C191HM

Powermeter and

Harmonic

Manager

Installation and Operation

Manual

BG0

280 Rev. A4

C191HM Powermeter &

Harmonic Manager

Installation and Operation

Manual

LIMITED WARRANTY

The manufacturer offers the customer an 24-month functional warranty on the instrument for faulty workmanship or parts from date of dispatch from the distributor. In all cases, this warranty is valid for 36 months from the date of production. This warranty is on a return to factory basis.

The manufacturer does not accept liability for any damage caused by instrument malfunction. The manufacturer accepts no responsibility for the suitability of the instrument to the application for which it was purchased.

Failure to install, set up or operate the instrument according to the instructions herein will void the warranty.

Your instrument may be opened only by a duly authorized representative of the manufacturer. The unit should only be opened in a fully anti-static environment.

Failure to do so may damage the electronic components and will void the warranty.

NOTE

The greatest care has been taken to manufacture and calibrate your instrument.

However, these instructions do not cover all possible contingencies that may arise during installation, operation or maintenance, and all details and variations of this equipment are not covered by these instructions.

For additional information regarding installation, operation or maintenance of this instrument, contact the manufacturer or your local representative or distributor.

IMPORTANT

Please read the instructions this manual before performing installation, and take note of the following precautions:

Ensure that all incoming AC power and other power sources are

turned OFF before performing any work on the instrument. Failure to do so may result in serious or even fatal injury and/or equipment damage.

Before connecting the instrument to the power source, check the labels on the side of the instrument to ensure that your instrument is equipped with the appropriate power supply voltage, input voltages, currents and communication protocol for your application.

Under no circumstances should the instrument be connected to a power source if it is damaged.

To prevent potential fire or shock hazard, do not expose the instrument to rain or moisture.

i

ii

The secondary of an external current transformer must never be allowed to be open circuit when the primary is energized. An open circuit can cause high voltages, possibly resulting in equipment damage, fire and even serious or fatal injury. Ensure that the current transformer wiring is made through shorting switches and is secured using an external strain relief to reduce mechanical strain on the screw terminals, if necessary.

Setup procedures must be performed only by qualified personnel familiar with the instrument and its associated electrical equipment.

DO NOT open the instrument under any circumstances.

Modbus is a trademark of Modicon, Inc.

Read this manual thoroughly before connecting the meter to the current carrying circuits. During operation of the meter, hazardous voltages are present on input terminals. Failure to observe precautions can result in serious or even fatal injury or damage to equipment.

BG0280 Rev. A4

Table of Contents

Quick Start ........................................................................................ iv

Chapter 1 Introduction .................................................................... 1

1.1

About This Manual.................................................................................. 1

1.2

About The C191HM ................................................................................. 1

Chapter 2 Installation ...................................................................... 7

2.1

Mechanical Installation .......................................................................... 7

2.2

Electrical Installation.............................................................................. 8

Chapter 3 Using The Menus ........................................................... 18

Chapter 4 Setup Menus................................................................... 20

4.1

Basic Setup Menu................................................................................... 20

4.2

Communications Port Setup Menu ....................................................... 22

4.3

Digital Input Setup Menu........................................................................ 23

4.4

Analog Output Setup Menu.................................................................... 24

4.5

Pulsing Output Setup Menu................................................................... 26

4.6

Alarm/Event Setpoints Setup Menu ...................................................... 27

4.7

Relay Operation Control Menu .............................................................. 32

4.8

Display Setup Menu................................................................................ 33

4.9

User Selectable Options Menu .............................................................. 35

4.10

Access Control Menu ............................................................................. 37

4.11

Reset/Synchronization Menu................................................................. 38

Chapter 5 Data Display ................................................................... 39

5.1

Navigating in the Display Mode............................................................. 39

5.2

Data Display Formats ............................................................................. 42

5.3

Self-Test Diagnostics Display................................................................ 46

Chapter 6 Viewing Status Information........................................... 47

6.1

The Status Information Menu ................................................................ 47

6.2

Status Display Formats.......................................................................... 47

Appendix: Technical Specifications .............................................. 49

Index .................................................................................................. 54

iii

Quick Start

TYPICAL INSTALLATION

Wiring Mode 4LL3

(see Section 2.2.4 for full instructions)

LINE 1(A)

LINE 2(B)

LINE 3(C)

N

K L

K L

K L

SW1

1A

PC

(PLC)

RS-485

LOAD

+ _

Shorting

Switches

+

UP TO 3 1

DEVICES

24V

LOAD

5

2

V

1

+

16 18

-

19

ANALOG OUTPUT x

13

+

Tx

14

-

Rx

15

RS-485

RS-232

I

1

1

3

V

2

I

2

4

6

8

V

3

V

11

N

1

RELAYS

2 3 4 5 6 7 8

INPUT

I

3

7

9

10

12

20 21 22 23 24 25 26 27 28 29 30 31 32

33

L

N

LINE AC

N

SW2

5A

LOAD

N

120-

230V AC

N N

120-

230V AC

120-

230V AC

N

iv

SETUP

(see Chapter 4 for full instructions)

Setups can be performed directly on the front panel or via PComTest communication software.

menu option value

bASc

ConF

4L-n

Press

⇑ ⇓ to scroll to desired option.

Press

⇑ ⇓ to scroll to desired value.

menu option

Port

Prot

ASCII

Pt

Ct

Freq

LoAd

Addr bAud dAtA

CPtb value

Basic and Communications Default Setups

Code

ConF d.P n.dp

A.dP buF rSt

Prot

Parameter Options Description

Wiring mode

PT ratio

CT primary current

Power demand period

Number of power demand periods

Ampere/Volt demand period

4Ln3

1.0

5

15

1

900

4-wire Wye using 3 PTs (3 element), line to neutral voltage readings

The phase potential transformer ratio

The primary rating of the phase current transformer, A

The length of the demand period for power demand calculations, in minutes. E = external synchronization

The number of demand periods to be averaged for sliding window demands

1 = block interval demand calculation

The length of the demand period for volt/ampere demand calculations, in seconds

0 = measuring peak current

Averaging buffer size

8

Reset enable/disable

diS

Protects all reset functions, both via the front panel or communications.

Nominal frequency

50/, 60

The nominal power utility frequency, Hz

Maximum demand load current

0

The number of measurements for RMS sliding averaging

The maximum demand load current used in

TDD calculations (0 = CT primary current)

Communications protocol

ASCII

Address

Baud rate

Data format

0 (ASCII)

9600

8n

ASCII compatibility mode

diS

ASCII protocol

Powermeter address

9600 bps

8 bits, no parity

Disables ASCII compatibility mode (For more information, see ASCII Communications

Protocol Reference Guide)

v

Chapter 1 Introduction

1.

1.1 About This Manual

This manual is intended for the user of the C191HM Powermeter. This

Powermeter is a microprocessor-based instrument used for the measurement, monitoring, and management of electrical parameters.

This chapter gives an overview of this manual and an introduction to the

C191HM.

Chapter 2, Installation, provides instructions for mechanical and electrical installation.

Chapter 3, Using the Menus, presents the structure of menus for setup and status viewing.

Chapter 4, Setup Menus, provides instructions for performing parameter setup via the front panel.

Chapter 5, Data Display, guides you through the display pages.

Chapter 6, Viewing Status Information, tells you how to access additional status information on the instrument. This information may be useful during installation.

Chapter 7 contains Technical Specifications for the C191HM.

1.2 About The C191HM

The C191HM is a compact panel mounted three-phase AC Powermeter and

Harmonic Manager, specially designed to meet the requirements of users ranging from electrical panel builders to substation operators. The C191HM provides basic voltage, current, frequency, power, power factor and energy measurements, plus total harmonic distortion (THD, TDD and K-Factor) and individual harmonic measurements.

The C191HM is suitable for mounting on 136x136mm square cut-outs.

Features

Harmonic Measurements

Individual voltage and current harmonics with harmonic angles up to order 40.

Harmonic power direction (through PAS software)

Synthesized voltage and current waveforms (through PAS software)

Display

The front panel features bright LED displays (three windows, up to 45 pages) with adjustable display update time. Display auto scroll is available on the main

Chapter 1 Introduction 1

2

screen with a programmable scroll interval of 2 to 15 seconds. Automatic return to the main screen is available after 30 seconds of uninterrupted use. The front panel also includes:

bar graph showing percentage load with respect to user-definable nominal

(100%) load current

alarm LED providing a local indication when a predefined alarm condition appears. The alarm LED is shut off manually (by pressing on both up and

down keys more than 5 sec)

RXD/TXD LEDs showing communications receive/transmit status

Setup is menu driven, with optional password protection. 16 programmable setups are provided for alarm and control functions (for programmable parameters, see ‘Measured Parameters’ below).

Communications are available using an RS-232 or RS-485 standard (factory set), with ASCII/Modbus (and optional DNP3.0) protocols. 120 user assignable registers are available in ASCII/Modbus protocols.

Eight relays are provided for energy pulsing (KYZ) or alarm and remote control.

Contacts of six relays may switch loads up to 250V, 5A AC and are recommended for alarm and remote control; contacts of two relays may switch loads up to 250V, 3A AC and may be used for energy pulsing.

One optically isolated analog output is provided for remote monitoring or control. Current loop options are 0-20 and 4-20 mA. The analog output must be used with an external power supply.

Four counters are provided for counting user-defined events or their duration.

These can be used for counting total operation time of generators or overload time of transformers or power lines. The counters are operated and released by user-defined triggers.

One digital input can be used as a status input for monitoring external contacts or as an external synchronization input for power demand interval synchronization. When no external synchronization pulse is provided, the power demand interval can be synchronized through communications.

Three user-selectable options are provided:

Power calculation mode

Energy rollover value

This option specifies the point at which the energy value rolls over to zero.

Phase energy calculations mode

This option is used to enable or disable phase energy calculations.

Chapter 1 Introduction

Measured Parameters

Note: Real-time values are measured over 1 cycle of fundamental frequency; Average values are of 8, 16 or 32 real-time values

Average Amps, Volts, Frequency

Average RMS voltage per phase L-N

Average RMS voltage per phase L-L

Average RMS current per phase

Average frequency

Average neutral current

Voltage & current unbalance

Amps & Volt Demand Parameters

Ampere demand per phase

Volt demand per phase

Ampere maximum demand per phase

Voltage maximum demand per phase

Average Power Values

Average active power per phase

Average reactive power per phase

Average apparent power per phase

Average total active power

Average total reactive power

Average total apparent power

Average power factor per phase

Average total power factor

Power Demand Parameters

Active power accumulated demand

Apparent power accumulated demand

Active power demand

Active power sliding demand

Apparent power demand

Apparent power sliding demand

Active power predicted demand

Apparent power predicted demand

Active power maximum demand

Apparent power maximum demand

Energy Per Phase

Active energy import per phase

Reactive energy import per phase

Apparent energy per phase

Total Energy

Total active energy import

Chapter 1 Introduction

$ = setup via PC

# = setup via panel

#$ #$

√ #$ #$

√ #$ #$

√ #$ #$

√ #$

√ #$

√ #$ #$

√ #$ #$

√ #$ #$

√ #$ #$

√ #$ #$

√ #$ #$

√ #$

√ #$

√ #$

√ #$

√ #$

√ #$

√ #$

3

4

Total active energy export

Total reactive energy import

Total reactive energy export

Total reactive energy net

Total reactive energy absolute

Total apparent energy

Min/Max Log

Min/Max volts

Min/Max amps, neutral current

Min/Max frequency

Min/Max kW, kvar, kVA, PF

Real-time Amps, Volts, Frequency

RT RMS voltage per phase L-N

RT RMS voltage per phase L-L

RT RMS current per phase

RT frequency

RT neutral current

Real-time Power Values

RT active power per phase

RT reactive power per phase

RT apparent power per phase

RT total active power

RT total reactive power

RT total apparent power

RT power factor per phase

RT total power factor

Real-time Harmonic Values

RT voltage THD per phase

RT current THD per phase

RT current TDD per phase

RT K-Factor per phase

Average Harmonic Values

Average Voltage THD per phase

Average Current THD per phase

Average Current TDD per phase

Average K-Factor per phase

Fundamental Frequency Values (H01)

Voltage & current per phase kW, PF per phase kvar, kVA per phase

Total kW, PF

Total kvar, kVA

√ #$

√ #$

√ #$

#$

√ #$

#$ #$

√ #$ #$

√ #$ #$

√ #$

√ #$

√ #$

√ #$

√ #$

√ #$

√ #$

√ #$

Chapter 1 Introduction

Individual Harmonic Distortion

Voltage harmonics 1-40 per phase

Current harmonics 1-40 per phase

Odd voltage harmonics 3-39 per phase

Odd current harmonics 3-39 per phase

High odd voltage harmonics 3-39 triggers

High odd current harmonics 3-39 triggers

Voltage harmonics angles 1-40 per phase

Current harmonics angles 1-40 per phase

Phase Rotation

Counters

Status Input

Relay Status

Remote Relay Control

Alarm Trigger Status

Self-Diagnostic Tests

√ #$

#$

#$

√ #$

√ #$

For 4Ln3 and 3Ln3 wiring configurations line to line and line to neutral voltages are displayed and transmitted via communication simultaneously; analog output and set points use line to neutral voltages. For other configurations only line to line voltages are used.

Chapter 1 Introduction 5

6

Instrument Dimensions

86 mm

MA

MIN

C19

1HM

LO

AD %

ESC

ALA

RM

K

1

K

2

K

3

K

4

V1,V kVA

2-2

Ane utra l

V2/V

2-3

144m m

K

5

K

6

K

7

K

8

SEL

ECT

EN

ERG

ENT

Y

ER

V3,V kW k va r

3-1

Figure 1-1 C191HM Dimensions

c99-10021/2

Chapter 1 Introduction

Chapter 2 Installation

2.

2.1 Mechanical Installation

Prepare the panel cut-out, 136 x 136 mm, prior to mounting.

STEP 1: Place the instrument through the cut-out.

STEP 2: Assemble the latches onto the outer wall of the enclosure.

STEP 3: Tighten the screws.

C191

HM

STE

STE

P 2

P 3

STE

P 1

136.

0

+1.0

Figure 2-1 Mounting the C191HM

c99-09046/2

Chapter 2 Installation 7

2.2 Electrical Installation

Before installation ensure that all incoming power sources are shut

OFF. Failure to observe this practice can result in serious or even fatal injury and damage to equipment.

2.2.1 Power Supply Connection

The power supply can be dedicated-fused, or from a monitored voltage if it is within the instrument’s power supply range. Use an external circuit breaker or switch.

AC power supply: line to terminal 12; neutral to terminal 10.

DC power supply: positive to terminal 12; negative to terminal 10.

2.2.2 Current Inputs

Connect the instrument to the current transformer as shown in Figures 2-2 through 2-8.

2.2.3 Ground

Connect the chassis ground C191HM terminal to the switchgear earth ground using dedicated wire of greater than 2.5 mm

2

/13 AWG.

2.2.4 Voltage Inputs

Input of 690V (Standard): Use any of the seven wiring configurations shown in

Figures 2-2 through 2-8.

Input of 120V (Option U): 120V input usually implies use of a potential transformer (PT). The PT requires use of any of the four wiring configurations shown in Figures 2-4 through 2-7.

8

Chapter 2 Installation

Wiring Configuration

(See parameter setup instructions in Section 4.1)

3-wire direct connection using 2 CTs (2-element)

4-wire WYE direct connection using 3 CTs (3-element)

4-wire WYE connection using 3 PTs, 3 CTs (3-element)

Setup Mode Connection

3dir2

4Ln3 or 4LL3 Figure 2-3

4Ln3 or 4LL3 Figure 2-4

3-wire open delta connection using 2 PTs, 2 CTs (2-element) 3OP2

Wiring

Figure 2-2

Figure 2-5

4-wire WYE connection using 2 PTs, 3 CTs (2½-element)

4-wire delta direct connection using 3 CTs (3-element)

LINE 1 (A)

LINE 2 (B)

LINE 3 (C)

3Ln3 or3LL3 Figure 2-7

4Ln3 or 4LL3 Figure 2-8

Voltages

2

5

8

11

Currents

-

1

+

3

-

4

6

7

9

10

+

-

12

K

+ -

L

K

+

-

L

LOAD

Shorting

Switches

Figure 2-2

Three Wire Direct

Connection Using 2

CTs (2-element)

Wiring Mode = 3dir2 c99-09042

Chapter 2 Installation 9

LINE 1 (A)

LINE 2 (B)

LINE 3 (C)

N

Voltages

V

1

V

2

V

3

Currents

1

+

-

3

4

+

6

-

7

+

9

-

10

V

N

12

K

+

-

L

K

+

-

L

K

+

-

L LOAD

Shorting

Switches

Figure 2-3

Four Wire WYE Direct

Connection Using 3

CTs (3-element)

Wiring Mode = 4LL3 or 4Ln3 c99-09036

LINE 1 (A)

LINE 2

LINE 3

(B)

(C)

N

+

-

+

-

+

-

+

-

+

-

+

-

Voltages

2

5

8

11

V

V

V

1

2

3

V

N

Currents

1

+

3

-

4

+

6

-

7

+

9

-

10

12

K L

K

+

-

L

K

+

-

L LOAD

Figure 2-4

Four Wire WYE

Connection Using 3

PTs, 3 CTs (3element)

Shorting

Switches

Wiring Mode = 4LL3 or 4Ln3 c99-09037

10

Chapter 2 Installation

LINE 1 (A)

LINE 2 (B)

LINE 3 (C)

-

+

-

+

+ +

K

+ -

L

K

+ -

L

LOAD

Shorting

Switches

Figure 2-5

Three Wire Open

Delta Connection

Using 2 PTs, 2 CTs

(2-element)

Wiring Mode = 3OP2

Voltages

2

V

1

Currents

1

3

+

-

I

1

5

V

2

4

6

I

2

8

V

3

7

9

10

+

-

I

3

11

V

N

12

-

+ +

-

+

-

+ c99-09038

LINE 1 (A)

LINE 2

LINE 3

(B)

(C)

Chapter 2 Installation

Voltages

2

5

8

11

V

V

V

1

2

3

V

N

Currents

1

+

3

-

4

+

6

-

7

+

9

-

10

12

K L

K

+

-

L

K

+

-

L

LOAD

Shorting

Switches

Figure 2-6

Three Wire Open

Delta Connection

Using 2 PTs, 3 CTs

(2½-element)

Wiring Mode = 3OP3 c99-09039

11

LINE 1

LINE 2

LINE 3

(B)

(C)

N

-

+

-

+

-

+

-

+

K

+

-

L

K

+

-

L

K

+

-

L LOAD

Shorting

Swit ches

Figure 2-7

Four Wire Wye

Connection Using 2

PTs, 3 CTs (2½element)

Wiring Mode = 3Ln3 or 3LL3

Voltage s

2

5

8

11

V

V

V

V

Currents

1

+

3

-

4

+

6

-

7

+

9

-

I

1

I

I

3

2

10

12 c99-09040

LINE 1(A)

LINE 2(B)

LINE 3(C)

*

L

1

*

L

1

(A)

240VAC

*

L

2

240VAC

240VAC

*

L

3

120VAC

208VAC

N

*

*

L

3

120VAC N

(C)

K

+ -

L

K

+

-

L

K

+ -

L

LOAD

N

Shorting

Switches

Grounded delta connection

*

L

1

(A)

*

L

2

(B)

120V

N

120V

*

L

3

(C)

Voltages

2

5

8

V

1

V

2

V

3

11

V

N

Currents

1

+

3

-

4

+

6

-

7

+

9

-

10

12

VOLTAGES DISPLAYED:

1. Line to neutral voltages: 120V; 208V; 120V.

2. Line to line voltages: 240V; 240V; 240V.

c99-09041

Figure 2-8 Four Wire Delta Direct Connection Using 3 CTs (3 element)

Wiring Mode = 4LL3 or 4Ln3

12

Chapter 2 Installation

2.2.5 Relay

Eight relays are provided for energy pulsing, alarms or remote control.

1 2 3

C191HM

CONTROL RE LAY S

4 5 6 7 8

FUSE

10-15A

20 21 22 23 24 25 26 27 28 29 30 31

120- 230V AC

N

LOAD

CONTROL

ENABLE/

DISABLE

FUSE

15 A

LOAD

FUSE

5A

12 0-23 0V AC

N N

120-230V AC

N

LOAD c99- 0904 5

Figure 2-9 Relay Connection

2.2.6 Status Input

One status input is provided for status monitoring or external synchronization input for power demand period.

C191HM

STATUS

INPUT

INTERNAL

SUPPLY

12V D C

32 33

EXTE RNAL

DRY

CONTACT c99- 0904 4

Figure 2-10 Status Input Connection

Chapter 2 Installation 13

2.2.7 Analog Output

The C191HM provides one optically isolated analog output with current output options of 0-20 mA and 4-20 mA (current loop load of up to 500 Ohm). The analog output must be used with a 24 V DC external power supply.

PLC OR SC ADA

24V DC

4-2 0mA

=

LOAD

UP TO

510

O HM

SHIELD

16 17

2 4V

18 19

OUT

AN ALOG OUTPU T

C191HM c99 -090 43

Figure 2-11 Analog Output Connection

14

Chapter 2 Installation

2.2.8 Communications

The C191HM is provided with an RS-232 or RS-485 communication port.

Connections can be made as follows:

RS-232: distance of up to 15 meters, one C191HM to one computer/PLC, using a flat or twisted pair cable of 0.33mm2/22AWG

RS-485: distance of up to 1200 meters, up to 32 instruments on one multi-drop line

POWERMETER

RS-232

SG

15

TxD

RxD

14

25-PIN DB25 MALE CONNECTOR

GND

7

TxD

2

MODEM

RxD

3

DSR/CTS

C99-11012

Figure 2-12 Connection for 25-pin Modem Connector

POWERMETER

RS-232

15

SG

13

TxD

14

RxD

9-PIN DB9 MALE CONNECTOR

GND

5

TxD

3

MODEM

RxD

2 c99-11013

Figure 2-13 Connection for 9-pin Modem Connector

POWERMETER

RS-232

SG

15

TxD

13

RxD

14

25-PIN DB25 FEMALE CONNECTOR

GND

7

RxD

3

TxD

2

IBM PC/COMPATIBLE

DSR

6

DTR

20

RTS

4

CTS

5 c99-11014

Figure 2-14 RS-232 Simple 3-Wire Computer Connection, 25-pin

Chapter 2 Installation 15

16

POWERMETER

RS-232

SG

15

TxD

13

RxD

14

9-PIN DB9 FEMALE CONNECTOR

GND

5

RxD

2

TxD

3

IBM PC/COMPATIBLE

DSR

6

DTR

4

RTS

7

CTS

8 c99-11015

Figure 2-15 RS-232 Simple 3-Wire Computer Connection, 9-pin

C192PF8 POWER FACTOR CONTROLLERS

RS-485

#1

Shi eld

13

14

+

-

15

#2

Sh ield

13

14

15

+

-

R1

IBM PC /COMPATIBLE or RS-2 32/RS-485 CONVERTER

RxD

TxD

RxD-

TxD-

R1, R2 = 200-500 Ohm,

0.5W

#32

Shield

13

14

15

+

-

R2 c99-09035

Figure 2-16 RS-485 Multi-drop Computer Connection

NOTE:

Where an RS-232/RS-485 converter is used on a computer connection, R1 is not applicable since it is built in to the converter.

Activity on the communications port lines is indicated via the TXD and RXD

LEDs, on the front panel and via the Status Information menu (see Chapter 6).

A full description of the communication protocols may be found in the C191HM

ASCII, Modbus and DNP3.0 Communications Manuals provided with your

Chapter 2 Installation

instrument.

Chapter 2 Installation 17

Chapter 3 Using The Menus

3.

Press and release to enter the setup mode. The primary menus will appear:

StA

OPS

CHG

SELECT

- Status Information Menu (see Chapter 6)

- Setup Options Menu

- Setup Change Menu (see Chapter 4)

Select CHG to initialize or modify the instrument setup, or to clear the accumulated values stored in the instrument. Entry to this menu can be protected by a password.

SELECT

CHG

ENTER

Select StA to view extended status information which may be useful during installation and in certain applications.

SELECT

StA

ENTER

Select OPS for viewing (not editing) the instrument setup options.

SELECT

OPS

ENTER

After selecting either OPS or CHG, the list of setup menus is displayed in the upper window. Figure 3-1 presents a complete menu list. Depending on the model of your instrument, some menus may not appear.

Password

The Setup Change Menu can be secured by a user-defined password comprised of 4 digits. The instrument is shipped with password protection disabled. To enable password protection, go to the Access Control Menu (see Section 4.10).

The Password Menu appears if password protection is enabled.

To enter a password:

Set the first digit using the up and down arrow keys.

PASS

0000

Set the other password digits in the same manner.

Press to continue setup. If your password is incorrect, you will return to the Primary Selection Menu.

18

Chapter 3 Using the Menus

SELECT ENTER

Status Information

StA

Setup Options

OPS

Setup Change

CHG

Password

PASS

ENTER

Reset Functions

rSt

Basic Setup

bASc

Port Setup

Port

Digital Inputs

dinP

Analog Outputs

Aout

Pulsing Setpoints

PulS

Event Setpoints

SetP

Relay Operation

rELo

Display Setup

diSP

Selectable Options

OPtS

Access Control

AccS

SELECT

Selects an active window

ENTER

Enters menu/sub-menu

ESC

Quits menu/sub-menu

Scrolls options forward

Scrolls options backward

Figure 3-1

Menu Structure

Chapter 3 Using the Menus

Phase Rotation

PHAS

Relay Status

rEL

Status Inputs

St.In

Counter #1

Cnt.1

Counter #2

Cnt.2

Counter #3

Cnt.3

Counter #4

Cnt.4

19

Chapter 4 Setup Menus

4. CHAPTER 3 SETUP MENUS

NOTE: Instrument setup can be performed directly on the front panel using the setup menus or via communications using PComTest communication software. PComTest is supplied with your instrument and provides full setup capabilities for your instrument. For information on using PComTest, refer to the user documentation supplied with your instrument.

Setup Display PComTest

Basic

Communication port

User Selectable options

Analog output

Digital inputs

Alarm/Event set points

Pulsing output

Pulse counter

Assignable registers

Display

+

++

++

+

+

+

+

+

-

++

+

+

+

+

+

+

+

+

++

-

++ Recommended method

4.1 Basic Setup Menu

SELECT

CHG

ENTER

bASc

ENTER

This menu contains the basic configuration options which define the general operating characteristics of your instrument, such as wiring mode, input scales, the size of the RMS averaging buffer, etc. Table 4-1 lists the basic setup options, their code names and applicable ranges.

Activate the middle window to scroll through the list of available options, and then activate the lower window to set the option value.

To select and view a setup option:

bASc

ConF

4L-n

Use the up/down arrow keys to scroll to the desired option. The current value for this option appears in the lower window.

To change the value of the selected option:

Press the up/down arrow keys to scroll to the desired value.

Press to store the selected value, or press to quit the setup menu.

ESC

20

Chapter 4 Setup Menus

Table 4-1 Basic Setup Options (

∗ default setting)

Code Parameter Options Description

ConF

Wiring mode 3OP2

3Ln3

3-wire open delta using 2 CTs

3dir2

(2 element)

4Ln3

∗ 4-wire Wye using 3 PTs (3 element), line to neutral voltage readings

3-wire direct connection using 2 CTs (2 element)

4LL3

3OP3

4-wire Wye using 3 PTs (3 element), line to line voltage readings

3-wire open delta using 3 CTs

(2½ element)

4-wire Wye using 2 PTs (2½ element), line to neutral voltage readings

Pt

Ct d.P n.dp

A.dP buF rSt

Freq

LoAd

PT ratio

Number of power demand periods

10*-6,500.0

CT primary current 1-6,500A

(5

∗)

Power demand period

1, 2, 5, 10,

15*, 20, 30,

60, E

1-15

(1*) line voltage readings

The phase potential transformer ratio

The primary rating of the phase current transformer

The length of the demand period for power demand calculations, in minutes. E = external synchronization

The number of demand periods to be averaged for sliding window demands

1 = block interval demand calculation

Ampere/Volt demand period

0-1800 s

(900*)

0-6,500A

(0

∗)

The length of the demand period for volt/ampere demand calculations in seconds

0 = measuring peak current

Averaging buffer size

Reset enable/disable

8

∗,16,32 diS

∗, En

The number of measurements for RMS sliding averaging

Protects all reset functions, both via the front panel or communications.

Nominal frequency 50, 60 Hz The nominal power utility frequency

Maximum demand load current

The maximum demand load current used in

TDD calculations (0 = CT primary current)

When the power demand period is specified in minutes, synchronization of the demand interval can be made through communications (see the C191HM ASCII/Modbus

Reference Guides) or via the front panel (see Section 4.11). If the power demand period is set to External Synchronization, an external synchronization pulse denoting the start of the next demand interval can be provided through a digital input or can be simulated by using the synchronization command sent via communications.

60 Hz default for North America; elsewhere, default is 50Hz.

NOTES

1) The maximum value for CT PRIMARY CURRENT

× PT RATIO is 10,000,000. If this product is greater, power related values will be zeroed.

2) Always specify WIRING MODE, PT RATIO and CT PRIMARY CURRENT prior to setting up alarm setpoints, otherwise the alarm/event setpoints which use these parameters will automatically be disabled.

Chapter 4 Setup Menus 21

4.2 Communications Port Setup Menu

SELECT

CHG

ENTER

Port

ENTER

This menu allows you to access the communications port options that the

C191HM uses to communicate with a master computer. Table 4-2 lists the

communications options, their code names and applicable choices.

Activate the middle window to scroll through the list of available options, and then activate the lower window to set the option value.

To select and view a setup option:

Port

Prot

ASCII

Use the up/down arrow keys to scroll to the desired option. The option setting will appear in the lower window.

To change the selected option:

bAud dAtA

CPtb

Press the up/down arrow keys to scroll to the desired value.

Press to store the selected value or press to quit the setup menu.

ENTER ESC

Table 4-2 Communications Options (

∗ default setting)

Code Parameter Options Description

Prot Communications protocol

ASCII protocol

Modbus RTU protocol

Addr

Address

Baud rate

Data format

ASCII compatibility mode

ASCII

rtu

0

-99 ASCII

1

-247 Modbus

110

300

600

1200

2400

4800

9600

19.20

7E

8n

8E diS

, En

Powermeter address

110 baud

300 baud

600 baud

1200 baud

2400 baud

4800 baud

9600 baud

19,200 baud

7 bits, even parity

8 bits, no parity

8 bits, even parity

Disables/enables ASCII compatibility mode. For more information, see ASCII

Communications Protocol

Reference Guide

22

Chapter 4 Setup Menus

4.3 Digital Input Setup Menu

SELECT

CHG

ENTER

dinP

This menu is used to set up a digital input provided by the C191HM.

ENTER

The digital input can be configured as:

- a status input to monitor external contact status, or

- an external synchronization pulse input to receive an external synchronization pulse indicating the beginning of a new demand interval for power demand measurements.

The setup menu is used for allocating an external synchronization pulse input. If you do not allocate the digital input as an external synchronization input, it is automatically configured as a status input

To change the digital input allocation:

External synchronization input

Use the up/down arrow keys to set the input allocation status.

E.Snc

1

the menu.

“1” indicates that the input is allocated as the external synchronization pulse input; “0” indicates that the input is allocated as the status input.

NOTES

1. A digital input configured as the status input can be monitored via the Status

Information Menu (see Chapter 6) and communications.

2. If the digital input has been allocated as the external synchronization pulse input, synchronization of the demand interval through communications is not available.

Chapter 4 Setup Menus 23

4.4 Analog Output Setup Menu

[This section is relevant to instruments ordered with this option.]

SELECT

CHG

ENTER

Aout

ENTER

This menu allows you to set up an output value and its zero and full scales for the internal analog output. Table 4-3 explains the analog output setup options, and Table 4-4 lists all measurement parameters that can be directed to analog output.

Output parameter

Aout

Outp

rt U1

Zero-scale output

Aout

Lo

0

Full-scale output

To view the setup options for the analog output:

Aout

Hi

828

Use the up/down arrow keys to scroll to the desired option. The value associated with this option is displayed in the lower window.

To change the setup options for the selected channel:

Use the up/down arrow keys to scroll to the desired value.

ENTER

unchanged.

ESC

To quit the setup without changes:

To quit the menu:

NOTES

1.

Except for the signed power factor, the output scale is linear within the value range.

The scale range will be inverted if the full scale specified is less than the zero scale.

2.

The output scale for the signed power factor is symmetrical with regard to

±1.000 and is linear from -0 to -1.000, and from 1.000 to +0 (note that -1.000

≡ +1.000). Negative power factor is output as [-1.000 minus measured value], and non-negative power factor is output as [+1.000 minus measured value]. To define the entire range for power factor from -0 to +0, the scales would be specified as -0.000/0.000.

3.

Each time you select the output parameter for the analog channel, its zero and full scales are set by default to the lower and upper parameter limits, respectively.

24

Chapter 4 Setup Menus

Table 4-3 Analog Output Setup Options

Code Option Description

OutP Output parameter

Lo

Zero scale (0/4 mA)

The output parameter for the analog output channel

The reading of the parameter corresponding to a zeroscale current output

Hi

Full scale (1/20 mA) The reading of the parameter corresponding to a full-scale current output

Table 4-4 Analog Output Parameters

Code Parameter Unit Scale

0

r. U 1 r. U 2 r. U 3 r. C1 r. C2 r. C3 r. P r. q r. S r. PF r. PF.LG r. PF.Ld r. Fr

Real-time Measurements

Voltage L1/L12

Voltage L2/L23

Voltage L3/L31

Current L1

Current L2

Current L3

Total kW

Total kvar

Total kVA

Total PF

Total PF lag

Total PF lead

Frequency

Average Measurements

A. U 1

A. U 2

A. U 3

A. C1

A. C2

A. C3

A. P

A. q

A. S

A. PF

A. PF.LG

A. PF.Ld

A. neU.C

A. Fr

Voltage L1/L12

Voltage L2/L23

Voltage L3/L31

Current L1

Current L2

Current L3

Total kW

Total kvar

Total kVA

Total PF

Total PF lag

Total PF lead

Neutral current

Frequency

Present Demands

Accd.P

Accd.S

Accumulated kW demand

Accumulated kVA demand

V/kV

V/kV

V/kV

A

0 to Vmax

0 to Vmax

0 to Vmax

0 to Imax

A

A

0 to Imax

0 to Imax kW/MW -Pmax to Pmax kvar/Mvar -Pmax to Pmax kVA/MVA 0 to Pmax

Hz

-0.000 to 0.000

0 to 1.000

0 to 1.000

0 to 100.00

V/kV

V/kV

V/kV

A

0 to Vmax

0 to Vmax

0 to Vmax

0 to Imax

A

A

0 to Imax

0 to Imax kW/MW -Pmax to Pmax kvar/Mvar -Pmax to Pmax kVA/MVA 0 to Pmax

-0.000 to 0.000

0 to 1.000

A

Hz

0 to 1.000

0 to Imax

0 to 100.00 kW/MW 0 to Pmax kVA/MVA 0 to Pmax

Imax (20% over-range) = 1.2

× CT primary current [A]

Direct wiring (PT Ratio = 1):

Vmax (690 V input option) = 828.0 V

Vmax (120 V input option) = 144.0 V

Pmax = (Imax

× Vmax × 3) [kW x 0.001] @ wiring modes 4Ln3, 3Ln3

Pmax = (Imax

× Vmax × 2) [kW x 0.001] @ wiring modes 4LL3, 3OP2, 3dir2, 3OP3, 3LL3

Chapter 4 Setup Menus 25

NOTE: Pmax is rounded to nearest whole kW units.

If Pmax is more than 9999.000 kW, it is truncated to 9999.000 kW

Wiring via PTs (PT Ratio > 1):

Vmax (690 V input option) = 144

× PT Ratio [V]

Vmax (120 V input option) = 144

× PT Ratio [V]

Pmax = (Imax

× Vmax × 3)/1000 [MW x 0.001] @ wiring modes 4Ln3, 3Ln3

Pmax = (Imax

× Vmax × 2)/1000 [MW x 0.001] @ wiring modes 4LL3, 3OP2, 3dir2, 3OP3, 3LL3

NOTE: Pmax is rounded to nearest whole kW units.

The actual frequency range is 45.00 - 65.00 Hz

4.5 Pulsing Output Setup Menu

SELECT

CHG

ENTER

PulS

ENTER

This menu allows you to program any of the eight relays provided by your

C191HM instrument to output energy pulses. Relays #7 and #8 are especially

recommended for use as pulsing relays because of their high endurance.

Available pulsing parameters are listed in Table 4-5.

rEL.1

Ac.Ei

1

To select a pulse relay:

Use the up/down arrow keys to scroll to the desired relay. The pulsing parameter assigned to the relay is displayed in the middle window, and the amount of unit-hours per pulse is displayed in the lower window.

To change the pulse relay setup:

Use the up/down arrow keys to scroll to the desired output parameter. Selecting nonE disables pulsing through this relay.

Use the up/down arrow keys to set the amount of unit-hours per pulse. The available range is 1-9999. setup without changes.

To quit the pulsing setup menu:

Table 4-5 Pulsing Output Parameters

Code Parameter

nonE

Ac.Ei

Output disabled

Active energy import

Ac.EE

Active energy export

rE.Ei

Reactive energy import

rE.EE

Reactive energy export

rE.Et

Reactive energy total

AP.Et

Apparent energy total

26

Units

kWh import (positive) kWh export (negative) kvarh import (inductive) kvarh export (capacitive) kvarh total (absolute) kVAh total

Chapter 4 Setup Menus

NOTES

1. If your instrument is not equipped with the optional relay, then this setup parameter will not appear on the display.

2. You will not be able to store your setup in the instrument if you assigned a parameter to relay output with a zero number of unit-hours per pulse.

3. If a relay you allocated for pulsing has been manually operated or released, it reverts automatically to normal operation.

4. If a relay you allocated for pulsing has been engaged by an alarm/event setpoint, the setpoint is automatically disabled.

4.6 Alarm/Event Setpoints Setup Menu

SELECT

CHG

ENTER

SEtP

ENTER

Your instrument provides 16 alarm/event setpoints that can monitor a wide variety of events; in turn, these events can be programmed to trigger specific actions. This menu is used to specify the events to be monitored by the setpoints, and actions to be triggered by those events.

To program a setpoint, you might need to define up to six setup parameters which include: the setpoint trigger parameter, operate and release limits, optional operate and release delays, and the setpoint action. Table 4-6 explains the setpoint setup parameters. For the entire list of available triggers and setpoint actions, refer to Tables 4-7 and 4-8.

Example:

SP 1

triG

RHi.C1

SP 1

On

1200

SP 1

OFF

1100

SP 1

On d

5

SP 1

OFFd

10

parameter

Operate limit }

Release limit }

}

Release delay }

}

}

Operate delay }

}

}

}

Setpoint 1 is set to monitor the real-time high current on phase 1 (the trigger parameter).

The operate (On) and release (OFF) limits which determine setpoint operation are defined as 1200A and 1100A respectively.

The delays before operation (On d) and release

(OFFd) are set at 5 seconds and 10 seconds respectively.

Chapter 4 Setup Menus 27

SP 1

Act

rEL.1

Setpoint action The action to be triggered is operation of relay #1.

To select a setpoint:

Scroll to the desired setpoint using the up/down arrow keys.

To view the setup options for the setpoint:

Use the up/down arrow keys to scroll to the desired setup option. The value associated with this option is displayed in the lower window.

To change the selected setup option:

Use the up/down arrow keys to scroll to the desired value.

Press to store the new value.

To store your new setup for the setpoint:

To quit the setpoint setup without changes:

To quit the setpoints setup menu:

NOTES

1. If your instrument is not equipped with the optional relay, then these setup parameters will not appear on the display.

2. When you enter the setpoints setup menu at the protected level, monitoring setpoints is temporarily suspended until you return to the main setup menu.

3. Each time you select a new trigger parameter, the operate and release limits are set by default to zero.

4. You will not be able to store your setpoint setup to the instrument if a setpoint action is directed to a relay allocated for pulsing.

5. The setpoint action directed to a relay output can be overridden using commands sent via communications. A relay can be manually operated or released. When the relay reverts to normal operation, it is automatically returned under setpoint control.

28

Chapter 4 Setup Menus

Table 4-6 Setpoint Setup Options (middle window)

Code Option Description

triG

On

OFF

On d

Operate limit

Release limit

OFF d

Release delay

Act

Trigger parameter

Operate delay

Setpoint action

The measurement parameter or signal to be monitored by the setpoint.

The threshold at which the setpoint becomes operative.

The threshold at which the setpoint is released (becomes inoperative).

The time delay (0.1 second resolution) before operation when the operate condition is fulfilled.

The time delay (0.1 second resolution) before release when the release condition is fulfilled.

The action performed when the setpoint is operative.

Table 4-7 Setpoint Triggers (lower window, when middle window is triG)

Unit Range Code Parameter

nonE Setpoint disabled

Status Input

St.On

St.OFF

Status input ON

Status input OFF

Phase Reversal

POS.ro.

Positive phase rotation reversal

NEG.ro.

Negative phase rotation reversal

Real-time Values on any Phase

r. Hi. U r. Lo. U

High voltage

Low voltage

r. Hi. C r. Lo. C r. thd.U r. thd.C r. HFc.C r. tdd.C

High current

Low current

High voltage THD

High current THD

High K-factor

High current TDD

Real-time Auxiliary Measurements

r. Hi.Fr r. Lo.Fr

High frequency

Low frequency

Average Values per Phase

A. Hi.C1

High current L1

A. Hi.C2

A. Hi.C3

A. Lo.C1

A. Lo.C2

A. Lo.C3

High current L2

High current L3

Low current L1

Low current L2

Low current L3

Average Values on any Phase

A. Hi. U

A. Lo. U

High voltage

Low voltage

A. Hi. C

A. Lo. C

High current

Low current

Average Total Values

A. Hi.P.i

A. Hi.P.E

A. Hi.q.i

A. Hi.q.E

A. Hi. S

A. PF.LG

High total kW import (positive)

High total kW export (negative)

High total kvar import (positive)

High total kvar export (negative)

High total kVA

Low total PF Lag

%

%

%

%

V

V

A

A

Hz

Hz

A

A

A

A

A

A

V

V

A

A kW kW kvar kvar kVA

0 to Vmax

0 to Vmax

0 to Imax

0 to Imax

0 to 999.9

0 to 999.9

1.0 to 999.9

0 to 100.0

0 to 100.00

0 to 100.00

0 to Imax

0 to Imax

0 to Imax

0 to Imax

0 to Imax

0 to Imax

0 to Vmax

0 to Vmax

0 to Imax

0 to Imax

0 to Pmax

0 to Pmax

0 to Pmax

0 to Pmax

0 to Pmax

0 to 1.000

Chapter 4 Setup Menus 29

30

Code

A. PF.Ld

Parameter

Low total PF Lead

Average Auxiliary Measurements

Ar neU.C

High neutral current

Ar Hi.Fr

High frequency

Ar Lo.Fr

Low frequency

Present Demands

A

Unit

Hz

Hz

Hi d.U1

Hi d.U2

Hi d.U3

Hi d.C1

Hi d.C2

Hi d.C3

Hi d.P

Hi d.S

Hi Sd.P

Hi Sd.S

Hi Ad.P

Hi Ad.S

Hi Pd.P

Hi Pd.S

High volt demand L1

High volt demand L2

High volt demand L3

High ampere demand L1

High ampere demand L2

High ampere demand L3

High block interval kW demand

High block interval kVA demand

High sliding window kW demand

High sliding window kVA demand

High accumulated kW demand kVA kW kVA kW

High accumulated kVA demand kVA

High predicted sliding window kW demand kW

High predicted sliding window kVA demand kVA

V

V

V

A

A

A kW

High Voltage Harmonic Distortions on any Phase

Range

0 to 1.000

0 to Imax

0 to 100.00

0 to 100.00

0 to Vmax

0 to Vmax

0 to Vmax

0 to Imax

0 to Imax

0 to Imax

0 to Pmax

0 to Pmax

0 to Pmax

0 to Pmax

0 to Pmax

0 to Pmax

0 to Pmax

0 to Pmax

Hd03.U

Hd05.U

...

Hd39.U

High voltage harmonic H03

High voltage harmonic H05

%

%

0 to 100.00

0 to 100.00

...

High voltage harmonic H39 %

High Current Harmonic Distortions on any Phase

0 to 100.00

Hd03.C

Hd05.C

...

Hd39.C

High current harmonic H03

High current harmonic H05

%

%

0 to 100.00

0 to 100.00

...

High current harmonic H39 % 0 to 100.00

For parameter limits, see notes to Table 4-4.

The setpoint is operated when the actual phase sequence does not match the indicated normal phase rotation.

The actual frequency range is 45.00 - 65.00 Hz.

When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.

Chapter 4 Setup Menus

Table 4-8 Setpoint Actions (lower window, when middle window is Act)

Code

NonE

ALAr rEL.1 rEL.2 rEL.3 rEL.4 rEL.5 rEL.6 rEL.7 rEL.8

In.Cn.1

In.Cn.2

In.Cn.3

In.Cn.3

In.Cn.4 ti.Cn.1 ti.Cn.1 ti.Cn.1 ti.Cn.1

Action

No action

Assert local alarm

Operate relay #1

Operate relay #2

Operate relay #3

Operate relay #4

Operate relay #5

Operate relay #6

Operate relay #7

Operate relay #8

Increment counter #1

Increment counter #2

Increment counter #3

Increment counter #3

Increment counter #4

Count operating time using counter #1

Count operating time using counter #2

Count operating time using counter #3

Count operating time using counter #4

When a setpoint is operated, its status is always stored to the alarm status register even if no action is assigned to the setpoint. The alarm status register can be polled and cleared through communications.

This action causes the alarm LED on the front panel to blink that gives the user a local alarm indication. The alarm LED operates in latched mode, i.e., even if an alarm condition disappears, the alarm LED is still blinking until the user acknowledges the alarm from the front panel (see Section 5.1). An alarm LED can be operated from any number of setpoints using an OR scheme.

Alarm relays operate in unlatched mode. This means that a relay is operated while an alarm condition is present and is automatically released when an alarm condition disappears. Each relay can be operated from any number of setpoints using an OR scheme, i.e., a relay will be in operate state while either of the alarm conditions is still present.

This action converts a common event counter to the time counter which measures time at 0.1 hour resolution while the setpoint is in the operated state. Each time counter has a non-volatile shadow counter that counts time at 1-second resolution before the corresponding time counter is incremented. The time counters can be inspected via the

Status Information Menu. They are labeled by an hour mark in the middle window.

Chapter 4 Setup Menus 31

4.7 Relay Operation Control Menu

SELECT

CHG

ENTER

rELo

ENTER

This menu allows you to set the relay operation mode: non-failsafe or failsafe.

Failsafe relay operation is the opposite of normal operation where relay contacts are closed when a relay is operated (activated), and are open when a relay is released (de-activated). In failsafe mode, an alarm is activated by a nonenergized relay which will open in all cases when an alarm condition is present or an alarm setpoint is not operational either due to a loss of control power or due to corruption of the setpoint setup configuration. A failsafe relay is closed only if it is under setpoint control and no alarm conditions exist, or if it is manually operated via communications.

To select a relay:

rELo

rEL.1

nor

the up/down arrow keys to scroll to the desired relay.

To change the relay operation mode:

Use the up/down arrow keys to set the desired option.

Select nor for normal (non-failsafe) relay operation, or select FSAFE for failsafe relay operation.

Press to store your new setting or press to leave your previous setting unchanged.

ESC

To quit the setup menu:

NOTES

1. You will not be able to change the relay operation mode if a relay has been allocated for pulsing.

2. When a failsafe relay is allocated for pulsing, it automatically reverts to normal operation.

32

Chapter 4 Setup Menus

4.8 Display Setup Menu

SELECT

CHG

ENTER

diSP

ENTER

This menu allows you to view and change display properties. Table 4-9 lists available options with their code names and applicable ranges.

Table 4-9 Display Options (

∗ default setting)

Display Code Parameter

diSP

UPdt

0.5

diSP

ScrL

5

diSP

rEtn

diS

diSP

bAr

5000 diSP

Ph.P

diS

UPdt

ScrL rEtn bAr

Ph.P

Display update time

Auto scroll

Auto return to the main screen

Nominal load current for LED bar graph

Phase powers display mode

Options

0.1 - 10.0 s

(0.5)* nonE*

2-15 s diS*, En

0-6,500A

(0*)

Description

Defines interval between display updates

Disables/enables auto scroll on common measurements display (main screen) and defines scroll interval

Disables/enables auto return to the main screen after 30 seconds of uninterrupted use

Defines the nominal load

(100%) level for the bar graph display

(0 = CT primary current)

diS*, En diSP

Fund

diS

Fund

Fundamental values display mode

diS*, En

Disables/enables display of phase powers in common measurements (main screen)

Disables/enables display of fundamental values in common measurements

(main screen)

Chapter 4 Setup Menus 33

To select a display option:

SELECT

keys to scroll to the desired option.

To change the display option:

Use the up/down arrow keys to set the desired option.

Press to store your new setting or press to leave your previous setting unchanged.

To quit the display setup menu:

34

Chapter 4 Setup Menus

4.9 User Selectable Options Menu

SELECT

CHG

ENTER

OPtS

ENTER

This menu allows you to change options which relate to the instrument features and functionality. Table 4-10 lists all available options with their code names and applicable ranges.

OPtS

P.cAL rEAc

To select an option:

Press to activate the middle window, and then use the up/down arrow keys to scroll to the desired option.

To change the selected option:

Press to activate the lower window.

Use the up/down arrow keys to set the desired value. previous setting unchanged.

To quit the display setup menu:

Table 4-10 User Selectable Options (

∗ default setting)

Code Parameter

P.cAL

Power calculation mode

Options

rEAc*

nAct

Description

Using reactive power

Using non-active power

roLL

Energy roll value

10.E4

10.E5

10.E6

10.E7

10.E8*

10,000 kWh

100,000 kWh

1,000,000 kWh

10,000,000 kWh

100,000,000 kWh

Ph.En

Phase energy measurements

diS*, En Enables/disables measurements of energies per phase

Power calculation mode (P.cAL):

Mode 1: Reactive power calculation (rEAc)

Active power P and reactive power Q are measured directly and apparent power

S =

√ P 2

+ Q

2

Mode 2: Non-active power calculation (nAct)

Active power is measured directly, apparent power S = V

× I (where V, I - rms voltage and currents) and non-active power N =

√ S

2

P

2

Mode 1 is recommended for electrical networks with low harmonic distortion (voltage

THD

< 5%, current THD < 10%); Mode 2 is recommended for all other cases.

Chapter 4 Setup Menus 35

Energy roll value example: If roll value = 10.E4, the energy counter contains 4 digits, i.e., energy is displayed up to 9.999 MWh (Mvarh, MVAh) with resolution 0.001 MWh.

Rollover

Value

Maximum Energy kWh (kvarh, kVAh)

10.E4 9,999

10.E5 99,999

10.E6 999,999

10.E7 9,999,999

10.E8 99,999,999

Maximum Display Reading

MWh (Mvarh, MVAh)

9.999

99.999

999.99

9,999.9

99,999

Display Resolution

MWh (Mvarh, MVAh)

0.001

0.001

0.01

0.1

1

The roll value may be changed in accordance with the average load of the power line.

For example, if average power is 400 kW and the counter must be reset every 3 months (2160 hours), then energy during this period equals 864000 kWh (6 digits) and the roll value = 10.E6.

36

Chapter 4 Setup Menus

4.10 Access Control Menu

SELECT

CHG

ENTER

AccS

ENTER

This menu can be only accessed via the Setup Change Menu (CHG). It is used in order to:

• change the user password

• enable or disable password check

To view an option setting:

Use the up/down arrow keys to scroll to the desired option (PASS or CtrL).

Password Setting Password Protection Control

AccS

PASS

8780

AccS

CtrL

OFF

To change the password:

Use the up/down arrow keys to modify the password. The password can be up to four digits long. unchanged.

To enable/disable password checking:

arrow keys to move to the CtrL entry.

Use the up/down arrow keys to change the password checking status: select

OFF to disable password protection, or select On to enable password protection.

SELECT

unchanged.

ESC

To quit the setup menu:

Store your password in a safe place. If you do not provide the correct password, you will need to contact your local distributor for the super-user password to override password protection.

Chapter 4 Setup Menus 37

4.11 Reset/Synchronization Menu

SELECT

CHG

ENTER

rSt

ENTER

This menu allows you to reset to zero the accumulators and Min/Max registers in your instrument, and also to synchronize the power demand interval. The menu can be only accessed via the Setup Change Menu (CHG). If the reset is disabled from the Basic Setup Menu (see Section 4.1), you will not be able to enter this menu.

The following designations are used in the menu to specify a data location to be affected:

EnrG

Resets total accumulated energies

dnd

Resets all total maximum demands

P.dnd

Resets total power maximum demands

A.dnd

Resets volt/ampere maximum demands

Cnt

Resets all event/time counters

Cnt.1

Resets counter # 1

Cnt.2

Resets counter # 2

Cnt.3

Resets counter # 3

Cnt.4

Resets counter # 4

Lo.Hi

Resets Min/Max registers (does not affect maximum demands)

d.Snc

Provides synchronization of the power demand interval (see NOTES below)

rSt

EnrG

do

To reset the desired locations:

Press to activate the middle window, and then use the up/down arrow keys to scroll to the desired data location entry.

Press to activate the lower window.

Press and hold for about 5 seconds until the do label is replaced with done, and then release the key. You will return to the middle window.

38

NOTES:

1. If the CHG menu is not secured by a password, fast reset of the Min/Max registers, maximum demands and energies can be done from the data display mode (see Section

5.1) and counters from the Status Information Menu (see Section 6.1) without entering the reset menu.

2. If you select the d.Snc entry, take into consideration the following:

- Synchronization of the instrument’s internal timer requires that the power demand period be specified in minutes (see Section 4.1, Basic Setup Options). If more than 30 seconds pass from the beginning of the current demand interval, the new demand interval starts immediately; otherwise synchronization is delayed until the next demand interval.

- Synchronization occurs exactly 5 seconds from the time you first pressed while you hold the key.

ENTER

Chapter 4 Setup Menus

Chapter 5 Data Display

5.

5.1 Navigating in the Display Mode

The front panel has a simple interface that allows you to display numerous measurement parameters in up to 45 display pages. For easier reading, the parameters are divided into three groups, each accessible by a designated key.

These are:

Common measurements

Min/Max measurements

- no selection key

Total Harmonic measurements

Individual Harmonics measurements

- selected by the key

Energy measurements

The up/down arrow keys are used as follows in the Display Mode:

Scrolls through the pages downward (forward)

Scrolls through the pages upward (backward)

Returns to the first page within current measurement group

When pressed for 5 seconds, clears the alarm LED arrow LEDs - indicate measured parameter

Load bar graph indicates % current load round LEDs indicate measurement group

The front panel display is updated approximately twice per second; you can adjust the display update rate via the Display Setup Menu (see Section 4.8).

Table 5-1 lists all displayed parameters and their LED indicators.

Chapter 5 Data Display 39

Load Bar Graph

The load bar graph displays the amount, in percent, of the current load with respect to user-defined nominal load current. The highest current measured by the C191HM is divided by the nominal load current as defined in the Display

Setup Menu (see Section 4.8) and expressed as a percent by the LEDs (40% to

110%) which are lit. For example, if all LEDs up to and including 90% are lit, this means that the load is 90% of the nominal load current. If the nominal load current is set to 0, it is taken from the CT primary current setup.

Alarm LED

The blinking Alarm LED gives you an alarm indication. It is controlled by the alarm/event setpoints (see Section 4.6) and operates in latched mode. Even if alarm conditions are no longer present, the alarm LED will continue to blink. To clear the alarm LED, press the up/down arrow keys simultaneously for 5 seconds.

Auto Scroll

If display Auto Scroll option is enabled (see Section 4.8), the common measurements display (main screen) will scroll automatically after 30 seconds of uninterrupted use.

To stop auto scrolling at the current page, press either arrow key.

Auto Return to the Main Screen

If display Auto Return option is enabled (see Section 4.8), the display will automatically return to the main screen from any other measurement screen after

30 seconds of uninterrupted use.

Fast Reset of Accumulated Data

When changing data via the front panel is not secured by a password, you can reset the Min/Max registers, maximum demands and energies from the display mode without entering the reset menu.

NOTES

1.

The common measurements display does not have a designated indicator LED. If no indicator LED is lit up below the display, this means that the common measurement parameters are being displayed at this time. To return to the common measurements from another group, press the illuminated key until it goes out.

2.

When you move to another measurement group, the instrument stores your last location; when you return to the previous group, the instrument restores the last page.

At power up, the instrument always returns to the common measurements group and shows you the last page that was displayed prior to loss of power.

Selecting a Display Page

Press the down/up arrow keys to scroll through display pages.

40

Selecting Common Measurements

Press the key pointed to by the illuminated round LED below the front panel display. If no LED is lit up, this means that the front panel displays the

Chapter 5 Data Display

common measurements parameters.

Selecting Min/Max Measurements

MAX/MIN

Min/Max measurements.

Selecting Total Harmonic Measurements

H/ESC

up/down arrow keys to scroll through the different harmonic parameters.

Selecting Individual Voltage Harmonics Measurements

H/ESC

LEDs at the right are lit. Use the up/down arrow keys to scroll through the different harmonics readings.

Selecting Individual Current Harmonics Measurements

LEDs at the right are lit. Use the up/down arrow keys to scroll through the different harmonics readings.

Selecting Energy Measurements

different energy readings.

Fast Reset of Accumulated Data

Select a display page where the data you want to reset is displayed. To reset:

• Min/Max log registers: select a Min/Max page from the Min/Max measurements display (where a MAX or MIN round LED is illuminated).

• Ampere and volt maximum demands: select the ampere or volt maximum demand page from the Min/Max measurements display (where a MAX

DMD LED is illuminated, and volts or amps LEDs at the right are lit).

• Power maximum demands: select the power maximum demand page from the Min/Max measurements display (where a MAX DMD LED is illuminated, and kVA/MVA and kW/MW LEDs at the right are lit).

• Total and phase energies: select the energy measurements display.

While holding the key, press and hold for about 5 seconds.

The displayed data is reset to zero.

ENTER

Chapter 5 Data Display 41

5.2 Data Display Formats

Table 5-1 specifies all front panel local displays available in the display mode.

The display windows are labeled in the table as follows: 1 = upper window, 2 = middle window, 3 = lower window.

Table 5-1 Displayed Parameters

Page Window Indicator

LED

Parameter

Common Measurements

Digits Unit

1 1 Voltage L12

1 2 Voltage L23

4 V/kV

4 V/kV

4 V/kV

2 1 V/kV

2 2 Voltage L2 4

2 3

V/kV

V3/V3-1 P. Voltage L3 4

A2

A3

PF kW

5 1 Neutral current

Hz kvar

Frequency

Total kvar

PF kW

Current L1

Current L2

Current L3

Total kVA

Total power factor

Total kW

Power factor L1 kW L1 kVA L1

4 A

4 A

4 A

4 kVA/MVA

4

4 kW/MW

4 A

4 Hz

4 kvar/Mvar

Label

4

4 kW/MW

PF kW

PF kW

kvar L1

Power factor L2 kW L2 kVA L2 kvar L2

Power factor L3 kW L3 kVA L3 kvar L3

H01 total power factor

H01 total kW

H01 power factor L1

H01 kW L1

4 kVA/MVA

Label

4 kvar/Mvar

Label

4

4 kW/MW

4 kVA/MVA

Label

4 kvar/Mvar

Label

4

4 kW/MW

4 kVA/MVA

Label

4 kvar/Mvar

Label

4

4 kW/MW

Label

4

4 kW/MW

42

Chapter 5 Data Display

Page Window Indicator

LED

Parameter Digits Unit

PF kW

H01 power factor L2

H01 kW L2

H01 power factor L3

H01 kW L3

Label

4

4 kW/MW

Label

4

4 kW/MW

Label

4 % 16 3 Voltage unbalance

17 3 Current unbalance

Min/Max Measurements

Label

4

MIN

%

1 1 V/kV

1 2 Min. real-time voltage L2/L23 4

V3/V3-1

V/kV

Min. real-time voltage L3/L31 4

A2

A3

PF kW

V1

V2

Min. real-time current L1

Min. real-time current L2

Min. real-time current L3

Min. real-time total kVA

Min. real-time total power factor

Min. real-time total kW

Max. real-time total kVA

Max. real-time total power factor

Max. real-time total kW

8 1 Max. real-time neutral current

Max. real-time frequency

Max. real-time total kvar

MAX DMD

4 A

4 A

4 A

4 kVA/MVA

4

4 kW/MW

PF kW

4 1 Min. real-time neutral current

Hz kvar

Min. real-time frequency

Min. real-time total kvar

4 A

4 Hz

4 kvar/Mvar

MAX

5 1 V/kV

5 2 Max. real-time voltage L2/L23 4

V3/V3-1

V/kV

Max. real-time voltage L3/L31 4

A1

A2

Max. real-time current L1

Max. real-time current L2

Max. real-time current L3

4 A

4 A

4 A

4 kVA/MVA

4

4 kW/MW

4 A

4 Hz

4 kvar/Mvar

Chapter 5 Data Display

A1

A2 kVA

PF

Max. ampere demand L1

Max. ampere demand L2

Max. ampere demand L3

Max. sliding window kVA demand

Power factor at max. kVA demand

4 A

4 A

4 A

4 kVA/MVA

4

43

44

Page Window Indicator

LED

Parameter

Max. sliding window kW demand

Digits Unit

4 kW/MW

THD/TDD

Total Harmonic Measurements

1 1 Voltage THD L1/L12

1 2 Voltage THD L2/L23

4 %

4 %

4 %

Current THD L1

Current THD L2

4 %

4 %

4 %

A1

A2

Current TDD L1

Current TDD L2

4 %

4 %

4 %

A2

4 3

HARMONICS

Current K-Factor L1

Current K-Factor L2

Current K-Factor L3

1 1 Voltage harmonic H03 L1/L12

1 2 Voltage harmonic H03 L2/L23

4

4

4

Individual Odd Voltage Harmonics H03-H39

4

4

%

%

4 %

...

20 1

20 2

HARMONICS

Voltage harmonic H39 L1/L12

Voltage harmonic H39 L2/L23

4 %

4 %

4 %

Individual Odd Current Harmonics H03-H39

Current harmonic H03 L1

Current harmonic H03 L2

4

4

%

%

4 %

1 3

...

Current harmonic H39 L1

Current harmonic H39 L2

Total Energies

MWh import

4

4

%

%

4 %

Label

Label

5 MWh

Mvarh rE.En.

IP.

2 3 Mvarh import

MVAh AP.En.

3 3

EP.

4 3 MWh export

Label

Label

5 Mvarh

Label

MVAh

Label

Label

5 MWh

Chapter 5 Data Display

Page Window Indicator

LED

Parameter Digits Unit

EP.

5 3 Mvarh export

Phase Energies

Ac.En.

6 2

IP.L1

6 3 MWh import L1

rE.En.

7 2

IP.L1

7 3 Mvarh import L1

AP.En.

8 2

L1

8 3 L1

Ac.En.

9 2

IP.L2

9 3 MWh import L2

rE.En.

10 2

IP.L2

10 3 Mvarh import L2

MVAh

11 2

AP.En.

L2

11 3 L2

MWh

12 2

Ac.En.

IP.L3

12 3 MWh import L3

Mvarh

13 2

rE.En.

IP.L3

13 3 Mvarh import L3

MVAh

14 2

AP.En.

L3

14 3 L3

Label

Label

5 Mvarh

5

Label

Label

5 MWh

Label

Label

5 Mvarh

Label

Label

MVAh

Label

Label

5 MWh

Label

Label

Mvarh

Label

Label

Label

Label

5 MWh

Label

Label

5 Mvarh

Label

Label

Display readings for all electrical quantities except Min/Max log and energies are sliding average values.

When using direct wiring (PT Ratio = 1), voltages are displayed in 0.1 V units, currents in 0.01 A units, and powers in 0.001 kW/kvar/kVA units. For wiring via PTs (PT Ratio >

1), voltages are displayed in 1V units, currents in 0.01 A units, and powers in 0.001

MW/Mvar/MVA units. When the value width is over the window resolution, the right most digits are truncated

By default, the maximum range for energy readings is 99,999,999 MWh/Mvarh/MVAh.

Beyond this value, the reading will roll over to zero. When the energy reading exceeds the window resolution, the right-most digits are truncated. To avoid truncation, you can change the energy roll value to lower limit via the User Selectable Options menu (see

Section 4.9). Negative (exported) energy readings are displayed without a sign.

Per phase power and power factor readings are displayed only in 4LN3/4LL3 and

3LN3/3LL3 wiring modes (see Section 4.1) if the phase powers display is enabled in the Display Setup menu (see Section 4.8).

Chapter 5 Data Display 45

Phase energy readings are displayed only in 4LN3/4LL3 and 3LN3/3LL3 wiring modes if they are enabled in the User Selectable Options menu (see Section 4.9).

When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.

Displayed only in the 4LN3 or 3LN3 wiring mode.

5.3 Self-Test Diagnostics Display

The C191HM periodically performs self-test diagnostics during operation. If the instrument fails the test, it discards the last measurement results, and an error code is displayed for one second on all LEDs. Error codes are listed in Table 5-2.

Code ‘8’ indicates normal operation.

Frequent failures may be the result of excessive electrical noise in the region of the instrument. If the instrument continuously resets itself, contact your local distributor.

Table 5-2 Self-Test Diagnostic Codes

Code Meaning

3 Watch dog timer reset

5 Out of control trap

8

9

Normal power up

External reset (warm restart)

NOTE

The C191HM provides a self-check alarm register accessible through communications that indicates possible problems with instrument hardware or setup configuration. The hardware problems are indicated by the appropriate bits which are set whenever the instrument fails self-test diagnostics or in the event of loss of power. The setup configuration problems are indicated by the dedicated bit which is set when either configuration register is corrupted. In this event, your instrument will use the default configuration. For more information on the self-check alarm register, refer to the communications reference guides shipped with your instrument.

46

Chapter 5 Data Display

Chapter 6 Viewing Status Information

6.

Through the Status Information Menu (StA), it is possible to view the status of various instrument features.

6.1 The Status Information Menu

SELECT

StA

ENTER

To enter the Status Information Menu:

To select a display page:

Press the up/down arrow keys to scroll through the display pages.

To quit the menu and return to the display mode:

Front Panel Display

When you are in the Status Information Menu, the front panel display is updated approximately four times per second and shows you a wide variety of status information that you can review by scrolling through display pages.

The status parameters are designated by the abbreviated labels in the upper and/or middle window. The upper window flashes, indicating that you are in the menu display.

Fast Reset of Counters

When changing data via the front panel is not secured by a password, you can reset the counters from the Status Information Menu display without entering the reset menu:

Select a display page where the counter you want to reset is displayed.

The displayed data is reset to zero.

6.2 Status Display Formats

Table 6-1 lists all the displays available from the Status Information Menu. The display windows are labeled in the table as follows: 1 = upper window, 2 = middle window, 3 = lower window.

Chapter 6 Viewing Status Information 47

Table 6-1 Status Information Display

Page Window Parameter

6

7

3

4

1 3 Phase rotation sequence (POS/NEG/ERR)

2 1

2 2 Relay #1 - #4 status

2 3 Relay #5 - #8 status

5

3

3

3

Status input

Counter #1

Counter #2

3

3

Counter #3

Counter #4

Digits Unit

Label

Label

4

Label

4

4

Label

1

Label

5

Label

5

Label

5

Label

5

48

Chapter 6 Viewing Status Information

Appendix: Technical Specifications

7. ions

Input and Output Ratings

3 galvanically isolated voltage inputs

3 galvanically isolated current inputs

Analog output (optional)

4-20 mA

0-20 mA

Status input

690 V:

(standard)

DIRECT INPUT (690V line-to-line voltage and 400V lineto-neutral) Burden: <0.5 VA

INPUT USING PT Burden: <0.15 VA

V:

(optional)

INPUT USING PT (120V line-to-line voltage)

Burden: <0.1 VA

5 A:

(standard)

1 A:

(optional)

INPUT VIA CT with 5A secondary output Burden: <0.1

VA

Overload withstand: 10A RMS continuous, 250A RMS for

1 second

INPUT VIA CT with 1A secondary output Burden: <0.02

VA

Overload withstand: 2A RMS continuous, 50A RMS for 1 second

Voltage and current input terminals

Optically isolated communication port

Relay outputs

UL recognized Screws: Brass, M4

Maximum wire section: 2.5 mm

Maximum wire section: 1.5 mm

2

2

(12 AWG)

EIA RS-485 or RS-232 standard (factory set)

(14 AWG)

5 relays rated at 5A, 250 V AC / 5A, 30 V DC /

0.5A, 110 V DC 2 contacts (SPST Form A)

1 relay rated at 5A, 250 V AC / 5A, 30 V DC /

0.5A, 110 V DC 3 contacts (SPDT Form C)

2 relays rated at 3A, 250 V AC / 3A, 30 V DC /

0.5A, 110 V DC 2 contacts (SPST Form A)

Maximum wire section: 1.5 mm

2

(16 AWG)

Accuracy 0.5%, Non-linearity 0.2%

Load up to 510 Ohm

24V DC external power supply required

Dry contact for external synchronization or monitoring

Display

3 windows high-brightness seven-segment digit LEDs

3 color LED bar graph 40-110%

Power Supply

Galvanically isolated power supply (factory set)

120&230V AC / 120&220 V DC

12 V DC

24 V DC

48 V DC

85 - 265V AC 50/60 Hz and 88- 290V DC 10 W

9.6 - 19 V DC

19 - 37 V DC

37 - 72 V DC

Appendix: Technical Specifications 49

Environmental Conditions

Operating temperature

Storage temperature

Humidity

-20°C to

+60°C (-4°F to +140°F)

-25°C to

+80°C (-13°F to +176°F)

0 to 95% non-condensing

Construction

Instrument body

Case enclosure: flame resistant ABS & Polycarbonate Blend

Dimensions: 144 x 144 x 86 mm ( 5.67 x 5.67 x 3.39 “)

Mounting: 136 x 136 mm square cut-out (DIN 43700)

Instrument weight

0.9 kg (2.04 lb.)

Standards Compliance

UL File # E129258 Pending

CE:

EMC: 89/336/EEC as amended by 92/31/EEC and 93/68/EEC

LVD: 72/23/EEC as amended by 93/68/EEC and 93/465/EEC

Harmonized standards to which conformity is declared:

EN55011:1991; EN50082-1:1992; EN61010-1:1993; A2/1995

Installation Category II, Pollution Degree 2

EN50081-2:1994 EMC Generic Emission Standard - Industrial Environment

EN50082-2:1995 EMC Generic Immunity Standard - Industrial Environment

EN55022: 1994 Class A

EN61000-4-2: 1995 Electrostatic Discharge

EN61000-4-4: 1995 Electrical Fast Transient

EN61000-4-8: 1993 Power Frequency Magnetic Field

ENV50140: 1993 Radio Frequency Electromagnetic Field, Amplitude Modulated

ENV50204: 1995 (200Hz) Radio Frequency Electromagnetic Field, Pulse

Modulated

ENV50141: 1993 Radio Frequency Common Mode, Amplitude Modulated

ANSI C37.90.1: 1989 Surge Withstand Capability

ANSI IEEE C62.41-1991 Surge Voltages in Low-Voltage AC Power Circuits

50 Appendix: Technical Specifications

I 1

A accuracy, 51 active energy, 3, 51 active power, 3, 4, 34, 50 alarms, 13 ampere demand, 20, 29, 42

analog output, 2, 5, 8, 14, 23, 24 analog outputs, 20

B basic setup, 19 burden, 48

C communications, 51

CT, 1, 2, 9, 20, 24, 32, 39, 48, 50, 51

CT PRIMARY CURRENT, 20, 50, 51 current inputs, 8, 48 current transformers, 51

D

demand, 2, 3, 14, 20, 22, 24, 29, 37, 40, 42,

43, 51 demand period, 14, 20, 37 display, 1, 26, 27, 31, 32, 33, 34, 37, 38, 39,

40, 41, 44, 46 display mode, 32, 37, 39, 41, 46

E energy, 1, 2, 3, 13, 25, 34, 35, 40, 44, 45, 51 external synchronization, 2, 14, 20, 22, 48

F frequency, 1, 2, 3, 4, 20, 28, 29, 42, 50

I inputs, 22, 48

L

Load bar graph, 39

M measurement, 51 menu, 17, 19, 21, 22, 23, 25, 26, 27, 31, 32,

33, 34, 36, 37, 44, 45, 46

Modbus, ii, 16, 20, 21

Index

mounting, 1, 7

O open delta, 9, 20 options, 14 overload withstand, 48

P panel cut-out, 7 password, 2, 17, 36, 37, 39, 46

PComTest, 19

power, i, 2, 3, 4, 8, 14, 20, 22, 23, 31, 34,

35, 37, 39, 40, 41, 42, 44, 45, 48, 50, 51

power demand, 2, 3, 14, 20, 22, 37 power factor, 50 power source, i, 8 power supply, 48

PT, 9, 20, 24, 25, 44, 48, 50, 51

PT RATIO, 20

pulsing, 2, 13, 25, 26, 27, 31

R reactive energy, 3, 51 reactive power, 3, 4, 34, 50

relays, 2, 13, 25, 30, 48 reset, 20, 35, 37, 39, 40, 45, 46

S self tests, 45

setpoints, 20, 26, 27, 30, 39 setup menus, 17, 19 setup mode, 17 sliding demand, 3 standards, 48, 49 status, 1, 2, 14, 17, 22, 30, 36, 46, 47 technical specifications, 48 terminals, ii, 8, 9, 48

T

V voltage inputs, 48

W wiring configuration, 5, 9

Wye, 20

54

Index

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
