Application Example 01/2015

Monitoring and Control with the LOGO! CMR Module

LOGO! 8

http://support.automation.siemens.com/WW/view/en/105074237

Warranty and Liability

Warranty and Liability

Note

The Application Examples do not purport to cover all details or variations in equipment, nor do they provide for every possible contingency. The Application

Examples do not represent customer-specific solutions. They are only intended to provide support for typical applications. You are responsible for the correct operation of the described products. These Application Examples do not relieve you of the responsibility of safely and professionally using, installing, operating and servicing equipment. When using these Application Examples, you recognize that we cannot be made liable for any damage/claims beyond the liability clause described. We reserve the right to make changes to these

Application Examples at any time and without prior notice. If there are any deviations between the recommendations provided in this Application Example and other Siemens publications – e.g. Catalogs – the contents of the other documents shall have priority.

We do not accept any liability for the information contained in this document.

Any claims against us – based on whatever legal reason – resulting from the use of the examples, information, programs, engineering and performance data etc., described in this Application Example shall be excluded. Such an exclusion shall not apply in the case of mandatory liability, e.g. under the German Product Liability

Act (“Produkthaftungsgesetz”), in case of intent, gross negligence, or injury of life, body or health, guarantee for the quality of a product, fraudulent concealment of a deficiency or breach of fundamental contractual obligations (“wesentliche

Vertragspflichten”). The compensation for damages due to a breach of a fundamental contractual obligation is, however, limited to the foreseeable damage, typical for the type of contract, except in the event of intent or gross negligence or injury to life, body or health. The above provisions do not imply a change in the burden of proof to your disadvantage.

Any form of duplication or distribution of these Application Examples or excerpts hereof is prohibited without the expressed consent of Siemens Industry Sector.

Security information

Siemens provides products and solutions with industrial security functions that support the secure operation of plants, solutions, machines, equipment and/or networks. They are important components in a holistic industrial security concept. With this in mind, Siemens’ products and solutions undergo continuous development. Siemens recommends strongly that you regularly check for product updates.

For the secure operation of Siemens products and solutions, it is necessary to take suitable preventive action (e.g. cell protection concept) and integrate each component into a holistic, state-of-the-art industrial security concept. Third-party products that may be in use should also be considered. For more information about industrial security, visit http://www.siemens.com/industrialsecurity .

To stay informed about product updates as they occur, sign up for a productspecific newsletter. For more information, visit http://support.automation.siemens.com

.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

2

Table of Contents

Table of Contents

7

8

9

Warranty and Liability ................................................................................................. 2

1 Task ..................................................................................................................... 4

2 Solution............................................................................................................... 5

2.1

2.2

2.2.1

2.2.2

2.2.3

2.2.4

2.3

2.3.1

2.3.2

Overview............................................................................................... 5

Description of the core functionality ..................................................... 6

Scenario: “Temperature monitoring with SMS alarm” .......................... 6

Scenario: “receiving SMS commands” ................................................. 7

Scenario: “Time-of-day synchronization” ............................................. 8

Scenario: “GPS tracking”...................................................................... 9

Hardware and software components ................................................. 10

Validity ................................................................................................ 10

Components used .............................................................................. 10

3

4

5

Function Mechanisms ..................................................................................... 13

3.1

3.2

Overview............................................................................................. 13

“GPS tracking” scenario ..................................................................... 14

Configuration and Settings............................................................................. 15

4.1

4.2

4.3

4.4

“Temperature monitoring with SMS alarm” configuration .................. 15

“Receiving SMS commands” configuration ........................................ 20

“Time-of-day synchronization” configuration ...................................... 24

“GPS tracking” configuration .............................................................. 30

Installation and Commissioning .................................................................... 32

6

5.1

5.2

5.3

5.3.1

5.3.2

5.3.3

5.3.4

Hardware installation .......................................................................... 32

Software requirements ....................................................................... 33

Commissioning ................................................................................... 34

Commissioning LOGO! BM ................................................................ 34

Commissioning the LOGO! TDE ........................................................ 35

Commissioning the LOGO! CMR ....................................................... 36

Commissioning the KTP 700 .............................................................. 37

Operation of the Application .......................................................................... 39

6.1

6.2

6.3

6.4

“Temperature monitoring with SMS alarm” scenario ......................... 39

“Receiving SMS commands” scenario ............................................... 40

“Time-of-day synchronization” scenario ............................................. 42

“GPS tracking” scenario ..................................................................... 44

Further Notes, Tips & Tricks, etc. .................................................................. 47

Related Literature ............................................................................................ 50

History............................................................................................................... 50

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

3

1 Task

1 Task

Introduction

The devices from the LOGO! series enable solving small automation tasks quickly and efficiently. The modules of LOGO! 8 expand the function spectrum and cover further requirements. Simplified handling, a new display, and the full communication range via Ethernet facilitate the realization of small automation tasks.

The provided programs and the documentation show the possible application areas of the LOGO! CMR20X0 communication module. A wide range of functions is covered here, from “sending and receiving of SMS”, over “time-of-day synchronization”, to “tracking of position data”.

Overview of the automation task

The automation task consists of illustrating the application options of LOGO!

CMR20X0. The documentation is divided into four scenarios.

The figure below provides an overview of the general application options of

LOGO! 8 in conjunction with LOGO! CMR.

Figure 1-1 SMS layout diagram of the application

Description of the automation task

The aim of this solution is to realize the following scenarios:

1. Sending an SMS to a defined recipient depending on the state of the process

(here temperature monitoring).

2. Controlling a process by means of SMS (here fan control).

3. Controlling an outlet flap in animal breeding depending on the local sunrise and sunset using time-of-day synchronization.

4. Tracking the position of containers via GPS.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

4

2 Solution

2.1 Overview

2 Solution

2.1

Overview

Schematic layout

The figure below shows a schematic overview of the most important components of the solution:

Figure 2-1

SMS

Panel

Ethernet

LOGO! CMR + BM LOGO! TDE

Advantages

This application offers you the following advantages:

Overview over the application options of LOGO! CMR20X0 in interaction with

LOGO! 8 (LOGO! BM).

Adaptable example projects for simple adjustment to own requirements.

Step-by-step instructions for configuring the LOGO! CMR module.

Chapter

2.2

provides an overview of the realized scenarios.

Delimitation

This application does not contain a description of:

LOGO!Soft Comfort V8.

Ladder diagram (LAD) or function block diagram (FBD).

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

5

2 Solution

2.2 Description of the core functionality

2.2

Description of the core functionality

Generally, four scenarios are realized which illustrate the application options of

LOGO! CMR20X0. This chapter provides an overview of the realized scenarios.

The following scenarios are described:

1. Temperature monitoring: “Temperature monitoring with SMS alarm”

2. Fan control: “receiving SMS commands”

3. Time-of-day-dependent control of an outlet flap: “Time-of-day synchronization”

4. Position tracking of containers: “GPS tracking”

In this documentation, you will find the following information on the individual scenarios:

Table 2-1

Information

Function Mechanisms

Configuration

Commissioning

Operation

Chapter

3

4

5

6

2.2.1

Scenario: “Temperature monitoring with SMS alarm”

Schematic layout

The figure below provides an overview of the scenario:

Figure 2-2

LOGO!

CMR

LOGO!

BM

Content

LOGO! CMR monitors a temperature value of LOGO! BM. The temperature value can either be fed real via a LOGO! module, or directly be simulated in LOGO! BM.

The description in this document uses the simulated temperature value.

If in LOGO! CMR a defined limit value is exceeded or fallen short of, an SMS is sent to a defined recipient group via the LOGO! CMR module.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

6

2 Solution

2.2 Description of the core functionality

2.2.2

Scenario: “receiving SMS commands”

Schematic layout

The figure below provides an overview of the scenario:

Figure 2-3

LOGO!

CMR

LOGO!

BM

Content

To extend the temperature monitoring already realized in the first scenario, the option of controlling a fan signal via SMS is implemented.

If an SMS is sent to the LOGO! CMR module with a command (see

Figure 4-1

)

LOGO! 8 switches the respective signal on. In the example, the signal for a fan is switched.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

7

2 Solution

2.2 Description of the core functionality

2.2.3

Scenario: “Time-of-day synchronization”

Schematic layout

The figure below provides an overview of the scenario:

Figure 2-4

LOGO!

CMR

LOGO!

BM

Content

The system time of LOGO! CMR can be synchronized in different ways (GSM,

GPS, NTP).

The “time-of-day synchronization” scenario shows requirements and implementation for the various synchronization options.

A scenario for controlling an outlet flap in animal breeding at sunrise and sunset is laid out using function block “Astronomical clock”.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

8

2 Solution

2.2 Description of the core functionality

2.2.4

Scenario: “GPS tracking”

Schematic layout

The figure below provides an overview of the scenario:

Figure 2-5

LOGO!

CMR

LOGO!

BM

Content

The example project shows the tracking of a container. The GPS data is recorded via the CMR module mounted at the container, transferred to the LOGO! BM, and stored there in a .csv file via the data log function.

The following functions are realized:

recording the current GPS position.

storing the data in the microSD card as a .csv file.

preparing the data via an Excel macro.

displaying of the position curve via a freeware tool.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

9

2 Solution

2.3 Hardware and software components

2.3

Hardware and software components

2.3.1

Validity

This application is valid for

LOGO! 8

LOGO!Soft Comfort V8

WinCC V13 Basic

Components used 2.3.2

The individual scenarios were created using the following components:

Hardware components for all scenarios

Table 2-2

Component Qty.

LOGO! CMR20X0

LOGO! 12/24RCE

1

1

Article number

6GK7142-7BX00-0AX0

6ED1052-1MD00-0BA8

Note

LOGO! TDE

LOGO! CSM12/24

LOGO! Power

1

1

1

6ED1055-4MH00-0BA1

6GK7177-1MA20-0AA0

6EP1351-1SH02

In the documentation also referred to as LOGO! 8 or

LOGO! BM.

For visualization.

Any other switch can also be used.

You can also use any other

24V power supply.

Additional hardware components for “Temperature monitoring with SMS alarm” and

“Receiving SMS commands”

Table 2-3

Component

LOGO! AM2 RTD

Qty.

1

1

Article number

6ED1055-1MD00-0BA2

6AV2123-2GB03-0AX0

Note

For connecting a resistivity thermometer. Alternatively, the temperature simulation can also be used for testing.

For additional visualization.

SIMATIC HMI

KTP700 BASIC

Mobile wireless antenna

SIM card

1

1

6NH9860-1AA00

SMS to be sent/received.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

10

2 Solution

2.3 Hardware and software components

Additional hardware components “Time-of-day synchronization“

Table 2-4

Component

SIMATIC HMI

KTP700 BASIC

GPS antenna

Connection cable for

GPS antenna

Mobile wireless antenna

SIM card

1

1

1

Qty.

1

1

Article number

6AB2123-2GA03-0AX0

6GK5895-6ML00-0AA0

6XV1875-5LH50

6NH9860-1AA00

Note

For additional visualization.

When selecting the provider, please ensure that the required services are also supported.

Not every provider supports time-of-day synchronization via GSM, for example.

Additional hardware components “GPS tracking”

Table 2-5

Component

GPS antenna

Connection cable for

GPS antenna microSD card

1

1

Qty.

1

Article number

6GK5895-6ML00-0AA0

6XV1875-5LH50

Note

The following microSD cards are recommended:

max. speed class 6

Software components

Table 2-6

Component

LOGO!Soft Comfort

Version 8

WINCC Basic V13

Microsoft Excel

2010

1

1

1

Qty.

Article number

6ED1058-0BA08-0YA1

6AV2100-0AA03-0AA5

Note

Only optionally required for the first two scenarios.

Required for executing the

Microsoft Excel macro.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

11

2 Solution

2.3 Hardware and software components

Sample files and projects

The following list includes all files and projects that are used in this example.

Table 2-7

Component Note

105074237_LOGO!_CMR_2020_LOGO!_8.zip This zip-file contains

the LOGO!Soft Comfort project.

the WinCC V13 Basic project.

a configuration file for LOGO!

CMR20X0.

an Excel macro.

an Excel file with GPS data as an example.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

12

3 Function Mechanisms

3.1 Overview

3 Function Mechanisms

3.1

Overview

Division

Parts of the functionality of the four scenarios are already covered via the configuration of the LOGO! CMR module. The following overviews show where the functionality is realized in the example scenarios.

LOGO! CMR functionality

Figure 3-1

Send SMS

(temperature monitoring)

• Detect trigger (positive/negative edge of a flag)

• Initiate sending SMS by means of the trigger

Receive SMS

(fan control)

• Evaluate received SMS

• Execute received command

(controlling a tag in the LOGO! BM)

LOGO! CMR

Configuration

Time-of-day synchronization

• Calling the time-of-day (GPS, NTP or GSM)

• Synchronizing the time-of-day of LOGO! BM

GPS Logging

(container tracking)

• Determine current position

• Forward to trigger data at LOGO! BM

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

13

3 Function Mechanisms

3.2 “GPS tracking” scenario

User program functionality

Overview

The LOGO!Soft Comfort project is divided into four independent parts according to the four scenarios.

Figure 3-2

Send SMS

(temperature monitoring)

• Temperature acquisition

• Temperature simulation

• Message text and display lighting

• Trigger the sending of SMS

Receive SMS

(fan control)

• Fan control via an output

LOGO! BM

PROGRAM

Time-of-day synchronization

GPS Logging

• Synchronizing the time-of-day with

LOGO! CMR module

• Calling the “Astronomical clock” function

• Setting an output depending on the position of the sun.

• Trigger the transmission of GPS data from LOGO!CMR to BM

• Reading the GPS position from

LOGO! CMR

• Logging the GPS data on microSD card

3.2

The user program is well documented and commented.

“GPS tracking” scenario

The result of GPS data logging is a .csv file on the internal microSD card of

LOGO! BM. An Excel macro is provided for processing the .csv file.

LOGO! CMR provides the data to LOGO! BM in 16 byte structure (see manual

\4\ ,

Chapter 7.2).

When copying the data in LOGO! BM, the bytes are automatically converted into a word format. The data in the resulting .csv file therefore still needs to be prepared.

The Excel macro can then read the respective .csv file in Excel and convert it into a readable GPS format by pressing a button.

Handling as described in Chapter

6.4

.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

14

4 Configuration and Settings

4.1 “Temperature monitoring with SMS alarm” configuration

4 Configuration and Settings

This chapter shows the required configuration steps in LOGO! CMR, to provide the functionality of the scenarios.

4.1

“Temperature monitoring with SMS alarm” configuration

The following table describes the configuration at LOGO! CMR20X0 via the WBM

(web interface), to monitor a temperature value with the existing example project.

For sending an SMS you need to make the following settings:

activate the SIM card and the mobile wireless interface.

define text messages (content of the SMS to be sent).

define recipients (specifying the telephone numbers) and recipient groups.

define signals (symbolic naming of a data area, e.g. a flag).

configure events (exceeding a limit value).

define actions (sending an SMS).

assign the actions for the events (if a limit value was exceeded, an SMS shall be sent).

Alternatively, the supplied configuration file can also be used and adjusted to your application (see Chapter

5.3.3

).

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

15

4 Configuration and Settings

4.1 “Temperature monitoring with SMS alarm” configuration

Table 4-1

No.

1.

Action

Open your Web browser. enter the IP address of LOGO! CMR and log on at the start page of

WBM.

Factory settings:

IP address: 192.168.0.3

User name: admin

2.

For security reasons you need to assign your own password now.

Note

Make sure that LOGO! CMR20X0 can be reached from your PC via the network.

Go to “WAN > Mobile Wireless Settings”.

Make the following settings:

1. activate the “Activate mobile wireless interface” checkbox.

2. enter the PIN of your SIM card.

3. if necessary, enter the telephone number of the SMS service center of your provider.

1

2

3

3.

Go to “Users/groups > User” and create a new user. To do this, click on the “Add” button and follow the input mask. Confirm the entries with “Apply”.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

16

4 Configuration and Settings

4.1 “Temperature monitoring with SMS alarm” configuration

No.

4.

Action

Now go to “Users/groups > Recipient groups”. Add a new recipient group via the “Add” button in the input mask. By activating the checkbox at the user names you assign the user group. Confirm the entries with “Apply”.

5.

Go to the “Monitoring > LOGO! BM” menu and activate the “Active” checkbox. Enter the IP address of LOGO! BM. Confirm the entries by clicking on the “Apply” button.

You can test the connection by clicking on the “Ping LOGO! BM” button.

6.

Go to the “Message texts” tab. Create the following two message texts: these texts are used as content when sending an SMS.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

17

4 Configuration and Settings

4.1 “Temperature monitoring with SMS alarm” configuration

No.

7.

Action

Click on the “Signal definitions” tab and define a digital flag for the SMS.

Click on the “Add” button and confirm with “Apply” after entering the values.

Enter the following values:

8.

This assigns the name “Temperature_high/low” to the digital flag.

Next, define the “Temperature_is_high” and “Temperature_normal” events via the “Evants” tab.

To do this, use the signal defined in step 7.

“Temperature is high”:

“Temperature_normal”:

Confirm the entry of new events by clicking on the “Apply” button.

This causes the respective event to take place at a signal change.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

18

4 Configuration and Settings

4.1 “Temperature monitoring with SMS alarm” configuration

No.

9.

Action

In this step, actions are defined. Go to the “Actions” tab.

Press “Add” to define the actions “Temp_status_high” and “Temp_status_normal”.

Temp_status_high:

Temp_status_normal:

Confirm your entries respectively by clicking on “Apply”.

10.

Finally, the defined events and actions are logically connected via an “if …, then…” logic. Go to the “Assignments” tab.

Assign the “Temp_status_high” action to the “Temperature_is_high” event.

Assign the “Temp_status_normal” action to the “Temperature_normal” event.

This sends the changes of digital flag 1 defined in step 7 by SMS.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

19

4 Configuration and Settings

4.2 “Receiving SMS commands” configuration

4.2

“Receiving SMS commands” configuration

Function

If the “Receive SMS” function has been enabled at the LOGO! CMR module (see action 2,

Table 4-2

), the following actions can be performed as a standard (see

Figure 4-1

, screenshot from the manual).

Figure 4-1

When reading values, please note FAQ in

\7\ .

Description

The following table describes the configuration at LOGO! CMR via WBM, in order to control an output with the existing example project.

When changing the signal controlled via the LOGO! BM user program, a feedback shall be sent via SMS.

In the description it is assumed, that the configuration was already performed in

Chapter

4.1

.

Enabling the receiving of SMS.

Defining text messages.

Defining recipients and recipient groups.

Configuring of events.

Defining of actions.

Subsequent assignment of the actions for the events.

Alternatively, you can also use the configuration file supplied in the download and adjust it to your application.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

20

4 Configuration and Settings

4.2 “Receiving SMS commands” configuration

Table 4-2

No.

1.

Action

Open your Web browser. Enter the IP address of LOGO! CMR and log on at the start page of

WBM.

Factory settings:

IP address: 192.168.0.3

User name: admin

2.

For security reasons you need to then assign your own password.

Note

Make sure that LOGO! CMR20X0 can be reached from your PC via the network.

Go to “WAN > SMS”.

Make the following settings:

1. Activate the “Allow receipt of SMS messages” checkbox.

2. Enter a password of your choice, for example “LOGO!”.

3. Confirm the changes by clicking on “Apply”.

1

2

3

3.

By adopting the settings, the commands listed in

Figure 4-1 can be used.

Make the following settings in “Monitoring”, analog to Chapter

4.1

.

“Message texts”:

Fan_is_on_text: “The fan is on!”

Fan_is_off_text: “The fan is off!”

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

21

4 Configuration and Settings

4.2 “Receiving SMS commands” configuration

No.

4.

Action

Two signals are defined. The “Switch_fan_on/off” signal shows the program of LOGO! BM that the fan shall be switched on.

The “Fan_status_on/off” signal indicates the status of the fan. For any change of the fan status, an

SMS shall be sent.

“Signal definitions”:

“Switch_fan_on/off”:

“Fan_status_on/off”

5.

“Events”:

Fan_switches_on:

Fan_switches_off:

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

22

4 Configuration and Settings

4.2 “Receiving SMS commands” configuration

No.

6.

“Actions”:

Fan_status_on:

Action

Fan_status_off:

7.

“Assignments”:

SMS_fan_on:

SMS_fan_off:

8.

These settings acknowledge a change in the fan control (output signal Q1 of LOGO! 8) by sending an SMS message text.

In order to control the fan, you can use the following commands via SMS:

Switching on the fan: “LOGO;LOGO=VM6,1,BYTE”

Switching off the fan: “LOGO;LOGO=VM6,0,BYTE” (see

Figure 4-1 )

(Syntax: “Password; LOGO=VMx,y,BYTE”)

This controls the first bit of the internal flag 6. Depending on flag 6, output Q1 is then controlled for controlling the fan.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

23

4 Configuration and Settings

4.3 “Time-of-day synchronization” configuration

4.3

“Time-of-day synchronization” configuration

Note

The following tables show the configuration options at LOGO! CMR to ensure timeof-day synchronization.

The following synchronization methods are possible:

NTP procedure

via GPS

via mobile wireless network

If you have selected time-of-day forwarding to LOGO! BM: make sure that you have disabled the automatic daylight saving time switchover in the LOGO! BM. This avoids having different settings and resulting time deviations in LOGO! BM and LOGO! CMR.

Synchronization via GPS

In order to synchronize the time via GPS, the following requirements must be fulfilled:

GPS must be active.

a GPS antenna must be connected.

sufficient GPS reception is available.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

24

4 Configuration and Settings

4.3 “Time-of-day synchronization” configuration

Table 4-3

No.

1.

Action

Open your Web browser. enter the IP address of LOGO! CMR and log on at the start page of

WBM.

Factory settings:

IP address: 192.168.0.3

User name: admin

2.

For security reasons you need to assign your own password now.

Note

Make sure that LOGO! CMR20X0 can be reached from your PC via the network.

Go to “System > General” and activate GPS by selecting entry “Yes” in the drop-down menu.

Confirm the entry by clicking on “Apply”.

3.

Then go to the “System time” tab in “System > General”.

Activate the “Activate time-of-day synchronization” checkbox.

In the drop-down menu you select the “GPS” option.

Select how frequently the clock shall be synchronized via the drop-down menu.

Confirm the entry by clicking on “Apply”.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

25

4 Configuration and Settings

4.3 “Time-of-day synchronization” configuration

No.

4.

Action

The LOGO! CMR module synchronizes its time-of-day via GPS. To forward the time to LOGO! BM as well, activate checkbox “Forward time to LOGO! BM”.

Confirm the entry by clicking on “Apply”.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

26

4 Configuration and Settings

4.3 “Time-of-day synchronization” configuration

Synchronization via NTP

Note

Establishing the connection to an NTP server is only possible via the mobile wireless interface.

Synchronization via the Ethernet interface is not possible.

The following table describes how to establish the time-of-day synchronization via

NTP.

Table 4-4

No.

1.

Action

Open your Web browser. enter the IP address of LOGO! CMR and log on at the start page of

WBM.

Factory settings:

IP address: 192.168.0.3

User name: admin

2.

For security reasons you need to assign your own password now.

Note

Make sure that LOGO! CMR20X0 can be reached from your PC via the network.

Go to “WAN > mobile wireless settings” and activate the data connection via the mobile wireless network. Enter your access details. These can be obtained from your provider.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

27

4 Configuration and Settings

4.3 “Time-of-day synchronization” configuration

No.

3.

Action

Then go to the “System time” tab in “System > General”.

In the drop-down menu you select the “NTP” option.

Select how frequently the clock shall be synchronized via the drop-down menu.

Enter IP address or DNS name of the NTP server.

Confirm the entry by clicking on “Apply”.

4.

Depending on the used NTP server, it may be useful to activate the “Accept time of day from non-synchronized NTP servers” checkbox.

The LOGO! CMR module now synchronizes its time-of-day via NTP. To forward the time to

LOGO! BM as well, activate checkbox “Forward time to LOGO! BM”.

Confirm the entry by clicking on “Apply”.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

28

4 Configuration and Settings

4.3 “Time-of-day synchronization” configuration

Synchronization via mobile wireless network

Note

If you wish to synchronize the time-of-day via the mobile wireless network, you must ensure beforehand that your provider provides the time-of-day synchronization via mobile wireless network.

Table 4-5

No.

1.

Action

Open your Web browser. Enter the IP address of LOGO! CMR and log on at the start page of

WBM.

Factory settings:

IP address: 192.168.0.3

User name: admin

2.

For security reasons you need to assign your own password now.

Note

Make sure that LOGO! CMR20X0 can be reached from your PC via the network.

Then go to the “System time” tab in “System > General”.

In the drop-down menu you select the “Mobile wireless network” option.

3.

Confirm the entry by clicking on “Apply”.

When adopting the settings, the time-of-day synchronization is made via the mobile wireless network (see

\4\

Chapter 6.4.4). To forward the time to LOGO! BM as well, activate checkbox

“Forward time to LOGO! BM”.

Confirm the entry by clicking on “Apply”.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

29

4 Configuration and Settings

4.4 “GPS tracking” configuration

4.4

“GPS tracking” configuration

The following table describes the configuration at LOGO! CMR via WBM for recording the GPS data using the existing example project.

The following settings must be made:

activate the GPS connection.

define a trigger bit.

if the trigger condition becomes true: write GPS data to LOGO! BM.

Table 4-6

No.

1.

Action

Open your Web browser. Enter the IP address of LOGO! CMR and log on at the start page of

WBM.

Factory settings:

IP address: 192.168.0.3

User name: admin

2.

For security reasons you need to assign your own password now.

Note

Make sure that LOGO! CMR20X0 can be reached from your PC via the network.

Go to “System > General” and activate GPS by selecting entry “Yes” in the drop-down menu.

Confirm the entry by clicking on “Apply”.

3. Make the following settings in “Monitoring”, analog to Chapter

4.1

.

Signal definitions:

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

30

4 Configuration and Settings

4.4 “GPS tracking” configuration

No.

4.

Action

Make the following settings in the “Events” tab, analog to Chapter

4.1

.

Send_GPS:

5. Make the following settings in the “Actions” tab, analog to Chapter

4.1

.

Write_GPS:

6. Analog Chapter

4.1

you make the following settings in the “Assignments” tab:

When changing the “Signal_send_GPS” signal, the current GPS position is sent to LOGO! BM.

7. The GPS data is processed in the LOGO! BM user program and by means of the Excel macro also provided in the download.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

31

5 Installation and Commissioning

5.1 Hardware installation

5 Installation and Commissioning

This chapter describes the steps necessary for starting the example using the code from the download and the hardware list.

5.1

Hardware installation

The figure below shows the hardware configuration of the application.

Figure 5-1

Engineering PC

KTP 900

230V

LOGO! CSM12/24

LOGO! CMR

Industrial Ethernet

LOGO! 12/24RCE

& LOGO! AM2 RTD

LOGO! TDE

LOGO! Power

24V

Note

The setup guidelines for automation systems must generally be followed.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

32

5 Installation and Commissioning

5.2 Software requirements

Table 5-1

No.

Action

1.

2.

3.

Install the GSM antenna and the GPS antenna at the respectively provided antenna connections of the LOGO! CMR.

Insert the SIM card into the respective slot of the LOGO! CMR.

Insert your microSD card into the respective slot of the LOGO! CMR.

4. Connect the LOGO! BM with the

LOGO! AM2 RTD.

5. Connect the LOGO! TDE and the KTP 700 with an Ethernet cable.

Connect further modules (LOGO! TDE,

LOGO! BM, LOGO! CMR, Engineering PC) with the LOGO! CSM12/24 via Ethernet.

6. Connect the individual components with the respective power supply.

7.

8.

If using a temperature sensor: Connect the

LOGO! AM2 RTD with the temperature sensor.

Switch on the power supply at the devices.

Remarks

For the hardware setup of LOGO! CMR see also

\4\

.

Any other switch with a respective port number can also be used.

Alternatively, you can also simulate the temperature directly via the LOGO! BM.

5.2

Software requirements

It is assumed, that the required software (LOGO!Soft Comfort V8 and optionally

WinCC V13 Basic) has been installed on your PC, and that you are familiar with the basics of handling this software.

Also download the .zip-file provided in the entry (see

\1\ ). Then you unzip the file

on your PC:

Contains the following components:

the LOGO!Soft Comfort project.

the WinCC V13 Basic project.

a configuration file for LOGO! CMR20X0.

an Excel macro.

an Excel file with GPS data as an example.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

33

5 Installation and Commissioning

5.3 Commissioning

5.3

Commissioning

IP addresses

The factory settings for the used LOGO! devices are the IP addresses from the following table.

The subnet mask is 255.255.255.0.

Table 5-2

IP address Name

LOGO! 8/LOGO! BM

LOGO! TDE

LOGO! CMR

192.168.0.1

192.168.0.2

192.168.0.3

Assigning the IP address to the engineering station

For the engineering station (the PC) a free address in the subnet must be selected.

For example:

IP address: 192.168.0.15

Subnet mask: 255.255.255.0

5.3.1

The procedure for changing the IP address is, for example, described in the

Microsoft Knowledge Base (see

\8\

).

Commissioning LOGO! BM

The following table describes the procedure for commissioning the basis station

LOGO! BM.

Table 5-3

1.

2.

No.

Action

Open the downloaded LOGO!Soft Comfort project.

Right-click on the “LOGO!_LOGO! CMR20X0_LOGO!_8_3_0” diagram. Select the “Ethernet Connections”.

3.

Enter the IP address of the LOGO! BM module.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

34

5 Installation and Commissioning

5.3 Commissioning

4.

No.

Action

Load the diagram into the LOGO! BM via “Tools > Transfer > PC ->LOGO!”

5.

6.

Connect with IP 192.168.0.1 and acknowledge the dialog with OK.

After successful download you can restart the LOGO! BM via a dialog.

5.3.2

Commissioning the LOGO! TDE

The LOGO! TDE is directly commissioned at the device.

Operating the LOGO! TDE with a LOGO! BM only requires a connection between both devices. The procedure is described in the following table.

Table 5-4

No.

1.

2.

Action

First, check the IP address of the LOGO! TDE.

Navigate to “TDE Settings > Network > IP Address” and select IP address

192.168.0.2.

Navigate back to the start menu via the “ESC” button. Select “LOGO! Selection” and set the IP address to 192.168.0.1 (the IP address of the LOGO! BM).

LOGO! TDE then connects with LOGO! BM.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

35

5 Installation and Commissioning

5.3 Commissioning

5.3.3

Commissioning the LOGO! CMR

For commissioning the LOGO! CMR follow the instructions in the following table:

Table 5-5

No.

1.

Action

Open your Web browser. enter the IP address of LOGO! CMR and log on at the start page of WBM.

Factory settings:

IP address: 192.168.0.3

User name: admin

2.

For security reasons you need to assign your own password now.

Note

Make sure that LOGO! CMR20X0 can be reached from your PC via the network.

Go to “Maintenance > Configuration” and click on “Browse”. Select the downloaded configuration file (“user.cfg”) and then click on “Load”.

Note:

When loading the configuration, the password of the configuration file is also adopted.

The “admin” password for the WBM then changes to “LOGO8cmr.”. For security reasons you need to assign your own password.

3. The configuration described in Chapter

4 has now been performed. You only need

to adjust your mobile wireless parameters.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

36

5 Installation and Commissioning

5.3 Commissioning

No.

4.

Action

Go to “WAN > Mobile wireless settings”.

5.

Enter the following data:

PIN of your SIM card.

telephone number of the SMS service center, if necessary.

activate the data connection, if necessary (for example, for time-of-day synchronization with an NTP server). Enter your APN and, if necessary, user name, password, as well as authentication method.

Confirm the entries by clicking on “Apply”.

Go to “User/groups > User” and enter “Staff” as the user name as well as the telephone number of the mobile device.

5.3.4

Commissioning the KTP 700

The following table shows the procedure for commissioning the KTP700 BASIC panel.

For the scenarios “Temperature monitoring with SMS alarm” and “Receiving SMS commands”, the panel is used for visualization, control and simulation. The respective functions are also realized via the LOGO! TDE.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

37

5 Installation and Commissioning

5.3 Commissioning

Table 5-6

No.

Action

1. Start the TIA Portal and open the downloaded project.

2. In “Online Access” you select your interface and start the search for accessible nodes.

3. Select “Online & diagnostics” and assign the address 192.168.0.20 to the HMI via

“Functions > Assign IP address”.

4. In the project tree you then click on the HMI and download the project into the device.

5. Search the device and confirm the dialog window.

6. WinCC Runtime then automatically starts on the panel.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

38

6 Operation of the Application

6.1 “Temperature monitoring with SMS alarm” scenario

6 Operation of the Application

This chapter describes how you can operate the individual scenarios after commissioning.

6.1

“Temperature monitoring with SMS alarm” scenario

When following the instructions of the following table, you realize the following sequence:

simulating the temperature.

sending an SMS to an already defined recipient address.

Table 6-1

No.

Action

1.

2.

Commission the application as described in Chapter

5 .

Simulate the temperature value. Two options are available for this (step 3): simulation via LOGO! TDE or step 4: simulation via the WinCC panel).

3. Simulation via LOGO! TDE

Start the simulation by clicking on the F1 button at LOGO! TDE.

Increase the temperature to 22°C by keeping the F2 button pressed.

The display takes on a red color and an SMS is sent.

Reduce the simulated temperature to under 19 °C by keeping F3 pressed.

The background lighting of the display turns white again and an SMS is also sent.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

39

6 Operation of the Application

6.2 “Receiving SMS commands” scenario

No.

Action

4. Simulation via WinCC-Panel KTP700 BASIC

Click on the “Start simulation” button.

Click on “Simulation value temperature” and enter a temperature value

>22°C.

The display takes on a red color and an SMS is sent.

Click on “Simulation value temperature” and enter a temperature value

<19°C.

The background lighting of the display turns white again and an SMS is sent.

6.2

“Receiving SMS commands” scenario

Syntax of the SMS commands

The following figure shows the syntax for sending SMS commands. “Password” must be replaced by the password assigned via the WBM for sending SMS.

Figure 6-1

When reading values, please note FAQ in

\7\ .

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

40

6 Operation of the Application

6.2 “Receiving SMS commands” scenario

Switch fan on and off

The following table shows how you can switch on the fan of the example application via an SMS.

Table 6-2

No.

Action

1.

2.

3.

Commission the application as described in Chapter

5 .

Send an SMS with the following content to the LOGO! CMR:

“LOGO;LOGO=VM6,1,BYTE”.

(“LOGO” is the password set by “user.cfg” for writing SMS)

Byte VM6 is set to value ‘1’ by the command SMS. Output Q1 is set to ‘1’ via the user program and the fan switched on. LOGO! CMR confirms the command SMS.

A further confirmation is sent by the application (see screenshot).

4. Visually, you can also monitor the successful execution of the command directly at the LOGO! BM, the LOGO! TDE and the KTP700.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

41

6 Operation of the Application

6.3 “Time-of-day synchronization” scenario

6.3

“Time-of-day synchronization” scenario

The “Time-of-day synchronization” scenario realizes the opening and closing of an outlet flap in animal breeding by means of the “Astronomical clock” depending on the position of the sun.

The “Astronomical clock” function sets your output to TRUE between sunrise and sunset. The data is calculated based on the current system time and the given geographical position.

Figure 6-2

Note

The system can be synchronized according to one of the ways described in

Chapter

4.3

.

The inputs for the end position switches of the outlet flap are realized as opener.

If the input = FALSE, it is assumed that this state is currently true.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

42

6 Operation of the Application

6.3 “Time-of-day synchronization” scenario

To test the scenario, please follow the instructions in the table:

Table 6-3

No.

Action

1. Commission the application as described in Chapter

5 .

2. Interconnect inputs I1 and I2 of LOGO! BM with optional 24V, to simulate active endposition switches of the outlet flap via the hardware.

3. Open the LOGO!Soft Comfort project.

4. Press on the “Online Test” button above the function diagram and connect with IP

192.168.0.1.

5. Monitor the scenario. When currently between the configured sunrise and sunset, output Q3 will be active to open the outlet flap.

6. Go back offline.

Change the system time of LOGO! BM. Go to “Tools > Transfer > PC LOGO!”.

Confirm the stopping of LOGO! BM.

7. Change the time to 0 h 1.

Acknowledge by clicking on “Apply to LOGO!” and restart LOGO! BM.

8. Press on the “Online Test” button and connect with LOGO! BM.

Since input I2 indicates that the outlet flap is not closed, output Q4 is set active.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

43

6 Operation of the Application

6.4 “GPS tracking” scenario

6.4

“GPS tracking” scenario

The application in the LOGO! BM logs the current GPS data every 5 minutes. In order to process the data stored on the microSD card in .csv-format, an Excel macro is provided for download.

The following table writes the procedure

for logging GPS data and storing it in the .csv file.

Processing the .csv file using the Excel macro.

Visualizing the created file via an online tool.

Table 6-4

No.

Action

1.

2.

3.

Commission the application as described in Chapter

5 .

Remove the microSD card after some time.

Note

Alternatively, you can also use the .csv file provided for download with a fictitious route.

Since the data has been stored as words, yet originally they came as bytes, the .csv

file must be prepared. Start the Excel macro and enable the execution.

4.

Click on “load data” and enter the .csv file.

5.

Clicking on “OK” automatically starts preparing the .csv file.

Store the prepared file as .csv file. After preparation, the .csv file contains a time stamp as well as longitude and latitude.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

44

6 Operation of the Application

6.4 “GPS tracking” scenario

No.

6.

7.

Action

For visualizing the GPS data, for example, open the web page in

\9\

.

Select the file saved in 5. by clicking on the “Choose file” button. Then click on the

“Go!” button.

1

2

8.

A new window opens and your GPS data is visualized.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

45

6 Operation of the Application

6.4 “GPS tracking” scenario

No.

9.

Action

Alternatively, you can delete the time stamp in step 5. This gives you a “route” mapped out according to the GPS data.

Note

The used freeware “GPS Visualizer” is a free converter for .csv files, for example into .gpx files. Siemens does not provide this service.

If necessary, check the respective license terms of the freeware tool for your application purpose.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

46

7 Further Notes, Tips & Tricks, etc.

7 Further Notes, Tips & Tricks, etc.

Time-of-day synchronization

When using GPS functions in an application, it is recommended to use the GPS signal for time-of-day synchronization.

Using the GPS signal for time-of-day synchronization is favorable for the following reasons:

synchronization via mobile wireless network is not provided by all provider services.

no separate costs unlike for synchronization via NTP or mobile wireless network.

Adjusting the GPS log cycle

The following table shows the procedure of changing the time difference between log processes in the user program.

In the supplied program, data is polled every 5 minutes. A maximal array size of

20,000 entries enables data archiving over approx. 70 days.

Table 7-1

No.

Action

1.

2.

Open the LOGO!Soft Comfort project.

On the second page in “Data logging of GPS data” you click on the B020 block (pulse encoder) to change the given time cycle.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

47

7 Further Notes, Tips & Tricks, etc.

No.

3.

Action

Change the given time cycle in “Transmit GPS data constantly to LOGO! 8”. The time cycle must be smaller or equal to the cycle in “Data logging of GPS data”.

4.

Download the project into the LOGO! BM.

Note

Note that the smallest polling interval of the process interval of the LOGO! BM at the LOGO! CMR is one second!

Adjusting longitude and latitude

Controlling an output depending on sunrise and sunset, the correct location must be sent to the “Astronomical clock” function.

The following table describes how to proceed using Google Maps.

Table 7-2

No.

1.

2.

Action

Open Google Maps in your web browser (see

\10\

).

Enter your address into the search bar and acknowledge by pressing the Return key.

3.

Right-click on the desired position on the map and select “What’s here?” from the context menu.

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

48

7 Further Notes, Tips & Tricks, etc.

No.

4.

Action

Under the search bar you click on the decimal specification of the geo data to receive the specification in degrees, minutes, seconds.

Geo data in degrees, minutes, seconds format:

5.

6.

Open the LOGO!Soft Comfort project.

Enter the coordinates contained in step 4 into both functions “Astronomical clock”

(B11 and B17). Confirm the entry with “OK”.

7.

Load the diagram into the LOGO! BM via “Tools > Transfer > PC LOGO!”).

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

49

8 Related Literature

8 Related Literature

Table 8-1

Topic

Online Support

\2\ Download page of the entry

Manual

CMR20X0 delivery release

\6\ STEP 7 Basic

V13.0

What should you watch out for with communication by text message

(SMS) between a

LOGO! CMR2020 and a LOGO! 8 with values of the data type BYTE,

WORD or

DWORD?

the

TCP/IP settings

\10\ Google Maps

Title

http://support.automation.siemens.com

http://support.automation.siemens.com/WW/view/en/105074237 http://support.automation.siemens.com/WW/view/en/100761780 http://support.automation.siemens.com/WW/view/en/103657268 http://support.automation.siemens.com/WW/view/en/104507729 http://support.automation.siemens.com/WW/view/en/89336297 http://support.automation.siemens.com/WW/view/en/107146628 http://windows.microsoft.com/en-us/windows/change-tcp-ipsettings#1TC=windows-7 http://www.gpsvisualizer.com/ http://www.google.com/maps

9 History

Table 9-1

Version

V1.0

Date

02/2015 First version

Modifications

Applications Logo! CMR 2020

Entry ID: 105074237, V1.0, 01/2015

50

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
