CDI Diagnostic Tool Kit

Kit contains:

511-60 Multimeter

511-9766 Spark tester

511-9710 Trigger tester

511-9764 Neon test light

511-9770 Piercing probe set

511-9773-NI DVA adapter

511-9775 Pack load resistor

511-9800 Multimeter test card

553-2700 Amphenol pin tool set

912-9708 Terminal kit, troubleshooting guide, laminated DVA charts and an aluminum storage case.

CDI 511-9900

CDI Multimeter

Auto-ranging

DC & AC volts range: 0.0001 to 1000 volts

Diode

Continuity beeper

Milli and micro ampere (400mA MAX)

Amps (10 amps MAX)

Ohms

Temperature

Auto shutdown

Back lighted display

511-9773-NL DVA Adapter

Includes storage case, test leads and manual.

CDI 511-60A

CDI Neon Spark Tester 1 Cylinder

Sealed spark tester can be used inline to the spark plug while the engine is running or it can be connected to engine ground for cranking speed tests.

CDI 511-9764

CDI Spark Tester

Spark tester can be used to test from

1 to 8 cylinders. Sealed design reduces the possibility of re.

CDI 511-9766

CDI Piercing Probe Set

Set contains 1 red and 1 black test probe.

Fully insulated probes have a spring loaded clamp with a tiny stainless steel pin that self centres and punctures the insulation.

CDI 511-9770

CDI Electronics

517

CDI Multi Engine Diagnostic System Complete

M.E.D.S. is the only system capable of testing multiple engine platforms with one package. No more fumbling with multiple computers and programs. The system is designed to be installed quickly and easily onto your

Windows based computer. Your platform provides the software interface, USB adapter, optical isolation (to prevent damage to your computer), 12 foot interface cable with security veri cation to protect your investment.

CDI Engine Diagnostic System - Mercury, Yamaha,

Mercurys made by Yamaha and Mercury Plus

CDI 531-0118T

CDI Engine Diagnostic System - Mercury Only Platform

CDI 531-0118M

CDI Engine Diagnostic System - Yamaha Only Platform

CDI 531-0118Y

CDI Peak Reading Adapter

DVA adapter uses your meters test leads

CDI 511-9773NL

CDI Gearcase Filler

This 3 gallon design ller makes it easier to ll or ush gearcases. Translucent plastic container allows you to check tank oil level. Sturdy teardrop design resists tipping over.Includes the check valve venting system. The check valve on the vent allows you to remove the ller nozzle without loosing any appreciable amount of lubricant.

CDI 551-33-1

CDI Pressure/Vacuum Pump

Combination unit does both pressure and vacuum testing in one unit. Simply ip a valve on the side and change it from vacuum to pressure. Includes 551-34HA hose assembly,

551-334M and 551-334S adapters

CDI 551-34PV

CDI Pin Tool Set

Set contains 1 each of:

553-2697, Insertion tool

533-2698, Pin Removal tool

553-2699, Socket Removal tool

CDI 553-2700

518

Funnels / Tie Downs

Scepter Funnel

18" polypropylene exible funnel

Strainer in the funnel neck

Molded handle

SCE 03603

Lubrimatic Nesting Funnel Set

3-Piece funnel set includes 1/2 pint, 1 pint, and

2 pint units.

LUB 75-075

LubriMatic Multi-Purpose Flex Funnel

Plastic funnel features a molded plastic handle, 2 piece funnel with detachable 12" exible spout.

Overall length: 15"

Diameter: 6"

Tip: 3/4" OD

LUB 75-074

Racor Fuel Filter Funnels

Heavy duty, fast ow, pre- lter funnel which separates free water and contaminates from gasoline, diesel, heating fuel and kerosene.

RAC RFF3C

RAC RFF8C

3.9 GPM

5 GPM

Shurhold Fuel Filter Funnels

A heavy-duty, fast- ow, portable funnel with built-in lter. Designed to lter out water, dirt, and debris from most fuels including, gasoline, diesel, heating oil and kerosene.

SHU SIF3C

SHU SIF8C

SHU SIF15C

3.5 GPM

5 GPM

15 GPM

Scepter Spill Proof Spout

Designed to eliminate spillage through a self-venting spout that provides an automatic shutoff feature that engages when the fuel tank reaches capacity.

SCE 05459

Fuel Spill Guard System

The "ONLY" system that eliminates "ALL" fuel vent spills into our waterways.

• No more messy cups, catch bottles

• or oil absorbed towels while fuelling

Eliminates fuel streak stains on your boat

Adds safety to your vessel

Intrinsically safe LED warning light and audible buzzer that alerts you when to stop fuelling

The Fuel Spill Guard system is installed inline between the overboard vent tting and the fuel tank

FSG 2-058

Green Marine Fuel Whistle

The “Fuel Whistle” is a simple solution to prevent spills while fuelling. Provides an audible signal during fuel lling which stops when an over ow situation arises.

• Fits 5/8” fuel lines

• Easy one-time installation

WES 204

Gator Tuff Gas Tank Strap

1" x 6' weather-resistant polypropylene webbing and rust-resistant metal hardware with stainless steel screws for mounting.

EPC GS1

Sea-Dog Gas Tank Strap

1" x 6' nylon webbing with a zinc plated steel buckle.

SED 359990-1

Moeller Electric Sending Units

Internal measurement components will not rust or corrode

All electrical senders are calibrated 33 to 240 ohms

100% inspected during manufacturing

Swing-arm oat rotates easily in 90° increments for tank wall or baf e clearance

MOE 035722-10

6” - 12” tank depth

MOE 035729-10

12” - 24” tank depth

Parts:

MOE 035728-10

Five hole gasket

Moeller Electric Sending Unit with Diesel Return

To meet the needs of a return found on diesel and some fuel injected engines

All electrical senders are calibrated to 33 to 240 ohms

Swing-arm oat rotates easily in

90-degree increments for tank wall or baf e clearance

MOE 035724-10

6” - 27” tank depth

Parts:

MOE 035728-10

Five hole gasket

Moeller Mechanical Sending Units

Mechanical direct sight gauge on a swing arm sender

Internal measurement components will not rust or corrode

MOE 035752-10

10” tank

MOE 035753-10

11-3/4" tank

MOE 035757-10

17-3/4” tank

MOE 035758-10

22” tank

Parts:

MOE 035728-10

Five hole gasket

MOE 035760-10

Mech. to Elect conversion capsule

MOE 035759-10

Direct sight mech read capsule

► Also See

:

Electric Senders pg 613

► Also See

:

Fuel Gauges pg 158

Fuel Senders / Fittings

Faria Electric Fuel Gauge Sending Units

Stainless steel construction with sealed electrical connections. 6' electrical leads.

FAR 91001

FAR 91003

FAR 91004

FAR 91017

8 to 16"

14 to 24* single station

14 to 24" dual station

Installation kit for tanks without a ange

Moeller Anti Siphon Valves

Industry standard anti-siphon protection on all gasoline-powered boats

Aluminum construction

MOE 033801-10

3/8” hose x 1/4 NPT

MOE 033802-10

3/8” hose x 3/8 NPT

EVM Tank Withdrawal Elbow

Aluminum tank withdrawal elbow

3/8" x 1/4" NPT with 3/8" hose barb

EVM WE-3814-WA

EVM Tank Withdrawal Assembly

Aluminum tank withdrawal assembly

3/8" NPT male x 1/4" NPT female withdrawal assembly

24" rigid nylon hose

EVM 3814WA2400N-P

Sierra Hose Barbs

• Brass construction

SIE 18-8042

SIE 18-8055

SIE 18-8074

1/4" NPT x 1/4" Hose

1/4" NPT x 5/16" Hose

1/4" NPT x 3/8" Hose

Moeller Hose Barbs

• Brass construction

MOE 033405-10

1/4” NPT, 3/8” hose barb

MOE 033430-10

1/4” NPT, 5/16” hose barb
