid’. The specified attribute is used to validate the user name
entered when the user logs in to Authorized Send.
Attribute of E-mail
Address:
Specify the mail attribute name such as ‘mail’. The specified
attribute is used to obtain the currently logged on user’s e-mail
address from the authentication server. The obtained address is
specified as destination when the user presses [Send Mail To
Self]. (See Chapter 2, “Sending Documents,” in the Sending and
Facsimile Guide.)
Login Information:
Specify the authentication method used when the machine
communicates with the authentication server. Select [Use] to use
the Simple authentication method, or [Use (Security
Authentication)] to use the Kerberos authentication method. The
Kerberos authentication method is available for Active Directory.
Domain Name:
If you select [Use (Security Authentication)] for <Login
Information>, enter the directory tree name of the Active
Directory, such as <team1.salesdept.canon.co.jp>.
Use System
Manager ID:
This setting is available only when [Use] is selected from [Login
Information] as the authentication method. Select this check box
to use the administrator’s ID and password for the authentication
server when performing the first bind of the simple binding
process. If you use anonymous binding, deselect this check box.
User Name:
This text box is available only when [Use System Manager ID] is
selected. Enter the administrator’s user name.
Password:
This text box is available only when [Use System Manager ID] is
selected. Enter the administrator’s login password.
Use SSL:
This setting is available only when [Use] is selected from [Login
Information] as the authentication method. Select this check box
to use the Secure Sockets Layer (SSL) protocol when the
machine communicates with the authentication server. If you
select this check box, the value for <Port Number> automatically
changes to ‘636’.
Customizing Settings
4
4-20
Specifying the Authorized Send Settings
IMPORTANT
• For your network server settings, consult your network administrator.
• <Location to Start Search> can be left blank. In this case, the value of the
defaultNamingContext attribute is retrieved and used as the location of the directory
tree to start searching. When no value is available, the attribute value with the shortest
length in the namingContexts attributes is selected instead. If this fails, <Location to
Start Search> is left blank.
• <Attribute of User Name> cannot be specified when the Kerberos authentication
method is selected in <Login Information>. If this method is selected or <Attribute of
User Name> is left blank, ‘sAMAccountName’ is automatically used as the user
attribute name.
• If <Attribute of E-mail Address> is left blank, ‘mail’ is automatically used as the mail
attribute name.
<LDAP Search Server Settings>
Specifying the Authorized Send Settings
4-21
4
Customizing Settings
Press [Register] and specify the search server settings in the machine, according to
the server used. Up to five search servers can be registered.
To change or delete the registered server settings, select the desired server name and
press [Edit] or [Delete].
For information on the settings other than the one below, see Chapter 3, “Setting up
the Machine for Your Network Environment,” in the System Settings Guide.
Authentication
Method:
This setting is available only when Authorized Send is activated.
Specify whether to carry over the login information (user name
and password) from Authorized Send to the authentication
information used when users search for e-mail addresses and
fax numbers via the LDAP server. To use the same user name
and password for LDAP search authentication, select [Assume
the same authentication information as when operation to send
was started]. If not, select [Use device-specific authentication
information].
IMPORTANT
For your network server settings, consult your network administrator.
<Timeout Settings>
4
Customizing Settings
Authentication/
Attribute Retrieval
Timeout:
Specify the time that the machine takes to authenticate a user
against the authentication server and to retrieve attributes about
the user from the server.
IMPORTANT
Depending on the conditions such as authentication methods you are using, the
timeout time may be shorter than designated.
<SMTP Authentication Settings>
4-22
SMTP
Authentication
Basic Settings:
To edit the SMTP authentication settings, press [Change
Settings]. For instructions on how to specify the SMTP
authentication settings, see Chapter 3, “Setting up the Machine
for Your Network Environment,” in the System Settings Guide.
Authentication
Method:
You can specify whether to carry over the login information (user
name only) from Authorized Send to SMTP authentication. Select
the desired option from the following:
• [Assume the same user name as when operation to send was
started and display authentication screen]: Displays the
authentication screen with the user name for Authorized Send
automatically inserted in the [User Name] text box of the SMTP
authentication screen.
• [Display authentication screen with the authentication
information empty]: Displays the authentication screen with no
entries in the [User Name] text box of the SMTP authentication
screen. Users need to enter the user name each time they send
e-mails and I-faxes.
• [Use device-specific authentication information and do not
display authentication screen]: Does not display the
authentication screen. The user name and password specified
for the machine are used as the login information.
Specifying the Authorized Send Settings
<SMB/FTP Authentication Settings>
You can specify whether to carry over the login information (user name and password)
from Authorized Send to the authentication information used when users send
documents to a file server. Specify the settings below to suit your needs.
When Sending File
to Address
Registered in
Address Book:
This setting is used when users specify the destination by pressing
[File] on the top screen (Send) and specifying the file server
address manually. Select the desired option from the following:
• [Assume the same authentication information as when
operation to send was started and display authentication
screen]: Displays the authentication screen with the user name
and password for Authorized Send automatically inserted in the
[User] text box and the [Password] text box of the screen.
• [Display authentication screen with the authentication
information empty]: Displays the authentication screen with no
entries in the [User] text box and the [Password] text box of the
screen. Users need to enter the user name and password each
time they send documents to a file server.
This setting is used when users specify the destination by
selecting the file server address from the Address Book list.
Select the desired option from the following:
• [Assume the same authentication information as when
operation to send was started and display authentication
screen]: Displays the authentication screen with the user name
and password for Authorized Send automatically inserted in the
[User] text box and the [Password] text box of the screen.
• [Display authentication screen with the authentication
information empty]: Displays the authentication screen with no
entries in the [User] text box and the [Password] text box of the
screen. Users need to enter the user name and password each
time they send documents to a file server.
• [Use authentication information of address book and do not
display authentication screen]: Does not display the
authentication screen. The user name and password of each
address in the Address Book are used as the login information.
Specifying the Authorized Send Settings
4-23
4
Customizing Settings
When Sending File
to New Address:
When Sending File
to Own Address:
Customizing Settings
4
This setting is used when users specify the destination by
pressing [Send File To Self] on the top screen (Send). Select the
desired option from the following:
• [Assume the same authentication information as when
operation to send was started and display authentication
screen]: Displays the authentication screen with the user name
and password for Authorized Send automatically inserted in the
[User] text box and the [Password] text box of the screen.
• [Display authentication screen with the authentication
information empty]: Displays the authentication screen with no
entries in the [User] text box and the [Password] text box of the
screen. Users need to enter the user name and password each
time they send documents to a file server.
• [Assume the same authentication information as when
operation to send was started and do not display
authentication screen]: Does not display the authentication
screen. The user name and password for Authorized Send is
used as the login information.
<Send Restriction Settings>
You can enable and disable sending functionalities. Specify the settings below to suit
your needs.
4-24
E-mail Send:
• [Do not allow]: Disables user from sending e-mails and I-faxes
from the machine.
• [Allow]: Enables user to send e-mails and I-faxes from the
machine.
• [Only allow sending to own address]: Restricts the destination
of sending documents to the e-mail address of a logged on
user. With this setting, users also cannot send I-faxes from the
machine. For instructions on how to send documents to the
e-mail address of a logged on user, see Chapter 2, “Sending
Documents,” in the Sending and Facsimile Guide.
Fax Send:
• [Do not allow]: Disables user from sending faxes from the
machine.
• [Allow]: Enables user to send faxes from the machine.
Specifying the Authorized Send Settings
• [Do not allow]: Disables user from sending documents to a file
server.
• [Allow]: Enables user to send documents to a file server.
• [Only allow sending to own address or specified folder]:
Restricts the destination of sending documents to the folder of
a logged on user or to the specified folder. If Active Directory is
used as an authentication server, the home directory (folder) of
a logged on user is used as the destination. If not, or you want
to manually specify the destination folder, select [Specify
destination folder], then enter the name of the file server and
the folder name in [File Server] and [Folder Path]. Selecting
[Add user name] enables you to use the user name of a logged
on user to specify the destination of sending documents under
the specified folder. For example, if <share> is entered in
[Folder Path] and the user name of a logged on user is ‘john’,
the [john] folder in the [share] folder is specified as the
destination. For instructions on how to send documents to the
folder of a logged on user, see Chapter 2, “Sending
Documents,” in the Sending and Facsimile Guide.
<Sender E-mail Address Settings>
Specify LDAP
authentication user
address as the
sender name:
Select this check box to use the e-mail address of a logged on
user as the sender information when sending e-mails or I-faxes.
The e-mail address is displayed or printed as the sender
information at the recipient’s machine, instead of the unit name.
(See Chapter 1, “Introduction to Send and Fax Functions,” in the
Sending and Facsimile Guide.)
Specifying the Authorized Send Settings
4-25
4
Customizing Settings
File Send:
Customizing the Machine Settings
You can edit the various machine settings on the Settings page in the [Add.Func.]
(Additional Functions) menu. Although many of the settings can be made both on
the Remote UI and on the machine’s control panel, some settings are accessible
only on the machine’s control panel.
On the Remote UI, the Additional Functions settings are located as shown in the
table below.
NOTE
• You can access the Additional Functions settings from the machine’s control panel by
pressing
(Additional Functions).
• For information on the Volume Settings, see Chapter 3, “Configuring the Machine’s Basic
Settings,” in the Reference Guide.
Customizing Settings
4
Additional Functions
menu on the Machine
4-26
Menus on the Remote UI
References
Common Settings
[Add.Func.] ➞ [Settings]
➞ [Common Settings]
Chapter 3,
“Configuring the Machine’s Basic
Settings,”
in the Reference Guide
Copy Settings
Available only on the
machine’s control panel.
Chapter 4,
“Customizing Settings,”
in the Copying Guide
Timer Settings
[Add.Func.] ➞ [Settings]
➞ [Timer Settings]
Chapter 3,
“Configuring the Machine’s Basic
Settings,”
in the Reference Guide
Communications Settings
[Add.Func.] ➞ [Settings]
➞ [Send/
Receive Settings]
Chapter 7,
“Customizing the Machine’s
Settings,” in the Sending and
Facsimile Guide
Adjustment/Cleaning
Available only on the
machine’s control panel.
Chapter 5,
“Routine Maintenance,” and
Chapter 6,
“Troubleshooting,” in the
Reference Guide
Printer Settings
[Add.Func.] ➞ [Settings]
➞ [Printer Settings]
Chapter 4,
“Customizing Settings,”
in the Printer Guide
Customizing the Machine Settings
Additional Functions
menu on the Machine
Menus on the Remote UI
References
Report Settings
[Add.Func.] ➞ [Settings]
➞ [Report Settings]
Chapter 8,
“Printing Communication Reports
and Lists,” in the Sending and
Facsimile Guide
Address Book Settings
[Address]
Chapter 4,
“Specifying Destinations Easily
and Quickly,” in the Sending and
Facsimile Guide
System Settings
See the table on p. 4-2.
-
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
Customizing Settings
4
NOTE
The available settings menu varies depending on the models or options you have
installed or activated.
2
Click the setting item you want to edit.
The settings page for the selected item is displayed.
Customizing the Machine Settings
4-27
3
Edit the settings as necessary ➞ click [OK].
Customizing Settings
4
The screen shot above is for the Volume Settings.
NOTE
• For information on the settings, see the other references listed on the table in
“Customizing the Machine Settings,” on p. 4-26.
• For information on the settings of [Send Function Authentication Settings], see
“Specifying the Authorized Send Settings,” on p. 4-17.
4-28
Customizing the Machine Settings
Specifying the SNMPv3 Settings
Specify the settings for SNMPv3 as described below.
NOTE
The settings for SNMPv3 can be specified only on the Remote UI, while the settings
for SNMPv1 can be specified both on the machine’s control panel and the Remote UI.
For more information on the settings for SNMPv1, see Chapter 2, “Connecting the
Machine to a TCP/IP Network,” in the System Settings Guide.
Specifying the SNMPv3 Settings
4-29
4
Customizing Settings
IMPORTANT
• Specifying the settings for SNMPv3 is available only when the Remote UI is in the
System Manager Mode.
• Specifying the settings for SNMPv3 is available only when SSL communication is
enabled. See the following information on the settings for SSL communication.
- Chapter 3, “Setting up the Machine for Your Network Environment,” in the System
Settings Guide
- “Managing Key Pairs and Digital Certificates from a Web Browser,” on p. 2-25
Enabling SNMPv3
Enable SNMPv3 as described below.
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
Customizing Settings
4
The Settings page is displayed.
2
Click [SNMP Settings] on the page shown in step 1.
The SNMP Settings page is displayed.
4-30
Specifying the SNMPv3 Settings
3
Select the check box for [Use SNMP v. 3] ➞ click [OK].
NOTE
You can enable both SNMPv1 and SNMPv3 at the same time, depending on your
needs. For more information on settings for SNMPv1, see Chapter 2, “Connecting the
Machine to a TCP/IP Network,” in the System Settings Guide.
4
Restart the machine.
Turn OFF the machine, wait at least 10 seconds, and then turn it ON.
IMPORTANT
The setting for [Use SNMP v.3] becomes effective after the machine is restarted, while
restarting the machine is not necessary to enable the settings for [User Settings]
(p. 4-31) and [Context Settings] (p. 4-34).
Specifying the User Information for SNMPv3
Specify the user information for SNMPv3 as described below.
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Enabling SNMPv3,” on p. 4-30.
The Settings page is displayed.
Specifying the SNMPv3 Settings
4-31
Customizing Settings
4
2
Click [SNMP Settings].
For help, see the screen shot in step 1 in “Enabling SNMPv3,” on p. 4-30.
The SNMP Settings page is displayed.
3
Click [User Settings].
Customizing Settings
4
The User Settings page is displayed.
4
Select the function.
● To register a new user:
NOTE
• A default user “initial” is registered. Edit it as necessary.
- User Name: initial
- MIB Access Permission: ON
- Security Settings: Auth. Yes/Encry. Yes
- Authent. Algorithm: MD5
- Authentication Password: initial
- Encryption Algorithm: DES
- Encryption Password: initial
• You can register up to five users (including the default user “initial”).
4-32
Specifying the SNMPv3 Settings
❑ Click [Register].
The Register User page is displayed.
❑ Specify the necessary information ➞ click [OK].
Customizing Settings
4
User Name:
Enter the user name (32 alphanumeric characters
maximum).
MIB Access Permission:
Select this check box to give read/write permission to the
user.
Security Settings:
Select the security setting ([Auth. Yes/Encry. Yes], [Auth.
Yes/Encry. No], or [Auth. No/Encrypt. No]).
If you select [Auth. Yes/Encry. Yes], for example, both
authentication and encryption are enabled.
Authent. Algorithm:
Select the algorithm to be used for authentication ([MD5]
or [SHA1]).
Authentication Password:
Enter the password for authentication (6 to 16
alphanumeric characters).
Confirm:
Enter the password again to confirm it.
Specifying the SNMPv3 Settings
4-33
Encryption Algorithm:
Only [DES] can be selected as the encryption algorithm.
Encryption Password:
Enter the password for encryption (6 to 16 alphanumeric
characters).
Confirm:
Enter the password again to confirm it.
● To enable/disable a user:
❑ Select the button for the user you want to enable/disable under <Select> in the user
list ➞ click [User On/Off].
Customizing Settings
4
● To edit a user:
❑ Click the user name you want to edit in the user list in the User Settings page.
The Edit User page is displayed.
❑ Edit the information as necessary ➞ click [OK].
● To delete a user:
❑ Select the button for the user you want to delete under <Select> in the user list in the
User Settings page ➞ click [Delete].
The selected user is deleted.
Specifying the Context Settings for SNMPv3
Specify the context settings for SNMPv3 as described below.
1
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
For help, see the screen shot in step 1 in “Enabling SNMPv3,” on p. 4-30.
The Settings page is displayed.
4-34
Specifying the SNMPv3 Settings
2
Click [SNMP Settings].
For help, see the screen shot in step 1 in “Enabling SNMPv3,” on p. 4-30.
The SNMP Settings page is displayed.
3
Click [Context Settings].
For help, see the screen shot in step 3 in “Specifying the User Information for
SNMPv3,” on p. 4-31.
The Context Settings page is displayed.
Select the function.
● To register a new context:
4
NOTE
• You can register up to five contexts.
• A default context “NULL” is registered. It is not shown in the context list and cannot
be deleted.
❑ Click [Register].
The Register Context page is displayed.
❑ Enter the context name up to 32 characters ➞ click [OK].
Specifying the SNMPv3 Settings
4-35
Customizing Settings
4
● To edit a context:
❑ Click the context name you want to edit in the context list in the Context Settings
page.
The Edit Context page is displayed.
❑ Edit the context name ➞ click [OK].
● To delete a context:
❑ Select the button for the context you want to delete under <Select> in the context list
in the Context Settings page ➞ click [Delete].
The selected context is deleted.
Customizing Settings
4
4-36
Specifying the SNMPv3 Settings
Verifying SSL Server Certificates
You can set the machine to check the validity of the SSL server certificate when the
machine is receiving/sending data with POP/SMTP. The machine verifies the
certificate by checking the expiration date, certificate chain, and as well as CN
(Common Name).
IMPORTANT
The settings for the SSL server certificate verification are available only on the Remote
UI (System Manager Mode).
4
Click [Add.Func.] ➞ [Settings] in the [Add.Func.] menu.
Customizing Settings
1
The Settings page is displayed.
2
Click [E-mail/I-Fax Settings] on the page shown in step 1.
The E-mail/I-Fax Settings page is displayed.
Verifying SSL Server Certificates
4-37
3
Select the function.
● To set the machine to verify the SSL server certificate when receiving
data with POP:
❑ Select the check box for [Confirm SSL Certificate for POP RX].
To include the CN (Common Name) for the verification, select the check box for [Add
CN to Verification Items].
● To set the machine to verify the SSL server certificate when sending data
with SMTP:
❑ Select the check box for [Confirm SSL Certificate for SMTP TX].
To include the CN (Common Name) for the verification, select the check box for [Add
CN to Verification Items].
Customizing Settings
4
IMPORTANT
If you do not enable the SSL server certificate verification settings described
above, SSL communication may be performed even with an invalid certificate.
4-38
Verifying SSL Server Certificates
NOTE
If the machine detects a problem with the certificate, communication will not be
completed and the error message <SSL Error (POP)> or <SSL Error (SMTP
Send)> (error code #0842 for the job log) will be displayed.
4
Click [OK] on the page shown in step 3.
5
Restart the machine.
Turn OFF the machine, wait at least 10 seconds, and then turn it ON.
Customizing Settings
4
Verifying SSL Server Certificates
4-39
Customizing Settings
4
4-40
Verifying SSL Server Certificates
Appendix
5
CHAPTER
This chapter includes the glossary and index.
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5-1
Glossary
B
BOOTP
BOOTstrap Protocol. A protocol that enables a client machine to automatically obtain
network setup information from a server over a TCP/IP network. BOOTP enables a
client to automatically locate such information as the host name, domain name, and
IP address, so that it is not necessary to enter these items manually.
bps
Stands for bits per second. The measure of transmission speed used in relationship
to networks and communication lines.
5
Appendix
C
Cookie
A file left on a user’s computer when the user visits a Web site. A cookie allows the
Web site to recognize the user on subsequent visits. Cookies are generally used to
enable a user to automatically sign on to certain Web sites and to customize the
features offered by such sites.
D
DHCP
Dynamic Host Configuration Protocol. A protocol which automatically specifies the
network settings of a client on a TCP/IP network. Many of the settings required to set
up TCP/IP, which is the standard protocol of the Internet, can be made automatically
using DHCP.
F
FTP
File Transfer Protocol. A client-server protocol enabling a user to transfer files on one
computer to and from another computer over a TCP/IP network. The File Transfer
Protocol also governs the client program with which the user transfers files.
5-2
Glossary
H
HTTP
Hypertext Transfer Protocol. The client-server TCP/IP protocol used on the World
Wide Web for the transfer of HTML (Hyper Text Mark-up Language) documents
across the Internet.
I
IEEE802.1X authentication
An authentication method that permits only supplicants (devices) authenticated by a
RADIUS (Remote Authentication Dial-In User Service) server to connect to the
network via an authenticator.
Internet Protocol (IP)
IP address
Internet Protocol address. A network address used by IP (Internet Protocol) to specify
a computer or device on the Internet. Currently, two versions of IP are in use: IPv4
and IPv6.
IPv4
Internet Protocol version 4. An IPv4 address is a 32-bit numeric address, usually
written as four numbers delimited by periods. For example, ‘128.121.4.5’.
IPv6
Internet Protocol version 6. An IPv6 address is 128-bit long and consists of eight
groups of four hexadecimal digits delimited by colons. For example,
‘2002:0db6:58b1:02c3:3308:7a2e:6309:2665’. In an IPv6 network, a computer or
device can use multiple addresses, as represented by link local address, stateless
address, etc.
L
LDAP
Lightweight Directory Access Protocol. A network protocol that enables you to locate
organizations, individuals, and other resources, such as files and printers on a
network, whether on the public Internet or on a corporate intranet.
Glossary
5-3
5
Appendix
The underlying set of networking rules that describes how data is transmitted across
the Internet. Internet Protocol enables data from one computer to be split into
packets, and sent to another computer with a specific IP address.
P
PDF
Portable Document Format. The page description language used in Adobe Systems’
Acrobat document exchange system, which is restricted neither by device nor
resolution. PDF displays documents in a way that is independent of the original
application software, hardware, and operating system used to create those
documents. A PDF document can contain any combination of text, graphics, and
images.
Protocol
A set of rules that govern the transmission of data across a network. Examples of
protocols are DHCP, BOOTP, RARP, and TCP/IP.
Proxy server
A server that provides a cache of files available on remote servers that are slow or
expensive to access. The term “proxy server” normally refers to a World Wide Web
server that, upon receiving a URL, tries to supply the requested file from its cache. If
the proxy server cannot locate the file in its cache, it obtains the file from the remote
server, and saves a copy in its cache so that the next request can be obtained locally.
Appendix
5
R
RARP
Reverse Address Resolution Protocol. A protocol which associates a network adapter
address (MAC address) with an IP (Internet Protocol) address.
Remote UI
Remote User Interface. The Remote UI is software that enables you to perform
operations, which are usually performed on the machine’s control panel, using a Web
browser (such as Microsoft Internet Explorer or Safari) over a network.
S
SSL
Secure Sockets Layer. A protocol that ensures security and privacy when transmitting
private documents over the Internet.
SSL encryption
SSL uses two keys to encrypt data: a public key, which is known to “everyone,” and a
private or secret key, which is known only to the recipient of the message.
5-4
Glossary
T
TCP/IP
Transmission Control Protocol/Internet Protocol. The protocol used to connect to the
Internet or wide area networks.
U
URL
Uniform Resource Locator. A standard way of specifying the location of an object,
usually a Web page on the Internet. The URL for a Web page would look something
like this: “http://www.w3.org/default.htm”. Here, “http:” indicates that a Web page is
being accessed, “www.w3.org” is the address of the server containing the Web page,
and “default.htm” is the file name under which the Web page is stored on the server.
Appendix
5
Glossary
5-5
Index
Appendix
5
A
E
Add.Func. menu
(Additional Functions menu), 4-2, 4-26
Additional Functions setting data
Exporting, 2-21
Importing, 2-23
Address Book, 2-5
Deleting the destination, 2-10
Editing the destination, 2-9
Exporting, 2-12
Importing, 2-13
Registering a new destination, 2-7
Registering a new Group Address, 2-8
Authorized Send, 4-17
End-User Mode, 1-10
F
Forwarding Settings, 4-14
Deleting the Forwarding Condition, 4-16
Editing the Forwarding Condition, 4-16
Forwarding Documents without specific
conditions, 4-15
Registering a Forwarding Condition, 4-14
FTP, 5-2
H
B
HTTP, 5-3
BOOTP, 5-2
bps, 5-2
Buttons on the Remote UI, 1-6
I
CA certificate, 2-25
Cookie, 5-2
IEEE802.1X authentication, 2-25, 5-3
Internet Protocol (IP), 5-3
IP address, 1-4, 1-9, 5-3
IPv4, 5-3
IPv6, 5-3
D
J
Department ID
Deleting, 3-9
Editing, 3-9
Registering, 3-7
Department ID Management, 3-2
Enabling, 3-2
DHCP, 5-2
Job Logs, 2-4
C
5-6
Index
K
Key and certificate, 2-25
L
S
LDAP search attributes, 4-13
LDAP server, 4-10
Deleting, 4-12
Editing, 4-12
Registering, 4-11
Logon mode, 1-5, 1-10
End-User Mode, 1-5
System Manager Mode, 1-5
Machine settings, customizing, 4-26
SNMPv3, 4-29
SSL, 5-4
SSL encryption, 5-4
SSL server certificate, 4-37
System Manager ID, specifying, 4-9
System Manager Mode, 1-10
System Password, specifying, 4-9
System requirements, 1-7
OS (Macintosh), 1-7
OS (Windows), 1-7
Web browser (Macintosh), 1-7
Web browser (Windows), 1-7
System Settings, specifying, 4-5
P
T
PDF, 5-4
Print Job, managing, 2-2
Protocol, 5-4
Proxy server, 5-4
TCP/IP, 5-5
Top page of the Remote UI, 1-4
5
Appendix
M
U
R
RARP, 5-4
Remote UI, 5-4
Restrict the Send function, specifying, 4-8
URL, 1-9, 5-5
User ID
Deleting, 3-14
Editing, 3-13
Registering, 3-10
User Management, 3-2
Enabling, 3-2
User Management data
Exporting, 2-14
Importing, 2-15
Resetting, 2-17
W
Web browser, 1-4, 1-7, 1-9
Index
5-7
Appendix
5
5-8
Index
CANON INC.
30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON U.S.A., INC.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
CANON CANADA INC.
6390 Dixie Road Mississauga, Ontario L5T 1P7, Canada
CANON EUROPA N.V.
Bovenkerkerweg 59-61 1185 XB Amstelveen, The Netherlands
(See http://www.canon-europe.com/ for details on your regional dealer)
CANON LATIN AMERICA, INC.
703 Waterford Way Suite 400 Miami, Florida 33126 U.S.A.
CANON AUSTRALIA PTY. LTD
1 Thomas Holt Drive, North Ryde, Sydney, N.S.W. 2113, Australia
CANON CHINA CO., LTD
15F Jinbao Building No.89 Jinbao Street, Dongcheng District, Beijing 100005, China
CANON SINGAPORE PTE. LTD.
1 HarbourFront Avenue #04-01 Keppel Bay Tower, Singapore 098632
CANON HONGKONG CO., LTD
19/F., The Metropolis Tower, 10 Metropolis Drive, Hunghom, Kowloon, Hong Kong
USRM2-2197-00
© CANON INC. 2012
