THE FUTURE IS ON

®

Smart Products.

Ingenious Solutions.

Wiring Devices, Energy Management

Solutions and Commercial Data

Infrastructure Products

L-200

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Time-Saving Systems

INDEX

LevLok ®

Wiring Modules ............................................. 656

Hospital Grade

Industrial Grade

Commercial Grade

Commercial Grade

EZE Rough ® ....................................................... 677

PowerMount™ .................................................. 679

Residential and Commercial Grade

Cheetah Speed Systems™

Dimmers & Fan Speed Controls .................... 694

Screwless Wallplates ................................... 696

Wallplate Housings & Connectors ................ 699

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

655

Time-Saving Systems

Lev-Lok

®

Modular Wiring Devices Are Easy To Install

ROUGH-IN STEPS

1 - Attach MSTWL Wiring Module

• Attach wiring module. Pre-stripped leads equals one less tool.

• Peel back the module’s protective cover to test.

• Place the protective cover back over the contacts.

• Label circuit using the factory installed circuit ID label.

2 - Ready for Drywall & Painting

• Place wired and protected module inside the box.

• Finish the room – drywall, paint, flooring and don’t worry about

the wiring.

FINISHING STEPS

3 - Make the Receptacle Connection

• Remove the wiring module’s protective cover.

• Place wiring module over receptacle’s connection pins.

Twist clockwise – receptacle is secured.

4 - Finished and Ready for Use!

• Secure the receptacle’s strap and wallplate.

656

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Lev-Lok

®

Modular Wiring Device System

Simple & Easy to Use, Yet Provides Secure Connections.

Leviton’s latest wiring device family is a revolutionary design called the Lev-Lok ® Modular Wiring Device System. It consists of a wiring module (locking connector with leads) and a rugged wiring device (receptacle or switch) with solid brass locking connection pins. Place the wiring module over the device’s locking pins, twist clockwise and the connection is secured. Leviton’s modular devices address the reliability and performance concerns of specification engineers without sacrificing the contractor’s need for fast, easy installation.

Specifications and Features

• Devices constructed with impact-resistant thermoplastic nylon cover and body

• Four corner latches securely fasten the device’s face to the body

• Solid brass locking pins for strong, secure connection between device and wiring module

• Backed by a Limited Ten-Year Warranty

• Wiring module locks and latches to the device

• Wiring module ships with protective cover, preventing debris from entering contacts until device is attached

• Wiring modules include factory-installed circuit ID label. Electricians can save a step by labeling device locations during rough-in

• Receptacles offered in commercial, industrial and hospital grades; in both conventional and tamper-resistant configurations

Simple…

Designed with the busy contractor in mind.

Wiring Modules arrive equipped with a protective cover and a circuit ID label.

The protective cover keeps the

Lev-Lok™ module’s contacts debrisfree until the receptacle is installed.

Use the wiring module’s circuit

ID label and make walkthrough troubleshooting faster and easier.

Easy…

Connect and twist to lock.

In two steps, the receptacle is securely attached to the module. Place the module over the receptacle’s connection pins and twist clockwise to lock. The locking design allows only one module orientation.

Replacement is just as easy. Reverse the two steps. Turn module counter clockwise to unlock and remove.

Secure…

Lock & latch system.

Leviton’s unique connection system locks and latches the

Lev-Lok™ wiring module to the receptacle providing double the security without adding to the assembly steps.

Wiring module with protective cover

Place wiring module over

connection pins

Wiring module locked and latched

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

657

Time-Saving Systems

Wiring Modules

Lev-Lok

®

Wiring Modular Receptacle System

Specifications and Features

• Modules are constructed of an impact-resistant polycarbonate

• #12 AWG THHN wire leads, 6” length, either solid or stranded wire

• Available with 4-port pushwire connector for even faster installation

• Wiring module locks and latches to the device body providing double the connection security

• Wiring modules are shipped with protective cover and factory-installed circuit ID label

• Backed by a Limited Ten-Year Warranty

Wiring modules include factory-installed circuit ID label so that electricians can save a step by labeling device locations during rough-in

MSTWL-IG MSTWL-WST

MSTWL-A

658

LEV-LOK

®

WIRING MODULES

Device Type Description

Receptacles Stranded Wire Leads

Stranded Wire Leads with 4-port push wire connectors

Solid Wire Leads

Solid Wire Leads with 4-port push wire connectors

IG Receptacles Stranded Wire Leads

Stranded Wire Leads with 4-port push wire connectors

Solid Wire Leads

Cat. No.

MSTWL-A

MSTWL-WST

MSTWL-SDA

MSTWL-WSD

MSTWL-IG

MSTWL-WIG

MSTWL-SIG

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Decora Plus™ Extra Heavy-Duty Hospital Grade Modular Receptacles

Hospital Grade

Specifications and Features

• Constructed with impact-resistant thermoplastic nylon cover and body

• Smooth face prevents dirt from collecting

• Four corner latches securely fasten the receptacle’s face to the body

• Large triple-wipe, brass “T” line contacts for superior contact and conductivity

• #12 AWG THHN wire leads, 6” length on MSTWL series wiring modules

• Nickel-plated brass single-piece, wrap-around mounting strap with integral ground contact for continuous conductivity and secure ground path

• For Isolated Ground versions, device strap is nickel plated steel and isolated ground system is brass

• Grounding clip permanently secured to strap for easy, simple, and secure installation

• Wiring module locks and latches to the receptacle body providing double the connection security

• Receptacle to be installed only with Leviton MSTWL series wiring modules

• MSTWL wiring module shipped separately with protective label and factory-installed Circuit ID label

• Backed by a Limited Ten-Year Warranty

Two latches mate with wiring module for twice the security

Grounding clip permanently secured to strap makes for most reliable ground connection

Solid Brass locking pins for strong, secure connection between receptacle and wiring module

Smooth receptacle face makes cleaning faster and simpler

Constructed with impact-resistant thermoplastic nylon cover and body

Four corner latches securely fasten the receptacle’s face to the body

Nickel-plated brass single-piece, wrap around mounting strap with integral ground contacts for continuous conductivity and secure ground path

M1636-HGW

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

659

Time-Saving Systems

Hospital Grade

MT163

WITH

MSTWL-A

MDT83-IG

DECORA PLUS™ MODULAR RECEPTACLES

2-Pole, 3-Wire Grounding

Description Color Cat. No.

NEMA

Rating

Duplex, Tamper Resistant

Duplex

Duplex, Power Indication

Duplex, Isolated Ground,

Tamper Resistant

Duplex, Isolated Ground

Duplex, Isolated Ground,

Power Indication

Cat. No.

White

Ivory

Grey

Red

White

Ivory

5-15R 5-20R

15A–125V 20A-125V

MT162-HGW

MT162-HGI

MT162-HGG

MT162-HGR

M1626-HGW

M1626-HGI

Light Almond M1626-HGT

Grey M1626-HGG

MT163-HGW

MT163-HGI

MT163-HGG

MT163-HGR

M1636-HGW

M1636-HGI

M1636-HGT

M1636-HGG

Black M1626-HGE M1636-HGE

Brown M1626-HG0 M1636-HG0

Red

Blue

M1626-HGR

M1626-HGB

M1636-HGR

M1636-HGB

White M1626-PLW M1636-PLW

Ivory M1626-PLI M1636-PLI

Light Almond M1626-PLT

Grey M1626-PLG

M1636-PLT

M1636-PLG

Red

White

M1626-PLR

MDT82-IGW

Ivory MDT82-IGI

Light Almond MDT82-IGT

M1636-PLR

MDT83-IGW

MDT83-IGI

MDT83-IGT

Black MDT82-IGE MDT83-IGE

Orange MDT82-IG MDT83-IG

White MD820-IGW MD830-IGW

Ivory MD820-IGI MD830-IGI

Light Almond MD820-IGT MD830-IGT

Black MD820-IGE MD830-IGE

Orange MD820-IG MD830-IG

White MPD82-IGW MPD83-IGW

Ivory MPD82-IGI MPD83-IGI

Orange MPD82-IG MPD83-IG

660

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Hospital Grade

TESTING AND CODE COMPLIANCE

• NEMA WD 1 and 6

• cULus Listed

• NOM Certified (#057)

• ANSI Standard C-73

ENVIRONMENTAL

• Flammability: Rated V-2 per UL-94

• Operating Temperature: -40°C (without impact) to 60°C

Continuous

MATERIAL SPECIFICATIONS:

• Cover: Nylon

• Base: Nylon

• Mounting Strap (non-IG): Single Piece Nickel-Plated Brass

with integral ground contact

• Mounting Strap (IG versions): Nickel-Plated Steel

• Isolated Ground System (IG Versions): Brass

• Ground Clip: Nickel-Plated Brass

• Line Contacts: 0.040” Thick Brass

• Locking Pins: Solid Brass

• Mounting Screws: Triple Combination Head, Steel

• Shutter Mechanism (Tamper Resistant versions):

Delrin ® Acetal

DIMENSIONS

lev-lok ®

M1636 20 Amp-125 Volts

Dimensions apply to

Cat. Nos.

M1626-HG, MT162-HG,

M1626-PL, M1636-HG,

MT163-HG, M1636-PL &

MSTWL-A

ELECTRICAL

• Dielectric Voltage: Withstands 2000V per UL 498HG

• Max. Working Voltage: 125V as rated

• Current Interrupting: Full rated current

• Temp. Rise: Max 30°C after 250 cycles of overload at 200% of rated current

MECHANICAL

• Product I.D.: Ratings are permanently stamped on device

HORSEPOWER

15A - 125V — 1 ⁄

2

20A - 125V — 1

Standard, PI, MRI Tamper Resistant

M1636 – IGO

Dimensions apply to Cat. Nos.

M1626-IG, M1636-IG, MPD83-IG & MSTWL-IG, MD820-IG,

MD830-IG, MPD82-IG, MPD83-IG

MDT82 – IG

Dimensions apply to Cat. Nos.

MT162-IG, MT163-IG, MT163-IG & MSTWL-IG, MDT82-IG,

MDT83-IG

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

661

Time-Saving Systems

Hospital Grade

Extra Heavy-Duty Hospital Grade Modular Receptacles

Specifications and Features

• Constructed with impact-resistant thermoplastic nylon cover and body

• Smooth face prevents dirt from collecting

• Four corner latches securely fasten the receptacle’s face to the body

• Large triple-wipe, brass “T” line contacts for superior contact and conductivity

• #12 AWG THHN wire leads, 6” length on MSTWL series wiring modules

• Nickel-plated steel, wrap-around mounting strap with integral ground contacts for continuous conductivity and secure ground path

• Grounding clip permanently secured to strap for easy, simple, and secure installation

• Receptacle face includes threaded brass bushing for reliable, secure wallplate attachment

• Wiring module locks and latches to the receptacle body providing double the connection security

• Receptacle to be installed only with Leviton MSTWL series wiring modules

• MSTWL wiring module shipped separately with protective cover and factory-installed circuit ID label

• Backed by a Limited Ten-Year Warranty

M8300-R

Grounding clip permanently secured to strap makes for most reliable ground connection

Constructed with impact-resistant thermoplastic nylon cover and body

Smooth face prevents dirt from collecting and makes cleaning faster and simpler

Face includes threaded bushing for reliable, secure wallplate attachment

Large triple-wipe “T” contacts for superior contact and conductivity day-in and day-out

Four corner latches securely fasten the receptacle’s face to the body

Two latches mate with wiring module for twice the security

Solid brass locking pins for strong, secure connection between receptacle and wiring module

Nickel-Plated Brass

Single Piece Wraparound mounting strap with integral ground contacts for continuous and secure ground path

662

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

EXTRA HEAVY-DUTY MODULAR RECEPTACLES

2-Pole, 3-Wire Grounding

Description Color Cat. No.

NEMA

Cat. No.

Rating

Duplex, Tamper Resistant

Duplex

Duplex, Power Indication

Duplex, MRI

Duplex, Isolated Ground,

Tamper Resistant

Duplex, Isolated Ground

Duplex, Isolated Ground,

Power Indication

White

Ivory

5-15R 5-20R

15A–125V 20A-125V

M8200-SGW

M8200-SGI

Light Almond M8200-SGT

Grey M8200-SGY

M8300-SGW

M8300-SGI

M8300-SGT

M8300-SGY

Black M8200-SGE M8300-SGE

Brown M8200-SG M8300-SG

Blue M8200-SGB M8300-SGB

White M8300-W

Ivory M8200-I

Light Almond M8200-T

Grey

Black

M8200-GY

M8200-E

M8300-I

M8300-T

M8300-GY

M8300-E

Brown M8200 M8300

Red

Blue

White

Ivory

M8200-R

M8200-B

M8200-PLW

M8200-PLI

Light Almond M8200-PLT

Grey M8200-PLG

Red

White

M8200-PLR

MRI15-W

M8300-R

M8300-B

M8300-PLW

M8300-PLI

M8300-PLT

M8300-PLG

M8300-PLR

MRI20-W

Ivory MRI15-I

Light Almond MRI15-T

Grey

Red

MRI15-GY

MRI15-R

White

Ivory

MT820-IGW

MT820-IGI

Light Almond MT820-IGT

MRI20-I

MRI20-T

MRI20-GY

MRI20-R

MT830-IGW

MT830-IGI

MT830-IGT

Black MT820-IGE MT830-IGE

Orange MT820-IG MT830-IG

White M8200-IGW M8300-IGW

Ivory M8200-IGI M8300-IGI

Light Almond M8200-IGT M8300-IGT

Grey M8200-IGG M8300-IGG

Black M8200-IGE M8300-IGE

Red M8200-IGR M8300-IGR

Orange M8200-IG M8300-IGG

White

Ivory

MP820-IGW

MP820-IGI

MP830-IGW

MP830-IGI

Orange MP820-IG MP830-IG

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Hospital Grade

MT830-IG

(FRONT)

MT830-IG

WITH

MSTLW-IG

(BACK)

663

Time-Saving Systems

Hospital Grade

TESTING AND CODE COMPLIANCE

• NEMA WD 1 and 6

• cULus Listed

• NOM Certified (#057)

• ANSI Standard C-73

ENVIRONMENTAL

• Flammability: Rated V-2 per UL-94

• Operating Temperature: -40°C (without impact) to 60°C

Continuous

MATERIAL SPECIFICATIONS:

• Cover: Nylon

• Base: Nylon

• Mounting Strap (non-IG): Single Piece Nickel-Plated Brass

with integral ground contact

• Mounting Strap (IG versions): Nickel-Plated Steel

• Mounting Strap (MRI versions): Brass

• Isolated Ground System (IG versions): Brass

• Ground Clip: Nickel-Plated Brass

• Ground Clip (MRI versions): Brass

• Line Contacts: 0.040” Thick Brass

• Locking Pins: Solid Brass

• Mounting Screws: Triple Combination Head, Steel

• Shutter Mechanism (Tamper Resistant versions):

Delrin ® Acetal

ELECTRICAL

• Dielectric Voltage: Withstands 2000V per UL 498HG

• Max. Working Voltage: 125V as rated

• Current Interrupting: Full rated current

• Temp. Rise: Max 30°C after 250 cycles overload at 200% of rated current

MECHANICAL

• Product I.D.: Ratings are permanently stamped on device

HORSEPOWER

15A - 125V — 1 ⁄

2

20A - 125V — 1

DIMENSIONS

lev-lok ®

M8300 20 Amp-125 Volts

Dimensions apply to

Cat. Nos.

M8200, MT820-SG, MT820-PL,

MRI15

M8300, M8300-SG, M8300-PL,

MRI20 & MSTWL -A

Standard Tamper-Resistant

CAT MT563-IG

664

M5362-IG

Dimensions apply to Cat. Nos.

M5262-IG, M5362-IG, M5362-IG & MSTWL-IG, M8200-IG,

M8300-IG, MP820-IG, MP830-IG

MT830-IG

Dimensions apply to Cat. Nos.

MT562-IG, MT563-IG, MT563-IG & MSTWL-IG, MT820-IG,

MT830-IG

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Hospital Grade

SmartlockPro

®

GFCI Receptacles

Specifications and Features

• GFCI protects one duplex receptacle. No feed-through capability

• Constructed with impact-resistant nylon cover

• Large triple-wipe, brass “T” line contacts on 20A for superior contact and conductivity

• The SmartLockPRO receptacle automatically tests the GFCI every time the RESET

button is pushed. The GFCI will not reset if the GFCI circuit is not functioning properly

• Built-in end-of-life indication. If the SmartLockPRO receptacle can no longer provide

GFCI protection, it will not reset and no power is supplied to the face

• Trip threshold meets or exceeds UL requirements for tripping time

• Right Angle Wiring module’s thin profile makes it easier to place GFCI receptacle in the box

• #12 AWG THHN wire leads, 6” length on MSTWL series wiring modules

• Wiring module locks and latches to the receptacle body providing double the connection security

• Receptacle to be installed only with Leviton MSTWL series wiring modules

• MSTWL wiring module shipped separately with protective label and factory-installed Circuit ID label

Right Angle Wiring Module makes GFCI easier to install and reduces footprint in the box

M7599-HGI

MSTWL-A

Right Angle Wiring Module

Two latches mate with wiring module for twice the security

Look for the Lock! Patented lockout feature prevents RESET if the GFCI is not wired properly or the GFCI circuit is no longer functioning properly

Impact resistant nylon cover withstands abuse

Advanced electronics offers superior resistance to surges and over-voltages

Green LED indicator light:

When illuminated, it indicates power is present

Grounding clip permanently secured to strap makes for most reliable ground connection

Solid brass locking pins for strong, secure connection between receptacle and wiring module

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

665

Time-Saving Systems

Hospital Grade

M7599-HGI

WITH

MSTWL-A

SMARTLOCKPRO

®

MODULAR RECEPTACLES

2-Pole, 3-Wire Grounding

Description Color Cat. No.

NEMA

Rating

Duplex, Tamper Resistant

Duplex

Cat. No.

White

Ivory

5-15R 5-20R

15A–125V 20A-125V

M7599-HGW

M7599-HGI

Light Almond M7599-HGT

Grey M7599-HGY

M7899-HGW

M7899-HGI

M7899-HGT

M7899-HGY

Black M7599-HGE M7899-HGE

Brown M7599-HG M7899-HG

Red M7599-HGR M7899-HGR

Ivory MT759-HGI

Light Almond MT759-HGT

Grey

Black

MT759-HGY

MT759-HGE

MT789-HGI

MT789-HGT

MT789-HGY

MT789-HGE

Brown MT759HG MT789-HG

Red MT759-HGR MT789-HGR

TESTING AND CODE COMPLIANCE

• NEMA WD 1 and 6

• cULus Listed

• NOM Certified (#057)

• ANSI Standard C-73

ENVIRONMENTAL

• Flammability: Rated V-2 per UL-94

• Operating Temperature: -40°C (without impact) to 60°C

Continuous

MATERIAL SPECIFICATIONS:

• Cover: Nylon

• Base: Polycarbonate

• Mounting Strap: Galvanized Steel with rivited ground contact

• Ground Clip: Brass

• Line Contacts: Brass

• Locking Pins: Solid Brass

• Mounting Screws: Triple Combination Head, Steel

• Shutter Mechanism (Tamper Resistant versions):

Delrin ® Acetal

ELECTRICAL

• Dielectric Voltage: Withstands 2000V per UL 498HG

• Max. Working Voltage: 125V as rated

• Current Interrupting: Full rated current

• Temp. Rise: Max 30°C after 250 cycles of overload at 200% of rated current

MECHANICAL

• Product I.D.: Ratings are permanently stamped on device

DIMENSIONS

lev-lok ®

M7899-HG 20Amp-125 Volts

Dimensions apply to

Cat. Nos.

M7599-HG, MT759-HG,

M7899-HG, MT789-HG

& MSTWL-A

666

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Industrial Grade

Extra Heavy-Duty Specification Grade Modular Receptacles

Specifications and Features

• Constructed with impact-resistant thermoplastic nylon cover and body

• Smooth face prevents dirt from collecting

• Four corner latches securely fasten the receptacle’s face to the body

• Large triple-wipe, brass “T” line contacts for superior contact and conductivity

• #12 AWG THHN wire leads, 6” length on MSTWL series wiring modules

• Solid brass, wrap-around mounting strap with integral ground contacts for continuous conductivity and secure ground path

• Grounding clip permanently secured to strap for easy, simple, and secure installation

• Receptacle face includes threaded brass bushing for reliable, secure wallplate attachment

• Wiring module locks and latches to the receptacle body providing double the connection security

• Receptacle to be installed only with Leviton MSTWL series wiring modules

• MSTWL wiring module shipped separately with protective cover and factory-installed circuit ID label

• Backed by a limited Ten-Year Warranty

M5362-W

Solid brass single-piece, wrap-around mounting strap with integral ground contacts, for continuous conductivity and secure ground path

Grounding clip permanently secured to strap makes for most reliable ground connection

Constructed with impact-resistant thermoplastic nylon cover and body

Smooth face prevents dirt from collecting and makes cleaning faster and simpler

Face includes threaded bushing for reliable, secure wallplate attachment

Large triple-wipe

“T” contacts for superior contact and conductivity day-in and day-out

Solid brass locking pins for strong, secure connection between receptacle and wiring module

Four corner latches securely fasten the receptacle’s face to the body

Two latches mate with wiring module for twice the security

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

667

Time-Saving Systems

Industrial Grade

M5262-I

WITH

MSTWL-A

EXTRA HEAVY-DUTY SPECIFICATION MODULAR RECEPTACLES

2-Pole, 3-Wire Grounding

Description Color Cat. No. Cat. No.

NEMA

Rating

Duplex, Tamper Resistant

Duplex

Duplex, Isolated Ground,

Tamper Resistant

Duplex, Isolated Ground

White

Ivory

5-15R 5-20R

15A–125V 20A-125V

M5262-SGW

M5262-SGI

Light Almond M5262-SGT

Grey M5262-SGG

M5362-SGW

M5362-SGI

M5362-SGT

M5362-SGG

Black M5262-SGE M5362-SGE

Brown M5262-SG M5362-SG

Red

Blue

M5262-SGR

M5262-SGB

M5362-SGR

M5362-SGB

White

Ivory

M5262-W

M5262-I

Light Almond M5262-T

Grey M5262-GY

M5362-W

M5362-I

M5362-T

M5362-GY

Black M5262-E M5362-E

Brown M5262 M5362

Red

Blue

White

Ivory

M5262-R

M5262-B

MT562-IGW

MT562-IGI

Light Almond MT562-IGT

M5362-R

M5362-B

MT563-IGW

MT563-IGI

MT563-IGT

Black MT562-IGE MT563-IGE

Orange MT562-IG MT563-IG

White M5262-IGW M5362-IGW

Ivory M5262-IGI M5362-IGI

Light Almond M5262-IGT M5362-IGT

Grey M5262-IGG M5362-IGG

Black M5262-IGE M5362-IGE

Red M5262-IGR M5362-IGR

Orange M5262-IG M5362-IG

668

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

TESTING AND CODE COMPLIANCE

• NEMA WD 1 and 6

• cULus Listed

• NOM Certified (#057)

• ANSI Standard C-73

ENVIRONMENTAL

• Flammability: Rated V-2 per UL-94

• Operating Temperature: -40°C (without impact) to 60°C

Continuous

MATERIAL SPECIFICATIONS:

• Cover: Nylon

• Base: Nylon

• Mounting Strap (non-IG): Single Piece Solid Brass

with integral ground contact

• Mounting Strap (IG versions): Steel

• Isolated Ground System (IG Versions): Brass

• Ground Clip: Brass

• Line Contacts: 0.040” Thick Brass

• Locking Pins: Solid Brass

• Mounting Screws: Triple Combination Head, Steel

• Shutter Mechanism (Tamper Resistant versions):

Delrin ® Acetal

DIMENSIONS

lev-lok ®

M5262 15 Amp-125 Volts

Dimensions apply to

Cat. Nos.

M5262, M5262-SG,

M5362, M5362-SG, and MSTWL-A

Lev-Lok

®

Industrial Grade

ELECTRICAL

• Dielectric Voltage: Withstands 2000V per UL 498

• Max. Working Voltage: 125V as rated

• Current Interrupting: Full rated current

• Temp. Rise: Max 30°C after 250 cycles of overload at 200% of rated current

MECHANICAL

• Product I.D.: Ratings are permanently stamped on device

HORSEPOWER

15A - 125V — 1 ⁄

2

20A - 125V — 1

Dimensions apply to

Cat. Nos.

M5262-IG, MT526-IG,

M5362-IG, MT563-IG &

MSTWL-IG

CAT MT563-IG

Standard Tamper-Resistant

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

669

Time-Saving Systems

Commercial Grade

Decora Plus™ Heavy-Duty Specification Modular Receptacles

Specifications and Features

• Constructed with impact-resistant thermoplastic nylon cover and body

• Smooth face prevents dirt from collecting

• Four corner latches securely fasten the receptacle’s face to the body

• Large triple-wipe, brass “T” line contacts for superior contact and conductivity

• #12 AWG THHN wire leads, 6” length on MSTWL series wiring modules

• Galvanized steel, wrap-around mounting strap with riveted ground contacts

• Grounding clip permanently secured to strap for easy, simple, and secure installation

• Wiring module locks and latches to the receptacle body providing double the connection security

• Receptacle to be installed only with Leviton MSTWL series wiring modules

• MSTWL wiring module shipped separately with protective label and factory-installed Circuit ID label

• Backed by a limited 10-Year Warranty

M1636-W

Grounding clip permanently secured to strap makes for most reliable ground connection

Constructed with impact-resistant thermoplastic nylon cover and body

Smooth face prevents dirt from collecting and makes cleaning faster and simpler

Large triple-wipe “T” contacts for superior contact and conductivity day-in and day-out

Four corner latches securely fasten the receptacle’s face to the body

Two latches mate with wiring module for twice the security

Solid brass locking pins for strong, secure connection between receptacle and wiring module

Galvanized steel single-piece, wrap-around mounting strap with riveted ground contacts

670

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Commercial Grade

DECORA PLUS™ HEAVY-DUTY SPECIFICATION GRADE

2-Pole 3-Wire Grounding

Description Color Cat. No. Cat. No.

NEMA

Rating

Duplex, Tamper Resistant

Duplex

Duplex, Isolated Ground,

Tamper Resistant

Duplex, Isolated Ground

White

Ivory

Lt. Almond

Grey

5-15R 5-20R

15A–125V 20A-125V

MT162-W

MT162-I

MT162-T

MT162-GY

MT163-W

MT163-I

MT163-T

MT163-GY

Black MT162-E MT163-E

Brown MT162 MT163

Red

Blue

White

Ivory

MT162-R

MT162-B

M1626-W

M1626-I

MT163-R

MT163-B

M1636-W

M1636-I

Lt. Almond

Grey

M1626-T

M1626-GY

M1636-T

M1636-GY

Black M1626-E M1636-E

Brown M1626 M1636

Red

Blue

White

Ivory

M1626-R

M1626-B

MT162-IGW

MT162-IGI

Light Almond MT162-IGT

M1636-R

M1636-B

MT163-IGW

MT163-IGI

MT163-IGT

Black MT162-IGE MT163-IGE

Orange MT162-IG MT163-IG

White M1626-IGW M1636-IGW

Ivory M1626-IGI M1636-IGI

Light Almond M1626-IGT M1636-IGT

Grey M1626-IGG M1636-IGG

Black M1626-IGE M1636-IGE

Red M1626-IGR M1636-IGR

Orange M1626-IG M1636-IG

TESTING AND CODE COMPLIANCE

• NEMA WD 1 and 6

• cULus Listed

• NOM Certified (#057)

• ANSI Standard C-73

ENVIRONMENTAL

• Flammability: Rated V-2 per UL-94

• Operating Temperature: -40°C (without impact) to 60°C

Continuous

MATERIAL SPECIFICATIONS:

• Cover: Nylon

• Base: Nylon

• Mounting Strap (non-IG): Single Piece Galvanized Steel

with riveted ground contact

• Mounting Strap (IG versions): Galvanized Steel

M1636-W

MSTLW-A

• Isolated Ground System (IG Versions): Brass

• Ground Clip: Brass

• Line Contacts: 0.040” Thick Brass

• Locking Pins: Solid Brass

• Mounting Screws: Triple Combination Head, Steel

• Shutter Mechanism (Tamper Resistant versions):

Delrin ® Acetal

ELECTRICAL

• Dielectric Voltage: Withstands 2000V per UL 498

• Max. Working Voltage: 125V as rated

• Current Interrupting: Full rated current

• Temp. Rise: Max 30°C after 250 cycles of overload at 200% of rated current

MECHANICAL

• Product I.D.: Ratings are permanently stamped on device

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

671

Time-Saving Systems

Commercial Grade

DIMENSIONS

lev-lok ®

M1636 20 Amp-125 Volts

Dimensions apply to

Cat. Nos.

M1626, MT162, M1636,

MT163 & MSTWL-A

M1636 – IG

Dimensions apply to

Cat. Nos.

M1626-IG, MT162-IG,

M1636-IG, MT163-IG,

MSTWL-IG

Standard Tamper-Resistant

672

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Commercial Grade

SmartlockPro

®

GFCI Modular Receptacles

Specifications and Features

• GFCI protects one duplex receptacle. No feed-through capability

• Constructed with impact-resistant nylon cover

• Large triple-wipe, brass “T” line contacts on 20A for superior contact and conductivity

• The SmartlockPro receptacle automatically tests the GFCI every time the RESET button is pushed. The GFCI will not reset if the GFCI circuit is not functioning properly

• Built-in end-of-life indication. If the SmartlockPro receptacle can no longer provide

GFCI protection, it will not reset and no power is supplied to the face

• Trip threshold meets or exceeds UL requirements for tripping time

• Right Angle Wiring module’s thin profile makes it easier to place GFCI receptacle in the box

• #12 AWG THHN wire leads, 6” length on MSTWL series wiring modules

• Wiring module locks and latches to the receptacle body providing double the connection security

• Receptacle to be installed only with Leviton MSTWL series wiring modules

• MSTWL wiring module shipped separately with protective label and factory-installed Circuit ID label

Right Angle Wiring Module makes GFCI easier to install and reduces footprint in the box

M7599-I

MSTWL-A

Right Angle Wiring Module

Two latches mate with wiring module for twice the security

Look for the Lock! Patented lockout feature prevents RESET if the GFCI is not wired properly or the GFCI circuit is no longer functioning properly.

Impact resistant nylon cover withstands abuse

Advanced electronics offers superior resistance to surges and over-voltages

Green LED indicator light:

When illuminated, it indicates power is present

Grounding clip permanently secured to strap makes for most reliable ground connection

Solid brass locking pins for strong, secure connection between receptacle and wiring module

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

673

Time-Saving Systems

Commercial Grade

SMARTLOCKPRO

®

MODULAR RECEPTACLES

2-Pole, 3-Wire Grounding

Description Color Cat. No.

NEMA

Cat. No.

M7599-I

WITH

MSTWL-A

Rating

Duplex, Tamper Resistant

Duplex

TESTING AND CODE COMPLIANCE

• NEMA WD 1 and 6

• cULus Listed

• NOM Certified (#057)

• ANSI Standard C-73

ENVIRONMENTAL

• Flammability: Rated V-2 per UL-94

• Operating Temperature: -40°C (without impact) to 60°C

Continuous

MATERIAL SPECIFICATIONS:

• Cover: Nylon

• Base: Polycarbonate

• Mounting Strap (non-IG): Single Piece Galvanized Steel

with riveted ground contact

• Mounting Strap (IG versions): Nickel-Plated Steel

• Isolated Ground System (IG Versions): Brass

• Ground Clip: Nickel-Plated Brass

White

Ivory

5-15R 5-20R

15A–125V 20A-125V

MT759-W

MT759-I

Light Almond MT759-T

Grey MT759-GY

MT789-W

MT789-I

MT789-T

MT789-GY

Black MT759-E MT789-E

Brown MT759 MT789

Red MT759-R MT789-R

White M7899-W

Ivory M7599-I

Light Almond M7599-T

M7899-I

M7899-T

Grey

Black

M7599-GY

M7599-E

M7899-GY

M7899-E

Brown M7599 M7899

Red M7599-R M7899-R

• Line Contacts: Brass

• Locking Pins: Solid Brass

• Mounting Screws: Triple Combination Head, Steel

• Shutter Mechanism (Tamper Resistant versions):

Delrin ® Acetal

ELECTRICAL

• Dielectric Voltage: Withstands 2000V per UL 498

• Max. Working Voltage: 125V as rated

• Current Interrupting: Full rated current

• Temp. Rise: Max 30°C after 250 cycles of overload at 200% of rated current

MECHANICAL

• Product I.D.: Ratings are permanently stamped on device

DIMENSIONS

lev-lok ®

M7899 20 Amp-125 Volts

Dimensions apply to

Cat. Nos.

M7599, MT759,

M7899, MT789 & MSTWL-A

674

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Lev-Lok

®

Commercial Grade

Lev-Lok

®

Heavy-Duty Specification Grade Modular Receptacles

Specifications and Features

• Constructed with impact-resistant thermoplastic nylon cover and body

• Smooth face prevents dirt from collecting

• Four corner latches securely fasten the receptacle’s face to the body

• Large triple-wipe, brass “T” line contacts for superior contact and conductivity

• #12 AWG THHN wire leads, 6” length on MSTWL series wiring modules

• Galvanized steel, wrap-around mounting strap with riveted ground contacts

• Grounding clip permanently secured to strap for easy, simple, and secure installation

• Wiring module locks and latches to the receptacle body providing double the connection security

• Receptacle to be installed only with Leviton MSTWL series wiring modules

• MSTWL wiring module shipped separately with protective label and factory-installed Circuit ID label

• Backed by a limited 10-Year Warranty

MT563-SW

Grounding clip permanently secured to strap makes for most reliable ground connection

Constructed with impact-resistant thermoplastic nylon cover and body

Smooth face prevents dirt from collecting and makes cleaning faster and simpler

Face includes threaded bushing for reliable, secure wallplate attachment

Large triple-wipe “T” contacts for superior contact and conductivity day-in and day-out

Unique tamper-resistant shutter system prevents incidental contact with live contacts

Four corner latches securely fasten the receptacle’s face to the body

Two latches mate with wiring module for twice the security

Solid brass locking pins for strong, secure connection between receptacle and wiring module

Galvanized steel single-piece, wrap-around mounting strap with riveted ground contacts

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

675

Time-Saving Systems

Commercial Grade

HEAVY-DUTY SPECIFICATION GRADE MODULAR RECEPTACLES

2-Pole, 3-Wire Grounding

Description Color Cat. No. Cat. No.

NEMA

M5362-S

WITH

MSTWL-A

Rating

Duplex, Tamper Resistant

Duplex

White

Ivory

5-15R 5-20R

15A–125V 20A-125V

MT562-SW

MT562-SI

Light Almond MT562-ST

Grey MT562-SGY

MT563-SW

MT563-SI

MT563-ST

MT563-SGY

Brown MT562-S MT563-S

White M5262-SW M5362-SW

Ivory M5262-SI

Light Almond M5262-ST

M5362-SI

M5362-ST

Grey M5262-GYS M5362-GYS

Brown M5262-S M5362-S

TESTING AND CODE COMPLIANCE

• NEMA WD 1 and 6

• cULus Listed

• NOM Certified (#057)

• ANSI Standard C-73

ENVIRONMENTAL

• Flammability: Rated V-2 per UL-94

• Operating Temperature: -40°C (without impact) to 60°C

Continuous

MATERIAL SPECIFICATIONS:

• Cover: Nylon

• Base: Nylon

• Mounting Strap (non-IG): Single Piece Galvanized Steel

with riveted ground contact

• Ground Clip: Brass

• Line Contacts: 0.040” Thick Brass

DIMENSIONS

lev-lok ®

M5262, 15 Amp-125 Volts

Dimensions apply to

Cat. Nos.

M5262-S, M5362-S, MT562-S,

MT563-S and MSTWL

• Locking Pins: Solid Brass

• Mounting Screws: Triple Combination Head, Steel

• Shutter Mechanism (Tamper Resistant versions):

Delrin ® Acetal

ELECTRICAL

• Dielectric Voltage: Withstands 2000V per UL 498

• Max. Working Voltage: 125V as rated

• Current Interrupting: Full rated current

• Temp. Rise: Max 30°C after 250 cycles of overload at 200% of rated current

MECHANICAL

• Product I.D.: Ratings are permanently stamped on device

HORSEPOWER

15A - 125V — 1 ⁄

2

20A - 125V — 1

676

Standard Tamper-Resistant

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

EZE-Rough

®

Commercial Grade

EZE-Rough

®

Prefab Branch Wiring System

The leader in the prefabricated wiring assembly market with over 14,000 unit installations. Superior technical service, quality assurance, engineering, research and development, testing and the highest manufacturing standards.

Industry Trends

Recent studies show that prefabricated wiring systems are the most effective way to complete projects faster.

Using prefabricated and preassembled electrical components bring substantial cost savings, especially for large projects with many identical layouts such as hotels, condos and hospitals. With this principle in mind, the revolutionary

EZE-Rough System was born.

Partner with EZE-Rough ®

The most advanced, turnkey branch wiring solution in commercial construction. Combines advanced engineering layout services with prefab electrical wiring assemblies customized to job specs. The result: projects completed faster and under budget.

Specifications and Features

Cost Savings:

• Exclusive design verification at estimate phase reduces errors and oversights

• Improves profitability with efficient skill set allocation

• Layout service maximizes on site workflow efficiency

Accelerated Project Completion:

• Prefab process dramatically reduces clean up time

• Install complete system out of the box without leaving the work area

• Prefabricated components significantly speed installation time

Expert Project Management:

• Professional Engineer engaged at proposal phase

• On site system mock up prior to full production

• Project Coordinator trains installation crew on site, and remains available for consultation throughout the project

Powered by Leviton:

• Over a century of experience developing world class quality products

• The number one choice of electrical contractors for building, expanding, and remodeling hospitals, commercial office buildings, convention centers and other multiple unit structures

EZE-Rough System, Inc.

A Leviton Company

12400 S.W. 134 Ct. #1, Miami, FL 33186

Ph: 305-779-6400 Fax: 305-779-6450

Website: www.EZErough.com email: [email protected]

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

677

Time-Saving Systems

Commercial Grade

How EZE-Rough System Works

1. SUBMIT ELECTRICAL DRAWINGS FOR PROPOSAL

Our professional engineers review your drawings and confirm your local building codes to ensure complete accuracy of the proposal. Proposals provide detailed materials list including estimated install time.

678

2. PLACE THE ORDER

Layout drawings are generated detailing location and elevation of all rough-in boxes, and show all cable assemblies with required wire and length information.

Plans then submitted to you for approval prior to fabrication.

3. ON-SITE SYSTEM MOCK UP

Prior to production, Project Coordinator will assist with complete installation mock up on site as a final plan verification. Modifications at this stage are much less costly than after full production.

4. PRODUCTION AND PACKAGING

All Components are produced per final set of plans. They are designed for ease of installation and superior productivity. Our state of the art production facility ensures timely production & consistent quality. All EZE-Rough assemblies are packaged in banded, double-wall cartons and labeled by location with project name, floor number, and unit designation. White shipping cartons make EZE-Rough easily identifiable.

Cartons are palletized for ease of unloading and on-site handling.

5. DELIVERY AND INSTALLATION

Delivery can be coordinated to match your schedule. When you’re ready to install your EZE-Rough system, we provide an experienced Project Coordinator to visit the job site and assist your workers until they are proficient EZE-Rough installers.

The same Project Coordinator will be available for phone consultations throughout the project and will assist with any changes that may be required.

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

PowerMount

Commercial Grade

PowerMount™ Pre-Fab Wiring Assemblies

Electrical Contractors, like much of the construction industry, are under increasing pressure to reduce total project costs, and complete them in shorter periods of time. With material costs and labor wages increasing, it seems to be an impossible task. Most electrical contractors estimate labor costs account for 60% to 75% of the total project costs. Completing your projects faster reduces your total project costs.

How?

Recent studies show that prefabricated wiring systems are the most effective way to complete projects faster.

Using prefabricated and preassembled electrical components brings substantial cost savings, especially for large projects with many identical layouts such as hotels, condos and hospitals. Leviton ’s new PowerMount Pre-Fab

Wiring Assemblies were designed to help you complete projects faster. We engineered components that install quickly right out of the box, and easily reconfigure for those last minute on-site changes. With PowerMount prefabricated wiring assemblies, you eliminate variations and errors that plague conventionally wired projects.

And with all assemblies installed at the rough-in stage, your projects are completed faster.

Specifications and Features

• Pre-assembled metal boxes

• Horizontal wall mount brackets

• Vertical floor mount brackets

• All PowerMount™ assemblies are cULus Listed wiring assemblies

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

679

Time-Saving Systems

Commercial Grade

Universal Box Assemblies

The core of the PowerMount system is the universal box assembly. It consists of a 4” metal box, mud ring, stud-mounting brackets, box supports, ground wire and Lev-Lok wiring module(s). The box assembly is supplied with a protective cover to keep the box interior debris-free during installation, rough-in and finish.

Installation is quick and easy: simply position the box assembly onto the preferred stud location (or to other

PowerMount brackets) and secure with conventional screws. The integrated bracket serves as both a “site line” and spacer for precise, consistent locating every time.

Zinc-galvanized steel box

Sturdy 16 gauge steel brackets allow for mounting directly to the stud

(steel or wood) or to other PowerMount mounting brackets

Mud rings are available in both single-gang and two gang configurations, for wall thicknesses from ½” to 1¼”

Box “far side” supports are preset at the factory for standard

3½” stud depths, and are easily adjustable to fit 4” to 6” stud depths

Ground wire is fixed to box, and includes a 6-port push wire type connector for simple, quick connection of all ground leads

Protective plate protects wiring components during rough-in

MBBB0

Related Products

Lev-Lok™ receptacles (sold separately).

For more information on Lev-Lok Receptacles

see pages 657-676.

Floor Bracket Assemblies

The PowerMount Floor Bracket Assembly consists of a pre-configured Universal Box Assembly mounted to a vertical kickstand bracket. The box height is preset at the factory to your specification. The unique perforated rails allow for simple reconfiguration on the job site and provide for custom, multi-gang configurations unattainable in other pre-fab systems. And, installation couldn’t be easier. Kick the bracket under the wall base and secure into place with two screws. That’s it!

680

MVABN

Perforated rails allow for mounting box at any height between 6” and 20” (in ½” increments)

Box is independently secured to floor bracket, preventing it from falling off during mud ring removal

Lev-Lok wiring module makes receptacle installation quick, easy and secure

Heavy gauge steel formed channels provide for superior strength and rigidity

“Locator Tab” can be bent down to indicate center line of electrical box when bracket is initially covered by drywall

“Kickstand” bracket provides for simple, quick installation anywhere between studs.

* Lev-Lok receptacles sold separately

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

PowerMount

Commercial Grade

Horizontal Bracket Assemblies

The PowerMount Horizontal Bracket Assembly consists of a pre-configured Universal Box Assembly mounted to a bracket. The box position is preset at the factory to your specification (default location is centered on the bracket). The unique perforated rails not only allow for simple reconfiguration on the job site, but also provide for custom, multi-gang configurations unattainable in other pre-fab systems. Installation is quick and easy. Simply position the bracket in the desired location and secure directly to the studs. That’s it!

Bracket is automatically fixed to fit standard 16” on center stud spacing

Heavy gauge steel formed channels provide for superior strength and rigidity

Perforated rails allow for mounting the box in a variety of positions and easily accommodate multi-gang installations

Slot indicates center of box, making it easy to install bracket in proper location

Box is independently secured to bracket, preventing it from falling off during mud ring removal for full box access

MHABL

Adjustable-Width Horizontal Bracket Assemblies

For the ultimate in flexibility, the PowerMount Adjustable-Width Horizontal Bracket Assembly consists of a preconfigured Universal Box Assembly mounted to a bracket. The box position is preset at the factory to your specification (default location is centered on the bracket.) The unique perforated rails allow for simple reconfiguration on the job site, and provide for custom, multi-gang configurations unattainable in other pre-fab systems.

Heavy gauge steel formed channels provide for superior strength and rigidity

Perforated rails allow for mounting the box in a variety of positions and easily accommodate multi-gang installations

Slot indicates center of box, making it easy to install bracket in proper location

Lev-Lok wiring module makes receptacle installation quick, easy and secure

16” to 24”

MABBL

Bracket is adjustable to fit standard 16” on center stud spacing up to 24” on center stud spacing

* Lev-Lok receptacles sold separately

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

681

Time-Saving Systems

Commercial Grade

DIMENSIONS

Horizontal Bracket Assembly

Universal Box Assembly

Floor Bracket Assembly

682

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

PowerMount™

Commercial Grade

To Create Your 5-Digit Catalog Number First Use Letters From Chart A

CHART A

Family Component Box 1 Assembly Mud Ring Floor Bracket Height

M

Build

le v it on your own!

.com

/ conf ig ur a to r

V = Vertical Floor

Bracket Assembly

H = Fixed-width

Horizontal Wall

Bracket Assembly

A = Adj-Width

Horizontal Wall

Bracket Assembly

B = Universal Box

Assembly Only

O = No Box

(Bracket Only)

A = 4” X 2

1

/

8

’” Box,

1-Gang Mud Ring

1 Wiring Module

B = 4” X 2

1

/

8

” Box

2-Gang Mud-ring,

2- Wiring Modules

E = 4” X 2

1

/

8

” Box,

1-Gang Mud Ring,

No Wiring Module

F = 4” X 2

1

/

8

” Box,

2-Gang Mud Ring,

No Wiring Module

0 = No Mud Ring

A =

1

/

2

” wall thickness

B =

5

/

8

” wall thickness

C =

3

/

4

” wall thickness

D = 1” wall thickness

E = 1

1

/

4

” wall thickness

F = Adjustable

O = Default

A = 6”

B = 7”

C = 8”

D = 9”

E = 10”

F = 11”

G = 12”

H = 13”

J = 14”

K = 15”

L = 16”

M = 17”

N = 18”

P = 19”

Q = 20”

R = 24”

– Horizontal Bracket Only

If Additional Boxes Are Required Use Information From Chart B To Create 3-Digit Suffix.

CHART B

O O O

Options Box 2

Type

O = No Box

A = 4” X 2

1

/

8

” Box,

1-Gang Mud Ring

1 Wiring Module

B = 4” X 2

1

/

8

” Box,

2-Gang Mud Ring

2 Wiring Modules

E = 4” X 2

1

/

8

” Box,

1-Gang Mud Ring

No Wiring Module

F = 4” X 2

1

/

8

” Box,

2-Gang Mud Ring

Box 2

Position

A = Adjacent Left

B = Adjacent Right

C = Adjacent Below

D = Both inside perimeter of Bracket

O

No Wiring Module

(These are the most popular PowerMount™ configurations)

STOCK CONFIGURATION TABLE

U S

Bracket Type

Vertical Fixed

Code

MVABN

MVBBN

Horizontal Fixed MHABL

Horizontal Adj.

Universal Box

Assembly

MHBBL

MAABL

MABBL

MBAB0

MBBB0

Description

Vertical 4” Box Assembly, 1G

5

/

8

” Mud Ring, 18 ” centered

Vertical 4” Box Assembly, 2G

5

/

8

” Mud Ring, 18” centered

Horizontal Fixed 4” Box Assembly, 1G

5

/

8

” Mud Ring, 8” centered

Horizontal Fixed 4” Box Assembly, 2G

5

/

8

” Mud Ring, 8” centered

Horizontal Adjust 4” Box Assembly at 16”, 1G

5

/

8

” Mud Ring, 8” centered

Horizontal Adjust 4” Box Assembly at 16”, 2G

5

/

8

” Mud Ring, 8” centered

1G 4” Box Assembly, 1G

5

/

8

” Mud Ring

1G 4” Box Assembly, 2G

5

/

8

” Mud Ring

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

683

Time-Saving Systems

Residential and Commercial Grade

Cheetah Speed System - How The System Works

The patented Cheetah Speed System™ enables electrical devices, switches, receptacles, and wallplates to be installed without screws using a revolutionary speed anchor and snap & lock system, researched and developed with and by electricians. The Cheetah Speed System™ increases the speed of installation by up to 40% to 50%, and at the same time, offers the elegance, style, and designer look of screwless wallplates, at a very affordable price.

Specifications and Features

• Increases the speed of installation by 40% to 50%

• Enables electrical devices to be installed without screws

• Speed Anchor System snaps and locks into place

• Installs flush to the wall

3 2 1

1. CHEETAH SPEED BOX (1 – 4 GANG BOXES)

• High strength thermoplastic composites with speed anchor slots

• Each slot has molded teeth to receive speed anchors

• Teeth on box zip-tie to hold speed anchors

2. CHEETAH SPEED DEVICE (SWITCHES, RECEPTACLES, DIMMERS, ETC.)

• Speed Anchor zip-ties into the patented Cheetah Speed Wallboxes

• Fastens with a standard 6-32 Screw

• Quickwire or side terminals

• No screws needed

3. CHEETAH SCREWLESS WALLPLATE

• Wallplates snap into 4 holes in each Cheetah device

• Midway matte finish in high strength thermoplastic

684

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

Decora

®

, Toggle and Combination Switches

Cheetah-enabled Decora, toggle and combination switches complement any décor. Preassembled with Cheetah

Speed Anchors, they install quickly and blend beautifully with the matte finish screwless wallplates. Cheetah switches are available in Single Pole, 3-Way and 4-Way configurations.

Specifications and Features

• Complement any home décor

• Single pole, 3-way and 4-way configurations

• Quickwire or Side Wire for easy installation

• Combination switches save space

Thermoplastic Resin, Unbreakable - Resilient (does not bend)

Patented 1-Step Screwless Wallplate Snap-In Holes

6 /

32

Tri-drive Screw holds Cheetah Speed Anchor

• Standard Vertical

• Adjustment (crooked box/stud installation)

• Remove to service device (speed anchor stays

in box)

1.77”

4.20”

Ground screw location for combination switches

Cheetah-enabled with speed anchors

Tapped screw hole for standard wallplates

Break-off Split-circuit Tab

Universal Adapter Ring fastened to

Combination Switch w/ Cheetah Speed Anchors using 6-32 Tri-drive screws

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

685

Time-Saving Systems

Residential and Commercial Grade

6030-COW

DECORA

®

SWITCHES

Side and Quickwire

Description

Rating

Single Pole Switch, no ground

3-Way Switch, no ground

4-Way Switch, no ground

Color

White

Ivory

Light Almond

15A-120/277VAC

6030-C0W

6030-C0I

6030-C0T

Black 6030-C0E

White 6040-C0W

Ivory 6040-C0I

Light Almond 6040-C0T

Black 6040-C0E

White 6050-C0W

Ivory 6050-C0I

Light Almond 6050-C0T

Black 6050-C0E

Note: Non-Metallic strap for use with Cheetah Wallplates only.

6000-COW

TOGGLE SWITCHES

Side and Quickwire

Description

Rating

Single Pole Switch, no ground

3-Way Switch, no ground

4-Way Switch, no ground

Color

White

Ivory

Light Almond

15A-120VAC

6000-C0W

6000-C0I

6000-C0T

Black 6000-C0E

White 6010-C0W

Ivory 6010-C0I

Light Almond 6010-C0T

Black 6010-C0E

White 6020-C0W

Ivory 6020-C0I

Light Almond 6020-C0T

Black 6020-C0E

Note: Non-Metallic strap for use with Cheetah Wallplates only.

1754-COW

COMBINATION DECORA SWITCHES

Side and Quickwire

Description

Rating

Color

Single Pole

Dual Combination Switch

White

Ivory

Light Almond

COMBINATION TOGGLE SWITCHES

Side and Quickwire

Color Description

Rating

Single Pole

Dual Combination Switch

White

Ivory

Light Almond

Individual Switches: 15A-120VAC,

Device Total: 20A-120VAC

1754-C0W

1754-C0I

1754-C0T

Cat. No

15A-120/277VAC

5224-C0W

5224-C0I

5224-C0T

686

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

DECORA

®

SWITCHES

Back and Side Wired

Description

Rating

Single Pole Decora Switch

3-Way Decora Switch

Color

White

20A-120/277VAC

5621-C0W

Ivory 5621-C0I

Light Almond

White

5621-C0T

5623-C0W

Ivory 5623-C0I

Light Almond 5623-C0T

ILLUMINATED DECORA SWITCHES

Back and Side Wired

Description

Rating

Single Pole Decora Switch

Color

White

20A-120/277VAC

5631C-C0W

Ivory 5631C-C0I

Light Almond 5631C-C0T

5621-C0W

TOGGLE SWITCHES

Side Wired

Description

Rating

Single Pole Toggle Switch

3-Way Toggle Switch

Color

White

20A-120/277VAC

54521-C0W

Ivory 54521-C0I

Light Almond

White

54521-C0T

54523-C0W

Ivory 54523-C0I

Light Almond 54523-C0T

ILLUMINATED TOGGLE SWITCHES

Back and Side Wired

Description

Rating

Single Pole Toggle Switch

Color

Clear

20A-120/277VAC

1221C-LHC

White 1221C-LHW

Ivory 1221C-LHI

Light Almond 1221C-LHT

54521-C0W

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

1221C-LHW

687

Time-Saving Systems

Residential and Commercial Grade

TESTING AND CODE COMPLIANCE

• ETL Listed, tested to UL20 and CSA Standards; meets

NEMA and ANSI requirements

• UL 20

• CSA C22.22 No. 111

MATERIAL CHARACTERISTICS

• Environmental: Flammability, Rated V2

• Operating Temperature: Max continuous +60˚C; Min -40˚C

ELECTRICAL

• Dielectric Voltage: Withstands 1500V minimum

• Maximum Working Voltage: Commercial Grade

Switches 277VAC

• Overload: Minimum 4.8 times rated current for 100 cycles

• Current Interrupting: Certified for current interrupting at full-rated current

• Temperature Rise: Max 30˚C. at full-rated current after 50 cycles

• (For Commercial Devices) Endurance: 50,000 cycles minimum, resistive, inductive, tungsten filament lamp load (Fed Spec)

MECHANICAL

• Terminal Identification: UL20 - Brass (hot), Black (hot)

• Terminal Size: #14 - #10 AWG Copper Conductor Only

• Product ID: Ratings marked permanently on device

WIRING DIAGRAM

Warning: Although each individual rocker switch is rated up to 15A-120V, the total combined load for both rockers must not exceed 20 AMPS

1 Pole, 3-Way, 4-Way Switches Wire Diagrams

688

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

Cheetah Receptacles — Residential and Commercial Grade

Built with high strength thermoplastic resins, Cheetah receptacles are heavy duty and resilient to bending or breaking. They come in a wide range of versions for every application. The selection includes Decora, Single and

Duplex Receptacles, Tamper Resistant and Weather Resistant devices, GFCIs and Dryer/Range receptacles.

Specifications and Features

All Receptacles

• Preassembled with Cheetah Speed Anchors fastened with 6-32 screws for easy removal or adjustment after installation

• Heavy duty and resilient

Tamper Resistant and Tamper/Weather Resistant Receptacles

• Shutter mechanism inside the receptacle blocks access to the contacts unless a two-prong plug is inserted, helping ensure hairpins, keys, etc., will be locked out

• Tamper Resistant Receptacle meets 2008 NEC Code, Section 406.11

• Tamper/Weather Resistant Receptacle also meets UL 498 requirements, as well as Sections 406.8

(weather resistant) and 406.11 (tamper resistant) of the NEC code

• Tamper/Weather Resistant Receptacle is ideal in damp or wet locations

• Available in Decora, single or duplex versions

SmartlockPro ® GFCI Receptacles

• Automatically tests the GFCI every time the RESET button is pushed

• Blocks RESET of the GFCI if protection has been compromised

• Available in Tamper Resistant and Tamper/Weather Resistant versions

Dryer/Range Receptacles

• Made of durable thermoplastic

• Heavy-gauge, double-wipe copper alloy contacts

• Includes stainless steel wallplate

1-Step Screwless Wallplate Snap-In Holes

Thermoplastic Resin, Unbreakable - Resilient (does not bend)

Tapped screw hole for standard wallplates

Break-off Split-circuit Tab

6-32 Tri-drive Screw holds Cheetah Speed Anchor

• Standard Vertical Adjustment

(crooked box/stud installation)

• Remove to service device

(speed anchor stays in box)

T5320-C0W

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

689

Time-Saving Systems

Residential and Commercial Grade

DECORA

®

AND DUPLEX RECEPTACLES

Side and Quickwire

Description Color

NEMA

690

7020-C0W

7000-C0W

T5325-C0W

T5320-C0W

Rating

Decora Receptacle

Duplex Receptacle

5-15R

White

15A-125V

7020-C0W

Ivory 7020-C0I

Light Almond 7020-C0T

Black 7020-C0E

White 7000-C0W

Ivory 7000-C0I

Light Almond 7000-C0T

Black 7000-C0E

Color Description

NEMA

Rating

Duplex Receptacle

5-20R

White

20A-125V

CR20-C0W

Ivory CR20-C0I

Light Almond CR20-C0T

TAMPER RESISTANT AND TAMPER/WEATHER RESISTANT RECEPTACLES

Description Color

NEMA

Rating

Tamper Resistant

Decora Receptacle

Tamper Resistant

Duplex Receptacle

Tamper/Weather Resistant

Duplex Receptacle

Tamper Resistant

Single Receptacle

Description

NEMA

5-15R

White

Ivory

Light Almond

15A-125V

T5325-C0W

T5325-C0I

T5325-C0T

Black T5325-C0E

White

Ivory

T5320-C0W

T5320-C0I

Light Almond T5320-C0T

Black T5320-C0E

White

Ivory

W5320-TCW

W5320-TCI

White

Ivory

Light Almond

T5015-C0W

T5015-C0I

T5015-C0T

Color

Rating

5-20R

20A-125V

White T5020-C0W

Ivory T5020-C0I

Light Almond T5020-C0T

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

TAMPER RESISTANT RECEPTACLES

Description Color

NEMA

Rating

Tamper Resistant

Decora ® Receptacle

Tamper Resistant

Duplex Receptacle

5-20R

White

Ivory

Light Almond

20A-125V

TDR20-C0W

TDR20-C0I

TDR20-C0T

Black TDR20-C0E

White

Ivory

TBR20-C0W

TBR20-C0I

Light Almond TBR20-C0T

Black TBR20-C0E

COMMERCIAL SPEC GRADE

SMARTLOCKPRO

®

GFCI RECEPTACLES

Description

NEMA

Color

Rating

GFCI with LED Indicator Light

5-15R

15A-125V @ Receptacle,

20A-125V Feed Through

White 7599-C0W

Ivory 7599-C0I

Light Almond 7599-C0T

Black 7599-C0E

NEMA

Rating

GFCI with LED Indicator Light

5-20R

20A-125V @ Receptacle,

20A-125V Feed Through

White 7899-C0W

Ivory 7899-C0I

Light Almond 7899-C0T

Black 7899-C0E

7599-C0W

7899-C0W

TESTING AND CODE COMPLIANCE

• ETL Listed, tested to UL498 and UL943 Standards; tested

to CSA Standards; meets NEMA and ANSI requirements

• UL 20

• CSA C22.22 No. 111

ELECTRICAL

• Dielectric Voltage: Withstands 2000V minimum

• Current Interrupting: Certified for current interrupting at full-rated current

MATERIAL CHARACTERISTICS

• Environmental: Flammability, Rated V2

• Operating Temperature: Max continuous +60˚C; Min -40˚C

Receptacles Maximum Continuous +66ºC; Minimum -35ºC GFCIs

MECHANICAL

• Terminal Identification: UL20 - Brass (hot), Black (hot)

• Terminal Size: #14 - #10 AWG Copper Conductor Only

• Product ID: Ratings marked permanently on device

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

691

Time-Saving Systems

Residential and Commercial Grade

TAMPER RESISTANT AND TAMPER/WEATHER RESISTANT

GFCI RECEPTACLES

Description

NEMA

Color

5-15R

White

Ivory

15A-125V @ Receptacle,

20A-125V Feed Through

T7599-C0W

T7599-C0I

Light Almond T7599-C0T

Black T7599-C0E

T7599-COW

Rating

Tamper Resistant GFCI with LED Indicator Light

NEMA

Rating

Tamper Resistant GFCI with LED Indicator Light

5-20R

White

Ivory

20A-125V @ Receptacle,

20A-125V Feed Through

T7899-C0W

T7899-C0I

Light Almond T7899-C0T

Black T7899-C0E

NEMA

T7899-COW

Rating

Tamper/Weather Resistant GFCI White with LED Indicator Light Black

NEMA

5-15R

15A-125V @ Receptacle,

20A-125V Feed Through

W7599-TCW

W7599-TCE

Rating

Tamper/Weather Resistant GFCI White with LED Indicator Light Black

5-20R

20A-125V @ Receptacle,

20A-125V Feed Through

W7899-TCW

W7899-TCE

692

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

DRYER/RANGE RECEPTACLES

Description

NEMA

Color

Rating

Flush Mount, Grounded,

3-Pole, 4-Wire; Stainless Steel

Wallplate Included

NEMA

Black Device,

Stainless Steel

Wallplate

14-30R

30A-125/250V

278C

Rating

Flush Mount, Grounded,

3-Pole, 4-Wire; Stainless Steel

Wallplate Included

50A-125/250VAC

Black Device,

Stainless Steel

Wallplate

14-50R

279C

TESTING AND CODE COMPLIANCE

• ETL Listed; tested to UL 498 and CSA Standards;

meets NEMA and ANSI requirements

• Dryer/Range meets NEMA WD-6,

ANSI C-73, UL 498

ELECTRICAL

• Dielectric Voltage: Withstands 2000V minimum

• Current Interrupting: Certified for current interrupting at full-rated current

MATERIAL CHARACTERISTICS

• Environmental: Flammability UL-94, V2 Rating

• Operating Temperature: From -40˚C to 60˚C

MECHANICAL

• Terminal I.D.: UL498 – Brass (hot), White

(neutral), Green (ground)

• Terminal Size: #14 - #10 AWG

Copper Conductor Only; Dryer Range up to

4AWG Copper Conductor Only

• Product ID: Ratings marked permanently on device

278C

279C

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

693

Time-Saving Systems

Residential and Commercial Grade

Cheetah Lighting Controls and Sensors

The labor-saving Cheetah line includes rotary, slide and toggle dimmers, fan speed controls and occupancy sensors for quick installation in homes, offices and commercial venues.

Specifications and Features

• Preset toggle and slide dimmers

• Traditional rotary dimmers

• Single pole or 3-way

• Radio frequency interference filtering

• Quiet 1.5A fan speed control

• Title 24 compliant occupancy sensor

How It Works

ON/OFF (energy efficient)

- Lights Ramp UP Slowly to Smart Set

- Lights Ramp DOWN Slowly

DIM LIGHTS

- Hold/Press toggle switch in UP position

- Lights cycle through the dimmer range

- SMART SET: Release Toggle Switch at desired

smart setting

STYLE & QUALITY

- Matte finish (no glossy Wallplates)

- Easy to Clean (dishwasher safe)

- High Strength Lexan Resin

- UL Standards Tested

Green

Black / Line

Red

L

Insulated wires connect to Line

(usually black) and load (light).

1. Connect green dimmer ground wire to

bare copper ground in outlet box.

2. Fasten black dimmer wire to black/line wire.

3. Fasten Red dimmer wire to

remaining wire (load).

DIMMERS

Description

Rating

IllumaTech™ Decora ® Preset

Slide Dimmer, Single Pole or 3-way

ToggleTouch™ Dimmer, Single Pole

IPI06-CLZ

Electronic Smart Preset Dimmer,

Single Pole

Trimatron™ Rotary Dimmer,

Single Pole or 3-way

Rotary Dimmer,

Single Pole or 3-way

Color

600W-120VAC

Packaged with 3 colors: IPI06-CLZ

White, Ivory, Light Almond

White TGI06-CLW

Ivory TGI06-CLI

Light Almond

White

TGI06-CLT

6250-C0W

Ivory

Light Almond

Packaged with 3 colors:

White, Ivory, Light Almond

6250-C0I

6250-C0T

6683-C0Z

White

Ivory

6060-C0W

6060-C0I

Light Almond 6060-C0T

Black 6060-C0E

FAN SPEED CONTROL

Description

Rating

Quiet Fan Speed Control with LED,

Single Pole or 3-Way

Color

1.5A-120VAC

Packaged with 3 colors: IPF01-CLZ

White, Ivory, Light Almond

694

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

PIR OCCUPANCY SENSOR

U S

Description

Rating

Occupancy Sensor, Single Pole and 3-Way, 180˚ field of view,

900 sq. ft. California

Title 24 Compliant.

Time Adjustment 30s – 30m

Color

White

Ivory

Light Almond

1800W @ 120VAC, 60Hz

IPP15-C0W

IPP15-C0I

IPP15-C0T

IPP15-CLW

Dimmers

TESTING AND CODE COMPLIANCE

ETL Listed: Tested to UL and CSA Standards; meets

NEMA and ANSI requirements

MATERIAL CHARACTERISTICS*

• Environmental: Flammability UL94, V2 Rating

• Operating Temperature: Indoor Use Only

ELECTRICAL

Voltage: 120 Volt AC - 60 Hz

Load Type: Incandescent and fluorescent (for IPP15)

Load Rating: Toggle and Rotary: 600W,

Slide: 700W

Filtering: Radio Frequency Interference Filtering

De-Rating: Finned Aluminum Tabbed - 600W/500W/400W

Push-ON/Push-OFF: Pre-Set Toggle Electronic, Slide and

Rotary

LED: TGI06, IPP15 and IPI06 have an LED indicator light

Adjustable Time Delay: 30 seconds to 30 minutes (IPP15)

Neutral connection is required for IPP15

Construction: Printed Solid-State Circuit Board

MECHANICAL

• Size: Toggle and Slide fits single and multi-gang NEMA wall boxes

• Wiring: 6” color-coded Leads Pre-Stripped - 18 gauge

• Heat Sink: Wide Mount Aluminum Fins

• Back Body: Toggle and Slide: Unbreakable ABS

Fan Speed Controls and Occupancy Sensors

TESTING AND CODE COMPLIANCE

ETL Listed: Tested to UL and CSA Standards; meets NEMA and ANSI requirements

MATERIAL CHARACTERISTICS*

• Environmental: Flammability UL94, V2 Rating

• Operating Temperature: Indoor Use Only

ELECTRICAL

Filtering: Radio Frequency Interference

Pre-Set: Electronic

Construction: Printed Solid-State Circuit Board

Decora ® is a registered trademark and IllumaTech™, Trimatron™ and ToggleTouch™ are trademarks of Leviton Manufacturing Corp.

DIMENSIONS

IllumaTech™ Preset Slide Dimmer

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

695

Time-Saving Systems

Residential and Commercial Grade

Cheetah Screwless Wallplates

Combine the stylish look of screwless wallplates with the fast speed of a Cheetah installation and you’ve got a product consumers and electricians will love. The wallplates snap into four holes in each Cheetah device.

Made of high strength thermoplastic, they give a clean, finishing touch to any installation.

Specifications and Features

• Sleek and easy to clean

• Quick, easy snap-on design

• Flush to wall finish

• No tool required

• In White, Ivory, Light Almond, Black

• Midway matte finish in high-strength thermoplastic

• Satin finished thermoplastic doesn’t show fingerprints

The patented Cheetah screwless wallplates have been designed to provide exceptional tight fit to

Cheetah-enabled devices using eight (8) specially designed tabs.

Each tab (top and bottom) provides resistance.

As many as 6 tabs may break off and the wallplate still ensures a snug fit to the wall.

2 tabs per Cheetah wallplate opening.

Advanced Engineering Design

Cheetah wallplates are made from high strength thermoplastic for unbreakable quality and stylish matte finish.

Each wallplate is specified to NEMA standards for

Third Party compatability. 4.93”

3.16”

TESTING AND CODE COMPLIANCE

• ETL Listed: tested to UL and CSA Standards; meets NEMA

and ANSI requirements

MATERIAL CHARACTERISTICS

• Environmental: Flammability UL-94, V2 Rating

MECHANICAL

• Material: Thermoplastic

• Finish: Matte Finish

• Resilience: Unbreakable

696

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

DECORA

®

Description

1-Gang Decora Wallplate

Screwless design

2-Gang Decora Wallplate

Screwless design

3-Gang Decora Wallplate

Screwless design

4-Gang Decora Wallplate

Screwless design

TOGGLE

Standard UL 514D, Standard CSA-C22.2 No. 111

Description

1-Gang Toggle Wallplate

Screwless design

2-Gang Toggle Wallplate

Screwless design

3-Gang Toggle Wallplate

Screwless design

4-Gang Toggle Wallplate

Screwless design

DUPLEX AND BLANK

Description

1-Gang Duplex Wallplate

Unbreakable plastic

Screwless design

2-Gang Duplex Wallplate

Screwless design

Cheetah Speed Systems

Residential and Commercial Grade

White

Light Almond

White

Light Almond

White

Light Almond

White

Light Almond

SJ26C-C0W

SJ26C-C0T

S262C-C0W

S262C-C0T

S263C-C0W

S263C-C0T

S264C-C0W

S264C-C0T

White

Light Almond

Black

White

Light Almond

White

Light Almond

White

Light Almond

PJ1C-C0W

PJ1C-C0T

PJ1C-C0E

PJ2C-C0W

PJ2C-C0T

PJ3C-C0W

PJ3C-C0T

PJ4C-C0W

PJ4C-C0T

White

Ivory

Light Almond

White

Light Almond

PJ8C-C0W

PJ8C-C0I

PJ8C-C0T

PJ82C-C0W

PJ82C-C0T

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

697

Time-Saving Systems

Residential and Commercial Grade

COMBO PLATES — 1- AND 2-GANG

1-Gang Blank Wallplate

Unbreakable plastic

Screwless design

Use with blank plate adapter

2-Gang Blank Wallplate

Unbreakable plastic

Screwless design

Use with blank plate adapter

COMBO PLATES — 2-GANG

2-Gang Toggle/Decora Wallplate

Unbreakable plastic

Screwless design

2-Gang Toggle/Duplex Wallplate

Unbreakable plastic

Screwless design

2-Gang Duplex/Decora Wallplate

Unbreakable plastic

Screwless design

COMBO PLATES — 3 - AND 4-GANG

3-Gang, 2 Toggle/Decora Wallplate

Unbreakable plastic

Screwless design

3-Gang, 2 Toggle/Duplex Wallplate

Unbreakable plastic

Screwless design

4-Gang, 3 Toggle/Decora Wallplate

Unbreakable plastic

Screwless design

White

Ivory

Light Almond

Black

White

Ivory

Light Almond

Black

PJ13C-C0W

PJ13C-C0I

PJ13C-C0T

PJ13C-C0E

PJ23C-C0W

PJ23C-C0I

PJ23C-C0T

PJ23C-C0E

White P126C-C0W

Ivory P126C-C0I

Light Almond P126C-C0T

Black P126C-C0E

White PJ18C-C0W

Ivory PJ18C-C0I

Light Almond PJ18C-C0T

Black PJ18C-C0E

White P826C-C0W

Ivory P826C-C0I

Light Almond P826C-C0T

Black P826C-C0E

White P226C-C0W

Ivory P226C-C0I

Light Almond P226C-C0T

Black P226C-C0E

White PJ21C-C0W

Ivory PJ21C-C0I

Light Almond

Black

PJ21C-C0T

PJ21C-C0E

White 2262C-C0W

Ivory 2262C-C0I

Light Almond 2262C-C0T

Black 2262C-C0E

TESTING AND CODE COMPLIANCE

• ETL Listed: Tested to UL and CSA Standards; meets NEMA

and ANSI requirements

MATERIAL CHARACTERISTICS

• Environmental: Flammability UL-94, V2 Rating

MECHANICAL

• Material: Thermoplastic

• Finish: Matte Finish

• Resilience: Unbreakable

698

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

High Quality Screw Connectors

Easy Wire Openings

High Strength Wire Fittings

TESTING AND CODE COMPLIANCE

• Meets NEMA WD-6, ANSI C-73

MATERIAL CHARACTERISTICS

Environmental: Flammability UL-94, V2 Rating

Operating Temperature: Max continuous +60˚C; Min -40˚C

MECHANICAL

Terminal Identification: T568A and T568B wiring patterns

Wiring: Fully compliant with published TIA-568-C0A requirements

ELECTRICAL

• Current Interrupting: Meets FCC Part 68 - UL 1863

• Temperature Rise: Max 30 Deg C. at full-rated current after 50 cycles

DESIGNER TELEPHONE AND COAX DEVICES

Designer Telephone Jack

Designer Coax Cable Jack

Designer Telephone / Coax Jack

White

Ivory

CH149-00W

CH149-00I

Light Almond CH149-00T

Black CH149-00E

White CH181-00W

Ivory CH181-00I

Light Almond CH181-00T

Black CH181-00E

White CH159-00W

Ivory CH159-00I

Light Almond CH159-00T

Black CH159-00E

CH149-00W

CH181-00W

+ =

Cat. No. SJ26C

Requires a Designer Wallplate (Cat. No. SJ26C)

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

CH159-00W

699

Time-Saving Systems

Residential and Commercial Grade

DATACOM BOX INSTALLATIONS

Datacom Nail-on Box

Cat. No. 3005C-CØØ

(Includes two nails and two self-tapping screws)

Low Voltage Cut-In Bracket Assembled

Cat. No. 4007C-CØØ

Low Voltage / High Voltage Divider

Cat. No. 4003C (Standard Box)

Cat. No. 4004C (Big A Box)

5020C-C0W

Cat 5e

41084

KEYSTONE MOUNT DEVICES

U S

3 Port Datacom Keystone Mount White 5020C-C0W

Ivory 5020C-C0I

Light Almond 5020C-CAL

Black 5020C-C0B

KEYSTONE JACKS - SNAP-IN CONNECTORS

U

Cat 3 - RJ11 Telephone

Cat 5e Snap-In Jack

4-Pair - 8 wire conductor Category 5e

T568A and T568B wiring patterns

Nickel Plated, Feedthrough

White

Light Almond

41108-RW3

41108-RT3

Ivory 41108-RI3

White 5G108-RW5

Light Almond

Ivory

5G108-RT5

5G108-RI5

Light Almond 41084-FTF

Ivory 41084-FIF

MATERIAL CHARACTERISTICS

Environmental: Flammability UL-94, V2 Rating

Operating Temperature: Max continuous

+60˚C; Min -40˚C

MECHANICAL

Terminal Identification: T568A and T568B wiring patterns

700

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

Cheetah Electrical Boxes

Cheetah Speed Boxes (1 - 4 gang boxes) are made from high strength thermoplastic composites with specially designed speed anchor slots. Each slot has teeth molded to receive Cheetah Speed Anchors. As the speed anchor is pushed into the speed anchor slot, the teeth on the box and speed anchor engage in a zip-tie fashion to securely hold the anchor.

Specifications and Features

• Fast installation stud guides

• Multi-gang support arm included

• Easy entry, locking wire ports

• No punch-out required to wire boxes

• Standard and Oversized boxes

• Speed Anchor Slots

• Multi-gang reinforced nail sleeves

Cheetah Speed Boxes

Standard and “Big-A” Sizes

Reinforced Nail/Screw Sleeves

Patented Speed

Anchor System

“No Punch”

Easy Wire

Entry Ports

Multi-gang support arm

Low Voltage divider guides

High Strength

Thermoplastic

2-HR Fire Rated — ASTM E-814 (UL 1479) & ASTM E119-3

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Use on Wood or

Metal Studs

701

Time-Saving Systems

Residential and Commercial Grade

WOOD STUD BOX INSTALLATIONS

S

Description

1-Gang Box

18 cu Inches

Cat. No.

3001C

1-Gang Big-A Box

22.2 cu inches

1-Gang Datacom Box

18 cu inches

2-Gang Big-A box

Dryer/Range Port

40 cu inches

3-Gang Box

44 cu inches

3004C

3005C-C00

1-Gang Adjustable Big-A 3023C

22 cu inches

2-Gang Box

34 cu inches

3006C

3007C

3008C

3009C 3-Gang Big-A box

58 cu inches

4-Gang Box

60 cu inches

4-Gang Big-A box

76 cu inches

3010C

3011C

Wire Capacity

#14 - 9, #12 - 8, #10 - 7

#14 - 11, #12 - 10, #10 - 9

Low Voltage Wire

#14 - 11, #12 - 10, #10 - 9

#14 - 17, #12 - 15, #10 - 13, #6 - 6

#14 - 20, #12 - 18, #10 - 16, #6 - 6

#14 - 22, #12 - 19, #10 - 17, #6 - 8

#14 - 30, #12 - 28, #10 - 24, #6 - 12

#14 - 30, #12 - 28, #10 - 24, #6 - 14

#14 - 40, #12 - 36, #10 - 32, #6 - 16

Dimensions

2.25” W x 3.75” H x 2.75” D

2.25” W x 3.75” H x 3.5” D

2.25” W x 3.75” H x 3.5” D

2.25” W x 3.75” H x 3.5” D

4.0” W x 3.75” H x 2.95” D

4.0” W x 3.75” H x 3.5” D

5.75” W x 3.75” H x 2.75” D

5.75” W x 3.75” H x 3.5” D

7.65” W x 3.75” H x 2.75” D

7.65” W x 3.75” H x 3.5” D

702

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

METAL STUD INSTALLATIONS

S

Description

1-Gang Metal Stud Box

18 cu inches

1-Gang Big A Metal Stud Box w/Self-drilling Metal Screws

22 cu. inches

1-Gang Box Extender

Cat. No.

3002C

Wire Capacity

#14 - 9, #12 - 8, #10 - 7

3029C

3021C

#14 - 11, #12 - 10, #10 - 9

Dimensions

2.25” W x 3.75” H x 4.15” D

2.25” W X 3.75” H X 3.5” D

2.5” W x 4.25” H x 1.25” D

2-Gang Big-A box w/ Self Drilling Metal Screws

40 cu inches

3-Gang Big-A box w/ Self Drilling Metal Screws

58 cu inches

4-Gang Big-A box w/ Self Drilling Metal Screws

76 cu inches

1-Gang Big-A Adjustable w/ Metal Screws

22 cu inches

1-Gang ½” Mud Ring

Fits 4”x4” Square box

1-Gang 5 /

8

” Mud Ring

Fits 4”x4” Square box

2-Gang ½” Mud Ring

Fits 4”x4” Square box

2-Gang 5 /

8

” Mud Ring

Fits 4”x4” Square box

3026C

3027C

3028C

3025C

3015C

3016C

3017C

3018C

#14 - 20, #12 - 18, #10 - 16, #6 - 6 4.0” W x 3.75” H x 3.5” D

#14 - 30, #12 - 28, #10 - 24, #6 - 12 5.75” W x 3.75” H x 3.5” D

#14 - 40, #12 - 36, #10 - 32, #6 - 16 7.65” W x 3.75” H x 3.5” D

#14 - 11, #12 - 10, #10 - 9 2.25” W x 3.75” H x 3.5” D

Cheetah Metal Stud boxes come with metal self-drilling screws for side wall installations and greater stability.

Cheetah Mud Rings convert

4” square boxes into Cheetah speed Boxes.

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

703

Time-Saving Systems

Residential and Commercial Grade

CUT-IN BOX INSTALLATIONS

Description

1-Gang Shallow Cut-In Box

14 cu inch

Cat. No.

3000C

3003C 1-Gang Cut-In Box

18 cu inches

2-Gang Cut-In Box

34 cu inches

Low Voltage /

Datacom Cut-In Bracket

3022C

4007C-C0W

Wire Capacity

#14 - 6 , #12 - 5, #10 - 4

#14 - 9, #12 - 8, #10 - 7

#14 - 17, #12 - 15, #10 - 13, #6 - 6

Dimensions

2.5” W x 4.2” H x 2.5” D

2.5” W x 4.2” H x 3.35” D

4.2” W x 4.2” H x 3.35” D

Low Voltage Cut-In Bracket is designed to “zip-tie” to sheet rock and then brake tabs off flush with wall.

CEILING INSTALLATIONS

3” Ceiling Box 3012C

Ceiling Speed Anchor - 52 MM

100 lbs pull test rated

Lampholder —

Keyless

Lampholder —

Pull Chain

4001C

4008C

4009C

Cheetah Cut-In Boxes are 2-Hour Fire Rated.

Screws self-tighten pop-up flange to back of sheet rock.

704

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Cheetah Speed Systems

Residential and Commercial Grade

DATACOM SOLUTIONS

UL Standard 514C Nail-on Box, Mixed Voltage Dividers (multi-gang installations), Low Voltage Cut-In Bracket

Description

1 - Gang Datacom Box

18 cu inches

Cat. No.

3005C

Wire Capacity

Low Voltage wire

Dimensions

2.25” W X 3.75” H X 3.5” D

Mixed Voltage Divider -

Standard Box

Fits 2, 3 and 4 Standard gang boxes

Low Voltage / Datacom

Cut-In Bracket

Fits directly to wall without stud

4003C

4007C

CHEETAH ACCESSORIES

Spark Rings, Speed Anchor Inserts, Blank Wallplate Adapter, Universal Adapter Ring

1 Gang Spark Ring

Protective sleeve

3019C

Speed Anchor - 30 MM

50 lb pull test rated

Blank Wallplate Adapter

Speed Anchor Attached/

Included

Universal Adaptor

Adapts most standard devices to receive

Cheetah screwless wallplates

Device Shims (Spacers)

Shims to hold device flush to walls when drywall is cut too wide.

4000C

4005C

4006C

4010C

1 Gang Universal Spark Ring (Cat. No. 3019C) supports multi-gang installations.

Spark Rings are used for extending a protective sleeve for devices where backsplash or wall to box exceeds

1

/

4

”.

See local NEC requirements for further clarification of use.

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

705

Time-Saving Systems

Residential and Commercial Grade

WEATHERPROOF COVERS - “CHEETAH ENABLED” SOLUTIONS

UL Standard 514C Covers w/ UL 498 Standard Duplex or GFCI Receptacles (per assembled)

Clear Bubble Cover w/ 15 Amp Duplex TR/WR

Clear Bubble Cover w/ 15 Amp GFCI TR/WR

Low Profile Cover w/ 15 Amp Duplex TR/WR

Low Profile Cover w/ 15 Amp GFCI TR/WR

15A Duplex

15A GFCI

15A Duplex

15A GFCI

86592-CCL

86594-CGY

86595-CGY

86596-CGY

WEATHERPROOF COVERS

UL Standard 514C Covers w/ UL 498 Standard Duplex or GFCI Receptacles (per assembled)

Horizontal Weatherproof Cover w/ 15 Amp Duplex TR/WR-GRAY

Vertical Weatherproof Cover w/ 15 Amp Duplex TR/WR-GRAY

Vertical Weatherproof Cover w/ 15 Amp GFCI TR/WR-GRAY

15A

15A

15A

All devices will be Tamper and Weather Resistant and comply with the 2008 NEC Tamper and Weather Resistent Requirements.

86597-CGY

86598-CGY

86599-CGY

86594 - CGY 86596-CGY

86597-CGY

86598-CGY

706

For technical support call 800-824-3005 Online catalog available at leviton.com

This document provided by Barr-Thorp Electric Co., Inc. 800-473-9123 www.barr-thorp.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
