Nikon COOLPIX S6600 Camera User Guide

Nikon COOLPIX S6600 Camera User Guide

No reproduction in any form of this manual, in whole or in part

(except for brief quotation in critical articles or reviews), may be made without written authorization from NIKON CORPORATION.

Printed in Hong Kong

YP3G01(11)

6MN26011-01

DIGITAL CAMERA

User’s Manual

En

Highlight Feature of the COOLPIX S6600

c Gesture control - Easily Take Self-portraits

The direction and angle of the monitor on this camera can be adjusted.

You can easily take self-portrait images in combination with Gesture control.

When you open the monitor and face it forward in the same direction as the camera lens, you can take images without pressing the shutter-release button, simply by moving your hand toward an icon displayed on the monitor.

3

Move your hand toward p.

Countdown starts.

The shooting functions listed below are available.

- q: Start recording a movie

- r: Zoom out (wide-angle)

- p: Take a still image

- s: Zoom in (telephoto)

For detailed operating instructions, see page

A46.

An image is taken.

Introduction

Parts of the Camera

The Basics of Shooting and Playback

Shooting Features

Playback Features

Recording and Playing Back Movies

General Camera Setup

Using the Wi-Fi (Wireless LAN) Function

Connecting the Camera to a TV, Computer, or Printer

Technical Notes and Index

i

Introduction

Read This First

Thank you for purchasing the Nikon COOLPIX S6600 digital camera. Before using the camera,

please read the information in “For Your Safety” (

Aviii-x) and familiarize yourself with the

information provided in this manual. After reading, please keep this manual handy and refer to it to enhance your enjoyment of your new camera.

Confirming the Package Contents

In the event that any items are missing, please contact the store where you purchased the camera.

COOLPIX S6600

Digital Camera

Camera Strap Rechargeable Li-ion

Battery EN-EL19

(with battery case)

Charging AC Adapter

EH-70P*

ii

USB Cable UC-E6 ViewNX 2 CD Reference Manual CD

User’s Manual (this manual)

Warranty

* A plug adapter is included if the camera was purchased in a country or region that requires a plug

adapter. The shape of the plug adapter varies with the country or region of purchase (

A12).

NOTE: A memory card is not included with the camera.

About This Manual

If you want to start using the camera right away, see “The Basics of Shooting and Playback”

(

A10).

To learn about the parts of the camera and information that is displayed in the monitor, see

“Parts of the Camera” (

A1).

About the Included “Reference Manual CD”

A PDF version of the COOLPIX S6600 Reference Manual can be found on the included CD.

Refer to it for more detailed information.

Viewing the “Reference Manual CD”

The Reference Manual can be viewed using Adobe Reader, available for free download from the Adobe website.

1 Start the computer and insert the “Reference Manual CD”.

2 Double-click the CD (COOLPIX S6600) icon in Computer or My Computer (Windows) or on the desktop (Mac OS).

3 Double-click the INDEX.pdf icon to display the language selection screen.

Click a language and follow the links to view the Reference Manual.

iii

iv

Other Information

Symbols and Conventions

To make it easier to find the information you need, the following symbols and conventions are used in this manual:

B

Symbol Description

This icon indicates cautions and information that should be read before using the camera.

C

A/E/F

This icon indicates notes and information that should be read before using the camera.

These icons indicate other pages containing relevant information;

E*: “Reference Section”, F: “Technical Notes and Index.”

*Refer to the Reference Manual for pages indicated with

E.

SD and SDHC/SDXC memory cards are referred to as “memory cards” in this manual.

The setting at the time of purchase is referred to as the “default setting.”

The names of menu items displayed in the camera monitor, and the names of buttons or messages displayed on a computer monitor appear in bold.

In this manual, images are sometimes omitted from monitor display samples so that monitor indicators can be more clearly shown.

Illustrations and monitor content shown in this manual may differ from the actual product.

Information and Precautions

Life-Long Learning

As part of Nikon’s “Life-Long Learning” commitment to ongoing product support and education, continually updated information is available online at the following sites:

For users in the U.S.A.: http://www.nikonusa.com/

For users in Europe and Africa: http://www.europe-nikon.com/support/

For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/

Visit these sites to keep up-to-date with the latest product information, tips, answers to frequently asked questions (FAQs), and general advice on digital imaging and photography. Additional information may be available from the Nikon representative in your area. Visit the site below for contact information:

http://imaging.nikon.com/

Use Only Nikon Brand Electronic Accessories

Nikon COOLPIX cameras are designed to the highest standards and include complex electronic circuitry. Only Nikon brand electronic accessories (including battery chargers, batteries, Charging AC adapters, and AC adapters) certified by Nikon specifically for use with this Nikon digital camera are engineered and proven to operate within the operational and safety requirements of this electronic circuitry.

T

HE USE OF NON-

N

IKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND MAY

VOID YOUR

N

IKON WARRANTY.

The use of third-party rechargeable Li-ion batteries not bearing the Nikon holographic seal could interfere with normal operation of the camera or result in the batteries overheating, igniting, rupturing, or leaking.

For more information about Nikon brand accessories, contact a local authorized Nikon dealer.

Holographic seal: Identifies this device as an authentic Nikon product.

Before Taking Important Pictures

Before taking pictures on important occasions (such as at weddings or before taking the camera on a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable for damages or lost profits that may result from product malfunction.

v

vi

About the Manuals

No part of the manuals included with this product may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form, by any means, without

Nikon’s prior written permission.

Nikon reserves the right to change the specifications of the hardware and software described in these manuals at any time and without prior notice.

Nikon will not be held liable for any damages resulting from the use of this product.

While every effort was made to ensure that the information in these manuals is accurate and complete, we would appreciate it were you to bring any errors or omissions to the attention of the

Nikon representative in your area (address provided separately).

Notice Concerning Prohibition of Copying or Reproduction

Note that simply being in possession of material that was digitally copied or reproduced by means of a scanner, digital camera or other device may be punishable by law.

• Items prohibited by law from being copied or reproduced

Do not copy or reproduce paper money, coins, securities, government bonds or local government bonds, even if such copies or reproductions are stamped “Sample.” The copying or reproduction of paper money, coins, or securities which are circulated in a foreign country is prohibited. Unless the prior permission of the government was obtained, the copying or reproduction of unused postage stamps or post cards issued by the government is prohibited.

The copying or reproduction of stamps issued by the government and of certified documents stipulated by law is prohibited.

• Cautions on certain copies and reproductions

The government has issued cautions on copies or reproductions of securities issued by private companies (shares, bills, checks, gift certificates, etc.), commuter passes, or coupon tickets, except when a minimum of necessary copies are to be provided for business use by a company. Also, do not copy or reproduce passports issued by the government, licenses issued by public agencies and private groups, ID cards and tickets, such as passes and meal coupons.

• Comply with copyright notices

The copying or reproduction of copyrighted creative works such as books, music, paintings, woodcut prints, maps, drawings, movies, and photographs is governed by national and international copyright laws. Do not use this product for the purpose of making illegal copies or to infringe copyright laws.

Disposing of Data Storage Devices

Please note that deleting images or formatting data storage devices such as memory cards or built-in camera memory does not completely erase the original image data. Deleted files can sometimes be recovered from discarded storage devices using commercially available software, potentially resulting in the malicious use of personal image data. Ensuring the privacy of such data is the user’s responsibility.

Before discarding a data storage device or transferring ownership to another person, erase all data using commercial deletion software, or format the device and then completely refill it with images containing no private information (for example, pictures of empty sky). Be sure to also replace any pictures selected for the Select an image option in the Welcome screen setting (

A78). Care

should be taken to avoid injury or damage to property when physically destroying data storage devices.

vii

For Your Safety

To prevent damage to your Nikon product or injury to yourself or to others, read the following safety precautions in their entirety before using this equipment. Keep these safety instructions where all those who use the product will read them.

The consequences that could result from failure to observe the precautions listed in this section are indicated by the following symbol:

This icon marks warnings, information that should be read before using this Nikon product, to prevent possible injury.

WARNINGS

viii

Turn off in the event of malfunction

Should you notice smoke or an unusual smell coming from the camera or Charging

AC Adapter, unplug the Charging AC

Adapter and remove the battery immediately, taking care to avoid burns.

Continued operation could result in injury.

After removing or disconnecting the power source, take the equipment to a Nikonauthorized service representative for inspection.

Do not disassemble

Touching the internal parts of the camera or

Charging AC Adapter could result in injury.

Repairs should be performed only by qualified technicians. Should the camera or

Charging AC Adapter break open as the result of a fall or other accident, take the product to a Nikon-authorized service representative for inspection, after unplugging the product and/or removing the battery.

Do not use the camera or Charging

AC Adapter in the presence of flammable gas

Do not use electronic equipment in the presence of flammable gas, as this could result in explosion or fire.

Handle the camera strap with care

Never place the strap around the neck of an infant or child.

Keep out of reach of children

Particular care should be taken to prevent infants from putting the battery or other small parts into their mouths.

Do not remain in contact with the camera, battery charger, or AC adapter for extended periods while the devices are on or in use

Parts of the devices become hot. Leaving the devices in direct contact with the skin for extended periods may result in lowtemperature burns.

Do not leave the product where it will be exposed to extremely high temperatures, such as in an enclosed automobile or in direct sunlight

Failure to observe this precaution could cause damage or fire.

Observe caution when handling the battery

The battery may leak, overheat, or explode if improperly handled. Observe the following precautions when handling the battery for use in this product:

Before replacing the battery, turn the product off. If you are using the Charging

AC Adapter/AC adapter, be sure it is unplugged.

Use only a Rechargeable Li-ion Battery

EN-EL19 (included). Charge the battery by using a camera that supports battery charging or by using a Battery Charger

MH-66 (available separately). To charge the battery with the camera, use either

Charging AC Adapter EH-70P (included) or the Charge by computer function.

When inserting the battery, do not attempt to insert it upside down or backwards.

Do not short or disassemble the battery or attempt to remove or break the battery insulation or casing.

Do not expose the battery to flame or to excessive heat.

Do not immerse in or expose to water.

Put the battery in the battery case before transporting it. Do not transport or store with metal objects such as necklaces or hairpins.

The battery is prone to leakage when fully discharged. To avoid damage to the product, be sure to remove the battery when no charge remains.

Discontinue use immediately should you notice any change in the battery, such as discoloration or deformation.

If liquid from the damaged battery comes in contact with clothing or skin, rinse immediately with plenty of water.

Observe the following precautions when handling the Charging AC

Adapter

Keep dry. Failure to observe this precaution could result in fire or electric shock.

Dust on or near the metal parts of the plug should be removed with a dry cloth.

Continued use could result in fire.

Do not handle the plug or go near the

Charging AC Adapter during lightning storms. Failure to observe this precaution could result in electric shock.

ix

x

Do not damage, modify, forcibly tug or bend the USB cable, place it under heavy objects, or expose it to heat or flames.

Should the insulation be damaged and the wires become exposed, take it to a

Nikon-authorized service representative for inspection. Failure to observe these precautions could result in fire or electric shock.

Do not handle the plug or Charging AC

Adapter with wet hands. Failure to observe this precaution could result in electric shock.

Do not use with travel converters or adapters designed to convert from one voltage to another or with DC-to-AC inverters. Failure to observe this precaution could damage the product or cause overheating or fire.

Use appropriate cables

When connecting cables to the input and output jacks, use only the cables provided or sold by Nikon for the purpose, to maintain compliance with product regulations.

Handle moving parts with care

Be careful that your fingers or other objects are not pinched by the lens cover or other moving parts.

CD-ROMs

The CD-ROMs included with this device should not be played back on audio CD equipment. Playing CD-ROMs on an audio

CD player could cause hearing loss or damage the equipment.

Using the flash close to your subject's eyes could cause temporary visual impairment.

The flash should be no less than 1 meter

(3 ft 4 in.) from the subject.

Particular care should be observed when photographing infants.

Do not operate the flash with the flash window touching a person or object

Failure to observe this precaution could result in burns or fire.

Avoid contact with liquid crystal

Should the monitor break, care should be taken to avoid injury caused by broken glass and to prevent liquid crystal from the monitor touching the skin or entering the eyes or mouth.

Turn the power off when using inside an airplane or the hospital

Turn the power off while inside the airplane during take off or landing. Do not use wireless network functions while in the air.

Follow the instructions of the hospital when using while in a hospital. The electromagnetic waves emitted by this camera may disrupt the electronic systems of the airplane or the instruments of the hospital. If you are using an Eye-Fi card, remove it from the camera before boarding an aircraft or entering a hospital.

Notices

Notices for Customers in the

U.S.A.

IMPORTANT SAFETY

INSTRUCTIONS -

SAVE THESE INSTRUCTIONS.

DANGER - TO REDUCE THE RISK OF FIRE

OR ELECTRIC SHOCK, CAREFULLY

FOLLOW THESE INSTRUCTIONS

For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper configuration for the power outlet if needed.

The power supply unit is intended to be correctly orientated in a vertical or floor mount position.

Federal Communications

Commission (FCC) Radio

Frequency Interference

Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/television technician for help.

CAUTIONS

Modifications

The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by

Nikon Corporation may void the user’s authority to operate the equipment.

xi

xii

Interface Cables

Use the interface cables sold or provided by

Nikon for your equipment. Using other interface cables may exceed the limits of

Class B Part 15 of the FCC rules.

Notice for customers in the State of

California

WARNING

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

Nikon Inc.,

1300 Walt Whitman Road

Melville, New York 11747-3064

USA

Tel: 631-547-4200

Notice for customers in Canada

CAN ICES-3 B / NMB-3 B

Notices for customers in Europe

CAUTIONS

RISK OF EXPLOSION IF BATTERY IS

REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES

ACCORDING TO THE INSTRUCTIONS.

This symbol indicates that electrical and electronic equipment is to be collected separately.

The following apply only to users in European countries:

This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste.

Separate collection and recycling helps conserve natural resources and prevent negative consequences for human health and the environment that might result from incorrect disposal.

For more information, contact the retailer or the local authorities in charge of waste management.

This symbol on the battery indicates that the battery is to be collected separately.

The following apply only to users in European countries:

All batteries, whether marked with this symbol or not, are designated for separate collection at an appropriate collection point. Do not dispose of as household waste.

For more information, contact the retailer or the local authorities in charge of waste management.

Wi-Fi (Wireless LAN Network)

This product is controlled by the United States Export Administration Regulations, and you are required to obtain permission from the United States government if you export or reexport this product to any country to which the United States embargoes goods. The following countries were subject to embargo: Cuba, Iran, North Korea, Sudan, and Syria. Since the target countries are subject to change, please contact the United States Department of

Commerce for the latest information.

Restrictions on Wireless Devices

The wireless transceiver included in this product conforms to wireless regulations in the country of sale and is not for use in other countries (products purchased in the EU or EFTA can be used anywhere within the EU and EFTA). Nikon does not accept liability for use in other countries. Users who are unsure as to the original country of sale should consult with their local Nikon service center or Nikon-authorized service representative. This restriction applies to wireless operation only and not to any other use of the product.

Notice for Customers in the U.S.A. and Canada

Federal Communications Commission (FCC) and Industry of Canada (IC)

Declaration of Conformity

This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

FCC/IC RF Exposure Statement

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure of low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research.

xiii

xiv

COOLPIX S6600 (FCC ID:CGJ1150EB/IC ID:4634A-1150EB) has been tested and found to comply with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-

102 of the IC radio frequency (RF) Exposure rules. Please refer to the SAR test report that was uploaded to FCC website.

Declaration of Conformity (Europe)

Hereby, Nikon Corporation, declares that COOLPIX S6600 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The declaration of conformity may be consulted at http://imaging.nikon.com/support/pdf/DoC_S6600.pdf.

Notice for Customers in Singapore

This device complies with radio-frequency regulations.

Complies with

IDA Standards

DA103423

Precautions when Using Radio Transmissions

Always keep in mind that radio transmission or reception of data is subject to interception by third parties. Note that Nikon is not responsible for data or information leaks that may occur during data transfer.

The operating frequency band of this equipment is used by industrial, scientific, consumer and medical equipment including microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring no license), and amateur radio stations (hereinafter referred to as “another station”). 1.

Before using this equipment, confirm that another station is not being operated nearby. 2.

In the event of this equipment causing harmful radio wave interference with another station, promptly change the operating frequency or stop radio wave emission by turning off the power, etc. 3. If you have further questions, contact a Nikon service center or Nikon authorized service representative.

Personal Information Management and Disclaimer

User information registered and configured on the product, including wireless LAN connection settings and other personal information, is susceptible to alteration and loss resulting from operational error, static electricity, accident, malfunction, repair or other handling. Always keep separate copies of important information. Nikon is not responsible for any direct or indirect damages or lost profits resulting from alteration or loss of content that is not attributable to Nikon.

Before discarding this product or transferring it to another owner, perform Reset all in the

setup menu (

A79) to delete all user information registered and configured with the

product, including wireless LAN connection settings and other personal information.

xv

Table of Contents

Introduction ................................................... ii

Read This First ....................................................... ii

Confirming the Package Contents................. ii

About This Manual .................................................. iii

Information and Precautions ............................. v

For Your Safety ................................................. viii

WARNINGS ................................................................ viii

Notices .................................................................... xi

Wi-Fi (Wireless LAN Network)...................... xiii

Preparation 4 Setting the Display Language,

Date, and Time................................................... 16

Step 1 Turn the Camera On........................... 20

Step 2 Select a Shooting Mode.................... 22

Available Shooting Modes................................ 23

Step 3 Frame a Picture .................................... 24

Using the Zoom ...................................................... 25

Step 4 Focus and Shoot.................................. 26

The Shutter-release Button .............................. 27

Step 5 Play Back Images ................................. 28

Step 6 Delete Images....................................... 30

Parts of the Camera ..................................... 1

The Camera Body................................................. 1

Attaching the Camera Strap............................... 3

Opening and Adjusting the Angle of the

Monitor............................................................................ 3

Using Menus (the d Button)....................... 4

The Monitor ........................................................... 6

Shooting Mode .......................................................... 6

Playback Mode ........................................................... 8

The Basics of Shooting and Playback

........................................................................... 10

Preparation 1 Insert the Battery .................. 10

Preparation 2 Charge the Battery ............... 12

Preparation 3 Insert a Memory Card.......... 14

Internal Memory and Memory Cards......... 15

Shooting Features ..................................... 32 x (Scene Auto Selector) Mode................... 32

Scene Mode (Shooting Suited to Scenes)

................................................................................. 34

Tips and Notes.......................................................... 35

Special Effects Mode (Applying Effects

When Shooting) ................................................ 40

Smart Portrait Mode (Capturing Images of

Smiling Faces) .................................................... 42

A (Auto) Mode ................................................ 44

Using Quick Effects................................................ 45

Using the Self-timer with Gesture Control

................................................................................. 46

Functions That Can Be Set Using the Multi

Selector................................................................. 48

Using the Flash ........................................................ 49

Using the Self-timer .............................................. 51

xvi

Refer to the Reference Manual for pages indicated with

E.

Using Macro Mode................................................ 53

Adjusting Brightness (Exposure

Compensation)........................................................ 54

Default Settings....................................................... 55

Functions That Can Be Set with the d

Button (Shooting Menu) ................................ 57

Options Available in the Shooting Menu

........................................................................................... 58

Functions That Cannot Be Used

Simultaneously .................................................. 60

Focusing............................................................... 63

Using Target Finding AF .................................... 63

Using Face Detection .......................................... 64

Using Skin Softening............................................ 65

Subjects Not Suitable for Autofocus.......... 66

Focus Lock.................................................................. 67

Using the Wi-Fi (Wireless LAN) Function

.......................................................................... 80

Functions That Can Be Performed Using

Wi-Fi ....................................................................... 80

Take Photos................................................................ 80

View Photos ............................................................... 80

Installing the Software on the Smart Device

................................................................................. 80

Connecting the Smart Device to the Camera

................................................................................. 81

Connecting the Camera to a TV,

Computer, or Printer................................. 83

Connection Methods....................................... 83

Using ViewNX 2 ................................................. 85

Installing ViewNX 2................................................ 85

Transferring Images to the Computer....... 88

Viewing Images ....................................................... 90

Playback Features....................................... 68

Playback Zoom .................................................. 68

Thumbnail Playback, Calendar Display..... 69

Functions That Can Be Set with the d

Button (Playback Menu) ................................. 70

Recording and Playing Back Movies.... 72

Recording Movies ............................................. 72

Functions That Can Be Set with the d

Button (Movie Menu) .......................................... 75

Playing Back Movies ........................................ 76

General Camera Setup.............................. 78

Functions That Can Be Set with the d

Button (Setup Menu) ....................................... 78

Reference Section .................................

E1

Using Easy Panorama (Shooting and

Playback) .........................................................

E2

Shooting with Easy Panorama .................

E2

Viewing Images Captured with Easy

Panorama ..............................................................

E5

Favorite Pictures Mode ..............................

E6

Adding Images to Albums..........................

E6

Playing Back Images in Albums...............

E7

Removing Images from Albums .............

E8

Changing the Favorites Album Icon ....

E9

Auto Sort Mode ..........................................

E10

Refer to the Reference Manual for pages indicated with

E.

xvii

xviii

List by Date Mode......................................

E11

Viewing and Deleting Images Captured

Continuously (Sequence)........................

E12

Viewing Images in a Sequence ............

E12

Deleting Images in a Sequence ...........

E13

Editing Still Images....................................

E14

Before Editing Images ................................

E14

Quick Effects: Changing Hue or Mood

..................................................................................

E15

Quick Retouch: Enhancing Contrast and

Saturation...........................................................

E16

D-Lighting: Enhancing Brightness and

Contrast...............................................................

E16

Red-eye Correction: Correcting Red-eye

When Shooting with the Flash.............

E17

Glamour Retouch: Enhancing Human Faces

..................................................................................

E18

Small Picture: Reducing the Size of an

Image....................................................................

E20

Crop: Creating a Cropped Copy ..........

E21

Connecting the Camera to a TV (Viewing

Images on a TV) ..........................................

E22

Connecting the Camera to a Printer (Direct

Print) ...............................................................

E24

Connecting the Camera to a Printer

..................................................................................

E25

Printing Individual Images.......................

E27

Printing Multiple Images ..........................

E29

Editing Movies ............................................

E32

The Shooting Menu (for A (Auto) Mode)

..........................................................................

E34

Image Mode Settings (Image Size and

Quality) ................................................................

E34

Refer to the Reference Manual for pages indicated with

E.

White Balance (Adjusting Hue).............

E36

Continuous Shooting .................................

E39

ISO Sensitivity...................................................

E42

Color Options...................................................

E43

AF Area Mode ..................................................

E44

Autofocus Mode ............................................

E48

Quick Effects .....................................................

E48

The Smart Portrait Menu .........................

E49

Skin Softening..................................................

E49

Smile Timer........................................................

E50

Blink Proof ..........................................................

E51

The Playback Menu ...................................

E52

Print Order (Creating a DPOF Print Order)

..................................................................................

E52

Slide Show .........................................................

E56

Protect..................................................................

E57

Rotate Image....................................................

E59

Voice Memo......................................................

E60

Copy (Copy Between Internal Memory and

Memory Card)..................................................

E61

Sequence Display Options ......................

E63

Choose Key Picture ......................................

E63

The Movie Menu ........................................

E64

Movie Options.................................................

E64

Open with HS Footage ..............................

E68

Autofocus Mode ............................................

E68

Wind Noise Reduction ...............................

E69

The Setup Menu .........................................

E70

Welcome Screen............................................

E70

Time Zone and Date....................................

E71

Monitor Settings ............................................

E73

Print Date (Imprinting Date and Time)

..................................................................................

E75

Gesture Control..............................................

E76

Vibration Reduction.....................................

E77

Motion Detection..........................................

E78

AF Assist ..............................................................

E79

Digital Zoom ....................................................

E79

Sound Settings ...............................................

E80

Auto Off...............................................................

E80

Format Memory/Format Card...............

E81

Language ...........................................................

E82

TV Settings.........................................................

E82

Charge by Computer..................................

E83

Blink Warning...................................................

E84

Wi-Fi Options ...................................................

E85

Eye-Fi Upload...................................................

E87

Reset All...............................................................

E88

Firmware Version...........................................

E88

Error Messages............................................

E89

File Names ....................................................

E94

Optional Accessories ................................

E95

Technical Notes and Index..................

F1

Caring for the Product .................................

F2

The Camera............................................................

F2

The Battery .............................................................

F3

Charging AC Adapter ......................................

F4

Memory Cards......................................................

F5

Cleaning and Storage...................................

F6

Cleaning...................................................................

F6

Storage .....................................................................

F6

Troubleshooting ............................................

F7

Specifications ...............................................

F17

Approved Memory Cards...........................

F22

Index................................................................

F25

Refer to the Reference Manual for pages indicated with

E.

xix

xx

Parts of the Camera

The Camera Body

1 2 3 4 5 6

14

13

12

11

7

8

9

10

1

Flash............................................................................ 49

2

Shutter-release button.................................... 26

3

Zoom control........................................................ 25 f: wide-angle ................................................ 25 g: telephoto...................................................... 25

h: thumbnail playback............................ 69

i: playback zoom.......................................... 68

j: help ................................................................ 34

4

Power switch/power-on lamp ................... 20

5

c (playback) button....................................... 28

6

A (shooting mode) button....................... 22

Lens cover closed

7

Self-timer lamp.....................................................51

AF-assist illuminator ..........................................79

8

Microphone (stereo)

9

Lens

10

Lens cover

11

Eyelet for camera strap.......................................3

12

Connector cover..................................................83

13

HDMI micro connector (Type D) ...............83

14

USB/audio/video output connector.......83

1

2

1

11

4

5

6

7

2

3

10

9

8

1

Charge lamp .......................................................... 13

Flash lamp............................................................... 49

2

b (e movie-record) button..................... 72

3

Multi selector............................................................ 4

4

k (apply selection) button ............................4

5

l (delete) button...............................30, E61

6

d (menu) button............ 4, 57, 70, 75, 78

7

8

Battery-chamber/

memory card slot cover..........................10, 14

Power connector cover (for connection with optional AC adapter)

9

Tripod socket

10

Speaker

11

Monitor....................................................................3, 6

Attaching the Camera Strap

Opening and Adjusting the Angle of the Monitor

The direction and angle of the monitor on this camera can be adjusted. This is useful when shooting with the camera in a high or low position. In addition, using this feature with

Gesture control (

A46) makes it easy to take self-portrait images.

90° 180°

For normal shooting, fold the monitor against the back of the camera, facing rearward (3).

To protect the monitor from scratches and dirt while you are carrying or not using the camera, close the monitor so that it is facing inward against the back of the camera.

B

Notes About the Monitor

When moving the monitor, do not apply excessive force and make sure to turn it slowly within the adjustable range.

3

4

Using Menus (the

d Button)

Use the multi selector and k button to navigate the menus.

1

Press the d button.

The menu is displayed.

2

Press the multi selector

J.

The current menu icon is displayed in yellow.

Shooting menu

Image mode

White balance

Continuous

ISO sensitivity

Color options

AF area mode

Autofocus mode

Menu icons

3

Select the desired menu icon.

The menu is changed.

Set up

Welcome screen

Time zone and date

Monitor settings

Print date

Gesture control

Vibration reduction

Motion detection

4

Press the k button.

The menu options become selectable.

Welcome screen

Time zone and date

Monitor settings

Print date

Gesture control

Vibration reduction

Motion detection

5

Select a menu option.

Welcome screen

Time zone and date

Monitor settings

Print date

Gesture control

Vibration reduction

Motion detection

7

Select a setting.

Vibration reduction

On

Off

6

Press the k button.

The settings for the option you selected are displayed.

Vibration reduction

On

Off

8

Press the k button.

The setting you selected is applied.

When you are finished using the menu, press the d button.

C

Notes About Setting Menu Options

Certain menu options cannot be set depending on the current shooting mode or the state of the camera. Unavailable options are displayed in gray and cannot be selected.

When a menu is displayed, you can switch to shooting mode by pressing the shutter-release button, A (shooting mode) button, or b (e movie-record) button.

5

6

The Monitor

The information that is displayed in the monitor during shooting and playback changes depending on the camera’s settings and state of use.

By default, information is displayed when the camera is first turned on and when you operate the camera, and turns off after a few seconds (when Photo info is set to Auto info in

Monitor settings (

A78)).

Shooting Mode

41

40

39

37

38

36

35

34

33

31

32

28

29

30

1

2

3

4

5

10

9

6

8

7

11 12

+1.0

29m 0s

13

14

23

25

27 26

24

22 17 16

21 20 19 18

15

1

Shooting mode............................................ 22, 23

2

Flash mode............................................................. 49

3

Macro mode .......................................................... 53

4

Zoom indicator ............................................ 25, 53

5

Focus indicator..................................................... 26

6

Movie options (normal speed movies)

........................................................................75,

E64

7

Movie options (HS movies) ..........75,

E65

8

Image mode ..........................................58,

E34

9

Easy panorama..................................................... 38

10

Vibration reduction icon ................................ 78

11

Motion detection icon .................................... 79

12

Wind noise reduction ...................................... 75

13

Exposure compensation value .................. 54

14

Movie recording time remaining ............. 72

15

Number of exposures remaining

(still images) ........................................................... 20

16

Internal memory indicator............................ 20

17

Aperture value...................................................... 27

18

Focus area (target finding AF) .....26, 58, 63

19

Focus area (for manual or center) .... 58, 67

20

Focus area (face detection,

pet detection)................................39, 42, 58, 64

21

Focus area (subject tracking)...... 58,

E47

22

Shutter speed........................................................27

23

ISO sensitivity.........................................................58

24

Battery level indicator ......................................20

25

Print date..................................................................78

26

Travel destination icon ...........................

E71

27

“Date not set” indicator...................................16

28

Eye-Fi communication indicator...............79

29

Wi-Fi communication indicator .................79

30

Gesture control ............................................46, 78

31

White balance mode ........................................58

32

Skin softening........................................................59

33

Color options.........................................................58

34

Quick effects icon .......................................45, 58

35

Continuous shooting mode ........................58

36

Blink proof icon ....................................................59

37

Hand-held/tripod........................................35, 36

38

Backlighting (HDR) .............................................37

39

Self-timer indicator ............................................51

40

Smile timer..............................................................59

41

Pet portrait auto release .................................39

7

8

Playback Mode

1 2 3

4 5 6 7 8 9

10 11

12

13

25

27

26

9999. JPG

15 / 11 / 2013 15:30

24 23

22 21 20

14

15

16

17

19 18 a b

1

Album icon in favorite pictures mode

..................................................................................

E6

2

Category icon in auto sort mode .....

E10

3

List by date icon ..........................................

E11

4

Protect icon............................................70,

E57

5

Sequence display (when Individual

pictures is selected) ........................71,

E63

6

Print order icon ....................................70,

E52

7

Voice memo indicator.....................70,

E60

8

Glamour retouch icon .....................70,

E18

9

Quick effects icon.......................29, 45,

E15

10

D-Lighting icon....................................70,

E16

11

Quick retouch icon ............................70,

E16

12

Red-eye correction ............................70,

E17

13

Internal memory indicator............................ 20

14

(a) Current image number/ total number of images

(b) Movie length

15

Image mode.......................................... 58,

E34

16

Easy panorama .....................................................38

17

Movie options ...................................... 75,

E64

18

Crop icon................................................. 68,

E21

19

Small picture icon.............................. 70,

E20

20

Volume indicator................................ 76,

E60

21

Quick effects guide............................................29

22

Easy panorama playback guide ... 38,

E5

Sequence playback guide ............ 71,

E12

Movie playback guide......................................76

23

Time of recording

24

Date of recording

25

Battery level indicator ......................................20

26

File number and type..............................

E94

27

Eye-Fi communication indicator

....................................................................... 79,

E87

9

The Basics of Shooting and Playback

Preparation 1 Insert the Battery

1

Open the battery-chamber/memory card slot cover.

2

Insert the battery.

Push the orange battery latch in the direction indicated by the arrow (1), and fully insert the battery (2).

The battery locks into place when inserted correctly.

Battery latch

10

B

Be Careful to Insert the Battery in Correct

Direction

Inserting the battery upside down or backwards could damage the camera.

3

Close the battery-chamber/memory card slot cover.

Removing the Battery

Turn the camera off and make sure that the power-on lamp and the monitor have turned off, and then open the batterychamber/memory card slot cover.

Move the battery latch in the direction indicated by the arrow

(1) to eject the battery (2).

B

High Temperature Caution

The camera, battery, and memory card may be hot immediately after using the camera.

11

Preparation 2 Charge the Battery

1

Prepare the included Charging AC Adapter.

If a plug adapter* is included with your camera, attach the plug adapter to the plug on the Charging AC Adapter. Push the plug adapter firmly until it is securely held in place. Once the two are connected, attempting to forcibly remove the plug adapter could damage the product.

* The shape of the plug adapter varies according to the country or region in which the camera was purchased.

The Charging AC Adapter comes with the plug adapter attached in

Argentina and Korea.

2

Make sure the battery is installed in the camera, and then connect the camera to the Charging AC Adapter in order of 1 to 3.

Keep the camera turned off.

Make sure that the plugs are properly oriented. Do not insert or remove the plugs at an angle when connecting or disconnecting them.

Charge lamp

Electrical outlet

12

USB cable (included)

The charge lamp slowly flashes green to indicate that the battery is charging.

Shooting is not possible while the camera is connected to the Charging AC Adapter.

Charge lamp

Flashes quickly

(green)

Description

Flashes slowly (green) The battery is charging.

Off

When charging is complete, the charge lamp stops flashing green and turns off. About 3 hours are required to charge a fully exhausted battery.

The ambient temperature is not suited to charging. Charge the battery indoors with an ambient temperature of 5°C to 35°C (41°F to 95°F).

The USB cable or Charging AC Adapter is not properly connected, or there is a problem with the battery. Disconnect the USB cable or unplug the Charging AC Adapter and correctly connect it again, or change the battery.

3

Disconnect the Charging AC Adapter from the electrical outlet and then disconnect the USB cable.

C

Charging Using a Computer or Battery Charger

You can also charge the battery by connecting the camera to a computer (A83, E83).

You can use the Battery Charger MH-66 (available separately; E95) to charge the battery without using the camera.

13

Preparation 3 Insert a Memory Card

1

Turn off the camera and open the batterychamber/memory card slot cover.

2

Insert the memory card.

Slide the memory card in until it clicks into place.

Memory card slot

14

B

Be Careful to Insert the Memory Card in Correct

Direction

Inserting the memory card upside down or backwards could damage the camera and the memory card.

3

Close the battery-chamber/memory card slot cover.

B

Formatting Memory Cards

The first time you insert a memory card that has been used in another device into this camera, make sure to format it with this camera. Insert the card into the camera, press the d button, and select

Format card in the setup menu.

Removing Memory Cards

Turn the camera off and make sure that the power-on lamp and the monitor have turned off, and then open the batterychamber/memory card slot cover.

Gently push the memory card into the camera (1) to partially eject the card (2).

B

High Temperature Caution

The camera, battery, and memory card may be hot immediately after using the camera.

Internal Memory and Memory Cards

Camera data, including images and movies, can be saved either in the camera’s internal memory or on a memory card. To use the camera’s internal memory, first remove the memory card.

15

16

Preparation 4 Setting the Display Language, Date, and Time

When the camera is turned on for the first time, the language-selection screen and the date and time setting screen for the camera clock are displayed.

If you exit without setting the date and time, O will flash when the shooting screen is displayed.

1

Press the power switch to turn on the camera.

2

Use the multi selector

HI to select the desired language and press the k button.

3

Select Yes and press the k button.

Language

Choose time zone and set date and time?

Yes

No

4

Select your home time zone and press the k button.

To enable daylight saving time, press H.

When the daylight saving time function is enabled, W is displayed above the map.

To turn off the daylight saving time function, press

I.

5

Select the date format and press the k button.

London, Casablanca

6

Set the date and time, and press the k button.

Select a field: Press JK (changes between D, M, Y, hour, and minute).

Edit the date and time: Press HI.

Confirm the setting: Select the minute field and press the k button.

7

Select Yes and press the k button.

When settings are finished, the lens extends and the camera switches to shooting mode.

Date format

Year/Month/Day

Month/Day/Year

Day/Month/Year

Date and time

D

0 1

M

0 1

0 0

Y

2 0 1 3

0 0

Date and time

15/11/2013 15

:

30

Y

2 0 1 3

OK?

M

1 1

Yes

1 5

No

D

1 5

3 0

17

18

C

Changing the Language Setting and the Date and Time Setting

You can change these settings using the Language and Time zone and date settings in the

z setup menu (A78).

You can enable or disable daylight saving time in the z setup menu by selecting Time zone and

date followed by Time zone. Press the multi selector

K and then H to enable daylight saving time and move the clock forward one hour, or

I to disable daylight saving time and move the clock back one hour.

C

The Clock Battery

The camera’s clock is powered by a built-in backup battery.

The backup battery charges when the main battery is inserted into the camera or when the camera is connected to an optional AC adapter, and it can run the clock for several days after about ten hours of charging.

If the camera’s backup battery becomes exhausted, the date and time setting screen is displayed when the camera is turned on. Set the date and time again. See step 3 (

A16) of “Preparation 4

Setting the Display Language, Date, and Time” for more information.

C

Imprinting the Shooting Date on Printed Images

You can permanently imprint the shooting date on images as they are captured by setting Print

date in the setup menu (

A78).

If you want the shooting date to be printed without using the Print date setting, print using the

ViewNX 2 software (

A85).

19

20

Step 1 Turn the Camera On

1

Press the power switch.

The monitor turns on.

To turn the camera off, press the power switch again.

2

Check the battery level indicator and the number of exposures remaining.

Battery level indicator

Number of exposures remaining

Display b

B

N

Battery exhausted.

Description

The battery level is high.

The battery level is low.

The camera cannot capture images.

Recharge the battery.

Battery level indicator

Number of Exposures Remaining

The number of images that can be taken is displayed.

C is displayed when no memory card is inserted in the camera, and images are saved in the internal memory.

C

The Auto Off Function

Flashes

No operations performed

No operations performed

3 min

Camera enters standby mode.

Camera turns off.

The time that elapses before the camera enters standby mode is about one minute. The time can

be changed using the Auto off setting in the setup menu (

A78).

While the camera is in standby mode, the monitor turns back on if you perform any of the following operations or open the monitor:

➝ Press the power switch, shutter-release button, A (shooting mode) button, c (playback) button, or b (e movie-record) button

21

22

Step 2 Select a Shooting Mode

1

Press the A button.

2

Use the multi selector

HI to select a shooting mode and press the k button.

A (auto) mode is used in this example.

The shooting mode setting is saved even after the camera is turned off.

Auto mode

Available Shooting Modes

x b

D

F

A

Scene auto selector

Scene mode

A32

The camera automatically selects the optimum scene mode when you frame an image, making it even easier to take images using settings that suit the scene.

A34

Camera settings are optimized according to the scene that you select.

Special effects

A40

Effects can be applied to images during shooting.

Smart portrait

A42

When the camera detects a smiling face, you can take an image automatically without pressing the shutter-release button (smile timer). You can also use the skin softening option to smooth the skin tones of human faces.

Auto mode

A44

Used for general shooting. Settings can be adjusted to suit the shooting conditions and the type of shot you want to capture.

23

24

Step 3 Frame a Picture

1

Hold the camera steady.

Keep fingers and other objects away from the lens, flash, AF assist-illuminator, microphone, and speaker.

When taking pictures in portrait (“tall”) orientation, turn the camera so that the flash is above the lens.

2

Frame the picture.

C

When Using a Tripod

We recommend using a tripod to stabilize the camera in the following situations.

- When shooting in dim lighting

- When shooting with the flash mode (

A50) set to W (off)

- When using the telephoto setting

When using a tripod to stabilize the camera during shooting, set Vibration reduction to Off in

the setup menu (

A78) to prevent potential errors caused by this function.

Using the Zoom

When you move the zoom control, the zoom lens position changes.

To zoom in closer to the subject: Move toward g (telephoto)

To zoom out and view a larger area: Move toward f (wide-angle)

Zoom out Zoom in

When you turn the camera on, the zoom moves to the maximum wide-angle position.

A zoom indicator is displayed at the top of the monitor when the zoom control is moved.

Digital zoom, which allows you to further magnify the subject up to approximately 4× the maximum optical

Optical zoom

Digital zoom zoom ratio, can be activated by moving and holding the zoom control toward g when the camera is zoomed in to the maximum optical zoom position.

C

Digital Zoom and Interpolation

While using digital zoom, the image quality decreases due to interpolation when the zoom is increased beyond the V position. The position of V moves to the right as the size of an image decreases.

Small image size

25

Step 4 Focus and Shoot

1

Press the shutter-release button halfway.

When the subject is in focus, the focus area glows green

(multiple focus areas can glow green).

When you are using digital zoom, the camera focuses on the subject in the center of the frame and the focus area is not displayed. When the camera has focused, the focus indicator (

A7) glows green.

If the focus area or focus indicator flashes red, the camera is unable to focus. Modify the composition and try pressing the shutter-release button halfway again.

2

Without lifting your finger, press the shutterrelease button the rest of the way down.

26

3

To apply an effect to the captured image, press the k button.

The screen for selecting an effect is displayed.

See “Using Quick Effects” (

A45) for more information.

When you press the d button or when no operations are performed for about five seconds, the monitor display returns to the shooting screen.

To not display the screen shown on the right, set Quick

effects to Off in the shooting menu (

A57).

Quick effects

Cancel Choose effect

The Shutter-release Button

Press halfway

To set focus and exposure (shutter speed and aperture value), press the shutter-release button lightly until you feel a slight resistance. Focus and exposure remain locked while the shutterrelease button is pressed halfway.

Press all the way

Press the shutter-release button all the way to release the shutter and take an image.

Do not use force when pressing the shutter-release button, as this may result in camera shake and blurred images. Press the button gently.

B

Notes About Saving Images and Recording Movies

The indicator showing the number of exposures remaining or the indicator showing the maximum movie length flashes while images are being saved or while a movie is being recorded. Do not open

the battery-chamber/memory card slot cover or remove the battery or memory card while an indicator is flashing. Doing this could result in loss of data, or in damage to the camera or the memory card.

27

28

Step 5 Play Back Images

1

Press the c (playback) button.

If you press and hold down the c (playback) button while the camera is turned off, the camera turns on in playback mode.

2

Use the multi selector to select an image to display.

Press and hold down HIJK to scroll through the images quickly.

Display the previous image

Display the next image

To return to shooting mode, press the A button or shutter-release button.

0004. JPG

15 / 11 / 2013 15:30

C

Notes About the Quick Effects Function

When e is displayed in full-frame playback mode, you can press k button to apply an effect to the image.

When the effect selection screen is displayed, use the multi selector

HIJK to select an effect, press the k button, and then select Yes in the confirmation dialog and press the k button to save the image as a separate file.

See “Quick Effects: Changing Hue or Mood” (

E15) for more information.

0004. JPG

15 / 11 / 2013 15:30

29

30

Step 6 Delete Images

1

Press the l button to delete the image currently displayed in the monitor.

2

Use the multi selector

HI to select the desired deletion method and press the k button.

To exit without deleting, press the d button.

3

Select Yes and press the k button.

Deleted images cannot be recovered.

To cancel, select No and press the k button.

Delete

Current image

Erase selected images

All images

Erase 1 image?

Yes

No

Operating the Erase Selected Images Screen

1

Use the multi selector

JK to select an image to be deleted, and then use

H to display K.

To undo the selection, press I to remove K.

Move the zoom control (A1) toward g (i) to switch to

full-frame playback or f (h) to switch to thumbnail playback.

Erase selected images

2

Add K to all images that you want to delete and then press the k button to confirm the selection.

A confirmation dialog is displayed. Follow the instructions displayed in the monitor.

B

Deleting Images in a Sequence

If you press the l button and delete a key picture while only key pictures are displayed for

sequences of images (

A71), all images in the sequence, including the key picture, are deleted.

To delete individual images in a sequence, press the k button to display them one at a time and press the l button.

C

Deleting the Last Image Captured While in Shooting Mode

When using shooting mode, press the l button to delete the last image that was saved.

31

32

Shooting Features

x (Scene Auto Selector) Mode

The camera automatically selects the optimum scene mode when you frame an image, making it even easier to take images using settings that suit the scene.

Enter shooting mode

M A (shooting mode) button M x (scene auto selector) mode M k button

When you point the camera at the subject, the camera automatically selects the optimum scene mode from the list below and adjusts the shooting settings accordingly.

e b f h c g i j d d

Portrait (for taking close-up portraits of one or two people)

Portrait (for taking portraits of three or more people, or framing images with a large background size)

Landscape

Night portrait (for taking close-up portraits of one or two people)

Night portrait (for taking portraits of three or more people, or framing images with a large background size)

Night landscape

Close-up

Backlighting (for taking images of subjects other than people)

Backlighting (for taking portrait images)

Other scenes

The focus area depends on the composition of the image. When the camera detects a human face, it focuses on that face (

A64).

C

Selecting Scene Modes

When using digital zoom, d is selected as the shooting scene mode.

In some shooting conditions, the camera may not select the appropriate scene mode that you intended. If this happens, switch to A (auto) mode or select the scene mode that you want to use when taking images (

A22).

Functions Available in x (Scene Auto Selector) Mode

Flash mode (A49)

Self-timer (A51)

Exposure compensation (A54)

33

34

Scene Mode (Shooting Suited to Scenes)

When a scene is selected, camera settings are automatically optimized for the selected scene.

Enter shooting mode

M A (shooting mode) button M b (second icon from the top*)

M K M HIJK M select a scene M k button

* The icon of the last scene selected is displayed.

b Portrait

(default setting) f Party/indoor

(

A35)

2 c Landscape

Z Beach

2

1 i Dusk/dawn

1, 3 j Night landscape

1

(

A36)

l Museum

2

(

A37)

m Fireworks show

1, 3

(

A37)

d Sports z Snow

2

2

(

A35)

k Close-up (A36)

n Black and white copy

2

(

A37)

e Night portrait

(

A35)

h Sunset

2, 3

u Food (A36)

o Backlighting

2

(

A37)

1

2

3 p Easy panorama

(

A38)

O Pet portrait

(

A39)

The camera focuses at infinity.

The camera focuses on the area in the center of the frame.

Use of a tripod is recommended, because the shutter speed is slow. Set Vibration reduction to

Off in the setup menu (

A78) when using a tripod to stabilize the camera during shooting.

To View a Description (Help Display) of Each Scene

Select a scene and move the zoom control (

A1) toward

g (j) to view a description of that scene. To return to the original screen, move the zoom control toward g (j) again.

Easy panorama

Tips and Notes

d Sports

While the shutter-release button is held all the way down, the camera shoots up to about

6 images continuously at a rate of about 2 fps (when image mode is set to P).

The frame rate for continuous shooting may vary depending upon the current image mode setting, the memory card used, or shooting condition.

Focus, exposure, and hue are fixed at the values determined with the first image in each series.

e Night portrait

From the screen displayed after e Night portrait is selected, select Hand-held or Tripod.

• Hand-held (default setting):

- When the e icon at the top left of the monitor glows green, press the shutter-release button all the way to capture a series of images which are combined into a single image and saved.

- Once the shutter-release button is pressed all the way, hold the camera still until a still image is displayed. After taking an image, do not turn the camera off before the monitor switches to the shooting screen.

- If the subject moves while the camera is shooting continuously, the image may be distorted, overlapped, or blurred.

• Tripod:

- One image is captured at a slow shutter speed when the shutter-release button is pressed all the way.

- Vibration reduction is disabled even when Vibration reduction (

A78) in the setup menu is

set to On.

f Party/indoor

To avoid the effects of camera shake, hold the camera steady. Set Vibration reduction to Off in

the setup menu (

A78) when using a tripod to stabilize the camera during shooting.

35

36

j Night landscape

From the screen displayed after j Night landscape is selected, select Hand-held or Tripod.

• Hand-held (default setting):

- When the j icon at the top left of the monitor glows green, press the shutter-release button all the way to capture a series of images which are combined into a single image and saved.

- Once the shutter-release button is pressed all the way, hold the camera still until a still image is displayed. After taking an image, do not turn the camera off before the monitor switches to the shooting screen.

- The angle of view (i.e., the area visible in the frame) seen in the saved image is narrower than that seen in the monitor at the time of shooting.

• Tripod:

- One image is captured at a slow shutter speed when the shutter-release button is pressed all the way.

- Vibration reduction is disabled even when Vibration reduction (

A78) in the setup menu is

set to On.

k Close-up

Macro mode (A53) is enabled and the camera automatically zooms to the closest position at

which it can focus.

You can move the focus area. Press the k button, use the multi selector HIJK to move the focus area, and press the k button to apply the setting.

u Food

Macro mode (A53) is enabled and the camera automatically zooms to the closest position at

which it can focus.

You can adjust hue by using the multi selector HI. The hue setting is saved in the camera’s memory even after the camera is turned off.

You can move the focus area. Press the k button, use the multi selector

HIJK to move the focus area, and press the k button to apply the setting.

l Museum

The camera captures a series of up to ten images while the shutter-release button is held all the way down, and the sharpest image in the series is automatically selected and saved (BSS (Best

Shot Selector)).

The flash does not fire.

m Fireworks show

The shutter speed is fixed at about four seconds.

The zoom is restricted to four fixed positions.

n Black and white copy

Use together with macro mode (A53) when shooting subjects that are close to the camera.

o Backlighting

From the screen displayed after o Backlighting is selected, select On or Off to enable or disable the high dynamic range (HDR) function based on the type of image you want to take.

• Off (default setting): The flash fires to prevent the subject from being hidden in shadow.

- When the shutter-release button is pressed all the way down, one image is captured.

• On: Use when taking images with very bright and dark areas in the same frame.

- When the shutter-release button is pressed all the way, the camera shoots images continuously at high speed, and saves the following two images.

- A non-HDR composite image

- An HDR composite image in which the loss of details in highlights or shadows is minimized

- If there is only enough memory to save one image, an image processed by D-Lighting (

A70) at

the time of shooting, in which dark areas of the image are corrected, is the only image saved.

- Once the shutter-release button is pressed all the way, hold the camera still until a still image is displayed. After taking an image, do not turn the camera off before the monitor switches to the shooting screen.

- The angle of view (i.e., the area visible in the frame) seen in the saved image is narrower than that seen in the monitor at the time of shooting.

37

38

p Easy panorama

From the screen displayed after p Easy panorama is selected, select the shooting range from

Normal (180°) or Wide (360°).

The zoom position is fixed at wide-angle.

Press the shutter-release button all the way down, remove your finger from the button, and then slowly pan the camera horizontally. Shooting ends when the camera captures the specified shooting range.

Focus and exposure are locked when shooting starts.

If you press the k button when a captured image is displayed in full-frame playback mode, the image scrolls automatically.

The images cannot be edited on this camera.

See “Using Easy Panorama (Shooting and Playback)” (

E2) for more information.

B

Notes About Printing Panorama Images

The entire image may not be able to be printed depending on the printer’s settings. Additionally, printing may not be possible depending on the printer.

O Pet portrait

When you point the camera at a dog or cat, the camera detects the pet’s face and focuses on it. By default, the shutter is automatically released when focus is acquired (pet portrait auto release).

From the screen displayed after O Pet portrait is selected, select Single or Continuous.

- Single: Whenever the detected face is in focus, the camera captures one image.

- Continuous: Whenever the detected face is in focus, the camera captures three images continuously.

B

Pet Portrait Auto Release

Press the multi selector J (n) to change the Pet portrait auto release settings.

- Y: The camera detects a dog or cat face and automatically releases the shutter when the detected face is in focus.

- OFF: The camera does not release the shutter automatically, even if a dog or cat face is detected.

Press the shutter-release button. The camera also detects human faces when OFF is selected.

• Pet portrait auto release is set to OFF after five bursts have been taken.

Shooting is also possible by pressing the shutter-release button, regardless of the Pet portrait

auto release setting. When Continuous is selected, you can take images continuously while holding down the shutter-release button all the way.

B

Focus Area

When the camera detects a face, the face is displayed inside a yellow border. When the camera acquires focus on a face displayed inside a double border (focus area), the double border turns green. If no faces are detected, the camera focuses on the subject in the center of the frame.

In some shooting conditions, the pet face may not be detected and other subjects may be displayed inside a border.

39

Special Effects Mode (Applying Effects When Shooting)

Effects can be applied to images during shooting.

Enter shooting mode

M A (shooting mode) button M D (third icon from the top*) M

K M HIJK M select an effect M k button

* The icon of the last effect selected is displayed.

40

Category

D Soft*

(default setting)

Description

Softens the image by adding a slight blur to the entire image.

E Nostalgic sepia*

Adds a sepia tone and reduces the contrast to simulate the qualities of an old photograph.

F High-contrast monochrome

G High key

H Low key

I Selective color l Pop k Super vivid

Changes the image to black and white and gives it sharp contrast.

Gives the entire image a bright tone.

Gives the entire image a dark tone.

Creates a black and white image in which only the specified color remains.

Increases the color saturation of the entire image to create a bright look.

Increases the color saturation of the entire image and sharpens the contrast.

Gives the image a painting-like appearance.

h Painting m Toy camera effect

1 n Toy camera effect 2 o Cross process b Mirror*

Gives the entire image a yellowish hue and darkens the image periphery.

Decreases the color saturation of the entire image and darkens the image periphery.

Gives the image a mysterious appearance based on a specific color.

Creates a bilaterally symmetric image whose right half is an inverted mirror image of the left half.

* Some effects are not available when using certain Movie options (

A75) settings.

The camera focuses on the area in the center of the frame.

When Selective color or Cross process is selected, use the multi selector

HI to select the desired color from the slider.

To change settings for any of the following functions, press the k button to cancel color selection.

- Flash mode (

A49)

- Self-timer (

A51)

- Macro mode (

A53)

- Exposure compensation (

A54)

To return to the color selection screen, press the k button again.

Save

Slider

41

42

Smart Portrait Mode (Capturing Images of Smiling

Faces)

When the camera detects a smiling face, you can take an image automatically without

pressing the shutter-release button (smile timer (

A59)). You can use the skin softening

option to smooth the skin tones of human faces.

Enter shooting mode

M A (shooting mode) button M F Smart portrait mode M k button

1

Frame the picture.

Point the camera at a human face.

2

Without pressing the shutter-release button, wait for the subject to smile.

If the camera detects that the face framed by the double border is smiling, the shutter is automatically released.

Whenever the camera detects a smiling face, it automatically releases the shutter.

3

End automatic shooting.

Perform one of the operations listed below to end shooting.

- Set Smile timer to Off.

- Press the A button and select a different shooting mode.

B

Notes About Smart Portrait Mode

Under some shooting conditions, the camera may be unable to detect faces or detect smiles

(

A64). The shutter-release button can also be used for shooting.

C

When the Self-timer Lamp Flashes

When using smile timer, the self-timer lamp flashes when the camera detects a face and flashes quickly immediately after the shutter is released.

Functions Available in Smart Portrait Mode

Flash mode (A49)

Self-timer (A51)

Exposure compensation (A54)

Smart portrait menu (A57)

43

44

A (Auto) Mode

Used for general shooting. Settings can be adjusted to suit the shooting conditions and the type of shot you want to capture.

Enter shooting mode

M A (shooting mode) button M A (auto) mode M k button

You can change how the camera selects the area of the frame to focus on by changing the

AF area mode setting (

A58).

The default setting is Target finding AF (

A63).

Functions Available in A (Auto) Mode

Flash mode (A49)

Self-timer (A51)

Macro mode (A53)

Exposure compensation (A54)

Shooting menu (A57)

Using Quick Effects

When in A (auto) mode, you can apply effects to images immediately after releasing the shutter.

The edited image is saved as a separate file with a different name.

1

Press the k button when the image is displayed after it is taken in A (auto) mode.

When you press the d button or when no operations are performed for about five seconds, the monitor display returns to the shooting screen.

To not display the screen shown on the right, set Quick

effects to Off in the shooting menu (

A57).

Quick effects

Cancel Choose effect

2

Use the multi selector

HIJK to select the desired effect and press the k button.

Quick effects

Move the zoom control (A1) toward g (i) to switch to

full-frame playback or f (h) to switch to thumbnail playback.

To exit without saving the edited image, press the d button. When a confirmation screen is displayed, select

Yes and press the k button.

High key Toy camera

See “Quick Effects: Changing Hue or Mood” (E15) for information about the effect types.

3

Select Yes and press the k button.

45

46

Using the Self-timer with Gesture Control

When you position the monitor facing forward in the same direction as the camera lens and move your hand toward an icon displayed on the monitor, the shutter is released after a countdown. You can also move your hand toward the other icons to control the zoom position or record a movie. This function is useful when taking self-portrait images or shooting from a short distance.

This function is available in Portrait and Night portrait scene modes, smart portrait mode, and A (auto) mode.

1

Open the monitor and face it forward in the

same direction as the camera lens (

A3).

A message is displayed for about five seconds, and then n (palm detection) is displayed in the center of the frame.

2

Hold up your hand and align it with n in the center of the frame.

When the camera detects your palm, n changes to o and the icons listed below are displayed in the four corners of the frame.

- p: The camera captures a still image.

- q: The camera starts recording a movie.

- r: The camera zooms out (wide-angle).

- s: The camera zooms in (telephoto).

3

Frame the picture.

To adjust the zoom position, move your hand toward r (wide-angle) or s (telephoto). The zoom position changes one step at a time.

If the camera is unable to detect your palm, try step 2 again.

4

Take the picture.

When you move your hand toward p (to take a still image) or q (to record a movie), the camera releases the shutter after a countdown (about three seconds).

To end movie recording, press the b (e movie-record) button on the camera body.

See “

C Cutting Unwanted Scenes from Recorded Movies”

(

A77).

When shooting ends, the screen shown in step 2 is displayed again.

3

B

Notes About Gesture Control

The camera may not detect your palm or hand movement in some shooting conditions.

When moving your hand, hold up your palm vertically facing the camera, and maintain the same hand shape as you move it.

Some functions are not available when using the gesture control function (E76).

47

48

Functions That Can Be Set Using the Multi Selector

The functions that are available vary with the shooting mode, as shown below.

1

2 4

3

1

X Flash mode (A49)

2

n Self-timer (A51)

3

p Macro (A53)

4 o

Exposure compensation

(

A54)

x

(scene auto selector) w

*

w

– w

* Availability depends on the setting.

Scene

*

Special effects w w w w

Smart portrait w

*

w

*

– w

A (auto) w w w w

Using the Flash

You can select the flash mode to match the shooting conditions.

1

Press the multi selector

H (m).

2

Select the desired flash mode (

A50) and

press the k button.

If a setting is not applied by pressing the k button within a few seconds, the selection will be canceled.

Auto

B

The Flash Lamp

The status of the flash can be confirmed by pressing the shutterrelease button halfway.

- On: The flash fires when you press the shutter-release button all the way down.

- Flashing: The flash is charging. The camera cannot shoot images.

- Off: The flash does not fire when an image is taken.

If the battery level is low, the monitor turns off while the flash is charging.

49

Available Flash Modes

U

Auto

The flash fires when necessary, such as in dim lighting.

The flash mode icon on the shooting screen is displayed only immediately after the setting is made.

V

Auto with red-eye reduction

Reduce “red-eye” in portraits caused by the flash.

W

Off

The flash does not fire.

We recommend using a tripod to stabilize the camera when shooting in dark surroundings.

Fill flash

X

The flash fires whenever an image is taken. Use to “fill-in” (illuminate) shadows and backlit subjects.

Y

Slow sync

Suited to evening and night portraits that include background scenery.

The flash fires when necessary to illuminate the main subject; slow shutter speeds are used to capture background at night or under dim lighting.

50

C

The Flash Mode Setting

The setting may not be available with some shooting modes.

The setting applied in A (auto) mode is saved in the camera’s memory even after the camera is turned off.

C

Red-eye Reduction

If the camera detects red eye while saving an image, the affected area is processed to reduce red-eye before the image is saved.

Note the following when shooting:

More time than usual is required to save images.

Red-eye reduction may not produce the desired results in all situations.

In some rare cases, red-eye reduction may be applied unnecessarily to other areas of the image. In these cases, select another flash mode and take the image again.

Using the Self-timer

The camera is equipped with a self-timer that releases the shutter about ten seconds or two seconds after you press the shutter-release button.

Set Vibration reduction to Off in the setup menu (

A78) when using a tripod to stabilize

the camera during shooting.

1

Press the multi selector

J (n).

2

Select n 10s or n 2s, and press the k button.

Self-timer

n 10s (ten seconds): Use on important occasions, such as weddings.

n 2s (two seconds): Use to prevent camera shake.

If a setting is not applied by pressing the k button within a few seconds, the selection will be canceled.

When the shooting mode is Pet portrait scene mode,

Y (pet portrait auto release) is displayed ( A39). The self-timer cannot be used.

3

Frame the picture and press the shutter-release button halfway.

Focus and exposure are set.

51

52

4

Press the shutter-release button the rest of the way down.

Countdown starts. The self-timer lamp flashes and then glows steadily about one second before the shutter is released.

When the shutter is released, the self-timer is set to OFF.

To stop the countdown, press the shutterrelease button again.

99

Using Macro Mode

Use macro mode when taking close-up images.

1

Press the multi selector

I (p).

2

Select ON and press the k button.

If a setting is not applied by pressing the k button within a few seconds, the selection will be canceled.

Macro mode

3

Move the zoom control to set the zoom ratio to a position where F and the zoom indicator glow green.

When the zoom ratio is set to a position where the zoom indicator glows green, the camera can focus on subjects as close as approximately 10 cm (4 in.) from the lens.

When the zoom is at the position where G is displayed, the camera can focus on subjects as close as approximately 2 cm (0.8 in.) from the lens.

B

Notes About Using the Flash

The flash may be unable to light the entire subject at distances of less than 50 cm (1 ft 8 in.).

C

The Macro Mode Setting

The setting may not be available with some shooting modes.

The setting applied in A (auto) mode is saved in the camera’s memory even after the camera is turned off.

53

54

Adjusting Brightness (Exposure Compensation)

You can adjust overall image brightness.

1

Press the multi selector

K (o).

2

Select a compensation value and press the k button.

To brighten the image, set a positive (+) value.

To darken the image, set a negative (–) value.

The compensation value is applied, even without pressing the k button.

Exposure compensation

C

Exposure Compensation Value

The setting applied in A (auto) mode is saved in the camera’s memory even after the camera is turned off.

Default Settings

Default settings for each shooting mode are described below.

Flash

(

A49)

x (scene auto selector)

U

Scene b (portrait) c (landscape) d (sports) e (night portrait)

V

W

3

W

3

V

4 f (party/indoor)

Z (beach) z (snow) h (sunset)

V 5

U

U

W

3

W 3 i (dusk/dawn) j (night landscape) k (close-up) u (food)

W

3

W

W

3

W 3 l (museum) m (fireworks show)

W

3 n (black and white copy)

W

1

Off

Off

Off

Off

Off

Off

3

Off

Off

Off

Off

3

Off

Off

Off

Off

Off

Off

Self-timer

(

A51)

Off

2

Off

3

Off

3

Off

3

Off

3

Off

3

Off

3

Off

3

Off

3

Off

3

Off

3

On

3

On

3

Off

Off

3

Off

Macro

(

A53)

0.0

0.0

0.0

0.0

0.0

3

0.0

0.0

0.0

0.0

0.0

0.0

0.0

0.0

0.0

0.0

Exposure compensation

(

A54)

0.0

55

56

(

Flash

A49)

Self-timer

Off

Off

3

Y

7

Off

Off

9

(

A51)

Off

3

Off

3

Off

Off

Off

3

(

Macro

A53)

0.0

0.0

0.0

0.0

Exposure compensation

(

A54)

0.0

o (backlighting) X/W 6 p (easy panorama) W

3

O (pet portrait)

D (special effects)

W

3

W

F (smart portrait)

A (auto)

U

8

U

Off Off 0.0

6

7

8

2

3

4

5

1

9

The camera automatically selects the flash mode appropriate for the scene it has selected. W (off) can be selected manually.

Cannot be changed. The camera enters macro mode when i is selected.

The setting cannot be changed.

The setting cannot be changed. The flash mode setting is fixed at fill flash with red-eye reduction.

Slow sync with red-eye reduction flash mode may be used.

Flash is fixed at X (fill flash) when HDR is set to Off, and is fixed at W (off) when HDR is set to On.

Self-timer cannot be used. Pet portrait auto release can be turned on or off (

A39).

Cannot be used when Blink proof is set to On or when Smile timer is set to On (continuous) or On (BSS).

Can be set when Smile timer is set to Off.

Functions That Can Be Set with the

d Button (Shooting Menu)

The settings listed below can be changed by pressing the d button during shooting

(

A4).

Image mode

White balance

Continuous

ISO sensitivity

Color options

AF area mode

Autofocus mode

The settings that can be changed vary depending on the shooting mode, as shown below.

Image mode

1

White balance

Continuous

ISO sensitivity

Color options

AF area mode

Autofocus mode

Quick effects

Skin softening

Smile timer

Blink proof

Scene auto selector w

Scene w

2

Special effects w

Smart portrait w

– w w w

Auto mode w w w w w w w w

– –

1

2

The setting is also applied to other shooting modes.

Additional settings are available for some scene modes. See “Tips and Notes” (

A35) for more

information.

57

58

Options Available in the Shooting Menu

Option

Image mode

White balance

Continuous

ISO sensitivity

Color options

AF area mode

Autofocus mode

Quick effects

Description

Allows you to set the combination of image size and image quality used when saving images.

Default setting: P 4608×3456

Allows you to adjust white balance to suit the weather conditions or light source in order to make the colors in images match what you see with your eyes.

Default setting: Auto

Allows you to select single or continuous shooting.

Default setting: Single

Allows you to control the camera’s sensitivity to light.

Default setting: Auto

When Auto is selected, E is displayed in the monitor while shooting if ISO sensitivity increases.

Allows you to change the color tones of images.

Default setting: Standard color

Allows you to determine how the camera selects the focus area that is used for autofocus.

Default setting: Target finding AF (A63)

Allows you to select either Single AF, which focuses only when the shutter-release button is pressed halfway, or Full-time AF, which continues focusing even when the shutter-release button is not pressed halfway.

Default setting: Single AF

Allows you to enable or disable the quick effects function (

A45).

Default setting: On

A

E34

E36

E39

E42

E43

E44

E48

E48

Option

Skin softening

Smile timer

Blink proof

Description

Allows you to select the skin softening level for human faces.

Default setting: Normal

Allows you to select whether or not the camera automatically releases the shutter when it detects a human smiling face.

Default setting: On (BSS)

The camera automatically releases the shutter twice with every shot and saves one image in which the subject’s eyes are open.

Default setting: Off

A

E49

E50

E51

59

60

Functions That Cannot Be Used Simultaneously

Some functions cannot be used with other menu options.

Restricted function

Flash mode

Self-timer

Macro mode

Image mode

White balance

Option

Continuous (

A58)

Blink proof (

A59)

Smile timer (

A59)

Smile timer (

A59)

AF area mode (

A58)

AF area mode (

A58)

Continuous (

A58)

Color options (

A58)

Description

When a setting other than Single is selected, the flash cannot be used.

When Blink proof is set to On, the flash cannot be used.

When On (continuous) or On (BSS) is selected, the flash cannot be used.

When Smile timer is selected, the self-timer cannot be used.

When Subject tracking is selected, the selftimer cannot be used.

When Subject tracking is selected, macro mode cannot be used.

Image mode is set as follows depending on the continuous shooting setting:

• Continuous H: 120 fps: O (image size:

640 × 480 pixels)

• Continuous H: 60 fps: M (image size:

1280 × 960 pixels)

• Multi-shot 16: L (image size: 2560 × 1920 pixels)

When Black-and-white, Sepia, or

Cyanotype is selected, the White balance setting is fixed at Auto.

Restricted function

Continuous

ISO sensitivity

AF area mode

Quick effects

Smile timer

Blink proof

Monitor settings

Print date

Option

Self-timer (

A51)

Continuous (

White balance (

A58)

Continuous (

Blink proof (

A59)

Smile timer (

A59)

Quick effects (

A58)

Continuous (

A58)

A58)

A58)

Description

If the self-timer is used when Pre-shooting

cache is selected, the setting changes to

Single.

When Pre-shooting cache, Continuous H:

120 fps, Continuous H: 60 fps, or Multi-

shot 16 is selected, the ISO sensitivity setting is automatically specified according to the brightness.

When a setting other than Auto is selected for

White balance in Target finding AF mode, the camera does not detect the main subject.

The quick effects function cannot be used for images with continuous shooting.

When Blink proof is set to On, Smile timer is fixed at On (single) if On (continuous) or On

(BSS) is set.

When Smile timer is set to On (continuous) or On (BSS), Blink proof is fixed at Off.

When Quick effects is set to On, Image

review is fixed at On.

When Pre-shooting cache, Continuous H:

120 fps, or Continuous H: 60 fps is selected, date and time cannot be imprinted on images.

61

62

Restricted function Option

Continuous (

A58)

Motion detection

Blink warning

Digital zoom

Shutter sound

ISO sensitivity (

A58)

AF area mode (

A58)

Smile timer (

A59)

Continuous (

A58)

Continuous (

A58)

AF area mode (

A58)

Continuous (

A58)

Description

When a setting other than Single is selected,

Motion detection is disabled.

When the ISO sensitivity is set to any setting other than Auto, Motion detection is disabled.

When Subject tracking is selected, Motion

detection is disabled.

When On (continuous) or On (BSS) is selected, Motion detection is disabled.

When a setting other than Single is selected,

Blink warning is disabled.

When Multi-shot 16 is selected, digital zoom cannot be used.

When Subject tracking is selected, digital zoom cannot be used.

When a setting other than Single is selected, the shutter sound is disabled.

B

Notes About Digital Zoom

Depending on the shooting mode or the current settings, digital zoom may not be available

(

E79).

When digital zoom is in effect, the camera focuses in the center of the frame.

Focusing

The focus area varies depending on the shooting mode.

Using Target Finding AF

When AF area mode (

A58) in A (auto) mode is set to Target finding AF, the camera

focuses in the manner described below when you press the shutter-release button halfway.

The camera detects the main subject and focuses on it.

When the subject is in focus, the focus area glows green. If a human face is detected, the camera automatically sets focus priority on it.

If no main subject is detected, the camera automatically selects one or more of the nine focus areas containing the subject closest to the camera. When the subject is in focus, the focus areas that are in focus glow green.

Focus areas

Focus areas

B

Notes About Target Finding AF

Depending on shooting conditions, the subject that the camera determines to be the main subject may vary.

The main subject may not be detected when using certain White balance settings.

The camera may not detect the main subject appropriately in the following situations:

- When the subject is very dark or bright

- When the main subject lacks clearly defined colors

- When the shot is framed so that the main subject is at the edge of the monitor

- When the main subject is composed of a repeating pattern

63

64

Using Face Detection

In the following shooting modes, the camera uses face detection to automatically focus on human faces.

x (scene auto selector) mode (A32)

• Portrait or Night portrait scene mode (A34)

Smart portrait mode (A42)

When AF area mode (A58) in A (auto) mode (A44) is

set to Face priority.

If the camera detects more than one face, a double border is displayed around the face that the camera focuses on, and single borders are displayed around the other faces.

If the shutter button is pressed halfway when no faces are detected:

In x (scene auto selector) mode, the focus area changes depending on the scene.

In Portrait and Night portrait scene modes or in smart portrait mode, the camera focuses on the area in the center of the frame.

In A (auto) mode, the camera selects the focus area containing the subject closest to the camera.

B

Notes About Face Detection

The camera’s ability to detect faces depends on a variety of factors, including the direction in which the faces are looking.

The camera may be unable to detect faces in the following situations:

- When faces are partially hidden by sunglasses or otherwise obstructed

- When faces take up too much or too little of the frame

Using Skin Softening

When the shutter is released while using one of the shooting modes listed below, the camera detects human faces and processes the image to soften facial skin tones (up to three faces).

Smart portrait mode (A42)

- The skin softening level can be adjusted.

x (scene auto selector) mode (A32)

• Portrait or Night portrait scene mode (A34)

Editing functions such as Skin softening can be applied to saved images by using Glamour

retouch (

A70) even after shooting.

B

Notes About Skin Softening

It may take more time than usual to save images after shooting.

Under some shooting conditions, the desired skin softening results may not be achieved, and skin softening may be applied to areas of the image where there are no faces.

65

66

Subjects Not Suitable for Autofocus

The camera may not focus as expected in the following situations. In some rare cases, the subject may not be in focus despite the fact that the focus area or the focus indicator glows green:

Subject is very dark

Objects of sharply differing brightness are included in the scene (e.g. the sun behind the subject makes that subject appear very dark)

No contrast between the subject and surroundings (e.g. a portrait subject wearing a white shirt is standing in front of a white wall)

Several objects are at different distances from the camera (e.g. the subject is inside a cage)

Subjects with repeating patterns (window blinds, buildings with multiple rows of similarly shaped windows, etc.)

Subject is moving rapidly

In the situations noted above, try pressing the shutter-release button halfway to refocus several times, or focus on another subject positioned at the same distance from the camera as

the actual desired subject, and use focus lock (

A67).

Focus Lock

Focus lock shooting is recommended when the camera does not activate the focus area that contains the desired subject.

1

Set AF area mode to Center in A (auto) mode (

A57).

2

Position the subject in the center of the frame and press the shutterrelease button halfway.

Confirm that the focus area glows green.

Focus and exposure are locked.

3

Without lifting your finger, recompose the picture.

Make sure to maintain the same distance between the camera and the subject.

4

Press the shutter-release button the rest of the way down to take the picture.

67

68

Playback Features

Playback Zoom

Moving the zoom control toward

g (i) in full-frame playback mode (A28) zooms in on the

image.

Displayed area guide g

( i)

0004. JPG

15 / 11 / 2013 15:30

Full-frame Playback f

( h)

Image is zoomed in.

You can change the zoom ratio by moving the zoom control toward f (h) or g (i).

To view a different area of the image, press the multi selector HIJK.

If you are viewing an image that was captured using face detection or pet detection, the camera zooms in on the face detected at the time of shooting (except when viewing an image captured in a series). To zoom in on an area of the image where there are no faces, adjust the magnification rate and then press

HIJK.

When a zoomed image is displayed, press the k button to return to full-frame playback mode.

C

Cropping Images

When a zoomed image is displayed, you can press the d button to crop the image to include only the visible portion and save it as a separate file (

E21).

Thumbnail Playback, Calendar Display

Moving the zoom control toward

f (h) in full-frame playback mode (A28) displays

images as thumbnails.

f

( h) f

( h)

0004. JPG

15 / 11 / 2013 15:30

Full-frame Playback g

( i)

Thumbnail Playback g

( i)

2013 11

Su M Tu W Th F Sa

3 4 5

1 2

6 7 8 9

10 11 12

17 18 19

24 25 26

13 14

20 21 22 23

27

15 16

28 29 30

Calendar Display

You can change the number of thumbnails displayed by moving the zoom control toward f (h) or g (i).

While using thumbnail playback mode, press the multi selector HIJK to select an image and then press the k button to display that image in full-frame playback mode.

While using calendar display mode, press HIJK to select a date and then press the k button to display the images captured on that day.

B

Calendar Display

Images captured when the camera’s date is not set are treated as images captured on January 1,

2013.

69

70

Functions That Can Be Set with the

d Button

(Playback Menu)

When viewing images in full-frame playback mode or thumbnail playback mode, you can configure the menu operations listed below by pressing the

d button (A4).

Option

A

Quick retouch*

D-Lighting*

Red-eye correction*

Glamour retouch*

Print order

Slide show

Protect

Rotate image

Small picture*

Voice memo

Description

Allows you to create retouched copies in which contrast and saturation have been enhanced.

Allows you to create copies with enhanced brightness and contrast, brightening dark portions of an image.

Corrects “red-eye” that may occur in images when shooting with a flash.

Detects faces in images and retouches the detected faces glamorously.

Allows you to select which images are printed, and how many copies of each image are printed, prior to printing.

Allows you to view images in an automatic slide show.

Protects selected images from accidental deletion.

Allows you to rotate the displayed image to portrait or landscape orientation.

Creates a small copy of images.

Allows you to use the camera’s microphone to record voice memos and attach them to images.

E16

E16

E17

E18

E52

E56

E57

E59

E20

E60

Copy

Option

Sequence display options

Choose key picture

Favorite pictures

Remove from favorites

Description

Allows you to copy images between the internal memory and a memory card.

Allows you to select whether to display only the key picture for a sequence of images captured continuously or to display the sequence as individual images.

When only the key picture is displayed for a sequence, press the k button to display each image in the sequence. Press the multi selector

H to return to the key picture display.

Allows you to change the key picture for images captured in sequence.

Allows you to add images to an album.

This option is not displayed in favorite pictures mode.

Allows you to remove images from an album.

This option is displayed only in favorite pictures mode.

* Edited images are saved as separate files. Some images may not be edited.

A

E61

E63

E63

E6

E8

71

Recording and Playing Back Movies

Recording Movies

1

Display the shooting screen.

Check the remaining amount of movie recording time.

If Photo info in the Monitor settings (A78) in the setup

menu is set to Movie frame+auto info, the area that will be visible in the movie can be confirmed before movie recording starts.

Movie recording time remaining

2

Press the b (e movie-record) button to start movie recording.

The camera focuses on the subject in the center of the frame.

Press the multi selector K to pause recording, and press K again to resume recording (except when p iFrame 720/

30p (p iFrame 720/25p) or an HS movie option is selected in Movie options). Recording automatically ends if it remains paused for about five minutes.

72

3

Press the b (e movie-record) button again to end recording.

B

Maximum Movie Length

Individual movie files cannot exceed 4 GB in size or 29 minutes in length, even when there is sufficient free space on the memory card for longer recording.

The maximum movie length for a single movie is displayed on the shooting screen.

Recording may end before either limit is reached if camera temperature becomes elevated.

The actual movie length may vary depending on the movie content, subject movement, or type of memory card.

B

Notes About Saving Images and Recording Movies

The indicator showing the number of exposures remaining or the indicator showing the maximum movie length flashes while images are being saved or while a movie is being recorded. Do not open

the battery-chamber/memory card slot cover or remove the battery or memory card while an indicator is flashing. Doing this could result in loss of data, or in damage to the camera or the memory card.

B

Notes About Movie Recording

Memory cards with an SD Speed Class rating of 6 or faster are recommended when recording movies (

F22). Movie recording may stop unexpectedly when memory cards with a lower Speed

Class rating are used.

There may be some degradation in image quality when digital zoom is used.

The sounds of zoom control operation, zoom, autofocus lens drive movement, vibration reduction, and aperture operation when brightness changes may be recorded.

The following phenomena may be seen in the monitor while recording movies. These phenomena are saved in the recorded movies.

- Banding may occur in images under fluorescent, mercury-vapor, or sodium-vapor lighting.

- Subjects that move quickly from one side of the frame to the other, such as a moving train or car, may appear skewed.

- The entire movie image may be skewed when the camera is panned.

- Lighting or other bright areas may leave residual images when the camera is moved.

Depending on the distance to the subject or the amount of zoom applied, subjects with repeating patterns (fabrics, lattice windows, etc.) may have colored stripes (interference patterns, moire, etc.) in them during movie recording and playback. This occurs when the pattern in the subject and the layout of the image sensor interfere with each other; it is not a malfunction.

73

74

B

Camera Temperature

The camera may become warm when shooting movies for an extended period of time or when the camera is used in a hot area.

If the inside of the camera becomes extremely hot when recording movies, the camera will automatically stop recording.

The amount of time remaining until the camera stops recording (B10s) is displayed.

After the camera stops recording, it turns itself off.

Leave the camera off until the inside of the camera has cooled.

B

Notes About Autofocus

Autofocus may not perform as expected (

A66). Should this occur, try the following:

1. Set Autofocus mode in the movie menu to Single AF (default setting) before starting movie recording.

2. Frame another subject—positioned at the same distance from the camera as the intended subject—in the center of the frame, press the b (e movie-record) button to start recording, and then modify the composition.

Functions That Can Be Set with the

d Button (Movie

Menu)

Enter shooting mode

M d button M D menu icon M k button

The settings of the menu options listed below can be configured.

Movie options

Open with HS footage

Autofocus mode

Wind noise reduction

Option

Movie options

Open with HS footage

Autofocus mode

Wind noise reduction

Description

Select the movie type.

Select normal speed to record movies at normal speed, or HS

(high speed) to record movies that play in slow or fast motion.

Default setting: d 1080P/30p (R 1080P/25p)

Set whether to start recording at high speed or normal speed when recording HS movies.

Default setting: On

Select either Single AF, which locks focus when movie recording begins, or Full-time AF, which continues focusing during movie recording.

Default setting: Single AF

Set whether or not to reduce wind noise during movie recording.

Default setting: Off

A

E64

E68

E68

E69

75

76

Playing Back Movies

Press the c button to enter playback mode.

Movies are indicated by the movie options icon (

A75).

Press the k button to play back movies.

To adjust the volume, move the zoom control (A1).

0010. MOV

15 / 11 / 2013 15:30

4s

Movie options

Volume indicator

4s

Functions Available During Playback

Playback controls are displayed at the bottom of the monitor.

The operations listed below can be performed by using the multi selector

JK to select a control and then pressing the k button.

Paused

Function Icon

Rewind

Advance

Description

A

Hold down the k button to rewind the movie.

B

Hold down the k button to advance the movie.

Pause

E

Pause playback. The operations listed below can be performed while paused.

C

Rewind the movie one frame. Hold down the k button for continuous rewinding.

D

Advance the movie one frame. Hold down the k button for continuous advancing.

F

Resume playback.

End

I

Extract the desired portion of a movie and save it as a separate file.

G

Return to full-frame playback mode.

C

Cutting Unwanted Scenes from Recorded Movies

If a movie recorded using the gesture control function contains an unwanted scene of you stopping the recording (

A47), pause the movie during playback and follow the steps below to edit it.

1. Select I in the playback controls, and then press the k button.

2. Select M (choose end point) in the editing controls.

3. Select m (save) and press the k button.

Deleting movies

To delete a movie, select the desired movie in full-frame playback mode (

A28) or thumbnail

playback mode (

A69) and press the l button (A30).

77

78

General Camera Setup

Functions That Can Be Set with the

d Button

(Setup Menu)

Press the d button M z (setup) menu icon M k button

The settings of the menu options listed below can be configured.

Option

Welcome screen

Time zone and date

Monitor settings

Print date

Welcome screen

Time zone and date

Monitor settings

Print date

Gesture control

Vibration reduction

Motion detection

Description

Allows you to select whether or not the welcome screen is displayed when the camera is turned on.

Allows you to set the camera clock.

A

E70

E71

Allows you to adjust photo information display, post-shooting image review, and monitor brightness settings.

E73

Allows you to imprint the shooting date and time on images.

E75

Gesture control

Vibration reduction

Allows you to set whether or not the gesture control function

(

A46) is enabled when you position the monitor facing

forward in the same direction as the camera lens.

Allows you to select the vibration reduction setting used when shooting.

E76

E77

Motion detection

AF assist

Digital zoom

Sound settings

Auto off

Format memory/

Format card

Language

TV settings

Charge by computer

Blink warning

Wi-Fi options

Eye-Fi upload

Reset all

Option

Firmware version

Description

Allows you to set whether or not the camera automatically increases the shutter speed to reduce blurring caused by camera shake if motion is detected when shooting still images.

Allows you to enable or disable the AF-assist illuminator.

Allows you to enable and disable digital zoom.

Allows you to adjust sound settings.

Allows you to set the amount of time that passes before the monitor turns off to save power.

Allows you to format the internal memory or the memory card.

Allows you to change the camera’s display language.

Allows you to adjust TV-connection settings.

Allows you to set whether or not the battery in the camera is charged when the camera is connected to a computer.

Allows you to set whether or not closed eyes are detected when taking images of people using face detection.

Allows you to configure the Wi-Fi (wireless LAN) settings to connect the camera and a smart device.

See “Using the Wi-Fi (Wireless LAN) Function” (

A80) for more

information.

Allows you to set whether or not to enable the function for sending images to a computer using a commercially available

Eye-Fi card.

Allows you to reset the camera’s settings to their default values.

View the current camera firmware version.

A

E78

E79

E79

E80

E80

E81

E82

E82

E83

E84

E85

E87

E88

E88

79

80

Using the Wi-Fi (Wireless LAN) Function

Functions That Can Be Performed Using Wi-Fi

You can perform the following functions if you install the dedicated software “Wireless Mobile

Utility” on your smart device that runs on Android OS or iOS, and connect it to the camera.

Take Photos

You can take still images using the two methods described below.

Release the shutter on the camera and save the captured images to a smart device.

Use a smart device to remotely* release the camera shutter and save images to the smart device.

* Operations cannot be performed on the camera during remote control operation.

View Photos

You can copy the pictures saved in the camera’s memory card to your smart device.

Installing the Software on the Smart Device

1

Use your smart device to connect to Google Play Store, App Store or other online apps marketplace and search for “Wireless Mobile Utility.”

Check the user’s manual provided with your smart device for further details.

2

Check the description and other information and install the software.

For more information about how to operate the software, download the user’s manual from the website below.

- Android OS: http://nikonimglib.com/ManDL/WMAU/

- iOS: http://nikonimglib.com/ManDL/WMAU-ios/

Connecting the Smart Device to the Camera

Press the d button M z menu icon M Wi-Fi options M k button

1

Use the multi selector

HI to select the Wi-Fi

network and press the k button.

2

Select On and press the k button.

Wi-Fi options

Wi-Fi network

SSID

Auth./encryp.

Password

Channel

Current settings

Restore factory defaults

Wi-Fi network

On

Off

SSID and the password are displayed.

If no connection confirmation is received from the smart device within 3 minutes, the setting returns to Off.

Wi-Fi network

SSID:

XXXXXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXXX

Password:

XXXXXXXXXXXXXXXXXX

81

3

Set the Wi-Fi setting on the smart device to On.

Check the user’s manual provided with your smart device for further details.

After the network name (SSID) that can be used for the smart device is displayed, select the

SSID displayed on the camera.

When the message for entering a password is displayed, enter the password that is displayed on the camera.

When the camera is successfully connected to a Wi-Fi network, the shooting screen is displayed with the Wi-Fi icon (

A7).

4

Start the dedicated software installed on the smart device.

The screen for selecting “Take photos” or “View photos” is displayed.

When the message “Cannot connect to camera.” is displayed, retry the Wi-Fi network setting.

To Terminate the Wi-Fi Connection

Turn off the camera.

Set the Wi-Fi setting on the smart device to Off.

B

Notes About Wi-Fi Connection

Set the Wi-Fi network to Off in a place where the use of radio waves is prohibited.

When a memory card is not inserted in the camera, the Wi-Fi function cannot be used. When

Eye-Fi card (

E87) is inserted in the camera, the Wi-Fi function cannot be used.

When Wi-Fi is connected, Auto off is disabled.

When the Wi-Fi network is set to On, the battery drains faster than normal.

The Wi-Fi network cannot be selected when the battery level indicator in the monitor indicates

B. In addition, if the battery level indicator indicates B while a Wi-Fi connection is established, the connection is terminated.

82

C

Notes About Security Settings

If the camera is installed with the Wi-Fi function without proper security settings (encryption and password), unauthorized third parties may access the network and cause harm. We strongly recommend performing the required security settings before using the Wi-Fi function.

Use Wi-Fi options of the setup menu (

A79) to perform the security settings.

Connecting the Camera to a TV,

Computer, or Printer

Connection Methods

You can enhance your enjoyment of images and movies by connecting the camera to a TV, computer, or printer.

Open the connector cover.

USB/audio/video output connector

HDMI micro connector (Type D)

Insert the plug straight.

Before connecting the camera to an external device, make sure the remaining battery level is sufficient and turn the camera off. Before disconnecting, make sure to turn the camera off.

If the AC Adapter EH-62G (available separately) is used, this camera can be powered from an electrical outlet. Do not use any other make or model of AC adapter as it may cause the camera to heat up or malfunction.

For information about the connection methods and subsequent operations, refer to the documentation included with the device in addition to this document.

83

84

Viewing images on a TV

E22

Images and movies captured with the camera can be viewed on a TV.

Connection method: Connect the video and audio plugs of an optional audio video cable to the TV’s input jacks. Alternatively, connect a commercially available HDMI cable to the TV’s HDMI input jack.

Viewing and organizing images on a computer

A85

You can transfer images to a computer to perform simple retouching and manage image data.

Connection method: Connect the camera to the computer’s USB port with the USB cable.

Before connecting to a computer, install ViewNX 2 on the computer

(

A85). For information about using the ViewNX 2 CD-ROM and

transferring images to a computer, see page

A85.

If any USB devices that draw the power from the computer are connected, disconnect them from the computer before you connect the camera to it.

Connecting the camera and other USB-powered devices to the same computer simultaneously may cause a camera malfunction or excessive power supply from the computer, which could damage the camera or memory card.

Printing images without using a computer

E25

If you connect the camera to a PictBridge-compatible printer, you can print images without using a computer.

Connection method: Connect the camera directly to the printer’s USB port with the USB cable.

Using ViewNX 2

ViewNX 2 is an all-in-one software package which enables you to transfer, view, edit and share images. Install ViewNX 2 using the included ViewNX 2 CD-ROM.

Your Imaging Toolbox

ViewNX 2™

Installing ViewNX 2

An Internet connection is required.

Compatible Operating Systems

Windows

Windows 8, Windows 7, Windows Vista, Windows XP

Macintosh

Mac OS X10.6, 10.7, 10.8

Refer to the Nikon website for details on system requirements, including the latest information on operating system compatibility.

85

1

Start the computer and insert the ViewNX 2 CD-ROM into the CD-ROM drive.

Windows: If instructions for operating the CD-ROM are displayed in the window, follow the instructions to proceed to the installation window.

Mac OS: When the ViewNX 2 window is displayed, double-click the Welcome icon.

2

Select a language in the language selection dialog to open the installation window.

If the desired language is not available, click Region Selection to choose a different region and then choose the desired language (the Region Selection button is not available in the

European release).

Click Next to display the installation window.

86

3

Start the installer.

We recommend clicking Installation Guide in the installation window to check the installation help information and system requirements before installing ViewNX 2.

Click Typical Installation (Recommended) in the installation window.

4

Download the software.

When the Software Download screen is displayed, click I agree - Begin download.

Follow the on-screen instructions to install the software.

5

Exit the installer when the installation completion screen is displayed.

Windows: Click Yes.

Mac OS: Click OK.

The following software is installed:

ViewNX 2 (consisting of the three modules below)

- Nikon Transfer 2: For transferring images to the computer

- ViewNX 2: For viewing, editing, and printing transferred images

- Nikon Movie Editor: For basic editing of transferred movies

Panorama Maker (for creating a single panorama image of a landscape, etc. from a series of images that each capture a separate portion of the subject)

6

Remove the ViewNX 2 CD-ROM from the CD-ROM drive.

87

88

Transferring Images to the Computer

1

Choose how images will be copied to the computer.

Choose one of the following methods:

• Direct USB connection: Turn the camera off and ensure that the memory card is inserted in the camera. Connect the camera to the computer using the USB cable. The camera automatically turns on.

To transfer images that are saved in the camera’s internal memory, remove the memory card from the camera before connecting it to the computer.

• SD card slot: If your computer is equipped with an SD card slot, the card can be inserted directly in the slot.

• SD card reader: Connect a card reader (available separately from third-party suppliers) to the computer and insert the memory card.

If a message is displayed prompting you to choose a program, select Nikon Transfer 2.

• When using Windows 7

If the dialog shown at right is displayed, follow the steps below to select

Nikon Transfer 2.

1 Under Import pictures and videos, click

Change program. A program selection dialog will be displayed; select Import

File using Nikon Transfer 2 and click

OK.

2 Double-click Import File.

If the memory card contains a large number of images, it may take a while for Nikon Transfer 2 to start. Wait until Nikon Transfer 2 starts.

B

Connecting the USB Cable

The connection may not be recognized if the camera is connected to the computer via a USB hub.

2

Transfer images to the computer.

Confirm that the name of the connected camera or removable disk is displayed as the

“Source” on the “Options” title bar of Nikon Transfer 2 (1).

Click Start Transfer (2).

1

2

At default settings, all the images on the memory card will be copied to the computer.

89

90

3

Terminate the connection.

If the camera is connected to the computer, turn the camera off and disconnect the USB cable. If you are using a card reader or card slot, choose the appropriate option in the computer operating system to eject the removable disk corresponding to the memory card and then remove the card from the card reader or card slot.

Viewing Images

Start ViewNX 2.

Images are displayed in ViewNX 2 when transfer is complete.

Consult online help for more information on using ViewNX 2.

C

Starting ViewNX 2 Manually

• Windows: Double-click the ViewNX 2 shortcut on the desktop.

• Mac OS: Click the ViewNX 2 icon in the Dock.

Technical Notes and Index

Caring for the Product....................................................

F2

The Camera.....................................................................................................................

F2

The Battery......................................................................................................................

F3

Charging AC Adapter ..................................................................................................

F4

Memory Cards................................................................................................................

F5

Cleaning and Storage.....................................................

F6

Cleaning...........................................................................................................................

F6

Storage .............................................................................................................................

F6

Troubleshooting .............................................................

F7

Specifications................................................................

F17

Approved Memory Cards .......................................................................................

F22

Index ..............................................................................

F25

F

1

Caring for the Product

The Camera

To ensure continued enjoyment of this Nikon product, observe the precautions described

below in addition to the warnings in “For Your Safety” (

Aviii-x) when using or storing the

device.

B

Do Not Drop

The product may malfunction if subjected to strong shock or vibration.

B

Handle the Lens and All Moving Parts with Care

Do not apply force to the lens, lens cover, monitor, memory card slot, or battery chamber. These parts are easily damaged. Applying force to the lens cover could result in camera malfunction or damage to the lens. Should the monitor break, care should be taken to avoid injury caused by broken glass and to prevent the liquid crystal from the display touching the skin or entering the eyes or mouth.

B

Keep Dry

The device will be damaged if immersed in water or subjected to high humidity.

B

Avoid Sudden Changes in Temperature

Sudden changes in temperature, such as when entering or leaving a heated building on a cold day, can cause condensation to form inside the device. To prevent condensation, place the device in a carrying case or a plastic bag before exposing it to sudden changes in temperature.

B

Keep away from Strong Magnetic Fields

Do not use or store this device in the vicinity of equipment that generates strong electromagnetic radiation or magnetic fields. Strong static charge or the magnetic fields produced by equipment such as radio transmitters could interfere with the monitor, damage data saved on the memory card, or affect the product’s internal circuitry.

F

2

B

Do Not Point the Lens at Strong Light Sources for Extended Periods

Avoid pointing the lens at the sun or other strong light sources for extended periods when using or storing the camera. Intense light may cause deterioration of the image sensor, producing a white blur effect in photographs.

B

Turn the Product off Before Removing or Disconnecting the Power Source

Do not remove the battery while the product is on, or while images are being saved or deleted.

Forcibly cutting power in these circumstances could result in loss of data or in damage to product memory or internal circuitry.

B

Notes About the Monitor

Monitors and electronic viewfinders are constructed with extremely high precision; at least 99.99% of pixels are effective, with no more than 0.01% being missing or defective. Hence while these displays may contain pixels that are always lit (white, red, blue, or green) or always off (black), this is not a malfunction and has no effect on images recorded with the device.

Images in the monitor may be difficult to see under bright lighting.

The monitor is lit by an LED backlight. Should the monitor begin to dim or flicker, contact your

Nikon-authorized service representative.

The Battery

Be sure to read and follow the warnings in “For Your Safety” (

Aviii-x) before use.

Check the battery level before using the camera and replace or charge the battery if necessary. Do not continue charging once the battery is fully charged as this will result in reduced battery performance. Whenever possible, carry a fully charged spare battery when taking images on important occasions.

Do not use the battery at ambient temperatures below 0°C (32°F) or above 40°C (104°F).

Charge the battery indoors with an ambient temperature of 5°C to 35°C (41°F to 95°F) before use.

When charging the battery inserted into this camera using the Charging AC Adapter or a computer, the battery is not charged at battery temperatures below 0°C (32°F) or above 45°C

(113°F).

F

3

Note that the battery may become hot during use; wait for the battery to cool before charging.

Failure to observe these precautions could damage the battery, impair its performance, or prevent it from charging normally.

On cold days, the capacity of batteries tends to decrease. If an exhausted battery is used at a low temperature, the camera will not turn on. Be sure that the battery is fully charged before heading outside to take images in cold weather. Keep spare batteries in a warm place and exchange as necessary. Once warmed, a cold battery may recover some of its charge.

Dirt on the battery terminals can prevent the camera from functioning. Should the battery terminals become dirty, wipe them off with a clean, dry cloth before use.

If the battery will not be used for some time, insert it in the camera and completely exhaust it before removing it for storage. The battery should be stored in a cool location with an ambient temperature of 15°C to 25°C (59°F to 77°F). Do not store the battery in hot or extremely cold locations.

Always remove the battery from the camera or optional battery charger when it is not being used.

When inserted, minute amounts of current are drawn from the battery even when not in use. This may result in excessive draining of the battery and complete loss of function. Turning the camera on or off while the battery is exhausted can result in reduced battery life.

Recharge the battery at least once every six months and completely exhaust it before returning it to storage.

After removing the battery from the camera or optional battery charger, put the battery in the included battery case and store it in a cool place.

A marked drop in the time a fully-charged battery retains its charge, when used at room temperature, indicates that the battery needs to be replaced. Purchase a new EN-EL19 battery.

Replace the battery when it no longer holds a charge. Used batteries are a valuable resource.

Please recycle used batteries in accordance with local regulations.

Charging AC Adapter

Be sure to read and follow the warnings in “For Your Safety” (

Aviii-x) before use.

The Charging AC Adapter EH-70P is for use only with compatible devices. Do not use with another make or model of device.

The EH-70P is compatible with AC 100-240 V, 50/60 Hz electrical outlets. When using in other countries, use a plug adapter (commercially available) as necessary. For more information about plug adapters, consult your travel agency.

F

4

Do not, under any circumstances, use another make or model of AC adapter other than Charging

AC Adapter EH-70P or USB-AC adapter. Failure to observe this precaution could result in overheating or in damage to the camera.

Memory Cards

Use only Secure Digital memory cards. See “Approved Memory Cards” (F22) for recommended

memory cards.

Observe the precautions noted in the documentation included with your memory card.

Do not affix labels or stickers to the memory card.

Do not format the memory card using a computer.

The first time you insert a memory card that has been used in another device into this camera, be sure to format it with this camera. We recommend formatting new memory cards with this camera before using them with this camera.

Note that formatting a memory card permanently deletes all images and other data on the

memory card. If there is data saved on the memory card that you wish to keep, copy that data to a computer before formatting.

If the message Card is not formatted. Format card? is displayed when the camera is turned on, the memory card must be formatted. If there is data on the memory card that you do not want to delete, select No and press the k button. Copy that data to a computer before formatting. To format the memory card, select Yes.

Observe the following precautions while formatting the memory card, saving and deleting images, and copying images to a computer, otherwise data or the memory card itself may be damaged.

- Do not open the battery-chamber/memory card slot cover or remove the memory card or battery.

- Do not turn off the camera.

- Do not disconnect the AC adapter.

F

5

Cleaning and Storage

Cleaning

Do not use alcohol, thinner, or other volatile chemicals.

Lens

Monitor

Body

Avoid touching glass parts with your fingers. Remove dust or lint with a blower

(typically a small device with a rubber bulb attached to one end that is pumped to produce a stream of air out the other end). To remove fingerprints or other stains that cannot be removed with a blower, wipe the lens with a soft cloth, using a spiral motion that starts at the center of them and working toward the edges. If this fails, clean the lens using a cloth lightly dampened with commercial lens cleaner.

Remove dust or lint with a blower. To remove fingerprints and other stains, clean the monitor with a soft, dry cloth, being careful not to apply pressure.

Use a blower to remove dust, dirt, or sand, then wipe gently with a soft, dry cloth.

After using the camera at the beach or other sandy or dusty environment, wipe off any sand, dust, or salt with a dry cloth lightly dampened with fresh water and dry thoroughly. Note that foreign matter inside the camera could cause damage not

covered by the warranty.

Storage

Turn the camera off when not in use. Be sure that the power-on lamp is off before putting the camera away. Remove the battery if the camera will not be used for an extended period. Do not store the camera with naphtha or camphor moth balls, or in any of the following locations:

Next to equipment that produces strong electromagnetic fields, such as televisions or radios

Exposed to temperatures below –10°C (14°F) or above 50°C (122°F)

Places that are poorly ventilated or subject to humidity of over 60%

To prevent mold or mildew, take the camera out of storage at least once a month. Turn the camera on and release the shutter a few times before putting the camera away again.

For storing the battery, follow the precautions in “The Battery” (

F3) in “Caring for the

Product” (

F2).

F

6

Troubleshooting

If the camera fails to function as expected, check the list of common problems below before consulting your retailer or Nikon-authorized service representative.

Power, Display, Settings Issues

Camera cannot be turned on.

Problem

The camera is on but does not respond.

Battery inserted in the camera cannot be charged.

Cause/Solution

Wait for recording to end.

If the problem persists, turn the camera off.

If the camera does not turn off, remove and reinsert the battery or batteries or, if you are using an AC adapter, disconnect and reconnect the AC adapter.

Note that although any data currently being recorded will be lost, data that have already been recorded will not be affected by removing or disconnecting the power source.

Confirm all connections.

When connected to a computer, the camera may not charge for any of the reasons described below.

- Off is selected for Charge by computer in the setup menu.

- Battery charging stops if the camera is turned off.

- Battery charging is not possible if the camera’s display language and date and time have not been set, or the date and time were reset after the camera’s clock battery was exhausted. Use the Charging AC Adapter to charge the battery.

- Battery charging may stop if the computer is in sleep mode.

- Depending upon the computer specifications, settings, and status, battery charging may not be possible.

A

20,

E95

12

79,

E83

16, 18

The battery is exhausted.

20

F

7

Camera turns off without warning.

Problem

Monitor is blank.

Monitor is hard to read.

Date and time of recording are not correct.

Cause/Solution

The camera automatically turns off to save power

(auto off function).

The camera or battery have become too cold and cannot operate properly.

The inside of the camera has become hot. Leave the camera off until the inside of the camera has cooled, and then try turning it on again.

The camera turns off if the USB cable connecting it to a computer or printer is disconnected.

Reconnect the USB cable.

The camera is off.

The camera has entered standby mode to save power. Press the power switch, shutter-release button, A button, c button, or b (e movierecord) button.

The flash lamp flashes while the flash is charging.

Wait for the flash to charge.

The camera and computer are connected via the

USB cable.

The camera and TV are connected via an audio/ video cable or HDMI cable.

Adjust the monitor brightness.

The monitor is dirty. Clean the monitor.

If the camera clock has not been set, the “Date not set” indicator flashes during shooting and movie recording. Images and movies saved before the clock is set are dated “00/00/0000 00:00” or “01/01/

2013 00:00” respectively. Set the correct time and date from the Time zone and date option in the setup menu.

The camera clock is not as accurate as ordinary watches or clocks. Periodically compare the time of the camera clock with that of a more accurate timepiece and reset as required.

21

F3

A

83, 88,

E25

20

1, 21

49

83, 88

83,

E22

78,

E73

F6

16, 78,

E71

F

8

No indicators displayed in monitor.

Problem

Print date not available.

Date not imprinted on images even when Print

date is enabled.

Screen for setting time zone and date is displayed when camera is turned on.

Camera settings reset.

Cause/Solution

Hide info is selected for Photo info in Monitor

settings in the setup menu.

Time zone and date has not been set in the setup menu.

The current shooting mode does not support Print

date.

The date cannot be imprinted on movies.

The clock battery is exhausted; all settings were restored to their default values.

A

78,

E73

16, 78,

E71

78,

E75

16, 18

Monitor turns off, and the power-on lamp flashes quickly.

Camera becomes hot.

Camera makes sound.

The battery temperature is high. Turn off the camera and allow the battery to cool down before resuming use. After the lamp flashes for three minutes, the camera turns off automatically. Pressing the power switch also turns off the camera.

The camera may become hot when used for an extended period of time to shoot movies or send images using an Eye-Fi card, or when used in a hot environment; this is not a malfunction.

When Autofocus mode is set to Full-time AF or while in some shooting modes, the camera may produce an audible focusing sound.

58, 75

F

9

Shooting Issues

Cannot switch to shooting mode.

Problem

No image captured when the shutter-release button is pressed.

Camera cannot focus.

Images are blurred.

Cause/Solution

Disconnect the HDMI cable or USB cable.

A

83, 88,

E22,

E25

12

The camera cannot be switched to shooting mode while connected to a power outlet via the

Charging AC Adapter.

When the camera is in playback mode, press the

A button, the shutter-release button, or the b (e movie-record) button.

When menus are displayed, press the d button.

The battery is exhausted.

When the flash lamp is flashing, the flash is charging.

The subject is too close. Try shooting using scene auto selector mode, Close-up scene mode, or macro mode.

The subject is hard to focus on.

Set AF assist in the setup menu to Auto.

Turn the camera off and then on again.

Use the flash.

Increase the ISO sensitivity value.

Enable vibration reduction or motion detection.

Use D (Best Shot Selector).

Use a tripod to stabilize the camera when shooting

(using the self-timer at the same time is more effective).

1, 28

4

20

49

32, 36, 53

66

79,

E79

20

49

58

78

37, 58,

E39

51

F

10

Problem

Bright specks appear in images captured with flash.

Flash does not fire.

Digital zoom cannot be used.

Image mode not available.

No sound when shutter is released.

Cause/Solution

The flash is reflecting off particles in the air. Set the flash mode setting to W (off).

The flash mode is set to W (off).

A scene mode that restricts the flash is selected.

• On is selected for Blink proof in the smart portrait menu.

• On (continuous) or On (BSS) is selected for Smile

timer in the smart portrait menu.

A function that restricts the flash is enabled.

• Digital zoom is set to Off in the setup menu.

Digital zoom cannot be used in the following situations.

- When Portrait, Night portrait, Night

landscape, Backlighting (when HDR is set to

On), Easy panorama, or Pet portrait is selected in scene mode

- When smart portrait mode is selected

- When Continuous in the shooting menu is set to Multi-shot 16

- When AF area mode in the shooting menu is set to Subject tracking

The gesture control function is in use.

A function that restricts the Image mode option is enabled.

Off is selected for Sound settings > Shutter sound in the setup menu. No sound is produced with some shooting modes and settings, even when On is selected.

50

49

55

59

59

A

60

79,

E79

34

42

58,

E39

58,

E44

46,

E76

60

79,

E80

F

11

AF-assist illuminator does not light.

Images appear smeared.

Colors are unnatural.

Randomly spaced bright pixels (“noise”) appear in image.

Problem

Images are too dark

(underexposed).

Images are too bright

(overexposed).

Unexpected results when flash set to V (auto with red-eye reduction).

Cause/Solution

• Off is selected for the AF assist option in the setup menu. AF-assist illuminator may not light depending on the position of the focus area or the current scene mode, even when Auto is selected.

The gesture control function is in use.

The lens is dirty. Clean the lens.

White balance or hue is not adjusted properly.

79,

A

E79

46,

E76

F6

36, 58,

E36

The subject is dark, and the shutter speed is too slow or ISO sensitivity is too high. Noise can be reduced by:

Using the flash.

Specifying a lower ISO sensitivity setting.

The flash mode is set to W (off).

The flash window is blocked.

The subject is beyond the range of the flash.

Adjust exposure compensation.

Increase ISO sensitivity.

The subject is backlit. Select Backlighting scene mode or set the flash mode setting to X (fill flash).

49

58,

E42

49

24

49

54

58,

E42

37, 49

Adjust exposure compensation.

54

When taking images with V (auto with red-eye reduction), scene auto selector mode, or fill flash with slow sync and red-eye reduction in Night portrait scene mode, In-Camera Red Eye Fix may be applied to areas not affected by red-eye in rare cases. Use any scene mode other than Night portrait, and change the flash mode to any setting other than V (auto with red-eye reduction) and try taking an image again.

32, 35, 49

F

12

A ring-shaped belt or rainbow-colored stripe appears in the monitor or images.

Problem

Skin tones are not softened.

Saving images takes time.

Cause/Solution

In some shooting conditions, facial skin tones may not be softened.

For images containing four or more faces, try using the Skin softening effect in Glamour retouch in the playback menu.

It may take more time to save images in the following situations.

When the noise reduction function is in operation, such as when shooting in a dark environment

When the flash mode is set to V (auto with redeye reduction)

When shooting in Night landscape, Night

portrait, or Backlighting (when HDR is set to On) scene mode

When the skin softening function is applied while shooting

When using continuous shooting mode

When shooting with backlighting or when a very strong light source (such as sunlight) is in the frame, a ring-shaped belt or rainbow-colored stripe (ghosting) may occur. Change the position of the light source, or frame the image so that the light source does not enter the frame, and try again.

42

A

70,

E18

50

35, 36, 37

59

58,

E39

F

13

Playback Issues

Cannot record voice memos.

Problem

File cannot be played back.

Cannot zoom in on image.

Cannot edit image.

Cause/Solution

This camera may not be able to play back images saved with another make or model of digital camera.

This camera cannot play back movies recorded with another make or model of digital camera.

This camera may not be able to play back data edited on a computer.

Playback zoom cannot be used with movies, small pictures, or images that have been cropped to a size of 320 × 240 or smaller.

This camera may not be able to zoom in on images captured with another make or model of digital camera.

Voice memos cannot be attached to movies.

Voice memos cannot be attached to images captured with other cameras. Voice memos attached to images using another camera cannot be played back on this camera.

Some images cannot be edited. Images that have already been edited may not be edited again.

There is not enough free space in the internal memory or on the memory card.

This camera is unable to edit images captured with other cameras.

Editing functions used for images are not available for movies.

A

70,

E60

38,

E14

70,

E14

F

14

Problem

Cannot rotate image.

Images are not displayed on

TV.

Nikon Transfer 2 does not start when camera is connected to a computer.

The PictBridge startup screen is not displayed when the camera is connected to a printer.

Cause/Solution

This camera cannot rotate images captured with another make or model of digital camera.

• Video mode or HDMI is not correctly set in the TV

settings setup menu.

The cables are connected to the HDMI micro connector (Type D) and to the USB/audio/video output connector simultaneously.

The memory card contains no images. Replace the memory card. Remove the memory card to play back images from the internal memory.

The camera is off.

The battery is exhausted.

The USB cable is not correctly connected.

The camera is not recognized by the computer.

Confirm system requirements.

The computer is not set to start Nikon Transfer 2 automatically. For more information about

Nikon Transfer 2, refer to help information contained in ViewNX 2.

With some PictBridge-compatible printers, the

PictBridge startup screen may not be displayed and it may be impossible to print images when Auto is selected for the Charge by computer option in the setup menu. Set the Charge by computer option to

Off and reconnect the camera to the printer.

A

79,

E82

83, 88,

E22,

E25

15

20

20

83, 88

85

90

79,

E83

F

15

Problem

Images to be printed are not displayed.

Cannot select paper size with camera.

Cause/Solution

The memory card contains no images. Replace the memory card.

Remove the memory card to print images from the internal memory.

The camera cannot be used to select the paper size in the following situations, even when printing from a

PictBridge-compatible printer. Use the printer to select the paper size.

The printer does not support the paper sizes specified by the camera.

The printer automatically selects the paper size.

14

15

A

83,

E28,

E29

F

16

Specifications

Nikon COOLPIX S6600 Digital Camera

Type Compact digital camera

Number of effective pixels

16.0 million

Image sensor

1

/

2.3

-in. type CMOS; approx. 16.79 million total pixels

Lens

Focal length

NIKKOR lens with 12× optical zoom

4.5-54.0 mm (angle of view equivalent to that of 25-300 mm lens in

35mm [135] format) f/-number f/3.3-6.3

9 elements in 7 groups (1 ED lens element) Construction

Digital zoom magnification

Vibration reduction

Motion blur reduction

Autofocus (AF)

Up to 4× (angle of view equivalent to that of approx. 1200 mm lens in 35mm [135] format)

Lens shift

Motion detection (still pictures)

Contrast-detect AF

Focus range

Focus-area selection

[W]: Approx. 50 cm (1 ft 8 in.)–∞,

[T]: Approx. 1.5 m (5 ft)–

Macro mode: Approx. 2 cm (0.8 in.)–∞ (wide-angle position)

(All distances measured from center of front surface of lens)

Face priority, manual with 99 focus areas, center, subject tracking, target finding AF

Monitor

Frame coverage

(shooting mode)

Frame coverage

(playback mode)

6.7 cm (2.7-in.), approx. 460k-dot, TFT LCD with anti-reflection coating and 5-level brightness adjustment

Approx. 97% horizontal and 97% vertical (compared to actual picture)

Approx. 99% horizontal and 99% vertical (compared to actual picture)

F

17

Storage

Media

File system

File formats

Image size

(pixels)

ISO sensitivity

(Standard output sensitivity)

Exposure

Metering mode

Exposure control

Shutter

Speed

Aperture

Range

Self-timer

Internal memory (approx. 25 MB), SD/SDHC/SDXC memory card

DCF, Exif 2.3, and DPOF compliant

Still pictures: JPEG

Sound files (Voice Memo): WAV

Movies: MOV (Video: H.264/MPEG-4 AVC, Audio: LPCM stereo)

16M (High) [4608 × 3456P]

16M [4608 × 3456]

8M [3264 × 2448]

4M [2272 × 1704]

2M [1600 × 1200]

VGA [640 × 480]

16:9 [4608 × 2592]

1:1 [3456 × 3456]

ISO 125-1600

ISO 3200, Hi 1 (equivalent to ISO 6400) (available when using

Auto mode)

Matrix, center-weighted (digital zoom less than 2×), spot (digital zoom 2× or more)

Programmed auto exposure and exposure compensation

(–2.0 – +2.0 EV in steps of

1

/

3

EV)

Mechanical and CMOS electronic shutter

1

/

2000

-1 s

1

/

4000

s (maximum speed during high-speed continuous shooting)

4 s (Fireworks show scene mode)

Electronically-controlled ND filter (–2 AV) selection

2 steps (f/3.3 and f/6.6 [W])

Can be selected from 10 s and 2 s

F

18

Flash

Range (approx.)

(ISO sensitivity: Auto)

Flash control

Interface

Data transfer protocol

Video output

HDMI output

I/O terminal

Supported languages

Power sources

Charging time

Battery life

1

Still pictures

Movies (actual battery life for recording)

2

Tripod socket

Dimensions (W × H × D)

Weight

[W]: 0.5–3.0 m (1 ft 8 in.–9 ft 10 in.)

[T]: 1.5–1.8 m (5 ft–5 ft 10 in.)

TTL auto flash with monitor preflashes

Hi-Speed USB

MTP, PTP

Can be selected from NTSC and PAL

Can be selected from Auto, 480p, 720p, and 1080i

Audio/video (A/V) output; digital I/O (USB)

HDMI micro connector (Type D) (HDMI output)

Arabic, Bengali, Bulgarian, Chinese (Simplified and Traditional),

Czech, Danish, Dutch, English, Finnish, French, German, Greek,

Hindi, Hungarian, Indonesian, Italian, Japanese, Korean, Marathi,

Norwegian, Persian, Polish, Portuguese (European and Brazilian),

Romanian, Russian, Serbian, Spanish, Swedish, Tamil, Telugu, Thai,

Turkish, Ukrainian, Vietnamese

One Rechargeable Li-ion Battery EN-EL19 (included)

AC Adapter EH-62G (available separately)

Approx. 3 h (when using Charging AC Adapter EH-70P and when no charge remains)

Approx. 150 shots when using EN-EL19

Approx. 25 min when using EN-EL19

1/4 (ISO 1222)

Approx. 96.9 × 57.1 × 27.2 mm (3.9 × 2.3 × 1.1 in.) (excluding projections)

Approx. 165 g (5.9 oz) (including battery and SD memory card)

F

19

Operating environment

Temperature

Humidity

Wi-Fi (Wireless LAN)

Standards

0°C–40°C (32°F–104°F)

85% or less (no condensation)

Communications protocols

Range (line of sight)

Operating frequency

Data rates (actual measured values)

Security

Access protocols

IEEE 802.11b/g/n (standard wireless LAN protocol)

IEEE 802.11b: DBPSK/DQPSK/CCK

IEEE 802.11g: OFDM

IEEE 802.11n: OFDM

Approx. 10 m (11 yd)

2412-2462 MHz (1-11 channels)

IEEE 802.11b: 5 Mbps

IEEE 802.11g: 20 Mbps

IEEE 802.11n: 20 Mbps

WPA2

Infrastructure

Unless otherwise stated, all figures assume a fully-charged battery and an ambient temperature of 23 ±3°C (73.4 ±5.4°F) as specified by the Camera and Imaging Products

Association (CIPA).

1

2

Battery life may vary depending on conditions of use, such as the interval between shots or the length of time that menus and images are displayed.

Individual movie files cannot exceed 4 GB in size or 29 minutes in length. Recording may end before this limit is reached if camera temperature becomes elevated.

F

20

Rechargeable Li-ion Battery EN-EL19

Type

Rated capacity

Operating temperature

Dimensions (W × H × D)

Weight

Rechargeable lithium-ion battery

DC 3.7 V, 700 mAh

0°C–40°C (32°F–104°F)

Approx. 31.5 × 39.5 × 6 mm (1.3 × 1.6 × 0.3 in.)

Approx. 14.5 g (0.5 oz) (excluding battery case)

Charging AC Adapter EH-70P

Rated input

Rated output

Operating temperature

Dimensions (W × H × D)

Weight

AC 100-240 V, 50/60 Hz, 0.07-0.044 A

DC 5.0 V, 550 mA

0°C–40°C (32°F–104°F)

Approx. 55 × 22 × 54 mm (2.2 × 0.9 × 2.2 in.) (excluding plug adapter)

For Argentina: Approx. 55 × 59 × 63 mm (2.2 × 2.4 × 2.5 in.)

For Korea: Approx. 55 × 59 × 66.5 mm (2.2 × 2.4 × 2.7 in.)

Approx. 47 g (1.7 oz) (excluding plug adapter)

For Argentina and Korea: Approx. 72 g (2.6 oz)

B

Specifications

Nikon will not be held liable for any errors this manual may contain.

The appearance of this product and its specifications are subject to change without notice.

F

21

Approved Memory Cards

The following Secure Digital (SD) memory cards have been tested and approved for use in this camera.

Memory cards with an SD Speed Class rating of 6 or faster are recommended for recording movies. When using a memory card with a lower Speed Class rating, movie recording may stop unexpectedly.

SanDisk

TOSHIBA

Panasonic

SD memory card

2 GB

1

2 GB

1

SDHC memory card

4 GB, 8 GB, 16 GB, 32 GB

4 GB, 8 GB, 16 GB, 32 GB

4 GB, 8 GB, 16 GB, 32 GB

2

SDXC memory card

3

64 GB, 128 GB

64 GB

64 GB

Lexar – 4 GB, 8 GB, 16 GB, 32 GB 64 GB, 128 GB

1

2

If the memory card will be used with a card reader or similar device, make sure that the device supports 2 GB cards.

SDHC compliant.

If the memory card will be used with a card reader or similar device, make sure that the device supports SDHC.

3

SDXC compliant.

If the memory card will be used with a card reader or similar device, make sure that the device supports SDXC.

Contact the manufacturer for details on the above cards. We cannot guarantee camera performance when using memory cards made by other manufacturers.

F

22

AVC Patent Portfolio License

This product is licensed under the AVC Patent Portfolio License for the personal and noncommercial use of a consumer to (i) encode video in compliance with the AVC standard

(“AVC video”) and/or (ii) decode AVC video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed to provide AVC video. No license is granted or shall be implied for any other use.

Additional information may be obtained from MPEG LA, L.L.C.

See http://www.mpegla.com.

F

23

Trademark Information

Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries. The iFrame logo and the iFrame symbol are trademarks of Apple Inc.

Adobe and Acrobat are registered trademarks of Adobe Systems Inc.

SDXC, SDHC and SD Logos are trademarks of SD-3C, LLC.

PictBridge is a trademark.

HDMI, HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Wi-Fi and the Wi-Fi logo are trademarks or registered trademarks of the Wi-Fi Alliance.

Android and Google Play are trademarks or registered trademarks of Google, Inc.

All other trade names mentioned in this manual or the other documentation provided with your Nikon product are trademarks or registered trademarks of their respective holders.

FreeType License (FreeType2)

Portions of this software are copyright © 2013 The FreeType Project

(http://www.freetype.org). All rights reserved.

MIT License (HarfBuzz)

Portions of this software are copyright © 2013 The HarfBuzz Project

(http://www.freedesktop.org/wiki/Software/HarfBuzz). All rights reserved.

F

24

Index

Symbols

x Scene auto selector ................................. 32

b Scene mode .................................................. 34

D Special effects mode ............................. 40

F Smart portrait mode............................... 42

A Auto mode....................................... 22, 44

c Playback mode........................................... 28

h Favorite pictures mode.................... E6

F Auto sort mode................................... E10

C List by date mode............................... E11

z Setup menu.................................................... 78

g (Telephoto)...................................................... 25 f (Wide-angle)................................................. 25

i Playback zoom .............................................. 68

h Thumbnail playback............................... 69

j Help.................................................................... 34

A Shooting mode button................. 1, 22

c Playback button ................................. 1, 28

b (e movie-record) button ........... 2, 72

d button .................. 4, 57, 70, 75, 78

l Delete button............................. 30, E61

m Flash mode .................................................... 49

n Self-timer.......................................................... 51

p Macro mode ................................................. 53

o Exposure compensation....................... 54

Refer to the Reference Manual for pages indicated with

E.

A

AC adapter ........................................ 83, E95

AF area mode .................................. 58, E44

AF assist........................................ 1, 79, E79

Album................................................................. E9

Aperture value .................................................... 27

Audio/video cable........................................... 84

Audio/video-in jack ........................................ 84

Auto flash ............................................................... 50

Auto mode................................................ 22, 44

Auto off...................................... 21, 79, E80

Auto sort mode.......................................... E10

Autofocus............. 58, 75, E48, E68

B

Backlighting o ....................................... 34, 37

Battery charger ................................ 13, E95

Battery latch.......................................................... 10

Battery level indicator..................................... 20

Battery-chamber/memory card slot cover

.................................................................... 2, 10, 14

Beach Z................................................................. 34

Best Shot Selector......................... 37, E40

Black and white copy n.................... 34, 37

Black-and-white ........................................ E43

Blink proof........................................... 59, E51

Blink warning ................................... 79, E84

F

25

Brightness ........................................... 78, E73

BSS.......................................................... 37, E40

Button sound.............................................. E80

C

Charge by computer .................. 79, E83

Charge lamp.................................................. 2, 13

Charger................................................. 13, E95

Charging AC Adapter ...................................... 12

Choose key picture .... 71, E12, E63

Close-up k ............................................... 34, 36

Color options ................................... 58, E43

Compression ratio ................................... E34

Computer................................................... 84, 88

Connector cover.................................................... 1

Continuous ....................................... 58, E39

Copying images............................... 71, E61

Crop................................................................... E21

Cross process o.............................................. 40

Cyanotype .................................................... E43

D

Date and time ........................ 16, 78, E71

Date format......................................... 17, E71

Daylight saving time ........... 17, 18, E71

Delete ................................. 30, E13, E61

Digital zoom........................... 25, 79, E79

Direct print ........................................ 84, E24

D-Lighting .......................................... 70, E16

DPOF print..................................................... E31

DSCN................................................................ E94

E

Easy panorama p................. 34, 38, E2

Easy panorama playback.............. 38, E5

Exposure compensation............................... 54

Extension....................................................... E94

Eye-Fi upload ................................... 79, E87

Eyelet for camera strap...................................... 1

F

Face detection ................................................... 64

Face priority................................................ E44

Favorite pictures ................................ 71, E6

Favorite pictures mode ........................... E6

File name....................................................... E94

Fill flash .................................................................... 50

Fireworks show m ................................ 34, 37

Firmware version........................... 79, E88

Fixed range auto....................................... E42

Flash .................................................................. 1, 49

Flash lamp ..................................................... 2, 49

Flash mode................................................. 49, 50

Flash off ................................................................... 50

Focus.......................................... 26, 58, E44

Focus area.............................................................. 26

Focus indicator ...................................................... 7

Focus lock .............................................................. 67

Food u.......................................................... 34, 36

Format internal memory ........... 79, E81

Refer to the Reference Manual for pages indicated with

E.

F

26

Format memory cards ...... 15, 79, E81

Formatting ............................... 15, 79, E81

FSCN................................................................. E94

Full-frame playback ......................................... 68

Full-time AF ........ 58, 75, E48, E68

G

Gesture control.................... 46, 78, E76

Glamour retouch............................ 70, E18

H

I

HDMI ................................................................ E82

HDMI cable ....................................... 84, E22

HDMI device control .............................. E82

HDMI micro connector...................................... 1

HDR............................................................................ 37

Help ........................................................................... 34

High key G.......................................................... 40

High-contrast monochrome F ............. 40

High-speed continuous ....................... E39

HS movie ......................... 75, E65, E66

Identifier......................................................... E94

Image copy ................................................... E61

Image mode..................................... 58, E34

Image review .................................... 78, E73

Image size.......................................... 58, E34

Imprinting date and time ......... 18, E75

Internal memory...................................... 15, 20

Internal memory indicator ...................... 7, 9

ISO sensitivity................................... 58, E42

J

JPG..................................................................... E94

L

Landscape c ...................................................... 34

Language ........................................... 79, E82

Lens............................................................... 1, F17

Lens cover.................................................................. 1

List by date mode..................................... E11

Low key H........................................................... 40

M

Macro mode......................................................... 53

Memory capacity............................................... 20

Memory card........................................................ 14

Memory card slot .............................................. 14

Microphone.............................................................. 1

Mirror b ................................................................ 40

Monitor......................................... 2, 3, 6, F6

Monitor settings.............................. 78, E73

Motion detection .......................... 79, E78

MOV.................................................................. E94

Movie editing ................................... 77, E32

Movie length............................................. 72, 73

Movie menu ..................................... 75, E64

Movie options ................................. 75, E64

Movie playback .................................................. 76

Movie recording ................................................ 72

Multi selector .................................................. 2, 4

Refer to the Reference Manual for pages indicated with

E.

F

27

Multi-shot 16............................................... E40

Museum l ............................................... 34, 37

N

Night landscape j .............................. 34, 36

Night portrait e..................................... 34, 35

Nikon Transfer 2 ...................................... 87, 89

Nostalgic sepia E .......................................... 40

Number of exposures remaining

................................................................... 20, E35

O

Open with HS footage

............................................... 75, E66, E68

Optical zoom ....................................................... 25

Optional accessories .............................. E95

P

Painting h........................................................... 40

Panorama Maker................................................ 87

Paper size ................................... E28, E29

Party/indoor f....................................... 34, 35

Pet portrait auto release ............................... 39

Pet portrait O.......................................... 34, 39

Photo info ........................................... 78, E73

PictBridge........................................... 84, E24

Playback ........................ 28, 68, 76, E60

Playback menu ................................ 70, E52

Playback mode ................................................... 28

Playback zoom.................................................... 68

Pop l.................................................................. 40

Portrait b............................................................... 34

Power........................................................................ 20

Power switch ................................................ 1, 20

Power-on lamp............................................ 1, 20

Preset manual............................................. E37

Pre-shooting cache.............. E39, E41

Pressing halfway ................................................ 27

Print...... 70, 84, E27, E29, E52

Print date.................................. 18, 78, E75

Print order.......................................... 70, E52

Print order date option

................................................ 18, E53, E55

Printer................................................... 84, E24

Protect.................................................. 70, E57

Q

Quick effects....... 29, 45, E15, E48

Quick retouch................................... 70, E16

R

Recording movies............................................. 72

Recording slow motion movies

............................................... 75, E65, E66

Red-eye correction........................ 70, E17

Red-eye reduction............................................ 50

Remove from favorites .................. 71, E8

Reset all ............................................... 79, E88

Rotate image.................................... 70, E59

RSCN................................................................. E94

Refer to the Reference Manual for pages indicated with

E.

F

28

S

Scene mode .............................................. 34, 35

Selective color I ............................................ 40

Self-timer ................................................................. 51

Self-timer lamp ............................................ 1, 52

Sepia................................................................. E43

Sequence display options

................................................ 71, E12, E63

Setup menu.......................................................... 78

Shooting ........................................... 22, 24, 26

Shooting menu .............................. 58, E34

Shooting mode .................................................. 22

Shutter sound............................................. E80

Shutter speed...................................................... 27

Shutter-release button ........................... 1, 26

Single.................................................... 58, E39

Single AF............... 58, 75, E48, E68

Skin softening....................... 59, 65, E49

Slide show ......................................... 70, E56

Slow sync ............................................................... 50

Small picture .................................... 70, E20

Smart portrait menu.................... 57, E49

Smart portrait mode ....................................... 42

Smile timer ........................................ 59, E50

Snow z.................................................................. 34

Soft D.................................................................... 40

Sound settings................................ 79, E80

Speaker....................................................................... 2

Special effects mode...................................... 40

Sports d...................................................... 34, 35

SSCN................................................................. E94

Standard color................................. 58, E43

Strap ............................................................................. 3

Subject tracking .................... E45, E47

Sunset h............................................................... 34

Super vivid k...................................................... 40

T

Target finding AF................ 58, 63, E46

Time difference .......................................... E71

Time zone ............................................ 18, E71

Time zone and date............ 16, 78, E71

Toy camera effect 1 m................................ 40

Toy camera effect 2 n ............................... 40

Tripod socket ......................................... 2, F19

TV............................................................. 84, E22

TV settings ......................................... 79, E82

U

USB cable ................................. 83, 88, E25

USB/audio/video output connector

........................................................................... 83, 88

V

Vibration reduction...................... 78, E77

Video mode ................................................. E82

ViewNX 2 ................................................................ 85

Vivid color ..................................................... E43

Voice memo..................................... 70, E60

Refer to the Reference Manual for pages indicated with

E.

F

29

Volume ................................................ 77, E60

W

WAV .................................................................. E94

Welcome screen............................ 78, E70

White balance ................................. 58, E36

Wi-Fi options......................... 79, 80, E85

Wind noise reduction................. 75, E69

Wireless LAN.......................... 79, 80, E85

Z

Zoom ........................................................................ 25

Zoom control ............................................... 1, 25

Zoom in................................................................... 25

Zoom out ............................................................... 25

Refer to the Reference Manual for pages indicated with

E.

F

30

No reproduction in any form of this manual, in whole or in part

(except for brief quotation in critical articles or reviews), may be made without written authorization from NIKON CORPORATION.

Printed in Hong Kong

YP3H02(11)

6MN26011-02

DIGITAL CAMERA

User’s Manual

En
