Brochure Ariston GL2.5-6

Brochure Ariston GL2.5-6
Ariston GL2.5; GL4; GL6+
Electric Point-of-Use Mini-Tank Water Heaters
Installing an Ariston electric mini-tank water heater
under the sink puts hot water right where you need it –
at the point of use. Lightweight and compact, this water
heater is available in three space-saving sizes: 2.5, 4 and 6+
gallons. These water heaters are aesthetic on the outside,
glass-lined on the inside, and offer superior insulation for
higher efficiency.
Ariston GL2.5; GL4; GL6+
Electric point-of-use water heaters
GL2.5 for 1 sink; GL4 for 2 sinks; GL6+ for 2 or more sinks.
Features
•
•
•
•
•
•
•
•
•
•
Glass-lined tank for longer life
6-year warranty on tank
All models plug into standard 120-volt outlet
Easy installation
Temperature/pressure relief valve included
GL6+ model can be mounted horizontally or vertically
Meets ASHRAE 90.1 standard
Mounts on wall or floor
Three sizes to choose from
Elegant Italian design
GL6+
GL2.5
GL4
Technical Specifications
ARISTON
GL2.5
GL4
GL6+
Tank Volume
2.75 gallons
3.85 gallons
7.0 gallons
Dimensions
14" x 14" x 10 ¼"
14" x 14" x 12 ¼"
Voltage
120V
Amperage
12.5 amps
12.5 amps
Wire Type
Plug-in
Plug-in
Heating Capacity
1500 watts
1500 watts
Recovery at 90˚F Rise
7 gph
7 gph
Temperature Range
65-145˚F
65-145˚F
65-145˚F
Water Connections
½" NPT
½" NPT
¾" NPT
Operating Pressure
150 PSI
150 PSI
150 PSI
Relief Valve
Installed
Installed
17 ½" x 17 ½" x 14 ½"
120V
120V
12.5 amps
Plug-in
1500 watts
7 gph
Included
gph: gallons per hour
Easy Installation
Simply tap into the cold water line and install the water heater directly
at the sink. All models plug into a standard 120 volt outlet. And when
you want to eliminate the wait for hot water but need more volume,
install the Ariston water heater in-line with a larger hot water source.
BBT NORTH AMERICA CORPORATION
Bosch Group
Bosch Water Heating
340 Mad River Park
Waitsfield, VT 05673
866.642.3199 • www.boschhotwater.com
77799017-L
