K i t R A N G E

C AtA l o G u E

From a single/two-family setup...

... to a medium-size system (10 users)

Scheme of expandable plant up to 10 users

Example of plant with two-family PLANUXKIT

1216

Door opening

1214KC

1214KC

2+2

1207

6101W+

6114KC

6101W+

6114KC

6101W+

6114KC

Composition of the kit

2

Expandable up to 10 users!

Comelit has designed two solutions capable of fulfilling all user requirements.

KIT BASIC

The Basic kit consists of a

single

and/or

two-family

door-entry and video entry phone system set featuring an innovative and elegant design.

The Basic range is easy to install and use, and is perfect for all residential solutions.

KIT

E

VOLUTION

The Evolution kit retains the elegance and excellence of a Comelit product, but is enhanced with performance features allowing system expansion for

up to 10 users

, with the intercom function provided as standard.

4

STYLE

2

STYLE

5

Stylekit 2 is a single-family door-entry phone kit created by Comelit; it is extremely easy to install as it uses just 2 wires. Stylekit 2 features an original and innovative design, characterised by unmistakable and exclusive blue LEDs, large nameplates and high audio quality. An elegant desk base guarantees flexibility, to suit all requirements.

Stylekit 5 is a 5-wire door-entry phone kit created by

Comelit. Stylekit 5 features an original and innovative design, characterised by unmistakable and exclusive blue LEDs, large nameplates and high audio quality. The simple inclusion of an additional door-entry phone offers easy expansion and an elegant desk base guarantees flexibility, to suit all requirements.

The external unit is wall-mounted, but the box art. 3554 used to install it as a flush-mounted product is also supplied as part of the package.

Single-Family

Kit

with IDEA

art. 8270

The kit includes

N°1 art. 2612

N°1 art. 1200

N°1 art. 3554

N°1 art. 3561

Accessories code Description

2612

3560

3561

3554

4887

4889

1200

1229

Style series basic intercom for 2-wire system

Flush-mounted external unit 2 wires

Surface-mounted external unit 2 wires

Spare flush mounted box

Waterproof housing for Idea surface-mounted entrance panel

Waterproof shield for Idea flush-mounted entrance panel

12Vac transformer with 230vac input

Accessory - additional ringtone

Single-Family

Kit

with IDEA

art. 8271

The kit includes

N°1 art. 2602

N°1 art. 1200

N°1 art. 3554

N°1 art. 3551

Two-Family

Kit

with IDEA

art. 8272

The kit includes

N°2 art. 2602

N°1 art. 1200

N°1 art. 3554

N°1 art. 3553

Three-Family

Kit

with IDEA

art. 8273

The kit includes

N°3 art. 2602

N°1 art. 1200

N°1 art. 3573

Four-Family

Kit

with IDEA

art. 8274

The kit includes

N°4 art. 2602

N°1 art. 1200

N°1 art. 3574

Accessories code Description

3550 Flush-mounted external unit

3551 Surface-mounted external unit

3552 Flush-mounted external unit

3553 Surface-mounted external unit

3573 3-Button external unit for 5-wire Stylekit

3574 4-Button external unit for 5-wire Stylekit

3554 Spare flush mounted box

4887 Waterproof housing for Idea surface-mounted entrance panel

4889 Waterproof shield for Idea flush-mounted entrance panel

1200 12Vac transformer with 230Vac input

2602 Style series 4 +1 traditional system basic intercom

1122/A 12-24Vdc-ac general purpose relay

1229 Accessory - additional ringtone

IKALL

VANDALCOM

Accessories

Description

Spare parts and/or accessories are standard products of the traditional cabling system

8241I

The kit includes:

N°1 art. 31162

N°1 art. 33401

N°1 art. 3311/2S

N°1 art. 3348

N°1 art. 1610

N°1 art. 1538

N°1 art. 2602

art. 8220S

The kit includes:

N°1 art. 2602

N°1 art. 1538

N°1 art. 3160/1

N°1 art. 3161/1

N°1 art. 3262/1

N°1 art. 1600

art. 8230S

The kit includes:

N°1 art. 2602

N°1 art. 1538

N°1 art. 3160/1

N°1 art. 3161/2

N°1 art. 3262/1

N°1 art. 1600

N°1 art. 3188

5

6

GENIUS

Single-Family B/W Kit

with IDEA

art. 8471

The kit includes

N° 1 art. 5801

N° 1 art. 5814K

N° 1 art. 4880

N° 1 art. 1205/B

N° 1 art. 1216

N° 1 art. 1214/2

Two-Family B/W Kit

with IDEA

art. 8472

The kit includes

N° 2 art. 5801

N° 2 art. 5814K

N° 1 art. 4881

N° 1 art. 1205/B

N° 1 art. 1216

N° 2 art. 1214/2

Accessories cod.

Description

4880

4881

4882

4883

3554

4887

4889

5801

5802

5814K

5814KC

5712

2608

2628

2610

1229

1224A

4833/A

4833C

1 user external panel for B/W

2 users external panel for B/W

1 user entrance panel for colour

2 User entrance panel for colour kit

Spare flush mounted box

Waterproof housing for Idea surface-mounted entrance panel

Waterproof shield for Idea flush-mounted entrance panel

Monitor Genius series B/W handset

Monitor Genius series colour handset

Geniuskit B/W additional bracket

Geniuskit colour additional bracket

Desk base with bushing for Bravo/Genius monitor

Style series Simplebus system basic intercom

Style series Simplebus 2 system elegance intercom - white

Style series Simplebus top/kit system elegance intercom

Accessory - additional ringtone

Simplebus system digital switching device

Line amplifier for simplebus video systems

Line amplifier for Simplebus color video systems

Particularly simple, versatile video intercom system, comprising a flush or surface mounted entrance panel. The b/w and colour monitor features an elegant gloss outer case with silk screen printing, and has 3 pushbuttons: door open, actuator

(or free C/N.O.) and staircase lighting (or video request).

GeniusKit allows call repetition by means of special terminals and duplication of the door open pushbutton even in the vicinity of the external unit. The standard configuration can be varied easily, by fitting additional monitors or telephones, or a second external video entry panel. Geniuskit can also provide for additional cameras and locks. The basic kit can be expanded to include up to 2 or more external units and 3 monitors per residential unit. Exapandable up to 16 internal units with art.1252.

Single-Family Colour Kit

with IDEA

art. 8481

The kit includes

N° 1 art. 5802

N° 1 art. 5814KC

N° 1 art. 4882

N° 1 art. 1205/B

N° 1 art. 1216

N° 1 art. 1214KC

Two-Family Colour Kit

with IDEA

art. 8482

The kit includes

N° 2 art. 5802

N° 2 art. 5814KC

N° 1 art. 4883

N° 1 art. 1205/B

N° 1 art. 1216

N° 2 art. 1214KC

1122/A

1256

1259/A

1259C

1214/2

1214KC

1216

1205/B

1212/B

12-24Vdc-ac general purpose relay

Simplebus system digital relay actuator

Switcher for remote cameras

Simplebus/colour kit for separate video cameras

Simplebus 2 connection terminal

Connecting terminal for color kit

Simplebus/kit system terminal

12Vac - 20vdc dual output power supply with 230vac input

20Vdc 14va power supply with 230vac input

4576/100 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

SMART

A single and two-family colour video entry phone system kit. This consists of the new IDEA entrance panel and the new Smart monitor, which helps to minimise the overall dimensions. The privacy and intercom functions are standard features of the Smartkit. In order to use the intercom function, the single-family kit must be expanded with one or more additional door-entry phones/monitors. The kit can be used as a system base, to create systems to which a maximum of

10 residences are connected. The kits can be expanded to create solutions with 2 or more external units and 3 monitors per residential unit; this can be expanded to a maximum of

16 units through the addition of art. 1252.

Single-Family Colour Kit

with IDEA art. 8471S

The kit includes

N°1 art. 6302

N°1 art. 4882

N°1 art. 1205/B

N°1 art. 1215

N°1 art. 1216

N°1 art. 6117

N°1 art. 6320

Two-Family Colour Kit

with IDEA art. 8472S

The kit includes

N°2 art. 6302

N°1 art. 4883

N°1 art. 1205/B

N°2 art. 1215

N°1 art. 1216

N°2 art. 6117

N°2 art. 6320

Accessories code Description

6333

6117

6118

2608

2628

2610

1229

1224A

4833C

4882

4883

3554

4887

4889

6302

6312

6320

1 User entrance panel for colour kit

2 User entrance panel for colour kit

Spare flush mounted box

Waterproof housing for Idea surface-mounted entrance panel

Waterproof shield for Idea flush-mounted entrance panel

Smart series sbc/kit system hands-free colour monitor

Desk base with bushing for Smart monitor

Surface-mounted support for Smart monitor

Accessory - additional 5 buttons for Smart monitor

Flush-mounted box for Planux and Smart monitor

Plasterboard fixing kit for Planux and Smart monitors

Style series Simplebus system basic intercom

Style series Simplebus 2 system elegance intercom - white

Style series Simplebus top/kit system elegance intercom

Accessory - additional ringtone

Simplebus system digital switching device

Line amplifier for Simplebus color video systems

1122/A

1256

1259C

1215

12-24Vdc-ac general purpose relay

Accessory - Simplebus system digital relay actuator

Accessory - Simplebus/colour kit for separate video cameras

Connection terminal

1216

1205/B

Simplebus/kit system terminal

12Vac - 20vdc dual output power supply with 230vac input

1212/B 20Vdc 14va power supply with 230vac input

4576/100 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

7

BRAVO

8

Single-Family B/W Kit

with IkAll

art. 8171I

The kit includes

N° 1 art. 5701

N° 1 art. 5714/K

N° 1 art. 4878K

N° 1 art. 1214/2

N° 1 art. 1207

N° 1 art. 1216

Two-Family B/W Kit

with IkAll

art. 8173I

The kit includes

N° 2 art. 5701

N° 2 art. 5714/K

N° 1 art. 4879K

N° 2 art. 1214/2

N° 1 art. 1207

N° 1 art. 1216

Accessories code Description

4878K

4878KC

4879K

4879KC iKall Simplebus kit single family B/W external unit iKall Simplebus kit single family colour external unit iKall Simplebus kit two family B/W external unit iKall Simplebus kit two family colour external unit

31121

31161

Natural anodised aluminium rain shield

Natural anodised aluminium housing with rain shield

4680K iKall series Simplebus kit B/W audio/video unit

4680KC iKall series Simplebus kit colour audio/video unit

5701

5702

5714/K

5714KC

5712

5733

5734

1207

2608

2610

Monitor Bravo series B/W handset

Monitor Bravo series colour handset

Bravokit B/W additional bracket

Bravokit colour additional bracket

Desk base with bushing for Bravo/Genius monitor

Bravo monitor additional 4 buttons

Bravo monitor additional 2 buttons and 2 leds

Power supply for simplebus kit - iKall

Style series Simplebus system basic intercom

Style series Simplebus top/kit system elegance intercom

Bravokit - the new video door entry system from Comelit

Based on technology exclusive to Comelit, Simplebus is the last word in simplicity. It comprises the Powercom entrance panel, with its distinctive blue LEDs and original design, and Bravo, the elegant video door entry monitor suitable for all types of residence.The kits are available in both colour and black and white versions. Both types are available in surface-mounted, single-fa-mily or two-family versions. The

Bravokit includes the “privacy” function and the intercom function. In order to use the intercom function, the singlefamily kit must be expanded with one or more additional door entry telephones/ monitors. The basic kit can be expanded to include up to 2 or more external units and 3 monitors per residential unit. Exapandable up to 16 internal units with art.1252.

Single-Family Colour Kit

with IkAll

art. 8184I

The kit includes

N° 1 art. 5702

N° 1 art. 5714KC

N° 1 art. 4878KC

N° 1 art. 1214KC

N° 1 art. 1207

N° 1 art. 1216

Two-Family Colour Kit

with IkAll

art. 8185I

The kit includes

N° 2 art. 5702

N° 2 art. 5714KC

N° 1 art. 4879KC

N° 2 art. 1214KC

N° 1 art. 1207

N° 1 art. 1216

1229

1224A

4833/A

4833C

1122/A

1256

1259/A

1259C

1214/2

Accessory - additional ringtone

Simplebus system digital switching device

Line amplifier for Simplebus video systems

Line amplifier for Simplebus color video systems

Simplebus system digital switching device

Accessory - Simplebus system digital relay actuator

Switcher for remote cameras

Accessory - Simplebus/colour kit for separate video cameras

Simplebus 2 connection terminal

1214KC

1216

Connecting terminal for color kit

Simplebus/kit system terminal

1212/B Simplebus/kit system terminal

4576/100 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

SMART

A single and two-family colour video entry phone system kit.

This consists of the new IKALL entrance panel, with clean and attractive lines, and the new Smart monitor, which helps to minimise the overall dimensions. The privacy and intercom functions are standard features of the Smartkit. In order to use the intercom function, the single-family kit must be expanded with one or more additional door-entry phones/monitors. The kit can be used as a system base, to create systems to which a maximum of 10 residences are connected. The kits can be expanded to create solutions with 2 or more external units and 3 monitors per residential unit; this can be expanded to a maximum of 16 units through the addition of art. 1252.

Single-Family Colour Kit

with IkAll art. 8171IS

The kit includes

N° 1 art. 6302

N° 1 art. 6117

N° 1 art. 6320

N° 1 art. 1207

N° 1 art. 1215

N° 1 art. 1216

N° 1 art. 4878KC

Two-Family Colour Kit

with IkAll art. 8172IS

The kit includes

N° 2 art. 6302

N° 2 art. 6117

N° 2 art. 6320

N° 1 art. 1207

N° 2 art. 1215

N° 1 art. 1216

N° 1 art. 4879KC

Accessories code Description

6333

6117

6118

1207

2608

2628

2610

1229

4878KC iKall simplebus kit single family colour external unit

4879KC iKall simplebus kit two family colour external unit

31121

31161

Natural anodised aluminium rain shield

Natural anodised aluminium housing with rain shield

4680KC iKall series simplebus kit colour audio/video unit

6302 Smart series sbc/kit system hands-free colour monitor

6312

6320

Desk base with bushing for Smart monitor

Surface-mounted support for Smart monitor

Accessory - additional 5 buttons for Smart monitor

Flush-mounted box for planux and Smart monitor

Plasterboard fixing kit for planux and Smart monitors

Power supply for simplebus kit - iKall

Style series Simplebus system basic intercom

Style series Simplebus 2 system elegance intercom - white

Style series Simplebus top/kit system elegance intercom

Accessory - additional ringtone

1224A Simplebus system digital switching device

4833C

1122/A

1256

1259C

Line amplifier for Simplebus color video systems

Simplebus system digital switching device

Accessory - Simplebus system digital relay actuator

Accessory - Simplebus/colour kit for separate video cameras

1215

1216

Connection terminal

Simplebus/kit system terminal

1212/B 20Vdc 14va power supply with 230vac input

4576/100 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 MM2 + 2x1.5 MM2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 MM2 + 2x1.5 MM2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 MM2 + 2x1.5 MM2

9

10

PLANUX

Single-Family Colour Kit

with IkAll

art. 8171IP

The kit includes

N° 1 art. 6101W

N° 1 art. 6101N

N° 1 art. 6114KC

N° 1 art. 6117

N° 1 art. 6120

N° 1 art. 1207

N° 1 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

Two-Family Colour Kit

with IkAll

art. 8172IP

The kit includes

N° 2 art. 6101W

N° 2 art. 6101N

N° 2 art. 6114KC

N° 2 art. 6117

N° 2 art. 6120

N° 1 art. 1207

N° 2 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

A single and two-family colour video entry phone system kit.

It consists of the new IKALL entrance panel, with clean and attractive lines, and the Planux monitor with touch-sensitive technology. The privacy and intercom functions are standard features of the Planux kit. In order to use the intercom function, the single-family kit must be expanded with one or more additional door-entry phones/monitors. The kit can be used as a system base, to create systems to which a maximum of

10 residences are connected. The kits can be expanded to create solutions with 2 or more external units and 3 monitors per residential unit; this can be expanded to a maximum of

16 units through the addition of art. 1252.

Accessories code Description

6112

6117

6118

6120

6121

6122

1207

2608

4878KC iKall Simplebus kit single family colour external unit

4879KC iKall Simplebus kit two family b/w external unit

31121

31161

Natural anodised aluminium rain shield

Natural anodised aluminium housing with rain shield

4680KC IKall series Simplebus kit colour audio/video unit

6101B Planux series hands-free colour monitor - absolute black

6101W Planux series hands-free colour monitor - white

6114KC Planuxkit colour additional bracket

2628

2610

1229

Desk base with junction box for Planux monitor

Flush-mounted box for planux and Smart monitor

Plasterboard fixing kit for planux and Smart monitors

Surface-mounted support for Planux monitor

High surface-mounted support for Planux monitor

Tilting accessory for Planux monitors

Power supply for simplebus kit - iKall

Style series Simplebus system basic intercom

Style series Simplebus 2 system elegance intercom - white

Style series Simplebus top/kit system elegance intercom

Accessory - additional ringtone

1224A

4833C

1122/A

1256

Simplebus system digital switching device

Line amplifier for Simplebus color video systems

12-24Vdc-ac general purpose relay

Accessory - Simplebus system digital relay actuator

1259C Accessory - Simplebus/colour kit for separate video cameras

1214KC Connecting terminal for colour kit

1216

1212/B

Simplebus/kit system terminal

20Vdc 14va power supply with 230vac input

4576/100 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 Mm2 + 2x1.5 Mm2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 Mm2 + 2x1.5 Mm2

PLANUX

LUX

A single colour video entry phone system kit. It includes the new IKALL entrance panel, with clean and attractive lines, and the Planux Lux monitor with touch-sensitive technology. The privacy and intercom functions are standard features of the

Planux Lux and Planux Lux kit. In order to use the intercom function, the single-family kit must be expanded with one or more additional door-entry phones/monitors.

The kit can be used as a system base, to create systems to which a maximum of 10 residences are connected. The kits can be expanded to create solutions with 2 or more external units and 3 monitors per residential unit; this can be expanded to a maximum of 16 units through the addition of art. 1252.

Single-Family Colour Kit

with IkAll art. 8171IPlB

The kit includes

N° 1 art. 6101B/C

N° 1 art. 6114KC

N° 1 art. 6117

N° 1 art. 1207

N° 1 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

Single-Family Colour Kit

with IkAll art. 8171IPlW

The kit includes

N° 1 art. 6101W/C

N° 1 art. 6114KC

N° 1 art. 6117

N° 1 art. 1207

N° 1 art. 1214KC

N° 1 art. 1216

N° 1 art. 4878KC

Accessories

code Description

4878KC iKall Simplebus kit single family colour external unit

4879KC iKall Simplebus kit two family b/w external unit

31121

31161

Natural anodised aluminium rain shield

Natural anodised aluminium housing with rain shield

4680KC IKall series Simplebus kit colour audio/video unit

6101B/C Planux lux series hands-free colour monitor - black

6101W/C Planux lux series hands-free colour monitor - white

6114KC Planuxkit colour additional bracket

6117

6118

Flush-mounted box for Planux and smart monitors

Plasterboard fixing kit for Planux and smart monitors

6101L/C White colour template for video Planux lux

6101N/C Black colour template for video Planux lux

1207 Power supply for Simplebus kit - iKall

2608

2628

Style series Simplebus system basic intercom

Style series Simplebus 2 system elegance intercom - white

2610

1229

1224A

4833C

Style series simplebus top/kit system elegance intercom

Accessory - additional ringtone

Simplebus system digital switching device

Line amplifier for Simplebus color video systems

1122/A

1256

12-24Vdc-ac general purpose relay

Accessory - Simplebus system digital relay actuator

1259C Accessory - Simplebus/colour kit for separate video cameras

1214KC Connecting terminal for colour kit

1216

1212/B

Simplebus/kit system terminal

20Vdc 14va power supply with 230vac input

4576/100 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 Mm2 + 2x1.5 Mm2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 Mm2 + 2x1.5 Mm2

11

PLANUX

MEMO

Single-Family Colour Kit

with IkAll

art. 8171IPM

The kit includes:

N° 1 art. 6101WM

N° 1 art. 6214C

N° 1 art. 6117

N° 1 art. 6120

N° 1 art. 1207

N° 1 art. 4888C

N° 1 art. 4878KC

with TOUCH SCREEN

A single colour video entry phone system kit. It consists of the new IKALL entrance panel, with clean and attractive lines, and the PlanuxMemo monitor with touch-sensitive technology.

The privacy and intercom functions are standard features of the PlanuxMemo kit. In order to use the intercom function, the single-family kit must be expanded with one or more additional door-entry phones/monitors. The kit can be used as a system base, to create systems to which a maximum of 10 residences are connected.

Accessories code Description

6118

6120

6121

6122

1207

2608

2628

2610

4878KC iKall Simplebus kit single family colour external unit

31121 Natural anodised aluminium rain shield

31161 Natural anodised aluminium housing with rain shield

4680KC IKall series Simplebus kit colour audio/video unit

6101WM White Planux hands-free colour monitor with memovideo

6214C Simplebus top bracket for Planux memo and Planux manager

6112

6117

Desk base with junction box for Planux monitor

Flush-mounted box for planux and Smart monitor

1229

1224A

4833C

Plasterboard fixing kit for planux and Smart monitors

Surface-mounted support for Planux monitor

High surface-mounted support for Planux monitor

Tilting accessory for Planux monitors

Power supply for simplebus kit - iKall

Style series Simplebus system basic intercom

Style series Simplebus 2 system elegance intercom - white

Style series Simplebus top/kit system elegance intercom

Accessory - additional ringtone

Simplebus system digital switching device

Line amplifier for Simplebus color video systems

4888C Simplebus colour system power supply mixer

1122/A 12-24Vdc-ac general purpose relay

1256

1259C

Accessory - Simplebus system digital relay actuator

Switcher for remote cameras

1214/2C Simplebus 2 and Simplebus colour connection terminal

1216 Simplebus/kit system terminal

1212/B 20Vdc 14va power supply with 230vac input

4576/100 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 100 m

4576/500 Simplebus system Comelit cable 2x0.5 Mm2 + 2x1.5 Mm2 - 500 m

4578/100 Simplebus external Comelit 100 m cable 2x0.5 Mm2 + 2x1.5 Mm2

4578/500 Simplebus external Comelit 500 m cable 2x0.5 Mm2 + 2x1.5 Mm2

14

VARIANTS

6101B

+6114KC

6101W

+6114KC

2+2

1207 1224A

6101B

+6114KC

6101W

+6114KC

2+2

1207 1224A

Variant diagrams

6101B

+6114KC

6101W

+6114KC

2+2

1207 1224A

6101B

+6114KC

6101W

+6114KC

2+2

1207 1224A

2+2 2+2 2+2 2+2

4878KC

1214KC

1195

1998/A - 1998VC

2

4878KC

2

1214KC

4878KC

2

2

4878KC

1214KC

2

1214KC

2

1216

2

1195

1595

2+2

6101B

+6114KC

*

6101W

+6114KC

2+2

1224A 1207

2+2

1216

6101W+

6114KC

1214KC

Door opening

2

Door opening

2

4878KC 4878KC

Variant with second entrance for single-family kit

1214KC

6101W+

6114KC

6101W+

6114KC

1214KC

2+2

1207

6101B

+6114KC

*

6101W

+6114KC

2+2

2+2

1216

1214KC

1214KC

2+2

1224A 1207

2+2

*

6101B

+6114KC

6101W

+6114KC

2+2

2+2

2

Door opening

Door opening

2

Door opening

4879KC 4879KC

Variant with second entrance for two-family kit

2

Variant of expandable plant up to 10 users

Door opening

1216

1214KC

6101B

+6114KC

2+2

2+2

1207

6101W

+6114KC

*

1212/B 1212/B

230V 230V

2

2

6101B

+6114KC

6101W

+6114KC

*

2

2

*

6101W

+6114KC

6101B

+6114KC

2+2

2

4878KC

Variant with two additional monitors for single-family kit

6101B

+6114KC

2610

2610

2

1216

1214/2C

2

1214/2C

6101W

+6114KC

*

2+2

1214KC

2+2

Door opening

1214KC

2+2

1214KC

2+2

6101B

+6114KC

*

*

6101W

+6114KC

1214KC

2+2

1205B

230V

2+2

*

4879KC

Variant with two additional monitors or entry phones for two-family kit

Door opening

1216

1214/2C

2

1214/2C

2

1214KC

1207

2+2

2

2

2610

2610

2+2

6101B

+6114KC

6101W

+6114KC

*

4878KC

Variant with two additional entry phones for single-family kit

COAX

COAX

6101B

+6114KC

*

6101W

+6114KC

2+2

1259C 1207

2+2

COAX

Door opening

2

4878KC

Variant with additional cameras for single-family kit

*

6101B

+6114KC

*

6101W

+6114KC

2

2+2

1256 1207

Door opening

2+2

4878KC

2

Variant with additional lock for single-family kit

1229

6101B

+6114KC

*

2+2

1207

6101W

+6114KC

Door opening

2+2

Door opening

4879KC

Variant with floor door call connection and additional bell for single and two-family kit

For PLANUX LUX monitor use

art. 6101W/C + 6114KC

or art. 6101B/C + 6114KC

For SMART monitor use

art. 6302

For BRAVO monitor use

art. 5702+5714KC (COLOUR) or

art. 5701+5714/K (B/W)

15

ACCESSORIES

4878K B/W single-family external unit simplebus - IKALL kit

Audio/video external unit with black 1-button faceplate, fitted with

4680K jack, die-cast aluminium module-holder frame and flushmounted box. Dimensions: 125x125x45 mm.

4878KC Colour single-family external unit simplebus - IKALL kit

Audio/video external unit with black 1-button faceplate, fitted with 4680KC jack, die-cast aluminium module-holder frame and flushmounted box. Dimensions:

125x125x45 mm.

4879K B/W two-family external unit simplebus - IKALL kit

Audio/video external unit with black 2-button faceplate, fitted with4680K jack, die-cast aluminium module-holder frame and flushmounted box. Dimensions:

125x125x45 mm.

4879KC Colour two-family external unit simplebus - IKALL kit

Audio/video external unit with black 2-button faceplate, fitted with 4680KC jack, die-cast aluminium module-holder frame and flushmounted box. Dimensions:

125x125x45 mm.

31121 Natural anodised aluminium rain shield

Natural anodised aluminium rain shield. 1 module. Dimensions 154x152x44 mm.

31161 Natural anodised aluminium housing with rain shield

Natural anodised aluminium housing with rain shield. 1 module. Dimensions

154x152x85 mm.

4680K IKALL series simplebus kit b/w audio/video unit

Simplebus Color system audio/video unit with terminal block complete with front-adjustable wide-angle 1/4” B/W camera and LED camera illumination.

Complete with terminal block and digital audio management system with

Eco-cancelling, watertight loudspeaker and electrets microphone; loudspeaker volume can be adjusted from the front. Complete with microprocessor and DIP

SWITCH with 8 positions for programming calls to users. Audiovisual indications for disabled individuals assistance request can be activated via programming.

33Vdc power supply via special power supply unit Art. 1595. On-board electronic lock-release function (3A), plus C, NC, NO contacts for 10A relay. For use in modules Art. 33410, 33411 and 33412. Dimensions: 102x55x38 mm.

4680KC IKALL series simplebus kit colour audio/video unit

Simplebus Color system audio/video unit with terminal block complete with front-adjustable wide-angle 1/4” colour camera and LED camera illumination.

Complete with terminal block and digital audio management system with

Eco-cancelling, watertight loudspeaker and electrets microphone; loudspeaker volume can be adjusted from the front. Complete with microprocessor and DIP

SWITCH with 8 positions for programming calls to users. Audiovisual indications for disabled individuals assistance request can be activated via programming.

33Vdc power supply via special power supply unit Art. 1595. On-board electronic lock-release function (3A), plus C, NC, NO contacts for 10A relay. For use in modules Art. 33410, 33411 and 33412. Dimensions: 102x55x38 mm.

4880 1 user external panel for B/W kit

Flush/Surface-mounted external video entry phone (the external unit is surface mounted but a box art. 3554 is also provided to allow flush mounted installation of the external unit) with anodized aluminium facing and ample name holder slots, with LED rear-lighting. 12V AC power supply. Dimensions of external unit:

95x176x15 mm. Dimensions of flush-mounted box: 95,5x176x5x35 mm.

4881 2 user entrance panel for B/W kit

Flush/Surface-mounted external video entry phone (the external unit is surface mounted but a box art. 3554 is also provided to allow flush mounted installation of the external unit) with anodized aluminium facing and ample name holder slots, with LED rear-lighting. 12V AC power supply. Dimensions of external unit: 95x176x15 mm. Dimensions of flush-mounted box: 95,5x176x5x35 mm.

4882 2 user entrance panel for colour

Flush/Surface-mounted external video entry phone (the external unit is surface mounted but a box art. 3554 is also provided to allow flush mounted installation of the external unit) with anodized aluminium facing and ample name holder slots, with LED rear-lighting. 12V AC power supply. Dimensions of external unit: 95x176x15 mm. Dimensions of flush-mounted box: 95,5x176x5x35 mm.

4883 2 user entrance panel for colour kit

Flush/surface-mounted external video entry phone (the external unit is surface mounted but a box art. 3554 is also provided to allow flush mounted installation of the external unit) with anodized aluminium facing and nameplate holder, with LED rear-lighting. 12V AC power supply. Dimensions of external unit: 95x176x15 mm. Dimensions of flushmountedbox: 95,5x176x5x35 mm.

3550 Flush-mounted external unit

Flush-mounted door entry phone external unit with front in anodised aluminium and large nameholder label lit from the rear with an LED. Complete with speaker unit, adjustment of the 2 volumes, callgenerator, watertight loudspeaker and electret micro-phone. 12V AC power supply. Dimensions of external unit:95x176x15 mm.

Dimensions of flushmounted box: 95,5x176,5x35 mm.

3551 Surface-mounted external unit

Surface-mounted door entry phone external unit with front in anodised aluminium and large nameholder label lit from the rear with an LED. Complete with speaker unit, adjustment of the 2 volumes, call generator, watertight loudspeaker and electret microphone. 12V AC power supply. Dimensions of external unit: 95x176x25mm.

3552 Flush-mounted external unit

Flush-mounted door entry phone external unit with front in anodised aluminium and large nameholder label lit from the rear with an LED. Complete with speaker unit, adjustment of the 2 volumes, callgenerator, watertight loudspeaker and electret micro-phone. 12V AC power supply. Dimensions of external unit: 95x176x15 mm.

Dimensions of flush-mounted box: 95,5x176,5x35 mm.

3553 Surface-mounted external unit

Surface-mounted door entry phone external unit with front in anodised aluminium and large nameholder label lit from the rear with an LED. Complete with speaker unit, adjustment of the 2 volumes, call generator, watertight loudspeaker and electret microphone.12V AC power supply. Dimensions of external unit: 95x176x25mm.

3560 Flush-mounted external unit 2 wire

Flush-mounted door entry external unit with front in anodised aluminium and 1 aluminium call push-button, large name holder lit from the rear with an LED. Complete with speaker unit, adjustment of the 2 volumes, watertight loudspeaker and electret microphone. Dimensions of external unit: 95x176x15 mm.

3561 Surface-mounted external unit

Flush-mounted door entry external unit with front in anodised aluminium and 2 aluminium call push-button, large name holder lit from the rear with an LED. Complete with speaker unit, adjustment of the 2 volumes, watertight loudspeaker and electret microphone. Dimensions of external unit: 95x176x15 mm.

3573 3-button external unit for 5-wire STYLE kit

Flush-mounted door entry phone external unit with the faceplate in anodised aluminium and a single call pushbutton, large name holder backlit with the exclusive blue

LED. Complete with speaker unit, call volume adjustment, call generator, watertight loudspeaker and electret microphone. 12V AC power supply. Dimensions of external unit: 95x176x15 mm.

3574 4-button external unit for 5-wire STYLE kit

Flush-mounted door entry phone external unit with the faceplate in anodised aluminium and a single call pushbutton, large name holder backlit with the exclusive blue LED. Complete with speaker unit, call volume adjustment, call generator, watertight loudspeaker and electret microphone. 12V AC power supply. Dimensions of external unit: 95X176X15 mm.

3554 Spare flush mounted box for IDEA

Flush-mounting box. Dimensions: 95,5x176,5x35mm.

4887 Waterproof housing for idea surface-mounted entrance panel

Protection housing with rain shield for Idea wall-mounted keypad.

Dimensions: 119x196x76 mm.

4889 Waterproof shield for idea flush-mounted entrance panel

Protection visor with rain shield for Idea flush-mounted button pad.

Dimensions: 115x195x52 mm.

5801 Monitor GENIUS series B/W handset

Genius monitor with 4’ B/W screen, white matt finish. Fitted as standard with blue door-open pushbutton and two grey pushbuttons for various functions. It has brightness control and a selector for the call volume, adjustable to three different positions (high, medium and low). It can be converted into a desk version using art. 5712. Dimensions: 204x225x63 mm.

5802 Monitor GENIUS series colour handset

Genius monitor with 3,5’ colour screen, white matt finish. Fitted as standard with blue door-open pushbutton and two grey pushbuttons for various functions. the brightness control and a selector for the call volume, adjustable to three different positions (high, medium and low). It can be converted into the desk version using art. 5712. Dimensions: 204x225x63 mm.

5814K Geniuskit B/W additional bracket

Completion bracket for monitor art. 5801. Fitted with branch terminal art.

1214/2.

5814KC Geniuskit colour additional bracket

Completion bracket for Genius monitor art. 5802. Provided with branch terminal 1214KC.

5701 Monitor BRAVO series B/N handset

Handset version Bravo monitor with 4’ B/W screen, The chrome keys, the brilliant white gloss finish combined with the silver colour base combined with the etched glass effect facia. It is fitted as standard with door open pushbuttons and two pushbuttons for various functions, signalling LED, brightness adjustment, contrast adjustment, and slide call volume adjustment. The

Call tone function, which allows the call tone to be temporarily excluded, is standard and is obtained by positioning the call volume on zero. It can be converted into a desk version with art. 5712. Dimensions: 212x225x55 mm.

5702 Monitor BRAVO series colour handset

Handset version Bravo monitor with 3.5’ colour screen. The chrome keys, the brilliant white gloss finish combined with the silver colour base combined with the etched glass effect facia. It is fitted as standard with door open pushbuttons and two pushbuttons for various functions, signalling

LED, brightness adjustment, contrast adjustment, and slide call volume adjustment. The “Call tone’ function, which allows the call tone to be temporarily excluded, is standard and is obtained by positioning the call volume on zero. It can be converted into a desk version with art. 5712. Dimensions:

212x225x55 mm.

5714/K Bravokit B/W additional bracket

Completion bracket for Bravo monitor art. 5701. Fitted with branch terminal art. 1214/2.

5714KC Bravokit colour additional bracket

Completion bracket for Bravo monitor with colour Bravokit. Fitted with branch terminal art. 1214KC.

5712 Desk base with bushing for Bravo/Genius monitor

Desk base. Allows conversion into desk version of all the GENIUS/BRAVO monitors both in the handset and hands-free versions. Complete with 2 mt of cable and connection box. Dimensions: 173x186.5x174 mm.

5733 Bravo monitor additional 4 buttons

Card with 4 additional pushbuttons (N/O or for digital services), provided with screws. Can be inserted inside all the BRAVO series monitors rapidly without having to open the monitor.

5734 Bravo monitor additional 2 buttons and 2 leds

Card with 2 additional pushbuttons (N/O or for digital services) and 2 additional LEDs, provided with screws. Can be inserted inside all the BRAVO series monitors rapidly without having to open the monitor.

6302 Smart series SBC/kit system hands-free colour monitor

Flush-mounted (on box Art. 6117) or Surface Mounted (with bracket Art.

6320) colour monitor with 3.5” screen and Full-Duplex hands-free audio.

Allows audio volume adjustment, ringtone volume adjustment with privacy activation indicator light and brightness control. Fitted as standard with key button, audio enabling/disabling button with corresponding indication

LEDs and 2 other buttons pre-set for self-ignition and switchboard call (these can, however, be programmed for various uses). It is normally used for local floor call management and call repetition, and comes complete with an 8-position DIP SWITCH for user code programming, as well as a second

8-position DIP SWITCH for programming management. Inclusion of the button card Art. 6333 allows a further 5 additional programmable buttons to be made available. The monitor can be used in SBC Simplebus TOP colour systems, or as an additional monitor for Simplebus KITS. Dimensions

138x138x24 mm.

6312 Desk base with bushing for Smart monitor

Adjustable tilt desk base converts the Smart monitor into a desktop version.

Complete with 1 x 2 m labelled RJ45 cable for connecting the monitor terminals to the clasp or to a civil series jack. Dimensions: 145x190x120 mm.

6320 Supporto da parete per monitor Smart

Adjustable tilt desk base converts the Smart monitor into a desktop version.

Complete with 1 x 2 m labelled RJ45 cable for connecting the monitor terminals to the Junction box or to a civil series jack. Dimensions:

145x190x120 mm.

6333 Accessory for 5 additional buttons on the Smart monitor

Accessory for Smart monitor which allows the addition of 5 extra programmable buttons for digital services. Can be installed quickly, without opening up the monitor.

6101B PLANUX series hands-free colour monitor - absolute black

Colour monitor with 3.5” On-Screen Display. With touch-sensitive technology and full-duplex hands-free function. Audio volume, call volume, colour, brightness and contrast adjustment. Ringtones can be customised, selecting from the 7 melodies provided. Backlit control panel consisting of:

1 key button, 1 enable/disable audio button, 1 privacy or doctor function button which can be selected via the menu (with red LED to indicate privacy enabled), 1 self-ignition button, 2 buttons for various uses and 4 buttons for entry, confirmation and navigation within the menus. The monitor, used in conjunction with art. 6112, can be converted into the desk version. Dimensions 145x145x33 mm.

17

18

6101W PLANUX hands-free colour monitor - white

Colour monitor with 3.5” On-Screen Display. With touch-sensitive technology and full-duplex hands-free function. Audio volume, call volume, colour, brightness and contrast adjustment. Ringtones can be customised, selecting from the

7 melodies provided. Backlit control panel consisting of: 1 key button, 1 enable/ disable audio button, 1 privacy or doctor function button which can be selected via the menu (with red LED to indicate privacy enabled), 1 self-ignition button,

2 buttons for various uses and 4 buttons for entry, confirmation and navigation within the menus. The monitor, used in conjunction with art. 6112, can be converted into the desk version. Dimensions 145x145x33 mm.

6101B/C PLANUX LUX series hands-free colour monitor - black

Colour monitor with 3.5” On-Screen Display and glass cover. With touchsensitive technology and full-duplex hands-free function. Audio volume, call volume, colour, brightness and contrast adjustment. Ringtones can be customised, selecting from the 7 melodies provided. Backlit control panel consisting of: 1 key button, 1 enable/disable audio button, 1 pri vacy or doctor function button which can be selected via the menu (with red LED to indicate privacy enabled),

1 self-ignition button, 2 buttons for various uses and 4 buttons for entry, confirmation and navigation within the menus. Dimensions 160x167x4 mm.

6101W/C PLANUX LUX series hands-free colour monitor - white

Colour monitor with 3.5” On-Screen Display and glass cover. With touch-sensitive technology and full-duplex hands-free function. Audio volume, call volume, colour, brightness and contrast adjustment. Ringtones can be customised, selecting from the 7 melodies provided. Backlit control panel consisting of: 1 key button, 1 enable/disable audio button, 1 privacy or doctor function button which can be selected via the menu (with red LED to indicate privacy enabled),

1 self-ignition button, 2 buttons for various uses and 4 buttons for entry, confirmation and navigation within the menus. Dimensions 160x167x4 mm.

6114KC PLANUX kit colour additional bracket

The video door entry system is complete conversation privacy as standard.

Handles local floor calls and call repetition as standard. Dimensions: 96x106x17 mm.

6101L/C Template PLANUX LUX MONITOR White

6101N/C Template PLANUX LUX MONITOR Black

6112 Desk base with junction box for PLANUX monitor

Desk base allowing the Planux monitor to be converted for desk use, complete with two 2 m RJ45 headed cables: one for connection to the VIP network, the other to connect the extra terminals to the junction box. Dimensions: 145x190 x120 mm.

6117 Flush-mounted box for PLANUX and SMART monitors

Flush-mounted box for Planux and Smart monitors. Accessory art. 6122 can be used for tilting the Planux monitor. Dimensions: 132x132x50 mm.

6118 Plasterboard installation kit for Planux and Smart monitors

Accessory allowing installation of Planux monitors on plasterboard walls, without the application of box art. 6117. Installation kit for plasterboard walls.

6120 Surface-mounted support for PLANUX monitor

Short surface support for Planux monitor for use with tilt facility art 6122 Accessory art. 6122 cannot be used for tilting. Dimensions: 145x145x26 mm.

6121 High surface-mounted support for PLANUX monitor

Long support for Planux monitor wall mounting Accessory art. 6122 can be used for tilting. Dimensions: 145x145x45 mm.

6122 Tilting accessory for planux monitors

Accessory for tilting Planux monitors to be used in combination with the long support art.6121 and the flush-mounted box art. 6117. Dimensions:

136x136x40 mm.

2602 STYLE series 4 +1 traditional system BASIC intercom

Telephone with electronic call, conversation button on the base, call tonevolume adjustment and privacy, door opener pushbutton and supplementary isolated pushbutton for additional services with independent common. With this model, addition of pushbuttons or supplementary LEDs is not possible.

Dimensions: 95x215x58 mm.

2608 STYLE series simplebus system BASIC intercom

Telephone with electronic call call tone adjustment, privacy of speech, call tone privacy, door open pushbutton and supplementary pushbutton for porter switchboard call or free (C/N.O.). By means of selection jumper, the second pushbutton can be used to control actuator art. 1256. Allows management of the local floor call and call repetition. Complete with dip-switch with 8 positions for selection of the desired user code. With this model, addition of pushbuttons or supplementary LEDs is not possible. Dimensions: 95x215x58 mm. From the

RI006 it is compatible with all SBTOP functions and products.

2610 STYLE series Simplebus top/kit system ELEGANCE intercom

Telephone with electronic call, call volume adjustment, privacy of speech, call tone privacy. Fitted as standard with door open pushbuttons, porter switchboard call, actuator control Art. 1256 and LED for various functions (engaged and doctor function). Up to 6 supplementary pushbuttons can be added, of which a maximum of 3 LEDs. Allows management of the floor door call and call repetition. Complete with dip-switch with 8 positions for selection of the desired user code. Telephone to be used in mixed audio/video Simplebus 1, Simplebus 2 systems. Fitted with branch terminal art. 1214/2C. With this model, the facia can be replaced. From the RI010 it is compatible with all SBTOP functions and products. Allows direct intercommunication between users with the same address

(without the aid of an interface or porter switchboard), transmission of alarm signals to the porter switchboard, separate call to main switchboard, secondary switchboard and guardian door-entry phone. Dimensions: 95x215x58 mm.

2612 STYLE series BASIC intercom for 2-wire

Additional entry phone for kit 8270, with electronic call, call button on the base, call volume adjustment, privacy, door open pushbutton and free (C/N.O.) pushbutton. Dimensions: 95x215x58 mm.

2628 STYLE series Simplebus2 system ELEGANCE intercom - white

Telephone with electronic call call volume adjustment, privacy call tone, privacy of speech. Fitted with door open pushbutton, switchboard call, actuator control art. 1256 and free (C/N.O.). Up to 6 supplementary pushbuttons can be added, of which a maximum of 3 LEDs. Allows management of the local floor call and call repetition. Complete with dip-switch with 8 positions for selection of the desired user code. Telephone to be used in mixed audio/video systems

(Simplebus 1 and Simplebus 2) or in audio systems when the call repetition function is required. Fitted with terminal 1214/2. With this model, the can facia can be replaced. Dimensions: 95x215x58 mm. From the RI005 it is compatible with all SBTOP functions and products.

1229 Accessory - additional ringtone

Additional bell for call repetition can be controlled directly from terminals S- and S+ of the brackets and/or from the telephones. Surfacemounted or on civil series 503 box. Dimensions: 110x75x29 mm.

1224A Simplebus system digital switching device

Switching device for audio or audio-video systems with 2 or more entrances.

Complete with 2 DIP SWITCHES with 8 positions for defining the user range of the riser. 12V AC power supply (use transformer Art. 1200/U). Dimensions:

60x85x35 mm (4 DIN modules).

4833/A Line amplifier for SIMPLEBUS video systems

Video amplifier to be used in the following cases: 1. After the 50th mo nitor in systems with more than 50 monitors. 2. Each 150 m. (if twisted pair is used) or 100 m. (if normal cable is used) or 80 m. (if twisted and shielded pair is used). 3. At the base of each riser in systems with video main panel and audio or video secondary panels. 4. At the base of each riser in systems with main panel and star-connected risers (max 10). Power supplied at 12 VAC. Dimensions

66x85x35 mm (4 DIN modules).

4833C Line amplifier for SIMPLEBUS color video systems

Amplifier for Simplebus Color video systems. Regenerates the riser signal regarding the video component. Complete with microcontroller for optimum operation management. For its use, follow the indications given in the technical documentation. Power supply: 12V AC or 20V DC. Only to be mounted on the part of the system on input into the mixers art. 4888CU (Simplebus 1 part).

Dimensions: 66x85x35 mm (4 DIN modules).

1122/A 12-24 Vdc-Ac general purpose relay

All systems. 12-24 V DC-AC 10 A relay for general uses. Can be controlled directly, for call repetition, from terminals S+ and S of the brackets and/or from the digital telephones Dimensions:68x85x35 mm (4 DIN modules).

1256 Simplebus system digital relay actuor

Intelligent Simplebus device for controlling a 10 A (12-24 V relay contact) on board. It can be used in Simplebus 1 and Simplebus 2 systems. For use and programming of the function required, follow the indications given in the technical documentation. If used in mixed audio/video systems, the actuator relay needs terminal art. 1214/2 to be purchased separately. Power supply: 12V AC or 20V DC. Dimensions: 66x85x35 (4 DIN modules).

1259/A Switcher for remote cameras

Module which allows modulation and transmission of the video signal coming from 3 B/W cameras visible sequentially together with the image coming from the external unit.Sequential switching of the cameras is possible by using the

Bravo or Videocom monitor actuator pushbutton. Possibility of managing private cameras. Power supply: 12 V AC or 20 V DC. Dimensions: 60x85x35 mm (4

DIN modules).

1259C Simplebus colour kit for separate video cameras

Module which allows modulation and transmission of the video signal coming from 3 colour cameras visible sequentially together with the image coming from the external unit. Sequential switching of the cameras is possible by using the Diva, Bravo or Genius actuator pushbutton. Possibility of managing private cameras. Power supply: 12 V AC or 20 V DC. Dimensions: 60x85x35 mm (4 DIN modules).

1214/2 Simplebus 2 connection terminal

Line branch terminal. The terminal is to be mounted on the riser to branch towardsbrackets or telephones. It is provided as standard with the bracket art.

4714W/2.use. Dimensions: 53x95x65 mm (3 DIN modules).

1214/2C Simplebus 2 and Simplebus colour connection terminal

Line branch terminal for GENIUS monitor. The terminal must be connected on the riser to be branched towards brackets or telephones.

1215 Simplebus2/colour/kit connection terminal

Terminal required when expanding the system with an additional SMART door entry monitor. Dimensions 20x20x25 mm.

1216 Simplebus/kit system terminal

Line termination terminal. To be mounted at the end of the riser, according to the indications given in the technical documentation, to optimise distribution of the signals.

1200 12Vac transformer with 230Vac input

Transformer with 230V primary winding, 12V AC / 900 mA secondary winding for continuous use.Dimensions: 53x95x65 mm (3 DIN modules).

1205/B 12Vac - 20Vdc dual output power supply with 230Vac input

Technical characteristics: The transformer has 2 outputs: one to supply the external unit and the electric lock, and one to supply the monitor.

Dimensions: 105x85x85.mm 500mA delayed protection fuse.Terminal board:AC230V input mains voltage ~~ AC output for external unit and electric lock+ - 20V DC output for the monitor power supply.

1207 Dual power supply unit, output 33Vdc-20 Vdc, input 230 Vac

Power supply unit with overload and short circuit protection devices. It has two separate continuous outputs: one to power the external unit and electric lock, and the other to power the monitor. Input voltage 120-230 VAC.

Dimensions: 105x85x85 mm (6 DIN modules).

1212/B 20Vdc 14Va power supply with 230Vac input

Power supply with 230V AC input, 0-20V DC / 15VA output. The transformer is fitted with PTC internal protection. Dimensions:71.5x90x62 mm (4 DIN modules).

4576/100 SIMPLEBUS system Comelit cable 2x0.5 mm2 + 2x1.5

mm2 - 100 m

Specific cable for Simplebus 1 systems consisting of two power supply conductors (1.5 mm2) and a small telephone braid for the signals.

100 mt coil.

4576/500 SIMPLEBUS system Comelit cable 2x0.5 mm2 + 2x1.5

mm2 - 500 m

Specific cable for Simplebus 1 systems consisting of two power supply conductors (1.5 mm2) and a small telephone braid for the signals. 500 mt coil.

4578/100 SIMPLEBUS external Comelit 100 m cable 2x0.5 mm2 +

2x1.5 mm2

Specific cable for outdoors for Simplebus systems 2 consisting of two power supply conductors (1.5 mm2) and a small telephone braid for the signals.

100 mt coil.

4578/500 SIMPLEBUS external Comelit 500 m cable 2x0.5 mm2 +

2x1.5 mm2

Specific cable for outdoors for Simplebus systems 2 consisting of two power supply conductors (1.5 mm2) and a small telephone braid for the signals.

500 mt coil.

19

[ I ]

Comelit Group Spa

Via Don Arrigoni 5

24020 Rovetta S. Lorenzo

Bergamo Italy

Tel. +39 (0) 346 750011

Fax +39 (0) 346 71436 www.comelitgroup.com - [email protected]

[ B ] Comelit Group Belgium

Doornveld 170

1731 Zellik (Asse)

Tel. +32 24115099

Fax +32 24115097 www.comelit.be - [email protected]

[ D ] Comelit Group Germany GmbH

Brusseler Allee 23 - 41812 Erkelenz

Tel. +49 243190151-23 - 49 243190151-24

Fax +49 24319015125 www.comelit.de  [email protected]

[ E ]

Comelit Group Spa- Sucursal en España

Calle Pintor Roig i Soler 28

08916 Badalona, Barcelona Spain

+34 932430376

+34 934084683 www.comelit.es

[email protected]

[ F ]

Comelit Immotec

Siège: 18, rue Séjourné

94000 CRETEIL CEDEX

Tél. +33 (0) 1 43 53 97 97

Fax +33 (0) 1 43 53 97 87 www.comelit.fr [email protected]

[ GR ] Comelit Hellas

9 Epiru str. - 16452 Argiroupolis

Athens Greece

Tel. +30 210 99 68 605-6

Fax +30 210 99 45 560 www.comelit.gr - [email protected]

[ IRL ]

Comelit Ireland

Ground Floor

14 Herbert Street - Dublin 2

Tel. +353 (0) 1 619 0204

Fax +353 (0) 1 619 0298 www.comelit.ie - [email protected]

[ NL ]

Comelit Nederland BV

Buitendijks 1 - 3356 Lx Papendrecht

Tel. +31 786511201

Fax +31 786170955 www.comelit.nl

[email protected]

[ PRC ] Comelit (Shanghai)

Electronics Co.,Ltd

5 Floor No. 4 Building No.30,

Hongcao Road, Hi-Tech Park

Caohejing,

Shanghai, China

Tel. +86-21-64519192/9737/3527

Fax +86-21-64517710 www.comelit.com.cn [email protected]

[ SG ]

Comelit Far East

Block 1002, Nr.06-1407

Toa Payoh Industrial Park

Singapore 319074

Tel. +65 6352 3456

Fax. +65 6352 8557 [email protected]

[ UAE ] Comelit Group U.A.E.

Middle East Office

P.O. Box 54433

Dubai U.A.E.

Tel. +971 4 299 7533

Fax +971 4 299 7534 www.comelit.ae [email protected]

[ UK ] Comelit Group UK Ltd

Unit 4 Mallow Park - Watchmead

Welwyn Garden City Herts

AL7 1GX

Tel: +44 (0)1707377203

Fax: +44 (0)1707377204 www.comelitgroup.co.uk [email protected]

[ USA ] Comelit Usa

2021 S. Myrtle Avenue

Monrovia, CA 91016

Tel. +1 626 930 0388

Fax +1 626 930 0488 www.comelitusa.com [email protected]

Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo - Bergamo [Italy]

Ph. +39 (0) 346 750011 - Fax +39 (0) 34671436 - www.comelitgroup.com - [email protected]

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
