Nikon COOLPIX S6700 Camera User Guide

Nikon COOLPIX S6700 Camera User Guide

No reproduction in any form of this manual, in whole or in part

(except for brief quotation in critical articles or reviews), may be made without written authorization from NIKON CORPORATION.

Printed in Singapore

YP4A01(11)

6MN42411-01

DIGITAL CAMERA

User’s Manual

En

Introduction

Parts of the Camera

The Basics of Shooting and Playback

Shooting Features

Playback Features

Recording and Playing Back Movies

General Camera Setup

Connecting the Camera to a TV, Computer, or Printer

Technical Notes and Index

i

Introduction

Read This First

Thank you for purchasing the Nikon COOLPIX S6700 digital camera. Before using the camera,

please read the information in “For Your Safety” (

Aviii-x) and familiarize yourself with the

information provided in this manual. After reading, please keep this manual handy and refer to it to enhance your enjoyment of your new camera.

Confirming the Package Contents

In the event that any items are missing, please contact the store where you purchased the camera.

COOLPIX S6700

Digital Camera

Camera Strap Rechargeable Li-ion

Battery EN-EL19

ii

Charging AC Adapter

EH-70P*

USB Cable UC-E6 ViewNX 2 CD

User’s Manual (this manual)

Warranty

* A plug adapter is included if the camera was purchased in a country or region that requires a plug adapter. The shape of the plug adapter varies with the country or region of purchase

(

A12).

NOTE: A memory card is not included with the camera.

About This Manual

If you want to start using the camera right away, see “The Basics of Shooting and Playback”

(

A10).

To learn about the parts of the camera and information that is displayed in the monitor, see

“Parts of the Camera” (

A1).

Downloading the “Reference Manual”

Refer to the Reference Manual (PDF format) for more detailed information. The Reference

Manual can be downloaded from the Nikon website.

http://nikonimglib.com/manual/

The Reference Manual can be viewed using Adobe Reader, available for free download from the Adobe website.

iii

iv

Other Information

Symbols and Conventions

Symbol

B

Description

This icon marks cautions and information that should be read before using the camera.

C

This icon marks notes and information that should be read before using the camera.

A/E/

F

These icons indicate other pages containing relevant information;

E*: “Reference Section”, F: “Technical Notes and Index”

* Refer to the Reference Manual for pages indicated with

E.

SD, SDHC, and SDXC memory cards are referred to as “memory cards” in this manual.

The setting at the time of purchase is referred to as the “default setting.”

The names of menu items displayed in the camera monitor, and the names of buttons or messages displayed on a computer monitor appear in bold.

In this manual, images are sometimes omitted from monitor display samples so that monitor indicators can be more clearly shown.

Illustrations and monitor content shown in this manual may differ from the actual display.

Information and Precautions

Life-Long Learning

As part of Nikon’s “Life-Long Learning” commitment to ongoing product support and education, continually updated information is available online at the following sites:

For users in the U.S.A.: http://www.nikonusa.com/

For users in Europe and Africa: http://www.europe-nikon.com/support/

For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/

Visit these sites to keep up-to-date with the latest product information, tips, answers to frequently asked questions (FAQs), and general advice on digital imaging and photography. Additional information may be available from the Nikon representative in your area. Visit the site below for contact information.

http://imaging.nikon.com/

Use Only Nikon Brand Electronic Accessories

Nikon COOLPIX cameras are designed to the highest standards and include complex electronic circuitry. Only Nikon brand electronic accessories (including battery chargers, batteries, Charging AC

Adapter, and AC adapters) certified by Nikon specifically for use with this Nikon digital camera are engineered and proven to operate within the operational and safety requirements of this electronic circuitry.

T

HE USE OF NON-

N

IKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND MAY

VOID YOUR

N

IKON WARRANTY.

The use of third-party rechargeable Li-ion batteries not bearing the

Nikon holographic seal could interfere with normal operation of the camera or result in the batteries overheating, igniting, rupturing, or leaking.

For more information about Nikon brand accessories, contact a local authorized Nikon dealer.

Holographic seal:

Identifies this device as an authentic Nikon product.

Before Taking Important Images

Before taking images on important occasions (such as at weddings or before taking the camera on a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable for damages or lost profits that may result from product malfunction.

v

vi

About the Manuals

No part of the documentation included with this product may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form, by any means, without Nikon’s prior written permission.

Nikon reserves the right to change the specifications of the hardware and software described in the documentation at any time and without prior notice.

Nikon will not be held liable for any damages resulting from the use of this product.

While every effort was made to ensure that the information in the documentation is accurate and complete, we would appreciate it were you to bring any errors or omissions to the attention of the

Nikon representative in your area (address provided separately).

Notice Concerning Prohibition of Copying or Reproduction

Note that simply being in possession of material that was digitally copied or reproduced by means of a scanner, digital camera or other device may be punishable by law.

• Items prohibited by law from being copied or reproduced

Do not copy or reproduce paper money, coins, securities, government bonds or local government bonds, even if such copies or reproductions are stamped “Sample.” The copying or reproduction of paper money, coins, or securities which are circulated in a foreign country is prohibited. Unless the prior permission of the government was obtained, the copying or reproduction of unused postage stamps or post cards issued by the government is prohibited. The copying or reproduction of stamps issued by the government and of certified documents stipulated by law is prohibited.

• Cautions on certain copies and reproductions

The government has issued cautions on copies or reproductions of securities issued by private companies (shares, bills, checks, gift certificates, etc.), commuter passes or coupon tickets, except when a minimum of necessary copies are to be provided for business use by a company. Also, do not copy or reproduce passports issued by the government, licenses issued by public agencies and private groups, ID cards and tickets, such as passes and meal coupons.

• Comply with copyright notices

The copying or reproduction of copyrighted creative works such as books, music, paintings, woodcut prints, maps, drawings, movies and photographs is governed by national and international copyright laws. Do not use this product for the purpose of making illegal copies or to infringe copyright laws.

Disposing of Data Storage Devices

Please note that deleting images or formatting data storage devices such as memory cards or builtin camera memory does not completely erase the original image data. Deleted files can sometimes be recovered from discarded storage devices using commercially available software, potentially resulting in the malicious use of personal image data. Ensuring the privacy of such data is the user’s responsibility.

Before discarding a data storage device or transferring ownership to another person, erase all data using commercial deletion software, or format the device and then completely refill it with images containing no private information (for example, images of empty sky). Be sure to also replace any images selected for the Select an image option in the Welcome screen setting (

A73). Care

should be taken to avoid injury or damage to property when physically destroying data storage devices.

vii

For Your Safety

To prevent damage to your Nikon product or injury to yourself or to others, read the following safety precautions in their entirety before using this equipment. Keep these safety instructions where all those who use the product will read them.

The consequences that could result from failure to observe the precautions listed in this section are indicated by the following symbol:

This icon marks warnings, information that should be read before using this Nikon product, to prevent possible injury.

WARNINGS

viii

Turn off in the event of malfunction

Should you notice smoke or an unusual smell coming from the camera or Charging

AC Adapter, unplug the Charging AC

Adapter and remove the battery immediately, taking care to avoid burns.

Continued operation could result in injury.

After removing or disconnecting the power source, take the equipment to a Nikonauthorized service representative for inspection.

Do not disassemble

Touching the internal parts of the camera or

Charging AC Adapter could result in injury.

Repairs should be performed only by qualified technicians. Should the camera or

Charging AC Adapter break open as the result of a fall or other accident, take the product to a Nikon-authorized service representative for inspection, after unplugging the product and/or removing the battery.

Do not use the camera or Charging

AC Adapter in the presence of flammable gas

Do not use electronic equipment in the presence of flammable gas, as this could result in explosion or fire.

Handle the camera strap with care

Never place the strap around the neck of an infant or child.

Keep out of reach of children

Particular care should be taken to prevent infants from putting the battery or other small parts into their mouths.

Do not remain in contact with the camera, battery charger, or AC adapter for extended periods while the devices are on or in use

Parts of the devices become hot. Leaving the devices in direct contact with the skin for extended periods may result in lowtemperature burns.

Do not leave the product where it will be exposed to extremely high temperatures, such as in an enclosed automobile or in direct sunlight

Failure to observe this precaution could cause damage or fire.

Observe caution when handling the battery

The battery may leak, overheat or explode if improperly handled. Observe the following precautions when handling the battery for use in this product:

Before replacing the battery, turn the product off. If you are using the Charging

AC Adapter/AC adapter, be sure it is unplugged.

Use only a Rechargeable Li-ion Battery

EN-EL19 (included). Charge the battery by using a camera that supports battery charging. To perform this operation, use either Charging AC Adapter EH-70P

(included) or the Charge by computer function. The Battery Charger MH-66

(available separately) is also available to charge the battery without using a camera.

When inserting the battery, do not attempt to insert it upside down or backwards.

Do not short or disassemble the battery or attempt to remove or break the battery insulation or casing.

Do not expose the battery to flame or to excessive heat.

Do not immerse in or expose to water.

Put the battery in a plastic bag, etc. in order to insulate it before transporting.

Do not transport or store with metal objects such as necklaces or hairpins.

The battery is prone to leakage when fully discharged. To avoid damage to the product, be sure to remove the battery when no charge remains.

Discontinue use immediately should you notice any change in the battery, such as discoloration or deformation.

If liquid from the damaged battery comes in contact with clothing or skin, rinse immediately with plenty of water.

Observe the following precautions when handling the Charging AC

Adapter

Keep dry. Failure to observe this precaution could result in fire or electric shock.

Dust on or near the metal parts of the plug should be removed with a dry cloth.

Continued use could result in fire.

Do not handle the plug or go near the

Charging AC Adapter during lightning storms. Failure to observe this precaution could result in electric shock.

ix

x

Do not damage, modify, forcibly tug or bend the USB cable, place it under heavy objects, or expose it to heat or flames.

Should the insulation be damaged and the wires become exposed, take it to a

Nikon-authorized service representative for inspection. Failure to observe these precautions could result in fire or electric shock.

Do not handle the plug or Charging AC

Adapter with wet hands. Failure to observe this precaution could result in electric shock.

Do not use with travel converters or adapters designed to convert from one voltage to another or with DC-to-AC inverters. Failure to observe this precaution could damage the product or cause overheating or fire.

Use appropriate cables

When connecting cables to the input and output jacks, use only the cables provided or sold by Nikon for the purpose, to maintain compliance with product regulations.

Handle moving parts with care

Be careful that your fingers or other objects are not pinched by the lens cover or other moving parts.

CD-ROMs

The CD-ROMs included with this device should not be played back on audio CD equipment. Playing CD-ROMs on an audio

CD player could cause hearing loss or damage the equipment.

Using the flash close to your subject’s eyes could cause temporary visual impairment

The flash should be no less than 1 meter (3 ft 4 in.) from the subject.

Particular care should be observed when photographing infants.

Do not operate the flash with the flash window touching a person or object

Failure to observe this precaution could result in burns or fire.

Avoid contact with liquid crystal

Should the monitor break, care should be taken to avoid injury caused by broken glass and to prevent liquid crystal from the monitor touching the skin or entering the eyes or mouth.

Turn the power off when using inside an airplane or the hospital

Turn the power off while inside the airplane during take off or landing. Do not use wireless network functions while in the air.

Follow the instructions of the hospital when using while in a hospital. The electromagnetic waves emitted by this camera may disrupt the electronic systems of the airplane or the instruments of the hospital. If you are using an Eye-Fi card, remove it from the camera before boarding an aircraft or entering a hospital.

Notices

Notices for Customers in the

U.S.A.

IMPORTANT SAFETY INSTRUCTIONS–

SAVE THESE INSTRUCTIONS.

DANGER - TO REDUCE THE RISK OF FIRE

OR ELECTRIC SHOCK, CAREFULLY

FOLLOW THESE INSTRUCTIONS

For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper configuration for the power outlet if needed.

The power supply unit is intended to be correctly orientated in a vertical or floor mount position.

Federal Communications Commission

(FCC) Radio Frequency Interference

Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/television technician for help.

CAUTIONS

Modifications

The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by

Nikon Corporation may void the user’s authority to operate the equipment.

Interface Cables

Use the interface cables sold or provided by

Nikon for your equipment. Using other interface cables may exceed the limits of

Class B Part 15 of the FCC rules.

xi

xii

Notice for Customers in the State of

California

WARNING

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

Nikon Inc.,

1300 Walt Whitman Road

Melville, New York 11747-3064

USA

Tel: 631-547-4200

Notice for Customers in Canada

CAN ICES-3 B / NMB-3 B

Notices for Customers in Europe

CAUTIONS

RISK OF EXPLOSION IF BATTERY IS

REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES

ACCORDING TO THE INSTRUCTIONS.

This symbol indicates that electrical and electronic equipment is to be collected separately.

The following apply only to users in European countries:

This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste.

Separate collection and recycling helps conserve natural resources and prevent negative consequences for human health and the environment that might result from incorrect disposal.

For more information, contact the retailer or the local authorities in charge of waste management.

This symbol on the battery indicates that the battery is to be collected separately. The following apply only to users in

European countries:

All batteries, whether marked with this symbol or not, are designated for separate collection at an appropriate collection point. Do not dispose of as household waste.

For more information, contact the retailer or the local authorities in charge of waste management.

Table of Contents

Introduction ................................................... ii

Read This First ....................................................... ii

Confirming the Package Contents................. ii

About This Manual .................................................. iii

Information and Precautions ............................. v

For Your Safety ................................................. viii

WARNINGS ................................................................ viii

Notices .................................................................... xi

Step 3 Frame a Picture .................................... 24

Using the Zoom ...................................................... 25

Step 4 Focus and Shoot.................................. 26

The Shutter-release Button .............................. 27

Step 5 Play Back Images ................................. 28

Step 6 Delete Images....................................... 30

Parts of the Camera ..................................... 1

The Camera Body................................................. 1

Attaching the Camera Strap............................... 3

Using Menus (the d Button)....................... 4

The Monitor ........................................................... 6

Shooting Mode .......................................................... 6

Playback Mode ........................................................... 8

The Basics of Shooting and Playback

........................................................................... 10

Preparation 1 Insert the Battery .................. 10

Preparation 2 Charge the Battery ............... 12

Preparation 3 Insert a Memory Card.......... 14

Internal Memory and Memory Cards......... 15

Preparation 4 Setting the Display Language,

Date, and Time................................................... 16

Step 1 Turn the Camera On........................... 20

Step 2 Select a Shooting Mode.................... 22

Available Shooting Modes ............................... 23

Shooting Features ..................................... 32 x (Scene Auto Selector) Mode................... 32

Scene Mode (Shooting Suited to Scenes)

................................................................................. 33

Tips and Notes.......................................................... 34

Special Effects Mode (Applying Effects

When Shooting) ................................................ 38

Smart Portrait Mode (Capturing Images of

Smiling Faces) .................................................... 40

A (Auto) Mode ................................................ 42

Using Quick Effects................................................ 43

Functions That Can Be Set Using the Multi

Selector................................................................. 44

Using the Flash ........................................................ 45

Using the Self-timer .............................................. 47

Using Macro Mode ................................................ 49

Adjusting Brightness (Exposure

Compensation) ........................................................ 50

Default Settings....................................................... 51

Functions That Can Be Set with the d

Button (Shooting Menu) ................................ 53

Refer to the Reference Manual for pages indicated with

E.

xiii

Options Available in the Shooting Menu

........................................................................................... 54

Functions That Cannot Be Used

Simultaneously .................................................. 56

Focusing............................................................... 58

Using Face Detection .......................................... 58

Using Skin Softening............................................ 59

Using Target Finding AF .................................... 60

Subjects Not Suitable for Autofocus.......... 61

Focus Lock.................................................................. 62

Playback Features....................................... 63

Playback Zoom .................................................. 63

Thumbnail Playback/Calendar Display ..... 64

Functions That Can Be Set with the d

Button (Playback Menu) ................................. 65

Recording and Playing Back Movies.... 67

Recording Movies ............................................. 67

Functions That Can Be Set with the d

Button (Movie Menu) .......................................... 70

Playing Back Movies ........................................ 71

General Camera Setup.............................. 73

Functions That Can Be Set with the d

Button (Setup Menu) ....................................... 73

Connecting the Camera to a TV,

Computer, or Printer ................................. 75

Connection Methods....................................... 75

Using ViewNX 2 ................................................. 77

Installing ViewNX 2................................................ 77

Transferring Images to the Computer....... 80

Viewing Images ....................................................... 82

Reference Section .................................

E1

Using Panorama Assist...............................

E2

Favorite Pictures Mode ..............................

E5

Adding Images to Albums..........................

E5

Playing Back Images in Albums...............

E6

Removing Images from Albums .............

E7

Changing the Favorites Album Icon ....

E8

Auto Sort Mode ............................................

E9

List by Date Mode......................................

E10

Editing Images (Still Images) .................

E11

Before Editing Images ................................

E11

Quick Effects: Changing Hue or Mood

..................................................................................

E12

Quick Retouch: Enhancing Contrast and

Saturation...........................................................

E13

D-Lighting: Enhancing Brightness and

Contrast ...............................................................

E13

Red-eye Correction: Correcting Red-eye

When Shooting with the Flash .............

E14

Glamour Retouch: Enhancing Human Faces

..................................................................................

E15

Small Picture: Reducing the Size of an

Image ....................................................................

E17

Crop: Creating a Cropped Copy...........

E18

Connecting the Camera to a TV (Playback on a TV) ..........................................................

E19

Connecting the Camera to a Printer (Direct

Print) ...............................................................

E20

xiv

Refer to the Reference Manual for pages indicated with

E.

Connecting the Camera to a Printer

..................................................................................

E21

Printing Images One at a Time .............

E23

Printing Multiple Images ..........................

E25

The Shooting Menu (for A (Auto) Mode)

..........................................................................

E28

Image Mode (Image Size and Quality)

..................................................................................

E28

White Balance (Adjusting Hue) ............

E30

Continuous Shooting .................................

E33

ISO Sensitivity ..................................................

E35

Color Options ..................................................

E36

AF Area Mode..................................................

E37

Autofocus Mode............................................

E41

Quick Effects.....................................................

E41

The Smart Portrait Menu.........................

E42

Skin Softening .................................................

E42

Smile Timer .......................................................

E43

Blink Proof..........................................................

E44

The Playback Menu ...................................

E45

Print Order (Creating a DPOF Print Order)

..................................................................................

E45

Slide Show .........................................................

E49

Protect..................................................................

E50

Rotate Image....................................................

E52

Voice Memo .....................................................

E53

Copy (Copy Between Internal Memory and Memory Card) .......................................

E54

The Movie Menu ........................................

E56

Movie Options.................................................

E56

Autofocus Mode............................................

E57

Movie VR .............................................................

E58

Wind Noise Reduction ...............................

E58

The Setup Menu .........................................

E59

Welcome Screen............................................

E59

Time Zone and Date....................................

E60

Monitor Settings ............................................

E62

Print Date (Imprinting Date and Time)

..................................................................................

E64

Photo VR..............................................................

E65

Motion Detection..........................................

E66

AF Assist ..............................................................

E67

Digital Zoom ....................................................

E67

Sound Settings................................................

E68

Auto Off ...............................................................

E68

Format Memory/Format Card ...............

E69

Language............................................................

E70

Video Mode.......................................................

E70

Charge by Computer ..................................

E71

Blink Warning...................................................

E72

Eye-Fi Upload...................................................

E73

Reset All ...............................................................

E74

Firmware Version...........................................

E74

Error Messages............................................

E75

File Names ....................................................

E79

Optional Accessories ................................

E80

Technical Notes and Index ..................

F1

Caring for the Product..................................

F2

The Camera ............................................................

F2

The Battery..............................................................

F4

Charging AC Adapter.......................................

F5

Memory Cards ......................................................

F5

Cleaning and Storage...................................

F6

Cleaning ...................................................................

F6

Refer to the Reference Manual for pages indicated with

E.

xv

Storage .....................................................................

F6

Troubleshooting ............................................

F7

Specifications ...............................................

F16

Approved Memory Cards...........................

F20

Index................................................................

F22

xvi

Refer to the Reference Manual for pages indicated with

E.

Parts of the Camera

The Camera Body

1 2 3 4 5 6 7

Lens cover closed

11 10 9 8

1

Shutter-release button.................................... 26

2

Zoom control........................................................ 25 f: Wide-angle................................................ 25 g: Telephoto.................................................... 25

h: Thumbnail playback.......................... 64

i: Playback zoom......................................... 63

j: Help................................................................ 33

3

Power switch/power-on lamp ................... 20

4

Flash............................................................................ 45

5

Built-in microphone.................................

E53

6

Self-timer lamp..................................................... 48

AF-assist illuminator..........................................74

7

Lens

8

Lens cover ...........................................................

F2

9

Eyelet for camera strap.......................................3

10

Connector cover .................................................75

11

USB/audio/video output connector....... 75

1

2

1

2

3

4

5

8

9

6

7

1

Charge lamp.......................................................... 13

Flash lamp............................................................... 45

2

b (e movie-record) button..................... 67

3

A (shooting mode) button

........................................................22, 33, 38, 40, 42

4

c (playback) button ...................................... 28

5

Multi selector

6

k (apply selection) button

7

l (delete) button ......................30, 72, E54

10 11 12 13

8

d button............................... 4, 53, 65, 70, 73

9

Monitor ........................................................................6

10

Speaker

11

Tripod socket..................................................

F18

12

Battery-chamber/

memory card slot cover.......................... 10, 14

13

Power connector cover (for connection with optional AC adapter)....................

E80

Attaching the Camera Strap

3

4

Using Menus (the

d Button)

Use the multi selector and the k button to navigate the menus.

1

Press the d button.

The menu is displayed.

2

Press the multi selector

J.

The current menu icon is displayed in yellow.

Shooting menu

Image mode

White balance

Continuous

ISO sensitivity

Color options

AF area mode

Autofocus mode

Menu icons

4

Press the k button.

The menu options become selectable.

3

Select the desired menu icon.

The menu is changed.

Set up

Welcome screen

Time zone and date

Monitor settings

Print date

Photo VR

Motion detection

AF assist

Welcome screen

Time zone and date

Monitor settings

Print date

Photo VR

Motion detection

AF assist

5

Select a menu option.

Welcome screen

Time zone and date

Monitor settings

Print date

Photo VR

Motion detection

AF assist

7

Select a setting.

Photo VR

On

Off

6

Press the k button.

The settings for the option you selected are displayed.

Photo VR

On

Off

8

Press the k button.

The setting you selected is applied.

When you are finished using the menu, press the d button.

C

Setting Menu Options

Certain menu options cannot be set depending on the current shooting mode or the state of the camera. Unavailable options are displayed in gray and cannot be selected.

When a menu is displayed, you can switch to shooting mode by pressing the shutter-release button, A (shooting mode) button, or b (e movie-record) button.

5

6

The Monitor

The information that is displayed in the monitor during shooting and playback changes depending on the camera’s settings and state of use.

By default, information is displayed when the camera is turned on and when you operate the camera, and turns off after a few seconds (when Photo info is set to Auto info in Monitor

settings (

A73)).

Shooting Mode

38

37

36

33

35

34

32

1

2

3

4

5 6

7

8

31

29

30

9

10 11 12

28

27

13

14

26

15

25

22 17 16

24

23 21 20 19 18

1

Shooting mode

...................22, 33, 38, 40, 42

2

Flash mode............................................................. 45

3

Macro mode .......................................................... 49

4

Zoom indicator ............................................ 25, 49

5

Focus indicator .................................................... 26

6

AE/AF-L indicator...........................................

E4

7

Movie options.......................................70,

E56

8

Image mode ..........................................54,

E28

9

Photo VR icon .......................................73,

E65

10

Movie VR icon .......................................70,

E58

11

Motion detection icon ....................73,

E66

12

Wind noise reduction ......................70,

E58

13

Exposure compensation value .................. 50

14

Movie length ......................................................... 67

15

Number of exposures remaining

(still images) ...........................................20,

E29

16

Internal memory indicator............................ 20

17

Aperture value...................................................... 27

18

Focus area (target finding AF) ....60,

E39

19

20

Focus area (for manual or center)

...............................................................................

E38

Focus area (face detection, pet detection)

....................................................... 37, 40, 58,

E37

21

Focus area (subject tracking)..............

E38

22

Shutter speed........................................................ 27

23

ISO sensitivity ........................................54,

E35

24

Battery level indicator ...................................... 20

25

Print date..................................................73,

E64

26

“Date not set” indicator...................................16

27

Eye-Fi communication indicator

........................................................................74,

E73

28

Travel destination ......................................

E60

29

White balance mode........................54,

E30

30

Skin softening .......................................55,

E42

31

Color options.........................................54,

E36

32

Quick effects icon .......................43, 54,

E41

33

Continuous shooting mode

........................................................................54,

E33

34

Blink proof ...............................................55,

E44

35

Hand-held/tripod ............................................... 34

36

Self-timer indicator ............................................ 47

37

Smile timer..............................................55,

E43

38

Pet portrait auto release ......................... 37, 47

7

8

Playback Mode

1 2 3

4 5 6 7 8 9 10

11

12 13

999 / 999

9999 / 9999

29m00s

29m00s

a b

25

24 a b

23

9999. JPG

15 / 05 / 2014 15:30

22 21

20 19 18

14 15

16

17

1

Album icon in favorite pictures mode...............................

E5

2

Category icon in auto sort mode ...............................................

E9

3

List by date icon ..........................................

E10

4

Protect icon............................................65,

E50

5

Print order icon ....................................65,

E45

6

Voice memo icon ...............................65,

E53

7

Glamour retouch icon .....................65,

E15

8

Quick effects icon...............................29,

E12

9

D-Lighting icon....................................65,

E13

10

Quick retouch icon............................65,

E13

11

Red-eye correction icon.................65,

E14

12

Internal memory indicator

13

a Current frame number/ total number of frames

b Movie length

14

Image mode ..........................................54,

E28

15

Movie options.......................................70,

E56

16

Small picture icon...............................65,

E17

17

Crop icon .................................................63,

E18

18

Volume indicator ................................................ 71

19

Quick effects guide

20

Movie playback guide

21

Time of recording

22

Date of recording

23

a Battery level indicator..................................20

b Charging AC Adapter connection indicator

24

File number and type..............................

E79

25

Eye-Fi communication indicator

........................................................................74,

E73

9

The Basics of Shooting and Playback

Preparation 1 Insert the Battery

1

Open the battery-chamber/memory card slot cover.

2

Insert the battery.

Push the orange battery latch in the direction indicated by the arrow (

1), and fully insert the battery (2).

The battery locks into place when inserted correctly.

Battery latch

10

B

Be Careful to Insert the Battery in Correct

Direction

Inserting the battery upside down or backwards could damage the camera.

3

Close the battery-chamber/memory card slot cover.

Removing the Battery

Turn the camera off and make sure that the power-on lamp and monitor have turned off, and then open the batterychamber/memory card slot cover.

Move the battery latch in the direction indicated by the arrow

(

1) to eject the battery (2).

B

High Temperature Caution

The camera, battery, and memory card may be hot immediately after using the camera.

11

12

Preparation 2 Charge the Battery

1

Prepare the included Charging AC Adapter.

If a plug adapter* is included with your camera, attach the plug adapter to the plug on the Charging AC Adapter. Push the plug adapter firmly until it is securely held in place. Once the two are connected, attempting to forcibly remove the plug adapter could damage the product.

* The shape of the plug adapter varies according to the country or region in which the camera was purchased. This step can be omitted if the plug adapter comes permanently bonded to the Charging AC

Adapter.

2

Make sure the battery is installed in the camera, and then connect the camera to the Charging AC Adapter in order of

1 to 3.

Keep the camera turned off.

Make sure that the plugs are properly oriented. Do not insert or remove the plugs at an angle when connecting or disconnecting them.

Charge lamp

Electrical outlet

USB cable

(included)

The charge lamp slowly flashes green to indicate that the battery is charging.

Shooting is not possible while the camera is connected to the Charging AC Adapter.

Charge lamp

Flashes slowly

(green)

Off

Flashes quickly

(green)

Description

The battery is charging.

When charging is complete, the charge lamp stops flashing green and turns off. About 2 hours and 40 minutes are required to charge a fully exhausted battery.

The ambient temperature is not suited to charging. Charge the battery indoors with an ambient temperature of 5°C to 35°C (41°F to 95°F).

The USB cable or Charging AC Adapter is not properly connected, or there is a problem with the battery. Disconnect the USB cable or unplug the Charging AC Adapter and correctly connect it again, or change the battery.

3

Disconnect the Charging AC Adapter from the electrical outlet and then disconnect the USB cable.

C

Charging Using a Computer or Battery Charger

You can also charge the battery by connecting the camera to a computer (A74, E71).

You can use the Battery Charger MH-66 (available separately; E80) to charge the battery without using the camera.

13

Preparation 3 Insert a Memory Card

1

Turn off the camera and open the batterychamber/memory card slot cover.

2

Insert the memory card.

Slide the memory card in until it clicks into place.

Memory card slot

14

B

Be Careful to Insert the Memory Card in Correct

Direction

Inserting the memory card upside down or backwards could damage the camera and memory card.

3

Close the battery-chamber/memory card slot cover.

B

Formatting a Memory Card

The first time you insert a memory card that has been used in another device into this camera, make sure to format it with this camera. Insert the memory card into the camera, press the d button, and select Format card in the setup menu.

Removing the Memory Card

Turn the camera off and make sure that the power-on lamp and monitor have turned off, and then open the batterychamber/memory card slot cover.

Gently push the memory card into the camera (

1) to partially eject the card (

2).

B

High Temperature Caution

The camera, battery, and memory card may be hot immediately after using the camera.

Internal Memory and Memory Cards

Camera data, including images and movies, can be saved either in the camera’s internal memory or on a memory card. To use the camera’s internal memory, first remove the memory card.

15

16

Preparation 4 Setting the Display Language, Date, and Time

When the camera is turned on for the first time, the language-selection screen and the date and time setting screen for the camera clock are displayed.

If you exit without setting the date and time, O will flash when the shooting screen is displayed.

1

Press the power switch to turn on the camera.

2

Use the multi selector

HI to select the desired language and press the k button.

3

Select Yes and press the k button.

Language

Choose time zone and set date and time?

Yes

No

4

Select your home time zone and press the k button.

To enable daylight saving time, press H.

When the daylight saving time function is enabled, W is displayed above the map. To disable the daylight saving time function, press

I.

5

Select the date format and press the k button.

London, Casablanca

6

Set the date and time, and press the k button.

Select a field: Press JK (changes between D, M, Y, hour, and minute).

Edit the date and time: Press HI.

Confirm the settings: Select the minute field and press the k button.

7

Select Yes and press the k button.

When settings are finished, the lens extends and the camera switches to shooting mode.

Date format

Year/Month/Day

Month/Day/Year

Day/Month/Year

Date and time

D M Y h m

0 1 0 1

2 0 1 4

0 0 0 0

Edit

Date and time

15/05/2014 15 : 30

OK?

2 0 1 4 0 1 0 1

Yes

No

0 0 0 0

Edit

17

18

C

Changing the Language or the Date and Time Setting

You can change these settings using the Language and Time zone and date settings in the

z setup menu (A73).

You can enable or disable daylight saving time in the z setup menu by selecting Time zone and

date followed by Time zone. Press the multi selector

K and then H to enable daylight saving time and move the clock forward one hour, or

I to disable daylight saving time and move the clock back one hour.

C

The Clock Battery

The camera’s clock is powered by a built-in backup battery.

The backup battery charges when the main battery is inserted into the camera or when the camera is connected to an optional AC adapter, and it can run the clock for several days after about ten hours of charging.

If the camera’s backup battery becomes exhausted, the date and time setting screen is displayed

when the camera is turned on. Set the date and time again. See step 3 (

A16) of “Preparation 4

Setting the Display Language, Date, and Time” for more information.

C

Imprinting the Shooting Date on Printed Images

You can permanently imprint the shooting date on images as they are captured by setting Print

date in the setup menu (

A73).

You can use the ViewNX 2 software (A77) to print the shooting date on images that were

captured without using the Print date option.

19

20

Step 1 Turn the Camera On

1

Press the power switch.

The monitor turns on.

To turn the camera off, press the power switch again.

2

Check the battery level indicator and the number of exposures remaining.

Battery Level Indicator

Number of exposures remaining

Display Description b

The battery level is high.

B

The battery level is low.

P

Battery exhausted.

The camera cannot capture images.

Recharge the battery.

Battery level indicator

Number of Exposures Remaining

The number of images that can be taken is displayed.

C is displayed when no memory card is inserted in the camera, and images are saved in the internal memory.

C

The Auto Off Function

Flashes

No operations performed

No operations performed

Camera enters standby mode.

3 min

Camera turns off.

The time that elapses before the camera enters standby mode is about one minute. The time can

be changed using the Auto off setting in the setup menu (

A73).

While the camera is in standby mode, the monitor turns back on if you perform any of the following operations:

- Press the power switch, shutter-release button, A (shooting mode) button, c (playback) button, or b (e movie-record) button.

21

22

Step 2 Select a Shooting Mode

1

Press the A button.

2

Use the multi selector

HI to select a shooting mode and press the k button.

x (scene auto selector) mode is used in this example.

The shooting mode setting is saved even after the camera is turned off.

Scene auto selector

Available Shooting Modes

x b

D

F

A

Scene auto selector

Scene

A32

The camera automatically selects the optimum scene mode when you frame an image, making it even easier to take images using settings that suit the scene.

A33

Camera settings are optimized according to the scene that you select.

Special effects

A38

Effects can be applied to images during shooting.

Smart portrait

A40

When the camera detects a smiling face, you can take an image automatically without pressing the shutter-release button (smile timer). You can also use the skin softening option to smooth the skin tones of human faces.

Auto mode

A42

Used for general shooting. Settings can be adjusted to suit the shooting conditions and the type of shot you want to capture.

23

Step 3 Frame a Picture

1

Hold the camera steady.

Keep fingers and other objects away from the lens, flash, AF assist-illuminator, microphone, and speaker.

When taking pictures in portrait (“tall”) orientation, turn the camera so that the flash is above the lens.

2

Frame the picture.

When the camera automatically determines the scene mode, the shooting mode icon changes (

A32).

Shooting mode icon

24

B

Notes About x (Scene Auto Selector) Mode

Depending upon shooting conditions, the camera may not select the desired scene mode. In this

case, select another shooting mode (

A33, 38, 40, 42).

When the digital zoom is in effect, the scene mode changes to d.

C

When Using a Tripod

We recommend using a tripod to stabilize the camera in the following situations:

- When shooting in dim lighting

- When shooting with the flash mode (

A46) set to W (off)

- When using the telephoto setting

When using a tripod to stabilize the camera during shooting, set Photo VR to Off in the setup

menu (

A73) to prevent potential errors caused by this function.

Using the Zoom

When you move the zoom control, the zoom lens position changes.

To zoom in closer to the subject: Move toward g (telephoto).

To zoom out and view a larger area: Move toward f (wideangle).

When you turn the camera on, the zoom moves to the maximum wide-angle position.

Zoom out

Zoom in

A zoom indicator is displayed at the top of the monitor when the zoom control is moved.

Digital zoom, which allows you to further magnify the subject up to approximately 4× the maximum optical zoom ratio, can be activated by moving and holding the zoom control toward g when the camera is zoomed in to the maximum optical zoom position.

Optical zoom

Digital zoom

C

Notes About Digital Zoom

The zoom indicator turns blue when the digital zoom is activated, and it turns yellow when the zoom magnification is increased further.

Zoom indicator is blue: Image quality is not noticeably reduced by using the Dynamic Fine Zoom.

Zoom indicator is yellow: Image quality is noticeably reduced.

The indicator remains blue across a wider area when the image size is smaller.

The zoom indicator may not turn blue when using certain continuous shooting settings.

25

26

Step 4 Focus and Shoot

1

Press the shutter-release button halfway.

When the subject is in focus, the focus area glows green (multiple focus areas can glow green).

When you are using digital zoom, the camera focuses in the center of the frame and the focus area is not displayed. When the camera has focused, the focus indicator (

A7) glows

green.

If the focus area or focus indicator flashes, the camera is unable to focus. Modify the composition and try pressing the shutterrelease button halfway again.

2

Without lifting your finger, press the shutterrelease button the rest of the way down.

The Shutter-release Button

Press halfway

Press all the way

To set focus and exposure (shutter speed and aperture value), press the shutter-release button lightly until you feel a slight resistance. Focus and exposure remain locked while the shutterrelease button is pressed halfway.

Press the shutter-release button all the way to release the shutter and take an image.

Do not use force when pressing the shutter-release button, as this may result in camera shake and blurred images. Press the button gently.

B

Notes About Saving Images and Recording Movies

The indicator showing the number of exposures remaining or the indicator showing the maximum movie length flashes while images are being saved or while a movie is being recorded. Do not open

the battery-chamber/memory card slot cover or remove the battery or memory card while an indicator is flashing. Doing this could result in loss of data, or in damage to the camera or the memory card.

27

28

Step 5 Play Back Images

1

Press the c (playback) button.

If you press and hold down the c (playback) button while the camera is turned off, the camera turns on in playback mode.

2

Use the multi selector to select an image to display.

Press and hold down HIJK to scroll through the images quickly.

Display the previous image

Display the next image

To return to shooting mode, press the A button or shutter-release button.

0004. JPG

15 / 05 / 2014 15:30

C

The Quick Effects Function

When e is displayed in full-frame playback mode, you can press the k button to apply an effect to the image.

When the effect selection screen is displayed, use the multi selector

HIJK to select an effect, press the k button, and then select Yes in the confirmation dialog and press the k button to save the image as a separate file.

See “Quick Effects: Changing Hue or Mood” (

E12) for more information.

0004. JPG

15 / 05 / 2014 15:30

29

30

Step 6 Delete Images

1

Press the l button to delete the image currently displayed in the monitor.

2

Use the multi selector

HI to select the desired deletion method and press the k button.

To exit without deleting, press the d button.

3

Select Yes and press the k button.

Deleted images cannot be recovered.

To cancel, select No and press the k button.

Delete

Current image

Erase selected images

All images

Erase 1 image?

Yes

No

Operating the Erase Selected Images Screen

1

Use the multi selector

JK to select an image to be deleted, and then use

H to display K.

To undo the selection, press I to remove K.

Move the zoom control (A1) toward g (i) to switch to

full-frame playback or f (h) to switch to thumbnail playback.

Erase selected images

2

Add K to all images that you want to delete and then press the k button to confirm the selection.

A confirmation dialog is displayed. Follow the on-screen instructions to complete operations.

C

Deleting the Last Image Captured while in Shooting Mode

When using shooting mode, press the l button to delete the last image that was saved.

31

Shooting Features

x (Scene Auto Selector) Mode

The camera automatically selects the optimum scene mode when you frame an image, making it even easier to take images using settings that suit the scene.

Enter shooting mode

M A (shooting mode) button M x (scene auto selector) M k button

32

When the camera selects a scene mode, the shooting mode icon displayed in the shooting screen changes to that for the scene mode currently enabled.

e b f h c g i j d d

Portrait (for taking close-up portraits of one or two people)

Portrait (for taking portraits of three or more people, or images in which a large background takes up the frame)

Landscape

Night portrait (for taking close-up portraits of one or two people)

Night portrait (for taking portraits of three or more people, or images in which a large background takes up the frame)

Night landscape

Close-up

Backlighting (for taking images of subjects other than people)

Backlighting (for taking portrait images)

Other scenes

Functions Available in x (Scene Auto Selector) Mode

Flash mode (A45)

Self-timer (A47)

Exposure compensation (A50)

Scene Mode (Shooting Suited to Scenes)

When a scene is selected, camera settings are automatically optimized for the selected scene.

Enter shooting mode

M A (shooting mode) button M b (second icon from the top*)

M K M HI M select a scene M k button

* The icon for the last scene selected is displayed.

b Portrait

(default setting) c Landscape

1

Z Beach

2 d Sports

2

(

A34)

z Snow

2 f Party/indoor

2

(

A34)

i Dusk/dawn 1, 3 l Museum

(

A35)

2 j Night landscape

(

A34)

1, 3 m Fireworks show

1, 3

(

A35)

k Close-up

(

A35)

n Black and white copy

2

(

A35)

e Night portrait h Sunset

2, 3 u Food

(

A35)

o Backlighting

(

A36)

2

3

1

2

3

U Panorama assist

(

A36)

O Pet portrait

(

A37)

The camera focuses at infinity.

The camera focuses on the area in the center of the frame.

Use of a tripod is recommended, because the shutter speed is slow. Set Photo VR to Off in the

setup menu (

A73) when using a tripod to stabilize the camera during shooting.

Displaying a Description of Each Scene Mode (Help Display)

Select a scene and move the zoom control (

A1) toward g (j) to

view a description of that scene. To return to the original screen, move the zoom control toward g (j) again.

Panorama assist

33

34

Tips and Notes

d Sports

While the shutter-release button is held all the way down, the camera shoots up to about 6 images continuously at a rate of about 1.1 fps (when image mode is set to x).

The frame rate for continuous shooting may vary depending on the current image mode setting, the memory card used, or shooting conditions.

Focus, exposure, and hue are fixed at the values determined with the first image in each series.

f Party/indoor

To avoid the effects of camera shake, hold the camera steady. Set Photo VR to Off in the setup menu (

A73) when using a tripod to stabilize the camera during shooting.

j Night landscape

From the screen displayed after j Night landscape is selected, select u Hand-held or w

Tripod.

u Hand-held (default setting): Select this option to produce shots with reduced blurring and noise even when the camera is hand-held.

w Tripod: Select this option when using a tripod or other means to stabilize the camera when shooting.

- Vibration reduction is disabled even when Photo VR (

A73) in the setup menu is set to On.

k Close-up

Macro mode (A49) is enabled and the camera automatically zooms to the closest position at

which it can focus.

You can move the focus area. Press the k button, use the multi selector HIJK to move the focus area, and press the k button to apply the setting.

u Food

Macro mode (A49) is enabled and the camera automatically zooms to the closest position at

which it can focus.

You can adjust hue by using the multi selector HI. The hue setting is saved in the camera’s memory even after the camera is turned off.

You can move the focus area. Press the k button, use the multi selector

HIJK to move the focus area, and press the k button to apply the setting.

l Museum

The camera captures a series of up to ten images while the shutter-release button is held all the way down, and the sharpest image in the series is automatically selected and saved (BSS (Best

Shot Selector)).

The flash does not fire.

m Fireworks show

The shutter speed is fixed at four seconds.

n Black and white copy

Use with macro mode (A49) when shooting a subject at close distance.

35

36

o Backlighting

The flash always fires.

U Panorama assist

You can use this mode when shooting a series of images that can later be joined on a computer to form a single panorama.

Select the direction in which to add images to the panorama by using the multi selector

HIJK and then press the k button.

After taking the first image, take the additional shots needed while checking how each image will connect to the next. To finish shooting, press the k button.

Transfer the images to a computer and use Panorama Maker (A79) to join them into a single

panorama.

See “Using Panorama Assist” (

E2) for more information.

O Pet portrait

When you point the camera at a dog or cat, the camera detects the pet’s face and focuses on it.

By default, the camera detects a dog or cat face and automatically releases the shutter (pet portrait auto release).

On the screen displayed when O Pet portrait is selected, select U Single or V Continuous.

- U Single: The camera captures one image when a dog or cat face is detected.

- V Continuous: The camera captures three images continuously when a dog or cat face is detected.

B

Pet Portrait Auto Release

Press the multi selector J (n) to change the Pet portrait auto release setting.

- Y: The camera detects a dog or cat face and automatically releases the shutter.

- OFF: The camera does not release the shutter automatically, even if a dog or cat face is detected.

Press the shutter-release button. The camera also detects human faces when OFF is selected.

• Pet portrait auto release is set to OFF after five bursts have been taken.

Shooting is also possible by pressing the shutter-release button, regardless of the Pet portrait

auto release setting. When V Continuous is selected, you can take images continuously while holding down the shutter-release button all the way.

B

Focus Area

When the camera detects a face, the face is displayed inside a yellow border. When the camera acquires focus on a face displayed inside a double border (focus area), the double border turns green. If no faces are detected, the camera focuses on the subject in the center of the frame.

Under some shooting conditions, the pet face may not be detected and other subjects may be displayed inside a border.

37

38

Special Effects Mode (Applying Effects When Shooting)

Effects can be applied to images during shooting.

Enter shooting mode

M A (shooting mode) button M D (third icon from the top*) M

K M HI M select an effect M k button

* The icon of the last effect selected is displayed.

Category

D Soft

(default setting)

E Nostalgic sepia

F High-contrast monochrome

G High key

H Low key

I Selective color l Pop k Super vivid h Painting

Description

Softens the image by adding a slight blur to the entire image.

Adds a sepia tone and reduces the contrast to simulate the qualities of an old photograph.

Changes the image to black and white and gives it sharp contrast.

Gives the entire image a bright tone.

Gives the entire image a dark tone.

Creates a black and white image in which only the specified color remains.

Increases the color saturation of the entire image to create a bright look.

Increases the color saturation of the entire image and sharpens the contrast.

Gives the image a painting-like appearance.

Category m

Toy camera effect 1 n

Toy camera effect 2 o Cross process

Description

Gives the entire image a yellowish hue and darkens the image periphery.

Decreases the color saturation of the entire image and darkens the image periphery.

Gives the image a mysterious appearance based on a specific color.

The camera focuses on the area in the center of the frame.

When Selective color or Cross process is selected, use the multi selector

HI to select the desired color from the slider.

To change settings for any of the following functions, press the k button to cancel color selection.

- Flash mode (

A45)

- Self-timer (

A47)

- Macro mode (

A49)

- Exposure compensation (

A50)

To return to the color selection screen, press the k button again.

Save

Slider

39

40

Smart Portrait Mode (Capturing Images of Smiling

Faces)

When the camera detects a smiling face, you can take an image automatically without

pressing the shutter-release button (smile timer (

A55)). You can use the skin softening

option to smooth the skin tones of human faces.

Enter shooting mode

M A (shooting mode) button M F Smart portrait M k button

1

Frame the picture.

Point the camera at a human face.

2

Without pressing the shutter-release button, wait for the subject to smile.

If the camera detects that the face framed by the double border is smiling, the shutter is automatically released.

Whenever the camera detects a smiling face, it automatically releases the shutter.

3

End automatic shooting.

Perform one of the operations listed below to end shooting.

- Set Smile timer to Off.

- Press the A button and select a different shooting mode.

B

Notes About Smart Portrait Mode

Under some shooting conditions, the camera may be unable to detect faces or smiles (

A58). The

shutter-release button can also be used for shooting.

C

When the Self-timer Lamp Flashes

When using smile timer, the self-timer lamp flashes when the camera detects a face and flashes quickly immediately after the shutter is released.

Functions Available in Smart Portrait Mode

Flash mode (A45)

Self-timer (A47)

Exposure compensation (A50)

Smart portrait menu (A53)

41

42

A (Auto) Mode

Used for general shooting. Settings can be adjusted to suit the shooting conditions and the type of shot you want to capture.

Enter shooting mode

M A (shooting mode) button M A (auto) mode M k button

You can change how the camera selects the area of the frame to focus on by changing AF

area mode setting (

A54). The default setting is Target finding AF (A60).

Functions Available in A (Auto) Mode

Flash mode (A45)

Self-timer (A47)

Macro mode (A49)

Exposure compensation (A50)

Shooting menu (A54)

Using Quick Effects

When in A (auto) mode, you can apply effects to images immediately after releasing the shutter.

The edited image is saved as a separate file with a different name.

1

Press the k button when the image is displayed after it is taken in A (auto) mode.

When you press the d button or when no operations are performed for about five seconds, the monitor display returns to the shooting screen.

To not display the screen shown on the right, set Quick

effects to Off in the shooting menu (

A54).

Quick effects

Cancel Choose effect

2

Use the multi selector

HIJK to select the desired effect and press the k button.

Quick effects

Move the zoom control (A1) toward g (i) to switch to

full-frame playback or f (h) to switch to thumbnail playback.

Pop Super vivid Painting

To exit without saving the edited image, press the d button. When a confirmation dialog is displayed, select Yes and press the k button.

Photo illustration

Cancel

High key Toy camera effect 1

See “Quick Effects: Changing Hue or Mood” (E12) for information about the effect types.

3

Select Yes and press the k button.

43

44

Functions That Can Be Set Using the Multi Selector

The functions that are available vary depending on the shooting mode, as shown below.

1

2

3

4

1

X Flash mode (A45)

2

n Self-timer (A47)

3

p Macro mode (A49)

4 o

Exposure compensation

(

A50)

x

(scene auto selector) w w

– w

* Availability depends on the setting.

Scene

*

Special effects w w w w

Smart portrait w

*

w

*

– w

A (auto) mode w w w w

Using the Flash

You can select a flash mode to match the shooting conditions.

1

Press the multi selector

H (m).

2

Select the desired flash mode (

A46) and

press the k button.

If a setting is not applied by pressing the k button within a few seconds, the selection will be canceled.

Auto

B

The Flash Lamp

The status of the flash can be confirmed by pressing the shutterrelease button halfway.

- On: The flash fires when you press the shutter-release button all the way down.

- Flashing: The flash is charging. The camera cannot shoot images.

- Off: The flash does not fire when an image is taken.

If the battery level is low, the monitor turns off while the flash is charging.

45

Available Flash Modes

U

Auto

The flash fires when necessary, such as in dim lighting.

The flash mode icon on the shooting screen is displayed only immediately after the setting is made.

V

Auto with red-eye reduction

Reduce “red-eye” in portraits caused by the flash.

W

Off

The flash does not fire.

We recommend using a tripod to stabilize the camera when shooting in dark surroundings.

X

Fill flash

The flash fires whenever an image is taken. Use to “fill-in” (illuminate) shadows and backlit subjects.

Y

Slow sync

Suited to evening and night portraits that include background scenery. The flash fires when necessary to illuminate the main subject; slow shutter speeds are used to capture background at night or under dim lighting.

46

C

The Flash Mode Setting

The setting may not be available with some shooting modes.

The setting applied in A (auto) mode is saved in the camera’s memory even after the camera is turned off.

C

Red-eye Reduction

If the camera detects red eye while saving an image, the affected area is processed to reduce red-eye before the image is saved.

Note the following when shooting:

More time than usual is required to save images.

Red-eye reduction may not produce the desired results in some situations.

In some rare cases, red-eye reduction may be applied unnecessarily to other areas of the image. In these cases, select another flash mode and take the image again.

Using the Self-timer

The camera is equipped with a self-timer that releases the shutter about ten seconds or two seconds after you press the shutter-release button.

Set Photo VR to Off in the setup menu (

A73) when using a tripod to stabilize the camera

during shooting.

1

Press the multi selector

J (n).

2

Select n10s or n2s, and press the k button.

Self-timer

n10s (ten seconds): Use on important occasions, such as weddings.

n2s (two seconds): Use to prevent camera shake.

If a setting is not applied by pressing the k button within a few seconds, the selection will be canceled.

When the shooting mode is Pet portrait scene mode, Y

(pet portrait auto release) is displayed (

A37). The self-timer cannot be used.

3

Frame the picture and press the shutter-release button halfway.

Focus and exposure are set.

47

48

4

Press the shutter-release button the rest of the way down.

Countdown starts. The self-timer lamp flashes and then glows steadily about one second before the shutter is released.

When the shutter is released, the self-timer is set to OFF.

To stop the countdown, press the shutterrelease button again.

99

Using Macro Mode

Use macro mode when taking close-up images.

1

Press the multi selector

I (p).

2

Select ON and press the k button.

If the setting is not applied by pressing the k button within a few seconds, the selection will be canceled.

Macro mode

3

Move the zoom control to set the zoom ratio to a position where F and the zoom indicator glow green.

When the zoom ratio is set to a position where the zoom indicator glows green, the camera can focus on subjects as close as approximately 30 cm (1 ft) from the lens. When the zoom is at the position where G is displayed, the camera can focus on subjects as close as approximately 5 cm (2 in.) from the lens.

B

Notes About Using the Flash

The flash may be unable to light the entire subject at distances of less than 50 cm (1 ft 8 in.).

C

The Macro Mode Setting

The setting may not be available with some shooting modes.

The setting applied in A (auto) mode is saved in the camera’s memory even after the camera is turned off.

49

50

Adjusting Brightness (Exposure Compensation)

You can adjust overall image brightness.

1

Press the multi selector

K (o).

2

Select a compensation value and press the k button.

To brighten the image, set a positive (+) value.

To darken the image, set a negative (–) value.

The compensation value is applied, even without pressing the k button.

Exposure compensation

+

2

.

0

+

0

.

3

-

2

.

0

C

Exposure Compensation Value

The setting applied in A (auto) mode is saved in the camera’s memory even after the camera is turned off.

Default Settings

Default settings for each shooting mode are described below.

Flash mode

(

A45)

x (scene auto selector) U

1

Scene b (portrait) c (landscape) d (sports) e (night portrait) f (party/indoor)

Z (beach) z (snow) h (sunset) i (dusk/dawn)

U

U

W

2

W

2 j (night landscape) W

2 k (close-up) W u (food) l (museum)

W

2

W

2

W

2 m (fireworks show) n (black and white copy)

W

V

W

2

W

2

V

3

V

4

Off

Self-timer

(

A47)

Off

Off

Off

Off

Off

Off

Off

2

Off

Off

Off

Off

Off

Off

Off

2

Off

Macro mode

(

A49)

Off

2

Exposure compensation

(

A50)

0.0

Off

2

Off

2

Off

2

Off

2

Off

2

Off

2

Off

2

Off

2

Off

2

Off

2

On

2

On

2

Off

Off

2

Off

0.0

0.0

0.0

0.0

0.0

0.0

0.0

2

0.0

0.0

0.0

0.0

0.0

0.0

0.0

0.0

51

52

Flash mode

(

A45)

Self-timer

(

A47)

Macro mode

(

A49)

Exposure compensation

(

A50) o (backlighting)

U (panorama assist)

W

O (pet portrait) W

2

D (special effects)

F (smart portrait)

A (auto)

X

2

W

U

U

Off

Off

Y

Off

Off

Off

5

Off

Off

Off

Off

Off

Off

2

2

0.0

0.0

0.0

0.0

0.0

0.0

4

5

1

2

3

U (auto flash) or W (off) can be selected. When U (auto flash) is selected, the camera automatically selects the flash mode appropriate for the scene it has been selected.

The setting cannot be changed.

The setting cannot be changed. The flash mode setting is fixed at the fill flash with slow sync and red-eye reduction.

Slow sync with red-eye reduction flash mode may be used.

Self-timer cannot be used. Pet portrait auto release can be turned on or off (

A37).

Functions That Can Be Set with the

d Button (Shooting Menu)

The settings listed below can be changed by pressing the

d button during shooting (A4).

8m 0s

1400

Image mode

White balance

Continuous

ISO sensitivity

Color options

AF area mode

Autofocus mode

The settings that can be changed vary depending on the shooting mode, as shown below.

Image mode

1

White balance

Scene auto selector w

Scene w

2

Special effects w

Smart portrait w

Auto mode w w

Continuous

ISO sensitivity

– w w

Color options

AF area mode

– w w

Autofocus mode

Quick effects

Skin softening

– w w w

Smile timer

Blink proof

– w w

1

2

The setting is also applied to other shooting modes.

Additional settings are available for some scene modes. See “Tips and Notes” (

A34) for more

information.

53

54

Options Available in the Shooting Menu

Option

Image mode

White balance

Continuous

ISO sensitivity

Color options

AF area mode

Autofocus mode

Quick effects

Description

Allows you to set the combination of image size and image quality used when saving images.

Default setting: x 5152×3864

Allows you to adjust white balance to suit the weather conditions or light source in order to make the colors in images match what you see with your eyes.

Default setting: Auto

Allows you to select single or continuous shooting.

Default setting: Single

Allows you to control the camera’s sensitivity to light.

Default setting: Auto

When Auto is selected, E is displayed in the monitor while shooting if ISO sensitivity increases.

Allows you to change the color tones of images.

Default setting: Standard color

Allows you to determine how the camera selects the focus area that is used for autofocus.

Default setting: Target finding AF (A60)

Allows you to select either Single AF, which focuses only when the shutter-release button is pressed halfway, or Full-

time AF, which continues focusing even when the shutterrelease button is not pressed halfway.

Default setting: Single AF

Allows you to enable or disable the quick effects function

(

A43).

Default setting: On

A

E28

E30

E33

E35

E36

E37

E41

E41

Option

Skin softening

Smile timer

Blink proof

Description

Allows you to select the skin softening level for human faces.

Default setting: Normal

Allows you to select whether or not the camera automatically releases the shutter when it detects a human smiling face.

Default setting: On

The camera automatically releases the shutter twice with every shot and saves one image in which the subject’s eyes are open.

Default setting: Off

A

E42

E43

E44

55

56

Functions That Cannot Be Used Simultaneously

Some functions cannot be used with other menu options.

Restricted function Option

Continuous (

A54)

Flash mode

Blink proof (

A55)

Self-timer

Macro mode

Image mode

White balance

ISO sensitivity

AF area mode

AF area mode

(

A54)

Smile timer (

A55)

AF area mode

(

A54)

Continuous (

A54)

ISO sensitivity

(

A54)

Color options

(

A54)

Continuous (

A54)

Digital zoom

(

A74)

Description

When a setting other than Single is selected, the flash cannot be used.

When Blink proof is set to On, the flash cannot be used.

When Subject tracking is selected, self-timer cannot be used.

When Smile timer is selected, the self-timer cannot be used.

When Subject tracking is selected, macro mode cannot be used.

When Multi-shot 16 is selected, the Image mode setting is fixed at L (image size: 2560 × 1920 pixels).

When 3200 is selected, the image mode setting of only r 2272×1704, q 1600×1200, or

O 640×480 can be selected. If any image mode setting other than above is selected, the image mode setting is automatically changed to r 2272×1704 when ISO sensitivity is set to

3200.

When Black-and-white, Sepia, or Cyanotype is selected, the White balance setting is fixed at Auto.

When Multi-shot 16 is selected, the ISO sensitivity setting is fixed at Auto.

When digital zoom is in effect, the camera focuses in the center of the frame regardless of the AF area

mode setting.

Restricted function

Quick effects

Monitor settings

Motion detection

Digital zoom

Shutter sound

Blink warning

(

Option

Continuous (

A54)

Quick effects

A54)

Continuous (

A54)

ISO sensitivity

(

A54)

AF area mode

(

A54)

Continuous (

A54)

AF area mode

(

A54)

Continuous (

A54)

Continuous (

A54)

Description

Quick effects cannot be applied to images immediately after they are taken with continuous shooting.

When Quick effects is set to On while shooting still images, the captured image is displayed after shooting, regardless of the Image review setting.

When Multi-shot 16 is selected, Motion detection is disabled.

When a setting other than Auto is selected, Motion

detection is disabled.

When Subject tracking is selected, Motion

detection is disabled.

When Multi-shot 16 is selected, digital zoom cannot be used.

When Subject tracking is selected, digital zoom cannot be used.

When a setting other than Single is selected, the shutter sound is disabled.

When a setting other than Single is selected, Blink

warning is disabled.

B

Notes About Digital Zoom

Depending on the shooting mode or the current settings, digital zoom may not be available

(

E67).

When digital zoom is in effect, the camera focuses in the center of the frame.

57

58

Focusing

The focus area varies depending on the shooting mode.

Using Face Detection

When the camera is pointed at a human face in the shooting modes as shown below, the camera automatically detects the face and focuses on it.

e/b Portrait, h/c Night portrait, or d

Backlighting in x (scene auto selector) mode (

A32)

• Portrait or Night portrait in scene mode (A33)

Smart portrait mode (A40)

When AF area mode (A54) is set to Face priority in A

(auto) mode (

A42)

When the camera detects more than one face, the double border (focus area) is displayed around the face that is focused on, and single borders around the others.

If the shutter button is pressed halfway when no faces are detected:

When x (scene auto selector) mode is selected, the focus area changes depending on the scene.

In Portrait and Night portrait scene modes or in smart portrait mode, the camera focuses in the center of the frame.

In A (auto) mode, the camera selects the focus area containing the subject closest to the camera.

B

Notes About Face Detection

The camera’s ability to detect faces depends on a variety of factors, including the direction in which the faces are looking.

The camera may be unable to detect faces in the following situations:

- When faces are partially hidden by sunglasses or otherwise obstructed

- When faces take up too much or too little of the frame

Using Skin Softening

When the shutter is released while using one of the shooting modes listed below, the camera detects human faces and processes the image to soften facial skin tones (up to three faces).

Smart portrait mode (A40)

- The skin softening level can be adjusted.

e Portrait, h Night portrait, or d Backlighting in x (scene auto selector) mode

(

A32)

• Portrait or Night portrait in scene mode (A33)

Editing functions such as Skin softening can be applied to saved images by using Glamour

retouch (

A65) even after shooting.

B

Notes About Skin Softening

It may take more time than usual to save images after shooting.

Under some shooting conditions, the desired skin softening results may not be achieved, and skin softening may be applied to areas of the image where there are no faces.

59

60

Using Target Finding AF

When AF area mode (

A54) in A (auto) mode is set to Target finding AF, the camera

focuses in the manner described below when you press the shutter-release button halfway.

The camera detects the main subject and focuses on it.

When the subject is in focus, the focus area glows green. If a human face is detected, the camera automatically sets focus priority on it.

If no main subject is detected, the camera automatically selects one or more of the nine focus areas containing the subject closest to the camera. When the subject is in focus, the focus areas that are in focus glow green.

Focus areas

Focus areas

B

Notes About Target Finding AF

Depending on shooting conditions, the subject that the camera determines to be the main subject may vary.

The main subject may not be detected when using certain White balance settings.

The camera may not detect the main subject appropriately in the following situations:

- When the subject is very dark or bright

- When the main subject lacks clearly defined colors

- When the shot is framed so that the main subject is at the edge of the monitor

- When the main subject is composed of a repeating pattern

Subjects Not Suitable for Autofocus

The camera may not focus as expected in the following situations. In some rare cases, the subject may not be in focus despite the fact that the focus area or the focus indicator glows green:

Subject is very dark

Objects of sharply differing brightness are included in the scene (e.g. the sun behind the subject makes that subject appear very dark)

No contrast between the subject and surroundings (e.g. a portrait subject wearing a white shirt is standing in front of a white wall)

Several objects are at different distances from the camera (e.g. the subject is inside a cage)

Subjects with repeating patterns (window blinds, buildings with multiple rows of similarly shaped windows, etc.)

Subject is moving rapidly

In the situations noted above, try pressing the shutter-release button halfway to refocus several times, or focus on another subject positioned at the same distance from the camera as

the actual desired subject, and use focus lock (

A62).

61

62

Focus Lock

Focus lock shooting is recommended when the camera does not activate the focus area that contains the desired subject.

1

Set AF area mode to Center in A (auto) mode (

A54).

2

Position the subject in the center of the frame and press the shutterrelease button halfway.

The camera focuses on the subject and the focus area glows green.

Focus and exposure are locked.

3

Without lifting your finger, recompose the picture.

Make sure to maintain the same distance between the camera and the subject.

4

Press the shutter-release button the rest of the way down to take the picture.

Playback Features

Playback Zoom

Moving the zoom control toward

g (i) in full-frame playback mode (A28) zooms in on the

image.

Display area guide g

( i)

0004. JPG

15 / 05 / 2014 15:30

Full-frame Playback f

( h)

Image is zoomed in

You can change the zoom ratio by moving the zoom control toward f (h) or g (i).

To view a different area of the image, press the multi selector HIJK.

If you are viewing an image that was captured using face detection or pet detection, the camera zooms in on the face detected at the time of shooting, except for images captured with Continuous, BSS, Multi-shot 16, or Subject tracking. To zoom in on an area of the image where there are no faces, change the zoom ratio and then, press

HIJK.

When a zoomed image is displayed, press the k button to return to full-frame playback mode.

C

Cropping Images

When a zoomed image is displayed, you can press the d button to crop the image to include only the visible portion and save it as a separate file (

E18).

63

64

Thumbnail Playback/Calendar Display

Moving the zoom control toward

f (h) in full-frame playback mode (A28) displays

images as thumbnails.

f

( h) f

( h)

Sun

44

Mon

55

Tue

2014

Wed

05

Thu

66 77 88

11

Fr i

22

99

Sat

33

44

0004. JPG

15 / 05 / 2014 15:30

Full-frame Playback g

( i)

Thumbnail Playback g

( i)

Calendar display

You can change the number of thumbnails displayed by moving the zoom control toward f (h) or g (i).

While using thumbnail playback mode, press the multi selector HIJK to select an image and then press the k button to display that image in full-frame playback mode.

While using calendar display mode, press HIJK to select a date and then press the k button to display the image captured on that day.

B

Notes About Calendar Display

Images captured when the camera’s date is not set are treated as images captured on January 1,

2014.

Functions That Can Be Set with the

d Button

(Playback Menu)

When viewing images in full-frame playback mode or thumbnail playback mode, you can configure the menu operations listed below by pressing the

d button (A4).

Option

Quick retouch*

D-Lighting*

Red-eye correction*

Glamour retouch*

Print order

Slide show

Protect

Rotate image

Small picture*

Voice memo

Copy

Description

Allows you to create retouched copies in which contrast and saturation have been enhanced.

Allows you to create copies with enhanced brightness and contrast, brightening dark portions of an image.

Corrects “red-eye” that may occur in images when shooting with a flash.

Detects faces in images and retouches the detected faces glamorously.

Allows you to select which images are printed, and how many copies of each image are printed, prior to printing.

Allows you to view images in an automatic slide show.

Protects selected images from accidental deletion.

Allows you to rotate the displayed image to portrait or landscape orientation.

Creates a small copy of images.

Allows you to use the camera’s microphone to record voice memos and attach them to images.

Allows you to copy images between the internal memory and a memory card.

A

E13

E13

E14

E15

E45

E49

E50

E52

E17

E53

E54

65

66

Option

Favorite pictures

Remove from favorites

Description

Allows you to add images to an album.

This option is not displayed in favorite pictures mode.

Allows you to remove images from an album.

This option is displayed only in favorite pictures mode.

* Edited images are saved as separate files. Some images may not be edited.

A

E5

E7

Recording and Playing Back Movies

Recording Movies

1

Display the shooting screen.

Check the remaining amount of movie recording time.

When the Photo info option in Monitor settings (A73)

in the setup menu is set to Movie frame+auto info, the area that will be visible in the movie can be confirmed before movie recording starts.

Maximum movie length

2

Press the b (e movie-record) button to start movie recording.

The camera focuses in the center of the frame.

3

Press the b (e movie-record) button again to end recording.

67

68

B

Maximum Movie Length

Individual movie files cannot exceed 2 GB in size or 29 minutes in length, even when there is sufficient free space on the memory card for longer recording.

The maximum movie length for a single movie is displayed on the shooting screen.

Recording may end before either limit is reached if camera temperature becomes elevated.

The actual movie length may vary depending on the movie content, subject movement, or type of memory card.

B

Notes About Saving Images and Recording Movies

The indicator showing the number of exposures remaining or the indicator showing the maximum movie length flashes while images are being saved or while a movie is being recorded. Do not open

the battery-chamber/memory card slot cover or remove the battery or memory card while an indicator is flashing. Doing this could result in loss of data, or in damage to the camera or the memory card.

B

Notes About Movie Recording

Memory cards with an SD Speed Class rating of 6 or faster are recommended when recording movies (

F20). Movie recording may stop unexpectedly when memory cards with a lower Speed

Class ratings are used.

There may be some degradation in image quality when digital zoom is used.

The sounds of zoom control operation, zoom, autofocus lens drive movement, movie vibration reduction, and aperture operation when brightness changes may be recorded.

Smear (F3) visible in the monitor with movie recording will be recorded with movies. Avoiding

bright objects such as the sun, reflections of the sun, and electric lights when recording movies is recommended.

Depending on the distance to the subject or the amount of zoom applied, subjects with repeating patterns (fabrics, lattice windows, etc.) may have colored stripes (interference patterns, moire, etc.) in them during movie recording and playback. This occurs when the pattern in the subject and the layout of the image sensor interfere with each other; it is not a malfunction.

B

Notes About Vibration Reduction During Movie Recording

When Movie VR in the movie menu (A70) is set to On (hybrid), the angle of view (i.e., the area

visible in the frame) becomes narrower during movie recording.

When using a tripod to stabilize the camera during shooting, set Movie VR to Off to prevent potential errors caused by this function.

B

Notes About Camera Temperature

The camera may become hot when shooting movies for an extended period of time or when the camera is used in a hot area.

If the inside of the camera becomes extremely hot when recording movies, the camera will automatically stop recording.

The amount of time remaining until the camera stops recording (B10s) is displayed.

After the camera stops recording, it turns itself off.

Leave the camera off until the inside of the camera has cooled.

B

Notes About Autofocus for Movie Recording

Autofocus may not perform as expected (

A61). Should this occur, try the following:

1. Set Autofocus mode in the movie menu to Single AF (default setting) before starting movie recording.

2. Frame another subject (positioned at the same distance from the camera as the intended subject) in the center of the frame, press the b (e movie-record) button to start recording, and modify the composition.

69

70

Functions That Can Be Set with the

d Button (Movie

Menu)

Enter shooting mode

M d button M D menu icon M k button

The settings of the menu options listed below can be configured.

Movie options

Autofocus mode

Movie VR

Wind noise reduction

Option Description

Movie options

Autofocus mode

Select the movie type.

Default setting: f 720/30p/V 720/25p

The default setting is g 480/30p/W 480/25p when the internal memory is used.

Select either Single AF, which locks focus when movie recording begins, or Full-time AF, which continues focusing during movie recording.

Default setting: Single AF

Movie VR

Wind noise reduction

Select the vibration reduction setting used when recording movies.

Default setting: On (hybrid)

Set whether or not to reduce wind noise during movie recording.

Default setting: Off

A

E56

E57

E58

E58

Playing Back Movies

Press the c button to enter playback mode.

Movies are indicated by the movie options icon (

A70).

Press the k button to play back movies.

To adjust the volume, move the zoom control while a movie is playing (

A1).

0010. AVI

15 / 05 / 2014 15:30

4s

Movie options

Volume indicator

71

72

4s

Operation During Movie Playback

Playback controls are displayed at the bottom of the monitor.

The operations listed below can be performed by using the multi selector

JK to select a control and then pressing the k button.

Function

Rewind

Advance

Pause

End

Icon

A

B

E

G

Paused

Description

Hold down the k button to rewind the movie.

Hold down the k button to advance the movie.

Pause playback.

The operations listed below can be performed while paused.

C

Rewind the movie one frame. Hold down the k button for continuous rewinding.

D

Advance the movie one frame. Hold down the k button for continuous advancing.

F

Resume playback.

Return to full-frame playback mode.

Deleting Movies

To delete a movie, select the desired movie in full-frame playback mode (

A28) or thumbnail

playback mode (

A64) and press the l button (A30).

General Camera Setup

Functions That Can Be Set with the

d Button

(Setup Menu)

Press the d button M z (setup) menu icon M k button

The settings of the menu options listed below can be configured.

Welcome screen

Time zone and date

Monitor settings

Print date

Photo VR

Motion detection

AF assist

Option

Welcome screen

Description

Allows you to select whether or not the welcome screen is displayed when the camera is turned on.

Time zone and date Allows you to set the camera clock.

Monitor settings

Print date

Allows you to adjust photo information display, post-shooting image review, and monitor brightness settings.

Allows you to imprint the shooting date and time on images.

Photo VR

Motion detection

Allows you to select the vibration reduction setting used when shooting still images.

Allows you to set whether or not the camera reduces blurring caused by camera shake if motion is detected when shooting still images.

E66

A

E59

E60

E62

E64

E65

73

74

Option

AF assist

Digital zoom

Sound settings

Auto off

Format memory/

Format card

Language

Video mode

Charge by computer

Blink warning

Eye-Fi upload

Reset all

Firmware version

Description

Allows you to enable or disable the AF-assist illuminator.

Allows you to enable and disable digital zoom.

Allows you to adjust sound settings.

Allows you to set the amount of time that passes before the monitor turns off to save power.

Allows you to format the internal memory or the memory card.

E69

Allows you to change the camera’s display language.

Allows you to adjust video mode settings for connection to a television. Select from NTSC and PAL.

Allows you to set whether or not the battery in the camera is charged when the camera is connected to a computer.

E70

E70

E71

Allows you to set whether or not closed eyes are detected when taking images of people using face detection.

E72

Allows you to set whether or not to enable the function for sending images to a computer using a commercially available

Eye-Fi card.

E73

Allows you to reset the camera’s settings to their default values.

E74

View the current camera firmware version.

E74

A

E67

E67

E68

E68

Connecting the Camera to a TV,

Computer, or Printer

Connection Methods

You can enhance your enjoyment of images and movies by connecting the camera to a TV, computer, or printer.

USB/audio/video output connector

Open the connector cover.

Insert the plug straight.

Before connecting the camera to an external device, make sure the remaining battery level is sufficient and turn the camera off. Before disconnecting, make sure to turn the camera off.

If the AC Adapter EH-62G (available separately) is used, this camera can be powered from an electrical outlet. Do not use any other make or model of AC adapter as it may cause the camera to heat up or malfunction.

For information about the connection methods and subsequent operations, refer to the documentation included with the device in addition to this document.

75

76

Viewing images on a TV

E19

Images and movies captured with the camera can be viewed on a TV.

Connection method: Connect the video and audio plugs of an optional audio video cable to the TV’s input jacks.

Viewing and organizing images on a computer

A77

You can transfer images to a computer to perform simple retouching and manage image data.

Connection method: Connect the camera to the computer’s USB port with the USB cable.

Before connecting to a computer, install ViewNX 2 on the computer

(

A77).

If any USB devices that draw the power from the computer are connected, disconnect them from the computer before you connect the camera to it.

Connecting the camera and other USB-powered devices to the same computer simultaneously may cause a camera malfunction or excessive power supply from the computer, which could damage the camera or memory card.

Printing images without using a computer

E20

If you connect the camera to a PictBridge-compatible printer, you can print images without using a computer.

Connection method: Connect the camera directly to the printer’s USB port with the USB cable.

Using ViewNX 2

ViewNX 2 is an all-in-one software package which enables you to transfer, view, edit and share images. Install ViewNX 2 using the included ViewNX 2 CD-ROM.

Your Imaging Toolbox ViewNX 2™

Installing ViewNX 2

An Internet connection is required.

Compatible Operating Systems

Windows

Windows 8.1, Windows 7, Windows Vista, Windows XP

Mac

OS X 10.9, 10.8, 10.7

Refer to the Nikon website for details on system requirements, including the latest information on operating system compatibility.

77

1

Start the computer and insert the ViewNX 2 CD-ROM into the CD-ROM drive.

Windows: If instructions for operating the CD-ROM are displayed in the window, follow the instructions to proceed to the installation window.

Mac: When the ViewNX 2 window is displayed, double-click the Welcome icon.

2

Select a language in the language selection dialog to open the installation window.

If the desired language is not available, click Region Selection to choose a different region, and then choose the desired language (the Region Selection button is not available in the

European release).

Click Next to display the installation window.

78

3

Start the installer.

We recommend clicking Installation Guide in the installation window to check the installation help information and system requirements before installing ViewNX 2.

Click Typical Installation (Recommended) in the installation window.

4

Download the software.

When the Software Download screen is displayed, click I agree - Begin download.

Follow the on-screen instructions to install the software.

5

Exit the installer when the installation completion screen is displayed.

Windows: Click Yes.

Mac: Click OK.

The following software is installed:

ViewNX 2 (consisting of the three modules below)

- Nikon Transfer 2: For transferring images to the computer

- ViewNX 2: For viewing, editing, and printing transferred images

- Nikon Movie Editor: For basic editing of transferred movies

Panorama Maker (for creating a single panorama photo using a series of images shot in panorama assist scene mode)

6

Remove the ViewNX 2 CD-ROM from the CD-ROM drive.

79

80

Transferring Images to the Computer

1

Choose how images will be copied to the computer.

Choose one of the following methods:

• Direct USB connection: Turn the camera off and ensure that the memory card is inserted in the camera. Connect the camera to the computer using the USB cable. The camera automatically turns on.

To transfer images that are saved in the camera’s internal memory, remove the memory card from the camera before connecting it to the computer.

• SD card slot: If your computer is equipped with an SD card slot, the card can be inserted directly in the slot.

• SD card reader: Connect a card reader (available separately from third-party suppliers) to the computer and insert the memory card.

If a message is displayed prompting you to choose a program, select Nikon Transfer 2.

• When using Windows 7

If the dialog shown at right is displayed, follow the steps below to select

Nikon Transfer 2.

1 Under Import pictures and videos, click

Change program. A program selection dialog will be displayed; select Import

File using Nikon Transfer 2 and click

OK.

2 Double-click Import File.

If the memory card contains a large number of images, it may take a while for Nikon Transfer 2 to start. Wait until Nikon Transfer 2 starts.

B

Connecting the USB Cable

The connection may not be recognized if the camera is connected to the computer via a USB hub.

2

Transfer images to the computer.

Click Start Transfer.

Start Transfer

At default settings, all the images on the memory card will be copied to the computer.

81

82

3

Terminate the connection.

If the camera is connected to the computer, turn the camera off and disconnect the USB cable. If you are using a card reader or card slot, choose the appropriate option in the computer operating system to eject the removable disk corresponding to the memory card, and then remove the card from the card reader or card slot.

Viewing Images

Start ViewNX 2.

Images are displayed in ViewNX 2 when transfer is complete.

Consult online help for more information on using ViewNX 2.

C

Starting ViewNX 2 Manually

• Windows: Double-click the ViewNX 2 shortcut on the desktop.

• Mac: Click the ViewNX 2 icon in the Dock.

Technical Notes and Index

Caring for the Product....................................................

F2

The Camera.....................................................................................................................

F2

The Battery......................................................................................................................

F4

Charging AC Adapter ..................................................................................................

F5

Memory Cards................................................................................................................

F5

Cleaning and Storage.....................................................

F6

Cleaning...........................................................................................................................

F6

Storage .............................................................................................................................

F6

Troubleshooting .............................................................

F7

Specifications................................................................

F16

Approved Memory Cards .......................................................................................

F20

Index ..............................................................................

F22

F

1

Caring for the Product

The Camera

To ensure continued enjoyment of this Nikon product, observe the precautions described

below in addition to the warnings in “For Your Safety” (

Aviii-x) when using or storing the

device.

B

Keep Dry

The device will be damaged if immersed in water or subjected to high humidity.

B

Do Not Drop

The product may malfunction if subjected to strong shock or vibration.

B

Handle the Lens and All Moving Parts with Care

Do not apply force to the lens, lens cover, monitor, memory card slot, or battery chamber. These parts are easily damaged. Applying force to the lens cover could result in camera malfunction or damage to the lens. Should the monitor break, care should be taken to avoid injury caused by broken glass and to prevent the liquid crystal from the display touching the skin or entering the eyes or mouth.

B

Do Not Point the Lens at Strong Light Sources for Extended Periods

Avoid pointing the lens at the sun or other strong light sources for extended periods when using or storing the camera. Intense light may cause deterioration of the CCD image sensor, producing a white blur effect in photographs.

B

Keep Away from Strong Magnetic Fields

Do not use or store this device in the vicinity of equipment that generates strong electromagnetic radiation or magnetic fields. Strong static charge or the magnetic fields produced by equipment such as radio transmitters could interfere with the monitor, damage data saved on the memory card, or affect the product’s internal circuitry.

F

2

B

Avoid Sudden Changes in Temperature

Sudden changes in temperature, such as when entering or leaving a heated building on a cold day, can cause condensation to form inside the device. To prevent condensation, place the device in a carrying case or a plastic bag before exposing it to sudden changes in temperature.

B

Turn the Product Off Before Removing or Disconnecting the Power Source or

Memory Card

Do not remove the battery while the product is on, or while images are being saved or deleted.

Forcibly cutting power in these circumstances could result in loss of data or in damage to product memory or internal circuitry.

B

Notes About the Monitor

Monitors and electronic viewfinders are constructed with extremely high precision; at least 99.99% of pixels are effective, with no more than 0.01% being missing or defective. Hence while these displays may contain pixels that are always lit (white, red, blue, or green) or always off (black), this is not a malfunction and has no effect on images recorded with the device.

White or colored streaks may be visible when bright subjects are framed in the monitor. This phenomenon, known as “smear,” occurs when extremely bright light strikes the image sensor; it is characteristic of image sensors and does not indicate a malfunction. Smear may also take the form of partial discoloration in the monitor during shooting. It does not appear in images saved with the camera except in the cases of movies and of images saved with Multi-shot 16 selected for

Continuous. When shooting in these modes, we recommend that you avoid bright subjects such as the sun, reflected sunlight, and electric lights.

Images in the monitor may be difficult to see under bright lighting.

The monitor is lit by an LED backlight. Should the monitor begin to dim or flicker, contact your

Nikon-authorized service representative.

F

3

The Battery

Be sure to read and follow the warnings in “For Your Safety” (

Aviii-x) before use.

Check the battery level before using the camera and replace or charge the battery if necessary. Do not continue charging once the battery is fully charged as this will result in reduced battery performance. Whenever possible, carry a fully charged spare battery when taking images on important occasions.

Do not use the battery at ambient temperatures below 0°C (32°F) or above 40°C (104°F).

Charge the battery indoors with an ambient temperature of 5°C to 35°C (41°F to 95°F) before use.

When charging the battery inserted into this camera using the Charging AC Adapter or a computer, the battery is not charged at battery temperatures below 0°C (32°F) or above 45°C

(113°F).

Note that the battery may become hot during use; wait for the battery to cool before charging.

Failure to observe these precautions could damage the battery, impair its performance, or prevent it from charging normally.

On cold days, the capacity of batteries tends to decrease. Be sure that the battery is fully charged before heading outside to take images in cold weather. Keep spare batteries in a warm place and exchange as necessary. Once warmed, a cold battery may recover some of its charge.

Dirt on the battery terminals can prevent the camera from functioning. Should the battery terminals become dirty, wipe them off with a clean, dry cloth before use.

If the battery will not be used for some time, insert it in the camera and completely exhaust it before removing it for storage. The battery should be stored in a cool location with an ambient temperature of 15°C to 25°C (59°F to 77°F). Do not store the battery in hot or extremely cold locations.

Always remove the battery from the camera or optional battery charger when it is not being used.

When inserted, minute amounts of current flow even when unused, and the battery may become excessively drained and no longer function. Turning the camera on or off while the battery is exhausted can result in reduced battery life.

Recharge the battery at least once every six months and completely exhaust it before returning it to storage.

After removing the battery from the camera or optional battery charger, put the battery in a plastic bag, etc. in order to insulate it and store it in a cool place.

A marked drop in the time a fully charged battery retains its charge, when used at room temperature, indicates that the battery needs to be replaced. Purchase a new EN-EL19 battery.

F

4

Replace the battery when it no longer holds a charge. Used batteries are a valuable resource.

Please recycle used batteries in accordance with local regulations.

Charging AC Adapter

Be sure to read and follow the warnings in “For Your Safety” (

Aviii-x) before use.

The Charging AC Adapter EH-70P is for use only with compatible devices. Do not use with another make or model of device.

The EH-70P is compatible with AC 100-240 V, 50/60 Hz electrical outlets. When using in other countries, use a plug adapter (commercially available) as necessary. For more information about plug adapters, consult your travel agency.

Do not, under any circumstances, use another make or model of AC adapter other than Charging

AC Adapter EH-70P or USB-AC adapter. Failure to observe this precaution could result in overheating or in damage to the camera.

Memory Cards

Use only Secure Digital memory cards. See “Approved Memory Cards” (F20) for recommended

memory cards.

Be sure to follow the precautions described in the documentation included with the memory card.

Do not put labels or stickers on memory cards.

The first time you insert a memory card that has been used in another device into this camera, be sure to format it with this camera. We recommend formatting new memory cards with this camera before using them with this camera.

Note that formatting a memory card permanently deletes all images and other data on the

memory card. Be sure to make copies of any images you wish to keep before formatting the memory card.

If the message Card is not formatted. Format card? is displayed when the camera is turned on, the memory card must be formatted. If there is data that you do not want to delete, select No.

Copy the necessary data to a computer, etc. If you want to format the card, select Yes. The confirmation dialog will be displayed. To start formatting, press the k button.

Do not perform the following during formatting, while data is being written to or deleted from the memory card, or during data transfer to a computer. Failure to observe this precaution could result in the loss of data or in damage to the camera or memory card:

- Open the battery-chamber/memory card slot cover to remove/insert the battery or memory card.

- Turn off the camera.

- Disconnect the AC adapter.

Do not format the memory card using a computer.

F

5

Cleaning and Storage

Cleaning

Do not use alcohol, thinner, or other volatile chemicals.

Lens

Monitor

Body

Avoid touching the lens with your fingers. Remove dust or lint with a blower

(typically a small device with a rubber bulb attached to one end that is pumped to produce a stream of air out the other end). To remove fingerprints or other stains that cannot be removed with a blower, wipe the lens with a soft cloth, using a spiral motion that starts at the center of them and working toward the edges. If this fails, clean the lens using a cloth lightly dampened with commercial lens cleaner.

Remove dust or lint with a blower. To remove fingerprints and other stains, clean the monitor with a soft, dry cloth, being careful not to apply pressure.

Use a blower to remove dust, dirt, or sand, then wipe gently with a soft, dry cloth.

After using the camera at the beach or other sandy or dusty environment, wipe off any sand, dust, or salt with a dry cloth lightly dampened with fresh water and dry thoroughly. Note that foreign matter inside the camera could cause damage not

covered by the warranty.

Storage

Turn the camera off when not in use. Be sure that the power-on lamp is off before putting the camera away. Remove the battery if the camera will not be used for an extended period. Do not store the camera with naphtha or camphor moth balls, or in any of the following locations:

Next to equipment that produces strong electromagnetic fields, such as televisions or radios

Exposed to temperatures below –10°C (14°F) or above 50°C (122°F)

Places that are poorly ventilated or subject to humidity of over 60%

To prevent mold or mildew, take the camera out of storage at least once a month. Turn the camera on and release the shutter a few times before putting the camera away again.

For storing the battery, follow the precautions in “The Battery” (

F4) in “Caring for the

Product” (

F2).

F

6

Troubleshooting

If the camera fails to function as expected, check the list of common problems below before consulting your retailer or Nikon-authorized service representative.

Power, Display, Settings Issues

Problem

A

The camera is on but does not respond.

Battery inserted in the camera cannot be charged.

Cause/Solution

Wait for recording to end.

If the problem persists, turn the camera off.

If the camera does not turn off, remove and reinsert the battery or batteries or, if you are using an AC adapter, disconnect and reconnect the AC adapter.

Note that although any data currently being recorded will be lost, data that have already been recorded will not be affected by removing or disconnecting the power source.

Confirm all connections.

When connected to a computer, the camera may not charge for any of the reasons described below.

- Off is selected for Charge by computer in the setup menu.

- Battery charging stops if the camera is turned off.

- Battery charging is not possible if the camera’s display language and date and time have not been set, or the date and time were reset after the camera’s clock battery was exhausted. Use the Charging AC Adapter to charge the battery.

- Battery charging may stop if the computer is in sleep mode.

- Depending upon the computer specifications, settings, and status, battery charging may not be possible.

20,

E80

12

74,

E71

16, 18

The camera cannot be turned on.

The battery is exhausted.

20

F

7

Problem

The camera turns off without warning.

Monitor is blank.

Monitor is hard to read.

Date and time of recording are not correct.

Cause/Solution

The camera automatically turns off to save power (auto off function).

The camera and battery may not work properly at low temperatures.

The inside of the camera has become hot. Leave the camera off until the inside of the camera has cooled, and then try turning it on again.

The camera turns off if the USB cable connecting it to a computer or printer is disconnected. Reconnect the USB cable.

The camera is off.

The battery is exhausted.

The camera has entered standby mode to save power. Press the power switch, shutter-release button, A button, c button, or b (e movierecord) button.

The flash lamp flashes while the flash is charging. Wait for the flash to charge.

The camera and computer are connected via the USB cable.

The camera and TV are connected via an audio video cable.

Adjust the monitor brightness.

The monitor is dirty. Clean the monitor.

If the camera clock has not been set, the “Date not set” indicator flashes during shooting and movie recording. Images and movies recorded before the clock is set are dated “00/00/0000

00:00” and “01/01/2014 00:00” respectively. Set the correct time and date for Time zone and

date in the setup menu.

The camera clock is not as accurate as ordinary watches or clocks. Periodically compare the time of the camera clock with that of a more accurate timepieces, and reset as required.

21

F4

A

75, 80,

E21

20

20

21

45

75, 80

75,

E19

73,

E62

F6

16, 73,

E60

F

8

Problem

No indicators displayed in monitor.

Print date not available.

Date not imprinted on images even when Print

date is enabled.

Screen for setting time zone and date is displayed when the camera is turned on.

The camera settings reset.

Cause/Solution

Hide info is selected for Photo info in Monitor

settings in the setup menu.

Time zone and date has not been set in the setup menu.

The current shooting mode does not support

Print date.

The date cannot be imprinted on movies.

The clock battery is exhausted; all settings were restored to their default values.

The camera becomes hot.

The camera makes sound.

73,

A

E62

16, 73,

73,

E64

16, 18

The camera may become hot when used for an extended period of time to shoot movies or send images using an Eye-Fi card, or when used in a hot environment; this is not a malfunction.

When Autofocus mode is set to Full-time AF or while in some shooting modes, the camera may produce an audible focusing sound.

54, 70,

E41,

E57

E60

Shooting Issues

Cannot switch to shooting mode.

Problem

No image captured when the shutter-release button is pressed.

Cause/Solution

The camera cannot be switched to shooting mode while connected to a power outlet via the

Charging AC Adapter.

When the camera is in playback mode, press the

A button, shutter-release button, or b (e movie-record) button.

When menus are displayed, press the d button.

The battery is exhausted.

When the flash lamp is flashing, the flash is charging.

12

28

4

20

45

A

F

9

Problem

The camera cannot focus.

Images are blurred.

Streaks of light or partial discoloration are visible in the monitor.

Cause/Solution

The subject is too close. Try shooting using macro mode or x (scene auto selector) mode, or Close-up scene mode.

The subject is hard to focus on.

Set AF assist in the setup menu to Auto.

Turn the camera off and then on again.

Use the flash.

Increase the ISO sensitivity value.

Enable Photo VR and/or Motion detection when shooting still images. Enable Movie VR when recording movies.

A

32, 35, 49

61

74,

E67

20

45

54,

E35

70, 73,

E58,

E65,

E66

35,

E33

47

Use BSS (Best Shot Selector).

Use a tripod to stabilize the camera when shooting (using the self-timer at the same time is more effective).

Smear may occur when extremely bright light strikes the image sensor. When shooting with

Continuous set to Multi-shot 16 and when recording movies, avoiding bright objects, such as the sun, reflections of the sun, and electric lights is recommended.

68,

E34,

F3

F

10

Problem

Bright specks appear in images captured with flash.

Cause/Solution

The flash is reflecting off particles in the air. Set the flash mode setting to W (off).

46

A

Flash does not fire.

Digital zoom cannot be used.

The flash mode is set to W (off).

A scene mode that restricts the flash is selected.

• On is selected for Blink proof in the smart portrait menu.

A function that restricts the flash is enabled.

• Digital zoom is set to Off in the setup menu.

Digital zoom cannot be used in the following situations:

- When Portrait, Night portrait, or Pet

portrait scene mode is selected

- When smart portrait mode is selected

- When Continuous is set to Multi-shot 16 in

A (auto) mode

- When AF area mode is set to Subject

tracking in A (auto) mode

46

51

55

56

74,

33

40

54,

54,

E67

E33

E37

Image mode not available.

A function that restricts Image mode is enabled.

56

No sound when the shutter is released.

• Off is selected for Shutter sound in the Sound

settings setup menu. No sound is produced with some shooting modes and settings, even when On is selected.

The speaker is blocked. Do not cover the speaker.

74,

E68

2, 24

AF-assist illuminator does not light.

Off is selected for AF assist in the setup menu.

AF-assist illuminator may not light depending on the position of the focus area or the current scene mode, even when Auto is selected.

74,

E67

F

11

Images appear smeared.

Colors are unnatural.

Randomly spaced bright pixels (“noise”) appear in image.

Problem

Randomly spaced bright pixels (“noise”) appear in movies.

Images are too dark

(underexposed).

Images are too bright

(overexposed).

Unexpected results when flash set to V (auto with red-eye reduction).

Cause/Solution

The lens is dirty. Clean the lens.

White balance is not adjusted properly.

The subject is dark and the shutter speed is too slow, or ISO sensitivity is too high. Noise can be reduced by:

Using flash

Specifying a lower ISO sensitivity setting

When recording movies in dim lighting, the image may become somewhat “grainy” in appearance.

This occurs when the ISO sensitivity increases, and it does not indicate a malfunction.

The flash mode is set to W (off).

The flash window is blocked.

The subject is beyond the range of the flash.

Adjust exposure compensation.

Increase ISO sensitivity.

The subject is backlit. Select Backlighting scene mode or set the flash mode setting to X

(fill flash).

A

F6

35, 54,

E30

45

54,

E35

46

24

45

50

54,

E35

36, 46

Adjust exposure compensation.

50

When taking images with V (auto with red-eye reduction) or fill flash with slow sync and red-eye reduction in Night portrait scene mode, the In-

Camera Red Eye Fix processing may be applied to areas not affected by red-eye in rare cases. Use any scene mode other than Night portrait, and change the flash mode to any setting other than V (auto with red-eye reduction) and try taking an image again.

33, 46

F

12

Problem

Skin tones are not softened.

Saving images takes time.

Colored circles or light streaks appear in the monitor or images.

Cause/Solution

In some shooting conditions, facial skin tones may not be softened.

For images containing four or more faces, try using the Skin softening effect in Glamour

retouch in the playback menu.

It may take more time to save images in the following situations:

When the noise reduction function is in operation

When the flash mode is set to V (auto with red-eye reduction)

When the skin softening function is applied while shooting

When shooting with backlighting or when a very strong light source (such as sunlight) is in the frame, colored circles or light streaks (ghosting) may occur. Change the position of the light source, or frame the image so that the light source does not enter the frame, and try again.

59

A

65,

E15

46

55, 59,

E42

Playback Issues

Problem

File cannot be played back.

Cause/Solution

This camera may not be able to play back images saved with another make or model of digital camera.

This camera cannot play back movies recorded with another make or model of digital camera.

This camera may not be able to play back data edited on a computer.

A

F

13

Problem

Cannot zoom in on image.

Cannot record or play back voice memos.

Cannot edit images.

Images are not displayed on

TV.

Nikon Transfer 2 does not start when the camera is connected to a computer.

Cause/Solution

Playback zoom cannot be used with movies.

For small images, the zoom ratio displayed on the screen may not be compatible with the actual zoom ratio.

This camera may not be able to zoom in on images captured with another make or model of digital camera.

Voice memos cannot be attached to movies.

Voice memos cannot be attached to images captured with other cameras. Voice memos attached to images using another camera cannot be played back on this camera.

Some images cannot be edited. Images that have already been edited may not be edited again.

There is not enough free space in the internal memory or on the memory card.

This camera is unable to edit images captured with other cameras.

Editing functions used for images are not available for movies.

• Video mode is not correctly set in the setup menu.

The memory card contains no images. Replace the memory card. Remove the memory card to play back images from the internal memory.

The camera is off.

The battery is exhausted.

The USB cable is not correctly connected.

The camera is not recognized by the computer.

The computer is not set to start Nikon Transfer 2 automatically. For more information about

Nikon Transfer 2, refer to help information contained in ViewNX 2.

A

65,

E53

E11

74,

E70

14

20

20

75

77

F

14

Images to be printed are not displayed.

Problem

The PictBridge startup screen is not displayed when the camera is connected to a printer.

Cannot select paper size with the camera.

Cause/Solution

With some PictBridge-compatible printers, the

PictBridge startup screen may not be displayed and it may be impossible to print images when

Auto is selected for Charge by computer in the setup menu. Set Charge by computer to Off and reconnect the camera to the printer.

Memory card contains no images. Replace the memory card.

Remove the memory card to print images from the internal memory.

The camera cannot be used to select the paper size in the following situations, even when printing from a PictBridge-compatible printer. Use the printer to select the paper size.

The printer does not support the paper sizes specified by the camera.

The printer automatically selects the paper size.

A

74,

E71

14

75,

E24,

E25

F

15

Specifications

Nikon COOLPIX S6700 Digital Camera

Type Compact digital camera

Number of effective pixels 20.1 million

Image sensor

1

/

2.3

-in. type CCD; total pixels: approx. 20.48 million

Lens NIKKOR lens with 10× optical zoom

Focal length f/-number

Construction

4.5–45.0 mm (angle of view equivalent to that of 25–250 mm lens in 35mm [135] format) f/3.5–6.5

10 elements in 9 groups

Digital zoom magnification Up to 4× (angle of view equivalent to that of approx. 1000 mm lens in 35mm [135] format)

Vibration reduction

Lens shift (still pictures)

Lens shift and electronic VR (movies)

Motion blur reduction

Autofocus (AF)

Focus range

Motion detection (still pictures)

Contrast-detect AF

[W]: Approx. 50 cm (1 ft 8 in.)–∞

[T]: Approx. 1.5 m (5 ft)–

Macro mode: Approx. 5 cm (2 in.)–∞ (wide-angle position)

(All distances measured from center of front surface of lens)

Focus-area selection

Monitor

Frame coverage

(shooting mode)

Frame coverage

(playback mode)

Face priority, center, manual with 99 focus areas, subject tracking, target finding AF

7.5 cm (3-in.), approx. 230k-dot, TFT LCD with anti-reflection coating and 5-level brightness adjustment

Approx. 98% horizontal and 98% vertical (compared to actual image)

Approx. 98% horizontal and 98% vertical (compared to actual image)

F

16

Storage

Media

File system

File formats

Image size

(pixels)

ISO sensitivity (Standard output sensitivity)

Exposure

Metering mode

Exposure control

Shutter

Speed

Aperture

Range

Self-timer

Internal memory (approx. 25 MB), SD/SDHC/SDXC memory card

DCF, Exif 2.3, and DPOF compliant

Still pictures: JPEG

Sound files (Voice Memo): WAV

Movies: AVI (Motion-JPEG compliant)

20M (High) [5152×3864P]

20M [5152×3864]

10M [3648×2736]

4M [2272×1704]

2M [1600×1200]

VGA [640×480]

16:9 (14M) [5120×2880]

1:1 [3864×3864]

ISO 80–1600

ISO 3200 (available when using Auto mode)

Matrix, center-weighted (digital zoom less than 2×), spot (digital zoom 2× or more)

Programmed auto exposure and exposure compensation (–2.0 –

+2.0 EV in steps of

1

/

3

EV)

Mechanical and CCD electronic shutter

1

/

2000

–1 s

4 s (when scene mode is set to Fireworks show)

Electronically-controlled ND filter (–3.3 AV) selection

2 steps (f/3.5 and f/11.1 [W])

Can be selected from 10 s and 2 s

F

17

Flash

Range (approx.)

(ISO sensitivity: Auto)

Flash control

Interface

Data transfer protocol

Video output

I/O terminal

Supported languages

Power sources

[W]: 0.5–3.5 m (1 ft 8 in.–11 ft)

[T]: 1.5–2.0 m (5 ft–6 ft 6 in.)

TTL auto flash with monitor preflashes

Hi-Speed USB

MTP, PTP

Can be selected from NTSC and PAL

Audio/video (A/V) output; digital I/O (USB)

Arabic, Bengali, Bulgarian, Chinese (Simplified and Traditional), Czech,

Danish, Dutch, English, Finnish, French, German, Greek, Hindi,

Hungarian, Indonesian, Italian, Japanese, Korean, Marathi, Norwegian,

Persian, Polish, Portuguese (European and Brazilian), Romanian,

Russian, Serbian, Spanish, Swedish, Tamil, Telugu, Thai, Turkish,

Ukrainian, Vietnamese

One Rechargeable Li-ion Battery EN-EL19 (included)

AC Adapter EH-62G (available separately)

Approx. 2 h 40 min (when using Charging AC Adapter EH-70P and when no charge remains)

Charging time

Battery life

1

Still pictures

Movies (actual battery life for recording)

2

Tripod socket

Dimensions

(W × H × D)

Weight

Operating environment

Temperature

Humidity

Approx. 230 shots when using EN-EL19

Approx. 50 min when using EN-EL19

1/4 (ISO 1222)

Approx. 95.3 × 58.2 × 21.4 mm (3.8 × 2.3 × 0.9 in.) (excluding projections)

Approx. 137 g (4.9 oz) (with battery and SD memory card)

0°C–40°C (32°F–104°F)

85% or less (no condensation)

F

18

Unless otherwise stated, all figures assume a fully-charged battery and an ambient temperature of 23 ±3°C (73.4 ±5.4°F) as specified by the Camera and Imaging Products

Association (CIPA).

1

2

Battery life may vary depending on conditions of use, such as the interval between shots or the length of time that menus and images are displayed.

Individual movie files cannot exceed 2 GB in size or 29 minutes in length. Recording may end before this limit is reached if camera temperature becomes elevated.

Rechargeable Li-ion Battery EN-EL19

Type

Rated capacity

Operating temperature

Dimensions

(W × H × D)

Weight

Rechargeable lithium-ion battery

DC 3.7 V, 700 mAh

0°C–40°C (32°F–104°F)

Approx. 31.5 × 39.5 × 6 mm (1.3 × 1.6 × 0.3 in.)

Approx. 14.5 g (0.5 oz)

Charging AC Adapter EH-70P

Rated input

Rated output

Operating temperature

Dimensions

(W × H × D)

AC 100–240 V, 50/60 Hz, 0.07–0.044 A

DC 5.0 V, 550 mA

0°C–40°C (32°F–104°F)

Approx. 55 × 22 × 54 mm (2.2 × 0.9 × 2.2 in.) (excluding plug adapter)

For Argentina: Approx. 55 × 59 × 63 mm (2.2 × 2.4 × 2.5 in.)

Weight Approx. 47 g (1.7 oz) (excluding plug adapter)

For Argentina: Approx. 72 g (2.6 oz)

B

Specifications

Nikon will not be held liable for any errors this manual may contain.

The appearance of this product and its specifications are subject to change without notice.

F

19

Approved Memory Cards

The following Secure Digital (SD) memory cards have been tested and approved for use in this camera.

Memory cards with an SD Speed Class rating of 6 or faster are recommended for recording movies. Movie recording may stop unexpectedly when memory cards with a lower Speed

Class rating are used.

SanDisk

TOSHIBA

SD memory card

2 GB

1

2 GB

1

SDHC memory card

2

4 GB, 8 GB, 16 GB, 32 GB

4 GB, 8 GB, 16 GB, 32 GB

SDXC memory card

3

64 GB, 128 GB

64 GB

Panasonic 4 GB, 8 GB, 16 GB, 32 GB 64 GB

Lexar – 4 GB, 8 GB, 16 GB, 32 GB 64 GB, 128 GB

1

2

3

If the memory card is used with a card reader or similar device, make sure that the device supports

2 GB cards.

SDHC compliant. If the memory card is used with a card reader or similar device, be sure that the device is compliant with the SDHC standard.

SDXC compliant. If the memory card is used with a card reader or similar device, be sure that the device is compliant with the SDXC standard.

Contact the manufacturer for details on the above cards. We cannot guarantee camera performance when using memory cards made by other manufacturers.

F

20

Trademark Information

Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries.

Mac and OS X are trademarks or registered trademarks of Apple Inc., in the U.S. and other countries.

Adobe and Acrobat are registered trademarks of Adobe Systems Inc.

SDXC, SDHC, and SD Logos are trademarks of SD-3C, LLC.

PictBridge is a trademark.

All other trade names mentioned in this manual or the other documentation provided with your Nikon product are the trademarks or registered trademarks of their respective holders.

FreeType License (FreeType2)

Portions of this software are copyright © 2012 The FreeType Project

(http://www.freetype.org). All rights reserved.

MIT License (HarfBuzz)

Portions of this software are copyright © 2014 The HarfBuzz Project

(http://www.freedesktop.org/wiki/Software/HarfBuzz). All rights reserved.

F

21

Index

Symbols

x Scene auto selector mode .................. 32

A Auto mode................................................... 42

b Scene mode .................................................. 33

D Special effects mode .............................. 38

F Smart portrait mode.............................. 40

c Playback mode........................................... 28

h Favorite pictures mode..................... E5

F Auto sort mode..................................... E9

C List by date mode.............................. E10

z Setup menu................................. 73, E59

g (Telephoto)............................................... 1, 25 f (Wide-angle).......................................... 1, 25

i Playback zoom ....................................... 1, 63

h Thumbnail playback....................... 1, 64

j Help............................................................. 1, 33

b (e movie-record) button ........... 2, 67

A (Shooting mode) button............. 2, 22

c Playback button ................................ 2, 28 k Apply selection button............................. 2

d Menu button

...................................... 2, 4, 53, 65, 70, 73

l Delete button.......... 2, 30, 72, E54

m Flash mode ..................................................... 45

n Self timer ......................................................... 47

p Macro mode ................................................ 49

Refer to the Reference Manual for pages indicated with

E.

F

22

o Exposure compensation ....................... 50

R ......................................................... E4

A

AC adapter ........................................ 75, E80

Adding favorite pictures.............. 66, E5

AF area mode .................................. 54, E37

AF assist............................................... 74, E67

Album................................................................. E8

Aperture value .................................................... 27

Audio video cable...... 76, E19, E80

Auto flash .............................................................. 46

Auto mode........................................................... 42

Auto off...................................... 21, 74, E68

Auto sort mode............................................ E9

Auto with red-eye reduction .................... 46

Autofocus............. 54, 70, E41, E57

Autofocus mode

.................................... 54, 70, E41, E57

AVI...................................................................... E79

B

Backlighting o .................................................. 36

Battery .................................................. 10, 12, 18

Battery chamber ....................................... E80

Battery charger ................................ 13, E80

Battery latch.......................................................... 10

Battery level .......................................................... 20

Battery-chamber/memory card slot cover

..................................................................... 2, 11, 14

Beach Z................................................................. 33

Best Shot Selector.......................... 35, E33

Black and white copy n .............................. 35

Black-and-white ........................................ E36

Blink proof.......................................... 55, E44

Blink warning ................................... 74, E72

Brightness ..................................................... E62

BSS........................................................... 35, E33

Built-in microphone ............................................ 1

Button sound.............................................. E68

C

Calendar Display............................................... 64

Center................................................... 62, E38

Charge by computer ................... 74, E71

Charge lamp............................... 2, 13, E71

Charging AC Adapter ...................................... 12

Close-up k .......................................................... 35

Cloudy............................................................. E30

Color options ................................... 54, E36

Compression ratio ................................... E28

Computer.................................................... 76, 80

Connector cover.................................................... 1

Continuous ....................................... 54, E33

Copying images............................. 65, E54

Crop........................................................ 63, E18

Cross process o............................................... 39

Cyanotype .................................................... E36

D

Date and time .................................. 17, E60

Date format........................................ 17, E60

Daylight.......................................................... E30

Daylight saving time .......... 17, 18, E61

Delete........................................ 30, 72, E54

Digital zoom.......................... 25, 74, E67

Direct print ........................................ 76, E20

D-Lighting........................................... 65, E13

DPOF ................................................................ E45

DPOF printing ............................................ E27

DSCN................................................................ E79

Dusk/dawn i .................................................... 33

Dynamic Fine Zoom........................................ 25

E

Editing images ............................................ E11

EH-70P............................................................... F19

EN-EL19 ............................................................ F19

Exposure compensation............................... 50

Extension....................................................... E79

Eye-Fi upload ................................... 74, E73

Eyelet for camera strap...................................... 1

F

Face detection .................................................... 58

Face priority................................................. E37

Favorite pictures mode ............................ E5

File names..................................................... E79

Refer to the Reference Manual for pages indicated with

E.

F

23

Fill flash................................................................... 46

Fireworks show m ........................................... 35

Firmware version........................... 74, E74

Fixed range auto....................................... E35

Flash .......................................................................... 45

Flash lamp ..................................................... 2, 45

Flash mode ............................................... 45, 46

Flash off .................................................................. 46

Fluorescent .................................................. E30

Focus................................ 26, 54, 58, E37

Focus area................................................... 26, 58

Focus indicator ........................................... 7, 26

Focus lock .............................................................. 62

Food u .................................................................... 35

Format internal memory .......... 74, E69

Format memory cards ..... 15, 74, E69

Formatting .............................. 15, 74, E69

FSCN................................................................. E79

Full-frame playback ................... 28, 63, 64

Full-time AF ........ 54, 70, E41, E57

Functions that cannot be used

simultaneously.................................................... 56

G

Glamour retouch............................ 65, E15

H

Help ........................................................................... 33

High key G........................................................... 38

High-contrast monochrome F .............. 38

I

Identifier......................................................... E79

Image mode.................. 54, E28, E29

Image review .............................................. E62

Image size.......................................... 54, E28

Imprinting date and time......... 73, E64

Incandescent .............................................. E30

Internal memory................................................. 15

Internal memory indicator .................. 7, 20

ISO sensitivity................................... 54, E35

J

JPG..................................................................... E79

L

Landscape c ...................................................... 33

Language ........................................... 74, E70

Lens.............................................................. 1, F16

Lens cover.................................................................. 1

List by date mode..................................... E10

Low key H............................................................ 38

M

Macro mode........................................................ 49

Manual............................................................ E38

Memory card...................................... 14, F20

Memory card slot .............................................. 14

Monitor................................................. 2, 6, F6

Monitor settings............................. 73, E62

Motion detection .......................... 73, E66

Movie length............................................. 67, 68

Refer to the Reference Manual for pages indicated with

E.

F

24

Movie menu ..................................... 70, E56

Movie options ................................. 70, E56

Movie playback ................................................... 71

Movie recording ................................................ 67

Movie VR............................................. 70, E58

Multi selector .......................................................... 2

Multi-shot 16............................................... E33

Museum l .......................................................... 35

N

Night landscape j ......................................... 34

Night portrait e................................................ 33

Nikon Transfer 2 ....................................... 79, 81

Nostalgic sepia E ........................................... 38

Number of exposures remaining

.................................................................. 20, E29

O

Optical zoom ....................................................... 25

Optional accessories .............................. E80

P

Painting h............................................................ 38

Panorama assist U ......................... 36, E2

Panorama Maker............................... 36, E4

Paper size ................................... E24, E25

Party/indoor f.................................................. 34

Pet portrait auto release ............................... 37

Pet portrait O..................................................... 37

Photo info ..................................................... E62

Photo VR .............................................. 73, E65

PictBridge....................... 76, E20, E45

Playback .................................... 28, 71, E53

Playback menu ............................... 65, E45

Playback mode ................................................... 28

Playback zoom.................................................... 63

Pop l................................................................... 38

Portrait b............................................................... 33

Power............................................................. 16, 20

Power switch ................................................ 1, 20

Power-on lamp............................................ 1, 20

Preset manual.............................................. E31

Pressing halfway ................................................ 27

Print....... 65, 76, E23, E25, E45

Print date

................ 18, 73, E46, E48, E64

Print order.......................................... 65, E45

Printer................................................... 76, E20

Protect.................................................. 65, E50

Q

Quick effects....... 43, 54, E12, E41

Quick retouch................................... 65, E13

R

Rechargeable Li-ion battery ................ F19

Red-eye correction.................................. E14

Removing favorite pictures........ 66, E7

Reset all ............................................... 74, E74

Rotate image..................................... 65, E52

RSCN................................................................. E79

Refer to the Reference Manual for pages indicated with

E.

F

25

S

Scene auto selector ......................................... 32

Scene mode .............................................. 33, 34

Selective color I ............................................. 38

Self-timer ................................................................ 47

Self-timer lamp ................................. 1, 41, 48

Sepia................................................................. E36

Setup menu....................................... 73, E59

Shooting ........................................... 22, 24, 26

Shooting menu .............................. 54, E28

Shooting mode .................................................. 22

Shutter sound............................................. E68

Shutter speed...................................................... 27

Shutter-release button ........................... 1, 26

Single.................................................... 54, E33

Single AF............... 54, 70, E41, E57

Skin softening........................ 55, 59, E42

Slide show ......................................... 65, E49

Slow sync .............................................................. 46

Small picture ..................................... 65, E17

Smart portrait menu.................... 41, E42

Smart portrait mode ...................................... 40

Smile timer ........................................ 55, E43

Snow z.................................................................. 33

Soft D..................................................................... 38

Sound settings................................ 74, E68

Speaker....................................................................... 2

Special effects mode....................................... 38

Sports d................................................................. 34

SSCN................................................................. E79

Standard color................................. 54, E36

Strap ............................................................................. 3

Subject tracking .................... E38, E40

Sunset h............................................................... 33

Super vivid k....................................................... 38

T

Target finding AF................ 54, 60, E39

Telephoto............................................................... 25

Televisions .......................................... 76, E19

Thumbnail display ........................................... 64

Time difference ......................................... E60

Time zone ........................................... 17, E60

Time zone and date..................... 73, E60

Toy camera effect 1 m................................. 39

Toy camera effect 2 n ................................ 39

Tripod socket ......................................... 2, F18

U

USB cable .................................. 12, 80, E21

USB/audio/video output connector

............................................................................... 1, 75

V

Video mode ...................................... 74, E70

Video-in jack/audio-in jack.................. E19

ViewNX 2 ................................................................ 77

Vivid color ..................................................... E36

Voice memo...................................... 65, E53

Refer to the Reference Manual for pages indicated with

E.

F

26

Volume ................................................. 71, E53

W

WAV .................................................................. E79

Welcome screen............................. 73, E59

White balance ................................. 54, E30

Wide-angle............................................................ 25

Wind noise reduction.......... 7, 70, E58

Z

Zoom control ..................................... 1, 25, 71

Zooming in/out ................................................. 25

Refer to the Reference Manual for pages indicated with

E.

F

27

No reproduction in any form of this manual, in whole or in part

(except for brief quotation in critical articles or reviews), may be made without written authorization from NIKON CORPORATION.

Printed in Singapore

YP3L01(11)

6MN42411-01

DIGITAL CAMERA

User’s Manual

En
