PM 65 TP SS
2621 Ridgepoint Drive, Suite 235 Austin, TX 78754
800.866.6506
www.ikey.com
PM-65-TP-SS
Panel Mount Stainless Steel with Touchpad
iKey's stainless steel panel mount keyboards are durable, cleanable and easily
customized to fit the unique demands of its application. The PM-65-TP-SS
integrates an industrial touchpad for controlled usability. For public display kiosks,
these features create a waterproof, environmentally durable solution perfect for
harsh kiosk implementations. Because most kiosks do not require supervision by
operators or retailers, these products help prevent theft and damage by vandals
through stainless steel keys, an easily mountable design and unparalleled
durability.
Technical Specifications
Certifications
Meets or exceeds: IEC 60512-6 IEC 60512-4 IP65 FCC Part 15, Class B
Shock
3 x 11 ms pulses of 50g on each of 3 axes
Cable
LENGTH: 7' straight
Key Switch
MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION
FORCE: 6.35 oz. +/- 0.70 oz. (180g +/- 20g)
Vibration
POWER SPECTRAL DENSITY: 0.04g/HZ FREQUENCY RANGE: 20Hz-2Khz DURATION OF TEST PER AXIS: 3
hours
Power
KEYBOARD: [email protected] (from CPU port) TOUCHPAD: [email protected] (from mouse connection port)
Compatability
USB KEYBOARD: All Windows and Macintosh OS
Temperature Range
STORAGE: -40C to +90C(-40F to +194F) OPERATING: -40C to +60C (-40F to +140F)
Weight
4..00 lbs +/- 0.10 lbs (1.84 kg +/- 0.05 kg)
Warranty
1 year limited warranty
Humidity
100%
Dimensions
16.25" x 5.11" x 1.25" (w-h-d) 412.8mm x 129.8mm x 31.8mm CUTOUT: 15.76" x 4.62" (w-h) 400.3mm x 117.3 mm
Model Numbers
PM-65-TP-SS-USB
Features and Benefits
10-Year Lifespan
Integrated Touchpad
Integrated, programmable function keys
Low-profile stainless steel keys
Vandal Proof design
©2011 iKey, Ltd. All rights reserved. 2621 Ridgepoint Drive Suite 235 Austin, TX 78754 1-800- 866-6506
